Insulation Family Guide for Residential Applications
WHERE QUALITY AND PERFORMANCE MAKE A HOME
Insulation is a critical feature of any home impacting overall comfort by helping maintain a uniform temperature throughout the house. Owens Corning provides home builders and home buyers with a number of insulation solutions to meet their needs. Every home is different though. Factors such as architecture, climate and building codes combine to create a wide variety of needs which demand an equally wide range of high-performance insulation solutions. The FOAMULAR® Extruded Polystyrene (XPS) Insulation family of rigid foam board products is here to offer these solutions. Together with EcoTouch® insulation and housewrap, FOAMULAR® insulation is an integral part of Owens Corning® ResidentialComplete® Wall Systems.
FOAMULAR® XPS INSULATION FAMILY VALUES FOR RESIDENTIAL APPLICATIONS
COMPREHENSIVE LINE OF PRODUCTS. · Wide choice of sizes, thicknesses and edges for
fast installation, less labor. · Choose the strength you need, from 15 to 100 psi. · Available unfaced or with film facing for added
damage resistance. LIFETIME LIMITED WARRANTY.* · For the life of the home or building. · Maintains at least 90% of its R-value**. · Covers all product properties - ASTM C578.
*See actual warranty for complete details, limitations and requirements. **R-value means resistance to heat flow. The higher the R-value the greater the insulating power. As manufactured, Fiberglas insulation is resistant to mold growth. However, mold growth can occur on building materials, including insulation, when it becomes contaminated with organic material and when water is present. To avoid mold growth on FiberglasTM insulation, remove any water that has accumulated and correct or repair the source of the water as soon as possible. Insulation that has become wet should be inspected for evidence of residual moisture and contamination, and any insulation that is contaminated should be promptly removed and replaced.
EXCEPTIONAL MOISTURE RESISTANCE.
· Resists moisture and retains R-value even after exposure to standing water, wet soil and more.
· Resists common acid soils and decay. · Effectively blocks mildew, corrosion and rot.
OUTSTANDING INSULATING PROPERTIES.
· High, stable R-value (5 per inch of product thickness). · Higher R-value than wood fiber, plywood or 1/2"
gypsum board products. · Readily combines with EcoTouch® insulation for
greater R-value in walls. · Used in fire-rated exterior wall assemblies for
application in single and multi-family residential buildings, office buildings, schools, shopping centers and more.
INCREDIBLE EASE OF USE.
· Easy to handle, score, cut and install; no special tools needed.
· Can be used on either wood or steel framing or concrete walls.
· Compatible with common exterior finishes & claddings.
· Meets all applicable codes and standards.
SUSTAINABLE BENEFITS.
· Foamular is certified to meet indoor air quality standards under the stringent GREENGUARD Gold Certification Program.
· Foamular has third party certified recycled content by Scientific Certification Systems (SCS) to contain an average of 20% recycled content.
· Made with a zero ozone depletion formula. · Reusable.
THE OWENS CORNING® FOAMULAR® XPS INSULATION FAMILY ALBUM
BILD-R-TAPE® Construction Tape
FOAMULAR® INSULATION PHYSICAL PROPERTIES(1)
PROPERTY
TEST METHOD2
Thermal Resistance, R-Value (180 day)3, minimum, ºF * ft2 * hr/btu (RSI, ºC * m2/W)
ASTM C518
Compressive Strength, minimum psi (kPa)4
ASTM D1621
Flexural Strength, minimum psi (kPa)5 Water Absorption, maximum % by volume6 Water Vapor Permeance, maximum perm (ng/Pa/s/m2)7 Dimensional Stability, maximum % linear change Flame Spread 8, 9 Smoke Developed 8, 9, 10 Oxygen Index, minimum % by volume 8 Service Temperature, maximum °F (°C) Linear Coefficient of Thermal Expansion, in/in/ ºF (m/m/°C) Type Classifications
ASTM C203 ASTM C272 ASTM E96 ASTM D2126 ASTM E84 ASTM E84 ASTM D2863
ASTM E228 ASTM C578
1. Properties shown are representative values for 1" thick material, unless otherwise specified. Testing modified as needed for products less than 1/2" thickness.
