Hardware. The XC3747 e-ink display module is nice 200x200 display using e-ink technology. The board is controlled via cable connector and using an SPI ...
Extracted Text
!1.54-inch e-ink display XC3747 User Guide Hardware The XC3747 e-ink display module is nice 200x200 display using e-ink technology. The board is controlled via cable connector and using an SPI protocol. Advantages of e-ink over traditional LED, LCD and OLED displays are low power consumption, wide viewing angle, reflective viewing and persistent displays without power, making this suitable for long-lasting, outdoor applications where visibility is the main concern. Note: while this module is compatible with arduino and uno based code, it is recommended to use devices with higher ram, such as the XC3812 SAMD21 board, ESP family of boards, or the raspberry pi. Currently, the arduino does not have enough RAM to draw, so this functionality has been removed from the arduino library. Specifications Outline dimension Display size Dot pitch Resolution Display Color Grey Level Full refresh time Refresh power Standby power Viewing Angle 48mm � 33mm 27.6mm � 27.6mm 0.138 x 0.138 200 x 200 Red, black, white 2 8 seconds 26.4 mW (typical) < 0.017 mW >170� Pinout Connections XC3742 VCC GND DIN CLK CS DC RST BUSY UNO 5V GND D 11 D 13 D 10 D 9 D 8 D 7 RPi 3.3V GND MOSI SCLK CE0 25 (BCM) 17 (BCM) 24 (BCM) Description (!) indicates low. Power Ground Data in ( SPI MOSI ) Clock (SPI CLK) Chip Select ( SPI CS) Data/ (!)Command Control (!) External Reset (!) Busy state output. Remember with the Raspberry Pi, you must use sudo raspi-config to enable the SPI interface. Repository You can download complete example code from the following location, or on our website: https://github.com/waveshare/e-Paper.git Australia www.jaycar.com.au techstore@jaycar.com.au 1800 022 888 New Zealand www.jaycar.co.nz techstore@jaycar.co.nz 0800 452 922 Page 1 of 2 XC3747 User Guide !1.54-inch e-ink display Arduino Code After you have downloaded the code from above, look in the Arduino directory for epd1in54b � this is the code that corresponds to this display. Load the .ino file into your arduino ide and press upload. This code uses binary images in the source code. You can do similar by using software such as gimp to save 200x200 sized images as c-styled headers. Raspberry Pi It is possible that you need to install BCM2835 development libraries, along with some more python libraries, depending on your installation. wget http://www.airspayce.com/mikem/bcm2835/bcm2835-1.60.tar.gz tar zxvf bcm2835-1.60.tar.gz cd bcm2835-1.60/ sudo ./configure sudo make sudo make check sudo make install #For more details, please refer to http://www.airspayce.com/mikem/bcm2835/ For python libraries: sudo apt-get install wiringpi #For Pi 4, you need to update it cd /tmp wget https://project-downloads.drogon.net/wiringpi-latest.deb sudo dpkg -i wiringpi-latest.deb gpio �v #2.52 or higher sudo apt-get update sudo apt-get install python3-pip sudo apt-get install python3-pil sudo apt-get install python3-numpy sudo pip3 install RPi.GPIO sudo pip3 install spidev Then run the C / python code as normal, in the epd1in54b folder. Australia www.jaycar.com.au techstore@jaycar.com.au 1800 022 888 New Zealand www.jaycar.co.nz techstore@jaycar.co.nz 0800 452 922 Page 2 of 2
