Operation manual
EE310
Humidity/Temperature Transmitter
BA_EE310_e // V2.2 // Technical data subject to change // 194474

E+E Elektronik® Ges.m.b.H. provides no warranty of any kind for this publication and accepts no liability for improper use of the products described.
This publication might contain technical inaccuracies or typographical errors. The content is revised regularly and is not subject to change management. The manufacturer reserves the right to modify or change its described products at any time.
© Copyright E+E Elektronik® Ges.m.b.H. All rights reserved.
USA FCC notice
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
CANADA ICES-003 Issue 5:
CAN ICES-3 A / NMB-3 A

CONTENT

1 General..................................................................................................................................................4
1.1 Explanation of symbols..................................................................................................................................4 1.2 Safety instructions..........................................................................................................................................4
1.2.1. General safety instructions....................................................................................................................................4 1.2.2. Alarm module with voltages >50 V (option AM2).................................................................................................. 4 1.2.3. Integrated power supply 100...240 V AC (option AM3)......................................................................................... 4 1.2.4. Mounting, start-up and operation.......................................................................................................................... 4 1.2.5. Intended Use.........................................................................................................................................................5 1.2.6. Disclaimer.............................................................................................................................................................5 1.3 Environmental aspects...................................................................................................................................5 1.4 ESD Protection...............................................................................................................................................5
2 Scope of supply....................................................................................................................................6

3 Product design.....................................................................................................................................6
3.1 Dimensions ....................................................................................................................................................7 3.1.1. Enclosure..............................................................................................................................................................7 3.1.2. Probes...................................................................................................................................................................7
4 Installation............................................................................................................................................8
4.1 Mechanical installation...................................................................................................................................8 4.1.1. Mounting of the polycarbonate enclosure............................................................................................................. 8 4.1.2. DIN rail mounting of the polycarbonate enclosure................................................................................................ 8
4.2 Electrical connection......................................................................................................................................9 4.2.1. Electrical connection and wiring.......................................................................................................................... 10
4.3 Probe mounting (wall / duct version)............................................................................................................13 4.4 Mounting remote sensing probe of EE310-T5..............................................................................................13 4.5 Mounting pressure tight probe of EE310-T10..............................................................................................14
4.5.1. Installation of the probe directly in the process (see Fig. 10).......................................................... 14
4.5.2. Installation of the probe with ball valve set.......................................................................................................... 14

5 Optional modules...............................................................................................................................16
5.1 Alarm module (option AM2)..........................................................................................................................16 5.2 Integrated power supply 100...240 V AC (option AM3)................................................................................17 5.3 RS485 Module - Modbus RTU (option J3)...................................................................................................18 5.4 Ethernet Module - Modbus TCP (option J4).................................................................................................18
5.4.1. Available TCP and UDP ports............................................................................................................................. 18 5.4.2. IPv4-Settings.......................................................................................................................................................19 5.4.3. Retrofit with Ethernet Module.............................................................................................................................. 20 5.5 Modbus Map.................................................................................................................................................20 5.6 Pluggable probe (option PC4)......................................................................................................................21

6 Operation............................................................................................................................................22
6.1 Configuration interface.................................................................................................................................22 6.2 3.5" TFT Colour Display...............................................................................................................................23 6.3 Chart + Data logger .....................................................................................................................................23 6.4 Configuration Menu ....................................................................................................................................24 6.5 Status information .......................................................................................................................................25 6.6 Buzzer ON / OFF ........................................................................................................................................25 6.7 Error indication ............................................................................................................................................25
7 Maintenance........................................................................................................................................26
7.1 Self diagnosis and error messages..............................................................................................................26 7.1.1. Error messages via display.................................................................................................................................26 7.1.2. Error messages via LEDs...................................................................................................................................26 7.1.3. Solving typical problems.....................................................................................................................................27
7.2 Cleaning the sensing head / filter replacement............................................................................................27 7.3 RH / T adjustment and calibration................................................................................................................27
8 Replacement parts / Accessories.....................................................................................................28

9 Technical data.....................................................................................................................................29

10 Appendix ............................................................................................................................................30
10.1 Overview......................................................................................................................................................30 10.2 Detailed information.....................................................................................................................................30 10.3 Optional menu .............................................................................................................................................33

Operating instructions for EE310 Humidity / Temperature Transmitter

3

1 General
This operation manual serves for ensuring proper handling and optimal functioning of the device. The operation manual shall be read before commissioning the equipment and it shall be provided to all staff involved in transport, installation, operation, maintenance and repair.
The operation manual may not be used for the purposes of competition without the written consent of E+E Elektronik® and may not be forwarded to third parties. Copies may be made for internal purposes. All information, technical data and diagrams included in these instructions are based on the information available at the time of writing.
1.1 Explanation of symbols
This symbol indicates safety information. It is essential that all safety information is strictly observed. Failure to comply with this information can lead to personal injuries or damage to property. E+E Elektronik® assumes no liability if this happens.
This symbol indicates instructions. The instructions shall be observed in order to reach optimal performance of the device.

1.2 Safety instructions

1.2.1 General safety instructions

· Avoid any unnecessary mechanical stress and inappropriate use. · When replacing the filter cap make sure not to touch the sensing elements. · For sensor cleaning and filter cap replacement please see "Cleaning instructions" at www.epluse.com. · Installation, electrical connection, maintenance and commissioning shall be performed by qualified
personnel only. · The devices are designed for the operation with class III supply (EU) and class 2 supply (NA). · The power supply must be switched off before opening the housing. · An existing Ethernet connection must be disconnected before opening the housing.

1.2.2 Alarm module with voltages >50 V (option AM2)

The optional alarm module is isolated from the low-voltage side of EE310 by a special partition; this must remain fitted at all times in the back section of the enclosure. The EE310 enclosure must be tightly closed during operation. An open enclosure corresponds to IP00 and exposes components carrying dangerous voltage. Any work (maintenance for instance) on the device may be performed by qualified staff only.

1.2.3 Integrated power supply 100...240 V AC (option AM3)

The EE310 enclosure must be tightly closed during operation. An open enclosure corresponds to IP00 and exposes components carrying dangerous voltage. Any work (maintenance for instance) on the device may be performed by qualified staff only.

1.2.4 Mounting, start-up and operation

The device has been produced under state of the art manufacturing conditions, has been thoroughly tested and has left the factory fulfilling all safety criteria. The manufacturer has taken all precautions to ensure safe operation of the device. The user must ensure that the device is set up and installed in a manner that does not have a negative effect on its safe use.

The user is responsible for observing all applicable safety guidelines, local and international, with respect to safe installation and operation on the device. This operating manual contains information and

4

Operating instructions for EE310 Humidity / Temperature Transmitter

warnings that must be observed by the user in order to ensure safe operation.
· Mounting, start-up, operation and maintenance of the device may be performed by qualified staff only. · Such staff must be authorized by the plant operator to carry out the mentioned activities. · The qualified staff must have read and understood this operating manual and must follow the instruc-
tions contained within. · All process and electrical connections shall be thoroughly checked by authorized staff before putting
the system into operation. · Do not install or start-up a device supposed to be faulty. Make sure that such devices are not acciden-
tally used by marking them clearly as faulty. · A faulty device may only be investigated and possibly repaired by qualified, trained and authorized
staff. If the fault cannot be fixed, the device shall be removed from the system. · Service operations other than described in this operating manual may only be performed by the
manufacturer.
1.2.5 Intended Use
EE310 is optimized for reliable measurement in demanding industrial applications. In addition to highly accurate measurement of relative humidity (RH) and temperature (T), the transmitter also calculates parameters such as dew point, absolute humidity and mixing ratio. Various models are available including wall, duct and remote probe. The remote probe can be used up to 180 °C (356 °F) and the pressure tight probe up to 20 bar (290 psi). The use of the EE310 other than described in this manual is not allowed.
The manufacturer cannot be held responsible for damages as a result of incorrect handling, installation and maintenance of the device.
Unauthorized modifications of the product lead to loss of all warranty claims. The device may only be powered as decried in this manual.
1.2.6 Disclaimer
The manufacturer or his authorized agent can only be held liable in case of willful or gross negligence. In any case, the scope of liability is limited to the corresponding amount of the order issued to the manufacturer. The manufacturer assumes no liability for damages incurred due to failure to comply with the applicable regulations, operating instructions or the operating conditions. Consequential damages are excluded from the liability.
1.3 Environmental aspects
Products from E+E Elektronik® are developed and manufactured observing of all relevant requirements with respect to environment protection. Please observe local regulations for the device disposal.
For disposal, the individual components of the device must be separated according to local recycling regulations. The electronics shall be disposed of correctly as electronics waste.
1.4 ESD Protection
The sensing elements and the electronics board are ESD (electrostatic discharge) sensitive components of the device and must be handled as such. The failure to do so may damage the device by electrostatic discharges when touching exposed sensitive components.

