STM32L5 MCU series excellence in ultra-lowpower with more security STM32L5 series MPU High Perf MCUs Mainstream MCUs STM32F0 106 CoreMark 48 MHz Cortex-M0 Ultra-low Power MCUs Wireless MCUs STM32L0 75 CoreMark 32 MHz Cortex-M0+ STM32G0 142 CoreMark 64 MHz Cortex-M0+ STM32L1 93 CoreMark 32 MHz Cortex-M3 STM32F2 Up to 398 CoreMark 120 MHz Cortex-M3 STM32F1 177 CoreMark 72 MHz Cortex-M3 STM32F4 Up to 608 CoreMark 180 MHz Cortex-M4 STM32F7 1082 CoreMark 216 MHz Cortex-M7 STM32F3 245 CoreMark 72 MHz Cortex-M4 STM32G4 550 CoreMark 170 MHz Cortex-M4 Optimized for mixed-signal Applications STM32MP1 4158 CoreMark 650 MHz Cortex �A7 209 MHz Cortex �M4 STM32H7 Up to 3224 CoreMark Up to 550 MHz Cortex -M7 240 MHz Cortex -M4 STM32L4 273 CoreMark 80 MHz Cortex-M4 STM32WL 162 CoreMark 48 MHz Cortex-M4 48 MHz Cortex-M0+ STM32L4+ 409 CoreMark 120 MHz Cortex-M4 STM32WB 216 CoreMark 64 MHz Cortex-M4 32 MHz Cortex-M0+ STM32L5 443 CoreMark 110 MHz Cortex-M33 STM32U5 651 CoreMark 160 MHz Cortex-M33 Optimized for mixed-signal applications Cortex-M0+ Radio co-processor 2 Main concerns for embedded design � Security � Increase the robustness against attacks � Low power consumption � Long life time, small battery size � Integration, performance, ecosystem � Best fit versus the application requirements 3 First STM32 based on Cortex-M33 STM32L5 is the answer � More security with TrustZone and ST security implementation � HW to increase resistance to logical and board level attack � Lower Power consumption � STM32 ultra-low-power technology � Integration, performance, ecosystem � More performance, choice of packages and wide ecosystem 4 Security: TrustZone for isolation ST implementation provides a high granularity of isolation STM32L5 Un-Trusted Trusted Un-Trusted Application Trusted Application � Each GPIO or peripheral, DMA channel, clock configuration register, ART or small part of Flash memory or SRAM can be configured as Trusted or un-Trusted � Full isolation of trusted and non-trusted worlds 5 Security: TrustZone for isolation TrustZone provides full isolation Example of IoT application implementation STM32L5 Un-Trusted Trusted Un-Trusted Application Trusted Application RF Sensors 6 Privileged Security: TrustZone and privileged zones STM32L5 Un-Trusted Trusted Un-Trusted & Privileged Trusted & Privileged Un-Trusted & Un-Privileged Trusted & Un-Privileged � More partitioning � Possibility to separate the trusted and un-trusted area with privileged and un-privileged zone � Strong granularity to define each part of memory or each peripheral, DMA channel as privileged or un-privileged Un-Privileged 7 TrustZone: example STM32L5 Un-Trusted Trusted Un-Trusted & Privileged Trusted & Privileged RTOS Secured Keys Secured Boot Privileged Un-Privileged Un-Trusted & Un-Privileged Trusted & Un-Privileged Secured data RF RF Stack Sensor IP Sensors 8 Encryption Decryption Authentication � AES-128/256 Encryption � SHA-256 Authentication � Public Key Acceleration (PKA): for RSA, Diffie-Hellmann or ECC (Elliptic Curve Cryptography) � Certified Crypto library � True Random Number Generator � Unique ID � OTP Zone STM32L5 A full set of security Memory & IP Protection � Active and static Anti-tamper detection � Memory Protection Unit (MPU) � Secure Boot � Read and Write Protection � HDP (Hide Protect) � Unique Boot Entry � OTFDEC (On-the-fly decryption) on Octo SPI to protect external memory � JTAG fuse � TrustZone � SFI (Secure Firmware Installation) 9 Extends battery lifetime � STM32L5 reuses the STM32L4/L4+ technology achieving best-in-class power consumption � STM32L5 