1 Refractometer
1
1 Refractometer
The sanitary refractometers PR-43-AC and PR-43-AP provide a digital interface detection system for alimentary industry. The PR-43-AC/AP (figure 1.1) measures the refractive index nD and the temperature of the process medium. The concentration of the process liquid is calculated from these values when the composition of the process medium is known. The output values of the refractometer are transmitted through mA output and digitally through an Ethernet connection by using a UDP/IP protocol (see the general manual for specifications). mA output is available with mA output cable (mA only) or with a split cable (mA and Ethernet).
PR-43-AC
PR-43-AP
Figure 1.1 Refractometer models
© Copyright Vaisala 2019. All rights reserved.
2
PR-43-AC/AP instruction manual
2 Mounting
The refractometer mounting location should be chosen with care to ensure reliable readings from the process.
2.1 Choosing the mounting location
The mounting location needs to be such that sediments or gas bubbles cannot accumulate by the refractometer. Good flow velocity is essential in keeping the prism clean. Important: If the process pipe vibrates, support the pipe. A vibrating pipe might damage the in-line refractometer mounted on it. A Vaisala K-PATENTS® inline refractometer can be located either indoors or outdoors in most climates. However, when a refractometer is located outdoors, some basic protection against direct exposure to sunlight and rain should be provided. Special care should be taken if the pipe wall is translucent (e.g. of fiberglass), as light from outside reaching the prism through the pipe wall may disturb the measurement. The refractometer cover should not be exposed to high temperature radiation. In most cases, draft and natural convection provide sufficient air cooling if the air gets to flow freely around the refractometer head. Additional cooling is necessary when the ambient temperature is higher than 45 °C (113 °F) or when the process temperature is above 110 °C (230 °F) and the ambient temperature is above 35 °C (95 °F). The air cooling is improved by blowing pressurized air against the refractometer cover. The pressurized air can be supplied by the ventilation system. It is also possible to mount a PR-14038 cooling cover for cooling with water. Important: Always mount the refractometer so that the interconnecting cable points downwards from the refractometer head.
2.2 Check list for pipe mounting
The PR-43-AC and PR-43-AP are mounted in a pipe. Vaisala recommends a flow velocity between 1 and 3 m/s (310 ft/s). If the flow velocity exceeds 6 m/s (20 ft/s), there is a risk of cavitation. Cavitation may damage the refractometer and the piping. Too
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
2 Mounting
3
slow a flow velocity may cause erraneous measurement readings due to coating of stratification (layering) of the sample on the prism. The diameter and form of the pipe and the process temperature all affect the measurement and need to be taken into account.
If the process pipe diameter varies, select the position with the smallest diameter (and accordingly highest velocity). Then the prism stays clean better.
If the refractometer is used in a feed-back control loop, make the time lag short. E.g. when a dilution valve is controlled, mount the refractometer close to the dilution point. However, make sure complete mixing has occurred at mounting location.
If the temperature varies along the process pipe, select the position with the highest process temperature. That minimizes the risk of coating, because higher temperature means higher solubility and also lower viscosity.
Often the position with the highest process pressure (= after pump + before valve) has favorable flow conditions without sedimentation or air trapping risks.
The refractometer should be conveniently accessible for service.
2.3 Check list for mounting in a tank, a vessel or a large pipe
A probe refractometer PR-43-AP can be inserted with a flange or clamp into tanks and vessels which either don't have a scraper or where the mixer doesn't touch the vessel wall. A probe refractometer can also be flush mounted in a cooker where the scraper touches the wall.
The inserted probe refractometer is mounted close to a stirrer to ensure representative sample of the process liquid and to keep the prism clean.
The refractometer should be conveniently accessible for service.
© Copyright Vaisala 2019. All rights reserved.
Effective: September 2, 2019
Document/Revision No. IM-EN-PR43ACAP/2.00
Prevent outside light
Easy access Ambient air cooling
High pressure High temperature
Easy access Upper pipe bend
High pressure
Small diameter High temperature High velocity >1.5m/s (>5ft/s)
PR-43-AC/AP instruction manual
4
2 Mounting
5
2.4 Electrical connections
The refractometer has an M12 connector in the refractometer for power supply, mA output and Ethernet connections.
Figure 2.1 The M12 connector PR-43 refractometers are powered with 24 VDC. For connecting the refractometer to Multichannel user interface MI, see the manual for Multichannel user interface. For connecting the refractometer to Compact user interface CI, see the manual for Compact user interface. See Figure 2.2 for instruction how to connect the M12 refractometer cable.
2.4.1 Wiring options The PR-43 refractometer provides both analogue (mA) and digital output signals. See Figure 2.3 for the wiring when only analogue output is used. Options for connecting the refractometer with both analogue and digital outputs are shown in Figure 2.4. Both Compact user interface CI and Multichannel user interface MI use the digital output signal.
© Copyright Vaisala 2019. All rights reserved.
fractometer only Cables
PR-43 REFRACTOMETER
6
M-12-8 pin, A-code, M non-Ex
m (33ft)
F 10m (33ft)
PR-843P1R-43-AC/AP instruction manual
Split cable M12 M12-8 pin, A-code, F Ethernet (M12-4 pin, D-code,M) mA, 24V
M
m (295ft)
PR-43 REFRACTOMETER
M-12-8 pin, A-code, M
non-Ex
Align groove and
gFuide
PR-8430
Connector screw thread
Platform 4 cable
M12-8 pin, A-code, F+M
Ethernet, mA, 24V
max. 90m (295ft)
M
F
PR-8431
Split cable M12 Turn to tighten M12-8 pin, A-code, F
Ethernet (M12-4 pin, D-code,M) mA, 24V
1m (3ft)
M
m (590ft)
PR-43 REFRACTOMETER
M-12-8 pin, A-code, M non-Ex
PR-8660
Platform 4 cable extender
M12-8 pin, A-code, F+M
PR-8430
F
Platform 4 cable
M12-8 pin, A-code, F+M
Ethernet, mA, 24V
PR-8430
Platform 4 cable M12-8 pin, A-code, F+M Ethernet, mA, 24V
PR-8431
Split cable M12 M12-8 pin, A-code, F Ethernet (M12-4 pin, D-code,M) mA, 24V
1m (3ft)
P4-031
maFxig. 9u0rme 2(2.295ftC) oMnnecting thFe refrmacatxo.m90emte(r2c9a5bftl)e toMthe rFefractometer
PR-43 REFRACTOMETER
M-12-8 pin, A-code, M
non-Ex
F
m (656ft)
PR-8680
M12-8 pin, A-code, F
Field plug
PR-8432
Power supply and mA output cable
max. 200m (656ft)
Figure 2.3 Wiring with analogue output only
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
2 Mounting
Figure 2.4 Wiring options when both analogue and digital outputs are used
© Copyright Vaisala 2019. All rights reserved.
