For more than 70 years, State has committed to providing it's valued partners with high quality products built to perform. State's comprehensive commercial product family is no exception.
COMMERCIAL PRODUCT CATALOG TABLE OF CONTENTS STATE COMMERCIAL PRODUCT CATALOG The EliminatorTM...................................................................................... 1 PermaGlas® Ultra CoatTM......................................................................... 1 iCOMMTM Remote Monitoring System...................................................... 2 Building Management System BACnet & Modbus interface.................... 3 COMMERCIAL TANKLESS Commercial Rack System.................................................................21-22 Tankless High Efficiency Condensing.................................................... 23 Tankless Heavy-Duty............................................................................. 24 COMMERCIAL GAS Modulating Ultra Force®.......................................................................... 5 Ultra Force® LV........................................................................................ 6 Force® 90 HE Power Direct Vent............................................................... 7 Force® 90 HE Power Vent......................................................................... 8 Unrivaled Venting Flexibility.................................................................... 9 Polaris® High Efficiency........................................................................ 10 TX1 Integrated Tankless on Tank........................................................... 11 Sandblaster® Self Cleaning.................................................................. 12 Sandblaster® SBL Ultra-Low NOx.......................................................... 13 Sandblaster® Light Duty....................................................................... 14 Sandblaster® Light Duty Ultra-Low NOx................................................ 15 Sandblaster® Force Power Direct Vent................................................... 16 Titan® Power Burner.............................................................................. 17 COMMERCIAL ELECTRIC Light-Service......................................................................................... 26 Patriot®............................................................................................27-28 Sandblaster® CSB................................................................................. 29 Statesman.......................................................................................30-31 Large Volume Electric SEV/SEH........................................................32-34 COMMERCIAL HEAT PUMP CHP Fully Integrated Heat Pump........................................................... 36 COMMERCIAL STORAGE TANKS Factory Jacketed & Insulated Storage Tanks....................................38-39 Standard Jacketed Storage Tanks......................................................... 40 Uninsulated Standard Stock Bare Storage Tanks.................................. 41 Heavy-Duty Large Volume Storage Tanks..........................................42-43 COMMERCIAL OIL-FIRED Titan® Power Oil Burner Low NOx........................................................... 19 Customer Service | phone:800.845.1108 | fax:800.634.3097 | email: orderaos@statewaterheaters.com. For more than 70 years, State has committed to providing it's valued partners with high quality products built to perform. State's comprehensive commercial product family is no exception. With products ranging from standard gas and electric, to high efficiency, hybrid and tankless, State can offer the right product for every job. We view this accomplishment as a mere beginning, and will continue to work towards greater things--newer and more durable technologies. For everyone here at State, it's never been just about outdoing what we have achieved in the past--it's always been about growing beyond our expectations for the future. Solid. State. THE ELIMINATORTM SELF-CLEANING TECHNOLOGY STATE DURABILITY & QUALITY... ENGINEERED INTO EVERY PRODUCT STARTING WITH PREMIUM COMPONENTS As deposits of lime and other sediments accumulate inside the tank, they form a barrier between the burner and the water, concentrating heat around the critical weld areas. The result is reduced energy efficiency, higher operating costs, and greater risk of premature tank leaks. The Eliminator directs incoming cold water under pressure to sweep the bottom of the tank to keep sediment moving so it doesn't accumulate. With the Eliminator, every Sandblaster® water heater can be expected to maintain its rated efficiency longer and deliver reliable service year after year. PERMAGLAS® ULTRA COATTM GLASS COATING PermaGlas Ultra Coat is State's exclusive "slush coat" process that heat-bonds glass to each tank's inner surface after all connections and seams have been welded. Because of this, there is no chance of "weld burn" that can burn away normal glass lining and expose bare steel to water. PermaGlas Ultra Coat provides protection for the tank's top, bottom, and outer shell and all weld seams. All welds completed prior to PermaGlas Ultra Coat. Once tanks are filled with PermaGlas, they are rotated (computer controlled) for precise, even coating. Technician removes hand-hole clean-out to prepare it for the next step. Tanks are then rotated further, allowing the excess PermaGlas to drain from the tank. After pre-drying in 200ºF ovens, the tanks are then fired to 1,600ºF, fusing the PermaGlas to the steel tank. 1 iCOMMTM REMOTE MONITORING SYSTEM CONNECTIVITY NOW STANDARD ON ALL SUF MODELS The iCOMM connectivity service allows users to view and manage their water heater operation remotely. Detailed information on current status, usage history, set points and other key parameters is available within the iCOMM function on the State Water Heaters app. Fault and alert information is communicated via text message and/or e-mail providing valuable information needed to restore the unit to proper operation. iCOMM now can be maintained and managed from the convenience of the State app available for iPhone and Android. Get real time information delivered to your phone directly from your water heater. There are no subscription or app fees related to the iCOMM connectivity service. iCOMM SYSTEM REQUIREMENTS · Standard equipment on Ultra Force® SUF 120-500 models with touch display (Series 300 to present) · Internet connection via Wi-Fi or Ethernet. · The latest version of the State app (available for iOS and Android devices). iCOMM BENEFITS · iCOMM connectivity helps ensure businesses have the hot water needed. · Contractors can stay connected to their customers by monitoring operation and receiving fault notifications remotely. · Operators with multiple locations can manage their fleet of water heaters remotely. iCOMM FEATURES · Remote monitoring via Wi-Fi or Ethernet cable. Once the unit is registered to iCOMM on the app, registered users can view current water heater status and all pertinent information available from the convenience of their phone. · Automated service notifications in the event of any alarm or fault conditions. Registered users are notified by text and/or email. · Appliance run time shows the total on time, cycle count and burner on time. · Custom notification settings allow for alerts when tank temperatures are above or below user parameters. · Users can view one or multiple water heaters associated with their user account. 