RP-D1237
DAVISJR
144988743 REPAIR PARTS
DBC 6 Ton Belt Drive Commercial Package Cooling Unit
DBC0723V000001SAA DBC0724V000001SAA DBC0727V000001SAA
© 2009 Goodman M
Houston, TX 77056
This manual is to be used by qualified technicians only.
RP-D1237
© 2020
www.daikinac.com
19001 Kermier Rd. Waller, TX 77484
March 2020
Important Information Index
Functional Parts List Illustration and Parts
................................................................................................... ...................................................................................................
Views shown are for parts illustrations only, not servicing procedures
3 4 - 15
Text Codes:
AR - As Required
NA - Not Available
NS - Not Shown
00000000 - See Note
QTY - Quantity Example (QTY 3) (If Quantity not shown, Quantity = 1)
M - Model
Example (M1) (If M Code not shown, then part is used on all Models)
Expanded Model Nomenclature:
Example M1 - Model#1 M2 - Model#2 M3 - Model#3
Daikin Company, L.P. is not responsible for personal injury or property damage resulting from improper service. Review all service information before beginning repairs.
Warranty service must be performed by an authorized technician, using authorized factory parts. If service is required after the warranty expires, Daikin Company, L.P. also recommends contacting an authorized technician and using authorized factory parts.
Daikin Company, L.P. reserves the right to discontinue, or change at any time, specifications or designs without notice or without incurring obligations.
For assistance within the U.S.A. contact:
Equipment Support Daikin North America, LLC 19001 Kermier Road Waller, Texas 77484 855-770-5678-Telephone 713-863-2382-Facsimile
For assistance outside the U.S.A. contact: International Division GDaoiokdinmNaonrCthoAmmpearnicya, ,LL.PL.C 71490101SKeceurmritiyerWRaoyad HWoaullsetro,nT,eTxeaxsa7s774780440 713-861-2500-Telephone 713-863-2382-Facsimile
2
www.daikinac.com
RP-D1237
Functional Parts
Part
No:
Description:
B1368056 CAP100000440LA CAP100000370LA CAP050000440LA ZPS60K5ETFD130 ZPS60K5ETF5130 ZPS60K5ETFE130 CONT3P025024V CONT3P030024V 0130M00178 B1086765 0130M00280 0130M00087 0131L00041 0131L00043 0131L00042 0131M00430 0131M00774 0131M00858 PCBFM103 0130M00038 B1370772 0130M00598 0130M00595 B1141654
BLOWER WHEEL CAP 10 MFD/440V/OVAL (M2) CAP, 10 MFD/370V/OVAL (M1) CAPACITOR (M3) COMP, 60900, 460/60/3 2 STAGE (M2) COMP, 61000, 200/230/60/3 2 ST (M1) COMP, 61000, 575/60/3 2 STAGE (M3) CONT, 3 POLE, 25 AMP, 24 VAC (QTY 2) CONT, 3 POLE, 30 AMP, 24 VAC (M1) DPDT RELAY 24VAC (QTY 2) FAN BLADE, TYPE 3 HIGH PRESSURE SWITCH LOW PRESSURE SWITCH MOTOR 2 HP BELT DRIVE 208-230V (M1) MOTOR 2HP BELT DRIVE 460V (M2) MOTOR 2HP BELT DRIVE 575V (M3) MOTOR, 1/3 HP, 1 SP, 6 PL (M1) MOTOR, 1/3 HP, OD (M2) MOTOR, 1/3 HP, OD (M3) PCB, TIME DELAY, EBTDR TERMINAL BOARD TIME DEALY (ICM) 180 SEC DELA TRANSFMR, 75VA, 575V TO 24V (M3) TRANSFORMER, 75VA, 480V TO 24V (M2) TRANSFORMER,208-240,75VA,RESET (M1)
