AT Command Manual. [2]. ITU-T Draft new. recommendationV.25ter. Serial asynchronous automatic dialing and control. [3]. GSM 07.10.
Confidential File SIM8200EA-M2 _ Hardware Design_V1.01 SIMCom Smart Machine Smart Decision Document Title SIM8200EA-M2 _ Hardware Design_V1.01 Version V1.01 Date 2019-10-25 Status Released Document Control ID SIM8200EA-M2 _ Hardware Design_V1.01 tial General Notes SIMCom offers this information as a service to its customers to support the application and n engineering efforts that use the products designed by SIMCom. The information provided is based on the requirements specifically from the customers. SIMCom has not undertaken any independent e search for additional relevant information, including any information that may be in the customer's fid possession. Furthermore, the system validation of the product designed by SIMCom within a larger electronic system remains the responsibility of the customer or the customer's system integrator. All specifications supplied herein are subject to change without notice. n Copyright This document contains the proprietary technical information which is the property of SIMCom o Limited, copying of this document, giving it to others, the using or communication of the contents C thereof are forbidden without the official authority by SIMCom. Offenders are liable to the payment of the damages. All rights are reserved in the event of grant of a patent or the registration of a utility model or design. All specifications supplied herein are subject to change without notice SIMCom Copyright © SIMCom Wireless Solutions Co., Ltd. 2019 File SIM8200EA-M2 card Hardware Design _V1.01 2 2019-06-27 Contents Smart Machine Smart Decision Contents .............................................................................................................................................3 Table Index ........................................................................................................................................5 Revision History................................................................................................................................7 1 Introduction................................................................................................................................8 1.1 Product Outline .....................................................................................................................8 1.3 Hardware Block Diagram..........................................................................................................9 1.4 Functional Overview ...............................................................................................................10 l 2 Package Information................................................................................................................12 2.1 Pin Assignment Overview ...................................................................................................12 tia 2.2 Pin Description....................................................................................................................14 2.3 Mechanical Information ......................................................................................................19 3 Interface Application ...............................................................................................................20 n 3.1 Power Supply ......................................................................................................................20 3.1.1 Power Supply Design Guide ........................................................................................20 e 3.1.2 Recommended Power Supply Circuit ..........................................................................21 3.2 Voltage Monitor.......................................................................................................................22 fid 3.3 Turn on and off module.......................................................................................................22 3.3.1 FUL_CARD_POWER_OFF# ......................................................................................22 3.3.2 Power off ......................................................................................................................23 n 3.4 Reset Function .........................................................................................................................24 3.5 WoWWAN#.............................................................................................................................25 o 3.6 USB3.1 Interface .....................................................................................................................26 C 3.7 USB2.0 Interface .....................................................................................................................26 3.8 PCIe Interface ..........................................................................................................................26 3.9 UIM Interface ..........................................................................................................................26 3.10 I2S Interface.....................................................................................................................28 3.10.1 I2S timing .................................................................................................................29 m 3.10.2 I2S reference circuit..................................................................................................29 3.11 DPR* ...............................................................................................................................30 o 3.12 I2C Interface ....................................................................................................................30 3.13 CONFIG Pins...................................................................................................................31 C3.14 LED1# .............................................................................................................................32 3.15 W_DISABLE1#...............................................................................................................33 3.16 W_DISABLE2#...............................................................................................................33 IM4 Antenna Interfaces...................................................................................................................35 4.1. Main/Diversity Antenna Interfaces.........................................................................................35 S 4.1.1. Operating Frequency........................................................................................................36 4.2. GNSS Antenna Interface ........................................................................................................37 4.3. Antenna Installation................................................................................................................37 4.3.1 Antenna Requirements ......................................................................................................37 SIM8200EA-M2 card Hardware Design _V1.01 3 2019-06-27 File Smart Machine Smart Decision 4.3.2. Recommended RF Connector for Antenna Installation ...................................................38 5 Electrical Specifications...........................................................................................................40 5.1 Absolute maximum ratings .................................................................................................40 5.2 Operating conditions ...........................................................................................................40 5.3 Operating Mode ..................................................................................................................41 5.3.1 Operating Mode Definition ..........................................................................................41 5.3.2 Sleep mode ...................................................................................................................42 5.3.3 Minimum functionality mode and Flight mode............................................................42 5.4 Current Consumption ..........................................................................................................43 5.5. RF Output Power....................................................................................................................46 5.6 Conducted Receive Sensitivity ................................................................................................46 l 5.5 ESD .....................................................................................................................................48 tia 6 Top and Bottom View of Module ............................................................................................49 7 Label description Information ................................................................................................50 7.1 Ordering Information ..........................................................................................................50 n 8 Packaging..................................................................................................................................51 e Appendix ..........................................................................................................................................53 A. Coding Schemes and Maximum Net Data Rates over Air Interface ........................................53 fid B. Related Documents ...................................................................................................................55 C. Terms and Abbreviations..........................................................................................................57 Con D. Safety Caution ..........................................................................................................................59 SIMCom File SIM8200EA-M2 card Hardware Design _V1.01 4 2019-06-27 Smart Machine Smart Decision Table Index Table 1: SIM8200EA-M2 frequency bands ......................................................................................................... 