easy installation. • Three housing color options of white, black and graphite. • 80 CRI (For DLC Certifications). • 90 CRI, R9>65. • TM30 Color: Fidelity (Rf) > 92,.Missing:
LED LIGHTING PRODUCT GUIDE INDOOR LED PRODUCTS LED DYNAMIC SKYLIGHT 2 LED SPECIFICATION LINEAR 4 LED SPECIFICATION DOWNLIGHT 6 LED RETROFIT DOWNLIGHTS 8 LED TROFFERS 10 LED UPGRADE SOLUTIONS 14 LED SUSPENDED AMBIENT 18 LED SURFACE AMBIENT 22 LED HIGH-BAY/LOW-BAY 26 LED LAMPS 30 LED TRACK LIGHTING 34 TRACK ACCESSORIES 40 OUTDOOR LED PRODUCTS LED AREA 44 LED DECORATIVE STREET & ROADWAY 48 LED STREET & ROADWAY 52 LED CANOPY & SOFFIT 56 LED PARKING STRUCTURE 60 LED FLOOD 64 LED WALL MOUNT 68 CREE LIGHTING TECHNOLOGIES CREE SMARTCAST INTELLIGENCE PLATFORMTM 71 CREE WAVEMAX® TECHNOLOGY 76 COLORFAST DELTAGUARD® FINISH 76 CREE TRUEWHITE® TECHNOLOGY 77 NANOOPTIC® TECHNOLOGY 77 *LED lighting replacements are general recommendations only. They can vary dependent upon application and optical performance requirements. Consult factory for specific product recommendation based on application. 1 LED DYNAMIC SKYLIGHT 2 Indoor LED DYNAMIC SKYLIGHT COMING SOON CadiantTM Dynamic Skylight PRELIMINARY · CCT: 3000K - 6500K · Up to 3500 lumens · Up to 75 LPW · Input Power: 6W - 50W · Dimming: Smartcast® Technology to 5% · 90+ CRI, R9>65 APPLICATIONS: Office, education, healthcare, retail, hospitality Innovative architectural dynamic skylight for any space looking to bring the outdoors in by realistically recreating the natural arc of the sky to allow people to create a connection with nature. · Enhances architectural designs with visual impact and dramatic scene-setting · Proprietary spectral recipe simulates the natural cycle of the day from sunrise to sunset with variation of warm and cool light and east to west orientation · Deep 8" recessed element looks like a portal to the sky and creates the feeling of cycling throughout a day · Local standalone system uses an intuitive wall-mounted touchscreen with a clean graphic interface that provides control over multiple luminaires · SmartCast® Technology allows nearby fixtures to connect and harmonize in sync with CadiantTM dynamic skylights 3 LED SPECIFICATION LINEAR 4 Indoor LED SPECIFICATION LINEAR Direct Surface Suspended Direct Suspended Direct/Indirect Recessed COMING SOON Stylus Series Specification grade modern 3" linear portfolio designed around architectural simplicity and human comfort PRELIMINARY · Full linear 3" portfolio to design an entire space: suspended, recessed, surface and wall mounts · Uplight/downlight option for both suspended and wall mount · Continuous row options from 2' to 72' (120V) or 144' (277V) with just one power drop for easy installation · Three housing color options of white, black and graphite · 90+ CRI, R9>65 · CCT: 3000K, 3500K, 4000K · Input Power: 9W 141W · Three lumen options: Low: ~ 400 lumens/ft Medium: ~ 650 lumens/ft High: ~ 900 lumens/ft · Up to 85 LPW · 120-277 VAC or 347 VAC · 10-year limited warranty · Individual mount or continuous row for recess, surface, suspended and wall mount · Multiple dimming and network control options APPLICATIONS: Office, education, healthcare, retail, hospitality Wall Direct Wall Direct/Indirect 5 LED SPECIFICATION DOWNLIGHTS 6 Indoor LED SPECIFICATION DOWNLIGHTS Cree® LED specification downlights allow designers to meet interior lighting performance requirements while achieving beautiful color consistency with easy installation. KR8TM KR6TM Square KR6TM Round KR Series · Minimum 90 CRI · CCT: 2700K, 3000K, 3500K, 4000K, 5000K · Up to 8000 lumens · Input Power: 13W 118W · Cree TrueWhite® Technology · Cree WaveMax® Technology in 8" round for precise optical control · Controls/Dimming: KR4 and KR6: TRIAC 5%, 0-10V 10%, KR8: 0-10V 1%, Cree Sunset Dimming Technology (2700K 1800K CCT), SmartCast® Technology to 5%, and Lutron EcoSystem® Enabled to 5% · 4" or 6" round and square apertures with Sunset Dimming from 2700K to 1800K, and SmartCast® Technology · 10-year limited warranty APPLICATIONS: New construction (heights up to 40') 6" Downlight Essentia® Series Downlights · 90+ CRI · CCT: 2700K, 3000K, 3500K, 4000K · Up to 6315 lumens · Input Power: 12W 86W · 0-10V continuous dimming to 1%, TRIAC dimming to 10% · 4", 6" and 8" round apertures, along with wall wash and adjustable accent configurations · Available with Emergency Backup option · 5-year limited warranty APPLICATIONS: New construction and retrofit 4" Downlight Adjustable Downlight 7 LED RETROFIT DOWNLIGHTS 8 Indoor LED RETROFIT DOWNLIGHTS Cree® LED retrofit downlights deliver beautiful light with superior color quality and high energy efficiency -- a true no-compromise solution that takes only seconds to install. LR Series Replaces multi-CFL pin-based configurations up to 42 watts. · 90 CRI · CCT: 2700K, 3500K, 4000K · 650, 1050 or 1800 lumens · Up to 100 LPW · Input Power: 7.5W, 10.5W or 22W · Cree TrueWhite® Technology · Continuous dimming to 5% (120V forward phase; 277V trailing edge) · 10-year limited warranty APPLICATIONS: Recessed lighting in both new construction and retrofit commercial settings CR-T Series Replaces 75W, 100W or 150W incandescent downlights. · 90 CRI · CCT: 2700K, 3000K, 3500K, 4000K · Up to 1600 lumens · Input Power: 10.5W - 21W · Deep recess options for reduced glare · Dimmable with TRIAC dimmers at 120V · 4" and 6" sizes · 5-year limited warranty APPLICATIONS: Recessed lighting in both new and retrofit residential and light commercial DDS Series Replaces 65W or 75W incandescent downlights. · 90 CRI · CCT: 2700K, 3000K, 4000K · 750 or 900 lumens · Up to 85 LPW · Input Power: 9W or 10.5W · 4" and 6" sizes · Dimmable with most standard dimmers · Wet rated · 5-year limited warranty APPLICATIONS: Recessed lighting in both new and retrofit residential and light commercial 9 LED TROFFERS 10 Indoor LED TROFFERS CR Series Replaces linear fluorescent fixtures in new construction or renovation. · 80+ 90 CRI · CCT: 3000K, 3500K, 4000K, 5000K or adjustable CCT with Cree SmartCast® Technology · 2000 to 5000 lumens · 90 - 130 LPW · Input Power: 22W 50W · Cree TrueWhite® Technology (90 CRI) · Available with Cree SmartCast® Technology; step level to 50%, 0-10V dimming to 5% or Lutron EcoSystem® Enabled to 5% · 10-year limited warranty APPLICATIONS: Office, education and healthcare SmartCast® Adjustable CCT with Technology optional optional SmartCast® Technology On CR HD On CRHE TW and CR TW SmartCast® Technology optional Removable lens ZR Series Replaces linear fluorescent fixtures in new construction or renovation. · 80+ CRI for ZR-FD & ZR-C · 90+ CRI for ZR-MT & ZR Series · CCT: 3000K, 3500K, 4000K or 5000K* · 3200 to 5000 lumens · High efficacy up to 132 LPW · Input Power: 25W 44W · Cree TrueWhite® Technology (90 CRI) · 0-10V dimming to 5% standard; SmartCast® Technology optional · Intuitive removable lens · 10-year limited warranty for ZR-FD, ZR-MT and ZR Series · 5-year limited warranty on ZR-C Series APPLICATIONS: Office, education and healthcare * Not available on all types On ZRMT TW On ZRM-FD and ZRC-FD 11 Indoor LED TROFFERS FLEX Series Specification LED troffer that replaces linear fluorescent fixtures in new construction or renovation. · 83+ CRI · CCT: 3000K, 3500K, 4000K, 5000K · 3200 or 5000 lumens (2x2) · 3200, 4000, 5000 or 6000 lumen options (2x4, 1x4) · Up to 145 LPW · Input Power: 23W - 43W · 0-10V dimming to 1% standard; SmartCast® Technology optional · Inner Optic accessory options for more flexibility and enhanced aesthetics · Brushed Metal, Striped, Perforated, Wavy, and Standard Diffused options · Emergency Battery option on board · 10-year limited warranty APPLICATIONS: Office, retail, education, and healthcare Targeted to meet DLC Premium certification 5 INNER OPTIC DESIGN CHOICES The inner optics simply snap into the FLEX lens channel for enhanced design flexibility. Brushed Metal Striped Perforated Wavy Standard Diffused 12 13 LED UPGRADE SOLUTIONS 14 Indoor LED UPGRADE SOLUTIONS Cree® LED upgrade solutions offer customers the ability to maintain the existing aesthetic of a fluorescent fixture but take advantage of the greater energy efficiency and long lifespan of LED lights. ZR-RK Commercial Series LED Troffer Retrofit Kit Replaces most existing 2'x4' and 2'x2' recessed troffers. · Easy installation: 4 parts, 4 minutes · 80+ CRI · CCT: 3000K, 3500K, 4000K · 3200 to 5000 lumens · Up to 132 LPW · Input Power: 24W 38W · 0-10V dimming to 5% · 5-year limited warranty APPLICATIONS: Office, education, hospitality, healthcare and petroleum. ZR-RK SERIES RETROFIT KIT TROFFER 1 3 2 Unassembled 4 ONLY 4 PARTS Assembled 15 Indoor LED UPGRADE SOLUTIONS UR Series LED Retrofit Replaces existing fluorescent troffers and linear fluorescent fixtures. · 80 CRI · CCT: 3500K, 4000K · 3600 lumens for 2' lightbar · 4500 lumens for 4' lightbar · Up to 102 LPW · Input Power: 36W 44W · Step level to 50% or 0-10V dimming to 5% · Available in 2- or 3-lamp options · 7-year limited warranty APPLICATIONS: Office, education, hospitality, healthcare and petroleum UR2-24 Retrofit 2' Lightbar Kit UR2-48 Retrofit 4' Lightbar Kit UR3-24 Retrofit 2' Lightbar Kit UR3-48 Retrofit 4' Lightbar Kit 16 17 LED SUSPENDED AMBIENT 18 Indoor LED SUSPENDED AMBIENT Cree's suspended ambient indirect/direct luminaire gives architects an adaptable and supremely high-functioning light system with a super-modern, low-profile look at an appealing price point. LN Series Replaces linear fluorescent indirect/direct suspended fixtures. · 90 CRI · CCT: 3500K, 4000K · 3400 3700 lumens · 115 LPW · Input Power: 32W · Cree WaveMax® Technology · Cree TrueWhite® Technology · 0-10V dimming to 5% or Cree SmartCast® Technology · Modular light engine for simpler design and installation · 10-year limited warranty APPLICATIONS: Office, education SmartCast® Technology Ambient/Motion Sensor Interlocking Units LSQ Square Series Replaces linear fluorescent lamp systems, strips, wraps and more. · 80+, 90 CRI · CCT: 3500K, 4000K, 5000K · 4,000 - 10,000 lumens · Up to 130 LPW · Input Power: 44W - 87W · 120-277 or 347 VAC · 0-10V dimming to 5% · Individual mount or continuous row - surface mount, suspended, pendant and cove · 5-year limited warranty LSQ-C; 10-year limited warranty LSQ APPLICATIONS: Office, education, grocery and retail Square Beauty End Cap 19 Indoor LED SUSPENDED AMBIENT Round Beauty End Cap LS Series Replaces linear fluorescent lamp systems, strips, wraps and more. · 90+ CRI (LS TrueWhite®) or 80+ CRI (LS-C) · CCT: 3500K, 4000K, 5000K · 2500, 4000 and 5000 lumens for 4' · 8000 and 10,000 lumens for 8' · Up to 150 LPW · Input Power: 44W and 88W (LS TrueWhite®) 20W and 51W (LS-C) · Cree TrueWhite® Technology · 0-10V dimming to 5% · 4' and 8' sizes · Occupancy Sensor accessory and thruwiring option available (S-WRAC-OC-1) · 10-year limited warranty for LS TrueWhite® · 5-year limited warranty on LS-C APPLICATIONS: Industrial, manufacturing, grocery and retail LS TrueWhite® LS-C Suspended mount with optional reflectors CS Series Replaces fluorescent indirect/direct suspended fixtures. · 90 CRI · CCT: 3500K, 4000K · 2200 to 8000 lumens · Up to 115 LPW · Input Power: 22W 75W · Cree TrueWhite® Technology · Available with Cree SmartCast® Technology; 0-10V dimming to 5% · 10-year limited warranty APPLICATIONS: Grocery, retail or light industrial 20 21 LED SURFACE AMBIENT 22 Indoor LED SURFACE