monarch m5 reticle weight length eye relief (in) fov-ft @ 100 yds adjust grad max internal adjust travel per rotation parallax (yds) 16649 3-12x42sf matte bdc 19.2 13.1 3.6 - 3.4 38.3 - 9.4 1/4 moa 115 moa 25 moa 50 - ∞
TWENTY NINETEEN TABLE OF CONTENTS RIFLESCOPES HUNTING RIFLESCOPES . . . . . . . . . . . . 4-5 NEW MONARCH M5 . . . . . . . . . . . . . . 6-7 NEW PROSTAFF P5 . . . . . . . . . . . . . . . 8-9 NEW PROSTAFF P3 . . . . . . . . . . . . . . . 10-11 NEW PROSTAFF P3 SPECIALTY. . . . . . . . . 12-15 BUCKMASTERS . . . . . . . . . . . . . . . . . . 16 FORCE XR . . . . . . . . . . . . . . . . . . . . . 17 NEW PROSTAFF P3 CROSSBOW . . . . . . . . . 17 RIMFIRE . . . . . . . . . . . . . . . . . . . . . . 18 NEW PROSTAFF P3 TARGET EFR . . . . . . . . . 19 BLACK SERIES . . . . . . . . . . . . . . . . 20-21 BLACK FX1000 . . . . . . . . . . . . . . . . 22-25 BLACK X1000 . . . . . . . . . . . . . . . . . 26-27 NEW BLACK FORCE 100 . . . . . . . . . . . 28-29 BLACKFORCE 1000 . . . . . . . . . . . . . . 30-31 M-TACTICAL . . . . . . . . . . . . . . . . . . 32-33 P-TACTICAL . . . . . . . . . . . . . . . . . . 34-35 P-TACTICAL SPUR . . . . . . . . . . . . . . . 36-37 P-TACTICAL SUPERDOT . . . . . . . . . . . . 36-37 LASER RANGEFINDERS BLACK RANGEX 4K . . . . . . . . . . . . . . 38-39 MONARCH 3000 STABILIZED . . . . . . . . . 40-41 NEW MONARCH 2000 . . . . . . . . . . . . 42-43 LASERFORCE RANGEFINDER BINOCULAR . 44-45 NEW PROSTAFF 1000i/1000 RANGEFINDERS . 46-47 ARROW ID 3000 RANGEFINDER . . . . . . . . . 47 BINOCULARS MONARCH INTRO . . . . . . . . . . . . . . . 48-49 MONARCH HG . . . . . . . . . . . . . . . . 50-51 MONARCH 7- 5. . . . . . . . . . . . . . . . . 52-53 PROSTAFF 7S-5-3S . . . . . . . . . . . . . . 54-55 ACULON . . . . . . . . . . . . . . . . . . . . 56-57 SPECIALTY. . . . . . . . . . . . . . . . . . . 58-61 FIELDSCOPES FIELDSCOPE INTRO. . . . . . . . . . . . . . 62-63 NEW MONARCH . . . . . . . . . . . . . . . 64-65 FIELDSCOPE 50MM ED . . . . . . . . . . . . . . 66 PROSTAFF 5-3. . . . . . . . . . . . . . . . . . . 67 NEW SCOPE MOUNTING SOLUTIONS . . . . 68-69 BALLISTIC TECHNOLOGIES . . . . . . . . . . . 69 RIFLESCOPE RETICLE SUBTENSIONS . . . 70-73 FEATURE ICON DESCRIPTION KEY . . . . . 74-75 2 GLASS FIRST. For over 100 years, the guiding principle behind every Nikon product has been to engineer it from the inside out and create an optical system specific to the function of the product and to the needs of the user. As one of the few makers of optical glass in the world, Nikon has the advantage of being able to specify and select the exact type of glass, lens geometry and multicoatings needed to optimize the optical performance of any given optic. The result is what we call our "Glass First Principle," and it applies to every binocular, riflescope, fieldscope and laser rangefinder that bears the Nikon brand. FEATURE AND PERFORMANCE ICONS Throughout the pages of this catalog, feature and performance icons are used to help in comparing and selecting the right product for your intended use. See 74-75 for detailed descriptions for each. LIFETIME REPAIR/REPLACEMENT Excludes lost or stolen products and intentionally caused damage, and also excludes Nikon Rangefinders, Reflex Sights, Red Dot Sights, StabilEyes Binoculars & Specialty Optics. NO FAULT POLICY When you build a quality product, the warranty is seldom used. That's why you don't hear Nikon talk much about warranties. Nevertheless, it is important to know that every Nikon riflescope, binocular and fieldscope/spotting scope is covered by both our Lifetime Limited Warranty for manufacturing defects and our exclusive No Fault Lifetime Repair/Replacement Policy for just about everything else. No receipts, no time limits and no excuses. Above all, Nikon is a 100+ year old company that you can count on to be around should anything ever happen. 3 HUNTING RIFLESCOPES LIFETIME REPAIR/REPLACEMENT 4 Hunting Riflescopes Our 2019 hunting riflescope line not only introduces three new families of performance optics containing 26 new riflescope models, it also makes selecting the right model easier than ever. To start, all MONARCH series riflescopes--including the new MONARCH M5--are now engineered for a 30mm main body tube platform. All PROSTAFF series riflescopes--including new PROSTAFF P5 and PROSTAFF P3--are built on one-inch main body tube platforms. As you explore our new hunting riflescope families, know that every model will deliver the optical quality, repeatable mechanical precision and ruggedness that you can count on for a lifetime of hunting success. 5 NEW THE NEW HUNTING FLAGSHIP LIFETIME REPAIR/REPLACEMENT 6 MONARCH M5--the all-new patriarch of the Nikon hunting riflescope family. Engineered from the inside out to check all the boxes on your long-range riflescope wish list, the MONARCH M5 keenly illustrates Nikon's Glass First principle as it pertains to the development of our hunting optics. The MONARCH M5's highly efficient 4x zoom optical system was created specifically to deliver a brighter, sharper, higher contrast sight picture for the times that you vitally need it--just as the first vestiges of light appear, and disappear into the darkness, together with your prey. MONARCH M5's rugged and robust 30mm main body tube not only protects the riflescope's optical system--but also increases its internal adjustment range. With Nikon's MK1-MOA hash mark reticle well integrated into the MONARCH M5 lineup, long-range dialers will be able to make use of the increased elevation travel. Low profile turrets and caps are ergonomically shaped to match the riflescope's sleek modern profile, as are its side focus parallax adjustment, zoom ring and ocular focus ring. FULLY MULTICOATED OPTICS GENEROUS, CONSISTENT EYE RELIEF 4x ZOOM RATIO WATERPROOF SHOCKPROOF 7 NITROGEN PURGED 30mm MAIN BODY TUBE INTERCHANGEABLE TURRET QUICK FOCUS EYEPIECE SIDE FOCUS PARALLAX ADJUSTMENT SPRING-LOADED INSTANT ZERO-RESET TURRETS Spring-Loaded Instant Zero-Reset Turrets Precise, positive-click ¼-MOA reticle adjustments to get you zeroed quickly and maintain your setting, even with heavy recoil. Low Profile Aluminum Turret Caps Low profile turrets and caps are ergonomically shaped to match the riflescope's sleek modern profile, as are its side focus parallax adjustment, zoom ring and ocular focus ring. Side Focus Parallax Adjustment Parallax dial allows adjustment without changing shooting position NEW MONARCH M5 16649 3-12x42SF Matte 16650 16651 16652 16653 16654 16655 3-12x42SF Matte 3-12x42SF Matte 4-16x42SF Matte 4-16x50SF Matte 4-16x50SF Matte 5-20x50SF Matte RETICLE BDC Nikoplex MK1-MOA BDC BDC MK1-MOA MK1-MOA EYE RELIEF WEIGHT LENGTH (IN) 19.2 13.1 3.6 - 3.4 FOV-FT @ 100 YDS 38.3 - 9.4 19.2 13.1 3.6 - 3.4 38.3 - 9.4 19.2 13.1 3.6 - 3.4 38.3 - 9.4 19.4 13.6 3.6 - 3.5 28.8 - 7.3 22.4 14.8 3.6 - 3.4 28.3 - 7.3 22.4 14.8 3.6 - 3.4 28.3 - 7.3 22.2 15.0 3.6 - 3.4 23.0 - 5.8 ADJUST MAX INTERNAL TRAVEL PER GRAD ADJUST ROTATION 1/4 MOA 115 MOA 25 MOA PARALLAX (YDS) 50 - 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 115 MOA 115 MOA 85 MOA 85 MOA 85 MOA 70 MOA 25 MOA 25 MOA 25 MOA 25 MOA 25 MOA 25 MOA 50 - 50 - 50 - 50 - 50 - 50 - MK1-MOA BDC NIKOPLEX MONARCH M5 Reticles The new MONARCH M5 line offers models with the newly designed MK1-MOA reticle, as well as the popular BDC and Nikoplex reticle. The MK1-MOA reticle can be used to estimate range, target size, elevation holdover and wind-drift at the designated magnification. The asymmetrical design allows for additional holdover for extreme distances. All Nikon reticles can be optimized for any caliber or load with Spot On Ballistic Technology at NikonSportOptics.ca/SpotOn 7 NEW YOUR NEXT LEVEL OF PERFORMANCE LIFETIME REPAIR/REPLACEMENT 8 The all-new PROSTAFF P5 elevates hunting riflescope performance through a combination of proprietary Nikon optical design, superior glass, durable materials and over 100 years of innovation. Engineered for minimum weight and maximum durability, Nikon builds the PROSTAFF P5 riflescopes' one-inch main tube, zoom ring, focusing eyepiece and turret caps from aircraftgrade aluminum. Matched knurling on all controls is ergonomically designed for visual appeal and increased grip during use. PROSTAFF P5 models feature a versatile 4x zoom ratio that offers the wide field of view needed for close-up shots or moving targets and the increased image detail that comes with higher magnifications. Long-range PROSTAFF P5 models feature a turret-mounted side focus parallax adjustment to enable fine-tuning of the sight image without changing shooter's position. FULLY MULTICOATED OPTICS GENEROUS, CONSISTENT EYE RELIEF 4x ZOOM RATIO WATERPROOF SHOCKPROOF 7 NITROGEN PURGED ONE-INCH TUBE INTERCHANGEABLE TURRET QUICK FOCUS EYEPIECE SIDE FOCUS PARALLAX ADJUSTMENT SPRING-LOADED INSTANT ZERO-RESET TURRETS Spring-Loaded Instant Zero-Reset Turrets Precise, positive-click ¼-MOA reticle adjustments to get you zeroed quickly and maintain your setting, even with heavy recoil. Aluminum Turret Caps PROSTAFF P5 features aluminum construction for enhanced durability. Turret caps, zoom ring and eyepiece focus share ergonomic knurling design. Side Focus Parallax Adjustment Parallax dial allows adjustment without changing shooting position (except 2.5-10x models). NEW PROSTAFF P5 16618 2.5-10x42 Matte 16619 2.5-10x42 Matte 16620 3-12x42SF Matte 16621 3-12x42SF Silver 16622 4-16x42SF Matte 16623 4-16x42SF Matte 16624 4-16x50SF Matte 16625 6-24x50SF Matte RETICLE BDC Nikoplex BDC BDC BDC MK1-MOA BDC BDC WEIGHT LENGTH EYE RELIEF FOV-FT @ (OZ) (IN) (IN) 100 YDS 15.5 12.6 4.0 - 3.8 40.3 10.1 15.5 12.6 4.0 - 3.8 40.3 10.1 17.1 13.1 4.0 - 3.7 33.6 8.4 17.1 13.1 4.0 - 3.7 33.6 8.4 17.3 13.5 4.0 - 3.7 25.2 6.3 17.3 13.5 4.0 - 3.7 25.2 6.3 20.1 14.7 4.0 - 3.7 25.2 6.3 20.5 15.5 4.0 - 3.6 16.8 4.2 ADJUST GRAD 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA MAX INTERNAL TRAVEL PER ADJUST ROTATION 75 MOA 12 MOA PARALLAX (YDS) 100 75 MOA 12 MOA 100 60 MOA 12 MOA 50 - 60 MOA 12 MOA 50 - 40 MOA 12 MOA 50 - 40 MOA 12 MOA 50 - 40 MOA 12 MOA 50 - 30 MOA 12 MOA 50 - MK1-MOA BDC NIKOPLEX PROSTAFF P5 Reticles The new PROSTAFF P5 line offers models with the newly designed MK1-MOA reticle, as well as the popular BDC and Nikoplex reticles. The MK1-MOA reticle can be used to estimate range, target size, elevation holdover and wind-drift at the designated magnification. The asymmetrical design allows for additional holdover for extreme distances. All Nikon reticles can be optimized for any caliber or load with Spot On Ballistic Technology at NikonSportOptics.ca/SpotOn 9 LIFETIME REPAIR/REPLACEMENT 10 NEW FOR EVERY HUNT, THERE'S A PROSTAFF P3 The all-new PROSTAFF P3 riflescope series was designed to deliver Nikon's legendary optical performance and mechanical consistency over a lifetime of tough hunting use. Built on an a new aluminum platform for enhanced durability and modern looks, PROSTAFF P3 models feature a one-inch main body tube and a 3x zoom ratio. The versatile magnification range results in an ideal balance of compact size, wide field of view at the low end and increased detail at the high end. The PROSTAFF P3 lineup also encompasses a full range of specialty scopes, including models for predator hunting rifles, muzzleloaders, shotguns/slug guns, rimfire target rifles/air guns and crossbows. Spring-Loaded Instant Zero-Reset Turrets Precise, positive-click ¼-MOA reticle adjustments to get you zeroed quickly and maintain your setting, even with heavy recoil. Aluminum Turret Caps PROSTAFF P3 features aluminum construction for enhanced durability. Turret caps, zoom ring and eyepiece focus share ergonomic knurling design. Adjustable Objective (on 6-18x models) The long range 6-18x40AO models integrate an adjustable objective lens to dial-out parallax from 50-yards to infinity. NEW PROSTAFF