8 Table 2: General features ................................................................................................................................... 10 Table 3: IO parameters definition....................................................................................................................... 14 Table 4: IO parameters definition....................................................................................................................... 14 Table 5: Pin description...................................................................................................................................... 15 Table 6: VBAT pins electronic characteristic ..................................................................................................... 20 Table 7: Recommended TVS diode list.............................................................................................................. 21 Table 8: Power on timing and electronic characteristic...................................................................................... 23 Table 9: Power off timing and electronic characteristic ..................................................................................... 24 l Table 10: RESET pin electronic characteristic................................................................................................... 25 Table 11: UIM electronic characteristic in 1.8V mode (UIM-PWR=1.8V)........................................................ 26 tia Table 12: UIM electronic characteristic 2.85V mode (UIM-PWR=2.85V)........................................................27 Table 13: I2S format .......................................................................................................................................... 28 Table 14: I2S timing parameters ........................................................................................................................ 29 n Table 15: DPR interface ..................................................................................................................................... 30 Table 16: CONFIG Pins ..................................................................................................................................... 31 e Table 17: Config interface.................................................................................................................................. 31 Table 18: LED1# pin status................................................................................................................................ 32 fid Table 19: FLIGHTMODE pin status.................................................................................................................. 33 Table 20: Antenna Port Definitions .................................................................................................................... 35 Table 21: SIM8200EA-M2 Operating frequencies ............................................................................................ 36 n Table 22: GNSS frequencies .............................................................................................................................. 37 Table 23: Recommended Antenna Characteristics ............................................................................................. 37 o Table 24: the major specifications of the RF connector ..................................................................................... 38 Table 25: Absolute maximum ratings................................................................................................................. 40 C Table 26: Recommended operating ratings ........................................................................................................ 40 Table 27: 1.8V Digital I/O characteristics* ........................................................................................................ 40 Table 28: Operating temperature........................................................................................................................ 41 Table 29: Operating mode Definition................................................................................................................. 41 m Table 30: Current consumption on VBAT Pins (VBAT=3.8V) .......................................................................... 43 Table 31: Conducted Output Power ................................................................................................................... 46 o Table 32:SIM8200EA-M2 Conducted RF Receiving Sensitivity....................................................................... 46 Table 33: The ESD performance measurement table (Temperature: 25, Humidity: 45%) ............................. 48 CTable 37: Label description of Module Information .......................................................................................... 50 Table 38: SIM8200EA-M2 Information............................................................................................................. 50 Table 39: Tray size ............................................................................................................................................. 52 IMTable 40: Small Carton size ............................................................................................................................... 52 Table 41: Big Carton size................................................................................................................................... 52 S Table 42: Coding Schemes and Maximum Net Data Rates over Air Interface................................................... 53 Table 43: Related Documents ............................................................................................................................ 55 Table 44: Terms and Abbreviations.................................................................................................................... 57 Table 45: Safety Caution.................................................................................................................................... 59 File SIM8200EA-M2 card Hardware Design _V1.01 5 2019-06-27 Smart Machine Smart Decision Figure Index Figure 1: Standard Module block diagram........................................................................................................... 9 Figure 2: Pin map............................................................................................................................................... 13 Figure 3: pin out diagram................................................................................................................................... 19 Figure 4: Power supply application circuit......................................................................................................... 20 Figure 5: Linear regulator reference circuit ....................................................................................................... 21 Figure 6: Switching mode power supply reference circuit ................................................................................. 21 Figure 7: Reference power on/off circuit ........................................................................................................... 22 Figure 8: Power on timing sequence .................................................................................................................. 23 Figure 9: Power off timing sequence ................................................................................................................. 24 l Figure 10: Reference reset circuit ...................................................................................................................... 24 Figure 11: WOWWAN# behaviourSMS and URC report .......................................................................... 25 tia Figure 12: WOWWAN# behaviourSMS and URC report.......................................................................... 25 Figure 13: USIM interface reference circuit ...................................................................................................... 27 Figure 14: UIM interface reference circuit with UIM_DET .............................................................................. 28 n Figure 15: I2S timing ......................................................................................................................................... 29 Figure 16: Audio codec reference circuit ........................................................................................................... 30 e Figure 17: I2C reference circuit ......................................................................................................................... 31 Figure 18: LED1# reference circuit ................................................................................................................... 32 fid Figure 19: Flight mode switch reference circuit................................................................................................. 33 Figure 20: GNSS function switch reference circuit............................................................................................ 34 Figure 21: Main/Diversity/GNSS antenna interfaces ......................................................................................... 35 n Figure 22: Antenna connector ............................................................................................................................ 38 Figure 23: Top and bottom view of Module....................................................................................................... 49 o Figure 24: Label description of Module............................................................................................................. 