6 Parts & Assembly UNIVERSAL POWER FEED (04221000) Universal Unit fits Model 100 - 300 - 1065 machines Item Part Number Description Qty. 1 00113600 Screw, hex head cap ¼-20 x 5⁄8 2
The following instructions are for manual machines. Skip steps 1 through 4 when replacing older power feed units. 1. Remove set collar on distributor arm ...
6 Parts & Assembly UNIVERSAL POWER FEED (04221000) Universal Unit fits Model 100 - 300 - 1065 machines Item Part Number Description Qty. 1 00113600 Screw, hex head cap ¼-20 x 5⁄8 2
PRODUCT MANUAL Power Cable Feed Spartan Tool LLC | 1618 Terminal Road | Niles, MI 49120 order by phone 800.435.3866 order online SpartanTool.com © 2020 Spartan Tool LLC Part #04421100 (Rev. G) 2020-011 Contents WARNINGS & INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 CABLE SAFETY GUIDE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Attaching the Cable Safety Guide to the Power Cable Feed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 SETTING CABLE SIZE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Setting Your Spartan Power Cable Feed Cable Size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Setting Cable Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 PARTS & ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Universal Power Feed (04221000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Power Feed Assembly (04217500). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Bearing Block Assembly, Long (04224000). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Bearing Block Assembly, Short (44219900). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Wheel Carrier Body Comp, Long (44119600). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Wheel Carrier Body Comp, Short (44119700). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 INSTALLATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Installation Instructions for Model 1065 & 2001. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Installation Instructions for Model 300. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Installation Instructions for Model 100. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 CLEANING OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 DISASSEMBLY & REASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Disassembly of Short Bearing Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Disassembly of Long Bearing Blocks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Disassembly of Short Bearing Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Re-Assembly of Short Bearing Blocks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Re-Assembly of Long Bearing Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 WARRANTY INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 2 Warnings & Introduction · Read the safety and operating instructions before using any Spartan Tool products. Drain and sewer cleaning can be dangerous if proper procedures are not followed and appropriate safety gear is not utilized. · Before starting unit, be sure to wear personal protective equipment such as safety goggles or face shield and protective clothing such as gloves, coveralls or raincoat, rubber boots with metatarsal guards, and hearing protection. · Drains and sewer can carry bacteria and other infectious micro-organisms or materials which can cause death or severe illness. Avoid exposing eyes, nose, mouth, ears, hands, and cuts and abrasions to waste water or other potentially infectious materials, wash hands, arms and other areas of the body, as needed, with hot, soapy water and, if necessary, flush mucous membranes with water. Also, disinfect potentially contaminated equipment by washing such surfaces with a hot soapy wash using a strong detergent. · For any questions, contact the company at the address shown below. CONTACT US Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 800.435.3866 SpartanTool.com CALIFORNIA PROP. 65 This product may contain an extremely small amount of lead in the coating. Lead is a material known to the State of California to cause cancer or reproductive toxicity. INTRODUCTION The Spartan Tool Power Cable Feed with "dial-a-cable" reflects the latest improvement in the marketplace. The operation, repair, and maintenance of the Power Feed are simple to