Keysight X-Series MXE EMI Receiver N9038B Specification Guide
1 Keysight MXE EMI Receiver
This chapter contains the specifications for the EMI receiver. The specifications and characteristics for the measurement applications and options are covered in the chapters that follow.
11
Keysight MXE EMI Receiver Definitions and Requirements
Definitions and Requirements
This book contains EMC receiver specifications and supplemental information. The distinction among specifications, typical performance, and nominal values are described as follows.
Definitions
� Specifications describe the performance of parameters covered by the product warranty (temperature = 5� to 50�C, unless otherwise noted).
� 95th percentile values indicate the breadth of the population (2) of performance tolerances expected to be met in 95% of the cases with a 95% confidence, for any ambient temperature in the range of 20 to 30�C. In addition to the statistical observations of a sample of instruments, these values include the effects of the uncertainties of external calibration references. These values are not warranted. These values are updated occasionally if a significant change in the statistically observed behavior of production instruments is observed.
� Typical describes additional product performance information that is not covered by the product warranty. It is performance beyond specification that 80% of the units exhibit with a 95% confidence level over the temperature range 20 to 30�C. Typical performance does not include measurement uncertainty.
� Nominal values indicate expected performance, or describe product performance that is useful in the application of the product, but is not covered by the product warranty.
Conditions Required to Meet Specifications
The following conditions must be met for the receiver to meet its specifications. � The receiver is within its calibration cycle. See the General section of this
chapter. � Under auto couple control, except that Auto Sweep Time Rules = Accy. � For signal frequencies <10 MHz, DC coupling applied. � Any receiver that has been stored at a temperature range inside the allowed
storage range but outside the allowed operating range must be stored at an ambient temperature within the allowed operating range for at least two hours before being turned on. � The receiver has been turned on at least 30 minutes with Auto Align set to Normal, or if Auto Align is set to Off or Partial, alignments must have been run recently enough to prevent an Alert message. If the Alert condition is changed from "Time and Temperature" to one of the disabled duration choices, the receiver may fail to meet specifications without informing the user. If Auto Align is set to Light, performance is not warranted, and nominal performance will degrade to become a factor of 1.4 wider for any specification subject to alignment, such as amplitude tolerances.
12
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Definitions and Requirements
Certification
Keysight Technologies certifies that this product met its published specifications at the time of shipment from the factory. Keysight Technologies further certifies that its calibration measurements are traceable to the International System of Units (SI) via national metrology institutes (www.keysight.com/find/NMI) that are signatories to the CIPM Mutual Recognition Arrangement.
Keysight N9038B MXE Specification Guide
13
Keysight MXE EMI Receiver Frequency and Time
Frequency and Time
Description Frequency Range Maximum Frequency RF Input 1 Option 503 Option 508 Option 526 Option 544
Specifications
3.6 GHz 8.4 GHz 26.5 GHz 44 GHz
Supplemental Information
RF Input 2 Minimum Frequency RF Preselector Off Preamp Off Preamp On RF Preselector On Preamp Off Preamp On
1.0 GHz
AC Coupleda 10 MHz 10 MHz AC Coupleda 10 MHz 10 MHz
DC Coupled 20 Hz 100 kHz DC Coupled 20 Hz 1 kHz
Band
Harmonic Mixing Mode
LO Multiple (Nb)
Band Overlapsc
0 (20 Hz to 3.6 GHz)
1-
1
Options 503, 508, 526, 544
1 (3.5 GHz to 8.4 GHz)
1-
1
Options 508, 526, 544
2 (8.3 GHz to 13.6 GHz)
1-
2
Options 526, 544
3 (13.5 to 17.1 GHz)
2-
2
Option 526, 544
4 (17.0 to 26.5 GHz)
2-
4
Option 526, 544
5 (26.4 to 34.5 GHz)
2-
4
Option 544
6 (34.4 to 44 GHz)
4-
8
Option 544
a. AC Coupled only applicable to Freq Options 503, 508 and 526. b. N is the LO multiplication factor. For negative mixing modes (as indicated by the "-" in the "Harmonic Mixing
Mode" column), the desired 1st LO harmonic is higher than the tuned frequency by the 1st IF (5.1225 GHz for band 0, 322.5 MHz for all other bands).
14
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Frequency and Time
c. In the band overlap regions, for example, 3.5 to 3.6 GHz, the receiver may use either band for measurements, in this example Band 0 or Band 1. The receiver gives preference to the band with the better overall specifications (which is the lower numbered band for all frequencies below 26 GHz), but will choose the other band if doing so is necessary to achieve a sweep having minimum band crossings. For example, with CF = 3.58 GHz, with a span of 40 MHz or less, the receiver uses Band 0, because the stop frequency is 3.6 GHz or less, allowing a span without band crossings in the preferred band. If the span is between 40 and 160 MHz, the receiver uses Band 1, because the start frequency is above 3.5 GHz, allowing the sweep to be done without a band crossing in Band 1, though the stop frequency is above 3.6 GHz, preventing a Band 0 sweep without band crossing. With a span greater than 160 MHz, a band crossing will be required: the receiver scans up to 3.6 GHz in Band 0; then executes a band crossing and continues the sweep in Band 1. Specifications are given separately for each band in the band overlap regions. One of these specifications is for the preferred band, and one for the alternate band. Continuing with the example from the previous paragraph (3.58 GHz), the preferred band is band 0 (indicated as frequencies under 3.6 GHz) and the alternate band is band 1 (3.5 to 8.4 GHz). The specifications for the preferred band are warranted. The specifications for the alternate band are not warranted in the band overlap region, but performance is nominally the same as those warranted specifications in the rest of the band. Again, in this example, consider a signal at 3.58 GHz. If the sweep has been configured so that the signal at 3.58 GHz is measured in Band 1, the analysis behavior is nominally as stated in the Band 1 specification line (3.5 to 8.4 GHz) but is not warranted. If warranted performance is necessary for this signal, the sweep should be reconfigured so that analysis occurs in Band 0. Another way to express this situation in this example Band 0/Band 1 crossing is this: The specifications given in the "Specifications" column which are described as "3.5 to 8.4 GHz" represent nominal performance from 3.5 to 3.6 GHz, and warranted performance from 3.6 to 8.4 GHz.
Keysight N9038B MXE Specification Guide
15
Keysight MXE EMI Receiver Frequency and Time
Description Standard Frequency Reference Accuracy
Temperature Stability 20 to 30�C Full temperature range
Aging Rate Achievable Initial Calibration Accuracy Settability Residual FM
(Center Frequency = 1 GHz 10 Hz RBW, 10 Hz VBW) Precision Frequency Reference Accuracy
Temperature Stability 20 to 30�C Full temperature range
Aging Rate Total Aging
1 Year 2 Years Settability Warm-up and Retraced 300 s after turn on 900 s after turn on
Achievable Initial Calibration Accuracye
Specifications
Supplemental Information
�[(time since last adjustment � aging rate) + temperature stability + calibration accuracyb]
�2 � 10-6 �2 � 10-6 �1 � 10-6/yeara �1.4 � 10-6 �2 � 10-8
10 Hz � Nf p-p in 20 ms (nominal)
�[(time since last adjustment � aging rate) + temperature stability + calibration accuracyb]c
�1.5 � 10-8 �5 � 10-8
�5 � 10-10/day (nominal)
�1 � 10-7 �1.5 � 10-7 �2 � 10-9
Nominal �1 � 10-7 of final frequency �1 � 10-8 of final frequency
�4 � 10-8
16
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Frequency and Time
Description
Specifications
Supplemental Information
Standby power to reference oscillator
Not supplied
Residual FM (Center Frequency = 1 GHz 10 Hz RBW, 10 Hz VBW)
0.25 Hz � Nf p-p in 20 ms (nominal)
a. For periods of one year or more. b. Calibration accuracy depends on how accurately the frequency standard was adjusted to 10 MHz. If the adjust-
ment procedure is followed, the calibration accuracy is given by the specification "Achievable Initial Calibration Accuracy." c. The specification applies after the receiver has been powered on for four hours. d. Standby mode does not apply power to the oscillator. Therefore warm-up applies every time the power is turned on. The warm-up reference is one hour after turning the power on. Retracing also occurs every time warm-up occurs. The effect of retracing is included within the "Achievable Initial Calibration Accuracy" term of the Accuracy equation. e. The achievable calibration accuracy at the beginning of the calibration cycle includes these effects: 1) Temperature difference between the calibration environment and the use environment 2) Orientation relative to the gravitation field changing between the calibration environment and the use environment 3) Retrace effects in both the calibration environment and the use environment due to turning the instrument power off. 4) Settability f. N is the LO multiplication factor.
Keysight N9038B MXE Specification Guide
17
Keysight MXE EMI Receiver Frequency and Time
Description
Specifications
Supplemental Information
Frequency Readout Accuracy
�(marker freq � freq ref accy. + 0.25% � span + 5% � RBWa + 2 Hz + 0.5 � horizontal resolutionb)
Single detector onlyc
Example for EMCd
�0.0032% (nominal)
a. The warranted performance is only the sum of all errors under autocoupled conditions. Under non-autocoupled conditions, the frequency readout accuracy will nominally meet the specification equation, except for conditions in which the RBW term dominates, as explained in examples below. The nominal RBW contribution to frequency readout accuracy is 2% of RBW for RBWs from 1 Hz to 390 kHz, 4% of RBW from 430 kHz through 3 MHz (the widest autocoupled RBW), and 30% of RBW for the (manually selected) 4, 5, 6 and 8 MHz RBWs. First example: a 120 MHz span, with autocoupled RBW. The autocoupled ratio of span to RBW is 106:1, so the RBW selected is 1.1 MHz. The 5% � RBW term contributes only 55 kHz to the total frequency readout accuracy, compared to 300 kHz for the 0.0.25% � span term, for a total of 355 kHz. In this example, if an instrument had an unusually high RBW centering error of 7% of RBW (77 kHz) and a span error of 0.20% of span (240 kHz), the total actual error (317 kHz) would still meet the computed specification (355 kHz). Second example: a 20 MHz span, with a 4 MHz RBW. The specification equation does not apply because the Span: RBW ratio is not autocoupled. If the equation did apply, it would allow 50 kHz of error (0.25%) due to the span and 200 kHz error (5%) due to the RBW. For this non-autocoupled RBW, the RBW error is nominally 30%, or 1200 kHz.
b. Horizontal resolution is due to the marker reading out one of the sweep points. The points are spaced by span/(Npts �1), where Npts is the number of sweep points. For example, with the factory preset value of 1001 sweep points, the horizontal resolution is span/1000. However, there is an exception: When both the detector mode is "normal" and the span > 0.25 � (Npts �1) � RBW, peaks can occur only in even-numbered points, so the effective horizontal resolution becomes doubled, or span/500 for the factory preset case. When the RBW is autocoupled and there are 1001 sweep points, that exception occurs only for spans > 750 MHz.
c. Specifications apply to traces in most cases, but there are exceptions. Specifications always apply to the peak detector. Specifications apply when only one detector is in use and all active traces are set to Clear Write. Specifications also apply when only one detector is in use in all active traces and the "Restart" key has been pressed since any change from the use of multiple detectors to a single detector. In other cases, such as when multiple simultaneous detectors are in use, additional errors of 0.5, 1.0 or 1.5 sweep points will occur in some detectors, depending on the combination of detectors in use.
d. In most cases, the frequency readout accuracy of the receiver can be exceptionally good. As an example, Keysight has characterized the accuracy of a span commonly used for Electro-Magnetic Compatibility (EMC) testing using a source frequency locked to the receiver. Ideally, this sweep would include EMC bands C and D and thus sweep from 30 to 1000 MHz. Ideally, the analysis bandwidth would be 120 kHz at -6 dB, and the spacing of the points would be half of this (60 kHz). With a start frequency of 30 MHz and a stop frequency of 1000.2 MHz and a total of 16168 points, the spacing of points is ideal. The detector used was the Peak detector. The accuracy of frequency readout of all the points tested in this span was with �0.0032% of the span. A perfect receiver with this many points would have an accuracy of �0.0031% of span. Thus, even with this large number of display points, the errors in excess of the bucket quantization limitation were negligible.
18
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Frequency and Time
Description
Specifications
Supplemental Information
Frequency Countera
See noteb
Count Accuracy
�(marker freq � freq ref accy. + 0.100 Hz)
Delta Count Accuracy
�(delta freq. � freq ref accy. + 0.141 Hz)
Resolution
0.001 Hz
a. Instrument conditions: RBW = 1 kHz, gate time = auto (100 ms), S/N 50 dB, frequency = 1 GHz b. If the signal being measured is locked to the same frequency reference as the receiver, the specified count
accuracy is �0.100 Hz under the test conditions of footnote a. This error is a noisiness of the result. It will increase with noisy sources, wider RBWs, lower S/N ratios, and source frequencies > 1 GHz.
Description Frequency Span Range Swept and FFT Option 503 Option 508 Option 526 Option 544
Specifications
0 Hz, 10 Hz to 3.6 GHz 0 Hz, 10 Hz to 8.4 GHz 0 Hz, 10 Hz to 26.5 GHz 0 Hz, 10 Hz to 44 GHz
Supplemental Information
Resolution
2 Hz
Span Accuracy
Stepped
�(0.25% � span + horizontal resolutiona)
Swept
�(0.25% � span + horizontal resolutiona)
FFT
�(0.1% � span + horizontal resolutiona)
a. Horizontal resolution is due to the marker reading out one of the sweep points. The points are spaced by span/(Npts - 1), where Npts is the number of sweep points. For example, with the factory preset value of 1001 sweep points, the horizontal resolution is span/1000. However, there is an exception: When both the detector mode is "normal" and the span > 0.25 � (Npts - 1) � RBW, peaks can occur only in even-numbered points, so the effective horizontal resolution becomes doubled, or span/500 for the factory preset case. When the RBW is auto coupled and there are 1001 sweep points, that exception occurs only for spans >750 MHz.
Keysight N9038B MXE Specification Guide
19
Keysight MXE EMI Receiver Frequency and Time
Description Sweep Time Range
Span = 0 Hz Span 10 Hz Accuracy Span 10 Hz, swept Span 10 Hz, FFT Span = 0 Hz
Specifications 1 s to 6000 s 1 ms to 4000 s
Supplemental Information �0.01% (nominal) �40% (nominal) �0.01% (nominal)
Sweep Trigger
Free Run, Line, Video, External 1, External 2, RF Burst, Periodic Timer
Delayed Triggera
Range
Span 10 Hz, swept
0 to 500 ms
Span = 0 Hz or FFT
-150 ms to +500 ms
Resolution
0.1 s
a. Delayed trigger is available with line, video, RF burst and external triggers.
20
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Frequency and Time
Description
Specifications
Supplemental Information
Triggers
Video Minimum settable level Maximum usable level
Detector and Sweep Type relationships Sweep Type = Swept Detector = Normal, Peak, Sample or Negative Peak
-170 dBm
Additional information on some of the triggers and gate sources Independent of Display Scaling and Reference Level Useful range limited by noise Highest allowed mixer levela + 2 dB (nominal)
Triggers on the signal before detection, which is similar to the displayed signal
Detector = Average
Triggers on the signal before detection, but with a single-pole filter added to give similar smoothing to that of the average detector
Sweep Type = FFT
Triggers on the signal envelope in a bandwidth wider than the FFT width
RF Burst
Level Range
-50b to -10 dBm plus attenuation (nominal)
Level Accuracy
�2 dB + Absolute Amplitude Accuracy (nominal)
Bandwidth (-10 dB)
Most cases
16 MHz (nominal)
Sweep Type = FFT; FFT Width = 25 MHz; Span 8 MHz
30 MHz (nominal)
Frequency Limitations
If the start or center frequency is too close to zero, LO feedthrough can degrade or prevent triggering. How close is too close depends on the bandwidth listed above.
External Triggers
See "Trigger Inputs (Trigger 1 In, Trigger 2 In)" on page 74
a. The highest allowed mixer level depends on the IF Gain. It is nominally �10 dBm for Preamp Off and IF Gain = Low.
b. Noise will limit trigger level range at high frequencies, such as above 15 GHz.
Keysight N9038B MXE Specification Guide
21
Keysight MXE EMI Receiver Frequency and Time
Description Gated Sweep Gate Methods
Span Range Gate Delay Range Gate Delay Settability Gate Delay Jitter Gate Length Range
(Except Method = FFT) Gated Frequency and Amplitude Errors
Specifications
Gated LO Gated Video Gated FFT Any span 0 to 100.0 s 4 digits, 100 ns
100 ns to 5.0 s
Gate Sources
External 1 External 2 Line RF Burst Periodic
Description Number of Frequency Sweep/Step Points (buckets) Factory preset Range
Specifications
1001 1 to 100,001
Supplemental Information
33.3 ns p-p (nominal) Gate length for the FFT method is fixed at 1.83/RBW, with nominally 2% tolerance. Nominally no additional error for gated measurements when the Gate Delay is greater than the MIN FAST setting Pos or neg edge triggered
Supplemental Information
Zero and non-zero spans
22
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Frequency and Time
Description Resolution Bandwidth (RBW) Range (-3.01 dB bandwidth)
CISPR Standard Bandwidths
MIL Standard Bandwidths
Other Bandwidths
Power bandwidth accuracya
RBW Range
CF Range
1 Hz to 750 kHz
All
820 kHz to 1.2 MHz
< 3.6 GHz
1.3 to 2.0 MHz
< 3.6 GHz
2.2 to 3 MHz
< 3.6 GHz
4 to 8 MHz
< 3.6 GHz
Specifications
Supplemental Information
1 Hz to 8 MHz Bandwidths above 3 MHz are 4, 5, 6, and 8 MHz. Bandwidths 1 Hz to 3 MHz are spaced at 10% spacing using the E24 series 24 per decade: 1.0, 1.1, 1.2, 1.3, 1.5, 1.6, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.6, 3.9, 4.3, 4.7, 5.1, 5.6, 6.2, 6.8, 7.5, 8.2, 9.1 in each decade. 200 Hz, 9 kHz, 120 kHz, 1 MHz
10 Hz, 100 Hz, 1 kHz, 10 kHz, 100 kHz, 1 MHz 30 Hz, 300 Hz, 3 kHz, 30 kHz, 300 kHz, 3 MHz, 10 MHz
�6 dB, subject to CISPR mask �6 dB
�6 dB
�1.0% (0.044 dB) �2.0% (0.088 dB)
�0.07 dB (nominal) �0.15 dB (nominal) �0.25 dB (nominal)
Accuracy (-3.01 dB bandwidth)b 1 Hz to 1.3 MHz RBW 1.5 MHz to 3 MHz RBW CF 3.6 GHz CF > 3.6 GHz 4 MHz to 8 MHz RBW CF 3.6 GHz CF > 3.6 GHz
Selectivity (-60 dB/-3 dB)
�2% (nominal)
�7% (nominal) �8% (nominal)
�15% (nominal) �20% (nominal) 4.1:1 (nominal)
Keysight N9038B MXE Specification Guide
23
Keysight MXE EMI Receiver Frequency and Time
a. The noise marker, band power marker, channel power and ACP all compute their results using the power bandwidth of the RBW used for the measurement. Power bandwidth accuracy is the power uncertainty in the results of these measurements due only to bandwidth-related errors. (The receiver knows this power bandwidth for each RBW with greater accuracy than the RBW width itself, and can therefore achieve lower errors.) The warranted specifications shown apply to the Gaussian RBW filters used in swept and zero span analysis. There are four different kinds of filters used in the receiver: Swept Gaussian, Swept Flattop, FFT Gaussian and FFT Flattop. While the warranted performance only applies to the swept Gaussian filters, because only they are kept under statistical process control, the other filters nominally have the same performance.
b. Resolution Bandwidth Accuracy can be observed at slower sweep times than auto-coupled conditions. Normal sweep rates cause the shape of the RBW filter displayed on the receiver screen to widen by nominally 6%. This widening declines to 0.6% nominal when the Swp Time Rules key is set to Accuracy instead of Normal. The true bandwidth, which determines the response to impulsive signals and noise-like signals, is not affected by the sweep rate.
24
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Frequency and Time
Description RF Preselector Filters Filter Band
20 Hz to 150 kHz 150 kHz to 1 MHz 1 to 2 MHz 2 to 5 MHz 5 to 8 MHz 8 to 11 MHz 11 to 14 MHz 14 to 17 MHz 17 to 20 MHz 20 to 24 MHz 24 to 30 MHz 30 to 70 MHz 70 to 150 MHz 150 to 300 MHz 300 to 600 MHz 600 MHz to 1 GHz 1 to 2 GHz 2 to 3.6 GHz
Specifications
Filter Type Fixed lowpass Fixed bandpass Fixed bandpass Fixed bandpass Fixed bandpass Fixed bandpass Fixed bandpass Fixed bandpass Fixed bandpass Fixed bandpass Fixed bandpass Tracking bandpass Tracking bandpass Tracking bandpass Tracking bandpass Tracking bandpass Tracking bandpass Fixed highpass
Supplemental Information
6 dB Bandwidth (Nominal) 310 kHz 1.7 MHz 2.4 MHz 7.5 MHz 10 MHz 9.5 MHz 9.5 MHz 10 MHz 9.5 MHz 9.5 MHz 9.0 MHz 10 MHz 24 MHz 28 MHz 50 MHz 60 MHz 180 MHz 1.89 GHz (�3 dB corner frequency)
Keysight N9038B MXE Specification Guide
25
Keysight MXE EMI Receiver Frequency and Time
Description
Specifications
Supplemental Information
Microwave Preselector Bandwidth Mean Bandwidth at CFa
5 GHz 10 GHz 15 GHz 20 GHz 25 GHz
Relevant to many options, such as B25 Wide IF Bandwidth, in Bands 1 and higher. Nominal.
Freq option 526
Freq option >526
58 MHz
46 MHz
57 MHz
52 MHz
59 MHz
53 MHz
64 MHz
55 MHz
74 MHz
56 MHz
35 GHz
62 MHz
44 GHz
70 MHz
Standard Deviation
9%
7%
-3 dB Bandwidth
-7.5% relative to -4 dB bandwidth, nominal
a. The microwave preselector can have a passband ripple up to 3 dB. To avoid ambiguous results, the �4 dB bandwidth is characterized.
Description
Specification
Supplemental information
Analysis Bandwidtha
Standard
10 MHz
With Option B25
25 MHz
With Option B85
85 MHz
With Option B1X
160 MHz
a. Analysis bandwidth is the instantaneous bandwidth available about a center frequency over which the input signal can be digitized for further analysis or processing in the time, frequency, or modulation domain.
Description
Specifications
Supplemental Information
Video Bandwidth (VBW)
Range
Same as Resolution Bandwidth range plus wide-open VBW (labeled 50 MHz)
Accuracy
�6% (nominal) in swept mode and zero spana
a. For FFT processing, the selected VBW is used to determine a number of averages for FFT results. That number is chosen to give roughly equivalent display smoothing to VBW filtering in a swept measurement. For example, if VBW = 0.1 � RBW, four FFTs are averaged to generate one result.
26
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Amplitude Accuracy and Range
Description Measurement Range Preamp Off Preamp On Input Attenuation Range
Specifications
Displayed Average Noise Level to +30 dBm Displayed Average Noise Level to +30 dBm 0 to 70 dB, in 2 dB steps
Description
Specifications
Maximum Safe Input Level RF Input 1
RF Input
Average Total Power
+30 dBm (1 W)
Peak Pulse Power
+45 dBm (31.6 W)
RF Input 2
+30 dBm (1 W) +50 dBm (100 W)
Surge Power
DC voltage DC Coupled AC Coupled
Description Display Range Log Scale
Linear Scale
2 kW (10 s pulse width)
�0.2 Vdc �100 Vdc
Specifications
�0.2 Vdc �100 Vdc
Ten divisions displayed; 0.1 to 1.0 dB/division in 0.1 dB steps, and 1 to 20 dB/division in 1 dB steps Ten divisions
Supplemental Information
Supplemental Information Applies with or without preamp (10 s pulse width, 1% duty cycle, input attenuation 30 dB)
Supplemental Information
Keysight N9038B MXE Specification Guide
27
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Description Marker Readout Resolution
Log (decibel) units Trace Averaging Off, on-screen Trace Averaging On or remote
Linear units resolution
Specifications
0.01 dB 0.001 dB
Supplemental Information 1% of signal level (nominal)
28
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Frequency Response
Description
Specifications
Frequency Response
(Maximum error relative to reference condition (50 MHz) Mechanical attenuator only Non-FFT operation onlyb Preamp off: 10 dB atten Preamp on: 0 dB atten)
Option 544 (mmW) Option 503, 508 or 526 (RF/W) RF Preselector off Preamp off
RF Input 1: to 44 GHz RF Input 2: to 1 GHz 20 to 30�C 5 to 50�C
Supplemental Information
Refer to the footnote for Band Overlaps on page 14. Modes above 18 GHza
3 Hz to 20 Hz 20 Hz to 10 MHz
20 Hz to 10 MHz 10 MHzc to 3.6 GHz 10 to 50 MHz 50 MHz to 3.6 GHz 3.5 to 8.4 GHzde 3.5 to 5.2 GHzde 5.2 to 8.4 GHzde 8.3 to 13.6 GHzde 8.3 to 13.6 GHzde 13.5 to 17.1 GHzde 13.5 to 17.1 GHzde 17.0 to 18.0 GHzde 18.0 to 22.0 GHzde 17.0 to 22 GHzde 22.0 to 26.5 GHzde 22.0 to 26.5 GHzde
95th Percentile (2)
xx
�0.25 dB (nominal)
x
�0.60 dB
�0.75 dB
�0.22 dB
x
�0.60 dB
�0.75 dB
�0.25 dB
x
�0.65 dB
�0.85 dB
�0.22 dB
x
�0.65 dB
�0.85 dB
�0.21 dB
x
�0.65 dB
�0.85 dB
�0.15 dB
x
�1.5 dB
�2.0 dB
�0.47 dB
x
�1.6 dB
�3.1 dB
�0.6 dB
x
�1.5 dB
�2.0 dB
�0.57 dB
x
�1.5 dB
�2.0 dB
�0.46 dB
x
�1.5 dB
�2.0 dB
�0.54 dB
x
�1.5 dB
�2.1 dB
�0.53 dB
x
�1.5 dB
�2.1 dB
�0.64 dB
x
�1.5 dB
�2.1 dB
�0.57 dB
x
�1.7 dB
�2.6 dB
�0.64 dB
x
�1.7 dB
�2.6 dB
�0.72 dB
x
�1.7 dB
�2.6 dB
�0.61 dB
x
�1.7 dB
�2.6 dB
�0.71 dB
Keysight N9038B MXE Specification Guide
29
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Description
Specifications
Supplemental Information
26.4 to 34.5 GHzde 34.4 to 44 GHzde
x
�2.5 dB
x
�3.2 dB
�3.5 dB �4.9 dB
�0.93 dB �1.24 dB
a. Signal frequencies above 18 GHz are prone to response errors due to modes in the Type-N connector used. With the use of Type-N to APC 3.5 mm adapter part number 1250-1744, there are nominally six such modes. The effect of these modes with this connector are included within these specifications.
b. For FFT based measurements, Frequency Response errors are more complicated. One case is where the input signal is at the center frequency of the FFT measurement. In this case, the Frequency Response errors are given by this table. The total absolute amplitude accuracy is given by the combination of the absolute amplitude accuracy at 50 MHz with the Frequency Response from this table. The other case is when the input signal is not at the center frequency of the FFT measurement. In this case, the total frequency response error is computed by adding the RF flatness errors of this table to the IF Frequency Response. The total absolute amplitude accuracy is given by the combination of the absolute amplitude accuracy at 50 MHz with this total frequency response error. An additional error source, the relative error in switching between swept and FFT-based measurements, is nominally �0.01 dB. The effect of this relative error on absolute measurements is included with the "Absolute Amplitude Accuracy" specifications.
c. Specifications apply with DC coupling at all frequencies. With AC coupling, specifications apply at frequencies of 50 MHz and higher. Statistical observations at 10 MHz show that most instruments meet the specifications, but a few percent of instruments can be expected to have errors exceeding 0.5 dB at 10 MHz at the temperature extreme. The effect at 20 to 50 MHz is negligible, but not warranted.
d. Specifications for frequencies >3.5 GHz apply for sweep rates 100 MHz/ms. e. Microwave preselector centering applied.
