ZEISS Hunting Catalogue 2020/2021 zeiss.com ZEISS EYE-TO-EYE WITH THE WORLD OF NATURE Hunting means looking nature right in the eyes. Taking in its rougher sides and defying them. Finding the right way, even in the dark, where others see nothing at all. Waiting for the 2 decisive moment to arrive, despite the cold, heat or rain. Nature can be 3 grasped in its entirety only by those who are aware of all its facets. Those of us who strive to achieve total awareness need a strong partner who can take the sometimes harsh conditions in their stride. A partner who delivers superior performance paired with highest quality and can be relied upon in every situation. A partner like ZEISS. ZEISS R E A L- L I F E H U N T I N G O P T I C S LABORATORY TESTED PROVEN OUTDOOR PERFORMERS Simulation of extreme situations: extreme temperature variations within minutes and shot simulations at 1,500 times the force of gravity. For more than a century, ZEISS has been manufacturing premium optical products that stand out due to their optical excellence, technical innovations and out standing ergonomics. Nevertheless, it is not only the pursuit of perfection that makes ZEISS optics what they are. Hunting optics are not scientific instruments; they are tools that must deliver the best results in the toughest conditions, at all times. A jacket with a tear or leaking boots are annoying, but a defective rifle or optical device can ruin what promised to be a good day's hunting. This is why our watchword is absolute reliability even in the most adverse conditions. Supreme confidence, whatever the weather Thanks to the best materials and uncompromising manufacturing quality, we can guarantee a level of reliability and ruggedness that is appreciated by hunters around the world. Again and again, hunters and their equipment must face and overcome harsh climatic conditions and difficult terrain. If a torrential downpour begins when you are waiting for game to appear, there's usually only one piece of advice to follow: sit it out! Hoping that your optics are waterproof should be the least of your problems. Exposure to vigorous salt spray when hunting in coastal regions is just as impossible to avoid as extreme temperature variations when leaving the warmth of your vehicle and stepping out into the cold winter air. Environmental factors are, however, only one part of the equation. A fall in rugged terrain with a shouldered rifle, the rifle falling to the floor of a high seat or a bumpy ride in the back ZEISS ZEISS Hunting Catalogue 2020/2021 4 5 Take no chances: ZEISS quality is proven not only in the laboratory, but also on tough hunting trips. of a vehicle on rough tracks are all situations in which the resilience of your optics is put to the test. Your ZEISS optics are ready to face it all This is why all ZEISS optics are extensively tested in the company's own laboratory to ensure their endurance and suitability for everyday use. Proven testing procedures push the optics to the absolute limit. ZEISS conducts special testing procedures for this. Whether transport simulation, continuous impacts, shot simulations with 1,500 times the force of gravity, 24-hour corrosion testing in vigorous salt spray or checking waterproofness by immersion all these tests simulate stresses that are many times higher than those encountered in normal hunting situations. These stringent testing procedures guarantee trouble-free performance in the often-harsh conditions of everyday hunting and enable you to act with supreme confidence in your equipment at the decisive moment and that for years and decades to come. No holds barred: View our video and see how Anette Dahl and Marius Elpers put the robustness and resilience of their ZEISS optics to the test in a wide range of different hunting situations: www.youtube.com/user/ zeisssportsoptics ZEISS BINOCULARS FROM ZEISS 3 6 THE THERMAL IMAGING CAMERA FROM ZEISS 1 6 RIFLESCOPES FROM ZEISS 2 0 Real Life Hunting Optics............................ 4 Tailored Carl Zeiss AG the company..................... 8 to your needs ZEISS always offers the Hunting App........................................... 10 ideal product to fulfil the most stringent personal Augmented Reality.................................. 14 expectations and the different challenges of Reticles from ZEISS..................................34 every type of hunting. Uncompromising in design, ZEISS Hunting Community.......................58 ergonomics and optical systems, and simultaneously robust and easy to use riflescopes, binoculars, THERMAL IMAGING CAMERA................16 spotting scopes and the thermal imaging camera DTI 3/35..................................................18 from ZEISS. ZEISS RIFLESCOPES................................20 Victory V8...............................................26 Victory HT...............................................29 Conquest V6...........................................30 Conquest V4...........................................32 BINOCULARS...............................36 Victory SF................................................40 Victory Rangefinder System.....................44 Victory HT...............................................46 Victory Pocket......................................... 50 Conquest HD...........................................52 Terra ED..................................................54 ZEISS Hunting Catalogue 2020/2021 SPOTTING SCOPES FROM ZEISS 6 0 THE HUNTING APP FROM ZEISS 10 THE RANGEFINDER SYSTEM FROM ZEISS 44 SPOTTING SCOPES..................60 Victory Harpia.........................................64 Conquest Gavia.......................................68 SPECIALS.........................................56 Night Vision............................................56 Monos....................................................57 20×60....................................................57 Dialyt.......................................................70 TECHNICAL SPECIFICATIONS........................72 Riflescopes............................................. 72 Thermal imaging camera.........................76 Binoculars.........................................78/86 Spotting scopes...................................... 82 ACCESSORIES..............................83 Accessories for riflescopes.......................83 Accessories for spotting scopes................85 Accessories for binoculars........................85 ZEISS HUNTING COMMUNITY 58 6 7 ZEISS A B O U T C A R L Z E I S S AG DID YOU KNOW THAT... SEMICONDUCTOR MANUFACTURING TECHNOLOGY (SMT) ... a large proportion of all microchips produced around the globe is manufactured with technologies from ZEISS? ZEISS supplies equipment for semiconductor manufacturing to the Dutch company ASML, the world's largest producer of wafer steppers and wafer scanners extremely complex machines for manufacturing microchips. Contact between the two companies was established around 30 years ago: ... ZEISS makes driving safer? (DriveSafe) Developed together with research institutes, ZEISS DriveSafe spectacle lenses are optimised to meet the visual needs of drivers. The special lens coating reduces glare by attenuating the proportion of short wavelength light. In addition to this, ZEISS DriveSafe lenses offer optimised fields of vision for dynamic vision and, in return, a more relaxed view for wearers of varifocal spectacles. Former Formula One racing driver Christian Danner also relies on this technology. ... numerous Oscar-winning films were shot with ZEISS lenses? Cinematography lenses from ZEISS helped to create the unmistakeable, atmospheric mood of numerous Oscar-winning films like The Lord of the Rings, King Kong and Perfume: The Story of a Murderer the jury of the Academy of Motion Picture Arts and Sciences awarded three technical Oscars to these cinematographic innovations. In 2012 two engineers from ZEISS were presented with the prestigious Scientific and Engineering Award for the mechanical and optical design of the ZEISS Master Prime cinematography lenses jointly developed by ZEISS and the camera manufacturer ARRI. In 1999 the company received the award for the concept and optical design of zoom lenses with the optical performance of prime lenses (Variable Prime) and, in 1987, for the design and development of extremely fast lenses (Super Speeds). ZEISS ZEISS Hunting Catalogue 2020/2021 ... that the dwarf planet Pluto was discovered magnification, but also with reticle illumination. The with optical technology from ZEISS? On 18 February 1930, Clyde Tombaugh, a research assistant at the Lowell Observatory in Arizona (United riflescopes featured a light tube on the side that could be 8 fitted with an illuminating device. This accessory was supplied only at the special request of customers. A fine adjustment 9 States) discovered Planet X, today better known as control regulated the brightness of the illumination to allow it Pluto. His discovery was made with the aid of a so-called to be adapted to the visibility of the game. blink comparator from ZEISS, as the German planetologist Ulrich Köhler from Schwäbisch Gmünd found out, ... ZEISS revolutionised riflescope mounting? 85 years after the discovery of Pluto. A blink comparator The introduction of the ZEISS inner rail in 1990 meant that has an eyepiece similar to that of a microscope and is gunsmiths no longer needed to perform the laborious used to flick quickly, or `blink', between two photographs tasks of cementing and drilling the individual components of particular segments of the night sky taken at different to attach them to the riflescope. Since the patent expired times to identify changes. in 2008, the ZEISS inner rail is now offered by almost all prominent European manufacturers. SPORTS OPTICS ... ZEISS was the first to bring binoculars with ZEISS TODAY AND TOMORROW mechanical image stabilisation to the market? ... ZEISS constantly sets new standards? With the 20×60 S, ZEISS became the world's first Characterised by a spirit of innovation and progress, manufacturer to launch a pair of binoculars with mechanical the 170-year history of the company is reflected in every image stabilisation that allowed shake-free handheld viewing idea, every product and in every service offered by ZEISS. with 20× magnification. Because, just as the world of nature constantly changes and never stands still, ZEISS works with untiring scientific ... ZEISS constructed the first riflescopes with reticle curiosity and unconditional passion always questioning illumination as long ago as 1921? the status quo and setting new standards with technical The Zieldovier and Zieldosechs models were the first innovations. two riflescopes that ZEISS offered not only with variable ZEISS T H E Z E I S S H U N T I N G A P P THE APP FOR TODAY'S HUNTERS The ZEISS Hunting App prepare. Document. Share. The ZEISS Hunting App the ZEISS Hunting App is available to hunters as a mobile app or a web app for the desktop. In addition to a multitude of useful features for the preparation and documentation of hunting trips, it now also offers an option for managing hunting grounds together with other hunters. This makes organisation and communication in the hunting grounds even easier. The app also allows hunters to share diary entries, ballistic profiles and equipment data with friends. Dashboard