accomplish. These features allow a quick change for cable size and provide easy maintenance. The Power Feed, which weighs just over 10 pounds, will feed and retrieve up to 30 feet per minute. A universal mounting plate allows adaptation to current Spartan Model 1065s, 300s, and 100s. (The Model 2001 does not need a mounting plate.) The power cable feed can be used on cable size from 5/16" to ¾". Spartan Tool, LLC strongly recommends the use of a Spartan Cable Safety Guide (44225300) with the Power Cable Feed unit (see Fig. 1). The Cable Safety Guide attaches to the front of the Power Feed unit, and is intended to help protect the operator from possible cable buckling and other hazards associated with handling rotating cable. Contact Spartan Tool, LLC at (800) 435-3866 or www.SpartanTool.com with questions regarding the Cable Safety Guide. 3 Cable Safety Guide ATTACHING THE CABLE SAFETY GUIDE TO THE POWER CABLE FEED Disconnect the cable machine from its power source to avoid accidental starting. Pick up the Cable Safety Guide and place the spring against the hub on the Power Cable Feed and turn it counterclockwise until the spring rests against the plate behind the hub. Reconnect the power by plugging in the machine. Ensure the electrical switch on the machine is in the forward position. Ensure the adjusting knob on the feed has been tightened until it makes contact with the cable. Place the lever (actuator assembly) midway between the "N" (neutral) and "F" (Forward) position to allow the cable to enter the Cable Safety Guide slowly. Depress the foot pedal to engage the machine and allow the end of the cable the exit the Cable Safety Guide. Release the footpedal. Disconnect the machine from its power source, and attach the selected tool to the cable. Move the machine as close to the entry point of the pipe as possible. The end of the Cable Safety Guide and attachment should be within inches of the pipe. Reconnect the power. WARNING: Unexpected machine start up can cause death or severe injury. Disconnect the machine from its power source before installing, servicing or removing the Power Cable Feed, Cable Safety Guide, cable tools and cutters, or other machine components. REV ECO DATE DESCRIPTION APPROVED FIG 1 UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES .XX = ± .01 .XXX = ± .005 FRACTIONS = ± 1/64 ANGLES = ± 1° WARNING: THIS DRAWING IS GENERATED FROM 3D BODY DATA AND ANY GEOMETRY CHANGES SHOULD BE CARRIED OUT IN 3D ONLY. TITLE SPARTAN TOOL NILES, MI 49120 CRITICAL DIMENSION THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION AND SUCH INFORMATION MAY NOT BE POWER FEED, 300 READY THIRD ANGLE PROJECTION DISCLOSED TO OTHERS FOR ANY PURPOSE NOR USED FOR MANUFACTURING PURPOSES WITHOUT WRITTEN PERMISSION FROM SPARTAN TOOL L.L.C. DATE DRAWN BY 7/27/2020 KTD ECO - SHEET NUMBER 1 of 1 SIZE B SCALE 1/4 DRA0WI4NG2N2U1M0BE0R0-WITH REV CABLE GUIDE 4 Setting Cable Size SETTING YOUR SPARTAN POWER CABLE FEED CABLE SIZE FIG 2 SETTING CABLE SIZE 1. To adjust for cable size, push in on the Power Feed Select Knob located on the bottom of the bearing blocks to unlock from setting. 2. Turn knob clockwise and pull out. As each cable setting is reached the knob can be felt locking in. The body assembly will move in for smaller cable diameters and out for larger cable diameters. 3. Rotating the Dial-A-Cable through the various settings and matching the dial label will make it easy to adjust cable size by feel. 4. Follow the chart (Fig. 3) to set your Dial-A-Cable for the cable size you have selected. Make sure both right and left block settings are the same. Cable diameter (inches) Set Power Cable Feed 516" 516 38" or 1332" 1332 ½" or .55" .55 58" or .66" .66 ¾" ¾ FIG 3 5 Parts & Assembly UNIVERSAL POWER FEED (04221000) Universal Unit fits Model 100 - 300 - 1065 machines 1 3 2 REV ECO DATE 5 Item 1 2 3 4 5 4 Part Number 00113600 00162400 00167000 03409000 04217599 (11.39) De21scrip22tio00n00116123460000 SCREW, HX HD WASHER, FLAT CAP 3/16 1/4-20 USS QX t5y/8. Sc3rew, h2ex0h01e6a7d00c0ap ¼-20INxT5E/R8 NAL TOOTH LOCKWASH2ER 4 1 03409000 BUSHING LOCK W5asher1, fla0t432/1167U50S0S SPARTAN POWER CABLE FEED2 - 2001- IInTtEeMrnQalTTYooPtAhRTLoNcUkMwBaEsRher DESCRIPTION 2 Bushing Lock 1 Spartan Power Cable Feed 1 UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES GE A .XX = ± .01 .XXX = ± .005 FRACTIONS = ± 1/64 ANGLES = ± 1° CRITICAL DIMENSION PR SU DI THIRD ANGLE PROJECTION W 6 Parts & Assembly REV DATE ECO J 3/6/2014 8099 K 8/21/2014 8099 L 7/9/2019 8485 DESCRIPTION APPROVED POWER FEED ASSEMBLY (04217500) REDRAWN FROM 2-18-83 ORIGINAL; REPLACE 44249900 WITH 04218701 RW ITEM 9 WAS: 04218701; NOW: 04218700 RW ITEM 13: 44220110, WAS 44220100 31 11 13 41 5 10 6 2 Item 14 13 12 11 10 9 8 7 6 5 4 3 2 1 7 13 14 8 12 7 Part Number 44223900 44220110 44219900 04224000 04220000 04218700 04218600 04218300 04134900 02856900 00480300 00169500 00167100 00162600 Description 2001 Actuator Assembly Decal, Dial-A-Cable Detent Assy, Bearing Block Bearing Block Assy Long Decal Brg Plate Mod 75 Feed Mounting Plate Plate Brg Mod 75 Feed Plate Stationary 75 Feed Nut, Acorn Cap 5/16-18 Knob, 3/8-16 Black #35K Screw, hex hd cap 5/16-18 x 3¼ Screw, hex hd cap 5/16-18 x 3½ Internal Tooth Lockwasher Washer, flat 5/16 USS 9 8 UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES .XX = .03 .XXX = .005 FRACTIONS = 1/64 Qty. ANGLES = 1~ THIRD ANGLE PROJECTION 1 2 2 14 1 44223900 2001 ACTUAT 13 2 44220110 DECAL, DIAL 12 2 44219900 ASSY, BEARIN 11 1 04224000 BEARING BLO 10 1 04220000 DECAL BRG P 9 1 04218700 MOUNTING PL 8 2 04218600 PLATE BRG M 7 2 04218300 PLATE STATIO 6 6 04134900 NUT ACORN C 5 1 02856900 KNOB, 3/8-16 4 4 00480300 SCREW, HEX H 3 2 00169500 SCREW, HEX H 2 6 00167100 INTERNAL TO 1 6 00162600 WASHER, FLA ITEM QTY PART NUMBER WARNING: THIS DRAWING IS GENERATED FROM 3D BODY DATA AND ANY GEOMETRY CHANGES SHOULD BE CARRIED OUT IN 3D ONLY. TITLE SP THIS DOCUMENT CONTANINS PROPRIETARY INFORMATION AND SUCH INFORMATION MAY NOT BE DISCLOSED TO OTHERS FOR ANY PURPOSE NOR USED FOR MANUFACTURING PURPOSES WITHOUT WRITTEN PERMISSION FROM SPARTAN TOOL L.L.C. POWE DATE DRAW 3/6/14 SIZE B SCALE 1=4 1 1 1 2 2 6 1 4 2 6 6 7 Parts & Accessories 4 3 04224000 BEARING BLOCK ASSY LONG REV C BEARING BLOCK ASSEMBLY, LONG (04224000)D 2 ECO 8335 8375 2 10 B 3 11 DATE 4/13/17 R 10/19/17 A 8 8 5 4 7 9 Item 1 Part Number 00113700 Description Screw, hex hd ¼-20 x ¾ 1 6 1 4 00113700 2 1 01921801 3 1 03312001 4 1 03415700 5 1 04217900 6 1 04219000 7 1 04220100 8 1 04220610 9 1 44119600 10 1 44221900 11 1 44230100 ITEM QTY PART NUMBE UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES .XX = .01 .XXX = .005 FRACTIONS = 1/64 ANGLES = 1 THIRD ANGLE PROJECTION Qty. 4 WARNING: THIS DRAWING IS GENERATED FROM 3D BODY DA AND ANY GEOMETRY CHANGE SHOULD BE CARRIED OUT IN 3D ONLY. THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION AN SUCH INFORMATION MAY NOT B DISCLOSED TO OTHERS FOR AN PURPOSE NOR USED FOR MANUFACTURING PURPOSES WITHOUT WRITTEN PERMISSIO FROM SPARTAN TOOL L.L.C. 4 2 01921801 Screw, ma3rch rd hd sl 8-32 x ½ 1 2 3 03312001 Nut kep #8-32 zinc plates 1 4 03415700 Bushing & Ball Assembly 1 5 04217900 Block Bearing Long Mod 75 Feed 1 6 04219000 Cap End Weld Assembly 75 1 7 04220100 Spring hvy duty Mod 75 Feed 1 8 04220610 Top Knob, Power Feed 1 9 44119600 Wheel Carrier Body Comp (long) 1 10 44221900 2001 Cover Spring 1 11 44230100 2001 Spring Feed Ext 1 Parts & Accessories BEARING BLOCK ASSEMBLY, SHORT (44219900) FIG 7 Item Part Number Description Qty. 29 04217800 Block Bearing, short Model 75 feed 1 31 00113901 Screw, hex hd ¼-20 x 1 4 33 04219600 Thrust Race 2 34 04219500 Thrust Bearing 1 35 44222100 2001 Knob 1 36 44213800 Dial-A-Cable Block 1 37 44222200 Roll Pin 2001 1 Fig. 8 44119700 Wheel Carrier Body Comp (short) 1 9 Parts & Accessories WHEEL CARRIER BODY COMP, LONG (44119600) FIG 6 Item Part Number Description Qty. 24 04217700 Pin Drive, Model 75 feed 1 26 04219700 Bearing Drive, Model 75 feed 1 27 04219800 Washer, 75 Feed stainless 2 28 04219900 Ring Retaining, external 1 30 44250200 O-Ring Seal, wheel carrier 1 32 04218400 Body Wheel Carrier w/hole long (incl. Item 30) 1 WHEEL CARRIER BODY COMP, SHORT (44119700) FIG 8 10 Item Part Number Description Qty. 21 04218500 Body Wheel Carrier w/holy long (incl. Item 30) 1 26 04217700 Pin Drive, Model 75 feed 1 27 04219700 Bearing Drive, Model 75 feed 1 28 04219800 Washer, 75 feed stainless 2 29 04219900 Ring Retaining, external 1 30 44250200 O-Ring Seal, wheel carrier 1 Installation Instructions INSTALLATION INSTRUCTIONS FOR MODEL 1065 & 2001 (See Fig. 4 & Fig. 5) The following instructions are for manual machines. Skip steps 1 through 4 when replacing older power feed units. 