Smart Machine Smart Decision SIM7906 SIM7912 Series AT Command Manual V1.01 . 3. 2019-11-21. Contents . Version History
Command Manual V1.01. SIMCom Confidential File. Smart Machine Smart Decision. ... SIM7906 SIM7912 Series AT Command Manual V1.01.
Nov 21, 2019 · All specification supplied herein are subject to change without notice at any time. Copyright © Shanghai SIMCom Wireless Solutions Ltd. 2019.
l File SIM7906_SIM7912
Series_AT
Confidentia Command Manual _V1.01
SIMCom
Smart Machine Smart Decision
Document Title: SIM7906_SIM7912 Series_AT Command Manual
Version: Date:
ile Status:
Document ID:
1.01 2019-11-21 Release SIM7906_SIM7912 Series_AT Command Manual_V1.01
l F General Notes tia SIMCom offers this information as a service to its customers, to support application and engineering efforts
that use the products designed by SIMCom. The information provided is based upon requirements
specifically provided to SIMCom by the customers. SIMCom has not undertaken any independent search
n for additional relevant information, including any information that may be in the customer's possession.
Furthermore, system validation of this product designed by SIMCom within a larger electronic system
e remains the responsibility of the customer or the customer's system integrator. All specifications supplied
herein are subject to change.
fid Copyright
This document contains proprietary technical information which is the property of SIMCom Limited.,
n copying of this document and giving it to others and the using or communication of the contents thereof, o are forbidden without express authority. Offenders are liable to the payment of damages. All rights reserved
in the event of grant of a patent or the registration of a utility model or design. All specification supplied
C herein are subject to change without notice at any time.
SIMCom Copyright © Shanghai SIMCom Wireless Solutions Ltd. 2019
SIM7906_SIM7912 Series_AT Command Manual_V1.01
1
2019-11-21
Smart Machine Smart Decision
Version History
Version V1.00 V1.01 V1.01
Date
Chapter
2019-05-28
ile 2019-06-12
Confidential F 2019-09-16 4.19 AT+SIMEI
What is new New version Add Sim7912 support Modify this command
SIMCom
SIM7906_SIM7912 Series_AT Command Manual_V1.01
2
2019-11-21
Smart Machine Smart Decision
Contents
V e r s i o n H i s t o r y ........................................................................................................................... 2 C o n t e n t s ............................................................................................................................................ 3 1 Introduction...................................................................................................................................... 8
ile 1.1 Scope ...................................................................................................................................................... 8
1.2 References .............................................................................................................................................. 8 1.3 Terms and abbreviations......................................................................................................................... 8
F 1.4 Definitions and conventions ................................................................................................................... 9
2 AT Interface Synopsis .....................................................................................................................11
l 2.1 Interface settings ...................................................................................................................................11
2.2 AT command syntax..............................................................................................................................11
tia 2.3 Information responses .......................................................................................................................... 12
3 AT Commands According V.25TER.............................................................................................. 13
3.1 A/ Repeat last command.................................................................................................................... 13
n 3.2 ATH Disconnect existing call............................................................................................................ 13
3.3 ATI Display product identification information ................................................................................ 14
e 3.4 ATE Enable command echo .............................................................................................................. 15
3.5 AT&V Display current configuration ................................................................................................ 16
fid 3.6 ATV Set result code format mode ..................................................................................................... 16
3.7 AT&F Set all current parameters to manufacturer defaults ............................................................... 17 3.8 ATQ Set Result Code Presentation Mode ......................................................................................... 18
n 3.9 ATX Set CONNECT Result Code Format ........................................................................................ 19
3.10 AT\V Set CONNECT Result Code Format About Protocol .............................................................. 19
o 3.11 AT&E Set CONNECT Result Code Format About Speed ................................................................ 20 C 3.12 AT&W Save the user setting to ME .................................................................................................. 21
3.13 ATZ Restore the user setting from ME.............................................................................................. 22 3.14 AT+CGMI Request manufacturer identification ............................................................................... 22 3.15 AT+CGMM Request model identification ........................................................................................ 23 3.16 AT+CGMR Request revision identification ...................................................................................... 24
m 3.17 AT+CGSN Request product serial number identification ................................................................. 24
3.18 AT+CSCS Select TE character set .................................................................................................... 25
o 3.19 AT+CIMI Request international mobile subscriber identity ............................................................. 26
3.20 AT+CIMIM Request another international mobile subscriber identity ............................................. 27
C 3.21 AT+GCAP Request overall capabilities ............................................................................................ 27
4 AT Commands for Status Control.................................................................................................. 29
4.1 AT+CFUN Set phone functionality ................................................................................................... 29
IM4.2 AT+CPIN Enter PIN.......................................................................................................................... 30 4.3 AT+CICCID Read ICCID from SIM card......................................................................................... 31
S 4.4 AT+CSIM Generic SIM access ......................................................................................................... 32 4.5 AT+CRSM Restricted SIM access .................................................................................................... 33 4.6 AT+SPIC Times remain to input SIM PIN/PUK............................................................................... 37 4.7 AT+CSPN Get service provider name from SIM .............................................................................. 38
SIM7906_SIM7912 Series_AT Command Manual_V1.01
3
2019-11-21
Smart Machine Smart Decision
4.8 AT+CSQ Query signal quality .......................................................................................................... 39 4.9 AT+AUTOCSQ Set CSQ report........................................................................................................ 40 4.10 AT+CSQDELTA Set RSSI delta change threshold............................................................................ 41 4.11 AT+CPOF Power down the module .................................................................................................. 42 4.12 AT+CRESET Reset the module ........................................................................................................ 42
ile 4.13 AT+CACM Accumulated call meter ................................................................................................. 43
4.14 AT+CAMM Accumulated call meter maximum ............................................................................... 44 4.15 AT+CPUC Price per unit and currency table..................................................................................... 45 4.16 AT+CCLK Real time clock management.......................................................................................... 46
F 4.17 AT+CMEE Report mobile equipment error ...................................................................................... 47 l 4.18 AT+CPAS Phone activity status ........................................................................................................ 48
4.19 AT+SIMEI Set IMEI for the module................................................................................................. 49
tia 4.20 AT+CUSBPIDSWITCH Change module's PID................................................................................ 50
5 AT Commands for Network........................................................................................................... 52
5.1 AT+CREG Network registration ....................................................................................................... 52
n 5.2 AT+COPS Operator selection ........................................................................................................... 53
5.3 AT+CLCK Facility lock .................................................................................................................... 55
e 5.4 AT+CPWD Change password ........................................................................................................... 57
5.5 AT+CCUG Closed user group........................................................................................................... 59
fid 5.6 AT+CUSD Unstructured supplementary service data ....................................................................... 60
5.7 AT+CAOC Advice of charge ............................................................................................................ 61 5.8 AT+CSSN Supplementary service notifications................................................................................ 62 5.9 AT+CPOL Preferred operator list...................................................................................................... 64
n 5.10 AT+COPN Read operator names ...................................................................................................... 66 o 5.11 AT+CNMP Preferred mode selection................................................................................................ 67
5.12 AT+CNBP Preferred band selection.................................................................................................. 68
C 5.13 AT+CNAOP Acquisitions order preference ...................................................................................... 71
5.14 AT+CPSI Inquiring UE system information ..................................................................................... 72 5.15 AT+CNSMOD Show network system mode..................................................................................... 74 5.16 AT+CEREG EPS network registration status.................................................................................... 75
m 5.17 AT+CTZU Automatic time and time zone update............................................................................. 77
5.18 AT+CTZR Time and time zone reporting ......................................................................................... 78
o 6 AT Commands for SMS................................................................................................................. 81 6.1 AT+CSMS Select message service.................................................................................................... 81 6.2 AT+CPMS Preferred message storage .............................................................................................. 82 C 6.3 AT+CMGF Select SMS message format........................................................................................... 84 6.4 AT+CSCA SMS service centre address............................................................................................. 85
IM6.5 AT+CSCB Select cell broadcast message indication ........................................................................ 86 6.6 AT+CSMP Set text mode parameters ................................................................................................ 87
S 6.7 AT+CSDH Show text mode parameters............................................................................................ 88 6.8 AT+CNMA New message acknowledgement to ME/TA .................................................................. 89 6.9 AT+CNMI New message indications to TE ...................................................................................... 90 6.10 AT+CGSMS Select service for MO SMS messages ......................................................................... 92
SIM7906_SIM7912 Series_AT Command Manual_V1.01
4
2019-11-21
Smart Machine Smart Decision
6.11 AT+CMGL List SMS messages from preferred storeDescription..................................................... 93 6.12 AT+CMGR Read message ................................................................................................................ 97 6.13 AT+CMGS Send message ............................................................................................................... 101 6.14 AT+CMSS Send message from storage .......................................................................................... 102 6.15 AT+CMGW Write message to memory .......................................................................................... 103
ile 6.16 AT+CMGD Delete message ............................................................................................................ 105
6.17 AT+CMGMT Change message status ............................................................................................. 106 6.18 AT+CMVP Set message valid period .............................................................................................. 106 6.19 AT+CMGRD Read and delete message .......................................................................................... 107
F 6.20 AT+CMGSEX Send message.......................................................................................................... 109 l 6.21 AT+CMSSEX Send multi messages from storage ...........................................................................110
7 AT Commands for Phonebook......................................................................................................112
tia 7.1 AT+CPBS Select phonebook memory storage.................................................................................112
7.2 AT+CPBR Read phonebook entries .................................................................................................113 7.3 AT+CPBF Find phonebook entries ..................................................................................................115
n 7.4 AT+CPBW Write phonebook entry..................................................................................................116
7.5 AT+CNUM Subscriber number........................................................................................................117
e 8 AT Commands for GPRS..............................................................................................................119 8.1 AT+CGREG GPRS network registration status ...............................................................................119 fid 8.2 AT+CGATT Packet domain attach or detach .................................................................................. 120 8.3 AT+CGACT PDP context activate or deactivate............................................................................. 121 8.4 AT+CGDCONT Define PDP context.............................................................................................. 122 8.5 AT+CGDSCONT Define Secondary PDP Context ......................................................................... 124 n 8.6 AT+CGTFT Traffic Flow Template ................................................................................................ 126 o 8.7 AT+CGQREQ Quality of service profile (requested) ..................................................................... 129 8.8 AT+CGEQREQ 3G quality of service profile (requested) .............................................................. 132 C 8.9 AT+CGQMIN Quality of service profile (minimum acceptable).................................................... 137 8.10 AT+CGEQMIN 3G quality of service profile (minimum acceptable) ............................................ 139 8.11 AT+CGDATA Enter data state......................................................................................................... 144 8.12 AT+CGPADDR Show PDP address ................................................................................................ 145 m 8.13 AT+CGCLASS GPRS mobile station class .................................................................................. 147 8.14 AT+CGEREP GPRS event reporting .............................................................................................. 148 o 8.15 AT+CGAUTH Set type of authentication for PDP-IP connections of GPRS.................................. 150
9 AT Commands for SIM Application Toolkit................................................................................ 152
9.1 AT+STIN SAT Indication................................................................................................................ 152
C 9.2 AT+STGI Get SAT information ...................................................................................................... 153
9.3 AT+STGR SAT respond .................................................................................................................. 156
IM9.4 AT+STK STK switch ...................................................................................................................... 157 9.5 AT+STKFMT Set STK pdu format ................................................................................................. 158
S 9.6 AT+STENV Original STK PDU Envelope Command.................................................................... 159 9.7 AT+STSM Get STK Setup Menu List with PDU Mode ................................................................. 160 10 AT Commands for File Transmission ...................................................................................... 161 10.1 AT+CFTRANRX Transfer a file to EFS ......................................................................................... 161
SIM7906_SIM7912 Series_AT Command Manual_V1.01
5
2019-11-21
Smart Machine Smart Decision
10.2 AT+CFTRANTX Transfer a file from EFS to host ......................................................................... 162
11 AT Commands for Open/Close Network ................................................................................. 164
11.1 AT+CNETSTART Open network.................................................................................................... 164 11.2 AT+CNETSTOP Close network...................................................................................................... 165 11.3 AT+CNETIPADDR Inquire PDP address ....................................................................................... 166
ile 11.4 Unsolicited Open/Close network command <err> Codes .................................................................. 166
12 AT Commands for GPS ........................................................................................................... 168
12.1 AT+CGPS Start/Stop GPS session .................................................................................................. 168 12.2 AT+CGPSINFO Get GPS fixed position information..................................................................... 169
F 12.3 AT+CGPSCOLD Cold start GPS .................................................................................................... 171 l 12.4 AT+CGPSHOT Hot start GPS ........................................................................................................ 171
12.5 AT+CGPSURL Set AGPS default server URL ............................................................................... 172
tia 12.6 AT+CGPSSSL Set AGPS transport security ................................................................................... 173
12.7 AT+CGPSAUTO Start GPS automatic ........................................................................................... 173 12.8 AT+CGPSNMEA Configure NMEA sentence type ........................................................................ 174
n 12.9 AT+CGPSNEMARATE Set NMEA output rate ........................................................................... 175
12.10 AT+CGPSMD Configure AGPS MO method ................................................................................. 176
e 12.11 AT+CGPSFTM Start GPS test mode .............................................................................................. 177
12.12 AT+CGPSDEL Delete the GPS information ................................................................................... 178
fid 12.13 AT+CGPSXE Enable/Disable GPS XTRA function ....................................................................... 179
12.14 AT+CGPSXD Download XTRA assistant file ................................................................................ 180 12.15 AT+CGPSXDAUTO Download XTRA assistant file automatically............................................... 181 12.16 AT+CGPSINFOCFG Report GPS NMEA-0183 sentence .............................................................. 181
n 12.17 AT+CGPSPMD Configure positioning mode ................................................................................. 183 o 12.18 AT+CGPSMSB Configure based mode switch to standalone ......................................................... 184
12.19 AT+CGPSHOR Configure positioning desired accuracy................................................................ 185
C 12.20 AT+CGPSNOTIFY LCS respond positioning request .................................................................... 186
12.21 AT+CGNSSINFO Get GNSS fixed position information ............................................................... 187 12.22 AT+CGNSSMODE Configure GNSS support mode ...................................................................... 189 12.23 Unsolicited XTRA download Codes .................................................................................................. 190
m 12.24 AT+CLBS Base station location...................................................................................................... 190
12.25 AT+CLBSCFG Base station location configure.............................................................................. 193
o 12.26 AT+CGTP Get the IZAT location.................................................................................................... 194
13 AT Commands for Call Control ............................................................................................... 198
13.1 AT+CVHU Voice hang up control .................................................................................................. 198
C 13.2 AT+CHUP Hang up call .................................................................................................................. 199
13.3 AT+CBST Select bearer service type .............................................................................................. 199
IM13.4 AT+CRLP Radio link protocol ........................................................................................................ 201 13.5 AT+CR Service reporting control.................................................................................................... 202
S 13.6 AT+CRC Cellular result codes ........................................................................................................ 204 13.7 AT+CLCC List current calls............................................................................................................ 205 13.8 AT+CEER Extended error report .................................................................................................... 207 13.9 AT+CCWA Call waiting.................................................................................................................. 208
SIM7906_SIM7912 Series_AT Command Manual_V1.01
6
2019-11-21
Smart Machine Smart Decision
13.10 AT+CHLD Call related supplementary services ............................................................................. 209 13.11 AT+CCFC Call forwarding number and conditions.........................................................................211 13.12 AT+CLIP Calling line identification presentation ........................................................................... 212 13.13 AT+CLIR Calling line identification restriction.............................................................................. 214 13.14 AT+COLP Connected line identification presentation .................................................................... 215
ile 13.15 AT+VTS DTMF and tone generation.............................................................................................. 217
13.16 AT+VTD Tone duration .................................................................................................................. 218 13.17 AT+CSTA Select type of address .................................................................................................... 219 13.18 AT+CMOD Call mode .................................................................................................................... 220
F 13.19 AT+CSDVC Switch voice channel device ...................................................................................... 221 l 13.20 AT+CLVL Loudspeaker volume level............................................................................................. 222
13.21 AT+SIDET Set sidetone .................................................................................................................. 223
tia 14 AT Command for Hardware..................................................................................................... 224 14.1 AT+CBC Read the voltage value of the power supply.................................................................... 224 14.2 AT+CVALARM Low and high voltage Alarm................................................................................ 224 n 14.3 AT+CPMVT Low and high voltage Power Off............................................................................... 225 14.4 AT+CPMUTEMP Read the temperature of the module .................................................................. 226 e 14.5 AT+CADC0 Read ADC0 value....................................................................................................... 227 14.6 AT+CADC1 Read ADC1 value....................................................................................................... 228 fid 14.7 AT+CADC2 Read ADC2 value....................................................................................................... 229 14.8 AT+CVAUS Set state of the pin named VREG_L14_SDC................................................................ 230 14.9 AT+CVAUV Set microvolt of the pin named VREG_L14_SDC ....................................................... 231
n 15 Appendixes .............................................................................................................................. 232 15.1 Verbose code and numeric code ......................................................................................................... 232 o 15.2 Response string of AT+CEER ............................................................................................................ 232 15.3 Summary of CME ERROR codes ...................................................................................................... 236 C 15.4 Summary of CMS ERROR codes ...................................................................................................... 239
SIMCom
SIM7906_SIM7912 Series_AT Command Manual_V1.01
7
2019-11-21
1 Introduction
ile 1.1 Scope The present document describes the AT Command Set for the SIMCom Module: F SIM7906/SIM7912 series l More information about the SIMCom Module which includes the Software Version information can be retrieved by the command ATI. In this document, a short description, the syntax, the possible setting values tia and responses, and some examples of AT commands are presented. Prior to using the Module, please read this document and the Version History to know the difference from n the previous document. e In order to implement communication successfully between Customer Application and the Module, it is recommended to use the AT commands in this document, but not to use some commands which are not fid included in this document.
1.2 References
on The present document is based on the following standards:
[1] 3GPP TS 27.005: Use of Data Terminal Equipment Data Circuit terminating Equipment (DTE
C DCE) interface for Short Message Service (SMS) and Cell Broadcast Service (CBS).
[2] 3GPP TS 27.007: AT command set for User Equipment (UE). [3] WAP-224-WTP-20010710-a [4] WAP-230-WSP-20010705-a
m [5] WAP-209-MMSEncapsulation-20010601-a
o 1.3 Terms and abbreviations
CFor the purposes of the present document, the following abbreviations apply:
AT
ATtention; the two-character abbreviation is used to start a command line to be sent
IMfrom TE/DTE to TA/DCE
DCE
Data Communication Equipment; Data Circuit terminating Equipment
S DCS
Digital Cellular Network
DTE
Data Terminal Equipment
DTMF
Dual Tone MultiFrequency
EGPRS Enhanced General Packet Radio Service
Smart Machine Smart Decision
GPIO
GeneralPurpose Input/Output
GPRS
General Packet Radio Service
GSM HSDPA HSUPA I2C IMEI IMSI ME MO MS MT PCS PDU PIN PUK SIM SMS SMSSC TA TE UE UMTS USIM WCDMA FTP HTTP
Global System for Mobile communications High Speed Downlink Packet Access High Speed Uplink Packet Access InterIntegrated Circuit International Mobile station Equipment Identity International Mobile Subscriber Identity Mobile Equipment MobileOriginated
l Mobile Station
MobileTerminated; Mobile Termination
tia Personal Communication System
Protocol Data Unit Personal Identification Number
n Personal Unlock Key
Subscriber Identity Module
e Short Message Service
Short Message Service Service Center
fid Terminal Adaptor; e.g. a data card (equal to DCE)
Terminal Equipment; e.g. a computer (equal to DTE) User Equipment Universal Mobile Telecommunications System
n Universal Subscriber Identity Module o Wideband Code Division Multiple Access
File Transfer Protocol
C Hyper Text Transfer Protocol
File
RTC URC
Real Time Clock Unsolicited Result Code
m 1.4 Definitions and conventions
o 1. For the purposes of the present document, the following syntactical definitions apply:
C<CR>
<LF> <...>
SIM[...]
Carriage return character.
Linefeed character.
Name enclosed in angle brackets is a syntactical element. Brackets themselves do not appear in the command line. Optional subparameter of AT command or an optional part of TA information response is enclosed in square brackets. Brackets themselves do not appear in the command line.
If subparameter is not given, its value equals to its previous value or the recommended
default value.
underline Underlined defined subparameter value is the recommended default setting or factory
SIM7906_SIM7912 Series_AT Command Manual_V1.01
9
2019-11-21
Smart Machine Smart Decision
setting.
2. Document conventions:
Display the examples of AT commands with Italic format. Not display blank-line between command line and responses or inside the responses.
ile Generally, the characters <CR> and <LF> are intentionally omitted throughout this document.
If command response is ERROR, not list the ERROR response inside command syntax. NOTE: AT commands and responses in figures may be not following above conventions.
F 3. Special marks for commands or parameters:
l SIM PIN Is the command PIN protected?
tia YES AT command can be used only when SIM PIN is READY.
NO AT command can be used when SIM card is absent or SIM PIN validation is pending.
References Where is the derivation of command?
n 3GPP TS 27.007 3GPP Technical Specification 127 007.
V.25ter
ITUT Recommendation V.25ter.
Confide Vendor
This command is supported by SIMCom.
SIMCom
SIM7906_SIM7912 Series_AT Command Manual_V1.01
10
2019-11-21
Smart Machine Smart Decision
2 AT Interface Synopsis
ile 2.1 Interface settings Between Customer Application and the Module, standardized RS232 interface is used for the F communication, and default values for the interface settings as following: l 115200bps, 8 bit data, no parity, 1 bit stop, no data stream control.
tia 2.2 AT command syntax The prefix "AT" or "at" (no case sensitive) must be included at the beginning of each command line n (except A/ and +++), and the character <CR> is used to finish a command line so as to issue the command line to the Module. It is recommended that a command line only includes a command. e When Customer Application issues a series of AT commands on separate command lines, leave a pause fid between the preceding and the following command until information responses or result codes are retrieved by Customer Application, for example, "OK" is appeared. This advice avoids too many AT commands are issued at a time without waiting for a response for each command.
In the present document, AT commands are divided into three categories: Basic Command, S Parameter
n Command, and Extended Command. Co 1. Basic Command
The format of Basic Command is "AT<x><n>" or "AT&<x><n>", "<x>" is the command name, and "<n>" is/are the parameter(s) for the basic command, and optional. An example of Basic Command is "ATE<n>", which informs the TA/DCE whether received characters should be echoed back to the TE/DTE according to the value of "<n>"; "<n>" is optional and a default value will be used if omitted.
m 2. S Parameter Command o The format of S Parameter Command is "ATS<n>=<m>", "<n>" is the index of the Sregister to set, and
"<m>" is the value to assign to it. "<m>" is optional; in this case, the format is "ATS<n>", and then a
C default value is assigned. IM3. Extended Command S The Extended Command has several formats, as following table list:
Table 2-1: Types of Extended Command
SIM7906_SIM7912 Series_AT Command Manual_V1.01
11
2019-11-21
Smart Machine Smart Decision
Command Type
Syntax
Comments
Test Command
AT+<NAME>=?
Test the existence of the command; give some
Read Command
AT+<NAME>?
Write Command
AT+<NAME>=<...>
ile Execution Command AT+<NAME>
information about the command subparameters. Check the current values of subparameters. Set user-definable subparameter values. Read non-variable subparameters determined by internal processes.
F NOTE: The character "+" between the prefix "AT" and command name may be replaced by other
character. For example, using "#" or "$"instead of "+".
tial 2.3 Information responses
If the commands included in the command line are supported by the Module and the subparameters are
n correct if presented, some information responses will be retrieved by from the Module. Otherwise, the
Module will report "ERROR" or "+CME ERROR" or "+CMS ERROR" to Customer Application.
e Information responses start and end with <CR><LF>, i.e. the format of information responses is
"<CR><LF><response><CR><LF>". Inside information responses, there may be one or more <CR><LF>.
Confid Throughout this document, only the responses are presented, and <CR><LF> are intentionally omitted.
SIMCom
SIM7906_SIM7912 Series_AT Command Manual_V1.01
12
2019-11-21
Smart Machine Smart Decision
3 AT Commands According V.25TER
3.1 A/ Repeat last command
Description
This command is used for implement previous AT command repeatedly (except A/), and the return value depends on the last AT command. If A/ is issued to the Module firstly after power on, the
l response "OK" is only returned. tia SIM PIN References
NO V.25ter
n Syntax e Execution Command fid A/
Responses The response the last AT command return
Examples
n AT+GCAP
+GCAP:+CWCDMA,+FCLASS,+DS
o OK C A/
+GCAP:+CWCDMA,+FCLASS,+DS
OK
m 3.2 ATH Disconnect existing call o Description
This command is used to disconnect existing call. Before using ATH command to hang up a voice
Ccall, it must set AT+CVHU=0. Otherwise, ATH command will be ignored and "OK" response is
given only.
This command is also used to disconnect PS data call, and in this case it doesn't depend on the
IMvalue of AT+CVHU. SIM PIN References
S NO V.25ter
File
Syntax
SIM7906_SIM7912 Series_AT Command Manual_V1.01
13
2019-11-21
Smart Machine Smart Decision
Execution Command ATH
Responses If AT+CVHU=0: VOICE CALL: END: <time> OK
OK
Defined values
<time> Voice call connection time:
l Format HHMMSS (HH: hour, MM: minute, SS: second) tia Examples
AT+CVHU=0 OK
n ATH
VOICE CALL:END:000017
e OK fid 3.3 ATI Display product identification information n Description
This command is used to request the product information, which consists of manufacturer
o identification, model identification, revision identification, International Mobile station Equipment C Identity (IMEI) and overall capabilities of the product.
SIM PIN References NO V.25ter
m Syntax o Execution Command SIMCATI
Responses Manufacturer: <manufacturer> Model: <model> Revision: <revision> IMEI: <sn> +GCAP: list of <name>s
OK
File
Defined values
SIM7906_SIM7912 Series_AT Command Manual_V1.01
14
2019-11-21
Smart Machine Smart Decision
<manufacturer>
The identification of manufacturer.
<model>
The identification of model.
<revision>
The revision identification of firmware.
<sn>
Serial number identification, which consists of a single line containing IMEI (International Mobile
station Equipment Identity) number.
<name>
l List of additional capabilities:
+FCLASS FAX function is supported
tia +DS
Data compression is supported
+ES
Synchronous data mode is supported.
+MS
Mobile Specific command set
n Examples e ATI
Manufacturer: SIMCOM INCORPORATED
fid Model: SIMCOM_SIM7906
Revision: SIM7600C _V3.0
IMEI: 351602000330570
n +GCAP: +CGSM,+FCLASS,+DS
Co OK
3.4 ATE Enable command echo
Description
m This command sets whether or not the TA echoes characters.
SIM PIN References
o NO V.25ter
C Syntax
Execution Command
SIMATE[<value>]
Responses OK ERROR
File
Defined values
SIM7906_SIM7912 Series_AT Command Manual_V1.01
15
2019-11-21
Smart Machine Smart Decision
<value> 0 Echo mode off 1 Echo mode on
Examples
ATE1
OK
3.5 AT&V Display current configuration
l Description tia This command returns some of the base configuration parameters settings.
SIM PIN References YES V.25ter
en Syntax fid Execution Command
AT&V
Responses <TEXT> OK ERROR
on Defined values C <TEXT>
All relative configuration information.
Examples
m AT&V
&C: 0; &D: 2; &F: 0; E: 1; L: 0; M: 0; Q: 0; V: 1; X: 0; Z: 0; S0: 0;
o S3: 13; S4: 10; S5: 8; S6: 2; S7: 50; S8: 2; S9: 6; S10: 14; S11: 95;
+FCLASS: 0; +ICF: 3,3; +IFC: 2,2; +IPR: 115200; +DR: 0; +DS: 0,0,2048,6;
C+WS46: 12; +CBST: 0,0,1;
...... OK
SIM3.6 ATV Set result code format mode
File
Description
This parameter setting determines the contents of the header and trailer transmitted with result
SIM7906_SIM7912 Series_AT Command Manual_V1.01
16
2019-11-21
Smart Machine Smart Decision
codes and information responses. NOTE: In case of using This command without parameter <value> will be set to 0. SIM PIN References
No V.25ter
Syntax
Write Command
l ATV[<value>]
Responses If <value> =0 0 If <value> =1 OK
tia Defined values n <value>
0 Information response: <text><CR><LF>
e Short result code format: <numeric code><CR>
1 Information response: <CR><LF><text><CR><LF>
fid Long result code format: <CR><LF><verbose code><CR><LF>
Examples
n ATV1 Co OK
3.7 AT&F Set all current parameters to manufacturer defaults
Description
m This command is used to set all current parameters to the manufacturer defined profile.
NOTE:List of parameters reset to manufacturer default can be found in defined values, factory
o default settings restorable with AT&F[<value>].
Every ongoing or incoming call will be terminated.
CSIM PIN References NO V.250
IMSyntax S Execution Command
Responses
AT&F[<value>]
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
17
2019-11-21
Smart Machine Smart Decision
Defined values
<value>
0 -- Set some temporary TA parameters to manufacturer defaults. The setting after power on or reset is
same as value 0.
default values
TA parameters
VALUE
AT+CATR
0
AT+CNMP AT+CNAOP
l AT+CTZU tia Examples
AT&F OK
2 7,9,4,2,5,3,11 0
en 3.8 ATQ Set Result Code Presentation Mode
fid Description Specify whether the TA transmits any result code to the TE or not. Text information transmitted in response is not affected by this setting n SIM PIN References YES 3GPP TS 27.005
Co Syntax
Write Command ATQ<n>
om Execution Command CATQ SIMDefined values
Responses If <n>=0: OK
If <n>=1: No Responses
Responses Set default value:0 OK No Responses
<n>
0 DCE transmits result code
1 DCE not transmits result code
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
18
2019-11-21
Smart Machine Smart Decision
Examples
ATQ0 OK
3.9 ATX Set CONNECT Result Code Format
Description
This parameter setting determines whether the TA transmits unsolicited result codes or not. The unsolicited result codes are
l <CONNECT><SPEED><COMMUNICATION PROTOCOL>[<TEXT>]
SIM PIN References
tia YES 3GPP TS 27.005
Syntax
n Write Command e ATX<VALUE> fid Execution Command n ATX
Responses OK ERROR
Responses Set default value:1 OK ERROR
Co Defined values
<value> 0 CONNECT result code returned 1,2,3,4 May be transmits extern result codes according to AT&E and AT\V settings. Refer to
m AT&E. o Examples
ATX1
COK IM3.10 AT\V Set CONNECT Result Code Format About Protocol S Description
This parameter setting determines whether report the communication protocol. If PS call, it also
determines wether report APN, uplink rate, downlink rate.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
19
2019-11-21
Smart Machine Smart Decision
SIM PIN References YES 3GPP TS 27.005
Syntax
Write Command
Responses
AT\V<value>
OK
Execution Command
tial AT\V
ERROR
Responses Set default value: 0 OK ERROR
Defined values
n <value>
0 Don't report
e 1 Report communication protocol. And report APN, uplink rate, downlink rate if PS call. fid Refer to AT&E. The maybe communication protocol report include
"NONE","PPPoverUD","AV32K","AV64K","PACKET". And APN in string format while
uplink rate and downlink rate in integer format with kb unit.
n Examples o AT\V0 C OK
3.11 AT&E Set CONNECT Result Code Format About Speed
m Description This parameter setting determines to report Serial connection rate or Wireless connection speed. It o is valid only ATX above 0. SIM PIN References CYES 3GPP TS 27.005
Syntax
IMWrite Command S AT&E<value>
Responses OK
ERROR
Execution Command
Responses
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
20
2019-11-21
Smart Machine Smart Decision
AT&E
Set default value: 1 OK
Defined values
<value>
0 Wireless connection speed in integer format.
1 Serial connection rate in integer format. Such as: "115200"
Examples
l AT&E0 tia OK
3.12 AT&W Save the user setting to ME
n Description e This command will save the user settings to ME which set by ATE, ATQ, ATV, ATX, AT&C AT&D,
AT&S, AT\V, AT+IFC and ATS0.
fid SIM PIN References YES 3GPP TS 27.005
n Syntax o Write Command C AT&W<value>
Responses OK
Execution Command AT&W
om Defined values C<value>
0 Save
IMExamples S AT&W0
ERROR
Responses Set default value: 0 OK ERROR
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
21
2019-11-21
Smart Machine Smart Decision
3.13 ATZ Restore the user setting from ME
Description
This command will restore the user setting from ME which set by ATE, ATQ, ATV, ATX, AT&C AT&D, AT&S, AT\Q, AT\V, and ATS0.
SIM PIN References
YES 3GPP TS 27.005
Syntax
l Write Command tia ATZ<value>
Execution Command
en ATZ
Responses OK ERROR
Responses Set default value: 0 OK ERROR
fid Defined values <value> n 0 Restore
o Examples C ATZ0
OK
3.14 AT+CGMI Request manufacturer identification
om Description This command is used to request the manufacturer identification text, which is intended to permit Cthe user of the Module to identify the manufacturer. SIM PIN References NO 3GPP TS 27.007
SIMSyntax
Test Command AT+CGMI=?
Responses OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
22
2019-11-21
Smart Machine Smart Decision
Execution Command AT+CGMI
Responses <manufacturer> OK
Defined values
<manufacturer>
The identification of manufacturer.
Examples
l AT+CGMI tia SIMCOM INCORPORATED
OK
n 3.15 AT+CGMM Request model identification
e Description
This command is used to requests model identification text, which is intended to permit the user of
fid the Module to identify the specific model.
SIM PIN References
NO 3GPP TS 27.007
on Syntax C Test Command
Responses
AT+CGMM=? Execution Command
m AT+CGMM
OK Responses <model> OK
o Defined values
<model>
CThe identification of model. IMExamples
AT+CGMM
S SIMCOM_SIM7600C
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
23
2019-11-21
Smart Machine Smart Decision
3.16 AT+CGMR Request revision identification
Description
This command is used to request product firmware revision identification text, which is intended to
permit the user of the Module to identify the version.
SIM PIN References
NO 3GPP TS 27.007
Syntax
l Test Command tia AT+CGMR=?
Execution Command
n AT+CGMR
Responses OK Responses +CGMR: <revision> OK
e Defined values fid <revision>
The revision identification of firmware.
n Examples o AT+CGMR
+CGMR: LE11B01SIM7906
C OK
3.17 AT+CGSN Request product serial number identification
m Description o This command requests product serial number identification text, which is intended to permit the
user of the Module to identify the individual ME to which it is connected to.
CSIM PIN References NO 3GPP TS 27.007
IMSyntax S Test Command
Responses
AT+CGSN=?
OK
Execution Command
Responses
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
24
2019-11-21
Smart Machine Smart Decision
AT+CGSN
<sn> OK
Defined values
<sn> Serial number identification, which consists of a single line containing the IMEI (International Mobile station Equipment Identity) number of the MT.
Examples
l AT+CGSN tia 351602000330570
OK
n 3.18 AT+CSCS Select TE character set e Description fid Write command informs TA which character set <chest> is used by the TE. TA is then able to
convert character strings correctly between TE and MT character sets. Read command shows current setting and test command displays conversion schemes implemented
n in the TA. o SIM PIN References C YES 3GPP TS 27.007
Syntax
Test Command
m AT+CSCS=? o Read Command
AT+CSCS?
CWrite Command
AT+CSCS=<chset>
IMExecution Command S AT+CSCS
Responses +CSCS: (list of supported <chset>s) OK Responses +CSCS: <chset> OK Responses OK
ERROR Responses Set subparameters as default value:
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
25
2019-11-21
Smart Machine Smart Decision
Defined values
<chest> Character set, the definition as following:
"IRA" International reference alphabet. "UCS2" 16-bit universal multiple-octet coded character set; UCS2 character strings are
converted to hexadecimal numbers from 0000 to FFFF.
Examples
AT+CSCS="IRA"
l OK
AT+CSCS?
tia +CSCS: "IRA"
OK
n 3.19 AT+CIMI Request international mobile subscriber identity e Description fid Execution command causes the TA to return <IMSI>, which is intended to permit the TE to identify
the individual SIM card which is attached to MT. NOTE: If USIM card contains two apps, like China Telecom 4G card, one RUIM/CSIM app, and another USIM app; so there are two IMSI in it; AT+CIMI will return the RUIM/CSIM IMSI;
n AT+CIMIM will return the USIM IMSI; o SIM PIN References C YES 3GPP TS 27.007
Syntax
Test Command
m AT+CIMI=? o Execution Command
AT+CIMI
IMC Defined values S <IMSI>
Responses OK ERROR Responses <IMSI> OK ERROR
International Mobile Subscriber Identity (string, without double quotes).
File
Examples
SIM7906_SIM7912 Series_AT Command Manual_V1.01
26
2019-11-21
Smart Machine Smart Decision
AT+CIMI
460010222028133
OK
3.20 AT+CIMIM Request another international mobile subscriber identity
ile Description
Execution command causes the TA to return <IMSI>, which is intended to permit the TE to identify
F the individual SIM card which is attached to MT. l NOTE: If USIM card contains two apps, like China Telecom 4G card, one RUIM/CSIM app, and
another USIM app; so there are two IMSI in it; AT+CIMIM will return the USIM IMSI; AT+CIMI
tia will return the RUIM/CSIM IMSI;
SIM PIN References
YES 3GPP TS 27.007
n Syntax e Test Command fid AT+CIMIM=?
Execution Command
Con AT+CIMIM
Responses OK ERROR Responses <IMSI> OK ERROR
Defined values
<IMSI> International Mobile Subscriber Identity (string, without double quotes).
om Examples AT+CIMIM C460110222028133 OK
IM3.21 AT+GCAP Request overall capabilities S Description
Execution command causes the TA reports a list of additional capabilities.