AMBIENT Cree® surface ambient fixtures provide exceptional illumination performance, costeffective lighting and are designed for easy installation to save time and money. Round Beauty End Cap LS Series Replaces linear fluorescent lamp systems, strips, wraps and more. · 90+ CRI (LS TrueWhite®) or 80+ CRI (LS-C) · CCT: 3500K, 4000K, 5000K · 2500, 4000 and 5000 lumens for 4' · 8000 and 10,000 lumens for 8' · Up to 150 LPW · Input Power: 44W and 88W (LS TrueWhite®) 20W and 51W (LS-C) · Cree TrueWhite® Technology · 0-10V dimming to 5% · 4' and 8' sizes · Occupancy Sensor accessory and thruwiring option available (S-WRAC-OC-1) · 10-year limited warranty for LS TrueWhite® · 5-year limited warranty on LS-C APPLICATIONS: Industrial, manufacturing, grocery and retail LS TrueWhite® LS-C Suspended mount with optional reflectors LSQ Square Series Replaces linear fluorescent lamp systems, strips, wraps and more. · 80+, 90 CRI · CCT: 3500K, 4000K, 5000K · 4,000 - 10,000 lumens · Up to 130 LPW · Input Power: 44W - 87W · 120-277 or 347 VAC · 0-10V dimming to 5% · Individual mount or continuous row - surface mount, suspended, pendant and cove · 5-year limited warranty LSQ-C; 10-year limited warranty LSQ APPLICATIONS: Office, education, grocery and retail Square Beauty End Cap 23 Indoor LED SURFACE AMBIENT WS Series Replaces linear fluorescent lamp systems, strips, wraps and more. · 80 CRI · CCT: 3500K, 4000K, 5000K · 4100 or 6100 lumens · Up to 142 LPW · Input Power: 30W - 43W · 0-10V dimming to 10% (standard) · IP65 and IP66 rated · NSF Splash Zone II certified · 5-year limited warranty APPLICATIONS: Industrial, manufacturing, grocery and retail settings 24 25 LED HIGH-BAY/LOW-BAY 26 Indoor LED HIGH-BAY/LOW-BAY Cree® interior high-bay and low-bay lighting is the ideal source for energyefficient, low-maintenance illumination in large spaces. KBL Series Replaces 250W, 400W HID or up to six-lamp 54W T5HO fixtures. · 70, 80+ CRI · CCT: 3000K, 3500K, 4000K, 5000K · 20,900 or 27,500 lumens · Up to 150 LPW · Input Power: 142W 189W · Operating temperature: -40°C up to 50°C · 0-10V dimming to 10% · Low-profile, lightweight design -14 lbs. · Universal mounting · Optional multi-level occupancy sensing · IP65 optical assembly · 10-year limited warranty · Onboard emergency battery backup Coming Soon: Optional Synapse® SimplySNAP controls APPLICATIONS: Industrial, warehouse, manufacturing, retail, grocery and gymnasiums Opaque Glare Shield Uplight HXB Series Replaces 750W and 1000W HID fixtures. · 70 CRI; 80 CRI · CCT: 3500K, 4000K, 5000K · 35,000 and 70,000 lumens · Up to 150 LPW · Input Power: 276W 485W · 0-10V dimming to 10% · Operating temperature: -40°C to +60°C · Universal mounting: hook & cord or pendant mount · Input Voltage: 120-277V (UL), 347-480V (UH) · 10-year limited warranty APPLICATIONS: Industrial, warehouse, manufacturing, grocery, gymnasium and retail spaces Translucent Glare Shield Uplight 27 Indoor 28 LED HIGH-BAY/LOW-BAY LXB Series Replaces up to 8-lamp T5HO and 1000W metal halide fixtures. · 80+ CRI · CCT: 4000K, 5000K · Up to 60,000 lumens · Up to 162 LPW · Input Power: 80W - 365W · Operating temperature: -30°C up to 55°C · 0-10V dimming to 10% or multi-level occupancy sensor accessory · 5-year limited warranty APPLICATIONS: Retail and industrial high-bay, airport hangars, and gymnasiums Cree EdgeTM Series High Output Replaces multiple 1000W MH fixtures. · 70 CRI (4000K & 5700K); 90 CRI (5000K) · CCT: 5700K standard, 5000K, 4000K · Up to 76,123 lumens · Input Power: 267W 831W · Cree TrueWhite® Technology on 5000K luminaires · 0-10V dimming to 5% · 10-year limited warranty APPLICATIONS: Retail and industrial high-bay, airport hangars, and gymnasiums 304 SeriesTM Replaces up to 320W MH fixtures. · 70 CRI · CCT: 4000K, 5700K · Input Power: 46W 101W · UL wet listed · Multi-Level options · IC rated and non-IC rated available · Modular, low-profile design · 10-year limited warranty APPLICATIONS: Interior high-bay or low-bay, convenience stores, warehouses and gymnasiums 29 LED LAMPS 30 Indoor LED LAMPS Soft accents or dramatic highlights -- Cree® Pro Series LED lamps offer design freedom with beautiful, high-impact illumination for every lamp application. A19 Pro Series 40W, 60W and 75W equivalent. · 90 CRI · CCT: 2700K, 3000K, 4000K (60W only), 5000K · 460, 800, 1100 lumens · Up to 91 LPW · Input Power: 5.5W, 10W, 12W · 25,000 hour rated lifetime · Dimmable to 5% with select dimmers · Suitable for damp locations · Good for enclosed use · 5-year limited warranty APPLICATIONS: Residential, hospitality, retail and grocery A21 Pro Series 100W and 40W/60W/100W equivalent. · 90 CRI · A21 100W: 2700K, 3000K, 5000K · A21 3-way: 2700K · Up to 1600 lumens · Up to 94 LPW · Input Power: 17W; 5.5/9/17W · 25,000 hour rated lifetime · Dimmable to 5% with select dimmers · Suitable for damp locations · 5-year limited warranty APPLICATIONS: Hospitality, retail, grocery and residential 31 Indoor 32 LED LAMPS R20 BR30 BR40 BR Pro Series · 90 CRI · 25,000 hour rated lifetime · Suitable for damp locations · Dimmable to 5% with select dimmers · 5-year limited warranty APPLICATIONS: Residential, hospitality, retail and grocery R20 50W and 75W equivalent · CCT: 2700K, 5000K · 560, 980 lumens · Up to 80 LPW · Input Power: 7W, 13W BR30 65W and 100W equivalent · BR30 65W: 2700K, 3000K, 4000K · BR30 100W: 2700K, 3000K, 5000K · 665, 1400 lumens · Up to 88 LPW · Input Power: 8.8W; 16W BR40 120W equivalent · BR40 120W: 2700K, 3000K, 5000K · 1750 lumens · 76 LPW · Input Power: 23W B11 Candelabra Pro Series 25W, 40W and 60W equivalent. · 90 CRI · CCT: 2700K, 5000K · 220, 300, 515 lumens · Up to 97 LPW · Input Power: 2.6W - 5.3W · 15,000 