ONYX Collection by FRANKE ?force-download=true A Kitchen Made For Sharing
Cook with Ease in a Kitchen Designed for Sharing
The kitchen is a place of magic. It transforms ingredients into delicious dishes and everyday moments into precious memories. Cooking with your family, enjoying a romantic dinner with your partner, taste-testing a stillwarm cake baked by your kids, sharing a glass of wine with friends... Laughter, joy, conversation and, of course, great home-cooked food. Every single moment in the kitchen is worth sharing.
Franke's ONYX collection of kitchen appliances will not only delight you with its outstanding design and stylish looks, but amaze you with its dazzling array of smart features and professional functions. It promises an easier, more relaxed cooking experience that means more quality time for you to spend with family and friends.
The scene is set for joyous memories waiting to be made and shared.
Table of Contents:
1. Product Series
1
2. Product Categories
9
- Hoods
11
- Hobs
27
- Ovens/Steamers
49
- Dishwashers/Sterilisers
63
- Taps
73
3. Products Overview
79
4. Functions Overview
87
1 Product Series Designed for Asian families
1
2
Integrated Design for Enjoyable Cooking
A Smarter Way of Cooking
Control the amount of airflow simply with a gentle fingertip slide and set your cooking time in single touch. A dynamic BBQ rotation feature puts superbly grilled dishes within your reach. Cook meat and vegetables simultaneously without any exchange of flavours. And complete your cooking experience on a relaxed note, thanks to the selfcleaning feature of Onyx's built-in dishwasher. Your fast-in Onyx sink can be quickly and easily installed. The Amfag aerator of the tap can also end splashes, reduce noise, and save water efficiently. Who would think that a sink could do so much? Be prepared to enjoy the smart functions of Onyx appliances that will spare you the tedious chores of cooking and invite you to embrace the full-on fun of it with classy style.
A kitchen is so much more than a stack of appliances. It should have a style of its own and a distinct personality, just like your family.
All Onyx kitchen components are stylistically aligned to ensure aesthetic harmony and a perfectly orchestrated cooking experience with family.
Togetherness is at the heart of the Franke Onyx family of kitchen appliances.
3
4
Inspiring Possibilities
5
While their functions and features have been specifically designed to cater to the needs of Asian home kitchens and cooking preferences, Onyx appliances can easily handle Asian cuisine, Western dishes and baking. Their ease of operation will inspire every cook, from the absolute beginner to the master chef, to venture into the exciting possibilities of the international kitchen.
With a focus on lifestyle details, the Onyx collection aims to liberate you from the chores of cooking and help you experience its endless joys, together with the people you love the most.
6
Outstanding Design
Freedom of Choice
When it comes to our kitchens, everyone has their own wish-list. Onyx satisfies all your wishes. It offers multiple modular combinations from which you can choose. You enjoy the freedom to create your kitchen, your way.
Truly great design improves quality of life and embodies timeless style. The Onyx collection does both, with its combination of classic black glass and modern stainless steel, touch sliders, elegant gold and bronze colours, pristine white LCD screens, and matte brushed finish. Good taste is evident in every detail, and in every dish produced in an Onyx kitchen.
7
8
2 Product Categories Excellent Design, Outstanding Performance
9
10
HOODS
11
Keep Your Kitchen Wonderfully Fresh
Banishing kitchen smells and cooking odours has never been easier. Onyx hoods are engineered to extract kitchen vapours and smoke effectively and precisely throughout the entire cooking process, saving you from the trouble of cleaning and keeping the kitchen fresh. Your kitchen remains a comfortable place for cooking, gathering and spending wonderful times together.
12
DET Dynamic Fume Exhaust Technology
Free Your Kitchen from Cooking Oil Residue
DC Converter System
DC Converter Motor
Installed with a highly efficient DC Converter Motor, the hood has outperformed the traditional AC motor in its performance. Its air volume is up to 23 cubic meters/minute and wind pressure up to 600Pa. This powerful, quiet performer disperse fumes instantly and invisibly. With a total pressure efficiency that outperforms the traditional AC motor by 66%, it is also energy-saving and environmentally friendly.
13
Public Exhaust Pipe
Effortless Speed Control
Enjoy free speed control with the industryleading PWM electronic control technology. With a gentle swipe, just as you would swipe a smartphone, you can set the air volume to your liking, with exceptional accuracy and minimised noise.
Wind Compensation
The intelligent control system detects external resistance in real time. When the exhaust is blocked, it will automatically adjust the wind in accordance with the set air volume. Realtime detection and real-time control translate into intelligent self-servicing with no need for manual intervention.
14
New Air Suction Structure
Umbrella Air Suction
The umbrella-shaped one-piece deep-drawing smoke collector is designed in accordance with the rules of aerodynamics. Together with double-sided steel deflectors, the influx of negative pressure allows the central air inlet to be diverted into a curtain of outlets, thus tripling the area of the smoke suction range. Hence smoke is immediately absorbed upon emission, leaving the air quality in your kitchen fresh and pollution-free.
Improved Umbrella Air Suction
VS. Traditional Central Air Suction
Lowered Negative Pressure
The traditional side suction ventilator structure has been upgraded with the suction outlet repositioned lower than on conventional models. Together with parallel side suction features and aided by the strength of DC power, it efficiently absorbs smoke immediately upon emission.
15
Extremely Functional Design
Exhaust Volume
High Volume/High Noise
Quick-Fry Function Air Volume/Low noise
100
Cooking Time
Quick-fry Function
Smoke tests show that the volume of fumes reaches its peak during the first 100 seconds of quick-frying, then rapidly declines.
The Quick-fry function operates in tandem exhaust to automatically adjust when it is needed most, a truly thoughtful function with exhaustion efficiency, noise comfort and energy saving. It optimises air quality, enhances the enjoyment of cooking, and saves energy.
24-hour Air Circulation
Not all kitchen smoke is extracted immediately after cooking, so this function runs for 10 minutes at minimum air volume every hour over a 24-hour period, keeping the air in your kitchen constantly circulating and fresh.