2 COMMERCIAL WATER SYSTEMS BUILDING MANAGEMENT SYSTEM BACNET & MODBUS INTERFACE MODELS: ETH-1000 Ethernet Connection XLTR-1000 Serial RS-485 Connection INTRODUCING THE BMS GATEWAY FOR CONTROL OF STATE WATER HEATERS Connect your State water heater to your building management system using the new Millennium control from ICC* (Industrial Control Communications, Inc.) · Works with Force, SSE/SEV/SEH · Use the ICC Control to enable/disable the water heater · Change Temperature Set points and differentials · Two models with four different configurations to connect to BACnet and Modbus thernet and Serial RS485 versions available · 2 wire or 4 wire RS485 Network · Power can be supplied via the USB cable, as a 7-24 · VDC input on the main terminal Block, or via IEEE 802.3af Power over Ethernet (PoE on ETH-1000 only) · Configure protocols, network characteristics, and client/server object definitions · Graphically interact with the internal database in real-time via USB connection · Automatically discover and configure IP settings · Ethernet gateways connected to the current subnet · Update Firmware PROTOCOL BACnet Modbus ICC ENERGY MANAGEMENT INTERFACES PART NUMBER 100121264 100131365 100131370 100131371 100131371 100131368 CONNECTION TYPE APPLICATION Serial (RS485) Commercial Gas - Force 90 and Modulating Ultra Force-100 Commercial Electric SSE, SEV, SEH Ethernet (IP) Serial (RS485) Commercial Gas - Force 90 and Modulating Ultra Force-100 Commercial Electric, SSE, SEV, SEH Commercial Gas - Force 90 and Modulating Ultra Force-100 Commercial Electric, SSE, SEV, SEH 100131373 100131374 Ethernet (IP) Commercial Gas - Force 90 and Modulating Ultra Force-100 Commercial Electric, SSE, SEV, SEH · Heater connection wiring supplied with unit · For questions on this product Call 888-928-3702 Opt 1 · RTU and serial connect via RS485 · Ethernet and IP connect via RJ45 3 STATE COMMERCIAL GAS WATER HEATERS (optional) COMMERCIAL GAS MODULATING ULTRA FORCE® Up to 98% Efficient Intelligent Control System with Touch Screen Display · Exclusive State designed control system · Provides detailed water heater status information · Precise temperature control adjustable from 90 to 180 degrees · Built-in diagnostics · Run history information · iCOMM remote monitoring on-board with Wi-Fi connectibility Submerged Combustion Chamber, with Helical Heat Exchanger Coil · Positioned in center of tank, surrounded by water to virtually eliminate radiant heat loss from chamber · Direct spark ignition · Spiral heat exchanger keeps hot burner gases swirling, uses centrifugal force to maximize efficiency of heat transfer to water in tank · Spiral heat exchanger reduces lime scale from forming on water-side surfaces, which maintains energy efficiency over time Modulating Pre-Mix Powered Burner · Top-mounted down-fired burner modulates to match demand providing optimum fuel efficiency, and quiet operation. Ultra-Low NOx Operation · Complies with SCAQMD Rule 1146.2 and other Air Quality Management Districts with similar requirements for NOx emissions of less than 14 ng/J or 20 ppm. Power Anodes Standard on All Models · Provides long-lasting tank protection in varying water conditions · Powered anodes are non-sacrificial · Automatically adjusts output needed to properly protect the tank 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete warranty information, consult written warranty or go to statewaterheaters.com. Model Number Gallon Capacity BTU/H Input Recovery GPH Temperature Rise 40°F 100°F 140°F SUF60 12ONE 60 120,000 345 138 99 SUF100 150NE 100 150,000 445 178 127 SUF100 199NE 100 199,900 588 235 168 SUF100 250NE 100 250,000 727 291 208 SUF119 300NE 119 300,000 873 349 249 SUF119 400NE 119 399,900 1151 460 329 SUF119 500NE 119 499,900 1439 576 411 Optional Concentric Vent Kits 100111100 (SUF60-120 through SUF100-250 models). 100113124 (SUF119 300-through SUF119-500 models). Electrical characteristics- 120V-60 Hz A.C., 5.0A. "A" in the model number represents ASME construction. Models are certified from sea level to 10,100 ft. elevation. Dimensions in Inches Height Diameter 55.5 27.75 76 27.75 76 27.75 76 27.75 75.75 33.12 75.75 75.75 33.12 33.12 Approx. Shipping Weight (lbs) Standard ASME 460 490 523 553 523 553 523 553 855 855 855 855 855 855 5 (All models except SUFL-220-500A) COMMERCIAL GAS ULTRA FORCE® LV (LARGE VOLUME) Up to 96% Efficient Intelligent Control System with Touch Screen Display · Exclusive State designed control system · Provides detailed water heater status information · Precise temperature control adjustable from 90 to 180 degrees · Built-in diagnostics · Run history information · iCOMM remote monitoring on-board with Wi-Fi connectibility Submerged Combustion Chamber, with Helical Heat Exchanger Coil · Positioned in center of tank, surrounded by water to virtually eliminate radiant heat loss from chamber · Direct spark ignition · Spiral heat exchanger keeps hot burner gases swirling, uses centrifugal force to maximize efficiency of heat transfer to water in tank · Spiral heat exchanger reduces lime scale from forming on water-side surfaces, which maintains energy efficiency over time Modulating Pre-Mix Powered Burner · Top-mounted down-fired burner modulates to match demand providing optimum fuel efficiency, and quiet operation Ultra-Low NOx Operation · Complies with SCAQMD Rule 1146.2 and other Air Quality Management Districts with similar requirements for NOx emissions of less than 14 ng/J or 20 ppm Power Anodes Standard on All Models · Provides long-lasting tank protection in varying water conditions · Powered anodes are non-sacrificial · Automatically adjusts output needed to properly protect the tank 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete warranty information, consult written warranty or go to statewaterheaters. com Model Number Gallon Capacity BTU/H Input Recovery GPH Temperature Rise 40°F 100°F 140°F Dimensions in Inches Height Diameter Approx. Shipping Weight (lbs) ASME SUFL-250-150A 250 150,000 436 175 125 91-1/2 42-1/8 1125 SUFL-250-199A 250 199,900 575 230 164 91-1/2 42-1/8 1125 SUFL-250-250A SUFL-220-300A SUFL-220-400A SUFL-220-500A 250 250,000 712 285 203 91-1/2 42-1/8 1125 220 300,000 855 342 244 91-1/2 42-1/8 1420 220 399,900 1127 451 322 91-1/2 42-1/8 1420 220 499,900 1394 557 398 91-1/2 42-1/8 1420 Optional Concentric Vent Kits 100111100 (SUFL-250-150A through SUFL-250-250A models). 100113124 (SUFL-220-300A through SUFL-220-500A models). Optional Condensate Neutralization Kits available. 100112380 (SUFL-250-150A through SUFL-250-199A models), 100112381 (SUFL-250-250A through SUFL-220500A models). Electrical characteristics- 120V-60 Hz A.C., 5.0A. "A" in the model number represents ASME construction. Models are certified from sea level to 10,100 ft. elevation. 6 COMMERCIAL GAS FORCE® 90+ POWER DIRECT VENT High Efficiency Condensing Design · Operates at 96% thermal efficiency which saves money on operating costs compared to a standard 80% efficient gas water heater Intelligent Control System with LCD Display · Exclusive State designed control system · Provides detailed water heater status information · Precise temperature control · Built-in diagnostics · Run history information Helical Internal Heat Exchanger · Spiral heat exchanger keeps hot combustion gases in the tank longer to lengthen the heat transfer cycle · Positioned in the center of the tank for more even heat distribution Advanced Electronic Control · Touch screen display with precise temperature control, built in diagnostics and status information. Ultra-Low NOx Operation · Complies with SCAQMD Rule 1146.2 and other Air Quality Management Districts with similar requirements for NOx emissions of less than 14 ng/J or 20 ppm. Power Direct Vent Design · Combined vertical and horizontal runs terminating through an outside wall. Vents using PVC, CPVC, or polypropylene piping. Canadian installations require ULC S636 approved pipe for venting. · 2" pipe, vents up to 45 equivalent feet · 3" pipe, vents up to 128 equivalent feet Side-Mounted Hot and Cold Recirculating Taps · Allows Force® 90+ to be installed as part of combination space heating/water heating applications. 