SPECIAL PARTS
RP-FIOPSC*
ACCESSORY RP MANUAL
Expanded Model Nomenclature
M1 - DBC0723V000001SAA M2 - DBC0724V000001SAA M3 - DBC0727V000001SAA
RP-D1237
www.goodmanmfg.com
www.amana-hac.com
3
CABINET ASSEMBLY
4
www.goodmanmfg.com
www.amana-hac.com
RP-D1237
CABINET ASSEMBLY
Ref. Part No: No:
Description:
Image 1:
51 0121L01650SB
PAINTED FILTER PANEL
61 0121L01651SB
PAINTED ECON OMIZER PANEL
71 0121L02264SB
PAINTED BLOW ER PANEL
91 0121L02265SB
PAINTED COMPRESSOR PANEL
101 0121L02262SB
PAINTED CONTROL BOX PANEL
111 0121L03643SB
PAINTED, COMPRESSOR BACK PANEL
221 0121L02910SB
PAINTED COVER-DUCT RETURN
231 0121L02911SB
PAINTED COVER-DUCT SUPPLY
251 0121L03346SB
PAINTED, DUCT PANEL
Expande d M ode l Nom e nclature
M1 - DBC0723V000001SAA M2 - DBC0724V000001SAA M3 - DBC0727V000001SAA
Ref. Part No: No:
Description:
RP-D1237
w w w .goodmanmfg.co w w w .amana-hac.com
5
TOP PANEL AND TUBING ASSEMBLY
6
www.goodmanmfg.com
www.amana-hac.com
RP-D1237
TOP PANEL AND TUBING ASSEMBLY
Ref. Part No: No:
Description:
Image 1:
11 0121L01626SB
PAINTED, TOP PANEL
21 0131M00430
MOTOR, 1/3 HP, 1 SP, 6 PL (M1)
21 0131M00774
MOTOR, 1/3 HP, OD (M2)
21 0131M00858
MOTOR, 1/3 HP, OD (M3)
31 0163M00006P
ACORN NUT 5/16 HEX BLACK (QTY 4)
41 0152G00000
FAN GRILLE, R AISED
51 0161R00003P
CONDUIT
61 B1086765
FAN BLADE, TY PE 3
71 0161R00048
MOLDED RING-VENTURI 22
81 0163M00004
SCREW #10X3/4", BLACK (QTY 8)
111 0130M00087
LOW PRESSUR E SWITCH
121 20485201
FILTER/DRIER- BI-FLOW
131 0130M00280
HIGH PRESSUR E SWITCH
141 0121L01620
SMALL SIDE RAIL (QTY 2)
151 0121L01621
SMALL END RAIL (QTY 2)
191 0121L01634
OD COIL BLOCKOFF
201 0201L00323
ASSY., OD COI L TUBING
211 0202L00423
ASSY., EVAP TU BING
301 B1339533
COMPRESSOR GROMMET (QTY 4)
311 B1393740
COMP. BOLT & SLEEVE (QTY 4)
321 ZPS60K5ETFD130 COMP, 60900, 460/60/3 2 STAGE (M2)
321 ZPS60K5ETF5130 COMP, 61000, 200/230/60/3 2 ST (M1)
321 ZPS60K5ETFE130 COMP, 61000, 575/60/3 2 STAGE (M3)
331 0159L00065
Harness, comp s croll
341 0159G00010
CABLE, COMPR SCROLL
NS 0141L00003X
BOARD-FORK (QTY 3)
NS 0121L03516
PNL, BRACKET, FORK BOARD (QTY 4)
NS 0163M00005P
WASHER, BLAC K (.50 OD .218ID) (QTY 4)
Expande d M ode l Nom e nclature
M1 - DBC0723V000001SAA M2 - DBC0724V000001SAA M3 - DBC0727V000001SAA
Ref. Part No: No:
Description:
RP-D1237
w w w .goodmanmfg.co w w w .amana-hac.com
7
PARTITION ASSEMBLY
8
www.goodmanmfg.com
www.amana-hac.com
RP-D1237
PARTITION ASSEMBLY
Ref. Part No: No:
Description:
Image 1:
11 0121L02584
BLOWER DECK SIDE
21 0121L03869
BLOWER DECK
31 0121L02986
HEAT KIT BOX
41 0121L00144
COVER-ELECTR IC HEAT
61 0121L01709
BLOWER DECK PLATE
91 B1392147
UNIVERSIAL BU SHING WITH SLICE (QTY 2)
121 0121L00321
COVER-SMOKE DETECTOR (QTY 2)
331 0121L01628
DRAINPAN SUPPORT
341 0161L00007
DRAIN PAN, EVAPORATOR 3-5 TON
351 0163L00071
PLUG, DRAIN
371 0154L00180
GASKET, DRAIN PAN
401 0121L02698SB
PAINTED SIDE POST
481 0121L01625SB
PAINTED CORN ER POST (QTY 2)
491 0121L03445SB
PAINTED, SIDE POST
NS 0160L00173
AIR FILTER 14X20X2 (QTY 2)