Seamless Design
The deflector is the closest part to the smoke, it does not only diverts but also eliminates smoke and oil. Its seamless double-sided steel design rapidly converts the rising oil and vapours into liquid, which is then collected directly into the container. The easily removable top panel feature allows you to access every corner for thorough cleaning.
16
FC928KB
·· Flat Front Glass Design, Easy For Cleaning ·· Slide Down Closing with Anti-Pinch Function ·· Easy Removal Filter ·· DC motor, Much Higher Suction Power Than AC ·· Slide Touch Control, meet with Different Cooking Style With One Slide ·· Big Impeller Design 256×150 and Air Flow as High as 21m3/min ·· LCD Display and Slowly Brightening LED ·· 24h Re-circulation Feature
Installation Type: Materials: Product Dimensions : (W×D×H) Exhaust Dimensions
Wall-mounted Black Glass and Stainless Steel 895×414×930mm
185mm×2m
Max Air Flow: Max Pressure: Max Noise Level
Standard 20.5m3/min (±10%) Booster 22m3/min (±10%) Max 23m3/min Standard 450Pa Booster 470Pa Standard 68dB(A) Booster 70dB(A)
17
FC926CB
·· Big Baffle to Enlarge Fume Capture Area ·· Stainless Steel Filter ·· Seamless Welding Body Design for Easy Cleaning ·· DC Motor, Much Higher Suction Power Than AC ·· Slide Touch Control, meet with Different Cooking Style With One Slide ·· Big Impeller Design 256×150 and Air Flow as High as 21m3/min ·· LCD Display and Slowly Brightening LED ·· 24h Re-circulation Feature
Installation Type: Materials: Product Dimensions : (W×D×H) Exhaust Dimensions
Wall-mounted Black Glass and Stainless Steel 900×514×590mm
185mm×2m
Max Air Flow: Max Pressure: Max Noise Level
Standard 20m3/min (±10%) Booster 21m3/min (±10%) Max 22m3/min Standard 400Pa Booster 450Pa Max 600Pa Standard 68dB(A) Booster 70dB(A)
18
FT922C
·· Umbrella-feature with an Enlarged Fume Capture Area ·· Stainless Steel Filter ·· Seamless Welding Body Design for Easy Cleaning ·· Freely Adjustable Speed Control with the 8-keys 4-speed Touch Control to meet
with Different Cooking Style ·· Improved Exhaust Design of 256×150 for an Optimal Air Flow as High as
20m3/min
FC921M
·· Anti-pinch Closing Cover Design ·· Seamless Welding Body Design for Easy Cleaning ·· Freely Adjustable Speed Control with 6-key 3-speed Touch Control to Ensure the Perfect Air Auction
for Your Cooking Styles ·· Enlarge Exhaust up to 256×150 for the Most Efficient Air Flow as High as 19mm3/min ·· LED Screen with Time Display ·· LED Lighting for the Perfect Illumination While Cooking
Installation Type: Materials: Product Dimensions: (W×D×H) Exhaust Dimensions
Wall-mounted Black Glass and Stainless Steel 900×514×590mm
185mm×2m
Max Air Flow: Max Pressure: Max Noise Level
Standard 19.5m3/min (±10%) Booster 21m3/min (±10%) Standard 320Pa Max 420Pa Standard 69dB(A) Booster 70dB(A)
19
Installation Type: Materials: Product Dimensions : (W×D×H) Exhaust Dimensions
Wall-mounted Black Glass and Stainless Steel 895×390×980mm
185mm x 2m
Max Air Flow: Max Pressure:
Standard 18.5m3/min (±10%) Standard 320Pa Booster 380Pa
Max Noise Level: Standard 68dB(A)
20
FTS603
·· Touch Control ·· Three Speeds ·· Optional Charcoal Filter
60 400-780 400
230 29
303
275
150
500
600
Material:
Stainless Steel
Type:
60 cm Pull-out Hood
Energy Class:
N/A
Grease Filter:
Aluminium
Lighting Type:
LED Lighting
Exterior Dimensions: 900 x 280mm (W×H)
21
Max Air Flow: Max Noise Level
10.8m3/h 70 dBA
FT903P
· ·
Double Inverted Cone Filter Design
· ·
Low Noise Design, Lower than 65dB(A) without Compromising the Air Suction
Capacity Reach 16m3/min
· ·
Seamless Welding Body Design for Easy Cleaning
· ·
5-key 3-speed touch Control Feature to Freely Adjust to Your Home Cooking Styles
· ·
Designed with a Larger Impeller of 256×150 to Maximise the Air Flow up to
19m3/min
· ·
LED Lightning
Installation Type: Materials: Product Dimensions : (W×D×H) Exhaust Dimensions
Wall-mounted Black Glass and Stainless Steel 900×500×570mm
185mm×2m
Max Air Flow: Max Pressure: Max Noise Level
Standard 20.5m3/min (±10%) Standard 320Pa Standard 69dB(A)
22
FT926CB
·· Big Baffle to enlarge Fume Capture Area ·· Seamless Welding Body Design for easy Cleaning ·· DC Motor (Higher Suction power than AC) ·· Slide Touch Control ·· Big Impeller Design ·· LCD Display ·· Slowly Brightening LED + 24h Re-Circulation Featured · ·
Material:
Stainless Steel & Tempered Black Glass
Type:
Wall-mounted hood
Energy Class:
N/A
Grease Filter:
Stainless steel filter
Lighting Type:
LED spotlight
Exterior Dimensions: 900 x 513 x 708mm (W×H)
Max Air Flow: Max Noise Level
1320m3/h 70 dBA
23
FPG905SA/PH
·· Physical Switch ·· Two Speeds ·· 5-layer Alu Filter ·· Available in 60 and 90 cm
Material:
Stainless Steel
Type:
Pull-out
Energy Class:
N/A
Grease Filter:
Alu Filter
Lighting Type:
LED lighting
Exterior Dimensions: 900 x 280mm (W×H)
Max Air Flow: Max Noise Level
10.8m3/h 70dB(A)
24
FS905/PH
·· Stainless steel panel ·· 2 speed switch ·· Withdrawing fumes collection chamber; ·· 5 layer aluminum oil network; ·· LED light. ·· Optional Carbon filter
Material:
Stainless Steel
Type:
Pull-out hood
Energy Class:
N/A
Grease Filter:
Carbon Filter (Optional)
Lighting Type:
2 x 2W
Exterior Dimensions: 900 x (300-450) x 270mm (W×H)
25
Max Air Flow: Max Noise Level
620m3/h 69 dBA
FD6005A 904 XS
·· Stainless steel panel/ Mechanical Command Button ·· 2 speed switch ·· Withdrawing fumes collection chamber ·· 5 layer aluminum oil network ·· LED light ·· Optional Carbon filter
Material:
Stainless Steel
Type:
Cabinet Hood
Energy Class:
N/A
Grease Filter:
Carbon filter (optional)
Lighting Type:
1 x 2W
Exterior Dimensions: 900 x 150 x 500mm (W×H)
Max Air Flow: Max Noise Level
300m3/h N/A
26
HOBS
27
Fall in Love with Cooking
Every good cook knows the importance of heat -- only an adequate heat source with intense strength and balanced firepower will bring out the full colour and flavour of your food. Show off your cooking skills, unleash your culinary creativity, and master the technique of quick-frying to produce dish after tasty dish.