Personally configured start screen with direct navigation to your features. Ballistics Ballistic calculations matched to your riflescope and ballistic reticle/BDC (ASV), including ammunition database with over 7,000 entries. Hunting diary Documentation of all hunting experiences with relevant data such as information about game and shots, photos, videos and more. ZEISS Hunting grounds Set up and manage your hunting grounds from the app or your browser. Simply mark important points on the map and display your current position as a useful aid to orientation in the field. NEW: Manage your hunting grounds together with fellow hunters and communicate with them on the hunting grounds bulletin board. Weather information Personalised weather forecast with information relating to the current location and preferred hunting grounds. My products Create a clear and detailed overview of your hunting equipment with instant access to important product information from a single source. ZEISS Hunting Catalogue 2020/2021 10 11 Connected products Connection and configuration of the ZEISS Victory Rangefinder and the ZEISS DTI 3/35 thermal imaging camera via Bluetooth. Synchronisation of personal ballistic profiles from the app with the rangefinder, live streaming via the app with the DTI 3/35. News NEW: Clearly laid out overview of all shared posts in newsfeed, together with exclusive offers and the latest products from ZEISS. THE ZEISS HUNTING APP available for free. Downloadable from the App Store or Google Play. Download the browser version from: hunting.zeiss.com More information about the app can be found at: zeiss.com/hunting/app Sharing NEW: Use the app to share ballistics data, entries from your hunting diary and details about your equipment with friends. ZEISS T H E Z E I S S H U N T I N G A P P YOU CAN NOW MANAGE YOUR HUNTING GROUNDS WITH YOUR FRIENDS AND SHARE ENTRIES! New! ZEISS ZEISS Hunting Catalogue 2020/2021 SHARING HUNTING GROUNDS Conveniently share your hunting grounds 12 with other hunters. You define permissions for sharing the hunting grounds map, managing 13 the hunting grounds and documenting events for everyone involved. On the hunting ground bulletin board, you can communicate things to be done and post important messages for your fellow hunters. IN-APP SHARING Keep your friends up-to-date and share entries from your ballistics data, your hunting diary and details about your equipment. All posts shared by you and your friends appear in a clearly laid out overview in the new newsfeed. Mark the posts you like and leave comments. Diary entries Ballistics My equipment ZEISS The rangefinder is just one of the numerous products you can discover and explore with the app. AUGMENTED REALITY SEE FURTHER: Z EISS AR SPORTS OPTICS APP Technical innovation is as deeply rooted in the DNA of ZEISS as the commitment to uncompromising quality, in even the smallest of details. Our new app links these two topics and raises the ZEISS optics product experience to an entirely new level. Thanks to the innovative ZEISS AR Sports Optics App, you can now take a look around inside our extremely complex optics products from your mobile device. Features like the distance-measuring system of the Victory Rangefinder System or adjustment of the illuminated dot in the Victory V8 are now not only made visible, but also easy to grasp. Numerous pages of this catalogue including the following page serve as `markers' for the app. All you need to do is hold your device above the marker pages to discover perfectly detailed 3D models of our products. You can take a walk around each of the products, get up-close to them or take direct control of the animation. Discover what makes ZEISS a legendary name while you're there: the undying passion for precision and quality even down to the tiniest screw. ZEISS ZEISS Hunting Catalogue 2020/2021 Use this picture as a placeholder for our AR App. 14 Note: always keep a part of the picture in the field of view of the camera 15 1.Download and install the ZEISS AR Sports Optics App. 2.Activate the App and hold your device above a catalogue page that contains a ZEISS AR logo. 3.Select a product and activate the animation by touch. 4.Move your tablet or smartphone to discover new angles and perspectives. ZEISS HANDLE THE NIGHT THANKS TO INTUITIVE ERGONOMICS 16 17 ZEISS ZEISS Hunting Catalogue 2020/2021 Hunting at night demands out standing powers of vision. Powers of vision that identify what really matters, even in darkness. Night hunting can only be successful when one can count on these powers at the decisive moment. The right equipment is essential for ethical night hunting for wild boar. After all, in darkness, it is almost impossible to rely solely on your unaided powers of vision. But, for a hunter, the night is the most important time for driven boar-hunting. What is needed is a companion that enables clear target identification in the hours of darkness. A companion with the highest optical that can be relied on in the night. A companion in accustomed ZEISS quality. This is the reason that ZEISS has developed a thermal imaging camera, designed by fellow hunters, for hunters. ZEISS PRODUCT PORTRAIT THE FIRST THERMAL IMAGING CAMERA IN THE HISTORY OF ZEISS: ZEISS DTI 3/35 The ZEISS DTI 3/35 a technical innovation that unites night-vision optics in accustomed ZEISS quality with unique ergonomic design. With the ZEISS DTI 3/35, ZEISS brings a thermal imaging camera developed especially for hunting to the market. Even in darkness, its outstanding optical systems deliver richly detailed images that enable clear identification of game. The indispensable, perfect ergonomics transform hunting at night into a unique experience: the outstanding handling of the ZEISS DTI 3/35 is due to the intelligent layout of the control buttons that enables intuitive operation of the thermal imaging camera in darkness with each individual finger, even when wearing gloves. This combination of unique features clearly illustrates the commitment of ZEISS to continuous development and intelligent innovation. ZEISS ZEISS Hunting Catalogue 2020/2021 Live-streaming via the ZEISS Hunting App The ZEISS Hunting App allows the transfer of data from the thermal imaging camera to a smartphone and enables livestream documentation of hunting experiences in real-time. New! Perfect ergonomics Thanks to the ErgoControl operating concept and its intelligent placement of the buttons, each function can be controlled intuitively, and the perfectly shaped control elements can be identified quickly even when wearing gloves. 18 19 Outstanding optics in accustomed ZEISS quality The high-resolution HD-LCOS display delivers richly detailed images even in complete darkness. Precise zoom function for confident target identification In steps of 0.5×, the fine incremental settings of the zoom always ensure a perfect combination of magnification and detail resolution. ZEISS ZEISS R I F L E S CO P E S F R O M Z E I S S D E D I C AT E D TO A PERFECT VIEW OF YOUR GAME The experiences made by every individual when specific needs of every hunting situation. Despite their hunting are as varied as their demands on their differences, all these models have one thing in common riflescope. The awareness of this enables ZEISS exceptional quality, made by ZEISS. This also justifies the design engineers to develop the perfect riflescopes claim that no matter what challenges you encounter when to meet each hunter's individual needs. hunting, ZEISS always has the ideal optics to master them. Thanks to a selection of reliable premium products that Riflescopes must take the needs of different hunting types address and fulfil individual needs and expectations, you and personal needs with regard to weight, magnification, always have the best companion at your side: your ZEISS field of view, handling and the brightness and clarity of riflescope. the viewing image into account. Our online product guide will lead you step by step to the 20 ZEISS has found the ideal answer to this. This comprises a perfect riflescope for your needs: range of models that offers a broad spectrum of product zeiss.com/hunting/productfinder 21 features and performance profiles that caters for the SEE PERFECTION IN MORE DIMENSIONS D O W N LOA D T H E Z EI S S A R SP O R T S O P T I C S A P P. G A I N D E TA I L ED I N SI G H T S I N TO T H E Q UA L I T Y, CONSTRUCTION AND FUNCTIONALITY OF THE RIFLESCOPES FROM ZEISS. ZEISS Maximum precision The finest and brightest illuminated dot Revolutionary brightness and image contrast High-transmission glasses Extreme versatility Highest magnification ranges ZEISS Z E I S S V I C TO R Y R I F L E S CO P E S FOR A UNIQUE HUNTING EXPERIENCE Hunting leaves little room for compromises. This is why dedicated hunters around the world place their complete trust in ZEISS Victory riflescopes the measure of all things. It is the sum of sophisticated features and the perfect interplay between these features that makes riflescopes from ZEISS indispensable hunting companions: Scanning the hunting terrain delivers an image with razor-sharp details and brilliant colours. This is made possible only by the unique interplay of SCHOTT HT glasses with transmission values of up to 95 per cent, FL fluoride glass lens elements for the highest imaging quality and extremely broad fields of view. The handling ergonomics of the riflescopes is also uncompromisingly good. The finest illuminated dot guarantees minimal target subtension. It can be steplessly dimmed for maximum precision and can be adjusted easily with either hand, even with cold fingers. The short, compact construction ensures best weapon handling. Their extreme long-range capabilities are naturally also among the outstanding characteristics of the riflescopes. Thanks to the intuitive and easy-touse BDC (ASV) LongRange, the ZEISS Victory V8 stands at the pinnacle of modern riflescope technology. FAC T S: HT glass from SCHOTT: Simply `brighter'. The utilisation of high- transmission (HT) glass ensures a visible increase in light transmission. Glassless reticle: 22 It lies in the second image plane and guarantees a 23 constant, fine illuminated dot throughout the entire magnification range. This results in minimum target coverage and noticeably higher aiming accuracy at long distances. LotuTec® coating: The dust, dirt and water- repellent coating guarantees a permanently clear view. Excellent ergonomics: Functional control e lements, intelligent illuminated dot c ontrol and robust engineering provide clear proof that the development of ZEISS riflescopes are founded on real-life hunting experiences. ZEISS R I F L E S CO P E S F R O M Z E I S S FOCUSING ON THE ESSENTIALS: A COMPARATIVE OVERVIEW OF ALL ZEISS RIFLESCOPES Light transmission Optical quality ZEISS Victory HT BDC (ASV) Illuminated dot control 9 Ballistic rings availa- ble as standard Direct read-out of shot distances Retrofittable BDC (ASV) Multifunction button A Stepless illuminated dot brightness control Finest illuminated dot for minimum target coverage Automatic deactivation Reticle Reticle 60 Mounting Ring and inner rail ZEISS Victory V8 ZEISS Conquest V6 9Ballistic rings availa- ble as standard Direct read-out of shot distances Retrofittable BDC (ASV) Optimised multifunction button, left- or right-handed use A Stepless illuminated dot brightness