Operating instructions for EE310 Humidity / Temperature Transmitter

5

2 Scope of supply
EE310 according to ordering guide Operation manual Inspection certificate according to DIN EN 10204 ­ 3.1 Mating plug for integrated power supply Mating plug RKC 5/7 Mating plug RSC 5/7 (2 pcs. for option E12) Mating plug HPP V4 RJ45 Cat5
3 Product design
1 2
3

Included in the scope of supply of: all versions all versions all versions AM3
AM3 / E4 / E6 / E12 E5 / E6 / E12 J4
1

4 4

5 5
6

6

7

7

8

8

EE310-T5/T10

EE310-T1

Fig. 1 Product design

1 Front section with electronic / display* and probe cable 2 3.5" TFT colour display* 3 5 push-buttons for configuration menu 4 Back section with electrical connection, alarm* + supply module* and mounting holes 5 Micro USB service interface 6 Standard cable glands / connectors* 7 Additional cable gland / connector* 8 Probe / cable gland / connector*

* optional

Connection terminal block

RS485 add on chip

Back section
Space for optional modules

Fig. 2 6

Modular enclosure

Front section Mounting plate
Operating instructions for EE310 Humidity / Temperature Transmitter

3.1 Dimensions

3.1.1 Enclosure
Polycarbonate
180 (7.09") 166 (6.54") 153 (6.02")

71
(2.80")

Stainless steel
218 (8.58") 200 (7.87") 186 (7.32")

73
(2.87")

54 (2.13") 104 (4.09") 75 (2.95") 110 (4.33")

5.1
(0.20")
3.1.2 Probes T1: Wall mount

5.1
(0.20")

T5: Remote probe up to 180 °C (356 °F)

code ,,cable length"1)

L2)

code ,,probe length"1)

15 (0.60")

12 (0.47")

53 (2.09")

L2)

T2: Duct mount

200 (7.87")

L2)

12 (0.47") 13 (0.51")
12
(0.47")

T10: P ressure tight probe up to 20 bar (300 psi)

code ,,cable length"1)

L2)

200 (7.87")

15 (0.60")

adjustable

1/2" ISO or 1/2" NPT

min. 23 (1") / max. 164 (6.5")

1) Refer to ordering guide 2) L = filter length; refer to data sheet "Accessories"

Operating instructions for EE310 Humidity / Temperature Transmitter

7

4 Installation
4.1 Mechanical installation
4.1.1 Mounting of the polycarbonate enclosure · Drill the mounting holes according to the corresponding mounting pattern below. · Mount the back section of the enclosure with 4 screws (screw diameter < 4.2 mm (0.2"), not included in the scope of supply).
166 (6.54")

54 (2.13") 14 (0.55")

7 (0.28")

5.1 (0.20")

Fig. 3

Drilling pattern of polycarbonate enclosure in mm / inch 200 (7.87")

75 (2.95")

7 (0.28")

5.1 (0.20")

Fig. 4 Drilling pattern of stainless steel enclosure in mm / inch

4.1.2 DIN rail mounting of the polycarbonate enclosure

· Mount the two DIN rail brackets (to be ordered separately, see chapter 8) onto the back section. · Snap in the enclosure onto the DIN rail

Fig. 5 DIN rail installation 8

Operating instructions for EE310 Humidity / Temperature Transmitter

4.2 Electrical connection
The electrical installation of the EE310 shall be performed by qualified personnel only. Observe all applicable national and international requirements for the installation of electrical devices as well as for power supply according to EN 61140, class III (EU) and class 2 supply (North America).
For EE310 with alarm module (option AM2) or integrated power supply 100...240 V AC (option AM3), the metal housing must be grounded during operation.
Connection diagram

8 - 35 V DC 12 - 30 V AC
V mA V mA

V+ GND GND OUT 1 OUT 2 GND RS485 RS485 A (=D+) RS485 B (=D-)

1
Supply 2

3

4 Analogue outputs

5

6

Modbus RTU

7

(galvanically isolated)

8

Fig. 6 Electrical connection
Analogue outputs Both analogue outputs shall be configured to either voltage or current. Measurands, analogue output range and scaling are freely selectable. All settings can be performed via display and push buttons or using the EE-PCS Product Configuration Software, see EE-PCS Product Configuration Software, see chapter 6.1.
Error indication The analogue outputs feature an error indication function according to NAMUR NE43. In the case of an error the output signal will freeze at 21 mA or 11 V respectively.
Note By default the error indication is disabled.

When changing one of the analogue outputs from current to voltage and vice versa, the second output will change automatically as well. The output scaling changes automatically if it is out of physical range (i.e. 20 mA will be changed to 10 V instead of 20 V).
Check output scale after changing between voltage and current output.

Operating instructions for EE310 Humidity / Temperature Transmitter

9

4.2.1
Option Cable glands
J4

EleScttarincdalacrdonnection andEwEi3ri1n0g/EE360 - Electrical connection for stainless steel housing (HS2)

Standard PSSotltayancnadrdbaaorrnddate enclosure

Standard StainlSestsasntSdeteaalnreddnaclrVods+ure
GNVD+

1

Pin assignment Option E4

21

V+

1

2x M16x1.5
Option J24x M16x1.5 Option2Jx 4M16x1.5 OOppttiioonnJ2J4x4M16x1.5

GGNVND+D V+

3121

OGUGNTND1D

423

GVN+D

12

GGNNDD

23

GND

2

OOGUUNTTD21

534

OGUNTD1

34

O1OxpSRRpRMtStSitSGGa1o4i4GG46o8NNn8n8NNx55nDDd15DDA2J.BaARR5OO2JxRR4(OOOxSSr(=m(UU4M=SS=GdUUU44DMTTDo44D188NTTT+u8816-5512+D))n556122x)tx1e1.d5.5

3 6445 7556 6876

1 xRRMRSSS1446488x85155A.A5B(=e((=Dn=DcD+l+o)-))sed

778

OOUUTT12 GNDORUST482V5 + RGS4N8D5 RAS(=4D8G5+N)D RRSS484585AB(=(D=G+D)N-)D

45
56 1 67 2 paonwaleorg7su8ue3populytp+ut

o

RS485 B (=D-)

8

RS485 B (=ODU-)T 1

84

RS485 B (=D-)

8

OUT 2

5

2x M16x1.5
OpOtpiotionnJE45

GND RS485

6

Option E6

RS485 A (=D+)

7

RS485 B (=D-)

8

EE310/EE360 - Electrical connection for stainless steel housing (HS2)

Ethernet

MEothdebrunseTt CP

SEtathnedrnaertd

Option E4

EE310/EE360 - EleEMcthotedrrbincuestaTlCcPonnection for stainElMtehoesdrnbseutssTtCePel housing (HS2)

OptioMnEothdEebr4unseTt CP

Modbus TCP

Modbus TCP
StaOndpatirodn E4

OptOiopntMio1En6x4E1.45 GND Output

Oppotwioenr sAuMpp3ly +

E4

OOppttiioonnEE44

OptionMoEdb4us RTU GND Output

OUT 2

GND OuGtpNuDt

GaNnaDloOgutepuotutput ModbuGsNRDTUOutput

power supply +

1 x M16x1.5apnmoawolouegnrutseeudopuptlypu+t

1 x M16xO1.p5papaonteoniwanowaleocleonrlgorgsussuuEeeuepdop5poupluytlyptp+u+utt

E5

OpantiaolonguEe o5utput

OpOtOioppnttiEioo5nnEE55

4 3 OUT 2

Ethernet Modbus TCP

GND

Output GND

OUT 2
4 5 3 1OxUMT126x1.5 mounted 144 5 32 1OxVMp+1ti6ox1n.5Een4closed

GND GND OUT 1

1 5 32 V+

OUT 1

11 5 22 ppaoVonVw+wa+eleor rgssuuuepppoplyulypat+pon+uwatleorgsuuepopulytp+uOOt UUTT11

anaOlopgutieoonuEtp5ut GND RS485

Option E5 Option E5

(sGhNieDldRedS)485 G(sNhDieRldSed4)85

3 4 nO.c.ption E6 (sGhNieDldRedS)4R85S485 A
np.ocw. er supply + (shielded) RS(4=8D5+A)

OUT 2

GND

OUT 2
414 55 332 V+ 1 2 V+Modbus RTU

GND
power supply + GanNaDloOgOuueUtpTouut1tput
OUT 1

(only with

4 3 OoUrdTe2r code J3)

GND

OapntaiolonguEe6output

V+

1

GND RS48p5ower supply
5 100...240 V AC
G(NshDieRldSe4d8) 5OUT 1
2 (shOiepldtieodn) AM2

n.c.

