Thermo Pride Parts and Specification Catalog #106
Keeping You Warm Since 1946
Introduction
Thermo Pride products have been the name for high-quality, handcrafted, hometown values, and high-efficiency for 76 years. Thermo Products, LLC offers a full line of oil and gas-fired warm air furnaces, coils, and accessories.
Product specifications may change. Please refer to www.thermopride.com for the most current product specifications.
Oil Furnaces and Accessories
Oil Furnaces
Oil Furnaces - Furnace and Burner Must Be Ordered Separately
MODEL NO.
DESCRIPTION
AFUE% BECKETT/CARLIN
AFUE% RIELLO
BTU/H OUTPUT
SHIPPING WEIGHT (lbs.)
380692
TP2501 - Beckett AFG Oil Burner for 6 Series
380835
Carlin EZ-1 Oil Burner for 6 Series
380693
Riello BF3 Oil Burner for 6 Series
OH6FA072D48 / DV4 B
Low-Profile Highboy, Front Flue
86
86.1
60,000/72,000/90,000
280
OH6FA072DV4
Low-Profile Highboy, Front Flue
86
86.1
60,000/72,000/90,000
280
OL6FA072D48
Lowboy, Front Flue
86.5/86
87
60,000/72,000/90,000
315
OL6RA072D48
Lowboy, Rear Flue
86.5/86
87
60,000/72,000/90,000
315
OD6FA072D48
Counterflow/Horizontal, Front Flue
85.7/85
85.7
60,000/72,000/90,000
250
OD6RA072D48
Counterflow/Horizontal, Rear Flue
85.7/85
85.7
60,000/72,000/90,000
250
380754
TP2502 - Beckett AFG Oil Burner for 8 Series
380836
Carlin EZ-1 Oil Burner for 8 Series
380756
Riello BF3 Oil Burner for 8 Series
OH8FA119D60
Highboy, Front Flue
85.8/85
86
101,000/120,000/132,000
390
OL8FA119T60
Lowboy, Front Flue
85
85
101,000/119,000/132,000
315
OT11-105FBP
Horizontal, Front Flue, Exposed Burner
83
83
101,000
445
OT16-125FBP
Horizontal, Front Flue, Exposed Burner
83
83
125,000
500
OL20FA151T60
Lowboy, Front Flue
85
85
153,000
600
*... and many more models listed in the catalog.
Oil Furnace Accessories
Oil Accessories
DESCRIPTION
PART NO.
FURNACE or ACCESSORY MODEL
SHIPPING WT. (lbs.)
4" Clean Out Assembly (Cover, Gasket, T-Bar, Nut) - Pair
AOPS7586
OC2-5, OH2-16, OL2-39, OT5-16
2
Clean Out Plug Assembly - Each
S00S4489
OH6, OD6F, OL6, OH8, OD6R, OME
1
D6 Base
D6-BASE
OD6 Counterflow Applications Only
36
D6 Cottage Base
D6COT-BASE
OD6 Counterflow Applications Only
46
Optional Fan Timer
AOPS7433
Only used with models using a combination fan limit control
2
Combustion Air Intake Hood Kit
AOPS7402
General Application
3
Field Direct Vent Termination Kit (includes vent hood & 15' flexible vent pipe)
AOPS8393
OH6, OL6 & OD6
41
Sidewall Vent Accessory Kit for Beckett Burner*
AOPS8394
OH6, OH8, OL6, OL8 & OD6
4
Blocked Vent Switch (Canadian Applications)
350156
All Oil
2
*... and many more accessories listed.
Gas Furnaces and Accessories
Gas Furnaces
Gas Furnaces
MODEL NO.
AFUE%
MAXIMUM A/C CAPACITY (tons)
BTU/H INPUT
SHIPPING WT. (lbs.)
CLQS1-050T36N
95
3
50,000
155
CLQS1-075T42N
95
3.5
75,000
166
CLQS1-100T48N
95
4
100,000
183
CLQS1-125T60N
95
5
125,000
196
*All gas furnaces supplied as natural gas with a propane kit included.
Gas Furnace Accessories
Gas Accessories
DESCRIPTION
PART NO.
FURNACE
SHIPPING WT. (lbs.)
Concentric Vent Kit - 2"
AOPS7488
CLQS1-050, 075
11
Concentric Vent Kit - 3"
AOPS7489
CLQS1-100, 125
11
Sidewall Vent Cap
370191
CLQS1
2
LP Conversion Kit
AOPS7749
CLQS1
1
Nat. Conversion Kit
AOPS7745
CLQS1
1
Neutralizer Kit
320095
CLQS1
6
Mini Condensate Pump
AOPS7614
CLQS1
5
50CLQ Base
50CLQ-Base
CLQS1-050
15
125CLQ Base
125CLQ-Base
CCLQS1-075, 100, 125
18
Mobile Home/Cottage Furnaces and Accessories
Oil Mobile Home/Cottage Furnaces
Oil Mobile Home/Cottage Furnaces
MODEL NO.
AFUE%
BTU/H OUTPUT
SHIPPING WT. (lbs.)
OME-72D36 (with PSC blower motor and Beckett AFG Burner)
86
60,000/72,000
210
OME-72T36 (with ECM blower motor and Beckett AFG Burner)
86
60,000/72,000
210
Gas Mobile Home/Cottage Furnaces
Gas Mobile Home/Cottage Furnaces
MODEL NO.
AFUE%
BTU/H OUTPUT
SHIPPING WT. (lbs.)