control Finest illuminated dot for minimum target coverage Automatic deactivation with attitude sensor Reticle 43 Reticle 54 Reticle 60 Ring and inner rail Turret design enables multiple rotations for precise shots at extreme distances Retrofittable BDC (ASV) Multifunction button A Stepless illuminated dot brightness control Finest illuminated dot for minimum target coverage Automatic deactivation with attitude sensor Reticle 6 (Z-Plex) Reticle 43 (non-illuminated) Reticle 60 ZMOA-1 ZMOA-2 ZBR-1 ZBR-2 Ring and inner rail ZEISS Conquest V4 Turret design enables multiple rotations for precise shots at extreme distances Multifunction button Ten-step dot brightness control BDC (ASV) not retrofittable Reticle 20 (Z-Plex) Reticle 60 ZMOAi-1 ZMOA-1 ZMOA-2 ZBR-1 Ring ZBR-2 ZBi ZMOAi-20 ZMOAi-T20 ZMOAi-T30 Ultra-HT concept High Transmission SCHOTT glasses for optimum identification and resolution of targets in low light. LotuTec® For fast and easy cleaning of exposed lens surfaces. ZEISS UFL Concept Optical system containing several SCHOTT fluoride glasses for absolute colour fidelity, brightness, clarity and the finest resolution of details. T* Multi-layer coating for a bright, crystal-clear and high-contrast viewing image Fluoride glass SCHOTT fluoride glass for a bright viewing image and optimum target resolution. ZEISS Hunting Catalogue 2020/2021 Main use Driven hunt Stalking High seat/night Medium range/ alpine hunting Long range HT 2.510×50 HT 312×56 V8 1.18×30 24 V8 1.814×50 25 V8 2.820×56 V8 4.835×60 V6 1.16×24 V6 212×50 V6 2.515×56 V6 318×50 V6 530×50 V4 14×24 V4 312×56 V4 416×44 V4 624×50 #6: non-illuminated #43: non-illuminated #43: illuminated #54: illuminated ZMOAi-1: illuminated ZBR-1: non-illuminated ZBR-2: non-illuminated ZBi: illuminated #60: illuminated ZMOAi-20: illuminated ZMOA-1: non-illuminated ZMOA-2: non-illuminated #20 (Z-Plex): non-illuminated ZMOAi-T20: illuminated ZMOAi-T30: illuminated ZEISS P R O D U C T P O R T R A I T THE MOST VERSATILE RIFLESCOPE: ZEISS VICTORY V8 Hunting has many facets. Driven hunts, stalking or shooting from high seats have different needs and seasonal requirements. The weather and the terrain also influence the difficulty of hunting conditions. These special needs demand an uncompromising riflescope. The ZEISS Victory V8 is optimised for all hunting situations, and is therefore the global reference standard. It is very impressive with numerous innovations and sets an entirely new standard in the premium class. No other riflescope has ever been so flexible and versatile. The main reasons for this are its maximum zoom and reticle adjustment ranges. Hunters can also look forward to new standards in terms of ergonomics. For instance, the world's finest and brightest illuminated dot can be precisely adjusted and easily set, while the short and compact construction ensures the best weaponhandling characteristics. The crowning glory of the Victory V8 is ASV LongRange, which, thanks to its large adjustment range, enables precise shots at maximum distances. Regardless of the hunting situation, the Victory V8 always guarantees absolute precision and perfection. OPTICAL EXPERTISE Ultra-fine illuminated dot for minimal target coverage and accurately placed shots in line with the principles of ethical hunting. ZEISS HT, V8 and V6 riflescopes contain the finest illuminated dot available on the market today. This allows for minimum target coverage and thus a secure, expert shot. 2× 7.3cm 8× 1.8cm 14× 1.0cm on 100m 3.5cm 0.9cm 0.5cm ZEISS The illustration shows the size of our competitors' illuminated reticles (left) compared to the ZEISS reticles (right) Example: ZEISS illuminated dot (HT, V8, V6) ZEISS Hunting Catalogue 2020/2021 True long-range shooting capability With an adjustment range of up to 100 clicks, the BDC (ASV) LongRange (ASV LR/ASV Competition) enables accurate aiming at distances of up to 600 metres. Long distances are no longer an obstacle. Cutting-edge technologies In combination with the multifunction button for control of the illuminated dot, an intelligent motion sensor system automatically activates the illuminated dot as soon as the rifle is raised to take aim. This enables hunters to concentrate on the essentials. Precise images Perfect aim at all distances, thanks to parallax compensation 26 as a standard feature. 27 Performance-oriented design The 36-millimetre centre tube diameter offers more room for optical excellence and a greater reticle adjustment range to maximise the chances of hunting success in every situation. Short reaction time Generously-sized eyebox and broad field of view for dynamic target acquisition: this is ensured by large exit pupils and maximum fields of view at low magnification factors. Lig ht transmiss ion *An explanation of the labels for classification of the optical quality on the respective products can be found on page 24. ZEISS V8 1.18×30 The up to 8-fold magnification range fulfils the needs of real-life hunting practice in driven hunts and when stalking. With the lowest magnification factor, hunters can keep both eyes open to maximise the field of view when shooting on the fly ideal for fast and dynamic stalking and driven hunting. Enables continued clear identification of game and precise placement of shots at medium ranges. A distinct advantage over simple red dot sighting. Lig ion V8 1.814×50 From driven hunts and stalking to stand hunting. The large zoom range with parallax compensation and relaxed viewing characteristics make this riflescope an ideal companion in every situation. ht transmiss ion ht transmiss Lig Lig HT 2.510×50 The all-rounder for all hunting applications: whether you are shooting on the move or stand hunting, the optional BDC+ (ASV+) makes this riflescope ideal for every hunting situation. The optical concept of the ZEISS Victory HT reveals its true strengths especially in the twilight hours. HT 312×56 The specialist for stand hunting at night. The SCHOTT HT glass of the brightest riflescope from ZEISS ensures maximum night hunting capability. In combination with the optional BDC+ (ASV+), the Victory HT also guarantees hunting success at long ranges. 28 ion ion ht transmiss ht transmiss 29 ACCESSORIES OPTICAL EXPERTISE Lig V8 2.820×56 The 20× magnification and bullet drop compensation as a standard feature make this model an ideal choice for long-range shots. In addition, the 92% transmission offers outstanding reserves for shooting into the last hours of daylight. V8 4.835×60 The benchmark model of the Victory V8 line. The 35× magnification combined with the BDC (ASV Competition) stands for ultimate long-range shooting capability. The o ptical system of the Victory V8 impresses with consistently excellent sharpness and the highest resolution of details from minimum to maximum magnification. ion ion Lig ht transmiss ZEISS ht transmiss ZEISS Hunting Catalogue 2020/2021 Bullet drop compensator BDC (ASV) Direct read-out of shot distances makes the BDC (ASV) the world's most precise long-range shooting concept. This accessory enables accurate aiming at distances of up to 600 metres. Comfortable viewing characteristics The eyebox is the zone in which the eye can see the entire field of view. Due to its large size in all ZEISS riflescopes, this is especially comfortable. This offers hunters greater freedom when positioning their eye, enabling faster target acquisition a crucial advantage on driven hunts. ZEISS riflescope viewing characteristics ZEISS Lig Lig P R O D U C T P O R T R A I T THE HIGH-PERFORMANCE RIFLESCOPE WITH A 6× ZOOM RANGE: ZEISS CONQUEST V6 Fast and precise The optional bullet drop compensation enables accurate aiming at maximum hunting distances. The large exit pupil enables rapid aiming. Advanced technology Automatic activation and deactivation of dot illumination by intelligent motion sensor technology extends battery life and, in turn, the length of time the illuminated dot is available for use. ion Advanced technology Automatic activation and deactivation of dot illumination by intelligent motion sensor technology extends battery life and, in turn, the length of time the illuminated dot is available for use. ht transmiss ZEISS Bright and sharp FL glass and high light transmission ensure image brightness with optimum target resolution the prerequisites for a perfectly placed shot. V6 2.515×56 With the highest light-gathering power, the Conquest V6 is an excellent choice for stand hunting and, thanks to the optional BDC (ASV), is also ideal for long-range shots. The minimum coverage of the target by the illuminated reticle ensures a perfect aim. ZEISS Hunting Catalogue 2020/2021 Lig Lig ion V6 1.16×24 Its wide field of view is ideal for keeping everything in sight on driven hunts. A maximum magnification factor of 6.5× guarantees the flexibility required when hunting and intuitive handling ensures quick responses. Enables continued clear identification of game and precise placement of shots at medium ranges. A distinct advantage over simple red dot sighting. ht transmiss Lig V6 212×50 This compact and versatile riflescope is a reliable companion in every hunting ground. The extremely fine illuminated dot and high magnification range of the Conquest V6 212×50 bring high performance well into the twilight hours. 30 ht transmiss ion 31 V6 318×50 The lightweight and lean design of this versatile riflescope makes it ideal for medium to long-range shooting. It is also reliable and simple to use. A ballistic turret is available as an optional accessory. Reticle 6 and ballistic reticles ZBR-2 and ZMOA-2. V6 530×50 The Conquest V6 530×50 offers a high magnification factor for long-range shots. In addition to this, it also features a wide zoom range that guarantees maximum flexibility. A further advantage is its lightweight construction and lean design. Ballistic reticles ZBR-1/ ZMOA-1, and additional Reticle 43 are available. ion ion Lig ht transmiss ht transmiss ZEISS P R O D U C T P O R T R A I T HIGH-QUALITY OPTICS FOR EVEN THE HARSHEST HUNTING CONDITIONS: ZEISS CONQUEST V4 Ballistic reticle The ballistic reticle enables fast elevation and crosswind corrections. Ballistic turret The large bullet drop compensation range of the ballistic turret provides the flexibility hunters need for a wide range of hunting needs. vaeNvraesiwiloanbsle! Lig V4 14×24 Proven to be exactly the right riflescope for hunting at short range and in situations when fast target acquisition is essential. At higher magnification factors, clear identification of game and precise placement of shots is still possible at medium ranges. A distinct advantage over simple red dot sighting. V4 416×44 The balance between its wide field of view and magnification range make this compact riflescope ideal for all types of hunting. 