50 Figure 25: packaging diagram............................................................................................................................ 51 C Figure 26: Tray drawing..................................................................................................................................... 51 Figure 27: Small carton drawing........................................................................................................................ 52 SIMCom Figure 28: Big carton drawing ........................................................................................................................... 52 File SIM8200EA-M2 card Hardware Design _V1.01 6 2019-06-27 Smart Machine Smart Decision Revision History Data 2019-06-27 2019-09-25 Version 1.00 1.01 Description of change Author Olivier.wu original version Xutao.jiang Confidential Modifytheerror Cunbao.feng Olivier.wu File SIMCom SIM8200EA-M2 card Hardware Design _V1.01 7 2019-06-27 Smart Machine Smart Decision 1 Introduction This document describes the electronic specifications, RF specifications, interfaces, mechanical characteristics and testing results of the SIMCom M.2 card. With the help of this document and other software application notes/user guides, users can understand and use SIM8200EA-M2 to design and develop laptop applications quickly. 1.1 Product Outline l Aimed at the EMEA/APAC/Brazil market, SIM8200EA-M2 supports Multi-Band 5G NR tia LTE-FDD/LTE-TDD/WCDMA, support R15 5G NSA/SA up to 4.0 Gbps data transfer. The supported radio frequency bands are described in the following table. Table 1: SIM8200EA-M2 frequency bands n Standard e 5G NR fid LTE(FDD) LTE(TDD) n WCDMA GNSS SIM8200EA-M2 n1,n2,n3,n5,n7,n8,n12,n20,n25,n28,n40,n41,n66.n71.n77,n78,n79 B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/B30/ B32/B66/B71 B34/B38/B39/B40/B41/B42/B43/B48 B1/B2/B3/B4/B5/B8 GPS/GLONASS/ BeiDou/Galileo/QZSS o With a physical dimension of 30.0*52.0*2.3 mm, SIM8200EA-M2 can meet PCI Express key B C M.2 Specification, and can meet almost any space requirement in users' applications. With M.2 Type 3052, SIM8200EA-M2 had almost all common interface integrated, such as USB2.0,USB3.1, PCIe Gen3.0, UIM(×2) card, Digital audio(I2S or PCM), I2C, GPIOs, Antenna × 6 etc. With all the interfaces, SIM8200EA-M2 can also be utilized in the industrial handheld, SIMCom machine-to-machine laptop application and especially the CPE/AR/VR/MR. File SIM8200EA-M2 card Hardware Design _V1.01 8 2019-06-27 Smart Machine Smart Decision 1.2 Hardware Block Diagram The Block Diagram of SIM8200EA-M2 is shown as below: M.2 KEY-B 75PIN INTERFACE USIM x2 USB2.0 USB3.1 PCIE GEN 3.0 I2C ANTCTL0~3 DPR COEX WOWWAN LED_1 GPIOs PCM/I2S W_Disable1_N W_Disable2_N CONFIG0 CONFIG1 CONFIG2 CONFIG3 GND One On Chip eSIM UIM Interface (2.85V/1.8V) l High Speed Interface tia Low Speed Peripherals (All can be configured as GPIOs) en GPIOs BB Modem 5GNR/4G/3G Modem MODEM+Audio DSP Processor Qualcomm Location Gen 9V4 Baseband 4G+5G(sub-6 GHz)RF GRFC'S RFFE'S RF PMU Supplies Pa sense QLINK_0 QLINK_EN_0 QLINK_REQ_0 WMSS_RESET_ 0 Transceiver RFFE'S Tx/Rx GRFC'S Cotex-A7 Application processor subsystem RF Front End MMPA/ LPAF/ LPAMIDs QDM Module QLNA Tuner RF Switch Diplexer/ N-Plexer RFCLK1 fid Control Signal RPMh Cotex-M3 System RAM+ROM Power System& Clock System BBCLK 19.2MHz 8-bit NAND 16-bit LPDDR4X POWER Sleep CLK 32kHz SPMI on MCP NAND 4Gb CLPDDR4X 4Gb PMU 38.4MHz 32kHz PMU 38.4MHz XO FileANT0 ANT1 ANT2 ANT3 ANT4 ANT5 RESET FULL_CARD_POWER_OFF_N VBAT__3.3v SIMComFigure 1: Standard Module block diagram SIM8200EA-M2 SIM8200EA-M2 card Hardware Design _V1.01 9 2019-06-27 1.3 Functional Overview Smart Machine Smart Decision Table 2: General features Feature Implementation Power supply VBAT:3.34.4(TDB) Typical Power Rail: 3.3V Power consumption Radio frequency bands Transmitting power Data Transmission Throughput Antenna GNSS SMS USIM interface USIM application toolkit Current in sleep mode : TBD Please refer to the table 1 5GNR power class: TBD l LTE power class: 3 (0.25W) WCDMA power class: 3 (0.25W) tia 5GNR: 1.5 Gbps (UL), 4 Gbps (DL) FDD-LTE CAT20+:Max 2.4Gbps (DL), 300Mbps (UL) TDD-LTE CAT20+:Max2.4Gbps (DL), 300Mbps (UL) n HSPA+: 5.76 Mbps(UL), 42 Mbps(DL) 5G main antenna. e WCDMA/LTE diversity antenna GNSS antenna fid GNSS engine (GPS/GLONASS/ BeiDou/Galileo/QZSS) Protocol: NMEA MT, MO, CB, Text and PDU mode n SMS storage: USIM card or ME(default) Transmission of SMS alternatively over CS or PS. o Support identity card: 1.8V/ 2.85V CSupport SAT class 3, GSM 11.14 Release 98 Phonebook management SIMCom Digital Audio feature Support USAT Support phonebook types: DC,MC,RC,SM,ME,FD,ON,LD,EN One I2S interface with dedicated main-clock for primary digital audio, the I2S also can be configured as PCM Half Rate (ETS 06.20) Full Rate (ETS 06.10) MCLK frequency: 12.288MHz (default) Enhanced Full Rate (ETS 06.50 / 06.60 / 06.80) WCDMA AMR-NB VoLTE AMR-WB Echo Cancellation Noise Suppression One port PCIE interface, support PCIe Gen 3 (PCIe Gen 1/2 PCIE interface compatible) High communication data rate which is up to 8 Gbps per lane. File SIM8200EA-M2 card Hardware Design _V1.01 10 2019-06-27 Smart Machine Smart Decision One USB 3.1 SuperSpeed and high-speed (for backward compatibility) USB USB3.1: super speed, with data rate which is up to 10 Gbps. USB2.0: high speed interface, support USB operations at low-speed and full-speed, which refer to USB1.0 and USB1.1. Firmware upgrade Firmware upgrade over USB interface or FOTA Physical characteristics Size: 30*52*2.3mm Weight: TBD Normal operation temperature: -30°C to +75°C Temperature range Extended operation temperature: -40°C to +85°C* l Storage temperature -45°C to +90°C *Note: Module is able to make and receive voice calls, data calls, SMS and make tia GPRS/UMTS/HSPA+/LTE traffic in -40 ~ +85. The performance will be reduced slightly from the 3GPP specifications if the temperature is outside the normal operating temperature Confiden range and still within the extended operating temperature range. SIMCom File SIM8200EA-M2 card Hardware Design _V1.01 11 2019-06-27 Smart Machine Smart Decision 2 Package Information 2.1 Pin Assignment Overview All functions of the M.2 card will be provided through 75 (including 8 notch pins) pads that will be connected to the customers' platform. The following figure is the high-level view of the pin assignment of the card. Confidential File SIMCom SIM8200EA-M2 card Hardware Design _V1.01 12 2019-06-27 Smart Machine Smart Decision Confidential File SIMCom Figure 2: Pin map SIM8200EA-M2 card Hardware Design _V1.01 13 2019-06-27 Smart Machine Smart Decision 2.2 Pin Description Table 3: IO parameters definition Pin type Description PI Power input PO Power output AI Analog input AIO Analog input/output l DIO Bidirectional digital input /output DI Digital input tia DO Digital output DOH Digital output with high level DOL Digital output with low level n PU Pull up PD Pull down e OD Open Drain OC Open collector fid Table 4: IO parameters definition n Voltage domain Parameter Min Typ o VDD_P3=1.8V VOH High level output 1.35V - C VOL Low level output 0V - Max 1.8V 0.45V P3 VIH High level input VIL Low level input m Rp Pull up/down resistor VDD_P4=1.8V oVOH High level output VOL Low level output CVIH High level input VIL Low level input IMP4 Rp Pull up/down resistor VDD_P4=2.85V S VOH High level output 1.2V -0.3V 80K ohm 1.44V 0V 1.26V -0.3V 360K ohm 2.28V 1.8V - 1.8V - - VOL Low level output 0V - 2.1V 0.6V 240K ohm 1.8V 0.4V 2.1V 0.36V 2.85V 0.4V VIH High level input 2.0V - 3.15V VIL Low level input -0.3V - 0.57V File SIM8200EA-M2 card Hardware Design _V1.01 14 2019-06-27 Smart Machine Smart Decision Rp Pull up/down 285K ohm Table 5: Pin description Pin name Pin No. Electrical Description Description Comment Power supply VBAT GND System Control FUL_CARD_POWER _OFF# RESET# W_DISABLE1# W_DISABLE2# WOWWAN# WAKE_ON_WWAN 2,4,70,72,74 3,5,11,27,33 ,39,45,51,57 ,71,73 6 67 8 26 23 PI M,2 card power supply, voltage User should connect range: 3.34.3V. these pins together. l Ground tia DI,PD n P3 DI,PU fide P3 DI n P3 DI Co P3 OC High level effective System reset control input, active low. WWAN RF Disable, active low GNSS Disable,active low (WAKE_ON_WWAN) WWAN is used to wake up host, active low It's 3.3V voltage domain but can be driven by either 1.8V or 3.3V GPIO. RESET_N internally pulled to1.8V by 100k resistance It's 3.3V voltage domain but can be driven by either 1.8V or 3.3V GPIO. It's 3.3V voltage domain but can be driven by either 1.8V or 3.3V GPIO. If unused, please keep open. WL_TX_EN 65 P3 Configuration pins m CONFIG_0 21 o CONFIG_1 69 CCONFIG_2 75 CONFIG_3 1 IMUSB2.0/USB3.1 S USB D+ 7 DI GND GND GND NC AIO USB D- 9 AIO Adjustable WIFI coexists with N79/LAA If unused, please keep open. Internally connected to the ground Internally connected to the ground Internally connected to the ground Not connected SIM8200EA-M2 module is configured as WWAN USB3.1 interface type Positive line of the differential, bi-directional USB signal. Negative line of the differential, bi-directional USB signal. Main communication interface. USB3.1 up to 10Gbps data rate. USB3.1-Tx- 29 AO USB3.1 transmit data minus USB2.0 up to File SIM8200EA-M2 card Hardware Design _V1.01 15 2019-06-27 USB3.1-Tx+ 31 Smart Machine Smart Decision AO USB3.1 transmit data plus 480Mbps data rate. USB3.1-Rx- 35 AI USB3.1 receive data minus USB3.1-Rx+ 37 AI USB3.1 receive data plus PCIe interface PETn0 41 AO PCIe TX Differential signals Negative PETp0 43 PERn0 47 PERp0 49 REFCLKN 53 REFCLKP 55 PCIE assistant interface PERSTR# 50 CLKREQ# 52 PEWAKE# 54 USIM interface UIM1-PWR 36 AO PCIe TX Differential signals Positive AI PCIe RX Differential signals Negative Support PCIe GEN 3.0, up to 8Gbps data rate. l AI PCIe RX Differential signals Positive If unused, please keep open. tia AIO PCIe Reference Clock signal Negative AIO PCIe Reference Clock signal Positive n DI PCIe reset signalactive low e DIO PCIe clock request signalactive 3.3V voltage domain low If unused, please keep fid open. DO PCIe walk up signalactive low Con P4 PO