P3 16596 2-7x32 Matte 16590 3-9x40 Matte 16591 3-9x40 Matte 16592 3-9x40 Silver 16594 3-9x50 Matte 16595 3-9x50 Matte 16597 4-12x40 Matte 16598 4-12x40 Matte 16599 4-12x40 Matte 16600 6-18x40AO Matte 16601 6-18x40AO Matte RETICLE BDC Nikoplex BDC BDC Nikoplex BDC Nikoplex BDC Mildot BDC Mildot WEIGHT LENGTH EYE RELIEF FOV-FT @ (OZ) (IN) (IN) 100 YDS 14.3 11.5 3.8 - 3.8 44.6 -12.6 15.0 12.4 3.6 - 3.6 33.5 -11.5 15.0 12.4 3.6 - 3.6 33.5 -11.5 15.0 12.4 3.6 - 3.6 33.5 -11.5 17.8 12.5 3.6 - 3.6 33.5 -11.5 17.8 12.5 3.6 - 3.6 33.5 -11.5 15.5 14.1 3.7 - 3.7 23.6 7.9 15.5 14.1 3.7 - 3.7 23.6 7.9 15.5 14.1 3.7 - 3.7 23.6 7.9 17.8 14.6 3.5 - 3.5 15.7 5.2 17.8 14.6 3.5 - 3.5 15.7 5.2 ADJUST GRAD 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA 1/4 MOA MAX INTERNAL TRAVEL PER PARALLAX ADJUST ROTATION (YDS) 90 MOA 12 MOA 100 75 MOA 12 MOA 100 75 MOA 12 MOA 100 75 MOA 12 MOA 100 75 MOA 12 MOA 100 75 MOA 12 MOA 100 55 MOA 12 MOA 100 55 MOA 12 MOA 100 55 MOA 12 MOA 100 35 MOA 12 MOA 50 - 35 MOA 12 MOA 50 - FULLY MULTICOATED OPTICS GENEROUS, CONSISTENT EYE RELIEF 3x ZOOM RATIO WATERPROOF SHOCKPROOF 7 NITROGEN PURGED ONE-INCH TUBE INTERCHANGEABLE TURRET QUICK FOCUS EYEPIECE SPRING-LOADED INSTANT ZERO-RESET TURRETS MILDOT BDC NIKOPLEX PROSTAFF P3 Reticles The new PROSTAFF P3 line offers models with the popular BDC, Mildot or Nikoplex reticles. The Mildot reticle features 1 Mil dot spacing on the crosshair for ranging. All Nikon reticles can be optimized for any caliber or load with Spot On Ballistic Technology at NikonSportOptics.ca/SpotOn 11 LIFETIME REPAIR/REPLACEMENT 12 NEW SERIOUS ABOUT PREDATORS Designed for the dedicated predator hunter who values optical performance, ruggedness and purpose-specific reticle technology in pursuit of their prey. The new PROSTAFF P3 PREDATOR HUNTER is available in both 3-9x40 and 4-12x40 models and features Nikon's proprietary BDC Predator reticledesigned to facilitate shots at fast-moving targets. Each of the models shares all of the other performance attributes of the PROSTAFF P3 family. WATERPROOF SHOCKPROOF 7 NITROGEN PURGED ONE-INCH TUBE INTERCHANGEABLE TURRET QUICK FOCUS EYEPIECE SPRING-LOADED INSTANT ZERO-RESET TURRETS FULLY MULTICOATED OPTICS GENEROUS, CONSISTENT EYE RELIEF 3x ZOOM RATIO NEW Spring-Loaded Instant Zero-Reset Turrets Precise, positive-click ¼-MOA reticle adjustments to get you zeroed quickly and maintain your setting, even with heavy recoil. Aluminum Turret Caps PROSTAFF P3 Predator Hunter features aluminum construction for enhanced durability. Turret caps, zoom ring and eyepiece focus share ergonomic knurling design. NEW PROSTAFF P3 PREDATOR HUNTER 16609 3-9x40 Matte 16610 4-12x40 Matte Optional sunshade is available RETICLE BDC PREDATOR WEIGHT LENGTH EYE RELIEF FOV-FT @ (OZ) (IN) (IN) 100 YDS 15 12.4 3.6-3.6 33.5-11.5 ADJUST GRAD 1/4 MOA BDC PREDATOR 15.5 14.1 3.7-3.7 23.6-7.9 1/4 MOA MAX INTERNAL TRAVEL PER ADJUST ROTATION 75 MOA 12 MOA 55 MOA 12 MOA PARALLAX (YDS) 100 100 BDC PREDATOR Nikon's BDC Predator Reticle. This proprietary predator hunting reticle is designed to facilitate shots at moving targets. Featuring "stepped" ballistic open-design circles, the Predator reticle doesn't obscure the sight picture and makes shots at distant or smaller targets easier. Can be optimized with Spot On Ballistic Match Technology for various calibers and loads. 13 THE RIGHT TOOL FOR LONG-RANGE MUZZLELOADING Nikon's new purpose-built muzzleloader scope sports a new name, and new performance and durability features. Bright, fully multicoated optics ensure high light transmission while crisp, positiveclick 1/4-MOA low-profile turrets and Nikon's proven BDC 300 reticle are designed specifically for use with inline type muzzleloaders. NEW FULLY MULTICOATED OPTICS GENEROUS, CONSISTENT EYE RELIEF 3x ZOOM RATIO WATERPROOF SHOCKPROOF 7 NITROGEN PURGED ONE-INCH TUBE INTERCHANGEABLE TURRET LIFETIME REPAIR/REPLACEMENT NEW PROSTAFF P3 MUZZLELOADER WEIGHT LENGTH EYE RELIEF FOV-FT @ RETICLE (OZ) (IN) (IN) 100 YDS 16603 3-9x40 Matte BDC 300 15.2 11.4 3.6-3.6 25.1-8.4 16604 3-9x40 Silver BDC 300 15.2 11.4 3.6-3.6 25.1-8.4 16612 3-9x40 TrueTimber® KANATI BDC 300 15.2 11.4 3.6-3.6 25.1-8.4 Optional matte and silver sunshades are available ADJUST GRAD 1/4 MOA 1/4 MOA 1/4 MOA MAX INTERNAL TRAVEL PER PARALLAX ADJUST ROTATION (YDS) 55 MOA 12 MOA 100 55 MOA 12 MOA 100 55 MOA 12 MOA 100 14 Spring-Loaded Instant Zero-Reset Turrets Precise, positive-click ¼-MOA reticle adjustments to get you zeroed quickly and maintain your setting, even with heavy recoil. Aluminum Turret Caps PROSTAFF P3 Muzzleloader features aluminum construction for enhanced durability. Turret caps, zoom ring and eyepiece focus share ergonomic knurling design. QUICK FOCUS EYEPIECE SPRING-LOADED INSTANT ZERO-RESET TURRETS BDC 300 MUZZLELOADER Nikon's BDC 300 Reticle This trajectory-compensating reticle integrates unique, easyto-see "ballistic circles" that provide instant aiming points and take the guesswork out of holdover at longer ranges. Optimized for use with Nikon's Spot On Ballistic Match Technology, the BDC 300 allows you to get exact aiming points at various yardages with virtually any load imaginable. BDC 200 SHOTGUN Nikon's BDC 200 Reticle The trajectory-compensating BDC 200 slug gun reticle integrates unique, easy-to-see "ballistic circles" that provide instant aiming points and take the guesswork out of holdover at longer ranges. Optimized for use with Nikon's Spot On Ballistic Match Technology, the BDC 200 provides exact aiming points at various yardages with virtually any load imaginable. FULLY MULTICOATED OPTICS GENEROUS, CONSISTENT EYE RELIEF 3x ZOOM RATIO WATERPROOF SHOCKPROOF 7 NITROGEN PURGED ONE-INCH TUBE NEW TAKE YOUR SLUG GUN LONGER RANGE The new PROSTAFF P3 SHOTGUN scope line helps extend the effective range of your slug gun to 200 yards and beyond. An ideal match for today's powerful slug loads, these compact and versatile optics feature Nikon's BDC 200 reticle, precise 1/4 MOA adjustments with Spring-Loaded Instant Zero-Reset Turrets and fully multicoated optics for maximum light transmission. Offered in two configurations: 2-7x32 and 3-9x40, both with the BDC 200 reticle. INTERCHANGEABLE TURRET Spring-Loaded Instant Zero-Reset Turrets Precise, positive-click ¼-MOA reticle adjustments to get you zeroed quickly and maintain your setting, even with heavy recoil. Aluminum Turret Caps PROSTAFF P3 Shotgun features aluminum construction for enhanced durability. Turret caps, zoom ring and eyepiece focus share ergonomic knurling design. QUICK FOCUS EYEPIECE SPRING-LOADED INSTANT ZERO-RESET TURRETS LIFETIME REPAIR/REPLACEMENT NEW WEIGHT LENGTH EYE RELIEF FOV-FT @ PROSTAFF P3 SHOTGUN RETICLE (OZ) (IN) (IN) 100 YDS 16607 2-7x32 Matte BDC 200 14.3 11.5 3.8-3.8 44.6-12.6 ADJUST GRAD 1/4 MOA MAX INTERNAL TRAVEL PER PARALLAX ADJUST ROTATION (YDS) 90 MOA 12 MOA 100 16602 3-9x40 Matte BDC 200 15.2 11.4 5-5 25.1-8.4 1/4 MOA 55 MOA 12 MOA 100 Optional sunshade available for 3-9x40 model. 15 THE RIGHT CHOICE FOR YOUR NEXT HUNT Nikon's BUCKMASTERS II riflescope is designed for deer hunters across North America. Fully multicoated lenses and Nikon's favored BDC reticle provide highresolution images during the peak deer movement windows of dawn and dusk. From the humid swamps of the South to the blistering cold wilderness of Canada, the BUCKMASTERS II will continue to be a preferred scope for deer hunters. FULLY MULTICOATED OPTICS GENEROUS, CONSISTENT EYE RELIEF 3x ZOOM RATIO Spring-Loaded Instant Zero-Reset Turrets Engraved for maximum readability and internals provide precise, repeatable corrections while zeroing. BUCKMASTERS II 16338 3-9x40 Matte 16339 4-12x40 Matte 16419 3-9x50 Matte TRAVEL PER WEIGHT LENGTH FOV-FT @ ADJUST GRAD MAX INTERNAL ROTATION PARALLAX RETICLE (OZ) (IN) EYE RELIEF (IN) 100 YDS @ 100 YDS ADJUST @ 100 YDS (YDS) BDC 13.1 12.3 3.6-3.6 33.8-11.3 1/4 inch 80 MOA 12" 100 BDC 13.6 14 3.7-3.7 23.6-7.9 1/4 inch 60 MOA 12" 100 BDC 15.9 12.4 3.6-3.6 33.8-11.3 1/4 inch 80 MOA 12" 100 16 WATERPROOF SHOCKPROOF 7 NITROGEN PURGED ONE-INCH TUBE INTERCHANGEABLE TURRET SPRING-LOADED INSTANT ZERO-RESET TURRETS LIFETIME REPAIR/REPLACEMENT FULLY MULTICOATED OPTICS GENEROUS, CONSISTENT EYE RELIEF 3x ZOOM RATIO WATERPROOF SHOCKPROOF 7 NITROGEN PURGED ONE-INCH TUBE INTERCHANGEABLE TURRET QUICK FOCUS EYEPIECE SPRING-LOADED INSTANT ZERO-RESET TURRETS EXTENDED EYE RELIEF HANDGUN SCOPES Nikon has become the master of creating specific reticle technologies and optical platforms for the needs of the hunter. FORCE XR extended eye relief handgun scopes are no exception. Engineered with the option of Nikon's unique BDC Handgun reticle, the FORCE XR can be optimized with Nikon's Spot On Ballistic Match Technology to take the guesswork out of compensating for bullet drop of your favorite handgun cartridge and load. BDC HANDGUN BDC BDC 60 CROSSBOW The BDC reticle allows hunters to hold `deadon' at ranges exceeding those previously thought possible. The BDC's unique seethrough ballistic circles offer an incredible advantage for long-range shooting, yet allow a normal sight picture for shorter-range shots where the crosshair itself is the aiming point. WATERPROOF FULLY MULTICOATED OPTICS GENEROUS, CONSISTENT EYE RELIEF SHOCKPROOF 7 NITROGEN PURGED ONE-INCH TUBE INTERCHANGEABLE TURRET SPRING-LOADED INSTANT ZERO-RESET TURRETS PRECISION OPTIC FOR CROSSBOW HUNTERS The new PROSTAFF P3 CROSSBOW is the ideal choice for hunters looking to upgrade the optic on their crossbows this season. Signature Nikon optical performance coupled with a proprietary BDC reticle designed specifically to maximize the range and efficiency of today's hunting crossbows. FORCE XR 8468 2.5-8x28 EER Matte RETICLE BDC Handgun WEIGHT LENGTH FOV-FT @ (OZ) (IN) EYE RELIEF (IN) 100 YDS 14.5 9.8 12-30 (at 2.5x) 9-13 (at 8x) 13.1-4.1 TRAVEL PER ADJUST GRAD MAX INTERNAL ROTATION PARALLAX @ 100 YDS ADJUST @ 100 YDS (YDS) 1/4 inch 40 MOA 12" 100 WEIGHT LENGTH FOV-FT @ NEW PROSTAFF P3 CROSSBOW RETICLE (OZ) (IN) EYE RELIEF (IN) 100 YDS 16608 3x32 Matte BDC 60 10.9 8.2 3.4 35.6 ADJUST GRAD 1 MOA MAX INTERNAL TRAVEL PER PARALLAX ADJUST ROTATION (YDS) 130 MOA 48 MOA 20 LIFETIME REPAIR/REPLACEMENT 17 A RIMFIRE RIFLESCOPE MODEL FOR EVERY USE Nikon's RIMFIRE riflescope series has a scope model for virtually any rimfire rifle. The P-TACTICAL RIMFIRE riflescope offers a 2-7x32 optical system and choice of either a hash mark MK1-MOA or caliber-designated BDC 150 Reticle. The fully multicoated optical system of the PROSTAFF RIMFIRE II delivers naildriving precision to rimfire long rifles. PROSTAFF P3 Target EFR with Adjustable Objective is well suited for either rimfire or air rifles. Every RIMFIRE model will extract optimal accuracy from rimfire rifles, especially when used with Spot On Ballistic Match Technology. LIFETIME REPAIR/REPLACEMENT FULLY MULTICOATED OPTICS GENEROUS, CONSISTENT EYE RELIEF 3x ZOOM RATIO WATERPROOF SHOCKPROOF 7 NITROGEN PURGED P-TACTICAL RIMFIRE 16528 2-7x32 Matte 16529 2-7x32 Matte 18 WEIGHT LENGTH EYE RELIEF FOV-FT @ RETICLE (OZ) (IN) (IN) 100 YDS MK1-MOA 16.2 11.5 3.8-3.8 44.6-12.6 BDC 150 16.2 11.5 3.8-3.8 44.6-12.6 ADJUST GRAD 1/4 MOA 1/4 MOA MAX INTERNAL TRAVEL PER ADJUST ROTATION 90 MOA 20 MOA 90 MOA 20 MOA PARALLAX (YDS) 50 50 ONE-INCH TUBE INTERCHANGEABLE TURRET QUICK FOCUS EYEPIECE SPRING-LOADED INSTANT ZERO-RESET TURRETS BDC 150 RIMFIRE MK1-MOA The P-TACTICAL RIMFIRE scope offers models with the newly designed MK1MOA reticle, as well as the caliber-designated BDC 150 (see next page for RIMFIRE II & EFR). The MK1-MOA reticle can be used to estimate range, target size, elevation holder and wind-drift at designated magnification. FULLY MULTICOATED OPTICS GENEROUS, CONSISTENT EYE RELIEF 3x ZOOM RATIO WATERPROOF SHOCKPROOF 7 NITROGEN PURGED ONE-INCH TUBE INTERCHANGEABLE TURRET SPRING-LOADED INSTANT ZERO-RESET TURRETS BDC 150 RIMFIRE Designed specifically for rimfire, the BDC 150 reticle allows shooters to compensate for bullet drop at extended shooting distances. The BDC's unique see-through ballistic circles offer an incredible advantage for long-range shooting--yet allow a normal sight picture for shorter-range shots where the crosshair itself is the aiming point. WATERPROOF SHOCKPROOF 7 NITROGEN PURGED NEW ONE-INCH TUBE FULLY MULTICOATED OPTICS INTERCHANGEABLE TURRET GENEROUS, CONSISTENT EYE RELIEF QUICK FOCUS EYEPIECE 3x ZOOM RATIO SPRING-LOADED INSTANT ZERO-RESET TURRETS PROSTAFF RIMFIRE II 16329 3-9x40 Matte 16330 4-12x40 Matte RETICLE BDC 150 TRAVEL PER WEIGHT LENGTH EYE RELIEF FOV-FT @ ADJUST GRAD MAX INTERNAL ROTATION (OZ) (IN) (IN) 100 YDS @ 100 YDS ADJUST @ 100 YDS 13.1 12.3 3.6-3.6 33.8-11.3 1/4-INCH 80 MOA 12" PARALLAX (YDS) 50 BDC 150 13.6 14 3.7-3.7 23.6-7.9 1/4-INCH 60 MOA 12" 75 NEW PROSTAFF P3 TARGET EFR TRAVEL PER WEIGHT LENGTH EYE RELIEF FOV-FT @ ADJUST GRAD MAX INTERNAL ROTATION RETICLE (OZ) (IN) (IN) 100 YDS @ 100 YDS ADJUST @ 100 YDS 16606 3-9x40 AO Matte PRECISION 16.6 12.5 3.6-3.6 33.5-11.5 1/4 MOA 75 MOA 12 MOA Optional sunshade is available PARALLAX (YDS) 10 - PRECISION LIFETIME REPAIR/REPLACEMENT PURPOSE-DRIVEN ENGINEERING The new PROSTAFF P3 TARGET EFR is engineered for air rifle, 22 LR and other applications where the versatility of focusing on smaller targets at extended ranges--both close and distant-- is needed. To facilitate this sharp focus at closer ranges, the PROSTAFF P3 TARGET EFR integrates an adjustable objective lens that allows the shooter to dial out parallax at any distance from 10 yards to infinity. 