28
DHT Dynamic Heating Technology
Preserving Taste with Heat Control Triple Fire-distribution Innovation Technology
35°
About Triple Fire-distribution Innovation Technology
The stove is equipped with a breakthrough triple fire-distribution burner, the each flame is kept in a separate, independently controlled fire zone. The denser flames heat evenly and are readily adjusted to meet a wide range of firepower requirements.
29
Independent Staged Fire Control
The knob can be turned up to 225°C to achieve multistage independent firepower settings. Firepower settings are clearly displayed on the pristine white LCD screen.
5.2kw Strong Firepower
Whether it is for quick cooking over a high fire or slow stewing over a low fire, firepower can be readily and accurately adjusted. Your homemade dishes such as soy sauce beef and double-boiled soups will hold their own against the offerings of five-star restaurants.
Precise Gas Dispersion Holes angled at 35 Degrees
The large burner encloses the main fire, while the small burner stabilises the flame. The results of extensive tests show that an angle of 35 degrees ensures optimal energy and minimises carbon monoxide emission. This ingenious design optimises the efficiency of the cooking process.
30
Highlights of Onyx's Stylish Design
Premium Materials
The Onyx family is clad in pure copper, a material known for its tolerance to high temperatures, uniform heat conduction and long-term durability. The 8mm explosion-proof tempered glass panel trimmed with aluminum alloy promises its users with safety-of-use, hassle-free cleaning and piece-of-mind. To top it all off, the four-ring matte enamel hob will perfectly accommodate with almost all sizes and shaped of kitchen pots and pans.
Attractive Look
The eye-catching 3.5 mm gold belt alleviates the monotony of traditional dull black burners and infuses the kitchen with a stylish vintage vibe.
Thoughtful Details
The 1-mm protective edge around the fire hole prevents overflowing soups and sauces from spilling and entering the fire hole. The inner, middle and outer rings come with independent lever damper adjustors, that can be easily altered while maintain a steady blue flame.
31
Efficient, Safe and Energy-saving
The precise pulsing ignition is swift and stable. The thermocouple flameout protection and flameout alarm device can eliminate the risk of accidental flameout. The air and gas are fully premixed with stable pressure for reassuringly safe usage. The gas utilisation rate easily complies with national regulatory requirements for energy efficiency.
32
FGH3116
·· Single-burner Gas Hob (Domino) ·· Double Circuit Semi-brass Burners ·· Matt Enamel Cast Iron Pan Support ·· Alloy Laser Knob Control ·· One-hand Ignition ·· Electrical Spark Ignition ·· Flame Failure Safety Device
Material: Gas Type/Preset: Max Output : Product Dimensions (W×H×D): Cut out Dimensions (W×H):
High Quality Tempered Glass 6mm) NG (12T) 4.2kw (12T) 310×520×132 mm 265×490mm
33
FGH3216
·· Double-burner Gas Hob (Domino) ·· Double Circuit Semi-brass Burners ·· Matt Enamel Cast Iron Pan Support ·· Alloy Laser Knob Control ·· One-hand Ignition ·· Electrical Spark Ignition ·· Flame Failure Safety Device
Material: Gas Type/Preset: Max Output : Product Dimensions (W×H×D): Cut out Dimensions (W×H):
High Quality Tempered Glass (6mm) NG (12T) 2.0kW 1.4kW (12T) 310×520×132mm 265×490 mm
34
FG8228
·· Horizontal Double Burner Gas Hob ·· Triple Circuit Brass Burners ·· Matt Enamel Cast Iron Pan Support ·· Alloy Laser Knob Control ·· White LCD Lighting Power Display ·· White LCD timer 99-minute Timer ·· One-hand Ignition ·· Electrical Spark Ignition ·· Flame Failure Safety Device
Material: Gas Type/Preset: Max Output: Product Dimensions (W×H×D): Cut out Dimensions (W×H):
High Quality Tempered Glass (8mm) NG (12T) L5.2kw R5.2kw 820×460×150mm 700×400mm
35
FG7226
·· Horizontal Double-burner Gas Hob ·· Double Circuit Brass Burners ·· Matt Enamel Cast Iron Pan Support ·· Alloy Laser Knob Control ·· White LCD Display ·· Timer Function up to 99 Minutes ·· One-hand Ignition ·· Electrical Spark Ignition ·· Flame Failure Safety Device
Material: Gas Type/Preset: Max Output : Product Dimensions (W×H×D): Cut out Dimensions (W×H):
High Quality Tempered Glass (8mm) NG (12T) L: 5.0kw R: 5.0kw 760×450×150mm 650×350mm
36
FHG 8216
·· Powerful dual double circuit brass burners ·· Cast iron wok right support (dishwasher-friendly) ·· Enameled burner caps ·· One hand ignition ·· Electrical spark ignition ·· Alloy laser design know control
Material: Gas Type/Preset: Max Output: Product Dimensions (W×H×D): Cut out Dimensions (W×H):
Tempered Black glass LPG/TG L4.5kw , R4.5kw 780×460×150mm 680×380 mm
37
FHS7212
·· Horizontal Double-burner Gas Hob ·· Double Circuit Semi-brass Burners ·· Matt Enamel Cast Iron Pan Support ·· Alloy Laser Knob Control ·· One-hand Ignition ·· Electrical Spark Ignition ·· Flame Failure Safety Device
