AN12631 Normal and Secure Debug for i.MX8/8X Family of Applications Processors Rev. 0 -- February 2020 Application Note 1 Introduction 1.1 Purpose This document describes how to configure and use Normal/Secure JTAG on the i.MX8/8X family applications processors. This document does not apply to i.MX8M family of Application process. See AN4686 for 8M devices. 1.2 Intended audience This document is intended for users who: � Need an explanation about the procedure of secure debugging. � Need an explanation about how to use Lauterbach tools to debug Uboot/Kernel/SCFW. 1.3 Definitions, Acronyms, and Abbreviations The terms and acronyms used in this document are: � ADM � Authenticated Debug Module; Module that works with the debug system and fuse configuration to provide security measures � AHAB � Advanced High Assurance Boot; A software library executed in internal ROM on the NXP processor at boot time which, among other things authenticates software in external memory by verifying digital signatures in accordance with a CSF Contents 1 Introduction............................................ 1 1.1 Purpose.................................. 1 1.2 Intended audience.................. 1 1.3 Definitions, Acronyms, and Abbreviations................... 1 2 Overview................................................1 2.1 System JTAG Controller......... 1 2.2 The Authenticated Debug Module.................................... 2 2.3 Debug Flow when Secure Debug is enabled.................... 3 3 Deploy SCFW for OEM Open ............... 4 3.1 Connect Lauterbach to the board....................................... 4 3.2 SCFW Debugging................... 5 3.3 Run SCFW..............................5 3.4 Attach to SCFW...................... 6 4 Debug U-boot........................................ 6 4.1 Attach to U-Boot..................... 7 5 Kernel Debug.........................................9 6 Secure Debug......................................11 6.1 Introduction........................... 11 6.2 Steps to connect Lauterbach debug tool via Secure Debug....................... 13 � OTP � One-Time Programmable; The OTP hardware includes the masked ROM and electrically programmable fuses (eFuses) � SCU � System Controller Unit � SCFW � SCU FirmWare � SDP � Serial Download Protocol; Also called UART/USB serial download mode. It allows code provisioning through UART or USB during the production and development phases � SECO � Security Controller � SJC � System JTAG Controller 2 Overview 2.1 System JTAG Controller The JTAG port provides debug access to hardware blocks, including the Arm processor and the system bus. This allows program control and manipulation as well as visibility to the chip peripherals and memory. NXP Semiconductors Overview The JTAG port must be accessible during initial platform development, manufacturing tests, and general troubleshooting. Given its capabilities, JTAG manipulation is a known attack vector for accessing sensitive data and gaining control over software execution. System JTAG Controller (SJC) protects against the whole range of attacks based on unauthorized JTAG manipulation. In i.MX8/8X family, the System JTAG Controller (SJC) provides a method of regulating the JTAG access. SJC provides the following security levels: � JTAG Disabled � JTAG use is permanently blocked � No-Debug � JTAG security sensitive features are permanently blocked � Secure JTAG � JTAG use is restricted (as in the No-Debug level) unless a secret-key challenge/response protocol is successfully executed � JTAG Enabled � JTAG use is unrestricted Security levels are selected via e-fuse configuration. The fuse burning is an irreversible process, once a fuse is burned it is not possible to change the fuse back to the unburned state. 2.1.1 Boundary Scan Arm signals DBGEN/NIDEN/SPIDEN/SPNIDEN are not tied with the Boundary Scan functionality, therefore, programming these fuses does not have any impact on Boundary Scan, which is enabled by default. Boundary Scan functionality can be disabled in either of these scenarios: � Setting the SJC Disable Fuse, since the JTAG controller is gated off. � The device is in "No Return" Lifecycle (regardless of the SJC_DISABLE eFUSE). 