1. Remove set collar on distributor arm and remove bearing assembly by removing screw in bottom. 2. Install new thrust bearing (inner race facing forward) on distributor arm. 3. Install new bearing assembly on distributor arm with swing bolts forward. Replace bottom screw and lockwasher, push bearing assembly back against thrust bearing and tighten lower screw. 4. Replace set collar and tighten. ATTENTION: Model 1065 users only: Replace upper front casting assembly with 03414700. 5. Set Dial-A-Cable adjusters for ¾" cable size (full open) and turn knob counterclockwise (left) to raise upper wheel carrier. Place actuator handle to "N" neutral position. 6. Place cable through back of power feed while sliding power feed unit over cable into proper position on new bearing assembly. Bring swing bolts up into slots on universal mounting plate and tighten hand tight. 7. Position cable forward to the point where the smallest diameter of cable will come in contact with the drive bearings, adjust your Dial-A-Cable for your cable size. Turn knob clockwise (right) until contact is made with drive bearing. 8. Apply grease through grease fitting on bearing assembly. Installation is complete. Refer to operating instructions for safe operation. SPECIAL NOTE: 2001 Dial-A-Cable Power Feed Replacement: When Replacing Dial-A-Cable power feed unit on 2001 machines, the two (2) long screws #15 must be used for old unit. 11 Installation Instructions INSTALLATION INSTRUCTIONS FOR MODEL 300 (See Fig. 4, Fig. 5, and Fig. 14) FIG 9 The following instructions are for manual machines. Skip steps 1 through 3 when replacing older power feed units. 1. Remove upper front casting assembly. 2. Install new upper front casting assembly (04202700). 3. Install bushing lock (#11) to mounting plate (#16) on drive unit. Use items #39, 40, and 41. Position as per Fig. 5. Place screws in bushing lock finger tight only. 4. Set Dial-A-Cable adjusters for ¾" cable size (full open) and turn knob (#18) counterclockwise (left) to raise upper wheel carrier. Place actuator handle (#12) to "N" neutral position. 5. Place cable through back of power feed while sliding power feed unit over cable into proper position on upper front casting assembly. Make certain lip of bushing lock engages slot in distributor arm bushing (Fig. 9). Swing up clamps on upper front casting into slots provided on mounting plate lock down tight. Now, tighten bushing lock screws. 6. Position cable forward to the point where the smallest diameter of cable will come in contact with the drive bearings, adjust your Dial-A-Cable for your cable size. Turn knob (#18) clockwise (right) until contact is made with drive bearing. 7. Installation is complete. Refer to operating instructions for safe operation. 12 Installation Instructions INSTALLATION INSTRUCTIONS FOR MODEL 100 (See Fig. 4 & Fig. 5) The following instructions are for manual machines. Skip steps 1 through 3 when replacing older power feed units. 1. Remove mounting plate from Dial-A-Cable power feed and reposition bolts in upper holes in plate. 2. Remove thumb screws and latch assembly from trunnion on machine. 3. Position drum into place on power drive unit. 4. Set Dial-A-Cable adjusters for ¾" cable size (full open) and turn knob counter clockwise (left) to raise upper wheel carrier. Place actuator handle to "N" neutral position. 5. Slide Dial-A-Cable power feed unit over cable end. Position mounting plate on trunnion using the two (2) round holes and locking in place with the two (2) thumb screws removed in step 2. Tighten securely. 6. Position the cable forward to the point where the smallest diameter of cable will come in contact with the drive bearings, adjust your Dial-A-Cable for your cable size. Turn knob clockwise (right) until contact is made with drive bearing. 7. Installation is complete. Refer to operating instructions for safe operation. 