Smart IOT Gateway - images-na.ssl-images-amazon.com
Dual row, 4 circuits C Dimension (115 x 105 x 45mm) Weight 304g 294g 294g 282g Mounting, Bulkhead, 4x M4 holes, DINrail with adapter - mentals Operating temperature -30C to 70C -30C to 70C -30C to 70C -30C to 70C Storag…
• HSPA: 14.4 Mbps (Cat 10) down 5.76 (Cat 6) up Not included Rx Diversity Simultaneous Equalization and Rx Diversity on all bands Simultaneous Equalization and
Full PDF Document
If the inline viewer fails, it will open the original document in compatibility mode automatically. You can also open the file directly.
Extracted Text
Smart IOT Gateway � Transports & Logistics � Industrial & Remote Asset Monitoring � Smart Cities & Environmental Monitoring CloudGate MODELS LTE WW CG LTE US rev 3 3G EMEA rev 3 Ethernet 2.0 WWAN Modem LTE WWAN Modem 700/800/850/900/1800/1900/2100/ Supported frequency bands 2600/AWS (B 1-5, 7, 8, 13, 17, 18, 19, 20) Max. connectivity speeds 100Mbps down, 50Mbps up (Cat3) Theoretical LTE data rates � UMTS/HSDPA/HSUPA/HSPA+: 850/900/1900/2100 MHz and AWS band (1700/2100 MHz) Supported frequency bands (B 1, 2, 4, 5, 8) � GSM/GPRS/EDGE: 850/900/1800/1900 MHz LTE FDD: 700/850/1900/AWS (B2/B4/B5/B13/B17) 100Mbps Down, 50Mbps Up (Cat3) � UMTS/HSDPA/HSUPA/HSPA+: 850/1900/AWS (B2/B4/B5) � GSM/GPRS/EDGE: 850/900/1800/1900 Mhz Not applicable � UMTS/HSDPA/HSUPA/HSPA+: 900-2100 MHz (B1, 8) � GSM/GPRS/EDGE: 900/1900 MHz Not included 3G/2G � DC-HSPA+: 42 Mbps (Cat 24) down Max. connectivity speeds 5.76 (Cat 6) up � DC-HSDPA: 42Mbps (Cat24) down, 5.76Mbps (Cat6) Up � HSPA+: 14.4 Mbps (Cat 10) down 5.76 (Cat 6) up Not included WWAN Antenna GPS Rx Diversity Antenna connector Simultaneous Equalization and Rx Diversity on all bands � 1 x SMA: WWAN Main � 1 x SMA: WWAN Div/GPS � High sensitivity A-GPS /A-GLONASS receiver (SUPL 1.0 & SUPL 2.0) � Active GPS antenna support SIM CPU Ethernet (IEEE 802.3) microSD card holder USIM/SIM connection � Class B and Class C 10/100Mb/s RJ45 Connector ARM926EJ-S @ 450 MHz Memory available for customer apps 512MB Flash (available : 20MB for data, 30MB for application, 372MB extra data partition) 128MB RAM (available : 85 MB) Timed Wakeup Power control Ignition Sensing DC Power in, 9-33 V DC Power Connector type Micro-Fit, Dual row, 4 circuits Dimension (115 x 105 x 45mm) Case Weight 304g Mounting, Bulkhead, 4x M4 holes, DINrail with adapter Operating temperature -30�C to +70�C Environmentals Storage temperature Humidity operational.: 5% - 95% -40�C to +70�C 5% - 95% Certifications CE, FCC, IC, PTCRB, E-mark, EN50155, AT&T, T-Mobile, Verizon, Latam, Australia, Singapore Std. compliance ROHS, Reach CloudGate Universe Device can be configured OTA using CloudGate Universe Expansion cards 2 x expansion slots for adding cards Support CloudGate For developers development kit: Developer board, Breadboard, SDK, HDK In the box Accessories are available (i.e. Power cable, antenna's etc.) CloudGate Gateway Product Code CG0114-12019 Simultaneous Equalization and Rx Diversity on all bands � 1 x SMA: WWAN Main � 1 x SMA: WWAN Mimo/Div/GPS � Standalone GPS, Assisted GPS, GPS OneXTRATM � Wideband GPS processing (20MHz) for improved measurement accuracy � Passive/active GPS antenna support Simultaneous Equalization and Rx Diversity on all bands � 1 x SMA: WWAN Main � 1 x SMA: WWAN Div/GPS � Standalone GPS, Assisted GPS, GPS OneXTRATM � Wideband GPS processing (20MHz) for improved measurement accuracy � Passive/active GPS antenna support Not included Not included Not included Not applicable ARM926EJ-S @ 450 MHz Memory available for customer apps 512MB Flash (available : 20MB for data, 30MB for application, 372MB extra data partition) 128MB RAM (available : 85 MB) ARM926EJ-S @ 450 MHz Memory available for customer apps 512MB Flash (available : 20MB for data, 30MB for application, 372MB extra data partition) 128MB RAM (available : 85 MB) ARM926EJ-S @ 450 MHz Memory available for customer apps 512MB Flash (available : 20MB for data, 30MB for application, 384MB extra data partition) 128MB RAM (available : 85 MB) Not included Not included Optional � Timed wake-up possible with RTC and Cortex M0 in sleep mode � Remote modem wake-up � Timed wake-up possible with RTC and Cortex M0 in sleep mode � Remote modem wake-up � Timed wake-up possible with