快速指南
File info: application/pdf · 14 pages · 983.89KB
快速指南
Multimedia Player for Transportation XI'AN NOVASTAR TECH ...
Specifications MBOX600 Multimedia Player for Transportation V1.2.0 NS120100578 User Manual XI'AN NOVASTAR TECH CO.,LTD.
XI'AN NOVASTAR TECH CO.,LTD. - Stage Lighting Store
The MBOX600 is an independent sending device from NovaStar, featuring big loading capacity. It is applicable to the scenarios where no PC is used to control ...
Multimedia Player for Transportation XI'AN NOVASTAR TECH CO.,LTD.
Specifications MBOX600 Multimedia Player for Transportation V1.2.0 NS120100578 User Manual XI'AN NOVASTAR TECH CO.,LTD.
Full PDF Document
If the inline viewer fails, it will open the original document in compatibility mode automatically. You can also open the file directly.
Extracted Text
MBOX600 Multimedia Player for Transportation V1.2.0 NS120100578 SUpseecrifMicatniounasl MBOX600 Industrial Controller User Manual Change History Change History Version V1.2.0 V1.1.9 V1.1.8 V1.1.7 V1.1.6 V1.1.5 Release Date Description 2019-06-15 Updated the cover and back cover. 2019-04-12 None. 2019-03-15 None. 2019-03-10 Add descriptions of changing system language. 2019-03-04 Updated hardware connection diagram and description of the front panel. 2019-03-01 First release www.novastar.tech i MBOX600 Industrial Controller User Manual Contents Contents Change History..................................................................................................................................i 1 About This Document..................................................................................................................1 2 Hardware Connection .................................................................................................................. 2 3 Software Installation .................................................................................................................... 3 3.1 Preinstalled with Linux ................................................................................................................................. 3 3.1.1 Installing Windows .................................................................................................................................... 3 3.1.2 Installing Applications ............................................................................................................................... 3 3.1.3 Checking Configuration Options ............................................................................................................... 4 3.1.4 Changing System Language .................................................................................................................... 7 3.2 Preinstalled with Windows ........................................................................................................................... 7 3.2.1 Activating Windows................................................................................................................................... 7 3.2.2 Installing Applications ............................................................................................................................... 7 3.2.3 Checking Configuration Options ............................................................................................................... 8 3.2.4 Changing System Language .................................................................................................................... 8 4 Screen Configuration ................................................................................................................... 9 5 Program Playback ....................................................................................................................... 10 5.1 Remote Publishing (VPlayer+VNNOX) ..................................................................................................... 10 5.2 Local Playback (NovaStudio) .................................................................................................................... 10 5.3 Preview Playback (VPlayer+ViPlex Express) ............................................................................................ 10 www.novastar.tech ii MBOX600 Industrial Controller User Manual 1 About This Document 1 About This Document The MBOX600 is an independent sending device from NovaStar, featuring big loading capacity. It is applicable to the scenarios where no PC is used to control the LED display. This document introduces the main operations of the MBOX600, including hardware connection, software installation, screen configuration and program playback, to help users get started with the product. www.novastar.tech 1 MBOX600 Industrial Controller User Manual 2 Hardware Connection Front Panel 2 Hardware Connection Note: The 4G module and SIM card are not hot-pluggable. Only the 4G modules from GosuncnWelink are supported. Rear Panel www.novastar.tech 2 MBOX600 Industrial Controller User Manual 3 Software Installation 3 Software Installation 3.1 Preinstalled with Linux For the MBOX600 preinstalled with Linux, if necessary, install Windows and required applications according to the description in this section. 