Power output for USIM1 card, the voltage depends on the USIM1 card type. Its output current is up to 50mA. USIM1 Card data I/O, which has UIM1-DATA 34 P4 m UIM1-CLK 32 P4 o UIM1-RESET 30 P4 CSIM1_DET 66 P3 SIMUIM2_PWR 48 P4 DIO DO DO DI PO been pulled up via a 10KR resistor to USIM_VDD internally. Do not pull it up or down externally. USIM1 clock output USIM1 Reset output 1.8/3.0V voltage domain, All lines of USIM interface should be protected against ESD. USIM1 card detecting input signal which has been pulled up via a 10KR resistor to VDD_P3 internally. Power output for USIM2 card, the voltage depends on the USIM1 card type. Its output current is up to 50mA. USIM2 Card data I/O, which has 1.8/3.0V voltage domain, All lines of USIM interface should been pulled up via a 10KR be protected against UIM2_DATA 42 P4 DIO resistor to USIM_VDD ESD. internally. Do not pull it up or down externally. File SIM8200EA-M2 card Hardware Design _V1.01 16 2019-06-27 UIM2_CLK 44 P4 DO Smart Machine Smart Decision USIM2 clock output UIM2_RESET 46 P4 DO USIM2 Reset output USIM2 card detecting input SIM2_DET 40 P3 DI signal which has been pulled up via a 10KR resistor to VDD_P3 internally. ANTCTL interface ANTCTL0 59 ANTCTL1 61 ANTCTL2 63 RFFE_SDATA 58 RFFE_SCLK 56 I2S interface I2S_CLK 20 I2S_RX 22 I2S_TX 24 I2S_WA 28 I2S_MCLK 60 I2C I2C_SDA 68 I2C_SCL 38 Coex interface COEX1 P3 DO P3 DO l P3 DO tia P3 DIO P3 D0 Tunable ANT CTRL0 Tunable ANT CTRL1 Tunable ANT CTRL2 Tunable ANT MIPI DATA Tunable ANT MIPI CLK These signals are used for Antenna Control and should be routed to the appropriate If unused, please keep them open. n P3 DO P3 DI e P3 DO fid P3 DO P3 DO I2S clock output I2S data input I2S data output I2S word select (L/R) I2S master clock 1.8Vvoltage domain Can be multiplexed into PCM signalsIf unused, please keep them open. n P3 DIO P3 D0 I2C data signal I2Cclock signal 1.8Vvoltage domain If unused, please keep them open. CoWireless coexistence of WWAN 64 P3 DI and WiFi/BT, based on BT-sig (COEX_RX*) COEX2 62 P3 (COEX_TX*) m Other pins o LED1# 10 P3 CDPR SIMNotch 25 P3 DO OC DI coex is tence protocol Wireless coexistence of WWAN and WiFi/BT, based on BT-sig coex is tence protocol If unused, please keep them open. OCactive lowStatus indicator driver LED The Pin is used to control SAR sensor on or offactive low, (default H) H: SAR SENSOR does not work, PA maximum power is not reduced L: SAR SENSOR work, If unused, please keep them open. 1.8Vvoltage domain 12, 13, 14, Notch 15, 16, 17, Notch 18, 19 File SIM8200EA-M2 card Hardware Design _V1.01 17 2019-06-27 Smart Machine Smart Decision Confidential File SIMCom SIM8200EA-M2 card Hardware Design _V1.01 18 2019-06-27 2.3 Mechanical Information Smart Machine Smart Decision Confidential File The following figure shows the package outline drawing of the M.2 card. SIMCom Figure 3: pin out diagram SIM8200EA-M2 card Hardware Design _V1.01 19 2019-06-27 Smart Machine Smart Decision 3 Interface Application 3.1 Power Supply The recommended power supply of SIM8200EA-M2 is 3.8V and the voltage ranges from 3.3V to 4.3 V. The SIM8200EA-M2 has 5 power pins and 11 Ground pins, to ensure the SIM8200EA -M2 card works normally, all the pins must be connected. The M.2 connector pin is defined to support 500mA current per pin continuously. l Table 6: VBAT pins electronic characteristic tia Symbol VBAT n IVBAT(peak) IVBAT(power-off) Description Module power voltage Module power peak current in normal mode. Module power current in power off mode. Min. Typ. 3.135 3.8 - TDB - TDB Max. Unit 4.3 V - A - uA e 3.1.1 Power Supply Design Guide fid Make sure that the voltage on the 3.8V pins will never drop below 3.135V, even during a transmit burst, when current consumption may rise up to 1.0A. If the voltage drops below 3.135V, the n module will be powered off automatically. Note: Be sure the power supply for VBAT pins can support more than1.0A, using a total of more o than 100uF capacitors is recommended, in order to avoid the voltage drop to lower than 3.135V. C Some multi-layer ceramic chip (MLCC) capacitors (0.1/1uF) with low ESR in high frequency band can be used for EMC. These capacitors should be put as close as possible to VBAT pads. Also, users should keep VBAT trace on circuit board wider than 2 mm to minimize PCB trace impedance. The following figure shows the recommended circuit. m3.3V 2 o 3.3V 4 3.3V 70 C 3.3V 72 3.3V 74 GND IM GND Cd Cc Cb Cb 33pF 100nF 100uF 100uF VBAT Ca D1 220uF 5.1V S SIM8200EA-M.2 File Figure 4: Power supply application circuit Note: The test condition: The voltage of power supply for VBAT is 3.3V, Ca is 220 µF tantalum SIM8200EA-M2 card Hardware Design _V1.01 20 2019-06-27 Smart Machine Smart Decision capacitor (ESR=0.7). In addition, in order to guard for over voltage protection, it is suggested to use a D1 diode to protect the M.2 card. Table 7: Recommended TVS diode list No. Manufacturer Part Number VRWM Package 1 JCET ESDBW5V0A1 5V DFN1006-2L 2 Prisemi 3 WAYON 4 WILL l 5 WILL tia 6 WAYON PESDHC2FD4V5BH 4.5V WS05DPF-B 5V ESD5611N 5V ESD56151W05 5V WS4.5DPV 4.5V DFN1006-2L DFN1006-2L DFN1006-2L SOD-323 DFN1610-2L 3.1.2 Recommended Power Supply Circuit n It is recommended that a switching mode power supply or a linear regulator power supply is used. e It is important to make sure that all the components used in the power supply circuit can resist the current which could be more than 4 ATBD. fid The following figure shows the linear regulator reference circuit with 5V input and 3.3V output. DC INPUT Con FUSE + C101 100uF C102 1uF U101 MIC29302 2 Vin Vout 4 GND 1 On/Off FB 5 PWR_CTRL 3 VBAT R101 49.9K(1%) R102 30K(1%) + R103 C103 C104 470R 330uF 100nF Figure 5: Linear regulator reference circuit m If there is a high dropout between input and VBAT, or the efficiency is extremely important, then a switching mode power supply will be preferable. The following figure shows the switching mode o power supply reference circuit with 12V input and 3.3V output. DC INPUT SIMCFUSE U101 LM2596- ADJ 1 Vin Vout 2 + C101 C102 5 On/Off 100uF 1uF PWR_CTRL 3 GND FB 4 L101 100uH R101 D102 49.9K(1%) MBR360 R102 30K(1%) + C103 330uF C104 100nF VBAT Figure 6: Switching mode power supply reference circuit File Note: The Switching Mode power supply solution for VBAT must be chosen carefully against SIM8200EA-M2 card Hardware Design _V1.01 21 2019-06-27 Smart Machine Smart Decision Electro Magnetic Interference and ripple current from depraving RF performance. 3.2 Voltage Monitor To monitor the VBAT voltage, the AT command "AT+CBC" can be used. Note: For more details about voltage monitor commands, please refer to Document [1] in the appendix. 3.3 Turn on and off module l 3.3.1 FUL_CARD_POWER_OFF# tia Module can be powered on by pulling the FUL_CARD_POWER_OFF# pin, which is 3.3V tolerantup to high level through GPIO. n FUL_CARD_POWER_OFF# signal is an active low input signal and will turn the module on when asserted high (1.7 V) and will force the module to shut down when asserted low (0.2 V). This pin e is 3.3V tolerant and can be driven by either 1.8V or 3.3V GPIO and has been pulled down internal. fid MCU n GPIO Co (1.8V/3.3V) Turn ON SIM8200EA-M2 FUL_CARD_ POWER_OFF# mFigure 7: Reference power on/off circuit o Note: Module could be automatically power on by connecting FUL_CARD_POWER_OFF# pin Cto 3.3 V via 0R resistor directly. SIMThe power-on scenarios are illustrated in the following figure. File SIM8200EA-M2 card Hardware Design _V1.01 22 2019-06-27 Smart Machine Smart Decision 3V3 RESET# (Input) FUL_CARD_POWER_OFF# ile (Input) Twait USB Port Power off Ton(usb) Undefined l F Figure 8: Power on timing sequence Active tia Table 8: Power on timing and electronic characteristic n Symbol Twait e Ton(usb) fid VIH n VIL Parameter The time which is used to wait the 3.3v to be stable. The time from power-on issue to USB port ready Input high level voltage on FUL_CARD_POWER_OFF# pin Input low level voltage on FUL_CARD_POWER_OFF# pin Min. TBD 1.0 -0.3 Typ. TBD 1.7 0 Max. - Unit ms s 4.4 V 0.2 V Co 3.3.2 Power off The following methods can be used to power off the card. Method 1: Power off the card by holding the FUL_CARD_POWER_OFF# pin to a low level. Method 2: Power off Module by AT command "AT+CPOF". Method 3: over-voltage or under-voltage automatic power off. m Method 4: over-temperature or under-temperature automatic power off. o Note: If the temperature is outside the range of -30~+75, some warning will be reported via AT Cport. If the temperature is outside the range of -40~+85, Module will be powered off automatically. For details about "AT+CPOF", please refer to Document [1] in the appendix. SIMThese procedures will make the M.2 card disconnect from the network and allow the software to enter a safe state, and save data before the card be powered off completely. The power off scenario by pulling down the FUL_CARD_POWER_OFF# pin is illustrated in the following figure. SIM8200EA-M2 card Hardware Design _V1.01 23 2019-06-27 Smart Machine Smart Decision FUL_CARD_POWER_OFF# (Input) ile USB Port Ton-off Active Toff(USB) Active Power off Figure 9: Power off timing sequence tial F Table 9: Power off timing and electronic characteristic Symbol n Toff(usb) e Ton-off Parameter The time from power-off issue to USB port off The buffer time from power-off issue to power-on issue Time value Unit Min. Typ. Max. - TBD - s TBD - - s fid 3.4 Reset Function Module can be reset by pulling the RESET# pin down to ground. on Note: This function is only used as an emergency reset, when both AT command "AT+CPOF" C and the FUL_CARD_POWER_OFF# pin have lost efficacy. The RESET# pin has been pulled up with a resistor to 1.8V internally, so it does not need to be pulled up externally. It is strongly recommended to put an ESD protection diode close to the Hardware circuit RESET# pin. Please refer to the following figure for the recommended reference m circuit. o 1.8V CReset Impulse IM 4.7 K Treset RESET# 1K R Reset Logic 47K S MODULE Figure 10: Reference reset circuit SIM8200EA-M2 card Hardware Design _V1.01 24 2019-06-27 Smart Machine Smart