This user manual contains important information on the safe operation of the device. Read and follow all safety notes and all instructions.
In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. Letterings. Displays.
FRFR-112A Guitar DSP guitar combo user manual Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 06.05.2020, ID: 478594 Table of contents Table of contents 1 General information................................................................................................................................. 4 1.1 Further information........................................................................................................................... 5 1.2 Notational conventions.................................................................................................................... 6 1.3 Symbols and signal words............................................................................................................... 6 2 Safety instructions..................................................................................................................................... 8 3 Features....................................................................................................................................................... 12 4 Starting up.................................................................................................................................................. 13 5 Connections and controls................................................................................................................... 15 6 DSP functions............................................................................................................................................ 18 7 Technical specifications....................................................................................................................... 23 8 Plug and connection assignment.................................................................................................... 25 9 Cleaning....................................................................................................................................................... 28 10 Protecting the environment.............................................................................................................. 29 FRFR-112A Guitar DSP 3 General information 1 General information This user manual contains important information on the safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device to another user, be sure that they also receive this manual. Our products and user manuals are subject to a process of continuous development. We there- fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. guitar combo 4 General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Keyword search Use the search function in the electronic version to find the topics of interest for you quickly. Online guides Our online guides provide detailed information on technical basics and terms. Personal consultation For personal consultation please contact our technical hotline. Service If you have any problems with the device the customer service will gladly assist you. FRFR-112A Guitar DSP 5 General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: `24ch' , `OFF' . 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. guitar combo 6 Signal word DANGER! CAUTION! NOTICE! Warning signs General information Meaning This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. This combination of symbol and signal word indicates a pos- sible dangerous situation that can result in minor injury if it is not avoided. This combination of symbol and signal word indicates a pos- sible dangerous situation that can result in material and environmental damage if it is not avoided. Type of danger Warning high-voltage. Warning danger zone. FRFR-112A Guitar DSP 7 Safety instructions 2 Safety instructions Intended use This device is intended to be used for amplification and playback of signals from musical instruments with electromagnetic pickups. Any other use or use under other operating condi- tions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use. This device may be used only by persons with sufficient physical, sensorial, and intellectual abilities and having corresponding knowledge and experience. Other persons may use this device only if they are supervised or instructed by a person who is responsible for their safety. DANGER! Danger for children Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and choke! Never let children unattended use electrical devices. guitar combo 8 Safety instructions DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Do not use the device if covers, protectors or optical components are missing or damaged. DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro- tective contact plug. Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a regis- tered electrician. FRFR-112A Guitar DSP 9 Safety instructions 10 CAUTION! Possible hearing damage The device can produce volume levels that may cause temporary or permanent hearing impairment. Over an extended period of time, even levels that seem to be uncritical can cause hearing damage. Decrease the volume level immediately if you experience ringing in your ears or hearing impairment. If this is not possible, keep a greater distance or use suffi- cient ear protectors. NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. guitar combo Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user. Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric shock or fire. NOTICE! Possible damage due to installation of a wrong fuse The use of different types of fuses can cause serious damage to the unit. Fire hazard! Only fuses of the same type may be used. FRFR-112A Guitar DSP 11 Features 3 Features The device is characterized by the following features: n Full range flat-response speaker box for a modern digital guitar setup (amp modelling and multi-effects processor) n 4 DSP sound programmes n various DSP equalizer modes, each with ±12 dB level control per band n 1200 watt power amp, class D n 12-inch woofer and 1-inch tweeter n suitable for use as floor monitor or on a tripod n 2 × XLR / 1/4" phone jack combo socket for adjustable MIC / Line input n 1 × 3.5 mm phone jack socket as AUX input for connecting line devices n 1 × XLR output n suitable dust cover optional (item no. 410589) guitar combo 12 Starting up 4 Starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards. NOTICE! Possible property damage by magnetic fields Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate distance to devices that can be adversely affected or damaged by an external magnetic field. FRFR-112A Guitar DSP 13 Starting up NOTICE! Use of stands When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does not exceed the maximum permissible load capacity of the stand. The unit can be mounted on a tripod or set up on the floor or a sufficiently sized and stable surface. guitar combo 14 5 Connections and controls Connections and controls FRFR-112A Guitar DSP 15 Connections and controls Front panel 1 [DSP] backlit display for DSP functions 2 [MASTER / PUSH FOR DSP] Rotary control for the overall volume, push button for activating the DSP functions 3 [INPUT 1 LINE] Rotary gain control for input 1. Turning clockwise increases the input gain for connecting microphones. Turning counterclockwise decreases the input gain for connecting instruments or devices with line level outputs. 4 [INPUT 2 LINE] Rotary gain control for input 2. Turning clockwise increases the input gain for connecting microphones. Turning counterclockwise decreases the input gain for connecting instruments or devices with line level outputs. 5 Mic / Line input, designed as XLR / 1/4" phone jack combo socket, balanced 6 Mic / Line input, designed as XLR / 1/4" phone jack combo socket, balanced guitar combo 16 Connections and controls Front panel 7 [OUTPUT] Line output, designed as XLR chassis plug. The combined signal of both inputs is present here, unaffected by DSP. 8 [AUX IN] 3.5 mm phone socket for connecting line level devices such as MP3 or CD players. Stereo signals are combined. Rear panel 9 IEC chassis plug with fuse holder for the power supply 10 [ON OFF Auto Stand-by] Turns the automatic shutdown function on and off. When pressed, the function is deactivated, when not pressed, it is activated. The device will turn off after approx. 60 minutes without input signal. When the input signal recurs, the device returns automatically. 11 This LED lights up when the automatic shutdown function is active. 12 [POWER ON / OFF] Mains switch. Turns the device on and off. FRFR-112A Guitar DSP 17 DSP functions 6 DSP functions Function selection 1. Press [MASTER | PUSH FOR DSP] to call up the main menu. 2. Turn [MASTER | PUSH FOR DSP] to switch between menu items or values. 3. Press [MASTER | PUSH FOR DSP] to activate the menu shown in the display or to confirm a value. 4. To exit a menu item without changes, select `EXIT' and press [MASTER | PUSH FOR DSP] to confirm. Setting the sound programme 1. Press [MASTER | PUSH FOR DSP] to call up the main menu. 2. Turn [MASTER | PUSH FOR DSP] until the display shows `MODE' and press [MASTER | PUSH FOR DSP] to confirm. 3. Turn [MASTER | PUSH FOR DSP] until the display shows `Sim1' , `Sim2' , `Sim3' or `OFF' and press [MASTER | PUSH FOR DSP] to confirm. ð The selected sound program is set. guitar combo 18 DSP functions EQ setting 1. Press [MASTER | PUSH FOR DSP] to call up the main menu. 2. Turn [MASTER | PUSH FOR DSP] until the display shows `EQ SET' and press [MASTER | PUSH FOR DSP] to confirm. 3. Turn [MASTER | PUSH FOR DSP] until the display shows `EQ TYPE' and press [MASTER | PUSH FOR DSP] to confirm. 4. Turn [MASTER | PUSH FOR DSP] until the display shows `PA' , `GUITAR1' or `GUITAR2' and press [MASTER | PUSH FOR DSP] to confirm. ð The selected EQ setting is set. Setting the level of a frequency band 1. Press [MASTER | PUSH FOR DSP] to call up the main menu. 2. Turn [MASTER | PUSH FOR DSP] until the display shows `EQ SET' and press [MASTER | PUSH FOR DSP] to confirm. 3. Turn [MASTER | PUSH FOR DSP] until the display shows `EQ LOW' (bass control), `EQ MID' (mids control) or `EQ HIGH' (treble control) and press [MASTER | PUSH FOR DSP] to con- firm. FRFR-112A Guitar DSP 19 DSP functions Setting the LED mode Dimming the display 20 4. Turn [MASTER | PUSH FOR DSP] to raise or lower the level of the selected frequency band and press [MASTER | PUSH FOR DSP] to confirm. 1. Press [MASTER | PUSH FOR DSP] to call up the main menu. 2. Turn [MASTER | PUSH FOR DSP] until the display shows `LED MODE' and press [MASTER | PUSH FOR DSP] to confirm. 3. Turn [MASTER | PUSH FOR DSP] until the display shows `OFF' (LED not active), `ON' (LED active) or `LIMITER' (LED flashes when limiter is activated) and press [MASTER | PUSH FOR DSP] to confirm. 