30
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Description
Specifications
Frequency Response
RF Input 1: to 44 GHz RF Input 2: to 1 GHz
(Maximum error relative to reference condition (50 MHz) Mechanical attenuator only Non-FFT operation onlyb Preamp off: 10 dB atten Preamp on: 0 dB atten)
Option 544 (mmW)
Option 503, 508 or 526 (RF/W)
RF Preselector on Preamp off
20 to 30�C 5 to 50�C
3 Hz to 20 Hz 20 Hz to 300 MHzc 300 MHz to 1 GHz 1 to 3.6 GHz 3.5 to 8.4 GHzde 3.5 to 5.2 GHzde 5.2 to 8.4 GHzde 8.3 to 13.6 GHzde 8.3 to 13.6 GHzde 13.5 to 17.1 GHzde 13.5 to 17.1 GHzde 17.0 to 18.0 GHzde 18.0 to 22.0 GHzde 17.0 to 22 GHzde 22.0 to 26.5 GHzde 22.0 to 26.5 GHzde 26.4 to 34.5 GHzde 34.4 to 44 GHzde
x
x
x
x �0.65 dB
�0.9 dB
x
x �0.65 dB
�0.9 dB
x
x �0.85 dB
�1.3 dB
x
�1.5 dB
�2.0 dB
x
�1.6 dB
�3.1 dB
x
�1.5 dB
�2.0 dB
x
�1.5 dB
�2.0 dB
x
�1.5 dB
�2.0 dB
x
�1.5 dB
�2.1 dB
x
�1.5 dB
�2.1 dB
x
�1.5 dB
�2.1 dB
x
�1.7 dB
�2.6 dB
x
�1.7 dB
�2.6 dB
x
�1.7 dB
�2.6 dB
x
�1.7 dB
�2.6 dB
x
�2.5 dB
�3.5 dB
x
�3.2 dB
�4.9 dB
Supplemental Information Refer to the footnote for Band Overlaps on page 14. Modes above 18 GHza
95th Percentile (2) �0.3dB (nominal) �0.3 dB �0.28 dB �0.36 dB �0.47 dB
�0.6 dB �0.57 dB �0.46 dB �0.54 dB �0.53 dB �0.64 dB �0.57dB �0.64 dB �0.72 dB �0.61 dB �0.71 dB �0.93 dB �1.24 dB
Keysight N9038B MXE Specification Guide
31
Keysight MXE EMI Receiver Amplitude Accuracy and Range
a. Signal frequencies above 18 GHz are prone to response errors due to modes in the Type-N connector used. With the use of Type-N to APC 3.5 mm adapter part number 1250-1744, there are nominally six such modes. The effect of these modes with this connector are included within these specifications.
b. For FFT based measurements, Frequency Response errors are more complicated. One case is where the input signal is at the center frequency of the FFT measurement. In this case, the Frequency Response errors are given by this table. The total absolute amplitude accuracy is given by the combination of the absolute amplitude accuracy at 50 MHz with the Frequency Response from this table. The other case is when the input signal is not at the center frequency of the FFT measurement. In this case, the total frequency response error is computed by adding the RF flatness errors of this table to the IF Frequency Response. The total absolute amplitude accuracy is given by the combination of the absolute amplitude accuracy at 50 MHz with this total frequency response error. An additional error source, the relative error in switching between swept and FFT-based measurements, is nominally �0.01 dB. The effect of this relative error on absolute measurements is included with the "Absolute Amplitude Accuracy" specifications.
c. Specifications apply with DC coupling at all frequencies. With AC coupling, specifications apply at frequencies of 50 MHz and higher. Statistical observations at 10 MHz show that most instruments meet the specifications, but a few percent of instruments can be expected to have errors exceeding 0.5 dB at 10 MHz at the temperature extreme. The effect at 20 to 50 MHz is negligible, but not warranted.
d. Specifications for frequencies >3.5 GHz apply for sweep rates 100 MHz/ms. e. Microwave preselector centering applied.
32
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Description
Specifications
Supplemental Information
IF Frequency Responsea
Modes above 18 GHzb
(Demodulation and FFT response relative to the center frequency)
Freq (GHz)
Analysis Widthc (MHz)
Max Errord (Exceptione)
Midwidth Error (95th Percentile)
Slope (dB/MHz) (95th Percentile)
RMSf (nominal)
<3.6g
10
�0.40 dB
�0.12 dB
�0.10
0.04 dB
3.6, 26.5 10 Preselected
0.25 dB
>26.5
10 Preselected
0.35 dB
a. The IF frequency response includes effects due to RF circuits such as input filters, that are a function of RF frequency, in addition to the IF passband effects.
b. Signal frequencies above 18 GHz are prone to additional response errors due to modes in the Type-N connector used. With the use of Type-N to APC 3.5 mm adapter part number 1250-1744, there are nominally six such modes. These modes cause nominally up to -0.35 dB amplitude change, with phase errors of nominally up to �1.2�.
c. This column applies to the instantaneous analysis bandwidth in use. In the Spectrum Analyzer Mode, this would be the FFT width.
d. The maximum error at an offset (f) from the center of the FFT width is given by the expression � [Midwidth Error + (f � Slope)], but never exceeds �Max Error. Here the Midwidth Error is the error at the center frequency for a given FFT span. Usually, the span is no larger than the FFT width in which case the center of the FFT width is the center frequency of the analyzer. When using the Spectrum Analyzer mode with an analyzer span is wider than the FFT width, the span is made up of multiple concatenated FFT results, and thus has multiple centers of FFT widths; in this case the f in the equation is the offset from the nearest center. Performance is nominally three times better at most center frequencies.
e. The specification does not apply for frequencies greater than 3.6 MHz from the center in FFT widths of 7.2 to 8 MHz.
f. The "rms" nominal performance is the standard deviation of the response relative to the center frequency, integrated across the span. This performance measure was observed at a center frequency in each harmonic mixing band, which is representative of all center frequencies; it is not the worst case frequency.
g. The Frequency Response with the RF Preselector on is verified at the analyzer center frequency in zero span. When the RF Preselector is a fixed filter (for frequencies up through 30 MHz), the effect of the RF Preselector is included in this Frequency Response specification. When the RF Preselector is a tracking filter, its effect at analysis frequencies away from the center frequency, such as can be measured with FFT-based measurements, can be significant but is not included in this expression of Frequency Response. The nominal response of the RF Preselector relative to its response at the center frequency is �20� log ((f/f0)2+1), where f0 in this equation is half of the �6 dB bandwidth of the RF preselector filter.
Keysight N9038B MXE Specification Guide
33
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Description
Specifications
Supplemental Information
IF Phase Linearity
Deviation from mean phase linearity Modes above 18 GHza RF preselector off only
Center Freq (GHz)
Span (MHz)
Nominal
RMS (nominal)b
0.02, <3.6
10
�0.5�
0.2�
3.6, 26.5
10
�1.5�
0.4�
>26.5
10
�1.4�
0.4�
a. Signal frequencies above 18 GHz are prone to additional response errors due to modes in the Type-N connector used. With the use Type-N to APC 3.5 mm adapter part number 1250-1744, there are nominally six such modes. These modes cause nominally up to -0.35 dB amplitude change, with phase errors of nominally up to �1.2�.
b. The listed performance is the standard deviation of the phase deviation relative to the mean phase deviation from a linear phase condition, where the rms is computed across the span shown and over the range of center frequencies shown.
34
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Description
Absolute Amplitude Accuracy RF Preselector off and on Preamp off
Specifications RF Input 1: to 44 GHz RF Input 2: to 1 GHz
Supplemental Information
RF Input 1
95th percentile
At 50 MHzab 20 to 30�C 5 to 50�C
�0.33 dB �0.42 dB
�0.25 dB
At all frequenciesab 20 to 30�C 5 to 50�C
�(0.33 dB + frequency response) �(0.42 dB+ frequency response)
RF Input 2
At 50 MHzac 20 to 30�C 5 to 50�C
�0.36 dB �0.45 dB
�0.27 dB
At all frequenciesac 20 to 30�C 5 to 50�C
�(0.36 dB + frequency response) �(0.45 dB + frequency response)
CISPR requirements
This instrument meets or exceeds the current CISPR 16-1-1:2019 sine wave accuracy requirements from 15 to 35�C
Amplitude Reference Accuracy
�0.05 dB (nominal)
a. Absolute amplitude accuracy is the total of all amplitude measurement errors, and applies over the following subset of settings and conditions: 1 Hz RBW 1 MHz; Input signal -10 to -50 dBm; Input attenuation 10 dB; span < 5 MHz (nominal additional error for span 5 MHz is 0.02 dB); all settings auto-coupled except Swp Time Rules = Accuracy; combinations of low signal level and wide RBW use VBW 30 kHz to reduce noise. When using FFT sweeps, the signal must be at the center frequency. This absolute amplitude accuracy specification includes the sum of the following individual specifications under the conditions listed above: Scale Fidelity, Reference Level Accuracy, Display Scale Switching Uncertainty, Resolution Bandwidth Switching Uncertainty, 50 MHz Amplitude Reference Accuracy, and the accuracy with which the instrument aligns its internal gains to the 50 MHz Amplitude Reference. When using Time Domain scan, only the 95th percentile specification applies.
b. Same settings as footnote a, except that the signal level at the preamp input is �40 to �80 dBm. Total power at the preamp (dBm) = total power at the input (dBm) minus input attenuation (dB).
c. Same settings as footnote a, except that the signal level at the preamp input is �40 to �80 dBm. Total power at the preamp (dBm) = total power at the input (dBm) minus input attenuation (dB) � 9 dB.
Keysight N9038B MXE Specification Guide
35
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Description Input Attenuation Switching Uncertainty
Atten >2 dB, preamp off (Relative to 10 dB (reference setting)) 50 MHz (reference setting)
Specifications �0.20 dB
Supplemental Information Refer to the footnote for Band Overlaps on page 14
�0.08 dB (typical)
36
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Description RF Input VSWR at tuned frequency 10 dB Atten, 50 MHz, RF Presel off
Specifications RF Input 1: to 44 GHz RF Input 2: to 1 GHz
Supplemental Information 1.07:1 (nominal)
RF Preselector off Preamp off
DC Coupled 9 kHza to 1 GHz 1 to 18 GHz 18 to 26.5 GHzb 26.5 to 40 GHz 40 to 44 GHz
AC Coupled (Option 503, 508, 526) 50 MHz to 1 GHz 1 to 18 GHz 18 to 26.5 GHzb
Input Attenuation 0 dB
10 dB
---
---
3.0:1
2.0:1
3.0:1
2.0:1
3.0:1
2.5:1
---
---
---
---
3.0:1
2.0:1
3.0:1
2.4:1
Typical
10 dB Attenuation
1.8:1 1.8:1 1.8:1 2.0:1
1.8:1 2.0:1
RF Preselector on Preamp off
Input Attenuation
DC Coupled 9 kHz to 1 GHz 1 to 26.5 GHzb 26.5 to 40 GHz 40 to 44 GHz
AC Coupled (Option 503, 508, 526) 50 MHz to 1 GHz 1 to 18 GHz 18 to 26.5 GHzb
0 dB
2.0:1 3.0:1 3.0:1 ---
2.0:1 3.0:1 3.0:1
10 dB
1.2:1
2.0:1
1.8:1
2.5:1
1.8:1
---
2.0:1
1.2:1
2.0:1
1.8:1
2.4:1
2.0:1
a. For preamp on case, low frequency is 100 kHz. b. For Option 526, VSWR specifications above 18 GHz apply only with Option C35 (3.5 mm connector).
Keysight N9038B MXE Specification Guide
37
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Description Resolution Bandwidth Switching Uncertainty 1.0 Hz to 1.5 MHz RBW 1.6 MHz to 3 MHz RBW Manually selected wide RBWs: 4, 5, 6, 8 MHz
Specifications
�0.05 dB �0.10 dB �1.0 dB
Supplemental Information Relative to reference BW of 30 kHz
Description Reference Level Range
Log Units Linear Units Accuracy
Specifications
-170 to +30 dBm, in 0.01 dB steps 707 pV to 7.07 V, with 0.01 dB resolution (0.11%) 0 dB
Supplemental Information
Description
Specifications
Supplemental Information
Display Scale Switching Uncertainty
Switching between Linear and Log
0 dBa
Log Scale Switching
0 dBa
a. Because Log/Lin and Log Scale Switching affect only the display, not the measurement, they cause no additional error in measurement results from trace data or markers.
38
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Description
Total Measurement Uncertainty Signal level 0 to 90 dB below reference point, RF attenuation 0 to 40 dB, RBW 1 MHz, 20� to 30� C: AC coupled 10 MHz to 26.5 GHz DC coupled 9 kHz to 44 GHz
Option 544 (mmW) Option 503, 508 or 526 (RF/W) RF Presel off Preamp off
Specifications
Supplemental Information 95th Percentile ( 2)
9 kHz to 2 GHz
x
x
2 to 3.6 GHz
x
x
3.6 to 8 GHz
x
3.6 to 8 GHz
x
8 to 18 GHz
x
8 to 18 GHz
x
18 to 26.5 GHz
x
x
26.5 to 40 GHz
x
40 to 44 GHz
x
RF Presel on Preamp off
9 kHz to 2 GHz
x
x
2 to 3.6 GHz
x
x
3.6 to 8 GHz
x
3.6 to 8 GHz
x
8 to 18 GHz
x
8 to 18 GHz
x
18 to 26.5 GHz
x
x
26.5 to 40 GHz
x
40 to 44 GHz
x
� 0.5 dB � 0.6 dB � 0.8 dB
� 1.7 dB � 1.1 dB
� 1.3 dB � 1.6 dB
� 1.7 dB � 2.3 dB
� 0.5 dB � 0.5 dB � 0.8 dB
� 1.7 dB � 1.1 dB
� 1.3 dB � 1.6 dB
� 1.7 dB � 2.3 dB
Keysight N9038B MXE Specification Guide
39
Keysight MXE EMI Receiver Amplitude Accuracy and Range
Description
Specifications
Supplemental Information
Display Scale Fidelityab
Absolute Log-Linear Fidelity (Relative to the reference condition for Input 1: -25 dBm input through 10 dB attenuation, thus -35 dBm at the input mixer)
Input mixer levelc
Linearity
-80 dBm ML -10 dBm
�0.10 dB
ML < -80 dBm
�0.15 dB
Relative Fidelityd
Applies for mixer levelc range from -10 to -80 dBm, mechanical attenuator only, preamp off, and dither on.
Sum of the following terms:
Nominal
high level term
Up to �0.045 dBe
instability term
Up to �0.018 dB
slope term
From equationf
prefilter term
Up to �0.005 dBg
a. Supplemental information: The amplitude detection linearity specification applies at all levels below -10 dBm at the input mixer; however, noise will reduce the accuracy of low level measurements. The amplitude error due to noise is determined by the signal-to-noise ratio, S/N. If the S/N is large (20 dB or better), the amplitude error due to noise can be estimated from the equation below, given for the 3-sigma (three standard deviations) level. 3 = 3(20dB)log(1+10�((S/N+ 3dB)/ 20dB)) The errors due to S/N ratio can be further reduced by averaging results. For large S/N (20 dB or better), the 3-sigma level can be reduced proportional to the square root of the number of averages taken.
b. The scale fidelity is warranted with ADC dither set to On. Dither increases the noise level by nominally only 0.24 dB for the most sensitive case (preamp Off, best DANL frequencies). With dither Off, scale fidelity for low level signals, around -60 dBm or lower, will nominally degrade by 0.2 dB.
c. Mixer level = Input Level - Input Attenuation d. The relative fidelity is the error in the measured difference between two signal levels. It is so small in many cases
that it cannot be verified without being dominated by measurement uncertainty of the verification. Because of this verification difficulty, this specification gives nominal performance, based on numbers that are as conservatively determined as those used in warranted specifications. We will consider one example of the use of the error equation to compute the nominal performance. Example: the accuracy of the relative level of a sideband around -60 dBm, with a carrier at -5 dBm, using attenuation = 10 dB, RBW = 3 kHz, evaluated with swept analysis. The high level term is evaluated with P1 = -15 dBm and P2 = -70 dBm at the mixer. This gives a maximum error within �0.025 dB. The instability term is �0.018 dB. The slope term evaluates to �0.050 dB. The prefilter term applies and evaluates to the limit of �0.005 dB. The sum of all these terms is �0.098 dB.
40
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Amplitude Accuracy and Range
e. Errors at high mixer levels will nominally be well within the range of �0.045 dB � {exp[(P1 - Pref)/(8.69 dB)] - exp[(P2 - Pref)/(8.69 dB)]} (exp is the natural exponent function, ex). In this expression, P1 and P2 are the powers of the two signals, in decibel units, whose relative power is being measured. Pref is -10 dBm (-10 dBm is the highest power for which linearity is specified). All these levels are referred to the mixer level.
f. Slope error will nominally be well within the range of �0.0009 � (P1 - P2). P1 and P2 are defined in footnote e. g. A small additional error is possible. In FFT sweeps, this error is possible for spans under 4.01 kHz. For non-FFT
measurements, it is possible for RBWs of 3.9 kHz or less. The error is well within the range of �0.0021 � (P1 P2) subject to a maximum of �0.005 dB. (The maximum dominates for all but very small differences.) P1 and P2 are defined in footnote e.
Description Display Units
Specifications dBm, dBV, dBmV, dBA, dBmA, Watts, Volts, Amps, dBV/m, dBA/m, dBpT, dBG, dBpW
Supplemental Information
Description Available Detectors
Specifications Normal, Peak, Sample, Negative Peak, Average Quasi-Peak, EMI-Average, RMS-Average
Supplemental Information Average detector works on RMS, Voltage and Logarithmic scales Meet CISPR 16-1-1:2019 requirements
Description Amplitude Probability Distribution Dynamic Range Amplitude Accuracy Maximum Measureable Time Period
(no dead time) Minimum Measureable Probability
Amplitude Level Assignment Sampling Rate Amplitude Resolution
Specifications
> 70 dB
2 minutes 10�7 1000 levels 10 MSa/s 0.1881 dB
Supplemental Information Meets CISPR16-1-1:2019 requirements. <� 2.7 dB
Within a 1 MHz RBW
Keysight N9038B MXE Specification Guide
41
Keysight MXE EMI Receiver Dynamic Range
Dynamic Range
Gain Compression
Description
Specifications
1 dB Gain Compression Point (Two-tone)abcd
Maximum power at mixere
(RF Input 1f)
Option 544 (mmW)
Option 503, 508 or 526 (RF/W) RF Preselector on or off, Preamp off
Supplemental Information
9 kHz to 10 MHz
x
x
+4 dB (nominal)
10 to 500 MHz
x
x 0 dBm
+3 dBm (typical)
500 MHz to 3.6 GHz
x
x +1 dBm
+5 dBm (typical)
3.6 to 26.5 GHz
x
x 0 dBm
+4 dBm (typical)
26.4 to 44 GHz
x
-3 dBm
+2 dBm (typical)
a. Large signals, even at frequencies not shown on the screen, can cause the receiver to incorrectly measure on-screen signals because of two-tone gain compression. This specification tells how large an interfering signal must be in order to cause a 1 dB change in an on-screen signal.
b. Specified at 1 kHz RBW with 100 kHz tone spacing. Time Domain scan nominal values verified using a 1 kHz RBW with 50 MHz tone spacing. The compression point will nominally equal the specification for tone spacing greater than 5 times the prefilter bandwidth. At smaller spacings, ADC clipping may occur at a level lower than the 1 dB compression point.
c. Reference level and off-screen performance: The reference level (RL) behavior differs from some earlier receivers in a way that makes this receiver more flexible. In other receivers, the RL controlled how the measurement was performed as well as how it was displayed. Because the logarithmic amplifier in these receivers had both range and resolution limitations, this behavior was necessary for optimum measurement accuracy. The logarithmic amplifier in this receiver, however, is implemented digitally such that the range and resolution greatly exceed other instrument limitations. Because of this, the receiver can make measurements largely independent of the setting of the RL without compromising accuracy. Because the RL becomes a display function, not a measurement function, a marker can read out results that are off-screen, either above or below, without any change in accuracy. The only exception to the independence of RL and the way in which the measurement is performed is in the input attenuation setting: When the input attenuation is set to auto, the rules for the determination of the input attenuation include dependence on the reference level. Because the input attenuation setting controls the tradeoff between large signal behaviors (third-order intermodulation, compression, and display scale fidelity) and small signal effects (noise), the measurement results can change with RL changes when the input attenuation is set to auto.
d. When using Time Domain scan, all indicated values shown here are nominal values. e. Mixer power level (dBm) = input power (dBm) - input attenuation (dB) (�9 dB for RF Input 2). f. RF Input 2 operates to 1 GHz. The 1 dB gain compression is nominally 9 dB higher.
42
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Dynamic Range
Description Clipping (ADC Over-range) Any signal offset Signal offset > 5 times IF prefilter bandwidth and IF Gain set to Low
Specifications Maximum power at mixera -10 dBm
Supplemental Information
Low frequency exceptionsb +12 dBm (nominal)
IF Prefilter Bandwidth
Zero Span or
Sweep Type = FFT,
�3 dB Bandwidth
Swept, RBW =
FFT Width =
(nominal)
3.9 kHz
< 4.01 kHz
8.9 kHz
4.3 to 27 kHz
< 28.81 kHz
79 kHz
30 to 160 kHz
< 167.4 kHz
303 kHz
180 to 390 kHz
< 411.9 kHz
966 kHz
430 kHz to 8 MHz
< 7.99 MHz
10.9 MHz
a. Mixer power level (dBm) = input power (dBm) - input attenuation (dB) (�9 dB for RF Input 2). b. The ADC clipping level declines at low frequencies (below 50 MHz) when the LO feed through (the signal that
appears at 0 Hz) is within 5 times the prefilter bandwidth (see table) and must be handled by the ADC. For example, with a 300 kHz RBW and prefilter bandwidth at 966 kHz, the clipping level reduces for signal frequencies below 4.83 MHz. For signal frequencies below 2.5 times the prefilter bandwidth, there will be additional reduction due to the presence of the image signal (the signal that appears at the negative of the input signal frequency) at the ADC.
Keysight N9038B MXE Specification Guide
43
Keysight MXE EMI Receiver Dynamic Range
Displayed Average Noise Level
Description
Specifications
Displayed Average Noise Level (DANL)a
(RF Input 1b)
Input terminated Sample or Average detector Averaging type = Log 0 dB input attenuation IF Gain = High 1 Hz Resolution Bandwidth
Option 544 (mmW)
Option 503, 508 or 526 (RF/W)
RF Preselector off, Preamp off
20 to 30�C
5 to 50�C
Supplemental Information Refer to the footnote for Band Overlaps on page 14.
Typical DANL including NFEc
3 Hz to 10 Hz
xx
-97dBm (nominal, no NFE)
20 Hzd
x x �97 dBm
�96 dBm
100 Hzd
x x �106 dBm
�105 dBm
1 kHzd
x x �118 dBm
�117 dBm
9 kHzd
x x -119 dBm
-118 dBm
100 kHzd
x x -131 dBm
-130 dBm
1 MHzd
x x -150 dBm
-149 dBm
10 MHz to 2.1 GHz
x x -150 dBm
-149 dBm
-158 dBm
2.1 to 3.6 GHz
x x -148 dBm
-147 dBm
-157 dBm
3.5 GHz to 8.4 GHz
x
-148 dBm
-147 dBm
-159 dBm
3.5 GHz to 8.4 GHz
x -145 dBm
-144 dBm
-153 dBm
8.3 GHz to 13.6 GHz
x
-147 dBm
-145 dBm
-158 dBm
8.3 GHz to 13.6 GHz
x -147 dBm
-145 dBm
-156 dBm
13.5 to 17.1 GHz
x x -141 dBm
-139 dBm
-151 dBm
17.0 to 20.0 GHz
x x -142 dBm
-140 dBm
-152 dBm
20.0 to 26.5 GHz
x x -135 dBm
-133 dBm
-146 dBm
26.4 to 34.5 GHz
x -141 dBm
-138 dBm
-148 dBm
34.4 to 44 GHz
x -135 dBm
-132 dBm
-143 dBm
a. DANL for zero span and swept is measured in a 1 kHz RBW and normalized to the narrowest available RBW, because the noise figure does not depend on RBW and 1 kHz measurements are faster. Does not apply to Time Domain scan.