Decision Table 10: RESET pin electronic characteristic Symbol ile Treset VIH VIL Description The active low level impulse time on RESET_N pin to reset Module Input high level voltage Input low level voltage Min. TBD 1.17 -0.3 Typ. Max. Unit TBD TBD ms 1.8 2.1 V 0 0.8 V l F 3.5 WoWWAN# tia The WoWWAN# pin is an open collector signal which can be used as an interrupt signal to the host. Normally it will keep high logic level until certain conditions such as receiving SMS, voice call (CSD, video) or URC reporting, then WoWWAN# will change to low logic level to inform the host (client PC), the pulse time is 1 second. en WoWWAN# HIGH fid 1s on LOW C Figure 11: WOWWAN# behaviourSMS and URC report WAKE_ON_WWAN Reference circuit is recommended in the following figure. m VCC From Host oSIM8200EA-M2 C WoWWAN# 4.7K BB Chip SIM 47K 10 ~100K Interrupt input HOST Figure 12: WOWWAN# behaviourSMS and URC report SIM8200EA-M2 card Hardware Design _V1.01 25 2019-06-27 3.6 USB3.1 Interface Smart Machine Smart Decision The module support one integrated USB interface which complies with the USB 3.1 specifications and supports super speed up to 10Gbps. The USB interface is used for AT command communication, data transmission, GNSS NMEA output, software debugging and voice over USB. NoteThe USB3.1-Tx+ and USB3.1-Tx- should be routed together and the nets must be traced by 90Ohm+/-10% differential impedance. The same treatment should be needed for the routing of USB3.1-RX+ and USB3.1-RX,Four times the width between TX and RX. l 3.7 USB2.0 Interface tia The Module implements a USB interface compliant with the USB2.0 specification. The module supports three USB speeds: low-speed (1.5Mbps), full-speed (12Mbps) and high-speed (480Mbps). But the OTG function and USB charging function are not supported. n NoteThe USB_DN and USB_DP nets must be traced by 90Ohm+/-10% differential impedance. e Module is used as a USB device by default. Module supports the USB suspend and resume mechanism which can reduce power consumption. If there is no data transmission on the USB bus, fid Module will enter suspend mode automatically, and will be resumed by some events such as voice call, receiving SMS, etc. n 3.8 PCIe Interface Co Under development File 3.9 UIM Interface There is an eSIM card on the board that is connected to the inside of the SIM2 signal line. Users m can use eSIM card on the board or an external SIM card. Module supports both 1.8V and 2.85V UIM Cards. o Table 11: UIM electronic characteristic in 1.8V mode (UIM-PWR=1.8V) CSymbol Parameter Min. IMUIM-PWR VIH S VIL LDO power output voltage High-level input voltage Low-level input voltage 1.75 0.65*UIM-PWR -0.3 Uni Typ. Max. t 1.8 1.95 V - UIM-PWR +0.3 V 0 0.35*UIM-PWR V VOH High-level output voltage UIM-PWR -0.45 - UIM-PWR V SIM8200EA-M2 card Hardware Design _V1.01 26 2019-06-27 VOL Low-level output voltage 0 Smart Machine Smart Decision 0 0.45 V Table 12: UIM electronic characteristic 2.85V mode (UIM-PWR=2.85V) Symbol Parameter Min. Typ. Max. Unit UIM-PW R LDO power output voltage 2.75 2.85 3.05 V VIH High-level input voltage 0.65*UIM-PWR - UIM-PWR +0.3 V VIL Low-level input voltage -0.3 0 0.25*UIM-PWR V l VOH High-level output voltage UIM-PWR -0.45 - UIM-PWR V tia VOL Low-level output voltage 0 0 0.45 V It is recommended to use an ESD protection component such as ESDA6V1-5W6 produced by ST n (www.st.com ) or SMF12C produced by ON SEMI (www.onsemi.com ). Note that the USIM peripheral circuit should be close to the USIM card socket. The following figure shows the 6-pin e SIM card holder reference circuit. nfid Module UIM-PWR UIM-RESET UIM-CLK UIM-DATA 22 0 22 USIM Socket VCC RST CLK GND VPP I/O C707 10M006 512 22pF 22pF 22pF Co (NC) (NC) (NC) 100nF TVS File Figure 13: USIM interface reference circuit m The SIM Detect pin is used for detection of the UIM card hot plug in. User can select the 8-pin o UIM card holder to implement UIM card detection function. SIMCThe following figure shows the 8-pin SIM card holder reference circuit. SIM8200EA-M2 card Hardware Design _V1.01 27 2019-06-27 Smart Machine Smart Decision MODULE UIM-PWR UIM-RESET UIM-CLK SIM Detect UIM-DATA MOLEX - 91228 VCC GND 22R RST VPP 0R CLK I/O 22R PRESENCE Deserved 22R UIM Card TVS1 22pF 22pF 22pF (NC) (NC) (NC) 100nF l Figure 14: UIM interface reference circuit with UIM_DET tia If the UIM card detection function is not used, user can keep the SIM Detect pin open. SIM card circuit is susceptible, the interference may cause the SIM card failures or some other situations, so it is strongly recommended to follow these guidelines while designing: Make sure that the SIM card holder should be far away from the antenna while in PCB n layout. e SIM traces should keep away from RF lines, VBAT and high-speed signal lines. The traces should be as short as possible. fid Keep SIM holder's GND connect to main ground directly. Shielding the SIM card signal by ground. Recommended to place a 0.11uF capacitor on UIM-PWR line and keep close to the holder. n The rise/fall time of UIM-CLK should not be more than 40ns. Add some TVS and the parasitic capacitance should not exceed 60pF. Co 3.10 I2S Interface Module provides an I2S interface for external codec, which comply with the requirements in the Phillips I2S Bus Specifications m Table 13: I2S format o Characteristics CLine Interface Format Data length I2S Clock/Sync Source IMI2S Clock Rate I2S MCLK rate S Data Ordering Specification Linear(Fixed) 16bits(Fixed) Master Mode(Fixed) 1.536 MHz (Default) 12.288MHz (Default) MSB Note: For more details about I2S AT commands, please refer to document [1]. in the appendix. File SIM8200EA-M2 card Hardware Design _V1.01 28 2019-06-27 3.10.1 I2S timing Smart Machine Smart Decision Module supports 48 KHz I2S sampling rate and 32 bit coding signal (16 bit word length), the timing diagram is showed as following: tial Figure 15: I2S timing Table 14: I2S timing parameters n Signal fide I2S_MCLK Con I2S_CLK Paramete r Frequency T t(HC) t(LC) Frequency T t(HC) t(LC) Description Frequency Clock period Clock high Clock low Frequency Clock period Clock high Clock low Min. 81.380 0.45T 0.45T 8 20.83 0.45T 0.45T Typ. Max. 12.288 81.380 48 20.83 12.288 0.55T 0.55T 48 125 0.55T 0.55T m I2S_WS t(sr) t(hr) t(dtr) t(htr) DIN/DOUT and WS input setup time DIN/DOUT and WS input hold time DIN/DOUT and WS output delay DIN/DOUT and WS output hold time o 3.10.2 I2S reference circuit SIMCThe following figure shows the external codec reference design. 16.276 0 0 65.10 File Unit MHz ns ns ns KHz us ns ns ns ns ns ns SIM8200EA-M2 card Hardware Design _V1.01 29 2019-06-27 Smart Machine Smart Decision VDD_1V8 3.3V 3.3V VDD_1V8 2.2K 2.2K VDDA I2C1_SCL I2C1_SDA SCLK SDIO VDDSPK VDDD I2S_DIN I2S_DOUT MODULE I2S_WS I2S_CLK ADCOUT DACIN FS BCLK MICBIAS MIC+ MIC- 2.2K 1uF 1uF I2S_MCLK MCLK 2.2K MIC MOUT 47uF 33pF 47uF NAU88U10 Receiver l Figure 16: Audio codec reference circuit tia 3.11 DPR* DPR (Dynamic Power Reduction) signal is used by SIM8200EA-M2 to assist in meeting n regulatory SAR (Specific Absorption Rate) requirements for RF exposure. The signal is provided by a host system proximity sensor to the wireless device to provide an input trigger causing a e reduction in the radio transmit output power. User can use AT command to active this function, if do not need this function, this pin can be fid keep floating. Table 15: DPR interface n Pin no Pin Name Co 25 DPR Pin status Low High Function Max transmitting power will be reduced Max transmitting power will not be reduced (default) Floating Max transmitting power will not be reduced Note:* means the DRP function is under developing. m 3.12 I2C Interface o Module provides an I2C interface compatible with I2C specification, version 5.0, with clock rate Cup to 400 kbps. Its operation voltage is 1.8V. SIMThe following figure shows the I2C bus reference design. File SIM8200EA-M2 card Hardware Design _V1.01 30 2019-06-27 VDD_1V8 Smart Machine Smart Decision N C NC I2C_SCL I2C_SDA GND Module SCL SDA GND I2C device Figure 17: I2C reference circuit l NoteSDA and SCL have pull-up resistors in Module. So, 2 external pull up resistors are NO necessary in application circuit. For more details about AT commands please refer to document tia [1]. in the appendix. n 3.13 CONFIG Pins e These signals provide the means to indicate the specific configuration of the module. SIM8200EA-M2 is configured as WWAN-USB3.0. Confid Table 16: CONFIG Pins Pin no Pin Name 21 CONFIG_0 m 69 CONFIG_1 75 CONFIG_2 o 1 CONFIG_3 Description Connected to GND internally. Connected to GND internally. Connected to GND internally. No Connect internally. CIn the M.2 specification, the 4 pins are defined as below: Table 17: Config interface IMConfig_0 Config_1 S (Pin 21) (Pin 69) Config_2 (Pin 75) Config_3 (Pin 1) Module type and Main host interface GND GND GND GND SSD SATA Port Configuration N/A GND NC GND GND SSD PCIe N/A GND GND NC GND WWAN PCIe 0 SIM8200EA-M2 card Hardware Design _V1.01 31 2019-06-27 File Smart Machine Smart Decision GND NC NC GND WWAN PCIe 1 GND GND GND NC WWAN USB 3.1 0 GND NC GND NC WWAN USB 3.1 1 GND GND NC NC WWAN USB 3.1 2 GND NC NC NC WWAN USB 3.1 3 NC GND GND GND WWAN SSIC 0 NC NC GND GND WWAN SSIC 1 NC GND NC GND WWAN SSIC 2 NC NC NC GND WWAN SSIC 3 l NC GND GND NC WWAN PCIe 2 tia NC NC GND NC WWAN PCIe 3 NC GND NC NC RFU N/A NC NC NC NC No Module Present N/A en 3.14 LED1# fid LED1# is open drain output and is used to allow SIM8200EA-M2 to provide network status via LED which will be provided by the host. on VCC C SIM8200EA-M2 omBB Chip R LED1# IMC Figure 18: LED1# reference circuit S Note: The value of the resistor named "R" depends on the LED characteristic. The timing sequence is as followed: File Table 18: LED1# pin status SIM8200EA-M2 card Hardware Design _V1.01 32 2019-06-27 NETLIGHT pin status Always On 200ms ON, 200ms OFF 800ms ON, 800ms OFF OFF Smart Machine Smart Decision Module status Searching Network; Call Connect(include VOLTE,SRLTE) Data Transmit; 4G registered; 3G registered network Power off ;Sleep 3.15 W_DISABLE1# The W_DISABLE1# pin controls SIM8200EA-M2 to enter or exit the flight mode, when the W_DISABLE1# signal is asserted to low level, all RF functions would be disabled. When the l W_DISABLE1# signal is not asserted, the RF function will be active if it was not disabled by tia other means such as software. Its reference circuit is shown in the following figure. VDD n 4.7K fide W_DISABLE1# Switch n Module 4.7K Co Figure 19: Flight mode switch reference circuit m Table 19: FLIGHTMODE pin status o FLIGHTMODE pin status Input Low Level CInput High Level Module operation Flight Mode: RF is closed AT+CFUN=4: RF is closed AT+CFUN=1: RF is working IM3.16 W_DISABLE2# S The W_DISABLE2# pin controls SIM8200EA-M2 to enable or disable the GNSS function, when the W_DISABLE2# signal is asserted to low level, the GNSS function would be disabled. Its reference circuit is shown in the following figure. File SIM8200EA-M2 card Hardware Design _V1.01 33 2019-06-27 Smart Machine Smart Decision VDD_1V8 W_DISABLE2# File Module 4.7K Switch 4.7K Confidential Figure 20: GNSS function switch reference circuit SIMCom SIM8200EA-M2 card Hardware Design _V1.01 34 2019-06-27 4 Antenna Interfaces Smart Machine Smart Decision SIM8200EA-M2 provides a main antenna interface, a diversity antenna interface and a GNSS antenna interface. The antenna ports have an RF impedance of 50. 