integrates an optional SMPS (DC/DC buck voltage regulator) which can be enabled/disabled on the fly to avoid external noise for external RF or data acquisition. � Proven by EEMBC test results: 370 ULPMark-CP 54 ULPMark-PP 10 Ultra-low-power modes Best power consumption numbers with full flexibility Wake-up time VBAT 250 �s Shutdown 3 nA / 187 nA* 17 nA / 122 nA* Tamper detection: 3 I/Os, RTC Wake-up sources: reset pin, 5 I/Os, RTC 14 �s 14 �s 5 �s 6 cycles Standby 108 nA / 222 nA* Standby + 4-Kbyte RAM 272 nA / 386nA* Wake-up sources: + BOR, IWDG Stop 2 (full retention: 256-Kbyte RAM) 3.0 �A / 3.1 �A* Wake-up sources: + all I/Os, PVD, COMPs, I�C, LPUART, LPTIM Sleep 26 �A / MHz Wake-up sources: any interrupt or event Run up to 110 MHz Down to 62 �A / MHz Note : * without RTC / with RTC 11 More performance Better responsiveness of the application � New Arm� Cortex�-M33 performance: +20% versus Cortex-M4 1.5 DMIPS/MHz 4.02 CoreMark/MHz 165 DMIPS 442 CoreMark � New ST ART AcceleratorTM: working both on internal and external Flash � 8 Kbytes of instruction cache 12 High integration and innovation Large memory, USB Type-CTM w/ power delivery controller, CAN FD 13 7 packages, several options Large portfolio 14 STM32L ULP portfolio STM32L5 completes the ultra-low-power subclass Cost-smart ULP champion STM32L0 Cortex-M0+ at 32 MHz 1.65 to 3.6V 8-/16-bit applications Wide range of pin-counts 3 product lines, Cost-effective, Smaller packages, USB, LCD, Analog 8 to 192 Kbytes of Flash, Up to 20 Kbytes of SRAM Broad-range foundation STM32L1 Cortex-M3 at 32 MHz 1.65 to 3.6V Wide choice of memory sizes 3 product lines, USB, LCD, AES, Rich Analog True EEPROM, Dual-bank Flash memory (RWW), 32 to 512 Kbytes of Flash, Up to 80 Kbytes of SRAM ULP With performance STM32L4 Cortex-M4 w/ FPU at 80 MHz 1.71 to 3.6V High-performance, advanced analog circuits 5 product lines, 5-MSPS ADC, PGA, Compar., DAC, Op Amp, USB OTG, LCD, AES 64 Kbytes to 1 Mbyte Up to 320 Kbytes of SRAM ULP with more performance STM32L4+ Cortex-M4 w/ FPU at 120 MHz 1.71 to 3.6V Wide choice of memory sizes 3 product lines, 5-MSPS ADC, PGA, Compar., DAC, Op Amp, USB OTG, LCD, AES 1 to 2 Mbytes of Flash, Up to 640 Kbytes of SRAM Advanced security STM32L5 Cortex-M33 w/ FPU at 110 MHz 1.71 to 3.6V Wide choice of memory sizes 1 product line, 5-MSPS ADC, PGA, Compar., DAC, Op Amp, USB Type C, AES 256 to 512 Kbytes of Flash, Up to 256 Kbytes of SRAM 15 A Complete Ecosystem STM32CubeL5 One-stop-shop software package STM32Cube Middleware Generic Middleware � FreeRTOS � FatFS file system � mbedTLS and mbedCrypto � USB Device stacks Dedicated Middleware � Secure Boot and Secure Firmware Update � TF-M for trusted execution environment � USB-PD device driver � STM32 Touch Sensing library Peripheral drivers HAL API Hardware Abstraction Layer, highly portable and easy to use LL APIs Low-Layer APIs, light weight and highly optimized for runtime efficiency Project Examples STM32CubeMX ready More than 300 project examples for KEIL, IAR and STM32CubeIDE toolchains, with a STM32CubeMX configuration file www.st.com/stm32cubel5 17 SBSFU and TF-M in STM32CubeL5 Reference code framework for a trusted Execution Environment STM32L5 Un-Trusted Un-Privileged Un-Trusted Privileged TF-M (Application Root of Trust) TF-M (PSA Root of Trust) SBSFU TF-M (PSA immutable Root of Trust) TF-M Framework � Isolation and Secure execution � Secure services (crypto, initial attestation, secure storage) � Easy addition of user secure services � Leveraging STM32L5 security features SBSFU TF-M � Secure Boot � Secure Firmware Update 