44
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Dynamic Range
b. RF Input 2 operates to 1 GHz. The DANL is nominally 11 dB higher for RF Input 2. c. NFE = Noise Floor Extension. Typical DANL including NFE = (Typical DANL � DANL improvement with NFE). d. DANL below 10 MHz is affected by phase noise around the LO feedthrough signal. Specifications apply with the
best setting of the Phase Noise Optimization control, which is to choose the "Best Close-in Noise" for frequencies below 25 kHz, and "Best Wide Offset Noise" for frequencies above 25 kHz.
Keysight N9038B MXE Specification Guide
45
Keysight MXE EMI Receiver Dynamic Range
Description
Specifications
Displayed Average Noise Level (DANL)a (RF Input 1b)
Option 544 (mmW) Option 503, 508 or 526 (RF/W)
Input terminated Sample or Average detector Averaging type = Log 0 dB input attenuation IF Gain = High 1 Hz Resolution Bandwidth
RF Preselector on, Preamp off
20 to 30�C 5 to 50�C
3 Hz to 10 Hz
xx
20 Hzd
x x �92 dBm
�91 dBm
100 Hzd
x x �101 dBm �100 dBm
1 kHzd
x x �114 dBm �113 dBm
9 kHzd
x x -118 dBm -117 dBm
100 kHzd
x x -130 dBm -129 dBm
1 to 3 MHzd
x x -147 dBm -146 dBm
3 to 30 MHzd
x x -150 dBm -149 dBm
30 to 300 MHz
x x -151 dBm -150 dBm
300 to 600 MHz
x x -153 dBm -152 dBm
600 MHz to 1 GHz
x x -151 dBm -150 dBm
1 to 2 GHz
x x -150 dBm -148 dBm
2 to 2.5 GHz
x x -152 dBm -151 dBm
2.5 to 3 GHz
x x -151 dBm -149 dBm
3 to 3.6 GHz
x x -148 dBm -147 dBm
3.5 to 8.4 GHz
x
-148 dBm -147 dBm
3.5 to 8.4 GHz
x
-145 dBm
-144 dBm
8.3 to 13.6 GHz
x
-147 dBm -145 dBm
8.3 to 13.6 GHz
x
-147 dBm
-145 dBm
13.5 to 17.1 GHz
x x -141 dBm -139 dBm
17.0 to 20.0 GHz
x x -142 dBm -140 dBm
20.0 to 26.5 GHz
x x -135 dBm -133 dBm
26.4 to 34.5 GHz
x
-141 dBm
-138 dBm
Supplemental Information Refer to the footnote for Band Overlaps on page 14.
Typical DANL including NFEc
-92 dBm (nominal, no NFE) �100 dBme �109 dBme �120 dBme -132 dBm -143 dBm -158 dBm -160 dBm -161 dBm -164 dBm -162 dBm -161 dBm -164 dBm -163 dBm -161 dBm -159 dBm
-153 dBm -158 dBm
-156 dBm -151 dBm -152 dBm -146 dBm
-148 dBm
46
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Dynamic Range
Description
Specifications
Supplemental Information
34.4 to 44 GHz
x
-135 dBm
-132 dBm
-143 dBm
a. DANL for zero span and swept is measured in a 1 kHz RBW and normalized to the narrowest available RBW, because the noise figure does not depend on RBW and 1 kHz measurements are faster. Does not apply to Time Domain scan.
b. RF Input 2 operates to 1 GHz. The DANL is nominally 11 dB higher for RF Input 2. c. NFE = Noise Floor Extension. Typical DANL including NFE = (Typical DANL � DANL improvement with NFE). d. DANL below 10 MHz is affected by phase noise around the LO feedthrough signal. Specifications apply with the
best setting of the Phase Noise Optimization control, which is to choose the "Best Close-in Noise" for frequencies below 25 kHz, and "Best Wide Offset Noise" for frequencies above 25 kHz. e. NFE is not part of the difference between warranted and typical specifications at this frequency.
Keysight N9038B MXE Specification Guide
47
Keysight MXE EMI Receiver Dynamic Range
Description
Indicated Noise (Receiver)a (RF Input 1b) Calculatedc: Derived from DANL data
Specifications
Option 544 (mmW) Option 503, 508 or 526 (RF/W) RF Preselector on, Preamp off
3 Hz to 10 Hz (1 Hz RBW) 20 Hz (1 Hz RBW)d 100 Hz (10 Hz)d 1 kHz (100 Hz)d
9 kHz (200 Hz) 100 kHz (200 Hz) 1 to 3 MHz (9 kHz) 3 to 30 MHz (9 kHz) 30 to 300 MHz (120 kHz) 300 to 600 MHz (120 kHz) 600 MHz to 1 GHz (120 kHz) 1 to 2 GHz (1 MHz) 2 to 2.5 GHz (1 MHz) 2.5 to 3 GHz (1 MHz) 3 to 3.6 GHz (1 MHz) 3.5 to 8.4 GHz (1 MHz)
3.5 to 8.4 GHz (1 MHz) 8.3 to 13.6 GHz (1 MHz)
8.3 to 13.6 GHz (1 MHz) 13.5 to 17.1 GHz (1 MHz) 17.0 to 20.0 GHz (1 MHz) 20.0 to 26.5 GHz (1 MHz)
26.4 to 34.5 GHz (1 MHz)
xx xx
xx
xx
xx xx xx xx xx xx xx xx xx xx xx x
x x
x xx xx xx
x
Supplemental Information Input terminated EMI Average detector 0 dB input attenuation IF Gain = High All indicated RBW are CISPR BW, except as noted.
Typical Indicated Noise including NFEc
+17 dBV (nominal) +10 dBVe +10 dBVe +9 dBVe �2 dBV �13 dBV �11 dBV �13 dBV �3 dBV �6 dBV �4 dBV +6 dBV +3 dBV +4 dBV +6 dBV +8 dBV
+14 dBV +9 dBV
+11 dBV +16 dBV +15 dBV +21 dBV
+19 dBV
48
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Dynamic Range
Description
Specifications
Supplemental Information
34.4 to 44 GHz (1 MHz)
x
+24 dBV
a. Does not apply to Time Domain scan. b. RF Input 2 operates to 1 GHz. The DANL is nominally 11 dB higher for RF Input 2. c. Typical Indicated Noise including NFE = Typical DANL + RBW correction + Log Detector correction � DANL
Improvement with NFE +107. d. Indicated RBW is a 3 dB bandwidth. e. NFE is not part of the difference between warranted and typical specifications at this frequency.
Description
Specifications
DANL and Indicated Noise Improvement with Noise Floor Extensiona
Option 544 (mmW) Option 503, 508 or 526 (RF/W) RF Preselector off RF Input 1
20 MHz to 3.6 GHz 3.5 to 8.4 GHz
3.5 to 8.4 GHz 8.3 to 13.6 GHz
8.3 to 13.6 GHz 13.5 to 17.1 GHz 17.0 to 26.5 GHz
26.5 to 34.5 GHz 34.4 to 44 GHz
x
x
x
x
x
x
x
x
x
x
x
x
Supplemental Information
95th Percentile ( 2 )
Preamp off
7 dB 8 dB
6 dB 8 dB
8 dB 6 dB 7 dB
6 dB 6 dB
RF Input 2
20 MHz to 1 GHz
x
x
5 dB
RF Preselector on
RF Input 1
9 to 150 kHz
x
x
7 dB
150 kHz to 1 MHz
x
x
7 dB
1 to 2 MHz
x
x
9 dB
Keysight N9038B MXE Specification Guide
49
Keysight MXE EMI Receiver Dynamic Range
Description
Specifications
Supplemental Information
2 to 5 MHz
x
x
10 dB
5 to 8 MHz
x
x
9 dB
8 to 11 MHz
x
x
9 dB
11 to 14 MHz
x
x
9 dB
DANL and Indicated Noise Improvement with Noise Floor Extension (cont.)
14 to 17 MHz
x
x
9 dB
17 to 20 MHz
x
x
9 dB
20 to 24 MHz
x
x
10 dB
24 to 30 MHz
x
x
10 dB
30 to 70 MHz
x
x
9 dB
70 to 150 MHz
x
x
8 dB
150 to 300 MHz
x
x
9 dB
300 to 600 MHz
x
x
9 dB
600 MHz to 1 GHz
x
x
8 dB
1 to 2 GHz
x
x
9 dB
2 to 3.6 GHz
x
x
10 dB
3.5 to 8.4 GHz
x
8 dB
3.5 to 8.4 GHz
x
6 dB
8.3 to 13.6 GHz
x
8 dB
8.3 to 13.6 GHz
x
8 dB
13.5 to 17.1 GHz
x
x
6 dB
17.0 to 26.5 GHz
x
x
7 dB
26.5 to 34.5 GHz
x
6 dB
34.4 to 44 GHz
x
6 dB
a. This statement on the improvement in DANL is based on the accuracy of the fit of the noise floor model to the measured values of that noise. This measure of the performance correlates well with improvement versus frequency. The improvement actually measured and specified in "Examples of Effective DANL" usually meet these limits as well, but not with the confidence in some cases. Does not apply to Time Domain scan.
50
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Dynamic Range
Description
Specifications
Supplemental Information
DANL and Indicated Noise Improvement with Noise Floor Extensiona RF Preselector on
RF Input 2 9 to 150 kHz 150 kHz to 1 MHz 1 to 2 MHz 2 to 5 MHz
95th Percentile ( 2 )
Preamp off
6 dB 7 dB 10 dB 9 dB
5 to 8 MHz 8 to 11 MHz 11 to 14 MHz 14 to 17 MHz 17 to 20 MHz 20 to 24 MHz 24 to 30 MHz 30 to 70 MHz
8 dB 9 dB 9 dB 10 dB 9 dB 10 dB 10 dB 9 dB
70 to 150 MHz
9 dB
150 to 300 MHz
9 dB
300 to 600 MHz
9 dB
600 MHz to 1 GHz
9 dB
a. This statement on the improvement in DANL is based on the accuracy of the fit of the noise floor model to the measured values of that noise. This measure of the performance correlates well with improvement versus frequency. The improvement actually measured and specified in "Examples of Effective DANL" usually meet these limits as well, but not with the confidence in some cases. Does not apply to Time Domain scan.
Keysight N9038B MXE Specification Guide
51
Keysight MXE EMI Receiver Dynamic Range
Spurious Responses
Description
Specifications
Supplemental Information
Spurious Responses RF Preselector on and off
RF Input 1: to 44 GHz RF Input 2: to 1 GHz
Preamp Offa (see Band Overlaps on page 14)
Residual Responsesbc 200 kHz to 8.4 GHz (swept) Zero span or FFT or other frequencies Image Responses
-100 dBm
-100 dBm (nominal)
Tuned Freq (f)
Excitation Freq
10 MHz to 26.5 GHz
f+45 MHz
10 MHz to 3.6 GHz
f+10245 MHz
10 MHz to 3.6 GHz
f+645 MHz
3.5 to 13.6 GHz
f+645 MHz
13.5 to 17.1 GHz
f+645 MHz
17.0 to 22 GHz
f+645 MHz
22 to 26.5 GHz
f+645 MHz
26.5 to 34.5 GHz
f+645 MHz
34.4 to 44 GHz
f+645 MHz
Other Spurious Responses
Carrier Frequency 26.5 GHz
First RF Ordere ( f 10 MHz from carrier)
Higher RF Orderg (f 10 MHz from carrier)
Carrier Frequency >26.5 GHz
First RF Ordere (f 10 MHz from carrier)
Higher RF Orderg (f 10 MHz from carrier)
LO-Related Spurious Responses (f > 600 MHz from carrier 10 MHz to 3.6 GHz)
Mixer Leveld -10 dBm -10 dBm -10 dBm -10 dBm -10 dBm -10 dBm -10 dBm -30 dBm -30 dBm
-10 dBm
-40 dBm
-30 dBm
-30 dBm
-10 dBm
Response -80 dBc -80 dBc -80 dBc -78 dBc -74 dBc -70 dBc -68 dBc -70 dBc -60 dBc
-113 dBc (typical) -107 dBc (typical) -108 dBc (typical) -88 dBc (typical) -85 dBc (typical) -82 dBc (typical) -78 dBc (typical) -94 dBc (typical) -79 dBc (typical)
-80 dBc + 20 � log(Nf)
-80 dBc + 20 � log(Nf)
Includes IF feedthrough, LO harmonic mixing responses Includes higher order mixer responses
-90 dBc (nominal)
-90 dBc (nominal)
-60 dBc + 20 -90 dBc + 20 � log(N)
� log(Nf)
(typical)
52
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Dynamic Range
Description
Specifications
Supplemental Information
Sidebands, offset from CW signal
200 Hz
-76 dBch (nominal)
200 Hz to 3 kHz
-66 dBch (nominal)
3 kHz to 30 kHz
-65 dBc (nominal)
30 kHz to 10 MHz
-58 dBc (nominal)
a. The spurious response specifications only apply with the preamp turned off. When the preamp is turned on, performance is nominally the same as long as the mixer level is interpreted to be: Mixer Level = Input Level - Input Attenuation + Preamp Gain. Mixer Level for RF Input 2 = Input Level - 9 dB - Input Attenuation + Preamp Gain.
b. Input terminated, 0 dB input attenuation. c. RF Input 2 performance = RF Input 1 performance + 11 dB for Residual Responses. d. RF Input 1 Mixer Level = Input Level - Input Attenuation. RF Input 2 Mixer Level = Input Level � Input attenua-
tion � 9 dB. e. With first RF order spurious products, the indicated frequency will change at the same rate as the input, with
higher order, the indicated frequency will change at a rate faster than the input. f. N is the LO multiplication factor. g. RBW=100 Hz. With higher RF order spurious responses, the observed frequency will change at a rate faster
than the input frequency. h. Nominally -40 dBc under large magnetic (0.38 Gauss rms) or vibrational (0.21 g rms) environmental stimuli.
Keysight N9038B MXE Specification Guide
53
Keysight MXE EMI Receiver Dynamic Range
Second Harmonic Distortion
Description
Second Harmonic Distortiona (Input power = -9 dBm Input attenuation = 6 dB RF Input 1b)
Specifications
Option 544 (mmW)
Option 503, 508 or 526 (RF/W)
RF Preselector off Preamp off
SHIc
Source Frequency
10 MHz to 1.0 GHz 1.0 to 1.8 GHz 1.8 to 6.8 GHz
1.8 to 3 GHz 3 to 6.8 GHz 6.8 to 11 GHz 11 to 13.25 GHz 13.2 to 22 GHz RF Preselector on, Preamp off Source Frequency 10 to 30 MHz 30 to 500 MHz 500 MHz to 1 GHz 1 to 1.6 GHz 1.6 to 1.8 GHz
x x +45 dBm
x x +41 dBm
x
+65 dBm
x +58 dBm
x +60 dBm
x x +55 dBm
x x +50 dBm
x +44 dBm
x x +47 dBm x x +57 dBm x x +45 dBm x x +58 dBm x x +46 dBm
Supplemental Information
Typical
+54 dBm +50 dBm +68 dBm
+64 dBm +69 dBm +64 dBm +60 dBm +51 dBm
+50 dBm +63 dBm +47 dBm +70 dBm +52 dBm
54
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Dynamic Range
Description
Specifications
Supplemental Information
Second Harmonic Distortion RF Preselector on, Preamp off
Source Frequency (cont.)
1.8 to 6.8 GHz
x
+65 dBm
+68 dBm
1.8 to 3 GHz
x
+58 dBm
+64 dBm
3 to 6.8 GHz
x
+60 dBm
+69 dBm
6.8 to 11 GHz
x x +55 dBm
+64 dBm
11 to 13.25 GHz
x x +50 dBm
+60 dBm
13.2 to 22 GHz
x
+44 dBm
+51 dBm
a. When using Time Domain scan, all indicated values shown here are nominal values. b. RF Input 2 operates to 1 GHz. The second harmonic distortion intercept is nominally 9 dB higher for RF Input 2. c. SHI = second harmonic intercept.
Keysight N9038B MXE Specification Guide
55
Keysight MXE EMI Receiver Dynamic Range
Third Order Intermodulation
Description
Specifications
Supplemental Information
Third Order Intermodulationa (Tone separation > 5 times IF Prefilter Bandwidthb Verification conditionsc RF Input 1d)
RF Preselector off, Preamp off 10 to 100 MHz 100 to 400 MHz 400 MHz to 1.7 GHz
Intercepte 20 to 30�C +12 dBm +15 dBm +16 dBm
5 to 50�C +10 dBm +13 dBm +14 dBm
Typical +17 dBm +20 dBm +20 dBm
1.7 to 3.6 GHz 3.5 to 8.4 GHz 8.3 to 13.6 GHz 13.5 to 26.5 GHz 26.4 to 44 GHz RF Preselector on, Preamp off 10 to 30 MHz 30 MHz to 1 GHz
+16 dBm +15 dBm +15 dBm +10 dBm +10 dBm
+12 dBm +12.5 dBm
+14 dBm +13 dBm +13 dBm +8 dBm +8 dBm
+11 dBm +11.5 dBm
+19 dBm +18 dBm +18 dBm +14 dBm +13 dBm
+16 dBm +15 dBm
1 to 1.5 GHz
+12.5 dBm
+11.5 dBm
+14 dBm
1.5 to 3.6 GHz
+14.5 dBm
+13.5 dBm
+16 dBm
3.5 to 8.4 GHz
+15 dBm
+13 dBm
+18 dBm
8.3 to 13.6 GHz
+15 dBm
+13 dBm
+18 dBm
13.5 to 26.5 GHz
+10 dBm
+8 dBm
+14 dBm
26.4 to 44 GHz
+10 dBm
+8 dBm
+13 dBm
a. When using Time Domain scan, all indicated values shown here are nominal values. b. See the IF Prefilter Bandwidth table in the Gain Compression specifications on page 43. When the tone sepa-
ration condition is met, the effect on TOI of the setting of IF Gain is negligible. TOI is verified with IF Gain set to its best case condition, which is IF Gain = Low. c. TOI is verified with two tones, each at -14 dBm at the input with 4 dB input attenuation, spaced by 100 kHz. Time Domain scan nominal TOI values verified with two tones. each at-14 dBm at the input with 4 dB input attenuation, spaced by 50 MHz. d. RF Input 2 operates to 1 GHz. The intercept is nominally 9 dB higher for RF Input 2. e. TOI = third order intercept. The TOI is given by the mixer tone level (in dBm) minus (distortion/2) where distortion is the relative level of the distortion tones in dBc.
56
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Dynamic Range
Phase Noise
Description
Specifications
Supplemental Information
Phase Noise
Noise Sidebands
(Center Frequency = 1 GHza Best-case Optimizationb Internal Referencec)
Offset Frequency
20 to 30�C
Full range
10 Hz
-80 dBc/Hz (nominal)
100 Hz
-91 dBc/Hz
-90 dBc/Hz
-100 dBc/Hz (typical)
1 kHz
-112 dBc/Hz (nominal)
10 kHz
-113 dBc/Hz -113 dBc/Hz -114 dBc/Hz (typical)
100 kHz
-116 dBc/Hz -115 dBc/Hz -117 dBc/Hz (typical)
1 MHz
-135 dBc/Hz -134 dBc/Hz -136 dBc/Hz (typical)
10 MHzd
-148 dBc/Hz (nominal)
a. The nominal performance of the phase noise at center frequencies different than the one at which the specifications apply (1 GHz) depends on the center frequency, band and the offset. For low offset frequencies, offsets well under 100 Hz, the phase noise increases by 20 � log[(f + 0.3225)/1.3225]. For mid-offset frequencies such as 10 kHz, band 0 phase noise changes as 20 � log[(f + 5.1225)/6.1225]. For mid-offset frequencies in other bands, phase noise changes as 20 � log[(f + 0.3225)/6.1225] except f in this expression should never be lower than 5.8. For wide offset frequencies, offsets above about 100 kHz, phase noise increases as 20 � log(N). N is the LO Multiple as shown on page 14; f is in GHz units in all these relationships; all increases are in units of decibels.
b. Noise sidebands for lower offset frequencies, for example, 10 kHz, apply with the phase noise optimization (PhNoise Opt) set to Best Close-in Noise. Noise sidebands for higher offset frequencies, for example, 1 MHz, as shown apply with the phase noise optimization set to Best Wide-offset Noise.
c. Specifications are given with the internal frequency reference. The phase noise at offsets below 100 Hz is impacted or dominated by noise from the reference. Thus, performance with external references will not follow the curves and specifications. The internal 10 MHz reference phase noise is about �120 dBc/Hz at 10 Hz offset; external references with poorer phase noise than this will cause poorer performance than shown.
d. Analyzer-contributed phase noise at the low levels of this offset requires advanced verification techniques because broadband noise would otherwise cause excessive measurement error. Keysight uses a high level low phase noise CW test signal and sets the input attenuator so that the mixer level will be well above the normal top-of-screen level (-10 dBm) but still well below the 1 dB compression level. This improves dynamic range (carrier to broadband noise ratio) at the expense of amplitude uncertainty due to compression of the phase noise sidebands of the analyzer. (If the mixer level were increased to the "1 dB Gain Compression Point," the compression of a single sideband is specified to be 1 dB or lower. At lower levels, the compression falls off rapidly. The compression of phase noise sidebands is substantially less than the compression of a single-sideband test signal, further reducing the uncertainty of this technique.) Keysight also measures the broadband noise of the analyzer without the CW signal and subtracts its power from the measured phase noise power. The same techniques of overdrive and noise subtraction can be used in measuring a DUT, of course.
Keysight N9038B MXE Specification Guide
57
Keysight MXE EMI Receiver Dynamic Range
Nominal Phase Noise at Different Center Frequencies [Plot]
58
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Power Suite Measurements (RF Preselector off only)
Power Suite Measurements (RF Preselector off only)
Description Channel Power Amplitude Accuracy
Specifications
Case: Radio Std = 3GPP W-CDMA, or IS-95
Absolute Power Accuracy (20 to 30�C, Attenuation = 10 dB)
�0.82 dB
a. See "Absolute Amplitude Accuracy" on page 35. b. See "Frequency and Time" on page 14. c. Expressed in dB.
Supplemental Information
Absolute Amplitude Accuracya + Power Bandwidth Accuracybc
�0.23 dB (95th percentile)
Description Occupied Bandwidth Frequency Accuracy
Specifications
Supplemental Information
�(Span/1000) (nominal)
Keysight N9038B MXE Specification Guide
59
Keysight MXE EMI Receiver Power Suite Measurements (RF Preselector off only)
Description Adjacent Channel Power (ACP) Case: Radio Std = None Accuracy of ACP Ratio (dBc) Accuracy of ACP Absolute Power
(dBm or dBm/Hz)
Accuracy of Carrier Power (dBm), or Carrier Power PSD (dBm/Hz)
Passband Widthe Case: Radio Std = 3GPP W-CDMA Minimum power at RF Input ACPR Accuracyg
Radio MS (UE)
Offset Freq 5 MHz
Specifications -3 dB �0.14 dB
MS (UE)
10 MHz
�0.21 dB
BTS
5 MHz
BTS
10 MHz
�0.49 dBh �0.44 dB
BTS
5 MHz
Dynamic Range
�0.21 dB
Noise Correction Off Off Off On On On
Offset Freq 5 MHz 5 MHz 10 MHz 5 MHz 5 MHz 10 MHz
Method
Filtered IBW Fast Filtered IBW Filtered IBW Filtered IBW Filtered IBW
Supplemental Information RF Input 1, RF Preselector Off
Display Scale Fidelitya Absolute Amplitude Accuracyb + Power Bandwidth Accuracycd Absolute Amplitude Accuracyb + Power Bandwidth Accuracycd
(ACPR; ACLR)f -36 dBm (nominal) RRC weighted, 3.84 MHz noise bandwidth, method RBW
At ACPR range of -30 to -36 dBc with optimum mixer levelh
At ACPR range of -40 to -46 dBc with optimum mixer leveli
At ACPR range of -42 to -48 dBc with optimum mixer levelj
At ACPR range of -47 to -53 dBc with optimum mixer leveli
At -48 dBc non-coherent ACPRk
RRC weighted, 3.84 MHz noise bandwidth
ACLR (typical)l
Optimum MLm (Nominal)
-73 dB
-8 dBm
-72 dB
-9 dBm
-79 dB
-2 dBm
-78 dB
-8 dBm
-78 dBn
-8 dBm
-82 dB
-2 dBm
60
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Power Suite Measurements (RF Preselector off only)
Description
Specifications
Supplemental Information
RRC Weighting Accuracyo White noise in Adjacent Channel TOI-induced spectrum rms CW error
0.00 dB nominal 0.001 dB nominal 0.012 dB nominal
a. The effect of scale fidelity on the ratio of two powers is called the relative scale fidelity. The scale fidelity specified in the Amplitude section is an absolute scale fidelity with �35 dBm at the input mixer as the reference point. The relative scale fidelity is nominally only 0.01 dB larger than the absolute scale fidelity.
b. See Amplitude Accuracy and Range section. c. See Frequency and Time section. d. Expressed in decibels. e. An ACP measurement measures the power in adjacent channels. The shape of the response versus frequency of
those adjacent channels is occasionally critical. One parameter of the shape is its 3 dB bandwidth. When the bandwidth (called the Ref BW) of the adjacent channel is set, it is the 3 dB bandwidth that is set. The passband response is given by the convolution of two functions: a rectangle of width equal to Ref BW and the power response versus frequency of the RBW filter used. Measurements and specifications of analog radio ACPs are often based on defined bandwidths of measuring receivers, and these are defined by their -6 dB widths, not their -3 dB widths. To achieve a passband whose -6 dB width is x, set the Ref BW to be x - 0.572 � RBW. f. Most versions of adjacent channel power measurements use negative numbers, in units of dBc, to refer to the power in an adjacent channel relative to the power in a main channel, in accordance with ITU standards. The standards for W-CDMA analysis include ACLR, a positive number represented in dB units. In order to be consistent with other kinds of ACP measurements, this measurement and its specifications will use negative dBc results, and refer to them as ACPR, instead of positive dB results referred to as ACLR. The ACLR can be determined from the ACPR reported by merely reversing the sign. g. The accuracy of the Adjacent Channel Power Ratio will depend on the mixer drive level and whether the distortion products from the analyzer are coherent with those in the UUT. These specifications apply even in the worst case condition of coherent analyzer and UUT distortion products. For ACPR levels other than those in this specifications table, the optimum mixer drive level for accuracy is approximately -37 dBm - (ACPR/3), where the ACPR is given in (negative) decibels. h. To meet this specified accuracy when measuring mobile station (MS) or user equipment (UE) within 3 dB of the required -33 dBc ACPR, the mixer level (ML) must be optimized for accuracy. This optimum mixer level is -22 dBm, so the input attenuation must be set as close as possible to the average input power - (-22 dBm). For example, if the average input power is -6 dBm, set the attenuation to 16 dB. This specification applies for the normal 3.5 dB peak-to-average ratio of a single code. Note that, if the mixer level is set to optimize dynamic range instead of accuracy, accuracy errors are nominally doubled. i. ACPR accuracy at 10 MHz offset is warranted when the input attenuator is set to give an average mixer level of -14 dBm. j. In order to meet this specified accuracy, the mixer level must be optimized for accuracy when measuring node B Base Transmission Station (BTS) within 3 dB of the required -45 dBc ACPR. This optimum mixer level is -19 dBm, so the input attenuation must be set as close as possible to the average input power - (-19 dBm). For example, if the average input power is -7 dBm, set the attenuation to 12 dB. This specification applies for the normal 10 dB peak-to-average ratio (at 0.01% probability) for Test Model 1. Note that, if the mixer level is set to optimize dynamic range instead of accuracy, accuracy errors are nominally doubled. k. Accuracy can be excellent even at low ACPR levels assuming that the user sets the mixer level to optimize the dynamic range, and assuming that the analyzer and UUT distortions are incoherent. When the errors from the UUT and the analyzer are incoherent, optimizing dynamic range is equivalent to minimizing the contribution of analyzer noise and distortion to accuracy, though the higher mixer level increases the display scale fidelity errors. This incoherent addition case is commonly used in the industry and can be useful for comparison of analysis equipment, but this incoherent addition model is rarely justified. This derived accuracy specification is based on a mixer level of -14 dBm.