Refractometer only Cables
10m (33ft)
PR-43 REFRACTOMETER
M-12-8 pin, A-code, M non-Ex
F 10m (33ft)
PR-8431
Split cable M12 M12-8 pin, A-code, F Ethernet (M12-4 pin, D-code,M) mA, 24V
M
F
90m (295ft)
PR-43 REFRACTOMETER
M-12-8 pin, A-code, M non-Ex
PR-8430
Platform 4 cable M12-8 pin, A-code, F+M Ethernet, mA, 24V
max. 90m (295ft)
M
F
PR-8431
Split cable M12 M12-8 pin, A-code, F Ethernet (M12-4 pin, D-code,M) mA, 24V
1m (3ft)
M
PR-43 REFRACTOMETER
M-12-8 pin, A-code, M non-Ex
PR-8660
Platform 4 cable extender
M12-8 pin, A-code, F+M
PR-8430
F
Platform 4 cable
M12-8 pin, A-code, F+M
Ethernet, mA, 24V
PR-8430
Platform 4 cable M12-8 pin, A-code, F+M Ethernet, mA, 24V
180m (590ft)
max. 90m (295ft) M
F max. 90m (295ft) M F
PR-43 REFRACTOMETER
M-12-8 pin, A-code, M
non-Ex
PR-8431
Split cable M12 M12-8 pin, A-code, F Ethernet (M12-4 pin, D-code,M) mA, 24V
1m (3ft)
M
F
200m (656ft)
PR-8680
M12-8 pin, A-code, F
Field plug
PR-8432
Power supply and mA output cable
max. 200m (656ft)
7
Effective: September 2, 2019
Document/Revision No. IM-EN-PR43ACAP/2.00
digital outputs are used, with RJ45 ethernet connector
Figure 2.5 Wiring options when both analogue and
Stand-alone refractometer with RJ45
PR-43 REFRACTOMETER
M-12-8 pin, A code, M Unclassified area
F
10m (33ft)
PR-43 REFRACTOMETER
M-12-8 pin, A code, M Unclassified area
F
90m (295ft)
PR-8444-001/010
Split cable M12 M12-8 pin, A-code, F Ethernet (RJ 45) mA, 24V
1m (3ft) or 10m (33ft)
PR-8430-___
Platform 4 cable M12-8 pin, A-code, F+M Ethernet, mA, 24V
max. 90m (295ft)
MF
PR-8444-001
Split cable M12 M12-8 pin, A-code, F Ethernet (RJ45) mA, 24V
1m (3ft)
PR-43 REFRACTOMETER
M-12-8 pin, A code, M Unclassified area
F
180m (590ft)
PR-8660
Platform 4 cable extender
M12-8 pin, A-code, F+M
PR-8430-___
Platform 4 cable M12-8 pin, A-code, F+M Ethernet, mA, 24V
PR-8430-___
Platform 4 cable M12-8 pin, A-code, F+M Ethernet, mA, 24V
max. 90m (295ft) M
F max. 90m (295ft) M F
PR-8444-001
Split cable M12 M12-8 pin, A-code, F Ethernet (RJ45) mA, 24V
1m (3ft)
P4-001/1
PR-43-AC/AP instruction manual
8
2 Mounting
9
Figure 2.6 Connections in M12 and RJ-45 connectors
In split cables the power cable and the mA output cable are marked near the end of the cable. Power cable: · white: +24 DC · brown: GND
mA output cable: · white: mA+ · brown: mA-
© Copyright Vaisala 2019. All rights reserved.
10
PR-43-AC/AP instruction manual
3 Specifications
3.1 Compatibility
Electrically: The PR-43 refractometers are not interchangeable with any other refractometer model. All PR-43-AC/AP refractometers are however interchangeable with each other as long as they have the same prism. The PR-43-AC/AP refractometers are not compatible with the indicating transmitters DTR, STR or IT-R.
Mechanically: The sanitary process refractometer PR-43-AC/AP fits the same sanitary process connections as PR-23-AC/AP.
3.2 Refractometer rangeability
The refractive index standard range of a PR-43-AC/AP is 1.320-1.530 (corresponds to 0-100 Brix), Figure 3.1, with a Sapphire prism. A PR-43-AC can also be equipped with a Sapphire prism with a refractive index range 1.260-1.470.
PR-43-AC-74
PR-43-AC-73
nD
1.25
1.30
1.35
1.40
1.45
1.50
1.55
Figure 3.1 PR-43-AC rangeability
3.3 Sanitary process refractometer PR-43-AC
The refractometer PR-43-AC is a 3-A and EHEDG certified sanitary process refractometer for measuring concentrations in a pipeline. It is easy to install in any pipe size directly or using a flow cell. The Sanitary process refractometer is suitable for all food and beverage processing applications where real-time monitoring and control can help to improve product quality and reduce costs.
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
11
Figure 3.2 PR-43-AC dimensions
© Copyright Vaisala 2019. All rights reserved.
12
PR-43-AC/AP instruction manual
3.3.1 PR-43-AC model code
SANITARY COMPACT REFRACTOMETER for pipelines
Model and description
Model
PR-43 = Refractometer
PR-43
Refractometer model
-AC = Compact sanitary certified process refractometer, insertion length 14 -AC mm
Prism material and Refractive Index range limit
-73 = R.I. 1.320-1.530 nD (0-100 Brix) Sapphire prism
-73
-74 = R.I. 1.260-1.470 nD Sapphire prism
-74
Connection type and size
-E25-P15 = Varivent DN65, 15 bar (A)
-E25-P15
-H25-P15 = Sanitary 3A-clamp, 2½ inch, 15 bar (A)
-H25-P15
-H25-P40 = Sanitary 3A-clamp, 2½ inch, High Pressure, 40 bar @ 20°C (A) -H25-P40
-Z25-P15 = 2½ inch I-clamp, 15 bar (B)
-Z25-P15
Refractometer wetted parts material
-SS = AISI 316 L
-SS
-HC = Alloy C276
-HC
Electrical classification
-UN = Unclassified area, general purpose, ordinary location
-UN
-AX = EX and IECEx certified Ex II 3G, Ex nA IIC T4 Gc
-AX
(up to zone 2) (Tamb -40...+65°C)
-IA = ATEX and IECEx certified Ex II 1G, Ex ia IIC T4 Ga
-IA
(up to zone 0) (Tamb -40 ... +65°C)
High accuracy option
-HAC = High accuracy version in range 0-30 Brix 4-30°C
-HAC
EHEDG option
-EH = EHEDG Type EL class I Certified Model
-EH
Polishing option
-EP = Electropolished refractometer wetted parts (Ra 0.4 µm, 15 µ inch) -EP
(A) EHEDG certified version available D(Boc)uSmaennitt/aRreyvis3io-An Ncoe.rItMif-iEeNd-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
13
3.3.2 PR-43-AC mounting hardware model code
Mounting hardware (without wash nozzles)
MODEL AND DESCRIPTION AFC = Elbow flow cell Refractometer connection -H = Sanitary 3A clamp, 2 1/2 inch Construction material SS = AISI 316 Process connection -H = Sanitary 3A clamp Pipe section diameter 10 = 25 mm (1 inch) (A) 15 = 40 mm (1 1/2 inch) 20 = 50 mm (2 inch) 25 = 65 mm (2 1/2 inch) (A) 30 = 80 mm (3 inch) (A) 40 = 100 mm (4 inch) (A) Flow cell inlet type -SI = Straight pipe -RI = Reduced pipe (cone) Options -EP = Electropolished process wetted parts (RA 0.4µm, 15 µ inch) (A) with -SI option only
EHEDG certified mounting hardware
MODEL AND DESCRIPTION AFC = Elbow flow cell Refractometer connection -H = Sanitary 3A clamp, 2 1/2 inch Construction material SS = AISI 316 Process connection -H = Sanitary 3A clamp Pipe section diameter 20 = 50 mm (2 inch) Flow cell inlet type -SI = Straight pipe EHEDG -EH = EHEDG Type EL Class I Certified model Polishing option -EP = Electropolished process wetted parts (Ra 0.4µm, 15 µ inch)
For EHEDG certified refractometers use ISO2852 type EHEDG certified gasket PR-9202-EH (2½ inch) or PR-9272-EH (4 inch).
MODEL AFC
-H
SS
-H
10 15 20 25 30 20
-SI -RI
-EP
MODEL AFC
-H
SS
-H
20
-SI
-EH
-EP
© Copyright Vaisala 2019. All rights reserved.
