OWNERS MANUAL Vehicle conditions, amplifier, music preferences, & other variables make it difficult to give you exact dimensions for an enclosure deisgn. For enclosure designs tailored to your specific needs, please contact us at tech-support@ soundstream.com, or 1-800-724-1377. All enclosures should be made of .75” (3/4”) material only.
OWNERS MANUAL. Thank you for choosing Soundstream subwoofers, designed & engineered in the U.S.A. This product combines innovative technology with the finest materials to consistently deliver...
OWNERS MANUAL. Thank you for choosing Soundstream subwoofers, designed & engineered in the U.S.A. This product combines innovative technology with the finest...
OWNERS MANUAL Thank you for choosing Soundstream subwoofers, designed & engineered in the U.S.A. This product combines innovative technology with the finest materials to consistently deliver absolutely state of the art performance, sound quality, reliability, and value. This Bass Xtreme subwoofer reflects our commitment to offer you unparalleled performance and quality for years of dependable service and listening enjoyment. Complimenting Bass Xtreme amplifiers, 2019's BXW-12 woofers combine extreme performance and affordability. Each 12" woofer has a 4-layer 2" dual 4-ohm voice coil, with spruce paper cones attached to foam surrounds to keep the momentum in check. Double-stack 114oz magnet motor structure provide the energy to get'em jumpin'. Each woofer can handle 800w RMS, and 2,400w peak. FEATURES, PARAMETERS, & SPECIFICATIONS Overcompensating Motor Sturcture for Increased Magnetic Strength 10mm T-Yoke & Top Plate Improve Low Frequency Dynamics Vented T-Yoke & Frame Reduces Voice Coil Heat Build-up 2" 4-Layer Voice Coil w/ Spring Loaded Compression Wire Terminals High-Temperature Tollerance Adhesives Resist Thermal Failure Spruce Pulp Cone w/ UV & Chemical Protection Sitched and Glued Surround/Cone Joints for Strongest Bond Extended Excursion Polyether Foam Surround w/ UV & Chemical Protection Poly-Cotton Suspension Dampen Violent Accelerations 1-pc Gasket/Trim Ring w/ Concealed Mounting Holes Included Specification Fs (Hz) Qms Vas (ft3) Cms (mm/N) Mms (g) Xmax (mm) Xmech (mm) Qes Re () Z () BL (Tm) MAX Power RMS Power Qts NO (%) Efficiency (1w/1m) Impedance BXW-124 31.5 4.22 2.68 .21 121.1 8 18 .677 7.0 8 16.1 2,400w 800w .56 .35 87.5dB DVC 4 Vehicle conditions, amplifier, music preferences, & other variables make it difficult to give you exact dimensions for an enclosure deisgn. For enclosure designs tailored to your specific needs, please contact us at tech-support@ soundstream.com, or 1-800-724-1377. All enclosures should be made of .75" (3/4") material only. When possible, make the baffle 1.5" (1 ½) thick and add .75" (3/4") to the depth of the enclosure to compensate. All volumes INCLUDE vent/port and subwoofer displacements. DO NOT change the volume unless you plan on adding a substantial amount of bracing. For added performance, applying a coat of fiberglass resin to the interior walls will greatly improve sealing the enclosure. Adding a thin layer of poly-fill will improve response by smoothing out reflections within the enclosure. Below are recommended enclsoure designs and their expected performance: BXW-124 Recommended Sealed Enclosures Min. Opt. Max. Volume (ft3) 1.25 1.50 1.75 QTC .884 .785 .725 Tuning (Hz) 52.5 50.3 49.5 BXW-124 Recommended Ported Enclosures Min. Opt. Max. Volume (ft3) 2.25 2.50 2.75 Round Port 3" x 12"L 4" x 12"L 4" x 14"L Tuning (Hz) 33.3 31.1 29.3 OWNERS MANUAL DIMENSIONS Soundstream Technologies® 1550 South Maple Ave. Montebello, CA 90640 specifications & designs are subject to change without noticeAdobe PDF Library 15.0 Adobe InDesign CC 13.0 (Windows)