SIM7906_SIM7912 Series_AT Command Manual_V1.01
27
2019-11-21
Smart Machine Smart Decision
SIM PIN References YES V.25ter
Syntax
Test Command
Responses
AT+GCAP=?
OK
Execution Command
tial AT+GCAP
ERROR
Responses +GCAP: (list of <name>s) OK
ERROR
Defined values
n <name>
e List of additional capabilities.
+CGSM GSM function is supported
fid +FCLASS FAX function is supported
+DS
Data compression is supported
+ES
Synchronous data mode is supported.
+MS
Mobile Specific command set
on Examples C AT+GCAP
+GCAP:+CGSM,+FCLASS,+DS
SIMOK Com
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
28
2019-11-21
Smart Machine Smart Decision
4 AT Commands for Status Control
4.1 AT+CFUN Set phone functionality
Description
This command is used to select the level of functionality <fun> in the ME. Level "full functionality" is where the highest level of power is drawn. "Minimum functionality" is where
l minimum power is drawn. Level of functionality between these may also be specified by tia manufacturers. When supported by manufacturers, ME resetting with <rst> parameter may be
utilized. NOTE: AT+CFUN=6 must be used after setting AT+CFUN=7. If module in offline mode, must execute AT+CFUN=6 or restart module to online mode.
n SIM PIN References e NO 3GPP TS 27.007
fid Syntax Test Command Con AT+CFUN=?
Responses +CFUN: (list of supported <fun>s), (list of supported <rst>s) OK ERROR +CME ERROR: <err>
Read Command
Responses
AT+CFUN?
om Write Command CAT+CFUN=<fun>[,<rst>]
+CFUN: <fun> OK ERROR +CME ERROR: <err>
Responses OK ERROR +CME ERROR: <err>
IMDefined values S <fun>
0 minimum functionality
1 full functionality, online mode
4 disable phone both transmit and receive RF circuits
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
29
2019-11-21
Smart Machine Smart Decision
5 Factory Test Mode
6 Reset
7 Offline Mode
<rst>
0 do not reset the ME before setting it to <fun> power level
1 reset the ME before setting it to <fun> power level. This value only takes effect when
<fun> equals 1.
Examples
AT+CFUN?
l +CFUN: 1 tia OK
AT+CFUN=0 OK
n 4.2 AT+CPIN Enter PIN e Description fid This command is used to send the ME a password which is necessary before it can be operated
(SIM PIN, SIM PUK, PH-SIM PIN, etc.). If the PIN is to be entered twice, the TA shall automatically repeat the PIN. If no PIN request is pending, no action is taken towards MT and an
n error message, +CME ERROR, is returned to TE.
If the PIN required is SIM PUK or SIM PUK2, the second pin is required. This second pin,
o <newpin>, is used to replace the old pin in the SIM. C SIM PIN References
NO 3GPP TS 27.007
Syntax
m Test Command o AT+CPIN=?
Responses OK
Read Command
IMCAT+CPIN?
Responses +CPIN: <code> OK ERROR +CME ERROR: <err>
Write Command
Responses
S AT+CPIN=<pin>[,<newpin> OK
]
ERROR
+CME ERROR: <err>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
30
2019-11-21
Smart Machine Smart Decision
Defined values
<pin>
String type values.
<newpin>
String type values.
<code>
Values reserved by the present document:
READY
ME is not pending for any password
SIM PIN
ME is waiting SIM PIN to be given
SIM PUK ME is waiting SIM PUK to be given
l PH-SIM PIN ME is waiting phone-to-SIM card password to be given
tia SIM PIN2 ME is waiting SIM PIN2 to be given
SIM PUK2 ME is waiting SIM PUK2 to be given
PH-NET PIN ME is waiting network personalization password to be given
n Examples e AT+CPIN?
+CPIN: SIM PUK2
fid OK
4.3 AT+CICCID Read ICCID from SIM card
n Description o This command is used to Read the ICCID from SIM card C SIM PIN References
NO Vendor
m Syntax
Test Command
o AT+CICCID=?
Execution Command
SIMCAT+CICCID
Responses OK
Responses +ICCID: <ICCID> OK ERROR +CME ERROR: <err>
Defined values
File
<ICCID>
SIM7906_SIM7912 Series_AT Command Manual_V1.01
31
2019-11-21
Smart Machine Smart Decision
Integrate circuit card identity, a standard ICCID is a 20-digit serial number of the SIM card, it presents the publish state, network code, publish area, publish date, publish manufacture and press serial number of the SIM card.
Examples
AT+CICCID
+ICCID: 898600700907A6019125
OK
l 4.4 AT+CSIM Generic SIM access
tia Description This command is used to control the SIM card directly. Compared to restricted SIM access command AT+CRSM, AT+CSIM allows the ME to take more n control over the SIM interface. For SIMME interface please refer 3GPP TS 11.11. e NOTEThe SIM Application Toolkit functionality is not supported by AT+CSIM. Therefore the following SIM commands can not be used: TERMINAL PROFILE, ENVELOPE, fid FETCH and TEMINAL RESPONSE. SIM PIN References NO 3GPP TS 27.007
on Syntax C Test Command
Responses
AT+CSIM=?
Write Command AT+CSIM=<length>,<com
om mand>
OK
Responses +CSIM: <length>, <response> OK ERROR +CME ERROR: <err>
C Defined values
<length>
IMInterger type; length of characters that are sent to TE in <command> or <response> <command>
S Command passed from MT to SIM card.
<response>
Response to the command passed from SIM card to MT.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
32
2019-11-21
Smart Machine Smart Decision
Examples
AT+CSIM=? OK
4.5 AT+CRSM Restricted SIM access
Description
By using AT+CRSM instead of Generic SIM Access AT+CSIM, TE application has easier but more limited access to the SIM database.
l Write command transmits to the MT the SIM <command> and its required parameters. MT handles
internally all SIM-MT interface locking and file selection routines. As response to the command,
tia MT sends the actual SIM information parameters and response data. MT error result code +CME
ERROR may be returned when the command cannot be passed to the SIM, but failure in the execution of the command in the SIM is reported in <sw1> and <sw2> parameters.
n SIM PIN References e NO 3GPP TS 27.007
fid Syntax
Test Command AT+CRSM=?
Responses OK
n Write Command o AT+CRSM=<command>[,<f
ileID>[,<p1>,<p2>, <p3>
C [,<data>]]]
Responses +CRSM: <sw1>,<sw2>[,<response>] OK ERROR
+CME ERROR: <err>
m Defined values <command> o Command passed on by the MT to the SIM: 176 READ BINARY C178 READ RECORD 192 GET RESPONSE 214 UPDATE BINARY
IM220 UPDATE RECORD 242 STATUS
S 203 RETRIEVE DATA 219 SET DATA
<fileID>
Identifier for an elementary data file on SIM, if used by <command>.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
33
2019-11-21
Smart Machine Smart Decision
The following list the fileID hex value, user needs to convet them to decimal.
EFs under MF
0x2FE2
ICCID
0x2F05
Extended Language Preferences
0x2F00
EF DIR
0x2F06
Access Rule Reference
EFs under USIM ADF
0x6F05 0x6F07 0x6F08 0x6F09 0x6F60 0x6F30 0x6F31 0x6F37 0x6F38 0x6F39 0x6F3E 0x6F3F 0x6F46 0x6F41 0x6F45 0x6F78 0x6F7B 0x6F7E 0x6FAD 0x6F48
Language Indication IMSI Ciphering and Integrity keys
l C and I keys for pkt switched domain
User controlled PLMN selector w/Acc Tech
tia User controlled PLMN selector
HPLMN search period ACM maximum value
n USIM Service table
Accumulated Call meter
e Group Identifier Level
Group Identifier Level 2
fid Service Provider Name
Price Per Unit and Currency table Cell Bcast Msg identifier selection Access control class
n Forbidden PLMNs o Location information
Administrative data
C Cell Bcast msg id for data download
0x6FB7 0x6F50 0x6F73
m 0x6F3B
0x6F3C
o 0x6F40
0x6F42
C0x6F43
0x6F49 0x6F4B
IM0x6F4C 0x6F47 0x6F80
S 0x6F81
Emergency call codes Cell bcast msg id range selection Packet switched location information Fixed dialling numbers Short messages MSISDN SMS parameters SMS Status Service dialling numbers Extension 2 Extension 3 SMS reports Incoming call information Outgoing call information
0x6F82
Incoming call timer
0x6F83
Outgoing call timer
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
34
2019-11-21
Smart Machine Smart Decision
0x6F4E
Extension 5
0x6F4F
Capability Config Parameters 2
0x6FB5
Enh Multi Level Precedence and Pri
0x6FB6
Automatic answer for eMLPP service
0x6FC2
Group identity
0x6FC3
Key for hidden phonebook entries
0x6F4D
Barred dialling numbers
0x6F55 0x6F58 0x6F56 0x6F57 0x6F2C 0x6F32 0x6F5B 0x6F5C 0x6F61 0x6F5D 0x6F62 0x6F06 0x6F65 0x6FC4 0x6F11 0x6F12, 0x6F13 0x6F14 0x6F15 0x6F16
Extension 4 Comparison Method information Enabled services table
l Access Point Name Control List
De-personalization Control Keys
tia Co-operative network list
Hyperframe number Maximum value of Hyperframe number
n OPLMN selector with access tech
OPLMN selector
e HPLMN selector with access technology
Access Rule reference
fid RPLMN last used access tech
Network Parameters CPHS: Voice Mail Waiting Indicator CPHS: Service String Table
n CPHS: Call Forwarding Flag o CPHS: Operator Name String
CPHS: Customer Service Profile
C CPHS: CPHS Information
0x6F17 0x6FC5 0x6FC6
m 0x6F9F
0x6F92
o 0x6F98
0x6F9B
C0x4F30
0x4F22 0x4F23
IM0x4F24 0x4F52 0x4F63
S 0x4F64
CPHS: Mailbox Number PLMN Network Name Operator PLMN List Dynamic Flags Status Dynamic2 Flag Setting Customer Service Profile Line2 EF PARAMS - Welcome Message Phone book reference file Phone book synchronization center Change counter Previous Unique Identifier GPRS ciphering key CPBCCH information Investigation scan
0x4F40
MExE Service table
0x4F41
Operator Root Public Key
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
35
2019-11-21
Smart Machine Smart Decision
0x4F42
Administrator Root Public Key
0x4F43
Third party Root public key
0x6FC7
Mail Box Dialing Number
0x6FC8
Extension 6
0x6FC9
Mailbox Identifier
0x6FCA
Message Waiting Indication Status
0x6FCD
Service Provider Display Information
0x6FD2
UIM_USIM_SPT_TABLE
0x6FD9
Equivalent HPLMN
0x6FCB
Call Forwarding Indicator Status
l 0x6FD6
GBA Bootstrapping parameters
0x6FDA
GBA NAF List
tia 0x6FD7
MBMS Service Key
0x6FD8
MBMS User Key
0x6FCE
MMS Notification
n 0x6FD0
MMS Issuer connectivity parameters
0x6FD1
MMS User Preferences
e 0x6FD2
MMS User connectivity parameters
0x6FCF
Extension 8
fid 0x5031
Object Directory File
0x5032
Token Information File
0x5033
Unused space Information File
EFs under Telecom DF
n 0x6F3A
Abbreviated Dialing Numbers
o 0x6F3B
Fixed dialling numbers
0x6F3C
Short messages
C 0x6F3D
Capability Configuration Parameters
0x6F4F 0x6F40 0x6F42
m 0x6F43
0x6F44
o 0x6F49
0x6F4A
C0x6F4B
0x6F4C 0x6F4D
IM0x6F4E 0x6F47 0x6F58
S 0x6F54
Extended CCP MSISDN SMS parameters SMS Status Last number dialled Service Dialling numbers Extension 1 Extension 2 Extension 3 Barred Dialing Numbers Extension 4 SMS reports Comparison Method Information Setup Menu elements
0x6F06
Access Rule reference
0x4F20
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
36
2019-11-21
Smart Machine Smart Decision
0x4F30
Phone book reference file
0x4F22
Phone book synchronization center
0x4F23
Change counter
0x4F24
Previous Unique Identifier
<p1> <p2> <p3>
Integer type; parameters to be passed on by the Module to the SIM.
<data>
Information which shall be written to the SIM (hexadecimal character format, refer AT+CSCS). <sw1> <sw2> Status information from the SIM about the execution of the actual command. It is returned in both
l cases, on successful or failed execution of the command.
<response>
tia Response data in case of a successful completion of the previously issued command.
"STATUS" and "GET RESPONSE" commands return data, which gives information about the currently selected elementary data field. This information includes the type of file and its size.
n After "READ BINARY" or "READ RECORD" commands the requested data will be returned.
<response> is empty after "UPDATE BINARY" or "UPDATE RECORD" commands.
e Examples fid AT+CRSM=?
OK
n 4.6 AT+SPIC Times remain to input SIM PIN/PUK o Description C This command is used to inquire times remain to input SIM PIN/PUK.
SIM PIN References NO Vendor
m Syntax o Test Command
AT+SPIC=?
CExecution Command
AT+SPIC
SIMDefined values
Responses OK
Responses +SPIC: <pin1>,<puk1>,<pin2>,<puk2> OK
File
<pin1> Times remain to input PIN1 code.
SIM7906_SIM7912 Series_AT Command Manual_V1.01
37
2019-11-21
Smart Machine Smart Decision
<puk1> Times remain to input PUK1 code. <pin2> Times remain to input PIN2 code. <puk2> Times remain to input PUK2 code.
Examples
AT+SPIC=? OK
l AT+SPIC tia +SPIC: 3,10,0,10
OK
n 4.7 AT+CSPN Get service provider name from SIM
e Description fid This command is used to get service provider name from SIM card.
SIM PIN References YES Vendor
n Syntax o Test Command C AT+CSPN=?
Responses OK
Read Command
Com AT+CSPN?
ERROR Responses +CSPN: <spn>,<display mode> OK OK ERROR +CME ERROR: <err>
IMDefined values <spn>
S String type; service provider name on SIM
<display mode>
0 doesn't display PLMN. Already registered on PLMN.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
38
2019-11-21
Smart Machine Smart Decision
1 display PLMN
Examples
AT+CSPN=?
OK
AT+CSPN?
+CSPN: "CMCC",0
OK
l 4.8 AT+CSQ Query signal quality
tia Description This command is used to return received signal strength indication <rssi> and channel bit error rate <ber> from the ME. Test command returns values supported by the TA as compound values. n SIM PIN References e NO 3GPP TS 27.007
fid Syntax Test Command AT+CSQ=? on Execution Command C AT+CSQ
Responses +CSQ: (list of supported <rssi>s),(list of supported <ber>s) OK
Responses +CSQ: <rssi>,<ber> OK
ERROR
Defined values
m <rssi>
o 0
1
C2...30
31
99
IM100
101
S 102...191
-113 dBm or less -111 dBm -109... -53 dBm -51 dBm or greater not known or not detectable -116 dBm or less -115 dBm -114... -26dBm
191 -25 dBm or greater
199
not known or not detectable
<ber>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
39
2019-11-21
Smart Machine Smart Decision
(in percent)
0 <0.01%
1 0.01% --- 0.1%
2 0.1% --- 0.5%
3 0.5% --- 1.0%
4 1.0% --- 2.0%
5 2.0% --- 4.0%
6 4.0% --- 8.0% 7 >=8.0% 99 not known or not detectable
l Examples tia AT+CSQ
+CSQ: 22,0 OK
en 4.9 AT+AUTOCSQ Set CSQ report fid Description
This command is used to enable or disable automatic report CSQ information, when automatic report enabled, the module reports CSQ information every five seconds or only after <rssi> or
n <ber> is changed, the format of automatic report is "+CSQ: <rssi>,<ber>".
SIM PIN References
Co NO Vendor
Syntax
Test Command AT+AUTOCSQ=?
om Read Command CAT+AUTOCSQ?
Write Command
IMAT+AUTOCSQ=<auto>[,< S mode>]
Responses +AUTOCSQ: (list of supported<auto>s),(list of supported<mod e>s) OK
Responses +AUTOCSQ: <auto>,<mode> OK
Responses OK ERROR
Defined values
File
<auto>
SIM7906_SIM7912 Series_AT Command Manual_V1.01
40
2019-11-21
Smart Machine Smart Decision
0 disable automatic report 1 enable automatic report <mode> 0 CSQ automatic report every five seconds 1 CSQ automatic report only after <rssi> or <ber> is changed NOTE: If the parameter of <mode> is omitted when executing write command, <mode> will be set to default value.
Examples
AT+AUTOCSQ=?
l +AUTOCSQ: (0-1),(0-1) tia OK
AT+AUTOCSQ? +AUTOCSQ: 1,1 OK
n AT+AUTOCSQ=1,1
OK
e +CSQ: 23,0 (when <rssi> or <ber> changing) fid 4.10 AT+CSQDELTA Set RSSI delta change threshold n Description
This command is used to set RSSI delta threshold for signal strength reporting.
o SIM PIN References C NO Vendor
File
Syntax
Test Command
m AT+CSQDELTA=? o Read Command CAT+CSQDELTA? IMWrite Command S AT+CSQDELTA=<delta>
Responses +CSQDELTA: (list of supported <delta>s) OK
Responses +CSQDELTA: <delta> OK ERROR
Responses OK ERROR
Execution Command
Responses
SIM7906_SIM7912 Series_AT Command Manual_V1.01
41
2019-11-21
Smart Machine Smart Decision
AT+CSQDELTA
Set default value<delta>=5: OK
Defined values
<delta> Range: from 0 to 5.
Examples
AT+CSQDELTA?
l +CSQDELTA: 5
OK
tia 4.11 AT+CPOF Power down the module
n Description e This command is used to power off the module. Once the AT+CPOF command is executed, The
module will store user data and deactivate from network, and then shutdown.
fid SIM PIN References NO Vendor
n Syntax o Test Command C AT+CPOF=?
Responses OK
Execution Command
Responses
AT+CPOF
OK
m Examples
AT+CPOF
o OK
C 4.12 AT+CRESET Reset the module
IMDescription S This command is used to reset the module.
SIM PIN References
NO Vendor
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
42
2019-11-21
Smart Machine Smart Decision
Syntax
Test Command AT+CRESET=?
Execution Command AT+CRESET
Responses OK
Responses OK
Examples
AT+CRESET=?
l OK
AT+CRESET
tia OK
4.13 AT+CACM Accumulated call meter
n Description e This command is used to reset the Advice of Charge related accumulated call meter value in SIM fid file EFACM.
SIM PIN References YES 3GPP TS 27.007
n Syntax o Test Command C AT+CACM=?
Responses OK
Read Command AT+CACM?
Com Write Command
AT+CACM=<passwd>
IMExecution Command S AT+CACM
ERROR
Responses +CACM: <acm> OK ERROR +CME ERROR: <err>
Responses OK ERROR +CME ERROR: <err>
Responses OK
ERROR
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
43
2019-11-21
Smart Machine Smart Decision
+CME ERROR: <err>
Defined values
<passwd>
String type, SIM PIN2.
<acm>
String type, accumulated call meter value similarly coded as <ccm> under +CAOC.
Examples
l AT+CACM?
+CACM: "000000"
tia OK
4.14 AT+CAMM Accumulated call meter maximum
en Description This command is used to set the Advice of Charge related accumulated call meter maximum value fid in SIM file EFACMmax. SIM PIN References YES 3GPP TS 27.007
on Syntax C Test Command
Responses
AT+CAMM=?
Read Command
m AT+CAMM? Co Write Command
AT+CAMM=
IM<acmmax>[,<passwd>] S Execution Command
OK ERROR
Responses +CAMM: <acmmax> OK ERROR +CME ERROR: <err>
Responses OK ERROR +CME ERROR: <err> Responses
AT+CAMM
OK
ERROR
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
44
2019-11-21
Smart Machine Smart Decision
+CME ERROR: <err>
Defined values
<acmmax>
String type, accumulated call meter maximum value similarly coded as <ccm> under AT+CAOC,
value zero disables ACMmax feature.
<passwd> String type, SIM PIN2.
l Examples
AT+CAMM?
tia +CAMM: "000000"
OK
n 4.15 AT+CPUC Price per unit and currency table e Description fid This command is used to set the parameters of Advice of Charge related price per unit and currency
table in SIM file EFPUCT..
SIM PIN References
n YES 3GPP TS 27.007 Co Syntax
Test Command AT+CPUC=?
m Read Command
AT+CPUC?
Co Write Command IMAT+CPUC=<currency>,<pp S u>[,<passwd>]
Responses OK ERROR
Responses +CPUC: [<currency>,<ppu>] OK ERROR +CME ERROR: <err>
Responses OK ERROR +CME ERROR: <err>
File
Defined values
SIM7906_SIM7912 Series_AT Command Manual_V1.01
45
2019-11-21
Smart Machine Smart Decision
<currency>
String type, three-character currency code (e.g. "GBP", "DEM"), character set as specified by
command Select TE Character Set AT+CSCS.
<ppu>
String type, price per unit, dot is used as a decimal separator. (e.g. "2.66").
<passwd>
String type, SIM PIN2.
Examples
AT+CPUC?
l +CPUC: "GBP" , "2.66" tia OK
4.16 AT+CCLK Real time clock management
n Description e This command is used to manage Real Time Clock of the module. fid SIM PIN References
NO 3GPP TS 27.007
n Syntax o Test Command
AT+CCLK=?
C Read Command
Responses OK
Responses
AT+CCLK? Write Command
om AT+CCLK=<time>
+CCLK: <time> OK
Responses OK ERROR
C Defined values <time> String type value; format is "yy/MM/dd,hh:mm:ss±zz", where characters indicate year (two last
IMdigits), month, day, hour, minutes, seconds and time zone (indicates the difference, expressed in quarters of an hour, between the local time and GMT; three last digits are mandatory, range
S -47...+48). E.g. 6th of May 2008, 14:28:10 GMT+8 equals to "08/05/06,14:28:10+32".
NOTE: 1. Time zone is nonvolatile, and the factory value is invalid time zone.
2. Command +CCLK? will return time zone when time zone is valid, and if time zone is
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
46
2019-11-21
Smart Machine Smart Decision
00, command +CCLK? will return "+00", but not "-00".
Examples
AT+CCLK="08/11/28,12:30:33+32"
OK
AT+CCLK?
+CCLK: "08/11/28,12:30:35+32" OK AT+CCLK="08/11/26,10:15:00" OK
l AT+CCLK? tia +CCLK: "08/11/26,10:15:02+32"
OK
n 4.17 AT+CMEE Report mobile equipment error e Description fid This command is used to disable or enable the use of result code "+CME ERROR: <err>" or
"+CMS ERROR: <err>" as an indication of an error relating to the functionality of ME; when enabled, the format of <err> can be set to numeric or verbose string. SIM PIN References
n NO 3GPP TS 27.007 Co Syntax
Test Command AT+CMEE=?
m Read Command
AT+CMEE?
o Write Command CAT+CMEE=<n> IMExecution Command S AT+CMEE
Responses +CMEE: (list of supported <n>s) OK
Responses +CMEE: <n> OK
Responses OK ERROR Responses Set default value: OK
File
Defined values
SIM7906_SIM7912 Series_AT Command Manual_V1.01
47
2019-11-21
Smart Machine Smart Decision
<n> 0 Disable result code,i.e. only "ERROR" will be displayed. 1 Enable error result code with numeric values. 2 Enable error result code with string values.
Examples
AT+CMEE? +CMEE: 2 OK AT+CPIN="1234","1234"
l +CME ERROR: incorrect password tia AT+CMEE=0
OK AT+CPIN="1234","1234" ERROR
n AT+CMEE=1
OK
e AT+CPIN="1234","1234"
+CME ERROR: 16
fid 4.18 AT+CPAS Phone activity status n Description o This command is used to return the activity status <pas> of the ME. It can be used to interrogate the
ME before requesting action from the phone.
C NOTE: This command is same as AT+CLCC, but AT+CLCC is more commonly used. So
AT+CLCC is recommended to use. SIM PIN References
NO 3GPP TS 27.007
om Syntax
Test Command
CAT+CPAS=? IMExecution Command S AT+CPAS
Responses +CPAS: (list of supported <pas>s) OK
Responses +CPAS: <pas> OK
File
Defined values
SIM7906_SIM7912 Series_AT Command Manual_V1.01
48
2019-11-21
Smart Machine Smart Decision
<pas> 0 ready (ME allows commands from TA/TE) 3 ringing (ME is ready for commands from TA/TE, but the ringer is active) 4 call in progress (ME is ready for commands from TA/TE, but a call is in progress)
Examples
RING (with incoming call)
AT+CPAS +CPAS: 3 OK
l AT+CPAS=? tia +CPAS: (0,3,4)
OK
n 4.19 AT+SIMEI Set IMEI for the module e Description
This command is used to set the module's IMEI value.
fid SIM PIN References
NO Vendor
on Syntax C Test Command
Responses
AT+SIMEI=?
Read Command AT+SIMEI?
om Write Command CAT+SIMEI=<imei>
OK
Responses +SIMEI: <imei> OK ERROR
Responses OK ERROR
IMDefined values <imei>
S The 15-digit IMEI value.
File
Examples
SIM7906_SIM7912 Series_AT Command Manual_V1.01
49
2019-11-21
Smart Machine Smart Decision
AT+SIMEI=357396012183170
OK
AT+SIMEI?
+SIMEI: 357396012183170
OK
AT+SIMEI=?
OK
4.20 AT+CUSBPIDSWITCH Change module's PID
l Description tia Execution command change the module's PID. This command will reset the module if change to
other PID (not current used PID). SIM PIN References
n NO Vendor
e Syntax
fid Test Command Con AT+CUSBPIDSWITCH=?
Responses +CUSBPIDSWITCH: (9000,9001,9002,9003,9004,9005,9006,9007,9011,9016,9018,9019 ,901A,901B,9020,9021,9022,9023,9024,9025,9026,9027,9028,902 9,902A),(0-1),(0-1) OK
ERROR
Read Command
Responses
AT+CUSBPIDSWITCH?
+CUSBPIDSWITCH: <pid>
OK
mERROR
Write Command
o AT+CUSBPIDSWITCH=<p
id>, < reserve1>,< reserve2>
Responses OK ERROR
C Defined values IM<pid>
This command support pids, 9001 is the default value.
S 9000,9001,9002,9003,9004,9005,9006,9007,9011,9016,9018,9019,901A,901B,9020,9021,9022,90
23,9024,9025,9026,9027,9028,9029,902A
< reserve1>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
50
2019-11-21
Smart Machine Smart Decision
0 or 1, this value is for the reserve < reserve2> 0 or 1, this value is for the reserve
Examples
AT+CUSBPIDSWITCH? +CUSBPIDSWITCH: 9001 OK AT+CUSBPIDSWITCH=9001,1,1 OK
tial PID configuration:
9000:Diag, NMEA, At, Modem, Audio, Rmnet 9001:Diag, NMEA, At, Modem, Audio, Rmnet 9002:Diag, NMEA, At, Modem, Audio, Rmnet
n 9003:Diag, NMEA, At, Modem, Audio, MBIM
9004:Diag, NMEA, At, Modem, Audio, GNSS, Rmnet
e 9005:Diag, NMEA, At, Modem, Audio, GNSS, MBIM
9006:Diag, NMEA, At,Modem
fid 9007:Diag, NMEA, At, Modem, Audio, Rmnet,mass_storage
9011:RNDIS,Diag, NMEA, At, Modem, Audio 9016:Diag, Rmnet
n 9018:Diag, NMEA, At, Modem, Audio, Ecm
9019:RNDIS
o 901A: Diag, NMEA, At, Rmnet C 901B:NMEA, At, Rmnet
9020: Diag, At, Modem 9021: Diag, Modem 9022: Diag, Modem, Rmnet 9023: Modem
m 9024: At, Modem
9025: Modem,rmnet
o 9026: Modem,Audio
9027: Modem,Audio, Rmnet
C 9028:Diag, Modem,Audio, Rmnet
9029:Diag, Modem,Audio
SIM902A: At
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
51
2019-11-21
Smart Machine Smart Decision
5 AT Commands for Network
5.1 AT+CREG Network registration
Description
This command is used to control the presentation of an unsolicited result code +CREG: <stat> when <n>=1 and there is a change in the ME network registration status, or code +CREG:
l <stat>[,<lac>,<ci>] when <n>=2 and there is a change of the network cell. tia Read command returns the status of result code presentation and an integer <stat> which shows
whether the network has currently indicated the registration of the ME. Location information elements <lac> and <ci> are returned only when <n>=2 and ME is registered in the network. SIM PIN References
n NO 3GPP TS 27.007
e Syntax fid Test Command
AT+CREG=?
n Read Command Co AT+CREG?
Responses +CREG: (list of supported <n>s) OK
Responses +CREG: <n>,<stat>[,<lac>,<ci>] OK ERROR
Write Command
m AT+CREG=<n> o Execution Command CAT+CREG IMDefined values S <n>
+CME ERROR: <err>
Responses OK ERROR +CME ERROR: <err>
Responses Set default value<n>=0: OK
0 disable network registration unsolicited result code
1 enable network registration unsolicited result code +CREG: <stat>
2 enable network registration and location information unsolicited result code +CREG:
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
52
2019-11-21
Smart Machine Smart Decision
<stat>[,<lac>,<ci>] <stat>
0 not registered, ME is not currently searching a new operator to register to 1 registered, home network 2 not registered, but ME is currently searching a new operator to register to 3 registration denied 4 unknown 5 registered, roaming 6 Internal use only <lac>
l Two byte location area code in hexadecimal format (e.g."00C3" equals 193 in decimal). tia NOTE: The <lac> not supported in CDMA/HDR mode
<ci> Cell Identify in hexadecimal format.
n GSM : Maximum is two byte
WCDMA : Maximum is four byte
e TDS-CDMA : Maximum is four byte fid NOTE: The <ci> not supported in CDMA/HDR mode
Examples
n AT+CREG?
+CREG: 0,1
Co OK
5.2 AT+COPS Operator selection
SIMCom Description
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
53
2019-11-21
Smart Machine Smart Decision
Write command forces an attempt to select and register the UMTS network operator. <mode> is
used to select whether the selection is done automatically by the ME or is forced by this command
to operator <oper> (it shall be given in format <format>). If the selected operator is not available,
no other operator shall be selected (except <mode>=4). The selected operator name format shall
apply to further read commands (AT+COPS?) also. <mode>=2 forces an attempt to deregister from
the network. The selected mode affects to all further network registration (e.g. after <mode>=2, ME
shall be unregistered until <mode>=0 or 1 is selected).
Read command returns the current mode and the currently selected operator. If no operator is selected, <format> and <oper> are omitted. Test command returns a list of quadruplets, each representing an operator present in the network.
l Quadruplet consists of an integer indicating the availability of the operator <stat>, long and short
alphanumeric format of the name of the operator, and numeric format representation of the operator.
tia Any of the formats may be unavailable and should then be an empty field. The list of operators shall
be in order: home network, networks referenced in SIM, and other networks. It is recommended (although optional) that after the operator list TA returns lists of supported
n <mode>s and <format>s. These lists shall be delimited from the operator list by two commas.
When executing AT+COPS=? , any input from serial port will stop this command.
e SIM PIN References YES 3GPP TS 27.007
fid Syntax n Test Command Co AT+COPS=?
Responses [+COPS: [list of supported (<stat>,long alphanumeric <oper> ,short alphanumeric <oper>,numeric <oper>[,< AcT>])s] [,,(list of supported <mode>s),(list of supported <format>s)]]
OK
m Read Command
AT+COPS?
Co Write Command IMAT+COPS=<mode>[,<form S at>[,<oper>[,< AcT>]]]
ERROR +CME ERROR: <err>
Responses +COPS: <mode>[,<format>,<oper>[,< AcT>]] OK ERROR +CME ERROR: <err>
Responses OK ERROR +CME ERROR: <err>
Execution Command
Responses
AT+COPS
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
54
2019-11-21
Smart Machine Smart Decision
Defined values
<mode> 0 automatic 1 manual 2 force deregister 3 set only <format> 4 manual/automatic 5 manual,but do not modify the network selection mode(e.g WCDMA) after module resets.
l NOTE: if <mode> is set to 1, 4, 5 in write command, the <oper> is needed. tia <format>
0 long format alphanumeric <oper> 1 short format alphanumeric <oper> 2 numeric <oper>
n <oper> string type, <format> indicates if the format is alphanumeric or numeric.
e <stat>
0 unknown
fid 1 available
2 current 3 forbidden
n <AcT>
Access technology selected
o 2 UTRAN C 7 EUTRAN
File
Examples
m AT+COPS?
+COPS: 0,0,"China Mobile Com",0
o OK
AT+COPS=?
C+COPS: (2,"China Unicom","Unicom","46001",0),(3,"China Mobile Com","DGTMPT",
"46000",0),,(0,1,2,3,4,5),(0,1,2) OK
SIM5.3 AT+CLCK Facility lock Description
SIM7906_SIM7912 Series_AT Command Manual_V1.01
55
2019-11-21
Smart Machine Smart Decision
This command is used to lock, unlock or interrogate a ME or a network facility <fac>. Password is normally needed to do such actions. When querying the status of a network service (<mode>=2) the response line for 'not active' case (<status>=0) should be returned only if service is not active for any <class>.
SIM PIN References YES 3GPP TS 27.007
Syntax
Test Command AT+CLCK=?
Write Command AT+CLCK=<fac>,<mode> [,<passwd>[,<class>]]
Defined values
Responses
l +CLCK: (list of supported <fac>s) tia OK
ERROR
+CME ERROR: <err>
n Responses
OK
e When <mode>=2 and command successful:
+CLCK:<status>[,<class1>[<CR><LF>
fid +CLCK: <status>,<class2>
[...]] OK
n ERROR Co +CME ERROR: <err>
<fac> "PF"
m "SC"
"AO"
o "OI"
"OX" "AI"
C"IR"
"AB"
IM"AG" "AC" "FD"
S "PN"
lock Phone to the very First inserted SIM card or USIM card lock SIM card or USIM card Barr All Outgoing Calls Barr Outgoing International Calls Barr Outgoing International Calls except to Home Country Barr All Incoming Calls Barr Incoming Calls when roaming outside the home country All Barring services (only for <mode>=0) All outGoing barring services (only for <mode>=0) All inComing barring services (only for <mode>=0) SIM fixed dialing memory feature Network Personalization
"PU" network subset Personalization
"PP" service Provider Personalization
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
56
2019-11-21
Smart Machine Smart Decision
"PC" Corporate Personalization <mode>
0 unlock 1 lock 2 query status <status> 0 not active 1 active <passwd> Password.
l string type; shall be the same as password specified for the facility from the ME user interface or
with command Change Password +CPWD
tia <classX>
It is a sum of integers each representing a class of information (default 7): 1 voice (telephony)
n 2 data (refers to all bearer services)
4 fax (facsimile services)
e 8 short message service
16 data circuit sync
fid 32 data circuit async
64 dedicated packet access 128 dedicated PAD access 255 The value 255 covers all classes
on Examples C AT+CLCK="SC",2
+CLCK: 0 OK
m 5.4 AT+CPWD Change password o Description
Write command sets a new password for the facility lock function defined by command Facility
CLock AT+CLCK.
Test command returns a list of pairs which present the available facilities and the maximum length of their password.
IMSIM PIN References S YES 3GPP TS 27.007
File
Syntax
SIM7906_SIM7912 Series_AT Command Manual_V1.01
57
2019-11-21
Smart Machine Smart Decision
Test Command AT+CPWD=?
Responses +CPWD: (list of supported (<fac>,<pwdlength>)s) OK ERROR
+CME ERROR: <err>
Write Command
Responses
AT+CPWD= <fac>,<oldpwd>,<newpwd>
OK ERROR +CME ERROR: <err>
tial Defined values <fac> Refer Facility Lock +CLCK for other values: n "SC" SIM or USIM PIN1 "P2" SIM or USIM PIN2 e "AB" All Barring services "AC" All inComing barring services (only for <mode>=0) fid "AG" All outGoing barring services (only for <mode>=0) "AI" Barr All Incoming Calls "AO" Barr All Outgoing Calls n "IR" Barr Incoming Calls when roaming outside the home country "OI" Barr Outgoing International Calls o "OX" Barr Outgoing International Calls except to Home Country <oldpwd> C String type, it shall be the same as password specified for the facility from the ME user interface or
with command Change Password AT+CPWD. <newpwd> String type, it is the new password; maximum length of password can be determined with
m <pwdlength>.
<pwdlength>
o Integer type, max length of password. C Examples
AT+CPWD=? +CPWD: ("AB",4),("AC",4),("AG",4),("AI",4),("AO",4),("IR",4),("OI",4),("OX",4),(
IM"SC",8),("P2",8) S OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
58
2019-11-21
Smart Machine Smart Decision
5.5 AT+CCUG Closed user group
Description
This command allows control of the Closed User Group supplementary service. Set command enables the served subscriber to select a CUG index, to suppress the Outgoing Access (OA), and to suppress the preferential CUG.
SIM PIN References YES 3GPP TS 27.007
l Syntax tia Test Command
AT+CCUG=?
n Read Command e AT+CCUG? fid Write Command n AT+CCUG=
<n>[,<index>[,<info>]]
Co Execution Command
Responses OK ERROR
Responses +CCUG: <n>,<index>,<info> OK ERROR +CME ERROR: <err>
Responses OK ERROR +CME ERROR: <err>
Responses
AT+CCUG
Set default value: OK
m Defined values o <n>
0 disable CUG temporary mode
C1 enable CUG temporary mode
<index> 0...9 CUG index
IM10 no index (preferred CUG taken from subscriber data) <info>
S 0 no information
1 suppress OA
2 suppress preferential CUG
3 suppress OA and preferential CUG
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
59
2019-11-21
Smart Machine Smart Decision
Examples
AT+CCUG? +CCUG: 0,0,0 OK
5.6 AT+CUSD Unstructured supplementary service data
Description
This command allows control of the Unstructured Supplementary Service Data (USSD). Both
l network and mobile initiated operations are supported. Parameter <n> is used to disable/enable the
presentation of an unsolicited result code (USSD response from the network, or network initiated
tia operation) +CUSD: <m>[,<str>,<dcs>] to the TE. In addition, value <n>=2 is used to cancel an
ongoing USSD session.