Material: Gas Type/Preset: Max Output : Product Dimensions (W×H×D): Cut out Dimensions (W×H):
High Quality Stainless Steel Surface LPG (20Y) L4.5kw R4.5kw 710×400×150 mm 630×330 mm
38
FHG7212
·· Horizontal Double-burner Gas Hob ·· Double Circuit Semi-brass Burners ·· Matt Enamel Cast Iron Pan Support ·· Alloy Laser Knob Control ·· One-hand Ignition ·· Electrical Spark Ignition ·· Flame Failure Safety Device
Material: Gas Type/Preset: Max Output : Product Dimensions (W×H×D): Cut out Dimensions (W×H):
High Quality Tempered Glass (8mm) LPG (20Y) L4.5kw R4.5kw 730×420×150 mm 630×330 mm
39
FHG 8312
·· Horizontal Triple-burner Gas Hob ·· Double Circuit Semi-brass Burners ·· Matt Enamel Cast Iron Pan Support ·· Alloy Laser Knob Control ·· One-hand Ignition ·· Electrical Spark Ignition ·· Flame Failure Safety Device
Material: Gas Type/Preset: Max Output: Product Dimensions (W×H×D): Cut out Dimensions (W×H):
High Quality Tempered Glass (8mm) LPG20Y) L4.5kw Mid: 1.4kw R4.5kw 780×460×150mm 680×380 mm
40
FHG8318
·· Triple-burner Gas Hob ·· Triple Circuit Brass Burners ·· Matt Enamel Cast Iron Pan Support ·· Alloy Laser Knob Control ·· One-hand Ignition ·· Electrical Spark Ignition ·· Flame Failure Safety Device
Material: Gas Type/Preset: Max Output : Product Dimensions (W×H×D): Cut out Dimensions (W×H):
High Quality Tempered Glass LPG (20Y) L5.0kw Mid: 1.8kw R5.0kw (20Y) 800×460×150 mm 700×400 mm
41
FHG 8316
·· Powerful dual double circuit brass burners ·· Cast iron wok right support (dishwasher-friendly) ·· Enameled burner caps ·· One hand ignition ·· Electrical spark ignition ·· Alloy laser design know control
Material: Gas Type/Preset: Max Output Product Dimensions (W×H×D): Cut out Dimensions (W×H):
Tempered Black Glass LPG/TG L: 5.0kW / Mid: 1.8kW / R: 5.0kW 800 x 460 x 150mm 700 x 400mm
42
FG6416
·· Four-burner Gas Hob ·· Double Circuit Semi-brass Burners ·· Matt Enamel Cast Iron Pan Support ·· Alloy Laser Knob Control ·· One-hand Ignition ·· Electrical Spark Ignition ·· Flame Failure Safety Device
Material: Gas Type/Preset: Max Output :
Product Dimensions (W×H×D): Cut out Dimensions (W×H):
43
High Quality Tempered Glass (8mm) NG (12T) Front L1.4kw Front R2.0kw Rear L4.2kw Rear R2.0kw 600×510×150mm 555×475mm
FS6416
·· Four-burner Gas Hob ·· Double Circuit Semi-brass Burners ·· Matt Enamel Cast Iron Pan Support ·· Alloy Laser Knob Control ·· One-hand Ignition ·· Electrical Spark Ignition ·· Flame Failure Safety Device
Material: Gas Type/Preset: Max Output :
Product Dimensions (W×H×D): Cut out Dimensions (W×H):
High Quality Stainless Steel Surface NG (12T) Front L1.4kw Front R2.0kw Rear L4.2kw Rear R2.0kw 580×510×150mm 555×475mm
44
FIH7210
·· Horizontal Double-zone Induction Hob ·· Sliding Touch Control Panel, with LED Display ·· 10 Power Stage Setting ·· Featured with a Timer, and the Child Lock Safety ·· Overheat Protect ·· Residual Heat Indicator
Material: Max Output : Electrical Voltage: Electrical Frequency: Product Dimensions (W×H×D): Cut out Dimensions (W×H):
Schott/Eurokera-quality Tempered Glass 1.8KW+1.3KW 220V 50Hz 800×460×150 mm 700×400 mm
45
FCIH7210
·· Hybrid Double Zone 1×Ceramic and 1×Induction Hob ·· E.G.O Radiant Plate ·· Sliding Touch Control ·· 9 Power Stage Setting ·· Featured with the Child Lock Safety and a Timer
Material: Max Output : Electrical Voltage: Electrical Frequency: Product Dimensions (W×H×D): Cut out Dimensions (W×H):
High Quality Tempered Glass Ceramic 2200W (central: 1000W) + induction 2000W 220V 50Hz 800×460×150 mm 700×400 mm
46
FIH3126
·· Built-in Schott Ceran ceramic domino hob ·· LED display ·· Sensor touch control panel ·· 9-power level ·· Equipped with booster feature ·· Electronic timer ·· Safety cooling device ·· Overheat-protect feature ·· Residual heat indicator
Material: Max Output : Electrical Voltage: Electrical Frequency: Product Dimensions (W×H×D): Cut out Dimensions (W×H):
Tempered Black Glass 3.7kW 220-240V, 16A 5-60Hz 310 x 520 x 50mm 280 x 490mm
47
FIH3226
·· Built-in Schott Ceran ceramic domino hob ·· LED display ·· Sensor touch control panel ·· 9-power level ·· Equipped with booster feature ·· Electronic timer ·· Safety cooling device ·· Overheat-protect feature ·· Residual heat indicator
Material: Max Output : Electrical Voltage: Electrical Frequency: Product Dimensions (W×H×D): Cut out Dimensions (W×H):
Tempered Black Glass 3.7kW (2.0kW, 1.5kW) 220-240V, 16A 50-60Hz 310 x 520 x 50mm 280 x 490mm
48
Ovens / Steamers
Cook like a Chef, at Home
Whether it's used for everyday cooking and baking or producing a lavish spread for special occasions, this professional-grade oven will guarantee compliments to the chef. From roasting a Thanksgiving turkey to grilling a family BBQ and baking teatime treats for friends, it will never let you down.