Keysight N9038B MXE Specification Guide
61
Keysight MXE EMI Receiver Power Suite Measurements (RF Preselector off only)
l. Keysight measures 100% of the signal analyzers for dynamic range in the factory production process. This measurement requires a near-ideal signal, which is impractical for field and customer use. Because field verification is impractical, Keysight only gives a typical result. More than 80% of prototype instruments met this "typical" specification; the factory test line limit is set commensurate with an on-going 80% yield to this typical. The ACPR dynamic range is verified only at 2 GHz, where Keysight has the near-perfect signal available. The dynamic range is specified for the optimum mixer drive level, which is different in different instruments and different conditions. The test signal is a 1 DPCH signal. The ACPR dynamic range is the observed range. This typical specification includes no measurement uncertainty.
m. ML is Mixer Level, which is defined to be the input signal level minus attenuation. n. All three production units hand-measured had performance better than 88 dB with a test signal even better
than the "near-ideal" one used for statistical process control in production mentioned in the footnotel above. Therefore, this value can be considered "Nominal" not "Typical" by the definitions used within this document. These observations were done near 2 GHz because that is a common W-CDMA operating region in which the analyzer third-order dynamic range is near its best. o. 3GPP requires the use of a root-raised-cosine filter in evaluating the ACLR of a device. The accuracy of the passband shape of the filter is not specified in standards, nor is any method of evaluating that accuracy. This footnote discusses the performance of the filter in this instrument. The effect of the RRC filter and the effect of the RBW used in the measurement interact. The analyzer compensates the shape of the RRC filter to accommodate the RBW filter. The effectiveness of this compensation is summarized in three ways: - White noise in Adj Ch: The compensated RRC filter nominally has no errors if the adjacent channel has a spectrum that is flat across its width. - TOI-induced spectrum: If the spectrum is due to third-order intermodulation, it has a distinctive shape. The computed errors of the compensated filter are -0.001 dB for the 100 kHz RBW used for UE testing with the IBW method. It is 0.000 dB for the 27 kHz RBW filter used for BTS testing with the Filtered IBW method. The worst error for RBWs between 27 and 390 kHz is 0.05 dB for a 330 kHz RBW filter. - rms CW error: This error is a measure of the error in measuring a CW-like spurious component. It is evaluated by computing the root of the mean of the square of the power error across all frequencies within the adjacent channel. The computed rms error of the compensated filter is 0.012 dB for the 100 kHz RBW used for UE testing with the IBW method. It is 0.000 dB for the 27 kHz RBW filter used for BTS testing. The worst error for RBWs between 27 kHz and 470 kHz is 0.057 dB for a 430 kHz RBW filter.
62
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Power Suite Measurements (RF Preselector off only)
Description
Specifications
Supplemental Information
Multi-Carrier Adjacent Channel Power Case: Radio Std = 3GPP W-CDMA ACPR Dynamic Range
(5 MHz offset, Two carriers) ACPR Accuracy
(Two carriers, 5 MHz offset, -48 dBc ACPR)
RF Input 1, RF Preselector Off
RRC weighted, 3.84 MHz noise bandwidth -70 dB (nominal)
�0.42 dB (nominal)
ACPR Accuracy (4 carriers)
Radio
Offset Cohera NC
UUT ACPR Range MLOptb
BTS
5 MHz no
Off �0.39 dB
-42 to -48 dB
-18 dBm
BTS
5 MHz no
On �0.15 dB
-42 to -48 dB
-21 dBm
ACPR Dynamic Range (4 carriers, 5 MHz offset)
Nominal DR
Nominal MLOptc
Noise Correction (NC) off Noise Correction (NC) on
-64 dB -72 dB
-18 dBm -21 dBm
a. Coher = no means that the specified accuracy only applies when the distortions of the device under test are not coherent with the third-order distortions of the analyzer. Incoherence is often the case with advanced multi-carrier amplifiers built with compensations and predistortions that mostly eliminate coherent third-order effects in the amplifier.
b. Optimum mixer level (MLOpt). The mixer level is given by the average power of the sum of the four carriers minus the input attenuation.
c. Optimum mixer level (MLOpt). The mixer level is given by the average power of the sum of the four carriers minus the input attenuation.
Description
Specifications
Supplemental Information
Power Statistics CCDF
Histogram Resolutiona
0.01 dB
a. The Complementary Cumulative Distribution Function (CCDF) is a reformatting of a histogram of the power envelope. The width of the amplitude bins used by the histogram is the histogram resolution. The resolution of the CCDF will be the same as the width of those bins.
Keysight N9038B MXE Specification Guide
63
Keysight MXE EMI Receiver Power Suite Measurements (RF Preselector off only)
Description Burst Power Methods
Results
Specifications
Description TOI (Third Order Intermodulation) Results
Description Harmonic Distortion Maximum harmonic number Results
Specifications
Relative IM tone powers (dBc) Absolute tone powers (dBm) Intercept (dBm)
Specifications
10th Fundamental Power (dBm) Relative harmonics power (dBc) Total harmonic distortion (%, dBc)
Supplemental Information Power above threshold Power within burst width Output power, average Output power, single burst Maximum power Minimum power within burst Burst width
Supplemental Information Measures TOI of a signal with two dominant tones
Supplemental Information
64
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Power Suite Measurements (RF Preselector off only)
Description
Specifications
Supplemental Information
Spurious Emissions Case: Radio Std = 3GPP W-CDMA
Table-driven spurious signals; search across regions
Dynamic Rangea (1 to 3.6 GHz)
96.7 dB
101.7 dB (typical)
Sensitivity, absolute (1 to 3.6 GHz)
-85.4 dBm
Accuracy
Attenuation = 10 dB
20 Hz to 3.6 GHz
�0.29 dB (95th Percentile)
3.5 to 8.4 GHz
�1.17 dB (95th Percentile)
8.3 to 13.6 GHz
�1.54 dB (95th Percentile)
a. The dynamic range is specified with the mixer level at +3 dBm, where up to 1 dB of compression can occur, degrading accuracy by 1 dB.
Keysight N9038B MXE Specification Guide
65
Keysight MXE EMI Receiver Power Suite Measurements (RF Preselector off only)
Description
Specifications
Supplemental Information
Spectrum Emission Mask
Case: Radio Std = cdma2000 Dynamic Range, relative
(750 kHz offsetab) Sensitivity, absolute
(750 kHz offsetc) Accuracy
(750 kHz offset)
78.9 dB -100.7 dBm
Table-driven spurious signals; measurement near carriers 85.0 dB (typical)
Relatived Absolutee
(20 to 30�C)
�0.12 dB �0.88 dB
�0.27 dB (95th Percentile 2)
Case: Radio Std = 3GPP W-CDMA
Dynamic Range, relative (2.515 MHz offsetad)
Sensitivity, absolute (2.515 MHz offsetc)
81.9 dB -100.7 dBm
88.2 dB (typical)
Accuracy (2.515 MHz offset)
Relatived
�0.12 dB
Absolutee (20 to 30�C)
�0.86 dB
�0.27 dB (95th Percentile 2)
a. The dynamic range specification is the ratio of the channel power to the power in the offset specified. The dynamic range depends on the measurement settings, such as peak power or integrated power. Dynamic range specifications are based on default measurement settings, with detector set to average, and depend on the mixer level. Default measurement settings include 30 kHz RBW.
b. This dynamic range specification applies for the optimum mixer level, which is about -18 dBm. Mixer level is defined to be the average input power minus the input attenuation.
c. The sensitivity is specified with 0 dB input attenuation. It represents the noise limitations of the analyzer. It is tested without an input signal. The sensitivity at this offset is specified in the default 30 kHz RBW, at a center frequency of 2 GHz.
d. The relative accuracy is a measure of the ratio of the power at the offset to the main channel power. It applies for spectrum emission levels in the offsets that are well above the dynamic range limitation.
e. The absolute accuracy of SEM measurement is the same as the absolute accuracy of the spectrum analyzer. See "Absolute Amplitude Accuracy" on page 35 for more information. The numbers shown are for 0 to 3.6 GHz, with attenuation set to 10 dB.
66
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Options
Options
Option 503: Option 508: Option 526: Option 544: Option B1X: Option B25: Option B85: Option CR3: Option ESC: Option EXM: Option P03: Option P08: Option P26: Option P44: Option PFR: Option RT1 Option SS1: Option TDS: Option YAS: N9063EMOE: N9068EMOE: N9069EMOE:
The following options and applications affect instrument specifications.
Frequency range, 3 Hz to 3.6 GHz Frequency range, 3 Hz to 8.4 GHz Frequency range, 3 Hz to 26.5 GHz Frequency range, 3 Hz to 44 GHz Analysis bandwidth, 160 MHz Analysis bandwidth, 25 MHz Analysis bandwidth, 85 MHz Connector Rear, 2nd IF output External Source Control External Mixing Preamplifier option Preamplifier option Preamplifier option Preamplifier option Precision Frequency Reference Real Time Analysis up to 160 MHz BW, basic detection license Additional removable solid state drive Time Domain Scan Y-Axis Screen Video output Analog Demodulation measurement application Phase Noise measurement application Noise Figure measurement application
Keysight N9038B MXE Specification Guide
67
Keysight MXE EMI Receiver General
General
Description Calibration Cycle
Specifications 1 year
Supplemental Information
Description
Specifications
Supplemental Information
Environmental Indoor use
Temperature Range
Operating
Altitude 2,300 m
0 to 55�C
Altitude = 4,500 m
0 to 47�C
Deratinga
Storage
-40 to +70�C
Altitude
4,600 m (approx 15,000 feet)
Humidity Relative humidity
Type tested at 95%, +40�C (non-condensing) Maximum Relative Humidity (non-condensing): 95%RH up to 40�C, decreases linearly to 45%RH at 55�C
a. The maximum operating temperature derates linearly from altitude of 4,600 m to 2,300 m.
Description Environmental
Specifications
Supplemental Information Samples of this product have been type tested in accordance with the Keysight Environmental Test Manual and verified to be robust against the environmental stresses of Storage, Transportation and End-use; those stresses include but are not limited to temperature, humidity, shock, vibration, altitude and power line conditions. Test Methods are aligned with IEC 60068-2 and levels are similar to MIL-PRF-28800F Class 3.
68
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver General
Description Screening Effectiveness
Specifications Instrument meets CISPR16-1-1 requirements for Screening Effectiveness with exceptions at f = finput
Supplemental Information
Description Acoustic Noise
Ambient Temperature < 40�C
40�C
Specification
Supplemental Information Values given are per ISO 7779 standard in the "Operator Sitting" position
Nominally under 55 dBA Sound Pressure. 55 dBA is generally considered suitable for use in quiet office environments. Nominally under 65 dBA Sound Pressure. 65 dBA is generally considered suitable for use in noisy office environments. (The fan speed, and thus the noise level, increases with increasing ambient temperature.)
Description Power Requirements Low Range
Voltage Frequency High Range Voltage Frequency Power Consumption, On Power Consumption, Standby
Specification
100/120 V 50, 60 or 400 Hz
220/240 V 50 or 60 Hz 450 W 20 W
Supplemental Information
Fully loaded with options Standby power is not supplied to frequency reference oscillator.
Keysight N9038B MXE Specification Guide
69
Keysight MXE EMI Receiver General
Description Measurement Speeda
Supplemental Information Nominal
Local measurement and display update ratebc
4 ms (250/s)
Remote measurement and LAN transfer ratebc
5 ms (200/s)
Marker Peak Search
1.5 ms
Center Frequency Tune and Transfer (RF)
20 ms
Center Frequency Tune and Transfer (�W)
47 ms
Measurement/Mode Switching
39 ms
W-CDMA ACLR measurement time
See page 60
a. Sweep Points = 101. b. Factory preset, fixed center frequency, RBW = 1 MHz, 10 MHz < span 600 MHz, stop frequency 3.6 GHz,
Auto Align Off. c. Phase Noise Optimization set to Fast Tuning, Display Off, 32 bit integer format, markers Off, single sweep, mea-
sured with IBM compatible PC with 2.99 GHz Pentium� 4 with 2 GB RAM running Windows� XP, Keysight I/O Libraries Suite Version 14.1, one meter GPIB cable, National Instruments PCI-GPIB Card and NI-488.2 DLL.
Description
Specifications
Supplemental Information
Radio Disturbance Measuring Apparatus
CISPR 16-1-1:2019
The features in this instrument comply with the performance requirements of this basic standard.a
a. The use of Noise Floor Extension (NFE) is required to meet the "isolated pulse" test case in Bands B, C, and D. In addition, when making measurements in Band B below 160 k Hz using Time Domain scans or making measurements using meters in Monitor Spectrum, NFE is also required to meet the 1 Hz pulse repetition frequency (p.r.f.) test case for the quasi-peak detector (QPD) and for the 5 Hz p.r.f. test case for the RMS-Average detector.
Description
Specifications
Supplemental Information
Displaya
Resolution
1280 � 800
Capacitive multi-touch screen
Size
269 mm (10.6 in) diagonal (nominal)
a. The LCD display is manufactured using high precision technology. However, if a static image is displayed for a lengthy period of time (~2 hours) you might encounter "image sticking" that may last for approximately 2 seconds. This is normal and does not affect the measurement integrity of the product in any way.
70
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver General
Description Data Storage
Internal Total Internal User
Specifications
Description Weight Net Shipping
Cabinet Dimensions Height Width Length
Specifications
177 mm (7 inches) 426 mm (16.8 inches) 556 mm (21.9 inches)
Supplemental Information
Removable solid state drive (> 80 GB) > 9 GB available on separate partition for user data
Supplemental Information Weight without options 24 kg (52 lbs) (nominal) 36 kg (79 lbs) (nominal)
Cabinet dimensions exclude front and rear protrusions.
Keysight N9038B MXE Specification Guide
71
Keysight MXE EMI Receiver Inputs/Outputs
Inputs/Outputs
Front Panel
Description RF Input Connector RF Input 1
Impedance RF Input 2
Impedance
Specifications
Type-N female (standard) 3.5 mm male (Option C35) 2.4 mm male (Option 544)
Type-N female only
Supplemental Information
Option C35 is only available with Option 526 50 (nominal) 50 (nominal)
Description Probe Power Voltage/Current
Specifications
Supplemental Information
+15 Vdc, �7% at 0 to 150 mA (nominal) -12.6 Vdc, �10% at 0 to 150 mA (nominal) GND
Description USB Ports Host (3 ports)
Connector Output Current
Port marked with Lightning Bolt Port not marked with Lightning Bolt
Specifications USB Type "A" (female) 0.5 A
Supplemental Information Compliant with USB 2.0 1.2 A (nominal)
Description Headphone Jack Connector Output Power
Specifications miniature stereo audio jack
Supplemental Information
3.5 mm (also known as "1/8 inch") 90 mW per channel into 16 (nominal)
72
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Inputs/Outputs
Rear Panel
Description 10 MHz Out Connector Impedance Output Amplitude Output Configuration Frequency
Specifications
Supplemental Information
BNC female
AC coupled, sinusoidal 10 MHz � (1 + frequency reference accuracy)
50 (nominal) 0 dBm (nominal)
Description Ext Ref In Connector
Specifications BNC female
Impedance Input Amplitude Range
sine wave square wave Input Frequency
Lock range
�2 � 10-6 of ideal external reference input frequency
Supplemental Information
Note: Receiver noise sidebands and spurious response performance may be affected by the quality of the external reference used. See footnotec in the Phase Noise specifications within the Dynamic Range section on page 57. 50 (nominal)
-5 to +10 dBm (nominal) 0.2 to 1.5 V peak-to-peak (nominal) 1 to 50 MHz (nominal) (selectable to 1 Hz resolution)
Description Sync Connector
Specifications BNC female
Supplemental Information Reserved for future use
Keysight N9038B MXE Specification Guide
73
Keysight MXE EMI Receiver Inputs/Outputs
Description Trigger Inputs
(Trigger 1 In, Trigger 2 In) Connector Impedance Trigger Level Range
Specifications BNC female -5 to +5 V
Supplemental Information Either trigger source may be selected
10 k (nominal) 1.5 V (TTL) factory preset
Description Trigger Outputs
(Trigger 1 Out, Trigger 2 Out) Connector Impedance Level
Specifications BNC female
Supplemental Information
50 (nominal) 0 to 5 V (CMOS)
Description Monitor Output 1 VGA compatible Connector Format
Monitor Output 2 Mini DisplayPort
Specifications
Supplemental Information
15-pin mini D-SUB
XGA (60 Hz vertical sync rates, non-interlaced) Analog RGB
Description Analog Out
Connector Impedance
Specifications BNC female
Supplemental Information Refer to Chapter 11, "Option YAS - Y-Axis Screen Video Output", on page 149 for more information.
<140 (nominal)
74
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Inputs/Outputs
Description Noise Source Drive +28 V (Pulsed) Connector Output voltage on Output voltage off
Specifications
BNC female 28.0 � 0.1 V < 1.0 V
Supplemental Information 60 mA maximum current
Description SNS Series Noise Source
Specifications
Supplemental Information For use with Keysight Technologies SNS Series noise sources
Description USB Ports Host, Super Speed
Compatibilty Connector Output Current Host, stacked with LAN Compatibility Connector Output Current Device Compatibility Connector
Specifications
USB 3.0 USB Type "A" (female) 0.9 A
USB 2.0 USB Type "A" (female) 0.5 A
USB 3.0 USB Type "B" (female)
Supplemental Information 2 ports 1 port 1 port
Description GPIB Interface Connector GPIB Codes
Mode
Specifications IEEE-488 bus connector
Supplemental Information
SH1, AH1, T6, SR1, RL1, PP0, DC1, C1, C2, C3 and C28, DT1, L4, C0 Controller or device
Description LAN TCP/IP Interface
Specifications RJ45 Ethertwist
Supplemental Information 1000 BaseT
Keysight N9038B MXE Specification Guide
75
Keysight MXE EMI Receiver Inputs/Outputs
Description Aux I/O Connector
Specifications 25-pin D-SUB
Supplemental Information
76
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Regulatory Information
Regulatory Information
This product is designed for use in INSTALLATION CATEGORY II and POLLUTION DEGREE 2 and MEASUREMENT CATEGORY NONE per IEC 61010 3rd ed, and 664 respectively. This product has been designed and tested in accordance with accepted industry standards, and has been supplied in a safe condition. The instruction documentation contains information and warnings which must be followed by the user to ensure safe operation and to maintain the product in a safe condition. This product is intended for indoor use.
ccr.keysight@keysight.com
ICES/NMB-001
ISM 1-B (GRP.1 CLASS B)
The CE mark is a registered trademark of the European Community (if accompanied by a year, it is the year when the design was proven). This product complies with all relevant directives. The Keysight email address is required by EU directives applicable to our product. "This ISM device complies with Canadian ICES-001." "Cet appareil ISM est conforme a la norme NMB du Canada." This is a symbol of an Industrial Scientific and Medical Group 1 Class B product. (CISPR 11, Clause 4) The CSA mark is a registered trademark of the CSA International.
The RCM mark is a registered trademark of the Australian Communications and Media Authority. This symbol indicates separate collection for electrical and electronic equipment mandated under EU law as of August 13, 2005. All electric and electronic equipment are required to be separated from normal waste for disposal (Reference WEEE Directive 2002/96/EC).
China RoHS regulations include requirements related to packaging, and require compliance to China standard GB18455-2001. This symbol indicates compliance with the China RoHS regulations for paper/fiberboard packaging. South Korean Certification (KC) mark; includes the marking's identifier code which follows this format: R-R-Kst--ZZZZZZZZZZZZZZ.
Keysight N9038B MXE Specification Guide
77
Keysight MXE EMI Receiver Regulatory Information
EMC: Complies with the essential requirements of the European EMC Directive as well as current editions of the following standards (dates and editions are cited in the Declaration of Conformity): -- IEC/EN 61326-1 -- CISPR 11, Group 1, class B -- AS/NZS CISPR 11 -- ICES/NMB-001 This ISM device complies with Canadian ICES-001. Cet appareil ISM est conforme a la norme NMB-001 du Canada.
This is a sensitive measurement apparatus by design and may have some performance loss (up to 40 dB in the range 80 MHz - 6 GHz, above the Spurious Responses, Residual Responses specification of -100 dBm) when in the presence of ambient electromagnetic field of 3V/m.
SAFETY: Complies with the essential requirements of the European Low Voltage Directive as well as current editions of the following standards (dates and editions are cited in the Declaration of Conformity): -- IEC/EN 61010-1 -- Canada: CSA C22.2 No. 61010-1 -- USA: UL std no. 61010-1
78
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver Regulatory Information
Acoustic statement: (European Machinery Directive) Acoustic noise emission LpA <70 dB Operator position Normal operation mode per ISO 7779 To find a current Declaration of Conformity for a specific Keysight product, go to: http://www.keysight.com/go/conformity
Keysight N9038B MXE Specification Guide
79
Keysight MXE EMI Receiver Regulatory Information
80
Keysight N9038B MXE Specification Guide
Keysight X-Series MXE EMI Receiver N9038B Specification Guide
2 I/Q Analyzer
This chapter contains specifications for the I/Q Analyzer measurement application (Basic Mode).
81
I/Q Analyzer Specifications Affected by I/Q Analyzer:
Specifications Affected by I/Q Analyzer:
The specifications in this chapter apply for RF Input 1 and RF Preselector off.
Specification Name Number of Frequency Display Trace Points (buckets) Resolution Bandwidth Video Bandwidth Clipping-to-Noise Dynamic Rangea
Resolution Bandwidth Switching Uncertainty Available Detectors
Information Does not apply.
See "Frequency" on page 83 in this chapter. Not available. See "Clipping-to-Noise Dynamic Range" on page 84 in this chapter. Not specified because it is negligible. Does not apply.
Spurious Responsesa
The "Spurious Responses" on page 52 of core specifications still apply. Additional bandwidth-option-dependent spurious responses are given in the Analysis Bandwidth chapter for any optional bandwidths in use.
IF Amplitude Flatnessa
See "IF Frequency Response" on page 33 of the core specifications for the 10 MHz bandwidth. Specifications for wider bandwidths are given in the Analysis Bandwidth chapter for any optional bandwidths in use.
IF Phase Linearitya
See "IF Phase Linearity" on page 34 of the core specifications for the 10 MHz bandwidth. Specifications for wider bandwidths are given in the Analysis Bandwidth chapter for any optional bandwidths in use.
Data Acquisitiona
See "Data Acquisition" on page 85 in this chapter for the 10 MHz bandwidth. Specifications for wider bandwidths are given in the Analysis Bandwidth chapter for any optional bandwidths in use.
a. This specification addresses the performance of the IQ Analyzer using the 10 MHz analysis bandwidth. For IQ Analyzer performance specifications in the optional 25 MHz or 85 MHz analysis bandwidths, see the Option B25 or Option B85 chapter.