19 LIFETIME REPAIR/REPLACEMENT 20 COMPETITION READY OPTICS Once again, Nikon continues to bring elevated performance and relevance to our flagship BLACK tactical optics line with the introduction of the new BLACK FORCE100 action-target optic. 21 LIFETIME REPAIR/REPLACEMENT 22 Match Grade FFP Optic Engineered to deliver your longest shots with confident precision, the BLACK FX1000 is set to raise eyebrows and expectations among long-range shooters. Competition-ready straight from the box, BLACK FX1000 integrates renowned Nikon optics into its first focal plane optical system for tack-sharp images and dialing functionality at any magnification and distance. Proprietary glass-etched tactical reticles paired with precise, high-speed turrets allow fast, repeatable distance corrections and intuitive hold-off points. The BLACK FX1000 also boasts Nikon's BLACK Return-to-Zero integral zero-stop in the elevation turret. Sunshade included. 8 6 4 2 8 6 4 2 2 4 6 8 2 4 6 8 30 20 10 30 20 10 10 20 30 10 20 30 FX-MRAD FX-MOA FX-MRAD and FX-MOA RETICLES Nikon's FX series glass-etched reticles present the shooter with highly functional and advanced tools designed with all aspects of long-range shooting in mind, including estimating range, maintaining holdovers, dialing elevation come ups, and also for compensating for wind and moving target leads. An advantage of using the FX series reticle is that it can be applied to virtually any shooting application regardless of caliber or ballistic performance, and when paired with the BLACK FX1000 riflescope and its precise MOA or MRAD adjustments, provides shooters with the tools necessary for long-range shooting precision. The BLACK FX1000 has the FX-MRAD or FX-MOA reticle placed in the riflescope's first focal plane, so holdover corrections, ranging and other measurements using the indicated reticle subtensions can be done at any magnification. Integral Zero Stop BLACK FX1000 features a return-tozero stop for rapid return to zero. High-Speed Windage and Elevation Turrets Exposed turrets engraved for maximum readability while offering smooth, repeatable adjustments. Directional indicators are clearly marked on windage and elevation turrets. 10-Level Rheostat Illuminated reticle models with side-mounted control offer 10 intensity levels of red illumination with OFF switch between each step for quick, easy brightness adjustments. GLASS FIRST. 23 LIFETIME REPAIR/REPLACEMENT 24 FULLY MULTICOATED OPTICS GLASS-ETCHED RETICLE GENEROUS, CONSISTENT EYE RELIEF 4x ZOOM RATIO BLACK FX1000 WEIGHT LENGTH EYE RELIEF FOV-FT @ ADJUST MAX INTERNAL TRAVEL PER PARALLAX ILL RETICLE (OZ) (IN) (IN) 100 YDS GRAD ADJUST ROTATION (YDS) 16511 4-16x50SF Matte FX-MOA 23.3 14.8 4-3.6 27.2-6.8 1/4 MOA 90 MOA 25 MOA 50-INFINITY 16512 4-16x50SF Matte FX-MRAD 23.3 14.8 16513 4-16x50SF Matte FX-MOA 23.8 14.8 16514 4-16x50SF Matte FX-MRAD 23.8 14.8 16515 6-24x50SF Matte FX-MOA 24.5 15.2 16516 6-24x50SF Matte FX-MRAD 24.5 15.2 4-3.6 4-3.6 4-3.6 4-3.5 4-3.5 27.2-6.8 0.1 MRAD 25 MRAD 27.2-6.8 1/4 MOA 90 MOA 27.2-6.8 0.1 MRAD 25 MRAD 18.0-4.7 1/4 MOA 60 MOA 18.0-4.7 0.1 MRAD 17 MRAD 10 MRAD 50-INFINITY 25 MOA 50-INFINITY 10 MRAD 50-INFINITY 25 MOA 50-INFINITY 10 MRAD 50-INFINITY BLACK Precision Mounts (30mm) 16404 BLACK Precision 1-piece (MSR) 16406 BLACK Precision 1- piece (Medium) BLACK Cantilever Mounts (30mm) 16403 BLACK Cantilever 16405 BLACK Cantilever (20 MOA Cant) WATERPROOF SHOCKPROOF 7 NITROGEN PURGED 30mm MAIN BODY TUBE INTERCHANGEABLE TURRET QUICK FOCUS EYEPIECE RETURN-TO-ZERO STOP SIDE FOCUS PARALLAX ADJUSTMENT 30 20 10 30 20 10 10 20 30 10 20 30 8 6 4 2 8 6 4 2 2 4 6 8 2 4 6 8 FX-MOA ILLUMINATION SHOWN FX-MRAD Precision & Cantilever 30mm Mounts Available See page 68-69 for more information 25 LIFETIME REPAIR/REPLACEMENT 26 FOCUSED ON PRECISION Enhanced optical performance, extreme durability and confidence-building mechanical precision are core values used to develop the BLACK X1000 precision long-range riflescope. Featuring tactical-style reticles, BLACK X1000 presents the shooter with highly functional and advanced tools for estimating range or maintaining holdovers. Sunshade included. FULLY MULTICOATED OPTICS GLASS-ETCHED RETICLE GENEROUS, CONSISTENT EYE RELIEF 4x ZOOM RATIO 10-Level Rheostat Illuminated reticle models with side-mounted control offer 10 intensity levels of red illumination with OFF switch between each step for quick, easy brightness adjustments. Precision Windage and Elevation Turrets Exposed turrets engraved for maximum readability while offering smooth, repeatable adjustments. Directional indicators are clearly marked on top of windage and elevation turrets. BLACK X1000 WEIGHT LENGTH EYE RELIEF FOV-FT @ ADJUST MAX INTERNAL TRAVEL PER PARALLAX ILL RETICLE (OZ) (IN) (IN) 100 YDS GRAD ADJUST ROTATION (YDS) 16381 4-16x50SF Matte X-MOA 23.8 14.8 4-3.6 27.2-6.8 1/4 MOA 90 MOA 12 MOA 50-INFINITY 16382 4-16x50SF Matte X-MOA 24.3 14.8 4-3.6 27.2-6.8 1/4 MOA 90 MOA 12 MOA 50-INFINITY 16383 4-16x50SF Matte X-MRAD 24.3 14.8 4-3.6 27.2-6.8 0.1 MRAD 25 MRAD 5 MRAD 50-INFINITY 16423 6-24x50SF Matte X-MOA 25 15.2 4-3.5 18.0-4.5 1/4 MOA 60 MOA 12 MOA 50-INFINITY 16384 6-24x50SF Matte X-MRAD 25 15.2 4-3.5 18.0-4.5 0.1 MRAD 17 MRAD 5 MRAD 50-INFINITY BLACK Precision Mounts (30mm) 16404 BLACK Precision 1-piece (MSR) 16406 BLACK Precision 1- piece (Medium) BLACK Cantilever Mounts (30mm) 16403 BLACK Cantilever 16405 BLACK Cantilever (20 MOA Cant) WATERPROOF SHOCKPROOF 7 NITROGEN PURGED 30mm MAIN BODY TUBE INTERCHANGEABLE TURRET QUICK FOCUS EYEPIECE SIDE FOCUS PARALLAX ADJUSTMENT SPRING-LOADED INSTANT ZERO-RESET TURRETS X-MRAD ILLUMINATION SHOWN X-MOA BLACK X-MOA and X-MRAD Reticles Nikon's X-MOA and X-MRAD reticles present the shooter with clean and visually simple, yet highly functional and advanced tools for estimating range, maintaining holdovers or dialing elevation come ups and compensating for wind. Precision & Cantilever 30mm Mounts Available See page 68-69 for more information 27 LIFETIME REPAIR/REPLACEMENT 28 NEW MORE POWER. MORE VERSATILITY. A true "next level" optic, whether called upon for close-quarters engagements or targets at extended ranges, the new BLACK FORCE100 1-6x24 brings a broader range of magnifications, new reticle design and increased ergonomics to your MSR platform. Through Nikon's Glass First engineering principal, the true 1x to 6x optical system of the BLACK FORCE100 was created to facilitate distortion-free targeting with both eyes open at 1x, and aiming precision for extended ranges when cranked up to 6x. An all-new FORCE-MOA reticle combines speed with precision through its illuminated center red dot that draws your eye toward the center and MOA-based hash mark design for extended range holdovers or hold-offs for wind. Low profile, capped turrets and one-piece 30mm main body tube assure extreme durability and sighting confidence under tough conditions. FULLY MULTICOATED OPTICS WIDE FIELD OF VIEW GLASS-ETCHED RETICLE GENEROUS, CONSISTENT EYE RELIEF 1x MAGNIFICATION 6x ZOOM RATIO Side-Mounted Illumination Control Illuminated reticle with side-mounted control offers 10 intensity levels of red illumination with OFF switch between each step for quick, easy brightness adjustments. Auto shutoff after two hours of non-operation. Low Profile Capped Turrets The BLACK FORCE100 riflescope features low profile, ¼-MOA turrets protected by sturdy aluminum caps. NEW BLACK FORCE100 16660 1-6x24 Matte WEIGHT LENGTH EYE RELIEF FOV-FT @ ADJUST MAX INTERNAL TRAVEL PER PARALLAX ILL RETICLE (OZ) (IN) (IN) 100 YDS GRAD ADJUST ROTATION (YDS) FORCE-MOA 20.8 11.6 3.8-3.7 111.2-18.3 1/4 MOA 100 MOA 25 MOA 100 BLACK Cantilever Mounts (30mm) 16403 BLACK Cantilever 16405 BLACK Cantilever (20 MOA Cant) BLACK Precision Mounts (30mm) 16404 BLACK Precision 1-piece (MSR) 16406 BLACK Precision 1- piece (Medium) WATERPROOF SHOCKPROOF 18 ARGON PURGED 30mm MAIN BODY TUBE ONE-PIECE MAIN BODY TUBE QUICK FOCUS EYEPIECE 12 8 8 12 12 8 8 12 8 12 16 20 24 8 12 16 20 24 FORCE-MOA ILLUMINATION SHOWN FORCE-MOA Reticle The FORCE-MOA is a multi-function, glass-etched reticle designed to enable continuous momentum shooting from target to target, and thus excel in closeto-medium range engagements. When the riflescope is set at its lowest 1x magnification, the reticle's illuminated center dot serves as a quick reference for centering on the target with both eyes open, similar to a red dot sight. At 6x, the reticle's lower hash marks provide hold-offs for wind and holdover points for longer known ranges as determined through the calculations of your ballistic table or app. Precision & Cantilever 30mm Mounts Available See page 68-69 for more information 29 LIFETIME REPAIR/REPLACEMENT 30 Accelerated Precision Nikon's BLACK FORCE1000 riflescope delivers extreme targeting speed, repeatable precision and superior accuracy for your MSR platform. Designed for both-eyes-open engagement as well as aiming precision for extended ranges, this compact optic's rugged construction and metal-capped turrets assure extreme durability and sighting confidence under tough conditions. FULLY MULTICOATED OPTICS WIDE FIELD OF VIEW GLASS ETCHED RETICLE GENEROUS, CONSISTENT EYE RELIEF 1x MAGNIFICATION 4x ZOOM RATIO Side-Mounted Illumination Control Illuminated reticle with side-mounted control offers 10 intensity levels of red illumination with OFF switch between each step for quick, easy brightness adjustments. Auto shutoff after two hours of non-operation. Capped Windage & Elevation Turrets The BLACK FORCE1000 riflescope features elevated ½-MOA turrets protected by sturdy aluminum caps. BLACK FORCE1000 16380 1-4x24 Matte WEIGHT LENGTH EYE RELIEF FOV-FT @ ILL RETICLE (OZ) (IN) (IN) 100 YDS SPEEDFORCE 16.4 10.5 4.1-3.8 110.1-27.2 ADJUST GRAD 1/2 MOA MAX INTERNAL TRAVEL PER PARALLAX ADJUST ROTATION (YDS) 350 MOA 24 MOA 100 BLACK Cantilever Mounts (30mm) 16403 BLACK Cantilever 16405 BLACK Cantilever (20 MOA Cant) BLACK Precision Mounts (30mm) 16404 BLACK Precision 1-piece (MSR) 16406 BLACK Precision 1- piece (Medium) WATERPROOF SHOCKPROOF 7 NITROGEN PURGED 30mm MAIN BODY TUBE INTERCHANGEABLE TURRET QUICK FOCUS EYEPIECE SPRING-LOADED INSTANT