49
50
Oven
Baking and Roasting, All in One Multiple Cooking Program Creates Impressive Menu
Dynamic Heating Technology
The upper and lower heating tubes, supplemented by fan-forced heat, deliver genuine 360-degree, three-dimensional heat. The precise temperature control delivers accuracy up to ±1°C. Be it for baking or grilling, the Dynamic Heating Technology enriches textures without compromising its nutritious values
51
Fun Cooking
The 10 heating modes complement the 3 commonly used automation menus fully meet the needs of all users, from absolute beginners to seasoned home cooks and professional bakers.
3D Turbo Grill The mode of top heating + bottom heating + fan circulation is ideal for roasting large pieces of meat such as lamb leg, steak, whole poultry , etc.
Grill The mode of top heating + roasting is ideal for finishing off baked and roasted dishes just before serving, as well as quick baking at high temperatures to ensure the food remains succulent and tasty.
Fan Circulation The mode of fan heating is suitable for baking ingredients on multi-layer trays at the same time, or for baking nuts, making dried fruit , etc.
Top/Bottom Heat The mode of top heating + bottom heating is ideal for baking cookies and sponge cakes, delivering an evenly baked texture and a lovely golden brown finish.
Turbo Grill The mode of Top Roasting + Fan Heating is ideal for baking several trays at the same time, ensuring that all ingredients are evenly heated and well-cooked.
Thawing Mode Employing low-power fan heating, this mode is suitable for quickly thawing seafood, frozen meat and other frozen food.
Conventional BBQ Grilling The mode of top roasting + grilling + bottom heating is suitable for cooking whole poultry, steak, mutton and fish, producing results similar to those of charcoal grilling.
Medium BBQ Grilling The mode of top roasting + rotated grilling is suitable for cooking kebab, chicken wings, sausages and other small pieces of food.
Strong BBQ Grilling The mode of hot air heating + grilling is suitable for glazing in the final stages of cooking, producing results similar to when food is air-dried in a windy outdoor environment. Ideally, a grilling tray should be placed under the grill to collect the dripping fat and juices during grilling.
Strong Wind BBQ Grilling
The mode of hot air heating + rotated grilling is suitable for
glazing in the final stage of cooking, producing results similar
+
to air-dried food that is dried in a windy outdoor environment.
Ideally, a grilling tray should be placed under the grill to collect
the dripping fat and juices during grilling.
52
Ultimate Convenience with Uncompromised Functionality
Reliable, Efficient and Safe
Designed for Ease of Use
Ease of use is ensured by the touch screen control panel, featuring a pristine white LCD display with 180-degree visibility and clear icons. The unique and flexible pull rail design makes cooking easy and effortless. The built-in multi-point temperature control enables precise temperature control and ready command of the fire.
A Breeze to Clean
Featuring an easy-to-remove design, the glass door panel is completely removable to make cleaning easy, fast and thorough. The inner surface and baking trays feature a dry enamel surface that is easy to clean and durable.
Feed a Hungry Family
With a generous volume of up to 60L, the oven can feed a large family with just one hearty roast. The 304 stainless steel grill and matching BBQ grill forks bring the fun of charcoal grilling to your family, without stepping outside your home.
The whole appliance is clad in high-quality heat insulation material to maintain the roasting temperature inside the oven while eliminating the risk of deforming or damaging the cabinetry from heat. The triple-layer insulated glass and low-E thermal reflective film effectively prevents scalding. The front tangential cooling fan forcibly dissipates the heat so that the circulating cold air blows away and protects the cabinetry.
53
54
Steamer
Optimal Nutrition through Steaming
Dynamic Heating for Steamed Dishes
Dual Functions: Heating and Thawing
Steam Heating The 360-degree steam heating process, under the micro-pressure of a sealed environment with a temperature range of 50-100°C, can be adjusted to different temperatures for cooking different dishes simultaneously. It also provides plate-warming, heating, disinfection and many other useful functions. Steam heating is a great way to cook fish, vegetables and other dishes, sealing in both flavour and nutrients.
Thawing Function Heating at a temperature of 50°C is ideal for the rapid thawing of frozen food, which can be heated according to the cooking instructions on its packaging.
The 360-degree dynamic circulation steam heating and micro-pressure heating enables healthy, original and nutritional dishes with high efficiency. The precise temperature control, accurate to within 1°C, ensures optimal flavour and overall results.
55
Use with Ease, Enjoy at Leisure
The quick-steam mode suits to a wide range of ingredients and helps retain the full nutritional value of the food. Three commonly used menus are set and just need one press. It is also featured with the pre-setting function so that you can enjoy a leisurely breakfast with your family on an early morning.
56
More Thoughtful Design Features
Steam Multiple Dishes Simultaneously
The multi-layer food racks enable the cooking of multiple dishes at the same time with no exchange of flavours.
The Human Touch
The steam oven is fitted with a 1.2 L water tank, enabling efficient high-volume water usage and long continuous cooking times. The built-in anti-fog and warm lighting allows the cook to intervene and control the process at any time.
Safe and Easy to Clean
The anti-scald glass door and LCD display touch are safe and easy to clean and maintain.
57
Safeguarding the Health of Your Family
Safety Protection
The food-safe 304 stainless steel-made interior and the smart anti-dry-burning double guard your safety. Complemented with the child-lock function help prevent mishaps and protect your curious children from the dangers of accidental operation.
Thermal Protection
The front cooling system is cabinetry-friendly. The whole steam oven is cotton-insulated so that the inside of the oven is kept warm and the food stays at its ideal temperature.