14
PR-43-AC/AP instruction manual
Mounting hardware with wash nozzles
MODEL AND DESCRIPTION
AFC = Elbow flow cell
Refractometer connection -H = Sanitary 3A clamp, 2 1/2 inch
Construction material SS = AISI 316
Process connection -H = Sanitary 3A clamp
Pipe section diameter 10 = 25 mm (1 inch) 15 = 40 mm (1 1/2 inch) 20 = 50 mm (2 inch) 25 = 65 mm (2 1/2 inch) (A) 30 = 80 mm (3 inch) (A) 40 = 100 mm (4 inch) (A)
Flow cell inlet type -SI = Straight pipe -RI = Reduced pipe (cone)
Wash nozzle connection -NC = Nozzle connection
Wash nozzles for 10/15 flow cells -SN = Steam nozzle, threads G ¼ inch female -WN = Water nozzle, threads G ¼ inch female -WP = Pressurized water nozzle, threads G ¼ inch female -PG = Plug for nozzle connection
(A) with -SI option only
MODEL AFC
-H
SS
-H
10 15 20 25 30 40
-SI -RI
-NC
-SN -WN -WP -PG
Example: Refractometer:PR-43-AC-73-H25-P15 Flow cell: AFC-HSS-H20-SI
Note: Prism wash control and diagnostics require the use of a Multichannel user interface MI (or customer's own control system).
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
Mounting hardware, mini flow cell MODEL AND DESCRIPTION MFC = Mini flow cell Refractometer connection -H = Sanitary 3A clamp, 2 1/2 inch Construction material SS = AISI 316 Process connection -H = Sanitary 3A clamp Pipe section diameter 05 = 15 mm (½ inch)
Mounting hardware, Varivent DN65 connection MODEL AND DESCRIPTION TDN = Varivent®in-line access unit clamp DN65 Type N (A) Pipe section diameter 40 = 100 mm (4 inch) 50 = 50 mm (2 inch) 65 = 65 mm (2 1/2 inch) 80 = 80 mm (3 inch) 100 = 100 mm (4 inch) 125 = 125 mm (5 inch) 150 = 150 mm (6 inch) Counter flange options -SN = Steam nozzle, threads G ¼ inch female -WN = Water nozzle, threads G ¼ inch female -WP = Pressurized water nozzle, threads G ¼ inch female -PG = Varivent blind flange type N (A) Includes one 2½ inch Type N blind flange with 2½ inch EPDM gasket
and 2½ inch Varivent clamp Type N
15
MODEL MFC
-H
SS
-H
05
MODEL TDN
-40 -50 -65 -80 -100 -125 -150
-SN -WN -WP -PG
© Copyright Vaisala 2019. All rights reserved.
16
PR-43-AC/AP instruction manual
Mounting hardware
MODEL AND DESCRIPTION
SFC = Side flow cell (A)
Refractometer connection -HH = Sanitary 3A clamp, 2 1/2 inch
Construction material SS = AISI 316
Process connection -H = Sanitary 3A clamp
Pipe section diameter 10 = 25 mm (1 inch) 15 = 40 mm (1 1/2 inch) 20 = 50 mm (2 inch) 25 = 65 mm (2 1/2 inch) (A)
Flow cell inlet and outlet orientation -090 = Elbow, 90 degree bend -180 = Straight pipe, 180 degree
(A) Includes one 2½ inch blind flange with 2½ inch EPDM gasket and
2½ inch sanitary clamp is included
MODEL SFC
-HH
SS
-H
10 15 20 25
-090 -180
3.3.3 PR-43-AC specifications
REFRACTOMETER PR-43-A Models Refractive Index range
Accuracy
Repeatability Speed of response Calibration
Standard
Optional
PR-43-AC Compact model for small pipelines
Full range, nD = 1.3200...1.5300 corresponds to hot water...100 Brix or % by weight.
nD 1.2600...1.4700.
Across the full range of 0-100 Brix: High accuracy version -HAC in the
Refractive Index nD ±0.0002
range of 0-30 Brix and 4-30°C:
corresponds typically to ±0.1 Brix ±0.05 Brix or % by weight.
or % by weight
±0.02 Brix or % by weight (in
set-point applications).
Across the full range of 0-100 Brix: nD ±0.00004 (corresponds typically to ±0.02 Brix or % by weight).
1 s undamped, damping time selectable up to 5 min
With NIST traceable Cargille standard R.I. liquids over full range
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
17
Standard
Optional
Patented CORE-Optics
No mechanical adjustments and digital measurement with 3648 pixel CCD element, sodium D-line light emitting diode (LED) built-in Pt-1000 temperature sensor (linearization according to IEC 751).
Temperature compensation
Automatic, digital compensation.
Instrument verification
With NIST traceable Cargille standard R.I. liquids and guided procedure, including a printable verification report
Process connection
Sanitary 3A-clamp 2.5"; Varivent in-line access unit clamp DN65 or via elbow flow cell (for line sizes of 2.5" and smaller); 2.5" I-clamp.
Hygienic design certification
3-A Sanitary Standard 46-03 certified and EHEDG (European Hygienic Engineering & Design Group) Type EL Class I certified
Process pressure
Sanitary 3A and I-clamp max. 15 bar (200 psi) at 20°C (70°F)/9 bar (125 psi) at 120°C (250°F). High pressure Sanitary 3A clamp HP 40 bar.
Process temperature
-40°C...130°C (-40°F...266°F)
Ambient temperature
Min. -40°C (-40°F), max. 45°C (113°F)
Process wetted parts
AISI 316L stainless steel, prism Alloy C276 sapphire, prism gasket modified PTFE (Teflon), gasket EPDM for Sanitary 3-A and ISO2852 type EHEDG certified gasket for EHEDG certified refractometers.
Refractometer protection class IP67, Type 4X
Refractometer weight
1.6 kg (3.5 lbs)
Current output
Isolated 4-20 mA, max. load 1000 Ohm, galvanic isolation 1000 VDC or AC (peak), hold function during prism wash
Remote and Ethernet connections 10/100BaseT Ethernet, web server for configuration and diagnostics, UDP/IP Protocol connection for data acquisition.
Power supply
+24 VDC ±10%, max. 2 VA
INTERCONNECTING CABLES
Standard length 10 m. Single cable maximum length 90 meters, with cable extender PR-8660 maximum length 90+90 meters.
© Copyright Vaisala 2019. All rights reserved.
18
3.3.4 PR-43-AC parts list
PR-43-AC/AP instruction manual
17
13
15
14
16
13
12
11
10
9
8
7
6
5
4 3
Item Description
Part no. Qty
2 1
1
Screw M4x10 DIN7380 Torx tamper proof
PR-14003 2
2
PR-43 end plate
PR-14001 1
3
Dryer pack
PR-9108 1
4
PR-43 sensor interface card
1
4.1 PR-43 interface card (Ex ia)
PR-50011
4.2 mA-output card (general purpose, Ex nA)
PR-50033
5
O-ring for PR-43 end plate FPM
PR-14002-FPM 2
6
Screw M3x6 DIN7985 TX A2
3
7
PR-43 sensor processor card
1
7.1 Ex processor card (Ex ia)
PR-50012
7.2 General purpose and Ex nA
PR-50038
8
Screw M3x10 DIN965 TX A2
3
9
PR-33/PR-43-A card holder
PR-14050 1
10
PR-33/PR-43-A disk spring ring
1
11
Screw M5x10 ISO 14583 TX A2
6
12
Nord-Lock washer NL5ss
6
13
PR-43 connector & cable set
1
13.1 P4 connector & cable set (general purpose, Ex nA) PR-14101
13.2 P4 connector & cable set (Ex ia)
PR-14101-EX
14
PR-43 sensor cover
PR-14000 1
15
O-ring 68x3 FPM
PR-10048 1
16
O-ring 14x1,78 FPM
PR-14102-FPM 1
17
Disk spring
1
Figure 3.3 Refractometer cover assembly
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
19
4 3
2 1
Item Description 1 PR-43-AC nameplate 2 PR-43 base assembly 3 PR-43 compact core
3.1 H73 Optics module 3.2 H74 Optics module 4 Sensor head 4.1 PR-43-AC-H25-SS head 4.2 PR-43-AC-E25-SS head 4.3 PR-43-AC-H25-HC head 4.4 PR-43-AC-E25-HC head 4.5 PR-43-Z25-SS head
Part no. Qty PR-14404 1
1 1 PR-14020 PR-14022 1 PR-10001 PR-10028 1 PR-10001-HC 1 PR-10028-HC
Figure 3.4 PR-43-AC assembly
© Copyright Vaisala 2019. All rights reserved.