ZERO-RESET TURRETS SPEEDFORCE Reticle The SPEEDFORCE reticle was designed for both reaction-speed target acquisition and engagement, and for intermediate-range target holdovers using BDC circles and hash marks. The SPEEDFORCE is an MOA subtension reticle engineered to enable you to continue momentum from target to target and thus, excel in close-to-medium range engagements both in competition and field use. When the riflescope is set at its lowest 1x magnification, the reticle's illuminated double horseshoe serves as quick reference for centering on the target with both eyes open, as well as for establishing movingtarget leads. SPEEDFORCE ILLUMINATION SHOWN Precision & Cantilever 30mm Mounts Available See page 68-69 for more information 31 LIFETIME REPAIR/REPLACEMENT 32 Bigger, Bolder Performance M-TACTICAL riflescopes are the result of Nikon's proprietary optical design, superior glass, innovative materials and over 100 years of optics ingenuity. The signature glass and multicoating technology used in these optics prioritizes bright, high contrast sight picturesand those views are complemented by purpose-driven reticles designed for long range. Highly innovative and intuitive MK1-MOA and MK1-MRAD tactical reticles with matched turrets are the ticket for dialing-in your longest shot with speed and precision. When platform-focused ballistic technology is desired, the M-TACTICAL lineup's caliber-designated reticles and Spot On ballistics are engineered to put the most challenging distances within reach. All long-range M-TACTICAL models feature side-focus parallax adjustments, while the full range of models feature directional indicators on turrets, 4x zoom ratio and utilize robust 30mm main body tubes drawn from aircraft-grade aluminum alloy. Turrets and zoom rings have knurling that is ergonomically designed for comfortable function with virtually any finger size. Each M-TACTICAL riflescope is finished with ultra-matte anodizing for extreme durability and reliability during a lifetime of real world performance. FULLY MULTICOATED OPTICS WIDE FIELD OF VIEW GENEROUS, CONSISTENT EYE RELIEF 1x MAGNIFICATION (1-4x24 Model) 4x ZOOM RATIO Exposed Turrets with Coarse Knurling Feature positive-click reticle adjustments to get you zeroed in quick and maintain your setting, even with heavy recoil. Directional indicators are clearly marked on windage and elevation turrets. M-TACTICAL 16521 1-4x24 Matte WEIGHT LENGTH EYE RELIEF FOV @ ADJUST MAX INTERNAL TRAVEL PER RETICLE (OZ) (IN) (IN) 100 YDS GRAD ADJUST ROTATION MK1-MOA 16.4 10.4 3.8-3.7 118.8-29.9 1/2 MOA 220 MOA 40 MOA PARALLAX (YDS) 100 16519 3-12x42SF Matte MK1-MOA 20.5 13.1 3.9-3.6 37.2-9.4 1/4 MOA 75 MOA 20 MOA 50-INFINITY 16520 3-12x42SF Matte MK1-MRAD 20.5 13.1 3.9-3.6 37.2-9.4 0.1 MRAD 15 MRAD 8 MRAD 50-INFINITY M-TACTICAL .308 16517 4-16x42SF Matte BDC 800 20.6 13.6 3.9-3.6 27.8-6.8 1/4 MOA 55 MOA 20 MOA 50-INFINITY M-TACTICAL .223 16518 4-16x42SF Matte BDC 600 20.6 13.6 3.9-3.6 27.8-6.8 1/4 MOA For M-TACTICAL Mounts, see page 68-69. 55 MOA 20 MOA 50-INFINITY WATERPROOF SHOCKPROOF 7 NITROGEN PURGED 30mm MAIN BODY TUBE INTERCHANGEABLE TURRET QUICK FOCUS EYEPIECE SIDE FOCUS PARALLAX ADJUSTMENT (Except 1-4x24 Model) SPRING-LOADED INSTANT ZERO-RESET TURRETS M-TACTICAL Reticles The M-TACTICAL line offers models with the newly designed MK1-MOA and MK1-MRAD reticles, as well as the platform-based, caliber-designated BDC 600 and BDC 800. The MK1MOA/MK1-MRAD reticles can be used to estimate range, target size, elevation holdover and wind-drift at the designated magnification. The asymmetrical design allows for additional holdover for extreme distances. All Nikon reticles can be optimized for any caliber or load with Spot On Ballistic Technology at NikonSportOptics.ca/ SpotOn. MK1-MRAD BDC 600 .223 MK1-MOA BDC 800 .308 33 LIFETIME REPAIR/REPLACEMENT 34 DEFINE Your Shooting Experience Nikon's P-TACTICAL riflescopes provide the features you need to maximize your shooting experience--regardless of the platform you mount it on. Fully multicoated optical systems housed in rugged, one-inch, aircraft-grade aluminum main tubes brighten even the most dismal environments and unforgiving conditions. The versatile 3x zoom ratio (on variable models) provides the field of view at the low end and the detail at the high end to satisfy most shooting demands. If you're a long-distance dialer, P-TACTICAL's hash-marked MK1MOA or MK1-MRAD reticles are matched to ergonomic turrets with directional indicators to make every come-up--or down--both simple and intuitive. The MK1-MOA reticle is also available in P-TACTICAL Rimfire, for stretching the legs of any rimfire platform. Dedicated caliber models--including rimfire--match the reticle to your preferred caliber, and when used in conjunction with Nikon's free Spot On Ballistic Technology offer exact holdover points for any long-range engagement. FULLY MULTICOATED OPTICS GENEROUS, CONSISTENT EYE RELIEF 3x ZOOM RATIO WATERPROOF SHOCKPROOF 7 NITROGEN PURGED ONE-INCH TUBE INTERCHANGEABLE TURRET QUICK FOCUS EYEPIECE SPRING-LOADED INSTANT ZERO-RESET TURRETS Exposed Turrets with Coarse Knurling Feature positive-click reticle adjustments to get you zeroed in quick and maintain your setting, even with heavy recoil. Directional indicators are clearly marked on windage and elevation turrets. P-TACTICAL Reticles The P-TACTICAL line offers models with the newly designed MK1-MOA and MK1-MRAD reticles, as well as the platform-based, caliber-designated BDC 150, BDC 600, BDC 800, BDC SUPERSUB and BDC CARBINE. The MK1-MOA and MK1-MRAD can be used to estimate range, target size, elevation holdover and winddrift at the designated magnification. An asymmetrical design allows for additional holdover for extreme distance shooting. All Nikon reticles can be optimized for any caliber or load with Spot On Ballistic Technology at NikonSportOptics.ca/SpotOn. P-TACTICAL 16530 3-9x40 Matte 16531 3-9x40 Matte RETICLE MK1-MOA WEIGHT LENGTH EYE RELIEF FOV @ (OZ) (IN) (IN) 100 YDS 16.9 12.4 3.6-3.6 33.5-11.5 ADJUST GRAD 1/4 MOA MAX INTERNAL TRAVEL PER ADJUST ROTATION 75 MOA 20 MOA MK1-MRAD 16.9 12.4 3.6-3.6 33.5-11.5 0.1 MRAD 20 MRAD 8 MRAD P-TACTICAL .308 16523 4-12x40 Matte BDC 800 17.5 14.1 3.7-3.7 23.6-7.9 1/4 MOA 55 MOA 20 MOA P-TACTICAL 300BLK 16522 2-7x32 Matte BDC SUPERSUB 16.2 11.5 3.8 44.6-12.6 1/4 MOA 90 MOA P-TACTICAL .223 16527 1.5-4.5x20 Matte BDC 600 14.8 10.2 3.5-3.5 63.1-20.4 1/4 MOA 150 MOA 16526 3x32 Matte BDC CARBINE 12.7 8.2 3.4 35.6 1/4 MOA 130 MOA 16525 3-9x40 Matte BDC 600 16.9 12.4 3.6-3.6 33.5-11.5 1/4 MOA 75 MOA 16524 4-12x40 Matte BDC 600 17.5 14.1 3.7-3.7 23.6-7.9 1/4 MOA 55 MOA 20 MOA 20 MOA 20 MOA 20 MOA 20 MOA P-TACTICAL RIMFIRE 16528 2-7x32 Matte MK1-MOA 16.2 11.5 3.8-3.8 44.6-12.6 1/4 MOA 16529 2-7x32 Matte BDC 150 16.2 11.5 3.8-3.8 44.6-12.6 1/4 MOA For P-TACTICAL Mounts, see page 68-69 90 MOA 90 MOA 20 MOA 20 MOA PARALLAX (YDS) 100 100 100 100 100 100 100 100 50 50 MK1-MRAD BDC 800 .308 MK1-MOA BDC CARBINE .223 BDC 150 RIMFIRE BDC SUPERSUB 300BLK BDC 600 .223 35 Rugged and Reliable--THE RIGHT OPTIC for Every Gun The P-TACTICAL SPUR and SUPERDOT each provide incredible image clarity, a crisp red sighting dot and the compact, lightweight specification needed for fast point-and-shoot action. Engineered for extreme durability and reliability regardless of platform, SPUR's lightweight aluminum alloy chassis is shockproof, waterproof and has a night vision compatible 3 MOA dot that boasts 15,000 hours of continuous use on a single battery. When outdoor conditions are at their worst, SUPERDOT securely houses internal components and night vision compatible 2 MOA dot within a shockproof, waterproof, aircraft-grade aluminum body that shrugs off rain, dirt, snow and mud. Both sights feature Nikon's proprietary TRUCOLOR lens-and-coating technology to provide a lifelike view with both-eyes-open sighting and offer 10 brightness settings, as well as extended battery life. 36 REFLEX SIGHT EXTENDED BATTERY LIFE 5-YEAR WARRANTY 10-LEVELS OF BRIGHTNESS Picatinny Mount Removeable mount included. FULLY MULTICOATED OPTICS WIDE FIELD OF VIEW 1x MAGNIFICATION TRUCOLOR WATERPROOF SHOCKPROOF 7 NITROGEN PURGED NIGHT VISION COMPATIBLE RED DOT SIGHT EXTENDED BATTERY LIFE 5-YEAR WARRANTY 10-LEVELS OF BRIGHTNESS INTEGRAL PICATINNY MOUNT RAISED PROTRUSION Integral Picatinny Mount Includes spacers to provide 1/3 co-witness or full co-witness. P-TACTICAL SPUR SIGHT BRIGHTNESS WINDOW WEIGHT L x W x H RETICLE SETTINGS (WxH) MM (BODY) (OZ) (IN) EYE RELIEF ADJUST. ADJUST. SCREW MAX. INTERNAL ADJUST. TRAVEL PER (IN) DOT SIZE GRAD. PRINT (E/W) ADJUST. MECHANISM ROTATION 16532 MATTE RED DOT 10* 27x16 1.1 1.8x1.1x1 Rear HT 0.4 UNLIMITED 3 MOA 1 MOA 1 MOA 120 MOA FLAT DRIVER 30 MOA *Initial two brightness settings are night vision compatible. PARALLAX (YDS) BRIGHTNESS SIGHT WINDOW WEIGHT L x W x H P-TACTICAL SUPERDOT RETICLE SETTINGS (DIAMETER) MM (BODY) (OZ) (IN) 16510 MATTE RED DOT 10* 22 4.2 2.8x1.7x1.7 EYE RELIEF (IN) UNLIMITED DOT SIZE 2 MOA ADJUST. MAX. INTERNAL ADJUST. TRAVEL PER GRAD. ADJUST. MECHANISM ROTATION 1 MOA 100 MOA FLAT DRIVER** 40 MOA PARALLAX (YDS) *Initial two brightness settings are night vision compatible. **Raised protrusion on knob functions as flat driver for adjustments. FULLY MULTICOATED OPTICS WIDE FIELD OF VIEW 1x MAGNIFICATION TRUCOLOR WATERPROOF SHOCKPROOF 7 NITROGEN PURGED NIGHT VISION COMPATIBLE 37 LONG RANGE JUST GOT LONGER Working out the solution for a crucial shot means you need an accurate range right now, regardless of the distance. Nikon's BLACK RANGEX 4K is engineered to deliver over 2 miles of ranging capability with the speed, precision and consistency you need for extreme long-distance shooting. Featuring Nikon's HYPER READ for extraordinarily fast, positive measurements, the rangefinder's integral monocular offers the bright, sharp view required for target spotting and acquisition. BLACK RANGEX 4K's high-visibility red OLED display provides ideal contrast on distant targets with automatic or five stages of selectable brightness. For incline or decline shooting angles, the BLACK RANGEX 4K is equipped with Nikon's ID Technology that delivers the one number you need for determining your best shot. 38 Tru-Target Technology Enables you to choose between two different ranging modes, depending on the situation. MULTILAYER COATING WIDE FIELD OF VIEW LONG EYE RELIEF First Target Priority Mode Provides the exact distance to the closest object among a group of targets being measured. In this mode, you can easily range an object as small as a fence post. 4,000 YARD MEASUREMENT RANGE Maximum measurement distance* Reflective Target - 4,000 yards Maximum measurement distance* Tree - 1,700 yards Maximum measurement distance* Deer - 1,500 yards 752 yards Horizontal Distance 787 yards Straight Distance WATERPROOF 7 NITROGEN PURGED TRIPOD ADAPTABLE OLED DISPLAY ID TECHNOLOGY HYPER READ TRU TARGET Distant Target Priority Mode Displays the range of the farthest target among a group of targets measured. This feature is especially useful if the subject is located behind tall grass or brush. ID [Incline/Decline] Technology Nikon's advanced ID [Incline/Decline] Technology provides the horizontal distance to the target, even when ranging at various incline or decline shooting angles--up to an incredible +/- 89 degrees [nearly vertical up or down]. BLACK RANGEX 4K 16557 MAG. EYE RELIEF REAL ANGULAR FOV FOV @ 100 MAX RANGE MAX RANGE MAX RANGE WEIGHT (W/O SIZE (LxHxW) OBJ DIA. (MM) (DEGREES) YARDS (FT) (REFLECTIVE)*(YDS) (TREE)*(YDS) (DEER)*(YDS) BATTERIES (OZ) (IN) 6x21 18.0 7.5 39.3 4,000 1,700 1,500 6.3 4.3x2.9x1.6 *Under Nikon's measurement conditions and reference values. The specifications of the product may not be achieved depending on the target object's shape, surface texture and nature, and/or weather conditions. The technology behind the Laser Rangefinder with inclinometer originated from technology incorporated in Nikon's Total Station DTM-1 surveying instrument. The Total Station DTM-1, first sold in 1985, was the first highly advanced electronic model of those surveying instruments that incorporated a distance and angle measuring capability developed by Nikon Corporation. 