32 ht transmiss ion Lig ht transmiss ion 33 ht transmiss ZEISS ion Functional mechanical systems Absolute reliability: the mechanical systems stand the test in all situations where hunters need to react on the spur of the moment. ZEISS Hunting Catalogue 2020/2021 Lig V4 624×50 Offering 24× magnification and parallax compensation, this riflescope is the specialist for precision shooting. V4 312×56 This riflescope is suitable for stand hunting and for long-range shots. The large objective lens diameter and illuminated reticle guarantee aiming accuracy, even in unfavourable light. ion ion Lig ht transmiss ht transmiss ZEISS Lig R E T I C L E S F R O M Z E I S S FOR DECISIONS WITH MAXIMUM PRECISION Reticles for ZEISS riflescopes ZEISS works constantly on the development of reticles, consistently sets new standards and impresses with incomparably high levels of precision. Illuminated reticles Depending on the brightness of the illuminated dot or cross, there are two fundamentally different types of illuminated reticle in the ZEISS riflescope range. Non-illuminated standard reticle Non-illuminated reticles are versatile and precise. They are ideal for use when hunting in very good light, in the early hours of dusk and the later hours of dawn. A further advantage is that non-illuminated reticles can be used for measuring distances: the fine scales on the horizontal and vertical crosshairs between the reticle posts enable the determination of useful information about the distance to the game. Non-illuminated reticles also bring distinct advantages for competitive marksmen, This is because certain reticles have extremely fine crosshairs that obscure very little of the target or game at long ranges. In the case of versions with a very bright illuminated dot, these are illuminated reticles suitable for use in daylight and twilight. These are found, for instance, in the Victory HT models and in the Conquest V6 and V4, and are particularly effective for rapid target acquisition when hunting fast moving game The second group of illuminated reticles from ZEISS is intended for use in the twilight hours. The Victory HT models and the Victory V8 feature finely-dimmable illuminated dots. These enable ideal adjustment to the widely varying lighting conditions encountered in the early hours of twilight. If the illuminated dot or cross were too bright, flare would obscure the target in deep twilight. These illuminated reticles therefore provide an option for optimum adjustment of the brightness either manually or automatically with the help of the riflescope. ACCESSORIES Bullet drop compensator (BDC/ASV) BDC/ASV for Victory V8 and Conquest V6, new orders or retrofittable. ZEISS Throw lever for Victory V8, Conquest V6 and V4 For fast magnification changes when speed is a critical factor. ZEISS Hunting Catalogue 2020/2021 RETICLES FROM ZEISS Illuminated reticle 43 For Victory V8 Reticle 43 Non-illuminated for Conquest V6 Illuminated reticle 54 For Victory V8 Illuminated reticle 60 For Victory V8, HT and Conquest V6 Illuminated reticle 60 For Conquest V4 Illuminated reticle ZMOAi-1 For Conquest V4 ZMOA-1 For Conquest V6, Conquest V4 ZMOA-2 For Conquest V6 ZBR-1 For Conquest V6 ZBR-2 For Conquest V6 Reticle 6 For Conquest V6 Reticle 20 (Z-Plex) 34 For Conquest V4 35 Illuminated reticle ZBi For Conquest V4 Illuminated reticle ZMOAi-20 For Conquest V4 Illuminated reticle ZMOAi-T20 (thin line) For Conquest V4 Illuminated reticle ZMOAi-T30 (thin line) For Conquest V4 ZEISS ZEISS B I N O C U L A R S F R O M Z E I S S VIEWED OVER TIME: THE BEST The optical performance, outstanding ergonomics, This legendary quality delivers the right optical products rugged construction and the ongoing innovations with for all hunting needs. From special binoculars for stand which the limits of the technically possible have been hunting at night to perfect all-round glasses for everyday continuously expanded make binoculars from ZEISS situations. But however much the various binoculars true legends that are handed on from generation to may differ in their specialisation and performance they generation. all have one thing in common: the trust of numerous generations of hunters in the ZEISS brand. In many cases, it is not only the passion for hunting that is passed on to the next generation of young hunters, but Our online product guide will lead you step by step to the also dependable hunting companions in the form of ZEISS perfect binoculars for your needs: binoculars. This is made possible by the robust construction zeiss.com/hunting/productfinder 36 that makes the glasses reliable partners for decades to come. This is what ZEISS quality means. 37 YOU CAN NOW TAKE A CLOSER LOOK AT THEIR QUALITIES WHAT MAKES OUR BINOCULARS UNIQUE, AND HOW ARE THEY CONSTRUCTED? THE ZEISS AR SPORTS OPTICS APP PROVIDES THE ANSWERS. ZEISS Z E I S S V I C TO R Y B I N O C U L A R S PERFECT PROPERTIES FOR FAR-SIGHTED DECISIONS Do you discover and recognise new perspectives where others see only limits and give up? Do you demand only the best from yourself, and accept nothing less? Do you enjoy having the freedom to make confident decisions? If all this applies to you, you simply can't ignore ZEISS Victory binoculars for your hunting needs. Anyone who has ever held a ZEISS model in their hands will never want to hand it back. For almost countless good reasons. Even the tiniest details are thought through to perfection. Innovative optical and mechanical systems interact with ergonomics with the ultimate perfection of a winning team to deliver the viewing image you need at the decisive moment. Sharp, precise, clear, uncompromising. Even in the most unfavourable conditions. At the same time, ZEISS binoculars are amazingly robust. With a ZEISS in your hands, you have everything in view and remain in perfect control of the situation, however unexpected or unusual it may be. Whether in the darkest hours of twilight or at the most extreme ranges. Whether lying in wait for the stag of your life or hunting game in mountainous terrain. Any ZEISS binoculars will soon become an invaluable companion. Regardless of whether you choose an all-rounder like the Victory SF, a specialist like the Victory HT or the particularly compact Victory Pocket. They all offer you the chance to collect unique insights and personal experiences that will become treasured memories. ZEISS FAC T S: Triple-link bridge: Constructional stability and robustness that stands up to even the harshest conditions. UFL Concept: Ensures natural colour fidelity, high contrast and finest detail rendition. Magnesium materials: The combination of extremely lightweight and high strength materials guarantees quality that lasts for generations. LotuTec® coating: The dust, dirt and water- repellent coating guarantees a permanently clear view. ErgoBalance concept: Perfectly balanced weight distribution guarantees fatigue-free observation. ZEISS FieldFlattener technology: Extreme edge sharpness, even with wide fields of view. Smart Focus concept: Optimum location of the focusing wheel ensures intuitive, fast and precise focusing. Unique carrying comfort Very lightweight, excellent grip characteristics Top of the class Extremely wide-angle fields of view 38 39 Precise and intuitive handling Rapid focusing Best image quality Bright, high-contrast image, natural colour fidelity ZEISS Rapid focusing The SmartFocus Concept ensures perfect positioning of the focusing wheel. Without having to splay the finger on the wheel, the viewing image can be brought quickly and precisely into pin-sharp focus with a maximum of only 1.6 or 1.8 turns (SF 32 and SF 42). Extremely broad field of view The incomparably broad field of view of both SF models provides a perfect overview in difficult terrain and their close focus distances of 1.95 metres (SF 32) and 1.5 metres (SF 42) allow the exploration of even the smallest details. PRODUCT PORTRAIT THE MOST VERSATILE BINOCULARS IN THE HISTORY OF ZEISS: ZEISS VICTORY SF Experience the most exciting moments of hunting as never before with the Victory SF models from ZEISS. ErgoBalance Concept The ZEISS Victory SF 32 and 42 models are the most versatile premium binoculars in the 170-year history of ZEISS. Their optical perfection, unrivalled field of view, revolutionary ergonomics and extremely lightweight construction make the Victory SF models the perfect all-rounders. They express everything ZEISS stands for: the creation of unrivalled optical products. heavy light Thanks to the ErgoBalance concept, the binoculars are ideally balanced in the hands and enable prolonged and steady observation with minimum fatigue by reducing stresses on the muscles of the upper and lower arms. ZEISS ZEISS Hunting Catalogue 2020/2021 40 41 mi t ut UFL UFL witho An exceptional viewing experience Natural, true-to-life colour rendition, a bright viewing image and finest resolution of details. The UFL concept delivers them all. The use of SCHOTT HT glass guarantees light transmission values of 90 per cent (SF 32) and 92 per cent (SF 42). Perfect ergonomics Thanks to the ErgoBalance Concept, the centre of gravity of the SF models is shifted closer to the eyepieces, which allows hour after hour of fatigue-free observation. ZEISS petitors ion ion Lig Lig than w PRODUCT PORTRAIT FOR A FIRST-CLASS OVERVIEW: ZEISS VICTORY SF 32 Superlative vision The UFL Concept delivers optimum resolution and natural colour rendition, and enables clear identification of even the finest details. New! 20% more observable ith terrain comparable com Extremely broad field of view The expanded field of view increases the observable area of interest by up to 20 per cent in comparison with market competitors. This provides a better overview of the terrain when hunting and enables considerably faster identification of well camouflaged game. Compact design With a weight of 600 grams, the Victory SF 8×32 is significantly lighter than other comparable binoculars. In combination with the ErgoBalance Concept, this particular property enables the to date longest and most comfortable viewing experience when hunting. ZEISS ht transmiss ZEISS Hunting Catalogue 2020/2021 PRODUCT PORTRAIT AN EXCEPTIONAL VIEWING EXPERIENCE: ZEISS VICTORY SF 42 Ultimate ergonomics and handling The perfect ergonomics and ruggedness provided by its TripleLink Bridge and lightweight construction with modern magnesium alloys are the basis for effortless observation and a previously unseen viewing experience. Fantastic handling The Smart Focus concept and the optimum location of the focusing wheel guarantee a pin-sharp viewing image in seconds. 42 43 Maximum FOV The extreme wide-angle field of view enables much faster identification of game than ever before. Superior vision The UFL Concept delivers outstanding colour fidelity, brightness and detail resolution. ht transmiss ZEISS Binocular real-time ballistics system The various measuring functions of the rangefinder take a multitude of relevant data into account and use them to calculate the precise setting for the BDC (ASV) in all environmental conditions. All the relevant factors The ability to save up to nine personalised ballistic profiles set up in the ZEISS Hunting App guarantees perfect adaptation to the hunter's needs. PRODUCT PORTRAIT TURNING SENSE INTO CERTAINTY: ZEISS VICTORY RANGEFINDER SYSTEM Experienced hunters can always rely on their senses. Nevertheless, with the right equipment, they can go further than this and transform intuitions into certainties. The Rangefinder System is a laser rangefinder with an integrated real-time ballistics computer. The consideration of all relevant factors and customisation with the aid of the ZEISS Hunting App ensures precisely placed shots at any distance. The RF family offers a choice of four models: the RF 8×42 and 10×42 for daylight hunting and the RF 8×54 and 10×54 for hunting into the twilight hours. ZEISS THE ZEISS HUNTING APP Completely new properties The capabilities of the rangefinder system are perfected by the ability to synchronise it with the ZEISS Hunting App via Bluetooth. The App enables you to transfer your personal ballistic data to the rangefinder, share it with your friends and manage your hunting grounds together with fellow hunters. News Dashboard Ballistics Hunting diary Weather information Connected Products My products Hunting grounds Sharing ZEISS Hunting Catalogue 2020/2021 Ultimate performance at the cutting edge of technology At ZEISS, we are never satisfied with the status quo. The software of the RF is being constantly revised and updated to further improve its performance. Bluetooth connectivity and our ZEISS Hunting App enable you to keep your rangefinder at the cutting edge of software developments. 