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete warranty information, consult written warranty or go to statewaterheaters.com. Model Number SHE50 SHE75 Gallon Capacity 50 75 BTU/H Input 100,000 100,000 Recovery GPH Temperature Rise 40°F 100°F 140°F 291 115 83 291 115 83 Standard model certified from sea level to 10,100 ft. elevation. Optional Concentric Vent Kits (100111100) and Condensate Neutralization Kits (100112380). Dimensions in Inches Height Diameter 66-3/4 22 65-1/4 27-3/4 Approx. Shipping Weight (lbs) 264 382 7 COMMERCIAL GAS FORCE® 90 Helical Coil Heat Exchanger · Submerged heat exchanger provides much greater heat transfer surface than standard straight flue tube · Produces 94% thermal efficiency, which saves money on operating costs, and increases hot water output compared to standard-efficiency water heaters Versatile Power Vent Design · System allows combined vertical and horizontal vent runs, terminating through an outside wall using Schedule 40 PVC, CPVC, or polypropylene pipe · 2" pipe vents up to 25 equivalent feet · 3" pipe vents up to 65 equivalent feet · 4" pipe vents up to 128 equivalent feet High Output With Small Footprint · 22 diameter, combined with 94% efficiency, 76,000 BTU input means FORCE 90 can be installed in less space than a larger 75-gallon unit with equal or better performance PermaGlas® Ultra Coat Glass Lining · State exclusive process provides superior protection against corrosion · Protects all interior tank surfaces including inside and outside of helical heat exchanger **Intelli-VentTM Gas Control · Equipped with long-lasting silicon nitride hot surface ignitor--no standing pilot · Advanced electronics for more precise control of water temperature and simplified system diagnostics · 180°F maximum temperature setting Side-Mounted Hot And Cold Recirculating Taps · Allows FORCE 90 to be installed as part of combination space heating/water heating applications, or any system requiring a recirculating hot water loop · Plugs for the recirculating taps are factory installed Two Heavy-Duty Anode Rods · Provide advanced protection against corrosion 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete warranty information, consult written warranty or go to statewaterheaters. com. **Intelli-VentTM is a registered trademark of Emerson Electric Company Model Number Gallon Capacity BTU/H Input SHE50 76NE 50 76,000 Available in natural gas only. Can be installed up to 5,300 feet without alteration. Use SMR S54 for installation up to 10,100 Ft. Recovery GPH Temperature Rise 40°F 100°F 140°F 215 86 61 Dimensions in Inches Height Diameter 71-1/8 22 Approx. Shipping Weight (lbs) 225 8 Unrivaled Venting Flexibility The modulating ULTRA FORCE® features power-vent and power direct vent design, allowing combustion air to be drawn from the equipment room conventionally or directly from the outdoor atmosphere through a sealed intake air pipe. Vent systems can be terminated vertically through the ceiling or horizontally through a sidewall. Front located exhaust and condensate connections allow for easy installation and serviceability. SEALED DIRECT VENT VERTICAL SEALED DIRECT VENT SIDEWALL INDOOR CONVENTIONAL VERTICAL See instruction manual for complete venting instructions and allowable vents lengths. INDOOR CONVENTIONAL SIDEWALL Common Venting Kit Available Up to three Modulating Ultra Force units can be common vented allowing for fewer wall penetrations, reduced installation costs, and greater flexibility in venting materials. 9 COMMERCIAL GAS POLARIS® HIGH EFFICIENCY Condensing Design · Operates at up to 96% thermal efficiency which saves money on operating costs compared to a standard 80% efficient gas water heater. · Helical internal heat exchanger keeps hot combustion gases in the tank longer to extract more heat into the water. · Modulating burner maintains high efficiency operation at lower input rates. Stainless Steel Construction · Tank and helical heat exchanger are constructed from 444 stainless steel for excellent corrosion resistance without the need for an anode. Ultra-Low NOx Operation · Complies with SCAQMD Rule 1146.2 and other air quality management districts with similar requirements for Ultra-Low NOx emissions requirements of 14 ng/J or 20 PPM. Quiet Operation · Quiet blower and burner minimize noise. Power Direct Vent Design · Direct vent using PVC (solid core only), CPVC or Polypropylene through a sidewall or roof. · Optional concentric vent kit Advanced Electronic Control · Touch screen display with precise temperature control, built in diagnostics and status information. Side-Mounted Hot And Cold Recirculating Taps · Allows Polaris to be installed as part of combination space heating/water heating applications, or any system requiring a recirculating hot water loop. 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete information, consult written warranty or go to statewaterheaters.com. Model Number Gallon Capacity BTU/h Input Gallon Per Hour Thermal Efficiency Recovery @ Dimensions in Inches 100° Rise Gallon Per Hour Height Diameter SPC 34 130 NE 34 130,000 96% SPC 34 150 NE 34 150,000 94% SPC 50 130 NE 50 130,000 95% SPC 50 150 NE 50 150,000 95% SPC 50 175 NE 50 175,000 96% SPC 50 199 NE 50 199,000 96% 149 48-1/2 22 171 48-1/2 22 149 62-3/8 22 171 63-3/4 22 200 63-3/4 22 227 63-3/4 22 Available in Propane (LP) gas. For Propane (LP) change NE to PE. Models certified for sea level to 7,700 ft. elevation. Vent Connection 2 or 3 2 or 3 2 or 3 2 or 3 3 3 1" Water Connections 15-3/4 15-3/4 15-3/4 15-3/4 15-3/4 15-3/4 40-1/2 40-1/2 54-1/2 55-3/4 55-3/4 55-3/4 Approx. T&P Gas Supply* Shipping Weight (lbs) 41 6-3/8 150 41 6-3/8 150 55 6-3/8 176 56-1/4 6-3/8 180 56-1/4 6-3/8 180 56-1/4 6-3/8 180 10 COMMERCIAL GAS TX1 INTEGRATED TANKLESS ON TANK Delivers 96% Thermal Efficiency Ultra-Low NOx Operation · Complies with SCAQMD Rule 1146.2 and other Air Quality Management Districts with similar requirements for ultra low-NOx emissions Integrated CT-199 Commercial Tankless · Modulating burner · Primary heat exchanger constructed of commercial grade copper · Secondary heat exchanger constructed of 316 grade stainless steel · Advanced electronic control with integrated diagnostics · 185°F maximum temperature 119 Gallon Storage Tank · 4.1 GPM pump · Glass lined tank · Multiple anodes to protect the tank · Front water inlet and top water outlet 6 Year Limited Heat Exchanger and Tank, 5 Year Limited Parts Warranty · For complete information, consult written warranty or go to statewaterheaters.com. Model Description Gallon Capacity Input BTU/HR Thermal Efficiency STX-199-N Indoor Nat 119 199,000 96% STX-199-P Indoor LP 119 199,000 96% Electrical characteristics-120V-60Hz A.C., 5.0 A. Models certified from sea level to 10,100 ft. elevation. Height 72 72 Dimensions Width 29.4 29.4 Depth 41 41 Recovery GPH Temperature Rise 40°F 579 2,192 100°F 232 878 140°F 165 625 Shipping Weight (lbs.) 520 520 11 (Select Models) COMMERCIAL GAS SANDBLASTER® SELF CLEANING Designed with Flexibility in Mind · Hot and cold water connections can be made through front, top or rear of unit · Low installation clearances The ELIMINATOR Self-Cleaning System · Designed to significantly reduce or eliminate sediment build-up inside the tank when using the front connection · Helps maintain thermal efficiency and reduce water-heating costs. · Maximizes tank life Factory-Installed Draft Diverter and Flue Damper · Low-profile draft diverter helps for installation in tight spaces · Automatic motorized flue damper helps minimize standby heat loss · SBD85 Uses Draft Inducer design PERMAGLAS® ULTRA COAT Glasslining · Exclusive process provides superior protection against corrosion CoreGard Anode Rods with Stainless Steel Core Provide Additional Corrosion Protection Intermittent Electronic Ignition · Eliminates standing pilot, saves energy · Includes power ON/OFF switch CSA Certified and ASME rated T&P Relief Valve, Factory-Installed Maximum Hydrostatic Working Pressure: 160 psi Fully Automatic Control System · Electric temperature control for precise temperature regulation adjustable 120ºF180ºF Handhole Clean Out 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete information, consult written warranty or go to statewaterheaters.com. Model Number SBD71 120NE SBD81 154NE SBD81 180NE SBD100 199NET SBD81 199NE SBD100 199NES(A) SBD100 250NE(A) SBD65 251NE(A) SBD100 275NE(A) SBD65 305NE(A) SBD85 365NE(A) SBD100 390NE(A) SBD85 500NE(A) Gallon Capacity BTU/H Input 71 120,00 81 180,000 81 180,000 100 199,000 81 199,000 100 199,000 100 250,000 65 251,000 100 275,000 65 305,000 85 365,000 100 390,000 85 500,000 Recovery GPH Temperature Rise 40°F 100°F 140°F 291 116 83 434 174 124 434 174 124 482 193 132 461 184 132 482 193 132 606 242 173 608 243 174 667 267 190 739 296 211 885 354 253 970 388 277 1212 485 346 Dimensions in Inches Height Diameter 69.75 27.5 67.5 27.5 67.5 27.5 75 27.5 67.5 27.5 72 30.25 72 30.25 75 27.75 72 30.25 75 27.75 