GOXAWEE Rotary Tool Kit

Grinder Structure

Diagram showing the GOXAWEE electric grinder with labels pointing to: A-Keyless Chuck (accepts 0.5-3.2 mm shank), B-Collet Nut (locks the chuck), C-Carbon Brush Mouth (for changing carbon brushes), D-On/Off Switch, E-Hanger, F-Cable (150 cm), G-Variable Speed Switch (5 steps).

Dimensions: 15.8cm (7.28") length, 5.5cm (2.16") height, 5cm (1.95") width.

Specifications

Safety & Notes

1. Before using the tool, please use personal protective equipment, always wear goggles and overalls to avoid accidents.
2. Before the grinder is energized, please make sure the switch is off.
3. When installing or replacing accessories, make sure to unplug the plug before starting.
4. Before operation, the rotary tool accessories should be carefully inspected; do not use broken or cracked accessories.
5. When installing accessories, the chuck of the electric grinder or flexible shaft must be tightened with the wrench.
6. Before starting work, ensure attachments and accessories are fastened, then test the electric grinder without load. If there is no abnormality, continue operation.
7. During use, pay attention to the pressure applied to the grinder to avoid excessive force.
8. When using cutting discs or other accessories, ensure your body is not in the tangential direction of the cutting disc to avoid injury.
9. For North American countries, this grinder supports 100-110V voltage; for European countries, it supports 220-240V voltage.

Operation Guide

Focus:

1. Correctly install the chuck:

   Ensure the chuck port aligns with the grinder port. [Correct insertion symbol] ✔️

   Incorrect alignment. [Incorrect insertion symbol] ❌
2. Insert the shank of accessories correctly:

   Be sure to insert most of the shank into the chuck. [Correct insertion symbol] ✔️

   Insufficient insertion. [Incorrect insertion symbol] ❌

Attachment Part: Flexible Shaft

Extend the working range of the grinder.

1. Open the plastic nut, press the chuck lock, and release the chuck.
2. Insert the shaft core into the chuck.
3. Press the chuck lock and tighten the chuck with the wrench.
4. Tighten the shaft cover by hand.
5. Before use, please ensure the flexible shaft runs at high speed in the vertical position for 1 minute to prevent twisting and enhance its lifespan.

After the flexible shaft test is satisfactory, install accessories:

1. Use the "L" Spanner to insert into the hole at the head of the shaft and press to open the collet nut.
2. Insert the accessory, press the "L" spanner, and tighten the collet nut with the small wrench.

Drill Locator

Control the depth of drilling.

1. Unscrew the plastic nut and install the drill bit.
2. Tighten the drill locator onto the head of the grinder, adjust the scale according to the desired drilling depth, and tighten the screws by hand.

Cover Shield

Prevent sparks and debris from harming the human body.

1. Unscrew the plastic nut, attach the cover shield to the grinder head, and tighten the nut.
2. Install the accessories, tighten the chuck, check it, and start working.

Collet & Keyless Chuck

Collet: 3.2 mm

Unscrew the collet cap, insert the 3.2 mm collet into the grinder port, and tighten the collet cap.

Keyless Chuck: 0.5-3.2 mm

Remove the 3.2mm collet, install the keyless chuck, insert the accessories, and tighten with the wrench.

Replace Carbon Brush

Conductive, transfer electrical energy.

1. Insert the end of the wrench into the carbon brush port and unscrew it to remove the damaged carbon brush.
2. Insert the new carbon brush into the carbon brush port correctly and cover the port with the wrench.

Remarks: a. If the grinder does not rotate after power-on, check if the carbon brush is loosened due to transportation and re-install it. If issues persist, contact after-sales service. b. If the grinder stops rotating after extended use (e.g., half a year), check if the carbon brush is consumed and replace it if necessary. For specific problems, contact after-sales service.

Accessories Part

Cutting Function

1. Diamond Cutting Disc (x3, 22 x 0.7mm)

   Suitable for stone, ceramic, gemstone, and other jade processing.

   Due to high temperature, use water to cool during work to prolong validity.

   Usage: Unscrew the head screw of the mandrel and attach the cutting disc. Install the mounted cutting disc into the chuck, and fasten the chuck and the cutting disc screw with the wrench.

2. HSS Cutting Disc (x3, 25 x 0.4mm)

   For cutting wood and plastic materials.

   When installing, pay attention to the same direction of rotation as the saw blade gear and the grinder.
3. Resin Cutting Disc (x36, 24 x 0.8mm)

   For cutting metals such as aluminum, iron, steel, copper, etc.

   Not suitable for alloy metal with too high hardness.

Grinding Function

1. Sanding Drum (18 pcs: 8pc 15 x 12.6mm, 10pc 13.5 x 9mm, 80 grit)

   Grind wood and metal to remove stains and mold, paint, etc.

   Usage: Loosen the screw of the mandrel, install the sanding drum, and tighten the screw with the wrench. Install the sanding drum fitting into the chuck and fasten it, then tighten the mandrel head screw again to ensure it is completely tightened.

2. Grinding Stone (x8, Ø 3 mm)

   Used to grind metals such as aluminum, iron, steel, copper, etc.

Engraving Function

1. Diamond Burr Bit (x10, Ø 3 mm)

   For carving stone materials, metal, glass, hardwood, etc.

   Due to high temperature, use water to cool during work to prolong validity.
2. HSS Burr Cutter (x3, Ø 3 mm)

   Mainly used for woodworking engraving, suitable for shaving wood, plastic, soft metal (aluminum), and soft stone with hardness below 3.5 degrees.

Polishing / Cleaning Function

1. Felt Wheel (x12: 2pc 25 x 7mm, 10pc 13.5 x 6mm)

   For polishing plastics, metals, jewellery, and models, etc. (Can be used with polishing paste).

   Usage: Insert the mandrel into the felt wheel and tighten by hand. Install the felt wheel to the chuck and tighten. Apply polishing paste to the felt wheel and rotate at a low speed on the polishing project.

2. Polishing Compound (x1)

   Used with felt wheel to enhance the polishing effect and achieve a touch-up effect.

3. Wire Brush (x2, Ø 3.2 mm)

   Suitable for cleaning, deburring, and surface treatment.

   Mainly used to remove rust and corrosion on metal surfaces, as well as wood work.

Drilling Function

1. HSS Twist Drill Bit (x4: 2 x 2.3mm, 2 x 3mm)

   Drilling work for wood and plastic.

   Generally used with the drill locator.

   Usage: Unscrew the mandrel screws and install 3 or more discs of sandpaper. Insert the installed sandpaper device into the chuck and tighten with the wrench. Then tighten the screws on the mandrel head with the wrench.

2. Sanding Paper Disc (x20, 20 x 0.4mm, 280 grit)

   Polish, grind, and remove stains on wood, glass, and metal.

   It is recommended to install and use 3 discs or more for better effect.

After-Sale Service

Brand Concept

GOXAWEE Tool is a source for hard-to-find mini tools for DIY crafts and hobbies. GOXAWEE takes great pride in providing excellent customer service. Whether you are a professional craftsman, a robot builder, or a model building hobbyist requiring precision small tools, GOXAWEE Tool can help.

GOXAWEE is committed to creating an excellent customer experience and strives to be the best seller. Feedback and advice are highly appreciated.

Warranty

The GOXAWEE Rotary Tool Kit comes with a 24-month warranty. For any product issues during this period, please contact GOXAWEE as soon as possible for assistance.