4.1. Main/Diversity Antenna Interfaces The Main/Diversity/GNSS antenna interfaces are shown as below. fidential Figure 21: Main/Diversity/GNSS antenna interfaces Con Table 20: Antenna Port Definitions File ANT item ANT0 ANT name LTE_LB/MB/HB_TRX m ANT1 o ANT2 5GN41_TRX; 5G_N77/N79_TRX LTE_LB/MB/HB_DIV #1 C ANT3 IMANT4 S ANT5 LTE_MB/HB_DIV #2; 5G_N77/N79_DIV #1 LTE_MB/HB_DIV #3; 5G_N77/N79_DIV #2 5G_N77/N79_DIV #3; GNSS Frequency Range 617MHz~960MHz, 1710MHz~2690MHz 2496MHz~2690MHz; 3300MHz~5000MHz 617MHz~960MHz, 1710MHz~2690MHz 1710MHz~2690MHz; 3300MHz~5000MHz 1710MHz~2690MHz; 3300MHz~5000MHz 3300MHz~5000MHz; 1166MHz~1610MHz Functional description 3G/4G/5G re-farming band signal send and receive 5G N41 band signal send and receive; 5G NR band signal send and receive 3G/4G/5G re-farming band signal receive 3G/4G/5G re-farming band signal receive; 5G NR band signal receive 3G/4G/5G re-farming band signal receive; 5G NR band signal receive 5G NR band signal receive; GNSS signal receive SIM8200EA-M2 card Hardware Design _V1.01 35 2019-06-27 4.1.1. Operating Frequency Smart Machine Smart Decision Table 21: SIM8200EA-M2 Operating frequencies Frequency Band Uplink (UL) Downlink (DL) Duplex Mode WCDMA B1 1920 ~1980 MHz 2110 ~2170 MHz FDD WCDMA B2 1850~1910 MHz 1930~1990 MHz FDD WCDMA B3 WCDMA B4 WCDMA B5 WCDMA B8 LTE B1 LTE B2 LTE B3 LTE B4 LTE B5 LTE B7 LTE B8 LTE B12 LTE B13 LTE B14 LTE B17 LTE B18 LTE B19 1710 ~1785 MHz 1805 ~1880 MHz FDD 1710 ~1755 MHz 2110~ 2155 MHz FDD 824849 MHz 869894MHz FDD l 880 ~915 MHz 925 ~960 MHz FDD tia 1920 ~1980 MHz 2110 ~2170 MHz FDD 1850~1910MHz 1930~1990MHz FDD 1710 ~1785 MHz 1805 ~1880 MHz FDD n 1710~1755MHz 2110~2155MHz FDD 824849 MHz 869894MHz FDD e 2500~2570MHz 2620~2690MHz FDD fid 880 ~915 MHz 925 ~960 MHz FDD 699~716MHz 729~746MHz FDD 777~787MHz 746~756MHz FDD 788~798MHz 758~768MHz FDD n 704~716MHz 734~746MHz FDD o 815~830MHz 860~875MHz FDD C 830~845MHz 875~890MHz FDD LTE B20 832~862MHz 791~ 821MHz FDD LTE B25 LTE B26 m LTE B28 LTE B29 o LTE B30 LTE B32 CLTE B34 LTE B38 IMLTE B39 LTE B40 S LTE B41 1850~1915MHz 814~849MHz 703~748MHz 2305~2315MHz 2010~2025MHz 2570 ~2620 MHz 1880~1920MHz 2300 ~2400 MHz 2496 ~2690 MHz 1930~1995MHz 859~894MHz 758~803MHz 717~728MHz 2350~2360MHz 1452~1496MHz 2010~2025MHz 2570 ~2620 MHz 1880~1920MHz 2300 ~2400 MHz 2496 ~2690 MHz FDD FDD FDD FDD FDD FDD TDD TDD TDD TDD TDD LTE B42 3400~3600MHz 3400~3600MHz TDD LTE B48 3550~3700MHz 3550~3700MHz TDD LTE B66 1710~1780MHz 2110~2200MHz FDD File SIM8200EA-M2 card Hardware Design _V1.01 36 2019-06-27 Smart Machine Smart Decision LTE B71 663~698MHz 617~652MHz FDD 5G N77 3300~4200MHz 3300~4200MHz TDD 5G N78 3300~3800MHz 3300~3800MHz TDD 5G N79 4400~5000MHz 4400~5000MHz TDD Note: LTE-FDD B29 and B32 support Rx only and are only for secondary component carrier. 4.2. GNSS Antenna Interface The following table shows frequency specification of GNSS antenna interface. l Table 22: GNSS frequencies tia Type GPS/Galileo/QZSS GLONASS n BeiDou/Compass Frequecy 1575.42±1.023MHz 1597.5~1605.8MHz 1561.098±2.046MHz fide 4.3. Antenna Installation 4.3.1 Antenna Requirements n The following table shows the requirements on main antenna, Diversity antenna and GNSS o antenna. C Table 23: Recommended Antenna Characteristics WCDMA/LTE antenna Passive m Direction Gain o Input impedance Efficiency CVSWR Cable insertion Loss <1GHz IMCable insertion Loss 1GHz~2.2GHz S Cable insertion Loss 2.3GHz~2.7GHz Recommended standard Omni directional > -3dBi (Avg) 50 > 30 % < 2 <1dB <1.5dB <2dB GNSS antenna Passive Recommended standard Frequency Range 1559~1609MHZ SIM8200EA-M2 card Hardware Design _V1.01 37 2019-06-27 File Direction VSWR Passive antenna gain Active antenna NF Active antenna gain Active antenna Enbeded LNA gain Smart Machine Smart Decision RHCP or liner, RHCP is the first choice < 2 > 0 dBi < 1.5 > 0 dBi < 17 dB Note: It is recommended to use a passive GNSS antenna when LTE B13 or B14 is supported, as the use of active antenna may generate harmonics which will affect the GNSS performance. l 4.3.2. Recommended RF Connector for Antenna Installation tia When choosing antennas, user should pay attentions to the connector on antenna which should match with the connector on the module. The standard 2x2 mm size RF receptacle connectors has been used on SIM7300x. The dimension of the connector on SIM8200EA is 2.0*2.0*0.6mm, which is from Murata, and the Part Number is n MM4829-2702B/ RA4/ RB0. Confide Shows the RF connector dimension in the following figure: IMCom Figure 22: Antenna connector S Table 24: the major specifications of the RF connector File Item Nominal Frequency Range SIM8200EA-M2 card Hardware Design _V1.01 Specification DC to 6 GHz 38 2019-06-27 Smart Machine Smart Decision Nominal Impedance 50 Temperature Rating -40 to + 85 Initial Contact Resistance (without conductor resistance) Center contact 20.0mmax. Outer contact 20.0mmax. Voltage Standing Wave Ratio (V.S.W.R.) Meet the requirements of 1.3max.(DC3GHz) 1.45max.(3GHz6GHz) There are two kinds of coaxial cables mating the RF connector in the SIM8200EA, SIMCom recommend use l Murata and SUZHOU KELI, and the Part Number is MXFR32HP1000 of the Murata and KLC-2058 of the Confidentia KELI. SIMCom File SIM8200EA-M2 card Hardware Design _V1.01 39 2019-06-27 Smart Machine Smart Decision 5 Electrical Specifications 5.1 Absolute maximum ratings Absolute maximum rating for digital and analog pins of Module are listed in the following table: Table 25: Absolute maximum ratings l Parameter Min. tia Voltage at 3.3V pins -0.3 Voltage at digital pins (GPIO,I2C,UART, I2S) -0.3 Voltage at digital pins (UIM) -0.3 Voltage at FUL_CARD_POWER_OFF# -0.3 n Voltage at RESET# -0.3 e 5.2 Operating conditions fid Table 26: Recommended operating ratings Parameter Min. n Voltage at 3.3V TBD Co Table 27: 1.8V Digital I/O characteristics* Typ. - Typ. 3.8 Max. Unit TBD V 2.1 V 3.05 V TBD 2.1 Max. Unit TBD V Parameter Description Min. Typ. Max. Unit VIH High-level input voltage VIL Low-level input voltage m VOH High-level output voltage o VOL Low-level output voltage CIOH High-level output current(no pull down resistor) Low-level output current(no pull IMIOL up resistor) S IIH Input high leakage current (no pull down resistor) 1.17 -0.3 1.35 0 - - - 1.8 0 2 -2 - 2.1 V 0.63 V 1.8 V 0.45 V - mA - mA 1 uA IIL Input low leakage current(no pull up resistor) -1 - - uA File *Note: These parameters are for digital interface pins, such as UART, I2C, I2S, RESET#, SIM8200EA-M2 card Hardware Design _V1.01 40 2019-06-27 Smart Machine Smart Decision ANTCTL, COEX and GPIOs (coex, DPR, SIM DETECT, SD_DET). The operating temperature of Module is listed in the following table. Table 28: Operating temperature ile Parameter Min. Typ. Max. Unit Normal operation temperature -30 25 75 Extended operation temperature* -40 25 85 Storage temperature -45 25 +90 F *Note: Module is able to make and receive voice calls, data calls, SMS and make UMTX/LTE l traffic in -40 ~ +85. The performance will be reduced slightly from the 3GPP specifications if the temperature is outside the normal operating temperature range and still within the extreme tia operating temperature range. 5.3 Operating Mode en 5.3.1 Operating Mode Definition fid The table below summarizes the various operating modes of Module product. Table 29: Operating mode Definition n Mode Co UMTS/LTE Sleep Function AT command "AT+CSCLK=1" can be used to set the module to a sleep mode. In this case, the current consumption of module will be reduced to a very low level and the module can still receive paging message and SMS. Normal operation UMTS/LTE Idle m UMTS/LTE Talk oUMTS/LTE Standby CUMTS/LTE SIM Data transmission Software is active. Module is registered to the network, and the Module is ready to communicate. Connection between two subscribers is in progress. In this case, the power consumption depends on network settings such as DTX off/on, FR/EFR/HR, hopping sequences, and antenna. Module is ready for data transmission, but no data is currently sent or received. In this case, power consumption depends on network settings. There is data transmission in progress. In this case, power consumption is related to network settings (e.g. power control level); uplink/downlink data rates, etc. AT command "AT+CFUN=0" can be used to set the Module to a Minimum functionality minimum functionality mode without removing the power supply. In mode this mode, the RF part of the Module will not work and the USIM card will not be accessible, but the serial port and USB port are still SIM8200EA-M2 card Hardware Design _V1.01 41 2019-06-27 Smart Machine Smart Decision accessible. The power consumption in this mode is lower than normal mode. Flight mode l File Power off AT command "AT+CFUN=4" or pulling down the W_disable1# pin