SIM PIN References
n YES 3GPP TS 27.007
e Syntax fid Test Command
AT+CUSD=?
n Read Command Co AT+CUSD?
Responses +CUSD: (list of supported <n>s) OK
Responses +CUSD: <n> OK
Write Command
Responses
AT+CUSD= <n>[,<str>[,<dcs>]]
m Execution Command o AT+CUSD
OK ERROR +CME ERROR: <err>
Responses Set default value (<n>=0): OK
C Defined values IM<n>
0 disable the result code presentation in the TA 1 enable the result code presentation in the TA
S 2 cancel session (not applicable to read command response)
<str>
String type USSD-string.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
60
2019-11-21
Smart Machine Smart Decision
<dcs>
Cell Broadcast Data Coding Scheme in integer format (default 0).
<m>
0 no further user action required (network initiated USSD-Notify, or no further
information needed after mobile initiated operation)
1 further user action required (network initiated USSD-Request, or further information
needed after mobile initiated operation)
2 USSD terminated by network 4 operation not supported 5 network time out
l Examples tia AT+CUSD?
+CUSD: 1 OK
n AT+CUSD=0
OK
fide 5.7 AT+CAOC Advice of charge Description n This command refers to Advice of Charge supplementary service that enables subscriber to get information about the cost of calls. With <mode>=0, the execute command returns the current call o meter value from the ME. This command also includes the possibility to enable an unsolicited event reporting of the CCM C information. The unsolicited result code +CCCM: <ccm> is sent when the CCM value changes, but
not more that every 10 seconds. Deactivation of the unsolicited event reporting is made with the same command.
SIM PIN References
m YES 3GPP TS 27.007
o Syntax CTest Command
AT+CAOC=?
SIMRead Command
Responses +CAOC: (list of supported <mode>s) OK ERROR
Responses
AT+CAOC?
+CAOC: <mode>
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
61
2019-11-21
Smart Machine Smart Decision
ERROR
+CME ERROR: <err>
Write Command AT+CAOC=<mode>
Responses +CAOC: <ccm>
OK
OK
l Execution Command tia AT+CAOC
ERROR +CME ERROR: <err>
Responses Set default value (<mode>=1): OK ERROR
n Defined values <mode> e 0 query CCM value 1 deactivate the unsolicited reporting of CCM value fid 2 activate the unsolicited reporting of CCM value <ccm>
String type, three bytes of the current call meter value in hexadecimal format (e.g. "00001E"
n indicates decimal value 30), value is in home units and bytes are similarly coded as ACMmax value
in the SIM.
Co Examples
AT+CAOC=0 +CAOC: "000000" OK
m 5.8 AT+CSSN Supplementary service notifications SIMCo Description
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
62
2019-11-21
Smart Machine Smart Decision
This command refers to supplementary service related network initiated notifications. The set
command enables/disables the presentation of notification result codes from TA to TE.
When <n>=1 and a supplementary service notification is received after a mobile originated call
setup, intermediate result code +CSSI: <code1>[,<index>] is sent to TE before any other MO call
setup result codes presented in the present document. When several different <code1>s are received
from the network, each of them shall have its own +CSSI result code.
When <m>=1 and a supplementary service notification is received during a mobile terminated call
setup or during a call, or when a forward check supplementary service notification is received, unsolicited result code +CSSU: <code2>[,<index>[,<number>,<type>[,<subaddr>,<satype>]]] is sent to TE. In case of MT call setup, result code is sent after every +CLIP result code (refer
l command "Calling line identification presentation +CLIP") and when several different <code2>s
are received from the network, each of them shall have its own +CSSU result code.
tia SIM PIN References YES 3GPP TS 27.007
n Syntax e Test Command
AT+CSSN=?
nfid Read Command Co AT+CSSN?
Responses +CSSN: (list of supported <n>s),(list of supported <m>s) OK ERROR
Responses +CSSN: <n>,<m> OK ERROR
Write Command
Responses
m AT+CSSN=<n>[,<m>]
OK ERROR +CME ERROR: <err>
o Defined values
<n>
CParameter sets/shows the +CSSI result code presentation status in the TA:
0 disable
IM1 enable <m> Parameter sets/shows the +CSSU result code presentation status in the TA:
S 0 disable
1 enable
<code1>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
63
2019-11-21
Smart Machine Smart Decision
0 unconditional call forwarding is active
1 some of the conditional call forwarding are active
2 call has been forwarded
3 call is waiting
5 outgoing calls are barred
<index>
Refer "Closed user group +CCUG".
<code2> 0 this is a forwarded call (MT call setup) 2 call has been put on hold (during a voice call)
l 3 call has been retrieved (during a voice call)
5 call on hold has been released (this is not a SS notification) (during a voice call)
tia <number>
String type phone number of format specified by <type>. <type>
n Type of address octet in integer format; default 145 when dialing string includes international
access code character "+", otherwise 129.
e <subaddr>
String type sub address of format specified by <satype>.
fid <satype>
Type of sub address octet in integer format, default 128.
n Examples AT+CSSN=1,1 o OK C AT+CSSN? +CSSN: 1,1
OK
m 5.9 AT+CPOL Preferred operator list o Description
This command is used to edit the SIM preferred list of networks.
CSIM PIN References
YES 3GPP TS 27.007
SIMSyntax
Test Command
Responses
AT+CPOL=?
+CPOL: (list of supported <index>s), (list of supported <format>s)
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
64
2019-11-21
Smart Machine Smart Decision
ERROR
Read Command
Responses
AT+CPOL?
[+CPOL:<index1>,<format>,<oper1>[<GSM_AcT1>,<GSM_Com
pact_AcT1>,<UTRAN_AcT1>,<LTE_AcT1>][<CR><LF>
+CPOL:
<index2>,<format>,<oper2>[,<GSM_AcT1>,<GSM_Compact_Ac
T1>,<UTRAN_AcT1>,<LTE_AcT1>]
[...]]] OK
l ERROR
Write Command
tia AT+CPOL=<index>
[,<format>[,<oper>][,<GSM _AcT1>,<GSM_Compact_A
n cT1>,<UTRAN_AcT1>,<LT
E_AcT1> ]]
e NOTE: If using USIM card,
the last four parameters must
fid set.
Responses OK ERROR +CME ERROR: <err>
Defined values
n <index> o Integer type, the order number of operator in the SIM preferred operator list.
If only input <index>, command will delete the value indicate by <index>.
C <format>
0 long format alphanumeric <oper> 1 short format alphanumeric <oper> 2 numeric <oper>
m <operX>
String type.
o <GSM_AcTn> GSM access technology: 0 access technology not selected C1 access technology selected <GSM_Compact_AcTn>
IMGSM compact access technology: 0 access technology not selected 1 access technology selected
S <UTRA_AcTn>
UTRA access technology:
0 access technology not selected
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
65
2019-11-21
Smart Machine Smart Decision
1 access technology selected <LTE_AcTn>
LTE access technology: 0 access technology not selected 1 access technology selected
Examples
AT+CPOL? +CPOL: 1,2,"46001",0,0,1,0 OK
l AT+CPOL=? tia +CPOL: (1-8),(0-2)
OK
n 5.10 AT+COPN Read operator names
e Description This command is used to return the list of operator names from the ME. Each operator code fid <numericX> that has an alphanumeric equivalent <alphaX> in the ME memory shall be returned. SIM PIN References YES 3GPP TS 27.007
on Syntax C Test Command
Responses
AT+COPN=? Write Command
m AT+COPN IMCo Defined values S <numericX>
OK ERROR
Responses +COPN:<numeric1>,<alpha1>[<CR><LF> +COPN: <numeric2>,<alpha2> [...]] OK ERROR +CME ERROR: <err>
String type, operator in numeric format (see AT+COPS).
<alphaX>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
66
2019-11-21
Smart Machine Smart Decision
String type, operator in long alphanumeric format (see AT+COPS).
Examples
AT+COPN
+COPN: "46000","China Mobile Com"
+COPN: "46001"," China Unicom"
......
OK
l 5.11 AT+CNMP Preferred mode selection
tia Description This command is used to select or set the state of the mode preference. NOTE: The set value in Write Command will take efficient immediately; The set value will retain n after module reset; NOTE: The response will be returned immediately for Test Command and Read Command; The e maximum response time for Write Command is 10 seconds. SIM PIN References fid NO Vendor
Syntax
n Test Command Co AT+CNMP=?
Responses +CNMP: (list of supported <mode>s) OK
Read Command AT+CNMP?
m Write Command
AT+CNMP=<mode>
IMCo Defined values <mode>
S 2 Automatic
Responses +CNMP: <mode> OK Responses OK If <mode> not supported by module, this command will return ERROR. ERROR
14 WCDMA Only
38 LTE Only
54 WCDMA+LTE Only
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
67
2019-11-21
Smart Machine Smart Decision
Examples
AT+CNMP=2 OK AT+CNMP? +CNMP: 2 OK
5.12 AT+CNBP Preferred band selection
l Description
This command is used to select or set the state of the band preference.
tia SIM PIN References NO Vendor
n Syntax
e Test Command fid AT+CNBP?
Write Command
n AT+CNBP=<mode>[,<lte_
mode>][,<tds_mode>]
Responses +CNBP: <mode>[,<lte_mode>][,<tds_mode>] OK Responses OK ERROR
Co Defined values
<mode>
64bit number, the value is "1" << "<pos>", then or by bit.
Some special mode value declared below:
m 0x40000000
BAND_PREF_NO_CHANGE
<pos>
o Value:
0xFFFFFFFF7FFFFFFF Any (any value)
C7
GSM_DCS_1800
8
GSM_EGSM_900
9
GSM_PGSM_900
IM16
GSM_450
17
GSM_480
S 18
GSM_750
19
GSM_850
20
GSM_RGSM_900
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
68
2019-11-21
Smart Machine Smart Decision
21
GSM_PCS_1900
22
WCDMA_IMT_2000
23
WCDMA_PCS_1900
24
WCDMA_III_1700
25
WCDMA_IV_1700
26
WCDMA_850
27
WCDMA_800
48
WCDMA_VII_2600
49
WCDMA_VIII_900
50
WCDMA_IX_1700
l <lte_mode>
64/256 bit number, the value is "1" << "<lte_pos>", then or by bit.
tia NOTE: FDD(band1 ~ band32, band66, band252 and band255), TDD(band33 ~ band42)
<lte_pos>
Value:
n 0x480000000000000000000000000000000000000000000002000007FF3FDF3FFF
Any (any value)
e 0
EUTRAN_BAND1(UL:1920-1980; DL:2110-2170)
1
EUTRAN_BAND2(UL:1850-1910; DL:1930-1990)
fid 2
EUTRAN_BAND3(UL:1710-1785; DL:1805-1880)
3
EUTRAN_BAND4(UL:1710-1755; DL:2110-2155)
4
EUTRAN_BAND5(UL: 824-849; DL: 869-894)
5
EUTRAN_BAND6(UL: 830-840; DL: 875-885)
n 6
EUTRAN_BAND7(UL:2500-2570; DL:2620-2690)
o 7
EUTRAN_BAND8(UL: 880-915; DL: 925-960)
8
EUTRAN_BAND9(UL:1749.9-1784.9; DL:1844.9-1879.9)
C 9
EUTRAN_BAND10(UL:1710-1770; DL:2110-2170)
10
EUTRAN_BAND11(UL:1427.9-1452.9; DL:1475.9-1500.9)
11
EUTRAN_BAND12(UL:698-716; DL:728-746)
12
EUTRAN_BAND13(UL: 777-787; DL: 746-756)
m 13
EUTRAN_BAND14(UL: 788-798; DL: 758-768)
16
EUTRAN_BAND17(UL: 704-716; DL: 734-746)
o 17
EUTRAN_BAND18(UL: 815-830; DL: 860-875)
18
EUTRAN_BAND19(UL: 830-845; DL: 875-890)
C19
EUTRAN_BAND20(UL: 832-862; DL: 791-821)
20
EUTRAN_BAND21(UL: 1447.9-1462.9; DL: 1495.9-1510.9)
22
EUTRAN_BAND23(UL: 2000-2020; DL: 2180-2200)
IM23
EUTRAN_BAND24(UL: 1626.5-1660.5; DL: 1525 -1559)
24
EUTRAN_BAND25(UL: 1850-1915; DL: 1930 -1995)
25
EUTRAN_BAND26(UL: 814-849; DL: 859 -894)
S 26
EUTRAN_BAND27(UL: 807.5-824; DL: 852 -869)
27
EUTRAN_BAND28(703-748; DL: 758-803)
28
EUTRAN_BAND29(UL:1850-1910 or 1710-1755;
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
69
2019-11-21
Smart Machine Smart Decision
DL:716-728)
29
EUTRAN_BAND30(UL: 2305-2315 ; DL: 2350 - 2360)
32
EUTRAN_BAND33(UL: 1900-1920; DL: 1900-1920)
33
EUTRAN_BAND34(UL: 2010-2025; DL: 2010-2025)
34
EUTRAN_BAND35(UL: 1850-1910; DL: 1850-1910)
35
EUTRAN_BAND36(UL: 1930-1990; DL: 1930-1990)
36
EUTRAN_BAND37(UL: 1910-1930; DL: 1910-1930)
37
EUTRAN_BAND38(UL: 2570-2620; DL: 2570-2620)
38
EUTRAN_BAND39(UL: 1880-1920; DL: 1880-1920)
39
EUTRAN_BAND40(UL: 2300-2400; DL: 2300-2400)
l 40
EUTRAN_BAND41(UL: 2496-2690; DL: 2496-2690)
41
EUTRAN_BAND42(UL: 3400-3600; DL: 3400-3600)
tia 42
EUTRAN_BAND43(UL: 3600-3800; DL: 3600-3800)
65
EUTRAN_BAND66(UL: 1710-1780; DL: 2110-2200)
251
EUTRAN_BAND252(DL: 5150-5250)
n 254
EUTRAN_BAND255(DL: 5725-5850)
<tds_mode>
e 64bit number, the value is "1" << "<tds_pos>", then or by bit.
<tds_pos>
fid Value:
0x000000000000003F
Any (any value)
0
TDS Band A (1900-1920 MHz, 2010-2020 MHz)
1
TDS Band B (1850-1910 MHz, 1930-1990 MHz)
n 2
TDS Band C (1910-1930 MHz)
o 3
TDS Band D (2570-2620 MHz)
4
TDS Band E (2300-2400 MHz)
C 5
TDS Band F (1880-1920 MHz)
Examples
AT+CNBP=,0x0000000000000095
m OK
AT+CNBP?
o +CNBP:
0x0x0000000000400000,0x000000000000000000000000000000000000000000000000000000000
C0000095,0x000000000000003F
AT+CNBP=,0x4800000000000000000000000000000000000000000000020000000000000095 OK
IMAT+CNBP? +CNBP:
S 0x0x0000000000400000,0x480000000000000000000000000000000000000000000002000000000 0000095,0x000000000000003F
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
70
2019-11-21
Smart Machine Smart Decision
5.13 AT+CNAOP Acquisitions order preference
Description
This command is used to reset the state of acquisitions order preference.
SIM PIN References
NO Vendor
Syntax
l Read Command tia AT+CNAOP?
Responses +CNAOP: <mode>[,<sys_mode1>,[<sys_mode2>[,<sys_mode3>[, <sys_mode4>[,<sys_mode5>[,<sys_mode6>]]]]]] OK
n Write Command
AT+CNAOP=<mode>[,<sys
e _mode1>[,<sys_mode2>[,<sy
s_mode3>[,<sys_mode4>[,<s
fid ys_mode5>[,<sys_mode6>]]]
]]]
Responses OK ERROR
n Defined values o <mode>
7 Acquistion by priority order list <sys_moden>s.
C <sys_moden>
sys_mode values: 2 CDMA 3 GSM
m 4 HDR
5 WCDMA
o 9 LTE
11 TDSCDMA
C Examples
AT+CNAOP=7,9,5,3,11,2,4
IMOK AT+CNAOP?
S +CNAOP: 7,9,5,3,11,2,4
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
71
2019-11-21
Smart Machine Smart Decision
5.14 AT+CPSI Inquiring UE system information
Description
This command is used to return the UE system information.
SIM PIN References
NO Vendor
Syntax
Test Command AT+CPSI=? Read Command
tial Responses
+CPSI: (scope of <time>) OK
n Responses e If camping on a wcdma cell:
+CPSI: <System Mode>,<Operation Mode>,<MCC>-<MNC>,<
fid LAC>,<Cell ID>,<Frequency Band>,<PSC>,<Freq>,<SSC>,<EC
/IO>,<RSCP>,<Qual>,<RxLev>,<TXPWR> OK
n If camping on a lte cell:
+CPSI: <System Mode>,<Operation Mode>[,<MCC>-<MNC>,<
o TAC>,<SCellID>,<PCellID>,<Frequency Band>,<earfcn>,<dlb Cw>,<ulbw>,<RSRQ>,<RSRP>,<RSSI>,<RSSNR>]
OK
Com Write Command
AT+CPSI=<time>
SIMDefined values
If no service: +CPSI: NO SERVICE, Online OK If power-off mode: +CPSI: NO SERVICE, Powering off OK
ERROR Responses OK ERROR
File
<time> The range is 0-255, unit is second, after set <time> will report the system information every the
SIM7906_SIM7912 Series_AT Command Manual_V1.01
72
2019-11-21
Smart Machine Smart Decision
seconds. <System Mode> System mode, values: "NO SERVICE", "WCDMA", "LTE" If module in LIMITED SERVICE state and +CNLSA command is set to 1, the system mode will display as "LTE-LIMITED", "WCDMA-LIMITED"... <Operation Mode> UE operation mode, values: "Unknown", "Online", "Offline", "Factory Test Mode", "Reset", "Low Power Mode". <MCC> Mobile Country Code (first part of the PLMN code)
l <MNC>
Mobile Network Code (second part of the PLMN code)
tia <LAC>
Location Area Code (hexadecimal digits) <Cell ID>
n Service-cell Identify.
<Absolute RF Ch Num>
e AFRCN for service-cell.
<Track LO Adjust>
fid Track LO Adjust
<C1> Coefficient for base station selection <C2>
n Coefficient for Cell re-selection o <Frequency Band>
Frequency Band of active set
C <PSC>
Primary synchronization code of active set. <Freq> Downlink frequency of active set.
m <SSC>
Secondary synchronization code of active set
o <EC/IO>
Ec/Io value
C<RSCP>
Received Signal Code Power <Qual>
IMQuality value for base station selection <RxLev> RX level value for base station selection
S <TXPWR> UE TX power in dBm. If no TX, the value is 500. <Cpid>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
73
2019-11-21
Smart Machine Smart Decision
Cell Parameter ID <TAC> Tracing Area Code <PCellID> Physical Cell ID <earfcn> E-UTRA absolute radio frequency channel number for searching LTE cells <dlbw> Transmission bandwidth configuration of the serving cell on the downlink <ulbw>
l Transmission bandwidth configuration of the serving cell on the uplink
<RSRP>
tia Current reference signal received power in -1/10 dBm. Available for LTE
<RSRQ> Current reference signal receive quality as measured by L1.
n <RSSNR>
Average reference signal signal-to-noise ratio of the serving cell
e <BID>
Base ID
fid Examples AT+CPSI? n +CPSI: WCDMA,Online,460-01,0xA809,11122855,WCDMA IMT 2000,279,10663,0,1.5,62,33, 52,500 o OK C AT+CPSI=? +CPSI: (0-255) OK
m 5.15 AT+CNSMOD Show network system mode o Description
This command is used to return the current network system mode.
IMCSIM PIN References S NO Vendor
Syntax
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
74
2019-11-21
Smart Machine Smart Decision
Test Command AT+CNSMOD=?
Responses +CNSMOD: (list of supported <n>s) OK
Read Command AT+CNSMOD?
Responses +CNSMOD: <n>,<stat> OK
Write Command
tial AT+CNSMOD=<n>
ERROR +CME ERROR: <err>
Responses OK ERROR +CME ERROR: <err>
n Defined values <n> e 0 disable auto report the network system mode information 1 auto report the network system mode information, command: +CNSMOD:<stat> fid <stat> 0 no service
4 WCDMA
n 5 HSDPA only(WCDMA)
6 HSUPA only(WCDMA)
o 7 HSPA (HSDPA and HSUPA, WCDMA) C 8 LTE
Examples
AT+CNSMOD?
m +CNSMOD: 0,8
OK
o 5.16 AT+CEREG EPS network registration status C Description IMThe set command controls the presentation of an unsolicited result code +CEREG: <stat> when
<n>=1 and there is a change in the MT's EPS network registration status in E-UTRAN, or unsolicited result code +CEREG: <stat>[,<tac>,<ci>[,<AcT>]] when <n>=2 and there is a change
S of the network cell in E-UTRAN; in this latest case <AcT>, <tac> and <ci> are sent only if available. NOTE 1: If the EPS MT in GERAN/UTRAN/E-UTRAN also supports circuit mode services and/or
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
75
2019-11-21
Smart Machine Smart Decision
GPRS services, the +CREG command and +CREG: result codes and/or the +CGREG command
and +CGREG: result codes apply to the registration status and location information for those
services.
The read command returns the status of result code presentation and an integer <stat> which shows
whether the network has currently indicated the registration of the MT. Location information
elements <tac>, <ci> and <AcT>, if available, are returned only when <n>=2 and MT is registered
in the network.
SIM PIN References NO 3GPP TS 24.008 [8]
l Syntax tia Test Command
AT+CEREG=?
n Read Command e AT+CEREG? fid Write Command n AT+CEREG=[<n>] Co Execution Command
Responses +CEREG: (list of supported <n>s) OK ERROR
Responses +CEREG: <n>,<stat>[,<tac>,<ci>[,<AcT>]] OK ERROR
Responses OK ERROR +CME ERROR: <err>
Responses
AT+CEREG
Set default value<n>=0:
OK ERROR
m Defined values o <n>
0 disable network registration unsolicited result code
C1 enable network registration unsolicited result code +CEREG: <stat>
2 enable network registration and location information unsolicited result code +CEREG: <stat>[,<tac>,<ci>[,<AcT>]]
IM<stat> 0 not registered, MT is not currently searching an operator to register to
S 1 registered, home network
2 not registered, but MT is currently trying to attach or searching an operator to register to
3 registration denied
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
76
2019-11-21
Smart Machine Smart Decision
4 unknown (e.g. out of E-UTRAN coverage)
5 registered, roaming
6 registered for "SMS only", home network (not applicable)
7 registered for "SMS only", roaming (not applicable)
8 attached for emergency bearer services only (See NOTE 2)
<tac>
string type; two byte tracking area code in hexadecimal format (e.g. "00C3" equals 195 in decimal)
<ci> string type; four byte E-UTRAN cell identify in hexadecimal format
<AcT>
l A numberic parameter that indicates the access technology of serving cell tia 2 UTRAN (not applicable)
4 UTRAN w/HSDPA (see NOTE 4) (not applicable) 5 UTRAN w/HSUPA (see NOTE 4) (not applicable) 6 UTRAN w/HSDPA and HSUPA (see NOTE 4) (not applicable)
n 7 E-UTRAN e Examples fid AT+CEREG?
+CEREG: 0,4 OK
n 5.17 AT+CTZU Automatic time and time zone update Co Description
This command is used to enable and disable automatic time and time zone update via NITZ
SIM PIN References
m YES 3GPP TS 27.007
o Syntax CTest Command
AT+CTZU=?
IMRead Command S AT+CTZU?
Responses +CTZU: (list of supported <on/off>s) OK
Responses +CTZU: < on/off >
OK
Write Command
Responses
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
77
2019-11-21
Smart Machine Smart Decision
AT+CTZU=< on/off >
OK ERROR
Defined values
<on/off> Integer type value indicating:
0 Disable automatic time zone update via NITZ (default). 1 Enable automatic time zone update via NITZ. NOTE: 1. The value of < on/off > is nonvolatile, and factory value is 0.
l 2. For automatic time and time zone update is enabled (+CTZU=1): If time zone is only received from network and it isn't equal to local time zone tia (AT+CCLK), time zone is updated automatically, and real time clock is updated based on local time and the difference between time zone from network and local time zone (Local time zone must be valid). If Universal Time and time zone are received from network, both time zone and real n time clock is updated automatically, and real time clock is based on Universal Time and e time zone from network.
fid Examples AT+CTZU? +CTZU: 0 n OK AT+CTZU=1 Co OK
5.18 AT+CTZR Time and time zone reporting
m Description o This command is used to enable and disable the time zone change event reporting. If the reporting
is enabled the MT returns the unsolicited result code +CTZV: <tz>[,<time>][,<dst>]whenever the time zone is changed.
CNOTE: The time zone reporting is not affected by the Automatic Time and Time Zone command SIM AT+CTZU.
SIM PIN References YES 3GPP TS 27.007
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
78
2019-11-21
Smart Machine Smart Decision
Syntax
Test Command AT+CTZR=?
Responses +CTZR: (list of supported < on/off >s) OK
Read Command
Responses
AT+CTZR?
+CTZR: < on/off >
Write Command AT+CTZR=< on/off >
tial Execution Command
AT+CTZR
OK
Responses OK ERROR
Responses Set default value: OK
n Defined values e <on/off> fid Integer type value indicating:
0 Disable time zone change event reporting (default). 1 Enable time zone change event reporting. +CTZV: <tz>[,<time>][,<dst>]
n Unsolicited result code when time zone received from network isn't equal to local time zone, and if
the informations from network don't include date and time, time zone will be only reported, and if
o network daylight saving time is present, it is also reported. For example: C +CTZV: 32 (Only report time zone)
+CTZV: 32,1 (Report time zone and network daylight saving time)
+CTZV: 32,08/12/09,17:00:00 (Report time and time zone) +CTZV: 32,08/12/09,17:00:00,1 (Report time, time zone and daylight saving time)
m For more detailed informations about time and time zone, please refer 3GPP TS 24.008. <tz> Local time zone received from network. o <time> Universal time received from network, and the format is "yy/MM/dd,hh:mm:ss", where characters indicate year (two last digits), month, day, hour, minutes and seconds. C<dst> Network daylight saving time, and if it is received from network, it indicates the value that has been used to adjust the local time zone. The values as following:
IM 0 No adjustment for Daylight Saving Time. 1 +1 hour adjustment for Daylight Saving Time. 2 +2 hours adjustment for Daylight Saving Time.
S NOTE: Herein, <time> is Universal Time or NITZ time, but not local time.
File
Examples
SIM7906_SIM7912 Series_AT Command Manual_V1.01
79
2019-11-21
Smart Machine Smart Decision
AT+CTZR?
+CTZR: 0
OK AT+CTZR=1 OK
Confidential File
SIMCom
SIM7906_SIM7912 Series_AT Command Manual_V1.01
80
2019-11-21
Smart Machine Smart Decision
6 AT Commands for SMS
6.1 AT+CSMS Select message service
Description
This command is used to select messaging service <service>.
l SIM PIN References YES 3GPP TS 27.005
tia Syntax n Test Command
AT+CSMS=?
e Read Command fid AT+CSMS?
Write Command
Con AT+CSMS=<service>
Responses +CSMS: (list of supported <service>s) OK
Responses +CSMS: <service>,<mt>,<mo>,<bm> OK
Responses +CSMS: <mt>,<mo>,<bm> OK ERROR +CMS ERROR: <err>
Defined values
m <service> 0 SMS at command is compatible with GSM phase 2. o 1 SMS at command is compatible with GSM phase 2+. <mt> Mobile terminated messages:
C0 type not supported.
1 type supported.
IM<mo> Mobile originated messages: 0 type not supported.
S 1 type supported.
<bm>
Broadcast type messages:
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
81
2019-11-21
Smart Machine Smart Decision
0 type not supported. 1 type supported.
Examples
AT+CSMS=0
+CSMS:1,1,1
OK AT+CSMS? +CSMS:0,1,1,1 OK
l AT+CSMS=? tia +CSMS:(0-1)
OK
n 6.2 AT+CPMS Preferred message storage e Description
This command is used to select memory storages <mem1>, <mem2> and <mem3> to be used for
fid reading, writing, etc.
SIM PIN References YES 3GPP TS 27.005
Con Syntax
Test Command AT+CPMS=?
om Read Command
AT+CPMS?
SIMCWrite Command
Responses +CPMS: (list of supported <mem1>s), (list of supported <mem2>s), (list of supported <mem3>s) OK
Responses +CPMS:<mem1>,<used1>,<total1>,<mem2>,<used2>,<total2>, <mem3>,<used3>,<total3> OK ERROR +CMS ERROR: <err>
Responses
AT+CPMS=<mem1>
+CPMS: <used1>,<total1>,<used2>,<total2>,<used3>,<total3>
[,<mem2>[,<mem3>]]
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
82
2019-11-21
Smart Machine Smart Decision
ERROR
+CMS ERROR: <err>
Execution Command
Responses
AT+CPMS
Set default value (<mem1>="SM", <mem2>="SM",
<mem3>="SM"):
+CPMS: <used1>,<total1>,<used2>,<total2>,<used3>,<total3>
OK ERROR
l Defined values
tia <mem1>
String type, memory from which messages are read and deleted (commands List Messages
AT+CMGL, Read Message AT+CMGR and Delete Message AT+CMGD).
"ME" and "MT" FLASH message storage
n "SM"
SIM message storage
"SR"
Status report storage
e <mem2>
fid String type, memory to which writing and sending operations are made (commands Send Message
from Storage AT+CMSS and Write Message to Memory AT+CMGW).
"ME" and "MT" FLASH message storage
"SM"
SIM message storage
n "SR"
Status report storage
<mem3>
o String type, memory to which received SMS is preferred to be stored (unless forwarded directly to
C TE; refer command New Message Indications AT+CNMI).
"ME"
FLASH message storage
"SM"
SIM message storage
<usedX>
Integer type, number of messages currently in <memX>.
m <totalX>
Integer type, total number of message locations in <memX>.
o Examples CAT+CPMS=?
+CPMS: ("ME","MT","SM","SR"),("ME","MT","SM","SR"),("ME","SM")
IMOK AT+CPMS?
S +CPMS:"ME", 0, 23,"ME", 0, 23,"ME", 0, 23
OK
AT+CPMS="SM","SM","SM"
+CPMS:3,50,3,50,3,50
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
83
2019-11-21
Smart Machine Smart Decision
OK
6.3 AT+CMGF Select SMS message format
Description
This command is used to specify the input and output format of the short messages.
SIM PIN References YES 3GPP TS 27.005
l Syntax tia Test Command
AT+CMGF=?
en Read Command
AT+CMGF?
fid Write Command n AT+CMGF=<mode> o Execution Command C AT+CMGF
Responses +CMGF: (list of supported <mode>s) OK ERROR
Responses +CMGF: <mode> OK ERROR
Responses OK ERROR
Responses Set default value (<mode>=0):
m Defined values o <mode>
0 PDU mode
C1 Text mode
Examples
IMAT+CMGF? +CMGF: 0
S OK
OK ERROR
AT+CMGF=?
+CMGF: (0-1)
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
84
2019-11-21
Smart Machine Smart Decision
OK AT+CMGF=1 OK
6.4 AT+CSCA SMS service centre address
Description
This command is used to update the SMSC address, through which mobile originated SMS are transmitted.
l SIM PIN References tia YES 3GPP TS 27.005
Syntax
n Test Command e AT+CSCA=?
Read Command
fid AT+CSCA?
Write Command
n AT+CSCA=<sca>[,<tosca>]
Responses OK Responses +CSCA: <sca>,<tosca> OK Responses OK
o Defined values C <sca>
Service Centre Address, value field in string format, BCD numbers (or GSM 7 bit default alphabet
characters) are converted to characters of the currently selected TE character set (refer to command
AT+CSCS), type of address given by <tosca>.
m <tosca>
SC address Type-of-Address octet in integer format, when first character of <sca> is + (IRA 43)
o default is 145, otherwise default is 129. C Examples
AT+CSCA="+8613012345678"
IMOK AT+CSCA?
+CSCA: "+8613010314500", 145
S OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
85
2019-11-21
Smart Machine Smart Decision
6.5 AT+CSCB Select cell broadcast message indication
Description
The test command returns the supported <mode>s as a compound value.
The read command displays the accepted message types.
Depending on the <mode> parameter, the write command adds or deletes the message types
accepted. SIM PIN
YES
References 3GPP TS 27.005
tial Syntax
Test Command AT+CSCB=?
en Read Command fid AT+CSCB? n Write Command
AT+CSCB=<mode>[,<mids
Co >[,<dcss>]]
Responses +CSCB: (list of supported <mode>s) OK ERROR Responses +CSCB: <mode>,<mids>,<dcss> OK ERROR Responses OK ERROR +CMS ERROR: <err>
Defined values
<mode>
m 0 message types specified in <mids> and <dcss> are accepted.
1 message types specified in <mids> and <dcss> are not accepted.
o <mids>
String type; all different possible combinations of CBM message identifiers.
C<dcss>
String type; all different possible combinations of CBM data coding schemes(default is empty string)
SIMExamples AT+CSCB=? +CSCB: (0-1) OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
86
2019-11-21
Smart Machine Smart Decision
AT+CSCB=0,"15-17,50,86","" OK
6.6 AT+CSMP Set text mode parameters
Description
This command is used to select values for additional parameters needed when SM is sent to the network or placed in storage when text format message mode is selected.
SIM PIN References
l YES 3GPP TS 27.005
tia Syntax
Test Command
Responses
n AT+CSMP=?
OK
Read Command
Responses
e AT+CSMP?
+CSMP: <fo>,<vp>,<pid>,<dcs>
fid OK
Write Command
Responses
AT+CSMP=[<fo>[,<vp>[,<p OK
n id>[,<dcs>]]]]
o Defined values C <fo>
Depending on the Command or result code: first octet of GSM 03.40 SMS-DELIVER, SMS-SUBMIT (default 17), SMS-STATUS-REPORT, or SMS-COMMAND (default 2) in integer format. SMS status report is supported under text mode if <fo> is set to 49.
m <vp>
Depending on SMS-SUBMIT <fo> setting: GSM 03.40,TP-Validity-Period either in integer format
o (default 167), in time-string format, or if is supported, in enhanced format (hexadecimal coded
string with quotes), (<vp> is in range 0... 255). <pid>
CGSM 03.40 TP-Protocol-Identifier in integer format (default 0).
<dcs>
IMGSM 03.38 SMS Data Coding Scheme (default 0), or Cell Broadcast Data Coding Scheme in integer format depending on the command or result code.
S Examples
File
AT+CSMP=17,23,64,244 OK
SIM7906_SIM7912 Series_AT Command Manual_V1.01
87
2019-11-21
Smart Machine Smart Decision
6.7 AT+CSDH Show text mode parameters
Description
This command is used to control whether detailed header information is shown in text mode result codes.
SIM PIN References
YES 3GPP TS 27.005
l Syntax tia Test Command
AT+CSDH=?
n Read Command e AT+CSDH? fid Write Command
AT+CSDH=<show>
n Execution Command Co AT+CSDH
Responses +CSDH: (list of supported <show>s) OK ERROR Responses +CSDH: <show> OK Responses OK ERROR Responses Set default value (<show>=0): OK
ERROR
Defined values
m <show> 0 Co 1
do not show header values defined in commands AT+CSCA and AT+CSMP (<sca>, <tosca>, <fo>, <vp>, <pid> and <dcs>) nor <length>, <toda> or <tooa> in +CMT, AT+CMGL, AT+CMGR result codes for SMS-DELIVERs and SMS-SUBMITs in text mode; for SMS-COMMANDs in AT+CMGR result code, do not show <pid>, <mn>, <da>, <toda>, <length> or <data> show the values in result codes
IMExamples S AT+CSDH?
+CSDH: 0
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
88
2019-11-21
Smart Machine Smart Decision
AT+CSDH=1 OK
6.8 AT+CNMA New message acknowledgement to ME/TA
Description
This command is used to confirm successful receipt of a new message (SMS-DELIVER or SMS-STATUSREPORT) routed directly to the TE. If ME does not receive acknowledgement within required time (network timeout), it will send RP-ERROR to the network.
l NOTE: The execute / write command shall only be used when AT+CSMS parameter <service>
equals 1 (= phase 2+) and appropriate URC has been issued by the module, i.e.:
tia <+CMT> for <mt>=2 incoming message classes 0, 1, 3 and none;
<+CMT> for <mt>=3 incoming message classes 0 and 3; <+CDS> for <ds>=1. SIM PIN References
n YES 3GPP TS 27.005
e Syntax fid Test Command Con AT+CNMA=?
Responses if text mode(AT+CMGF=1): OK if PDU mode (AT+CMGF=0): +CNMA: (list of supported <n>s) OK
Write Command
Responses
AT+CNMA=<n>
m Execution Command Co AT+CNMA
OK ERROR +CMS ERROR: <err> Responses OK ERROR +CMS ERROR: <err>
IMDefined values <n>
S Parameter required only for PDU mode.