20
PR-43-AC/AP instruction manual
3.3.5 PR-43-AC mounting specifics
Sanitary process refractometer PR-43-AC is connected to the process by a 2 1/2" 3A sanitary clamp. The recommended mounting is in a pipe bend, with a vertical flow upwards before the refractometer, and a horizontal pipe after. This mounting ensures
1. Self-cleaning of the prism due to the flow directed against its surface. 2. Efficient drainage when the pipe is emptied.
For pipe diameters of 3" or above, a ferrule is welded directly to the pipe wall, Figure 3.5 (a ferrule, length 21.5 mm, is delivered with standard refractometer delivery). For smaller pipe diameters, flow cells are available, Figures 3.6, 3.7, 3.8 and 3.9. The flow cells are exchangeable with standard 90° bend pieces.
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
21
Figure 3.5 Mounting with sanitary ferrule Pipe diameter 3" (80 mm) or more
© Copyright Vaisala 2019. All rights reserved.
22
PR-43-AC/AP instruction manual
Mark Rev.
B Drawing updated
4
5 1 B C
Date
Rev. by
29.8.06 HS
Appr.
HS
3
1 D
2
D
2
3
45°
SECTION A-A SCALE 1 : 2
A
AFC-HSS-H15-RI
AFC-HSS-H10/H15-SI
Flow cell type
A
B
C
D
AFC-H10-SI 22.6 [0.890] 22.6 [0.890] 25.6 [1.008] 50.8 [2]
AFC-H15-RI 22.6 [0.890] 35.6 [1.402] 38.6 [1.520] 70.3 [2.768]
AFC-H15-SI 35.6 [1.402] 35.6 [1.402] 38.6 [1.520] 70.3 [2.768]
Figure 3.6 Flow cell AFC-HSS- Item No. Description
1
Sanitary ferrule 1"/1.5"
Ma te ria l Supplie d by Qty/Pcs.
AISI316L Customer
2
2
Sanitary gasket 1"/1.5"
EPDM Customer
2
H10 for pip3e diameter Sanitary clamp 11"/"1.5("25 mm)AaISnI30d4 HC1us5tomfeor r pi2pe diameter 1 1/2" (40 mm)
4
PR-03-A/PR-23-AC sensor
K -P at ent s
1
5
AFC-HSS-H10/H15-SI/RI Flow cell AISI316L K-Patents
1
General tolerances
Scale
Join
1:2
File
MTG428.drw
Material
AISI316L
Drawing description
AFC-HSS-H10/H15-SI/RI
Drawing number
MTG428/B
Drawn 1.9.2004 HS Appr. 1.9.2004 HS
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
Mark Rev.
23
B
5 2
3
B
C
Date
4
A
Rev. by
Appr.
3 2 1
1 D
SECTION A-A SCALE 1 : 2
B
D
AFC-H10/H15-RI-NC AFC-H10/H15-SI-NC
Flow ce ll type
A
B
C
D
AFC-H10-RI-NC 16 [0.630] 22.6 [0.890] 25.6 [1.008] 50.8 [2]
AFC-H10-SI-NC 22.6 [0.890] 22.6 [0.890] 25.6 [1.008] 50.8 [2]
AFC-H15-RI-NC 22.6 [0.890] 35.6 [1.402] 38.6 [1.520] 70.3 [2.768]
AFC-H15-SI-NC 35.6 [1.402] 35.6 [1.402] 38.6 [1.520] 70.3 [2.768]
45°
8
6
Ite m No. De scription
Ma te ria l Supplie d by Qty/Pcs.
7
1
Sanitary ferrule 1"/1.5"
AISI316L Customer
2
2
Sanitary gasket 1"/1.5"
EPDM Customer
2
SECTION B-B
3
Sanitary clamp 1"/1.5"
AISI304 Customer
2
SCALE 1 : 2
4
PR-03-A/PR-23-AC sensor
K -P at ent s
1
Figure 3.7 Flow cell AFC-HSS- with wash nozzle connection (-NC) 5
AFC-HSS-H10/H15-SI/RI-NC Flow cell AISI316L K-Patents
1
6
Nozzle
AISI316L K-Patents
1
H10
for
pipe diameter 1" 6.1 Blind nozzle 6.2 Steam Nozzle (SN)
(25
mm)
and H15 for AISI316L K-Patents AISI316L K-Patents
pipe
diameter
1
1/2"
(40
mm)
6.3 Pressurized nozzle (PN)
AISI316L K-Patents
6.4 W ater nozzle(W N)
AISI316L K-Patents
7
Sanitary clamp 0.5"
AISI304 K-Patents
1
8
O-ring 6.3x2.4mm
EPDM K-Patents
1
General tolerances
Scale
Join
1:2
File
MTG429.drw
Material
Drawing description
AFC-HSS-H10/H15-SI/RI-NC
Drawing number
MTG429
Drawn 1.9.2004 HS Appr. 1.9.2004 HS
© Copyright Vaisala 2019. All rights reserved.
24
A
PR-43-AC/AP instruction manual
SECTION A-A SCALE 1 : 2
45° D
A
A
D
B C
Flow cell type
A
B
C
D
AFC-HSS-H20-SI 48.6
48.6
51.6
89.0
AFC-HSS-H20-RI 35.6
48.6
51.6
89.0
AFC-HSS-H25-SI 60.3
60.3
64.1
108.0
Figure 3.8 Flow cell AFC-HSSH20 for pipe diameter 2" (50 mm) and H25 for pipe diameter 2 1/2" (65 mm)
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
25
A
4
SECTION A-A
SCALE 1 : 2
B
45° D
A
3
5
21
3
2
1B
A
D B
C
10
Flow cell type
A
B
C
D
AFC-HSS-H20-SI-NC
48.6
48.6
51.6
89.0
45°
6
AFC-HSS-H20-RI-NC
35.6
48.6
51.6
89.0
AFC-HSS-H25-SI-NC
60.3
60.3
64.1
108.0
11
SECTION B-B SCALE 1 : 5
Figure 3.9 Flow cell AFC-HSS- with wash nozzle connection (-NC) H20 for pipe diameter 2" (50 mm) and H25 for pipe diameter 2 1/2" (65 mm)
© Copyright Vaisala 2019. All rights reserved.
26
PR-43-AC/AP instruction manual
163
A
163
A B
4
52
3
1
5 4
3 2
1
6
6
8
7
7 8
Size A
B
1"
66
132
1,5" 86
173
2"
80
161
2,5" 98
197
1
2
3
4
5
6
7
8
Size Angle Sensor
Flow cell
Sanitary gasket Sanitary clamp
Sanitary blind flange
Sanitary gasket Sanitary clamp Customer's pipe
90° 1"
180°
SFC-HHSS-H10-090 SFC-HHSS-H10-180
-
PR-9246
PR-9211
-
90°
SFC-HHSS-H15-090
-
1,5"
PR-9212
PR-9211
180° Sanitary SFC-HHSS-H15-180
-
refracto-
PR-9202
PR-9201
PR-9200
90° meter SFC-HHSS-H20-090
-
2"
PR-9222
PR-9221
180°
SFC-HHSS-H20-090
-
90° 2,5"
180°
SFC-HHSS-H25-090 SFC-HHSS-H25-090
-
PR-9202
PR-9201
Figure 3.10 Side flow cells
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
27
Sanitary Refractometer PR-43-AC-Z is mounted using 3-A Sanitary certified 2.5 inch Cherry Burrell I-Line fittings that are made of interlocking flat face ferrules, a flat gasket and a clamp. This interlocking, metal-to-metal design eliminates over compression by the clamp not allowing the gasket to be extruded into the product contact side. The sensor is male part of the connection. Refractometer wetted parts material is AISI 316L or Alloy C, gaskets EPDM.