RS485 A

o

Modbus RTU
M1M6oxd1b.5us RTU
OMpotdiobuns RET6U MOodMpboutdisobRunTsURET6U OOppttiioonnEE66

M16x1.5 M16x1.5 M16x1.5 M16x1.5

na.cn.alogue output

RS48(=5DA+)

n.c.

3 5 4 3 4 n.c. 233 5 414 3 5 4 RS48O5 Bption E5

n.cR.S(4=(8=D5D++A))

2 5 1 2 5 1 (=RDS-4)85 B M16x1.5

n.c.

RS485 B

2 5 1 2 1 R(=SD48-)5 B 2 1 (=RDS-4)85 B

Modbus RTMU16x1.5 M16x1.5

n.c. n.c.

R(S=4D8-)5 B (=D-) n.c.

RS48(=5DA+) (=D+)
GND RSn4.c8.5 (spahoniewalldeoerngd.suc)ue.populytp+ut Modbus RTU RS485 A

(=D-)Modbus RTU Modbus RTU power supply +

3

42x M16x1.5(=D+)

OptioMnodEbu6saRnTaUlogue output Option E6

RS485 B

2 5 1 n.c.

M16x1.5

(=D-)

Modbus RTU

Modbus RTU power supply + Modbus RTU apnoawloegruseuopuptlypu+t
MOMopoddtbbiuoussnRRTETUU12papaononwawaleoleorgrgsusuueuepoppoupluytlyptp+u+ut t Option E12analogue output OOppttiioonnEE1122 10

Option E6

GND RS485

GND Output

(sGhNieDldRedS)485

GNGDNRDS4O8u5tput

Modnb.cu.s RTU
3 4 4 3 Modbuns.cR. TU n.c.

papaononwawaleoleorgG(rgsusG((sssuuNehNhhuepiDeoiippDeeolupdlRllyutddRlepyStee+dpuSdd4+)utRR4))8Rt8SS5S544(488=(8=55D5D+AA+A))

3 5 4 34 5 43 Optni.oc.n E12 233 5 414 314455432 RS4O85pBtion E12

nR.cS. (4=(8=D5D++A))

OUT 2
OnU.cT. 2 OOnU.UcT.T22
V+

2 5 1 2155 132 (=RDS-4)85 B

n.c.

RS485 B V+

G(NshDGieNRldDSe4dO8G)u5NtpDut (shieGldNeDd)ORGuSNtp4Du8t5 A
RGSN4D8(=5DA+) GON(U=DTD+1)
GND RSn4.c8O.5UT 1

OUT 2 OUT 2
V+

2 5 1 21 512 1 R(=SD48-)5MBodbus 2 1 1 2 (=RDS-4)85 B
(=D-)

MRToUdbpuosweRr TsuUpplynn+.c.c. .OperaRti(nS=g4DinP8-s)5toruBwctioenVrVs+f+soruEpE3p10lyHu+midaitny(s/ahTleieomlgdpeenurd.acet)Ou.OrUoeUTTuTra1tn1psmuittter

V+

ModbaunasloRguTeUoutput (=D-)Powen.rc.sMupopdlbyu+s aRnTaUloguReSo4u85tpAutPowOeUrTs2up

M16x1.5

2 1 1
1

x x

MM1166xx11M..55oMdmeobndoucbuslounRssteeTRddUTU

power supply + Man1a6lox1g.u5e output

3 5 4 MoOdbpuMstoiRodTbnUusERpa6TonUwaleorgsuuepopulytp+ut

2 1 Option 3 4 4 3 E6

OOppPOttiioooplnyntciEoaE5rnb1o2AEn6aMte3Men16cxlo1s.5ure

(=D-) RS48n5.cB. (=D-) Modbus

RTU

n.c. paonG(paswaonNhlwaeoiDelrgeolsudrRgueesuSpdueo4p)pu8olpyt5uplRy+tupS+tu4(t8=5D+A)

Modbus RTU (only with
order code J3) GND Output
analogue output

SR(t=aSDi4n-O8)le5nps.Bcst.iosnO.tncep.etAlioeMnnc3Elo6sureG(sNhiDeldRRneSS.dc44().8=8R5D5S+A4)85

OUT 2

Pin assignment

A

n.c.

GNDp1o0w0.e..r2s4u0pVplAy C

GND RS485

(shOielpdetido)n

AM2
neutral

wire

2 35 51 4 13 5 2 3 Modbus RTU

(=D+)

RS485 B Modbus RTU

n.c. power supply +

Vn.+c.

GND RORSUS4T(48N851)5 A

n.c.

(shielded) (=D+)

2 1 1 4 Option E6 2 35 514 1 4 on for stainless steel housing (HS2)
2 1 1 MoMd1b6uxs1R.5TU power supply + 3 4 4 3 Option E4OMMMoopoddtdbbibuuoussnsRRaRTnTEoTUaUu1Ulotp2gauupanpateonaonwalwaoleolegorgrugsuesuueuepopopuopultuylptytpup+u+tutt

(=D-) RS485 B

analogue outpnu.tc.

(=D-O) ptMioondbEu1s2RTU

Power pshnua.csp.eply
RS485 B (L1)

+

RnS.4c8. 5 A analoguen.ocu. tp(=uDt+)

OUT 2 phase

ModbusGNRDTRUS485
(shielded)
nO.cp. tion AMpaon3waleorgGG(susNNuhepiDDeopludOlRytepSu+duRt4)ptS8u54t 85

A

(=D-)

RS48P5fooBrwpMeorolysdcubapurpbsloyRn1TaG0UtN0eD2-exO2nMu4c1tn0pl6.oucxV.ts1.u5ArCe

(=D-O) UT 2

GND GONuDtput

(L1) V+
Power supply for polycarbo

Modbus RTU OUTn.2ac.nalogue

(=D+) n.RcS. 485 A

OUT 2 ModbuGsNDROTuUtpuGt nNeDutral wire Power suppl

3321423 5554413241 1441145553233232 E12

power supply

output

(=D+)

OMpotdibouns RET1U2
Mod(bounslyRwTiUth orpdoewr ecrosduepJp3ly) +
Option AM3analogue output
Option E12
power supply +

Mo(dobnulysR(=R(wRS=DS4iTD-th84)UM(-no58).on5ncBdln..yBcb.Mc.wu.osiAtdhRbMnoTuMarUsodloeRdordTbgpcUbououG(swudseG(NheessiDpaNherRoJonilRsD3eduRTwau)leTdltSRpUeodpep4UrgS)dul8Rsuy4)5uRetS8npS5O4o.n(pc48=u.(Ul.cy8=5tDpT.5D++Au1+A)t )

OUTp2hVa+se

(N) GND On.uct.pOuUt T 1

(L1)

V+

gOroUuTn1ding

POonUw.cnT.ec2.r supply + analognOGueUNueTDt(rPao1lEuw)tirpeut

PowPeorwseurpspulyp+playn1a0lo0(Ng-)u2e40ouVtpAuCt

phase (L1)

5 5 analogue output

order

22 5 11 11 2 power supply +

Option

E6OMpotdiobuns

RATMU 2

analogue output power supply +

3 4 AM2

Modbus RTU analogue output

RELAY 2 RELAY 2

RELAY 2

2 5 1 1 OptaionoanulotpAguutMe 3
OMpodtbiousnRATUMpow3paeonrwasleuorpgpsuuleypopulytp+ut
4 3 3 4 3 Modbus RTU 35 5 4 3 (only with orde2rxcMo1d6exJ13.5) 1 2 2 1 1 power supply + 2 5 1 1 Oanpaltoigoune oAutMpu3t 3 4 4 33 Modbus RTU

RELAY 1 RELAY 1

RELAY 1

cR(=oR(=SdDSD4e-48)-J8)a535nB)aBOlogputeioountpAutp1Mo0w03.e..r2s4u0pVplAynC.nc.c. .

Modbus RTU

OptioOnMptoAiodMnbNA2uCsMR2 TU

1

REL 2

C GNGDNODuRtpSu4t 85 2

OUT 2n.c.

NO

(sG(hsNiheiDlednled.Rcde.S)d4R)8S543R85EAL 2

(=D+)

n.c.