0 Command operates similarly as execution command in text mode.
1 Send positive (RP-ACK) acknowledgement to the network. Accepted only in PDU
mode.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
89
2019-11-21
Smart Machine Smart Decision
2 Send negative (RP-ERROR) acknowledgement to the network. Accepted only in PDU mode.
Examples
AT+CNMI=1,2,0,0,0
OK
+CMT:"1380022xxxx","","02/04/03,11 :06 :38+32"<CR><LF> Testing (receive new short message) AT+CNMA(send ACK to the network)
l OK tia AT+CNMA
+CMS ERROR340 (the second time return error, it needs ACK only once)
n 6.9 AT+CNMI New message indications to TE e Description fid This command is used to select the procedure how receiving of new messages from the network is
indicated to the TE when TE is active, e.g. DTR signal is ON. If TE is inactive (e.g. DTR signal is OFF). If set <mt>3 or <ds>1, make sure <mode>1, If set <mt>=2,make sure <mode>=1 or
n 2, otherwise it will return error.
SIM PIN References
Co YES 3GPP TS 27.005
Syntax
Test Command
Responses
om AT+CNMI=?
+CNMI: (list of supported <mode>s),(list of supported <mt>s),(list of supported <bm>s),(list of supported <ds>s),(list of supported <bfr>s) OK
CRead Command
Responses
AT+CNMI?
+CNMI: <mode>,<mt>,<bm>,<ds>,<bfr> OK
IMWrite Command
Responses
AT+CNMI=<mode>[,<mt>[, OK
S <bm>[,<ds> [,<bfr>]]]]
ERROR
+CMS ERROR: <err>
Execution Command
Responses
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
90
2019-11-21
Smart Machine Smart Decision
AT+CNMI
Set default value: OK
Defined values
<mode> 0 Buffer unsolicited result codes in the TA. If TA result code buffer is full, indications can be buffered in some other place or the oldest indications may be discarded and replaced with the new received indications. 1 Discard indication and reject new received message unsolicited result codes when
l TA-TE link is reserved (e.g. in on-line data mode). Otherwise forward them directly
to the TE.
tia 2 Buffer unsolicited result codes in the TA when TA-TE link is reserved (e.g. in on-line data mode) and flush them to the TE after reservation. Otherwise forward them directly to the TE.
n <mt>
The rules for storing received SMS depend on its data coding scheme, preferred memory storage
e (AT+CPMS) setting and this value: 0 No SMS-DELIVER indications are routed to the TE. fid 1 If SMS-DELIVER is stored into ME/TA, indication of the memory location is routed to the TE using unsolicited result code: +CMTI: <mem3>,<index>. 2 SMS-DELIVERs (except class 2 messages and messages in the message waiting n indication group (store message)) are routed directly to the TE using unsolicited result code: o +CMT:[<alpha>],<length><CR><LF><pdu> (PDU mode enabled); or +CMT:<oa>,[<alpha>],<scts>[,<tooa>,<fo>,<pid>,<dcs>,<sca>,<tosca>,<length>] C <CR> <LF><data> (text mode enabled, about parameters in italics, refer command Show Text Mode Parameters AT+CSDH). 3 Class 3 SMS-DELIVERs are routed directly to TE using unsolicited result codes m defined in <mt>=2. Messages of other data coding schemes result in indication as defined in <mt>=1.
o <bm>
The rules for storing received CBMs depend on its data coding scheme, the setting of Select CBM
CTypes (AT+CSCB) and this value: 0 No CBM indications are routed to the TE. 2 New CBMs are routed directly to the TE using unsolicited result code:
IM +CBM: <length><CR><LF><pdu> (PDU mode enabled); or +CBM: <sn>,<mid>,<dcs>,<page>,<pages><CR><LF><data> (text mode enabled)
S <ds> 0 No SMS-STATUS-REPORTs are routed to the TE. 1 SMS-STATUS-REPORTs are routed to the TE using unsolicited result code: +CDS: <length><CR><LF><pdu> (PDU mode enabled); or
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
91
2019-11-21
Smart Machine Smart Decision
+CDS: <fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st> (text mode enabled)
2 If SMS-STATUS-REPORT is stored into ME/TA, indication of the memory location is
routed to the TE using unsolicited result code: +CDSI: <mem3>,<index>.
<bfr>
0 TA buffer of unsolicited result codes defined within this command is flushed to the TE
when <mode> 1 to 3 is entered (OK response shall be given before flushing the codes).
1 TA buffer of unsolicited result codes defined within this command is cleared when
<mode> 1 to 3 is entered.
Examples
l AT+CNMI? tia +CNMI: 0,0,0,0,0
OK AT+CNMI=? +CNMI: (0,1,2),(0,1,2,3),(0,2),(0,1,2),(0,1)
n OK
AT+CNMI=2,1 (unsolicited result codes after received messages.)
e OK fid 6.10 AT+CGSMS Select service for MO SMS messages n Description
The write command is used to specify the service or service preference that the MT will use to send
o MO SMS messages.
The test command is used for requesting information on which services and service preferences can
C be set by using the AT+CGSMS write command
The read command returns the currently selected service or service preference. SIM PIN References
YES 3GPP TS 27.007
om Syntax
Test Command
CAT+CGSMS=? IMRead Command S AT+CGSMS?
Responses +CGSMS: (list of supported <service>s) OK Responses +CGSMS: <service> OK
Write Command
Responses
AT+CGSMS=<service>
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
92
2019-11-21
Smart Machine Smart Decision
ERROR +CME ERROR: <err>
Defined values
<service>
A numeric parameter which indicates the service or service preference to be used
0 GPRS(value is not really supported and is internally mapped to 2) 1 circuit switched(value is not really supported and is internally mapped to 3) 2 GPRS preferred (use circuit switched if GPRS not available)
l 3 circuit switched preferred (use GPRS if circuit switched not available) tia Examples
AT+CGSMS? +CGSMS: 3
n OK
AT+CGSMS=?
e +CGSMS: (0-3) fid OK
6.11 AT+CMGL List SMS messages from preferred storeDescription
n This command is used to return messages with status value <stat> from message storage <mem1> o to the TE. C If the status of the message is 'received unread', the status in the storage changes to 'received read'.
SIM PIN References
YES 3GPP TS 27.005
m Syntax o Test Command
AT+CMGL=?
CWrite Command SIMAT+CMGL=<stat>
Responses +CMGL: (list of supported <stat>s) OK
Responses If text mode (AT+CMGF=1), command successful and SMS-S UBMITs and/or SMS-DELIVERs: +CMGL:<index>,<stat>,<oa>/<da>,[<alpha>],[<scts>][,<tooa>/<t oda>,<fo>,<pid>,<dcs>,<sca>,<tosca>,<length>]<CR><LF><data
>[<CR><LF>
+CMGL:<index>,<stat>,<oa>/<da>,[<alpha>],[<scts>][,<tooa>/<t
oda>,<fo>,<pid>,<dcs>,<sca>,<tosca>,<length>]<CR><LF><data
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
93
2019-11-21
Smart Machine Smart Decision
>[...]]
OK
If text mode (AT+CMGF=1), command successful and SMS-
STATUS-REPORTs:
+CMGL:<index>,<stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<s
t>[<CR><LF>
+CMGL:<index>,<stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<s t>[...]] OK If text mode (AT+CMGF=1), command successful and SMS-
l COMMANDs: tia +CMGL: <index>,<stat>,<fo>,<ct>[<CR><LF>
+CMGL: <index>,<stat>,<fo>,<ct>[...]] OK If text mode (AT+CMGF=1), command successful and CBM
n storage: e +CMGL:<index>,<stat>,<sn>,<mid>,<page>,<pages>
<CR><LF><data>[<CR><LF>
fid +CMGL:<index>,<stat>,<sn>,<mid>,<page>,<pages>
<CR><LF><data>[...]] OK
n If PDU mode (AT+CMGF=0) and Command successful:
+CMGL:<index>,<stat>,[<alpha>],<length><CR><LF><pdu>[<C
o R><LF> C+CMGL:<index>,<stat>,[<alpha>],<length><CR><LF><pdu>
[...]]
OK +CMS ERROR: <err>
m Defined values
o <stat>
1. Text Mode:
C"REC UNREAD" received unread message (i.e. new message)
"REC READ" received read message
"STO UNSENT" stored unsent message
IM "STO SENT" stored sent message
"ALL"
all messages
S 2. PDU Mode:
0 received unread message (i.e. new message)
1 received read message
2 stored unsent message
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
94
2019-11-21
Smart Machine Smart Decision
3 stored sent message 4 all messages <index> Integer type; value in the range of location numbers supported by the associated memory and start with zero. <oa> Originating-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default alphabet characters) are converted to characters of the currently selected TE character set, type of address given by <tooa>. <da>
l Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the currently selected TE character set, type of
tia address given by <toda>.
<alpha> String type alphanumeric representation of <da> or <oa> corresponding to the entry found in MT
n phonebook; implementation of this feature is manufacturer specific; used character set should be
the one selected with command Select TE Character Set AT+CSCS.
e <scts>
TP-Service-Centre-Time-Stamp in time-string format (refer <dt>).
fid <tooa>
TP-Originating-Address, Type-of-Address octet in integer format. (default refer <toda>). <toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character of <da> is +
n (IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255. o <length>
Integer type value indicating in the text mode (AT+CMGF=1) the length of the message body
C <data> in characters; or in PDU mode (AT+CMGF=0), the length of the actual TP data unit in
octets. (i.e. the RP layer SMSC address octets are not counted in the length) <data> In the case of SMS: TP-User-Data in text mode responses; format:
m 1. If <dcs> indicates that GSM 7 bit default alphabet is used and <fo> indicates that TP-User-Data-Header-Indication is not set: oa. If TE character set other than "HEX": ME/TA converts GSM alphabet into current TE character set. Cb. If TE character set is "HEX": ME/TA converts each 7-bit character of GSM 7 bit default alphabet into two IRA character long hexadecimal numbers. (e.g. character (GSM 7 bit default alphabet 23) is presented as 17 (IRA 49 and 55))
IM2. If <dcs> indicates that 8-bit or UCS2 data coding scheme is used, or <fo> indicates that TP-User-Data-Header-Indication is set: ME/TA converts each 8-bit octet into two IRA character long hexadecimal numbers. (e.g. octet with integer value 42 is presented to TE as
S two characters 2A (IRA 50 and 65)) 3. If <dcs> indicates that GSM 7 bit default alphabet is used: a. If TE character set other than "HEX": ME/TA converts GSM alphabet into current TE
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
95
2019-11-21
Smart Machine Smart Decision
character set. b. If TE character set is "HEX": ME/TA converts each 7-bit character of the GSM 7 bit
default alphabet into two IRA character long hexadecimal numbers. 4. If <dcs> indicates that 8-bit or UCS2 data coding scheme is used: ME/TA converts each
8-bit octet into two IRA character long hexadecimal numbers. <fo> Depending on the command or result code: first octet of GSM 03.40 SMS-DELIVER, SMS-SUBMIT (default 17), SMS-STATUS-REPORT, or SMS-COMMAND (default 2) in integer format. SMS status report is supported under text mode if <fo> is set to 49. <mr>
l Message Reference
GSM 03.40 TP-Message-Reference in integer format.
tia <ra>
Recipient Address GSM 03.40 TP-Recipient-Address Address-Value field in string format;BCD numbers (or GSM
n default alphabet characters) are converted to characters of the currently selected TE character
set(refer to command AT+CSCS);type of address given by <tora>
e <tora>
Type of Recipient Address
fid GSM 04.11 TP-Recipient-Address Type-of-Address octet in integer format (default refer <toda>)
<dt> Discharge Time GSM 03.40 TP-Discharge-Time in time-string format:"yy/MM/dd,hh:mm:ss+zz",where characters
n indicate year (two last digits),month,day,hour,minutes,seconds and time zone. o <st>
Status
C GSM 03.40 TP-Status in integer format
0...255 <ct> Command Type
m GSM 03.40 TP-Command-Type in integer format
0...255
o <sn>
Serial Number
CGSM 03.41 CBM Serial Number in integer format
<mid> Message Identifier
IMGSM 03.41 CBM Message Identifier in integer format <page> Page Parameter
S GSM 03.41 CBM Page Parameter bits 4-7 in integer format <pages> Page Parameter
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
96
2019-11-21
Smart Machine Smart Decision
GSM 03.41 CBM Page Parameter bits 0-3 in integer format <pdu> In the case of SMS: SC address followed by TPDU in hexadecimal format: ME/TA converts each octet of TP data unit into two IRA character long hexadecimal numbers. (e.g. octet with integer value 42 is presented to TE as two characters 2A (IRA 50 and 65)).
Examples
AT+CMGL=? +CMGL: ("REC UNREAD","REC READ","STO UNSENT","STO SENT","ALL") OK
l AT+CMGL="ALL" tia +CMGL: 1,"STO UNSENT","+10011",,,145,4
Hello World OK
n 6.12 AT+CMGR Read message e Description fid This command is used to return message with location value <index> from message storage
<mem1> to the TE.
SIM PIN References
n YES 3GPP TS 27.005 Co Syntax
Test Command AT+CMGR=?
Write Command
SIMCom AT+CMGR=<index>
Responses OK
Responses If text mode (AT+CMGF=1), command successful and SMSDELIVER: +CMGR: <stat>,<oa>,[<alpha>],<scts>[,<tooa>,<fo>,<pid>,<dcs>, <sca>, <tosca>, <length>]<CR><LF><data> OK If text mode (AT+CMGF=1), command successful and SMSSUBMIT: +CMGR:<stat>,<da>,[<alpha>][,<toda>,<fo>,<pid>,<dcs>,[<vp>], <sca>, <tosca>,<length>]<CR><LF><data> OK
If text mode (AT+CMGF=1), command successful and SMS-
STATUS-REPORT:
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
97
2019-11-21
Smart Machine Smart Decision
+CMGR: <stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st> OK
If text mode (AT+CMGF=1), command successful and SMSCOMMAND: +CMGR:<stat>,<fo>,<ct>[,<pid>,[<mn>],[<da>],[<toda>],<length >]<CR><LF><data> OK
If text mode (AT+CMGF=1), command successful and CBM storage: +CMGR:<stat>,<sn>,<mid>,<dcs>,<page>,<pages><CR><LF><d
l ata> tia OK
If PDU mode (AT+CMGF=0) and Command successful: +CMGR:<stat>,[<alpha>],<length><CR><LF><pdu> OK
n +CMS ERROR: <err> e Defined values fid <index>
Integer type; value in the range of location numbers supported by the associated memory and start with zero.
n <stat>
1.Text Mode
o "REC UNREAD" received unread message (i.e. new message) C "REC READ" received read message
"STO UNSENT" stored unsent message "STO SENT" stored sent message 2. PDU Mode 0 received unread message (i.e. new message)
m 1 received read message. o2 stored unsent message.
3 stored sent message <oa>
COriginating-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the currently selected TE character set, type of
IMaddress given by <tooa>. <alpha> String type alphanumeric representation of <da> or <oa> corresponding to the entry found in MT
S phonebook; implementation of this feature is manufacturer specific; used character set should be the one selected with command Select TE Character Set AT+CSCS. <scts>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
98
2019-11-21
Smart Machine Smart Decision
TP-Service-Centre-Time-Stamp in time-string format (refer <dt>). <tooa> TP-Originating-Address, Type-of-Address octet in integer format. (default refer <toda>). <fo> Depending on the command or result code: first octet of GSM 03.40 SMS-DELIVER, SMS-SUBMIT (default 17), SMS-STATUS-REPORT, or SMS-COMMAND (default 2) in integer format. SMS status report is supported under text mode if <fo> is set to 49. <pid> Protocol Identifier GSM 03.40 TP-Protocol-Identifier in integer format
l 0...255
<dcs>
tia Depending on the command or result code: SMS Data Coding Scheme (default 0), or Cell
Broadcast Data Coding Scheme in integer format. <sca>
n RP SC address Address-Value field in string format; BCD numbers (or GSM 7 bit default alphabet
characters) are converted to characters of the currently selected TE character set, type of address
e given by <tosca>.
<tosca>
fid RP SC address Type-of-Address octet in integer format (default refer <toda>).
<length> Integer type value indicating in the text mode (AT+CMGF=1) the length of the message body <data> > (or <cdata>) in characters; or in PDU mode (AT+CMGF=0), the length of the actual TP
n data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length). o <data>
In the case of SMS: TP-User-Data in text mode responses; format:
C 1 If <dcs> indicates that GSM 7 bit default alphabet is used and <fo> indicates that TP-User-Data-Header-Indication is not set: a. If TE character set other than "HEX": ME/TA converts GSM alphabet into current TE character set. m b. If TE character set is "HEX": ME/TA converts each 7-bit character of GSM 7 bit default alphabet into two IRA character long hexadecimal numbers. (e.g. character o (GSM 7 bit default alphabet 23) is presented as 17 (IRA 49 and 55)). 2 If <dcs> indicates that 8-bit or UCS2 data coding scheme is used, or <fo> indicates that
CTP-User-Data-Header-Indication is set: ME/TA converts each 8-bit octet into two IRA character long hexadecimal numbers. (eg. octet with integer value 42 is presented to TE as two characters 2A (IRA 50 and 65)).
IM3 If <dcs> indicates that GSM 7 bit default alphabet is used: a. If TE character set other than "HEX": ME/TA converts GSM alphabet into current TE character set.
S b. If TE character set is "HEX": ME/TA converts each 7-bit character of the GSM 7 bit default alphabet into two IRA character long hexadecimal numbers. 4 If <dcs> indicates that 8-bit or UCS2 data coding scheme is used: ME/TA converts
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
99
2019-11-21
Smart Machine Smart Decision
each 8-bit octet into two IRA character long hexadecimal numbers. <da> Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default alphabet characters) are converted to characters of the currently selected TE character set, type of address given by <toda>. <toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character of <da> is + (IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255. <vp> Depending on SMS-SUBMIT <fo> setting: TP-Validity-Period either in integer format (default
l 167) or in time-string format (refer <dt>).
<mr>
tia Message Reference
GSM 03.40 TP-Message-Reference in integer format. <ra>
n Recipient Address
GSM 03.40 TP-Recipient-Address Address-Value field in string format;BCD numbers(or GSM
e default alphabet characters) are converted to characters of the currently selected TE character
set(refer to command AT+CSCS);type of address given by <tora>
fid <tora>
Type of Recipient Address GSM 04.11 TP-Recipient-Address Type-of-Address octet in integer format (default refer <toda>) <dt>
n Discharge Time o GSM 03.40 TP-Discharge-Time in time-string format:"yy/MM/dd,hh:mm:ss+zz",where characters
indicate year (two last digits),month,day,hour,minutes,seconds and time zone.
C <st>
Status GSM 03.40 TP-Status in integer format 0...255
m <ct>
Command Type
o GSM 03.40 TP-Command-Type in integer format
0...255
C<mn>
Message Number GSM 03.40 TP-Message-Number in integer format
IM<sn> Serial Number GSM 03.41 CBM Serial Number in integer format
S <mid> Message Identifier GSM 03.41 CBM Message Identifier in integer format
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
100
2019-11-21
Smart Machine Smart Decision
<page>
Page Parameter
GSM 03.41 CBM Page Parameter bits 4-7 in integer format
<pages>
Page parameter
GSM 03.41 CBM Page Parameter bits 0-3 in integer format
<pdu>
In the case of SMS: SC address followed by TPDU in hexadecimal format: ME/TA converts each octet of TP data unit into two IRA character long hexadecimal numbers. (eg. octet with integer value 42 is presented to TE as two characters 2A (IRA 50 and 65)).
l Examples tia AT+CMGR=1
+CMGR: "STO UNSENT","+10011",,145,17,0,0,167,"+8613800100500",145,11 Hello World
n OK e 6.13 AT+CMGS Send message fid Description
This command is used to send message from a TE to the network (SMS-SUBMIT).
n SIM PIN References o YES 3GPP TS 27.005 C Syntax
Test Command AT+CMGS=?
Responses OK
m Write Command
If text mode (AT+CMGF=1):
o AT+CMGS=<da>[,<toda>]<
CR>Text is entered.
C<CTRL-Z/ESC>
If PDU mode(AT+CMGF=
0):
IMAT+CMGS=<length><CR> PDU is entered
S <CTRL-Z/ESC>
Responses If sending successfully: +CMGS: <mr> OK If cancel sending: OK If sending fails: ERROR If sending fails:
+CMS ERROR: <err>
File
Defined values
SIM7906_SIM7912 Series_AT Command Manual_V1.01
101
2019-11-21
Smart Machine Smart Decision
<da> Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default alphabet characters) are converted to characters of the currently selected TE character set, type of address given by <toda>. <toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character of <da> is + (IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255. <length> integer type value indicating in the text mode (AT+CMGF=1) the length of the message body <data> > (or <cdata>) in characters; or in PDU mode (AT+CMGF=0), the length of the actual TP
l data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length)
<mr>
tia Message Reference
GSM 03.40 TP-Message-Reference in integer format. NOTE: In text mode, the maximum length of an SMS depends on the used coding scheme: It is
n 160 characters if the 7 bit GSM coding scheme is used. e Examples
AT+CMGS="13012832788"<CR>(TEXT MODE)
fid > ABCD<ctrl-Z/ESC>
+CMGS: 46 OK
on 6.14 AT+CMSS Send message from storage C Description
This command is used to send message with location value <index> from preferred message storage <mem2> to the network (SMS-SUBMIT or SMS-COMMAND).
SIM PIN References
m YES 3GPP TS 27.005
o Syntax CTest Command
AT+CMSS=?
IMWrite Command AT+CMSS=
S <index> [,<da>[,<toda>]]
Responses OK Responses +CMSS: <mr> OK
ERROR
If sending fails:
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
102
2019-11-21
Smart Machine Smart Decision
+CMS ERROR: <err>
Defined values
<index>
Integer type; value in the range of location numbers supported by the associated memory and start
with zero.
<da> Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default alphabet characters) are converted to characters of the currently selected TE character set, type of
l address given by <toda>.
<mr>
tia Message Reference
GSM 03.40 TP-Message-Reference in integer format. <toda>
n TP-Destination-Address, Type-of-Address octet in integer format. (when first character of <da> is +
(IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255.
e NOTE: In text mode, the maximum length of an SMS depends on the used coding scheme: It is
160 characters if the 7 bit GSM coding scheme is used.
fid Examples AT+CMSS=3 n +CMSS: 0 OK o AT+CMSS=3,"13012345678" C +CMSS: 55 OK
6.15 AT+CMGW Write message to memory
m Description o This command is used to store message (either SMS-DELIVER or SMS-SUBMIT) to memory
storage <mem2>.
CSIM PIN References
YES 3GPP TS 27.005
SIMSyntax
Test Command
Responses
AT+CMGW=?
OK
File
Write Command
Responses
SIM7906_SIM7912 Series_AT Command Manual_V1.01
103
2019-11-21
Smart Machine Smart Decision
If text mode(AT+CMGF=1): If write successfully:
AT+CMGW=<oa>/<da>[,<t +CMGW: <index>
ooa>/<toda>[,<stat>]]<CR> OK
Text is entered.
If cancel write:
<CTRL-Z/ESC>
OK
If PDU mode(AT+CMGF=
0):
If write fails:
AT+CMGW=<length>[,<sta t>]<CR>PDU is entered. <CTRL-Z/ESC>
ERROR
If write fails: +CMS ERROR: <err>
tial Defined values <index>
Integer type; value in the range of location numbers supported by the associated memory and start
n with zero.
<oa>
e Originating-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default fid alphabet characters) are converted to characters of the currently selected TE character set, type of
address given by <tooa>.
<tooa>
TP-Originating-Address, Type-of-Address octet in integer format. (default refer <toda>).
n <da>
Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default
o alphabet characters) are converted to characters of the currently selected TE character set, type of C address given by <toda>.
<toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character of <da> is + (IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255. <length>
m Integer type value indicating in the text mode (AT+CMGF=1) the length of the message body o <data> > (or <cdata>) in characters; or in PDU mode (AT+CMGF=0), the length of the actual TP
data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length). <stat>
C1. Text Mode:
"STO UNSENT" stored unsent message "STO SENT" stored sent message
IM2. PDU Mode: 2 stored unsent message
S 3 stored sent message
NOTE: In text mode, the maximum length of an SMS depends on the used coding scheme: It is
160 characters if the 7 bit GSM coding scheme is used.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
104
2019-11-21
Smart Machine Smart Decision
Examples
AT+CMGW="13012832788" <CR> (TEXT MODE) ABCD<ctrl-Z/ESC> +CMGW:1 OK
6.16 AT+CMGD Delete message
Description
l This command is used to delete message from preferred message storage <mem1> location
<index>. If <delflag> is present and not set to 0 then the ME shall ignore <index> and follow the
tia rules for <delflag> shown below.
SIM PIN References
YES 3GPP TS 27.005
en Syntax fid Test Command
AT+CMGD=?
n Write Command o AT+CMGD= C <index>[,<delflag>]
Responses +CMGD: (list of supported <index>s)[,(list of supported <delflag>s)] OK Responses OK ERROR +CMS ERROR: <err>
Defined values
m <index>
Integer type; value in the range of location numbers supported by the associated memory and start
o with zero.
<delflag>
C0 (or omitted) Delete the message specified in <index>.
1 Delete all read messages from preferred message storage, leaving unread messages and stored mobile originated messages (whether sent or not) untouched.
IM2 Delete all read messages from preferred message storage and sent mobile originated messages, leaving unread messages and unsent mobile originated messages untouched.
S 3 Delete all read messages from preferred message storage, sent and unsent mobile originated messages leaving unread messages untouched.
4 Delete all messages from preferred message storage including unread messages.
NOTE: If set <delflag>=1, 2, 3 or 4, <index> is omitted, such as AT+CMGD=,1.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
105
2019-11-21
Smart Machine Smart Decision
Examples
AT+CMGD=1 OK
6.17 AT+CMGMT Change message status
Description
This command is used to change the message status. If the status is unread, it will be changed read. Other statuses don't change.
l SIM PIN References tia YES Vendor
Syntax
n Test Command e AT+CMGMT=?
Write Command
fid AT+CMGMT=<index>
Responses OK
Responses OK ERROR +CMS ERROR: <err>
on Defined values <index> C Integer type; value in the range of location numbers supported by the associated memory and start
with zero.
Examples
m AT+CMGMT=1 o OK C 6.18 AT+CMVP Set message valid period
Description
IMThis command is used to set valid period for sending short message. S SIM PIN References
YES Vendor
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
106
2019-11-21
Smart Machine Smart Decision
Syntax
Test Command AT+CMVP=?
Responses +CMVP: (list of supported <vp>s) OK
Read Command
Responses
AT+CMVP?
+CMVP:<vp>
Write Command
tial AT+CMVP=<vp>
OK
Responses OK ERROR +CMS ERROR: <err>
Defined values
n <vp>
Validity period value:
e 0 to 143
(<vp>+1) x 5 minutes (up to 12 hours)
fid 144 to 167 12 hours + (<vp>-143) x 30 minutes
168 to 196 (<vp>-166) x 1 day
197 to 255 (<vp>-192) x 1 week
on Examples C AT+CMVP=167
OK AT+CMVP? +CMVP: 167
m OK o 6.19 AT+CMGRD Read and delete message C Description
This command is used to read message, and delete the message at the same time. It integrate
IMAT+CMGR and AT+CMGD, but it doesn't change the message status. S SIM PIN References
YES Vendor
File
Syntax
SIM7906_SIM7912 Series_AT Command Manual_V1.01
107
2019-11-21
Smart Machine Smart Decision
Test Command AT+CMGRD=?
Responses OK
Write Command
Responses
AT+CMGRD=<index>
If text mode(AT+CMGF=1),command successful and SMS-DE-
LIVER:
+CMGRD:<stat>,<oa>,[<alpha>],<scts>[,<tooa>,<fo>,<pid>,<dcs
>, <sca>,<tosca>,<length>]<CR><LF><data> OK If text mode(AT+CMGF=1),command successful and SMS-SU-
l BMIT:
+CMGRD:<stat>,<da>,[<alpha>][,<toda>,<fo>,<pid>,<dcs>,[<vp
tia >], <sca>,<tosca>,<length>]<CR><LF><data>
OK If text mode(AT+CMGF=1),command successful and SMS-STA-
n TUS- REPORT:
+CMGRD: <stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st>
e OK
If text mode(AT+CMGF=1),command successful and SMS-CO-
fid MMAND:
+CMGRD:<stat>,<fo>,<ct>[,<pid>,[<mn>],[<da>],[<toda>],<lengt h><CR><LF><data>]
n OK
If text mode(AT+CMGF=1),command successful and CBM sto-
o rage:
+CMGRD:<stat>,<sn>,<mid>,<dcs>,<page>,<pages><CR><LF><
Cdata>
OK If PDU mode(AT+CMGF=0) and command successful: +CMGRD: <stat>,[<alpha>],<length><CR><LF><pdu>
mOK o ERROR
+CMS ERROR: <err>
C Defined values
Refer to command AT+CMGR.
SIMExamples AT+CMGRD=6
+CMGRD:"REC READ","+8613917787249",,"06/07/10,12:09:38+32",145,4,0,0, "+86138002105
00",145,4
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
108
2019-11-21
Smart Machine Smart Decision
How do you do OK
6.20 AT+CMGSEX Send message
Description
This command is used to send message from a TE to the network (SMS-SUBMIT). SIM PIN References
l YES 3GPP TS 27.005
tia Syntax
Test Command
Responses
n AT+CMGSEX=?
OK
Write Command
Responses
e If text mode (AT+CMGF=1):
AT+CMGSEX=<da>[,<toda
fid >][,<mr>,
<msg_seg>,
<msg_total>]<CR>Text is
entered.
n <CTRL-Z/ESC>
If sending successfully: +CMGSEX: <mr> OK If cancel sending: OK If sending fails:
o ERROR
If sending fails:
C+CMS ERROR: <err>
Defined values
m <da>
Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default
o alphabet characters) are converted to characters of the currently selected TE character set, type of
address given by <toda>.
C<toda>
TP-Destination-Address, Type-of-Address octet in integer format. (When first character of <da> is + (IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255.
IM<mr> Message Reference GSM 03.40 TP-Message-Reference in integer format.
S <msg_seg>
The segment number for long sms
<msg_total>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
109
2019-11-21
Smart Machine Smart Decision
The total number of the segments for long sms. Its range is from 2 to 255. NOTE: In text mode, the maximum length of an SMS depends on the used coding scheme: For single SMS, it is 160 characters if the 7 bit GSM coding scheme is used; For multiple long sms, it is 153 characters if the 7 bit GSM coding scheme is used.
Examples
AT+CMGSEX="13012832788", 190, 1, 2<CR>(TEXT MODE) > ABCD<ctrl-Z/ESC> +CMGSEX: 190 OK
l AT+CMGSEX="13012832788", 190, 2, 2<CR>(TEXT MODE) tia > EFGH<ctrl-Z/ESC>
+CMGSEX: 190 OK
n 6.21 AT+CMSSEX Send multi messages from storage e Description fid This command is used to send messages with location value <index1>,<index2>,<index3>... from
preferred message storage <mem2> to the network (SMS-SUBMIT or SMS-COMMAND).The max count of index is 13 one time.
n SIM PIN References YES 3GPP TS 27.005
Co Syntax
Test Command AT+CMSSEX=?
m Write Command
AT+CMSSEX=
IMCo <index> [,<index >[,... ]]
Responses OK Responses +CMSSEX: <mr>[,<mr>[,...]] OK ERROR If sending fails: [+CMSSEX: <mr>[,<mr>[,...]]] +CMS ERROR: <err>
S Defined values
<index>
Integer type; value in the range of location numbers supported by the associated memory and start
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
110
2019-11-21
Smart Machine Smart Decision
with zero. <mr> Message Reference GSM 03.40 TP-Message-Reference in integer format. NOTE: In text mode, the maximum length of an SMS depends on the used coding scheme: It is 160 characters if the 7 bit GSM coding scheme is used.
Examples
AT+CMSSEX=0,1 +CMSSEX: 239,240
tial OK
AT+CMSSEX=0,1 +CMSSEX: 238
Confiden +CMS ERROR: Invalid memory index SIMCom
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
111
2019-11-21
7 AT Commands for Phonebook
7.1 AT+CPBS Select phonebook memory storage
Description
This command selects the active phonebook storage, i.e. the phonebook storage that all subsequent phonebook commands will be operating on.
l SIM PIN References tia YES 3GPP TS 27.007
Syntax
n Test Command e AT+CPBS=? fid Read Command
AT+CPBS?
on Write Command C AT+CPBS=<storage>
Responses +CPBS: (list of supported <storage>s) OK Responses +CPBS: <storage>[,<used>,<total>] OK +CME ERROR: <err> Responses OK
ERROR
Execution Command
m AT+CPBS
+CME ERROR: <err>
Responses Set default value "SM": OK
o Defined values
C<storage>
Values reserved by the present document:
IM"DC"
ME dialed calls list
Capacity: max. 100 entries
AT+CPBW command is not applicable to this storage.
S "MC" ME missed (unanswered received) calls list
Capacity: max. 100 entries
AT+CPBW command is not applicable to this storage.
File
Smart Machine Smart Decision
"RC"
ME received calls list
Capacity: max. 100 entries
AT+CPBW command is not applicable to this storage.
"SM"
SIM phonebook
Capacity: depending on SIM card
"ME"
Mobile Equipment phonebook
Capacity: max. 500 entries
"FD"
SIM fixdialling-phonebook
Capacity:depending on SIM card
"ON"
MSISDN list
l Capacity:depending on SIM card
"LD"
Last number dialed phonebook
tia Capacity: depending on SIM card
AT+CPBW command is not applicable to this storage
"EN"
Emergency numbers
n Capacity: depending on SIM card
AT+CPBW command is not applicable to this storage.
e <used>
Integer type value indicating the number of used locations in selected memory.
fid <total>
Integer type value indicating the total number of locations in selected memory.
n Examples AT+CPBS=? o +CPBS: ("SM","DC","FD","LD","MC","ME","RC","EN","ON") C OK
AT+CPBS="SM"
OK AT+CPBS? +CPBS: "SM",1,200
m OK o 7.2 AT+CPBR Read phonebook entries C Description
This command gets the record information from the selected memory storage in phonebook. If the
IMstorage is selected as "SM" then the command will return the record in SIM phonebook, the same to others.
S SIM PIN References
YES 3GPP TS 27.007
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
113
2019-11-21
Smart Machine Smart Decision
Syntax
Test Command AT+CPBR=?
Responses +CPBR: (<minIndex>-<maxIndex>), [<nlength>], [<tlength>]
OK
+CME ERROR: <err>
Write Command AT+CPBR=
tial <index1>[,<index2>]
Responses [+CPBR: <index1>,<number>,<type>,<text>[<CR><LF> +CPBR: <index2>,<number>,<type>,<text>[...]]] OK ERROR +CME ERROR: <err>
n Defined values e <index1>
Integer type value in the range of location numbers of phonebook memory.
fid <index2>
Integer type value in the range of location numbers of phonebook memory. <index> Integer type.the current position number of the Phonebook index.
n <minIndex> o Integer type the minimum <index> number.
<maxIndex>
C Integer type the maximum <index> number
<number> String type, phone number of format <type>, the maximum length is <nlength>. <type>
m Type of phone number octet in integer format, default 145 when dialing string includes international
access code character "+", otherwise 129.
o <text>
String type field of maximum length <tlength>; often this value is set as name. <nlength>
CInteger type value indicating the maximum length of field <number>.
<tlength>
IMInteger type value indicating the maximum length of field <text>. S Examples
AT+CPBS?
+CPBS: "SM",2,200
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
114
2019-11-21
Smart Machine Smart Decision
OK AT+CPBR=1,10 +CPBR: 1,"1234567890",129,"James" +CPBR: 2,"0987654321",129,"Kevin" OK
7.3 AT+CPBF Find phonebook entries
Description
l This command finds the record in phonebook (from the current phonebook memory storage
selected with AT+CPBS) which alphanumeric field has substring <findtext>.If <findtext> is null, it
tia will list all the entries.
SIM PIN References YES 3GPP TS 27.007
n Syntax e Test Command fid AT+CPBF=? n Write Command Co AT+CPBF=[<findtext>]
Responses +CPBF: [<nlength>],[<tlength>] OK +CME ERROR: <err> Responses [+CPBF: <index1>,<number>,<type>,<text>[<CR><LF> +CPBF: <indexN>,<number>,<type>,<text>[...]]]
OK
ERROR
+CME ERROR: <err>
om Defined values
<findtext>
CString type, this value is used to find the record. Character set should be the one selected with
command AT+CSCS. <index>
IMInteger type values in the range of location numbers of phonebook memory. <number>
S String type, phone number of format <type>, the maximum length is <nlength>. <type>
Type of phone number octet in integer format, default 145 when dialing string includes international
access code character "+", otherwise 129.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
115
2019-11-21
Smart Machine Smart Decision
<text> String type field of maximum length <tlength>; Often this value is set as name. <nlength> Integer type value indicating the maximum length of field <number>. <tlength> Integer type value indicating the maximum length of field <text>.
Examples
AT+CPBF=" James " +CPBF: 1,"1234567890",129," James "
l OK
tia 7.4 AT+CPBW Write phonebook entry
n Description This command writes phonebook entry in location number <index> in the current phonebook e memory storage selected with AT+CPBS. fid SIM PIN References YES 3GPP TS 27.007
n Syntax o Test Command C AT+CPBW=?
Responses +CPBW:(list of supported <index>s),[<nlength>],
(list of supported <type>s),[<tlength>]
m Write Command
AT+CPBW=[<index>][,<nu
o mber>[,<type>[,<text>]]]
OK +CME ERROR:<err> Responses OK ERROR +CME ERROR:<err>
C Defined values IM<index>
Integer type values in the range of location numbers of phonebook memory. If <index> is not given,
S the first free entry will be used. If <index> is given as the only parameter, the phonebook entry
specified by <index> is deleted. If record number <index> already exists, it will be overwritten.
