3M Health Care 3MTM RangerTM blood & fluid warming systems: Smart, intuitive dry heat technology solution 2 Make your job easier with no hassle blood and fluid warming. A flexible solution The RangerTM blood and fluid warming system uses dry heat technology to help make your job easier and optimize patient care. Dry heat technology adapts to virtually any fluid warming need from KVO (keep vein open) to 500 mL/min or 30 L/hour. That means fast, accurate heat control which minimizes the risk of overheating fluids while avoiding the potential for cross contamination associated with traditional water bath systems.1 Safe and secure One of our latest innovations, the redesigned 3MTM RangerTM pressure infusor has important safety features that are a part of the re-design, including visual and audible alerts to let you know if a chamber's pressure drops below or exceeds the desired pressure range. By applying 300 mmHg of consistent, controlled pressure to IV fluid bags, the Ranger pressure infusor provides secure and simple administration of fluids to a flow rate up to 500 mL/ min. Two independent chambers accommodate a variety of fluid bag sizes, from 250 mL to 1000 mL. Save time and money To save time and money in training and system maintenance, just one warming unit is used for all flow rates � from pediatric cases to standard flow rates to high volume flow rates � all cases follow the same setup process. Disposable warming sets slide easily into the warming unit and only fit in one direction, so setup is intuitive. Because the Ranger system uses dry heat technology, there are no unsightly water reservoirs to change and maintenance is easy. One simple tool is all that's required to clean the Ranger warming unit in a matter of minutes. Clinically proven It can be so important to warm your surgical patients' fluid or blood. Infusing cold fluids can produce hypothermia.2 In fact, infusing one liter of room temperature fluid (21�C) or one unit of refrigerated blood (4�C) can decrease the patient's mean body temperature by 0.25�C2 and the effects are additive. So the higher the infusion volume, the more drastic the drop in mean body temperature.2 In contrast, fluid warming can minimize heat loss when large amounts of fluid or blood are needed. It is not a stand-alone option for patient warming (or normothermia maintenance), but it may offer a benefit when used with other patient warming modalities. Sustainability In the Health Care Business, 3M is working to make our manufacturing processes and internal operations more sustainable. We took it one step further and worked with suppliers to rid the entire warming set of components that are made of materials that contain DEHP (di-[2-ethylhexy] phthalate). 3 Inspired Design Lightweight 1 Space-saving Simple-to-use 3 2 4 5 6 8 7 1 Integrated handle for easy transport 2 Compact, space-saving design 3 Large, easy-to-read temperature display 4 Audible/visible over-and under-temperature alerts 5 Highly conductive aluminium plates for maximum heat transfer and no hotspots 6 Inexpensive, simple-to-use disposable warming sets 7 Convenient over-temperature test function 8 Built-in IV pole clamp for secure hold 4 Eliminate a potential source of water-related infection with advanced dry heat technology. You and your staff work hard to remove potential sources of nosocomial pathogens and healthcare associated infections. Warm water has long been identified as a potential source of gram-negative bacilli.1 Endocarditis, bacteremia and peritonitis with Pseudomonas or Acinetobacter have also been traced to contaminated 37�C waterbaths.1 Dry heat fluid warming devices like the 3MTM RangerTM blood/fluid warming system uses aluminum plates within the warming unit. No water bath. No risk of potential water-related infection due to a warm water bath. The revolutionary design and aluminum plates in the Ranger blood/fluid warming system are ideally spaced to create maximum contact area with the warming set while allowing unrestricted fluid flow. The tightly coupled heat system is highly responsive to changes in flow rates under all fluid warming conditions. A microprocessor based controller monitors the system temperature four times per second and is sensitive to variations as small as 0.1�C. This allows the warming unit to either increase or decrease heat as fluid temperature and flow rates change. 