2. Modified as required to meet ASTM C578 3. R means the resistance to heat flow; the higher the value, the greater the insulation power. This
insulation must be installed properly to get the marked R-value. Follow the manufacturer's instructions carefully. If a manufacturer's fact sheet is not provided with the material shipment, request this and review it carefully. R-values vary depending on many factors including the mean temperature at which the test is conducted, and the age of the sample at the time of testing. The R-value for FOAMULAR® XPS is provided from testing at two mean temperatures, 40º F and 75 º F, and 180 day real-time aged (as mandated by ASTM C578). The R-value at 180 day real-time age and 75º F mean temperature is commonly used to compare products and is the value printed on the product.
FOAMULAR® 150 Insulation
INSULPINK® Insulating Sheathing
FOAMULAR® 250 Insulation INSUL-DRAIN® Insulation
FOAMULAR® 400 Insulation
R-5/inch
R-5/inch
R-5/inch
15
25 (172)
40 (276)
40 (276) 0.3
1.5 (86) 2.0 10 175 24
165 (74) 3.5 x 10-5 (6.3x10-5)
Type X
50 (345) 0.3
1.5 (86) 2.0 10 175 24
165 (74) 3.5 x 10-5 (6.3x10-5)
Type lV
90 (621) 0.05
1.1 (63) 2.0 10 175 24
165 (74) 3.5 x 10-5 (6.3x10-5)
Type Vl
4. Values at yield or 10% deflection, whichever occurs first. Testing modified as needed for products less than 1/2" thickness.
5. Value at yield or 5%, whichever occurs first 6. Data ranges from 0.00 to value shown due to the level of precision of the test method 7. Water vapor permeance decreases as thickness increases 8. These laboratory tests are not intended to describe the hazards presented by this material under
actual fire conditions 9. Data from Underwriters Laboratories Inc.® classified. See Classification Certificate U-197 10. ASTM E84 is thickness-dependent, therefore a range of values is given
THERMAL RESISTANCE R-VALUES FOR TYPICAL FRAMED WALL
EXTERIOR FINISH
3/4" Wood Siding 1/2" Plywood Hardboard Siding Vinyl Siding 4" Face Brick 1" Stucco
R-VALUE 1.05 .62 .71 .44 .20
INSULATING BLANKET
THICKNESS (IN.)
3 1/2" R13 3 1/2" R15 6 1/4" R19
3 1/2" R13 3 1/2" R15 6 1/4" R19
3 1/2" R13 3 1/2" R15 6 1/4" R19
3 1/2" R13 3 1/2" R15 6 1/4" R19
3 1/2" R13 3 1/2" R15 6 1/4" R19
DESIGN THERMAL RESISTANCE (R) VALUE (WINTER CONDITIONS) FOR FOAMULAR® THICKNESS(1)
1/2" (R-3)
3/4" (R-4)
1" (R-5)
18.50 20.50 24.50
19.45 21.45 25.45
20.76 22.76 26.76
18.07 20.07 24.07
19.02 21.02 25.02
20.33 22.33 26.33
18.16 20.16 24.16
19.11 21.11 25.11
20.42 22.42 26.42
18.90 20.90 24.90
19.85 21.85 25.85
21.16 23.16 27.16
17.65 29.65 23.65
18.60 20.60 24.60
19.91 21.91 25.91
The higher the R-value, the greater the insulation value. Find out why in the Seller's Fact Sheet on R-values. * Nominal thickness
FOAMULAR® PINK Foam Insulation is produced using the Owens CorningTM patented HYDROVAC® process technology. Note: (1) resistances are calculated, including Inside/Outside air films, based upon procedures and design values for all components at 75° F mean temperature from current ASHRE Handbook of Fundamentals.