3.1.1 Installing Windows Please buy Windows from official channels and install it. 3.1.2 Installing Applications Required Software Table 3-1 Applications Name Description Where to Get .NET Framework 4.6.x Software operating environment www.novastar.tech VPlayer Playback software, used to play programs from VNNOX and preview and play programs from ViPlex Express http://www.en.vnnox.com/#do wnloadSyn ViPlex Express LAN-based screen management software, mainly used for screen management, program editing and publishing http://www.en.vnnox.com/#do wnloadT NovaLCT Screen configuration software, used to adjust the screen to the optimal display condition www.novastar.tech NovaStudio Playback software, mainly used for multi-screen, multiprogram and multi-window www.novastar.tech www.novastar.tech 3 MBOX600 Industrial Controller User Manual 3 Software Installation Name GosuncnWelink Drivers Nova 4G Redial Service Description playback GosuncnWelink 4G module drivers 4G auto-dial service Where to Get Please contact technical support engineers. Please contact technical support engineers. Installation Please note that ".NET Framework 4.6.x" must be installed first. During the installation of "Nova 4G Redial Service", please put the installation package in the root directory of disk C and run the "install.bat" file in the installation package as an administrator. The installation of other software is the same as the installation of common applications. If "GosuncnWelink Drivers" and "Nova 4G Redial Service" are not installed, the 4G function may not work normally. 3.1.3 Checking Configuration Options To ensure stable playback of MBOX600, please check the Windows configuration options according to the description in this section. Configuration Options The configuration options to be checked are shown in Table 3-2. If a configuration option does not conform to the target status, please change it. Table 3-2 Configuration options Configuration Options Windows automatic update Firewall Turn off screen Sleep Target Status Off Off Never Never Scaling size Multiple displays 100% Duplicate these displays Operation Access Click in Windows Start menu to enter the menu page as shown in Figure 3-1. www.novastar.tech 4 MBOX600 Industrial Controller User Manual Figure 3-1 Windows settings 3 Software Installation Checking Windows Automatic Update Step 1 Choose Update & Security. Step 2 On the Windows Update page, click Advanced options. Step 3 Check whether Windows automatic update is turned off. Check the Firewall Step 1 Choose Update & Security. Step 2 Choose Windows Security. Step 3 Click Open Windows Defender Security Center. Step 4 Check whether the firewall is turned off. www.novastar.tech 5 MBOX600 Industrial Controller User Manual 3 Software Installation Checking Screen Off and Sleep Step 1 Choose System. Step 2 Choose Power & sleep. Step 3 Check whether all the four configuration options are set to Never. Checking Scaling Size and Multiple Displays Step 1 Choose System. Step 2 Check whether the scaling size is 100% and the option of multiple displays is set to Duplicate these displays. Note: When multiple monitors are connected, the configuration option for multiple displays will appear. www.novastar.tech 6 MBOX600 Industrial Controller User Manual 3 Software Installation 3.1.4 Changing System Language If necessary, users can change the system language. Step 1 Click in Windows Start menu. Step 2 Choose Time & Language. Step 3 Choose Region & language and choose a language to set it as the system language. 3.2 Preinstalled with Windows For MBOX600 preinstalled with Windows 10 IOT Enterprise, please activate Windows and install required applications according to the description in this section. 3.2.1 Activating Windows View the registration code on the enclosure and activate Windows. 3.2.2 Installing Applications MBOX600 is preinstalled with Windows and the applications shown in Table 3-3. NovaStudio is not preinstalled. If necessary, users can visit www.novastar.tech to get and install NovaStudio. www.novastar.tech 7 MBOX600 Industrial Controller User Manual 3 Software Installation Table 3-3 Applications Name Description Where to Get .NET Framework 4.6.x Software operating environment www.novastar.tech VPlayer Playback software, used to play programs from VNNOX and preview and play programs from ViPlex Express http://www.en.vnnox.com/#do wnloadSyn ViPlex Express LAN-based screen management software, mainly used for screen management, program editing and publishing http://www.en.vnnox.com/#do wnloadT NovaLCT Screen configuration software, used to adjust the screen to the optimal display condition www.novastar.tech GosuncnWelink Drivers GosuncnWelink 4G module drivers Please contact technical support engineers. Nova 4G Redial Service 4G auto-dial service Please contact technical support engineers. 3.2.3 Checking Configuration Options For more information, see 3.1.3 Checking Configuration Options. 3.2.4 Changing System Language For more information, see 3.1.4 Changing System Language. www.novastar.tech 8 MBOX600 Industrial Controller User Manual 4 Screen Configuration 4 Screen Configuration NovaLCT is used to configure receiving card parameters. You can configure parameters manually or by loading configuration files. For more information, see NovaLCT LED Configuration Tool Synchronous System User Guide attached in the software. www.novastar.tech 9 MBOX600 Industrial Controller User Manual 5 Program Playback 5 Program Playback When the MBOX600 is installed with VPlayer and NovaStudio, the following three playback solutions will be supported. Remote publishing VNNOX cloud-based publishing service publishes programs to VPlayer and then VPlayer downloads and plays the programs. Local playback Create and play programs with NovaStudio. Preview playback Use VPlayer to preview programs created in ViPlex Express. 5.1 Remote Publishing (VPlayer+VNNOX) For more information, click the link below to see the online document VNNOX CloudBased Publishing Service Quick Start Guide. http://docs.vnnox.com:8090/display/EN/3++Quick+Start+Guide 5.2 Local Playback (NovaStudio) For more information, see NovaStudio User Manual attached in the software. 5.3 Preview Playback (VPlayer+ViPlex Express) For more information, see the Quick Start Guide chapter of ViPlex Express LANBased Screen Management Software User Manual attached in ViPlex Express. www.novastar.tech 10
