TERRAIN IS NO LONGER THE LIMIT TRACK SYSTEMS WINTER TRACKS APACHE BACKCOUNTRY & BACKCOUNTRY LT Finally explore winter with no traction limitations and no compromise, thanks to the unmatched performance of Apache Backcountry track kits. Engineered to thrive in the deepest snow--for work or play. Don't let winter stand in the way. SNOW YEAR ROUND TRACKS APACHE 360 & 360 LT These ATV & SSV track kits improve your vehicle's ground clearance and increase its contact patch with the terrain. Adapt your track setup to the conditions you'll be riding and for what purpose, with the Apache 360 & 360 LT system as our all-season, all-terrain masterpiece. MIXED CONDITIONS 2 DESIGNED Each track has a specific purpose and designed without compromise for work and play. Whether it's for deep snow riding, trail riding or for heavy loads, Apache tracks are akin to floating across the terrain. ENGINEERED Unmatched performance and durability with our purpose-built track systems: choose Apache Backcountry for leading snow performance or Apache 360 and 360 LT for all-season versatility. BUILT Designed by Can-Am for your Can-Am: Apache Track Kits are matched to your engine output, chassis setup, speedometer, and work with DPS power steering for perfect control, anywhere. 3 WINTER TRACKS GET THE MOST OUT OF YOUR CAN-AM VEHICLE THIS WINTER FOR ALL YOUR ENDEAVORS. EXPLORE WITHOUT COMPROMISE. Ride on untouched trails, traveling deep into winter's embrace and you'll know: the same technology behind our world-renowned snowmobiles is at your command. With a larger contact patch, and more aggressive track design, travel beyond what you thought possible with the best snow performance. APACHE BACKCOUNTRY TRACK SYSTEM FITS > All Can-Am ATVs > Maverick Trail > Maverick Sport Designed to support ATVs and lightweight SSVs while delivering better control. COVERED BY A 1-YEAR WARRANTY TRACK PATTERNS DPS MODULE APACHE 2'' lug and 3'' pitch to increase floatation and traction in various snow conditions. Enhance your track experience with Can-Am's unique Dynamic Power Steering module. By configuring BACKCOUNTRY LT GEOMETRY multiple settings such as powersteering response and speedometer with the TRACK SYSTEM Aluminum slider system reduces track ratio, your vehicle's speedometer rolling resistance and increases the and odometer will stay true and in sync. FITS contact patch. EASY INSTALLATION > Defender > Maverick X3 ACCESSORIES Can-Am's vehicle specific mounting Customize your kit to your riding conditions with additionnal brackets simplify initial track installation. The integrated design Designed to support the heavier loads of SSVs while delivering idler wheels, Vespel sliders and allows them to remain fitted while using better traction and an ice scratchers. wheels, making future installations unmatched flotation level. as simple as changing a tire. 4 5 YEAR ROUND TRACK 6 WORK & PLAY YEAR ROUND THROUGH MUD, SNOW, & ALL TYPES OF TERRAIN. RISE ABOVE TERRAIN, weather, and whole seasons with the Apache 360 LT and 360 track kits -- the upgrade that takes the Can-Am experience to another level. Designed for superior traction and carrying heavier loads in soft terrain, both 360 and 360LT track kits can be installed on ATV and SSV vehicles and used year round for exploring and completing tough tasks. APACHE 360 TRACK SYSTEM FITS > All Can-Am ATVs Multifunctional tracks, designed to fit most Can-Am ATVs. COVERED BY A 2-YEAR WARRANTY TRACK PATTERN The pattern is different for front and rear tracks in order to optimize steering and traction over all terrain and in any conditions. EASY INSTALLATION Can-Am's vehicle specific mounting brackets simplify initial track installation. The integrated design allows them to remain fitted while using wheels, making future installations as simple as changing a tire. DPS MODULE Enhance your track experience with Can-Am's unique Dynamic Power Steering module. By configuring multiple settings such as powersteering response and speedometer with the track ratio, your vehicle's speedometer and odometer will stay true and in sync. ADAPT THE TRACK TO YOUR NEEDS Adjustable attack angle allows you to customize your track to your terrain. APACHE 360 LT TRACK SYSTEM FITS > All Can-Am ATVs and SSVs Designed to support the heavier loads of high displacement ATVs and SSVs while delivering better traction and an unmatched flotation level. APACHE 360 LT 6X6 TRACK SYSTEM The 360 LT 6x6 has all the load and pulling capacity of the Outlander 6x6 