NC

RS4485 A
(=D+)

RER(L=R(S1=DSn4D-.84)c-58).n5SMA.BcBto.nadanblu2d2oMasxxangoRoMaMruuTdld1Not1eUpCb6g6Ouoxuxout1ep1usp.G(.5e5sotNhRrwpiaDeeuTtlrdRitUoseSOudn4pU)8RpnmT5lSny.1co4.(c.8=d56.R5DeE+A)L 1

phasVefA+onrasltoaginuleesosutG(ssptNhueiDeetldRlneSeO.dc4n)U.8cT5lo1 sure
(L1)
Powerns.cu. pply + analogue oRuSt4p8u5 tA
Power supplyNO100 - 240 V AC(1=D+) R(f=poSDh(4ra-L8)sp1p5eh)oaBnsl.nyce..cc.aNNNMrCCCObooNdNnCCObCautseGReNnTDcUn(Og(lNPoeruo)uEsn(tuntpNn)23e1rn(4unuaN.).uedcrctl)tueir.w.nta2354rgilarewl wireire
PfPfOoooIonrUpwrnw(Tvsh.Lp(ceaet1L2e.oasr)1rreti)lsnyesuNcdluCepOapsoprpsNbpllyCoeysrn1t1ae0a0te0ti0eol -en-e2n2nm4c4cn(0lNon0eloo.)56udVcnsVts.re.uaAucAlr6.rCweCeire

5 1 5 2 analogue 2 1 1 output
Option AaMnoau2lotpguutpeower supply

RELAY 2

4 3 Modbus RTU
(only with order

cpoodwe eJr3s) upply

4 5 3 Modbus RTU

1 5 2 (onlyanwaitlhogourdeer code J3) output

1 2 power supply

4 3 Modbus2Rx TMU16x1.5
(only with order code J3)

RELAY 1

1 5 2 Option AM2

REL REL

(only wiMth oorddebrucsGodNReDTJ3OU)utput

RS485 B (=D-)OUT 2

n.c.
GND Onu.tcp.ut

NC

1

OUT 2 Modbus RTU n.c.

2

C

2

n.c. NO

GND OutpOutUT 1
3

OUOTn2p.ctA.ionNnaClAogMu2e

OUT
outpunt.c4.

1

1

AnCalogue output 5

n.c.

OUT 1

NO

6

REL

StPaonwdeardsuoppelryat1io0n0 fon.rc.polycarbonate
phase

-me2non4cOd.0lcUoe.VTsu1ArCe
neutral wire

Pfoporhpw((ahLLpsa1e1oes))reAlysncuNaaCpOlrpoblgoyun1ea0to0eu-etp2n4uc0tlo(gN21Vn(rsNo)euu)uAnrtrCdeailnwgire

RELAY 2

(L1) NC

(P3gEro)unding

RELAY 1 RELAY 2

2 ph(aPLfsoP1foeo)rowrswesteartNariCsOnisNunlCueCplesppssplsylsys1te1t0ee00el0l-e-n(eg2nNer2n4co)5u4(4c0uPtlron0Ela2o1Vdsl)ViwsnuAguirrAeCerCe

NO NC

(P6E) 3

Power supp for stainles
n.c. NO
phase C (L1) NC
Power sup for polycar
NO C
phase NC
Inver(Lte1)d oper
Power su for stainl
N
N

RELRAEYLRA2EYLA1Y 2

RELAYR 2ELAY 2

Option AM2

StandAanradlooNgpCueeraotuiotnpumt ode1

REL 2

2CNx CM16x1.5

21

NO
InvPerotwederospueNprCaptliyon10m0 o- d2e40

1 V4AC

for stainleCNsOs steel enclos2u1re

N

REL 1

C

5

REL 2

NOC

32

NCC

32

NO

6

N

Option AM2

NO

3

NC

3

NNCC

14

StandaNrNdOOoperation mo1d4e

Inverted op

2x M16x1.5

RREELL21

CNCC

254

2x M16x1.5

REL 1

NNOOC

365

CNCO

254

NNCCC

365

RELAYRR1EELLAAYY12

RELAYRR1EELLAAYY 12

RELAY 1

2x M16x1.5
REL 1
Operating instructions for EE310 Humidity / Temperature Transmitter

StandardNoOperation mode6

NC

4

Standard operation mode

C

5

NO

6

RELAY 1

Inverted opNeCration mode 6

NO

4

Inverted operation mode

C

151

NC

6

OptioMnodEbu6s RTU

power supply + analogue output

onnection for stainless steel housing (HS2)

powGeNr DsuRpSpl4y8+5

Option OptioPOnoplyEtci4oarnboAnaMte3enclosure
AM3

Modbus RTU ana(lsohgieuledeodu)tput

Stainless

steel n.c.

eOncpltoiosunrAe M3

Pin assignment

RS485 A

n.c.

34

(=D+)

neutral wire
3 GND RS485(N)

Modbus RTU power supply +

5 Option AM3

2 1 RS485 B

GND RS485n.c.

(=D-)

(shielded)

(shielded)

1 np.ch.ase 3 (L1)

GND OutRpuStn4.8c5. A

4

(=D+)

n.c.

analogue output
Option E12
power supply + anaalnoagluoeguoeutput
output power supply
Modbus RTU
Option(onEly6with order code J3)
power supply + Modbus RTU analogue output

n.c.

RS485 A

3 4 Modbus RTU (=D+)

Modbus RTU
2 (only with
RoSrd4e8r5cBode J3)

5 GND Output 1 n.c.

(=D-)

4 3 OUTa2nalogue

output power

sunp.cp.ly

Modbus RT10U0...240 V AC

anoaulotOpguuptetion AM2

1 5 2 n.c.

OUT 1 power supply

Modbus RTU
(only wAithnoarldoegr cuoedeoJu3t)put

OUT 2

GND

5 Power supply 100 24 31 1 RS485fBor polycarbonate

-e2nn4c.c0lo. VsuArCe

(=D-)

phase (L1)

1 5 2 V+

OUT 1
Modbus RTU neutral wire Power su

(N)

for polyc

Poweprhsasuepply + anGaNlDogOuutepuot utput

(L1)

OUT 2

n.c.grounding

4

3

(PE)

5 Power supply 100 - 240 V AC 1 2 n.c.for stainless steelOeUnTc1losure

phase (L1)

OptpioownerAsuMpp2ly + OptionanAaloMgu3e output
Modbus RTU
2x M16x1.5
analogue output power supply
Modbus RTU (only with order code J3)

2xGMN1D6Rx1S.4585

NC (shielded)

1

Analogue output

NO

1

n.c.

REL 2

C

3 4 Option AM2

NO

2 5 1 RS485 B

(=D-)

NC

RS485 A
(=D2+)
3 n.c.
REL 2
4

RELAY 2

n.c.
phase (L1)

C3
NC NC
1 C
NO

neutral wire
(N) 2
13 n.c.
2 4

REL 1

ModbuCs RTU

5

NO
PfoorwpeorlyscuaprpbloyCn1a0t0e

-e2n4c0loVs3uArCe5

RELAY 1

NO GND Output 6

NC NC

46

2x M16x1.5

OUT 2Standard operationn.c.modeREL 1 InvertedCoperation mneoudtr5ael wire

43

phase

NO

(N)
6

n.c.

1 52

OUT 1

(L1)
Standard operation mgrooudneding
(PE)

RELAY 1

RELAY 2

RELAY 1

RELAY 2

Power s for stain Inverted o

Analogue output

Power supply 100 - 240 V AC for stainless steel enclosure

External diameter of the supply cable for option AM3: 10-12 mm (0.39-0.47").

MOapxtiimonumAMwi2re

cross

section

for

AM3

connecting
NC

cable:

1.5

m1 m²

(AWG

16)

.

NO

1

RELAY 2

RELAY 2

External Maximal

diameter of the cabRleELfo2r Modbus wire cross section for connecting

cRaTCbUlea: n0d.5amnamlo² g(AuW2eGo2u1)t.put

female

plugC:

4

-

6

mm

(0.162-

0.24").

NO

3

NC

3

RELAY 1

2x M16x1.5

NC

4

REL 1

C

5

NO

6

Standard operation mode

RELAY 1

NO

4

C

5

NC

6

Inverted operation mode

12

Operating instructions for EE310 Humidity / Temperature Transmitter

4.3 Probe mounting (wall / duct version)

Fig. 7

Mounting of model EE310-T1. The probe shall point downwards.

Fig. 8

Mounting of model EE310-T2. The probe shall be mounted horizontally or vertically pointing downwards.

4.4 Mounting remote sensing probe of EE310-T5

For mounting the probe into a separation wall use the stainless steel mounting flange. The immersion depth is adjustable. The probe shall be mounted horizontally.

416.8"

Ø

12 0.5"

sealing

13 0.5" 34 1.3"

temperature gradient along the probe shall be avoided

bow for draining condense water

drip water protection
85 3.3"

probe into separation wall

hanging probe

Fig. 9 Mounting the remote probe of EE310-T5

For accurate measurement it is of paramount importance to avoid T gradients along the probe. In case of large T difference between the front and the back of the probe, it is highly recommended to insert the probe completely into the process. Should this not be possible, place a thermal isolation layer on the part of the probe outside the process (on the cable side).

The stainless steel mounting flange is not appropriate for pressure tight mounting. For pressure tight requirements use EE310-T10.

For probe hanging onto its cable from the ceiling in applications where condensation is likely to happen it is important to avoid condense water getting from the cable to the probe and into the sensing head. For this use the drip water protection, see chapter 8.