1
1243,85 4
Max. 220,86
2
3 5
Figure 3.11 I-Line fitting for PR-43-AC
© Copyright Vaisala 2019. All rights reserved.
28
PR-43-AC/AP instruction manual
3.3.6 Mounting specifics for EHEDG certified PR-43-AC configuration
Vaisala offers certain PR-43-AC configurations which have been certified to fulfill the sanitary requirements published by EHEDG (European Hygienic Engineering & Design Group) organization. During this certification the hygienic characteristics of both the refractometer and the process connection were evaluated against the applicable requirements. To ensure EHEDG compliant installation, follow the mounting specifics provided on the mounting drawing supplied by Vaisala with each PR-43-AC refractometer ordered with the -EH option. An example of such mounting guideline is shown in the Figure 3.12.
3.3.7 3-A Sanitary Standard compliance
The user should ensure that the refractometer is not a source of contamination to product due to damaged or worn product contact surfaces. Misuse (e.g. too long prism wash time or too high wash pressure) or mishandling may result in metal scratches or roughened surfaces. Such surfaces may not stay clean in processing. Vaisala offers a 3-A Sanitary Standard Accepted repair and maintenance package in which all wetted parts, prism, gaskets and dryer are replaced. Note that this repair service can be completed by 3-A authorized service center only.
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
29
TYPE EL CLASS I
November 2015
No Item
Material
Pcs
1 Sensor PR-43-AC
1
2 Sanitary ferrule 2 1/2" ISO 2852 AISI 316L
1
3 Sanitary gasket 2 1/2"
ISO2852 type 1
EHEDG certified
Figure 3.12 Mounting with sanitary ferrule Pipe diameter 3" (80 mm) or more EHEDG certified configuration
© Copyright Vaisala 2019. All rights reserved.
30
PR-43-AC/AP instruction manual
3.4 Sanitary process refractometer PR-43-AP
Sanitary probe refractometer PR-43-AP provides an accurate in-line Brix measurement in cookers, tanks and large pipelines. The PR-43-APT refractometer version can be installed through an APV Tank bottom flange. It is flush mounted in the side wall and it allows the use of scrapers and mixers. It can also be installed through a steam jacket.
11,16 284
6,69 170
3,66 93
3,05 77,5 1,48 37,5
2.5" Sanitary clamp
M12-8pin, D-code, male connector
Figure 3.13 Dimensions of an inserted refractometer PR-43-AP-H25-L170
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
31
Figure 3.14 Flush mounted refractometer PR-43-AP-T10-L00
© Copyright Vaisala 2019. All rights reserved.
32
PR-43-AC/AP instruction manual
3.4.1 PR-43-AP model code
SANITARY PROBE REFRACTOMETER for large pipelines and vessels
Model and description
Model
PR-43 = Refractometer
PR-43
Refractometer model
-AP = Sanitary process refractometer, probe
-AP
Prism material and refractive index range limit
-73 = R.I. 1.320-1.530 nD (0-100 Brix) Sapphire prism
-73
Connection type and size
-E25-P15 = Varivent DN65, 15 bar
-E25-P15
-H25-P15 = Sanitary 3A-clamp, 2½inch, 15 bar
-H25-P15
-H25-P40 = Sanitary 3A-clamp, 2½inch, High Pressure, 40 bar @ 20°C
-H25-P40
-H40-P15 = Sanitary 3A-clamp, 4 inch, 15 bar
-H40-P15
-T10-P15 = MT4 DN25/1T APV tank bottom flange, flush mounted 1" DN10 -T10-P15
-V25-P15 = 2½inch, 15 bar with O-ring for refractometer head
-V25-P15
-Z25-P15 = 2½inch I-clamp, 15 bar
-Z25-P15
Insertion length, models H25-P15/P40
-L14 = insertion length 14 mm (A) (C)
-L14
-L42 = insertion length 42 mm (A) (C)
-L42
-L140 = insertion length 140 mm (B)
-L140
-L170 = insertion length 170 mm (A) (C)
-L170
Insertion length, models H40-P15
-L63 = insertion length 63 mm (A) (C)
-L63
-L170 = insertion length 170 mm (A) (C)
-L170
Insertion length, models T10-P15
-L00 = flush mount insertion length (C)
-L100
-L170 = insertion length 170 mm (B)
-L170
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
Insertion length, models E25-P15 -L170 = insertion length 170 mm (A) (C) Insertion length, models V25-P15 -L170 = insertion length 170 mm (B) Insertion length, models I-clamp Z25-P15 -L178 = insertion length 178 mm (C) Refractometer wetted parts material -SS = AISI 316 L Electrical classification -UN = Unclassified area, general purpose, ordinary location -AX = Ex and IECEx certified Ex II 3G, Ex nA IIC T4 Gc (up to zone 2) (Tamb -40...+65°C) -IA = ATEX and IECEx certified Ex II 1G, Ex ia IIC T4 Ga (up to zone 0) (Tamb -40...+65°C) EHEDG option -EH = EHEDG Type EL Class I Certified Model (D)
(A) EHEDG certified versions available (B) Design according to Sanitary 3-A (C) Sanitary 3-A certified (D) for models with (A) note
33
-L170 -L170 -L178 -SS -UN -AX -IA
-EH
© Copyright Vaisala 2019. All rights reserved.
34
PR-43-AC/AP instruction manual
SANITARY PROBE REFRACTOMETER with prism wash for large pipelines and vessels
Model and description
Model
PR-43 = Refractometer
PR-43
Refractometer model
-AP = Sanitary process refractometer, probe
-AP
Prism material and refractive index range limit
-73 = R.I. 1.320-1.530 nD (0-100%) Sapphire prism
-73
Connection type and size
-H40-P15 = Sanitary 3A-clamp, 4 inch, 15 bar
-H40-P15
Insertion length
-L170 = insertion length 170 mm
-L170
Refractometer wetted parts material
-SS = AISI 316 L
-SS
Electrical classification
-UN = Unclassified area, general purpose, ordinary location
-UN
-AX = Ex end IECEx certified Ex II 3G, Ex nA IIC T4 Gc (up to zone 2) -AX (Tamb -40...+65 °C) -IA = ATEX and IECEx certified Ex II 1G, Ex ia IIC T4 Ga (up to zone 0) -IA (Tamb -40...+65 °C) Prism wash
-NC = integral nozzle connection
-NC
-SN = integral steam cleaning nozzle
-SN
-WP = integral high pressure water cleaning nozzle
-WP
-WN = integral warm water cleaning nozzle
-WN
-YC = no integral nozzle connection
-YC
Note: Prism wash control and diagnostics require use of Multichannel user interface MI (or customer's own control system).
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
35
3.4.2 PR-43-AP mounting hardware model code
Mounting hardware for PR-43-AP refractometer Part number and description VFMA-T10 = MT4 DN25/1T APV tank bottom flange for PR-43-AP T10 VFBP-T10 = blind flange for MT4 DN25/1T APV tank bottom flange VFME-V25 = mount adaptor for PR-43-AP V25 HEXNUT type VFMF-V25 = mount adaptor for PR-43-AP V25 HEXNUT extended
Part No. VFMA-T10 VFBP-T10 VFME-V25 VFMF-V25
Note: For EHEDG certified refractometers use EHEDG certified gasket PR-9202-EH (2½ inch) or PR-9272-EH (4").