39 Unshakable is Unbeatable. The MONARCH 3000 STABILIZED is the latest example of Nikon's innovative and award-winning rangefinder technology at work. Designed for single-handed operation, the MONARCH 3000 STABILIZED instantly stabilizes the image you see in the 6x monocular and simultaneously activates HYPER READ for extraordinarily fast, positive measurements. Variable intensity red OLED reticle display provides either automatic or five selectable brightness levels for maximum contrast against most targets and backgrounds. The MONARCH 3000 STABILIZED, equipped with Nikon's ID Technology for incline/decline shooting, will change your perception of rangefinder capability and performance. 40 MULTILAYER COATING WIDE FIELD OF VIEW LONG EYE RELIEF 3,000 YARD MEASUREMENT RANGE Maximum measurement distance* Reflective Target - 3,000 yards Maximum measurement distance* Tree - 1,100 yards Maximum measurement distance* Deer - 1,000 yards UNSTABLE VIEW (WITHOUT STABILIZED) STABLE VIEW (WITH STABILIZED) WATERPROOF 7 NITROGEN PURGED OLED DISPLAY ID TECHNOLOGY STABILIZED HYPER READ TRU TARGET First Target Priority Mode Provides the exact distance to the closest object among a group of targets being measured. In this mode, you can easily range an object as small as a fence post. Distant Target Priority Mode Displays the range of the farthest target among a group of targets measured. This feature is especially useful if the subject is located behind tall grass or brush. 252 yards Horizontal Distance 287 yards Straight Distance ID [Incline/Decline] Technology Nikon's advanced ID [Incline/Decline] Technology provides the horizontal distance to the target, even when ranging at various incline or decline shooting angles--up to an incredible +/- 89 degrees [nearly vertical up or down]. MONARCH 3000 STABILIZED 16556 MAG. EYE RELIEF REAL ANGULAR FOV FOV @ 1000 MAX RANGE MAX RANGE MAX RANGE WEIGHT (W/O SIZE (LxHxW) OBJ DIA. (MM) (DEGREES) YARDS (FT) (REFLECTIVE)*(YDS) (TREE)*(YDS) (DEER)*(YDS) BATTERIES (OZ) (IN) 6x21 18.0 7.5 39.3 3,000 1,100 1,000 6.9 3.8x2.9x1.7 *Under Nikon's measurement conditions and reference values. The specifications of the product may not be achieved depending on the target object's shape, surface texture and nature, and/or weather conditions. The technology behind the Laser Rangefinder with inclinometer originated from technology incorporated in Nikon's Total Station DTM-1 surveying instrument. The Total Station DTM-1, first sold in 1985, was the first highly advanced electronic model of those surveying instruments that incorporated a distance and angle measuring capability developed by Nikon Corporation. 41 NEW NEW CONFIDENCE FOR LONGER RANGES. The all-new MONARCH 2000 6x21 Laser Rangefinder brings Nikon's advanced laser rangefinder technologies and a 8-2,000 yard* measurement range to the long-range hunter. With 1/2-yard precision** displayed in 0.1-yard increments, Tru-TargetTM Priority System and Nikon's ID (Incline/Decline) Technology, MONARCH 2000 is up to any hunting or shooting endeavor--whether bowhunting from a tree stand or executing incredibly long range shots. 42 Tru-Target Technology Enables you to choose between two different ranging modes, depending on the situation. First Target Priority Mode Provides the exact distance to the closest object among a group of targets being measured. In this mode, you can easily range an object as small as a fence post. MULTILAYER COATING WIDE FIELD OF VIEW LONG EYE RELIEF 2,000 YARD MEASUREMENT RANGE *Ranging Performance 2,000 yds. Reflective Targets 1,200 Tree/1,100 yds. Deer **Accuracy = 0.5 yd to 700 yds; 1.0 yd to 999 yds; 1.5 yds to 1000 yds and beyond WATERPROOF 7 NITROGEN PURGED OLED DISPLAY ID TECHNOLOGY HYPER READ TRU TARGET 252 yards Horizontal Distance 287 yards Straight Distance Distant Target Priority Mode Displays the range of the farthest target among a group of targets measured. This feature is especially useful if the subject is located behind tall grass or brush. ID [Incline/Decline] Technology Nikon's advanced ID [Incline/Decline] Technology provides the horizontal distance to the target, even when ranging at various incline or decline shooting angles--up to an incredible +/- 89 degrees [nearly vertical up or down]. Focusing Diopter Allows Crisp, Sharp Focus NEW MONARCH 2000 16661 MAG. EYE RELIEF REAL ANGULAR FOV FOV @ 1000 MAX RANGE MAX RANGE MAX RANGE WEIGHT (W/O SIZE (LxHxW) OBJ DIA. (MM) (DEGREES) YARDS (FT) (REFLECTIVE)*(YDS) (TREE)*(YDS) (DEER)*(YDS) BATTERIES (OZ) (IN) 6x21 18.0 7.5 39.3 2,000 1,200 1,100 6.1 3.8x2.9x1.7 * Under Nikon's measurement conditions and reference values. **Under Nikon's measurement conditions. The specifications of the product may not be achieved depending on the target object's shape, surface texture and nature, and/or weather conditions. The technology behind the Laser Rangefinder with inclinometer originated from technology incorporated in Nikon's Total Station DTM-1 surveying instrument. The Total Station DTM-1, first sold in 1985, was the first highly advanced electronic model of those surveying instruments that incorporated a distance and angle measuring capability developed by Nikon Corporation. 43 LIFETIME REPAIR/REPLACEMENT 44 ONE MILE OF INSTANT GRATIFICATION Combine Nikon binocular performance with the extreme speed and ranging technology of a 1900-yard laser rangefinder* and you have LaserForce, Nikon's 10x42 Rangefinder Binocular. Quite simply, LaserForce is the single optic solution for serious hunters who depend on both their binocular for picking out distant animals and their rangefinder for getting the exact distance before taking the shot. Featuring ED (Extra-low Dispersion) glass and Nikon's ID Technology to deliver the one number you need for incline or decline angles, LaserForce puts ranging precision, optical performance and rugged performance within your reach. FULLY MULTICOATED OPTICS ED GLASS LONG EYE RELIEF 8-SECOND SUSTAINED MEASUREMENT Continuously measure single or across multiple targets AUTO POWER SHUT-OFF FUNCTION Saves battery life, shuts down after 8 seconds of non-use. PRECISION DISPLAY Displays in .1-yard increments to 100 yards, 1-yard increments over 100 yards. FLIP DOWN OBJECTIVE COVERS Included with LaserForce ID TECHNOLOGY Delivers the one number you need for your best shot to account for incline or decline shooting angles. DISPLAY ADJUSTMENT Allows short focus of OLED RUBBER ARMOR Provides sure grip, wet or dry MODE CONTROL Select yards, meters or brightness DIOPTER CONTROL Allows crisp focus balance to your eyes WATERPROOF 7 NITROGEN PURGED TRIPOD ADAPTABLE OLED DISPLAY ID TECHNOLOGY Normal Glass ED Glass Nikon ED glass delivers the utmost in edge-to-edge sharpness, detail resolution and clear, true color images free of flare. Turn and Slide Eyecups Allow users to adjust the eye-relief for a custom fit-- providing a full field of view and maximum comfort during extended periods of use. LASERFORCE 16212 10x42 RF Bino EYE RELIEF REAL ANGULAR FOV @ MAX REFLECTIVE CLOSE WEIGHT (W/O SIZE (LxWxH) FINISH (MM) FOV (DEGREES) 1000 YDS (FT) RANGE (YDS) FOCUS (FT) BATTERIES (OZ) (IN) BLACK 16.7 6.1 320 1,900 23 30.9 5.8x5.2x2.8 Rangefinder Binocular with 10-1,900 yard range* Maximum measurement distance* Reflective Target - 1,900 yards Maximum measurement distance* Tree - 1,400 yards Maximum measurement distance* Deer - 1,100 yards *Under Nikon's measurement conditions and reference values. BRIGHT OLED DISPLAY High visibility red display provides ideal contrast on distant targets. 4-step intensity adjustment. 45 NEW RANGING CONSISTENCY FOR YOUR STYLE OF HUNTING The PROSTAFF 1000 and PROSTAFF 1000i Laser Rangefinders put a solid 1,000-yard maximum ranging capability into your hand, together with compact ergonomics that will fit your pocket. The 6x optical system makes seeing--and ranging--deer out to 600 yards a reality, while the Tru-Target system allows you to select either First Target or Distant Target Priority. Weather resistant/ rainproof construction. The PROSTAFF 1000i model also features ID (Incline/Decline) Technology--with a Horizontal Distance / Actual Distance display mode that can be easily switched. 46 Tru-Target Technology Enables you to choose between two different ranging modes, depending on the situation. First Target Priority Mode Provides the exact distance to the closest object among a group of targets being measured. In this mode, you can easily range an object as small as a fence post. Distant Target Priority Mode Displays the range of the farthest target among a group of targets measured. This feature is especially useful if the subject is located behind tall grass or brush. MULTILAYER COATING LONG EYE RELIEF ID TECHNOLOGY TRU TARGET MULTILAYER COATING LONG EYE RELIEF TRU TARGET Bowhunting Laser Rangefinder Tailored to the range-finding needs of archery hunters and competitors, the ARROW ID 3000 calculates the shot slope and distance, immediately providing your "shoot-for" distance. With a durable and ergonomic design, water resistant/rainproof housing, and refreshing eye relief, the engineers had the serious archery hunter and shooter in mind. Tru-Target Priority and Nikon's ID (Incline/ Decline) Technology remove the guesswork out of your shot's equation so you can focus on the most critical aspect of your hunt or competition: making your best shot. NEW PROSTAFF 1000i 16663 NEW PROSTAFF 1000 16664 MAG. EYE RELIEF REAL ANGULAR FOV FOV @ 100 MAX RANGE MAX RANGE MAX RANGE WEIGHT (W/O SIZE (LxHxW) OBJ DIA. (MM) (DEGREES) YARDS (FT) (REFLECTIVE)*(YDS) (TREE)*(YDS) (DEER)*(YDS) BATTERIES (OZ) (IN) 6x20 16.7 6 31.4 1,000 800 600 4.6 3.6x2.9x1.5 6x20 16.7 6 31.4 1,000 800 600 4.6 3.6x2.9x1.5 ARROW ID 3000 16224 MAG. EYE RELIEF REAL ANGULAR FOV FOV @ 100 OBJ DIA. (MM) (DEGREES) YARDS (FT) MAX RANGE (REFLECTIVE)*(YDS) 4x20 20.3 9 47.2 550 WEIGHT (W/O BATTERIES (OZ) 4.8 SIZE (LxHxW) (IN) 3.6x2.9x1.5 *Under Nikon's measurement conditions and reference values. The specifications of the product may not be achieved depending on the target object's shape, surface texture and nature, and/or weather conditions. The technology behind the Laser Rangefinder with inclinometer originated from technology incorporated in Nikon's Total Station DTM-1 surveying instrument. The Total Station DTM-1, first sold in 1985, was the first highly advanced electronic model of those surveying instruments that incorporated a distance and angle measuring capability developed by Nikon Corporation. 47 48 EXPERIENCE BETTER GLASS With its legendary bloodlines and enhanced optical systems, the MONARCH Series of all-terrain binoculars maximizes every hour you spend in the field. With incredibly bright, high-resolution views, each is engineered to perform from the first rays of light until the very last. Every MONARCH binocular utilizes Nikon's renowned ED (Extra-low Dispersion) glass and phase correction prisms with dielectric high reflective multilayer coatings to deliver a level of performance unlike any other. Combined with an inherent ruggedness and unmatched reputation for success, MONARCH will continue to prove itself as the greatest family in hunting. Multilayer coatings, which provide an even higher light transmittance across the entire visible light spectrum, are applied to all of the lens and prism surfaces that transmit light. This minimizes the loss of light due to reflection, thereby ensuring a more natural, clearer view. Dielectric high-reflective multilayer prism coating is applied to a roof prism unit that does not feature total internal reflection. This boosts light reflectivity of more than 99% (designed value) for the full visible range, giving you clearer whites and a sharper, brighter, more natural vision across the entire field of view. Normal Glass ED Glass Nikon's ED Glass reduces chromatic aberration to a remarkable degree, providing clear images with superior contrast. 