Operating instructions for EE310 Humidity / Temperature Transmitter

13

4.5 Mounting pressure tight probe of EE310-T10
General safety instructions for installation The installation, commissioning and operation of the EE310-T10 may be performed by qualified staff only. Special attention shall be paid to the correct installation of the probe into the process. In case of inappropriate installation there is the risk for the probe to be suddenly expulsed due to the pressure in the process.
Bending over the sensing probe should be avoided under any circumstances! Make sure that the surface of the probe is not damaged during installation. A damaged probe surface may lead to damaged seals and consequently to leakage and pressure loss.
The probe is rated with leakage rate B according to EN12266-1.
4.5.1 Installation of the probe directly in the process (see Fig. 10)
For direct probe installation shut-off valves shall be placed on both sides of the probe insert. This allows the sensor probe to be easily removed for maintenance and calibration. For direct installation into a pressure chamber make sure that the pressure in the chamber and the ambient pressure are equal before removing the probe. The temperature during probe installation may deviate by max. ±40 °C (±72 °F) from the regular temperature during normal operation. Replace the metal sealing ring (see Fig. 10) by a new one every time before re-installing the probe.
Probe installation steps · Close both shut-off valves. · Place the sensor probe into the probe insert and adjust the immersion depth. · Tighten the lock nut with a torque of 30 Nm. · Open the shut-off valves.
Observe strictly the tightening torque. A torque lower than 30 Nm results in a smaller retention force of the clamping sleeve. This leads the risk of sudden expulsion of the sensing probe due to the pressure. A torque higher than 30 Nm may lead to permanent deformation of the clamping sleeve and the sensing probe. This would make the removal and re-installation of the probe difficult or even impossible.
fixed installation (pressure tight up to 20 bar (300 psi))

metal sealing ring stop valve

1/2" ISO or 1/2" NPT inside diameter  13 mm (0.55")
stop valve

Fig. 10 Installation of the EE310-T10 probe directly into the process

4.5.2 Installation of the probe with ball valve set

The ball valve set allows for installation and removal of the probe without process interruption.

For mounting into a duct, the ball valve shall be installed perpendicular to the flow direction.

The two metal sealing rings (see Fig. 11) shall be replaced every time prior to re-installing the probe.

The temperature during probe installation may deviate by max. ±40 °C (±72 °F) from the regular temperature during normal operation.

14

Operating instructions for EE310 Humidity / Temperature Transmitter

Installation of the probe (see Fig. 11) · Install the probe into the ball valve while the ball valve is closed. · Open the ball valve. · Slide the probe through the ball valve to the desired immersion depth. Depending on the process
pressure additional tools may be necessary for pushing the probe into the process. Make sure not to damage the probe and the cable. · Tighten the lock nut with a torque of 30 Nm.
Observe strictly the tightening torque. A torque lower than 30 Nm results a smaller retention force of the clamping sleeve. This leads the risk of sudden expulsion of the sensing probe due to the pressure. A torque higher than 30 Nm may lead to permanent deformation of the clamping sleeve and the sensing probe. This would make the removal and re-installation of the probe difficult or even impossible.

metal sealing ring
(as a standard contained with the probe)
extension
(is not available for an NPT thread)

metal sealing ring
(as a standard contained with the ball valve set)
1/2" ball valve

lock nut

inside diameter  13.1 mm (0.55")

adapter body

clamping sleeve sealing element 2 sealing element 1

Fig. 11 Installation of the probe by utilizing the ball valve set
Removing the probe
· Hold firmly the probe to avoid it being suddenly expulsed when releasing the lock. Do not bend damage the probe cable.
· Loosen slowly the lock nut with a spanner (spanner width 24) only till the probe is pushed out by the overpressure in the process. Do not completely loosen the lock nut, but only as much as necessary for the probe to slide.
· After the probe has been pushed out of the process up to the stop, close the ball valve. · Remove the probe from the ball valve.
Observe the correct positioning of the sealing element 1 before reinstalling the probe.

Operating instructions for EE310 Humidity / Temperature Transmitter

15

5 Optional modules

5.1 Alarm module (option AM2)

The module offers two freely configurable relay outputs for alarm or control purposes. Various operation modes are available including hysteresis, window and error indication.

Max. switch load: Min. switch load:

250 V AC / 6 A 12 V / 100 mA

28 V DC / 6 A

No overcurrent and short circuit protection. Both relays shall be connected to either high or low voltage.

RELAY 2

NC

REL 2

C

NO

NO

1

C

2

NC

3

NC

NO

4

REL 1

C

C

5

NO

NC

6

Standard

Inverted

Fig. 12 Alarm module (option AM2)

RELAY 1

PROTECTIVE CONDUCTOR TERMINAL: Maximum wire cross section: 1.5 mm²

The metal housing must be grounded during operation. National regulations for installation must be observed!

When error indication mode is selected, various errors will trigger the alarm output. An alarm output in this operation mode is used for error indication only.

Switching point

% / RH

Hysteresis

open Terminal 1-2 / 4-5
closed open
Terminal 2-3 / 5-6 closed

Fig. 13 Example hysteresis mode

Switching point 2 Hysteresis 2
Switching point 1 Hysteresis 1

% / RH

open Terminal 1-2 / 4-5
closed open
Terminal 2-3 / 5-6 closed
Fig. 14 Example window mode 16

t
t

Operating instructions for EE310 Humidity / Temperature Transmitter

ON Power OFF

% / RH

Switching point

Hysteresis

open Terminal 2-3 closed

t
Standard

open Terminal 5-6 closed

Inverted

Fig. 15 Example of alarm in case of power supply failure using inverted alarm outputs.

The measurands at the outputs as well as switching points, hysteresis and the default state (standard / inverted) can be set via EE-PCS Product Configuration Software or using the display and the push buttons (see chapter 10.3 / Fig. 35).

5.2 Integrated power supply 100...240 V AC (option AM3)
This module allows the EE310 to be powered with 100...240 V AC (50/60 Hz), 2 VA.

polycarbonate enclosure
Fig. 16 Power supply module (option AM3)

stainless steel enclosure

The AM3 option includes a 1.25 A fuse on the 100-240 V side. This fuse may not be replaced by the user, only by the E+E after sales service. The protection of the supply cable against excess current and short-circuit must be designated to a wire cross section of 0.8 mm² (AWG 18) (6A fuse). The metal housing must be grounded during operation. All national regulations for installation shall be observed!

Operating instructions for EE310 Humidity / Temperature Transmitter

17

5.3 RS485 Module - Modbus RTU (option J3)

Up to 32 EE310 transmitters with Modbus RTU interface can be connected in a RS485 bus system.

Slave n (max. 32)

Slave 2

Slave 3

Slave 1

Fig. 17 Two wire RS485 bus

Modbus RTU Master

Both ends of the bus shall be terminated with a resistor Ra=120 Ohm.

The setup of the Modbus RTU communication can be performed via EE-PCS Product Configuration Software or via display and push buttons, see chapter 10.3 / Fig. 36.

Data transmission

Baud rate Data bits Parity Stop bits Slave address

Factory settings 9600 8 EVEN 1 231

Selectable values 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 76800 8 None, odd, even 1 or 2 1...247

The recommended setting for multiple devices in a Modbus RTU network is 9600 8 Even 1.

5.4 Ethernet Module - Modbus TCP (option J4)
The Ethernet module features power over Ethernet (PoE) and RJ45 connector with IP65 protection class.
The Ethernet connection shall be disconnected before opening the enclosure!
5.4.1 Available TCP and UDP ports
Modbus TCP (Port 502) See "Modbus TCP/IP implementation guide" which can be found on www.modbus.org/docs/Modbus_ Messaging_Implementation_Guide_V1_0b.pdf. The unit identifier of the MBAP header is not used and can be any value from 0 to 255.
HTTP-Webserver (Port 80) For a quick communication check enter the desired IP in a web browser and connect with the EE310 Ethernet Module's Webserver.

18

Operating instructions for EE310 Humidity / Temperature Transmitter

Alternatively send an ICMP echo request ("ping") to check correct communication settings.