GMD2-60N
81.6
50,000
185
GMD2-80N
81
65,000
185
CMA4-50D36N
95
48,000
185
CMA4-75D36N
95
72,000
185
CMC2-50D36N with PSC blower motor and integrated coil cabinet
95
48,000
220
CMC2-75D36N with PSC blower motor and integrated coil cabinet
95
72,000
220
CMC2-50DV3N with ECM blower motor and integrated coil cabinet
95
48,000
220
CMC2-75DV3N with ECM blower motor and integrated coil cabinet
95
72,000
220
Mobile Home Accessories
Mobile Home Accessories
DESCRIPTION
PART NO.
FURNACE or ACCESSORY MODEL
SHIPPING WT. (lbs)
70-Base
70-BASE
OME, GMD, CMA
25
Cottage Base
01COT-BASE
OME, GMD, CMA
35
4" Stainless Steel Vent Pipe (34" long)
VP-1
OME, GMD
6
1' Roof Jack
TRJ-1
OME, GMD
30
2' Roof Jack
TRJ-2
OME, GMD
30
3' Roof Jack
TRJ-3
OME, GMD
36
Slope Adapter for roof pitch 2-1/2"-12"
TSA-25
OME, GMD, CMA, CMC
8
Slope Adapter for roof pitch 3-1/2"-12"
TSA-30
OME, GMD, CMA, CMC
8
2" Concentric Vent Kit with 4" Adapter for 4" Roof Jack
AOPS7483
CMA, CMC
20
2" Concentric Vent Kit with 5" Adapter for 5" Roof Jack
AOPS7544
CMA, CMC
12
Dual Pipe Flashing Kit
AOPS7484
CMA, CMC
10
Combustion Air Intake Hood
AOPS7402
OME, GMD
3
Roof Jack Combustion Air Kit
AOPS7512
OME
16
Flexible Stainless Steel Offset Vent Kit
AOPS7518
OME, GMD
3
High Altitude Orifice Kit - 2001-4500 ft
AOPS7732
CMA, CMC
1
High Altitude Orifice Kit - 4501-6500 ft
AOPS7733
CMA, CMC
1
High Altitude Orifice Kit - 6501-8500 ft
AOPS7734
CMA, CMC
1
GMD1-80N Upgrade Blower Kit for 3 Ton AC
AOPS2677
GMD1-80
42
Neutralizing Kit
320095
CMA, CMC
6
Mini Condensate Pump
AOPS7614
CMA, CMC
3
Transition Boot with Screen
AOPS8419
OME, GMD
6
Air Conditioning Evaporator Coils and Cabinets
Thermo Pride Color-Matched Cased Coils for Upflow Furnaces
AC Evaporator Coils and Cabinets
CASED COIL MODEL NO.
CABINET DIM. W X D X H (in.)
PLENUM OPENING W X D (in.)
SHIPPING WEIGHT (lbs.)
HE33936PA212
21.25 X 21.25 X 19
19.8 X 19.8
50
HE47936PA212
21.25 X 21.25 X 29
19.8 X 19.8
72
HE50960PA212
21.25 X 21.25 X 29
19.8 X 19.8
72
Downflow Cabinet Applications
CABINET NO.
FURNACE APPLICATION
CABINET DIMENSIONS W X D X H (in.)
Uncased Coil Part No. (See Uncased Coil Pricing Below)
SHIPPING WEIGHT (lbs.)
CE112S
OD6 Downflow
20 X 30 X 18
HE33936UA170
36
CE312T
OD6 Downflow
23.25 X 30 X 29.5
HE47936UA205 HE50960UA205
48
CE215T
CLQS1-050
17.75 X 27.8 X 18.5
HE33936UA170 HE33936UA200
30
CE216T
CLQS1-075, 100, 125
21.25 X 27.8 X 28.5
HE50960UA205 HE47936UA205
42
CE217T
CLQS1-125
24.75 X 27.8 X 28.5
HE33936UA200 HE50960UA205 HE47936UA205
44
Mobile Home Cabinet Applications
CABINET NO.
FURNACE APPLICATION
CABINET DIMENSIONS W X D X H (in.)
Uncased Coil Part No. (See Uncased Coil Pricing Below)
SHIPPING WEIGHT (lbs.)
CE111S
OME, GMD, CMA
18.75 X 24.75 X 20
HE33936UA170
35
Uncased Coils
UNCASED COIL MODEL NO.
TONS
DIMENSIONS W X D X H (in.)
SHIPPING WEIGHT (lbs.)
HE33936UA170
2 to 3
17 X 19.5 X 17
32
HE33936UA200
2 to 3
20 X 19.5 X 17
32
HE47936UA205
2 to 3
20.5 X 19.5 X 27
50
HE50960UA205
3.5 to 5.0
20.5 X 19.5 X 27
50
Note: All Thermo Pride coils are made by ADP and use the same model numbers that match with many other condenser manufacturers. Please visit www.ahridirectory.org to match a Thermo Pride coil with one of those many condensers.
Air Handlers
Air Handlers with Optional Hydronic Heating Coils
The Thermo Pride air handlers are designed to be used as a stand-alone cooling, stand-alone heating or combination heating and cooling air handler. The air handlers can be installed in an upflow or horizontal application. The cooling coil comes factory installed. In heating mode, the air handler provides up to 70° temperature rise (at 180°F entering water temperature), which provides warmer air than many air handlers on the market. All units operate on 115V and coils use 410A refrigerant.
The air handler requires little maintenance and provides efficiency, longevity, and worry-free comfort. It also comes with our standard 10-year coil and 5-year parts warranty.