2.2 The Authenticated Debug Module The Authenticated Debug Module (ADM) is a module that works with the debug system and fuse configuration to provide security measures. It receives control signals from various sources such as pins, OTP fuses, and the SCU, Debug Access Port, and JTAG at boot and during runtime to determine, restrict, and indicate use of the debugging components. Certain debugging features are allowed or disallowed based on NXP and OEM requirements. It supports the following functions: � Debug Security Controls � SDP Security Controls � JTAG Security Controls � Content Key Security Controls � Chip Lifecycle Security Controls The chip has multiple debug domains, as shown in the table below. Having access to one debug domain does not grant access to the others. Table 1. Debug domains on the chip Life Cycle/ Enabled without authentication SCU SECO FW FW CLOSED OEM (with or without NXP firmware) PARTIAL FIELD RETURN FULL FIELD NO FIELD RETURN RETURN Debug Domain 0 (SCU) No Yes No Yes Yes No Debug Domain 3 (APPS) Yes Yes No Yes Yes No Debug Domain 5 (SECO) Yes No No No Yes No Application Note Normal and Secure Debug for i.MX8/8X Family of Applications Processors, Rev. 0, February 2020 2 / 14 NXP Semiconductors Overview 2.3 Debug Flow when Secure Debug is enabled In a closed configuration, the debug options are determined at boot time using signed code. However, if the Secure Debug level is chosen in the security fuse configuration then a successful Secure JTAG challenge/response allows access to debug features for the application and CM4 cores. In other words, secure debug is coupled with secure boot and is enabled only if chip LC is OEM Closed and the JTAG Challenge/ Response provides a means to open a Closed device for debug purposes. Therefore, when the device is in closed state, JTAG use is restricted unless a challenge/response protocol is successfully executed. If the chip is closed, normal JTAG does not work anymore and a signed message must be delivered through ADM Figure 1. Figure 1. App Cores TrustZone and Normal World Debugging The debug flow is as follows: 1. User request debug through JTAG interface 2. SOC responds with chip unique ID 3. Server finds corresponding secret (Trust Zone or Normal Debug) 4. User submits secret through JTAG interface 5. Secure JTAG module compares secret to pre-configured secret 6. If a match, ADM asks SECO to clear sensitive data Arm model is used to restrict debug access based on TZ/normal state. The OEM secret is used to enable debug for non-secure code (EL2 and below). Similarly, the TZ secret enables debug for secure code (EL3). Separating these worlds can cause some difficulties when debugging code that crosses these boundaries (that is, Linux -> ATF), so to get a full view both shall be enabled. Application Note Normal and Secure Debug for i.MX8/8X Family of Applications Processors, Rev. 0, February 2020 3 / 14 NXP Semiconductors 3 Deploy SCFW for OEM Open Deploy SCFW for OEM Open Figure 2. Boot image layout The boot image has two containers: SECO FW (AHAB) and SCFW+ATF+U-Boot as shown in Figure 2 1. Headers come first 2. The first container only contains the SECO 3. firmware image 4. Second container header aligned to 1k 5. Flexible image placement for the second container 6. which can contain one or multiple images 7. No CSF For SECO to be authenticated with success the boot image must be signed using CST. 3.1 Connect Lauterbach to the board After creating the image, you need to connect Lauterbach hardware to the board by following the steps below: 1. Disconnect the debug cable from the target while the target power is off 2. Connect the host system, the TRACE32 hardware and the debug cable 3. Power ON the TRACE32 hardware 4. Start the TRACE32 software to load the debugger firmware. 5. Connect the debug cable to the target. 6. Switch the target power ON. 7. Configure your debugger, e.g., via a start-up script. Next, add cores and start the debugger: 1. Add cores on which to run the debugger 2. Change the Temp file location (Advanced Settings->Paths) Application Note Normal and Secure Debug for i.MX8/8X Family of Applications Processors, Rev. 0, February 2020 4 / 14 NXP Semiconductors 3. Select the Arm core, and press start Figure 3 Deploy SCFW for OEM Open Figure 3. Add Cores and start the debugger 3.2 SCFW Debugging Lauterbach scripts can be found either in the Lauterbach release or by contacting NXP support. For SCFW Debugging the MX8_misc/coresight-jtag-provision.cmm script can be used. The &binFile and &scfwFile script variables should be set with the paths to flash.signed.bin and scfw_tcm.elf. In order to link the disassembled code to the C code, you need to set &scfwPath variable with the path to SCFW source code. Run SCFW Debugging script: 1. Put the board in SDP Mode 2. Power on the board, start the ARM-core and run the MX8_misc/coresight-jtag-provision.cmm script Figure 4. 