UDP (Port 5234) Backwards compatible communication protocol with EE31 device series. Communication via Ethernet takes place by means of UDP packets, which transport a command or a command response in EE31 protocol format as payload data. See "Ethernet - communication protocol" which can be found on www.epluse.com/en/service-support/ download-center

5.4.2 IPv4-Settings

Factory setting:

IP-Address: 192.168.0.64

Subnet-Mask: 255.255.255.0

Gateway:

192.168.0.1

DNS:

192.168.0.1

DHCP options can be set with jumper on the PCB Factory setting: DHCP disabled (static IP)

Fig. 18 Ethernet Module - DHCP setting
The setup of the Modbus TCP communication can be performed via EE-PCS Product Configuration Software or via display and push buttons, see chapter 10.3 / Fig. 37. Modifying the IP-Address via EE-PCS or display is possible only when the DHCP jumper is set to "Static". Otherwise the IP-settings are read-only.
Supported Ethernet standard: 802.3i/u/x and af;IPv6 is not supported

Operating instructions for EE310 Humidity / Temperature Transmitter

19

5.4.3 Retrofit with Ethernet Module
The EE310 can be retrofitted with an Ethernet Module. Before retrofitting please make sure, that the EE310 firmware is updated to the latest version by using the Configuration Software EE-PCS. · Firmware for Transmitter: V 1.0.22 or higher · Firmware for Display: V 1.0.9 or higher
Order code: HA010606 for remote probe type T5 and T10 HA010607 for duct mount type T2
Due to strong self-heating effects, the Ethernet interface only recomanded the types T2, T5 and T10 (duct mount and remote probe). Wall mount applications with Ethernet interface shall be realized with type T5 and 0.5m probe cable by fixing the probe onto the wall with the mounting bracket type HA010211.

5.5 Modbus Map

Register number1) Protocol address2)

[DEC]

[HEX]

Read registers: function code 0x03 / 0x04

1021

3FC

1003

3EA

1005

3EC

1105

450

1107

452

1131

46A

1133

46C

1113

458

1115

45A

1121

460

1123

462

1109

454

1111

456

1125

464

1129

468

1127

466

1101

44C

1103

44E

1151

47E

5001

1388

Measured value
Relative humidity Temperature Temperature Dew point temperature Dew point temperature Frost point / Dew point temperature Frost point / Dew point temperature Absolute humidity Absolute humidity Mixing ratio Mixing ratio Wet bulb temperature Wet bulb temperature Specific enthalpy Specific enthalpy Specific enthalpy Water vapour partial pressure Water vapour partial pressure Volume concentration Air pressure

Unit
% °C °F °C °F °C °F g/m3 gr/ft3 g/kg gr/lb °C °F kJ/kg BTU/lb ft lbf/lb mbar psi ppm mbar

Type
32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float 32-bit float

Write registers: function code 0x06 for 16-bit and 0x10 (decimal: 16) for 32-bit

0001

0

Slave-ID

/

5001

1388

Air pressure

mbar

1) Register number starts from 1

2) Protocol address starts from 0

16-bit integer 32-bit float

Modbus RTU Example

Example of MODBUS RTU command for reading the Temperature (float value) T = 26.953624 °C from the register 0x3EA

Device slave ID 231 [E7 in HEX] Reference document, chapter 6.3: www.modbus.org/docs/Modbus_Application_Protocol_V1_1b.pdf

Request [Hex]: E7 03 03 EA 00 02 F3 BD

Request [Hex]:

Modbus ID address
E7

Function code
03

Starting Starting address Hi address Lo

03

EA

No. of register Hi
00

No. of register Lo
02

CRC F3 BD

20

Operating instructions for EE310 Humidity / Temperature Transmitter

Response [Hex]: E7 03 04

Modbus ID Function

address

code

Response [Hex]:

E7

03

A1 Byte count
04

06 41 D7

Register 1 Register 1 value Hi value Lo

A1

06

CE 0E

Register 2 Register 2 value Hi value Lo

41

D7

CRC CE 0E

Conversion:

Response [Hex] Value in decimal

41 D7 A1 06

26.953624

See also Application Note AN0103 at www.epluse.com/EE310.

5.6 Pluggable probe (option PC4)
EE310-T5 and EE310-T10 transmitters are optionally available with pluggable sensing probe, which is attached to the EE310 enclosure by a push-pull plug. If the probe or the probe cable gets damaged it is possible to easily replace the probe without humidity and temperature adjustment. The replacement probe (see order information below) is supplied with a set of 7 individual parameters.
If you use two or more devices at the same time, make sure not to mix up the sensors! You can read out the serial number of the connected sensor by scanning the barcode on the basic unit.

Barcode for probe serial number

2.

1.

Fig. 19 Pluggable probe

Probe replacement procedure · Plug off the damaged probe · Plug on the new probe · Update the 7 parameters with EE-PCS Product Configuration Software or via display and push but-
tons (see chapter 10.2 / Fig. 33).

Note: When replacing the probe, the factory calibration loses its validity. A calibration to verify accuracy is recommended but not mandatory.

Ordering code for replacement probe

Type Filter
Cable length (incl. probe length) Probe length Process connection Optional features

stainless steel sintered PTFE H2O2 stainless steel - metal grid (up to 180 °C / 356 °F) 2 m (6.6 ft) 5 m (16.4 ft)
10 m (32.8 ft)
65 mm (2.55") 200 mm (7.87") 400 mm (15.75") 1/2" ISO thread 1/2" NPT thread E+E sensor coating

Tab. 1 Ordering code for replacement probe

T5 F4 F5 F12 F9 K2 K5 K10 L65 L200 L400
C1

PE310

T10 F4
F9 K2 K5 K10
L200 L400 PA23 PA25 C1

Operating instructions for EE310 Humidity / Temperature Transmitter

21

6 Operation

6.1 Configuration interface

The EE310 is ready to use and does not require any configuration by the user. The factory setup of EE310 corresponds to the type number ordered. For ordering guide please see data sheet at www. epluse.com/EE310. If needed, the user can change the factory setup by using a micro USB cable and the EE-PCS, Product configuration Software. The EE310 will be powered by the PC via the USB interface, an addition powered supply is not necessary. One can change the scaling of the analogue outputs, the settings of the alarm module the digital settings and perform a T and RH adjustment. In addition, is it possible to enable or disable the NAMUR error indication (factory setting: disabled).

1. Download the EE-PCS Product Configuration Software from www.epluse.com/configurator and install it on the PC.
2. Connect the E+E device to the PC using the appropriate configuration cable. 3. Start the EE-PCS software. 4. Follow the instructions on the EE-PCS opening page for scanning the ports and identifying the
connected device. 5. Click on the desired setup or adjustment mode from the main EE-PCS menu on the left and follow
the online instructions of the EE-PCS. .

Blind cover

USB cable

Fig. 20 USB serial interface

Voltage output

LED 1

power supply/ main board

LED 3

PCB

LED 2

Current output

LED 4

Error LED
error LED on = error category 1 error LED flashes = error category 2

Fig. 21 Status LEDs are located at the USB port
Ensure that the device is only powered by the USB interface during firmware update, otherwise the update may fail.

22

Operating instructions for EE310 Humidity / Temperature Transmitter

6.2 3.5" TFT Colour Display
The EE310 display includes a data logger and push buttons for full configuration of the device. Upon start-up of an EE310 with display, the data logger and the configuration menu will be initialised during the first 5 seconds.
1 Chart + data logger 2 Configuration menu 3 Status information 4 Buzzer ON / OFF 5 Error indication / information

Fig. 22 Display with push buttons

6.3 Chart + Data logger
The TFT display with the integrated data logging function saves all measured and calculated values to the internal memory. The data logger has a real time clock (UTC time) with a battery back-up.
Changing the UTC time erases all stored data.
The data logger can save 20.000 values for each measurand. The logging interval is to be set by the user from 1 second to 12 hours.
The data logger setup can be performed via display and push buttons, see chapter 10.2 / Fig. 29.
The data logger menu is also used to select the logged data to be shown as a graph as well as for scaling the graph, see chapter 10.2 / Fig. 29.

Axis 1 value (cursor position)

Axis 2 value (cursor position)

4 Cursor

1 Home button 2 Configuration incl. data logger menu

3 Time scale for the graph (5 min - 3 months)

Axis 1 Date
(cursor position)
Fig. 23 Data logging

Time

Axis 2

(cursor position)

Each point in the graph represents a logged value. The points are connected by a linear interpolation.

Operating instructions for EE310 Humidity / Temperature Transmitter

23

One point

The data logging continues even when the data memory is full; new data is stored while the oldest data is deleted (first in first out memory). The last 20.000 logged values are available in the internal memory.
The logged data can be downloaded with EE-PCS Product Configuration Software as .csv file by choosing the measurands and the time period.

6.4 Configuration Menu
Detailed information to the configuration menu see chapter 10. Menu

Data-logging

configuration of the data logger/graph - sampling rate | graphs

Display settings

setting of display layout - measurands | brightness | display alarm

Analog output

output configuration - mode | measurands | scaling | error indication

Alarm output*
Customer adjustment
Modbus settings*
IP settings*

relay configuration - mode | set points | state adjustment - 1 and 2 point humidity/temperature adjustment |
reset to factory adjustment | calibration status configuration of Modbus RTU data transmission
configuration of Ethernet Module

Device settings

settings - language | date, time | parameters | password protection

Status

status and device information

* Menu only available with the corresponding optional modules.