FOAMULAR® XPS INSULATION RESIDENTIAL PRODUCT SELECTION GUIDE
RESIDENTIAL APPLICATION
General Purpose
PRODUCT
FOAMULAR® 150 15 psi
ASTM C578 Type
X
FOAMULAR® 250
25 psi
IV
WALL Sheathing
FOAMULAR®
Insulating Sheathing
X
15 psi
FOAMULAR® PROPINK®
Insulating Sheathing
X
15 psi
FOAMULAR® Half-Inch
X
15 psi
RE-SIDING
FOAMULAR® Fanfold Foam Residing Board
FOUNDATION
Under Slab
FOAMULAR® 400
IV
40 psi
IV
Exterior Wall Foundation FOAMULAR® 250
IV
25 psi
ACCESSORIES
FOAMULAR®
IV
INSUL-DRAIN®
25 psi
HomeSealR® Foam Joint Tape
FlashSealR® Foam Flashing Tape
PINKWRAP® Housewrap TruWrap® Housewrap
BILD-R-TAPE® Construction Tape
ProPink ComfortSeal® Sill Gasket
raft-R-mate® Attic Rafter Vent
R-VALUE
R-5.0 R-7.5 R-10
R-5.0 R-7.5 R-10
THICKNESS (in Inches)
AVAILABILITY
1" 1-1/2"
2"
Square, Scored Square and Tongue & Groove Edges 24"x96", 48"x96" or 108"
1" 1-1/2"
2"
Square, Scored Square and Tongue & Groove Edges 24"x96", 48"x96" or 108"
USES
For exterior sheathing insulation projects and interior of basement walls in lieu of InsulPink® insulation.
For exterior of foundation walls, underslab for slab foundations or basement foundations and crawlspaces.
R-3.0 R-4.0 R-5.0
R-3.0 R-4.0 R-5
R-3
1/2"* 3/4" 1"
1/2" 3/4" 1"
1/2"
Square and Tongue & Groove Edges Film Faced Both Sides 48"x96" or 108" *Square only
Exterior above grade walls and underneath vinyl siding or other claddings by reducing thermal bridging from wood studs or continuous insulation.
Tongue & Groove Reinforced Fill Facing on both sides 48"x96" or 108"
Exterior above grade walls and underneath vinyl siding or other claddings by reducing thermal bridging from wood studs or continuous insulation. Extra strength with its reinforced laminated film.
Square and Shiplap Edges 24"x96", 48"x96" or 108"
For above grade sheathing.
R-1.0
1/4"
4'x50'; folded every 2 feet
For new or replacement siding. Laminated on one side.
R-5 R-10
R-5.0 R-7.5 R-10
R-4.4 R-6.9 R-10.6
1" 2"
1" 1-1/2"
2"
1" 1-1/2" 2-1/4"
24"x96" 24", 48" and 96"
Square, Scored Square and Tongue & Groove Edges 24"x96",48"x96" or 108"
1"x48"x96" 1.5"x48"x96" 2.25"x48"x96"
For under slab, concrete floors. High load applications.
For exterior foundation walls; insulates and protects the waterproofing membrane.
For exterior foundation walls; provides superior drainage capacity & protection for ground water concerns.
3" Width 180' length
Provides reliable adhesion to FOAMULAR® XPS that is both durable and flexible.
4" Width 6" Width 9" Width
90' length
Provides reliable adhesion to FOAMULAR® XPS and seals the rough openings around windows and doors; durable and flexible.
3'x100' / 9'x100' / 9'x150' / 10'x150' / 9'x195'
Reduces air infiltration through residential exterior side wall construction.
3'x100' / 4.5'x100'; 9'x100' / 10'x100'; 9'x150' / 10'x150'; 9'x195' / 10'x195'
Reduces air infiltration through residential exterior side wall construction; budget-friendly.
2.375" Width 72 yards length
Secures the seams of Owens Corning housewrap products and general construction repair.
1/4"
Air Infiltration Gasket, 3-1/2",
Helps eliminate drafts around foundations.
5-1/2" and 7-1/2" width; 50' length
22-1/2" x 44" Perforated for use between 24" or 16" rafter spacing
Assists in the constant flow of air and increases attic ventilation.
FOAMULAR® XPS INSULATION PLANT LOCATIONS
FOAMULAR® XPS manufacturing plants provide regionally available material manufactured and sourced within a 500 mile radius of project locations in most areas of the country.
Gresham, OR
Rockford, IL
Valley eld,QC Tallmadge, OH
FOR MORE INFORMATION ON THE OWENS CORNING FAMILY OF BUILDING PRODUCTS, CONTACT YOUR OWENS CORNING DEALER, CALL 1-800-GET-PINK® OR ACCESS OUR WEB SITES: WWW.FOAMULAR.COM AND WWW.OWENSCORNING.COM.