<number>
String type, phone number of format <type>, the maximum length is <nlength>.It must be an
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
116
2019-11-21
Smart Machine Smart Decision
non-empty string. <type> Type of address octet in integer format, The range of value is from 129 to 255. If <number> contains a leading "+" <type> = 145 (international) is used. Supported value are:
145 when dialling string includes international access code character "+" 161 national number. The network support for this type is optional 177 network specific number, ISDN format 129 otherwise
NOTE: Other value refer TS 24.008 [8] subclause 10.5.4.7.
l <text>
String type field of maximum length <tlength>; character set as specified by command Select TE
tia Character Set AT+CSCS.
<nlength> Integer type value indicating the maximum length of field <number>.
n <tlength>
Integer type value indicating the maximum length of field <text>.
e NOTE: If the parameters of <type> and <text> are omitted and the first character of <number> is
`+'it will specify <type> as 145(129 if the first character isn't `+') and <text> as NULL.
fid Examples AT+CPBW=3,"88888888",129,"John" n OK AT+CPBW=,"6666666",129,"mary" o OK C AT+CPBW=1 OK
m 7.5 AT+CNUM Subscriber number o Description
Execution command returns the MSISDNs related to the subscriber (this information can be stored
Cin the SIM or in the ME). If subscriber has different MSISDN for different services, each MSISDN
is returned in a separate line.
IMSIM PIN References S YES 3GPP TS 27.007
Syntax
File
Test Command
Responses
SIM7906_SIM7912 Series_AT Command Manual_V1.01
117
2019-11-21
Smart Machine Smart Decision
AT+CNUM=? Execution Command AT+CNUM
OK Responses [+CNUM: <alpha>,<number>,<type>[<CR><LF> +CNUM: <alpha>, <number>,<type> [...]]] OK +CME ERROR: <err>
Defined values
<alpha>
l Optional alphanumeric string associated with <number>, used character set should be the one tia selected with command Select TE Character Set AT+CSCS.
<number> String type phone number of format specified by <type>. <type>
n Type of address octet in integer format. see also AT+CPBR <type> e Examples fid AT+CNUM
+CNUM: "","13697252277",129
Con OK
SIMCom
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
118
2019-11-21
Smart Machine Smart Decision
8 AT Commands for GPRS
8.1 AT+CGREG GPRS network registration status
Description
This command controls the presentation of an unsolicited result code "+CGREG: <stat>" when <n>=1 and there is a change in the MT's GPRS network registration status.
l The read command returns the status of result code presentation and an integer <stat> which shows tia Whether the network has currently indicated the registration of the MT.
SIM PIN References NO 3GPP TS 27.007
n Syntax e Test Command fid AT+CGREG=?
Read Command
n AT+CGREG? o Write Command C AT+CGREG=<n>
Responses +CGREG: (list of supported <n>s) OK
Responses +CGREG: <n>,<stat>[,<lac>,<ci>] OK
Responses OK
Execution Command
Responses
AT+CGREG
Set default value: OK
m Defined values o <n>
0 disable network registration unsolicited result code
C1 enable network registration unsolicited result code +CGREG: <stat>
2 there is a change in the ME network registration status or a change of the network cell:
+CGREG: <stat>[,<lac>,<ci>]
IM<stat> 0 not registered, ME is not currently searching an operator to register to
S 1 registered, home network
2 not registered, but ME is currently trying to attach or searching an operator to register
to
3 registration denied
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
119
2019-11-21
Smart Machine Smart Decision
4 unknown 5 registered, roaming <lac> Two bytes location area code in hexadecimal format (e.g."00C3" equals 193 in decimal).
<ci> Cell ID in hexadecimal format. WCDMA : Maximum is four byte
l Examples tia AT+CGREG=?
+CGREG: (0-1) OK AT+CGREG?
n +CGREG: 0,0
OK
fide 8.2 AT+CGATT Packet domain attach or detach Description n The write command is used to attach the MT to, or detach the MT from, the Packet Domain service. The read command returns the current Packet Domain service state. o SIM PIN References C YES 3GPP TS 27.007
Syntax
m Test Command
AT+CGATT=?
Co Read Command
AT+CGATT?
IMWrite Command S AT+CGATT=<state>
Responses +CGATT: (list of supported <state>s) OK ERROR Responses +CGATT: <state> OK ERROR Responses OK
ERROR
+CME ERROR: <err>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
120
2019-11-21
Smart Machine Smart Decision
Defined values
<state> Indicates the state of Packet Domain attachment:
0 detached 1 attached
Examples
AT+CGATT? +CGATT: 0
l OK
AT+CGATT=1
tia OK
8.3 AT+CGACT PDP context activate or deactivate
n Description e The write command is used to activate or deactivate the specified PDP context (s). fid SIM PIN References
YES 3GPP TS 27.007
n Syntax o Test Command C AT+CGACT=?
Responses +CGACT: (list of supported <state>s)
OK
Read Command
Responses
om AT+CGACT?
+CGACT: [<cid>,<state> [<CR><LF> +CGACT: <cid>,<state> [...]]] OK
Write Command
Responses
CAT+CGACT=<state>[,<cid> OK
]
ERROR
+CME ERROR: <err>
SIMDefined values
<state>
Indicates the state of PDP context activation:
0 deactivated
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
121
2019-11-21
Smart Machine Smart Decision
1 activated <cid> A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT command).
1...24
Examples
AT+CGACT? +CGACT: 1,1 OK
l AT+CGACT=? tia +CGACT: (0,1)
OK AT+CGACT=0,1 OK
en 8.4 AT+CGDCONT Define PDP context fid Description
The set command specifies PDP context parameter values for a PDP context identified by the (local) context identification parameter <cid>. The number of PDP contexts that may be in a
n defined state at the same time is given by the range returned by the test command. A special form of
the write command (AT+CGDCONT=<cid>) causes the values for context <cid> to become
o undefined. C SIM PIN References
YES 3GPP TS 27.007
Syntax
m Test Command o AT+CGDCONT=? IMCRead Command S AT+CGDCONT?
Responses +CGDCONT: (range of supported<cid>s),<PDP_type>,,,(list of supported <d_comp>s),(list of supported <h_comp>s)(list of <ipv4_ctrl>s),(list of <emergency_flag>s) OK ERROR Responses +CGDCONT: [<cid>, <PDP_type>, <APN>,<PDP_addr>, <d_comp>, <h_comp>,<ipv4_ctrl>,<emergency_flag>[<CR><LF>
+CGDCONT: <cid>, <PDP_type>, <APN>, <PDP_addr>,
<d_comp>, <h_comp>,< ipv4_ctrl>,<emergency_flag>[...]]]
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
122
2019-11-21
Smart Machine Smart Decision
ERROR
Write Command
Responses
AT+CGDCONT=<cid>[,<P OK
DP_type>[,<APN>[,<PDP_a
ddr>[,<d_comp>[,<h_comp> ERROR
][,<ipv4_ctrl>[,<emergency_
flag>]]]]]]
Execution Command
l AT+CGDCONT
Responses OK ERROR
tia Defined values <cid>
(PDP Context Identifier) a numeric parameter which specifies a particular PDP context definition.
n The parameter is local to the TE-MT interface and is used in other PDP context-related commands.
The range of permitted values (minimum value = 1) is returned by the test form of the command.
e 1...24 fid <PDP_type>
(Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
IP Internet Protocol
PPP Point to Point Protocol
n IPV6 Internet Protocol Version 6
IPV4V6 Dual PDN Stack
o <APN> C (Access Point Name) a string parameter which is a logical name that is used to select the GGSN or
the external packet data network.
<PDP_addr> A string parameter that identifies the MT in the address space applicable to the PDP. Read command will continue to return the null string even if an address has been allocated during
m the PDP startup procedure. The allocated address may be read using command AT+CGPADDR. o <d_comp>
A numeric parameter that controls PDP data compression, this value may depend on platform: 0 off (default if value is omitted)
C1 on
2 V.42bis 3 V.44
IM<h_comp> A numeric parameter that controls PDP header compression, this value may depend on platform:
S 0 off (default if value is omitted)
1 on 2 RFC1144
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
123
2019-11-21
Smart Machine Smart Decision
3 RFC2507
4 RFC3095
<ipv4_ctrl>
Parameter that controls how the MT/TA requests to get the IPv4 address information:
0 Address Allocation through NAS Signaling
1 on
<emergency_flag>
emergency_flag: 0 off (default if value is omitted) 1 on
l Examples tia AT+CGDCONT?
+CGDCONT: 1,"IPV4V6","","0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0",0,0,0,0 +CGDCONT: 2,"IPV6","ims","0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0",0,0,0,0
n +CGDCONT: 3,"IPV4V6","","0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0",0,0,0,1 e OK
AT+CGDCONT=?
fid +CGDCONT: (1-24),"IP",,,(0-3),(0-4),(0-1),(0-1)
+CGDCONT: (1-24),"PPP",,,(0-3),(0-4),(0-1),(0-1) +CGDCONT: (1-24),"IPV6",,,(0-3),(0-4),(0-1),(0-1)
n +CGDCONT: (1-24),"IPV4V6",,,(0-3),(0-4),(0-1),(0-1) Co OK
8.5 AT+CGDSCONT Define Secondary PDP Context
Description
m The set command specifies PDP context parameter values for a Secondary PDP context identified
by the (local) context identification parameter, <cid>. The number of PDP contexts that may be in a
o defined state at the same time is given by the range returned by the test command. A special form of
the set command, AT+CGDSCONT=<cid> causes the values for context number <cid> to become
Cundefined.
SIM PIN References YES 3GPP TS 27.007
SIMSyntax
Test Command
Responses
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
124
2019-11-21
Smart Machine Smart Decision
AT+CGDSCONT=?
+CGDSCONT: (range of supported <cid>s),(list of <p_cid>s for active primary contexts), <PDP_type>, (list of supported <d_comp>s),(list of supported <h_comp>s)
OK
ERROR
Read Command
Responses
l AT+CGDSCONT?
+CGDSCONT: [<cid>,<p_cid>,<d_comp>,<h_comp> [<CR><LF>+CGDSCONT: <cid>,<p_cid>,<d_comp>,<h_comp> [...]]]
tia Write Command n AT+CGDSCONT=<cid>[,<
p_cid>[,<d_comp>[,<h_com
e p>]]]
OK ERROR Responses OK
ERROR
fid Defined values <cid> a numeric parameter which specifies a particular PDP context definition. The parameter is local to n the TE-MT interface and is used in other PDP context-related commands. The range of permitted o values (minimum value = 1) is returned by the test form of the command. C NOTE: The <cid>s for network-initiated PDP contexts will have values outside the ranges
indicated for the <cid> in the test form of the commands +CGDCONT and +CGDSCONT. <p_cid> a numeric parameter which specifies a particular PDP context definition which has been specified
m by use of the +CGDCONT command. The parameter is local to the TE-MT interface. The list of
permitted values is returned by the test form of the command.
o <PDP_type>
(Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
CIP Internet Protocol
PPP Point to Point Protocol IPV6 Internet Protocol Version 6
IMIPV4V6 Dual PDN Stack <d_comp> a numeric parameter that controls PDP data compression (applicable for SNDCPonly) (refer
S 3GPP TS 44.065 [61])
0 off
1 on (manufacturer preferred compression)
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
125
2019-11-21
Smart Machine Smart Decision
2 V.42bis 3 V.44 Other values are reserved.
<h_comp> a numeric parameter that controls PDP header compression (refer 3GPP TS 44.065 [61] and 3GPP TS 25.323 [62])
0 off 1 on (manufacturer preferred compression) 2 RFC1144 (applicable for SNDCP only) 3 RFC2507
l 4 RFC3095 (applicable for PDCP only) tia Other values are reserved.
Examples
n AT+CGDSCONT?
+CGDSCONT: 2,1,0,0
e OK fid AT+CGDSCONT=2,1
OK AT+CGDSCONT=?
n +CGDSCONT: (1-24),(),"IP",(0-3),(0-4)
+CGDSCONT: (1-24),(),"PPP",(0-3),(0-4)
o +CGDSCONT: (1-24),(),"IPV6",(0-3),(0-4)
+CGDSCONT: (1-24),(),"IPV4V6",(0-3),(0-4)
C OK
8.6 AT+CGTFT Traffic Flow Template
m Description o This command allows the TE to specify a Packet Filter - PF for a Traffic Flow Template - TFT that
is used in the GGSN in UMTS/GPRS and Packet GW in EPS for routing of packets onto different QoS flows towards the TE. The concept is further described in the 3GPP TS 23.060 [47]. A TFT
Cconsists of from one and up to 16 Packet Filters, each identified by a unique <packet filter
identifier>. A Packet Filter also has an <evaluation precedence index> that is unique within all TFTs
IMassociated with all PDP contexts that are associated with the same PDP address. SIM PIN References
S YES 3GPP TS 27.007
File
Syntax
SIM7906_SIM7912 Series_AT Command Manual_V1.01
126
2019-11-21
Smart Machine Smart Decision
Test Command
Responses
AT+CGTFT=?
+CGTFT: <PDP_type>,(list of supported <packet filter
identifier>s),(list of supported <evaluation precedence
index>s),(list of supported <source address and subnet
mask>s),(list of supported <protocol number (ipv4) / next header
(ipv6)>s),(list of supported <destination port range>s),(list of
Read Command AT+CGTFT?
supported <source port range>s),(list of supported <ipsec security parameter index (spi)>s),(list of supported <type of service (tos) (ipv4) and mask / traffic class (ipv6) and mask>s),(list of supported <flow label (ipv6)>s)
l [<CR><LF>+CGTFT: <PDP_type>,(list of supported <packet filter
identifier>s),(list of supported <evaluation precedence
tia index>s),(list of supported <source address and subnet
mask>s),(list of supported <protocol number (ipv4) / next header (ipv6)>s),(list of supported <destination port range>s),(list of
n supported <source port range>s),(list of supported <ipsec security
parameter index (spi)>s),(list of supported <type of service (tos)
e (ipv4) and mask / traffic class (ipv6) and mask>s),(list of supported
<flow label (ipv6)>s)
fid [...]]
OK
n ERROR o Responses
+CGTFT: [<cid>,<packet filter identifier>,<evaluation precedence
Cindex>,<source address and subnet mask>,<protocol number (ipv4)
/ next header (ipv6)>,<destination port range>,<source port range>,<ipsec security parameter index (spi)>,<type of service (tos) (ipv4) and mask / traffic class (ipv6) and mask>,<flow label
m(ipv6)> [<CR><LF>+CGTFT: <cid>,<packet filter identifier>,<evaluation
o precedence index>,<source address and subnet mask>,<protocol number (ipv4) / next header (ipv6)>,<destination port range>,<source port range>,<ipsec security parameter index
C (spi)>,<type of service (tos) (ipv4) and mask / traffic class (ipv6)
and mask>,<flow label (ipv6)>
IM [...]]] S OK
ERROR
File
Write Command
Responses
SIM7906_SIM7912 Series_AT Command Manual_V1.01
127
2019-11-21
Smart Machine Smart Decision
AT+CGTFT=<cid>[,[<packe OK
t
filter
identifier>,<evaluation
ERROR
precedence index>[,<source
address and subnet
mask>[,<protocol number
(ipv4) / next header
(ipv6)>[,<destination port
range>[,<source
port
range>[,<ipsec
security
l parameter
index
(spi)>[,<type of service (tos)
tia (ipv4) and mask / traffic
class
(ipv6)
and
mask>[,<flow
label
n (ipv6)>]]]]]]]]]
Execute Command
Responses
e AT+CGTFT
OK
fid ERROR
Defined values
n <cid>
a numeric parameter which specifies a particular PDP context definition (see the AT+CGDCONT
o and AT+CGDSCONT commands).
<PDP_type>
C (Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
IP Internet Protocol
PPP Point to Point Protocol
IPV6 Internet Protocol Version 6
m IPV4V6 Dual PDN Stack
<packet filter identifier>
o a numeric parameter, value range from 1 to 16.
<evaluation precedence index>
Ca numeric parameter. The value range is from 0 to 255.
<source address and subnet mask>
string type The string is given as dot-separated numeric (0-255) parameters on the form:
IM"a1.a2.a3.a4.m1.m2.m3.m4" for IPv4 or "a1.a2.a3.a4.a5.a6.a7.a8.a9.a10.a11.a12.a13.a14.a15.a16.m1.m2.m3.m4.m5.m6.m7.m8.m9.m10.m1
S 1.m12.m13.m14.m15.m16", for IPv6. <protocol number (ipv4) / next header (ipv6)>
a numeric parameter, value range from 0 to 255.
<destination port range>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
128
2019-11-21
Smart Machine Smart Decision
string type. The string is given as dot-separated numeric (0-65535) parameters on the form "f.t". <source port range> string type. The string is given as dot-separated numeric (0-65535) parameters on the form "f.t". <ipsec security parameter index (spi)> numeric value in hexadecimal format. The value range is from 00000000 to FFFFFFFF. <type of service (tos) (ipv4) and mask / traffic class (ipv6) and mask> string type. The string is given as dot-separated numeric (0-255) parameters on the form "t.m". <flow label (ipv6)> numeric value in hexadecimal format. The value range is from 00000 to FFFFF. Valid for IPv6 only.
l Examples tia AT+CGTFT?
+CGTFT: 2,1,0,"74.125.71.99.255.255.255.255",0,0.0,0.0,0,0.0,0
OK
n AT+CGTFT=2,1,0,"74.125.71.99.255.255.255.255"
OK
e AT+CGTFT=?
+CGTFT:
fid "IP",(1-16),(0-255),,(0-255),(0-65535.0-65535),(0-65535.0-65535),(0-FFFFFFFF),(0-255.0-255),(
0-FFFFF) +CGTFT:
n "PPP",(1-16),(0-255),,(0-255),(0-65535.0-65535),(0-65535.0-65535),(0-FFFFFFFF),(0-255.0-255
),(0-FFFFF)
o +CGTFT: C "IPV6",(1-16),(0-255),,(0-255),(0-65535.0-65535),(0-65535.0-65535),(0-FFFFFFFF),(0-255.0-25
5),(0-FFFFF) +CGTFT: "IPV4V6",(1-16),(0-255),,(0-255),(0-65535.0-65535),(0-65535.0-65535),(0-FFFFFFFF),(0-255.0255),(0-FFFFF)
m OK o 8.7 AT+CGQREQ Quality of service profile (requested) C Description
This command allows the TE to specify a Quality of Service Profile that is used when the MT sends
IMan Activate PDP Context Request message to the network.. A special form of the set command (AT+CGQREQ=<cid>) causes the requested profile for context number <cid> to become
S undefined. SIM PIN References YES 3GPP TS 27.007
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
129
2019-11-21
Smart Machine Smart Decision
Syntax
Test Command
Responses
AT+CGQREQ=?
+CGQREQ: <PDP_type>, (list of supported <precedence>s), (list
of supported <delay>s), (list of supported <reliability>s) , (list of
supported <peak>s), (list of supported <mean>s) [<CR><LF>
+CGQREQ: <PDP_type>, (list of supported <precedence>s), (list
Read Command AT+CGQREQ?
Write Command AT+CGQREQ=<cid>[,<prec edence>[,<delay>[,<reliabilit y>[,<peak>[,<mean>]]]]] Execution Command AT+CGQREQ
of supported <delay>s), (list of supported <reliability>s) , (list of supported <peak>s), (list of supported <mean>s) [...]]
l OK
ERROR
tia Responses
+CGQREQ: [<cid>, <precedence >, <delay>, <reliability>, <peak>, <mean>[<CR><LF>
n +CGQREQ: <cid>, <precedence >, <delay>, <reliability.>, <peak>,
<mean>[...]]]
e OK
ERROR
fid Responses
OK
n ERROR o Responses COK
ERROR
Defined values
m <cid> o A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT
command). The range is from 1 to 24. <PDP_type>
C(Packet Data Protocol type) a string parameter which specifies the type of packet data protocol. IP Internet Protocol PPP Point to Point Protocol
IMIPV6 Internet Protocol Version 6 IPV4V6 Dual PDN Stack
S <precedence>
A numeric parameter which specifies the precedence class:
0 network subscribed value
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
130
2019-11-21
Smart Machine Smart Decision
1 high priority 2 normal priority 3 low priority <delay> A numeric parameter which specifies the delay class: 0 network subscribed value 1 delay class 1 2 delay class 2 3 delay class 3 4 delay class 4
l <reliability>
A numeric parameter which specifies the reliability class:
tia 0 network subscribed value
1 Non real-time traffic,error-sensitive application that cannot cope with data loss 2 Non real-time traffic,error-sensitive application that can cope with infrequent data loss
n 3 Non real-time traffic,error-sensitive application that can cope with data loss, GMM/SM,and SMS
e 4 Real-time traffic,error-sensitive application that can cope with data loss
5 Real-time traffic error non-sensitive application that can cope with data loss
fid <peak>
A numeric parameter which specifies the peak throughput class: 0 network subscribed value 1 Up to 1000 (8 kbit/s)
n 2 Up to 2000 (16 kbit/s) o 3 Up to 4000 (32 kbit/s)
4 Up to 8000 (64 kbit/s)
C 5 Up to 16000 (128 kbit/s)
6 Up to 32000 (256 kbit/s) 7 Up to 64000 (512 kbit/s) 8 Up to 128000 (1024 kbit/s)
m 9 Up to 256000 (2048 kbit/s)
<mean>
o A numeric parameter which specifies the mean throughput class: 0 network subscribed value C1 100 (~0.22 bit/s) 2 200 (~0.44 bit/s) 3 500 (~1.11 bit/s)
IM4 1000 (~2.2 bit/s) 5 2000 (~4.4 bit/s) 6 5000 (~11.1 bit/s)
S 7 10000 (~22 bit/s) 8 20000 (~44 bit/s) 9 50000 (~111 bit/s)
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
131
2019-11-21
Smart Machine Smart Decision
10 100000 (~0.22 kbit/s)
11 200000 (~0.44 kbit/s)
12 500000 (~1.11 kbit/s)
13 1000000 (~2.2 kbit/s)
14 2000000 (~4.4 kbit/s)
15 5000000 (~11.1 kbit/s)
16 10000000 (~22 kbit/s)
17 20000000 (~44 kbit/s)
18 50000000 (~111 kbit/s)
31 optimization
l Examples tia AT+CGQREQ?
+CGQREQ:
OK
n AT+CGQREQ=?
+CGQREQ: "IP",(0-3),(0-4),(0-5),(0-9),(0-18,31)
e +CGQREQ: "PPP",(0-3),(0-4),(0-5),(0-9),(0-18,31)
+CGQREQ: "IPV6",(0-3),(0-4),(0-5),(0-9),(0-18,31)
fid +CGQREQ: "IPV4V6",(0-3),(0-4),(0-5),(0-9),(0-18,31)
OK
on 8.8 AT+CGEQREQ 3G quality of service profile (requested) C Description
The test command returns values supported as a compound value. The read command returns the current settings for each defined context for which a QOS was explicitly specified.
m The write command allows the TE to specify a Quality of Service Profile for the context identified
by the context identification parameter <cid> which is used when the MT sends an Activate PDP
o Context Request message to the network.
A special form of the write command, AT+CGEQREQ=<cid> causes the requested profile for
Ccontext number <cid> to become undefined.
SIM PIN References
YES 3GPP TS 27.007
SIMSyntax
Test Command
Responses
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
132
2019-11-21
Smart Machine Smart Decision
AT+CGEQREQ=?
+CGEQREQ: <PDP_type>,(list of supported <Traffic class>s),(list
of supported <Maximum bitrate UL>s),(list of supported
<Maximum bitrate DL>s),(list of supported <Guaranteed bitrate
UL>s,(list of supported <Guaranteed bitrate DL>s),(list of
supported <Deliv ery order>s),(list of supported <Maximum SDU
size>s),(list of supported <SDU error ratio>s),(list of supported
<Residual bit error Ratio>s),(list of supported <Delivery of
Read Command AT+CGEQREQ?
erroneous SDUs>s),(list of Supported <Transfer delay>s),(list of supported <Traffic handling priority>s),(list of supported <Source statistics descriptor>s),(list of supported <Signaling indication
l flag>s)
OK
tia ERROR
Responses
+CGEQREQ: [<cid>,<Traffic class>,<Maximum bitrate UL>,
n <Maximum bitrate DL>,<Guaranteed bitrate UL>,<Guaranteed
bitrate DL>,<Delivery order>,<Maximum SDU size>,<SDU error
e ratio>,<Residual bit error ratio>,<Delivery of erroneous SDUs>, fid <Transfer Delay>,<Traffic handling priority>,<Source statistics
descriptor>,< Signaling indication flag>][<CR><LF>+CGEQREQ: <cid>,<Traffic class>,<Maximum bitrate UL>,<Maximum bitrate DL>,<Guaranteed bitrate UL>,<Guaranteed bitrate DL>,<Delivery
n order>,<Maximum SDU size>,<SDU error ratio>,<Residual bit
error ratio>,<Delivery of erroneous SDUs>,<Transfer Delay>,
o <Traffic handling priority>,<Source statistics descriptor>, C<Signaling indication flag> [...]]
OK
ERROR
Write Command
Responses
m AT+CGEQREQ=<cid>[,<Tr
affic class>[,<Maximum bit
o rate UL>[,<Maximum bitrat
e DL>[,<Guaranteed bitrate
CUL>[,<Guaranteed bitrate
DL>[,<Delivery order>[,<M aximum SDU size>[,<SDU
IMerror ratio>[,<Residual bit error ratio>[,<Delivery of
S erroneous SDUs>[,<Transfe
OK ERROR +CME ERROR: <err>
r delay>[,<Traffic handling
priority>[,<Source statistic
s descriptor>[,<Signaling in
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
133
2019-11-21
Smart Machine Smart Decision
dication flag>]]]]]]]]]]]]]]
Execution Command
Responses
AT+CGEQREQ
OK
ERROR
Defined values
l <cid> tia Parameter specifies a particular PDP context definition. The parameter is also used in other PDP
context-related commands. The range is from 1 to 24. <Traffic class>
0 conversational
n 1 streaming
2 interactive
e 3 background fid 4 subscribed value
<Maximum bitrate UL> This parameter indicates the maximum number of kbits/s delivered to UMTS(up-link traffic)at a SAP. As an example a bitrate of 32kbit/s would be specified as 32(e.g. AT+CGEQREQ=...,32,...).
n The range is from 0 to 11520. The default value is 0. If the parameter is set to '0' the subscribed
value will be requested.
o <Maximum bitrate DL> C This parameter indicates the maximum number of kbits/s delivered to UMTS(down-link traffic)at a
SAP.As an example a bitrate of 32kbit/s would be specified as 32(e.g. AT+CGEQREQ=...,32,...). The range is from 0 to 42200. The default value is 0. If the parameter is set to '0' the subscribed value will be requested. <Guaranteed bitrate UL>
m This parameter indicates the guaranteed number of kbit/s delivered to UMTS(up-link traffic)at a
SAP(provided that there is data to deliver).As an example a bitrate of 32kbit/s would be specified as
o 32(e.g.AT+CGEQREQ=...,32,...).
The range is from 0 to 11520. The default value is 0. If the parameter is set to '0' the subscribed
Cvalue will be requested.
<Guaranteed bitrate DL> This parameter indicates the guaranteed number of kbit/s delivered to UMTS(down-link traffic)at a
IMSAP(provided that there is data to deliver).As an example a bitrate of 32kbit/s would be specified as 32(e.g.AT+CGEQREQ=...,32,...).
S The range is from 0 to 42200. The default value is 0. If the parameter is set to '0' the subscribed value will be requested. <Delivery order>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
134
2019-11-21
Smart Machine Smart Decision
This parameter indicates whether the UMTS bearer shall provide in-sequence SDU delivery or not. 0 no 1 yes 2 subscribed value
<Maximum SDU size> This parameter indicates the maximum allowed SDU size in octets. The range is from 0 to 1520. The default value is 0. If the parameter is set to '0' the subscribed value will be requested. <SDU error ratio> This parameter indicates the target value for the fraction of SDUs lost or detected as erroneous.SDU
l error ratio is defined only for conforming traffic.As an example a target SDU error ratio of 5*10-3
would be specified as "5E3"(e.g.AT+CGEQREQ=..,"5E3",...).
tia "0E0" subscribed value
"1E2" "7E3"
n "1E3"
"1E4"
e "1E5"
"1E6"
fid "1E1"
<Residual bit error ratio> This parameter indicates the target value for the undetected bit error ratio in the delivered SDUs. If no error detection is requested,Residual bit error ratio indicates the bit error ratio in the delivered
n SDUs.As an example a target residual bit error ratio of 5*10-3 would be specified as "5E3"(e.g. o AT+CGEQREQ=...,"5E3",..).
"0E0" subscribed value
C "5E2"
"1E2" "5E3" "4E3"
m "1E3"
"1E4"
o "1E5"
"1E6"
C"6E8"
<Delivery of erroneous SDUs> This parameter indicates whether SDUs detected as erroneous shall be delivered or not.
IM0 no 1 yes 2 no detect
S 3 subscribed value <Transfer delay> This parameter indicates the targeted time between request to transfer an SDU at one SAP to its
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
135
2019-11-21
Smart Machine Smart Decision
delivery at the other SAP,in milliseconds. The range is 0 and from 100 to 4000. The default value is 0. If the parameter is set to '0' the subscribed value will be requested. <Traffic handling priority> This parameter specifies the relative importance for handling of all SDUs belonging to the UMTS Bearer compared to the SDUs of the other bearers. The range is from 0 to 3. The default value is 0. If the parameter is set to '0' the subscribed value will be requested. <Source statistics descriptor> This parameter indicates profile parameter that Source statistics descriptor for requested UMTS
l QoS
The range is from 0 to 1. The default value is 0. If the parameter is set to '0' the subscribed value
tia will be requested.
<Signaling indication flag> This parameter indicates Signaling flag.
n The range is from 0 to 1 The default value is 0. If the parameter is set to '0' the subscribed value will
be requested.
e <PDP_type>
(Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
fid IP Internet Protocol
PPP Point to Point Protocol IPV6 Internet Protocol Version 6 IPV4V6 Dual PDN Stack
on Examples C AT+CGEQREQ?
+CGEQREQ: OK AT+CGEQREQ=? +CGEQREQ: "IP",(0-4),(0-11520),(0-42200),(0-11520),(0-42200),(0-2),(0-1520),("0E0","1E
m 1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","1E
4","1E5","1E6","6E8"),(0-3),(0,100-4000),(0-3) ,(0-1),(0-1)
o +CGEQREQ: "PPP",(0-4),(0-11520),(0-42200),(0-11520),(0-42200),(0-2),(0-1520),("0E0","1
E1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","1
CE4","1E5","1E6","6E8"),(0-3),(0,100-4000),(0-3) ,(0-1),(0-1)
+CGEQREQ: "IPV6",(0-4),(0-11520),(0-42200),(0-11520),(0-42200),(0-2),(0-1520),("0E0"," 1E1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","
IM1E4","1E5","1E6","6E8"),(0-3),(0,100-4000),(0-3) ,(0-1),(0-1) +CGEQREQ:"IPV4V6",(0-4),(0-11520),(0-42200),(0-11520),(0-42200),(0-2),(0-1520),("0E0","1E1
S ","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","1E4","1E5","1 E6","6E8"),(0-3),(0,100-4000),(0-3),(0-1),(0-1)
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
136
2019-11-21
Smart Machine Smart Decision
OK
8.9 AT+CGQMIN Quality of service profile (minimum acceptable)
Description
This command allows the TE to specify a minimum acceptable profile which is checked by the MT
against the negotiated profile returned in the Activate PDP Context Accept message.A special form of the set command,AT+CGQMIN=<cid> causes the minimum acceptable profile for context number <cid> to become undefined.
l SIM PIN References YES 3GPP TS 27.007
tia Syntax n Test Command
AT+CGQMIN=?
onfide Read Command C AT+CGQMIN?
Responses +CGQMIN: <PDP_type>, (list of supported <precedence>s), (list of supported <delay>s), (list of supported <reliability>s) , (list of supported <peak>s), (list of supported <mean>s) [<CR><LF> +CGQMIN: <PDP_type>, (list of supported <precedence>s), (list of supported <delay>s), (list of supported <reliability>s) , (list of supported <peak>s), (list of supported <mean>s)[...]] OK ERROR
Responses +CGQMIN: [<cid>, <precedence >, <delay>, <reliability>,
<peak>, <mean>[<CR><LF>
+CGQMIN: <cid>, <precedence >, <delay>, <reliability.>, <peak>, <mean> [...]]]
mOK o ERROR
Write Command
CAT+CGQMIN=<cid>[,<prec
edence>[,<delay>[,<reliabilit y>[,<peak> [,<mean>]]]]]
Responses OK
ERROR
IMExecution Command AT+CGQMIN
Responses OK
S ERROR
File
Defined values
SIM7906_SIM7912 Series_AT Command Manual_V1.01
137
2019-11-21
Smart Machine Smart Decision
<cid> A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT command). The range is from 1 to 24. <PDP_type> (Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
IP Internet Protocol PPP Point to Point Protocol IPV6 Internet Protocol Version 6 IPV4V6 Dual PDN Stack <precedence>
l A numeric parameter which specifies the precedence class: 0 network subscribed value tia 1 high priority 2 normal priority 3 low priority
n <delay>
A numeric parameter which specifies the delay class:
e 0 network subscribed value
1 delay class 1
fid 2 delay class 2
3 delay class 3 4 delay class 4 <reliability>
n A numeric parameter which specifies the reliability class: o 0 network subscribed value
1 Non real-time traffic,error-sensitive application that cannot cope with data loss
C 2 Non real-time traffic,error-sensitive application that can cope with infrequent data loss
3 Non real-time traffic,error-sensitive application that can cope with data loss, GMM/SM,and SMS
4 Real-time traffic,error-sensitive application that can cope with data loss
m 5 Real-time traffic error non-sensitive application that can cope with data loss
<peak>
o A numeric parameter which specifies the peak throughput class: 0 network subscribed value C1 Up to 1000 (8 kbit/s) 2 Up to 2000 (16 kbit/s) 3 Up to 4000 (32 kbit/s)
IM4 Up to 8000 (64 kbit/s) 5 Up to 16000 (128 kbit/s) 6 Up to 32000 (256 kbit/s)
S 7 Up to 64000 (512 kbit/s) 8 Up to 128000 (1024 kbit/s) 9 Up to 256000 (2048 kbit/s)
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
138
2019-11-21
Smart Machine Smart Decision
<mean> A numeric parameter which specifies the mean throughput class:
0 network subscribed value 1 100 (~0.22 bit/s) 2 200 (~0.44 bit/s) 3 500 (~1.11 bit/s) 4 1000 (~2.2 bit/s) 5 2000 (~4.4 bit/s) 6 5000 (~11.1 bit/s) 7 10000 (~22 bit/s)
l 8 20000 (~44 bit/s)
9 50000 (~111 bit/s)
tia 10 100000 (~0.22 kbit/s)
11 200000 (~0.44 kbit/s) 12 500000 (~1.11 kbit/s)
n 13 1000000 (~2.2 kbit/s)
14 2000000 (~4.4 kbit/s)
e 15 5000000 (~11.1 kbit/s)
16 10000000 (~22 kbit/s)
fid 17 20000000 (~44 kbit/s)
18 50000000 (~111 kbit/s) 31 optimization
n Examples o AT+CGQMIN? C +CGQMIN:
OK AT+CGQMIN=? +CGQMIN: "IP",(0-3),(0-4),(0-5),(0-9),(0-18,31) +CGQMIN: "PPP",(0-3),(0-4),(0-5),(0-9),(0-18,31)
m +CGQMIN: "IPV6",(0-3),(0-4),(0-5),(0-9),(0-18,31)
+CGQMIN: "IPV4V6",(0-3),(0-4),(0-5),(0-9),(0-18,31)
o OK C 8.10 AT+CGEQMIN 3G quality of service profile (minimum acceptable) IMDescription S The test command returns values supported as a compound value.
The read command returns the current settings for each defined context for which a QOS was explicitly specified. The write command allow the TE to specify a Quallity of Service Profile for the context identified
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
139
2019-11-21
Smart Machine Smart Decision
by the context identification parameter <cid> which is checked by the MT against the negotiated profile returned in the Activate/Modify PDP Context Accept message. A special form of the write command, AT+CGEQMIN=<cid> causes the requested for context number <cid> to become undefined. SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command AT+CGEQMIN=?
Read Command AT+CGEQMIN?