49 LIFETIME REPAIR/REPLACEMENT 50 NEW the MOST AWARDED monarch. ever. NOW IN 30mm! Every precious moment you spend in the field deserves the advantage of extraordinary performance. The new MONARCH HG 30mm series follows in the footsteps of its award-winning 42mm siblings in delivering class-ruling optical performance, unrivaled ruggedness and exceptional handling. Engineered throughout to match the performance specifications of the original 8x42 and 10x42 models, the new 30mm MONARCH HG binoculars do so in a smaller size and nearly eight ounce reduction in weight. FULLY MULTICOATED OPTICS WIDE FIELD OF VIEW ARMOR LENS COATING ED GLASS LONG EYE RELIEF FIELD FLATTENER DIELECTRIC HIGH REFLECTIVE MULTILAYER COATING PHASE CORRECTION COATING 30mm model WATERPROOF 7 NITROGEN PURGED LOCKING DIOPTER TRIPOD ADAPTABLE Turn and Slide Eyecups Allow users to adjust the eye-relief for a custom fit-- providing a full field of view and maximum comfort during extended periods of use. MONARCH HG NEW 16575 8x30 NEW 16576 10x30 16027 8x42 16028 10x42 REAL ANGULAR FOV @ CLOSE FOCUS FINISH EYE RELIEF (MM) FOV (DEGREES) 1000 YDS (FT) (FT) BLACK 16.2 8.3 435 6.6 BLACK 15.2 6.9 362 6.6 BLACK 17.8 BLACK 17 8.3 435 6.6 6.9 362 6.6 WEIGHT (OZ) 15.9 15.9 23.5 24 SIZE (LxW) (IN) 4.7x5 4.7x5 5.7x5.2 5.7x5.2 Lens Covers Stronger. Lighter. More Agile. Because a binocular of this significance must always perform and do so without weighing you down, MONARCH HG's body is die-cast magnesium alloy. Providing optimum strength, impact resiliency and weight reduction, the slim body profile is further enhanced with rubberized panels to provide a sure grip in any conditions. 42mm model 51 LIFETIME REPAIR/REPLACEMENT 52 YOUR greatest ADVENTURE AWAITS Built to satisfy the incredible needs of today's serious outdoorsmen and women, this is a level of MONARCH that not only provides exquisite optical performance in a compact body delivering a wide field of view, but whose dynamic handling and rugged performance leave zero doubt as to the MONARCH 7's long-standing All Terrain Binocular heritage. FULLY MULTICOATED OPTICS WIDE FIELD OF VIEW ARMOR LENS COATING (42mm Models) ED GLASS LONG EYE RELIEF DIELECTRIC HIGH REFLECTIVE MULTILAYER COATING PHASE CORRECTION COATING WATERPROOF 7 NITROGEN PURGED TRIPOD ADAPTABLE FULLY MULTICOATED OPTICS ED GLASS LONG EYE RELIEF DIELECTRIC HIGH REFLECTIVE MULTILAYER COATING PHASE CORRECTION COATING WATERPROOF 7 NITROGEN PURGED FLIP DOWN OBJECTIVE COVERS Included with MONARCH 5 & MONARCH 7 TRIPOD ADAPTABLE LIGHTWEIGHT CHAMPION OF DAWN & DUSK Even with an uncontested heritage of all-conditions optical performance, the MONARCH 5 further elevates its game with improved agility and advanced low light brilliance. The addition of Nikon's ED glass lenses puts it in a class of its own for battling darkness with sharp, high-contrast views. The rubber-armored coating provides a non-slip grip in even the toughest environments. MONARCH 7 7579 8x30 7580 10x30 7548 8x42 7549 10x42 MONARCH 5 7576 8x42 7577 10x42 7578 12x42 7583 20x56 EYE RELIEF REAL ANGULAR FOV @ CLOSE WEIGHT SIZE (LxW) FINISH (MM) FOV (DEGREES) 1000 YDS (FT) FOCUS (FT) (OZ) (IN) BLACK 15.1 8.3 435 6.6 15.3 4.7x4.8 BLACK 15.8 6.7 351 6.6 15.5 4.7x4.8 BLACK 17.1 8.0 420 8.2 22.9 5.6x5.1 BLACK 16.5 6.7 351 8.2 23.3 5.6x5.1 BLACK 19.5 6.3 BLACK 18.4 5.5 BLACK 15.1 5.0 BLACK 16.4 3.3 330 8.2 20.8 5.7x5.1 288 8.2 21.2 5.7x5.1 262 8.2 21.2 5.7x5.1 173 16.4 43.6 7.8x5.7 53 PASSION INSPIRED PERFORMANCE Nikon's PROSTAFF 7S 10x42 is a lightweight, easy to hold, all-terrain binocular that features an advanced optical system designed to deliver sharper images. Thanks to fully multicoated lenses and Phase-Correction Coated Roof Prisms, every model in the PROSTAFF 7S series provides the quality, brightness and resolution that make it the perfect accessory for almost any outdoor activity. FULLY MULTICOATED OPTICS LONG EYE RELIEF LIFETIME REPAIR/REPLACEMENT PHASE CORRECTION COATING PROSTAFF 7s 16000 8x30 16001 10x30 16002 8x42 16003 10x42 NEW 16642 10x42 FINISH BLACK BLACK BLACK BLACK TrueTimber® KANATI EYE RELIEF REAL ANGULAR FOV @ CLOSE (MM) FOV (DEGREES) 1000 YDS (FT) FOCUS (FT) 15.4 6.5 341 8.2 15.4 6.0 314 8.2 19.5 6.8 15.5 6.2 15.5 6.2 356 13.1 325 13.1 325 13.1 WEIGHT (OZ) 14.6 14.8 22.9 22.8 22.8 SIZE (LxW) (IN) 4.7x4.8 4.7x4.8 6.6x5.1 6.5x5.1 6.5x5.1 54 WATERPROOF 7 NITROGEN PURGED TRIPOD ADAPTABLE (42mm Model only) MULTILAYER COATING LONG EYE RELIEF Turn and Slide Eyecups Allow users to adjust the eye-relief for a custom fit--providing a full field of view and maximum comfort during extended periods of use. MULTILAYER COATING WIDE FIELD OF VIEW (10x42 Model) LONG EYE RELIEF LIFETIME REPAIR/REPLACEMENT WATERPROOF 7 NITROGEN PURGED BUILT TO HUNT AS HARD AS YOU DO When hunting conditions are at their worst, PROSTAFF 5 Binoculars can be trusted to still give you the vision you demand. PROSTAFF 5 Binoculars feature superb optics, ergonomic design and waterproof, fogproof performance. SILVER PRISM COATING WATERPROOF 7 NITROGEN PURGED The Power of PerformancE The PROSTAFF 3S binocular lives up to its namesake with bright, multicoated optics, wide field of view, long eye relief, and waterproof/fogproof performance. Notably lightweight and compact, the PROSTAFF 3S is a standout binocular for those looking for rugged-yet-portable optics worthy of any adventure. PROSTAFF 5 7572 10x50 7573 12x50 PROSTAFF 3s 16030 8x42 16031 10x42 EYE RELIEF REAL ANGULAR FOV @ CLOSE WEIGHT SIZE (LxW) FINISH (MM) FOV (DEGREES) 1000 YDS (FT) FOCUS (FT) (OZ) (IN) BLACK 19.6 5.6 293 16.4 28.7 7.4x5.5 BLACK 15.5 4.7 246 16.4 27.9 7.4x5.5 BLACK 20.2 7.2 BLACK 15.7 7.0 377 9.8 19.9 6x5.1 367 9.8 20.3 5.9x5.1 55 VERSATILITY FOR EVERY SITUATION The ACULON Series binoculars are great for a variety of hunting applications, thanks to the wide range of magnifications and sizes that are available. ACULON binoculars are a quality, cost-effective choice and a great fit for almost any activity. ACULON A211 binoculars feature multilayercoated optics to deliver a high quality image under a multitude of lighting conditions, making these binoculars effective during those ever-important low-light hours of hunting near dawn and dusk. These binoculars have a central focus knob, a fully rubber armored body, and turn-and-slide rubber eyecups to simplify use with eyewear. ACULON A211 EYE RELIEF REAL ANGULAR FOV @ CLOSE WEIGHT SIZE (LxW) FINISH (MM) FOV (DEGREES) 1000 YDS (FT) FOCUS (FT) (OZ) (IN) 8244 7x35 BLACK 11.8 9.3 488 16.4 24.2 4.6x7.3 8245 8x42 BLACK 12 8.0 420 16.4 26.6 5.7x7.3 8246 10x42 BLACK 11.6 6.0 314 16.4 26.8 5.7x7.3 8247 7x50 BLACK 17.6 6.4 335 26.2 31.9 7.1x7.8 8248 10x50 BLACK 11.8 6.5 341 23 31.7 7x7.8 8249 12x50 BLACK 11.5 5.2 272 26.2 32.1 7x7.8 8250 16x50 BLACK 12.6 4.2 220 29.5 32.6 7x7.8 8252 10-22x50 Zoom* BLACK 8.6@10x 3.8 199@10x 49.2@10x 33.9 7.8x7.8 * Includes free Tripod Adapter 56 LIFETIME REPAIR/REPLACEMENT TURN & SLIDE EYECUPS Perfect for use with or without eyeglasses. SMOOTH CENTRAL FOCUS Makes sharp focus simple. ASPHERICAL EYEPIECE LENSES Offer flat viewing field. (Except Zoom Model.) RUBBER ARMOR Provides a good grip, wet or dry. MULTILAYER COATING Multilayer-coated lenses for brighter images. 8-24x ZOOM RANGE Offers flexibility for a variety of situations. SMOOTH CENTRAL FOCUS Makes sharp focus simple. PORRO PRISM SYSTEM Offers a bright view. MULTILAYER COATING Multilayer-coated lenses for brighter images. MULTILAYER COATING Multilayer-coated lenses for brighter images. TURN & SLIDE EYECUPS Perfect for use with or without eyeglasses. RUBBER PANELS For easy gripping. COMPACT SIZE Fits into pocket or pack. The ACULON T11 ZOOM binocular is a portable, pocket-sized option. With the option of changing magnification anywhere between 8-power and 24-power through a centrally located zoom lever, this binocular will prove to be extremely versatile in many different circumstances. Turn-and-slide rubber eyecups simplify use with or without eyewear. SMOOTH CENTRAL FOCUS Makes sharp focus simple. TURN & SLIDE EYECUPS Perfect for use with or without eyeglasses. ROOF PRISM DESIGN Folds to fit in pocket. DUAL HINGE DESIGN To fit in pocket. A compact, lightweight roof prism binocular that is perfect for the hunt where you need to pack light. A smooth central focus knob and dual-hinge design are among its features. Available in 10x25 magnification, in black or TrueTimber® KANATI. LIFETIME REPAIR/REPLACEMENT ACULON T11 ZOOM FINISH EYE RELIEF REAL ANGULAR FOV @ CLOSE WEIGHT SIZE (LxW) (MM) FOV (DEGREES) 1000 YDS (FT) FOCUS (FT) (OZ) (IN) 7334 8-24x25 BLACK 13@8x 4.6 241@8x 13.1 10.8 4.8x4.3 ACULON A30 8263 10x25 BLACK 13 5.0 NEW 16641 10x25 TrueTimber® KANATI 13 5.0 262 9.8 9.7 4.8x4.5 262 9.8 9.7 4.8x4.5 57 MARINE BINOCULARS LIFETIME REPAIR/REPLACEMENT 58 Binoculars for the WATER Fishermen, boaters and mariners of every description should have at least one binocular on board their vessel. Whether you're exploring the flats for surface disturbances on a calm morning of tarpon fishing, checking out the tackle setup of the boat getting all the action or looking for a distant navigation marker, a 7x50 marine binocular is your ticket. Nikon's OceanPro binocular, with integral global compass, is designed for use in both Northern Hemisphere and Southern Hemisphere locations and features 7x magnification and 50mm objectives, to provide optimum viewing even in rough water. OCEANPRO MULTILAYER COATING LONG EYE RELIEF Rugged all-terrain binoculars The Action Extreme is a Porro prism with the waterproof and fogproof attributes of other Nikon All Terrain Binoculars. Nikon's lead-and-arsenic-free lenses and prism systems result in a high quality glass that is also lighter in weight. Each model features quick central focus knob, rubber armored body and multi-click turn-and-slide eyecups. WATERPROOF 7 NITROGEN PURGED TRIPOD ADAPTABLE Compass Display MULTILAYER COATING LONG EYE RELIEF WATERPROOF 7 NITROGEN PURGED TRIPOD ADAPTABLE EYE RELIEF REAL ANGULAR FOV @ CLOSE WEIGHT SIZE (LxW) OCEANPRO CF WP FINISH (MM) FOV (DEGREES) 1000 YDS (FT) FOCUS (FT) (OZ) (IN) 7440 7x50 BLACK 22.7 7.2 378 33 38 7.6x8.0 16026 7x50 Global Compass BLACK 22.7 7.2 377 33 39.9* 7.6x8.0 *Weight without batteries ACTION EXTREME 7237 7x35 7238 8x40 7239 7x50 7245 10x50 7246 12x50 7247 16x50 EYE RELIEF REAL ANGULAR FOV @ CLOSE WEIGHT SIZE (LxW) FINISH (MM) FOV (DEGREES) 1000 YDS (FT) FOCUS (FT) (OZ) (IN) BLACK 17.3 9.3 488 16.4 28.2 4.7x7.2 BLACK 17.2 8.2 430 16.4 30.2 5.5x7.4 BLACK 17.1 6.4 335 23.0 35.3 7.0x7.7 BLACK 17.2 6.5 341 23.0 36.0 7.0x7.7 BLACK 16.1 5.5 288 23.0 36.9 7.0x7.7 BLACK 17.8 3.5 183 23.0 36.7 7.0x7.7 59 SPECIALTY BINOCULARS Binocular of the Century The WX, in 7x50 and 10x50, is a hand-built, super-wide angle binocular delivering the widest field of view in Nikon's 101-year history, making it perfect for highly critical astronomical observation or highly-critical field use. Superior magnification and an incredible Apparent FOV (76.4° for the 10x50) make these your go-to optics for comet watching, stargazing or glassing entire hillsides without panning. This individual eye focus binocular features Abbe-Koenig prisms, which offer total reflection on all surfaces for a high light transmission rate. Tripod Adapter and hard case included. Objective lenses with filter threads to accept a 55mm filter (P=0.75) round out its features. FULLY