1. Press [MASTER | PUSH FOR DSP] to call up the main menu. 2. Turn [MASTER | PUSH FOR DSP] until the display shows `LCD DIM' and press [MASTER | PUSH FOR DSP] to confirm. 3. Turn [MASTER | PUSH FOR DSP] until the display shows `OFF' or `ON' and press [MASTER | PUSH FOR DSP] to confirm. guitar combo DSP functions Setting the display brightness 1. Press [MASTER | PUSH FOR DSP] to call up the main menu. 2. Turn [MASTER | PUSH FOR DSP] until the display shows `BRIGHT' and press [MASTER | PUSH FOR DSP] to confirm. 3. Turn [MASTER | PUSH FOR DSP] to set a value between `1' (low) and `10' (high) and press [MASTER | PUSH FOR DSP] to confirm. Setting the display contrast 1. Press [MASTER | PUSH FOR DSP] to call up the main menu. 2. Turn [MASTER | PUSH FOR DSP] until the display shows `CONTRAST' and press [MASTER | PUSH FOR DSP] to confirm. 3. Turn [MASTER | PUSH FOR DSP] to set a value between `1' (low) and `10' (high) and press [MASTER | PUSH FOR DSP] to confirm. FRFR-112A Guitar DSP 21 DSP functions Reset System information 22 1. Press [MASTER | PUSH FOR DSP] to call up the main menu. 2. Turn [MASTER | PUSH FOR DSP] until the display shows `RESET' and press [MASTER | PUSH FOR DSP] to confirm. 3. Turn [MASTER | PUSH FOR DSP] until the display shows `Confirm Reset: YES' and press [MASTER | PUSH FOR DSP] to confirm. ð The device is reset to factory default settings. 4. To keep the existing settings, choose `Confirm Reset: NO' and press [MASTER | PUSH FOR DSP] to confirm. 1. Press [MASTER | PUSH FOR DSP] to call up the main menu. 2. Turn [MASTER | PUSH FOR DSP] until the display shows `INFO' and press [MASTER | PUSH FOR DSP] to confirm. ð The current firmware version of the DSP function is displayed. guitar combo Technical specifications 7 Technical specifications Speaker Amp class Input connections Output connections Output power Frequency range Sound pressure level (SPL), max. Power consumption 12-inch woofer 1" tweeter Class-D power amp Mic / Line Line level player Voltage supply Line level mix from both inputs RMS: 300 W Peak: 1200 W 48 Hz ... 19 kHz, 3 dB 134 dB 461 W 2 × XLR / jack combo socket, balanced 1 × 3.5 mm jack socket IEC chassis plug C14 1 × XLR, 3-pin FRFR-112A Guitar DSP 23 Technical specifications Operating supply voltage Fuse Dimensions (W × H × D) Weight Ambient conditions Further information Dust cover optional 230 V 50 Hz 5 mm × 20 mm, 3 A, 250 V, slow-blow 348 mm × 607 mm × 355 mm 14.6 kg Temperature range 0 °C...40 °C Relative humidity 50 %, non-condensing Yes (item no. 410589) guitar combo 24 Plug and connection assignment 8 Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip- ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in `Sound & Light' caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or `just' in poor transmission quality! Balanced and unbalanced trans- mission Unbalanced transmission is mainly used in semi-professional environment and in hifi use. Instrument cables with two conductors (one core plus shielding) are typical representatives of the unbalanced transmission. One conductor is ground and shielding while the signal is trans- mitted through the core. Unbalanced transmission is susceptible to electromagnetic interference, especially at low levels, such as microphone signals and when using long cables. In a professional environment, therefore, the balanced transmission is preferred, because this enables an undisturbed transmission of signals over long distances. In addition to the conduc- tors `Ground' and `Signal', in a balanced transmission a second core is added. This also transfers the signal, but phase-shifted by 180°. FRFR-112A Guitar DSP 25 Plug and connection assignment 1/4" TS phone plug (mono, unbalanced) Since the interference affects both cores equally, by subtracting the phase-shifted signals, the interfering signal is completely neutralized. The result is a pure signal without any noise inter- ference. 1 Signal 2 Ground, shielding 1/4" TRS phone plug (mono, bal- anced) 1 2 3 Signal (in phase, +) Signal (out of phase, ) Ground guitar combo 26 XLR plug (balanced) XLR plug (unbalanced) Plug and connection assignment 1 Ground, shielding 2 Signal (in phase, +) 3 Signal (out of phase, ) 4 Shielding on plug housing (option) 1 Ground, shielding 2 Signal 3 Bridged to pin 1 FRFR-112A Guitar DSP 27 Cleaning 9 Cleaning Device components Clean the device components that are accessible from the outside regularly. The cleaning fre- quency depends on the operating environment: damp, smoky or particularly dirty environ- ments can cause greater accumulation of dirt on the device components. n Clean with a dry soft cloth. n Stubborn dirt can be removed with a slightly dampened cloth. n Never use solvents or alcohol for cleaning. guitar combo 28 Protecting the environment 10 Protecting the environment Disposal of the packaging mate- rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. Please follow the notes and markings on the packaging. Disposal of your old device This product is subject to the European Waste Electrical and Electronic Equipment Directive (WEEE) in its currently valid version. Do not dispose with your normal household waste. Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. FRFR-112A Guitar DSP 29 Notes guitar combo 30 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.deAH XSL Formatter V6.5 MR3 for Windows (x64) : 6.5.6.31956 (2018/02/02 12:52JST) Antenna House PDF Output Library 6.5.1216 (Windows (x64))
