Automated AI Temperature Sensing System (AATSS)
Model V2 USER MANUAL
Please Note:
This Manual is to ensure that the user can use the product correctly, to avoid danger or property loss in operation. So please read it carefully before using this product and keep it for future reference. Without written permission, no entity or individual is allowed to extract, copy, translate or modify all or part of this manual in any way. Unless otherwise agreed, the company does not provide any express or implied statement or guarantee for this manual
Attention Do not splash liquid or metal on the outer screen to avoid scratches or damages Use specialized detergent to clean the equipment to avoid watermarks Please ensure that the equipment is well grounded to avoid interference and damage to video and audio signals

- 1 -

1. About AATSS model V2 The V2 is designed for easy integration into your local area network and existing access control systems. Combining high-precision infrared temperature detection with face recognition technology and a full suite of software functions, the AATSS V2 is the finalized all-in-one solution for fully-automated quick contactless temperature screening. 2. Quick installation
2.1. Stand installation The AATSS V2 comes with a Table Stand, if you ordered a Display Pedestal, the installation method is very similar.
2.1.1. Open stand base backside, use the screw driver to remove the backside cover.

- 2 -

2.1.2. Slip the V2 interface cables through the center hole of the Stand Base
2.1.3. Affix the V2 to the Stand Base and secure from the bottom using the helix nut provided

- 3 -

2.1.4. Connect the USB, Ethernet, and Power Cable to the Stand Base connectors 2.1.5. Pass all the data interface cables through the hole in the stand backside cover.

- 4 -

2.1.6. Secure the backside cover using screws

2.1.7. Complete installation, adjust the screen to the side with the blue light bar.

- 5 -

2.2. Power adapter connection and ethernet connection
Connect the power supply to the base of the stand. The system will start automatically after powering on, the boot time is about 30 - 40 seconds.
If you need to manage the V2 through a network, connect the base to your router through an ethernet cable. For how to set up the network, please refer to the following Software section.
If you would like to connect the device to an existing access control system, please refer to the Access Control Integration section.

- 6 -

3. Software Note: We recommend using Windows 10 when managing the AATSS V2.
3.1. Network Preparation After connect the V2 and the router using an ethernet cable, you must make sure the V2 is within the same intranet as your computer. See Section 3.2.

- 7 -

3.2. Network Configuration (Please read carefully)
The default IP address of the V2 is 192.168.1.8.
You will need to change your computer's static IP address to be on the same network segment as V2. You can change your IP address to 192.168.1.XXX (XXX here could be from 2~254, but not 8 to avoid conflict with V2. So for example, 192.168.1.200 will work).
Subnet mask: 255.255.255.0
Default gateway: Ask your network administrator for gateway IP. If you don't know the gateway IP address, leave it blank.

If you have trouble, you can refer to a video demonstration for setting up the network on our website, www.richtech-ai.com
After that is complete, open Internet Explorer 10 or higher and put 192.168.1.8 in the URL and hit enter. This will connect to the V2 management portal.

- 8 -

3.3. Plugin Installation You will be guided to install a plug-in. Click the download link to download it and install the plug-in. Allow all access when prompted.
After installing the plug-in, visit 192.168.1.8 again to open the login page.

Initial username is admin, and the password is blank. After logging in, change your login information at:
Remote Settings -> System Configuration -> User Management.

- 9 -

3.4. Network Configuration
The default IP address of the V2 is 192.168.1.8. If you want to change the IP address to a different one, you can so in Remote Settings -> Network Configuration.
Please ask your network administrator about which IP address is allowed on your network. Please remember to keep V2's IP address in the same segment as your computer terminal.

You can always find the V2's IP address on left corner of its screen.
3.5. Face Recognition Library Setup
To input all your employees into the system, you will need to collect each employee's photo (each file should be less than 256k). You can add photos one by one or in a batch. Please enter all employee photos and names into the Whitelist group. If you want to block some from accessing your facility, please input the photo into the Blacklist group.

- 10 -

3.6. Record Query You can check all the face detection records and temperature records by going to:
Smart Configuration -> Records menu You can search data by time, face library, employee name, etc.
3.7. Temperature Monitoring The default normal temperature value is set to 96.1~99. It's not recommended to change this default value. Tick Enable from Temperature Monitoring option to active high temperature alarm.

- 11 -

3.8. User Management V2 allows one administrator account and five more normal user accounts. Only the administrator account can modify device parameters, all the other accounts can only view the data.
To check each account's login history, please go to: Remote Settings->System Configuration->Log Query

- 12 -

3.9. Email Notification Config.
To setup email notification, you can input your email account information from: Remote Settings -> Network Configuration -> Email Config
Please make sure the V2 can access internet through your local network.

3.10. Local Settings
To keep snapshots on local computer, please choose the disk and directory where you want to store pictures.

- 13 -

3.11. Firmware Updates
To update V2 with latest firmware, please get the firmware package from your reseller or official website. Install it from:
Remote Settings -> System Maintenance -> Firmware update. System will restart automatically when the update completes.

- 14 -

4. Integration 4.1. Interfaces

P1: USB

P7: Relay

P4: Reset P5: Alarm P6: Ethernet

P3: WG

P1: USB Host o Peripheral connection o Use: connect external devices like a USB storage stick

P2: DC

P2: DC o Power adapter: 12V

P3: Wiegand interface o Supports Weigand protocol o -WGI0 o +WGI1

P4: Reset button o Press for 5 seconds to restore default factory configuration

P5: Alarm o -GND o +ALMO o Alarm output 1: Output 3.3V when its inactive; output 0V when it's active

P6: Ethernet Port o Supports 100M network

- 15 -

P7: Relay Interface o Provides switch signal o Use: electronic door locks etc.

Default staus: Open. Default staus: Close.

RELAY DEFAULTS

4.2. Sample integration
Most electronic door system can be controlled through the relay interface. With our embedded program, you only need to connect the V2 with your existing door control system through relay interface and .
Here is an example of the hardware integration and software configuration.

Scan your temp.

Door opens

- 16 -

4.2.1. Hardware integration
Install V2 onto door base

Open door control system

Get V2 Interfaces ready Find DC/Ethernet/Relay Interface

- 17 -

Connect network cable with Ethernet port

Connect door control interface with and Connect 12V DC Power Adapter

- 18 -

Check all the connections
4.2.2. Software configuration To setup electronic door's open rules, please open Door Access from the Smart Configuration menu. There are three options:
· Face recognition: Detect if the visitor's face matches whitelist group & ignore temperature
· Temperature: Detect if visitor's temperature is normal only & ignore face recognition
· Temperature & Face: Only allow people from whitelist with normal temperature to enter

- 19 -