hours rated lifetime · E12 candelabra base · Decorative Glass Filament · Dimmable to 5% with select dimmers · Suitable for damp locations · Good for enclosed use (25W, 40W) · 5-year limited warranty APPLICATIONS: Chandeliers, lamps and ceiling fan fixtures Indoor LED LAMPS PAR30S PAR30L PAR Pro Series · Up to 50,000 hours rated lifetime · CCT: 2700K, 3000K, 4000K · Up to 92 LPW · Multiple beam angles available: 15°, 25°, 40° · Dimmable to 5% with select dimmers · Suitable for Wet Locations (PAR38) · 5-year limited warranty APPLICATIONS: Hospitality, restaurants, retail, grocery and residential Lamps available: PAR20 50W equivalent PAR30 Short 75W equivalent PAR30 Long 75W equivalent PAR38 120W equivalent PAR38 150W equivalent PAR38 MR16 GU10 MR Lamps · 90 CRI · 25,000 hour rated lifetime · CCT: 2700K, 3000K · Multiple beam angles available: 15°, 25°, 35° · GU5.3 12V, GU10 120V Input · Suitable for damp locations · Smooth dimming · 5-year limited warranty APPLICATIONS: Hospitality, restaurants, retail, grocery and residential Lamps available: MR16 50W equivalent MR16 75W equivalent 33 LED TRACK LIGHTING 34 Indoor LED TRACK LIGHTING LED Integrated Track Heads The Essentia® Series is well-designed and well-made to deliver exceptional track lighting. Essentia® Series Beveled Cylinder LED Track Head Replaces standard halogen and incandescent track heads. · 80 CRI · CCT: 3000K, 3500K, 4000K · 1000 lumens · Input Power: 15W (75W equivalent) · Available in White, Black and Silver finishes · 20° spot reflector with optional 40° diffuser included · Dimmable to 10% · Designed to last 35,000 hours · 3-year limited warranty APPLICATIONS: Indoor residential, commercial, retail or industrial Essentia® Series Mini Flat Back LED Track Head Replaces standard halogen and incandescent track heads. · 80 CRI · CCT: 2700K, 3000K, 3500K, 4000K · 500 lumens · Input Power: 8W · Available in White, Black and Silver finishes · 36° beam angle · Utilizes Cree LEDs · Designed to last 30,000 hours · 3-year limited warranty APPLICATIONS: Indoor commercial, residential, retail or industrial 35 Indoor LED TRACK LIGHTING 12" Wall Washer 24" Wall Washer Both shown with louver and track accessory Essentia® Series Wall Wash Track Head Replaces standard halogen, incandescent and fluorescent track heads. · 80 CRI · CCT: 2700K, 3000K, 3500K, 4000K · 3000 lumens: 12" Wall Wash · 6000 lumens: 24" Wall Wash · Up to 100 LPW · Input Power: 30W (39W CMH equivalent); 60W (70W CMH equivalent) · Dimmable to 10% using compatible TRIAC dimmers · Designed to last 55,000 hours at 25° · Five-year limited warranty APPLICATIONS: Indoor commercial, retail and hospitality Essentia® Series Track Systems Replaces standard one- and two-circuit track systems. · One- and two-circuit track · Extensive collection of connectors available · Available in White, Black and Silver finishes · 4, 6 and 8 feet · Fixtures can be surface or pendant mounted · UL and cUL listed · One-year limited warranty APPLICATIONS: Indoor commercial, retail and hospitality 36 Indoor LED TRACK LIGHTING Essentia® Series Front Loading Gimbal Ring Track Head Replaces standard halogen and incandescent gimbal ring track heads. · Lamp compatibility: PAR38 maximum 150W · Die-cast aluminum housing and polyester powder coated finish · UL and cUL listed · Easy relamping from the front of the gimbal ring · Line voltage - medium base · Recommended lamp: Cree PAR38 · One-year limited warranty APPLICATIONS: Indoor commercial, retail or industrial Essentia® Series Rear Loading Gimbal Ring Track Head Replaces standard halogen and incandescent rear-loading gimbal ring track heads. · Lamp compatibility: PAR20, PAR30, PAR38 · Deep-drawn steel housing with U-shaped double yoke and polyester powder coated finish · Line voltage - medium base · Fixture relamps from the back of the ring · UL and cUL listed · One-year limited warranty APPLICATIONS: Indoor commercial, retail or industrial 37 Indoor LED TRACK LIGHTING Essentia® Series Flat Back Line Voltage Track Head Replaces standard line voltage track heads. · Lamp compatibility: PAR20, BR30, PAR30L · Deep-drawn steel round back housing and polyester powder coated finish · Line voltage - medium base · This classic shape has a U-shaped double yoke with a single-locking knob to secure the aiming angle · UL and cUL listed · One-year limited warranty APPLICATIONS: Indoor commercial, retail or industrial 38 39 TRACK ACCESSORIES 40 Indoor TRACK ACCESSORIES Essentia® Series Track Accessories · Accessories including adaptors, connectors, clips, collars, caps and covers · For use with all Essentia® Series track products · For either one-circuit or two-circuit applications · Available in White, Black and Silver finishes · One-year limited warranty Current Limiters, Power Feeds and Circuit Breakers Current Limiter In-Line Adjustable Power Feed Current Limiter End Power Feed Title 24 Compliant Current Limiter In-Line Adjustable Power Feed Current Limiter Mini End Power Feed Circuit Breakers Title 24 Compliant Current Limiter End Power Feed Title 24 Compliant Current Limiter Mini End Power Feed Cord & Plug Feed Floating Feed Conduit Feed 41 Indoor TRACK ACCESSORIES Current Limiters, Power Feeds and Circuit Breakers Outlet Box Feed T-Bar End Feed End Feed Adjustable Connector/Feed "T" Connector Feed "X" Connector T-Bar Adjustable Connector/Feed Outlet Box Cover Mini Straight Connector Midpoint Mounting T-Bar Attachment Clips (Flush Tiles) Pendant Adaptor T-Bar Attachment Clips (Drop Tiles) 42 43 LED AREA 44 Outdoor LED AREA Diverse lighting options featuring NanoOptic® Technology for parking lots, roadways, pathways, security areas and flood applications. NEW Noctura Series Replaces up to 1000W MH fixtures* · Minimum 70 CRI · CCT: 3000K*, 4000K, 5000K, 5700K* · Up to 35,600 lumens · Up to 155 LPW · Input Power: 75W 230W · Versatile mounting: Direct Arm, Adjustable Arm and Trunnion · Suitable for wet locations · IP66 rated · 1.5G Vibration certified · NEMA® 3-Pin Photocell Receptacle available · 5-year limited warranty APPLICATIONS: Parking lots, security, site pathway and general site lighting *Limited availability, consult factory XSP Series Replaces up to 400W MH fixtures.