MULTICOATED OPTICS WIDE FIELD OF VIEW ED GLASS FIELD FLATTENER LONG EYE RELIEF PHASE CORRECTION COATING WATERPROOF 7 NITROGEN PURGED TRIPOD ADAPTABLE 60 TRAVELITE EX WATERPROOF O-ring sealed to prevent moisture from entering body. FOGPROOF Nitrogen purged for total reliability against thermal shock. MULTILAYER COATING Multilayer-coated lenses for brighter images. SPORTSTAR EX ROOF PRISM DESIGN Folds to fit in pocket. MULTILAYER COATING Multilayer-coated lenses for brighter images. SMOOTH CENTRAL FOCUS KNOB Fast range of focus for quick viewing. LONG EYE RELIEF Provides 15mm or more of eye relief (12mm+ for compacts). Perfect for eyeglass wearers. RUBBER-ARMORED COATING Provides a fast, sure, non-slip grip. BAK4 HIGH INDEX PRISMS Provide extra-high resolution images. COMPACTS TAKE IT WITH YOU Experienced hunters know that a good compact is worth its weight in gold. When every ounce counts, Nikon's Compacts give you the resolution to pick out horns from tree branches and glass big areas with ease. SMOOTH CENTRAL FOCUS KNOB Fast range of focus for quick viewing. WATERPROOF O-ring sealed to prevent moisture from entering body. FOGPROOF Nitrogen purged for total reliability against thermal shock. LIFETIME REPAIR/REPLACEMENT WX 16033 7x50 IF 16034 10x50 IF TRAVELITE EX 35501 8x25 35503 10x25 SPORTSTAR EX 35515 8x25 35516 10x25 EYE RELIEF REAL ANGULAR FOV @ CLOSE WEIGHT SIZE (LxW) FINISH (MM) FOV (DEGREES) 1000 YDS (FT) FOCUS (FT) (OZ) (IN) BLACK 17.7 10.7 563 40.4 85.4 10.7x6.7 BLACK 15.3 9.0 472 65.6 88.4 11.5x6.7 BLACK 15.5 6.3 BLACK 15.9 5.0 330 9.2 12.5 3.9x4.5 262 9.2 12.9 4.0x4.5 BLACK 10.0 8.2 BLACK 10.0 6.5 429 8.2 9.9 4.1x4.5 342 11.5 9.9 4.1x4.5 61 FIELDSCOPES 62 FOCUS ON THE DETAILS Whether you're spotting at extreme ranges or in low light, nothing matches the ability of Nikon's Fieldscopes to pull game out of the background and reveal every detail in optimum contrast, edge-to-edge resolution and brilliant color. At the top of the lineup is Nikon's MONARCH Fieldscope line, with a full complement of optical technologies and features. The Fieldscope 50mm ED is the lightweight workhorse of the bunch. The PROSTAFF 5 Fieldscopes are full-featured, yet compact and lightweight. The PROSTAFF 3 Outfit comes complete with compact tripod and carry case. You can't go wrong with any of them. 63 FULLY MULTICOATED OPTICS ED GLASS GLASS-ETCHED RETICLE (FS-MOA and FS-MRAD Eyepieces) LONG EYE RELIEF FIELD FLATTENER 3x ZOOM RATIO WATERPROOF 7 NITROGEN PURGED TRIPOD ADAPTABLE 82MM 60MM LIFETIME REPAIR/REPLACEMENT A BETTER LOOK AT YOUR WORLD True to its legendary name and reputation, the MONARCH Fieldscope pushes long-range viewing capability to an entirely new level for adventurous hunters and long-range shooters. Delivering a full complement of Nikon optical technologies engineered for an incredibly bright, clear, high resolution view across the entire viewing field, the flagship MONARCH Fieldscope makes long days of viewing both satisfying and strain-free. With an innovative focusing system that reduces high-magnification scope movements and tough, lightweight aluminum alloy construction, the MONARCH Fieldscope assures its owner of a lifetime of high performance optical capability, mechanical precision and all-out ruggedness. 64 MEP-30-60W MEP-20-60 MEP-38W MONARCH FIELDSCOPE MEP EYEPIECES Nikon has developed eyepieces exclusively for MONARCH Fieldscopes. Each employs an optical system, and a Field Flattener Lens System that delivers consistent sharpness and clarity across the entire field of view. NEW MEP-30 FS-MOA NEW 30 20 10 30 20 10 10 20 30 10 3 2 1 20 321 30 FS-MOA 30 0.05 MOA 8 6 4 2 8 6 4 2 2 4 6 8 2 4 1 1 6 0 8 FS-MRAD 8 0.014 MRAD MEP-30 FS-MRAD NEW MONARCH MEP-30 EYEPIECES WITH FS-MRAD or FS-MOA RETICLE: ENGINEERED FOR THE TACTICAL SPOTTER The new MEP-30 reticle eyepieces allow a spotter to locate and focus on the same target in the reticle as the shooter and then communicate reference points and follow-up shot corrections. Integral FS-MRAD or FS-MOA reticle includes milling scale for highly detailed measurements of targets. Can be fitted to straight or angled body 82mm or 60mm MONARCH Fieldscopes. 30x magnification on 82mm Fieldscope bodies and 24x magnification on 60mm Fieldscope bodies. LIFETIME REPAIR/REPLACEMENT MONARCH FIELDSCOPES 16102 60ED-S w/MEP-20-60 16103 60ED-A w/MEP-20-60 FINISH BLACK BLACK 16100 82ED-S w/MEP-20-60 BLACK EYE RELIEF REAL ANGULAR FOV @ CLOSE WEIGHT (MM) FOV (DEGREES) 1000 YDS (FT) FOCUS (FT) (OZ) 16.1 - 15.3 2.6 - 1.2 135 - 63 10.8 56.7 16.1 - 15.3 2.6 - 1.2 135 - 63 10.8 56.4 LENGTH* (IN) 10.3/11.2 10.6/11.5 16.1 - 15.3 2.1 - 1.0 111 - 51 16.4 70.5 12.8/14.0 16101 82ED-A w/MEP-20-60 BLACK 16.1 - 15.3 2.1 - 1.0 111 - 51 16.4 70.1 13.1/14.3 NEW 16686 NEW 16687 82ED-A w/ MEP-30 FS-MRAD BLACK 82ED-A w/ MEP-30 FS-MOA BLACK *With and without hood fully extended 15.2 2.0 15.2 2.0 105 16.4 74.4 13.1/14.3 105 16.4 74.4 13.1/14.3 MEP EYEPIECES W/FIELDSCOPE EYE RELIEF REAL ANGULAR FOV @ WEIGHT* SIZE (LxO.D.)* BODY MAGNIFICATION (MM) FOV (DEGREES) 1000 YDS (FT) (OZ) (IN) 16108 MEP-38W 60MM 30x 82MM 38x 18.5 2.5 2 132 105 9.5 2.9x2.4 16109 MEP-20-60 60MM 82MM 16x-48x 20x-60x 16.1-15.3** 2.6-1.2** 2.1-1.0** 135-63** 111-51** 12.3 3.5x2.4 16110 MEP-30-60W 60MM 82MM 24x-48x 30x-60x 15.2-14.2** 2.5-1.5** 2.0-1.2** 132-78** 105-63** 14.1 3.6x2.4 NEW 16646 MEP-30 FS-MRAD 60MM 82MM 24x 30x NEW 16647 MEP-30 FS-MOA 60MM 82MM 24x 30x 15.2 2.5 2.0 15.2 2.5 2.0 131 105 16.6 3.5x2.4 131 105 16.6 3.5x2.4 *(w/o caps) **Designed reference value at highest magnification 65 Fieldscope 50MM ED SMALL, YET MIGHTY The Fieldscope 50mm ED is incredibly compact and lightweight, perfect for tucking into your pack for all your hunting adventures. Nikon's ED glass delivers extremely bright, sharp true color images. Straight or angled body models. 66 50ED-A FULLY MULTICOATED OPTICS ED GLASS WATERPROOF 7 NITROGEN PURGED TRIPOD ADAPTABLE LIFETIME REPAIR/REPLACEMENT EYE RELIEF REAL ANGULAR FOV @ CLOSE WEIGHT FIELDSCOPE 50MM ED FINISH (MM) FOV (DEGREES) 1000 YDS (FT) FOCUS (FT) (OZ) 8321 13-30x50ED-A DK GREY 12.9@13x 3 157@13x 9.8 16.6 BODY SIZE (LxW)(IN) 8.1x2.8 82MM-A 60MM-S MULTILAYER COATING LONG EYE RELIEF 3x ZOOM RATIO WATERPROOF 7 NITROGEN PURGED TRIPOD ADAPTABLE WHERE POWER MEETS PRECISION The PROSTAFF 5 Fieldscope offers a wide field of view and superb viewing in all conditions. It is engineered for precision and high magnification capability. Multilayer-coated lenses and prisms provide you with superb brightness. Super-fast bayonet eyepieces make scouting wide areas simple. Easy-to-pack and easy-to-use. GRAB IT AND GO The PROSTAFF 3 Fieldscope Outfit combines quality optics in a compact, rugged package for a take-anywhere spotter. The fully multicoated optics and 16-48x Zoom eyepiece guarantee you the best in versatility and performance. Packaged as an outfit, with compact tripod and carry case, the PROSTAFF 3 Fieldscope is ready for your next outing. PROSTAFF 5 EYE RELIEF REAL ANGULAR FOV @ CLOSE WEIGHT LENGTH FINISH (MM) FOV (DEGREES) 1000 YDS (FT) FOCUS (FT) (OZ) (IN) 8776 60MM Straight body BLACK 16.9 2.1 109 20 41.4 14.8x3.7 8777 60MM Angled body BLACK 16.9 2.1 109 20 41.8 15.4x3.7 8774 82MM Straight body BLACK 16.9 2.6 136 13.1 34 11.4x3.3 8775 82MM Angled body BLACK 16.9 2.6 136 13.1 34.4 12x3.3 PROSTAFF 3 60mm Outfit 6983 16-48x60-S OUTFIT BLACK 19 2.3 120@16x 32.8 21.9 12.3x2.9 MULTILAYER COATING LONG EYE RELIEF 3x ZOOM RATIO LIFETIME REPAIR/REPLACEMENT 60MM-S OUTFIT WATERPROOF 7 NITROGEN PURGED TRIPOD ADAPTABLE 67 MOUNTING SOLUTIONS MOUNTS FOR EVERY RIFLESCOPE. Nikon's scope mounting systems are engineered to uphold the precision, strength and good looks designed into every Nikon riflescope. Choose from our new featherweight horizontal split rings, A-Series aluminum rings and bases, mounts for the BLACK riflescope line, as well as for MSR platforms and rings for most firearms. All are CNC machined from solid bar stock and are held to incredibly tight tolerances, and all are made in the USA. 30MM BLACK Cantilever Mounts! Nikon's BLACK cantilever-style mounting platform is designed for strength, precision and proper riflescope mounting position on MSR rifles. These precision-machined, one-piece mounts offer perfect alignment and maximum surface contact area for your 30mm tube riflescope. Mil-Spec 1/2" hex nut clamp accepts 65 in/lb. of torque. BLACK Precision Mounts! Nikon's BLACK Precision mount is a one-piece design engineered for exceptional precision, strength and perfect alignment of the integral 30mm. The unique design provides wider surface area contact with scope tube for maximum mounting security. Mil-Spec 1/2" hex nut accepts 65 in/lb. of torque. CANTILEVER Mounts Built of strong-yet-lightweight alloy construction, Nikon's Cantilever 6m8ounts provide ideal height and fore-aft position for proper eye relief and charging handle access. M-TACTICAL models for 30mm tubes, P-TACTICAL models for one-inch tubes. 30MM 1-inch LIFETIME REPAIR/REPLACEMENT 68 Also available in 20 MOA Cant One-Piece Mount Also available in 20 MOA Cant One-Piece Mount UNLOCK YOUR FIREARM'S ACCURACY POTENTIAL! Match your riflescope and reticle to virtually any ammunition. All you need is a rifle, a Nikon riflescope and a rangefinder--Spot On does all the work for you--showing you all the shot possibilities before you pull the trigger! With an expansive database Spot On provides you with the precise aiming points at your specified range for any Nikon BDC reticle riflescope and instant reference for sighting in other Nikon riflescopes with Nikoplex, hashmark, mildot or standard crosshair reticles. WE HOLD THE SPOT ON ADVANTAGE The passion for precision has brought over a million shooters to Spot On. Its speed, simplicity and effectiveness is what keeps them coming back. Spot On precisely matches any cartridge and load to a Nikon riflescope and BDC reticle--providing the exact aiming points for every shooting distance imaginable. And with over a million possible accuracy combinations for virtually every centerfire, rimfire and muzzleloader load--even crossbow bolts--Spot On offers a real advantage for long-range precision. give it a shot! NikonSportOptics.ca/SpotOn Free Mobile App Spot On is now available at no cost for the iPhone®, iPad® and AndroidTM platforms. Get the app and ensure that the world's hottest ballistics calculator is there when you need it. PERFORMANCE SHOOTING ACCESSORIES A-SERIES Rings Engineered specifically for lighterweight rifles, the lightweight and economical A-Series rings are designed for an incredible strength-to-weight ratio. NEW PRECISION RIFLE RINGS 16691 Precision Rifle Rings 1 - Low 16692 Precision Rifle Rings 1 - Med 16693 Precision Rifle Rings 1 - High 16694 Precision Rifle Rings 30mm - Low 16695 Precision Rifle Rings 30mm - Med 16696 Precision Rifle Rings 30mm - High BLACK SERIES 30mm MOUNTS 16403 BLACK Cantilever MSR Height 16405 BLACK Cantilever (20 MOA Cant) MSR Height 16404 BLACK Precision MSR Height 16406 BLACK Precision Medium Height M-TACTICAL 30mm CANTILEVER MOUNTS 839 M-TACTICAL 1-Piece 840 M-TACTICAL 1-Piece (20 MOA Cant) 16562 M-TACTICAL 2-Piece PRECISION RIFLE RINGS P-TACTICAL 1-INCH CANTILEVER MOUNTS 16560 P-TACTICAL 1-Piece 16561 P-TACTICAL 1-Piece (20 MOA Cant) 835 P-TACTICAL 2-Piece 16349 P-TACTICAL 2-Piece - Flat Dark Earth A-SERIES RINGS An all-new take on the classic horizontal split ring design, these new rings are precision CNCmachined from aircraft grade aluminum for high strength and low weight. Rings are available in low, medium and high variants for 1" and 30mm riflescope tubes. Compatible with most firearm/ 16166 A-Series Low Rings Matte 16167 A-Series Medium Rings Matte 16168 A-Series High Rings Matte 16179 A-Series (30mm) Rings Medium Matte 16180 A-Series (30mm) Rings High Matte 16181 A-Series Rimfire Rings Medium Matte scope combinations, these rings fit Picatinny and Weaver-style mount bases. 