82
Keysight N9038B MXE Specification Guide
I/Q Analyzer Frequency
Frequency
Description Frequency Span Standard instrument Option B25 Option B85 Option B1X Resolution Bandwidth
(Spectrum Measurement) Range
Overall Span = 1 MHz Span = 10 kHz Span = 100 Hz Window Shapes
Analysis Bandwidth (Span) (Waveform Measurement)
Standard instrument Option B25 Option B85 Option B1X
Specifications
10 Hz to10 MHz 10 Hz to 25 MHz 10 Hz to 85 MHz 10 Hz to 160 MHz
Supplemental Information
100 mHz to 3 MHz 50 Hz to 1 MHz 1 Hz to 10 kHz 100 mHz to 100 Hz Flat Top, Uniform, Hanning, Hamming, Gaussian, Blackman, Blackman-Harris, Kaiser Bessel (K-B 70 dB, K-B 90 dB & K-B 110 dB)
10 Hz to 10 MHz 10 Hz to 25 MHz 10 Hz to 85 MHz 10 Hz to 160 MHz
Keysight N9038B MXE Specification Guide
83
I/Q Analyzer Clipping-to-Noise Dynamic Range
Clipping-to-Noise Dynamic Range
Description Clipping-to-Noise Dynamic Rangea
Specifications
Supplemental Information Excluding residuals and spurious responses
Clipping Level at Mixer IF Gain = Low IF Gain = High
-10 dBm -20 dBm
Center frequency 20 MHz -8 dBm (nominal) -17.5 dBm (nominal)
Noise Density at Mixer at center frequencyb
(DANLc + IFGainEffectd) + 2.25 dBe
Examplef
a. This specification is defined to be the ratio of the clipping level (also known as "ADC Over Range") to the noise density. In decibel units, it can be defined as clipping_level [dBm] - noise_density [dBm/Hz]; the result has units of dBfs/Hz (fs is "full scale").
b. The noise density depends on the input frequency. It is lowest for a broad range of input frequencies near the center frequency, and these specifications apply there. The noise density can increase toward the edges of the span. The effect is nominally well under 1 dB.
c. The primary determining element in the noise density is the "Displayed Average Noise Level" on page 44.
d. DANL is specified with the IF Gain set to High, which is the best case for DANL but not for Clipping-to-noise dynamic range. The core specifications "Displayed Average Noise Level" on page 44, gives a line entry on the excess noise added by using IF Gain = Low, and a footnote explaining how to combine the IF Gain noise with the DANL.
e. DANL is specified for log averaging, not power averaging, and thus is 2.51 dB lower than the true noise density. It is also specified in the narrowest RBW, 1 Hz, which has a noise bandwidth slightly wider than 1 Hz. These two effects together add up to 2.25 B.
f. As an example computation, consider this: For the case where DANL = -151 dBm in 1 Hz, IF Gain is set to low, and the "Additional DANL" is -160 dBm, the total noise density computes to -148.2 dBm/Hz and the Clipping-to-noise ratio for a -10 dBm clipping level is -138.2 dBfs/Hz.
84
Keysight N9038B MXE Specification Guide
I/Q Analyzer Data Acquisition
Data Acquisition
Description
Specifications
Supplemental Information
Time Record Length Sample Rate
8,000,000 IQ sample pairs 100 MSa/s
Waveform Measurementa
IF Path 25 MHz
Option B85 or B1X IQ Pairs
ADC Resolution
400 MSa/s 16 Bits
IF Path 85 MHz Integer submultiples of 15Mpairs/s depending on the span for spans of 8 MHz or narrower
IF Path 25 MHz
Option B85 or B1X
14 Bits
IF Path 85 MHz
a. This can also be accessed with the remote programming command of "read:wav0?".
Keysight N9038B MXE Specification Guide
85
I/Q Analyzer Data Acquisition
86
Keysight N9038B MXE Specification Guide
Keysight X-Series MXE EMI Receiver N9038B Specification Guide
3 Option TDS - Time Domain Scan
This chapter contains specifications for the Time Domain Scan measurement application.
87
Option TDS - Time Domain Scan Specifications Affected by Time Domain Scan:
Specifications Affected by Time Domain Scan:
Specification Name Absolute Amplitude Accuracy Total Measurement Uncertainty 1dB Gain Compression Point (Two-tone) Displayed Average Noise Level Indicated Noise (Receiver) DANL and Indicated Noise Improvement with Noise Floor Extension Second Harmonic Distortion Third Order Intermodulation
Information See "Absolute Amplitude Accuracy" on page 35 of the core specifications. See "Total Measurement Uncertainty" on page 39 of the core specifications. See "1 dB Gain Compression Point (Two-tone)" on page 42 of the core specifications. See "Displayed Average Noise Level" on page 44 of the core specifications See "Indicated Noise (Receiver)" on page 48 of the core specifications. See "DANL and Indicated Noise Improvement with Noise Floor Extension" on page 49 of the core specifications. See "Second Harmonic Distortion" on page 54 of the core specifications. See "Third Order Intermodulation" on page 56 of the core specifications.
88
Keysight N9038B MXE Specification Guide
Option TDS - Time Domain Scan General Specifications
General Specifications
Description Frequency Range Option 503 Option 508 Option 526 Option 544
Specifications
20 Hz to 3.6 GHz 20 Hz to 8.4 GHz 20 Hz to 26.5 GHz 20 Hz to 44 GHz
Supplemental Information
Description Trace Detectors Quasi-Peak, Peak, EMI-Average, RMS-Average Negative peak, Voltage Average
Specifications Meet CISPR 16-1-1:2019 requirements
Supplemental Information
Description
Specifications
TDS Measurement
Maximum FFT Bandwidth (Frequency segment processed in parallel)
20 Hz to 3.6 GHz
8 MHz
3.6 to 26.5 GHz
12.5 MHz
FFT overlap
> 92%
Measurement time
10 ms to 30 s
Trace Point Range
1 to 4,000,001
Frequency step size
0.25 � Resolution Bandwidth
Supplemental Information
Description
Resolution Bandwidth (RBW) EMI Bandwidths (CISPR compliant) EMI Bandwidths (MIL-STD-461 compliant) Other Bandwidths (�6 dB)
Specification
Supplemental Information
200 Hz, 9 kHz, 120 kHz, 1 MHz 10 Hz, 100 Hz, 1 kHz, 10 kHz, 100 kHz, 1 MHz 1 Hz, 30 Hz, 300 Hz, 3 kHz, 30 kHz, 300 kHz, 3 MHz, 10 MHz
Keysight N9038B MXE Specification Guide
89
Option TDS - Time Domain Scan General Specifications
Description RF Preselector Filters Filter Band 20 Hz to 150 kHz 150 kHz - 1 MHz 1 to 2 MHz 2 to 5 MHz 5 to 8 MHz 9 to 11 MHz 11 to 14 MHz 14 to 17 MHz 17 to 20 MHz 20 to 24 MHz 24 to 30 MHz 30 - 70 MHz 70 - 150 MHz 150 - 300 MHz 300 - 600 MHz 600 MHz - 1 GHz 1 to 2 GHz 2 to 3.6 GHz
Specification
Filter type Fixed Lowpass Fixed Bandpass Fixed Bandpass Fixed Bandpass Fixed Bandpass Fixed Bandpass Fixed Bandpass Fixed Bandpass Fixed Bandpass Fixed Bandpass Fixed Bandpass Tracking Bandpass Tracking Bandpass Tracking Bandpass Tracking Bandpass Tracking Bandpass Tracking Bandpass Fixed Highpass
Supplemental Information
6 dB Bandwidth (nominal) 310 kHz 1.7 MHz 2.4 MHz 7.5 MHz 10 MHz 9.5 MHz 9.5 MHz 10 MHz 9.5 MHz 9.5 MHz 9.0 MHz 10 MHz 24MHz 28MHz 50 MHz 60 MHz 180 MHz (-3 dB corner frequency) 1.89 GHz (-3 dB corner frequency)
90
Keysight N9038B MXE Specification Guide
Option TDS - Time Domain Scan General Specifications
Description
TDS Measurement Speed
CISPR band B, 150 kHz to 30 MHz, RBW = 9 kHz, measurement time = 100 ms, Peak Detector
CISPR band B, 150 kHz to 30 MHz, RBW = 9 kHz, measurement time = 1 s, Quasi-Peak Detector
CISPR band C/D, 30 MHz to 1000 MHz, RBW = 120 kHz, measurement time = 10 ms Peak Detector
CISPR band C/D, 30 MHz to 1000 MHz, RBW = 9 kHz, measurement time = 10 ms Peak Detector
CISPR band C/D, 30 MHz to 1000 MHz, RBW = 120 kHz, measurement time = 1 s, Quasi-Peak Detector
Specification Supplemental Information
12.1 s (nominal) 181.7 s (nominal) 3.1 s (nominal) 18.1 s (nominal) 211.5 s (nominal)
Keysight N9038B MXE Specification Guide
91
Option TDS - Time Domain Scan General Specifications
92
Keysight N9038B MXE Specification Guide
Keysight X-Series MXE EMI Receiver N9038B Specification Guide
4 Option B25 - 25 MHz Analysis Bandwidth
This chapter contains specifications for the Option B25, 25 MHz Analysis Bandwidth, and are unique to this IF Path.
93
Option B25 - 25 MHz Analysis Bandwidth Specifications Affected by Analysis Bandwidth
Specifications Affected by Analysis Bandwidth
The specifications in this chapter apply when the 25 MHz path is in use. In IQ Analyzer, this will occur when the IF Path is set to 25 MHz, whether by Auto selection (depending on Span) or manually. The specifications in this chapter apply for RF Input 1 and RF Preselector off.
Specification Name
Information
IF Frequency Response
See specifications in this chapter.
IF Phase Linearity
See specifications in this chapter.
Spurious and Residual Responses
The "Spurious Responses" on page 52 still apply. Further, bandwidth-option-dependent spurious responses are contained within this chapter.
Displayed Average Noise Level, Third-Order Intermodulation and Phase Noise
The performance of the analyzer will degrade by an unspecified extent when using this bandwidth option. This extent is not substantial enough to justify statistical process control.
94
Keysight N9038B MXE Specification Guide
Option B25 - 25 MHz Analysis Bandwidth Other Analysis Bandwidth Specifications
Other Analysis Bandwidth Specifications
Description
Specifications Supplemental Information
IF Spurious Responsea
Preamp Offb
IF Second Harmonic
Apparent Freq
Excitation Freq
Mixer Levelc IF Gain
Any on-screen f
(f + fc + 22.5 MHz)/2
-15 dBm
Low
-54 dBc (nominal)
-25 dBm
High
-54 dBc (nominal)
IF Conversion Image
Apparent Freq
Excitation Freq
Mixer Levelc
IF Gain
Any on-screen f
2 � fc - f + 45 MHz
-10 dBm
Low
-70 dBc (nominal)
-20 dBm
High
-70 dBc (nominal)
a. The level of these spurs is not warranted. The relationship between the spurious response and its excitation is described in order to make it easier for the user to distinguish whether a questionable response is due to these mechanisms. f is the apparent frequency of the spurious signal, fc is the measurement center frequency.
b. The spurious response specifications only apply with the preamp turned off. When the preamp is turned on, performance is nominally the same as long as the mixer level is interpreted to be Mixer Level = Input Level - Input Attenuation - Preamp Gain.
c. Mixer Level = Input Level - Input Attenuation.
Keysight N9038B MXE Specification Guide
95
Option B25 - 25 MHz Analysis Bandwidth Other Analysis Bandwidth Specifications
Description
Specifications
Supplemental Information
IF Frequency Responsea (Demodulation and FFT response relative to the center frequency)
Modes above 18 GHzb
Freq (GHz)
Analysis Widthc (MHz)
Max Errord (Exceptionse)
20 to 30�C
Full range
Midwidth Error (95th Percentile)
Slope (dB/MHz) (95th Percentile)
RMSf (nominal)
3.6
10 to 25
�0.45 dB
�0.45 dB �0.12 dB
�0.10
0.051 dB
3.6 to 44
10 to 25g
0.45 dB
a. The IF frequency response includes effects due to RF circuits such as input filters, that are a function of RF frequency, in addition to the IF passband effects.
b. Signal frequencies above 18 GHz are prone to additional response errors due to modes in the Type-N connector used. With the use of Type-N to APC 3.5 mm adapter part number 1250-1744, there are nominally six such modes. These modes cause nominally up to -0.35 dB amplitude change, with phase errors of nominally up to �1.2�. The effect of these modes is not included within the Max Error specification. The effect on the RMS is negligible, except to note that the modes make the ratio of worst-case error to RMS error unusually high.
c. This column applies to the instantaneous analysis bandwidth in use. In the Spectrum Analyzer Mode, this would be the FFT width.
d. The maximum error at an offset (f) from the center of the FFT width is given by the expression � [Midwidth Error + (f � Slope)], but never exceeds �Max Error. Here the Midwidth Error is the error at the center frequency for the given FFT span. Usually, the span is no larger than the FFT width in which case the center of the FFT width is the center frequency of the analyzer. In the Spectrum Analyzer mode, when the analyzer span is wider than the FFT width, the span is made up of multiple concatenated FFT results, and thus has multiple centers of FFT widths so the f in the equation is the offset from the nearest center. These specifications include the effect of RF frequency response as well as IF frequency response at the worst case center frequency. Performance is nominally three times better at most center frequencies.
e. The specification does not apply for frequencies greater than 3.6 MHz from the center in FFT widths of 7.2 to 8 MHz.
f. The "RMS" nominal performance is the standard deviation of the response relative to the center frequency, integrated across the span. This performance measure was observed at a center frequency in each harmonic mixing band, which is representative of all center frequencies; it is not the worst case frequency.
g. For information on the microwave preselector which affects the passband for frequencies above 3.6 GHz, see "Microwave Preselector Bandwidth" on page 26.
96
Keysight N9038B MXE Specification Guide
Option B25 - 25 MHz Analysis Bandwidth Other Analysis Bandwidth Specifications
Description
Specifications
Supplemental Information
IF Phase Linearity
Deviation from mean phase linearity
Center Freq (GHz)
Span (MHz)
Microwave Preselector
Nominal
RMS (nominal)a
0.02, <3.6
25
N/A
�0.5�
0.2�
3.6, 44
25
Off
�1.5�
0.4�
a. The listed performance is the standard deviation of the phase deviation relative to the mean phase deviation from a linear phase condition, where the RMS is computed across the span shown.
Description
Specification
Supplemental Information
Full Scale (ADC Clipping)a
Default settings, signal at CF
(IF Gain = Low)
Band 0
-8 dBm mixer levelb (nominal)
Band 1 through 4
-7 dBm mixer levelb (nominal)
High Gain setting, signal at CF
(IF Gain = High)
Band 0
-18 dBm mixer levelb (nominal), subject to gain limitationsc
Band 1 through 4
-17 dBm mixer levelb (nominal), subject to gain limitationsc
Effect of signal frequency CF
up to �3 dB (nominal)
a. This table is meant to help predict the full-scale level, defined as the signal level for which ADC overload (clipping) occurs. The prediction is imperfect, but can serve as a starting point for finding that level experimentally. A SCPI command is also available for that purpose.
b. Mixer level is signal level minus input attenuation. c. The available gain to reach the predicted mixer level will vary with center frequency. Combinations of high gains
and high frequencies will not achieve the gain required, increasing the full scale level.
Keysight N9038B MXE Specification Guide
97
Option B25 - 25 MHz Analysis Bandwidth Data Acquisition
Data Acquisition
Description Time Record Length (IQ pairs) IQ Analyzer 89600 VSA software
Sample Rate
Specifications
Supplemental Information
8,000,000 IQ sample pairs
32-bit Data Packing 536 MSa (229 Sa) 90 MSa/s
64-bit Data Packing 268 MSa (228 Sa)
Waveform Measurementa
Memory 256 MB
ADC Resolution
14 bits
a. This can also be accessed with the remote programming command of "read:wav0?".
98
Keysight N9038B MXE Specification Guide
Keysight X-Series MXE EMI Receiver N9038B Specification Guide
5 Option B85/B1X - 85/160 MHz Analysis Bandwidth
This chapter contains specifications for the Option B85/B1X, 85/160 MHz Analysis Bandwidth, and are unique to this IF Path.
99
Option B85/B1X - 85/160 MHz Analysis Bandwidth Specifications Affected by Analysis Bandwidth
Specifications Affected by Analysis Bandwidth
The specifications in this chapter apply when the 85 or 160 MHz path is in use. In IQ Analyzer, this will occur when the IF Path is set to 85 or 160 MHz, whether by Auto selection (depending on Span) or manually.
Specification Name IF Frequency Response IF Phase Linearity Spurious Responses
Displayed Average Noise Level Third-Order Intermodulation
Phase Noise Absolute Amplitude Accuracy Frequency Range Over Which Specifications Apply
Information See specifications in this chapter. See specifications in this chapter. There are three effects of the use of Option B85/B1X on spurious responses. Most of the warranted elements of the Spurious Responses on page 52 still apply without changes, but the revised-for-B85/B1X table is shown in its place in this chapter. The image responses part of that table have the same warranted limits, but apply at different frequencies as shown in the table. The "higher order RF spurs" line is slightly degraded. Also, spurious-free dynamic range specifications are given in this chapter, as well as IF Residuals. See specifications in this chapter. This bandwidth option can create additional TOI products to those that are created by other instrument circuitry. These products do not behave with typical analog third-order behavior, and thus cannot be specified in the same manner. Nominal performance statements are given in this chapter, but they cannot be expected to decrease as the cube of the voltage level of the signals. The performance of the analyzer will degrade by an unspecified extent when using wideband analysis. This extent is not substantial enough to justify statistical process control. Nominally 0.5 dB degradation from base instrument absolute amplitude accuracy. (Refer to Absolute Amplitude Accuracy on page 35.) Specifications on this bandwidth only apply with center frequencies of 100 MHz and higher.
100
Keysight N9038B MXE Specification Guide
Option B85/B1X - 85/160 MHz Analysis Bandwidth Other Analysis Bandwidth Specifications
Other Analysis Bandwidth Specifications
Description
Specifications
Supplemental Information
SFDR (Spurious-Free Dynamic Range) Signal Frequency and spurious response anywhere within 85 MHz BW
For 85 MHz analysis BW, Test conditionsa �76 dBc (nominal)
a. Signal level is �6 dB relative to full scale at the center frequency. See the Full Scale table.
Description
Specifications
Supplemental Information
SFDR (Spurious-Free Dynamic Range) Signal Frequency within �12 MHz of center
For 160 MHz analysis BW, Test conditionsa �72 dBc (nominal)
Signal Frequency anywhere within 160 MHz analysis BW
Spurious response within �63 MHz of center
-71 dBc (nominal)
Response anywhere within 160 MHz analysis BW
-69 dBc (nominal)
a. Signal level is �6 dB relative to full scale at the center frequency. See the Full Scale table.
Keysight N9038B MXE Specification Guide
101
Option B85/B1X - 85/160 MHz Analysis Bandwidth Other Analysis Bandwidth Specifications
Description Spurious Responsesa (see Band Overlaps on page 14) Residual Responsesc
Specifications
Supplemental Information Preamp Offb
-100 dBm (nominal)
Image Responses
Tuned Freq (f)
Excitation Freq Mixer Leveld
Response
10 MHz to 3.6 GHz
f+10200 MHz
-10 dBm
-77 dBc
�121 dBc (nominal)
10 MHz to 3.6 GHz
f+600 MHz
-10 dBm
-77 dBc
�124 dBc (nominal)
3.5 to 13.6 GHz
f+600 MHz
-10 dBm
-75 dBc
�93 dBc (nominal)
13.5 to 17.1 GHz
f+600 MHz
-10 dBm
-71 dBc
�88 dBc (nominal)
17.0 to 22 GHz
f+600 MHz
-10 dBm
-67 dBc
�88 dBc (nominal)
22 to 26.5 GHz
f+600 MHz
-10 dBm
-65 dBc
�85 dBc (nominal)
26.5 to 34.5 GHz
f+600 MHz
-30 dBm
-60 dBc
�80 dBc (nominal)
34.4 to 44 GHz
f+600 MHz
-30 dBm
-57 dBc
�80 dBc (nominal)
Other Spurious Responses Carrier Frequency 26.5 GHz
First RF Ordere (f 10 MHz from carrier)
-10 dBm
-80 dBc + 20 �116 dBc (nominal) � log(Nf)
Higher RF Orderg (f 10 MHz from carrier)
-40 dBm
-75 dBc + 20 �103 dBc (nominal) � log(Nf)
Carrier Frequency >26.5 GHz First RF Ordere (f 10 MHz from carrier)
-30 dBm
�101 dBc (nominal)
Higher RF Orderg (f 10 MHz from carrier)
-30 dBm
�100 dBc (nominal)
LO-Related Spurious Response Offset from carrier 200 Hz to 10 MHz
-10 dBm
�97 dBc (nominal)
Line-Related Spurious Responses
-73 dBc + 20 � log(Nf) (nominal)
a. Microwave preselector enabled for frequencies >3.6 GHz. b. The spurious response specifications only apply with the preamp turned off. When the preamp is turned on, per-
formance is nominally the same as long as the mixer level is interpreted to be: Mixer Level = Input Level - Input Attenuation - Preamp Gain c. Input terminated, 0 dB input attenuation.
102
Keysight N9038B MXE Specification Guide
Option B85/B1X - 85/160 MHz Analysis Bandwidth Other Analysis Bandwidth Specifications
d. Mixer Level = Input Level - Input Attenuation. Verify with mixer levels no higher than �12 dBm if necessary to avoid ADC overload.
e. With first RF order spurious products, the indicated frequency will change at the same rate as the input, with higher order, the indicated frequency will change at a rate faster than the input.
f. N is the LO multiplication factor. g. RBW=100 Hz. With higher RF order spurious responses, the observed frequency will change at a rate faster
than the input frequency.
Description IF Residual Responses
Band 0
Specifications
Supplemental Information Relative to full scale; see the Full Scale table for details. �96 dBFS (nominal)
Keysight N9038B MXE Specification Guide
103
Option B85/B1X - 85/160 MHz Analysis Bandwidth Other Analysis Bandwidth Specifications
Description
Specifications
Supplemental Information
IF Frequency Responsea
Relative to center frequency Modes above 18 GHzb
Center Freq (GHz)
Span (MHz)
Microwave Preselector
Typical
RMS (nominal)c
0.15, <3.6
85
n/a
�0.6 dB
�0.17 dB
0.05 dB
0.15, <3.6
160
n/a
�0.2 dB (nominal)
0.07 dB
>3.6
On
See noted
a. The IF frequency response includes effects due to RF circuits such as input filters, that are a function of RF frequency, in addition to the IF pass-band effects.
b. Signal frequencies above 18 GHz are prone to response errors due to modes in the Type-N connector. Only analyzers with frequency Option 526 that do not also have input connector Option C35 will have these modes.With the use of Type-N to APC 3.5 mm adapter part number 1250-1744, there are nominally six such modes. These modes cause nominally up to -0.35 dB amplitude change, with phase errors of nominally up to �1.2�.
c. The listed performance is the rms of the amplitude deviation from the mean amplitude response of a span/CF combination. 50% of the combinations of prototype instruments, center frequencies and spans had performance better than the listed values.
d. The passband shape will be greatly affected by the microwave preselector. See "Microwave Preselector Bandwidth" on page 26.
104
Keysight N9038B MXE Specification Guide
Option B85/B1X - 85/160 MHz Analysis Bandwidth Other Analysis Bandwidth Specifications
Description
Specifications
Supplemental Information
IF Phase Linearity
Deviation from mean phase linearity
Center Freq (GHz)
Span (MHz)
Microwave Preselector
Peak-to-peak (nominal)
RMS (nominal)a
0.03, <3.6
85
n/a
1.6�
0.54�
160
n/a
4.7�
1.23�
a. The listed performance is the rms of the phase deviation relative to the mean phase deviation from a linear phase condition, where the rms is computed across the span shown.
Keysight N9038B MXE Specification Guide
105
Option B85/B1X - 85/160 MHz Analysis Bandwidth Other Analysis Bandwidth Specifications
Description
Specification
Supplemental Information
Full Scale (ADC Clipping)a Default settings, signal at CF
(IF Gain = Low; IF Gain Offset = 0 dB) Band 0 Band 1 through 6 High Gain setting, signal at CF (IF Gain = High; IF Gain Offset = 0 dB)
-8 dBm mixer levelb (nominal) -7 dBm mixer levelb (nominal)
Band 0
-18 dBm mixer levelb (nominal), subject to gain limitationsc
Band 1 through 6
-17 dBm mixer levelb (nominal), subject to gain limitationsc
IF Gain Offset 0 dB, signal at CF
See formulad, subject to gain limitationsc
Effect of signal frequency CF
up to �3 dB (nominal)
a. This table is meant to help predict the full-scale level, defined as the signal level for which ADC overload (clipping) occurs. The prediction is imperfect, but can serve as a starting point for finding that level experimentally. A SCPI command is also available for that purpose.
b. Mixer level is signal level minus input attenuation. c. The available gain to reach the predicted mixer level will vary with center frequency. Combinations of high gains
and high frequencies will not achieve the gain required, increasing the full scale level. d. The mixer level for ADC clipping is nominally given by that for the default settings, minus IF Gain Offset, minus
10 dB if IF Gain is set to High.
Description Third Order Intermodulation Distortion
Band 0 Band 1 Band 2 Band 3 Band 4
Specifications
Supplemental Information Two tones of equal level 1 MHz tone separation Each tone -11 dB relative to full scale (ADC clipping) IF Gain = High IF Gain Offset = 0 dB Freq Option 526 -77 dBc (nominal) -75 dBc (nominal) -74 dBc (nominal) -76 dBc (nominal) -74 dBc (nominal)
106
Keysight N9038B MXE Specification Guide
Option B85/B1X - 85/160 MHz Analysis Bandwidth Other Analysis Bandwidth Specifications
Description
Specifications
Supplemental Information
Noise Density
0 dB attenuation
Band
Freq (GHz)a
IF Gainb = Low
0
1.80
-146 dBm/Hz
a. Specifications apply at the center of each band. IF noise dominates the system noise, therefore the noise density will not change substantially with center frequency.
b. IF Gain Offset = 0 dB. IF Gain = High is about 10 dB extra IF gain, giving better noise levels but a full-scale level (ADC clipping) that is reduced by about 10 dB. For the best clipping-to-noise dynamic range, use IF Gain = Low and negative IF Gain Offset settings.