3.4.3 PR-43-AP specifications
REFRACTOMETER PR-43-A Models Refractive Index range
Accuracy
Repeatability
Speed of response Calibration Patented CORE-Optics
Temperature compensation Instrument verification
Process connection
Hygienic design certification
PR-43-AP probe model for large pipelines and vessels
Full range, nD = 1.3200...1.5300 corresponds to hot water...100 Brix or % by weight. Across the full range 0-100 Brix; Refractive Index nD ±0.0002 corresponds typically to 0.1 ±Brix or % by weight. Across the full range of 0-100 Brix: nD ±0.00004 (corresponds typically to ±0.02 Brix or % by weight). 1 s undamped, damping time selectable up to 5 min With NIST traceable Cargille standard R.I. liquids over full range No mechanical adjustments and digital measurement with 3648 pixel CCD element, sodium D-line light emitting diode (LED) built-in Pt-1000 temperature sensor (linearization according to IEC 751). Automatic, digital compensation. With NIST traceable Cargille standard R.I. liquids and guided procedure, including a printable verification report Sanitary 3A-clamp 2.5"; Sanitary 3A-clamp 4" or MT4 DN 25/1T APB tank bottom flange; 2.5" I-clamp 3-A Sanitary Standard 46-03 certified and EHEDG (European Hygienic Engineering & Design Group) Type EL Class I certified
© Copyright Vaisala 2019. All rights reserved.
36
PR-43-AC/AP instruction manual
Process pressure
Sanitary 3A and I-clamp max. 15 bar (200 psi) at 20°C (70°F)/9 bar (125 psi) at 120°C (250°F). High pressure Sanitary 3A clamp HP 40 bar.
Process temperature
-40°C...150°C (-40°F...302°F)
Ambient temperature
Min. -40°C (-40°F), max. 45°C (113°F)
Process wetted parts
AISI 316L stainless steel, prism sapphire, prism gasket modified PTFE (Teflon), gasket EPDM for Sanitary 3-A and ISO2852 type EHEDG certified gasket for EHEDG certified refractometers.
Refractometer protection class IP67, NEMA 4, 4X, 6, 6P
Refractometer weight
2.9 kg (6 lbs)
Current output
Isolated 4-20 mA, max. load 1000 Ohm, galvanic isolation 1000 VDC or AC (peak), hold function during prism wash
Remote and Ethernet connections 10/100BaseT Ethernet, web server for configuration and diagnostics, UDP/IP Protocol connection for data acquisition.
Power supply
+24 VDC ±10%, max. 2 VA
INTERCONNECTING CABLES
Standard length 10 m. Single cable maximum length 90 meters, with cable extender PR-8660 maximum length 90+90 meters.
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
37
3.4.4 PR-43-AP parts lists
17
13
15
14
16
13
12
11
10
9
8
7
6
5
4 3
Item Description
Part no. Qty
2 1
1
Screw M4x10 DIN7380 Torx tamper proof
PR-14003 2
2
PR-43 end plate
PR-14001 1
3
Dryer pack
PR-9108 1
4
PR-43 sensor interface card
1
4.1 PR-43 interface card (Ex ia)
PR-50011
4.2 mA-output card (general purpose, Ex nA)
PR-50033
5
O-ring for PR-43 end plate FPM
PR-14002-FPM 2
6
Screw M3x6 DIN7985 TX A2
3
7
PR-43 sensor processor card
1
7.1 Ex processor card (Ex ia)
PR-50012
7.2 General purpose and Ex nA
PR-50038
8
Screw M3x10 DIN965 TX A2
3
9
PR-33/PR-43-A card holder
PR-14050 1
10
PR-33/PR-43-A disk spring ring
1
11
Screw M5x10 ISO 14583 TX A2
6
12
Nord-Lock washer NL5ss
6
13
PR-43 connector & cable set
1
13.1 P4 connector & cable set (general purpose, Ex nA) PR-14101
13.2 P4 connector & cable set (Ex ia)
PR-14101-EX
14
PR-43 sensor cover
PR-14000 1
15
O-ring 68x3 FPM
PR-10048 1
16
O-ring 14x1,78 FPM
PR-14102-FPM 1
17
Disk spring
1
Figure 3.15 Refractometer cover assembly
© Copyright Vaisala 2019. All rights reserved.
38
2
4 3
PR-43-AC/AP instruction manual
1
Item Description
Part no.
1
PR-43-AP name plate
2
PR-43-base assembly
3
HX3 core assembly
PR-14021
4
Sensor head
4.1 PR-23-AP-PSS head
PR-10006
4.2 PR-23-AP-RSS head
PR-10007
4.3 PR-23-AP-TSS head
PR-10008
4.4 PR-23-AP-RSS-NC head
PR-10013
Nozzles and plug, contra nut, O-rings 9.3
4.4.1 and 5.2
4.5 PR-23-AP-VSS head
PR-10016
4.5.1 O-ring
4.6 PR-23-AP-QSS head
PR-10018
4.7 PR-23-AP-SSS head
PR-10024
4.8 PR-23-AP-ISS head
PR-10025
4.9 PR-23-AP-BSS head
PR-10026
4.10 PR-23-AP-HSS head
PR-10027
4.11 PR-23-AP-CSS head (DN65 Varivent head) PR-10029
4.12 PR-23-AP-ZP head
PR-10046
Qty Product code 1 1 1 1 PR-43-AP-T10-P15-L00 PR-43-AP-H40-L170 PR-43-AP-H25-L170 PR-43-AP-H40-L170-NC
PR-43-AP-V25-P15
PR-43-AP-H25-L140 PR-43-AP-H40-L63 PR-43-AP-H25-L42 PR-43-AP-T10-L170 PR-43-AP-H25-L14 PR-43-AP-E25-L170 PR-43-AP-Z25-L178
Figure 3.16 PR-43-AP assembly
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
39
3.4.5 PR-43-AP mounting specifics
The Probe refractometer PR-43-AP is primarily designed for mounting in a tank wall. To ensure that the measurement is representative and that the prism stays clean, the probe should be installed close to a stirrer.
Probe refractometer type PR-43-AP-H25 is connected to the process by a 2½ inch 3-A sanitary clamp.
Note: For higher process (or ambient) temperature, use instead a flush mounted refractometer, where the electronics in the refractometer head are farther away from the process heat.
1
2
3
min 20 [0.79]
4
max 60 [2.4]
93°
2,37 60,3
1,48 37,5
5
Figure 3.17 Insertion of Probe refractometer PR-43-AP-H25 The refractometer type PR-43-AP-T10-L00 is flush mounted using a sanitary APV tank bottom flange. The refractometer can be flush mounted in the side wall, which allows the use of a scraper. It is also easily installed through a steam jacket.
© Copyright Vaisala 2019. All rights reserved.
40
PR-43-AC/AP instruction manual
Figure 3.18 Flush mounting Probe refractometer PR-43-AP-T10-L100
Sanitary Refractometer PR-43-AP-Z is mounted using 3-A Sanitary certified 2.5 inch Cherry Burrell I-Line fittings that are made of interlocking flat face ferrules, a flat gasket and a clamp. This interlocking, metal-to-metal design eliminates over compression by the clamp not allowing the gasket to be extruded into the product contact side. The sensor is male part of the connection.
Refractometer wetted parts material is AISI 316L or Alloy C, gaskets EPDM.
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
41
12
3 Min 30 [1.18]
Max 60 [2.36]
93°
6,69 170
4 5
2,37 60,3
1,48 37,5
Figure 3.19 I-Line fitting for PR-43-AP
SECTION A-A
© Copyright Vaisala 2019. All rights reserved.
42
PR-43-AC/AP instruction manual
3.4.6 Mounting specifics for EHEDG certified PR-43-AP configuration
Vaisala offers certain PR-43-AP configurations which have been certified to fulfill the sanitary requirements published by EHEDG (European Hygienic Engineering & Design Group) organization. During this certification the hygienic characteristics of both the refractometer and the process connection were evaluated against the applicable requirements.
To ensure EHEDG compliant installation, follow the mounting specifics provided on the mounting drawing supplied by Vaisala with each PR-43-AP refractometer ordered with the -EH option.
An example of such mounting guideline is shown in the Figure 3.20.