69 RIFLESCOPE RETICLE SUBTENSIONS BLACK FX & BLACK X Reticle Subtensions (AT 100 YARDS) BLACK FX1000 BLACK X1000 4-16x50SF 6-24x50SF 4-16x50SF 6-24x50SF FX-MOA/IL FX-MOA FX-MRAD/IL FX-MRAD FX-MOA/IL FX-MOA FX-MRAD/IL FX-MRAD X-MOA/IL X-MOA IL X-MRAD IL X-MOA IL X-MRAD 4x-16x 4x-16x 6x-24x 6x-24x 16x 16x 18x 18x MOA MRAD MOA MRAD MOA MRAD MOA MRAD A 0.14 0.038 0.14 0.038 0.15 0.5 0.15 0.5 B 0.75 0.1 0.75 0.1 2 1 2 1 C 1 0.2 1 0.2 10 2 10 2 D 1.5 0.3 1.5 0.3 20 5 20 5 E 2.5 0.6 2.5 0.6 1 0.25 1 0.25 F 2.75 0.7 2.75 0.7 4 4 G 5 1 5 1 6 6 H 10 2 10 2 I 20 8 20 8 J 30 30 MONARCH M5 Reticle Subtensions (AT 100 YARDS) 3-12x42SF 3-12x42SF 3-12x42SF 4-16x42SF 4-16x50SF 4-16x50SF 5-20x50SF BDC Nikoplex MK1-MOA BDC BDC MK1-MOA MK1-MOA inches inches MOA inches inches MOA MOA 3x 12x 3x 12x 12x 4x 16x 4x 16x 16x 20x A 1 0.25 2.52 0.63 0.15 1 0.25 1 0.25 0.15 0.15 B 24 6 0.64 0.16 1 16 4 16 4 1 1 C 6 1.5 23.16 5.79 1.75 6 1.5 6 1.5 1.75 1.75 D 8 2 2 8 2 8 2 2 2 E 8 2 4 8 2 8 2 4 4 F 18 4.5 5 18 4.5 18 4.5 5 5 G 28 7 10 28 7 28 7 10 10 H 44 11 20 44 11 44 11 20 20 I 60 15 30 60 15 60 15 30 30 J 4 1 4 1 4 1 BLACK FORCE Reticle Subtensions (AT 100 YARDS) BLACK FORCE100 1-6x24 IL FORCE-MOA 6x MOA A 0.5 B 2 C 2 D 2 E 4 F 0.5 G 8 H 2 I 2 J 2.5 K 33 L 45 M 12 N 8 O 24 P 49 Q 25 R BLACK FORCE1000 1-4x24 IL SPEEDFORCE 4x MOA 2 17 25 1 1.5 0.5 4 2.5 10 17.5 20 35 3.2 6.3 6.5 8.5 5 3 70 30 20 10 30 20 10 10 20 30 10 20 10 30 B E CC 10 D A H I 10 J A F B A 20 E B D 30 E F G G FX-MOA 12 8 8 12 8 12 16 20 24 FORCE-MOA 8 6 4 2 8 6 4 2 2 4 6 8 2 4 6 8 B B E F DC E F 2 4 6 8 B C GC D 2H A I A 4 A G G FX-MRAD B E C D A X-MOA F B G L K J L K J RA Q O H P D D C B AF E A D I F F Q H A R G F M N F I L SPEEDFORCE A A EB A B D C X-MRAD RIFLESCOPE RETICLE SUBTENSIONS M-TACTICAL Reticle Subtensions (AT 100 YARDS) M-TACTICAL M-TACTICAL .308 1-4x24 3-12x42SF MK1-MOA MK1-MOA MK1-MRAD 4x 16x 16x MOA MOA MRAD A 0.35 0.15 0.05 B 1.5 1 0.25 C 1.75 1.75 0.5 D 2 2 1 E 4 4 1.5 F 5 5 6 G 10 10 10 H 20 20 I 30 30 J K L M N O P Q R S T U V W X 4-16x42SF BDC 800 16x inches 0.2 7 0.6 1 0.75 2 3.5 5 6.5 8.25 10.25 12.5 14.5 16.75 19 21.75 24.5 27.25 30.5 33.8 1 0.5 0.2 0.6 M-TACTICAL .223 4-16x42SF BDC 600 16x inches 0.25 8 0.5 1 0.75 1.5 2.5 3.75 5 6.5 8.25 10.25 12.5 14.75 17 1 P-TACTICAL Reticle Subtensions at 100 yards, P-TACTICAL RIMFIRE at 50 yards P-TACTICAL P-TACTICAL .308 P-TACTICAL 300BLK P-TACTICAL .223 P-TACTICAL RIMFIRE 3-9x40 4-12x40 2-7x32 1.5-4.5x20 3x32 3-9x40 4-12x40 2-7x32 MK1-MOA MK1-MRAD BDC 800 BDC Supersub BDC 600 BDC Carbine BDC 600 BDC 600 MK1-MOA BDC 150 9x 9x 12x 7x 4.5x 3x 9x 12x 7x 7x MOA MRAD inches inches inches inches inches inches MOA inches A 0.15 0.05 0.2 0.5 0.5 1 0.25 0.25 0.2 0.3 B 1 0.25 7 30 8 24 8 8 1 8 C 1.75 0.5 0.6 3 1 1 0.5 0.5 1.75 1 D 2 1 1 2 2 3.4 1 1 2 2 E 4 1.5 0.75 2.5 1 5.5 0.75 0.75 4 4.5 F 5 6 2 5 1.5 14.25 1.5 1.5 5 7 G 10 10 3.5 8 3.75 20 2.5 2.5 10 11 H 20 5 11.5 5 3 3.75 3.75 20 15 I 30 6.5 15 6.5 5 5 30 2 J 8.25 19.5 8.25 6.5 6.5 1.4 K 10.25 24 10.25 8.25 8.25 L 12.5 29 12.5 10.25 10.25 M 14.5 35 14.75 12.5 12.5 N 16.75 2 17 14.75 14.75 O 19 6 1 17 17 P 21.75 9 1 1 Q 24.5 12 R 27.25 0.5 S 30.5 1.5 T 33.8 U 1 V 0.5 W 0.2 X 0.6 A B E C F G H D J I BDC BDC 150 BDC 600 C BE D G H F I A MK1-MOA C D CB B E CF B C A D G D G F E A MK1-MRAD A C B Nikoplex BDC SuperSub BDC Carbine BDC 800 71 RIFLESCOPE RETICLE SUBTENSIONS PROSTAFF P3 RETICLE SUBTENSIONS (INCHES AT 100 YARDS) 2-7x32 3-9x40 3-9x40 3-9x50 3-9x50 4-12x40 4-12x40 4-12x40 BDC 2x 7x Nikoplex 3x 9x BDC 3x 9x Nikoplex 3x 9x BDC 3x 9x Nikoplex 4x 12x BDC 4x 12x Mildot 4x 12x A 0.75 0.25 2.58 0.86 0.75 0.25 2.58 0.86 0.75 0.25 1.95 0.65 0.75 0.25 6 2 B 30 10 0.66 0.22 24 8 0.66 0.22 30 10 0.51 0.17 18 6 0.75 0.25 C 4.5 1.5 23.76 7.92 4.5 1.5 23.76 7.92 4.5 1.5 17.82 5.94 4.5 1.5 108 36 D 6 2 6 2 6 2 6 2 2.16 0.72 E 6 2 6 2 6 2 6 2 10.8 3.6 F 13.5 4.5 13.5 4.5 13.5 4.5 13.5 4.5 G 21 7 21 7 21 7 21 7 H 33 11 33 11 33 11 33 11 I 45 15 45 15 45 15 45 15 J 3 1 3 1 3 1 3 1 6-18x40 BDC 6x 18x 0.75 0.25 30 10 4.5 1.5 6 2 6 2 13.5 4.5 21 7 33 11 45 15 3 1 6-18x40 Mildot 6x 12x 18x 4 2 1.33 0.5 0.25 0.17 72 36 24 1.44 0.72 0.48 7.2 3.8 2.4 BUCKMASTERS II Reticle Subtensions (INCHES @ 100 YARDS) 3-9x40 4-12x40 3-9x50 BDC BDC BDC 9x 12x 9x A 0.25 0.25 0.25 B 8 6 8 C 1.5 1.5 1.5 D 2 2 2 E 2 2 2 F 4.5 4.5 4.5 G 7 7 7 H 11 11 11 I 15 15 15 J 1 1 1 PROSTAFF P5 Reticle Subtensions (AT 100 YARDS) 2.5-10x42 2.5-10x42 3-12x42SF 4-16x42SF 4-16x42SF 4-16x50SF 6-24x50SF BDC Nikoplex BDC BDC MK1-MOA BDC BDC inches inches inches inches MOA inches inches 2.5x 10x 2.5x 10x 3x 12x 4x 16x 16x 4x 16x 6x 24x A 1 0.25 3 0.75 1 0.25 1 0.25 0.15 1 0.25 1 0.2 B 28 7 0.8 0.2 24 6 16 4 1 16 4 12 3 C 6 1.5 27.6 6.9 6 1.5 6 1.5 1.75 6 1.5 6.4 1.6 D 8 2 8 2 8 2 2 8 2 8 2 E 8 2 8 2 8 2 4 8 2 8 2 F 18 4.5 18 4.5 18 4.5 5 18 4.5 18 4.5 G 28 7 28 7 28 7 10 28 7 28 7 H 44 11 44 11 44 11 20 44 11 44 11 I 60 15 60 15 60 15 30 60 15 60 15 J 4 1 4 1 4 1 4 1 2 0.5 A C B Nikoplex A C D E B Mildot A B E C F G H D J I BDC C BE D G H F I A MK1-MOA 72 RIFLESCOPE RETICLE SUBTENSIONS PROSTAFF P3 SPECIALTY Reticle Subtensions (INCHES @ 100 YARDS) PROSTAFF P3 PREDATOR HUNTER PROSTAFF P3 MUZZLE-LOADER PROSTAFF P3 SHOTGUN 3-9x40 BDC PREDATOR 4-12x40 BDC PREDATOR at 100 yds at 100 yds 3x 9x 4x 12x A 0.75 0.25 0.75 0.25 B 24 8 24 8 C 9 3 9 3 D 6 2 6 2 E 3 1 3 1 F 12 4 12 4 G 9 3 9 3 H 16.5 5.5 16.5 5.5 I 24 8 24 8 J 3 1 3 1 3-9x40 BDC 300 at 100 yds 3x 9x 0.75 0.25 24 8 4.5 1.5 6 2 6 2 12 4 24 8 39 13 54 18 6 2 2-7x32 BDC 200 at 100 yds 2x 7x 1.75 0.5 28 8 5.25 1.5 8.75 2.5 8.75 2.5 18.38 5.3 28 8 42 12 63 18 7 2 3-9x40 BDC 200 at 100 yds 3x 9x 0.75 0.25 24 8 4.5 1.5 6 2 7.5 2.5 15.75 5.25 24 8 36 12 54 18 6 2 SPECIALTY Reticle Subtensions (INCHES) FORCE XR SCOPES PROSTAFF P3 CROSSBOW PROSTAFF P3 TARGET EFR PROSTAFF RIMFIRE II 2x20 2.5-8x28 3x32 3-9x40AO 3-9x40 4-12x40 Nikoplex BDC Handgun BDC 60 PRECISION BDC 150 BDC 150 at 100 yds at 100 yds at 100 yds at 50 yds at 50 yds at 50 yds 2x 8x 3x 3x 9x 9x 12x A 2.38 0.25 0.25 0.75 0.25 0.25 0.25 B 0.8 10 6 90 30 8 8 C 40.95 1.5 0.75 2.25 0.75 1.5 1.5 D 2 1.25 45 15 2 2 E 2.5 0.5 3 1 2 2 F 6 1 4.5 4.5 G 15 3 7 7 H 1 2.75 11 11 I 6.5 15 15 J 11 1 1 K 14 L 20 M 1 A B E F G H C I J D BDC 200 A F B J C G D H E I BDC Predator A B E F G C H I J D BDC 300 A C B Nikoplex A B E C F G D H BDC Handgun . ) / * + 0 1 , - 2 ( 3 4 BDC 60 ( ) * + , PRECISION BDC 150 73 FEATURE & PERFORMANCE ICON DESCRIPTION KEY Throughout the pages of this catalog, feature and performance icons are used to help in comparing and selecting the right product for your intended use. Below is a detailed description for each: Multilayer Coating Multilayer coating is applied to one or more lens and prism surfaces. Glass Etched Reticle Extremely durable, yet fine and detailed reticle design that maintains color and contrast in all light conditions. 1x Magnification For both-eyes-open engagement. Wide Field of View (Binocular) Models that have fields of view of 60° or greater, based on the ISO 14132-1:2002 standard. (Riflescope) Wide field of view is considered to be greater than 100 ft. at 100 yds. (Laser Rangefinder) Models that have fields of view of 7.50 or greater. Long Eye Relief (Binocular) Provides 15mm or more of eye relief (12mm+ for compacts). Perfect for eyeglass wearers. (Laser Rangefinder) Provides 15mm or more of eye relief. Perfect for eyeglass wearers. Generous, Consistent Eye Relief (Riflescope) Keeps your brow safe. 2x Zoom Ratio For select Fieldscope eyepieces. OPTICS Armor Lens Coating Scratch-resistant coatings for eyepiece and objective lenses. High Contrast Optical system provides ultra-high contrast and sharp images. 3x Zoom Ratio Offers flexibility for a variety of hunting situations. Fully Multicoated Optics Multiple layers of anti-reflective coating on all air-to-glass surfaces maximize light transmission, brightness and contrast. ED Glass ED (Extra-low Dispersion) glass reduces chromatic aberration to a remarkable degree, providing clear images with superior contrast. Field Flattener Delivers sharp images all the way to the edge of the field of view. 4x Zoom Ratio Offers maximum magnification versatility. 5x Zoom Ratio Offers extreme range of magnification adjustment. 6x Zoom Ratio Offers extreme range of magnification adjustment. TRUCOLOR Proprietary coating that minimizes the bluish tint common to reflex and dot sights. PRISMS 74 Dielectric High Reflective Multilayer Coating This coating features reflectance that exceeds 99%. By utilizing light interference, this coating assures high reflectivity across the full visible range, and ensures high color reproducibility. Phase Correction Coating Phase-correction coating is applied to the roof (Dach) prism surface to minimize loss of resolution, ensuring high-contrast images. Silver Prism Coating Silver-alloy prism coating which features high reflectance is applied to the roof (Dach) prism. BODY Waterproof O-ring sealed to prevent moisture from entering body. 18 Argon Purged Purged using higher-specification argon gas for total reliability against thermal shock and internal fogging. 30mm Main Body Tube Indicates 30mm diameter main body tube. Locking Diopter Retains your personal setting. Heavy Recoil Resistant Built to withstand the recoil of the hardesthitting calibers. Shockproof (Binocular, Rangefinder) Shrugs off rugged use. (Riflescope) Shrugs off hard recoil and rugged use. 7 Nitrogen Purged Purged using nitrogen gas for total reliability against thermal shock and internal fogging. Tripod Adaptable Ability to use tripod adapter to mount to tripod. One-Inch Tube Indicates One-Inch diameter main body tube. Interchangeable Turret Compatible with Nikon's Spot On Custom Turrets. (For North America only). OLED Display High visibility red display provides ideal contrast on distant targets. One-Piece Main Body Tube Construction For minimum weight, maximum strength and durability. Spring-Loaded Instant Zero-Reset Turrets Spring-loaded Windage and Elevation knobs can be reset to "zero" after sighting-in for easy reference when making field adjustments. STABILIZED Image-stabilized to provide the easiest single-handed operation. Quick Focus Eyepiece Smooth-turn aluminum ring with rubberized eye guard allows crisp reticle focus and quick target acquisition. Return-to-Zero Stop Proprietary design is easy to set up and retains your zero point until you change it. FUNCTION Night Vision Compatible Certain brightness settings are compatible with night vision gear (typically the initial 2 settings). HYPER READ Laser provides quick and stable measurement response regardless of distance (approx. 0.3 seconds). Side Focus Parallax Adjustment Side Parallax knob allows adjustment without changing shooting position. ID Technology Delivers the one number you need for your best shot to account for incline or decline shooting angles. TRU TARGET Technology that allows you to switch between First Target and Distant Target modes. 75 CONTACT All Nikon Trademarks are the property of Nikon Canada inc. Technical Information 1-877-534-5510 Service & Repair 1-877-534-5510 Nikon Service & Repair Centre 1366 Aerowood Dr., Mississauga, ON L4W 1C1 Features and specifications subject to change without notice. © Copyright 2019 Nikon Canada Inc. TM/ ® & © 2018 TrueTimber Outdoors Holding Company, LLC. Manufactured and/or distributed under official license by Nikon Canada Inc. iPhone and iPad are registered trademarks of Apple Inc. Android is a trademark of Google Inc. Scopecoat is a trademark of SENTRY Products Group, LLC. Switchview is a trademark of Mike Gibson Manufacturing. All Nikon Trademarks are the property of Nikon Corporation. www.nikonsportoptics.caAdobe InDesign CC 14.0 (Macintosh) Acrobat Distiller 15.0 (Windows)