Responses
l +CGEQMIN: <PDP_type>,(list of supported <Traffic class>s),(list
of supported <Maximum bitrate UL>s),(list of supported
tia <Maximum bitrate DL>s),(list of supported <Guaranteed bitrate
UL>s,(list of supported <Guaranteed bitrate DL>s),(list of
supported <Deliv ery order>s),(list of supported <Maximum SDU
n size>s),(list of supported <SDU error ratio>s),(list of supported
<Residual bit error Ratio>s),(list of supported <Delivery of
e erroneous SDUs>s),(list of Supported <Transfer delay>s),(list of
supported <Traffic handling priority>s),(list of supported <Source
fid statistics descriptor>s),(list of supported <Signaling indication
flag>s)
OK
n ERROR
Responses
o +CGEQMIN: [<cid>,<Traffic class>,<Maximum bitrate UL>, C<Maximum bitrate DL>,<Guaranteed bitrate UL>,<Guaranteed
SIMCom Write Command
bitrate DL>,<Delivery order>,<Maximum SDU size>,<SDU error ratio>,<Residual bit error ratio>,<Delivery of erroneous SDUs>, <Transfer Delay>,<Traffic handling priority>,<Source statistics descriptor>,< Signaling indication flag>][<CR><LF>+CGEQMIN: <cid>,<Traffic class>,<Maximum bitrate UL>,<Maximum bitrate DL>,<Guaranteed bitrate UL>,<Guaranteed bitrate DL>,<Delivery order>,<Maximum SDU size>,<SDU error ratio>,<Residual bit error ratio>,<Delivery of erroneous SDUs>,<Transfer Delay>, <Traffic handling priority>,<Source statistics descriptor>, <Signaling indication flag>[...]] OK
ERROR
Responses
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
140
2019-11-21
Smart Machine Smart Decision
AT+CGEQMIN=<cid>[,<Tr OK
affic class>[,<Maximum bit
rate UL>[,<Maximum bitrat
e DL>[,<Guaranteed bitrate
UL>[,<Guaranteed bitrate ERROR
DL>[,<Delivery order>[,<M
aximum SDU size>[,<SDU
error ratio>[,<Residual bit error ratio>[,<Delivery of erroneous SDUs>[,<Transfe
l r delay>[,<Traffic handling priority>[,<Source statistic
tia s descriptor>[,<Signaling in
dication flag>]]]]]]]]]]]]]]
+CME ERROR: <err>
Execution Command
Responses
en AT+CGEQMIN
OK ERROR
fid Defined values <cid> Parameter specifies a particular PDP context definition. The parameter is also used in other PDP n context-related commands. The range is from 1 to 24. <Traffic class> o 0 conversational C 1 streaming
2 interactive
3 background
4 subscribed value
<Maximum bitrate UL>
m This parameter indicates the maximum number of kbits/s delivered to UMTS(up-link traffic)at a
SAP.As an example a bitrate of 32kbit/s would be specified as 32(e.g. AT+CGEQMIN=...,32,...).
o The range is from 0 to 11520. The default value is 0. If the parameter is set to '0' the subscribed
value will be requested.
C<Maximum bitrate DL>
This parameter indicates the maximum number of kbits/s delivered to UMTS(down-link traffic)at a
SAP.As an example a bitrate of 32kbit/s would be specified as 32(e.g. AT+CGEQMIN=...,32,...).
IMThe range is from 0 to 42200. The default value is 0. If the parameter is set to '0' the subscribed value will be requested.
S <Guaranteed bitrate UL>
This parameter indicates the guaranteed number of kbit/s delivered to UMTS(up-link traffic)at a
SAP(provided that there is data to deliver).As an example a bitrate of 32kbit/s would be specified as
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
141
2019-11-21
Smart Machine Smart Decision
32(e.g.AT+CGEQMIN=...,32,...). The range is from 0 to 11520. The default value is 0. If the parameter is set to '0' the subscribed value will be requested. <Guaranteed bitrate DL> This parameter indicates the guaranteed number of kbit/s delivered to UMTS(down-link traffic)at a SAP(provided that there is data to deliver).As an example a bitrate of 32kbit/s would be specified as 32(e.g.AT+CGEQMIN=...,32,...). The range is from 0 to 42200. The default value is 0. If the parameter is set to '0' the subscribed value will be requested. <Delivery order>
l This parameter indicates whether the UMTS bearer shall provide in-sequence SDU delivery or not. 0 no tia 1 yes 2 subscribed value <Maximum SDU size>
n This parameter indicates the maximum allowed SDU size inoctets.
The range is from 0 to 1520. The default value is 0. If the parameter is set to '0' the subscribed value
e will be requested.
<SDU error ratio>
fid This parameter indicates the target value for the fraction of SDUs lost or detected as erroneous.SDU
error ratio is defined only for conforming traffic.As an example a target SDU error ratio of 5*10-3 would be specified as "5E3"(e.g.AT+CGEQMIN=..,"5E3",...).
"0E0" subscribed value
n "1E2" o "7E3"
"1E3"
C "1E4"
"1E5" "1E6" "1E1"
m <Residual bit error ratio>
This parameter indicates the target value for the undetected bit error ratio in the delivered SDUs. If
o no error detection is requested,Residual bit error ratio indicates the bit error ratio in the delivered
SDUs.As an example a target residual bit error ratio of 5*10-3 would be specified as "5E3"(e.g.
CAT+CGEQMIN=...,"5E3",..). "0E0" subscribed value "5E2"
IM"1E2" "5E3"
S "4E3" "1E3" "1E4" "1E5"
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
142
2019-11-21
Smart Machine Smart Decision
"1E6" "6E8" <Delivery of erroneous SDUs> This parameter indicates whether SDUs detected as erroneous shall be delivered or not. 0 no 1 yes 2 no detect 3 subscribed value <Transfer delay> This parameter indicates the targeted time between request to transfer an SDU at one SAP to its
l delivery at the other SAP,in milliseconds.
The range is 0 and from 100 to 4000. The default value is 0. If the parameter is set to '0' the
tia subscribed value will be requested.
<Traffic handling priority> This parameter specifies the relative importance for handling of all SDUs belonging to the UMTS
n Bearer compared to the SDUs of the other bearers.
The range is from 0 to 3. The default value is 0. If the parameter is set to '0' the subscribed value
e will be requested.
<Source statistics descriptor>
fid This parameter indicates profile parameter that Source statistics descriptor for requested UMTS
QoS The range is from 0 to 1. The default value is 0. If the parameter is set to '0' the subscribed value will be requested.
n <Signaling indication flag> o This parameter indicates Signaling flag.
The range is from 0 to 1 The default value is 0. If the parameter is set to '0' the subscribed value will
C be requested.
<PDP_type> (Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
IP Internet Protocol
m PPP Point to Point Protocol
IPV6 Internet Protocol Version 6
o IPV4V6 Dual PDN Stack C Examples
AT+CGEQMIN? +CGEQMIN:
IMOK AT+CGEQMIN=?
S +CGEQMIN: "IP",(0-4),(0-11520),(0-42200),(0-115200),(0-42200),(0-2),(0-1520),("0E0","1E 1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","1E 4","1E5","1E6","6E8"),(0-3),(0,100-4000),(0-3) ,(0-1),(0-1)
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
143
2019-11-21
Smart Machine Smart Decision
+CGEQMIN: "PPP",(0-4),(0-11520),(0-42200),(0-115200),(0-42200),(0-2),(0-1520),("0E0","1
E1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","1
E4","1E5","1E6","6E8"),(0-3),(0,100-4000),(0-3) ,(0-1),(0-1)
+CGEQMIN: "IPV6",(0-4),(0-11520),(0-42200),(0-115200),(0-42200),(0-2),(0-1520),("0E0","
1E1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","
1E4","1E5","1E6","6E8"),(0-3),(0,100-4000),(0-3) ,(0-1),(0-1)
+CGEQMIN:"IPV4V6",(0-4),(0-11520),(0-42200),(0-115200),(0-42200),(0-2),(0-1520),("0E0","1E
1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","1E4","1E5"," 1E6","6E8"),(0-3),(0,100-4000),(0-3),(0-1),(0-1)
l OK
tia 8.11 AT+CGDATA Enter data state
Description
n The command causes the MT to perform whatever actions are necessary to establish e communication between the TE and the network using one or more Packet Domain PDP types. This
may include performing a PS attach and one or more PDP context activations.
fid SIM PIN References YES 3GPP TS 27.007
n Syntax o Test Command C AT+CGDATA=?
Responses +CGDATA: (list of supported <L2P>s) OK
ERROR
Write Command AT+CGDATA=[<L2P>,[<ci
Com d>]]
Responses CONNECT [<text>] NO CARRIER OK ERROR +CME ERROR: <err>
IMDefined values <L2P>
S A string parameter that indicates the layer 2 protocol to be used between the TE and MT.
PPP Point-to-point protocol for a PDP such as IP
<text>
CONNECT result code string; the string formats please refer ATX/AT\V/AT&E command.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
144
2019-11-21
Smart Machine Smart Decision
<cid> A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT command).
1...24
Examples
AT+CGDATA=?
+CGDATA: ("PPP") OK AT+CGDATA="PPP",1
l CONNECT 115200
tia 8.12 AT+CGPADDR Show PDP address
n Description The write command returns a list of PDP addresses for the specified context identifiers. e SIM PIN References fid YES 3GPP TS 27.007
Syntax
n Test Command Co AT+CGPADDR=?
Responses [+CGPADDR: (list of defined <cid>s)] OK ERROR
Write Command AT+CGPADDR= <cid>[,<cid>[,...]]
SIMCom Execution Command
Responses [+CGPADDR:<cid>,<PDP_addr>[<CR><LF> +CGPADDR: <cid>,<PDP_addr>[...]]] OK SIM card supports IPV4V6 type and the PDP_type of the command "at+cgdcont" defined is ipv4v6 : [+CGPADDR: <cid>,<PDP_addr_IPV4>,<PDP_addr_IPV6>] +CGPADDR: <cid>,<PDP_addr_IPV4>,<PDP_addr_IPV6> [...]]] OK ERROR +CME ERROR: <err> Responses
AT+CGPADDR
[+CGPADDR: <cid>,<PDP_addr>]
+CGPADDR: <cid>,<PDP_addr>[...]]]
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
145
2019-11-21
Smart Machine Smart Decision
SIM card supports IPV4V6 type and the PDP_type of the command "at+cgdcont" defined is ipv4v6 : [+CGPADDR: <cid>,<PDP_addr_IPV4>,<PDP_addr_IPV6>] +CGPADDR: <cid>,<PDP_addr_IPV4>,<PDP_addr_IPV6> [...]]] OK ERROR +CME ERROR: <err>
Defined values
l <cid>
A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT
tia command). If no <cid> is specified, the addresses for all defined contexts are returned. 1...24 <PDP_addr>
n A string that identifies the MT in the address space applicable to the PDP. The address may be static
or dynamic. For a static address, it will be the one set by the AT+CGDCONT command when the
e context was defined. For a dynamic address it will be the one assigned during the last PDP context
activation that used the context definition referred to by <cid>. <PDP_addr> is omitted if none is
fid available.
<PDP_addr_IPV4> A string parameter that identifies the MT in the address space applicable to the PDP.
n <PDP_addr_IPV6>
A string parameter that identifies the MT in the address space applicable to the PDP when the
o sim_card supports ipv6. The pdp type must be set to "ipv6" or "ipv4v6" by the AT+CGDCONT C command.
Examples
AT+CGPADDR =? +CGPADDR: (1)
m OK o AT+CGPADDR=1
+CGDCONT: 1,"IPV4V6","","0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0",0,0,0,0
COK
AT+CGPADDR
IM+CGPADDR: 1,10.195.1.140,36.9.136.148.128.48.134.218.173.205.47.44.88.174.123.200 +CGPADDR: 2,10.195.34.92,36.9.136.148.128.48.146.115.92.140.135.230.248.131.5.90
S +CGPADDR: 3,0.0.0.0,0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0 OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
146
2019-11-21
Smart Machine Smart Decision
8.13 AT+CGCLASS GPRS mobile station class
Description
This command is used to set the MT to operate according to the specified GPRS mobile class.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command AT+CGCLASS=?
Read Command AT+CGCLASS?
Write Command AT+CGCLASS=<class>
Execution Command AT+CGCLASS
l Responses
+CGCLASS: (list of supported <class>s)
tia OK
ERROR Responses
n +CGCLASS: <class> e OK
ERROR
fid Responses
OK ERROR
n +CME ERROR: <err>
Responses
o Set default value: COK
ERROR
Defined values
m <class>
A string parameter which indicates the GPRS mobile class (in descending order of functionality)
o A class A (highest) C Examples
AT+CGCLASS=?
IM+CGCLASS: ("A") OK
S AT+CGCLASS? +CGCLASS: "A"
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
147
2019-11-21
Smart Machine Smart Decision
8.14 AT+CGEREP GPRS event reporting
Description
The write command enables or disables sending of unsolicited result codes, "+CGEV" from MT to
TE in the case of certain events occurring in the Packet Domain MT or the network. <mode>
controls the processing of unsolicited result codes specified within this command. <bfr> controls
the effect on buffered codes when <mode> 1 or 2 is entered. If a setting is not supported by the MT, ERROR or +CME ERROR: is returned. Read command returns the current <mode> and buffer settings.
l Test command returns the modes and buffer settings supported by the MT as compound values.
SIM PIN References
tia YES 3GPP TS 27.007
Syntax
n Test Command e AT+CGEREP=? fid Read Command
AT+CGEREP?
on Write Command C AT+CGEREP=
Responses +CGEREP: (list of supported <mode>s),(list of supported <bfr>s) OK ERROR
Responses +CGEREP: <mode>,<bfr> OK ERROR
Responses OK
<mode>[,<bfr>] Execution Command
m AT+CGEREP
ERROR
+CME ERROR: <err> Responses OK ERROR
o Defined values
C<mode>
0
SIM1
buffer unsolicited result codes in the MT; if MT result code buffer is full, the oldest ones can be discarded. No codes are forwarded to the TE. discard unsolicited result codes when MT-TE link is reserved (e.g. in on-line data mode); otherwise forward them directly to the TE.
2 buffer unsolicited result codes in the MT when MT-TE link is reserved (e.g. in on-line
data mode) and flush them to the TE when MT-TE link becomes available; otherwise
forward them directly to the TE.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
148
2019-11-21
Smart Machine Smart Decision
<bfr> 0 MT buffer of unsolicited result codes defined within this command is cleared when <mode> 1 or 2 is entered. 1 MT buffer of unsolicited result codes defined within this command is flushed to the TE when <mode> 1 or 2 is entered (OK response shall be given before flushing the codes).
The following unsolicited result codes and the corresponding events are defined: +CGEV: REJECT <PDP_type>, <PDP_addr> A network request for PDP context activation occurred when the MT was unable to report it to the TE with a +CRING unsolicited result code and was automatically rejected.
l +CGEV: NW REACT <PDP_type>, <PDP_addr>, [<cid>] The network has requested a context reactivation. The <cid> that was used to reactivate tia the context is provided if known to the MT. +CGEV: NW DEACT <PDP_type>, <PDP_addr>, [<cid>]
The network has forced a context deactivation. The <cid> that was used to activate the
n context is provided if known to the MT.
+CGEV: ME DEACT <PDP_type>, <PDP_addr>, [<cid>]
e The mobile equipment has forced a context deactivation. The <cid> that was used to
activate the context is provided if known to the MT.
fid +CGEV: NW DETACH The network has forced a Packet Domain detach. This implies that all active contexts have been deactivated. These are not reported separately. +CGEV: ME DETACH
n The mobile equipment has forced a Packet Domain detach. This implies that all active o contexts have been deactivated. These are not reported separately.
+CGEV: NW CLASS <class>
C The network has forced a change of MS class. The highest available class is reported
(see AT+CGCLASS). +CGEV: ME CLASS <class>
The mobile equipment has forced a change of MS class. The highest available class is
m reported (see AT+CGCLASS). o Examples
AT+CGEREP=?
C+CGEREP: (0-2),(0-1)
OK AT+CGEREP?
IM+CGEREP: 0,0 S OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
149
2019-11-21
Smart Machine Smart Decision
8.15 AT+CGAUTH Set type of authentication for PDP-IP connections of
GPRS
Description
This command is used to set type of authentication for PDP-IP connections of GPRS.
SIM PIN References YES Vendor
Syntax
Test Command AT+CGAUTH=?
Read Command AT+CGAUTH?
Write Command
tial Responses
+CGAUTH:(range of supported <cid>s),(list of supported <auth_-
type> s),127,127
n OK e ERROR
+CME ERROR: <err>
fid Responses
+CGAUTH:[ <cid>,<auth_type>[,<user>,<passwd>]]<CR><LF>
...
n OK
ERROR
o +CME ERROR: <err> CResponses
AT+CGAUTH=<cid>[,<aut h_type>[,<passwd>[,<user>] ]]
m Execution Command Co AT+CGAUTH
OK
ERROR Responses OK ERROR +CME ERROR: <err>
Defined values
IM<cid> Parameter specifies a particular PDP context definition. This is also used in other PDP
S context-related commands.
1...24
<auth_type>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
150
2019-11-21
Smart Machine Smart Decision
Indicate the type of authentication to be used for the specified context. If CHAP is selected another parameter <passwd> needs to be specified. If PAP is selected two additional parameters <passwd> and <user> need to specified.
0 none 1 PAP 2 CHAP 3 PAP or CHAP <passwd> Parameter specifies the password used for authentication. <user>
l Parameter specifies the user name used for authentication. tia Examples
AT+CGAUTH=? +CGAUTH: (1-24),(0-3),127,127
n OK e AT+CGAUTH=1,1,"123","SIMCOM" Confid OK SIMCom
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
151
2019-11-21
Smart Machine Smart Decision
9 AT Commands for SIM Application Toolkit
9.1 AT+STIN SAT Indication
Description
Every time the SIM Application issues a Proactive Command, via the ME, the TA will receive an indication. This indicates the type of Proactive Command issued.
l AT+STGI must then be used by the TA to request the parameters of the Proactive Command from tia the ME. Upon receiving the +STGI response from the ME, the TA must send AT+STGR to confirm
the execution of the Proactive Command and provide any required user response, e.g. a selected menu item. SIM PIN References
n YES Vendor
e Syntax fid Test Command
AT+STIN=?
n Read Command Co AT+STIN?
Responses OK Responses +STIN: <cmd_id>
OK
Unsolicited Result Codes
+STIN: <cmd_id>
m Proactive Command notification 21 display text o 22 get inkey 23 get input 24 select item
C+STIN: 25
Notification that SIM Application has returned to main menu. If user doesn't do any action in 2
IMminutes, application will return to main menu automatically. S Defined values
<cmd_id> 21 display text 22 get inkey
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
152
2019-11-21
Smart Machine Smart Decision
23 get input 24 select item 25 set up menu 81 session end (pdu mode only)
0 none command
Examples
AT+STIN? +STIN: 24 OK
tial 9.2 AT+STGI Get SAT information Description n Regularly this command is used upon receipt of an URC "+STIN" to request the parameters of the Proactive Command. Then the TA is expected to acknowledge the AT+STGI response with e AT+STGR to confirm that the Proactive Command has been executed. AT+STGR will also provide any user information, e.g. a selected menu item. The Proactive Command type value specifies to fid which "+STIN" the command is related. NOTE: Please check the format referred to AT+STKFMT SIM PIN References n YES Vendor Co Syntax
Test Command
Responses
AT+STGI=? Write Command
m AT+STGI=<cmd_id> SIMCo AT+STGI=<cmd_id>
OK
Responses PDU format +STGI: <cmd_id>,<tag>,<pdu_len>,<pdu_value> OK NOT PDU format, listed below: If <cmd_id>=10: OK If <cmd_id>=21: +STGI:21,<prio>,<clear_mode>,<text_len>,<text> OK
If <cmd_id>=22:
+STGI: 22,< rsp_format>,< help>,<text_len>,<text>
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
153
2019-11-21
Smart Machine Smart Decision
If <cmd_id>=23: +STGI:23,<rsp_format>,<max_len>,<min_len>,<help>,<show>,<t ext_len>,<text> OK
If <cmd_id>=24: +STGI:24,<help>,<softkey>,<present>,<title_len>,<title>,<item_n um> +STGI:24,<item_id>,<item_len>,<item_data> [...] OK
l If <cmd_id>=25: tia +STGI:25,<help>,<softkey>,<title_len>,<title>,<item_num>
+STGI:25,<item_id>,<item_len>,<item_data> [...] OK
en Defined values <cmd_id> fid 21 display text 22 get inkey 23 get input n 24 select item 25 set up menu o <prio> Priority of display text C 0 Normal priority 1 High priority <clear_mode> 0 Clear after a delay m 1 Clear by user <text_len> o Length of text <rsp_format> C0 SMS default alphabet 1 YES or NO 2 numerical only
IM3 UCS2 <help>
S 0 Help unavailable 1 Help available <max_len> Maximum length of input
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
154
2019-11-21
Smart Machine Smart Decision
<min_len> Minimum length of input
<show> 0 Hide input text 1 Display input text
<softkey> 0 No softkey preferred 1 Softkey preferred
<present> Menu presentation format available for select item
l 0 Presentation not specified
1 Data value presentation
tia 2 Navigation presentation
<title_len> Length of title
n <item_num> Number of items in the menu
e <item_id> Identifier of item
fid <item_len> Length of item <title>
Title in ucs2 format
n <item_data> o Content of the item in ucs2 format
<text>
C Text in ucs2 format.
<tag> Not used now.
<pdu_len>
m Integer type, pdu string length
<pdu_value>
o String type, the pdu string. C Examples
AT+STGI=25 (NOT PDU format) +STGI:25,0,0,10,"795E5DDE884C59295730",15
IM+STGI:25,1,8,"8F7B677E95EE5019" +STGI:25,2,8,"77ED4FE17FA453D1"
S +STGI:25,3,8,"4F1860E05FEB8BAF" +STGI:25,4,8,"4E1A52A17CBE9009" +STGI:25,5,8,"8D448D3963A88350"
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
155
2019-11-21
Smart Machine Smart Decision
+STGI:25,6,8,"81EA52A9670D52A1" +STGI:25,7,8,"8F7B677E5F6994C3" +STGI:25,8,8,"8BED97F367425FD7" +STGI:25,9,10,"97F34E506392884C699C" +STGI:25,10,8,"65B095FB59296C14" +STGI:25,11,8,"94C358F056FE7247" +STGI:25,12,8,"804A59294EA453CB" +STGI:25,13,8,"5F005FC34F1195F2" +STGI:25,14,8,"751F6D3B5E388BC6" +STGI:25,21,12,"00530049004D53614FE1606F"
l OK
AT+STGI=24 (PDU format)
tia +STGI:24,0,48,"D02E81030124008202818285098070ED70B963A883508F0A018053057F574E0
78C618F0C02809177917777ED6D88606F" OK
n 9.3 AT+STGR SAT respond fide Description
The TA is expected to acknowledge the AT+STGI response with AT+STGR to confirm that the Proactive Command has been executed. AT+STGR will also provide any user information, e.g. a selected menu item.
n NOTE: Please check the format referred to AT+STKFMT o SIM PIN References C YES Vendor
Syntax
Test Command
m AT+STGR=?
Write Command
o AT+STGR=<cmd_id>[,<dat
a>]
CAT+STGR=<pdu_len>,<pdu
_value>
Responses OK Responses NOT PDU format OK PDU format OK
IMDefined values S <cmd_id>
22 get inkey
23 get input
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
156
2019-11-21
Smart Machine Smart Decision
24 select item
25 set up menu
81 session end
83 session end by user
84 go backward
<data>
If <cmd_id>=22:
Input a character If <cmd_id>=23:
Input a string.
l If <rsp_format> is YES or NO, input of a character in case of ANSI character set requests one
byte, e.g. "Y".
tia If <rsp_format> is numerical only, input the characters in decimal number, e.g. "123"
If <rsp_faomat> is UCS2, requests a 4 byte string, e.g. "0031" <rsp_faomat> refer to the response by AT+STGI=23
n If <cmd_id>=24: Input the identifier of the item selected by user
e If <cmd_id>=25: Input the identifier of the item selected by user
fid If <cmd_id>=83: <data> ignore Note: It could return main menu during Proactive Command id is not 22 or 23 If <cmd_id>= 84:
n <data> ignore o <pdu_len>
Integer type, pdu string length
C <pdu_value>
String type, the pdu string.
Examples
m AT+STGR=25,1 (NOT PDU format)
OK
o +STIN: 24
AT+STGR=30,"810301240002028281830100900101"
COK
(PDU format)
IM9.4 AT+STK STK switch
S Description
This command is used to disable or enable the STK function. If the argument is 1, it is enabled.
While if the argument is 0, it is disabled.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
157
2019-11-21
Smart Machine Smart Decision
SIM PIN References NO Vendor
Syntax
Test Command
Responses
AT+STK=?
Read Command AT+STK?
Write Command AT+STK=<value>
Execution Command AT+STK
Defined values
<value> 0 Disable STK 1 Enable STK
Examples
+STK: (list of supported <value>s) OK Responses +STK: <value>
l OK tia Responses
OK
ERROR
n Responses e Set default value (<value>=0): Confid OK
AT+STK=1 OK
m 9.5 AT+STKFMT Set STK pdu format o Description
This command is used to disable or enable the STK pdu mode. If the argument is 1, it is enabled.
CWhile if the argument is 0, it is disabled.
NOTE: Module should reboot to take effective.
IMSIM PIN References S YES Vendor
Syntax
File
Read Command
Responses
SIM7906_SIM7912 Series_AT Command Manual_V1.01
158
2019-11-21
Smart Machine Smart Decision
AT+STKFMT?
Write Command AT+STKFMT=<value>
+STKFMT: <value> OK Responses OK
ERROR
Defined values
l <value> 0 Disable STK pdu format, decoded command mode. tia 1 Enable STK pdu format
Examples
n AT+STKFMT=1
OK
fide 9.6 AT+STENV Original STK PDU Envelope Command Description n This command is used to original stk pdu envelope command. NOTE: PDU format supported only. o SIM PIN References C YES Vendor
Syntax
Test Command
m AT+STENV=? o Write Command CAT+STENV=<len>,<pdu>
Responses OK Responses OK
ERROR
Defined values
IM<len> S Integer type, pdu string length
<pdu>
String type, pdu value
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
159
2019-11-21
Smart Machine Smart Decision
Examples
AT+STENV=18,"D30782020181900101" OK
9.7 AT+STSM Get STK Setup Menu List with PDU Mode
Description
This command is used to get the stk setup menu list with pdu mode NOTE: PDU format supported only.
l SIM PIN References tia YES Vendor
Syntax
n Test Command
AT+STSM=?
e Read Command fid AT+STSM?
Responses OK
Responses +STSM: <cmd_id>,<tag>,<pdu_len>, <pdu_value> OK ERROR
n Defined values o <cmd_id> C Integer type, please refer to AT+STIN
<tag> Not used now.
<pdu_len>
m Integer type, pdu string length
<pdu_value>
o String type, the pdu string. C Examples
AT+STSM? +STSM:25,0,120,"D07681030125008202818285078065B052BF529B8F0A018070ED70B963A883
IM508F06028070AB94C38F0A03806D41884C77ED4FE18F0A048081EA52A9670D52A18F0A0580 624B673A97F34E508F0606808D854FE18F0A07805A314E50753162118F0A0880767E53D8751F
S 6D3B8F0A09806D596C5F98919053"
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
160
2019-11-21
Smart Machine Smart Decision
10 AT Commands for File Transmission
10.1 AT+CFTRANRX Transfer a file to EFS
Description This command is used to transfer a file to EFS. Support SD card.
l SIM PIN References NO Vendor
tia Syntax
n Test Command
AT+CFTRANRX=?
e Write Command
Responses +CFTRANRX: [{non-ascii}]"FILEPATH" OK Responses
fid AT+CFTRANRX="<filepat on h>",<len>
> OK > ERROR ERROR
C Defined values
<filepath> The path of the file on EFS. <len>
m The length of the file data to send. o NOTE
The <filepath> must be a full path with the directory path.
C Examples
AT+CFTRANRX="c:/MyDir/t1.txt",10
IM>testcontent OK
S AT+CFTRANRX="d:/MyDir/t1.txt",10 >testcontent
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
161
2019-11-21
Smart Machine Smart Decision
10.2 AT+CFTRANTX Transfer a file from EFS to host
Description
This command is used to transfer a file from EFS to host. Before using this command, the
AT+CATR must be used to set the correct port used. Support SD card.
SIM PIN References
NO Vendor
Syntax
l Test Command tia AT+CFTRANTX=?
Write Command
Responses +CFTRANTX: [{non-ascii}]"FILEPATH" OK Responses
n AT+CFTRANTX="<filepath fide >"[,<location>,<size>]
[+CFTRANTX: DATA,<len> ... +CFTRANTX: DATA,<len>] +CFTRANTX: 0 OK
ERROR
n Defined values o <filepath> C The path of the file on EFS.
<len> The length of the following file data to output. <location> The beginning of the file data to output.
m <size> o The length of the file data to output.
NOTE 1. The <filepath> must be a full path with the directory path.
C2. When the number of digits in <len> is less than three digits, 0 will be padded in front of <len> to
form three digits. 3. When <len> is greater than 512, the data will be output in 512 bytes per packet.
SIMExamples
AT+CFTRANTX="c:/MyDir/t1.txt"
+CFTRANTX: DATA, 011
Testcontent
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
162
2019-11-21
Smart Machine Smart Decision
+CFTRANTX: 0 OK AT+CFTRANTX="d:/MyDir/t1.txt" +CFTRANTX: DATA, 011 Testcontent +CFTRANTX: 0 OK AT+CFTRANTX="d:/MyDir/t1.txt",1,4 +CFTRANTX: DATA, 004 estc
l +CFTRANTX: 0 Confidentia OK
File
SIMCom
SIM7906_SIM7912 Series_AT Command Manual_V1.01
163
2019-11-21
Smart Machine Smart Decision
11 AT Commands for Open/Close Network
11.1 AT+CNETSTART Open network
Description
This command opens packet network.
l SIM PIN References YES Vendor
tia Syntax n Read Command fide AT+CNETSTART?
Responses +CNETSTART: <net_state>
OK ERROR
Execution Command
Con AT+CNETSTART
Responses OK
+CNETSTART: <err> +CNETSTART: <err>
OK
+CNETSTART: <err>
mERROR o ERROR C Defined values
<net_state>
IMa numeric parameter that indicates the state of PDP context activation: 0 network close (deactivated)
S 1 network is opening 2 network open(activated) 3 network is closing <err >
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
164
2019-11-21
Smart Machine Smart Decision
The result of operation, 0 is success, other value is failure.
Examples
AT+CNETSTART OK
+CNETSTART: 0
AT+CNETSTART? +CNETSTART: 2
l OK
tia 11.2 AT+CNETSTOP Close network
n Description e This command closes network. Before calling this command, all opened sockets must be closed
first.
fid SIM PIN References YES Vendor
n Syntax o Execution Command C AT+CNETSTOP
Responses OK
IMCom Defined values S <err>
+CNETSTOP: <err> +CNETSTOP: <err>
OK +CNETSTOP: <err>
ERROR ERROR
The result of operation, 0 is success, other value is failure.
File
Examples
SIM7906_SIM7912 Series_AT Command Manual_V1.01
165
2019-11-21
Smart Machine Smart Decision
AT+CNETSTOP OK
+CNETSTOP: 0
11.3 AT+CNETIPADDR Inquire PDP address
Description
This command inquires the IP address of current active PDP.
l SIM PIN References
YES Vendor
tia Syntax n Read Command nfide AT+CNETIPADDR?
Responses +CNETIPADDR: < ip_address>
OK +CNETIPADDR: <err_info>
ERROR ERROR
o Defined values C <ip_address>
A string parameter that identifies the IP address of current active socket PDP. <err_info> A string parameter that displays the cause of occurring error.
m Examples o AT+CNETIPADDR?
+CNETIPADDR: 10.71.155.118
COK SIM11.4 Unsolicited Open/Close network command <err> Codes
Code of <err> 0
Description Operation succeeded
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
166
2019-11-21
Smart Machine Smart Decision
1
Unknown error
2
Open network failed
3 4 5 6 7 8
Close network failed Network not opened Operation not support
ile Busy
Network has been opened
Confidential F Network is also in use
SIMCom
SIM7906_SIM7912 Series_AT Command Manual_V1.01
167
2019-11-21
Smart Machine Smart Decision
12 AT Commands for GPS
12.1 AT+CGPS Start/Stop GPS session
Description
This command is used to start or stop GPS session. NOTE:
l 1. Output of NMEA sentences is automatic; no control via AT commands is provided. At tia present the module only supports standalone mode. If executing AT+CGPS=1, the GPS
session will choose cold or hot start automatically. 2. UE-based and UE-assisted mode depend on URL (AT+CGPSURL). When UE-based mode fails, it will switch standalone mode.
n 3. UE-assisted mode is singly fixed. Standalone and UE-based mode is consecutively
fixed.
e 4. After the GPS closed, it should to wait about 2s~30s for start again. ReasonIf the fid signal conditions are right (strong enough signals to allow ephemeris demodulation) or
ephemeris demodulation is on going, sometimes MGP will stay on longer in order to demodulate more ephemeris. This will help the engine provide faster TTFF and possibly better yield later (up to 2 hours), because it has the benefit of more ephemeris
n available.
SIM PIN References
Co NO Vendor
Syntax
Test Command
m AT+CGPS=? o Read Command
AT+CGPS?
CWrite Command
AT+CGPS=<on/off>
SIM[,<mode>]
Responses +CGPS: (list of supported <on/off>s),( list of supported <mode>s) OK
Responses +CGPS: <on/off>,<mode> OK
Responses OK If UE-assisted mode, when fixed will report indication: +CAGPSINFO:<lat>,<lon>,<alt>,<date>,<time> If <off>, it will report indication:
+CGPS: 0
ERROR
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
168
2019-11-21
Smart Machine Smart Decision
Defined values
<on/off> 0 stop GPS session 1 start GPS session
<mode> Ignore - standalone mode 1 standalone mode 2 UE-based mode 3 UE-assisted mode
<lat>
l Latitude of current position. Unit is in 10^8 degree tia <log>
Longitude of current position. Unit is in 10^8 degree <alt> MSL Altitude. Unit is meters.
n <date>
UTC Date. Output format is ddmmyyyy
e <time>
UTC Time. Output format is hhmmss.s
fid < unconfidence >
Unconfidence of the location, GPS fixed report 39, cell fixed report 100. < uncertainty_meter >
n Uncertainty meters. o Examples C AT+CGPS?
OK AT+CGPS=1,1 OK
m 12.2 AT+CGPSINFO Get GPS fixed position information o Description CThis command is used to get current position information.
SIM PIN References
IMNO Vendor S Syntax
File
Test Command AT+CGPSINFO=?
Responses +CCGPSINFO: (scope of <time>)
SIM7906_SIM7912 Series_AT Command Manual_V1.01
169
2019-11-21
Smart Machine Smart Decision
Read Command AT+CGPSINFO?
OK Responses +CCGPSINFO: <time> OK
Write Command
Responses
AT+CGPSINFO=<time>
OK
+CGPSINFO: [<lat>],[<N/S>],[<log>],[<E/W>],[<date>],[<UTC
l Execution Command tia AT+CGPSINFO
time>],[<alt>],[<speed>],[<course>] OK (if <time>=0)
Responses +CGPSINFO: [<lat>],[<N/S>],[<log>],[<E/W>],[<date>],[<UTC time>],[<alt>],[<speed>],[<course>] OK
n Defined values e <lat>
Latitude of current position. Output format is ddmm.mmmmmm
fid <N/S>
N/S Indicator, N=north or S=south <log>
n Longitude of current position. Output format is dddmm.mmmmmm
<E/W>
o E/W Indicator, E=east or W=west
<date>
C Date. Output format is ddmmyy
<UTC time> UTC Time. Output format is hhmmss.s <alt>
m MSL Altitude. Unit is meters.
<speed>
o Speed Over Ground. Unit is knots.
<course>
CCourse. Degrees.
<time> The range is 0-255, unit is second, after set <time> will report the GPS information every the
IMseconds. S Examples
AT+CGPSINFO=?
+CGPSINFO: (0-255)
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
170
2019-11-21
Smart Machine Smart Decision
OK
AT+CGPSINFO?
+CGPSINFO: 0
OK
AT+CGPSINFO
+CGPSINFO:3113.343286,N,12121.234064,E,250311,072809.3,44.1,0.0,0
OK
12.3 AT+CGPSCOLD Cold start GPS
l Description tia This command is used to cold start GPS session.
NOTE: Before using this command,it must use AT+CGPS=0 to stop GPS session. SIM PIN References
n NO Vendor
Syntax
e Test Command fid AT+CGPSCOLD=?
Execution Command AT+CGPSCOLD
Responses OK Responses OK
n Examples o AT+CGPSCOLD=? C OK
AT+CGPSCOLD OK
m 12.4 AT+CGPSHOT Hot start GPS o Description
This command is used to hot start GPS session
CNOTE: Before using this command, AT+CGPS=0 must be used to stop GPS session.
SIM PIN References
IMNO Vendor S Syntax
File
Test Command AT+CGPSHOT=?
Responses OK
SIM7906_SIM7912 Series_AT Command Manual_V1.01
171
2019-11-21
Smart Machine Smart Decision
Execution Command AT+CGPSHOT
Responses OK
Examples
AT+CGPSHOT=?
OK
AT+CGPSHOT OK
l 12.5 AT+CGPSURL Set AGPS default server URL
tia Description This command is used to set AGPS default server URL. It will take effect only after restarting. SIM PIN References n NO Vendor
e Syntax fid Test Command
AT+CGPSURL=?
n Read Command
AT+CGPSURL?
o Write Command C AT+CGPSURL=<URL>
Responses OK
Responses +CGPSURL: <URL> OK Responses OK
ERROR
m Defined values <URL> o AGPS default server URL. It needs double quotation marks.
C Examples
AT+CGPSURL="123.123.123.123:8888"
IMOK AT+CGPSURL?
+CGPSURL: "123.123.123.123:8888"
S OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
172
2019-11-21
Smart Machine Smart Decision
12.6 AT+CGPSSSL Set AGPS transport security
Description
This command is used to select transport security, used certificate or not. The certificate gets from
local carrier. If the AGPS server doesn't need certificate, execute AT+CGPSSSL=0.
SIM PIN References
NO Vendor
Syntax
l Test Command tia AT+CGPSSSL=?
Read Command
n AT+CGPSSSL? e Write Command fid AT+CGPSSSL=<SSL>
Responses +CGPSSSL: (list of supported <SSL>s) OK
Responses +CGPSSSL: <SSL> OK Responses OK
ERROR
n Defined values o <SSL>
0 don't use certificate
C 1 use certificate
Examples
AT+CGPSSSL=0
m OK o 12.7 AT+CGPSAUTO Start GPS automatic C Description
This command is used to start GPS automaticly when module powers on, GPS is closed defaultly.