58
FBO6200BX
·· Direct Touch Control Panel with White LCD Display ·· 10 Cooking Programs ·· 3 Auto Cook Menus ·· Pause Function ·· Start Delay ·· Digital Electronic Clock ·· Automatic Temperature Proposal with Actual Temperature Display ·· Integral Cooling Fan ·· 5-shelf Level ·· Telescopic Runners ·· Enamel Oven Interior ·· Interior Illumination Lighting ·· Triple Glass Cool Touch Door ·· Removable Oven Door
452
250cm 2 500 50
55 0
600 565
595 250cm 2
5 95
22
Material: Appliance (H×W×D): Cut out (H×W×D): Capacity:
Black Glass & Stainless Steel 593×595×550 mm 585×565×560 mm 60L
Heating temperature: Total connected load: Rlectrical Frequency Electrical Voltage
50 to 250°C 2400W 50-60Hz, 16A 220~ 240V
59
54 0 57 5
FBOK6200BX
·· Direct Touch Control Panel with White LCD Display ·· 10 Cooking Programs ·· 3 Auto Cook Menus ·· Pause Function ·· Start Delay ·· Automatic Temperature Proposal with Actual Temperature Display ·· 4-shelf Level ·· Enamel-material Interior ·· Triple Glass Cool Touch Door ·· Removable Oven Door for Easy Clean
45 5
22
55 0 595
540 44 7
Appliance (H×W×D): Cut out (H×W×D): Capacity: Heating temperature:
455×595×470 mm 452×565×550 mm 40L 50 to 250°C
Total connected load: Electrical Frequency Electrical Voltage
2400W 50-60Hz, 16A 220~ 240V
60
FDO6200BX
·· Direct Touch Control Panel with White LCD Display ·· Pure Steam Technology ·· 2 Steam Cooking Functions: Steam/ Defrost ·· 3 Auto Programs: P1- 100°C 30 mins/ P2- 90°C 45 mins/ P3- 80°C 20 mins ·· Digital Electronic Clock and Alarm Function ·· Automatic Temperature Proposal with Actual Temperature Display ·· 2-layer Glass Cool Touch Door Safety ·· Removable Oven Door for an Easy Clean ·· 4-shelf Level ·· Stainless Steel-material Cavity
250cm 2 500 50
600 565
22
55 0
250cm 2
59 5
Appliance (H×W×D) Cut out (H×W×D): Capacity Water Tank Capacity: Heating temperature:
593×595×550 mm 585×565×560 mm 30L 1.2L 50 ~ 100°C
61
Total connected load: Electrical Frequency Electrical Voltage Plug
2400W 50-60Hz 220~ 240V 10A
452
45 5 47 0
447 143
FWS6200XS
· ·
Push-to-open Mechanism
· ·
Food-warming Feature
· ·
Electronic Temperature Control
· ·
3 Warming Controls:
25°C tea cups warming/ 45°C plates warming/ 65°C food warming
· ·
Operating Indicator Light
565
Appliance (H×W×D) Cut out (H×W×D): Capacity Loading max: Temperature setting:
140×595×555 mm 138×565×523 mm 26L 20kg 25 ~ 70°C
Total connected load: Electrical Frequency Electrical Voltage Plug
320W 50-60Hz 220~ 240V 10A
62
Dishwashers / Sterilisers
Keep Your Kitchen Fresh
The inevitable downside of a great home-cooked meal is the stack of greasy bowls and plates at the end of it. But instead of washing them with your bare hands, you can simply press a button and, as if by magic, the dishes will 'clean themselves'. A dishwasher will free up both your hands and your time, giving you back to your family and friends. Mealtimes can stretch into leisurely afternoons and evenings of long conversation. It also sanitises your tableware and cookware, protecting the health of your loved ones while keeping your dishes and glasses sparkling clean.
63
64
Dishwasher
'Standard' Size, Exceptional Capacity
Meeting the Daily Needs of Asian Families
60cm
60cm
Standard Size
The Onyx family of dishwashers has been developed with Asian homes in mind. The flexible 60 cm x 60 cm standard size easily fits into cabinets of various heights, and can be conveniently replaced by other standard-size appliances such as steriliser cabinets. It means that your kitchen can be easily and costeffectively upgraded.
Customised Baskets and Racks for All Kitchen Utensils
The durable racks and baskets are designed to accommodate all shapes and sizes of cutlery and kitchen utensils.
65
Double Swirl and Jet-wash System
The super-efficient double swirling and jet-washing system features 22 water jet holes and 9 water jet angles to generate a 360-degree water column. Combined with a powerful centrifugal pump of 3,000 rpm and 75°C of ultra-high heat to dissolve stubborn grease and sterilise surfaces, it cleans right down to the bottom of every bowl.
66
Design that`Knows'and Meets Your Needs
7+n Programmes for a Wide Range of Washing Scenarios
Drying Enhancement
An optional drying function can be added to each program, utilising the 75°C of ultra-high heat to facilitate the drying effect. This eliminates the bane of damp plate bottoms, keeping your tableware hygienically dry.
Half-load Washing Mode
When you have only accumulated a few dirty dishes or less than four items, you may choose the energy-friendly half-load washing mode. (Note: Some models do not carry this function.)
Three-in-one Detergent Box
The dishwasher is fitted with a three-in-one detergent box that can contain a separate detergent, rinsing agent and softening salt. Homemakers have the freedom of choice to mix and match their favourite cleaning products.
Standard Wash The standard washing program is designed for daily washing and drying of tableware with moderate grease and dirt.
Strong Wash Specially designed for Asian cooking style, this mode completely removes stubborn grease and burnt residue on pots and puns.
Energy-saving Wash This mode is applicable to daily washing, fully immersed, ideal for cleaning general oil dishes; with energy-saving optimisation procedures, it is the best way to save water and electricity.
Pre-rinsing This mode uses cold water to soak and soften the dirt prior to washing. It can also be used for washing selected fruit and seafood. The cycle takes just 11 minutes.
Last-minute Adding Function
If you happen to find some dirty dishes that you forgot to load, you will not have need to wait for a cycle to finish. You may simply reload the dishwasher at any time before the detergent box is opened, without compromising the cleaning results.
Quick Wash Suitable for lightly soiled dishes, this energy-saving mode washes in just 30 minutes.