5 3MTMRangerTM Blood/Fluid Warming Unit Model 245 Specifications Set Point Temperature 41�C Flow Rates Pediatric KVO � 100 mL/min Standard Flow KVO � 150 mL/min High Flow KVO � 500 mL/min Alarms (audible and visual) Over-temperature primary setpoint: 43�C Over-temperature secondary setpoint: 44�C Leakage Current Meets leakage current requirements in accordance with UL / IEC 60601-1 Dimensions 19 W x 11 H x 25 D cm (7.5 W x 4.5 H x 10 D in) Weight 3.4 kg (7.7 lb) Device Rating 100 - 120 VAC, 50/60 Hz 220 - 240 VAC, 50/60 Hz Packaging 1/Box 3MTM RangerTM Blood/Fluid Warming Sets Warming sets accommodate up to 300 mmHg of pressure and are made without natural rubber latex and without DEHP. There are 10 warming sets contained in each case, that are sterilized - EtO. For single use only. High Flow Warming Sets: KVO - 500 mL/min or 30 L/hr Model 24355 Priming volume 150 mL Components two bag spikes drip chamber with 150 micron blood filter roller clamps cassette auto-venting bubble trap needleless injection port 52 cm (1.52 m) / 60 in (5 ft) patient line Model 24370 Priming volume 89 mL Components Cassette, auto-venting bubble trap, roller clamp 121 cm (1.21 m) / 48 in (4 ft) patient line Model 24365 Priming volume 65 mL Components Cassette auto-venting bubble trap 6 Standard Flow Warming Sets: KVO - 150 mL/min or 9 L/hr Model 24200 Priming volume 39 mL Components cassette needle injection port bubble trap roller clamp 76 cm (0.76 m) / 30 in (2.5 ft) patient line Model 24240 Priming volume 44 mL Components cassette needleless air bubble trap aspiration port roller clamp 152 cm (1.52 m) / 60 in (5 ft) patient line Model 24250 Priming volume: 44 mL Components cassette roller clamp bubble trap 152 cm (1.52 m) / 60 in (5 ft) patient line Model 24450 (Pediatric/Neonate)Priming volume 20 mL Components Cassette needleless injection port bubble trap with air aspiration port 60 cm (0.6 m) / 24 in (2 ft) patient line 7 3MTM RangerTM Fluid Warming Accessories 3MTM RangerTM High Flow Blood/Fluid Warming Set Drip Chamber with 150 Micron Filter Model 90029 Priming volume 64 mL Components 150 micron filter made without natural rubber latex 10 warming sets/case EtO Single-use only 3MTM RangerTM Warming Unit Cleaning Tool Model 90030 Use Clean heating plates of the Ranger blood/ fluid warming unit, Model 245 and the Ranger Irrigation warming unit, Model 247 Case quantity 12 Cleaning tools/case 3MTMRangerTM Pressure Infusor System The 3MTM RangerTM pressure infusor system is designed for use with the 3MTM RangerTM blood/fluid warming unit and 3MTM RangerTM high flow warming sets. The pressure infusor system can accept 250 mL to 1000 mL fluid bags and provides maximum dynamic operating pressure of 300 mmHg. The pressure infusor system includes three separate pieces: the pressure infusor, IV pole and IV pole base. 3MTM RangerTM Pressure Infusor Model 145 For use with Dimensions Weight Case quantity Pressure infusor IV pole (model 90068) and Ranger IV pole base (model 90124) 40 L x 51 W x 20 H cm (15.75 L x 20 W x 7.75 H in) 7.7 kg (17 lbs) 1/Box 3MTM RangerTM Pressure Infusor IV Pole Model 90068 For use with Dimensions Weight Case quantity Ranger pressure infusor (model 145) and Ranger pressure infusor base (model 90124) 187 L x 11 W x 4 H cm) (73-1/2 L x 4-1/2 W x 1-3/4 H in) 2.8 kg (6.2 lb) 1/Box 3MTM RangerTM Pressure Infusor IV Pole Base Model 90124 For use with Dimensions Weight Case quantity Ranger pressure infusor (model 145) and Ranger pressure infusor IV pole (model 90068) 81 L x 76 W x 20 H cm (32 L x 30 W x 8 H in) 16.1 kg (35.5 lb) 1/Box 8 The Centers for Disease Control and Prevention (CDC) guidelines recommend against medical devices containing water in the O.R. and suggest that facilities remove potential sources of contaminated water whenever possible.3 The 3MTM RangerTM high flow blood/fluid warming sets were designed with an auto-venting bubble trap which automatically vents up to 3000 mL of air per minute � a critical feature for the high flow rates used in trauma situations. Air emboli are amongst the list of the Centers for Medicare and Medicaid Services (CMS) `never events'-those deemed reasonably preventable through proper care.4 The forward-thinking Ranger blood/fluid warming system also meets all requirements of the American Association of Blood Bank (AABB) standards for infusion of blood products.5 Eliminate more air per minute 3MTM RangerTM Blood/Fluid High Flow Warming Set, Model 24355 vs. Smiths Medical Level 1TM D-50 & D-100 mL per minute 4000 3500 3000 2500 2000 1500 1000 500 0 3000 Ranger High Flow Set Model 24355 Test data on file 400 Smiths Medical Level 1 D-50 400 Smiths Medical Level 1 D-100 References 1. Rutala WA, Weber DJ. Water as a reservoir of nosocomial pathogens. Infection Control and Hospital Epidemiology September 1997; 18: 609-616. 2. Sessler DI. Consequences and treatment of perioperative hypothermia. Anesthesia Clinics of North America 1994; 12(3): 425-56. 3. Centers for Disease Control and Prevention. Guidelines for Environmental Infection Control in Health-Care Facilities. Recommendations of CDC and Healthcare Infection Control Practices Advisory Committee (HICPAC). 2003. 4. Centers for Medicare & Medicaid Services. www.cms.gov/Newsroom/MediaReleaseDatabase/Fact-Sheets/2008-Fact-Sheets- Items/2008-08-042.html. Accessed Oct. 8, 2013. 5. American Association of Blood Banks. Standards for Blood Banks and Transfusion Services. 27th Edition; 2011 3M Health Care Infection Prevention Division 2510 Conway Avenue St. Paul, MN 55144-1000 USA Phone 1-800-228-3957 Web www.mmm.com/infectionprevention 3M, BAIR HUGGER, RANGER and the BAIR HUGGER and RANGER logos are trademarks of 3M Company, used under license in Canada. Please recycle. Printed in USA. � 3M 2015. All rights reserved. 603748B 08/15