44 45 All you need at a glance The rangefinder determines the precise target distance up to a m aximum range of 2,300 metres. ZEISS Tradition revisited The elegant design is the continuation of the design concept of the ZEISS Dialyt timeless and functional. Form follows intuition The large focusing wheel of the Comfort Focus concept ensures superior handling ergonomics, even when wearing gloves. P R O D U C T P O R T R A I T MADE FOR THE TWILIGHT HOURS: ZEISS VICTORY HT 54 The day's hunting doesn't end as soon as the sun goes down. With the right equipment, it can easily continue into the hours of twilight. ZEISS developed the Victory HT models for precisely this situation. INNOVATIONS FROM ZEISS Victory HT premium binoculars let you experience an entirely new dimension of hunting. Thanks to a revolutionary optical concept, they bring spectacular transmission values of 95 per cent and more. An exceptional value that is achieved by the perfect combination of SCHOTT HT glasses, ZEISS T* multi-layer coating and an Abbe-König prism system and ensures maximum brightness. This means that you are able to observe your surroundings when hunting for much longer even in the latest hours of twilight. Equally innovative: the ergonomics. The new ComfortFocus Concept impresses with a large focusing wheel that is embedded in the double-link bridge. This makes it extremely robust, ensures easy handling and also guarantees a long service life. Experience the absolute pinnacle of leading-edge optics with the brightest ever binoculars from ZEISS. LotuTec® a clear view, whatever the weather There are always exciting things to be seen in the world of nature even in wet weather. This is why ZEISS developed LotuTec®. A coating for the lenses of binoculars and spotting scopes that enables a clear and unhindered view in all weather conditions. ZEISS ZEISS Hunting Catalogue 2020/2021 Lig ion Built to last a lifetime The use of magnesium alloys combining light weight with high rigidity guarantees a long and reliable service life. ht transmiss 46 47 A brighter outlook The ZEISS Victory HT is not simply bright: the integration of FL lenses increases its resolving power and brings outstanding brilliance to the viewing image. This ensures an ideal viewing experience in all lighting conditions. ZEISS RF 8/10×42 The compact rangefinder model. The binocular real-time ballistics system can be synchronised with the Hunting App via Bluetooth. RF 8/10×54 All the qualities of the rangefinder system in combination with powerful optics. The model for users who look for the best when it comes to optical performance. ZEISS FL BINOCULARS FOR FINEST DETAIL RESOLUTION New! SF 8/10×32 The SF 32 models offer brilliant, true-to-life colour rendition, an expanded field of view and an ergonomic design concept for prolonged, fatigue-free observation. ht transmiss ACCESSORIES SF 8/10×42 With a value of 148 metres at 1,000 metres, the field of view of these binoculars is absolutely outstanding. Thanks to the Smart Focus concept, the outstanding optical performance is also complemented by perfect ergonomics. ht transmiss 48 49 ion ion ion Lig Lig Lig HT 8/10×54 The models with the 54-millimetre objective lens are among the most powerful night-hunting binoculars from ZEISS. With a light transmission of 95 per cent, these binoculars guarantee maximum performance in the hours of dusk and dawn. At the same time, the 8×54 impresses with outstanding ergonomics and a large exit pupil. Without FL glass With FL glass Fluoride glass and the UFL Concept SCHOTT fluoride glass ensures a bright viewing image and optimum target resolution. In the UFL Concept , several elements made of SCHOTT fluoride glass are combined in a system that delivers absolute colour fidelity, brightness, high contrast and the finest resolution of details. ht transmiss ZEISS ZEISS Hunting Catalogue 2020/2021 Air Cell Comfort carrying strap The carrying strap enables binoculars with lens diameters greater than 30 millimetres to be carried much more comfortably. Embedded air cells make the strap very comfortable to wear, while quick-release fasteners make it easy to attach and remove. The strap length can be adjusted to meet the user's needs. Comfort carrying harness Made from premium materials, the harness prevents neck strain and distributes the weight of the binoculars over the upper body. When moving around, the binoculars remain steady and any uncontrolled swinging is prevented. The harness offers outstanding carrying comfort and enables binoculars to be quickly and easily fixed when not in use. ZEISS Lig Lig B I N O C U L A R S F R O M Z E I S S THE COMPACT COMPANION: ZEISS VICTORY POCKET Brilliant Broad field of view and FL glass for a particularly sharp and richly detailed viewing image. Modern The design, the mechanical system and the robustness of these binoculars fulfil the highest expectations. ht transmiss ZEISS ion ion Light Lightweight qualities and asymmetric folding make this model particularly handy to carry anywhere. ZEISS Hunting Catalogue 2020/2021 Pocket 8/10×25 Proven high-performance binoculars for virtually all observation situations. The compact size and light weight allow them to be conveniently carried in smaller jacket pockets when not in use. ht transmiss 50 51 ZEISS P R O D U C T P O R T R A I T PERFECT ALL-ROUNDERS: ZEISS CONQUEST HD Nature in HD The highest resolution of details and natural colour rendition of the HD lens system lets you experience new standards of optical excellence. Perfect balance Compact dimensions, low weight and modern design come together to create exemplary ergonomics and result in an intuitive and simple handling concept. Light in the darkness High transmission values are an essential prerequisite for impressive observation in the twilight hours. ZEISS Lig ion ht transmiss ZEISS Hunting Catalogue 2020/2021 Lig Lig ion HD 8/10×32 Thanks to the extra-wide field of view of the HD lens systems, compact dimensions, low weight and carrying comfort, the Conquest HD 8/10×32 is the ideal, high-performance companion for every situation. ht transmiss Lig HD 8/10×42 Exceptional quality and performance Made in G ermany. Ideal for users who are looking for sharpness, high resolution of details, natural colour rendition and outstanding quality in the close focusing range. ion ht transmiss 52 53 ion HD 8/10/15×56 This version is the specialist for situations in unfavourable light and impresses with a bright, high-contrast viewing image. The 15×56 is supplied complete with a tripod adapter. ht transmiss ZEISS P R O D U C T P O R T R A I T PERFECT FOR EVERY TRIP: ZEISS TERRA ED Ergonomic Focusing with a Terra ED is made particularly quick and easy by the smooth action and comfortable grip characteristics of its large, perfectly positioned focusing wheel. Lig ED Pocket 8/10×25 In its class, the extremely light and compact Terra ED Pocket delivers an outstanding viewing experience and impresses with intuitive handling. ED 8/10×32 Impressive images, precise focusing and compact size are the characteristic features of the 32-millimetre version of the Terra ED. ion ion Lig ht transmiss ht transmiss ZEISS IN PRACTICE 54 55 ion Compact, light and robust The fibreglass-reinforced waterproof casing of the Terra ED takes even the toughest outdoor situations in its stride. ht transmiss ZEISS Proven excellence The use of SCHOTT ED glass and hydrophobic multi-layer coating of exposed lens surfaces fulfils the highest optical demands. ZEISS Hunting Catalogue 2020/2021 Lig ion ED 8/10×42 A bright image, outstanding resolution of details and comfortable viewing characteristics. In combination with optimum ease of handling, these perfectly describe the outstanding properties of the Terra ED 42. ht transmiss Care and cleaning tips from ZEISS LotuTec® is a resilient and abrasion-resistant lens coating with a special surface and strong lotus effect that reduces the adhesion of water droplets and dirt on lenses. The use of a ZEISS lens cleaning cloth is recommended for cleaning lens surfaces. Coarse dirt on lenses for example, sand, mud or soil must not be wiped off: it should only be removed by rinsing with clear water or with a clean lens brush with soft, fine bristles. ZEISS Lig PRODUCT PORTRAIT OPTIMUM VISIBILITY, EVEN BY THE LIGHT OF A NEW MOON: ZEISS VICTORY NV Superior image intensifier tube The intensifier tube with a light amplification factor of around 20,000 contains a microchannel plate (MCP) for the generation of sharp, finely detailed images in the hours of darkness. ZEISS Mono ZEISS Mono The 3×12 is a powerful mini-telescope with 3× magnification. For a precisely detailed view at sporting events, in the It transforms Victory* and Conquest binoculars with theatre or at longer distances outdoors: The Monos with objective lens diameters of more than 30 millimetres and ZEISS T* multicoating impress with a bright and clear more and the Dialyt 8×56 GA into high-performance viewing image and, depending on the model, can also spotting scopes at the flick of a wrist by attaching it to the be used as magnifiers. eyepiece with an adapter ring. Can also be used separately as a magnifier in the close focus range. *Not Victory SF 56 57 Robust construction The optical and mechanical systems are effectively protected against environmental influences by the waterproof, rubber-armoured, nitrogen-filled casing. ZEISS Perfect interplay Available light is gathered by the 62-millimetre objective lens and focused on the e xtremely sensitive photocathode. ZEISS Hunting Catalogue 2020/2021 20×60 S Superlative binoculars in every respect: developed for the longest distances, and even used on missions to the International Space Station (ISS). The exceptional light transmission of the Porro prism system guarantees the brightest viewing images with outstanding resolution of the finest details even at 20× magnification. The technically unique mechanical image stabilisation system of the 20×60 T* S ensures a perfect viewing experience: the unavoidable shake always encountered when observing with handheld binoculars can be easily eliminated at the press of a button. 