Soft Wash Especially for delicate glassware and fragile porcelain, this mode employs a moderate temperature and gentle water flow to safely wash and dry your premium collectibles. It is also suitable for lightly soiled dishes.
Up to 12 hours Pre-set Function
The cleaning time can be flexibly pre-set up to 12 hours prior to your dishwasher commences its cycle, so that you can use clean tableware from the moment you reach home. You can even choose to operate it during periods of low electricity pricing, saving both energy and money.
Self-cleaning This unique self-cleaning mode allows the user to regularly clean the interior and the filter system of the dishwasher, without lifting a finger!
Customised Wash According to the individual needs and preferences, users can choose from 64 combinations with 16 optional time durations and 4 temperature settings. Once set, the customised program is 'remembered' and requires no further resetting.
67
68
Steriliser
Professional Disinfection for All-round Protection
Sterilisation at Ultra-high Temperature
An ultra-high temperature of 120°C sterilises every corner and crevice of your dishes and glasses. The high-temperature drawer employs leading refrigerator foaming insulation technology to ensure that your cabinetry remains unharmed.
69
Independent Double 'Drives'
The steriliser features an upper drawer for ozone + UV disinfection and a lower drawer for high-temperature disinfection. Both drawers are isolated and can work independently or simultaneously to efficiently cater to a wide range of disinfection needs in a more flexible and energy-efficient way.
Slide Rails
The advanced external square slide design is independent from the storage space of the tableware and chopsticks, thus eliminating any risk of contamination. The slide rail design is smoother and lighter than its predecessors, making it much more delightful.
Transformable Dishwashing Basket
The dishwashing basket is designed with various scenarios in mind, it can be easily reconfigured to accommodate a wide range of loads comprising tableware, glassware and cookware of varying sizes and shapes.
70
DWFDWS 608 A+ XS
·· 60cm Height, Flexible for Installation ·· 2 layer of Basket Customized for Asia User ·· LCD Display Touch Panel ·· 6 Standard Wash Mode1 DIY Mode ·· Strengthen Drying ·· Light Load ·· Self Cleaning Mode ·· Delay Start 1-12H ·· Stainless Steel 3 Layer Filter
Dimensions (W×H×D): Material: Type: Electrical Voltage: Rated Power: Plug:
595×598×505mm Black Glass & Stainless Steel Built-in 220V 1800W 10A
71
20
600 590
550 565 600
FDZTD100L-A2P
·· LCD Display, High Class and Fashion ·· Electronic Touch Control, easy Operation and Convenient for
Cleaning ·· Separate Room for High Temperature and Low Temperature
Sterilization, Flexible and Complete Outer mount Rail, no Concern for Hygiene ·· Stainless Steel Bracket, Endurable and Maximized Space by Considerate Design ·· Multiple Protection( Over Heat, Electromagnetic Lock, Cut off when Door Opened, Child Lock to avoid Wrong Operation )
Dimensions (W×H×D): Cut in Dimensions (W x H x D) Materials: Installation Type: Electrical Voltage: Electrical Frequency:
595×630×516 mm 565×615×520 mm
Tempered Glass & Stainless Steel Built-in 220V 50Hz
Rated Power: Volume: Sanitization way:
Drying way: Drying temperature: Carrying capacity:
600W 100L Ozone +UV (upper bracket) / high temp (lower bracket) Light wave lamp 120 5KG - 7KG
72
TAPS
73
Kitchen Preparation
Kick-start Your Cooking Journey
The cooking journey begins long before heat touches food, when your beautiful vegetables and delicate fish are washed in water. They emerge shiny and squeaky clean, awaiting their transformation.
74
Tap
Superb Craftsmanship, Stringent Hygiene
75
Premium Materials
High-quality 304 stainless steel is lead-free and therefore conducive to healthy drinking water. The imported ceramic valve core is guaranteed to last. And the 304 stainless steel hose is pressure-resistant and corrosionresistant.
Fine Craftsmanship
The brushed stainless steel is durable and long-lasting. Its sleek, premium design is at home in every elegant contemporary setting.
Excellent Design
The high-gloss pipe design is elegant, eye-catching and superb to the touch. It features fine Amfag bubbler to integrate the water outlet and water-saving functions. The pull-type shower design allows free control of the water outlet angle, while the classy black lever handle matches with your other kitchen appliances.