NS A4568804
GROMMET-D
NS 0164G00005
GROMMET-HOR SESHOW 1.675
NS 0121L02260
OD COIL BLOCKOFF ANGLE
NS 0121L03515
RETAINER - ELECTRIC HEAT
Expande d M ode l Nom e nclature
M1 - DBC0723V000001SAA M2 - DBC0724V000001SAA M3 - DBC0727V000001SAA
Ref. Part No: No:
Description:
RP-D1237
w w w .goodmanmfg.co w w w .amana-hac.com
9
BLOWER ASSEMBLY
10
www.goodmanmfg.com
www.amana-hac.com
RP-D1237
BLOWER ASSEMBLY
Ref. Part No: No:
Description:
Image 1:
21 0121L00297
ANGLE-BLOWER SLIDE
61 B1393738
BOLT, 1/4-20X3/ 4 (QTY 5)
71 B1392918
WASHER, FLAT 1/4IDX1OD (QTY 4)
81 0163L00276
SHEAVE, FIXED AK56H
91 B2120014
VARIABLE PITC H SHEAVE1VL44/7/8
101 0163M00407
MACHINE KEY, SPECIAL
111 0164L00000
FAN BELT, NOTCHED AX51
161 B1393726
ELECT CONNEC TING BUSHING
231 0131L00041
MOTOR 2 HP BELT DRIVE 208-230V (M1)
231 0131L00043
MOTOR 2HP BELT DRIVE 460V (M2)
231 0131L00042
MOTOR 2HP BELT DRIVE 575V (M3)
241 0121L03915
MOTOR BASE
261 3225000F
ANGLE, BELT TI GHTENER
271 0163M00045
BOLT 1/4-20X4
301 B1368056
BLOWER WHEEL
321 B1398603
STEEL KEY 4.5"
351 0163L00247
BEARING BALL, MOUNTED (QTY 2)
361 0163L00005
SHAFT-BLOWER BELT DRIVE
371 B3201300
MOUNTING BRACKET BEARING (QTY 2)
381 1864703
BLOWER CUT-OFF ASM,5TON,MORRIS
391 2539302F
BLWR SHL ASSM 11X10 1X10
NS 0121L03918
ANGLE-BLOWER MOUNT
NS 0121L02974
BLOWER SLIDE PLAE
NS 0121L00050
BRACET-BLOWR E MTG
NS 0163L00131
BUSHING 1"
NS B1446707
SCREW 5/16-18X1 (QTY 6)
NS B1392923
WASHER/FLAT (QTY 6)
Expande d M ode l Nom e nclature
M1 - DBC0723V000001SAA M2 - DBC0724V000001SAA M3 - DBC0727V000001SAA
Ref. Part No: No:
Description:
RP-D1237
w w w .goodmanmfg.co w w w .amana-hac.com
11
CONTROL BOX ASSEMBLY
12
www.goodmanmfg.com
www.amana-hac.com
RP-D1237
CONTROL BOX ASSEM BLY
Ref. Part No: No:
Description:
Image 1:
41 0130M00178
DPDT RELAY 24VAC (QTY 2)
61 802007090
TERM BOARD
81 0130M00038
TERMINAL BOARD
91 0130M00598
TRANSFMR, 75VA, 575V TO 24V (M3)
91 0130M00595
TRANSFORMER , 75VA, 480V TO 24V (M2)
91 B1141654
TRANSFORMER ,208-240,75VA,RESET (M1)
111 0130M00509
BLOCK-POWER
161 CAP100000440LA CAP 10 MFD/440V/OVAL (M2)
161 CAP100000370LA CAP, 10 MFD/370V/OVAL (M1)
161 CAP050000440LA CAPACITOR (M3)
171 CONT3P025024V CONT, 3 POLE, 25 AMP, 24 VAC (M2, M3)
171 CONT3P030024V CONT, 3 POLE, 30 AMP, 24 VAC (M1)
191 CONT3P025024V CONT, 3 POLE, 25 AMP, 24 VAC (QTY 2)
271 B1370772
TIME DEALY (IC M) 180 SEC DELA
281 PCBFM103
PCB, TIME DELAY, EBTDR
NS B821700
BOOT, CAPACITOR
NS 20520901
STRAP-CAPACI TOR
Expande d M ode l Nom e nclature
M1 - DBC0723V000001SAA M2 - DBC0724V000001SAA M3 - DBC0727V000001SAA
Ref. Part No: No:
Description:
RP-D1237
w w w .goodmanmfg.co w w w .amana-hac.com
13
ACCESSORY PARTS
14
www.goodmanmfg.com
www.amana-hac.com
RP-D1237
ACCESSORY PARTS
Ref. Part No: No:
Description:
Image 1:
NS RP-FIOPSC*
ACCESSORY R P MANUAL
Expande d M ode l Nom e nclature
M1 - DBC0723V000001SAA M2 - DBC0724V000001SAA M3 - DBC0727V000001SAA
Ref. Part No: No:
Description:
RP-D1237
w w w .goodmanmfg.co w w w .amana-hac.com
15