13 Operating Instructions WARNING: Follow all safety instructions as outlined in your product manual supplied with your machine. If a new product manual is required, contact Spartan Tool at (800) 435-3866 or download it at www.SpartanTool.com. (See Fig. 4 & Fig. 5) The following instructions refer to the use of the Spartan cable safety guide (44225300) (Fig. 1) which we recommend for safer operation. Always wear staple gloves or Ugly gloves when operating machines. Upon completion of installation instructions for your machine and before actual sewer cleaning, it is recommended you become familiar with your power feed operation. By moving the actuator assembly by use of the knob you will note the wheel carrier blocks and will turn. When the drum and cable are rotating the movement will feed the cable in and out by the slanting of the drive bearings. The decal on the front bearing plate is marked, from left to right, "R" (reverse), "N" (neutral), and "F" (forward). 1. Place the actuator handle to the midway point between "N" and "F" on the name plate. 2. No cutter should be attached to the cable at this time. 3. The forward/reverse electrical switch should be placed in the forward "F" with the machine plugged in to a power supply. Note: If drum rotation is reversed, feed of cable will be reversed. 4. Momentarily step on foot switch and check machine rotation. Drum and cable should rotate left or counter clockwise from cable end of machine. WARNING: Use care when performing the next operation as cable will be fed out and if allowed to feed too long may whip. Do not feed cable out more than 12 inches from feed unit. 5. With left hand on actuator assembly knob and right hand on adjusting knob, step on footswitch and slowly tighten (turn clockwise) knob. When cable is driving steadily forward, stop turning knob. Move actuator assembly knob to "R" position on name plate and cable should now retrieve. Cable movement will stop feeding in or out when actuator assembly knob is placed in the "N" position. You will note the farther the actuator assembly knob is moved to the forward or reverse position, the faster the cable will move out or in. 14 Cleaning Operation WARNING: Make sure to keep downward pressure on the cable safety guide at all times since flexible cable is subject to buckling under high torque conditions. If cable slips or whenever a stoppage is encountered, knob may be tightened down until cable is moving steadily. Caution! Do not tighten knob anymore than is necessary to cause cable to move in a steady motion in or out. Excessive tightening may damage cable or feed unit or overload motor. If at any time when cable is feeding into sewer line and torque build-up occurs, immediately move actuator control handle to the "R" (reverse) position to pull cable back. As soon as torque is relieved, move handle again to the "F" (forward) position. Repeat until stoppage is cleared. NOTE: The electrical switch is to be placed in the reverse position for a few seconds only to release an entangled blade or to negotiate a difficult turn or trap. Never continue operating the machine in the reverse position. The cable may exit the drum prematurely causing injury. Disassembly & Reassembly 1. Remove top two (2) acorn nuts from screws that holds feed unit to mounting plate. (On 2001 unit, remove two (2) screws at bottom that holds feed unit to upper front casting). 2. Remove feed unit from mounting screw by pulling forward. 3. Lay unit flat on back. 4. Remove remaining acorn nuts. 5. Remove bearing plate (with decal). 6. Remove handle assembly. 7. Remove stationary plate. 8. Remove the two (2) short bearing blocks as assemblies. 9. Remove the long bearing block as an assembly. 10. Remove bottom stationary plate. 11. Remove back bearing plate (without decal). 15 Disassembly & Reassembly DISASSEMBLY OF SHORT BEARING BLOCKS (See Fig. 10 and Fig. 11) 1. Pull wheel carrier bodies #21 from blocks #29. 2. Remove the two (2) thrust races #33 and one (1) thrust bearing #34 from each unit. 3. Remove four screws #31 holding Dial-A-Cable assembly #35, 36, and 37 to bearing block #29. (Do not disassemble unit) 4. Remove retaining rings #28 from drive pins #24 and pull pins from carrier bodies #21. This will release the drive roller #26 and two (2) spacers #27. Remove "O" ring #30 from carrier body grooves, use care not to damage same. FIG 10 FIG 11 16 Disassembly & Reassembly DISASSEMBLY OF LONG BEARING BLOCKS (See Fig. 12 and Fig. 13) 1. Remove the two (2) screws (#1) holding spring cover (#10) to top of long bearing block (#5). Leave remaining two (2) screws. 