can be used to set the Module to flight mode without removing the power supply. In this mode, the RF part of the Module will not work, but the serial port and USB port are still accessible. The power consumption in this mode is lower than normal mode. Module will go into power off mode by sending the AT command "AT+CPOF" or pull down the FUL_CARD_POWER_OFF# pin, normally. In this mode the power management unit shuts down the power supply, and software is not active. The serial port and USB are is not accessible. tia 5.3.2 Sleep mode n In sleep mode, the current consumption of Module will be reduced to a very low level, and Module can still receive paging message and SMS. e Several hardware and software conditions must be satisfied in order to let Module enter into sleep mode: fid 1. UART condition 2. USB condition 3. Software condition n Note: Before designing, pay attention to how to realize sleeping/waking function. o 5.3.3 Minimum functionality mode and Flight mode C Minimum functionality mode ceases a majority function of Module, thus minimizing the power consumption. This mode is set by the AT command which provides a choice of the functionality levels. m AT+CFUN=0: Minimum functionality AT+CFUN=1: Full functionality (Default) o AT+CFUN=4: Flight mode CIf Module has been set to minimum functionality mode, the RF function and UIM card function will be closed. In this case, the serial port and USB are still accessible, but RF function and UIM card will be unavailable. IMIf Module has been set to flight mode, the RF function will be closed. In this case, the serial port and USB are still accessible, but RF function will be unavailable. S When Module is in minimum functionality or flight mode, it can return to full functionality by the AT command "AT+CFUN=1". SIM8200EA-M2 card Hardware Design _V1.01 42 2019-06-27 5.4 Current Consumption Smart Machine Smart Decision The current consumption is listed in the table below. Table 30: Current consumption on VBAT Pins (VBAT=3.8V) SIM8200EA-M2 TBD GNSS GNSS supply current (AT+CFUN=0,with USB connection) UMTS sleep/idle mode l WCDMA supply current tia (GNSS offwithout USB connection) LTE sleep/idle mode LTE FDD supply current (GNSS offwithout USB connection) n LTE TDD supply current e (GNSS offwithout USB connection) UMTS Talk fid WCDMA B1 WCDMA B2 WCDMA B3 n WCDMA B4 WCDMA B5 o WCDMA B8 C HSDPA data @ -140dBmTracking Typical:TBD Sleep mode @DRX=9 Typical: TBD Idle mode @DRX=9 Typical: TBD Sleep mode Typical: TBD Idle mode Typical: TBD Sleep mode Typical: TBD Idle mode Typical: TBD @Power TBD Typical: TBD @Power TBD Typical: TBD @Power TBD Typical: TBD @Power TBD Typical: TBD @Power TBD Typical: TBD @Power TBD Typical: TBD WCDMA B1 WCDMA B2 WCDMA B3 WCDMA B4 m WCDMA B5 o WCDMA B8 LTE data CLTE-FDD B1 IMLTE-FDD B2 S LTE-FDD B3 @Power TBD @Power TBD @Power TBD @Power TBD @Power TBD @Power TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD @5Mbps TBD @10Mbps TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD @20Mbps TBD Typical: TBD LTE-FDD B4 @5Mbps TBD Typical: TBD @10Mbps TBD Typical: TBD File SIM8200EA-M2 card Hardware Design _V1.01 43 2019-06-27 LTE-FDD B5 LTE-FDD B7 LTE-FDD B8 LTE-FDD B12 LTE-FDD B13 LTE-FDD B14 LTE-FDD B17 LTE-FDD B18 LTE-FDD B19 LTE-FDD B20 LTE-FDD B25 LTE-FDD B26 m LTE-FDD B28 Co LTE-FDD B30 IMLTE-TDD B34 S LTE-TDD B38 LTE-TDD B39 Smart Machine Smart Decision @20Mbps TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD Typical: TBD @10Mbps TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD l @5Mbps TBD @10Mbps TBD tia @20Mbps TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD n @5Mbps TBD @10Mbps TBD e @20Mbps TBD @5Mbps TBD fid @10Mbps TBD @20Mbps TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD n@5Mbps TBD @10Mbps TBD o@20Mbps TBD @5Mbps TBD C@10Mbps TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD @20Mbps TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD SIM8200EA-M2 card Hardware Design _V1.01 44 2019-06-27 File LTE-TDD B40 LTE-TDD B41 LTE-TDD B42 LTE-TDD B48 LTE-FDD B66 LTE-FDD B71 5G data 5G N1 5G N2 5G N3 5G N5 5G N7 5G N8 m 5G N12 Co 5G N20 IM5G N25 S 5G N28 5G N40 Smart Machine Smart Decision @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD Typical: TBD @10Mbps TBD Typical: TBD @20Mbps TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD l @5Mbps TBD @10Mbps TBD @20Mbps TBD tia @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD n @5Mbps TBD e @10Mbps TBD @20Mbps TBD fid @5Mbps TBD @10Mbps TBD @20Mbps TBD @5Mbps TBD @10Mbps TBD n@20Mbps TBD @5Mbps TBD o@10Mbps TBD @20Mbps TBD C@5Mbps TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD @10Mbps TBD Typical: TBD @20Mbps TBD Typical: TBD @5Mbps TBD Typical: TBD @10Mbps TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD SIM8200EA-M2 card Hardware Design _V1.01 45 2019-06-27 File Smart Machine Smart Decision 5G N41 @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD 5G N66 @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD @5Mbps TBD Typical: TBD 5G N71 @10Mbps TBD Typical: TBD @20Mbps TBD Typical: TBD 5G N77 l 5G N78 tia 5G N79 @5Mbps TBD @10Mbps TBD @20Mbps TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD @5Mbps TBD @10Mbps TBD @20Mbps TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD Typical: TBD n 5.5. RF Output Power e The following table shows the RF output power of SIM8200EA_M2 module. fid Table 31: Conducted Output Power n Frequency WCDMA Bands o LTE-FDD Bands C LTE-TDD Bands Max 24dBm + 1/-3dB 23dBm + 2/-2dB 23dBm + 2/-2dB Min < -50dBm < -40dBm < -40dBm 5G Bands 23dBm + 2/-2dB < -40dBm 5.6 Conducted Receive Sensitivity m The following tables show conducted RF receiving sensitivity of SIM8200EA_M2module. o Table 32:SIM8200EA-M2 Conducted RF Receiving Sensitivity CFrequency IMWCDMA B1 WCDMA B2 S WCDMA B3 Primary (Typ.) TBD TBD TBD Diversity (Typ.) TBD TBD TBD SIMO1(Typ.) TBD TBD TBD SIMO2(Worst Case) TBD TBD TBD WCDMA B4 TBD TBD TBD TBD WCDMA B5 TBD TBD TBD TBD WCDMA B8 TBD TBD TBD TBD File SIM8200EA-M2 card Hardware Design _V1.01 46 2019-06-27 LTE-FDD B1(10M) TBD LTE-FDD B2(10M) TBD LTE-FDD B3(10M) TBD LTE-FDD B4(10M) TBD LTE-FDD B5(10M) TBD LTE-FDD B7(10M) TBD LTE-FDD B8(10M) TBD LTE-FDD B12(10M) TBD LTE-FDD B13(10M) TBD LTE-FDD B14(10M) TBD LTE-FDD B17(10M) TBD LTE-FDD B18(10M) TBD LTE-FDD B19(10M) TBD LTE-FDD B20(10M) TBD LTE-FDD B25(10M) TBD LTE-FDD B26(10M) TBD LTE-FDD B28(10M) TBD LTE-FDD B29(10M) TBD LTE-FDD B30(10M) TBD LTE-FDD B32(10M) TBD LTE-TDD B34(10M) TBD LTE-TDD B38(10M) TBD LTE-TDD B39(10M) TBD LTE-TDD B40(10M) TBD LTE-TDD B41(10M) TBD LTE-TDD B42(10M) TBD LTE-TDD B43(10M) TBD LTE-TDD B48(10M) TBD LTE-FDD B66(10M) TBD LTE-FDD B71(10M) TBD m 5G N1 TBD 5G N2 TBD o 5G N3 TBD 5G N5 TBD C5G N7 TBD 5G N8 TBD 5G N12 TBD IM5G N20 TBD 5G N25 TBD S 5G N28 TBD 5G N40 TBD 5G N41 TBD 5G N66 TBD Smart Machine Smart Decision TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD l TBD TBD TBD tia TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD n TBD TBD TBD e TBD TBD TBD TBD TBD TBD fid TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD nTBD TBD TBD oTBD TBD TBD TBD TBD TBD CTBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD TBD File SIM8200EA-M2 card Hardware Design _V1.01 47 2019-06-27 Smart Machine Smart Decision 5G N71 TBD TBD TBD TBD 5G N77 TBD TBD TBD TBD 5G N78 TBD TBD TBD TBD 5G N79 TBD TBD TBD TBD Note: The data in above table are gotten at static condition. 1. SIMO is a smart antenna technology that uses a single antenna at the transmitter side and multiple (two for SIM8200EA_M2) antennas at the receiver side, which can improve Rx performance. 2. Per 3GPP specification. 5.5 ESD l Module is sensitive to ESD in the process of storage, transporting, and assembling. When Module tia is mounted on the users' mother board, the ESD components should be placed beside the connectors which human body may touch, such as USIM card holder, SD card holder, audio jacks, switches, USB interface, etc. The following table shows the Module ESD measurement performance without any external ESD component. n Table 33: The ESD performance measurement table (Temperature: 25, Humidity: 45%) e Part fid VBAT,GND Antenna port FUL_CARD_POWER_OFF# n USB o RESET_N C UIM Card Contact discharge +/-TBD +/- TBD +/- TBD +/- TBD +/- TBD +/- TBD Air discharge +/- TBD +/- TBD +/- TBD +/- TBD +/- TBD +/- TBD Other PADs +/- TBD +/- TBD SIMCom File SIM8200EA-M2 card Hardware Design _V1.01 48 2019-06-27 Smart Machine Smart Decision 6 Top and Bottom View of Module Confidential File Figure 23: Top and bottom view of Module SIMCom SIM8200EA-M2 card Hardware Design _V1.01 49 2019-06-27 Smart Machine Smart Decision 7 Label description Information A B l C tia D n E F nfide T o Figure 24: Label description of Module C Table 34: Label description of Module Information No. Description A LOGO m B Project name C Product code oD QR code E Serial number CF International mobile equipment identity IM7.1 Ordering Information S Table 35: SIM8200EA-M2 Information File Product name SIM8200EA-M2 P/N S2-108R0 SIM8200EA-M2 card Hardware Design _V1.01 Shipping package -TR 50 2019-06-27 8 Packaging Smart Machine Smart Decision Module support tray packaging. fidential File Figure 25: packaging diagram Con Module tray drawing SIMCom Figure 26: Tray drawing SIM8200EA-M2 card Hardware Design _V1.01 51 2019-06-27 Table 36: Tray size Smart Machine Smart Decision Length±3mm 245.0 Small carton drawing Width±3mm 165.0 Number 10 ential Figure 27: Small carton drawing fid Table 37: Small Carton size Length±10mm Width±10mm n 270 180 Co Big carton drawing Height±10mm 120 Number 10*20=200 SIMCom Table 38: Big Carton size Figure 28: Big carton drawing Length±10mm Width±10mm Height±10mm Number 380 280 280 200*4=800 File SIM8200EA-M2 card Hardware Design _V1.01 52 2019-06-27 Smart Machine Smart Decision Appendix A. Coding Schemes and Maximum Net Data Rates over Air Interface Table 39: Coding Schemes and Maximum Net Data Rates over Air Interface HSDPA device category Category 1 Category 2 Category 3 Category 4 Category 5 Category 6 Category 7 Category 8 Category 9 