* · Minimum 70 CRI · CCT: 2700K, 3000K, 4000K, 5000K, 5700K · Up to 23,800 lumens · Up to 129 LPW · Input Power: 47W 184W · NanoOptic® Precision Delivery GridTM optic · Designed with 0-10V dimming capabilities · cULus listed · Utility label and NEMA® 7-Pin Photocell Receptacle · 10-year limited warranty APPLICATIONS: Parking lots, walkways and general area spaces 45 Outdoor LED AREA OSQ High Output Series Replaces multiple 1000W MH fixtures.* · Minimum 70 CRI (3000K, 4000K, 5700K); 90 CRI (5000K) · CCT: 3000K, 4000K, 5000K, 5700K · Up to 68,691 lumens · Up to 125 LPW · Input Power: 341W - 550W · Programmable Multi-Level options · IP66 rated · 3G Vibration certified · Colorfast DeltaGuard® finish · Optional NEMA® 7-Pin Photocell Receptacle · 10-year limited warranty APPLICATIONS: Auto dealerships, parking lots, campuses, facade lighting, high-mast and general site lighting OSQ Series (Medium & Large) Replaces up to 1000W MH fixtures.* · Minimum 70 CRI (3000K, 4000K & 5700K); 90 CRI (5000K) · CCT: 3000K, 4000K, 5000K, 5700K · Up to 27,103 lumens · Up to 139 LPW · Input Power: 53W 215W · NanoOptic® Precision Delivery GridTM optic · Versatile mounting · Programmable Multi-Level options · IP66 rated · 3G Vibration certified · Colorfast DeltaGuard® finish · 10-year limited warranty · Optional NEMA® 7-Pin Photocell Receptacle APPLICATIONS: Parking lots, walkways, campuses, auto dealerships, general site lighting and internal roadways 46 Outdoor LED AREA Cree EdgeTM Series Replaces multiple 1000W MH fixtures.* · Minimum 70 CRI (4000K & 5700K); 90 CRI (5000K) · CCT: 4000K, 5000K (High Output), 5700K · Up to 85,638 lumens · Input Power: 25W 831W · Utilizes Cree TrueWhite® Technology · UL wet listed · Programmable Multi-Level options · Modular, low-profile design · 3G Vibration certified · Colorfast DeltaGuard® finish · Optional NEMA® 7-Pin Photocell Receptacle · 10-year limited warranty APPLICATIONS: Auto dealerships, large parking lots, campuses, facade lighting and general site lighting applications Cree EdgeTM Series Round Replaces up to 400W MH or HPS fixtures.* · Minimum 70 CRI · CCT: 4000K, 5700K · Up to 25,065 lumens · Input Power: 46W 202W · UL wet listed · Modern, low-profile design · Colorfast DeltaGuard® finish · 10-year limited warranty APPLICATIONS: Campus pathway, parking facilities Cree EdgeTM Series Pathway Replaces up to 100W PSMH or 100W HPS fixtures.* · Minimum 70 CRI · CCT: 4000K, 5700K · Up to 2,716 lumens · Input Power: 22W 40W · UL wet listed · Two-Level options · Multiple heights available · IP66 rated · Colorfast DeltaGuard® finish · 10-year limited warranty APPLICATIONS: Landscape, walkways and general site lighting *Replacements are general recommendations only. They can vary dependent upon application and optical performance requirements. Consult factory for specific product recommendation based on application. 47 LED DECORATIVE STREET & ROADWAY 48 Outdoor LED DECORATIVE STREET & ROADWAY Maintain the day form, but modernize the incumbent technology with energyefficient, low-maintenance LED solutions from Cree. DPT Series Replaces up to 70W MH or HPS and up to 175W Mercury Vapor fixtures.* · Minimum 70 CRI · CCT: 3000K, 4000K · Up to 3,780 lumens · Input Power: 34W · Input Voltage: Integral 120-277V, 50/60Hz · Utilizes a standalone UL 1598 compliant light engine · Made with Cree® LED technology · 10-year limited warranty APPLICATIONS: Decorative street, pathway and general area lighting DPT luminaire shown mounted to an enabling luminaire base DPT Series with optional Backlight Control Shield accessory: DPT-BLS 49 Outdoor LED DECORATIVE STREET & ROADWAY LED Post-Top Upgrade Kit Replaces up to 175W MH or 150W HPS fixtures.* · Minimum 70 CRI · CCT: 2700K, 4000K · Up to 6,400 lumens · Input Power: 65W 97W · 0-10V dimming option · Field Adjustable Output for increased flexibility · Reuses most of existing luminaire for little waste · 10-year limited warranty APPLICATIONS: Decorative street, pathway and general area lighting BXRAAA Kit for Holophane® Granville Acorn BXRAAB Kit for Holophane® Washington PostLite® Acorn BXRAAD Kit for King Luminaire Washington Acorn BXRAAE Kit for Holophane® Esplanade® Teardrop BXRAAF Kit for Lumec® New Westminster Globe BXRAAH Kit for Holophane® Granville Utility Acorn w/ Hinged Door BXRAAK Kit for Holophane® Granville Utility Acorn w/ Removable Door *Replacements are general recommendations only. They can vary dependent upon application and optical performance 50 requirements. Consult factory for specific product recommendation based on application. 51 LED STREET & ROADWAY 52 Outdoor LED STREET & ROADWAY From rural streets to major highways, we have economical LED street lighting solutions that reduce energy and maintenance costs without sacrificing illumination performance. RSW Series Replaces up to 400W HPS fixtures.* · 80 CRI (Small & Medium); 70 CRI · CCT: 2700K (Small & Medium), 3000K, 4000K, 5000K · Up to 31,300 lumens · Up to 128 LPW · Input Power: 26W 244W · Utilizes WaveMax® Technology · IP66 rated optic box and driver · Lightweight and easy to install · Utility label and NEMA® 7-Pin Photocell Receptacle · 10-year limited warranty APPLICATIONS: Residential, local/collector roadways, intersections, major roads and highways XSP Series Replaces up to 400W HPS fixtures.