3. If the script succeeds, "SECO AUTH SUCCESS" is reported in the AREA window Figure 5. Figure 4. Run script Figure 5. Script log 3.3 Run SCFW In the B:: console use "list board_init". If you are seeing only disassembled code the path to the current source file (board.c) must be added from View->Symbols. Add a breakpoint at board_init from Break -> Set or press right click on the line you want to set it and select breakpoint. To start debugging press the go button Figure 6. Application Note Normal and Secure Debug for i.MX8/8X Family of Applications Processors, Rev. 0, February 2020 5 / 14 NXP Semiconductors Debug U-boot Figure 6. Menu bar The debugger should be at the beginning of the board_init function. Figure 7. You can advance with the single-step button. If you have built the SCFW with the M=1 option, SCU Console was activated (see iMX8 User Guide Manual). Logs can be seen in the SCU console while advancing with the go/step button. If the break button is pressed Figure 8, the execution is halted and the terminals should not accept any input. Figure 7. board_init function Figure 8. Break button 3.4 Attach to SCFW For attaching to SCFW you need to write the previous image on the SD card. For i.MX8QXP devices, this can be done using the following command: dd if=flash.signed.bin of=/dev/sde bs=1K seek=32; Set the switches for SD1 boot (1100) and insert the SD-card. The U-boot has to be stopped from console terminal before booting. On the Arm-core, the coresight-scu.cmm script is used to attach to SCFW. 4 Debug U-boot Application Note Normal and Secure Debug for i.MX8/8X Family of Applications Processors, Rev. 0, February 2020 6 / 14 NXP Semiconductors Debug U-boot 4.1 Attach to U-Boot Adding a branch to self at the start label in U-Boot sources and recompiling the imx-boot is needed as in section 3. For 2018.03r0 U-Boot version it can be found in $YOCTO_BUILD/tmp/work/imx8-poky-linux/u-boot-imx/2018.03-r0/git/ arch/arm/cpu/armv8/start.V Figure 9. Figure 9. u-Boot start.v Write the U-Boot on the SD-card, set the switches for SD1 boot (1100) and insert the SD-card. In Lauterbach start the ARM64 core Figure 10. Figure 10. Start core Next, run the coresight-ca35.cmm script to attach to U-Boot. To load the elf file in Lauterbach, you need to run: data.load.elf $PATH_TO_u_boot /NoCODE To add sources to the disassembled code, you need the "U-Boot" file. For iMX8QX, you can find it in $YOCTO_BUILD/tmp/work/imx8qxpmek-poky-linux/u-boot-imx/2018.03r0/build/ imx8qxp_mek_config/. For attaching the source code, the following command can be used: y.SourcePATH $PATH_TO_u-boot-imx The elf can be loaded with the sources simultaneously with: data.load.elf $PATH_TO_u_boot /Strippart 4 /NoCode /PATH $PATH_TO_u-boot-imx To see the code, go to View->List Source and move the PC to the next line by pressing right click "b reset" and Set PC Here to jump over the loop Figure 11. Application Note Normal and Secure Debug for i.MX8/8X Family of Applications Processors, Rev. 0, February 2020 7 / 14 NXP Semiconductors Debug U-boot Figure 11. Set PC The U-boot needs to relocate at a specific address in RAM. For that it uses relocate_code and relocate_done functions. Set two breakpoints at relocate_code and relocate_done Figure 12) and press GO until you reach relocate_done Figure 13. Figure 12. Set breakpoints Figure 13. Old rellocate_done adress Application Note Normal and Secure Debug for i.MX8/8X Family of Applications Processors, Rev. 0, February 2020 8 / 14 NXP Semiconductors Kernel Debug In Figure 14 you can see the relocate_done address highlighted. Run some steps until you reach the 2nd stage and there is no source file mapping synchronization. Figure 14. New relocate_done address The offset is the difference between the new relocate_done address and the old one. In this case Offset = 0xFFE9A838 � 0x800218E4 = 0x7FE78F54. Now you need to load the elf file with the new offset. You can do that using: Figure 15. Offset address 5 Kernel Debug For Kernel Debugging the linux image must be compiled with