2. Pull wheel carrier body (#32) from block (#5) with cove (#10) and spring (#11) attached. 3. Remove spring (#7) and ball and bushing assembly (#4) from long wheel carrier body. 4. Remove retaining ring (#28) from drive pin (#24) and pull pin from carrier body (#32) with feed spring and cover attached. This will release the drive roller (#26) and two (2) spacers (#27). Remove "O" ring (#30) from carrier body groove, use care not to damage same. 4 3 5. Unscrew knob (#8) and remove two (2) remaining s0c4re2w24s0(0#01)BfrEoAmReINnGd cBaLpO(#C6K).ASSY LONG REV C D 2 ECO 8335 8375 DATE 4/13/17 10/19/17 DES REPLACES D ADD (2) 027 2 10 B 3 11 FIG 12 8 1 1 4 00113700 SCREW, 2 1 01921801 SCREW, 6 3 1 03312001 4 1 03415700 NUT KEP BUSHIN Fig. 5 1 04217900 BLOCK B 12 6 1 04219000 CAP END 5 7 1 04220100 SPRING 8 1 04220610 TOP KNO 9 1 44119600 WHEEL 10 1 44221900 2001 CO 4 11 1 44230100 2001 SP ITEM QTY PART NUMBER A 7 9 UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES .XX = .01 .XXX = .005 FRACTIONS = 1/64 WARNING: THIS DRAWING IS GENERATED FROM 3D BODY DATA AND ANY GEOMETRY CHANGES SHOULD BE CARRIED OUT IN 3D ONLY. TITLE FIG 13 ANGLES = 1 THIRD ANGLE PROJECTION THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION AND SUCH INFORMATION MAY NOT BE DISCLOSED TO OTHERS FOR ANY PURPOSE NOR USED FOR MANUFACTURING PURPOSES WITHOUT WRITTEN PERMISSION FROM SPARTAN TOOL L.L.C. BEAR DATE 4/13/17 SIZE SCA B 4 3 2 17 Disassembly & Reassembly DISASSEMBLY OF SHORT BEARING BLOCKS WARNING: The cleaning of parts in this instruction section recommends the use of kerosene for parts cleaning which is combustible and care should be used. Always work in a well ventilated area away from fire or open flame. When parts cleaning, always wear eye protection, rubber gloves and plastic or rubber apron. When cleaning of parts is complete dispose of all cleaning rags and waste cleaner in proper manner. NEVER USE GASOLINE OR ANY OTHER HIGHLY COMBUSTIBLE SUBSTANCE FOR CLEANING PARTS. After unit disassembly, all parts with the exception of the drive rollers and "O" rings should be soaked and cleaned in kerosene to remove grease and grime. Wipe parts and allow to dry completely before lubricating in assembly. Drive rollers and "O" rings should be wiped clean only and not placed in cleaner. Rollers are prelubricated and sealed if drive bearings are rough turning or frozen and don't turn, replace with new parts. We recommend the purchase of three (3) extra drive bearings and three (3) extra "O" rings for replacement when necessary. Lubrication of drive parts should be done as parts are reassembled. We recommend using a multipurpose lithium grease NLGI #2 which is water resistant and is available in tubes and aerosol cans. RE-ASSEMBLY OF SHORT BEARING BLOCKS 1. Replace "O" rings into groove in short wheel carrier block. (Spring bottom on block) 2. Place drive wheels in short blocks. BE SURE SPACERS ARE ON EACH SIDE OF WHEEL. Slip drive pin through hole and replace retaining ring. 3. Lubricate inside cylindrical section of short bearing blocks, covering inside wall with thin film of grease. 4. Lubricate "O" rings and lower section of wheel carrier blocks and slide wheel carrier assembly into blank untreaded end of short bearing blocks until drive wheel cut-out is flush with top of bearing block allowing room for thrust bearing. 5. Turn assembly over and place one (1) race on bottom. Lubricate thrust bearing and place on top of race. Place second race on top of thrust bearing. 6. Place Dial-A-Cable block assembly on bottom of short bearing block. Insert four (4) long hex screws through holes and screw into block, tighten hex screws securely. Assembly is complete. 18 Disassembly & Reassembly RE-ASSEMBLY OF LONG BEARING BLOCKS 1. Replace "O" rings #30 into groove in long wheel carrier block #32. (Spring hole in bottom.) 2. Lubricate inside cylindrical section of long bearing block #23. Install end cap #19 on end of long bearing block with two (2) short screws #20. Place these screws in the short rib side of the bearing block. 3. Lubricate "O" ring #30 and lower section of wheel carrier block #32. Install spring #22 into spring hole and install bushing and ball assembly #25 into spring. Slide wheel carrier unit into bottom of long bearing block. 