* · Minimum 70 CRI · CCT: 2700K, 3000K, 4000K, 5000K, 5700K · Up to 23,800 lumens · Up to 129 LPW · Input Power: 47W 184W · NanoOptic® Precision Delivery GridTM optic · Designed with 0-10V dimming capabilities · cULus listed · Utility label and NEMA® 7-Pin Photocell Receptacle · 10-year limited warranty APPLICATIONS: Street lighting from residential streets to major roadways 53 Outdoor LED STREET & ROADWAY The word on the street is Cree. Communities are saving up to 70% on energy costs while enhancing driver and pedestrian safety. NEW Traveyo Series Replaces up to 400W HPS fixtures.* · Minimum 70 CRI · CCT: 2700K, 3000K, 4000K, 5000K · Up to 32,600 lumens · Up to 155 LPW · Input Power: 17W 219W · Lightweight and easy to install · Utility label and NEMA® 7-Pin Photocell Receptacle · 5-year limited warranty APPLICATIONS: Residential, local/collector roadways, intersections, major roads and highways RUL Series Replaces up to 100W HPS or 100W to 175W Mercury Vapor fixtures.* · Minimum 70 CRI · CCT: 3000K, 4000K · Up to 5,682 lumens · Up to 114 LPW · Input Power: 50W · UL wet listed · Significant energy and maintenance savings · Easy installation · Utility label and NEMA® 3-Pin Photocell Receptacle · Utility kits available · 10-year limited warranty APPLICATIONS: Rural and residential street lighting, agricultural, general security and loading/receiving areas RUL luminaire shown with reflector/ refractor included in ES-K2 option 54 Outdoor LED STREET & ROADWAY LEDway® High Output Series Replaces up to 400W HPS fixtures.* · Minimum 70 CRI · CCT: 3000K, 4000K, 5700K · Up to 28,462 lumens · Input Power: 136W or 274W · UL wet listed · Field Adjustable Output option · Utility option · 10-year limited warranty APPLICATIONS: Street lighting from local/collector streets to major roadways LEDway® Series Replaces up to 250W HPS fixtures.* · Minimum 70 CRI · CCT: 4000K, 5700K · Up to 24,717 lumens · Input Power: 35W 274W · UL wet listed · Modular design · Utility option · 10-year limited warranty APPLICATIONS: Street lighting from residential streets to major roadways *Replacements are general recommendations only. They can vary dependent upon application and optical performance requirements. Consult factory for specific product recommendation based on application. 55 LED CANOPY & SOFFIT 56 Outdoor LED CANOPY & SOFFIT Cree® recessed canopy and soffit luminaires efficiently light the way to exterior sites, surrounding areas and interior high-bay applications leading to an overall low total cost of ownership. Flat Lens Drop Lens CPY Series Replaces up to 400W HID fixtures.* · Minimum 70 CRI · CCT: 3000K, 4000K, 5700K · Up to 20,080 lumens · Input Power: 31W 145W · Direct, pendant or hook and cord mount · Flat or drop lenses available · Class I, Division II Hazardous Location rating · Programmable Multi-Level option · Easy and quick installation · IP66 rated · Upgrade Kit options · 10-year limited warranty APPLICATIONS: Petroleum stations, convenience stores, drivethru banks, restaurants, retail and grocery, industrial low-bay and high-bay 228 SeriesTM Replaces up to 400W HID fixtures.* · Minimum 70 CRI · CCT: 4000K, 5700K · Up to 21,486 lumens · Input Power: 54W 201W · UL wet listed · Programmable Multi-Level option · Upgrade kit options · Modular, flush mount design · 10-year limited warranty APPLICATIONS: Petroleum stations, convenience stores, drive-thru banks and restaurants, retail and grocery 57 Outdoor LED CANOPY & SOFFIT 304 SeriesTM Replaces up to 320W HID fixtures.* · 70 CRI · CCT: 4000K, 5700K · Up to 13,697 lumens · Input Power: 46W 135W · UL wet listed · IP66 rated · Driver centrally located · Convenient electrical inspection access from below · Modular, flush mount design · 10-year limited warranty APPLICATIONS: Petroleum stations, convenience stores, drivethru banks and restaurants, retail and grocery Cree EdgeTM Series Replaces up to 700W HID fixtures.* · 70 CRI · CCT: 4000K, 5700K · Up to 31,193 lumens · Input Power: 46W 263W · UL wet listed · IP66 rated · Programmable Multi-Level option · Modular, low-profile design · 10-year limited warranty APPLICATIONS: Petroleum canopies, medium-high bay general lighting and soffits *Replacements are general recommendations only. They can vary dependent upon application and optical performance 58 requirements. Consult factory for specific product recommendation based on application. 59 LED PARKING STRUCTURE 60 Outdoor LED PARKING STRUCTURE First impressions start in the garage. Cree® parking structure luminaires make it a better one by providing clean, uniform, low-glare illumination with superior performance that enhances safety and visibility. IG Series Replaces up to 175W HID fixtures.* · Minimum 80 CRI · CCT: 3000K, 4000K, 5700K · Up to 7,500 lumens · Up to 118 LPW · Input Power: 33W or 66W · Utilizes WaveMax® Technology · Designed with 0-10V dimming capabilities standard (non-PML) · UL wet listed · IP66 rated · Precise low-glare optics · Integrated Control options available · ENCELIUM® Enabled option · 10-year limited warranty Coming Soon: Optional Synapse® SimplySNAP controls APPLICATIONS: Parking structure VG Series Replaces up to 175W HID fixtures.* · Minimum 70 CRI · CCT: 3000K, 4000K, 5700K · Up to 5,700 lumens · Input Power: 33W or 54W · UL wet listed · IP66 rated · Low glare, indirect view LEDs · Programmable Multi-Level option · 10-year limited warranty APPLICATIONS: Parking structures 61 Outdoor LED PARKING STRUCTURE 304 SeriesTM Replaces up to 320W HID fixtures.