debug symbols. Enter in kernel menuconfig Figure 16 and: � disable General Setup -> unset "Compile drivers which will not load" (without this step the option below donot appear in menuconfig) � enable In "Kernel Hacking -> Compile-time checks and compiler options" -> "Compile the kernel with debug info" -> Save to default -> Exit Application Note Normal and Secure Debug for i.MX8/8X Family of Applications Processors, Rev. 0, February 2020 9 / 14 NXP Semiconductors Kernel Debug Figure 16. Enable debug info The U-Boot must be suspended in serial console to prevent kernel booting up. The address should be around relocate_done. Attach with Lauterbach using coresight-ca35.cmm and follow these steps: 1. Set a hardware breakpoint to kernel load address Figure 17 Figure 17. Print loadaddr 2. Set a hardware breakpoint at start_kernel and resume execution. 3. Load the elf using data.load.elf $PATH/vmlinux /Locateat $loadaddress /NoCode 4. Set hardware breakpoint at __enable_mmu Figure 18 5. Resume the execution 6. In U-Boot console type boot for loading the kernel. The first breakpoint should be hit Figure 19 Figure 18. Breakpoint list Application Note Normal and Secure Debug for i.MX8/8X Family of Applications Processors, Rev. 0, February 2020 10 / 14 NXP Semiconductors Secure Debug Figure 19. First breakpoint Resume the execution. The breakpoint from enable_mmu should be hit (Figure 20). The following fragment of code is executed with the MMU on in MMU mode. You can attach sources to disassembled code by using: data.load.elf $PATH_to_vmlinux /Locateat $loadaddress /NoCode /Strippart 4/PATH $PATH_TO_linux_imx The kernel entry point is at start_kernel. The elf file needs to be reloaded using: data.load.elf $PATH_to_vmlinux /NoCode /Strippart 4 /PATH $PATH_TO_linux_imx Figure 20. Code fragment If there are any problems in loading the sources, the /Strippart parameter should be adjusted. 6 Secure Debug 6.1 Introduction The Challenge eFuse Table 2 has double roles: Secure JTAG Challenge and Unique ID (64 bits). It is used by both Normal/ TrustZone environments. Application Note Normal and Secure Debug for i.MX8/8X Family of Applications Processors, Rev. 0, February 2020 11 / 14 NXP Semiconductors Table 2. Challenge eFuse ( SJC_CHALL[7:0] / UNIQUE_ID[7:0] ) ( SJC_CHALL[15:8] / UNIQUE_ID[15:8] ) ( SJC_CHALL[23:16] / UNIQUE_ID[23:16] ) ( SJC_CHALL[31:24] / UNIQUE_ID[31:24] ) ( SJC_CHALL[39:32] / UNIQUE_ID[39:32] ) ( SJC_CHALL/UNIQUE_ID[46:40] ) ( SJC_CHALL[47:43] / UNIQUE_ID[47:43] ) ( SJC_CHALL[55:48] / UNIQUE_ID[55:48] ) ( SJC_CHALL[63:56] / UNIQUE_ID[63:56] ) INDEX The Challenge eFuse can be read using the fuse read command as in Figure 21: Secure Debug Figure 21. Read eFuse The corresponding Challenge key is obtained by concatenating the fuses in: 0xeb64180b57ac1898. There are two response keys: � OEM key for Normal world � TrustZone key for Secure world If the device is NXP closed (OEM Open), then you can use normal debug for debugging the A cores (U-Boot, Linux, SCFW). Once it becomes OEM closed then you need the challenge/response fuses programmed and the challenge/response function becomes active. NOTE The response eFuses are writable only from LC OEM Open. After switching to LC OEM Closed, these eFuses are locked out. The OEM and TrustZone keys are formed as the Challenge Key from fuses and by default are 0x0. To modify the keys, you need to use: fuse prog [-y] <bank> <word> <hexval> command in the U-Boot terminal or fuse.w <word><hexval> from SCU firmware. Below is an example of writing the OEM and TrustZone keys from U-Boot. TrustZone KEY [127:0] fuse prog 0 704 0xcafecafe fuse prog 0 705 0xbabeface fuse prog 0 706 0xc001d00d Application Note Normal and Secure Debug for i.MX8/8X Family of Applications Processors, Rev. 0, February 2020 12 / 14 NXP Semiconductors fuse prog 0 707 0x12345678 //secure secret as you can see it in Lauterbach scripts &response_secret1= 0xBABEFACECAFECAFE &response_secret2= 0x12345678C001D00D OEM Key [127:0] fuse prog 0 722 0xca11b005 fuse prog 0 723 0xd00dca11 fuse prog 0 724 0xdeadbeef fuse prog 0 725 0xabcdefda // normal secret 128 bit as you can see it in Lauterbach scripts &response_normal1= 0xD00DCA11CA11B005 &response_normal2= 0xABCDEFDADEADBEEF Secure Debug 6.2 Steps to connect Lauterbach debug tool via Secure Debug The following steps connect the Lauterbach debug tool to the i.MX8/8X family when using Secure JTAG: Table 3. Fuse map for OEM key and TrustZone key Fuse Row 7 6 5 4 3 2 1 0 Index 722-725 OEM Key [127:0] 704-707 TrustZone KEY [127:0] 1. Read the OEM Key and the TrustZone Key from fuses using the "fuse read" command in u-boot terminal. 