300 Series Top Control 24-in Built-In Dishwasher (Stainless Steel) ENERGY STAR, 48-dBA 825225963134
24" Scoop Handle Dishwasher 300 Series Stainless Steel SHS843AF5N SHS843AF5N Stainless Steel The 3rd rack provides the perfect space for silverware and large utensils while its V shape leaves room below for taller items. Features & Benefits 48 dBA: dishwasher runs quietly so your kitchen conversations aren't interrupted. With PrecisionWashTM, intelligent sensors and precision spray arms target every item of every load, so dishes come out sparkling clean every time. Fingerprint Resistant providing the ultimate exterior protection against fingerprints, dirt, and smudges. The AquaStop® leak protection system contains leaks through a precisely engineered system. If a leak occurs, the system contains it by shutting down operation and pumping out water. So you have the ultimate peace of mind whether you are away or at home. General Properties Number of wash cycles 5 Number of options 4 dBA 48 Drying system PureDry Third rack Standard 3rd Rack Rack adjustability Rackmatic® Tub material Stainless Steel Control type Buttons Concealed water Yes heating element Leak protection system 24/7 AquaStop® Water softener No Five-level wash Yes ChildLock No Special features InfoLight®, Extra Dry Option, AntiFingerprint Finish Efficiency Water usage per cycle 3.5 Energy efficiency class Tier 1 ENERGY STAR® qualified Yes Total annual energy 269 consumption (kWh) Total annual water consumption (g) 623.5 Capacity Number of place settings 16 Technical Details Watts (W) 1440 W Current (A) 12 Amps Volts (V) 120 V Frequency (Hz) 60 Hz Power cord length 67" - Install length from corner of unit 45" Minimum water pressure 14 (lb/sin) Length outlet hose (in) 79" Dimensions & Weight Overall appliance dimensions (HxWxD) (in) 33 7/8" x 23 9/16" x 23 3/4" Required cutout size (HxWxD) (in) 33 7/8" x 23 5/8" x 24" Adjustable feet Yes Net weight (lbs) 91 lbs Accessories--Optional Junction Box SMZPCJB1UC Bosch Dishwasher Water SMZSH002UC Supply Hose Drain Hose Extension Kit SGZ1010UC Dishwasher Accessory SMZ5000 Kit Anti-Tarnish Silverware SMZ5002UC Cassette Edge Protector SMZEP001UC Accessories: To purchase Bosch accessories, cleaners & parts please visit www.bosch-home.com/us/store or call 1-800-944-2904 (Mon to Fri 5 am to 6 pm PST, Sat 6 am to 3 pm PST). Notes: All height, width and depth dimensions are shown in inches. BSH reserves the absolute and unrestricted right to change product materials and specifications, at any time, without notice. Consult the product's installation instructions for final dimensional data and other details prior to making cutout. Warranties: Please see Use & Care manual or Bosch website for statement of limited warranty. For more information on our entire line of products, go to www.bosch-home.com/us or call 1-800-944-2904 © BSH Home Appliances Corporation. All rights reserved. Bosch is a registered trademark of Robert Bosch GmbH. 10/19 24" Scoop Handle Dishwasher 300 Series Stainless Steel SHS843AF5N Installation Details Image 2: 2013 New Dish NBN_Revised 2019 MCG Included: Pre-connected drain hose Toe-kick Power cord (3-prong plug) a: New Dish EU, ADA and 18 inch - Rev 2019 MCG Front view Drain hose Electrical Power Cord: length shown according to Installation Instructions Inlet Drain Electrical All connections are at the rear of the appliance. Image 3b: New DishExEteUn,sAioDn Aforadnrdai1n8hoinsceha_vRaielavb_le20a1s9a_cMceCssGory. Junction Box for hard wired connection available as an accessory. measurements in inches (mm) Ø 2 1/2" (63.5 mm) 7" (178 mm) Note: Cutout required on left or right cabinet wall, depending on location of water inlet, drain and electrical connection 2 1/2" (63.5 mm) Junction box accessory available for purchase SMZPCJB1UC (not included) Example of Hardwire Installation Ø 2 1/2" (63.5 mm) 7" (178 mm) Note: Cutout required on left or right cabinet wall, depending on location of water inlet, drain and electrical connection 2 1/2" (63.5 mm) 3-prong power cord included Example of an Electrical Receptacle Installation Accessories: To purchase Bosch accessories, cleaners & parts please visit www.bosch-home.com/us/store or call 1-800-944-2904 (Mon to Fri 5 am to 6 pm PST, Sat 6 am to 3 pm PST). Notes: All height, width and depth dimensions are shown in inches. BSH reserves the absolute and unrestricted right to change product materials and specifications, at any time, without notice. Consult the product's installation instructions for final dimensional data and other details prior to making cutout. Warranties: Please see Use & Care manual or Bosch website for statement of limited warranty. For more information on our entire line of products, go to www.bosch-home.com/us or call 1-800-944-2904 © BSH Home Appliances Corporation. All rights reserved. Bosch is a registered trademark of Robert Bosch GmbH. 10/19 24" Scoop Handle Dishwasher 300 Series Stainless Steel SHS843AF5N Installation Details Image 5: New Dish 2019 with min 33" (84 cm) Non-metallic tie Non-metallic tie Remove plug Note: Plumbing installations will vary - refer to local codes. Drain hose included is 79" (201 cm) and can be extended to a maximum of 155 3/4" (396 cm). Always use the approved drain hose extension kit (SGZ1010UC). Ensure a portion of the drain hose is raised between min. 33" (84 cm) and max. 43" (110 cm) above the cabinet floor. min 33" (84 cm) max 43" (110 cm) min 33" (84 cm) max 43" (110 cm) Accessories: To purchase Bosch accessories, cleaners & parts please visit www.bosch-home.com/us/store or call 1-800-944-2904 (Mon to Fri 5 am to 6 pm PST, Sat 6 am to 3 pm PST). Notes: All height, width and depth dimensions are shown in inches. BSH reserves the absolute and unrestricted right to change product materials and specifications, at any time, without notice. Consult the product's installation instructions for final dimensional data and other details prior to making cutout. Warranties: Please see Use & Care manual or Bosch website for statement of limited warranty. For more information on our entire line of products, go to www.bosch-home.com/us or call 1-800-944-2904 © BSH Home Appliances Corporation. All rights reserved. Bosch is a registered trademark of Robert Bosch GmbH. 10/19Adobe InDesign 14.0 (Macintosh) Adobe PDF Library 15.0