* · Minimum 70 CRI · CCT: 4000K, 5700K · Up to 13,712 lumens · Input Power: 46W 135W · UL wet listed · IP66 rated · Programmable Multi-Level option · Integrated occupancy sensor · Low-profile design · 10-year limited warranty APPLICATIONS: Parking structures *Replacements are general recommendations only. They can vary dependent upon application and optical performance 62 requirements. Consult factory for specific product recommendation based on application. 63 LED FLOOD 64 Outdoor LED FLOOD Cree® luminaires for flood and sign lighting provide specific distributions of light for showcasing horizontal and vertical sign surfaces and architectural features. OSQ Series NEW Noctura Series Replaces up to 400W MH fixtures* · Minimum 70 CRI · CCT: 3000K*, 4000K, 5000K, 5700K* · Up to 28,400 lumens · Up to 158 LPW · Input Power: 12W 186W · IP66 rated · Suitable for wet locations · Versatile mounting: Small - Knuckle, Yoke Large - Adjustable Arm, Trunnion · 1.5G Vibration certified · NEMA® 3-Pin Photocell Receptacle available · 5-year limited warranty APPLICATIONS: Accent, sign or building facades *Limited availability, consult factory OSQ Series Replaces up to 1000W MH fixtures.* · Minimum 70 CRI (3000K, 4000K & 5700K); 90 CRI (5000K) · CCT: 3000K, 4000K, 5000K, 5700K · Up to 27,103 lumens · Input Power: 53W 215W · Up to 139 LPW · NanoOptic® Precision Delivery GridTM optic · Programmable Multi-Level options · P66 rated · 3G Vibration certified · Colorfast DeltaGuard® finish · Optional NEMA® 7-Pin Photocell Receptacle · 10-year limited warranty APPLICATIONS: Parking lots, walkways, campuses, auto dealerships and building façades 65 Outdoor LED FLOOD OSQ Series Utility UA Mount OSQ Series Utility Replaces up to 1000W MH fixtures.* · Minimum 70 CRI · CCT: 3000K, 4000K · Up to 26,583 lumens · Input Power: 53W 215W · 45° Utility Arm (with Cord Side or End Exit); Direct Mounts available · Utility label & NEMA® 7-Pin Photocell Receptacle included · Suitable for wet locations · 3G Vibration certified · Colorfast DeltaGuard® finish · 10-year limited warranty APPLICATIONS: Parking lots, walkways, campuses, auto dealerships and building façades designed for utilities 304 SeriesTM Replaces up to 250W HID fixtures.* · Minimum 70 CRI · CCT: 4000K, 5700K · Up to 13,712 lumens · Input Power: 46W 135W · UL wet listed · Programmable Multi-Level option · Modular, low-profile design · 10-year limited warranty APPLICATIONS: Underpasses and sign lighting *Replacements are general recommendations only. They can vary dependent upon application and optical performance 66 requirements. Consult factory for specific product recommendation based on application. Outdoor LED FLOOD Cree EdgeTM High Output Flood Cree EdgeTM Series Replaces multiple 1000W MH fixtures.* · Minimum 70 CRI (4000K & 5700K); 90 CRI (5000K) · CCT: 4000K, 5000K (High Output), 5700K · Up to 85,638 lumens · Input Power: 25W 831W · UL wet listed · Programmable Multi-Level options · Modular, low-profile design · IP66 rated (select versions) · 3G Vibration certified · Colorfast DeltaGuard® finish · Optional NEMA® Photocell Receptacle · 10-year limited warranty APPLICATIONS: Parking lots, walkways, campuses, auto dealerships and building façades Cree EdgeTM Flood Square 67 LED WALL MOUNT 68 Outdoor LED WALL MOUNT Sleek and stylish security and perimeter lighting features a low-profile design that provides clean, uniform illumination for increased visibility and a secure environment. NEW Noctura Series Replaces up to ?W MH fixtures* · Minimum 70 CRI · CCT: 3000K*, 4000K, 5000K, 5700K* · Up to 22,600 lumens · Input Power: 12W 148W · Suitable for wet locations · IP66 rated · 5-year limited warranty APPLICATIONS: Building facades, security, general outside lighting *Limited availability, consult factory XSP Series Replaces up to 250W MH fixtures.* · Minimum 70 CRI (3000K, 4000K & 5700K); 90 CRI (5000K) · CCT: 3000K, 4000K, 5000K,5700K · Up to 8,475 lumens · Input Power: 19W 78W · Suitable for wet locations · IP66 rated · Multi-Level options · Utilizes Cree TrueWhite® Technology · 10-year limited warranty APPLICATIONS: Security and perimeter outside lighting Cree EdgeTM Series Replaces up to 320W MH fixtures.* · Minimum 70 CRI · CCT: 4000K, 5700K · Up to 15,094 lumens · Input Power: 25W 134W · Suitable for wet locations · Multi-Level options · Modular, low-profile design · IP66 rated · Colorfast DeltaGuard® finish · 10-year limited warranty APPLICATIONS: Security and perimeter outside lighting *Replacements are general recommendations only. They can vary dependent upon application and optical performance requirements. Consult factory for specific product recommendation based on application. 69 CREE LIGHTING TECHNOLOGY 70 Indoor CREE LIGHTING TECHNOLOGY THE SMARTCAST INTELLIGENCE PLATFORMTM Wherever the lights, whatever the environment, the SmartCast Intelligence PlatformTM enables advanced lighting control and limitless business applications with value far beyond lighting. Simply Intuitive, Advanced Lighting Control--Everywhere. Featuring an intuitive, simple design and user experience for operation, commissioning and data collection, the SmartCast Intelligence PlatformTM brings scalable, intelligent lighting networks to every space, delivering energy savings of 70% or more and a highly personalized lighting experience. An Open System That Supports SmartCast® and 3rd-Party Technologies. This isn't another proprietary "black-box" system that locks you into costly vendor charges for upgrades or inter-network connectivity. BACnet integration and a ReST-based application programming interface (API) open the door to virtually unlimited applications through seamless connectivity with enterprise networks, building management software and the Internet of Things. A Secure Architecture. Designed with security in mind from day one, the SmartCast Intelligence PlatformTM employs industry-standard encryption to protect data streams, SmartCast® luminaires and other network endpoints. End users always retain control over access privileges, enabled applications and data streams shared with third parties. Software and security updates? They're seamless. Business Value Far Beyond Lighting. Add SmartCast AdvisorTM, and the platform lets you turn data into dollars from day one with occupancy-based space optimization and situational awareness. For the future, the SmartCast Intelligence PlatformTM is ready to pioneer data-driven applications that help businesses become more agile, productive and profitable. 