IMNOTE: If GPS start automatically, its operation mode is standalone mode. SIM PIN References
S NO Vendor
File
Syntax
SIM7906_SIM7912 Series_AT Command Manual_V1.01
173
2019-11-21
Smart Machine Smart Decision
Test Command AT+CGPSAUTO=?
Responses +CGPSAUTO:( list of supported <auto>s) OK
Read Command
Responses
AT+CGPSAUTO?
+CGPSAUTO:<auto>
OK
Write Command
Responses
AT+CGPSAUTO=<auto>
OK ERROR
l Defined values tia <auto>
0 Non-automatic 1 automatic
n Examples e AT+CGPSAUTO=1 fid OK
12.8 AT+CGPSNMEA Configure NMEA sentence type
n Description o This command is used to configure NMEA output sentences which are generated by the gpsOne C engine when position data is available.
NOTE: If nmea bit 2 GPGSV doesn't configure, GPGSV sentence also doesn't output on AT/modem port even set AT+CGPSFTM=1. Module should reboot to take effect.
m SIM PIN References NO Vendor
o Syntax CTest Command
AT+CGPSNMEA=?
IMRead Command S AT+CGPSNMEA?
Responses +CGPSNMEA: (scope of <nmea>) OK
Responses +CGPSNMEA: <nmea>
OK
Write Command
Responses
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
174
2019-11-21
Smart Machine Smart Decision
AT+CGPSNMEA=<nmea>
OK If GPS engine is running: ERROR
Defined values
<nmea> Range 0 to 262143 Each bit enables an NMEA sentence output as follows:
Bit 0 GPGGA (global positioning system fix data)
l Bit 1 GPRMC (recommended minimum specific GPS/TRANSIT data)
Bit 2 GPGSV (GPS satellites in view)
tia Bit 3 GPGSA (GPS DOP and active satellites)
Bit 4 GPVTG (track made good and ground speed) Bit 5 PQXFI (Global Positioning System Extended Fix Data.)
n Bit 6 GLGSV (GLONASS satellites in view GLONASS fixes only)
Bit 7 GNGSA (1. GPS/2. Glonass/3. GALILE DOP and Active Satellites.)
e Bit 8 GNGNS (fix data for GNSS receivers;output for GPS,GLONASS,GALILEO)
Bit 9 Reserved
fid Bit 10 GAGSV (GALILEO satellites in view)
Bit 11 Reserved Bit 12 Reserved
n Bit 13 Reserved
Bit 14 Reserved
o Bit 15 Reserved,
Bit 16 BDGSA/PQGSA (BEIDOU/QZSS DOP and active satellites)
C Bit 17 BDGSV/PQGSV (BEIDOUQZSS satellites in view)
Set the desired NMEA sentence bit(s). If multiple NMEA sentence formats are desired, "OR" the desired bits together. NOTE: Reserved default 0, set invalid.
m Examples o AT+CGPSNMEA=200191
OK
C 12.9 AT+CGPSNEMARATE Set NMEA output rate SIMDescription
This command is used to set nmea output rate NOTE: send the command before open gps
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
175
2019-11-21
Smart Machine Smart Decision
SIM PIN References NO Vendor
Syntax
Test Command
Responses
AT+CGPSNMEARATE=? +CGPSNMEARATE: (scope of < rate >)
Read Command AT+CGPSNMEARATE?
Write Command AT+CGPSNMEARATE=<r ate>
Defined values
<rate> 0 output rate 1HZ 1 output rate 10HZ
Examples
AT+CGPSNMEARATE =1 OK
OK
Responses +CGPSNMEARATE: <rate>
l OK tia Responses
OK
Confiden ERROR
12.10 AT+CGPSMD Configure AGPS MO method
Description
m This command specifies if the Mobile-Originated (MO) GPS session should use the control plane
session or user plane session.
o SIM PIN References NO Vendor
C Syntax IMTest Command S AT+CGPSMD=?
Responses +CGPSMD: (scope of <method>) OK
Read Command
Responses
AT+CGPSMD?
+CGPSMD: <method>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
176
2019-11-21
Smart Machine Smart Decision
Write Command AT+CGPSMD=<method>
OK Responses OK If GPS engine is running: ERROR
Defined values
<method> 0 Control plane
l 1 User plane tia Examples
AT+CGPSMD=1 OK
en 12.11 AT+CGPSFTM Start GPS test mode fid Description
This command is used to start GPS test mode. NOTE:
n 1. If test mode starts, the URC will report on AT port, Modem port and UART port.
2. If testing on actual signal, <SV> should be ignored, and GPS must be started by AT+CGPS,
o AT+CGPSCOLD or AT+CGPSHOT. C 3. If testing on GPS signal simulate equipment, <SV> must be choiced, and GPS will start
automatically.
4. URC sentence will report every 1 second. SIM PIN References
NO Vendor
om Syntax
Test Command
CAT+CGPSFTM=?
Read Command
IMAT+CGPSFTM? S Write Command
Responses OK
Responses +CGPSFTM: <on/off> OK Responses
AT+CGPSFTM=<on/off> OK
ERROR
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
177
2019-11-21
Smart Machine Smart Decision
Defined values
<on/off>
0 Close test mode
1 Start test mode
<CNo>
Satellite CNo value. Floating value.
URC format $GPGSV[,<SV>,<CNo>][...] $GLGSV[,<SV>,<CNo>][...] $BDGSV[,<SV>,<CNo>][...]
l $GAGSV[,<SV>,<CNo>][...] tia $PQGSV[,<SV>,<CNo>][...]
Examples
n AT+CGPSFTM=1
OK
e $GLGSV,78,20.6,66,25.6,77,21.6,79,21.9,67,26.2,68,23.6 fid $GPGSV,10,36.3,12,33.5,14,26.5,15,27.0,18,30.6,20,29.4,21,14.9,24,32.8,25,30.6,31,29.1,32,27.0
$BDGSV,201,28.7,204,29.0,206,27.3,207,25.9,209,25.0,210,18.5
n 12.12 AT+CGPSDEL Delete the GPS information Co Description
This command is used to delete the GPS information. After executing the command, GPS start is cold start. NOTE: This command must be executed after GPS stopped.
m SIM PIN References NO Vendor
o Syntax CTest Command
AT+CGPSDEL=?
IMExecution Command S AT+CGPSDEL
Responses OK
Responses OK ERROR
File
Examples
SIM7906_SIM7912 Series_AT Command Manual_V1.01
178
2019-11-21
Smart Machine Smart Decision
AT+CGPSDEL=? OK AT+CGPSDEL OK
12.13 AT+CGPSXE Enable/Disable GPS XTRA function
Description
l This command is used to enable/disable the GPS XTRA function.
NOTE: XTRA function must download the assistant file from network by HTTP, so the APN must
tia be set by AT+CGDCONT command.
SIM PIN References NO Vendor
n Syntax e Test Command fid AT+CGPSXE=?
Read Command
n AT+CGPSXE? o Write Command C AT+CGPSXE=<on/off>
Responses +CGPSXE: (list of supported <on/off>s) OK
Responses +CGPSXE: <on/off> OK
Responses OK
ERROR
Defined values
m <on/off> o 0 Disable GPS XTRA
1 Enable GPS XTRA
C Examples
AT+CGPSXE=?
IM+CGPSXE: (0,1) OK
S AT+CGPSXE=0
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
179
2019-11-21
Smart Machine Smart Decision
12.14 AT+CGPSXD Download XTRA assistant file
Description
This command is used to download the GPS XTRA assistant file from network through http protocol. Module will download the latest assistant file form server and write the file into module.
SIM PIN References
NO Vendor
Syntax
Test Command AT+CGPSXD=? Read Command AT+CGPSXD? Write Command AT+CGPSXD=<server>
Defined values
<server>
l Responses tia +CGPSXD: (list of supported <server>s)
OK Responses
n +CGPSXD: <server>
OK
e Responses fid OK
+CGPSXD: <resp> +CGPSXD: <resp>
Con ERROR
0 XTRA primary server (precedence) 1 XTRA secondary server 2 XTRA tertiary server <resp>
m refer to Unsolicited XTRA download Codes o Examples CAT+CGPSXD=?
+CGPSXD: (0-2) OK
IMAT+CGPSXD=0 OK
S +CGPSXD: 0
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
180
2019-11-21
Smart Machine Smart Decision
12.15 AT+CGPSXDAUTO Download XTRA assistant file automatically
Description
This command is used to control download assistant file automatically or not when GPS start. XTRA function must enable for using this command. If assistant file doesn't exist or check error, the module will download and inject the assistant file automatically.
SIM PIN References NO Vendor
l Syntax
tia Test Command
AT+CGPSXDAUTO=?
Responses +CGPSXDAUTO: (list of supported <on/off>s) OK
n Read Command e AT+CGPSXDAUTO?
Responses +CGPSXDAUTO: <on/off> OK
fid Write Command
AT+CGPSXDAUTO=<on/o ff>
Responses OK ERROR
n Defined values o <on/off> C 0 disable download automatically
1 enable download automatically
NOTE: Some URCs will report when downloading, it's same as AT+CGPSXD command.
m Examples AT+CGPSXDAUTO=? o +CGPSXDAUTO: (0,1) OK CAT+CGPSXDAUTO=0 OK
IM12.16 AT+CGPSINFOCFG Report GPS NMEA-0183 sentence S Description
This command is used to report NMEA-0183 sentence.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
181
2019-11-21
Smart Machine Smart Decision
SIM PIN References NO Vendor
Syntax
Test Command
Responses
AT+CGPSINFOCFG=?
+CGPSINFOCFG: (scope of <time>),(scope of <config>)
Read Command AT+CGPSINFOCFG?
tial Write Command
AT+CGPSINFOCFG=<time
n >[,<config>]
OK Responses +CGPSINFOCFG: <time>,<config> OK Responses OK (NMEA-0183 Sentence) ...... OK (if <time>=0)
fide Defined values <time> The range is 0-255, unit is second, after set <time> will report the GPS NMEA sentence every the n seconds. If <time>=0, module stop reporting the NMEA sentence. o <config> Range 0 to 262143 C Each bit enables an NMEA sentence output as follows:
Bit 0 GPGGA (global positioning system fix data) Bit 1 GPRMC (recommended minimum specific GPS/TRANSIT data) Bit 2 GPGSV (GPS satellites in view)
m Bit 3 GPGSA (GPS DOP and active satellites)
Bit 4 GPVTG (track made good and ground speed)
o Bit 5 PQXFI (Global Positioning System Extended Fix Data.)
Bit 6 GLGSV (GLONASS satellites in view GLONASS fixes only)
CBit 7 GNGSA (1. GPS/2. Glonass/3. GALILE DOP and Active Satellites.)
Bit 8 GNGNS (fix data for GNSS receivers;output for GPS,GLONASS,GALILEO) Bit 9 Reserved
IMBit 10 GAGSV (GALILEO satellites in view) Bit 11 Reserved
S Bit 12 Reserved Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved,
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
182
2019-11-21
Smart Machine Smart Decision
Bit 16 BDGSA/PQGSA (BEIDOU/QZSS DOP and active satellites) Bit 17 BDGSV/PQGSV (BEIDOUQZSS satellites in view) Set the desired NMEA sentence bit(s). If multiple NMEA sentence formats are desired, "OR" the desired bits together. NOTE: Reserved default 0, set invalid.
For example: If want to report GPRMC sentence by 10 seconds, should execute AT+CGPSINFOCFG=10,2
Examples
l AT+CGPSINFOCFG=? tia +CGPSINFO: (0-255),(0-262143)
OK AT+CGPSINFOCFG=10,31 OK
n $GPGSV,4,1,16,04,53,057,44,02,55,334,44,10,61,023,44,05,45,253,43*7D
$GPGSV,4,2,16,25,10,300,40,17,25,147,40,12,22,271,38,13,28,053,38*77
e $GPGSV,4,3,16,26,09,187,35,23,06,036,34,24,,,,27,,,*7A
$GPGSV,4,4,16,09,,,,31,,,,30,,,,29,,,*7D
fid $GPGGA,051147.0,3113.320991,N,12121.248076,E,1,10,0.8,47.5,M,0,M,,*45
$GPVTG,NaN,T,,M,0.0,N,0.0,K,A*42 $GPRMC,051147.0,A,3113.320991,N,12121.248076,E,0.0,0.0,211211,,,A*66
n $GPGSA,A,3,02,04,05,10,12,13,17,23,25,26,,,1.4,0.8,1.2*3B Co 12.17 AT+CGPSPMD Configure positioning mode
Description
This command is used to configure the positioning modes support. NOTE: Need to restart the module after setting the mode.
m SIM PIN References
NO Vendor
o Syntax CTest Command IMAT+CGPSPMD=? S Read Command
Responses +CGPSPMD: (scope of <mode>) OK Responses
AT+CGPSPMD?
+CGPSPMD: <mode>
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
183
2019-11-21
Smart Machine Smart Decision
Write Command AT+CGPSPMD=<mode>
Responses OK ERROR
Defined values
<mode> Default - 127 Range - 1 to 65407 Each bit enables a supported positioning mode as follows:
l Bit 0 Standalone
Bit 1 UP MS-based
tia Bit 2 UP MS-assisted
Bit 3 CP MS-based (2G) Bit 4 CP MS-assisted (2G)
n Bit 5 CP UE-based (3G)
Bit 6 CP UE-assisted (3G)
e Bit 7 NOT USED
Bit 8 UP MS-based (4G)
fid Bit 9 UP MS-assisted(4G)
Bit 10 CP MS-based (4G) Bit 11 CP MS-assisted (4G)
n Set the desired mode sentence bit(s). If multiple modes are desired, "OR" the desired bits together.
Example, support standalone, UP MS-based and UP MS-assisted, set Binary value 0000 0111, is 7.
Co Examples AT+CGPSPMD=127 OK
m 12.18 AT+CGPSMSB Configure based mode switch to standalone o Description
This command is used to configure AGPS based mode switching to standalone mode automatically
Cor not.
SIM PIN References
IMNO Vendor S Syntax
File
Test Command
Responses
SIM7906_SIM7912 Series_AT Command Manual_V1.01
184
2019-11-21
Smart Machine Smart Decision
AT+CGPSMSB=?
+CGPSMSB: (scope of <mode>) OK
Read Command
Responses
AT+CGPSMSB?
+CGPSMSB: <mode> OK
Write Command
Responses
AT+CGPSMSB=<mode>
OK ERROR
l Defined values tia <mode>
0 Don't switch to standalone mode automatically 1 Switch to standalone mode automatically
n Examples e AT+CGPSMSB=0
OK
fid 12.19 AT+CGPSHOR Configure positioning desired accuracy
n Description o The command is used to configure the positioning desired accuracy threshold in meters. C SIM PIN References
NO Vendor
Syntax
m Test Command o AT+CGPSHOR=?
Responses +CGPSHOR: (scope of <acc>), (scope of < acc_f >) OK
CRead Command
AT+CGPSHOR?
Responses +CGPSHOR: <acc>,<acc_f> OK
IMWrite Command AT+CGPSHOR=<acc>[,<ac
S c_f>]
Responses OK ERROR
File
Defined values
SIM7906_SIM7912 Series_AT Command Manual_V1.01
185
2019-11-21
Smart Machine Smart Decision
<acc> Range 0 to 1800000 Default value is 50 <acc_f> Reserved
Examples
AT+CGPSHOR=50 OK
l 12.20 AT+CGPSNOTIFY LCS respond positioning request
tia Description This command is used to respond to the incoming request for positioning request message. n SIM PIN References e NO Vendor
fid Syntax
Test Command
n AT+CGPSNOTIFY=? o Write Command C AT+CGPSNOTIFY=<resp>
Responses +CGPSNOTIFY: (list of supported <resp>s) OK
Responses OK
ERROR
Defined values
m <resp> 0 o 1 2
LCS notify verify accept LCS notify verify deny LCS notify verify no response
C Examples IMAT+CGPSNOTIFY=?
+CGPSNOTIFY: (0-2) OK
S AT+CGPSNOTIFY=0
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
186
2019-11-21
Smart Machine Smart Decision
12.21 AT+CGNSSINFO Get GNSS fixed position information
Description
This command is used to get current position related information.
SIM PIN References
NO Vendor
Syntax
Test Command AT+CGNSSINFO=? Read Command AT+CGNSSINFO? Write Command AT+CGNSSINFO=<time>
Execution Command AT+CGNSSINFO
l Responses
+CGNSSINFO: (scope of <time>)
tia OK
Responses +CGNSSINFO: <time>
n OK e Responses
OK
fid +CGNSSINFO:
[<mode>],[<GPS-SVs>],[<GLONASS-SVs>],[BEIDOU-SVs], [<lat>],[<N/S>],[<log>],[<E/W>],[<date>],[<UTC-time>],[<alt>], [<speed>],[<course>],[<PDOP>],[HDOP],[VDOP]
n OK (if <time>=0) o Responses C+CGNSSINFO:
[<mode>],[<GPS-SVs>],[<GLONASS-SVs>],[BEIDOU-SVs],
[<lat>],[<N/S>],[<log>],[<E/W>],[<date>],[<UTC-time>],[<alt>], [<speed>],[<course>],[<PDOP>],[HDOP],[VDOP] OK
om Defined values
<mode>
CFix mode 2=2D fix 3=3D fix
<GPS-SVs> GPS satellite valid numbers
IM< GLONASS-SVs > GLONASS satellite valid numbers
S <BEIDU-SVs>
scope: 00-12 scope: 00-12
BEIDOU satellite valid numbers
scope: 00-12
<lat>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
187
2019-11-21
Smart Machine Smart Decision
Latitude of current position. Output format is ddmm.mmmmmm <N/S> N/S Indicator, N=north or S=south <log> Longitude of current position. Output format is dddmm.mmmmmm <E/W> E/W Indicator, E=east or W=west <date> Date. Output format is ddmmyy <UTC time>
l UTC Time. Output format is hhmmss.s
<alt>
tia MSL Altitude. Unit is meters.
<speed> Speed Over Ground. Unit is knots.
n <course>
Course. Degrees.
e <time>
The range is 0-255, unit is second, after set <time> will report the GPS information every the
fid seconds.
<PDOP> Position Dilution Of Precision. <HDOP>
n Horizontal Dilution Of Precision. o <VDOP> C Vertical Dilution Of Precision.
Examples
AT+CGNSSINFO=? +CGNSSINFO: (0-255)
m OK
AT+CGNSSINFO?
o +CGPSINFO: 0
OK
CAT+CGNSSINFO
+CGNSSINFO: 2,09,05,00,3113.330650,N,12121.262554,E,131117,091918.0,32.9,0.0,255.0,1.1,0.8,0.7
IMOK AT+CGNSSINFO (if not fix,will report null)
S +CGNSSINFO: ,,,,,,,,,,,,,,, OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
188
2019-11-21
Smart Machine Smart Decision
12.22 AT+CGNSSMODE Configure GNSS support mode
Description
This command is used to configure GPS, GLONASS, BEIDOU and QZSS support mode. And DPO(Dynamic power optimization) status Module should reboot to take effective.
SIM PIN References NO Vendor
Syntax
Test Command AT+CGNSSMODE=?
Read Command AT+CGNSSMODE?
Write Command AT+CGNSSMODE=<mode >[,<dpo_mode>]
Defined values
<gnss_mode> Range 0 to 15
tial Responses
+CGNSSMODE: (scope of <gnss_mode>),(scope of <dpo_mode>) OK
n Responses
+CGNSSMODE: <gnss_mode>,<dpo_mode>
e OK fid Responses
OK
Con ERROR
Bit0: GLONASS Bit1: BEIDOU Bit2: GALILEO Bit3: QZSS
m 1: enable 0:disable o GPS always support
<dpo_mode> 1: enable DPO
C0: disable DPO IMExamples
AT+CGNSSMODE=15,1
S OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
189
2019-11-21
Smart Machine Smart Decision
12.23 Unsolicited XTRA download Codes
Code of <err>
Description
0
Assistant file download successfully
1
Assistant file doesn't exist
2
Assistant file check error
220
Unknown error for HTTP
221
HTTP task is busy
222
Failed to resolve server address
l 223
HTTP timeout
224
Failed to transfer data
tia 225
Memory error
226
Invalid parameter
227
Network error
n 220~227 codes are same as Unsolicited HTTP codes
e 12.24 AT+CLBS Base station location fid Description
The write command is used to base station location.
n NOTE: 1. The LBS is only support in WCDMA/LTE net mode. o 2. It needs to execute AT+CNETSTART to open network before execute the AT+CLBS write
C command. It needs to execute AT+CNETSTOP to close network after complete the LBS operation.
SIM PIN References
YES 3GPP TS 27.007
m Syntax o Test Command CAT+CLBS=?
Responses +CLBS: (1,2,3,4,9),(1-24),(-180.000000-180.000000),(-90.000000-90.00000 0),(0,1)
IMWrite Command S AT+CLBS=<type>[,<cid>[,
OK Responses OK
[<longitude>,<latitude>],[<l
on_type>]]]
1)type = 1,get longitude and latitude
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
190
2019-11-21
Smart Machine Smart Decision
+CLBS: <ret_code>[,<longitude>,<latitude>,<acc>]
2)type = 2,get detail address +CLBS: <ret_code>[,<detail_addr>]
3)type = 3,get access times +CLBS: <ret_code>[,<times>]
4)type = 4,get longitude latitude and date time +CLBS:
l <ret_code>[,<longitude>,<latitude>,<acc>,<date>,<time>] tia 5)type = 9, report positioning error
+CLBS: <ret_code> ERROR
n +CLBS: <ret_code> e ERROR fid Defined values
<type>
n A numeric parameter which specifies the location type. 1 use 3 cell's information o 2 get detail address 3 get access times C 4 get longitude latitude and date time 9 report positioning error <cid> A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT
m command). 1...24
o NOTEThis parameter takes no effect in SIM7906/SIM7912, it's only in order to keep compatible
with the previous software version and other projects, support convenience for the customers.
C<longitude> Current longitude in degrees. <latitude>
IMCurrent latitude in degrees. <detail_addr>
S Current detail address. It based the UCS2 coding. Each 4 characters in the URC is for one UCS2 character. <acc> Positioning accuracy.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
191
2019-11-21
Smart Machine Smart Decision
<lon_type>
The type of longitude and latitude
0 WGS84the default type
1 GCJ02.
<times>
access service times.
<data>
service date(UTC, the format is YYYY/MM/DD). <time>
service time(UTC, the format is HH:MM:SS).
l <ret_code> The result code. tia 0 Success 1 Parameter error returned by server. 2 Service out of time returned by server. n 3 Location failed returned by server. 4 Query timeout returned by server. e 5 Certification failed returned by server. 6 Server LBS error success. fid 7 Server LBS error failed. 80 Report LBS to server success 81 Report LBS to server parameter error 82 Report LBS to server failed n 110 Other Error o 8 LBS is busy. C 9 Open network error.
SIMCom Examples
10 Close network error. 11 Operation timeout. 12 DNS error. 13 Create socket error. 14 Connect socket error. 15 Close socket error. 16 Get cell info error. 17 Get IMEI error. 18 Send data error. 19 Receive data error. 20 NONET error. 21 Net not opened.
File
AT+CLBS=?
SIM7906_SIM7912 Series_AT Command Manual_V1.01
192
2019-11-21
Smart Machine Smart Decision
+CLBS: (1,2,3,4,9),( 1-24),(-180.000000-180.000000),(-90.000000-90.000000),(0,1)
OK AT+CLBS=1 (need execute AT+CNETSTART before this command) OK
+CLBS: 0,31.228525,121.380295,500
AT+CLBS=2 (need execute AT+CNETSTART before this command) OK
l +CLBS:
0,
4e0a6d775e020020957f5b81533a002091d1949f8def002097608fd166688baf79d162805927697c
tia AT+CLBS=3 (need execute AT+CNETSTART before this command)
OK
n +CLBS: 0,22
AT+CLBS=4 (need execute AT+CNETSTART before this command)
e OK
fid +CLBS: 0,31.228525,121.380295,500,2025/06/07,10:49:08
AT+CLBS=9 (need execute AT+CNETSTART before this command) OK
n +CLBS: 80
Co 12.25 AT+CLBSCFG Base station location configure
Description
The write command is used to set and query the base station location configure.
m SIM PIN References YES 3GPP TS 27.007
o Syntax CTest Command
AT+CLBSCFG=?
SIMWrite Command
Responses +CLBSCFG: (0-1), 3,"Param Value"
OK Responses
AT+CLBSCFG=<operate>,< +CLBSCFG: 0,<para>,<value>
para>[,<value>]
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
193
2019-11-21
Smart Machine Smart Decision
OK OK ERROR +CLBSCFG: <ret_code>
ERROR
Defined values
<operate>
l A numeric parameter which specifies the operator. tia 0 read operator
1 write operator <para> A numeric parameter which specifies the operator parameter.
n 3 Server's address lbs-simcom.com:3002
e <value>
The value of parameter.
fid The allowed <value> is "lbs-simcom.com:3002".
Server's address of "lbs-simcom.com:3002" is free. <ret_code>
n Please refer to the <ret_code> of AT+CLBS. o Examples C AT+CLBSCFG=?
+CLBSCFG: (0-1),3,"Param Value"
OK
m AT+CLBSCFG=0,3
+CLBSCFG: 0,3,"lbs-simcom.com:3002"
o OK CAT+CLBSCFG=1,3,"lbs-simcom.com:3002"
OK
IM12.26 AT+CGTP Get the IZAT location S Description
The write command is used to get IZAT location, you can get the IZAT location,data,time,accuary
File
SIM PIN References
SIM7906_SIM7912 Series_AT Command Manual_V1.01
194
2019-11-21
Smart Machine Smart Decision
YES 3GPP TS 27.007
Syntax
Test Command AT+CGTP=?
Read Command AT+CGTP?
Write Command /*Set IZAT NV param*/ AT+CGTP=<mode>
Execute Command /*Start IZAT location */ AT+CGTP
Defined Values < feature_control >
< user_session_control >
om < primary_svr_address > C < primary_svr_port > SIM< secondary_svr_address >
Response
ile OK
Response
+CGTP:
<feature_control>,<user_session_control>,<
F primary_svr_address>,<primary_svr_port>,<secondary_svr
l _address>,< secondary_svr_port>
tia OK
Response a)If successfully: OK
n b)If failed: e ERROR
Response
fid OK
+CTPCELL: <latitude>,<longitude>,<date>,<time>,<accuary>
on 0: GTP disabled C1: GTP enabled
If you want to use IZAT function,this value must be 1
0 Connection to the XTS is never permitted
1 Connection to the XTS is always permitted
If you want to use IZAT function,this value must be 1 the IP address of the primary GTP Server.
If you want to use IZAT function,this value must be gtp1.izatcloud.net the port number of the primary
If you want to use IZAT function,this value must be 443 the IP address of the secondary GTP Server.
If you want to use IZAT function,this value must be gtp2.izatcloud.net
SIM7906_SIM7912 Series_AT Command Manual_V1.01
195
2019-11-21
Smart Machine Smart Decision
< secondary_svr_port >
the port number of the primary
If you want to use IZAT function,this value must be 443
< latitude >
Latitude (specified in WGS84 datum). Type: Floating point
Units: Degrees
Range: -90.0 to 90.0
< longitude >
ntial <date>
< time >
Positive values indicate northern latitude Negative values indicate southern latitude Longitude (specified in WGS84 datum). Type: Floating point Units: Degrees Range: -180.0 to 180.0 Positive values indicate eastern longitude Negative values indicate western longitude Output format is yyyy-mm-dd
UTC time output format is hh:mm:ss
fide < accuary >
<mode>
Horizontal position uncertainty (circular). Type: Floating point Units: Meters 1:Set NV value
n Examples o Before all IZAT related operations, we should ensure the following: C a) ensure network is registered
AT+CSQ
m +CSQ: 23,0 o OK
AT+CREG?
C +CREG: 0,1
OK
SIMTest IZAT function
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
196
2019-11-21
Smart Machine Smart Decision
//Query IZAT NV set
AT+CGTP?
+CGTP: 1,1,gtp1.izatcloud.net,443,gtp2.izatcloud.net,443
OK //If query result is not this , need set it, then must restart module AT+CGTP=1
OK
l // Start IZAT location
AT+CGTP
tia OK Confiden +GTPCELL: 35.523384,104.507509,2018-12-10 09:12:48,1633580.000000 SIMCom
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
197
2019-11-21
Smart Machine Smart Decision
13 AT Commands for Call Control
13.1 AT+CVHU Voice hang up control
Description
Write command selects whether ATH or "drop DTR" shall cause a voice connection to be disconnected or not. By voice connection is also meant alternating mode calls that are currently in
l voice mode. tia SIM PIN References
NO 3GPP TS 27.007
n Syntax
Test Command
e AT+CVHU=? fid Read Command
AT+CVHU?
n Write Command Co AT+CVHU=<mode>
Responses +CVHU: (list of supported <mode>s) OK
Responses +CVHU: <mode> OK
Responses OK
ERROR
Execution Command AT+CVHU
Responses Set default value: OK
m Defined values o <mode>
0 "Drop DTR" ignored but OK response given. ATH disconnects.
C1 "Drop DTR" and ATH ignored but OK response given. IMExamples
AT+CVHU=0
S OK
AT+CVHU?
+CVHU: 0
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
198
2019-11-21
Smart Machine Smart Decision
13.2 AT+CHUP Hang up call
Description
This command is used to cancel voice calls. If there is no call, it will do nothing but OK response is given. After running AT+CHUP, multiple "VOICE CALL END: " may be reported which relies on how many calls exist before calling this command.
SIM PIN References NO 3GPP TS 27.007
l Syntax tia Test Command
AT+CHUP=? Execution Command
fiden AT+CHUP
Responses OK
Responses VOICE CALL: END: <time> [... VOICE CALL: END: <time>] OK
No call: OK
n Defined values o <time> C Voice call connection time.
Format HHMMSS (HH: hour, MM: minute, SS: second)
Examples
m AT+CHUP
VOICE CALL:END: 000017
o OK C 13.3 AT+CBST Select bearer service type IMDescription
Write command selects the bearer service <name> with data rate <speed>, and the connection element <ce> to be used when data calls are originated. Values may also be used during mobile
S terminated data call setup, especially in case of single numbering scheme calls.
File
SIM PIN References
SIM7906_SIM7912 Series_AT Command Manual_V1.01
199
2019-11-21
Smart Machine Smart Decision
YES 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CBST=?
+CBST: (list of supported <speed>s), (list of supported <name>s),
(list of supported <ce>s)
Read Command AT+CBST?
l Write Command tia AT+CBST=
<speed>[,<name>[,<ce>]] Execution Command
n AT+CBST
OK Responses +CBST: <speed>,<name>,<ce> OK Responses OK
ERROR Responses Set default value: OK
fide Defined values
<speed> 0
n 7 o 12
14
C 16
autobauding(automatic selection of the speed; this setting is possible in case of 3.1 kHz modem and non-transparent service) 9600 bps (V.32) 9600 bps (V.34) 14400 bps(V.34) 28800 bps(V.34)
17 39 43
m 48
51
o 71
75
C80
81 83
IM84 116
S 134
33600 bps(V.34) 9600 bps(V.120) 14400 bps(V.120) 28800 bps(V.120) 56000 bps(V.120) 9600 bps(V.110) 14400 bps(V.110) 28800 bps(V.110 or X.31 flag stuffing) 38400 bps(V.110 or X.31 flag stuffing) 56000 bps(V.110 or X.31 flag stuffing) 64000 bps(X.31 flag stuffing) 64000 bps(bit transparent) 64000 bps(multimedia)
<name>
0 Asynchronous modem
1 Synchronous modem
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
200
2019-11-21
Smart Machine Smart Decision
4 data circuit asynchronous (RDI) <ce>
0 transparent 1 non-transparent NOTE: If <speed> is set to 116 or 134, it is necessary that <name> is equal to 1 and <ce> is equal
to 0.
Examples
AT+CBST=0,0,1 OK
l AT+CBST? tia +CBST:0,0,1
OK
n 13.4 AT+CRLP Radio link protocol e Description
Radio Link Protocol(RLP) parameters used when non-transparent data calls are originated may be
fid altered with write command.
Read command returns current settings for each supported RLP version <verX>. Only RLP parameters applicable to the corresponding <verX> are returned.
n Test command returns values supported by the TA as a compound value. If ME/TA supports several
RLP versions <verX>, the RLP parameter value ranges for each <verX> are returned in a separate
o line. C SIM PIN References
YES 3GPP TS 27.007
Syntax
m Test Command o AT+CRLP=? SIMCRead Command
Responses +CRLP: (list of supported <iws>s), (list of supported <mws>s), (list of supported <T1>s), (list of supported <N2>s) [,<ver1> [,(list of supported <T4>s)]][<CR><LF> +CRLP: (list of supported <iws>s), (list of supported <mws>s), (list of supported <T1>s), (list of supported <N2>s) [,<ver2> [,(list of supported <T4>s)]] [...]] OK Responses
AT+CRLP?
+CRLP: <iws>, <mws>, <T1>, <N2> [,<ver1> [, <T4>]][<CR>
<LF>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
201
2019-11-21
Smart Machine Smart Decision
+CRLP:<iws>,<mws>,<T1>,<N2>[,<ver2>[,<T4>]] [...]] OK
Write Command
Responses
AT+CRLP=<iws>
OK
[,<mws>[,<T1>[,<N2> [,<ver>[,<T4>]]]]]
ERROR
Execution Command AT+CRLP
Responses OK
l Defined values tia <ver>, <verX>
RLP version number in integer format, and it can be 0, 1 or 2; when version indication is not
present it shall equal 1.
n <iws>
IWF to MS window size.
e <mws>
MS to IWF window size.
fid <T1>
Acknowledgement timer.
<N2>
n Retransmission attempts.
<T4>
o Re-sequencing period in integer format. C NOTE: <T1> and <T4> are in units of 10 ms.
Examples
AT+CRLP?
m +CRLP:61,61,48,6,0
+CRLP:61,61,48,6,1
o +CRLP:240,240,52,6,2
OK
C 13.5 AT+CR Service reporting control SIMDescription
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
202
2019-11-21
Smart Machine Smart Decision
Write command controls whether or not intermediate result code "+CR: <serv>" is returned from the TA to the TE. If enabled, the intermediate result code is transmitted at the point during connect negotiation at which the TA has determined which speed and quality of service will be used, before any error control or data compression reports are transmitted, and before the intermediate result code CONNECT is transmitted.
SIM PIN References
YES 3GPP TS 27.007
Syntax
l Test Command tia AT+CR=?
Read Command AT+CR?
en Write Command
AT+CR=<mode>
fid Execution Command
AT+CR
Responses +CR: (list of supported <mode>s) OK
Responses +CR: <mode> OK
Responses OK
Responses Set default value: OK
n Defined values o <mode> C 0 disables reporting
1 enables reporting
<serv>
ASYNC
asynchronous transparent
m SYNC
synchronous transparent
REL ASYNC asynchronous non-transparent
o REL sync
synchronous non-transparent
GPRS [<L2P>] GPRS
CThe optional <L2P> proposes a layer 2 protocol to use between the MT and the TE.
Examples
IMAT+CR? +CR:0
S OK
AT+CR=1
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
203
2019-11-21
Smart Machine Smart Decision
13.6 AT+CRC Cellular result codes
Description
Write command controls whether or not the extended format of incoming call indication or GPRS
network request for PDP context activation is used. When enabled, an incoming call is indicated to
the TE with unsolicited result code "+CRING: <type>" instead of the normal RING.
Test command returns values supported by the TA as a compound value. SIM PIN References
l YES 3GPP TS 27.007
tia Syntax Test Command AT+CRC=? en Read Command AT+CRC? fid Write Command AT+CRC=<mode> n Execution Command Co AT+CRC
Responses +CRC: (list of supported <mode>s) OK
Responses +CRC: <mode> OK
Responses OK
Responses Set default value: OK
Defined values
<mode>
0 disable extended format
m 1 enable extended format
<type>
o ASYNC
asynchronous transparent
SYNC
synchronous transparent
CREL ASYNC
asynchronous non-transparent
REL SYNC
synchronous non-transparent
FAX
facsimile
IMVOICE
normal voice
VOICE/XXX
voice followed by data(XXX is ASYNC, SYNC, REL ASYNC or REL
S SYNC)
ALT VOICE/XXX alternating voice/data, voice first
ALT XXX/VOICE alternating voice/data, data first
ALT FAX/VOICE alternating voice/fax, fax first
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
204
2019-11-21
Smart Machine Smart Decision
GPRS
GPRS network request for PDP context activation
Examples
AT+CRC=1
OK
AT+CRC?
+CRC: 1
OK
l 13.7 AT+CLCC List current calls
tia Description
This command isused to return list of current calls of ME. If command succeeds but no calls are
n available, no information response is sent to TE. e SIM PIN References
NO 3GPP TS 27.007
fid Syntax n Test Command
AT+CLCC=?
Co Read Command
Responses +CLCC: (list of supported <n>s) OK
Responses
AT+CLCC?
+CLCC: <n>
Write Command
m AT+CLCC=<n>
Execution Command
SIMCo AT+CLCC
OK
Responses OK
Responses +CLCC:<id1>,<dir>,<stat>,<mode>,<mpty>[,<number>,<type>[,< alpha>]][<CR><LF> +CLCC:<id2>,<dir>,<stat>,<mode>,<mpty>[,<number>,<type>[,< alpha>]] [...]] OK ERROR
+CME ERROR: <err>
File
Defined values
SIM7906_SIM7912 Series_AT Command Manual_V1.01
205
2019-11-21
Smart Machine Smart Decision
<n> 0 Don't report a list of current calls of ME automatically when the current call status
changes. 1 Report a list of current calls of ME automatically when the current call status changes.