Description
Specification
Supplemental Information
Signal to Noise Ratio
Ratio of clipping levela to noise levelb
Example: 1.8 GHz
140 dB nominal, log averaged, 1 Hz RBW, IF Gain = Low, IF Gain Offset = 0 dB
a. For the clipping level, see the table above, "Full Scale." Note that the clipping level is not a warranted specification, and has particularly high uncertainty at high microwave frequencies.
b. The noise level is specified in the table above, "Displayed Average Noise Level." Please consider these details and additional information: DANL is, by Keysight and industry practice, specified with log averaging, which reduces the measured noise level by 2.51 dB. It is specified for a 1 Hz resolution bandwidth, which will nominally have a noise bandwidth of 1.056 Hz. Therefore, the noise density is 2.27 dB above the DANL. Please note that the signal-to-noise ratio can be further improved by using negative settings of IF Gain Offset.
Keysight N9038B MXE Specification Guide
107
Option B85/B1X - 85/160 MHz Analysis Bandwidth Data Acquisition
Data Acquisition
Description
Specifications
Supplemental Information
Time Record Length IQ Analyzer Advanced Tools
8,000,000 IQ sample pairs
Data Packing 32-bit
64-bit
Waveform Measurementa 89600 VSA software
Length (IQ sample pairs)
536 MSa (229 Sa)
268 MSa (228 Sa)
2 GB total memory
Sample Rate (IQ Pairs)
1.25 x IFBW
ADC Resolution
14 bits
a. This can also be accessed with the remote programming command of "read:wav0?".
Capture Time [Plot]
NOTE
This plot is based on the full access to the 2 GB deep capture memory which requires either the 89600 VSA.
108
Keysight N9038B MXE Specification Guide
Keysight X-Series MXE EMI Receiver N9038B Specification Guide
6 Option CR3 - Connector Rear, 2nd IF Output
This chapter contains specifications for Option CR3, Connector Rear, 2nd IF Output.
109
Option CR3 - Connector Rear, 2nd IF Output Specifications Affected by Connector Rear, 2nd IF Output
Specifications Affected by Connector Rear, 2nd IF Output
No other analyzer specifications are affected by the presence or use of this option. New specifications are given in the following page.
110
Keysight N9038B MXE Specification Guide
Option CR3 - Connector Rear, 2nd IF Output Other Connector Rear, 2nd IF Output Specifications
Other Connector Rear, 2nd IF Output Specifications
Aux IF Out Port
Description Connector Impedance
Specifications SMA female
Supplemental Information Shared with other options 50 (nominal)
Second IF Out
Description
Specifications
Supplemental Information
Second IF Out Output Center Frequency
SA Mode, EMI Receiver Mode I/Q Analyzer Mode
IF Path 25 MHz IF Path 85 or 160 MHz
322.5 MHz
322.5 MHz 300 MHz
Conversion Gain at 2nd IF output center frequency
�1 to +4 dB (nominal) plus RF frequency responsea
Bandwidth
Low band High band
Up to 140 MHz (nominal)b
With microwave preselector
Depends on RF center frequencyc
Residual Output Signals
�94 dBm or lower (nominal)
a. "Conversion Gain" is defined from RF input to IF Output with 0 dB mechanical attenuation and the electronic attenuator off. The nominal performance applies in zero span.
b. The passband width at �3 dB nominally extends from IF frequencies of 230 to 370 MHz. c. The YIG-tuned microwave preselector bandwidth nominally varies from 55 MHz for a center frequencies of
3.6 GHz through 57 MHz at 15 GHz to 75 MHz at 26.5 GHz. (Refer to page 23 for details.) The microwave preselector effect will dominate the passband width.
Keysight N9038B MXE Specification Guide
111
Option CR3 - Connector Rear, 2nd IF Output Other Connector Rear, 2nd IF Output Specifications
112
Keysight N9038B MXE Specification Guide
Keysight X-Series MXE EMI Receiver N9038B Specification Guide
7 Option EXM - External Mixing
This chapter contains specifications for the Option EXM External Mixing.
113
Option EXM - External Mixing Specifications Affected by External mixing
Specifications Affected by External mixing
Specification Name RF-Related Specifications, such as TOI, DANL, SHI, Amplitude Accuracy, and so forth.
Information Specifications do not apply; some related specifications are contained in IF Input in this chapter
IF-Related Specifications, such as RBW range, RBW accuracy, RBW switching uncertainty, and so forth.
Specifications unchanged, except IF Frequency Response - see specifications in this chapter.
New specifications: IF Input Mixer Bias LO Output
See specifications in this chapter.
114
Keysight N9038B MXE Specification Guide
Option EXM - External Mixing Other External Mixing Specifications
Other External Mixing Specifications
Description Connection Port EXT MIXER Connector Impedance Functions
Mixer Bias Bias Current
Range Resolution Accuracy Output impedance Bias Voltage Range IF Input Maximum Safe Level Center Frequency IF BW 25 MHz IF BW = 85 MHz IF BW = 160 MHz Bandwidth ADC Clipping Levela 1 dB Gain Compressiona Gain Accuracyb Standard (or Option B25) Option B85/B1X
Specifications
Supplemental Information
SMA, female Triplexed for Mixer Bias, IF Input and LO output
50 (nominal) at IF and LO frequencies
�10 mA 10 A
Short circuit current
�20 A (nominal) 477 (nominal) Open circuit �3.7 V (nominal)
+7 dBm
322.5 MHz 300.0 MHz 300.0 MHz
20 to 30�C �1.2 dB
Full Range �2.5 dB
includes swept
Supports all optional IFs �14.5 �2.0 dBm (nominal) �2 dBm (nominal)
Swept and narrowband �1.2 dB (nominal)
Keysight N9038B MXE Specification Guide
115
Option EXM - External Mixing Other External Mixing Specifications
Description
Specifications
Supplemental Information
IF Frequency Response
RMS (nominal)
CF
Width
322.5 MHz
�5 MHz
0.05 dB
322.5 MHz
�12.5 MHz
0.07 dB
300 MHz
�80 MHz
0.5 dB
Noise Figure (322.5 MHz, swept operation)
9 dB (nominal)
VSWR
1.3:1 (nominal)
a. These specifications apply at the IF input port. The on-screen and mixer-input levels scale with the conversion loss and corrections values.
b. The amplitude accuracy of a measurement includes this term and the accuracy with which the settings of corrections model the loss of the external mixer.
Description
Specifications
Supplemental Information
LO Output
Frequency Range
3.75 to 14.1 GHz
Output Powera
20 to 30�C
Full Range
3.75 to 7.0 GHzb
+15.0 to 18.0 dBm
+14.5 to 18.5 dBm
7.0 to 8.72 GHzb
+15.0 to 18.0 dBm
+13.5 to 18.8 dBm
7.8 to 14.1 GHzc
+14.0 to 18.5 dBm
Not specified
Second Harmonic
�20 dB (nominal)
Fundamental Feedthrough and Undesired Harmonicsc
�15 dB (nominal)
VSWR
< 2.2:1 (nominal)
a. The LO output port power is compatible with Keysight M1970 and 11970 Series mixers except for the 11970K. The power is specified at the connector. Cable loss will affect the power available at the mixer. With non-Keysight mixer units, supplied loss calibration data may be valid only at a specified LO power that may differ from the power available at the mixer. In such cases, additional uncertainties apply.
b. LO Doubler = Off settings. c. LO Doubler = On setting. Fundamental frequency = 3.9 to 7.0 GHz.
116
Keysight N9038B MXE Specification Guide
Keysight X-Series MXE EMI Receiver N9038B Specification Guide
8 Options P03, P08, P26, P44 - Preamplifiers
This chapter contains the specifications for the EMI Receiver Options P03, P08, P26 and P44 preamplifiers.
117
Options P03, P08, P26, P44 - Preamplifiers Specifications Affected by Preamp
Specifications Affected by Preamp
Specification Name
Information
Nominal Dynamic Range vs. Offset Frequency vs. RBW
The graphic from the core specifications does not apply with Preamp On.
Measurement Range
Gain Compression DANL with NFE Off DANL with NFE (Noise Floor Extension)
Frequency Response
The measurement range depends on displayed average noise level (DANL). See "Amplitude Accuracy and Range" on page 27. See specifications in this chapter. See specifications in this chapter. See "DANL and Indicated Noise Improvement with Noise Floor Extension" on page 49 of the core specifications. See specifications in this chapter.
Absolute Amplitude Accuracy RF Input VSWR Display Scale Fidelity
Second Harmonic Distortion
See "Absolute Amplitude Accuracy" on page 35 of the core specifications. See plot in this chapter. See Display Scale Fidelity on page 40 of the core specifications. Then, adjust the mixer levels given downward by the preamp gain given in this chapter. See specifications in this chapter.
Third Order Intermodulation Distortion Other Input Related Spurious
Dynamic Range Gain Noise Figure
See specifications in this chapter. See "Spurious Responses" on page 52 of the core specifications. Preamp performance is not warranted but is nominally the same as non-preamp performance. See plot in this chapter. See "Preamp" specifications in this chapter. See "Preamp" specifications in this chapter.
118
Keysight N9038B MXE Specification Guide
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Other Preamp Specification
Description
Specifications
Supplemental Information
Preamp Gain
RF Preselector offa 100 kHz to 3.6 GHz 3.6 to 26.5 GHz 26.5 to 44 GHz
RF Preselector on 1 kHz to 3.6 GHz 3.6 to 26.5 GHz 26.5 to 44 GHz
Maximumb +20 dB (nominal) +35 dB (nominal) +40 dB (nominal) +20 dB (nominal) +35 dB (nominal) +40 dB (nominal)
a. The preamp follows the input attenuator, AC/DC coupling switch, and precedes the input mixer. In low band, it follows the RF Preselector. In high band, it precedes the microwave preselector.
b. Preamp Gain directly affect distortion and noise performance, but it also affects the range of levels that are free of final IF overload. The user interface has a designed relationship between input attenuation and reference level to prevent on-screen signal levels from causing final IF overloads. That design is based on the maximum preamp gains shown. Actual preamp gains are modestly lower, by up to nominally 5 dB for frequencies from 100 kHz to 3.6 GHz, and by up to nominally 10 dB for frequencies from 3.6 to 26.5 GHz.
Keysight N9038B MXE Specification Guide
119
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description
Specifications
1 dB Gain Compression Point (Two-tone)abcd
Maximum power at mixere
(RF Input 1f) Option 544 (mmW)
Option 503, 508 or 526 (RF/W) RF Preselector off, Preamp ong
Supplemental Information
10 MHz to 3.6 GHz 10 MHz to 3.6 GHz
3.6 to 26.5 GHz Tone spacing 100 kHz to 20 MHz Tone spacing 100 kHz to 20 MHz Tone spacing > 70 MHz 26.4 to 44 GHz
x x
x
x
x
x
x
-13 dBm (nominal) -13 dBm (nominal)
�26 dBm (nominal) �30 dBm (nominal)
�16 dBm (nominal) �30 dBm (nominal)
RF Preselector on, Preamp ong
9 kHz to 10 MHz
x
x
-16 dBm (nominal)
10 MHz to 2 GHz
x
-18 dBm (typical)
10 MHz to 2 GHz
x
-21 dBm (typical)
2 to 3.6 GHz
x
-16 dBm (typical)
2 to 3.6 GHz
x
-17 dBm (typical)
3.6 to 26.5 GHz
Tone spacing 100 kHz to 20 MHz
x
�26 dBm (nominal)
Tone spacing 100 kHz to 20 MHz
x
�30 dBm (nominal)
Tone spacing > 70 MHz
x
x
�16 dBm (nominal)
26.4 to 44 GHz
x
�30 dBm (nominal)
a. Large signals, even at frequencies not shown on the screen, can cause the receiver to incorrectly measure on-screen signals because of two-tone gain compression. This specification tells how large an interfering signal must be in order to cause a 1 dB change in an on-screen signal.
120
Keysight N9038B MXE Specification Guide
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
b. Specified at 1 kHz RBW with 100 kHz tone spacing. Time Domain scan nominal values verified using a 1 kHz RBW with 50 MHz tone spacing. The compression point will nominally equal the specification for tone spacing greater than 5 times the prefilter bandwidth. At smaller spacings, ADC clipping may occur at a level lower than the 1 dB compression point.
c. Reference level and off-screen performance: The reference level (RL) behavior differs from some earlier receivers in a way that makes this receiver more flexible. In other receivers, the RL controlled how the measurement was performed as well as how it was displayed. Because the logarithmic amplifier in these receivers had both range and resolution limitations, this behavior was necessary for optimum measurement accuracy. The logarithmic amplifier in this receiver, however, is implemented digitally such that the range and resolution greatly exceed other instrument limitations. Because of this, the receiver can make measurements largely independent of the setting of the RL without compromising accuracy. Because the RL becomes a display function, not a measurement function, a marker can read out results that are off-screen, either above or below, without any change in accuracy. The only exception to the independence of RL and the way in which the measurement is performed is in the input attenuation setting: When the input attenuation is set to auto, the rules for the determination of the input attenuation include dependence on the reference level. Because the input attenuation setting controls the tradeoff between large signal behaviors (third-order intermodulation, compression, and display scale fidelity) and small signal effects (noise), the measurement results can change with RL changes when the input attenuation is set to auto.
d. When using Time Domain scan, all indicated values shown here are nominal values. e. Mixer power level (dBm) = input power (dBm) - input attenuation (dB) (�9 dB for RF Input 2). f. RF Input 2 operates to 1 GHz. The 1 dB gain compression is nominally 9 dB higher. g. Total power at the preamp (dBm) = total power at the input (dBm) � input attenuation (dB).
Keysight N9038B MXE Specification Guide
121
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description
Absolute Amplitude Accuracy RF Preselector off and on Preamp on
Specifications RF Input 1: to 44 GHz RF Input 2: to 1 GHz
Supplemental Information
RF Input 1
95th percentile
At 50 MHzab 20 to 30�C 5 to 50�C
�0.33 dB �0.42 dB
�0.25 dB
At all frequenciesab 20 to 30�C 5 to 50�C
�(0.33 dB + frequency response) �(0.42 dB+ frequency response)
RF Input 2
At 50 MHzac 20 to 30�C 5 to 50�C
�0.36 dB �0.45 dB
�0.27 dB
At all frequenciesac 20 to 30�C 5 to 50�C
�(0.36 dB + frequency response) �(0.45 dB + frequency response)
CISPR requirements
This instrument meets or exceeds the current CISPR 16-1-1:2019 sine wave accuracy requirements from 15 to 35�C
Amplitude Reference Accuracy
�0.05 dB (nominal)
a. Absolute amplitude accuracy is the total of all amplitude measurement errors, and applies over the following subset of settings and conditions: 1 Hz RBW 1 MHz; Input signal -10 to -50 dBm; Input attenuation 10 dB; span < 5 MHz (nominal additional error for span 5 MHz is 0.02 dB); all settings auto-coupled except Swp Time Rules = Accuracy; combinations of low signal level and wide RBW use VBW 30 kHz to reduce noise. When using FFT sweeps, the signal must be at the center frequency. This absolute amplitude accuracy specification includes the sum of the following individual specifications under the conditions listed above: Scale Fidelity, Reference Level Accuracy, Display Scale Switching Uncertainty, Resolution Bandwidth Switching Uncertainty, 50 MHz Amplitude Reference Accuracy, and the accuracy with which the instrument aligns its internal gains to the 50 MHz Amplitude Reference. When using Time Domain scan, only the 95th percentile specification applies.
b. Same settings as footnote a, except that the signal level at the preamp input is �40 to �80 dBm. Total power at the preamp (dBm) = total power at the input (dBm) minus input attenuation (dB).
c. Same settings as footnote a, except that the signal level at the preamp input is �40 to �80 dBm. Total power at the preamp (dBm) = total power at the input (dBm) minus input attenuation (dB) � 9 dB.
122
Keysight N9038B MXE Specification Guide
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description
Specifications
Frequency Response
RF Input 1: to 44 GHz RF Input 2: to 1 GHz
(Maximum error relative to reference condition (50 MHz) Mechanical attenuator only Non-FFT operation onlyb Preamp off: 10 dB atten Preamp on: 0 dB atten)
Option 544 (mmW)
Option 503, 508 or 526 (RF/W)
RF Preselector off Preamp on
20 to 30�C 5 to 50�C
100 kHz to 3.6 GHz 100 kHz to 10 MHz
10c to 50 MHz 50 MHz to 3.6 GHz 3.5 to 8.4 GHzde 3.5 to 5.2 GHzde 5.2 to 8.4 GHzde 8.3 to 13.6 GHzde 8.3 to 13.6 GHzde 13.5 to 17.1 GHzde 13.5 to 17.1 GHzde 17.0 to 18.0 GHzde 18.0 to 22.0 GHzde 17.0 to 22 GHzde 22.0 to 26.5 GHzde 22.0 to 26.5 GHzde 26.4 to 34.5 GHzde 34.4 to 44 GHzde
x
�0.75 dB
�1.0 dB
x
�0.75 dB
�1.0 dB
x
�0.75 dB
�1.0 dB
x
�0.75 dB
�1.0 dB
x
�1.85 dB
�2.5 dB
x
�2.2 dB
�3.4 dB
x
�1.85 dB
�2.5 dB
x
�1.95 dB
�2.4 dB
x
�1.95 dB
�2.4 dB
x
�1.8 dB
�2.4 dB
x
�1.8 dB
�2.4 dB
x
�2.0 dB
�2.5 dB
x
�2.85 dB
�3.75 dB
x
�2.85 dB
�3.75 dB
x
�2.6 dB
�3.55 dB
x
�2.6 dB
�3.55 dB
x
�3.0 dB
�4.5 dB
x
�4.1 dB
�6.0 dB
Supplemental Information Refer to the footnote for Band Overlaps on page 14. Modes above 18 GHza
95th Percentile (2) �0.29 dB
�0.43 dB �0.29 dB �0.31 dB �0.63 dB �0.9 dB �0.7 dB �0.64 dB �0.79 dB �0.81 dB �0.88 dB �0.95 dB �1.23 dB �1.07 dB �1.37 dB �1.03 dB �1.35 dB �1.69 dB
Keysight N9038B MXE Specification Guide
123
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
a. Signal frequencies above 18 GHz are prone to response errors due to modes in the Type-N connector used. With the use of Type-N to APC 3.5 mm adapter part number 1250-1744, there are nominally six such modes. The effect of these modes with this connector are included within these specifications.
b. For FFT based measurements, Frequency Response errors are more complicated. One case is where the input signal is at the center frequency of the FFT measurement. In this case, the Frequency Response errors are given by this table. The total absolute amplitude accuracy is given by the combination of the absolute amplitude accuracy at 50 MHz with the Frequency Response from this table. The other case is when the input signal is not at the center frequency of the FFT measurement. In this case, the total frequency response error is computed by adding the RF flatness errors of this table to the IF Frequency Response. The total absolute amplitude accuracy is given by the combination of the absolute amplitude accuracy at 50 MHz with this total frequency response error. An additional error source, the relative error in switching between swept and FFT-based measurements, is nominally �0.01 dB. The effect of this relative error on absolute measurements is included with the "Absolute Amplitude Accuracy" specifications.
c. Specifications apply with DC coupling at all frequencies. With AC coupling, specifications apply at frequencies of 50 MHz and higher. Statistical observations at 10 MHz show that most instruments meet the specifications, but a few percent of instruments can be expected to have errors exceeding 0.5 dB at 10 MHz at the temperature extreme. The effect at 20 to 50 MHz is negligible, but not warranted.
d. Specifications for frequencies >3.5 GHz apply for sweep rates 100 MHz/ms. e. Microwave preselector centering applied.
124
Keysight N9038B MXE Specification Guide
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description
Specifications
Frequency Response
RF Input 1: to 44 GHz RF Input 2: to 1 GHz
(Maximum error relative to reference condition (50 MHz) Mechanical attenuator only Non-FFT operation onlyb Preamp off: 10 dB atten Preamp on: 0 dB atten)
Option 544 (mmW)
Option 503, 508 or 526 (RF/W)
RF Preselector on Preamp on
20 to 30�C 5 to 50�C
1 kHz to 30 MHzc 30c to 300 MHz 300 MHz to 1 GHz 1 to 2.75 GHz 2.75 to 3.6 GHz 3.5 to 8.4 GHz 3.5 to 5.2 GHzde 5.2 to 8.4 GHzde 8.3 to 13.6 GHzde 8.3 to 13.6 GHzde 13.5 to 17.1 GHzde 13.5 to 17.1 GHzde 17.0 to 18.0 GHzde 18.0 to 22.0 GHzde 17.0 to 22 GHzde 22.0 to 26.5 GHzde 22.0 to 26.5 GHzde 26.4 to 34.5 GHzde 34.4 to 44 GHzde
x
x �0.8 dB
�0.95 dB
x
x �0.7 dB
�1.0 dB
x
x �0.65 dB
�0.9 dB
x
x �0.95 dB
�1.2 dB
x
x �1.15 dB
�1.8 dB
x
�1.85 dB
�2.5 dB
x
�2.2 dB
�3.4 dB
x
�1.85 dB
�2.5 dB
x
�1.95 dB
�2.4 dB
x
�1.95 dB
�2.4dB
x
�1.8 dB
�2.4 dB
x
�1.8 dB
�2.4 dB
x
�2.0 dB
�2.5 dB
x
�2.85 dB
�3.75 dB
x
�2.85 dB
�3.75 dB
x
�2.6 dB
�3.55 dB
x
�2.6 dB
�3.55 dB
x
�3.0 dB
�4.5 dB
x
�4.1 dB
�6.0 dB
Supplemental Information Refer to the footnote for Band Overlaps on page 14. Modes above 18 GHza
95th Percentile (2) �0.36 dB �0.29 dB �0.3 dB �0.45 dB �0.55 dB �0.63 dB
�0.9 dB �0.70 dB �0.64 dB �0.79 dB �0.81 dB �0.88 dB �0.95 dB �1.23 dB �1.07 dB �1.37 dB �1.03 dB �1.35 dB �1.69 dB
Keysight N9038B MXE Specification Guide
125
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
a. Signal frequencies above 18 GHz are prone to response errors due to modes in the Type-N connector used. With the use of Type-N to APC 3.5 mm adapter part number 1250-1744, there are nominally six such modes. The effect of these modes with this connector are included within these specifications.
b. For FFT based measurements, Frequency Response errors are more complicated. One case is where the input signal is at the center frequency of the FFT measurement. In this case, the Frequency Response errors are given by this table. The total absolute amplitude accuracy is given by the combination of the absolute amplitude accuracy at 50 MHz with the Frequency Response from this table. The other case is when the input signal is not at the center frequency of the FFT measurement. In this case, the total frequency response error is computed by adding the RF flatness errors of this table to the IF Frequency Response. The total absolute amplitude accuracy is given by the combination of the absolute amplitude accuracy at 50 MHz with this total frequency response error. An additional error source, the relative error in switching between swept and FFT-based measurements, is nominally �0.01 dB. The effect of this relative error on absolute measurements is included with the "Absolute Amplitude Accuracy" specifications.
c. Specifications apply with DC coupling at all frequencies. With AC coupling, specifications apply at frequencies of 50 MHz and higher. Statistical observations at 10 MHz show that most instruments meet the specifications, but a few percent of instruments can be expected to have errors exceeding 0.5 dB at 10 MHz at the temperature extreme. The effect at 20 to 50 MHz is negligible, but not warranted.
d. Specifications for frequencies >3.5 GHz apply for sweep rates 100 MHz/ms. e. Microwave preselector centering applied.
126
Keysight N9038B MXE Specification Guide
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description RF Input VSWR at tuned frequency 10 dB Atten, 50 MHz, RF Presel off
Specifications RF Input 1: to 44 GHz RF Input 2: to 1 GHz
Supplemental Information 1.07:1 (nominal)
RF Preselector off Preamp on
DC Coupled 9 kHza to 1 GHz 1 to 18 GHz 18 to 26.5 GHzb 26.5 to 40 GHz 40 to 44 GHz
AC Coupled (Option 503, 508, 526) 50 MHz to 1 GHz 1 to 18 GHz 18 to 26.5 GHzb
Input Attenuation 0 dB
10 dB
---
---
3.0:1
2.0:1
3.0:1
2.0:1
3.0:1
2.5:1
---
---
---
---
3.0:1
2.0:1
3.0:1
2.4:1
Typical
10 dB Attenuation
1.8:1 1.8:1 1.8:1 2.0:1
1.8:1 2.0:1
RF Preselector on Preamp on
Input Attenuation
DC Coupled 9 kHz to 1 GHz 1 to 26.5 GHzb 26.5 to 40 GHz 40 to 44 GHz
AC Coupled (Option 503, 508, 526) 50 MHz to 1 GHz 1 to 18 GHz 18 to 26.5 GHzb
0 dB
2.0:1 3.0:1 3.0:1 ---
2.0:1 3.0:1 3.0:1
10 dB
1.2:1
2.0:1
1.8:1
2.5:1
1.8:1
---
2.0:1
1.2:1
2.0:1
1.8:1
2.4:1
2.0:1
a. For preamp on case, low frequency is 100 kHz. b. For Option 526, VSWR specifications above 18 GHz apply only with Option C35 (3.5 mm connector).