24

Operating instructions for EE310 Humidity / Temperature Transmitter

6.5 Status information i
The status information shows all actual EE310 settings.

Fig. 24 Status information
6.6 Buzzer ON / OFF
Buzzer ON

Buzzer OFF

6.7 Error indication
When an error occurs, the error indication shows the error code.

Operating instructions for EE310 Humidity / Temperature Transmitter

25

7 Maintenance
7.1 Self diagnosis and error messages

7.1.1 Error messages via display

Error description

Error code (display) Error category Recommended action

Voltage out short circuit - output 1 only*

1.1

Voltage out short circuit - output 2 only*

1.2

Voltage out short circuit - both outputs*

1.3

Current loop open - output 1 only

2.1

Current loop open - output 2 only

2.2

Current loop open - both outputs

2.3

RH sensor polluted

3.x

5.x

Hardware error

6.x

8.x

Temperature measurement failure

7.x

Humidity measurement failure

9.x 10.x

Check wiring of outputs
1 Check wiring of outputs
Cleaning sensor

2

Return the faulty unit to E+E for service

* not available with 0 - 1 V output

Tab. 2 Overview of error codes

Error category 1 = non-critical error, can be solved by the user · The display blinks and the buzzer beeps every 10 seconds. · The red status LED lights continuously.

Error category 2 = critical error, return the device to E+E for service · The display blinks and the buzzer beeps continuously. · The red status LED flashes.

7.1.2 Error messages via LEDs

Four status LEDs placed on both sides of a PCB are located close to the USB service interface, under a blind cover.

Voltage output

LED 1

power supply/ main board

LED 3

PCB

LED 2

Current output

LED 4

Error LED
error LED on = error category 1 error LED flashes = error category 2

Fig. 25 Status LEDs

LED 1 (blue): analogue outputs one set to voltage.

LED 2 (orange): analogue outputs one set to current.

LED 3 (flashing green): supply voltage applied (microprocessor is active).

LED 4 (red): constant lit: error category 1 flashes: error category 2

26

Operating instructions for EE310 Humidity / Temperature Transmitter

7.1.3 Solving typical problems

Error description
Display shows incorrect values
Long response time
High humidity values red LED blinks
Tab. 3 Self diagnosis

Likely causes and solutions
Error during re-adjustment of the transmitter.  Reset to factory calibration and repeat the adjustment routine. Filter polluted  Replace filter Output configured incorrectly  check configuration Filter polluted  Replace filter Inappropriate filter type  Contact E+E representative for advice. Water in sensing head  Investigate the cause for water / condensation.
Contact E+E representative for advice. Inappropriate filter type  Contact E+E representative for advice.

7.2 Cleaning the sensing head / filter replacement
In case of dusty, oily and polluted environment: · The filter cap shall be replaced once in a while with an E+E original one. A polluted filter cap causes
longer response time of the device. · If needed, the sensing head can be cleaned. For cleaning instructions please see
www.epluse.com/EE310.

7.3 RH / T adjustment and calibration

Humidity calibration and adjustment Depending on the application and the requirements of certain industries, there might arise the need for periodical humidity calibration (comparison with a reference) or adjustment (bringing the device in line with a reference).

Calibration and adjustment at E+E Elektronik Calibration and/or adjustment can be performed in the E+E Elektronik calibration laboratory. For information on the E+E capabilities in ISO or accredited calibration please see www.eplusecal.com.

Calibration and adjustment by the user Depending on the level of accuracy required, the humidity reference can be: · Humidity Calibrator (e.g. Humor 20), please see www.epluse.com/humor20. · Handheld device (e.g. Omniport30), please see www.epluse.com/omniport30. · Humidity calibration Kit (e.g. E+E Humidity Standards), please see www.epluse.com/EE310.

Perform 1 or 2 point adjustment via EE-PCS Product Configuration Software or via display (see below). Menu

Customer adjustment
Rel. humidity Temperature

Offset 2 point adjustment

Reference value
Current measured value
Reference value low
Reference value high

i Calibration status

value
Reference value Current measured
value

value

Reset to factory calibration

Fig. 26 Adjustment menu

Operating instructions for EE310 Humidity / Temperature Transmitter

27

Measured value

OFFSET

NEW CHARACTERISTICS

adjusted measured FACTORY (or

value current)

CHARACTERISTICS

current measured value

Fig. 27 Offset adjustment

Reference value

Measured value

1/2 OUTPUT SCALE

ADJUSTMENT POINT LOW Adjustment point NEW

ADJUSTMENT POINT HIGH FACTORNYE(WorCcHurAreRnAt)CCTHEARRISATCICTESRISTICS

current measurement

lower limit output scale (or last calibration point LOW)
Fig. 28 2 point adjustment procedure

Reference value

upper limit output scale (or last calibration point HIGH)

8 Replacement parts / Accessories

Description
- Filter caps - Mounting flange stainless steel - Drip water protection - RS485 kit for retrofitting - Ethernet module for retrofitting polycarbonate enclosure
- Bracket for installation onto mounting rails1) - Replacement probes2) - Humidity calibration kit
1) 2 pieces necessary per enclosure.
2) Only for devices with pluggable probe option PC4.

Order code
HA0101xx HA010201 HA010503 HA010605 HA010606 for remote probe type T5, T10 HA010607 for duct mounting type T2 HA010203 see 5.6 see data sheet ,,Humidity calibration kit"

For more details or illustrations refer also to data sheet "Accessories".

28

Operating instructions for EE310 Humidity / Temperature Transmitter

9 Technical data

Measurands

Relative humidity (RH)

Working range

0...100 % RH

Accuracy1) (incl. hysteresis, non-linearity and repeatability)

-15...40 °C (5...104 °F) RH 90 %

± (1.3 + 0.3 % * mv) % RH

-15...40 °C (5...104 °F) RH >90 %

± 2.3 % RH

mv = measured value

-25...70 °C (-13...158 °F)

± (1.4 + 1 % * mv) % RH

-40...180 °C (-40...356 °F)

± (1.5 + 1.5 % * mv) % RH

Temperature dependence of electronics

typ. ± 0.01 % RH/°C (0.0055 %RH / °F)

Response time Temperature (T)

< 15 s with metal grid filter at 20 °C (68 °F) / t90

Working range sensing probe

T1, wall:

-40...60 °C (-40...140 °F)

T2, duct:

-40...80 °C (-40...176 °F)

T5, remote:

-40...180 °C (-40...356 °F)

T10, pressure tight: -40...180 °C (-40...356 °F)

Accuracy1)

±  °C

°C

Temperature dependence of electronics

Calculated parameters

from

Dew point temperature

Td

Frost point temperature

Tf

Wet bulb temperature

Tw

Water vapour partial pressure

e

Mixing ratio

r

Absolute humidity

dv

Specific enthalpy

h

Outputs

Two analogue outputs

freely selectable and scalable

-40 (-40)

-40 (-40)

0 (32)

0

(0)

0

(0)

0

(0)

0

(0)

Digital interface / protocol

option J3

General Power supply class III

option J4 (EU) / class 2 (NA)

Current consumption at 24 V DC/AC (typ.)

Pressure range for pressure tight probe Probe material Enclosure material
Protection class Cable glands for polycarbonate enclosure
for metal enclosure Electrical connection Working and storage temperature range of electronics Electromagnetic compatibility
Two alarm outputs 2)
System requirements for EE-PCS software

typ. ± 0.005°C/°C

EE310-T1

60

(140)

0

(32)

60

(140)

200

(3)

425

(2900)

150

(60)

400 (50000)

up to

EE310-T2

80

(176)

0

(32)

80

(176)

500

(7.5)

999 (9999)

300

(120)

1000 (375000)

EE310-T5,T10

100 (212)

0

(32)

100 (212)

1100

(15)

999 (9999)

700 (300)

2800 (999999)

unit

°C °C °C mbar g/kg g/m³ kJ/kg

(°F) (°F) (°F) (psi) (gr/lb) (gr/f3) (Btu/lb)

0 - 1 / 5 / 10 V

-1 mA < IL < 1 mA

4 - 20 mA 3-wire

RL < 500 Ohm

0 - 20 mA 3 wire

RL < 500 Ohm

RS485 / Modbus RTU, max. 32 unit load devices on one bus

(EE310 = 1 unit load; factory settings: 9600 bps, parity even, stop bit 1 / slave-ID 231)

Ethernet-PoE with Modbus TCP

8...35 V DC

12...30 V AC

100...240 V AC, 50/60 Hz with option AM3 2)

15 mA / 40 mArms for 2 voltage outputs 35 mA / 100 mArms for 2 current outputs 50 mA / 150 mArms additional for display 30mA / 90 mArms additional for Ethernet 0.01...20 bar (0.15...300 psi)

stainless steel 1.4404 / AISI 316L

polycarbonate, UL94-V0 approved or

stainless steel 1.4404 / AISI 316 L

IP65 / NEMA 4

M16 x 1.5, for cable Ø 3 - 7 mm (0.12 - 0.28")

M16 x 1.5, for cable Ø 4.5 - 10 mm (0.18 - 0.39")

screw terminals max. 1.5 mm² (AWG 16)

-40...60 °C (-40...140 °F) without display

-20...50 °C (-4...122 °F) with display

EN61326-1 EN61326-2-3 ICES-003 ClassA

Industrial Environment

FCC Part15 ClassA

changeover contact

250 V AC / 6 A 28 V DC / 6 A

Windows XP or higher; USB port

1) T raceable to intern. standards, administrated by NIST, PTB, BEV,... The accuracy statement includes the uncertainty of the factory calibration with an enhancement factor k=2 (2-times standard deviation). The accuracy was calculated in accordance with EA-4/02 and with regard to GUM (Guide to the Expression of Uncertainty in Measurement). For model T1 the accuracy data is valid only for air speed higher than 0.2m/s.
2) Appropriate for outdoor use, wet location, degree of pollution 2, overvoltage category II, altitude up to 3000 m (9843 ft).