<idX> Integer type, call identification number, this number can be used in +CHLD command operations. <dir>
0 mobile originated (MO) call 1 mobile terminated (MT) call <stat>
l State of the call: 0 active tia 1 held 2 dialing (MO call) 3 alerting (MO call) n 4 incoming (MT call) 5 waiting (MT call) e 6 disconnect <mode>
fid bearer/teleservice: 0 voice 1 data 2 fax n 9 unknown
o <mpty> 0 call is not one of multiparty (conference) call parties C 1 call is one of multiparty (conference) call parties <number> String type phone number in format specified by <type>. <type>
m Type of address octet in integer format; 128 Restricted number type includes unknown type and format o 145 International number type 161 national number.The network support for this type is optional C177 network specific number,ISDN format 129 Otherwise <alpha>
IMString type alphanumeric representation of <number> corresponding to the entry found in phonebook; used character set should be the one selected with command Select TE Character Set
S AT+CSCS.
File
Examples
SIM7906_SIM7912 Series_AT Command Manual_V1.01
206
2019-11-21
Smart Machine Smart Decision
ATD10011;
OK
AT+CLCC
+CLCC: 1,0,0,0,0,"10011",129,"sm"
OK
RING (with incoming call)
AT+CLCC
+CLCC: 1,1,4,0,0,"02152063113",128,"gongsi" OK
tial 13.8 AT+CEER Extended error report Description n Execution command causes the TA to return the information text <report>, which should offer the e user of the TA an extended report of the reason for: 1 The failure in the last unsuccessful call setup(originating or answering) or in-call fid modification. 2 The last call release. 3 The last unsuccessful GPRS attach or unsuccessful PDP context activation. 4 The last GPRS detach or PDP context deactivation. n SIM PIN References Co YES 3GPP TS 27.007
Syntax
Test Command AT+CEER=?
m Execution Command o AT+CEER
Responses OK
Responses +CEER:<report> OK
C Defined values IM<report>
Wrong information which is possibly occurred.
S Examples
File
AT+CEER +CEER: Invalid/incomplete number
SIM7906_SIM7912 Series_AT Command Manual_V1.01
207
2019-11-21
Smart Machine Smart Decision
OK
13.9 AT+CCWA Call waiting
Description
This command allows control of the Call Waiting supplementary service. Activation, deactivation
and status query are supported. When querying the status of a network service (<mode>=2) the response line for 'not active' case (<status>=0) should be returned only if service is not active for any <class>. Parameter <n> is used to disable/enable the presentation of an unsolicited result code
l +CCWA: <number>,<type>,<class> to the TE when call waiting service is enabled. Command
should be abortable when network is interrogated.
tia SIM PIN References YES 3GPP TS 27.007
n Syntax e Test Command
AT+CCWA=?
fid Read Command
AT+CCWA?
on Write Command
AT+CCWA=
C <n>[,<mode>[,<class>]]
Responses +CCWA: (list of supported <n>s) OK
Responses +CCWA: <n> OK
Responses When <mode>=2 and command successful: +CCWA:<status>,<class>[<CR><LF>
om Execution Command
AT+CCWA
+CCWA: <status>, <class>[...]] OK ERROR +CME ERROR: <err>
Responses Set default value (<n>=0): OK
C Defined values IM<n>
Sets/shows the result code presentation status in the TA
S 0 disable
1 enable
<mode>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
208
2019-11-21
Smart Machine Smart Decision
When <mode> parameter is not given, network is not interrogated: 0 disable 1 enable 2 query status
<class> It is a sum of integers each representing a class of information (default 7)
1 voice (telephony) 2 data (refers to all bearer services) 4 fax (facsimile services) 7 voice,data and fax(1+2+4)
l 8 short message service
16 data circuit sync
tia 32 data circuit async
64 dedicated packet access 128 dedicated PAD access
n 255 The value 255 covers all classes
<status>
e 0 not active
1 active
fid <number>
String type phone number of calling address in format specified by <type>. <type> Type of address octet in integer format;
n 128 Restricted number type includes unknown type and format o 145 International number type C 129 Otherwise
Examples
AT+CCWA=? +CCWA:(0-1)
m OK
AT+CCWA?
o +CCWA: 0
OK
C 13.10 AT+CHLD Call related supplementary services SIMDescription
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
209
2019-11-21
Smart Machine Smart Decision
This command allows the control the following call related services:
1. A call can be temporarily disconnected from the ME but the connection is retained by the
network.
2. Multiparty conversation (conference calls).
3. The served subscriber who has two calls (one held and the other either active or alerting)
can connect the other parties and release the served subscriber's own connection.
Calls can be put on hold, recovered, released, added to conversation, and transferred. This is
based on the GSM/UMTS supplementary services. SIM PIN References
YES 3GPP TS 27.007
tial Syntax Test Command AT+CHLD=? n Write Command e AT+CHLD=<n> fid Execution Command n AT+CHLD Co Default to <n>=2.
Responses +CHLD: (list of supported <n>s) OK
Responses OK ERROR +CME ERROR: <err>
Responses OK ERROR +CME ERROR: <err>
Defined values
<n> 0 Terminate all held calls; or set User Determined User Busy for a waiting call
m 1 Terminate all active calls and accept the other call (waiting call or held call)
1X Terminate a specific call X
o 2 Place all active calls on hold and accept the other call (waiting call or held call) as the active call
C2X Place all active calls except call X on hold
3 Add the held call to the active calls 4 Connect two calls and cut off the connection between users and them simultaneously
IMExamples S AT+CHLD=?
+CHLD: (0,1,1x,2,2x,3,4)
OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
210
2019-11-21
Smart Machine Smart Decision
13.11 AT+CCFC Call forwarding number and conditions
Description
This command allows control of the call forwarding supplementary service. Registration, erasure, activation, deactivation, and status query are supported.
SIM PIN References
YES 3GPP TS 27.007
l Syntax
tia Test Command
AT+CCFC=?
Responses +CCFC: (list of supported <reason>s) OK
n Write Command
AT+CCFC=<reason>,<mode
e >[,<number>[,<type>[,<clas
s>[,<subaddr>[,<satype>[,<ti
fid me> ]]]]]]
Responses When <mode>=2 and command successful: +CCFC: <status>,<class1>[,<number>,<type> [,<subaddr>,<satype>[,<time>]]][<CR><LF> +CCFC: <status>,<class2>[,<number>,<type> [,<subaddr>,<satype>[,<time>]]][...]] OK
n ERROR
+CME ERROR:<err>
Co Defined values
<reason> 0 1
m 2
3
o 4
5
C<mode> 0 1
IM2 3
S 4
unconditional mobile busy no reply not reachable all call forwarding all conditional call forwarding
disable enable query status registration erasure
<number>
String type phone number of forwarding address in format specified by <type>.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
211
2019-11-21
Smart Machine Smart Decision
<type> Type of address octet in integer format:
145 dialing string <number> includes international access code character `+' 129 otherwise <subaddr> String type sub address of format specified by <satype>. <satype> Type of sub address octet in integer format, default 128. <classX> It is a sum of integers each representing a class of information (default 7):
l 1 voice (telephony)
2 data (refers to all bearer services)
tia 4 fax (facsimile services)
16 data circuit sync 32 data circuit async
n 64 dedicated packet access
128 dedicated PAD access
e 255 The value 255 covers all classes
<time>
fid 1...30 when "no reply" is enabled or queried, this gives the time in seconds to wait before call
is forwarded, default value 20. <status>
0 not active
n 1 active Co Examples
AT+CCFC=? +CCFC: (0,1,2,3,4,5) OK AT+CCFC=0,2
m +CCFC: 0,255
OK
Co 13.12 AT+CLIP Calling line identification presentation SIMDescription
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
212
2019-11-21
Smart Machine Smart Decision
This command refers to the GSM/UMTS supplementary service CLIP (Calling Line Identification
Presentation) that enables a called subscriber to get the calling line identity (CLI) of the calling
party when receiving a mobile terminated call.
Write command enables or disables the presentation of the CLI at the TE. It has no effect on the
execution of the supplementary service CLIP in the network.
When the presentation of the CLI at the TE is enabled (and calling subscriber allows), +CLIP:
<number>,<type>,,[,[<alpha>][,<CLI validity>]] response is returned after every RING (or
+CRING: <type>; refer sub clause "Cellular result codes +CRC") result code sent from TA to TE. It is manufacturer specific if this response is used when normal voice call is answered.
SIM PIN References
l YES 3GPP TS 27.007
tia Syntax Test Command n AT+CLIP=? e Read Command fid AT+CLIP? n Write Command Co AT+CLIP=<n>
Responses +CLIP: (list of supported <n>s) OK
Responses +CLIP: <n>,<m> OK ERROR +CME ERROR: <err>
Responses OK ERROR
Execution Command
m AT+CLIP
+CME ERROR: <err>
Responses Set default value(<n>=0): OK
o Defined values C<n>
Parameter sets/shows the result code presentation status in the TA: 0 disable
IM1 enable <m>
S 0 CLIP not provisioned
1 CLIP provisioned
2 unknown (e.g. no network, etc.)
<number>
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
213
2019-11-21
Smart Machine Smart Decision
String type phone number of calling address in format specified by <type>. <type> Type of address octet in integer format;
128 Restricted number type includes unknown type and format 145 International number type 161 national number.The network support for this type is optional 177 network specific number,ISDN format 129 Otherwise <alpha> String type alphanumeric representation of <number> corresponding to the entry found in phone
l book.
<CLI validity>
tia 0 CLI valid
1 CLI has been withheld by the originator 2 CLI is not available due to interworking problems or limitations of originating
n network e Examples
AT+CLIP=1
fid OK
RING (with incoming call) +CLIP: "02152063113",128,,,"gongsi",0
on 13.13 AT+CLIR Calling line identification restriction C Description
This command refers to CLIR-service that allows a calling subscriber to enable or disable the presentation of the CLI to the called party when originating a call. Write command overrides the CLIR subscription (default is restricted or allowed) when temporary
m mode is provisioned as a default adjustment for all following outgoing calls. This adjustment can be
revoked by using the opposite command.. If this command is used by a subscriber without
o provision of CLIR in permanent mode the network will act.
Read command gives the default adjustment for all outgoing calls (given in <n>), and also triggers
Can interrogation of the provision status of the CLIR service (given in <m>).
Test command returns values supported as a compound value.
IMSIM PIN References S YES 3GPP TS 27.007
Syntax
File
Test Command
Responses
SIM7906_SIM7912 Series_AT Command Manual_V1.01
214
2019-11-21
Smart Machine Smart Decision
AT+CLIR=?
+CLIR: (list of supported <n>s) OK
Read Command AT+CLIR?
Responses +CLIR: <n>,<m> OK
ERROR
Write Command
tial AT+CLIR=<n>
+CME ERROR: <err>
Responses OK ERROR +CME ERROR: <err>
Defined values
n <n> 0 presentation indicator is used according to the subscription of the CLIR service e 1 CLIR invocation 2 CLIR suppression
fid <m> 0 CLIR not provisioned 1 CLIR provisioned in permanent mode n 2 unknown (e.g. no network, etc.) 3 CLIR temporary mode presentation restricted o 4 CLIR temporary mode presentation allowed
C Examples
AT+CLIR=?
+CLIR:(0-2)
m OK o 13.14 AT+COLP Connected line identification presentation C Description
This command refers to the GSM/UMTS supplementary service COLP(Connected Line
IMIdentification Presentation) that enables a calling subscriber to get the connected line identity (COL) of the called party after setting up a mobile originated call. The command enables or
disables the presentation of the COL at the TE. It has no effect on the execution of the
S supplementary service COLR in the network.
When enabled (and called subscriber allows), +COLP:<number>, <type> [,<subaddr>, <satype>
[,<alpha>]] intermediate result code is returned from TA to TE before any +CR responses. It is
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
215
2019-11-21
Smart Machine Smart Decision
manufacturer specific if this response is used when normal voice call is established. When the AT+COLP=1 is set, any data input immediately after the launching of "ATDXXX;" will stop the execution of the ATD command, which may cancel the establishing of the call. SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command AT+COLP=? Read Command AT+COLP?
Write Command AT+COLP =<n>
Execution Command AT+COLP
Defined values
Responses +COLP: (list of supported <n>s)
l OK tia Responses
+COLP: <n>,<m> OK ERROR
n +CME ERROR: <err> e Responses
OK
fid ERROR
+CME ERROR: <err>
Responses
n Set default value(<n>=0, <m>=0): Co OK
<n> Parameter sets/shows the result code presentation status in the TA:
0 disable
m 1 enable o <m>
0 COLP not provisioned 1 COLP provisioned
C2 unknown (e.g. no network, etc.) IMExamples
AT+COLP?
S +COLP: 1,0 OK
ATD10086;
VOICE CALL: BEGIN
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
216
2019-11-21
Smart Machine Smart Decision
+COLP: "10086",129,,, OK
13.15 AT+VTS DTMF and tone generation
Description
This command allows the transmission of DTMF tones and arbitrary tones which cause the Mobile
l Switching Center (MSC) to transmit tones to a remote subscriber. The command can only be used
in voice mode of operation (active voice call).
tia NOTE: The END event of voice call will terminate the transmission of tones, and as an operator
option, the tone may be ceased after a pre-determined time whether or not tone duration has been reached. SIM PIN References
n NO 3GPP TS 27.007
e Syntax fid Test Command
AT+VTS=?
n Write Command o AT+VTS=<dtmf> C [,<duration>]
Responses +VTS: (list of supported<dtmf>s) OK
Responses OK
AT+VTS=<dtmf-string>
ERROR
Defined values
m <dtmf> o A single ASCII character in the set 0-9, *, #, A, B, C, D.
<duration>
CTone duration in 1/10 seconds, from 0 to 255. This is interpreted as a DTMF tone of different
duration from that mandated by the AT+VTD command, otherwise, the duration which be set the AT+VTD command will be used for the tone (<duration> is omitted).
IM<dtmf-string> A sequence of ASCII character in the set 0-9, *, #, A, B, C, D, and maximal length of the string is
S 29. The string must be enclosed in double quotes (""), and separated by commas between the ASCII
characters (e.g. "1,3,5,7,9,*"). Each of the tones with a duration which is set by the AT+VTD
command.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
217
2019-11-21
Smart Machine Smart Decision
Examples
AT+VTS=1
OK
AT+VTS=1,20
OK
AT+VTS="1,3,5"
OK
AT+VTS=? +VTS: (0-9,*,#,A,B,C,D) OK
tial 13.16 AT+VTD Tone duration
Description
n This refers to an integer <n> that defines the length of tones emitted as a result of the AT+VTS
command. A value different than zero causes a tone of duration <n>/10 seconds.
e SIM PIN References fid YES 3GPP TS 27.007
Syntax
n Test Command
AT+VTD=?
Co Read Command
Responses +VTD: (list of supported <n>s) OK
Responses
AT+VTD? Write Command
m AT+VTD=<n>
+VTD: <n> OK
Responses OK
o Defined values
C<n>
Tone duration in integer format, from 0 to 255, and 0 is factory value.
0
Tone duration of every single tone is dependent on the network.
IM1...255 Tone duration of every single tone in 1/10 seconds.
S Examples
AT+VTD=?
+VTD: (0-255)
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
218
2019-11-21
Smart Machine Smart Decision
OK AT+VTD? +VTD: 0 OK AT+VTD=5 OK
13.17 AT+CSTA Select type of address
l Description Write command is used to select the type of number for further dialing commands (ATD) according tia to GSM/UMTS specifications. Read command returns the current type of number. Test command returns values supported by the Module as a compound value. n SIM PIN References YES 3GPP TS 27.007
fide Syntax Test Command AT+CSTA=? n Read Command Co AT+CSTA?
Responses +CSTA:(list of supported <type>s) OK Responses +CSTA:<type> OK
Write Command
Responses
AT+CSTA=<type> Execution Command
m AT+CSTA
OK ERROR Responses OK
o Defined values C<type>
Type of address octet in integer format: 145 when dialling string includes international access code character "+"
IM161 national number.The network support for this type is optional 177 network specific number,ISDN format
S 129 otherwise
NOTE: Because the type of address is automatically detected on the dial string of dialing
command, command AT+CSTA has really no effect.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
219
2019-11-21
Smart Machine Smart Decision
Examples
AT+CSTA? +CSTA: 129 OK AT+CSTA=145 OK
13.18 AT+CMOD Call mode
l Description
Write command selects the call mode of further dialing commands (ATD) or for next answering
tia command (ATA). Mode can be either single or alternating.
Test command returns values supported by the TA as a compound value.
SIM PIN References
n NO 3GPP TS 27.007
e Syntax fid Test Command
AT+CMOD=?
n Read Command Co AT+CMOD?
Responses +CMOD: (list of supported <mode>s) OK
Responses +CMOD: <mode> OK
Write Command
Responses
AT+CMOD=<mode>
m Execution Command o AT+CMOD
OK ERROR
Responses Set default value: OK
C Defined values
<mode>
IM0 single mode(only supported) NOTE: The value of <mode> shall be set to zero after a successfully completed alternating mode
call. It shall be set to zero also after a failed answering. The power-on, factory and user resets shall
S also set the value to zero. This reduces the possibility that alternating mode calls are originated or
answered accidentally.
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
220
2019-11-21
Smart Machine Smart Decision
Examples
AT+CMOD? +CMOD: 0 OK AT+CMOD=0 OK
13.19 AT+CSDVC Switch voice channel device
l Description
This command is used to switch voice channel device. After changing current voice channel device
tia and if there is a connecting voice call, it will use the settings of previous device (loudspeaker
volume level, mute state of loudspeaker and microphone, refer to AT+CLVL, AT+VMUTE, and
AT+CMUT).
n SIM PIN References e NO Vendor
fid Syntax Test Command n AT+CSDVC=? o Read Command C AT+CSDVC?
Responses +CSDVC: (list of supported <dev>s) OK
Responses +CSDVC: <dev>
OK
Write Command AT+CSDVC=<dev>
Responses OK
m Defined values o <dev>
0 close voice channel device. only used after AT+CODECCTL=1
C1 handset
3 speaker phone
IMExamples S AT+CSDVC=1
OK
AT+CSDVC?
+CSDVC:1
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
221
2019-11-21
Smart Machine Smart Decision
OK
13.20 AT+CLVL Loudspeaker volume level
Description
Write command is used to select the volume of the internal loudspeaker audio output of the device. Test command returns supported values as compound value.
SIM PIN References
l NO 3GPP TS 27.007
tia Syntax Test Command n AT+CLVL=? e Read Command AT+CLVL? fid Write Command n AT+CLVL=<level>
Responses +CLVL: (list of supported <level>s) OK Responses +CLVL: <level> OK
Responses OK
ERROR
Co Defined values
<level> Integer type value which represents loudspeaker volume level. The range is from 0 to 5, and 0 represents the lowest loudspeaker volume level, 4 is default factory value. NOTE: <level> is nonvolatile, and it is stored when restart.
om Examples AT+CLVL? C+CLVL:4 OK AT+CLVL=3
SIMOK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
222
2019-11-21
Smart Machine Smart Decision
13.21 AT+SIDET Set sidetone
Description This command is used to enable or disable sidetone. Please refer to related hardware design
document for more information. This command is only used after call start.
SIM PIN References NO Vendor
Syntax
Test Command AT+SIDET=?
Read Command AT+SIDET?
Write Command AT+SIDET=<en>
Defined values
<en> 0: disable sidetone 1: enable sidetone
tial Responses
+SIDET: (list of supported <en>s) OK
Responses
n +SIDET: <en> e OK
Responses
fid OK Con ERROR
Examples
AT+SIDET?
m +SIDET: 0
OK
o AT+SIDET=?
+SIDET: (0-1)
COK
AT+SIDET=1
SIMOK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
223
2019-11-21
Smart Machine Smart Decision
14 AT Command for Hardware
14.1 AT+CBC Read the voltage value of the power supply
Description
This command is used to read the voltage value of the power supply
l SIM PIN References NO Vendor
tia Syntax n Read Command e AT+CBC
Responses +CBC: <vol> OK
ERROR
fid Defined values n <vol>
The voltage value, such as 3.8.
Co Examples
AT+CBC
+CBC: 3.591V
OK
om 14.2 AT+CVALARM Low and high voltage Alarm C Description
This command is used to open or close the low voltage alarm function.
IMSIM PIN References S NO Vendor
Syntax
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
224
2019-11-21
Smart Machine Smart Decision
Test Command
Responses
AT+CVALARM=?
+CVALARM: (list of supported <enable>s), (list of supported < <low voltage>s), (list of supported high < high voltage>s) OK
Read Command
Responses
AT+CVALARM?
+CVALARM: <enable>,<low voltage>, <high voltage>
OK
Write Command
Responses
AT+CVALARM=<enable>[,<l OK
l ow voltage>],[<high voltage>] ERROR
tia Defined values <enable> n 0 Close 1 Open. If voltage < < low voltage>, it will report "UNDER-VOLTAGE WARNNING" e every 10s. If voltage > <high voltage>, it will report "OVER-VOLTAGE WARNNING" every 10s. fid <low voltage> Between 3200mV and 4000mV. Default value is 3200. <high voltage> Between 4000mV and 4350mV. Default value is 4350. n NOTEThe three parameters will be saved automatically.
Co Examples
AT+CVALARM=1,3400,4300
OK
AT+CVALARM?
+CVALARM: 1,3400,4300
m OK
AT+CVALARM=?
o +CVALARM: (0,1),(3200-4000),(4000-4350)
OK
IMC 14.3 AT+CPMVT Low and high voltage Power Off S Description
This command is used to open or close the low and high voltage power off function.
File
SIM PIN References
SIM7906_SIM7912 Series_AT Command Manual_V1.01
225
2019-11-21
Smart Machine Smart Decision
NO Vendor
Syntax
Test Command
Responses
AT+CPMVT=?
+CPMVT: (list of supported <enable>s), (list of supported < low
voltage>s), (list of supported < high voltage>s)
Read Command AT+CPMVT?
tial Write Command
AT+CPMVT=<enable>[,<low voltage>],[<high voltage>]
OK Responses +CPMVT: <enable>,<low voltage>, <high voltage> OK
Responses OK
ERROR
n Defined values e <enable> fid 0 Close
1 Open. If voltage < < low voltage>, it will report "UNDER-VOLTAGE WARNNING POWER DOWN" and power off the module. If voltage > <high voltage>, it will report "OVER-VOLTAGE WARNNING POWER DOWN" and power off the module
n <low voltage> Between 3100mV and 4000mV. Default value is 3100.
o <high voltage> C Between 4000mV and 4300mV. Default value is 4420.
Examples
AT+CPMVT=1,3400,4300
m OK
AT+CPMVT?
o +CPMVT: 1,3400,4300
OK
CAT+CPMVT=?
+CPMVT: (0-1),(3100-4000),(4000-4420) OK
SIM14.4 AT+CPMUTEMP Read the temperature of the module
File
Description
SIM7906_SIM7912 Series_AT Command Manual_V1.01
226
2019-11-21
Smart Machine Smart Decision
This command is used to read the temperature of the module
SIM PIN References NO Vendor
Syntax
Read Command
l AT+CPMUTEMP
Responses +CPMUTEMP: <temp> OK
ERROR
tia Defined values <temp> The Temperature value, such as 29.
en Examples AT+CPMUTEMP fid +CPMUTEMP: 29 OK
n 14.5 AT+CADC0 Read ADC0 value Co Description
This command is used to read the ADC0 value from modem. ME supports 2 types of ADC0, which are raw type and voltage type.
SIM PIN References
m NO Vendor
o Syntax CTest Command
AT+CADC0=?
IMWrite Command S AT+CADC0=<adc>
Responses +CADC0: (range of supported <adc>s) OK Responses +CADC0: <value>
OK
ERROR
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
227
2019-11-21
Smart Machine Smart Decision
Defined values
<adc> ADC0 type:
0 raw type. 2 voltage type(mv) <value> Integer type value of the ADC0.
Examples
l AT+CADC0=?
+CADC0: (0,2)
tia OK
AT+CADC0=0 +CADC0: 187
n OK e 14.6 AT+CADC1 Read ADC1 value fid Description
This command is used to read the ADC1 value from modem. ME supports 2 types of ADC1, which
n are raw type and voltage type. o SIM PIN References C NO Vendor
File
Syntax
Test Command
m AT+CADC1=? o Write Command
AT+CADC1=<adc>
IMC Defined values S <adc>
Responses +CADC1: (range of supported <adc>s) OK
Responses +CADC1: <value> OK
ERROR
ADC1 type:
0 raw type.
SIM7906_SIM7912 Series_AT Command Manual_V1.01
228
2019-11-21
Smart Machine Smart Decision
2 voltage type(mv) <value> Integer type value of the ADC1.
Examples
AT+CADC1=?
+CADC1: (0,2)
OK AT+CADC1=0 +CADC1: 187
l OK
tia 14.7 AT+CADC2 Read ADC2 value
n Description e This command is used to read the ADC2 value from modem. ME supports 2 types of ADC2, which
are raw type and voltage type.
fid SIM PIN References NO Vendor
n Syntax o Test Command C AT+CADC2=?
Responses +CADC2: (range of supported <adc>s)
Write Command
m AT+CADC2=<adc>
OK
Responses +CADC2: <value> OK
ERROR
o Defined values C<adc>
ADC2 type:
IM0 raw type. 2 voltage type(mv)
S <value>
Integer type value of the ADC2.
File
Examples
SIM7906_SIM7912 Series_AT Command Manual_V1.01
229
2019-11-21
Smart Machine Smart Decision
AT+CADC2=? +CADC2: (0,2) OK AT+CADC2=0 +CADC2: 187 OK
14.8 AT+CVAUS Set state of the pin named VREG_L14_SDC
l Description This command is used to set state of the pin which is named VREG_L14_SDC. tia SIM PIN References NO Vendor
n Syntax e Test Command
AT+CVAUS=?
fid Read Command
AT+CVAUS?
on Write Command C AT+CVAUS=<state>
Responses +CVAUS: (list of supported <state>s) OK
Responses +CVAUS: <state> OK
Responses OK ERROR
Defined values
m <state> 0 the pin is closed. o 1 the pin is opend(namely, open the pin)
C Examples AT+CVAUS=1 OK
IMAT+CVAUS? +CVAUS: 1
S OK
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
230
2019-11-21
Smart Machine Smart Decision
14.9 AT+CVAUV Set microvolt of the pin named VREG_L14_SDC
Description
This command is used to set the voltage value of the pin which is named VREG_L14_SDC.
SIM PIN References
NO Vendor
Syntax
l Test Command tia AT+CVAUV=?
Read Command
n AT+CVAUV? e Write Command fid AT+CVAUV=<voltage>
Responses +CVAUV: (list of supported <voltage>s) OK
Responses +CVAUV: <voltage> OK
Responses OK ERROR
Defined values
n <voltage> o Voltage value of the pin which is named VREG_L14_SDC. The unit is in mV. And the value must C the multiple of 50mv.
File
Examples
AT+CVAUV=? +CVAUV: (1800-2850)
m OK o AT+CVAUV=2800
OK AT+CVAUV?
C+CVAUV: 2800 SIMOK
SIM7906_SIM7912 Series_AT Command Manual_V1.01
231
2019-11-21
Smart Machine Smart Decision
15 Appendixes
15.1 Verbose code and numeric code
Verbose result code OK CONNECT
l RING tia NO CARRIER
ERROR NO DIALTONE BUSY
n NO ANSWER
Numeric (V0 set) 0 1 2 3 4 6 7 8
Description Command executed, no errors, Wake up after reset Link established Ring detected Link not established or disconnected Invalid command or command line too long No dial tone, dialing impossible, wrong mode Remote station busy Connection completion timeout
e 15.2 Response string of AT+CEER
fid Number
CS internal cause
n 0 o 21
25
C 27
Response string
Phone is offline No service available Network release, no reason given Received incoming call
29
Client ended call
34
UIM not present
35
Access attempt already in progress
m 36
Access failure, unknown source
38
Concur service not supported by network
o 29
No response received from network
45
GPS call ended for user call
C46
SMS call ended for user call
47
Data call ended for emergency call
48
Rejected during redirect or handoff
IM100
Lower-layer ended call
101
Call origination request failed
102
Client rejected incoming call
S 103
Client rejected setup indication
104
Network ended call
105
No funds available
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
232
2019-11-21
Smart Machine Smart Decision
106
No service available
108
Full service not available
109
Maximum packet calls exceeded
301
Video connection lost
302
Video call setup failure
303
Video protocol closed after setup
304
Video protocol setup failure
305
CS network cause 1 3 6 8 16 17 18 19 21 22 26 27 28 29 30 31 34
Internal error
l Unassigned/unallocated number
No route to destination
tia Channel unacceptable
Operator determined barring Normal call clearing
n User busy
No user responding
e User alerting, no answer
Call rejected
fid Number changed
Non selected user clearing Destination out of order Invalid/incomplete number
n Facility rejected o Response to Status Enquiry
Normal, unspecified
CNo circuit/channel available
38
Network out of order
41
Temporary failure
42
Switching equipment congestion
m 43
Access information discarded
44
Requested circuit/channel not available
o 47
Resources unavailable, unspecified
49
Quality of service unavailable
C50
Requested facility not subscribed
55
Incoming calls barred within the CUG
57
Bearer capability not authorized
IM58
Bearer capability not available
63
Service/option not available
65
Bearer service not implemented
S 68
ACM >= ACMmax
69
Requested facility not implemented
70
Only RDI bearer is available
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
233
2019-11-21
Smart Machine Smart Decision
79
Service/option not implemented
81
Invalid transaction identifier value
87
User not member of CUG
88
Incompatible destination
91
Invalid transit network selection
95
Semantically incorrect message
96
Invalid mandatory information
97 98 99 100 101 102 111 117
CS network reject 2 3 4 5 6 7 8 9 10 11
Message non-existent/not implemented Message type not compatible with state IE non-existent/not implemented
l Conditional IE error
Message not compatible with state
tia Recovery on timer expiry
Protocol error, unspecified Interworking, unspecified
en IMSI unknown in HLR
Illegal MS
fid IMSI unknown in VLR
IMEI not accepted Illegal ME GPRS services not allowed
n GPRS & non GPRS services not allowed o MS identity cannot be derived
Implicitly detached
CPLMN not allowed
12
Location Area not allowed
13
Roaming not allowed
14
GPRS services not allowed in PLMN
m 15
No Suitable Cells In Location Area
16
MSC temporarily not reachable
o 17
Network failure
20
MAC failure
C21
Synch failure
22
Congestion
23
GSM authentication unacceptable
IM32
Service option not supported
33
Requested service option not subscribed
34
Service option temporarily out of orde
S 38
Call cannot be identified
40
No PDP context activated
95
Semantically incorrect message
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
234
2019-11-21
Smart Machine Smart Decision
96
Invalid mandatory information
97
Message type non-existent
98
Message type not compatible with state
99
Information element non-existent
101
Message not compatible with state
161
RR release indication
162
RR random access failure
163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179
PS internal cause lookup 0
RRC release indication RRC close session indication RRC open session failure
l Low level failure
Low level failure no redial allowed
tia Invalid SIM
No service Timer T3230 expired
n No cell available
Wrong state
e Access class blocked
Abort message received
fid Other cause
Timer T303 expired No resources Release pending
n Invalid user data Co Invalid connection identifier
1
Invalid NSAPI
2
Invalid Primary NSAPI
3
Invalid field
m 4
SNDCP failure
5
RAB setup failure
o 6
No GPRS context
7
PDP establish timeout
C8
PDP activate timeout
9
PDP modify timeout
10
PDP inactive max timeout
IM11
PDP lowerlayer error
12
PDP duplicate
13
Access technology change
S 14
PDP unknown reason
File
PS network cause
SIM7906_SIM7912 Series_AT Command Manual_V1.01
235
2019-11-21
Smart Machine Smart Decision
25
LLC or SNDCP failure
26
Insufficient resources
27
Missing or unknown APN
28
Unknown PDP address or PDP type
29
User Authentication failed
30
Activation rejected by GGSN
31
Activation rejected, unspecified
32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 81 95 96 97 98
Service option not supported Requested service option not subscribed Service option temporarily out of order
l NSAPI already used (not sent)
Regular deactivation
tia QoS not accepted
Network failure Reactivation required
n Feature not supported
Semantic error in the TFT operation
e Syntactical error in the TFT operation
Unknown PDP context
fid PDP context without TFT already activated
Semantic errors in packet filter Syntactical errors in packet filter Invalid transaction identifier
n Semantically incorrect message o Invalid mandatory information
Message non-existent/not implemented
CMessage type not compatible with state
99
IE non-existent/not implemented
100
Conditional IE error
101
Message not compatible with state
m 111
Protocol error, unspecified
o 15.3 Summary of CME ERROR codes
C Description
This result code is similar to the regular ERROR result code. The format of <err> can be either
IMnumeric or verbose string, by setting AT+CMEE command. SIM PIN References
S NO 3GPP TS 27.007
File
Syntax
SIM7906_SIM7912 Series_AT Command Manual_V1.01
236
2019-11-21
Smart Machine Smart Decision
+CME ERROR: <err>
Defined values
<err>
Values (numeric format followed by verbose format):
0
phone failure
1 2 3 4 5 6 7 10 11 12 13 14 15 16 17 18 20 21 22 23
no connection to phone phone adaptor link reserved operation not allowed
l operation not supported
PH-SIM PIN required
tia PH-FSIM PIN required
PH-FSIM PUK required SIM not inserted
n SIM PIN required
SIM PUK required
e SIM failure
SIM busy
fid SIM wrong
incorrect password SIM PIN2 required
n SIM PUK2 required
memory full
o invalid index
not found
C memory failure
24
text string too long
25
invalid characters in text string
26
dial string too long
m 27
invalid characters in dial string
30
no network service
o 31
network timeout
32
network not allowed - emergency calls only
C40
network personalization PIN required
41
network personalization PUK required
42
network subset personalization PIN required
IM43
network subset personalization PUK required
44
service provider personalization PIN required
S 45
service provider personalization PUK required
46
corporate personalization PIN required
47
corporate personalization PUK required
100 Unknown
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
237
2019-11-21
Smart Machine Smart Decision
103 Illegal MESSAGE 106 Illegal ME 107 GPRS services not allowed 111 PLMN not allowed 112 Location area not allowed 113 Roaming not allowed in this location area 132 service option not supported 133 requested service option not subscribed 134 service option temporarily out of order 148 unspecified GPRS error
l 149 PDP authentication failure
150 invalid mobile class
tia 257 network rejected request
258 retry operation 259 invalid deflected to number
n 260 deflected to own number
261 unknown subscriber
e 262 service not available
263 unknown class specified
fid 264 unknown network message
273 minimum TFTS per PDP address violated 274 TFT precedence index not unique 275 invalid parameter combination
n "CME ERROR" codes of MMS: o 170 Unknown error for mms
171 MMS task is busy now
C 172 The mms data is over size
173 The operation is overtime 174 There is no mms receiver 175 The storage for address is full
m 176 Not find the address
177 Invalid parameter
o 178 Failed to read mss
179 There is not a mms push message
C180 Memory error
181 Invalid file format 182 The mms storage is full
IM183 The box is empty 184 Failed to save mms 185 It's busy editing mms now
S 186 It's not allowed to edit now 187 No content in the buffer 188 Failed to receive mms
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
238
2019-11-21
Smart Machine Smart Decision
189 Invalid mms pdu 190 Network error 191 Failed to read file 192 None "CME ERROR" codes of FTP: 201 Unknown error for FTP 202 FTP task is busy 203 Failed to resolve server address 204 FTP timeout 205 Failed to read file
l 206 Failed to write file
207 It's not allowed in current state
tia 208 Failed to login
209 Failed to logout 210 Failed to transfer data
n 211 FTP command rejected by server
212 Memory error
e 213 Invalid parameter
214 Network error
fid Examples AT+CPIN="1234","1234" n +CME ERROR: incorrect password
Co 15.4 Summary of CMS ERROR codes Description
Final result code +CMS ERROR: <err> indicates an error related to mobile equipment or network. The operation is similar to ERROR result code. None of the following commands in the same
m command line is executed. Neither ERROR nor OK result code shall be returned. ERROR is
returned normally when error is related to syntax or invalid parameters. The format of <err> can be
o either numeric or verbose. This is set with command AT+CMEE.
SIM PIN References
C--- 3GPP TS 27.005 IMSyntax S +CMS ERROR: <err>
File
Defined values
<err>
SIM7906_SIM7912 Series_AT Command Manual_V1.01
239
2019-11-21
Smart Machine Smart Decision
300 ME failure 301 SMS service of ME reserved 302 Operation not allowed 303 Operation not supported 304 Invalid PDU mode parameter 305 Invalid text mode parameter 310 SIM not inserted 311 SIM PIN required 312 PH-SIM PIN required 313 SIM failure
l 314 SIM busy
315 SIM wrong
tia 316 SIM PUK required
317 SIM PIN2 required 318 SIM PUK2 required
n 320 Memory failure
321 Invalid memory index
e 322 Memory full
330 SMSC address unknown
fid 331 no network service
332 Network timeout 340 NO +CNMA ACK EXPECTED 341 Buffer overflow
n 342 SMS size more than expected o 500 unknown error C Examples
AT+CMGS=02112345678
SIMCom +CMS ERROR: 304
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
240
2019-11-21
Smart Machine Smart Decision
Contact us: Shanghai SIMCom Wireless Solutions Ltd.
Add: Building B, SIM Technology Building, No.633, Jinzhong Road, Changning District 200335
Tel: +86 21 3157 5100\3157 5200 Email: simcom@simcom.com Website: www.simcom.com
Confidential SIMCom
File
SIM7906_SIM7912 Series_AT Command Manual_V1.01
241
2019-11-21
yingfei.wei Adobe PDF Library 10.0