so you can always get the job done. 7 APACHE BACKCOUNTRY & BACKCOUNTRY LT TECHNICALS ASPECTS TRACKS WHEELS & SLIDERS The Backcountry track pattern is designed for optimal snow traction, without compromise. The 2'' lugs combined with the 3'' pitch allow your vehicle to "float" over deep powder and challenging terrain with class-leading traction. The Backcountry and Backcountry LT use a combination of rubber over molded wheels and a snowmobile-like slider system. This combination reduces rolling resistance, maximizing power transfer to the ground. FRAME The Backcountry system was designed for one purpose: to increase the contact patch. Composed of a steel upper section that supports lower aluminum sliders, the snowmobile-like geometry offers unmatched weight distribution on snow. ANTI-ROTATION ARM Adjustable pre-loaded spring and multiple rubber dampers keep tracks securely in place and ensure your machine's performance. Our unique system has been improved for better performance and control. SPROCKET The Backcountry and Backcountry LT use an external drive sprocket for slip-free power transfer. Developed exclusively for Can-Am vehicles, it uses a 3'' pitch for optimized performance in deep snow. TENSIONER The Backcountry and Backcountry LT use an easy to operate snowmobile type tensioner. 8 APACHE 360 & 360 LT TECHNICALS ASPECTS TRACKS The position-specific track pattern allows optimal traction and flotation for any conditions. The angled track edge greatly reduces steering effort, making turns easier, even on challenging terrain. FRAME The steel and aluminum frame combines the strength of a traditional steel chassis with a lightweight cast aluminum upper section to offer a lightweight-but-rugged track that can take on any element. SPROKET The 360 and 360LT use an internal drive sprocket, to ensure reliability in all conditions. Custom designed by Can-Am, for Can-Am, it is optimized for your vehicle's gear ratio. WHEELS ANTI-ROTATION ARM The 360 and 360 LT use rubber over molded heavy-duty wheels, positioned in an offset pattern to reduce vibration. Each wheel uses two removable bearings to minimize friction, which both improves reliability and reduces maintenance. Adjustable pre-loaded spring and multiple rubber dampers keep tracks securely in place and ensure track performance over uneven terrain. Can-Am uses vehicle-specific tuning for optimal track articulation. TENSIONER & ADJUSTMENT The attack angle on the 360 and 360 LT is adjustable: set a low attack angle to increase traction in soft terrain, or set a high attack angle to go over obstacles with greater ease. 9 TECHNICAL SPECIFICATIONS MODULES GEOMETRY DESCRIPTION Weight assembled tracks (lbs) Length front assembled track (in) Height front track (in) TRACK Total ground surface (in�) Added ground clearance (for vehicle with 26" tires) (in) Pitch (in) Length (in) Width (in) FRAME TENSIONER ANTI-ROTATION Lug height (in) Material Mechanism Mechanism SPROCKET Drive PERFORMANCE 10 Number of teeth Ground pressure ATV of 750 lbs + passenger 200 lbs (lbs/in�) Ground pressure ATV of 900 lbs + passenger 200 lbs (lbs/in�) Ground pressure SSV of 1600 lbs + passengers 200 lbs each (lbs/in�) APACHE BACKCOUNTRY Front: 70 Front: 39.9 Front: 30.5 2830.1 Rear: 96 Rear: 62.6 Rear: 30.6 7 3 Front: 96 Rear: 138 Front: 13.5 Rear: 14 Front: 2 Rear: 2 Comb. Steel-Alu Sliding Enclosed pre-loaded spring and rubbers External 17 with Large pitch 0.34 0.39 0.71 APACHE BACKCOUNTRY LT Front: 90 Front: 48.3 Front: 30.7 3179.5 Rear: 137 Rear: 69 Rear: 30.7 7 3 Front: 108 Rear: 144 Front: 13.5 Rear: 14 Front: 2 Rear: 2 Comb. Steel-Alu Sliding Enclosed pre-loaded spring and rubbers External 17 with Large pitch N/A N/A 0.63 APACHE 360 Front: 74 Front: 41.4 Front: 25.3 2079.7 Rear: 79 Rear: 43.3 Rear: 24.9 4.4 2.77 Front: 97.2 Rear: 100 Front: 11.5 Rear: 13 Front: 1 Rear: 1.25 Comb. Steel-Alu Eccentric Pre-loaded spring and rubbers Internal 17 0.46 0.53 N/A APACHE 360 LT Front: 86 Front: 41 Front: 26.2 2473.7 Rear: 105 Rear: 51.8 Rear: 26.3 4.4 2.77 Front: 100 Rear: 116.2 Front: 12.5 Rear: 14 Front: 1 Rear: 1.25 Comb. Steel/Alu Eccentric Pre-loaded spring and rubbers Internal 17 0.38 APACHE 360 LT (6X6) Front: 86 Front: 41.1 Front: 26.2 2738.5 Rear: 152 Rear: 62.2 Rear: 27.8 4.77 2.77 Front: 100 Rear: 140 Front: 12.5 Rear: 14 Front: 1 Rear: 1.25 Comb. Steel-Alu Eccentric Pre-loaded spring and rubbers Internal 17 0.35 0.44 0.40 0.81 N/A SELECT THE APACHE TRACK SYSTEM THAT BEST FITS YOUR VEHICLE & NEEDS CAN-AM SSV CAN-AM ATV TRACK SYSTEM APACHE BACKCOUNTRY APACHE 360 MODEL G2, G2S 2018 & prior & G2L G2, G2S 2019 G2, G2S 2018 & prior & G2L G2, G2S 2019 G2, G2S 2018 & prior & G2L APACHE 360 LT G2, G2S 2019 G2 6x6 models 2018 & prior G2 6x6 models 2019 & G2L 6x6 TRACKS 715003042 � $5,829.99 715005240 � $3,864.99 715005103 � $4,924.99 715005104 � $6,864.99 TRACK MOUNT KIT 715004830 � $609.99 715004796 � $609.99 715004829 � $274.99 715004795 � $274.99 715004829 � $274.99 PLUS: 715003063 (Adaptor) � $179.99 715004795 � $274.99 PLUS: 715003063 (Adaptor) � $179.99 715004991 � $214.99 715005105 � $214.99 DPS MODULE 715005243 � $159.99 1000R models: 715004707 � $159.99 Everything else: 715005243 � $159.99 715005243 � $159.99 1000R models: 715004707 � $159.99 Everything else: 715005243 � $159.99 715005243 � $159.99 1000R models: 715004707 � $159.99 Everything else: 715005243 � $159.99 715005243 � $159.99 APACHE BACKCOUNTRY APACHE BACKCOUNTRY LT Available September 2019 Maverick Trail Maverick Sport (Except X mr & X rc models) Defender (Except XT Cab 2018 & up, X mr and Lone Star) Defender XT Cab 2018 & up, X mr and Lone Star Maverick X3 64" Maverick X3 72" 715005247 � $5,829.99 715005891 � $7,999.99 715005891 � $7,999.99 715004734 � $7,999.99 Maverick* (X ds and Turbo models only) Maverick (Except X ds and Turbo models) APACHE 360 LT Commander Defender (Except XT Cab 2018 & up, X mr and Lone Star) Defender XT Cab 2018 & up, X mr, Lone Star Maverick Trail Maverick Sport (Except X mr & X rc models) Maverick X3* 64" 715005103 � $4,924.99 Maverick X3* 72" *For Maverick X3, Maverick X ds and Maverick Turbo models, we recommend snow use only. 715004285 � $634.99 715004834 � $634,99 715005888 � $739.99 715006196 � $799.99 715004397 � $949.99 715004394 � $1049.99 715003478 � $764.99 PLUS 715005760 (2x) (Adjustable Limiter Cable) � $94.99 715003013 � $754.99 PLUS 715005760 (2x) (Adjustable Limiter Cable) � $94.99 715004756 � $489.99 715004831 � $514.99 715004832 � $539.99 715004833 � $604.99 715004755 � $604.99 715004392 � $839.99 715004393 � $1,039.99 715004707 � $159.99 715004707 � $159.99 Included Included 715004707 � $159.99 PRE-FILTER Air Intake Pre-Filter 715004729 � $34.99 AND CVT Air Intake Pre-Filter (Standard on G2 models) 715003483 � $44.99 Engine & CVT Pre-Filter Kit 715004290 � $84.99 Air Intake Pre-Filter 715003483 � $44.99 AND CVT Air Intake Relocation Kit 715004183 � $54.99 Air Intake Pre-Filter 715004266 � $59.99 Air Intake Pre-Filter 715004266 � $59.99 Air Intake Pre-Filter 715004311 � $38.99 Air Intake Pre-Filter 715000953 � $36.99 Air Intake Pre-Filter 715000953 � $30.99 Air Intake Pre-Filter 715003483 � $44.99 AND CVT Air Intake Relocation Kit 715004183 � $54.99 Engine & CVT Pre-Filter Kit 715004290 � $84.99 Air Intake Pre-Filter 715004266 � $59.99 11 VISIT YOUR AUTHORIZED CAN-AM DEALER FOR MORE DETAILS OR SHOP ONLINE AT CAN-AMOFFROAD.COM �2019 Bombardier Recreational Products Inc. (BRP). All rights reserved. �, TM and the BRP logo are trademarks of BRP or its affiliates. In the U.S.A., products are distributed by BRP US Inc. BRP reserves the right, at any time, to discontinue or change specifications, prices, designs, features, models or equipment without incurring obligation. Some models depicted may include optional equipment. BRP highly recommends that all ATV drivers take a training course. For safety and training information, see your dealer or call the ATV Safety Institute at 1-800-887-2887. ATVs can be hazardous to operate. Never carry passengers on any ATV not specifically designed by the manufacturer for such use. All adult model Can Am ATVs are Category G ATVs (General Use Models) intended for recreational and/or utility use by an operator age 16 or older. For side-by-side vehicles (SxS): Read the BRP side-by-side Operator's Guide and watch the Safety DVD before driving. Fasten lateral net and seat belt at all times. Operator must be at least 16 years old. Passenger must be at least 12 years old and able to hold handgrips and plant feet while seated against the backrest. ATVs and SxS are for off-road use only; never ride on paved surfaces or public roads. For safety reasons, the operator and passenger must wear a helmet, eye protection and other protective clothing. Always remember that riding and alcohol/drugs don't mix. Never engage in stunt driving. Avoid excessive speed and be particularly careful on difficult terrain. Always ride responsibly and safely. Printed in Canada. TRACK SYSTEMS