Keysight N9038B MXE Specification Guide
127
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description
Total Measurement Uncertainty Signal level 0 to 90 dB below reference point, RF attenuation 0 to 40 dB, RBW 1 MHz, 20� to 30� C: AC coupled 10 MHz to 26.5 GHz DC coupled 9 kHz to 44 GHz
Option 544 (mmW) Option 503, 508 or 526 (RF/W) RF Presel off Preamp on
Specifications
Supplemental Information 95th Percentile ( 2)
100 kHz to 2 GHz 2 to 3.6 GHz 3.6 to 8 GHz
3.6 to 8 GHz 8 to 18 GHz 18 to 26.5 GHz
26.5 to 40 GHz 40 to 44 GHz RF Presel on Preamp on 9 kHz to 2 GHz 2 to 3.6 GHz 3.6 to 8 GHz 3.6 to 8 GHz 8 to 18 GHz 18 to 26.5 GHz 26.5 to 40 GHz 40 to 44 GHz
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
� 0.6 dB � 0.6 dB � 1.1 dB
� 1.8 dB � 1.3 dB � 1.9 dB
� 1.9 dB � 2.4 dB
� 0.5 dB � 0.7 dB � 1.1 dB
� 1.8 dB � 1.3 dB � 1.9 dB
� 1.9 dB � 2.4 dB
128
Keysight N9038B MXE Specification Guide
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description
Specifications
Displayed Average Noise Level (DANL)a
(RF Input 1b)
Input terminated Sample or Average detector Averaging type = Log 0 dB input attenuation IF Gain = High 1 Hz Resolution Bandwidth
Option 544 (mmW)
Option 503, 508 or 526 (RF/W) RF Preselector off, Preamp on
20 to 30�C 5 to 50�C
Supplemental Information Refer to the footnote for Band Overlaps on page 14.
Typical DANL including NFEc
100 kHzd
x x -144 dBm
-143 dBm
1 MHzd
x x -162 dBm
-161 dBm
10 MHz to 2.1 GHz
x x -163 dBm
-162 dBm
-174 dBm
2.1 to 3.6 GHz
x x -161 dBm
-160 dBm
-173 dBm
3.6 GHz to 8.4 GHz
x
-164 dBm
-163 dBm
-172 dBm
3.5 GHz to 8.4 GHz
x -161 dBm
-159 dBm
-166 dBm
8.3 GHz to 13.6 GHz
x
-162 dBm
-161 dBm
-173 dBm
8.3 GHz to 13.6 GHz
x -161 dBm
-160 dBm
-170 dBm
13.5 to 17.1 GHz
x x -160 dBm
-159 dBm
-171 dBm
17.0 to 20.0 GHz
x x -158 dBm
-157 dBm
-165 dBm
20.0 to 26.5 GHz
x x -155 dBm
-153 dBm
-162 dBm
26.4 to 34.5 GHz
x -156 dBm
-153 dBm
-164 dBm
34.4 to 44 GHz
x -150 dBm
-147 dBm
-158 dBm
a. DANL for zero span and swept is measured in a 1 kHz RBW and normalized to the narrowest available RBW, because the noise figure does not depend on RBW and 1 kHz measurements are faster. Does not apply to Time Domain scan.
b. RF Input 2 operates to 1 GHz. The DANL is nominally 11 dB higher for RF Input 2. c. NFE = Noise Floor Extension. Typical DANL including NFE = (Typical DANL � DANL improvement with NFE). d. DANL below 10 MHz is affected by phase noise around the LO feedthrough signal. Specifications apply with the
best setting of the Phase Noise Optimization control, which is to choose the "Best Close-in Noise" for frequencies below 25 kHz, and "Best Wide Offset Noise" for frequencies above 25 kHz.
Keysight N9038B MXE Specification Guide
129
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description
Specifications
Displayed Average Noise Level (DANL)a
(RF Input 1b)
Input terminated Sample or Average detector Averaging type = Log 0 dB input attenuation IF Gain = High 1 Hz Resolution Bandwidth
Option 544 (mmW)
Option 503, 508 or 526 (RF/W) RF Preselector on, Preamp on
20 to 30�C 5 to 50�C
Supplemental Information Refer to the footnote for Band Overlaps on page 14.
Typical Indicated Noise including NFEc
1 kHzd 9 kHzd 100 kHzd 1 to 2 MHzd 2 to 30 MHzd 30 to 600 MHz 600 to 800 MHz 800 MHz to 1 GHz 1 to 2 GHz 2 to 2.75 GHz 2.75 to 3.6 GHz 3.5 to 8.4 GHz
3.5 to 8.4 GHz 8.3 to 13.6 GHz
8.3 to 13.6 GHz 13.5 to 17.1 GHz 17.0 to 20.0 GHz 20.0 to 26.5 GHz
26.4 to 34.5 GHz 34.4 to 44 GHz
x
x �119 dBm
�118 dBm
�133 dBme
x x �143 dBm
�142 dBm
�154 dBm
x x �154 dBm
�153 dBm
�165 dBm
x x �166 dBm
�165 dBm
�174 dBm
x x �158 dBm
�157 dBm
�167 dBm
x x �159 dBm
�158 dBm
�166 dBm
x x �157 dBm
�156 dBm
�166 dBm
x x �158 dBm
�157 dBm
�167 dBm
x x �156 dBm
�155 dBm
�164 dBm
x x �160 dBm
�159 dBm
�168 dBm
x x �157 dBm
�156 dBm
�165 dBm
x
�164 dBm
�163 dBm
�172 dBm
x
�161 dBm
�159 dBm
�166 dBm
x
�162 dBm
�161 dBm
�173 dBm
x
�161 dBm
�159 dBm
�170 dBm
x x �160 dBm
�159 dBm
�171 dBm
x x �158 dBm
�157 dBm
�165 dBm
x x �155 dBm
�153 dBm
�162 dBm
x
�156 dBm
�153 dBm
�164 dBm
x
�150 dBm
�147 dBm
�158 dBm
130
Keysight N9038B MXE Specification Guide
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
a. DANL for zero span and swept is measured in a 1 kHz RBW and normalized to the narrowest available RBW, because the noise figure does not depend on RBW and 1 kHz measurements are faster.Does not apply to Time Domain scan.
b. RF Input 2 operates to 1 GHz. The DANL is nominally 11 dB higher for RF Input 2. c. NFE = Noise Floor Extension. Typical DANL including NFE = (Typical DANL � DANL improvement with NFE). d. DANL below 10 MHz is affected by phase noise around the LO feedthrough signal. Specifications apply with the
best setting of the Phase Noise Optimization control, which is to choose the "Best Close-in Noise" for frequencies below 25 kHz, and "Best Wide Offset Noise" for frequencies above 25 kHz. e. NFE is not part of the difference between warranted and typical specifications at this frequency.
Keysight N9038B MXE Specification Guide
131
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description
Indicated Noise (Receiver)a (RF Input 1b)
Specifications
Calculatedc: Derived from DANL data Option 544 (mmW)
Option 503, 508 or 526 (RF/W) RF Preselector on, Preamp on
Supplemental Information Input terminated EMI Average detector 0 dB input attenuation IF Gain = High All indicated RBW are CISPR BW, except as noted.
Typical Indicated Noise including NFEc
1 kHz (100 Hz RBW)d
xx
�4 dBVe
9 kHz (200 Hz)
xx
�24 dBV
100 kHz (200 Hz)
xx
�35 dBV
1 to 2 MHz (9 kHz)
xx
�31 dBV
2 to 30 MHz (9 kHz)
xx
�20 dBV
30 to 600 MHz (120 kHz)
xx
�8 dBV
600 to 800 MHz (120 kHz)
xx
�8 dBV
800 MHz to 1 GHz (120 kHz)
xx
�9 dBV
1 to 2 GHz (1 MHz)
xx
+3 dBV
2 to 2.75 GHz (1 MHz)
xx
�1 dBV
2.75 to 3.6 GHz (1 MHz)
xx
+2 dBV
3.5 to 8.4 GHz (1 MHz)
x
�5 dBV
3.5 to 8.4 GHz (1 MHz)
x
�1 dBV
8.3 to 13.6 GHz (1 MHz)
x
�6 dBV
8.3 to 13.6 GHz (1 MHz)
x
�4 dBV
13.5 to 17.1 GHz (1 MHz)
xx
�4 dBV
17.0 to 20.0 GHz (1 MHz)
xx
+2 dBV
20.0 to 26.5 GHz (1 MHz)
xx
+5 dBV
26.4 to 34.5 GHz (1 MHz)
x
+3 dBV
34.4 to 44 GHz (1 MHz)
x
+9 dBV
a. Does not apply to Time Domain scan. b. RF Input 2 operates to 1 GHz. The DANL is nominally 11 dB higher for RF Input 2.
132
Keysight N9038B MXE Specification Guide
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
c. Typical Indicatied Noise including NFE = Typical DANL + RBW correction + Log Detector correction � DANL Improvement with NFE +107.
d. Indicated RBW is a 3 dB bandwidth. e. NFE is not part of the difference between warranted and typical specifications at this frequency.
Description
Specifications
DANL and Indicated Noise Improvement with Noise Floor Extensiona
Option 544 (mmW)
Option 503, 508 or 526 (RF/W)
RF Preselector off RF Input 1
20 MHz to 3.6 GHz 3.5 to 8.4 GHz
3.5 to 8.4 GHz 8.3 to 13.6 GHz
8.3 to 13.6 GHz 13.5 to 17.1 GHz 17.0 to 26.5 GHz
26.5 to 34.5 GHz
x
x
x
x
x
x
x
x
x
x
x
34.4 to 44 GHz RF Input 2
20 MHz to 1 GHz RF Preselector on
RF Input 1 9 to 150 kHz 150 kHz to 1 MHz
x
x
x
x
x
x
x
1 to 2 MHz
x
x
2 to 5 MHz 5 to 8 MHz 8 to 11 MHz 11 to 14 MHz
x
x
x
x
x
x
x
x
Supplemental Information
95th Percentile ( 2 )
Preamp onb
10 dB 6 dB
4 dB 9 dB
8 dB 9 dB 5 dB
6 dB 5 dB
10 dB
6 dB 2 dB 10 dB 9 dB 10 dB 10 dB 9 dB
Keysight N9038B MXE Specification Guide
133
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description
Specifications
Supplemental Information
DANL and Indicated Noise Improvement with Noise Floor Extension (cont.)
14 to 17 MHz
x
x
8 dB
17 to 20 MHz 20 to 24 MHz 24 to 30 MHz 30 to 70 MHz 70 to 150 MHz 150 to 300 MHz
x
x
x
x
x
x
x
x
x
x
x
x
9 dB 9 dB 10 dB 6 dB 10 dB 8 dB
300 to 600 MHz 600 MHz to 1 GHz 1 to 2 GHz 2 to 3.6 GHz 3.5 to 8.4 GHz
3.5 to 8.4 GHz 8.3 to 13.6 GHz
x
x
x
x
x
x
x
x
x
x
x
8 dB 7 dB 7 dB 6 dB 6 dB
4 dB 9 dB
8.3 to 13.6 GHz
x
8 dB
13.5 to 17.1 GHz
x
x
9 dB
17.0 to 26.5 GHz
x
x
5 dB
26.5 to 34.5 GHz
x
6 dB
34.4 to 44 GHz
x
5 dB
a. This statement on the improvement in DANL is based on the accuracy of the fit of the noise floor model to the measured values of that noise. This measure of the performance correlates well with improvement versus frequency. The improvement actually measured and specified in "Examples of Effective DANL" usually meet these limits as well, but not with the confidence in some cases. Does not apply to Time Domain scan.
b. DANL of the preamp is specified with a 50 source impedance. Like all amplifiers, the noise varies with the source impedance. When NFE compensates for the noise with an ideal source impedance, the variation in the remaining noise level with the actual source impedance is greatly multiplied in a decibel sense.
134
Keysight N9038B MXE Specification Guide
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description
DANL and Indicated Noise Improvement with Noise Floor Extensiona
Specifications
Supplemental Information 95th Percentile ( 2 )
RF Preselector on
Preamp onb
RF Input 2
9 to 150 kHz
6 dB
150 kHz to 1 MHz
2 dB
1 to 2 MHz
10 dB
2 to 5 MHz
10 dB
5 to 8 MHz
9 dB
8 to 11 MHz
9 dB
11 to 14 MHz
10 dB
14 to 17 MHz
10 dB
17 to 20 MHz
10 dB
20 to 24 MHz
10 dB
24 to 30 MHz
10 dB
30 to 70 MHz
8 dB
70 to 150 MHz
9 dB
150 to 300 MHz
9 dB
300 to 600 MHz
7 dB
600 MHz to 1 GHz
7 dB
a. This statement on the improvement in DANL is based on the accuracy of the fit of the noise floor model to the measured values of that noise. This measure of the performance correlates well with improvement versus frequency. The improvement actually measured and specified in "Examples of Effective DANL" usually meet these limits as well, but not with the confidence in some cases. Does not apply to Time Domain scan.
b. DANL of the preamp is specified with a 50 source impedance. Like all amplifiers, the noise varies with the source impedance. When NFE compensates for the noise with an ideal source impedance, the variation in the remaining noise level with the actual source impedance is greatly multiplied in a decibel sense.
Keysight N9038B MXE Specification Guide
135
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description
Second Harmonic Distortiona (Input power = -9 dBm Input attenuation = 6 dB RF Input 1b)
Specifications
Option 544 (mmW)
Option 503, 508 or 526 (RF/W)
RF Preselector off Preamp on
SHIc
Source Frequency
Supplemental Information Typical
10 MHz to 1.8 GHz (preamp level = �45 dBm) 1.8 to 13.25GHz (preamp level = �50 dBm)
13.2 to 22 GHz
xx xx
x
+33 dBm (nominal) +10 dBm (nominal)
+0 dBm (nominal)
RF Preselector on, Preamp ond
Source Frequency (Input power = �9 dBm RF input attenution = 26 dB)
10 to 300 MHz
xx
+53 dBm (nominal)
300 to 500 MHz
xx
+58 dBm (nominal)
500 MHz to 1 GHz
xx
+47 dBm (nominal)
1 to 1.6 GHz
xx
+53 dBm (nominal)
1.6 to 1.8 GHz
xx
+30 dBm (nominal)
1.8 to 13.25 GHz (preamp level = �50 dBm)
xx
+10 dBm (nominal)
13.2 to 22 GHz
x
+0 dBm (nominal)
a. When using Time Domain scan, all indicated values shown here are nominal values. b. RF Input 2 operates to 1 GHz. The second harmonic distortion intercept is nominally 9 dB higher for RF Input 2. c. SHI = second harmonic intercept. d. Preamp level = Input level � Input Attenuation
136
Keysight N9038B MXE Specification Guide
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
Description
Specifications
Supplemental Information
Third Order Intermodulationa
(Tone separation > 5 times IF Prefilter Bandwidthb
Verification conditionsc
RF Input 1d)
Intercepte
RF Preselector off, Preamp on
10 to 500 MHzf 500 MHz to 3.6 GHzf 3.6 to 26.5 GHzg
26.4 to 44 GHz RF Preselector on, Preamp on 10 to 30 MHzh 30 MHz to 1 GHzh 1 to 2 GHzh
�9 dBm �9 dBm �4 dBm
�10 dBm �10 dBm �5 dBm
+4 dBm (nominal) +5 dBm (nominal) �15 dBm (nominal) �17dBm (nominal)
�5 dBm �4 dBm �2 dBm
2 to 3.6 GHzh 3.6 to 26.5 GHzg 26.4 to 44 GHz
�6 dBm
�7 dBm
�3 dBm �15 dBm (nominal) �17dBm (nominal)
a. When using Time Domain scan, all indicated values shown here are nominal values. b. See the IF Prefilter Bandwidth table in the Gain Compression specifications on page 30. When the tone sepa-
ration condition is met, the effect on TOI of the setting of IF Gain is negligible. TOI is verified with IF Gain set to its best case condition, which is IF Gain = Low. c. TOI is verified with two tones, each at -14 dBm at the input with 4 dB input attenuation, spaced by 100 kHz. Time Domain scan nominal TOI values verified with two tones. each at-14 dBm at the input with 4 dB input attenuation, spaced by 50 MHz. d. RF Input 2 operates to 1 GHz. The intercept is nominally 9 dB higher for RF Input 2. e. TOI = third order intercept. The TOI is given by the mixer tone level (in dBm) minus (distortion/2) where distortion is the relative level of the distortion tones in dBc. f. TOI is verified with two tones, each at �45 dBm at the preamp, spaced by 100 kHz. g. TOI is verified with two tones, each at �50 dBm at the preamp, spaced by 100 kHz. h. TOI is verified with two tones, each at �14 dBm at the input with 22 dB input attenuation, spaced by 100 kHz.
Keysight N9038B MXE Specification Guide
137
Options P03, P08, P26, P44 - Preamplifiers Other Preamp Specification
138
Keysight N9038B MXE Specification Guide
Keysight X-Series MXE EMI Receiver N9038B Specification Guide
9 Option ESC - External Source Control
This chapter contains specifications for the Option ESC, External Source Control.
139
Option ESC - External Source Control General Specifications
General Specifications
Description Frequency Range SA Operating range
Source Operating range
Specification
20 Hz to 3.6 GHz 20 Hz to 8.4 GHz 20 Hz to 26.5 GHz 20 Hz to 44 GHz 9 kHz to 3 GHz 9 kHz to 6 GHz 100 kHz to 3 GHz 100 kHz to 6 GHz 100 kHz to 20 GHz 100 kHz to 31.8 GHz 100 kHz to 40 GHz 9 kHz to 20 GHz 9kHz to 31.8 GHz 9 kHz to 40 GHz
Supplemental Information
N9038B-503 N9038B-508 N9038B-526 N9038B-544 N5171B/72B/81B/82B-503 N5171B/72B/81B/82B-506 N5161A/N5162A/N5181A/N5182A-503 N5161A/N5162A/N5181A/N5182A-506 N5183A-520 N5183A-532 N5183A-540 N5173B/N5183B-520 N5173B/N5183B-532 N5173B/N5183B-540
Span Limitations
Span limitations due to source range
Limited by the source and SA operating range
Offset Sweep
Sweep offset setting range
Limited by the source and SA operating range
Sweep offset setting resolution
1 Hz
Harmonic Sweep
Harmonic sweep setting rangea Multiplier numerator Multiplier denominator
N = 1 to 1000 N = 1 to 1000
Sweep Directionb
Normal, Reversed
a. Limited by the frequency range of the source to be controlled. b. The analyzer always sweeps in a positive direction, but the source may be configured to sweep in the opposite
direction. This can be useful for analyzing negative mixing products in a mixer under test, for example.
140
Keysight N9038B MXE Specification Guide
Option ESC - External Source Control General Specifications
Description
Dynamic Range (10 MHz to 3 GHz, Input terminated, sample detector, average type = log, 20 to 30�C)
SA span
SA RBW
1 MHz
2 kHz
10 MHz
6.8 kHz
100 MHz
20 kHz
1000 MHz
68 kHz
Specification
Supplemental Information
Dynamic Range = -10 dBm - DANL - 10 � log (RBW)a
105.0 dB 99.7 dB 95.0 dB 89.7 dB
Amplitude Accuracy
Multiple contributorsb Linearityc Source and Analyzer Flatnessd YTF Instabilitye VSWR effectsf
a. The dynamic range is given by this computation: -10 dBm - DANL - 10�log(RBW) where DANL is the displayed average noise level specification, normalized to 1 Hz RBW, and the RBW used in the measurement is in hertz units. The dynamic range can be increased by reducing the RBW at the expense of increased sweep time.
b. The following footnotes discuss the biggest contributors to amplitude accuracy. c. One amplitude accuracy contributor is the linearity with which amplitude levels are detected by the analyzer.
This is called "scale fidelity" by most spectrum analyzer users, and "dynamic amplitude accuracy" by most network analyzer users. This small term is documented in the Amplitude section of the Specifications Guide. It is negligibly small in most cases. d. The amplitude accuracy versus frequency in the source and the analyzer can contribute to amplitude errors. This error source is eliminated when using normalization in low band (0 to 3.6 GHz). In high band the gain instability of the YIG-tuned microwave preselector in the analyzer keeps normalization errors nominally in the 0.25 to 0.5 dB range. e. In the worst case, the center frequency of the YIG-tuned microwave preselector can vary enough to cause very substantial errors, much higher than the nominal 0.25 to 0.5 dB nominal errors discussed in the previous footnote. In this case, or as a matter of good practice, the microwave preselector should be centered. See the user's manual for instructions on centering the microwave preselector. f. VSWR interaction effects, caused by RF reflections due to mismatches in impedance, are usually the dominant error source. These reflections can be minimized by using 10 dB or more attenuation in the analyzer, and using well-matched attenuators in the measurement configuration.
Keysight N9038B MXE Specification Guide
141
Option ESC - External Source Control General Specifications
Description Power Sweep Range
Specification
Supplemental Information Limited by source amplitude range
Description
Specification
Supplemental Information
Measurement Time (RBW setting of the SA determined by the default for Option ESC)
Nominala
201 Sweep points (default setting) 601 Sweep points
RF MXG (N5181A/N5182A)b
Band 0
Band 1
450 ms
1.1s
1.1 s
3.3 s
W MXG (N5183A)b
Band 0
Band 1
201 Sweep points (default setting)
470 ms
1.2 s
601 Sweep points
1.1 s
3.9 s
a. These measurement times were observed with a span of 100 MHz, RBW of 20 kHz and the point triggering method being set to EXT TRIG1. The measurement times will not change significantly with span when the RBW is automatically selected. If the RBW is decreased, the sweep time increase would be approximately 23.8 times Npoints/RBW.
b. Based on MXG firmware version A.01.80 and Option UNZ installed.
Description
Specification
Supplemental Information
Supported External Sourcesa
Keysight EXG
N5171B/72B/73B
Keysight MXG
N5161A/62A N5181A/82A/83A N5181B/82B/83B
IO interface connection between:
EXG/MXG and MXE
LAN, GPIB, or USB
a. Firmware revision A.19.50 or later is required for the signal analyzer.
142
Keysight N9038B MXE Specification Guide
Keysight MXE EMI Receiver N9038B Specification Guide
10 Option RT1 - Real-time Spectrum Analyzer (RTSA)
This chapter contains specifications for the MXE Signal Analyzer Options RT1, real-time analysis up to 160 MHz maximum analysis bandwidth, basic detection.
143
Option RT1 - Real-time Spectrum Analyzer (RTSA) Specifications Affected by Real-Time Spectrum Analyzer
Specifications Affected by Real-Time Spectrum Analyzer
Specification Name IF Frequency Response Spurious Responses
Absolute Amplitude Accuracy
Spur-free Dynamic Range
Information Refer to "IF Frequency Response" on page 104 in the Option B85 chapter. The "Spurious Responses" on page 52 still apply. Additional bandwidth-option-dependent spurious responses are given in the B85 Analysis Bandwidth chapter. Nominally 0.5 dB degradation from the base instrument absolute amplitude accuracy. (Refer to "Absolute Amplitude Accuracy" on page 35.) Refer to "SFDR (Spurious-Free Dynamic Range)" on page 107 in the Option B85 chapter.
144
Keysight N9038B MXE Specification Guide
Option RT1 - Real-time Spectrum Analyzer (RTSA) Real-time Spectrum Analyzer Performance
Real-time Spectrum Analyzer Performance
Description General Frequency Domain Characteristics Maximum real-time analysis bandwidth (Option RT1) With Option B85
3.6 GHz > 3.6 GHz With Option B1X 3.6 GHz > 3.6 GHz Minimum signal duration with 100% probability of intercept (POI) at full amplitude accuracy With Option B85 With Option B1X Span = 85 MHz Span > 85 MHz Supported Detectors Number of Traces Resolution Bandwidths
Specs & Nominals
85 MHz 40 MHz 160 MHz 40 MHz
3.7 s 3.7 s 17.3 s 6
Span 160 MHz
100 MHz 85 MHz 50 MHz 10 MHz 1 MHz
Min RBW 383 kHz
239 kHz 204 kHz 120 kHz 23.9 kHz 2.39 kHz
Max RBW 12.2 MHza 7.6 MHz 6.25 MHz 3.8 MHz 763 kHz 76.3 kHz
Supplemental Information
Maximum span: Default window is Kaiser; Viewable on screen
Peak, Negative Peak, Sample, Average Clear Write, Max Hold, Min Hold 6 RBWs available for each window type, Nominal Span:RBW ratio for windows: Flattop = 6.7 to 212, Gaussian, Blackman-Harris = 13 to 417, Kaiser = 13 to 418, Hanning = 17 to 551
Keysight N9038B MXE Specification Guide
145
Option RT1 - Real-time Spectrum Analyzer (RTSA) Real-time Spectrum Analyzer Performance
Description
Specs & Nominals
Supplemental Information
100 kHz Window types
Maximum Sample Rate With Option B85 With Option B1X
239 Hz
7.6 kHz
Hanning, Blackman-Harris, Rectangular, Flattop, Kaiser, Gaussian
106 MSa/s 200 MSa/s
FFT Rate
FFT Length Supported Triggers
Number of Markers Supported Markers Amplitude resolution
292,969/s 1024
12 0.01 dB
Nominal value for maximum sample rate. For all spans greater than 300 kHz. Level, Level with Time Qualified (TQT), Line, External, RF Burst, Frame, Frequency Mask (FMT), FMT with TQT Normal, Delta, Noise, Band Power
Frequency points
821
Minimum acquisition time
104 sb
Value for maximum sample rate
a. This maximum RBW value applies to all window types. b. For spectrogram only. For Density view: 30 ms. For Density & spectrogram: 90 ms.