Operating instructions for EE310 Humidity / Temperature Transmitter

29

10 Appendix

10.1 Overview

Menu

Data-logging

configuration of data logger/graph - sampling rate | graphs

Display settings

setting of display layout - measurands | brightness | display alarm

Analog output

output configuration - mode | measurands | scaling | error indication

Alarm output*
Customer adjustment
Modbus settings*
IP settings*

relay configuration - mode | set points | state adjustment - 1 and 2 point humidity/temperature adjustment |
reset to factory adjustment | calibration status configuration of Modbus RTU data transmission
configuration of Ethernet Module

Device settings

settings - language | date, time | parameters | password protection

Status

status and device information

* Menu only available with connected modules.
10.2 Detailed information

Menu

Data-logging
Sampling rate

OFF 1 s / 10 s / 30 s 1 min / 5 min / 15 min / 30 min 1 h / 5 h / 12 h

Axis 1
Axis 2 Delete saved values
Fig. 29 Data-logging

Measurand Scale minimum Scale maximum
Measurand Scale minimum Scale maximum

value value

OFF Temperature [°C] Temperature [°F] Temperature [K] Rel. humidity [%] Vap. p. pressure [mbar] Vap. p. pressure [psi]
Dew point [°C] Dew point [°F] Wet bulb temp. [°C] Wet bulb temp. [°F] Abs. humidity [g/m³] Abs. humidity [gr/ft³] Mixing ratio [g/kg] Mixing ratio [gr/lb] Enthalpy [kJ/kg] Enthalpy [ft lbf/lb] Enthalpy [BTU/lb] Frost point [°C] Frost point [°F] Water activity [aw] Saturation [%] Water content [ppm] Wet bulb temp. [K] Dew point [K] Frost point [K] Volume concentr. [ppm]

30

Operating instructions for EE310 Humidity / Temperature Transmitter

Menu Display settings
Layout
Brightness Orientation

Measurand 1 Measurand 2 Measurand 3 Measurand 4 0.00 % - 100.00 %
Regular 180 degrees

Display alarm

Alarm 1 Alarm 2

Fig. 30 Display settings

Measurand Limit high Limit low Hysteresis

value value

OFF Temperature [°C] Temperature [°F] Temperature [K] Rel. humidity [%] Vap. p. pressure [mbar] Vap. p. pressure [psi]
Dew point [°C] Dew point [°F] Wet bulb temp. [°C] Wet bulb temp. [°F] Abs. humidity [g/m³] Abs. humidity [gr/ft³] Mixing ratio [g/kg] Mixing ratio [gr/lb] Enthalpy [kJ/kg] Enthalpy [ft lbf/lb] Enthalpy [BTU/lb] Frost point [°C] Frost point [°F] Water activity [aw] Saturation [%] Water content [ppm] Wet bulb temp. [K] Dew point [K] Frost point [K] Volume concentr. [ppm]

Menu

Analog output
Output number
Mode Measurand Analog range
Scaling Error indication
Fig. 31 Analog output

Output 1 Output 2 Current Voltage
min max ON OFF

value value

OK Cancel

OFF Temperature [°C] Temperature [°F] Temperature [K] Rel. humidity [%] Vap. p. pressure [mbar] Vap. p. pressure [psi]
Dew point [°C] Dew point [°F] Wet bulb temp. [°C] Wet bulb temp. [°F] Abs. humidity [g/m³] Abs. humidity [gr/ft³] Mixing ratio [g/kg] Mixing ratio [gr/lb] Enthalpy [kJ/kg] Enthalpy [ft lbf/lb] Enthalpy [BTU/lb] Frost point [°C] Frost point [°F] Water activity [aw] Saturation [%] Water content [ppm] Wet bulb temp. [K] Dew point [K] Frost point [K] Volume concentr. [ppm]

Menu

Customer adjustment
Rel. humidity Temperature

Offset 2 point adjustment

Reference value
Current measured value
Reference value low
Reference value high

i Calibration status

value
Reference value Current measured
value

value

Fig. 32

Reset to factory calibration
Customer adjustment

Operating instructions for EE310 Humidity / Temperature Transmitter

31

Menu Device settings
Language

German
English
Chinese (simplified)

Date

Date settings

dd.mm.yy

Date format

mm.dd.yy

yyyy-mm-dd

Time

Time settings

Date and time

Time format

hh:mm:ss hh:mm

Daylight saving time

OFF Central europe
US

UTC settings

UTC date UTC time

Timezone offset

Measuring system Parameters

SI units

US units
Working pressure Probe replacement

Capacity C76 Humidity coefficient
Capacity offset
Capacity gain
Resistance R0 Temperature coefficient TK Resistance Offset

Password protection

Activate

Code

Buzzer

ON OFF

** changing the UTC time will delete measurment data!

Fig. 33 Device settings

Date settings **

Time settings **

value

**

32

Operating instructions for EE310 Humidity / Temperature Transmitter

Menu

Status

i Status page

Fig. 34

i Device info
Status

10.3 Optional menu
(only available with plugged in modules during the start up procedure) Menu

Alarm output*
Alarm number

Alarm 1 Alarm 2

Measurand

Switch hystersis

Switching point

Mode

Normal state

Switch window

Measurand
Switching point low
Switching point high

Normal state

Error indication

Normal state

* Menu only available with connected alarm module during EE310 start-up
Fig. 35 Alarm output

Switching point Hysteresis Standard Inverted
Switching point Hysteresis
Switching point Hysteresis Standard Inverted Standard Inverted

OFF Temperature [°C] Temperature [°F] Temperature [K] Rel. humidity [%] Vap. p. pressure [mbar] Vap. p. pressure [psi]
Dew point [°C] Dew point [°F] Wet bulb temp. [°C] Wet bulb temp. [°F] Abs. humidity [g/m³] Abs. humidity [gr/ft³] Mixing ratio [g/kg] Mixing ratio [gr/lb] Enthalpy [kJ/kg] Enthalpy [ft lbf/lb] Enthalpy [BTU/lb] Frost point [°C] Frost point [°F] Water activity [aw] Saturation [%] Water content [ppm] Wet bulb temp. [K] Dew point [K] Frost point [K] Volume concentr. [ppm]

Operating instructions for EE310 Humidity / Temperature Transmitter

33

Menu

Modbus settings*

Baudrate

value

None

Parity

Odd

Even

Stop bits

value

Address

value

* Menu only available with connected Modbus RTU module during EE310 start-up.

Fig. 36 Modbus settings

Menu

IP settings

Type IP address Subnet mask

Gateway

Fig. 37

DNS server
IP settings

shows the status of the DHCP setting value value value value

34

Operating instructions for EE310 Humidity / Temperature Transmitter

Operating instructions for EE310 Humidity / Temperature Transmitter

35

COMPANY HEADQUARTERS
E+E ELEKTRONIK Ges.m.b.H. www.epluse.com Langwiesen 7 A-4209 Engerwitzdorf Austria Tel: +43 7235 605 0 Fax: +43 7235 605 8 info@epluse.com

TECHNICAL OFFICES
E+E CHINA www.epluse.cn BEIJING Tel: +86 10 84992361 info@epluse.cn SHANGHAI Tel: +86 21 61176129 info@epluse.cn
E+E GERMANY www.epluse.de Tel: +49 6172 13881 0 info@epluse.de
E+E FRANCE www.epluse.fr Tel: +33 4 7472 35 82 info@epluse.fr

E+E ITALY www.epluse.it Tel: +39 02 2707 8636 info@epluse.it
E+E KOREA www.epluse.co.kr Tel: +82 31 732 6050 info@epluse.co.kr
E+E USA www.epluse.com Tel: +1 508 530 3068 office@epluse.com


Adobe PDF Library 15.0 Adobe InDesign 14.0 (Windows)