RTC and Cortex M0 in sleep mode 294g 294g 282g -30�C to +70�C -40�C to +70�C -30�C to +70�C -40�C to +70�C -30�C to +70�C -40�C to +70�C 5% - 95% 5% - 95% 5% - 95% FCC, IC, AT&T, T-Mobile, Verizon CE, TRA, E-mark, RCM CE, FCC, IC CloudGate Gateway CG0199-12102 CloudGate Gateway CG118-12043 CloudGate Gateway C102-11972 CloudGate ACCESSORIES 1008855 3g/LTE antenna (Grandtek) 1008379 WiFi antenna (Taoglass) 1009568 External antenna LTE/GPS A/WiFi AP 1533-b 0,4m 1009607 External antenna LTE/GPS A/WiFi AP 1533-b 1,5m 1009608 External antenna LTE/GPS A/WiFi AP 1533-b 3m 1008098 868/900 MHz antenna (Pulse) 1008891 UK interchangeable plug for power supply 1008607 DC power cable with microfit connector 1009077 AU interchangeable plug for power supply 3m (3-wire) CG7101-12018 Telematics IO break-out board and cable 1009120 AC power supply 12V/1.5A class 6 1008837 Telematics card IO connector (9x2) and cable with microfit connector 1.5m 1008836 Precrimped cables for Telematiccs card IO (interchangeable blades) connector (300mm, 20 AWG) 1008890 US interchangeable plug for power supply 1008889 EU interchangeable plug for power supply CloudGate E XPANSION CARDS STANDARD CARDS Front slot Back slot NON-STANDARD Front slot STANDARD SERIAL CARD CG1101-11919 � One RS-232 serial port 921,6 Kbaud maximum speed INDUSTRIAL SERIAL CARD CG1102-11920 � One RS-232 serial port 921,6 Kbaud maximum speed � One 2KV isolated RS-485 serial port 921,6 Kbaud maximum speed, full duplex or half duplex, 2 wire or 4 wire. Switchable termination. ETHERNET EXPANSION CARD CG1104-11936 � 4-port 10/100 Base-T, �SD card holder DEVELOPER CARD for SW developer CG1105-11937 � Extended format card for with headers for all interfaces. � Includes headers for access to USB, USB on the go, RS-232, I2C, SPI/SD and GPIO lines. � On board temperature sensor, relay, SD card slot and RS232 serial port. BLE Bluetooth Low Energy CARD CG1119-12096 � Bluetooth 4.2 LE � Nordic Semiconductor nRF52 chipset � Multiprotocol radio allows other protocol stacks as well � OTA-DFU (Over-The-Air Device Firmware Update) capable � Connect (i)Beacons to your CloudGate for RTLS applications TELEMATICS CARD - extended IO & CAN CG5106-11984 � Adds flexible IO and RS232/ RS485/USB/CAN connectivity for industrial and telematics applications to CloudGate � Built-in 3 axis accelometer for movement detection and other applications � Additional SIM card slot for backup roaming SIM � Built-in microcontroller offloads all IO from CloudGate � Breakout card (CG7101-12018) available for developers BREADBOARD CARD for HW developer CG1108-11980 � Ideal for prototyping your own expansion card. � Supports 3 types of connections: � All signals on the back connector can be tapped off on breadboard area near this connector � 2.54 mm pitch components can be soldered on main breadboard area � 3.5 mm pitch connectors can be soldered on two front rows to provide a more reliable and longterm connection LoRaWAN CARD CG2118-12078 (868 MHz) CG2119-12091 (915 MHz) CG2121-12098 (433 MHz) � Available for 433 MHz, 868 MHz and 915 MHz LoRa devices � Connects LoRa sensors/actuators to private & public LoRa � networks � Optionally combined with WLAN connectivity WLAN CARD Client & Access point CG2101-11921 � 802.11 a/b/g/n � Access point up to 10 simultaneous users CG1109-11991 � Ethernet card - 1 port CG1103-11935 � Ethernet card - 4 port with PoE CG1106-11957 � Telematics card CG5106-11983 � Telematics card with extended IO CG5106-12052 � Telematics card with extended IO (4-port current loop) CG5106-12039 � Telematics card with extended IO and CAN (4-port current loop) CG1110-12012 � KNX card CG5221-12023 � KNX bus with RS485 expander and P1 CG1121-12080 � Xbee card CG1118-12064 � Smartcity card CG1120-12079 � M-bus slave - wM-bus card Back slot MONNIT� CARD CG2111-12049 (868 MHz) CG2112-12050 (900 MHz) CG2113-12054 (433 MHz) � Available for 433 MHz, 868 MHz and 900 MHz Monnit devices � Connects up to 100 Monnit sensors CG2102-11994 � WXLAN access point card CG2103-12047 � Monnit� card with WLAN (868 MHz) CG2104-12048 � Monnit� card with WLAN (900 MHz) CG2105-12053 � Monnit� card with WLAN (433 MHz) CG2117-12065 � Xbee card CG2120-12090 � Smart Metering card PARTNER CARDS � AiriCOM - Industrial grade IO card � ATIM - LoRa card � BiPOM - nano-WiPom card � BiPOM -2-RS232 & USB card � BiPOM - 4-port USB card Front slot � BiPOM - SiFlex card � BiPOM - Multiwireless card � BiPOM - Monnit card � BoilerConnect - GPIO card � Foxon � IQRF card � Giga Concept - RFID card � Paksense - Temperature sensing card � USRobotics - Modemulator card Back slot � 5A - MicroSD holder card CloudGate APPLICATIONS CloudGate UNIVERSE Award-winning visually configurable CloudGate application for design and deployment of smart IoT solutions delivering true IoT edge computing. Key features: � `Drag & drop and visual wiring' configuartion environment for Cloudgate devices � `Drag and drop' and visual wiring configuration with minimal programming � Rapid application development in only minutes � Supports a wide variety of sensors aka `node sets' � Reduces risk/lowers development cost � Shorter sales cycles � Drives innovation by enabling `risktaking' Provides Secure Remote Access from your laptop/smartphone to your CloudGate gateways and the devices attached to it. VPN tunnel is set-up from the CloudGate gateway to the SRAS server and from your computer to the SRAS server, creating a secure end-to-end connection Benefits: � CloudGate gateway can create VPN tunnels upon request without the need for a permanent VPN tunnel thus reducing the data traffic associated with secure remote access � VPN tunnel leverages built-in VPN clients of major OS suppliers and device manufacturers making life cycle management easier, robust & cost effective � Self provisioning and support for bulk device provisioning via webbased UI � Fully qualified domain names used to obtain access to the device � Multi-tier support - device access based on permissions With CloudGate Universe Option supports its partners by providing the easiest and most cost effective deployment mechanism for their software solutions. A provisioning system dedicated to delivering Option and third party software and product configuration to CloudGate gateways. CloudGate Universe is part of the CloudGate solution with no registraton cost or yearly fees and no competition with system integrator or software developer services and products. Configure just one, some or all your devices for a particular site, application or customer and configure all your devices to the same device setting. www.cloudgateuniverse.com Smart IOT Gateway Option Wireless Technology's CloudGate is the carrierapproved IoT solution platform that delivers device connectivity, security and processing power for global IoT applications. It includes the world wide carrier-approved intelligent Cloudgate gateway that comes with CloudGate Universe, Option's cloud-based configuration and deployment platform, as well as the CloudGate SDK for rapid application development, the CloudGate HDK for prototyping custom expansion cards and award-winning LuvitRed, a visually configurable device agent with easy-to-use graphical, "drag and drop &visual wiring " configuration. LuvitRed overcomes complexities of the vast variety of protocols used in different IoT verticals and delivers true IoT Edge Computing capabilities on Cloudgate in an easy way. A pre-built library of software applications and modular hardware extensions ensure ease of deployment and maximum flexibility. Only Option delivers a complete M2M ecosystem. CUSTOMER DEVICE BLE LoRa Wi-Fi Other Ethernet RS232/RS485 Analog/Digital I/O USB M-Bus Other Customer Software SOFTWARE � IPSec/VPN � Provisioning �Connection persistence Firmware �Remote login � Dyn DNS � Firewall Ethernet 3G with GPS LTE with GPS HARDWARE Primary expansion board Secondary expansion board THIRD-PARTY APPLICATIONS LTE/3G Wi-Fi Ethernet with fallback mechanism INTERNET option.com DataSheet_v1.5.4t As part of the continual product improvement process, OPTION reserves the right to alter the specifications of this product. � 2017 OPTION. Option and the Option logo are registered trademarks of OPTION. All third-party trademarks are the property of the respective owners. Option nv - Gaston Geenslaan 14 - 3001 Leuven Belgium - T +32 16 317 411 - F +32 16 207 164 - www.option.com 1. Select a CloudGate model with expansion cards and/or accessories to suit your needs 2. Configure CloudGate Universe, the provisioning server 3. ...and start to CONNECT THINGS to the Cloud