79.5 27.75 75.5 30.25 81.5 27.75 Approx. Shipping Weight (lbs) Standard ASME 400 N/A 470 N/A 470 N/A 603 N/A 470 N/A 630 725 630 725 750 862 630 725 750 862 725 833 760 874 812 857 Specify when ordering propane (LP) gas. *Model SBD 120 is shipped with 6" x 5" flue outlet adapter. Models SBD 250, 251 and 275 are shipped with a 8" x 6" flue outlet adapter. Standard models certified from sea level to 2,000 ft. elevation. Order SMR S54 for elevations up to 8,000 ft. SBD-500 model features induced draft design and no damper. "A" in the model number indicates optional ASME construction. e.g. SBD85 500 NEA 12 COMMERCIAL GAS SANDBLASTER® SBL ULTRA-LOW NOx Complies with California SCAQMD Rule 1146.2 and other Air Quality Management Districts with Similar Requirements of 20 PPM and 14 NG/J Low NOx Requirements. Rated Category 1 Appliance Top, Front, and Back Plumbing Connections Uses Standard Double Wall Type B Vent No Draft Hood or Barometric Damper CSA Certified and ASME rated T&P Relief Valve, Factory-Installed Handhole Cleanout The ELIMINATOR Self-Cleaning Feature CoreGard anode rods with stainless steel core provide additional corrosion protection 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete information, consult written warranty or go to statewaterheaters.com. (Optional on Select Models) Model Number SBL81 120NE SBL81 154NE SBL81 180NE SBL81 199NE SBL100 199NE SBL100 250NE(A) SBL100 275NE(A) SBL86 310NE(A) SBL86 366NE(A) SBL86 390NE(A) Gallon Capacity 81 81 81 81 100 100 100 86 86 86 BTU/H Input 120,000 154,000 180,000 199,000 199,000 250,000 275,000 310,000 366,000 390,000 Recovery GPH Temperature Rise 40°F 100°F 140°F 288 115 82 370 148 106 432 173 123 478 191 137 478 191 137 600 240 171 660 264 189 744 298 213 879 352 251 936 375 268 Electrical characteristics--120V-60 Hz A. C., 5.0A. (A) after model number designates optional ASMEconstruction. LEG KITS FOR UL SANITATION TO MEET NSF-5 (increases overall height by 4"). SBL models not available in LP gas. Dimensions in Inches Height Diameter 63-3/4 27-3/4 63-3/4 27-3/4 63-3/4 27-3/4 63-3/4 27-3/4 71-3/4 27-3/4 71-3/4 27-3/4 71-3/4 27-3/4 71-3/4 27-3/4 71-3/4 27-3/4 71-3/4 27-3/4 Approx. Shipping Weight (lbs) Standard ASME 650 N/A 650 N/A 650 N/A 650 N/A 750 800 750 800 750 800 810 860 810 860 810 860 13 COMMERCIAL GAS SANDBLASTER® LIGHT DUTY SBS models provide reliable, efficient service for applications such as office buildings and duplex apartment homes. CoreGard Anode Rods with Stainless Steel Core Provide Additional Corrosion Protection PERMAGLAS® Glasslining · Glass lining and anode rod protect steel tank from corrosion Fully Automatic Controls · Includes automatic safety shutoff gas if pilot is extinguished, and high temperature energy cutoff (ECO) Compact Design · Smaller diameters and shorter heights for greater installation flexibility Available in Natural Gas and Propane Piezo Ignitor · Natural gas models only CSA Certified and ASME Rated T&P Relief Valve, Factory-Installed 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete information, consult written warranty or go to statewaterheaters.com Model Number Gallon Capacity SBS75 76NE 74 SBS100 76NE 98 NSF leg kit 100111360. BTU/H Input 75,100 75,100 Recovery GPH Temperature Rise 40°F 100°F 140°F 182 73 52 182 73 52 Dimensions in Inches Height Diameter 61-1/8 26-1/2 68-5/8 27-3/4 Approx. Shipping Weight (lbs) 275 350 14 COMMERCIAL GAS SANDBLASTER® LIGHT DUTY ULTRA LOW NOX Compact Design · Smaller diameters and shorter heights for greater installation flexibility Fully Automatic Controls · Includes automatic safety shutoff gas if pilot is extinguished, and high temperature energy cutoff (ECO) PERMAGLAS® Glasslining · Glass lining and anode rod protect steel tank from corrosion Ultra-Low NOx Emissions · Complies with SCAQMD Rule 1146.2 and other Air Quality Management Districts with similar requirements of 14 ng/J or 20 ppm Easy-to-Install · Completely factory-assembled · Only gas, water and vent connections need to be made · All connections are located in front and top of heaters for ease-of-installation and service CSA Certified and ASME Rated T&P Relief Valve, Factory-Installed 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete warranty information, consult written warranty or go to statewaterheaters.com Model Number Gallon Capacity SBL75 76NE 74 SBL100 76NE 98 Natural gas only. ** Recovery based on 80% thermal efficiency. * Recovery based on 81% thermal efficiency. BTU/H Input 75,100 75,100 Recovery GPH Temperature Rise 40°F 100°F 140°F 182 73 52 184 74 53 Dimensions in Inches Height Diameter 62-1/16 25-1/4 70-1/2 27-3/4 Approx. Shipping Weight (lbs) 285 350 15 COMMERCIAL GAS SANDBLASTER® FORCE POWER DIRECT VENT Power Direct Vent Design · Combined horizontal and vertical vent runs up to 125' equivalent feet with 4" diameter venting (PVC, CPVC and polypropylene) · Two-pipe sealed combustion system uses outside air, eliminating problems caused by insufficient indoor ventilation Hot-surface Ignitor · More robust and reliable than standing pilot, and reduces energy consumption DynacleanTM Diffuser Dip Tube User-Friendly · State-of-the-art electronic gas control provides more precise temperature control · LED control light displays operation status and diagnostics information Enhanced-Flow Brass Drain Valve CSA Certified and ASME Rated T&P Relief Valve Available in Natural Gas and Propane 3-Year Limited Tank/1-Year Limited Parts Warranty · For complete information, consult written warranty or go to statewaterheaters.com Model Number SDV75 76NE Approx. Gallon Capacity 75 BTU/H Input 76,000 Certified for operation upto 10,100 Ft. without alteration. Recovery GPH Temperature Rise 40°F 100°F 140°F 185 74 52 Dimensions in Inches Height Diameter 70-5/8 26 Approx. Shipping Weight (lbs) 277 16 COMMERCIAL GAS TITAN® POWER BURNER Small Volume GPG Quality Features: · UL listed power burner · CSA Certified and ASME rated T&P relief valve · Handhole cleanout(s) for easy maintenance · Fully automatic controls ensure safe, efficient operation · Barometric draft damper ensures correct airflow in the vent · Multiple anodes for extra protection against tank corrosion · Flame inspection port opening for visual inspection of flame characteristics during operation · Factory-installed burner for easy installation · GPG85 540 and 650 comply with SCAQMD 1146.2 of 14 ng/J or 20 ppm. The 740 complies with Texas and other areas of 40 ng/J or 30 ppm. · Exclusive PermaGlas® Ultra Coat Glasslined Tank protects tank surfaces and all welds from the corrosive effects of hot water · Premix Combustion System provides super clean low-NOx flame. Helps eliminate hot spots and uneven heat transfer · Sealed Combustion Chamber reduces heat loss Options (Not Available On All Models) · 3 vent options: atmospheric, sidewall and direct vent 3-Year Limited Tank and 1-Year Limited Parts Warranty · Factory Start-Up included: required for activating warranty and assuring maximum operating performance (Continental U.S. only) · For complete information, consult written warranty or go to statewaterheaters.com Model Number GPG85 540NE(A) GPG85 650NE(A) GPG85 740NE(A) Gallon Capacity 85 85 85 BTU/H Input 540,000 650,000 740,000 Recovery GPH Temperature Rise 100°F 140°F 523 374 630 450 718 512 Not available in propane (LP). Vent Kit included in unit price when ordered with the heater. "A" in the model number indicates optional ASME construction. e.g.GPG85-740NEA Dimensions in Inches Height Diameter 93 29-1/2 93 29-1/2 93 29-1/2 Approx. Shipping Weight (lbs) 950 950 950 17 STATE COMMERCIAL OIL-FIRED WATER HEATERS COMMERCIAL OIL-FIRED TITAN® POWER OIL BURNER LOW NOx Efficient Combustion Chamber · Precast, high temperature combustion chamber made of alumina silica ceramic fiber · Engineered for maximum insulation and heat reflection · Unique design assures more complete combustion by stabilizing flame pattern Interrupted Ignition · Reduces electrical consumption Two Hand-hole Cleanouts · Allows easy cleaning on standard models GPO-385 and larger and ASME models Easy-to-Install Burner · Three-bolt mounting of burner assures easy installations. 