Description Density View Probability range Minimum Span Maximum Span
Persistence duration Color palettes
Spectrogram View
146
Specs & Nominals
Supplemental Information
0-100% 100 Hz
10 s Cool, Warm, Grayscale, Radar, Fire, Frost
0.001% steps 85 MHz in real-time. Stitched density supports full frequency of instrument
Keysight N9038B MXE Specification Guide
Option RT1 - Real-time Spectrum Analyzer (RTSA) Real-time Spectrum Analyzer Performance
Description Maximum number of acquisitions stored Dynamic range covered by colors
Specs & Nominals 10,000 200 dB
Supplemental Information 5,000 with power vs. time combination view
Description Power vs. Time Supported Detectors Supported Triggers
Number of Markers Maximum Time Viewable Minimum Time Viewable
Specs & Nominals
Supplemental Information
12 40 s 215 s
Peak, Negative Peak, Sample, Average Level, Level with Time Qualified (TQT), Line, External, RF Burst, Frame, Frequency Mask (FMT), FMT with TQT
Description Frequency Mask Trigger (FMT) Trigger Views Trigger resolution Trigger conditions
Minimum TQT Duration @ 160 MHz span (or BW)
Minimum signal duration (in �s) for 100% probability of FMT triggering with various RBW Option RT1 Span (MHz)
RBW 6 RBW 5 RBW 4 RBW 3 RBW 2 RBW 1
Specs & Nominals
Density, Spectrogram, Normal 0.5 dB Enter, Leave, Inside, Outside, Enter->Leave, Leave->Enter, TQT 5.12 s
160 17.23 17.39 17.71 18.35 19.63 22.19
85 17.38 17.68 18.28 19.49 21.90 26.72
40 17.72 18.36 19.64 22.20 27.32 37.56
20 18.44 19.72 22.28 27.40 37.64 58.12
Supplemental Information
The minimum TQT duration is inversely proportional to the span (or BW) RBW 1 through 6 can be selected under Bandwidth [BW] Manual.
Keysight N9038B MXE Specification Guide
147
Option RT1 - Real-time Spectrum Analyzer (RTSA) Real-time Spectrum Analyzer Performance
148
Keysight N9038B MXE Specification Guide
Keysight X-Series MXE EMI Receiver N9038B Specification Guide
11 Option YAS - Y-Axis Screen Video Output
This chapter contains specifications for Option YAS, Y-Axis Screen Video Output.
149
Option YAS - Y-Axis Screen Video Output Specifications Affected by Y-Axis Screen Video Output
Specifications Affected by Y-Axis Screen Video Output
No other analyzer specifications are affected by the presence or use of this option. New specifications are given in the following pages.
150
Keysight N9038B MXE Specification Guide
Option YAS - Y-Axis Screen Video Output Other Y-Axis Screen Video Output Specifications
Other Y-Axis Screen Video Output Specifications
General Port Specifications
Description Connector Impedance
Specifications BNC female
Supplemental Information Shared with other options <140 (nominal)
Keysight N9038B MXE Specification Guide
151
Option YAS - Y-Axis Screen Video Output Other Y-Axis Screen Video Output Specifications
Screen Video
Description
Specifications
Operating Conditions
Display Scale Types
All (Log and Lin)
Log Scales
All (0.1 to 20 dB/div)
Modes
Spectrum Analyzer only
FFT & Sweep
Select sweep type = Swept.
Gating
Gating must be off.
Output Signal
Replication of the RF Input Signal envelope, as scaled by the display settings
Differences between display effects and video output
Detector = Peak, Negative, Sample, or Normal
The output signal represents the input envelope excluding display detection
Average Detector
The effect of average detection in smoothing the displayed trace is approximated by the application of a low-pass filter
EMI Detectors Trace Averaging
Amplitude Range Minimum Maximum Overrange Output Scalinga
Offset Gain accuracy
The output will not be useful. Trace averaging affects the displayed signal but does not affect the video output
Bottom of screen Top of Screen + Overrange
0 to 1.0 V open circuit, representing bottom to top of screen respectively
Supplemental Information "Lin" is linear in voltage
Nominal bandwidth:
LPFBW = Npoints - 1 SweepTime
Range of represented signals Smaller of 2 dB or 1 division, (nominal) �1% of full scale (nominal) �1% of output voltage (nominal)
152
Keysight N9038B MXE Specification Guide
Option YAS - Y-Axis Screen Video Output Other Y-Axis Screen Video Output Specifications
Description
Specifications
Supplemental Information
Delay RF Input to Analog Out
Without Option DP2, or MPB
1.67 s + 2.56/RBW + 0.159/VBW (nominal)
a. The errors in the output can be described as offset and gain errors. An offset error is a constant error, expressed as a fraction of the full-scale output voltage. The gain error is proportional to the output voltage. Here's an example. The reference level is -10 dBm, the scale is log, and the scale is 5 dB/division. Therefore, the top of the display is -10 dBm, and the bottom is -60 dBm. Ideally, a -60 dBm signal gives 0 V at the output, and -10 dBm at the input gives 1 V at the output. The maximum error with a -60 dBm input signal is the offset error, �1% of full scale, or �10 mV; the gain accuracy does not apply because the output is nominally at 0 V. If the input signal is -20 dBm, the nominal output is 0.8 V. In this case, there is an offset error (�10 mV) plus a gain error (�1% of 0.8 V, or �8 mV), for a total error of �18 mV.
Keysight N9038B MXE Specification Guide
153
Option YAS - Y-Axis Screen Video Output Other Y-Axis Screen Video Output Specifications
Continuity and Compatibility
Description
Specifications
Supplemental Information
Continuity and Compatibility Output Tracks Video Level
During sweep Between sweeps
Yes See supplemental information
Except band breaks in swept spans
Before sweep interruptiona Alignments b Auto Align = Partialcd
External trigger, no triggerd
Yes
HP 8566/7/8 Compatibilitye Continuous output Output impedance Gain calibration RF Signal to Video Output Delay
Recorder output labeled "Video" Alignment differencesf Two variantsg LL and UR not supportedh See footnotei
a. There is an interruption in the tracking of the video output before each sweep. During this interruption, the video output holds instead of tracks for a time period given by approximately 1.8/RBW.
b. There is an interruption in the tracking of the video output during alignments. During this interruption, the video output holds instead of tracking the envelope of the RF input signal. Alignments may be set to prevent their interrupting video output tracking by setting Auto Align to Off.
c. Setting Auto Align to Off usually results in a warning message soon thereafter. Setting Auto Align to Partial results in many fewer and shorter alignment interruptions, and maintains alignments for a longer interval.
d. If video output interruptions for Partial alignments are unacceptable, setting the analyzer to External Trigger without a trigger present can prevent these from occurring, but will prevent there being any on-screen updating. Video output is always active even if the analyzer is not sweeping.
e. Compatibility with the HP/Keysight 8560 and 8590 families, and the ESA and PSA, is similar in most respects. f. The HP 8566 family did not have alignments and interruptions that interrupted video outputs, as discussed
above. g. Early HP 8566-family spectrum analyzers had a 140 output impedance; later ones had 190. The specifica-
tion was <475. The Analog Out port has a 50 impedance if the analyzer has Option DP2, or MPB. Otherwise, the Analog Out port impedance is nominally 140. h. The HP 8566 family had LL (lower left) and UR (upper right) controls that could be used to calibrate the levels from the video output circuit. These controls are not available in this option. i. The delay between the RF input and video output shown in Delay on page 153 is much higher than the delay in the HP 8566 family spectrum analyzers. The latter has a delay of approximately 0.554/RBW + 0.159/VBW.
154
Keysight N9038B MXE Specification Guide
Keysight X-Series MXE EMI Receiver N9038B Specification Guide
12 Analog Demodulation Measurement Application
This chapter contains specifications for the N9063EM0E Analog Demodulation Measurement Application.
155
Analog Demodulation Measurement Application Pre-Demodulation
Pre-Demodulation
Description Carrier Frequency Maximum Frequency
Option 503 Option 508 Option 526 Option 544
Specifications 3.6 GHz 8.4 GHz 26.5 GHz 44 GHz
Supplemental Information
Minimum Frequency AC Coupleda DC Coupled
10 MHz 20 Hz
In practice, limited by the need to keep modulation sidebands from folding, and by the interference from LO feedthrough.
Demodulation Bandwidth
8 MHz
Capture Memory (sample rate * demod time)
250 kSa
Each sample is an I/Q pair.
a. AC Coupled only applicable to Freq Options 503, 508, 513, and 526.
156
Keysight N9038B MXE Specification Guide
Analog Demodulation Measurement Application Post-Demodulation
Post-Demodulation
Description Maximum Audio Frequency Span Filters Low Pass
High Pass Band Pass De-emphasis
Specifications
300 Hz, 3 kHz, 15 kHz, 30 kHz, 80 kHz, 300 kHz 20 Hz, 50 Hz, 300 Hz CCITT 25 s, 50 s, 75 s, 750 s
Supplemental Information 4 MHz
FM only
Keysight N9038B MXE Specification Guide
157
Analog Demodulation Measurement Application Frequency Modulation - Level and Carrier Metrics
Frequency Modulation - Level and Carrier Metrics
Description
Specifications
Supplemental Information
FM Deviation Accuracy
(Rate: 1 kHz - 1 MHz, Deviation: 1 - 100 kHza)
FM Rate Accuracy
(Rate: 1 kHz - 1 MHzab)
�(1% of (rate + deviation) + 20 Hz) (nominal) �0.2 Hz (nominal)
Carrier Frequency Error Carrier Power
�0.5 Hz (nominal) + tfac Assumes signal still visible in channel BW with offset Same as Absolute Amplitude Accuracy at all frequencies (nominal).
a. For optimum measurement of rate and deviation, ensure that the channel bandwidth is set wide enough to capture the significant RF energy (as visible in the RF Spectrum window). Setting the channel bandwidth too wide will result in measurement errors.
b. Rate accuracy at high channel bandwidths assumes that the deviation is sufficiently large to overcome channel noise.
c. tfa = transmitter frequency � frequency reference accuracy
158
Keysight N9038B MXE Specification Guide
Analog Demodulation Measurement Application Frequency Modulation - Distortion
Frequency Modulation - Distortion
Description Residual
(Rate: 1 - 10 kHz, Deviation: 5 kHz) THD Distortion SINAD Absolute Accuracy (Rate: 1 - 10 kHz, Deviation: 5 kHz) THD
Distortion SINAD AM Rejection
(AF 100 Hz to 15 kHz, 50% Modulation Depth) Residual FM (RF 500 kHz - 10 GHz) Measurement Range (Rate: 1 to 10 kHz, Deviation: 5 kHz) THD
Distortion SINAD
Specifications
Supplemental Information
0.1% (nominal) 1.3% (nominal) 37.7 dB (nominal)
� (2% of measured value + residual) (nominal) Measured 2nd and 3rd harmonics �2% of measured value + residual (nominal) �0.4 dB + effect of residual (nominal) 24 Hz (nominal)
13 Hz (nominal)
Residual to 100% (nominal)That would be an Element, not a Measured 2nd and 3rd harmonics Measurement includes at most 10 harmonics Residual to 100% (nominal) 0 dB to residual (nominal)
Keysight N9038B MXE Specification Guide
159
Analog Demodulation Measurement Application Amplitude Modulation - Level and Carrier Metrics
Amplitude Modulation - Level and Carrier Metrics
Description
AM Depth Accuracy (Rate: 1 kHz to 1 MHz)
AM Rate Accuracy (Rate: 1 kHz to 1 MHz)
Carrier Power
Specifications
Supplemental Information �0.2% + 0.002 � measured value (nominal)
�0.05 Hz (nominal)
Same as Absolute Amplitude Accuracy at all frequencies (nominal).
160
Keysight N9038B MXE Specification Guide
Analog Demodulation Measurement Application Amplitude Modulation - Distortion
Amplitude Modulation - Distortion
Description
Residual (Depth: 50%, Rate: 1 to 10 kHz)
THD Distortion SINAD Absolute Accuracy
(Depth: 50%, Rate: 1 to 10 kHz) THD
Specifications
Distortion SINAD FM Rejection
(AF + deviation < 0.5 � channel BW, AF < 0.1 � channel BW) Residual AM (RF 500 kHz to 20 GHz) Measurement Range (Depth: 50% Rate: 1 to 10 kHz) THD
Distortion SINAD
Supplemental Information
0.16% (nominal) 0.17% (nominal) 55.5 dB (nominal)
�1% of measured value + residual (nominal) Measured 2nd and 3rd harmonics �1% of measured value + residual (nominal) �0.05 dB + effect of residual (nominal) 0.5% (nominal)
0.03% (nominal)
Residual to 100% (nominal) Measured 2nd and 3rd harmonics Measurement includes at most 10 harmonics Residual to 100% (nominal) 0 dB to residual (nominal)
Keysight N9038B MXE Specification Guide
161
Analog Demodulation Measurement Application Phase Modulation - Level and Carrier Metrics
Phase Modulation - Level and Carrier Metrics
Description
Specifications
Supplemental Information
PM Deviation Accuracy (Rate: 1 to 20 kHz Deviation: 0.2 to 6 rad)
PM Rate Accuracy (Rate: 1 to 10 kHza)
�(1 rad � (0.005 + (rate/1 MHz))) (nominal) �0.2 Hz (nominal)
Carrier Frequency Error
�0.02 Hz (nominal) + tfab Assumes signal still visible in channel BW with offset.
Carrier Power
Same as Absolute Amplitude Accuracy at all frequencies (nominal).
a. For optimum measurement of PM rate and deviation, ensure that the channel bandwidth is set wide enough to capture the significant RF energy (as visible in the RF Spectrum window). Setting the channel bandwidth too narrow or too wide will result in measurement errors.
b. tfa = transmitter frequency � frequency reference accuracy.
162
Keysight N9038B MXE Specification Guide
Analog Demodulation Measurement Application Phase Modulation - Distortion
Phase Modulation - Distortion
Description Residual
(Rate: 1 to 10 kHz, Deviation: 628 mrad) THD Distortion SINAD Absolute Accuracy (Rate: 1 to 10 kHz, Deviation: 628 mrad) THD Distortion SINAD AM Rejection (AF 1 kHz to 15 kHz, 50% Modulation Depth) Residual PM (RF = 1 GHz, highpass filter 300 Hz) Measurement Range (Rate: 1 to 10 kHz, Deviation: 628 mrad) THD
Distortion SINAD
Specifications
Supplemental Information
0.1% (nominal) 0.5% (nominal) 45 dB (nominal)
�1% of measured value + residual (nominal) �1% of measured value + residual (nominal) �0.1 dB + effect of residual (nominal) 3 mrad (nominal) 2 mrad (nominal)
Residual to 100% (nominal) Measured 2nd and 3rd harmonics Measurement includes at most 10 harmonics Residual to 100% (nominal) 0 dB to residual (nominal)
Keysight N9038B MXE Specification Guide
163
Analog Demodulation Measurement Application Phase Modulation - Distortion
164
Keysight N9038B MXE Specification Guide
Keysight X-Series MXE EMI Receiver N9038B Specification Guide
13 Noise Figure Measurement Application
This chapter contains specifications for the N9069EM0E Noise Figure Measurement Application.
165
Noise Figure Measurement Application General Specifications
General Specifications
Description
Specifications
Supplemental Information
Noise Figure
<10 MHzb 10 MHz to 26.5 GHz and 26.5 to 44 GHzc
Uncertainty Calculatora Using internal preamp (such as Option P26) and RBW = 4 MHz
Noise Source ENR
Measurement Range
Instrument Uncertaintyd
4 to 6.5 dB
0 to 20 dB
�0.02 dB
12 to 17 dB
0 to 30 dB
�0.025 dB
20 to 22 dB
0 to 35 dB
�0.03 dB
a. The figures given in the table are for the uncertainty added by the X-Series Signal Analyzer instrument only. To compute the total uncertainty for your noise figure measurement, you need to take into account other factors including: DUT NF, Gain and Match, Instrument NF, Gain Uncertainty and Match; Noise source ENR uncertainty and Match. The computations can be performed with the uncertainty calculator included with the Noise Figure
Measurement Personality. Go to Mode Setup then select Uncertainty Calculator. Similar calculators
are also available on the Keysight web site; go to http://www.keysight.com/find/nfu. b. Uncertainty performance of the instrument is nominally the same in this frequency range as in the higher fre-
quency range. However, performance is not warranted in this range. There is a paucity of available noise sources in this range, and the analyzer has poorer noise figure, leading to higher uncertainties as computed by the uncertainty calculator. c. At the highest frequencies, especially above 40 GHz, the only Keysight Supra-26-GHz noise source, the 346CK01, often will not have enough ENR to allow for the calibration operation. Operation with "Internal Cal" is almost as accurate as with normal calibration, so the inability to use normal calibration does not greatly impact usefulness. Also, if the DUT has high gain, calibration has little effect on accuracy. In those rare cases when normal calibration is required, the Noisecom NC5000 series and the NoiseWave NW346V do have adequate ENR for calibration. d. "Instrument Uncertainty" is defined for noise figure analysis as uncertainty due to relative amplitude uncertainties encountered in the analyzer when making the measurements required for a noise figure computation. The relative amplitude uncertainty depends on, but is not identical to, the relative display scale fidelity, also known as incremental log fidelity. The uncertainty of the analyzer is multiplied within the computation by an amount that depends on the Y factor to give the total uncertainty of the noise figure or gain measurement. See Keysight App Note 57-2, literature number 5952-3706E for details on the use of this specification. Jitter (amplitude variations) will also affect the accuracy of results. The standard deviation of the measured result decreases by a factor of the square root of the Resolution Bandwidth used and by the square root of the number of averages. This application uses the 4 MHz Resolution Bandwidth as default because this is the widest bandwidth with uncompromised accuracy.
166
Keysight N9038B MXE Specification Guide
Noise Figure Measurement Application General Specifications
Description
Specifications
Supplemental Information
Gain
Instrument Uncertaintya <10 MHzb 10 MHz to 3.6 GHz 3.6 to 26.5 GHz
�0.10 dB
DUT Gain Range = -20 to +40 dB �0.11 dB additionalc 95th percentile, 5 minutes after calibration
26.5 to 44 GHz
Nominally the same performance as for 3.6 to 26.5 GHz. Also, see footnote c.page 166.
a. "Instrument Uncertainty" is defined for gain measurements as uncertainty due to relative amplitude uncertainties encountered in the analyzer when making the measurements required for the gain computation. See Keysight App Note 57-2, literature number 5952-3706E for details on the use of this specification. Jitter (amplitude variations) will also affect the accuracy of results. The standard deviation of the measured result decreases by a factor of the square root of the Resolution Bandwidth used and by the square root of the number of averages. This application uses the 4 MHz Resolution Bandwidth as default since this is the widest bandwidth with uncompromised accuracy. Under difficult conditions (low Y factors), the instrument uncertainty for gain in high band can dominate the NF uncertainty as well as causing errors in the measurement of gain. These effects can be predicted with the uncertainty calculator.
b. Uncertainty performance of the instrument is nominally the same in this frequency range as in the higher frequency range. However, performance is not warranted in this range. There is a paucity of available noise sources in this range, and the analyzer has poorer noise figure, leading to higher uncertainties as computed by the uncertainty calculator.
c. For frequencies above 3.6 GHz, the analyzer uses a YIG-tuned filter (YTF) as a microwave preselector, which adds uncertainty to the gain. When the Y factor is small, such as with low gain DUTs, this uncertainty can be greatly multiplied and dominate the uncertainty in NF (as the user can compute with the Uncertainty Calculator), as well as impacting gain directly. When the Y factor is large, the effect of IU of Gain on the NF becomes negligible. When the Y-factor is small, the non-YTF mechanism that causes Instrument Uncertainty for Gain is the same as the one that causes IU for NF with low ENR. Therefore, we would recommend the following practice: When using the Uncertainty Calculator for noise figure measurements above 3.6 GHz, fill in the IU for Gain parameter with the sum of the IU for NF for 4 - 6.5 dB ENR sources and the shown "additional" IU for gain for this frequency range. When estimating the IU for Gain for the purposes of a gain measurement for frequencies above 3.6 GHz, use the sum of IU for Gain in the 0.01 to 3.6 GHz range and the "additional" IU shown.You will find, when using the Uncertainty Calculator, that the IU for Gain is only important when the input noise of the spectrum analyzer is significant compared to the output noise of the DUT. That means that the best devices, those with high enough gain, will have comparable uncertainties for frequencies below and above 3.6 GHz. The additional uncertainty shown is that observed to be met in 95% of the frequency/instrument combinations tested with 95% confidence. It applies within five minutes of a calibration. It is not warranted.
Keysight N9038B MXE Specification Guide
167
Noise Figure Measurement Application General Specifications
Description Noise Figure Uncertainty Calculatora Instrument Noise Figure Uncertainty
Instrument Gain Uncertainty Instrument Noise Figure
Instrument Input Match
Specifications
See the Noise Figure table earlier in this chapter See the Gain table earlier in this chapter
Supplemental Information With user calibration
Noise Figure is: DANL + 176.24 dB (nominal)b Note on DC couplingc For best accuracy, we recommend that you measure the return loss performance of your MXE. See "RF Input VSWR" on page 37 for specific VSWR data.
NFE Improvement/Internal Cald
See "DANL and Indicated Noise Improvement with Noise Floor Extension" on page 59.
a. The Noise Figure Uncertainty Calculator requires the parameters shown in order to calculate the total uncertainty of a Noise Figure measurement.
b. Nominally, the noise figure of the spectrum analyzer is given by NF = D - (K - L + N + B)
where D is the DANL (displayed average noise level) specification, K is kTB (-173.98 dBm in a 1 Hz bandwidth at 290 K) L is 2.51 dB (the effect of log averaging used in DANL verifications) N is 0.24 dB (the ratio of the noise bandwidth of the RBW filter with which DANL is specified to an ideal noise bandwidth) B is ten times the base-10 logarithm of the RBW (in hertz) in which the DANL is specified. B is 0 dB for the 1 Hz RBW. The actual NF will vary from the nominal due to frequency response errors. c. The effect of AC coupling is negligible for frequencies above 40 MHz. Below 40 MHz, DC coupling is recommended for the best measurements. The instrument NF nominally degrades by 0.2 dB at 30 MHz and 1 dB at 10 MHz with AC coupling. d. Analyzers with NFE (Noise Floor Extension) use that capability in the Noise Figure Measurement Application to allow "Internal Cal" instead of user calibration. With internal calibration, the measurement is much better than an uncalibrated measurement but not as good as with user calibration. Calibration reduces the effect of the analyzer noise on the total measured NF. With user calibration, the extent of this reduction is computed in the uncertainty calculator, and will be on the order of 16 dB. With internal calibration, the extent of reduction of the effective noise level varies with operating frequency, its statistics are given on the indicated page. It is usually about half as effective as User Calibration, and much more convenient. For those measurement situations where the output noise of the DUT is 10 dB or more above the instrument input noise, the errors due to using an internal calibration instead of a user calibration are negligible.
168
Keysight N9038B MXE Specification Guide
Keysight X-Series MXE EMI Receiver N9038B Specification Guide
14 Phase Noise Measurement Application
This chapter contains specifications for the N9068EM0E Phase Noise measurement application. The specifications in this chapter apply for RF Input 1 and RF Preselector off.
169
Phase Noise Measurement Application General Specifications
General Specifications
Description Maximum Carrier Frequency Option 503 Option 508 Option 526 Option 544
Specifications
3.6 GHz 8.4 GHz 26.5 GHz 44 GHz
Description Measurement Characteristics Measurements
Specifications Log plot, RMS noise, RMS jitter, Residual FM, Spot frequency
Supplemental Information Supplemental Information
170
Keysight N9038B MXE Specification Guide
Phase Noise Measurement Application General Specifications
Description
Specifications
Supplemental Information
Measurement Accuracy
Phase Noise Density Accuracyab
Offset < 1 MHz
�0.30 dB
Offset 1 MHz
Non-overdrive casec
�0.30 dB
With Overdrive
�0.48 dB (nominal)
RMS Markers
See equationd
a. This does not include the effect of system noise floor. This error is a function of the signal (phase noise of the DUT) to noise (analyzer noise floor due to phase noise and thermal noise) ratio, SN, in decibels. The function is: error = 10 � log(1 + 10 -SN/10) For example, if the phase noise being measured is 10 dB above the measurement floor, the error due to adding the analyzer's noise to the UUT is 0.41 dB.
b. Offset frequency errors also add amplitude errors. See the Offset frequency section, below. c. The phase noise density accuracy for the non-overdrive case is derived from warranted analyzer specifications.
It applies whenever there is no overdrive. Overdrive occurs only for offsets of 1 MHz and greater, with signal input power greater than -10 dBm, and controls set to allow overdrive. The controls allow overdrive if the "Overdriv (MAtn)" control is set to Auto (in the Meas Setup > Advanced menu) and the "Pre-Adjust for Min Clip" control (in the Amplitude menu under Attenuation) is not set to Off, and the Electronic Attenuator is licensed and set to On. The controls also allow overdrive if the "Overdriv (MAtn)" control is set to On. To prevent overdrive in all cases, set the Overdriv control to Auto and set the Electronic Attenuator (if licensed) to Off. d. The accuracy of an RMS marker such as "RMS degrees" is a fraction of the readout. That fraction, in percent, depends on the phase noise accuracy, in dB, and is given by 100 � (10PhaseNoiseDensityAccuracy / 20 - 1). For example, with +0.30 dB phase noise accuracy, and with a marker reading out 10 degrees RMS, the accuracy of the marker would be +3.5% of 10 degrees, or +0.35 degrees.
Description
Specifications
Supplemental Information
Offset Frequency
Range
3 Hz to (opt - CF)
opt: Maximum frequency determined by option CF: Carrier frequency of signal under test
Accuracy
Offset < 1 MHz
Negligible error (nominal)
Offset 1 MHz
�(0.5% of offset + marker resolution) (nominal) 0.5% of offset is equivalent to 0.0072 octavea
a. The frequency offset error in octaves causes an additional amplitude accuracy error proportional to the product of the frequency error and slope of the phase noise. For example, a 0.01 octave frequency error combined with an 18 dB/octave slope gives 0.18 dB additional amplitude error.
Keysight N9038B MXE Specification Guide
171
Phase Noise Measurement Application General Specifications
Description
Specifications
Supplemental Information
Amplitude Repeatability
< 1 dB (nominal)a
(No Smoothing, all offsets, default settings, including averages = 10)
a. Standard deviation. The repeatability can be improved with the use of smoothing and increasing the number of averages.
Nominal Phase Noise at Different Center Frequencies See the plot of core receiver Nominal Phase Noise on page 172.
172
Keysight N9038B MXE Specification Guide
This information is subject to change without notice. � Keysight Technologies 2020 Edition 1, November 2020
N9038-90048 www.keysight.com