71 Indoor CREE LIGHTING TECHNOLOGY So Easy, the Building of the Future Can Be the One You're Already In. ENVIRONMENTAL AWARENESS AND CONTROL Embedded sensors continually detect and share data on room occupancy and ambient light to fine-tune your environment and energy-saving strategies in real time. SIMPLE SET-UP AND COMMISSIONING OneButtonTM Setup commissions hundreds of luminaires in a single step, providing smart lighting that meets existing and emerging buildings codes, wirelessly and over Power over Ethernet (PoE) -- live in minutes, not weeks. 72 Indoor CREE LIGHTING TECHNOLOGY VALUE BEYOND LIGHTING SmartCast® Technology creates secure lighting networks that connect seamlessly with other building management systems and with third-party IoT sytems for even more value. A PLATFORM FOR INTELLIGENT LIGHTING SmartCast® Technology orchestrates the optimal environment for energy efficiency and productivity by adjusting brightness and color temperatures to tasks and personal preferences, and tracking improvements. 73 Indoor CREE LIGHTING TECHNOLOGY Cree SmartCast® Technology Products CR SERIES ARCHITECTURAL TROFFERS Integrated Motion Sensor CR24TM See page 11 for more information. ZR COMMERCIAL SPEC TROFFERS Integrated Motion Sensor ZR24TM See page 11 for more information. 74 Indoor CREE LIGHTING TECHNOLOGY LN SERIES SUSPENDED AMBIENT INDIRECT/DIRECT KR SERIES DOWNLIGHTS LN4TM See page 15 for more information. KR6TM See page 3 for more information. CS SERIES LINEAR LUMINAIRES CS14TM See page 16 for more information. 0-10V Interface Configuration Tool Light Dimmer CCT Dimmer Plug Load Controller Visit lighting.cree.com for additional offerings including Lutron EcoSystem® Enabled controls. 75 Indoor CREE LIGHTING TECHNOLOGY CREE WAVEMAX® TECHNOLOGY Cree WaveMax® Technology is a breakthrough in the execution of waveguide technology that challenges industry-standard assumptions of how light is delivered. Featuring up to 90% optical efficiency and precise optical control, Cree WaveMax® Technology enables customers to obtain unmatched visual comfort and improved color quality without sacrificing performance. This transformative technology redefines the limits of fixture design to optimize performance and provides more aesthetic options at an unmatched customer value. LN Series RSW Series IG Series Before: Metal Halide Lighting After: Cree WaveMax® Technology LED Lighting COLORFAST DELTAGUARD® FINISH Cree's exclusive Colorfast DeltaGuard® Finish protects our LED outdoor fixtures without compromise. Immersive conditioning across 18 stages delivers an e-coat epoxy primer with an ultra-durable powder topcoat, providing unmatched protection against corrosion, UV light, fading and weathering complete with a 10-year limited warranty. 76 Indoor CREE LIGHTING TECHNOLOGY CREE TRUEWHITE® TECHNOLOGY Cree TrueWhite® Technology provides exceptional color quality to lighting applications. Featuring a broad spectral power distribution, Cree TrueWhite® Technology delivers 90+ CRI, high R9 values, and accurate and consistent color. The result is high performing, beautiful white light that can dramatically improve the visual appearance of both interior and exterior spaces -- all while offering significant energy savings compared to traditional technologies. Before: Fluorescent Lighting After: Cree TrueWhite® LED Lighting NANOOPTIC® TECHNOLOGY With patented NanoOptic® Technology available in multiple distributions, Cree® outdoor LED fixtures provide precise optical control for exceptional application performance and energy savings. The NanoOptic® refractor system offers superior light control with more lumens delivered in the target area, improved uniformity ratios and controlled high-angle brightness. High Pressure Sodium Lighting Cree Edge SeriesTM Lighting 77 Visit creelighting.com or contact a Cree Lighting representative to learn more. © 2019 Cree, Inc. All rights reserved. For informational purposes only. Not a warranty or specification. See lighting.cree.com for warranty and specifications. Cree®, the Cree logo, TrueWhite®, Cree TrueWhite®, Essentia®,SmartCast®, Colorfast DeltaGuard®, NanoOptic®, LEDway® and WaveMax® are registered trademarks and the Cree TrueWhite Technology logo, NocturaTM, Precision Delivery GridTM, OneButtonTM, KR8TM, KR6TM,CR4TM, CR6TM, LN4TM, Cree EdgeTM, XSPTM, 228 SeriesTM, 304 SeriesTM, SmartCast Intelligence PlatformTM, SmartCast AdvisorTM, TraveyoTM, RULTM, and RSWTM are trademarks of Cree, Inc. Lutron® and Lutron EcoSystem® are registered trademarks of Lutron Electronics Co. Lumec is a registered trademark of Lumec Inc. Holophane®, Esplanade®, and Washington PostLite® are registered trademarks of ABL IP Holding LLC. Synapse® is a registered trademark of Synapse Wireless, Inc. ENCELIUM® is a registered trademark of Osram Sylvania, Inc. CAT/CSJ-C004 Rev. Date 05/08/2019Adobe InDesign CC 14.0 (Macintosh) Adobe PDF Library 15.0