18 STM32L5 is one of the first MCU PSA Level 2 certified 19 All-in-1 STM32 development tool STM32CubeIDE Configure and generate code STM32CubeMX integrated Develop code, Compile and Link TrustZone support Program and Debug TrustZone support � TrueSTUDIO / SW4STM32 importer � Advanced editor � GNU C/C++ for Arm� toolchain � GDB and OpenOCD debugger � Support of ST-Link and J-Link debug probes 20 Partners IDEs development flow Arm V8-M TrustZone architecture support STM32CubeMX STM32CubeMX enhanced for TrustZone � Peripherals/middleware configuration � Resources allocation to security domains IDEs Compile and Debug TrustZone Support � Partners IDE � STM32CubeIDE based on Eclipse � TrustZone debugging STM32 Programming Tool ST M32CubeProgrammer � Device and memory configuration � Program the application � Secure Firmware Install Optional step 21 Configuration tool Power Consumption Calculator Code Generation TrustZone support macOS� MCU or board Selector Load an Example .ioc file Pinout Configuration Middleware Parameters FreeRTOS FatFS USB device Clock Tree Initialization Peripherals Configuration TrustZone configuration and GPIOs, memories, DMA, peripherals allocation to security domains 22 macOS� All-in-one programming software tool MCU Internal Flash and external Flash services MCU configuration (Option bytes) Intuitive GUI Command Line Interface for scripting API DLL for Custom Integration STLink (JTAG, SWD) STM32 Bootloader Interface (USB, UART, SPI, I2C, CAN) Secure Firmware install (SFI) 23 STM32L5 hardware solutions Speed-up evaluation prototyping and design $275 Evaluation Boards Full feature STM32L5 evaluation � STM32L552E-EV $76 Discovery Kit Flexible prototyping & demo � STM32L562E-DK $20 Nucleo Boards Affordable and quick prototyping � NUCLEO-L552ZE-Q 24 Discovery kit Prototype your wearable or sensor application with STM32L562E-DK Fan-out expansion board included Key Features � STM32L562 MCU with AES and PKA � 240 x 240 pixel-TFT color Display � state-of-the-art Energy Meter � 3D accelerometer and 3D gyroscope � Bluetooth� V4.1 low energy module � Audio Codec and Headphone amplifier � Digital microphone � USB Type-CTM Sink device FS � 512Mbit Octal Flash memory extension � ST-Link V3 � STMod+ connector with fan-out expansion board for Wi-Fi�, Grove and mikroBUSTM compatible connectors 25 STM32CubeMonitor-power State-of-the-art on-board power consumption measurement STM32L562E-DK On-board Energy Meter 300 nA to 150 mA measurement range 26 Secure your production flow with Secure Firmware Install (SFI) Protect your code and control the number of products manufactured Customer premises Untrusted environment Encrypted FW transfer FW Encrypted FW Store encryption key and production counter into HSM ST Hardware Secure Module (HSM) HSM HSM physical transfer STM32L5 SFI Authenticate target STM32 Generate installation license HSM Number of products controlled 27 STM32L5 helps designers to answer IoT challenges � More security � Lower power consumption � Integration, performance, ecosystem Conclusion 28 Releasing your creativity /STM32 @ST_W orld community.st.com www.st.com/STM32L5 STM32L5 Online Training wiki.st.com/stm32mcu github.com/STMicroelectronics STM32L5 blog articles Thank you � STMicroelectronics - All rights reserved. ST logo is a trademark or a registered trademark of STMicroelectronics International NV or its affiliates in the EU and/or other countries. For additional information about ST trademarks, please refer to www.st.com/trademarks. All other product or service names are the property of their respective owners.