3-Year Limited Tank and 1-Year Limited Parts Warranty · Factory Start-Up included: required for activating warranty and assuring maximum operating performance (Continental U.S. only) · For complete information, consult written warranty or go to statewaterheaters.com (Select Models) Model Number GPO86 199 OE GPO86 245 OE GPO84 315 OE(A) GPO75 385 OE(A) GPO75 455 OE(A) GPO69 700 OE(A) Gallon Capacity 86 86 84 75 75 69 Btuh Input 199,000 245,000 315,000 385,000 455,000 700,000 Recovery GPH Temperature Rise 40°F 100°F 140°F 477 191 136 587 235 168 754 302 216 922 369 263 1090 436 311 1677 671 479 *Based on No. 2 fuel oil. All models have 1/8 HP motor. Add (A) to the model number for ASME construction, e.g. GPO-700A (not available on 199-245). Dimensions in Inches Height Diameter 74-1/2 27-3/4 74-1/2 27-3/4 74-1/2 27-3/4 73-3/4 27-3/4 73-3/4 27-3/4 73-3/4 27-3/4 Approx. Shipping Weight (lbs) Standard ASME 553 N/A 554 N/A 554 657 624 742 700 747 739 822 19 STATE COMMERCIAL TANKLESS WATER HEATERS WALL MOUNT FREE STANDING INLINE COMMERCIAL TANKLESS COMMERCIAL RACK SYSTEM The State Commercial Tankless Rack System is designed to give you all of the benefits of tankless water heaters in an easy-to-install package. The racks are available in a variety of configurations with up to 1,194,000 BTU on a single rack system. They feature our 199,000 BTU high efficiency condensing tankless heater for significant energy cost savings. The systems are pre-assembled, and only require three simple connections - cold water, hot water, and gas. Multiple Design and Installation Configurations · Wall mount, free standing in-line, and free standing back-to-back designs · Indoor and outdoor rack designs Expandable · Up to 1,194,000 BTU on a single rack system · Able to link up to 20 heaters together with Multi-Link system Redundancy · Multiple combustion systems provide piece of mind · Easily isolate a unit for maintenance which extends the life of the heaters Lightweight · Anodized aluminum frame · Utilizes the industry's lightest 199,000 BTU high efficiency condensing tankless heater Easy Field Installation · Reduce installation costs with three simple connections (cold water, hot water, and gas) · 1-1/2" Schedule 40 gas manifold pipe · 2" Copper hot/cold water manifold pipes Ultra-Low NOx Emissions · Complies with SCAQMD Rule 1146.2 NOx emission requirements of 14 ng/J or 20 PPM. 1-year limited warranty on rack parts · For complete information, consult written warranty or go to statewaterheaters.com. Continued on the following page. FREE STANDING BACK-TO-BACK 21 COMMERCIAL TANKLESS COMMERCIAL RACK SYSTEM (CONTINUED) Model* Description SCI-CRS-22WM-N 2 Unit Indoor Wall Mount Natural Gas Configuration Gas Consumption Input Minimum Maximum BTU/HR BTU/HR Max GPM @ 100 F** Dimensions Length Width Height Shipping Weight (lbs.) 15,000 398,000 7.6 46 13.02 57 240 SCI-CRS-23WM-N 2 Unit Indoor Wall Mount Natural Gas 15,000 398,000 7.6 66 13.02 57 250 SCI-CRS-33WM-N 3 Unit Indoor Wall Mount Natural Gas 15,000 597,000 11.4 66 13.02 57 350 SCI-CRS-24IL-N 2 Unit Indoor Inline Natural Gas 15,000 398,000 7.6 46 30.5 53.09 265 SCI-CRS-26IL-N 2 Unit Indoor Inline Natural Gas 15,000 398,000 7.6 66 30.5 53.09 285 SCI-CRS-24B2B-N 2 Unit Indoor Back-To-Back Natural Gas 15,000 398,000 7.6 46 30.5 53.09 265 SCI-CRS-36IL-N 3 Unit Indoor Inline Natural Gas 15,000 597,000 11.4 66 30.5 53.09 387 SCI-CRS-34B2B-N 3 Unit Indoor Back-To-Back Natural Gas 15,000 597,000 11.4 46 30.5 53.09 480 SCI-CRS-36B2B-N 3 Unit Indoor Back-To-Back Natural Gas 15,000 597,000 11.4 66 30.5 53.09 510 SCI-CRS-44B2B-N 4 Unit Indoor Back-To-Back Natural Gas 15,000 796,000 15.2 46 30.5 53.09 580 SCI-CRS-46B2B-N 4 Unit Indoor Back-To-Back Natural Gas 15,000 796,000 15.2 66 30.5 53.09 620 SCI-CRS-56B2B-N 5 Unit Indoor Back-To-Back Natural Gas 15,000 995,000 19 66 30.5 53.09 741 SCI-CRS-66B2B-N 6 Unit Indoor Back-To-Back Natural Gas 15,000 1,194,000 22.8 66 30.5 53.09 800 Racks utilize CT-199 tankless models. Model Number Format: - First number (2/3/4/5/6) = number of tankless units mounted - Second number (2/3/4/6) = rack size (maximum number of units) - Letters represent the rack configuration: WM = wall mount; IL = inline floor standing; B2B = back-to-back floor standing Note: Inline models can be flush mounted against a wall by field removing back shipping leg. For outdoor applications change SCI to SCO in the model number when ordering. Example: SCO-CRS-22WM-N *For Propane, change N to P in the model number when ordering. (Example: SCI-CRS-23WM-P).**Outdoor installations require vent cap. ** Current numbers based on factory testing; 0.5 GPM required for activation; 0.4 GPM required for continuous fire after initial ignition. 22 COMMERCIAL TANKLESS TANKLESS HIGH EFFICIENCY CONDENSING OUTDOOR MODEL INDOOR MODEL ANSI Z21.10.3 CSA 4.3 ENERGY STAR® Qualified Condensing Technology Provides 96% Thermal Efficiency Ultra-Low NOx Emissions · Complies with SCAQMD Rule 1146.2 NOx Emission Requirements Of 14 ng/J or 20 PPM Link Multiple Units into a Combined System · Common Vent up to 8 indoor units · Easy-Link up to 4 units · Multi-Link up to 20 units Heat Exhanger · Primary heat exchanger is constructed of a commercial-grade copper that is more resilient to erosion · Copper is 25x better at heat transfer than stainless steel thus stabilizing outgoing water temperature quicker and reducing pressure drop across the heat exchanger · Secondary heat exchanger is made of marine-grade 316L stainless steel to protect against corrosion Maximum Continuous Flow Rates up to 10.0 GPM Indoor Models · Include integrated temperature controls and advanced diagnostics to simplify troubleshooting · Factory-Installed Power Cord Included for Indoor Models Outdoor Models · Include a wall mount temperature remote controller and advanced diagnostics to simplify troubleshooting Safety Features · Air-Fuel Ration (AFR) Sensor · Exhaust & Water Temperature Safety Control · Overheat Cut-off Fuse Internal Freeze Protection System Power Vent or Power Direct Vent Design 6-year limited heat exchanger in commercial applications; 5-year limited warranty on parts · For complete information, consult written warranty or go to statewaterheaters.com Model Number* SCT-199I-N Type Indoor Gas Consumption Input Minimum** Maximum (BTU/H) (BTU/H) 15,000 199,000 Inlet Gas Pressure*** Thermal Minimum (in. Maximum (in. Efficiency W.C.) W.C.) 4.0 10.5 96% Connections UEF Maximum GPM Water Gas Dimensions in Inches Height Width Depth 0.93 10 3/4" NPT 3/4" NPT 23-5/8 17-3/4 11 1/4 Approx Shipping Weight (lbs) 63 SCT-199O-N Outdoor 15,000 199,000 4.0 10.5 96% 0.95 10 3/4" NPT 3/4" NPT 23-5/8 17-3/4 11 1/4 63 *For Propane, change the N to P in the model number when ordering. (Example: SCT-199I-P) **For Propane, minimum input is 13,000 BTU/H ***For Propane, inlet gas pressure is 8.0-14 in. W.C. Current numbers based on factory testing; 0.5 GPM required for activation; 0.4 GPM required for continuous fire after initial ignition. 15-150 PSI water pressure. 40 PSI or above is recommended for maximum flow. Indoor models are certified from sea level to 10,100 ft. elevation. Outdoor models are certified from sea level to 6,000 ft. elevation. 23 COMMERCIAL TANKLESS TANKLESS HEAVY DUTY Commercial-Grade Copper Heat Exchanger (Non-ASME Models) ASME Models Available 5" Category III Stainless Steel Venting Vertical or Horizontal Venting Installation Power Vent Design Electronic Ignition Low NOx Emissions Combined Indoor/Outdoor Models Easy-Link up to 4 Units Multi-Link up to 10 Units 6-year limited heat exchanger in commercial applications; 5-year limited warranty on parts · For complete information, consult written warranty or go to statewaterheaters.com Model Number* Type GTS-910-N Indoor Gas Consumption Input Minimum (BTU/H) Maximum (BTU/H) 15,000 380,000 Inlet Gas Pressure*** Minimum Maximum (in. W.C.) (in. W.C.) 4.0 10.5 Thermal Efficiency (NG / LP) Maximum GPM 80% / 82% 14.5 Connections Water Gas 1" NPT 1" NPT Dimensions in Inches Height Width Depth 25-1/4 24-7/8 12-3/4 Approx Shipping Weight (lbs) 113 GTS-910-AN** Indoor 15,000 380,000 4.0 10.5 80% / 82% 14.5 1" NPT 1" NPT 25-1/4 24-7/8 12-3/4 113 *For Propane, change the N to P in the model number when ordering. (Example: GTS-910-P) **ASME model ***For Propane, inlet gas pressure is 8.0-14 in. W.C. Current numbers based on factory testing; 0.5 GPM required for activation; 0.4 GPM required for continuous fire after initial ignition. 