4. Lay bearing block on bench with short rib side down. Place drive wheel #26 into end of wheel carrier block. BE SURE SPACERS #27 ARE ON EACH SIDE OF WHEEL. 5. Place drive Pin #24 (which has spring and cover attached) through hole and replace retaining ring #28. 6. Drive pin #24 should now be centered between the two (2) long ribs on the bearing block to allow spring #9 to lay between ribs. 7. Pull cover #7 up and place over end cap #19 attach with remaining two (2) short screws. Tighten all screws securely. 8. Replace knob #18 in end cap #19. 19 Instructions The Spartan Tool Cable Safety Guide has been designed to improve the operational safety. It's purpose is to prevent direct contact with the rotating cable. To install, place the spring end of the Cable Safety Guide against the hub of the power feed and rotate it counterclockwise under pressure until the spring rests against the wall of the Actuator Assembly. Figure 14 illustrates the proper positioning and appropriate safety gear when using the machine and Cable Safety Guide: FIG 14 WARNING: Read the appropriate "Operating & Safety Instructions" before operating any Spartan Tool machine. Sewer cleaning can be dangerous if precautions are not taken and rules are not followed. Before using the machine, make sure the operator's switch is in the "forward" position. (The drum will rotate clockwise when standing behind the machine.) WARNING: If the operator's switch is in the "reverse" position, the power feed will operate counter to the labeling on the power feed. "Reverse" will more the cable forward and "forward" will retrieve the cable. The length of the Cable Safety Guide is the correct distance the machine should be located from the pipe opening. If the machine cannot be located as prescribed, precautions must be taken. A pipe section must be placed in the area between the "cleanout entry" and the end of the Cable Safety Guide to avoid injury. WARNING: A distance exceeding 3' between the machine and the pipe opening may cause personal injury from a rotating, swinging cable, if precautions are not taken. 20 Instructions If a "cleanout" is positioned on a wall, then the machine should have support legs, found in the tool box, positioned as in Figure 15. Ensure the appropriate pipe section is placed between the Cable Safety Guide and the Cleanout Entry to avoid injury. WARNING: Make sure to keep downward pressure on the Cable Safety Guide to keep slack from developing on the cable to prevent looping. FIG 15 21 Warranty Information Spartan Tool warrants its equipment to be free from defects in material and workmanship for one year from the date of purchase. To obtain warranty service, a purchaser should notify Spartan Tool in writing, at the address provided below, within the warranty period, and Spartan Tool will direct where to take or send the equipment for service. If the defect is covered by the warranty, Spartan Tool will repair or replace, at its option, the defective equipment, without charge for labor or materials (freight and insurance are the purchaser's responsibility). This warranty is limited to the original retail purchaser and is not transferable. Spartan Tool assumes no responsibility for damage due to accident, neglect, abuse, tampering or misuse, nor damage from repairs or alterations by others. This warranty does not cover damage to the equipment resulting from the use of replacement parts other than Spartan Tool parts. Spartan Tool's sole obligation and the original purchaser's exclusive remedy under this warranty shall be for repair or replacement as described above. ALL OTHER WARRANTIES, WHETHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL SPARTAN TOOL BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES Spartan Tool LLC Niles, MI 49120 Spartan Tool LLC reserves the right to make changes at any time, without notice, to specifications and models and also discontinue models. The right is also reserved to change specifications or parts at any time without incurring any obligation to equip same on models manufactured prior to the date of change. CONTACT US Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 800.435.3866 SpartanTool.com 22 Notes 23 CONTACT US Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 800.435.3866 SpartanTool.comAdobe PDF Library 15.0 Adobe InDesign 14.0 (Windows)