5.6×62 NV State-of-the-art image intensifier tubes amplify even the lowest levels of light to make the game observed appear 20,000 times brighter. In the complete absence of light or residual light, the integrated IR-LED can be activated at the touch of a button. The LED radiates light in the infrared spectrum and allows observation with the NV device at distances of around 50 metres. By attaching a torch with an IR filter, illumination can be extended to several hundred metres. ZEISS THE ZEISS HUNTING COMMUNITY D ISCOVER ZEISS ONLINE Join the ZEISS Hunting community. On our social media channels, you will find exciting content from the world of hunting from inspiring European hunting regions and presentations of our products in the wilderness to regional recipes for game. FOLLOW US ONLINE: facebook.com/ZEISSHunting zeiss.com/hunting/blog youtube.com/user/zeisssportsoptics #passionforhunting ZEISShunting_EU ZEISS Our Instagram-channel and our Facebook page also regularly provide fascinating articles abut hunting. This is where you can experience our products in action and find first-hand information about their new features. If you wish to publicly post your own snapshots on the ZEISS Instagram channel, simply mark them with the hashtag #ZEISShuntingEU below the photos. The ZEISS Hunting blog offers opportunities to follow the adventures and experiences of prominent hunters like David Carsten Pedersen or Anette Dahl at fascinating locations around the world. Amongst other things, you will also find inspiration for cooking delicious dishes with game always created by hunters, for hunters. ZEISS Hunting Catalogue 2020/2021 58 If you want to get exclusive, in-depth 59 information about our products, you can also subscribe to our ZEISS Hunting YouTube channel. The content here includes, for example, loads of video material about the ZEISS Hunting App, product tests and detailed reviews of our optics. Anette Dahl Marius Elpers ZEISS ambassadors Anette grew up on an idyllic dairy For Marius, hunting is a family tradi- We work together with an extensive farm in Norway. She was only five tion. Many generations of the Elpers network of prominent hunters from when her father first took her with family have hunted in the beautiful around the globe to enable us to him on a moose-hunting trip. She was countryside of the Münsterland region provide you with the broadest possible hooked from that moment on. Today, of Germany. Marius is no exception, spectrum of topics and content. Two Anette works as a teacher of physical and qualified for his hunting licence of these are Anette Dahl and Marius education, hunting, wildlife and for- at the age of 17. He has a passion Elpers. They have exhaustively tested estry, owns her own hunting ground for travelling abroad and finding new our products in everyday hunting and, whenever possible, can be found kinds of game. He shares this passion scenarios and regularly share their roaming the wilds with her dogs. and his experiences on his YouTube experiences with them in their social channel `WildboarFanatic'. media channels. Follow Marius on Instagram: @wildboarfanatic ZEISS ZEISS S P OT T I N G S CO P E S F R O M Z E I S S WHEN RELIABILITY MEETS FASCINATION On the one side, curiosity and open-mindedness, on the other, high-tech spotting scopes from ZEISS. When these come together, encounters with the world of nature become unique experiences every time. Nature is all around us, and is fascinating in all weathers in extremes like the Arctic and the Amazon basin, as well as close to your home. This is why so many people have discovered their passion for observing wildlife and the world of nature. For this, they need equipment with guaranteed reliability at all times. Spotting scopes from ZEISS fulfil these needs in a variety of ways with outstanding brightness and contrast, the finest rendition of details, wide fields of view and stunning magnification. Fast and exact focusing on a subject and precise, fine focusing adjustment guarantee discerning wildlife watchers certain identification of their targets at long distances. At the same time, the high-quality products from ZEISS are characterised by a ruggedness that guarantees reliability in even the toughest conditions. Around the world and every day, all of this makes ZEISS spotting scopes firm favourites that enable people to get a better and closer view of nature than ever before. No matter whether you are watching the migration of enormous herds 60 of animals or the trajectory path of a single bird. 61 Our online product guide will lead you step by step to the perfect ZEISS observation optics for your specific needs: zeiss.com/hunting/productfinder YOU CAN NOW TAKE A CLOSER LOOK AT THEIR QUALITIES WHAT MAKES OUR SPOTTING SCOPES UNIQUE, AND HOW ARE THEY CONSTRUCTED? THE ZEISS AR SPORTS OPTICS APP PROVIDES THE ANSWERS. ZEISS Z E I S S V I C TO R Y S P OT T I N G S CO P E S A NEW VISUAL DIMENSION The Victory Harpia is a true ZEISS model in every respect absolutely premium optics, proven ruggedness and ergonomics meet state-of-the-art technology. This spotting scope features the DualSpeed Focus system with fast switching from close to long ranges and options for fine focusing and sharpness correction. One of the many innovations of this high-performance spotting scope from ZEISS is that magnification and focusing are controlled with collars on the body of the scope and not, as usual, with the eyepiece. This enables very fast adaptation to the current situation and brings dedicated birdwatchers and wildlife enthusiasts even more fascinating encounters with the world of nature. Further unquestionable benefits are the 72° field of view and the respective, model-specific close-focus distances of 3.5 and 4.5 metres. These values make the Victory Harpia ideal for observation on a larger scale, for example, by lakes or in woodland as well as at closer ranges. FAC T S: UFL Concept: Natural colour fidelity, high contrast, brilliance and the finest detail rendition. LotuTec® coating: The dust, dirt and water- repellent coating guarantees a permanently clear view. Dual Speed Focus: Precise focusing with automatic switch between fast and fine-focusing drive. Magnesium materials: The combination of extremely lightweight and high strength materials that last for generations. ZEISS H igh magnification factors Sharp image for precise long-range target identification 62 63 Optimum performance Objective lens diameters of up to 95 millimetres for clear and bright images with razor-ship details O utstanding ergonomics Large operating elements with smooth action for fast and precise focusing ZEISS PRODUC T PORTR AIT THE MOST POWERFUL SPOTTING SCOPE FROM ZEISS: ZEISS VICTORY HARPIA The world of nature is already truly fascinating when observed with the naked eye. But viewing it through a Victory Harpia transforms into an entirely new experience. ComfortVision Concept A subjective viewing angle of 72° throughout the entire zoom range for a noticeably broader overview of the terrain. This spotting scope offers a new and unusual optical system with a 3× wide-angle zoom, up to 70× magnification and choice of 85 and 95mm objective lens diameters. The extremely wide fields of view bring impressive results in every situation. DualSpeed Focus enables fast focusing and easy, precise, fine focus adjustment, even at high magnification factors. Thanks to its unique, 72° wide-angle field of view throughout the entire 3× zoom range, the unrivalled dynamic of the Victory Harpia guarantees superior performance at long or short distances in every unexpected viewing situation. ZEISS Victory Harpia Comparison of the field of view of a spotting scope with 30× min. magnification (small circle) with the field of view of the Harpia at 23× min. magnification (large circle). ZEISS ZEISS Hunting Catalogue 2020/2021 Compact, high-performance eyepiece Slim construction for a comfortable viewing experience. Securely lockable bayonet mount. DualSpeed Focus Automatic switch between fast- and fine-focusing drive for fast and precise focusing. 64 65 LotuTec® coating A clear view in all weather conditions. Raindrops and dirt simply roll off the lens. Lig ion ht transmiss ZEISS ACCESSORIES Lig Lig Harpia 95 The unusual optical system features a 3× wide-angle zoom, up to 70× magnification and an objective lens diameter of 95 millimetres. The extremely wide fields of view prove their worth in every situation. The Harpia 95 also features precise focusing with convenient automatic transition from rapid to fine adjustment, even at high magnification factors. Harpia 85 With the exception of its objective lens diameter of 85millimetres, this version offers the same overall advantages as the Harpia 95. Thanks to the use of FL glasses and other specially formulated glass types, the Harpia 85 also delivers an absolutely sharp viewing image with natural colour fidelity, even at maximum magnification. And a subjective angle of view of 72° throughout the entire zoom range provides a noticeably greater overview of the terrain. ion ion ht transmiss ht transmiss Tripod Professional The ZEISS Tripod Professional fulfils the most demanding requirements with regard to compatibility and loading weight and enables particularly smooth panning and tilting. It is specifically suitable for use with our Victory products and for digiscoping. Long Balance Plate Our Long Balance Plate is the ideal solution to perfectly balance your spotting scope, especially when digiscoping. (only for Tripod Professional). 66 67 ZEISS ZEISS Hunting Catalogue 2020/2021 Ever-ready carrying case for the Victory Harpia The case offers reliable protection against all kinds of weather and wet conditions, is comfortable to carry and enables fast readiness of the spotting scope for use. The caps for the eyepiece and the objective lens can be securely attached to the case to prevent loss. ZEISS photo adapter Whether for still pictures or film, the photo adapter (for M49, M52 or M58 filter threads) enables direct attachment of a digital camera to the Victory Harpia and transforms the spotting scope into a powerful tele lens. ZEISS ion ion Lig Lig P R O D U C T P O R T R A I T THE EXPLORER'S COMPANION: ZEISS CONQUEST GAVIA 85 Ergonomic The large focusing ring enables precise handling and easy focusing of the viewing image. Light The magnesium body and compact dimensions make the Gavia a lightweight and handy companion wherever you go. ht transmiss ZEISS Bright, clear and richly detailed Exceptionally precise roof prisms and an HD lens system guarantee a bright and clear viewing image. ZEISS Hunting Catalogue 2020/2021 ZEISS IN PRACTICE Gavia 85 This spotting scope with an 85-millimetre objective lens Perfectly matched to the filter is particularly lightweight and compact. This makes it the thread of your lens ideal instrument for close- and long-range observation, Sometimes, it would be fantastic to quickly and especially in regions that are difficult to access. Unique easily capture special outdoor experiences. Simple in this class is the short close-focus that enables stepping rings allow the ZEISS photo adapter to be problem-free acquisition of small targets. mounted on lenses with other filter thread sizes. Due to their lightweight properties, MFT (Micro Four ht transmiss Thirds) cameras with prime lenses between 17 and 25 68 millimetres are particularly suitable for digiscoping. APS-C cameras with suitable lenses, for example the 69 Sony ZEISS 2.8/35mm, also allow photography with all magnification factors of the spotting scope. ACCESSORIES You can share your photos with the ZEISS Community on Instagram and Facebook with the hashtag #passionforhunting. 