15-150 PSI water pressure. 40 PSI or above is recommended for maximum flow. 24 STATE COMMERCIAL ELECTRIC WATER HEATERS COMMERCIAL ELECTRIC LIGHT-SERVICE Designed for light duty commercial applications with intermittent hot water loads Glasslined Tank · Tank interior is coated with glass specially designed by State for water heater use Heating Elements · Two 4.5 KW zinc plated copper sheathed elements are standard Standard Voltages · The standard voltage is 240V single phase · Optional voltage is 208V single phase Junction Box Controls · Thermostat is adjustable through a range of 120º to 181ºF with a manual reset high temperature cutoff · The heater is wired for non-simultaneous single phase operation Coregard Anode Rod · Our anode rods have a stainless steel core that extends the life of the anode rod allowing superior tank protection for longer than standard anode rods Enhanced-Flow Brass Drain Valve · Solid brass, tamper resistant, enhanced-flow, ball type, drain valve Maximum Working Pressure 150 psi Factory Installed CSA Certified and ASME Rated Temperature and Pressure Relief Valve Certified to UL 1453 for Commercial Electric Water Heaters Electric Water Heaters 6-Year Limited Tank and 1-Year Limited Parts Warranty · For complete information, consult written warranty or go to statewaterheaters.com Model Number Gallon Capacity EDT 662ORT 66 EDT 8020RT 80 EDT 1200RT 119 Not available with top mounted T&P valve option. Inlet and outlet connections: 3/4" Standard Wattage 240 VAC 4,500 4,500 4,500 Dimensions in Inches Height Diameter 60.13 22 60.5 24 61.38 28 Approx. Shipping Weight (lbs) 146 175 268 26 COMMERCIAL ELECTRIC PATRIOT LIGHT DUTY Zinc-Plated Copper Sheath Heating Elements Standard · Medium-watt density design disperses element temperature over larger surface contact area to minimize scale build-up, maximize efficiency and prolong element life · Element options from 1.5 kW to 6 kW (non-simultaneous or simultaneous operation), recoveries from 6 gph to 49 gph at 100°F rise Standard Voltages for Easy Installation · 120V, 277V single-phase, and 208V, 240V and 480V unbalanced 3-phase delta · Easily converted to single-phase at terminal block (except for 208V with 6000W elements) · Single-element heater, single-phase only (see chart for dual-element options) Factory Installed Terminal Block · Provide electrical service to heater and connect to block (not supplied on 120V and 277V models) Factory-Wired Controls · Temperature control (adjustable from 110°F to 170°F on single element; 120°F to 181°F on dual-element models) · Manual reset high temperature cutoff per element · Wired for 3-Phase, easily convert-able to single phase Glasslined Tank · Provides long-lasting protection against corrosion · Equipped with anode rod for additional protection against corrosion Maximum Hydrostatic Working Pressure: 150 PSI 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete information, consult written warranty or go to statewaterheaters.com continued on the following page 27 COMMERCIAL ELECTRIC PATRIOT LIGHT DUTY (CONTINUED) Element Wattage (Upper/Lower) /1500 /2000 /2500 3000/3000 4000/4000 4500/4500 5000/5000 6000/6000 Simultaneous Operation 3000/3000 4000/4000 4500/4500 5000/5000 6000/6000 U.S. Gallons/Hr at Temperature Rise Indicated F° 100 Non-Simultaneous GPH 6 GPH 8 GPH 10 GPH 12 GPH 16 GPH 18 GPH 20 GPH 24 GPH 24 GPH 32 GPH 36 GPH 41 GPH 49 Model Number PCE 6 10MS A PCE 10 10MS A PCE 15 10MS A PCE 20 10MS A Lowboy Models PCE 30 20LS A PCE 40 20LS A PCE 50 20LS A Tall Models PCE 30 20RT A PCE 40 20RT A PCE 52 20RT A PCE 66 20RT A PCE 80 20RT A PCE 120 20RT A Gallon Capacity 6 10 15 20 30 40 50 30 40 50 66 80 119 Dimensions in Inches Height Diameter Compact Models 15-1/2 14-1/4 18-1/4 18 26 18 22-1/4 21-3/4 30-7/8 32-1/4 32-1/4 21-3/4 24 26-1/2 34-1/2 45-1/8 54-7/8 30-3/4 59-3/8 62-7/16 20-1/2 20-1/2 20-1/2 21-3/4 24 29-3/8 6 gallon model not available above 3.0 kW 6/10/15/20 gallon model all C2 circuit (2 wire) only S= Single Element D= Dual Elements Dual element models wired for 3-phase 208/240/480 volt. Field convertible to 1-phase. Approx. Shipping Weight (lbs) 35 54 58 73 100 125 166 98 113 131 176 211 326 28 COMMERCIAL ELECTRIC SANDBLASTER® SELF CLEANING Listed ASME/CRN (optional) Incoloy Sheath Heating Elements Standard · Industrial-grade Incoloy sheathed heating elements are designed for rugged long-lasting commercial service, and can withstand sheath temperatures up to 1500°F · Input options from 6 kW to 54 kW, recoveries from 25 gph to 221 gph at 100°F rise Power Circuit Fusing for System Protection · Safeguards elements and contactors from short circuits, overloading and line surges · Meets National Electrical Code requirements that non-ASME tanks must have internal fusing when current draw exceeds 48 amps 208, 240 and 480V Options for Easy Installation · Single-phase and 3-phase delta · Field-convertible voltages 3-phase to single-phase (and vice versa) except for 208V/54 kW · 277V single-phase also available Factory-Installed Terminal Block Other Standard CSB Features · Two anode rods for maximum corrosion protection · Simplified circuitry, color coded for ease of service · Bonderized undercoated baked enamel finished cabinets · Brass Drain Valve · CSA/ASME temperature and pressure relief valve CSB Model Controls · CSB SFE models have surface mount temperature controls adjustable 120° to 181°F. · Manual reset high-temperature cutoff CSB IFE Model Features · Advanced Electronic Controls · Displays operational, diagnostic and fault information in English. · Heavy-Duty Magnetic Contactors Precise Temperature Regulation · Operating Set Point adjustable 90° to 190°F · CSB IFE models are approved for 180 degree sanitizing · Banks of heating elements (3 elements per bank) are energized according to adjustable (1° to 20°) differential set points for each bank. Helps reduce short cycling and operating costs by matching kW output to load conditions · Linear sequencing - first bank on is last bank off · Helps reduce current surge/spikes and avoid peak demand charges · Helps reduce operating costs during low load conditions · Manual reset high-temperature cutoff 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete information, consult written warranty or go to statewaterheaters.com Model Number CSB 52 6 SFE CSB 82 36 SFE CSB 120 54 SFE Gallon Capacity 50 80 119 Height 55-3/4 60-1/4 62-1/4 Dimensions in Inches Diameter 21-3/4 25-1/2 29-1/2 Approx. Shipping Weight 265 280 390 Model Number CSB 52 6 IFE CSB 82 36 IFE CSB 120 54 IFE Tank Capacity 50 80 119 Height 55-3/4 60-1/4 62-1/4 CSB is maximum 36kW See specification sheets or contact your local rep for optional kW's available Dimensions Width 21-3/4 25-1/2 29-1/2 Diameter 27 31 35 Inlet/Outlet (NPT) 1-1/4 1-1/4 1-1/4 Approx. Shipping Weight 265 280 390 29 COMMERCIAL ELECTRIC STATESMAN PREMIUM HEAVY DUTY ASME AND NSF CONSTRUCTION Incoloy Sheath Heating Elements Standard · Industrial-grade Incoloy sheathed heating elements are designed for rugged longlasting commercial service, and can withstand sheath temperatures up to 1500°F · Each heating element has three separate heating loops, which provides more heating surface, lower watt density, maximum recovery efficiency and longer life · Input options from 3 kW to 90 kW, recoveries from 12 gph to 369 gph at 100°F rise Standard Voltages for Easy Installation · Single-phase and 3-phase · All 208V and 240V at 24 kW and below are supplied as phase-convertible units (single- to 3-phase and vice versa) · 277V single-phase also available (Contact State for 120V circuit availability) · International voltages also available (check with factory) Factory-Installed Terminal Block (Units with More than One Contactor) Advanced Electronic Controls · Plain English text and animated icons · Displays detailed operational and diagnostic information · Fault or alert messages appear if an operational issue occurs · Last 9 fault and alert messages saved with time stamp Progressive Sequencing · First heating element on is first heating element off · First heating element energized is rotated with each successive