Slide-In Induction Range Quick Start Guide

OPERATING INSTRUCTIONS

⚠️ WARNING: To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS, located in your appliance's Owner's Manual, before operating this appliance.

Using Your Oven

• Step 1. Select oven function
• Step 2. Set the temperature
• Step 3. Press Start
• Step 4. Place food inside the oven once set temperature is reached. Close the oven door.
• Step 5. (Optional) Enter time to cook
• Step 6. The Cancel button can be used to cancel the function during or after cook time.

NOTE: For more detailed instructions on specific functions, see the online Control Guide.

Using Your Range

⚠️ WARNING: Fire Hazard

Turn off all controls when done cooking. Failure to do so could result in death or fire.

To use, press Power [▶️] and touch the respective display area to turn on the desired heating element.

Select a heat setting from "1" through "9" by touching/sliding on the power slider.

REMEMBER: When the range is in use, the entire cooktop area may become hot.

POSITIONING RACKS AND BAKEWARE

⚠️ IMPORTANT: To avoid permanent damage to the porcelain finish, do not place food or bakeware directly on the oven door or bottom.

Racks

• Position racks before turning on the oven.
• Do not position racks with bakeware on them.
• Make sure racks are level.

To position a rack, pull it out to the stop position, raise the front edge, and then lift out. Use the following illustration as a guide.

For hamburger patties to have a well-seared exterior and a rare interior, use a flat rack in rack position 7. Cook Side 1 for approximately 2.5 to 3.5 minutes. Cook Side 2 for approximately 4 to 5 minutes. Expect a moderate degree of smoke when broiling.

BAKING COOKIES AND LAYER CAKES ON 2 RACKS

Baking Layer Cakes

For best results when baking cakes on 2 racks, use the Bake function, a flat rack in rack position 3, and a roll-out rack in rack position 5. Place the cakes on the racks. Keep at least 3 inches (7.6 cm) of space between the front of the racks and the front cakes.

Baking Cookies

For best results when baking cookies on 2 racks, use the Convection Bake function, a flat rack in rack position 3, and a roll-out rack in rack position 5.

ALUMINUM FOIL

⚠️ IMPORTANT: To avoid permanent damage to the oven bottom finish, do not line the oven bottom with any type of foil or liner.

For best cooking results, do not cover the entire oven rack with foil because air must be able to move freely.

Care must be taken to prevent aluminum foil and meat probes from contacting heating elements.

OVEN VENT

The oven vent releases hot air and moisture from the oven and should not be blocked or covered. Blocking or covering the oven vent will cause poor air circulation, affecting cooking and cleaning results. Do not place plastics, paper, or other items that could melt or burn near the oven vent.

A. Oven vent [?]

OVEN LIGHT

The oven light is a 40 W halogen bulb. Before replacing, ensure the oven and cooktop are cool and the control knobs are in the Off position.

To Replace:

1. Disconnect power.
2. Turn the glass bulb cover in the back of the oven counterclockwise to remove.
3. Remove bulb from socket.
4. Replace bulb, using tissue or wearing cotton gloves to handle the bulb. To avoid damage to or decreasing the life of the new bulb, do not touch the bulb with bare fingers.
5. Replace bulb cover by turning clockwise.
6. Reconnect power.

⚠️ IMPORTANT: Do not use lamps rated higher than 40 W.

SABBATH MODE

The Sabbath Mode sets the oven to remain on in a bake setting until disabled. For guidance on usage and a complete list of models with Sabbath Mode, visit www.star-k.org.

Online Ordering Information

For detailed installation instructions, maintenance information, winter storage, and transportation tips, please see the Owner's Manual included with your machine.

For information on the full cycle guide, detailed product dimensions, or for complete instructions for use and installation, please visit https://www.kitchenaid.com/service-and-support (US) or https://www.kitchenaid.ca/service-and-support (Canada). This may save the cost of a service call.

For additional assistance, use the contact information listed below for the appropriate region.

United States

KitchenAid Brand Home Appliances
Customer Experience Center
553 Benson Road
Benton Harbor, MI 49022-2692
Phone: 1-800-253-1301

Canada

KitchenAid Brand Home Appliances
Customer Experience Centre
200-6750 Century Ave.
Mississauga, Ontario L5N 0B7
Phone: 1-800-807-6777

⚠️ IMPORTANT: Retain this guide for future use.