1.25" astro adapter For mounting standard astro eyepieces. Ever-ready carrying case for the Conquest Gavia Developed especially for the Conquest Gavia, the case protects the spotting scope against environmental influences such as moisture and dirt. In addition to this, optimum carrying comfort, fast readiness of the spotting scope for use and an option for attaching the eyepiece and objective lens cap to the case make it an invaluable part of the equipment. ZEISS photo adapter Whether for still pictures or film, the photo adapter (for M49, M52 or M58 filter threads) enables direct attachment of a digital camera to the Conquest Gavia 85 and transforms the spotting scope into a powerful telephoto lens ZEISS P R O D U C T P O R T R A I T THE IDEAL HUNTING COMPANION: ZEISS DIALYT High performance Fascinates with a richly detailed viewing image and features 45× magnification for identification of objects at extreme distances. Versatile A bright, clear and richly detailed viewing image into the twilight hours for an optimum overview in all weathers and at any distance. Dialyt The light and compact `hunter's spotting scope' was developed especially for fast and precise target identification at extreme distances. A waterproof, non-fogging, construction, reliable functioning and simple handling make it the ideal companion for hunting in flat, open country or in rugged mountainous terrain. ACCESSORIES Tripod mount The Dialyt 1845×65 can be rested on a rucksack or supported against a tree trunk for steady viewing and also features a field-tested tripod mount. In the case of a lack of natural support, or for longer periods of observation, it is advisable to mount the spotting scope on a carbon tripod from ZEISS. Another alternative would be the use of a lightweight monopod for support. 70 71 Light Thanks to its compact, monobloc construction, the Dialyt is waterproof and the ideal companion for stalking and stand hunting. ZEISS ZEISS Hunting Catalogue 2020/2021 ZEISS TECHNICAL SPECIFICATIONS A DIVERSITY OF DEVELOPMENTS: ZEISS RIFLESCOPES Victory riflescopes Model Magnification Effective lens diameter Exit pupil diameter Twilight factor 1.18×30 1.18× 10.630mm 9.93.9mm 3.115.5 V8 1.814×50 2.820×56 1.813.5× 2.820× 18.650mm 27.556mm 10.33.7mm 9.82.8mm 5.126 7.933 4.835×60 4.835 × 48.160mm 9.91.4mm 13.645.8 Field of view at 100m 39.65.4m 233.1m 15.52.1m 8.61.2m Objective viewing angle Diopter adjustment range 22.2°3° 13.1°1.8° 8.9°1.2° -3.5 / +2 dpt 4.9°0.7° Eye relief 95mm Parallax free 100m 50m Vertical adjustment range at 100m 500cm 310cm 210cm 130cm Lateral adjustment range at 100m 320cm 200cm 135cm 85cm Adjustment per click at 100m 1cm 0.5cm Centre tube diameter 36mm Eyepiece tube diameter 46mm Objective tube diameter Coating 36mm 56mm LotuTec® 62mm 67mm Nitrogen filled yes Water resistance Operating temperature 400mbar -25°C/+50 °C Length 303mm 343mm 350mm 402mm Illuminated reticles 54, 60 60 60 43, 60 Weight with illuminated reticle without inner rail with inner rail 600g 620g 710g 730g 830g 855g 970g 1,000g Order number (XXXXXX-xxxx-xxx) without inner rail with inner rail 52 21 0752 21 06- 52 21 1752 21 16- 52 21 3752 21 36- 52 21 4752 21 46- 43 Choice of illuminated reticles 54 (xxxxxx-XXXX-xxx) 60 -9954-9960- -9960- -9960- -9943 -9960- Bullet drop without BDC -000 -000 compensator (ASV) BDC (elevation) -040 -040 -040 (xxxxxx-xxxx-XXX) BDC (elev. and windage) -050 -050 -050 BDC (ASV) LR BDC (ASV) LR BDC (ASV) Comp. Example for a complete order number for Victory V8 1.814×50 with inner rail, ret. 60, ASV LR (elevation): 522116-9960-040 Subject to changes in design and scope of delivery as a result of ongoing technical development. ZEISS Reticle 43 with illuminated dot in the centre Reticle 54 Perfected for driven hunts Reticle 60 extremely fine and bright illuminated dot ZEISS Hunting Catalogue 2020/2021 TECHNICAL S P E C I F I C AT I O N S Victory riflescopes Model Magnification Effective lens diameter Exit pupil diameter Twilight factor Field of view at 100m Objective viewing angle Diopter adjustment range Eye relief Parallax free Vertical adjustment range at 100m Lateral adjustment range at 100m Adjustment per click at 100m Centre tube diameter Eyepiece tube diameter Objective tube diameter Coating Nitrogen filled Water resistance Operating temperature Length Illuminated reticles Weight with illuminated reticle without inner rail with inner rail Order number (XXXXXX-xxxx-xxx) without inner rail with inner rail 52 24 2552 24 24- 43 Choice of illuminated reticles 54 (xxxxxx-XXXX-xxx) 60 Bullet drop compensator (ASV) (xxxxxx-xxxx-XXX) without BDC BDC (elevation) BDC (elev. and windage) 2.510×50 2.5×10× 37.750mm 155mm 7.122.4 14.84.1m 8.5°2.3° 140cm 140cm 56mm 321mm 60 525g 550g -9960- BDC+ (ASV+) HT -4 / +2 dpt 90mm 100m 1cm 30mm 42mm LotuTec® yes 400mbar -25°C/+50°C 52 24 3552 24 34- -000 -010 -020 312×56 3×12× 4456mm 14.94.7mm 8.525.9 12.53.5m 7.2°2° 120cm 120cm 62mm 347mm 60 573g 598g -9960- BDC+ (ASV+) 72 73 -000 -010 -020 Reticle 60 extremely fine and bright illuminated dot ZEISS Conquest riflescopes Model Magnification Effective lens diameter Exit pupil diameter Twilight factor Field of view at 100m Objective viewing angle Diopter adjustment range Eye relief Parallax setting Square adjustment range at 100m Adjustment per click at 100m Centre tube diameter Eyepiece tube diameter Objective tube diameter Coating Nitrogen filled Water resistance Operating temperature Length Weight without inner rail with inner rail Order number without inner rail with inner rail 60 Choice of reticles (xxxxxx-XXXX-xxx) 20 43 ZMOA-2 ZMOA-1 ZBR-2 ZBR-1 Bullet drop compensator (ASV) (xxxxxx-xxxx-XXX) BDC (ASV) Ballistic Turret 1.16×24 1.16.5× 10.524mm 9.53.7mm 3.112.5 38.16.6m 21.6°3.8° 100m 300cm 30mm 290mm 505g 545g 52 22 05 52 22 04 9960 212×50 212× 19.450mm 9.74.2mm 5.724.5 20.53.4m 11.7°2.0° 100m 250cm 1cm 56mm 335mm 620g 655g 52 22 25 52 22 24 9960 060 V6 2.515×56 2.515× 24.356mm 9.73.7mm 7.129.0 16.42.7m 9.4°1.6° +2/-3 dpt 90mm 100m 200cm 30mm 45.5mm 62mm LotuTec®/ZEISS T* yes 400mbar -25°C/+50°C 352mm 690g 725g 52 22 35 52 22 34 9960 060 Example of a complete order number for a Conquest V6 2.515×56 with inner rail, reticle 60 and BDC/ASV (elevation): 522234-9960-060 Subject to changes in design and scope of delivery as a result of ongoing technical development. 318×50 318× 28.650mm 9.52.8mm 8.530.0 12.42.1m 7.1°1.2° 530×50 530× 47.350mm 9.51.7mm 14.138.7 7.41.2m 4.2°0.7° 300×170m 180×100m 1/4 MoA (0.7cm/100m) 56mm 56mm 338mm 630g not available 52 22 41 9906 9994 9992 070 380mm 740g not available 52 22 51 9906 9943 9993 9991 070 ZEISS Reticle 43 with illuminated dot in the centre Reticle 54 Perfected for driven hunts Reticle 60 extremely fine and bright illuminated dot ZEISS Hunting Catalogue 2020/2021 TECHNICAL S P E C I F I C AT I O N S Conquest riflescopes Model Magnification Effective lens diameter Exit pupil diameter Twilight factor Field of view Angular field of view, real Diopter range Eye relief Parallax setting Adjustment range at 100m Adjustment per click at 100m Centre tube diameter Eyepiece tube diameter Lens tube diameter Coating Nitrogen filled Water resistance Operating temperature Length Weight without inner rail Order number (XXXXXX-xxxx-xxx) without ill. reticle with ill. reticle Choice of reticles 60 (xxxxxx-XXXX-xxx) 20 ZMOA-2 ZMOA-1 ZMOAi-1 ZBR-2 ZBR-1 ZBi ZMOAi-20 ZMOAi-T20 ZMOAi-T30 V4 14×24 312×56 416×44 624×50 1 4 3 12 4 16 6 24 12.1mm 24mm 27.7mm 56mm 33.2mm 44mm 44.9mm 50mm 11.9mm 6mm 9.2mm 4.7mm 8.5mm 2.8mm 7.5mm 2.1mm 3.5 9.8 9.1 25.9 11.5 26.5 16.4 34.6 38m 9.5m 12.7m 3.2m 9.5m 2.4m 6.3m 1.6m 21.5° 5.4° 7.2° 1.8° 5.4° 1.4° 3.6° 0.9° +2/-3 dpt 90mm 91.4m 45.7m 300cm 200cm 230×175cm 230×175cm 1,4cm 1/4 MoA (0.7cm /100m) 30mm 44mm 30mm 62mm 50mm 56mm LotuTec® yes 400mbar 74 256mm -25°C/+55°C 368mm 356mm 75 368mm 470g 610g 640g 690g 522921 522931 522951 522905 522925 522935 522955 9960 9960 9960 9960 9920 9920 9994 9993 9993 9992 9991 9968 9968 9989 9965 9964 Bullet drop Ballistic Turret compensator (ASV) (xxxxxx-xxxx-XXX) External Locking Windage 080 080 090 090 Example of a complete order number for a Conquest V4 312×56 without inner rail, with illuminated reticle 60: 522925-9960 Subject to changes in design and scope of delivery as a result of ongoing technical development. 60 ZMoA-1 ZMoA-2 ZMoAi-1 ZBR-1 ZBR-2 20 ZBi ZMOAi-20 ZMOAi-T20 ZMOAi-T30 ZEISS TECHNICAL SPECIFICATIONS THE PERFECT COMPANION WHEN HUNTING AT NIGHT: ZEISS THERMAL IMAGING CAMERA Modell Optics Focal length Lens type Thermal imaging camera DTI 3/35 35mm/F1.0 Germanium Range ~ 1,235m (according to Johnson's criteria; according to specification) Eyepiece field of view in degrees (subjective field of view) Diagonal: 30,25° bjective field of view in m at 100m Objective lens field of view in degrees (horizontal×vertical) Optical magnification factor Horizontal: 19m 10,7°×8° (diagonal 13,3°) 2,5× Maximum digital zoom 4× Zoom range Sensor In increments of 0.5×: 1.0×4.0× Sensor resolution Sensor pixel pitch 384×288px 17m Refresh rate Display Display resolution Display type Electronics 50Hz 1.280×960px LCOS Interfaces USB-C: Charging + data transfer WLAN: Data transfer Battery Lithium-ion Battery life (full charge) 7hrs. External power supply 5V/3A, 9V/2A, 12V/1,5A (USB-C) Built-in memory 15GB Video/still picture/livestream function Yes WLAN frequency 2,4GHz WLAN standard IEEE 802.11b/g/n Connectivity with other devices ZEISS Hunting App or USB-C General Protection rating IP 66 (Protected against heavy rain) Operating temperature range 10°C bis +40°C (+14°F/+104°F) Length×width×height 193mm×60mm×65mm Weight 450g Order number 527010 We reserve the right to make changes to features, functions and scope of delivery that reflect technical advancements. ZEISS ZEISS Hunting Catalogue 2020/2021 76 77 ZEISS TECHNICAL SPECIFICATIONS PATHFINDING SOLUTIONS: ZEISS RANGEFINDER SYSTEM AND BINOCULARS Victory Rangefinder System Model 8×42 RF System 10×42 8×54 10×54 Magnification Effective lens diameter 8× 10× 42mm 8× 10× 54mm Exit pupil diameter 5.3mm 4.2mm 6.8mm 5.4mm Twilight factor 18.3 20.5 20.8 23.2 Field of view 135m 115m 120m 110m Subjective angle of view 61°Ww 63°Ww 54°Ww 61°Ww Close-up setting limit Diopter adjustment range 2.5m +/-4 dpt. 3.5m +/-4dpt. Eye relief 16mm 14mm Pupil distance 53.576mm 58.576mm Lens type FL Prism system Coating Abbe-König LotuTec®/T* Nitrogen filled yes Waterproof Operating temperature 100mbar -25°C/+63°C Length Width with an eye spacing of 65mm Weight Measuring range Measuring accuracy Measuring duration Laser wavelength 930g 166mm 130mm 960g 1,095g 102,300m ±1 to 600/±0.5% over 600m <0.3 Sec 905nm 195mm 141mm 1,130g Laser beam divergence 1.6×0.5nm Battery 1× 3V Type CR 2 Battery life at +20°C >2.500 × Order number 52 45 48 52 45 49 52 56 48 52 56 49 Subject to changes in design and scope of delivery as a result of ongoing technical development. ZEISS ZEISS Hunting Catalogue 2020/2021 TECHNICAL S P E C I F I C AT I O N S Victory binoculars SF HT Model 8×32 10×32 8×42 10×42 8×54 10×54 Magnification 8× 10× 8× 10× 8× 10× Effective lens diameter 32mm 42mm 54mm Exit pupil diameter 4mm 3.2mm 5.3mm 4.2mm 6.7mm 5.4mm Twilight factor 16 17.9 18.3 20.5 20.7 23.2 Field of view at 1,000m 155m 130m 148m 120m 130m 110m Subjective viewing angle 67°Ww 69°Ww 64°Ww 60°Ww 63°Ww Close focusing distance 1.95m 1.5m 3.5m Diopter adjustment range +/-4dpt. +/-3dpt. Exit pupil distance 19mm 18mm 16mm Interpupillary distance (PD) 5476mm 5576mm 5876mm Objective type UFL UFL FL /HT-Typ Prism system Schmidt-Pechan Schmidt-Pechan Abbe-König Coating LotuTec® /T* Nitrogen filled yes Water resistance 400mbar 500mbar Operating temperature -30°C/+63°C Length 152mm 150mm 173mm 193mm Width at an interpupillary distance of 65mm 112mm 125mm 142mm Weight 600g 590g 790g 1.035g 1.050g 78 Order number 52 32 24 52 32 25 52 42 23 52 42 24 52 56 28 52 56 29 Subject to changes in design and scope of delivery as a result of ongoing technical development. 