Category 10 Category 11 Category 12 Category 13 Category 14 Category 15 Category 16 Category 17 Category 18 Category 19 m Category 20 o Category 21 Category 22 CCategory 23 Category 24 HSUPA device category IMCategory 1 Category 2 S Category 3 Max data ratepeak 1.2Mbps l 1.2Mbps 1.8Mbps tia 1.8Mbps 3.6Mbps 3.6Mbps n 7.2Mbps e 7.2Mbps 10.2Mbps fid 14.4Mbps 0.9Mbps 1.8Mbps n 17.6Mbps o21.1Mbps 23.4Mbps C28Mbps Modulation type 16QAM,QPSK 16QAM,QPSK 16QAM,QPSK 16QAM,QPSK 16QAM,QPSK 16QAM,QPSK 16QAM,QPSK 16QAM,QPSK 16QAM,QPSK 16QAM,QPSK QPSK QPSK 64QAM 64QAM 16QAM 16QAM 23.4Mbps 64QAM 28Mbps 64QAM 35.5Mbps 64QAM 42Mbps 64QAM 23.4Mbps 16QAM 28Mbps 16QAM 35.5Mbps 64QAM 42.2Mbps 64QAM Max data ratepeak Modulation type 0.96Mbps QPSK 1.92Mbps QPSK 1.92Mbps QPSK Category 4 3.84Mbps QPSK Category 5 3.84Mbps QPSK File SIM8200EA-M2 card Hardware Design _V1.01 53 2019-06-27 Category 6 LTE-FDD device category (Downlink) Category 1 Category 2 Category 3 Category 4 Category 5 Category 6 LTE-FDD device category (Uplink) Category 1 Category 2 Category 3 Category 4 Category 5 Category 6 SIMCom 5.76Mbps Smart Machine Smart Decision QPSK Max data ratepeak Modulation type 10Mbps QPSK/16QAM/64QAM 50Mbps QPSK/16QAM/64QAM 100Mbps QPSK/16QAM/64QAM 150Mbps QPSK/16QAM/64QAM 300Mbps 300Mbps l Max data ratepeak tia 5Mbps 25Mbps 50Mbps n 50Mbps 75Mbps Confide 50Mbps QPSK/16QAM/64QAM QPSK/16QAM/64QAM Modulation type QPSK/16QAM QPSK/16QAM QPSK/16QAM QPSK/16QAM QPSK/16QAM/64QAM QPSK/16QAM File SIM8200EA-M2 card Hardware Design _V1.01 54 2019-06-27 Smart Machine Smart Decision B. Related Documents Table 40: Related Documents ile NO. Title [1] SIM8200EA-M2 Series_AT Command Manual_V1.xx F [2] ITU-T Draft new recommendationV.25ter l [3] GSM 07.10 tia [4] GSM 07.05 n [5] GSM 11.14 fide [6] GSM 11.11 [7] GSM 03.38 n [8] GSM 11.10 Co [9] 3GPP TS 51.010-1 Description AT Command Manual Serial asynchronous automatic dialing and control Support GSM 07.10 multiplexing protocol Digital cellular telecommunications (Phase 2+); Use of Data Terminal Equipment Data Circuit terminating Equipment (DTE DCE) interface for Short Message Service (SMS) and Cell Broadcast Service (CBS) Digital cellular telecommunications system (Phase 2+); Specification of the SIM Application Toolkit for the Subscriber Identity Module Mobile Equipment (SIM ME) interface Digital cellular telecommunications system (Phase 2+); Specification of the Subscriber Identity Module Mobile Equipment (SIM ME) interface Digital cellular telecommunications system (Phase 2+); Alphabets and language-specific information Digital cellular telecommunications system (Phase 2) Mobile Station (MS) conformance specification Part 1: Conformance specification Digital cellular telecommunications system (Release 5); Mobile Station (MS) conformance specification [10] 3GPP TS 38.401 [11] 3GPP TS 34.124 m [12] 3GPP TS 34.121 o [13] 3GPP TS 34.123-1 C[14] 3GPP TS 34.123-3 SIM[15] EN 301 908-02 V2.2.1 [16] EN 301 489-24 V1.2.1 NG-RAN; Architecture description Electromagnetic Compatibility (EMC) for mobile terminals and ancillary equipment. Electromagnetic Compatibility (EMC) for mobile terminals and ancillary equipment. Technical Specification Group Radio Access Network; Terminal conformance specification; Radio transmission and reception (FDD) User Equipment (UE) conformance specification; Part 3: Abstract Test Suites. Electromagnetic compatibility and Radio spectrum Matters (ERM); Base Stations (BS) and User Equipment (UE) for IMT-2000. Third Generation cellular networks; Part 2: Harmonized EN for IMT-2000, CDMA Direct Spread (UTRA FDD) (UE) covering essential requirements of article 3.2 of the R&TTE Directive Electromagnetic compatibility and Radio Spectrum Matters (ERM); Electromagnetic Compatibility (EMC) standard for SIM8200EA-M2 card Hardware Design _V1.01 55 2019-06-27 Smart Machine Smart Decision radio equipment and services; Part 24: Specific conditions for IMT-2000 CDMA Direct Spread (UTRA) for Mobile and portable (UE) radio and ancillary equipment [17] [18] [19] [20] [21] [22] [23] IEC/EN60950-1(2001) 3GPP TS 51.010-1 ile GCF-CC V3.23.1 2002/95/EC F SIM8200EA-M2 l Series_UART_Application Note_V1.xx tia SIM8200EA-M2 Series_GPS_Application Note_V1.xx SIM8200EA-M2 Antenna n design guidelines for diversity Confide receiver system Safety of information technology equipment (2000) Digital cellular telecommunications system (Release 5); Mobile Station (MS) conformance specification Global Certification Forum - Certification Criteria Directive of the European Parliament and of the Council of 27 January 2003 on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS) This document describes how to use UART interface of SIMCom modules. GPS Application Note Antenna design guidelines for diversity receiver system SIMCom SIM8200EA-M2 card Hardware Design _V1.01 56 2019-06-27 Smart Machine Smart Decision C. Terms and Abbreviations Table 41: Terms and Abbreviations Abbreviation Description ADC Analog-to-Digital Converter ARP Antenna Reference Point BER BTS CS CSD CTS DAC DRX DSP DTE DTR DTX EFR EGSM EMC ESD ETS EVDO FCC FD FDMA Bit Error Rate Base Transceiver Station Coding Scheme l Circuit Switched Data Clear to Send tia Digital-to-Analog Converter Discontinuous Reception Digital Signal Processor n Data Terminal Equipment (typically computer, terminal, printer) Data Terminal Ready e Discontinuous Transmission Enhanced Full Rate fid Enhanced GSM Electromagnetic Compatibility Electrostatic Discharge European Telecommunication Standard n Evolution Data Only Federal Communications Commission (U.S.) o SIM fix dialing phonebook C Frequency Division Multiple Access FR Full Rate GMSK GNSS GPRS m GPS GSM o HR HSPA CHSIC I2C IMEI IMLTE MDIO S MMD Gaussian Minimum Shift Keying Global Navigation Satellite System General Packet Radio Service Global Positioning System Global Standard for Mobile Communications Half Rate High Speed Packet Access High-speed Inter-chip Inter-Integrated Circuit International Mobile Equipment Identity Long Term Evolution Management Data Input/Output MDIO manageable device MO Mobile Originated MS Mobile Station (GSM engine), also referred to as TE MT Mobile Terminated NMEA National Marine Electronics Association SIM8200EA-M2 card Hardware Design _V1.01 57 2019-06-27 File PAP PBCCH PCB PCS RF RMS RTC SIM SMS SPI SMPS TDMA TE TX UART VSWR SM SGMII NC EDGE HSDPA HSUPA ZIF WCDMA VCTCXO USIM UMTS UART Smart Machine Smart Decision Password Authentication Protocol Packet Switched Broadcast Control Channel Printed Circuit Board Personal Communication System, also referred to as GSM 1900 Radio Frequency Root Mean Square (value) Real Time Clock Subscriber Identification Module Short Message Service serial peripheral interface Switched-mode power supply l Time Division Multiple Access Terminal Equipment, also referred to as DTE tia Transmit Direction Universal Asynchronous Receiver & Transmitter Voltage Standing Wave Ratio SIM phonebook n Serial gigabit media independent interface Not connect e Enhanced data rates for GSM evolution High Speed Downlink Packet Access fid High Speed Uplink Packet Access Zero intermediate frequency Wideband Code Division Multiple Access n Voltage control temperature-compensated crystal oscillator Universal subscriber identity module o Universal mobile telecommunications system C Universal asynchronous receiver transmitter SIMCom File SIM8200EA-M2 card Hardware Design _V1.01 58 2019-06-27 Smart Machine Smart Decision D. Safety Caution Table 42: Safety Caution Confidential File Marks Requirements When in a hospital or other health care facility, observe the restrictions about the use of mobiles. Switch the cellular terminal or mobile off, medical equipment may be sensitive and not operate normally due to RF energy interference. Switch off the cellular terminal or mobile before boarding an aircraft. Make sure it is switched off. The operation of wireless appliances in an aircraft is forbidden to prevent interference with communication systems. Forgetting to think much of these instructions may impact the flight safety, or offend local legal action, or both. Do not operate the cellular terminal or mobile in the presence of flammable gases or fumes. Switch off the cellular terminal when you are near petrol stations, fuel depots, chemical plants or where blasting operations are in progress. Operation of any electrical equipment in potentially explosive atmospheres can constitute a safety hazard. Your cellular terminal or mobile receives and transmits radio frequency energy while switched on. RF interference can occur if it is used close to TV sets, radios, computers or other electric equipment. Road safety comes first! Do not use a hand-held cellular terminal or mobile when driving a vehicle, unless it is securely mounted in a holder for hands free operation. Before making a call with a hand-held terminal or mobile, park the vehicle. GSM cellular terminals or mobiles operate over radio frequency signals and cellular networks and cannot be guaranteed to connect in all conditions, especially with a mobile fee or an invalid SIM card. While you are in this condition and need emergent help, please remember to use emergency calls. In order to make or receive calls, the cellular terminal or mobile must be switched on and in a service marea with adequate cellular signal strength. Some networks do not allow for emergency call if certain network services or phone ofeatures are in use (e.g. lock functions, fixed dialing etc.). You may have to deactivate those features before you can make an emergency call. CAlso, some networks require that a valid SIM card be properly inserted in the SIM cellular terminal or mobile. SIM8200EA-M2 card Hardware Design _V1.01 59 2019-06-27 Contact us: Shanghai SIMCom Wireless Solutions Limited. Smart Machine Smart Decision Address: Building B, No.633 Jinzhong Road, Changning District, Shanghai P.R.China 200335 Tel: +86 21 3157 5100\3157 5200 Email: simcom@simcom.com Website: www.simcom.com Confidential File SIMCom SIM8200EA-M2 card Hardware Design _V1.01 60 2019-06-27张修宇 Adobe PDF Library 10.0