5
1
2
34
93°
b 1,48
37,5
a
Notes for EHEDG compliant installation:
1) The distance a shall be less than the dimeter b per the EHEDG guideline 10
2 For other installation specifications see the web address:
http://ehedg.org/index.php?nr=110&lang=en
TYPE EL CLASS I
February 2015
Item no. Name 1 Refractometer PR-43-AP 2 4" Sanitary clamp 3 EHEDG certified sanitary gasket 4" 4 4" Sanitary ferrule 5 Customer pipe/vessel
Figure 3.20 EHEDG certified PR-43-AP
Material AISI316L AISI304 ISO-2852 AISI316L AISI316L
Supplied by Pcs.
K-Patents
1
K-Patents
1
K-Patents
1
K-Patents
1
Customer
1
3.4.7 3-A Sanitary Standard compliance
The user should ensure that the refractometer is not a source of contamination to product due to damaged or worn product contact surfaces. Misuse (e.g. too long prism
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
3 Specifications
43
wash time or too high wash pressure) or mishandling may result in metal scratches or roughened surfaces. Such surfaces may not stay clean in processing.
K-Patents offers a 3-A Sanitary Standard accepted repair and maintenance package in which all wetted parts, prism, gaskets and dryer are replaced. Note that this repair service can be completed by 3-A authorized service center only (K-Patents factory or regional headquarters).
© Copyright Vaisala 2019. All rights reserved.
44
PR-43-AC/AP instruction manual
4 Prism wash
Prism wash requires a system for wash control and diagnostics. This can be achieved with Multichannel user interface (MI) with a relay module.
4.1 Prism coating
Deposit build-up on the prism surface disturbs the measurement. An abnormally high concentration reading, an upward concentration (CONC) drift, decreased QF value or increased LED value may indicate coating. In most applications the prism will keep clean due to the self-cleaning effect. If coating occurs, check the following:
Sufficient flow velocity A temperature difference between process fluid and refractometer probe may
cause coating. This may happen with small flows if the thermal insulation is inadequate. In some cases it helps to also insulate the clamp connector.
In case of a coating problem, the preferred solution is to try to increase the flow velocity, e.g. by installing a pipe portion with smaller diameter. Installing a wash nozzle can be considered, if increasing the velocity does not provide a solution (Section 4.2).
4.2 Prism wash
Three alternative wash media can be used for prism wash: steam, water, high pressure water. Relay modules in a Multichannel user interface MI can be configured to control the prism wash cycle, see MI manual, Chapter 6, "Module cards" and Chapter 7, "Prism wash". Important: In food industry applications, wash medium must be culinary steam or safe water. Shut-off valve and check valve must meet 3-A sanitary standards. Culinary steam: Shall mean steam produced using a system meeting criteria in the 3-A Accepted Practices for a Method of Producing Steam of a Culinary Quality, Number 609.
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
4 Prism wash
45
Safe Water: Shall mean water from a supply properly located, protected, and operated, and shall be of safe, sanitary quality. The water shall meet the standards prescribed in the National Primary Drinking Water Regulation of the Environmental Protection Agency (EPA) as referenced in The Code of Federal Regulations (CFR), Title 40, Parts 141, 142, and 143.
4.2.1 Recommended wash pressures and times The recommended wash pressures and times are given in the tables below.
Wash medium parameters for integral wash nozzles in PR-43-AP
Minimum above process pressure
Maximum above Wash Recovery Interval process pressure time
Steam (SN)
2 bar (30 psi)
4 bar (60 psi) 3 s 2030 s 2030 min
Water (WN)
2 bar (30 psi)
4 bar (60 psi) 10 s 2030 s 1020 min
High pressure water (WP)
15 bar (220 psi) 40 bar (600 psi) 10 s 2030 s 1020 min
Wash medium parameters for flowcell wash nozzle AFC
Minimum above process pressure
Maximum above Wash Reco- Interval process pressure time very
Steam (SN)
3 bar (45 psi)
6 bar (90 psi) 35 s 2030 s 2030 min
Water (WN)
3 bar (45 psi)
6 bar (90 psi) 1015 s 2030 s 1020 min
High pressure water (WP)
25 bar (350 psi) 35 bar (500 psi) 1015 s 2030 s 1020 min
Important: In steam wash, do not exceed the recommended wash times, because some process media may burn to the prism surface if steamed for longer time. In case of coating, shorten the wash interval.
Note: In water wash, water temperature should be above the process temperature.
Note: The check valve pressure drop is 0.7 bar (10 psi).
4.2.2 Prism wash systems
The prism wash system for steam is described in Figure 4.1. The prism wash system for high pressure water is described by Figure 4.3.
© Copyright Vaisala 2019. All rights reserved.
46
PR-43-AC/AP instruction manual
Warning! In high pressure wash systems, pressure increase can occur in a closed pipe section when the high pressure pump is operated. It is recommended to mount a pressure relief valve in the pipe section. Relief pressure should be according to pipe pressure rating.
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
4 Prism wash
47
Figure 4.1 A prism wash system for steam
© Copyright Vaisala 2019. All rights reserved.
Effective: September 2, 2019
Document/Revision No. IM-EN-PR43ACAP/2.00
Figure 4.2 Wiring for a prism wash system for steam
PR-43 REFRACTOMETER (1-4 pcs.)
PR-8430 Platform 4 cable
SAFETY SWITCH PR-7060
12 3 45 6789
LN
NL L L
LN
SOLENOID VALVE FOR PNEUMATICALLY OPERATED SHUT-OFF VALVE ASSEMBLY: PR-3340-24/110/240
MULTI CHANNEL USER INTERFACE MI
3894
RELAY OUTPUT MODULE PR-50023
RELAY RELAY
1
2
mA-OUTPUT MODULE PR-50021
mA + 1 -
mA + 2 -
2122 2324
11 12 15 16
LN
+-
OPTIONAL 24V POWER SUPPLY FOR MI
ETHERNET M12
INSTRUMENTS M12 CONNECTORS
MAINS POWER SWITCH PR-10900
PR-8440 Ethernet cable for interfaces
MAINS POWER SWITCH PR-10900
24VDC +
POWER SUPPLY N 100-240VAC/50-60Hz L
mA Output 1
-
4-20mA
+
ETHERNET M12-8pin, D-code, M
POWER SUPPLY VOLTAGE
N
110VAC/230VAC/24VDC
FUSE 10A
L
PR-43-AC/AP instruction manual
48
4 Prism wash
49
3892
1
4
2
7 3
9
10
12
6
5
13
14
11
Water supply min 10l/min( 2.5gal/min)
7
Max temp. 60°C (140°F).
8
Safe water for sanitary use.
No. Description 1 PR-43 refractometer 2 Multichannel user interface 3 Power relay unit PR_3603-300-U/M-230/110 4 Platform 4 cable PR-8430 5 Relay cable 3x1 (AWG 17) 6 Power supply for MI
6.1 Power supply 100-240 VAC/50-60 Hz 6.2 Power supply 24V DC
7 Water supply line min. 12 mm (1/2") 8 High pressure pump PR-3602-XXX 9 Solenoid cable 3x1 (AWG 17) 10 Power cable 4x2.5 (AWG 12) 11 Power supply 400-575 VAC/50-60 Hz 12 Mains power switchy PR-10900 13 mA output cable 14 Ethernet cable for interface PR-8840
Supplied by Qty K-Patents 1 K-Patents 1 K-Patents 1 K-Patents 1 Customer 1 Customer 1
Customer 1 K-Patents 1 Customer 1 Customer 1 Customer 1 K-Patents 1 Customer 1 Customer 1
Figure 4.3 A prism wash system for high pressure water
© Copyright Vaisala 2019. All rights reserved.
Effective: September 2, 2019
Document/Revision No. IM-EN-PR43ACAP/2.00
Figure 4.4 Wiring for a prism wash system for high pressure water
PR-43 REFRACTOMETER (1-4 pcs.)