79 Formore information, please visit www.zeiss.com/sports-optics Victory binoculars Model Magnification Effective lens diameter Exit pupil diameter Twilight factor Field of view at 1,000m Subjective viewing angle Close focus Diopter adjustment range Exit pupil distance Pupil distance Lens type Prism system Coating Nitrogen filled Water resistance Operating temperature Length Width at an interpupillary distance of 65mm Weight Order number Pocket 8×25 10×25 8× 10× 25mm 25mm 3.1mm 2.5mm 14.1 15.8 130m 105m 60° 1.9m +/-3dpt 16.5mm 3474mm FL Schmidt-Pechan LotuTec® yes 100mbar -25°C/+63 °C 112mm 100mm 290g 52 20 38 52 20 39 Subject to changes in design and scope of delivery as a result of ongoing technical development. ZEISS Conquest binoculars Model Magnification 8×32 8× 10×32 10× 8×42 8× HD 10×42 10× Effective lens diameter 32mm 32mm 42mm 42mm Exit pupil diameter 4mm 3.2mm 5.25mm 4.2mm Twilight factor 16 17.9 18.3 20.5 Field of view at 1,000m 140m 118m 128m 115m Subjective viewing angle 64°Ww 68°Ww 59°Ww 66°Ww Close focus Diopter adjustment range 1.5m +/-4 dpt 2m +/-4 dpt Exit pupil distance 16mm 18mm Pupil distance 5474mm 5474mm Lens type HD HD Prism system Coating Schmidt-Pechan LotuTec®/T* Schmidt-Pechan LotuTec®/T* Nitrogen filled yes yes Water resistance Functional temperature 400mbar -20°C/+63°C 400mbar -20°C/+63°C Length Width at an interpupillary distance of 65mm Weight Ordernumber 132mm 118mm 630g 52 32 11 630g 52 32 12 150mm 120mm 795g 52 42 11 795g 52 42 12 Subject to changes in design and scope of delivery as a result of ongoing technical development. 8×56 8× 56mm 7mm 21.2 125m 57°Ww 1,265g 52 56 31 10×56 10× 56mm 5.6mm 23.7 115m 66°Ww 3.5m +/-4 dpt 18mm 5474mm HD Abbe-König LotuTec®/T* yes 400mbar -20°C/+63°C 210mm 145mm 1,275g 52 56 32 15×56 15× 56mm 3.7mm 29.0 80m 69°Ww 1,295g 52 56 33 TECHNICAL S P E C I F I C AT I O N S Terra binoculars Model 8×25 10×25 ED 8×32 10×32 8×42 10×42 Magnification 8× 10× 8× 10× 8× 10× Effective lens diameter 25mm 32mm 42mm Exit pupil diameter 3.1mm 2.5mm 4.0mm 3.2mm 5.3mm 4.2mm Twilight factor 14.1 15.8 16.0 17.9 18.3 20.5 Field of view at 1,000m 119m 97m 135m 112m 125m 110m Subjective angle of view 52° 54° 61° 61° 56° 60° Close-up setting limit Diopter adjustment range 1.9m +/-3 dpt 1.6m +/-3 dpt 1.6m +/-3 dpt Exit pupil distance 16mm 16.5mm 18mm 14mm Pupil distance 3572mm 5674mm 5875.5mm Lens type ED ED ED Prism system Schmidt-Pechan Schmidt-Pechan Schmidt-Pechan Coating Hydrophobic ZEISSmC Hydrophobic ZEISSmC Hydrophobic ZEISSmC Nitrogen filled yes yes yes Water resistance Operating temperature Length 100mbar -20°C/+63°C 111mm 100mbar -15°C/+60°C 125mm 100mbar -15°C/+60°C 142mm 80 Width with an eye spacing of 65mm Weight 115mm 310g 117mm 510g 120mm 81 725g Ordernumber black/green 523203-9908 523204-9908 524203-9908 524204-9908 black/black 522502-9901-000 522503-9901-000 523203-9901 523204-9901 524203-9901 524204-9901 grey/grey 522502-9907 522503-9907 523203-9907 523204-9907 524203-9907 524204-9907 Subject to changes in design and scope of delivery as a result of ongoing technical development. ZEISS ZEISS Hunting Catalogue 2020/2021 ZEISS TECHNICAL SPECIFICATIONS QUALITY DEMANDED AROUND THE GLOBE: ZEISS SPOTTING SCOPES Victory Spotting Scope Model Focal length of lens Filter thread objective lens side Lens diameter Close focus Height×width×length Weight without eyepiece Waterproof Nitrogen filling Order number Harpia 85 95 162mm486mm 174mm523mm M86×1 M95×1 85mm 95mm 3.5m 4.5m 121×103×384mm 124×109×408mm 1,934g 2,078g 400mbar yes 52 80 47 52 80 57 Victory Spotting Scope Model Eyepiece Harpia 85 Harpia 95 Magnification 2265× 2370× Focal length 7.48mm Field of view m/1,000m 63.221.0m 58.819.5m Zoom factor 3× Exit pupil 2.501.31mm 2.501.34mm Diameter Ø 53mm Length 71mm Weight 220g Order number 528070 Including eyepiece and lens cover. All with ZEISS T*-multi-layer-coating. Model Magnification Lens diameter Exit pupil diameter Focal length Field of view at 1,000m Close focus Lens type Coating Nitrogen filled Water resistance Lens thread Length Weight (incl. eyepiece) Order number (incl. eyepiece 3060×85) Including eyepiece and lens cover. Adapter Astro adapter Photo lens adapter m49 Photo lens adapter m52 Photo lens adapter m58 Model Dialyt Spotting Scope 1845×65 Magnification 1845 × Lens diameter 65mm Exit pupil diameter 3.61.4mm Field of view at 1,000m 4023m Close focus 10m Lens type Achromat Nitrogen filled yes Water resistance 400mbar Length×height×width 395×78×76mm Weight ca. 1,195g Order number 52 80 07 Including eyepiece and lens cover, carrying strap. Gavia 85 3060× 85mm 2.8mm1.4mm 494mm 33m23m 3.3m HD LotuTec® yes 400mbar M86×1 396mm ca. 1,700g 52 80 48-0000-000 Order number 52 83 45 52 83 48-9901 52 83 48-9902 52 83 48-9903 Subject to changes in design and scope of delivery as a result of ongoing technical development. ZEISS ZEISS Hunting Catalogue 2020/2021 TECHNICAL SPECIFICATIONS NUMEROUS OPTIONS: ZEISS ACCESSORIES TECHNICAL S P E C I F I C AT I O N S Model Material Length closed Length open Weight Order number Tripods Professional Carbon ca. 700mm ca. 1,820mm ca. 2,460g 21 69-972 Long balance plate formodel Professional only 21 69-974 Model DiaScope 65 FL straight view DiaScope 65 FL angled view DiaScope 85 FL straight view DiaScope 85 FL angled view ConquestGavia 85 Victory Harpia 85 Victory Harpia 95 Model for standard astro eyepieces for 11/4" astronomy telescopes Astro adapter for DiaScope Astro adapter 52 83 85 52 83 86 52 83 82 Carrying case for 1778-946 1778-968 1778-973 1778-974 2169-979 2169-977 2169-976 82 83 Subject to changes in design and scope of delivery as a result of ongoing technical development. ZEISS TECHNICAL SPECIFICATIONS WITH PRECISION IN MIND: ZEISS ACCESSORIES Bullet drop compensator (BDC/ASV) BDC LongRange (BDC/ASV LR) for Victory V8 1.814×50, 2.820×56 for elevation, new orders for windage, new orders Windage (BDC/ASV) Competition for Victory V8 4.835×60 for windage, new orders BDC+ (ASV+) for Victory HT for elevation, new orders for elevation and windage, new orders BDC V6 (ASV V6) for Conquest V6 for elevation, new orders Throw lever for Victory V8 and Conquest V6 For Conquest V4 Flip cover for Victory V8/Victory HT Ø 30mm Ø 50mm Ø 56mm Ø 60mm Neoprene Cover Size S Size M Size L Size XL Size guide with model compatibility at zeiss.com/hunting/accessories Rubber light shield (not for V8) Battery cover for spare battery (battery container) ZEISS Order no. -040 -050 -050 -010 -020 -060 Order no. 2224-899 2248-168 Order no. 2152-898 2105-737 2105-798 2173-926 Order no. 2231-631 2231-632 2231-633 2231-634 Order no. 52 83 75 Order no. 52 16 24-8009 Protective cap for riflescopes please state the exact model Turret cap for windage and elevation please state the exact model Order no. Order no. ZEISS Hunting Catalogue 2020/2021 TECHNICAL SPECIFICATIONS IMPROVED PERFORMANCE: ZEISS ACCESSORIES ACCESSORIES Tripod adapter Binofix universal tripod mount for all binocular models Tripod adaptor 1/4" for Conquest HD (included in HD 15×56 delivery) Order no. 52 83 87 52 83 88 Magnification attachment Mono 3×12 Including carrying strap and leather pouch; triples normal binocular magnification Order no. 52 20 12 Binofix universal tripod mount Tripod adaptor 1/4" Adaptor for magnification attachment for Victory FL/RF/HT (not for SF) and Conquest HD 32 and 42 for Conquest HD 56 for Dialyt 8×56 GA Order no. 52 83 77 52 83 79 52 83 83 Adaptor for magnification attachment 84 85 Magnification attachment Mono 3×12 Accessories for Victory NV 5.6×62 SLR camera adapter 1"-flashlight mount Mini Maglite adapter Order no. 52 30 06-9007 52 30 06-9006 52 30 06-9008 Pouches for Victory SF for Terra Pocket Leather pouch for 20×60 S Order no. 2060-069 2197-806 52 90 83 SLR camera adaptor Pouch for Victory SF Cordura bags for Victory HT 42 for Victory HT 54 for Conquest HD 32 and Terra ED 32 for Conquest HD 42 and Terra ED 42 for Conquest HD 56 Order no. 1980-766 2074-447 52 90 35 1976-008 1379-711 Cordura bag Pouch for Terra Pocket Carrying straps Air Cell comfort straps Binocular comfort straps Order no. 52 91 13 52 91 15 Air Cell comfort straps Binocular comfort straps ZEISS Victory Model 3×12 4×12 Monos 6×18 8×20 10×25 Magnification Lens diameter 3× 4× 12mm 6× 18mm 8× 20mm 10× 25mm Exit pupil diameter 4mm 3mm 2.5mm Twilight factor 6 6.9 10.4 12.6 15.8 Field of view at 1,000m 220m 180m 120m 110m 88m Subjective viewing angle 38° 41° 51° Close focus Diopter adjustment range 0.2m 0.25m 0.3m 3m +/-4 dpt 4.5m Eye relief 12mm 15mm Lens type Achromat Prism system Schmidt-Pechan Water resistance Functional temperature range splash proof -20°C/+40°C Height×width 58mm 70mm 94mm 101mm 119mm Weight 54g 45g 58g 67g 77g Order number 52 20 12 52 20 50 52 20 51 52 20 52 52 20 53 All with ZEISS T*-multi-layer coating. Subject to changes in design and scope of delivery as a result of ongoing technical development. MiniQuick® 5×10 5× 10mm 2mm 7 100m 29° 4m 16.5mm 113mm 23g 52 20 10 Model Magnification Lens diameter Exit pupil diameter Twilight factor Field of view at 1,000m Subjective viewing angle Close focus Diopter adjustment range Eye relief Pupil distance Lens type Prism system Water resistance Binoculars with image stabilisation 20×60 S 20× 60mm 3mm 34.6 52m 60° Ww 14m +/-7dpt 13mm 5773mm Achromat Porro splash proof Functional temperature range -20°C/+40 °C Height×width Weight Order number 275×161mm 1,660g 52 60 00 Delivery including neoprene carrying strap, eyepiece cover, aluminium case. Subject to changes in design and scope of delivery as a result of ongoing technical development. Model Night Vision 5.6×62 NV Magnification Lens diameter Field of view at 1,000m Close focus Diopter adjustment range Eye relief Coating Nitrogen filled Length×height×width Weight Reticle: distance between lines Measuring range Order number 5.6× 62mm 142m 5m +/-4 dpt 20mm LotuTec® yes 233×100×80mm ca. 1,000g 0.5m/100m 500m 52 30 07-9901 Delivery including cordura pouch, carrying strap, eyepiece and lens covers and 2× AA batteries. Subject to changes in design and scope of delivery as a result of ongoing technical development. ZEISS ZEISS Hunting Catalogue 2020/2021 TECHNICAL S P E C I F I C AT I O N S 86 87 ZEISS EN_52_029_0003I_2372-866 02/20 Printed in Germany. We assume no liability for mistakes or printing errors. Join the ZEISS Hunting community. Follow us online: facebook.com/ZEISSHunting zeiss.com/hunting/blog youtube.com/user/zeisssportsoptics #passionforhunting ZEISShunting_EU ZEISS Customer Service Gloelstraße 3 - 5, 35576 Wetzlar Germany Phone +49 800 9347733 Fax +49 64 41 4 83 69 service.sportsoptics@zeiss.com Carl Zeiss AG Consumer Products division Carl-Zeiss-Straße 22 73447 Oberkochen Germany www.zeiss.com/consumer-productsAdobe PDF Library 15.0 Adobe InDesign 15.1 (Macintosh)