heating cycle on models with multiple heating elements · Evens out wear between heating elements Economy Operation Mode · Control system automatically lowers the operating set point by a programmed value during user-defined time periods · Helps reduce operating costs during unoccupied or low demand periods Precise Temperature Regulation · Operating Set Point adjustable 90° to 190°F · Approved for 180 degree sanitizing · Sequencing - Units with multiple element contactors are sequenced on with one second delay between stages. Adjustable modulating mode is optional · Helps reduce current surge/spikes and avoid peak demand charges · Manual reset high temperature cutoff continued on the following page 30 COMMERCIAL ELECTRIC STATESMAN PREMIUM HEAVY DUTY ASME AND NSF CONSTRUCTION (CONTINUED) Heavy-Duty Magnetic Contactors Power Curcuit Fusing for System Protection (120 AMP CURRENT DRAW AND ABOVE) Glasslined Tank, with ASME Construction CSA Certified and ASME Rated T&P Relief Valve Compliance Brass Drain Valve 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete information, consult written warranty or go to statewaterheaters.com Model Number SSE-5 SSE-10 SSE-20 SSE-30 SSE-40 SSE-50 SSE-65 SSE-80 SSE-100 SSE-120 Gallon Capacity 5 10 20 30 40 50 65 80 100 120 Maximum kW Input 3 6 18 24 36 90 90 90 90 90 Dimensions in Inches Height Diameter 22 28-1/4 31-3/4 43 1/4 54 3/4 66-1/2 57-1/4 58-1/4 70-1/4 70-1/4 16 18 22 22 22 22 26-1/2 28 28 31-1/8 Approx. Shipping Weight (lbs) 82 116 145 218 190 221 267 285 354 420 31 COMMERCIAL ELECTRIC LARGE VOLUME ELECTRIC ASME SEV/SEH MODELS SEV/SEH are the largest commercial electric units we manufacture. Ideal for use as recovery heaters for all types of large commercial and industrial applications, or for large process potable hot water requirements. They are customizable to meet any special application with the large selection of available options. Advanced Electronic Control Propriety electronic water heater control provides precise + or - 1ºF temperature control, ideal for industrial and food service applications where exact temperatures of hot water are needed. · Plain Text Animated icons display detailed operational and diagnostic information. Fault or Alert messages appear if an operational issue occurs · Low Water Cut Off Factory standard on board low water cut-off uses a remote electronic immersion type probe to prevent energizing of the elements in the event of low water condition and eliminates accidental dry firing · Progressive Modulating Sizes the input of available elements to match current load conditions. Rotates and lead lags element loads to provide long life and equal wear. · Economy Mode Operation Control system automatically lowers the operating set point by a programmed value during user defined time periods. Seven-day clock may be programmed for night set back and or weekend shutdown to reduce operating cost and save money. Glasslined Tank · Tank interior is coated with glass specially developed for use in water heaters. Tanks rated at 125 psi working pressure; 150 psi or 160 psi working pressure is optional. Vermin-proof fiberglass insulation reduces costly heat loss. Constructed to Section IV of ASME code, and UL standards. Tanks have channel skid base. A 4" x 6" handhole is furnished on 500, 600 and 700-gallon models; 12" x 16" manhole is furnished on 800-gallon and larger sizes. Incoloy Immersion Heaters · Heavy-duty elements (three per immersion heater) have Incoloy sheathing: provide excellent protection against oxidation and scaling · The input ranges from 15kW to 900kW Fusing · Control and power circuit fusing to meet N.E.C. Magnetic Contactor(s) · Heavy duty UL rated for 100,000 cycles Other Standard Features · Color-coded circuitry for easier servicing · Anode rods for maximum corrosion protection · Standard voltages include 208, 240, 480, 600 volt single or three-phase · Factory-installed terminal block(s) · Temperature and pressure relief valve continued on the following page 32 COMMERCIAL ELECTRIC LARGE VOLUME ELECTRIC ASME SEV/SEH MODELS (CONTINUED) Optional Dual-Energy Source Capability · Provides emergency backup energy source for winter/summer boiler operation · Can be specified with optional water to water or steam to water heat exchangers · Both single and double wall heat exchangers are available · Complete control packages can be factory-installed for hook up and run capability BMS COMPATIBLE · Modbus/BACnet compatible with optional · Gateway interface · Call 888 WATER02 for more information ASME CODE CONSTRUCTION · All models are constructed to the requirements of ASME and are available in 125, 150 and 160 psi working pressures (125 psi working pressure - standard) · Consult factory for ASME code tanks with greater or lesser working pressures and special configurations or materials 3-Year Limited Tank and 1-Year Limited Parts Warranty · For complete information, consult written warranty or go to statewaterheaters.com 33 COMMERCIAL ELECTRIC LARGE VOLUME ELECTRIC ASME SEV/SEH (CONTINUED) Model Number SEV-150A SEV-200A SEV-250A SEV-300A SEV-400A SEV-500A SEV-600A SEV-800A SEV-1000A SEV-1250A SEV-1500A SEV-2000A SEV-2500A Vertical Electric Storage Heater Gallon Capacity Dimensions in Inches Height Width Depth Vertical Round Electric Storage Heater 150 65-1/2" 32" 38-3/4" 200 78" 32" 38-3/4" 250 92" 34" 40-3/4" 300 80" 40" 46-3/4" 400 80" 46" 52-3/4" 500 92" 46" 52-3/4" 600 92" 52" 60-3/4" 750 104" 52" 60-3/4" 950 128" 52" 60-3/4" Vertical Square Electric Storage Heater 1,250 132-1/2" 64-1/2" 64-1/2" 1,500 128-1/2" 70-1/2" 70-1/2" 2,000 124-1/2" 78-1/2" 78-1/2" 2,500 146-1/2" 82-1/2" 82-1/2" Horizontal Electric Storage Heater Model Number Gallon Capacity Dimensions in Inches Height Width Depth Horizontal Square Electric Storage Heater SEH-150A 150 37" 68-1/2" 34-1/4" SEH-200A 200 37" 78" 34-1/4" SEH-250A 250 39" 90-1/4" 36-1/4" SEH-300A 300 45" 78-1/4" 42-1/4" SEH-400A 400 52" 78-1/4" 48-1/4" SEH-500A 500 52" 90-3/4" 48-1/4" SEH-600A 600 58" 90-3/4" 54-1/4" SEH-800A 750 58" 102-1/4" 54-1/4" SEH-1000A 950 58" 126-1/4" 54-1/4" SEH-1250A 1,250 64" 130-1/4" 60-1/4" SEH-1500A 1,500 70" 126-1/4" 66-1/4" SEH-2000A 2,000 82" 123-1/4" 78-1/4" SEH-2500A 2,500 82" 144-1/4" 78-1/4" Minimum installation clearances- refer to Installation Manual. For units higher than 72kW, additional height will be added to the dimensions. Please consult the factory for those orders. kW Input GPH 100°F Rise Btu/hr Equivalent No of Elements/ kW Per 15 62 51,180 1-15kW 18 74 61,416 1-18kW 30 123 102,360 1-15kW 36 148 122,832 1-18kW 45 185 153,540 1-15kW 54 221 184,248 1-18kW 60 246 204,720 2-15kW 72 295 245,664 2-18kW 90 369 307,080 2-18kW 108 443 368,496 2-18kW 120 492 409,440 3-15kW 135 554 460,620 3-15kW 144 590 491,328 3-18kW 162 664 552,744 3-18kW 180 738 614,160 4-18kW 216 886 736,992 4-18kW 234 959 798,408 5-18kW 252 1,033 859,824 5-18kW 270 1,107 921,240 5-18kW 288 1,181 982,656 6-18kW 306 1,255 1,044,072 6-18kW 324 1,328 1,105,488 6-18kW 342 1,402 1,166,904 7-18kW 360 1,476 1,228,320 7-18kW 378 1,550 1,289,736 7-18kW 396 1,624 1,351,152 8-18kW 414 1,697 1,412,568 8-18kW 432 1,771 1,473,984 8-18kW *Complete model number includes the desired kW at the end, e.g. SEV-300-150. Minimum installation clearances required. 