MAINS SWITCH
POWER RELAY UNIT PR-3603-____
T1T2T3
THERMAL
OVERLOAD
RELAY T1T2T3
12 3
4 5 6 7 8 9 101112
N
L N LN L L
LN
L1 L2L3 HIGH PRESSURE PUMP
SOLENOID VALVE FOR WATER INLET
PR-8430 Platform 4 cable +
MULTI CHANNEL USER INTERFACE MI
3894
RELAY MODULE PR-50023
RELAY RELAY
1
2
mA-OUTPUT MODULE PR-50021
mA + 1 -
mA + 2 -
21 22 23 24
11 12 15 16
LN
+-
OPTIONAL 24V POWER SUPPLY FOR MI
ETHERNET M12
INSTRUMENTS M12 CONNECTORS
MAINS POWER SWITCH PR-10900
PR-8440 Ethernet cable for interfaces
MAINS POWER SWITCH PR-10900
- 24VDC +
POWER SUPPLY N 100-240VAC/50-60Hz L
mA Output 1 - 4-20mA
ETHERNET M12-8pin, D-code, M
SUPPLY VOLTAGE 110VAC FUSE 10A
N 230VAC FUSE 10A L
N SUPPLY VOLTAGE L3 400/550VAC FUSE 10A L2 L1
PR-43-AC/AP instruction manual
50
4 Prism wash
51
4.2.3 Prism wash nozzles
When selecting a wash nozzle for PR-43-AP, take into account both the wash medium and the flowcell model: flowcells with larger pipe diameters need longer wash nozzles. Figure 4.5 below shows a wash nozzle for a flowcell and gives the measurements and part numbers for each nozzle type.
Flowcell -H10 or -H15
A
B part nr
steam water pressurized water
64.75 4.0 75 2.5 75 1.5
PR-3365 PR-3369 PR-3368
Flowcell -H20 or -H25
A
B part nr
steam water pressurized water
72.15 4.0 PR-3375 97Mark 2Re.5v. PR-3379 97 C 1M.5RP PnRr-o3t37m8 uuttuneet
Flowcell -H30
A
B part nr
steam
103 4.0 PR-3393
water
113 2.5 PR-3394
pressurized water 113 1.5 PR-3395
Flowcell -H40
A
A
B part nr
steam
133 4.0 PR-3390
water
143 2.5 PR-3391
pressurized water 143 1.5 PR-3392
Figure 4.5 Wash nozzles for flowcell AFC-HSS-XXX-XX-NC
B
Date
Rev. by
A
Figure 4.6 shows how the nozzle is mounted in a flowcell (-NC with stud for a wash nozzle).
© Copyright Vaisala 2019. All rights reserved.
52
PR-43-AC/AP instruction manual
Figure 4.6 Process connection of a wash nozzle in a flowcell
For PR-43-AP, select the wash nozzle according to wash medium, see Table 4.1 below.
Steam nozzle Water nozzle Pressurized water nozzle
PR-43-AP PR-9321 PR-9320 PR-9322
Table 4.1 Prism wash nozzle selection
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
5 Refractometer verification
53
5 Refractometer verification
Each Vaisala K-PATENTS® refractometer is provided with a calibration certificate comparing a set of standard liquids to the actual refractometer output. Therefore, the calibration and accuracy can be easily verified on-site with the certified refractive index liquids and menu guided verification procedure.
For verification you need:
Universal sample holder PR-1012 (see Figure 5.1 below). The sample holder keeps the sample on the prism surface and also keeps the ambient light out.
A set of standard refractive index liquids. Cleaning solution (ethanol) to clean the refractometer prism and the sample holder.
The verification of the PR-43 refractometer calibration is made using a set of standard refractive index liquids with the nominal values at 25 °C:
1.330 1.370 1.420 1.470 1.520
The accuracy of the certified standard refractive index liquids is ± 0.0002 and they can be traced back to national standards: NIST Standards # 1823 and # 1823 II. As the specified accuracy of PR-43 is ±0.0002, then the representative level is the sum of the two accuracy specifications, that is, ±0.0004.
Vaisala provides a set of standard R.I. liquids, PR2300, containing these five liquids. The set can be ordered directly from Vaisala or through your representative.
Figure 5.1 Universal sample holder PR-1012
A verification can be done by connecting to the refractometer over ethernet or by using a Multichannel user interface MI or Compact user interface CI. In web interface, choose Verification on the Main menu and follow the instructions on the page. In MI, tap the
© Copyright Vaisala 2019. All rights reserved.
54
PR-43-AC/AP instruction manual
three dots in the app for the refractometer to be verified, then choose Verification. Tap question mark in the Verification display to get verification instructions. In CI, choose Verification in the Main menu and follow the instructions on screen.
Important: For a successful verification, the refractometer and the standard refractive index liquids must be in room temperature (25 ±5 °C).
To check that the standard liquid is properly wetting the prism, the optical image can be monitored during the verification procedure. The optical image should show a sharp shadow edge.
The instrument measures each verification data point ten times and uses the average of these measurements. Measuring each verification liquid takes a few seconds, during which the measurement progress display is shown. Please wait until the verification step 2 display reappears before proceeding to next verification liquid. The limit for acceptance is that all measurements must be within ± 0.0004 of the nominal values.
If message is VERIFICATION FAILED, first check that the prism and the sample holder are absolutely clean and the sample holder sits tightly on the refractometer tip before a standard liquid is applied. Make sure the standard liquids are in good condition and not past their expiration date. Also, inspect the prism surface, checking that it is flat and glossy without any scratches. Repeat the verification procedure. If the verification still fails, fill in the PR-43 refractometer verification form, found at the end of this manual. The refractometer's serial number is shown in the upper right corner of each display. The list of CCD and TEMP values are found on the Verification results display. Send the form to your Vaisala K-PATENTS® representative or email the collected data to info@kpatents.com and wait for further instructions.
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
PR-43 refractometer verification form
55
PR-43 refractometer verification form
Fill in this form and email (or fax) it to your local service representative.
Refractometer serial no: Customer: Address: Fax: Email: Date: Verification made by:
Sample no 1 2 3 4 5
Nominal nD 1.330 1.370 1.420 1.470 1.520
VERIFICATION RESULTS DISPLAY
Measured nD
CCD
Temp
© Copyright Vaisala 2019. All rights reserved.
56
PR-43-AC/AP instruction manual
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
EU declaration of conformity
57
EU declaration of conformity
2019-09-01J/JAMO
1 (1)
EU DECLARATION OF CONFORMITY
Manufacturer: Vaisala Oyj Mail address: P.O. Box 26, FI-00421 Helsinki, Finland Street Address: Vanha Nurmijärventie 21, Vantaa, Finland
This declaration of conformity is issued under the sole responsibility of the manufacturer.
Object of the declaration: K-Patents Process Refractometer PR-43 series
The object of the declaration described above is in conformity with Directives: RoHS Directive (2011/65/EU) EMC Directive (2014/30/EU)
The conformity is declared using the following standards: EN 50581:2012 Technical documentation for the assessment of electrical and electronic products with respect to the restriction of hazardous substances EN 61010-1:2010 Safety requirements for electrical equipment for measurement, control and laboratory use Part 1: General requirements EN 61326-1:2013 Electrical equipment for measurement, control and laboratory use EMC requirements intended for use in industrial locations
Signed for and on behalf of Vaisala Oyj, in Vantaa, on 1st September 2019
______________________________________ Jukka Lyömiö Standards and Approvals Manager
Vaisala Oyj | PO Box 26, FI-00421 Helsinki, Finland Phone +358 9 894 91 | Fax +358 9 8949 2227 Email firstname.lastname@vaisala.com | www.vaisala.com Domicile Vantaa, Finland | VAT FI01244162 | Business ID 0124416-2
© Copyright Vaisala 2019. All rights reserved.
58
PR-43-AC/AP instruction manual
Document/Revision No. IM-EN-PR43ACAP/2.00
Effective: September 2, 2019
www.vaisala.com
LuaTeX-1.09