76
CT 193S
·· The Pull-out Spray tap by Onyx has a Swivel-mounted Tap Neck and a Spout you can Pull-out Sideways for Extra Versability
·· High Quality Franke Stainless Steel Made
·· Elegantly Designed, with a Black Handle to Match with the ONYX
Hot Water
Elements
Cold Water
·· Paired with the Fast-in Features for an Easy Installation
Tap Type: Tap Material: Tap Finish: Water Hose Material: Outlet Pipe Length: Outlet Height: Tap Height: Base Diameter:
Single Lever Swivel Pull-out Spray Cold & Hot Tap Stainless Steel Brushed Satin Stainless Steel Hose 229mm 242mm 435mm 54mm
77
78
3 Product Overview Flexible Combinations
79
80
Hoods
CXW-268-FC928KB Hood Dimensions (w×h×d): 895 × 414 × 930mm
CXW-268-FT926CB Hood Dimensions (w×h×d): 900 × 514 × 590mm
CXW-220-FT922C Hood Dimensions (w×h×d): 900 × 514 × 590mm
FD6005A 904 XS Hood Dimensions(w×d×h) :900 x 150 x 500mm
Hobs
CXW-220-FC921M Hood Dimensions (w×h×d): 895 × 390 × 980mm
CXW-220-FT903P Hood Dimensions (w×h×d): 900 × 500 × 570mm
CXW-268-FT926CB Hood Dimensions (w×h×d): 900 x 513 x 708mm
FGH3116 Gas Hob Dimensions (w×h×d): 310 × 520 × 132mm
FGH3216 Gas Hob Dimensions (w×h×d): 310 × 520 × 132mm
FG8228 Gas Hob Dimensions (w×h×d): 820 × 460 × 150mm
CXW-200-FPS905 Hood Dimensions (w×d): 900×280mm
81
CXW-200-FPS605 Hood Dimensions (w×d): 600 x 280mm
FPG905SA/PH Hood Dimensions (w×d): 900 x 280mm
FG7226 Gas Hob Dimensions (w×h×d): 760 × 450 × 150mm
FS7226 Gas Hob Dimensions (w×h×d): 760 × 450 × 150mm
FHS7212 Gas Hob Dimensions (w×h×d): 710 × 400 × 150mm
82
FHG7212 Gas Hob Dimensions (w×h×d): 730 × 420 × 150mm
FHG8216 Gas Hob Dimensions (w×h×d): 780 x 460 x 150mm
FHG8312 Gas Hob Dimensions (w×h×d): 780 × 460 × 150mm
FIH3126 Induction Hob Dimensions(w×d×h) :310 x 520 x 50mm
FIH7210 Induction Hob Dimensions (w×h×d): 800 × 460 × 150mm
FCIH7210 Induction Hob Dimensions (w×h×d): 800 × 460 × 150mm
FHG8318 Gas Hob Dimensions (w×h×d): 800 × 460 × 150mm
FH8316 Gas Hob Dimensions (w×h×d): 800 x 460 x 150mm
FG6416 Gas Hob Dimensions (w×h×d): 600 × 510 × 150mm
FIH3226 Dimensions(w×d×h) : 310 x 520 x 50mm
Cooking Appliances
FS6416 Gas Hob Dimensions (w×h×d): 580 × 510 × 150mm
83
FBO6200BX Oven Dimensions (w×h×d): 593 × 595 × 550mm
FBOK6200BX Compact Oven Dimensions (w×h×d): 455 × 595 × 470mm
FDO6200BX Steamer Dimensions (w×h×d): 593 × 595 × 550mm
84
Warming Drawers
FWS6200XS Warming Drawer Dimensions (w×h×d): 138 × 565 × 523mm
Dishwashers / Sterilizers
DWFDWS 608 A+ XS Dishwasher Dimensions (w×h×d): 595 × 598 × 505mm
FDZTD100L-A2P Steriliser Dimensions (w×h×d): 595 × 630 × 516mm
Taps
CT 193S Tap Dimensions (h) : 435mm
85
86
4 Functions Overview Convenient Operation, Better Cooking
87
88
Oven
3D Turbo Grill The mode of top heating + bottom heating + fan circulation is ideal for roasting large pieces of meat such as lamb leg, steak, whole poultry , etc.
Grill The mode of top heating + roasting is ideal for finishing off baked and roasted dishes just before serving, as well as quick baking at high temperatures to ensure the food remains succulent and tasty.
Fan Circulation The mode of fan heating is suitable for baking ingredients on multi-layer trays at the same time, or for baking nuts, making dried fruit , etc.
Top/Bottom Heat The mode of top heating + bottom heating is ideal for baking cookies and sponge cakes, delivering an evenly baked texture and a lovely golden brown finish.
Turbo Grill The mode of Top Roasting + Fan Heating is ideal for baking several trays at the same time, ensuring that all ingredients are evenly heated and well-cooked.
Thawing Mode Employing low-power fan heating, this mode is suitable for quickly thawing seafood, frozen meat and other frozen food.
Conventional BBQ Grilling
The mode of top roasting + grilling + bottom heating is suitable for cooking whole poultry, steak, mutton and fish, producing results similar to those of charcoal grilling.
Medium BBQ Grilling
The mode of top roasting + rotated grilling is suitable for cooking kebab, chicken wings, sausages and other small pieces of food.
Strong BBQ Grilling
The mode of hot air heating + grilling is suitable for glazing in the final stages of cooking, producing results similar to when food is airdried in a windy outdoor environment. Ideally, a grilling tray should be placed under the grill to collect the dripping fat and juices during grilling.
Strong Wind BBQ Grilling
The mode of hot air heating + rotated grilling
+
is suitable for glazing in the final stage of
cooking, producing results similar to air-
dried food that is dried in a windy outdoor
environment. Ideally, a grilling tray should be
placed under the grill to collect the dripping fat
and juices during grilling.
89
Steamer
Steam Heating The 360-degree steam heating process, under the micro-pressure of a sealed environment with a temperature range of 50-100°C, can be adjusted to different temperatures for cooking different dishes simultaneously. It also provides plate-warming, heating, disinfection and many other useful functions. Steam heating is a great way to cook fish, vegetables and other dishes, sealing in both flavour and nutrients.
Dishwasher
Standard Wash The standard washing program is designed for daily washing and drying of tableware with moderate grease and dirt.
Strong Wash Specially designed for Asian cooking style, this mode completely removes stubborn grease and burnt residue on pots and puns.
Quick Wash Suitable for lightly soiled dishes, this energysaving mode washes in just 30 minutes.
Self-cleaning This unique self-cleaning mode allows the user to regularly clean the interior and the filter system of the dishwasher, without lifting a finger!
Thawing Function Heating at a temperature of 50°C is ideal for the rapid thawing of frozen food, which can be heated according to the cooking instructions on its packaging.
Energy-saving Wash This mode is applicable to daily washing, fully immersed, ideal for cleaning general oil dishes; with energy-saving optimisation procedures, it is the best way to save water and electricity.
Pre-rinsing This mode uses cold water to soak and soften the dirt prior to washing. It can also be used for washing selected fruit and seafood. The cycle takes just 11 minutes.
Soft Wash Especially for delicate glassware and fragile porcelain, this mode employs a moderate temperature and gentle water flow to safely wash and dry your premium collectibles. It is also suitable for lightly soiled dishes.
Customised Wash According to the individual needs and preferences, users can choose from 64 combinations with 16 optional time durations and 4 temperature settings. Once set, the customised program is 'remembered' and requires no further resetting.
90
Franke Kitchen Systems Franke-Strasse 2 CH-4663 Aarburg Switzerland
Phone: +41 627 873 131 sales.sea@franke.com
www.franke.com Printed in January 2020
For more wonderful news follow us on Facebook and Instagram
Adobe PDF Library 10.0.1 Adobe InDesign CC (Macintosh)