34 STATE COMMERCIAL STORAGE TANKS 35 COMMERCIAL HEAT PUMP CHP FULLY INTEGRATED HEAT PUMP ENERGY SAVING & ENVIRONMENTALLY FRIENDLY · Heat pump transfers heat from surrounding area into the tank · Industry leading 4.2 COP · Multiple operating modes maximize efficiency while meeting specific hot water needs · Integrated, large capacity tank enables heat pump to operate more frequently than electric elements, saving money · Meets standby loss requirements of U.S. Department of Energy and current edition of ASHRAE 118.1 COMMERCIAL PERFORMANCE · First hour delivery of 150 GPH · Electric heating element capacity of 12 kW (240Vac) · Max. water temperature of 150° F. in Efficiency/Hybrid modes and 180° F. in Electric mode · Ambient room temperature operating range of 20° to 110° F. · Dual evaporator fans maximize performance and provide room cooling · Low operating sound measured at 59 dB (A) EASE OF OPERATION · Integrated design and pre-charged refrigeration system facilitates fast, easy installation · Large touch screen LCD display allows for mode selection, provides run information and includes troubleshooting alerts and detail · Three operating modes: Efficiency, Hybrid or Electric DEPENDABLE & LONG LASTING DESIGN · State-developed glass coated tank · Tank rated at 160 PSI working pressure · Commercial grade anode protects the tank and extends service life · Electric elements have incoloy sheathing and provide excellent protection from oxidation and scaling 3-YEAR LIMITED TANK AND 1-YEAR LIMITED PARTS/COMPRESSOR WARRANTY · For complete warranty information, consult written warranty or go to statewaterheaters. com Model Number Gallon Capacity COP CSHP 120 119 4.2 Model Number CSHP 120 A 69-11/16 B 28-1/32 Number of Elements Total Element Wattage (both elements @ 240V) 2 12,000 First Hour Delivery in Hybrid Mode (GPH) 150 Recovery in GPH at 100° Temperature Rise Efficency = 41 Hybrid = 90 Electric = 50 Approx. Shipping Weight (lbs) 620 C 39-11/64 Dimensions D E 23-5/8 58-7/64 F 57-51/64 G 6-1/32 H 30-29/32 36 STATE COMMERCIAL STORAGE TANKS 37 COMMERCIAL STORAGE TANKS FACTORY JACKETED & INSULATED STORAGE TANKS Glasslined per ASME, HLW Procedures Horizontal or Vertical Available ASME Construction Anodic Protection Meets R12.5 Minimum Thermal Insulation Requirements of the U.S. Department of Energy and Current Edition of ASHRAE/IES 90.1 5-Year Limited Tank Warranty · For complete information, consult written warranty or go to statewaterheaters.com OPTIONAL Model Number PVG-500-00VSA125 PVG-500-00VTA125 PVG-600-00VTA125 PVG-700-00VTA125 PVG-750-00VTA125 PVG-1000-00VTA125 PVG-1200-00VTA125 PVG-1500-00VTA125 PVG-1750-00VTA125 PVG-2000-00VTA125 PVG-2500-00VTA125 38 Vertical Round Jacketed ASME Height Diameter 91 46 77 52 88 52 97 52 100 52 124 52 Vertical Square Jacketed ASME 133 60 129 66 153 66 126 78 146.5 78 Gallons 500 500 600 700 750 1000 1,250 1,500 1,750 2,000 2,500 Model Number PVG-0250-00HTA125 PVG-0300-00HTA125 PVG-0400-00HTA125 PVG-0500-00HSA125 PVG-0500-00HTA125 PVG-0600-00HTA125 PVG-0700-00HTA125 PVG-0750-00HTA125 PVG-1000-00HTA125 Model Number PVG 1250 00HTA125 PVG 1500 00HTA125 PVG 2000 00HTA PVG 2500 00HTA COMMERCIAL STORAGE TANKS FACTORY JACKETED & INSULATED STORAGE TANKS (CONTINUED) Height 41 47 53 53 59 59 59 59 59 Horizontal Round Jacketed ASME Tanks Length 87 76 76 87 77 88 97 100 124 Diameter 34 40 46 46 52 52 52 52 52 Gallons 250 300 400 500 500 600 700 750 1000 Height 68.5 74.5 86.5 86.5 Horizontal Square Jacketed ASME Tanks Length 134 127 127 144 Depth 60.25 66.25 78.25 78.25 Gallons 1,250 1,500 2,000 2,500 39 COMMERCIAL STORAGE TANKS STANDARD JACKETED AND INSULATED STORAGE TANKS Glasslined per ASME, HLW Procedures Foam Insulation Heavy Gauge Steel Jacket With Baked Enamel Finish Fits through a 33" door ASME Construction on select models Anodic Protection All Tanks Have 2" Threaded Openings Meets R12.5 Minimum Thermal Insulation Requirements of the U.S. Department of Energy and Current Edition of ASHRAE/IES 90.1 5-Year Limited Tank Warranty · For complete warranty information, consult written warranty or go to statewaterheaters. com. Model Number Gallon Capacity PVG 0080 00VT 80 PVG 0120 00VT 119 PVG 0080 00VTA125 80 PVG 0120 00VTA125 119 PVG 0200 00VSA125 175 A denotes ASME construction. Example PVG 200 00VSA125 Dimensions in Inches Overall Length Diameter 63 25-1/4 62 29-3/8 54-7/8 26-1/2 61-3/4 28 77 32 Approx. Shipping Weight (lbs) 236 320 369 411 560 40 Model Number UVG-0500-00VSA125 UVG-0500-00VTA125 UVG-0600-00VTA125 UVG-0700-00VTA125 UVG-0750-00VTA125 UVG-1000-00VTA125 UVG-1250-00VTA125 UVG-1500-00VTA125 UVG-1750-00VTA125 UVG-2000-00VTA125 Model Number UVG-0500-00HSA125 UVG-0500-00HTA125 UVG-0600-00HTA125 UVG-0700-00HTA125 UVG-0750-00HTA125 UVG-1000-00HTA125 COMMERCIAL STORAGE TANKS UNINSULATED STANDARD BARE STORAGE TANKS Glasslined per ASME, HLW Procedures Horizontal or Vertical ASME Construction Anodic Protection 5-Year Limited Tank Warranty · For complete warranty information, consult written warranty or go to statewaterheaters.com. Gallons 500 500 600 700 750 1000 1250 1500 1750 2000 Gallons 500 500 600 700 750 1000 OPTIONAL Model Number UVG-0080-00VT UVG-0120-00VT UVG-0200-00VT UVG-0350-00VT UVG-0140-00VTA125 UVG-0200-00VTA125 UVG-0250-00VTA125 UVG-0350-00VTA125 UVG-0400-00VTA125 Gallons 80 119 200 350 140 200 250 350 400 Overall Dimentions Inches 20 x 62-1/8 24-1/4 x 65 30 x 72 36 x 88 24 x 76-1/4 30 x 72 30 x 84 36 x 88 36 x 97 Diameter 20 24-1/4 30 36 24 30 30 36 36 Height 61-1/2 64-3/8 70-3/4 86 75 70-3/4 84 86 96 Weight (LBS) Glass 160 psi 170 287 460 670 400 460 505 670 775 Diameter 42 48 48 48 48 48 54 60 60 72 Height 87 77 88 97 100 124 128 124 148 121 Weight (LBS) Glass 125 psi 763 1062 1193 1301 1337 1623 2100 2709 3156 3397 Diameter 42 48 48 48 48 48 Length 83 73 84 93 96 120 Weight (LBS) - Glass 125 psi 763 1062 1193 1301 1337 1623 41 COMMERCIAL STORAGE TANKS HEAVY-DUTY LARGE VOLUME STORAGE TANKS Glasslined per ASME, HLW Procedures Horizontal or Vertical Options Available Insulated Jackets or Bare Steel Tanks Cement or Epoxy Linings Available ASME Construction Anodic Protection 5-Year Limited Tank Warranty · For complete warranty information, consult written warranty or go to statewaterheaters. com. Continued on the following page. OPTIONAL Model Number Gallons UGV24-0120-*A125 118 UGV24-0140-*A125 141 UGV24-0200-*A125 188 UGV24-0250-*A125 235 UGV28-0175-*A125 175 UGV28-0200-*A125 200 UGV30-0150-*A125 147 UGV30-0185-*A125 184 UGV30-0220-*A125 220 UGV30-0250-*A125 257 UGV30-0300-*A125 294 UGV30-0375-*A125 367 UGV36-0275-*A125 265 UGV36-0325-*A125 318 UGV36-0400-*A125 370 UGV36-0425-*A125 423 UGV36-0500-*A125 528 All tanks built in Lebanon, TN H horizontal V vertical * for H or V 42 Diameter 24" 24" 24" 24" 28" 28" 30" 30" 30" 30" 30" 30" 36" 36" 36" 36" 36" Dimensions Vertical Height 64" 76" 100" 124" 65" 76" 52" 64" 76" 87" 100" 124" 64" 76" 87" 100" 124" Horizontal Length 60" 72" 96" 120" 48" 60" 72" 83" 96" 120" 60" 72" 83" 96" 120" 125 psi 368 428 556 684 353 488 400 468 548 628 701 868 577 673 770 866 1,058 Shipping Weight (lbs.) 150 psi 368 428 556 684 353 488 400 468 548 628 701 868 577 673 770 866 1,058 Cement Lined 695 812 958 1,103 1,242 1,540 995 1,173 1,343 1,513 1,861 Model Number Gallons UGV42-0450-*A125 UGV42-0500-*A125 UGV42-0600-*A125 UGV42-0750-*A125 UGV42-0900-*A125 UGV42-1000-*A125 UGV48-0700-*A125 UGV48-0750-*A125 UGV48-0950-*A125 UGV48-1150-*A125 UGV48-1300-*A125 UGV54-1000-*A125 UGV54-1200-*A125 UGV54-1450-*A125 UGV54-1700-*A125 UGV54-1900-*A125 UGV54-2150-*A125 UGV60-1500-*A125 UGV60-1750-*A125 UGV60-2000-*A125 UGV60-2400-*A125 UGV60-2650-*A125 UGV72-2100-*A125 UGV72-2500-*A125 UGV72-3000-*A125 UGV72-3400-*A125 UGV72-4000-*A125 432 504 576 720 864 1,008 658 752 940 1,128 1,315 951 1,189 1,427 1,665 1,903 2,141 2,056 2,350 2,056 2,350 2,644 2,115 2,538 2,961 3,384 3,807 H horizontal V vertical * For H or V J for Jacketed and Insulated C for Cement and E for Epoxy COMMERCIAL STORAGE TANKS HEAVY-DUTY LARGE VOLUME STORAGE TANKS (CONTINUED) Diameter 42" 42" 42" 42" 42" 42" 48" 48" 48" 48" 48" 54" 54" 54" 54" 54" 54" 60" 60" 60" 60" 60" 72" 72" 72" 72" 72" Dimensions Vertical Height 76" 88" 100" 124" 148" 172" 88" 100" 124" 148" 172" 100" 124" 148" 172" 196" 220" 172" 196" 172" 196" 220" 124" 148" 172" 196" 220" Horizontal Length 72" 84" 96" 120" 144" 168" 84" 96" 120" 144" 168" 96" 120" 144" 168" 192" 216" 168" 192" 168" 192" 216" 120" 144" 168" 192" 216" 125 psi 795 908 1,020 1,245 1,470 1,695 1,346 1,507 1,828 2,150 2,471 1,721 2,083 2,451 2,807 3,168 3,530 3,749 4,231 3,749 4,231 4,713 3,416 3,995 4,575 5,154 5,733 Shipping Weight (lbs.) 150 psi 909 1,050 1,190 1,470 1,751 2,031 1,346 1,507 1,828 2,150 2,471 1,972 2,423 2,881 3,326 3,777 4,228 4,425 5,026 4,425 5,026 5,628 3,904 4,627 5,350 6,073 6,795 Cement Lined 1,385 1,587 1,790 2,195 2,601 3,006 2,124 2,392 2,918 3,444 3,970 2,729 3,320 3,919 4,511 5,102 5,701 5,658 6,394 5,658 6,394 7,130 5,104 5,995 6,885 7,767 8,658 43 State Water Heaters | 500 Tennessee Waltz Parkway | Ashland City, TN 37015 | 800.527.1953 | statewaterheaters.com. SCBCA00507 | ©October 2019 State Industries, LLC | Printed in U.S.A.Adobe PDF Library 15.0 Adobe InDesign 14.0 (Windows)