2. In the iMX8_misc folder you can find the jtag_attach.cmm script. This script uses jtagc_calculateresponse.cmm, where you need to set the normal_response and trustzone_response variables. 3. Run jtag_attach.cmm from Lauterbach. If the keys correspond to the expected values, you should see the challenge. Figure 22. Challenge status 4. To attach to the ARM64 core, coresight_ca35.cm can be used. In OEM Closed state the line from Figure 23 has to be commented. Figure 23. Attach to Arm64 core Application Note Normal and Secure Debug for i.MX8/8X Family of Applications Processors, Rev. 0, February 2020 13 / 14 How To Reach Us Home Page: nxp.com Web Support: nxp.com/support Information in this document is provided solely to enable system and software implementers to use NXP products. There are no express or implied copyright licenses granted hereunder to design or fabricate any integrated circuits based on the information in this document. NXP reserves the right to make changes without further notice to any products herein. NXP makes no warranty, representation, or guarantee regarding the suitability of its products for any particular purpose, nor does NXP assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation consequential or incidental damages. "Typical" parameters that may be provided in NXP data sheets and/or specifications can and do vary in different applications, and actual performance may vary over time. All operating parameters, including "typicals," must be validated for each customer application by customer's technical experts. NXP does not convey any license under its patent rights nor the rights of others. NXP sells products pursuant to standard terms and conditions of sale, which can be found at the following address: nxp.com/ SalesTermsandConditions. While NXP has implemented advanced security features, all products may be subject to unidentified vulnerabilities. Customers are responsible for the design and operation of their applications and products to reduce the effect of these vulnerabilities on customer's applications and products, and NXP accepts no liability for any vulnerability that is discovered. Customers should implement appropriate design and operating safeguards to minimize the risks associated with their applications and products. NXP, the NXP logo, NXP SECURE CONNECTIONS FOR A SMARTER WORLD, COOLFLUX, EMBRACE, GREENCHIP, HITAG, I2C BUS, ICODE, JCOP, LIFE VIBES, MIFARE, MIFARE CLASSIC, MIFARE DESFire, MIFARE PLUS, MIFARE FLEX, MANTIS, MIFARE ULTRALIGHT, MIFARE4MOBILE, MIGLO, NTAG, ROADLINK, SMARTLX, SMARTMX, STARPLUG, TOPFET, TRENCHMOS, UCODE, Freescale, the Freescale logo, AltiVec, C5, CodeTEST, CodeWarrior, ColdFire, ColdFire+, CWare, the Energy Efficient Solutions logo, Kinetis, Layerscape, MagniV, mobileGT, PEG, PowerQUICC, Processor Expert, QorIQ, QorIQ Qonverge, Ready Play, SafeAssure, the SafeAssure logo, StarCore, Symphony, VortiQa, Vybrid, Airfast, BeeKit, BeeStack, CoreNet, Flexis, MXC, Platform in a Package, QUICC Engine, SMARTMOS, Tower, TurboLink, and UMEMS are trademarks of NXP B.V. All other product or service names are the property of their respective owners. AMBA, Arm, Arm7, Arm7TDMI, Arm9, Arm11, Artisan, big.LITTLE, Cordio, CoreLink, CoreSight, Cortex, DesignStart, DynamIQ, Jazelle, Keil, Mali, Mbed, Mbed Enabled, NEON, POP, RealView, SecurCore, Socrates, Thumb, TrustZone, ULINK, ULINK2, ULINK-ME, ULINK-PLUS, ULINKpro, �Vision, Versatile are trademarks or registered trademarks of Arm Limited (or its subsidiaries) in the US and/or elsewhere. The related technology may be protected by any or all of patents, copyrights, designs and trade secrets. All rights reserved. Oracle and Java are registered trademarks of Oracle and/or its affiliates. The Power Architecture and Power.org word marks and the Power and Power.org logos and related marks are trademarks and service marks licensed by Power.org. � NXP B.V. 2020. All rights reserved. For more information, please visit: http://www.nxp.com For sales office addresses, please send an email to: salesaddresses@nxp.com Date of release: February 2020 Document identifier: AN12631
