LG Single-Zone Four-Way Ceiling-Cassette System Engineering Manual

Explore LG's advanced Single-Zone Four-Way Ceiling-Cassette Heat Pump Systems, engineered for optimal climate control across a range of capacities from 3/4 to 3-1/2 Tons. This comprehensive engineering manual provides detailed technical specifications, performance data, and installation guidance for professionals.

System Overview and Models

The manual covers key models including:

Indoor Units: LC098HV4, LC128HV4, LC188HV4, LC248HV, LC368HV, LC428HV
Outdoor Units: Corresponding LUU series outdoor units.

It details crucial aspects such as electrical connections, refrigerant flow, and unit dimensions, supported by the LG Air Conditioner Technical Solution (LATS) software for design and validation.

Resources and Support

Discover detailed placement considerations, piping designs, and performance correction factors. For further technical documentation and resources, visit:

LG HVAC Official Website

Models: Single-Zone Four-Way Ceiling-Cassette Heat Pump Systems, LC098HV4, LC128HV4, LC188HV4, LC248HV, LC368HV, LC428HV
