Application Code Manager

Chapter 1

Application Code Manager Overview

Studio 5000� Application Code Manager is a tool that enables more efficient project development with libraries of reusable code. Application Code Manager creates modular objects with customizable configuration parameters using the reusable content. Application Code Manager can also create the associated visualization, historical and alarming elements for a project.
Use Application Code Manager to:
� Create databases � Register libraries � Create projects � Manage objects
Application Code Manager includes an additional command-line tool, the ACM Console. Use the ACM Console to perform the following actions:
� Edit Parameters � Export All Projects � Export Libraries by Attribute � Generate Controller (as an L5X or ACD file) � Import Project � Publish Library
Before starting a project, become familiar with the basic concepts used in Application Code Manager; the design process, the different library objects, the available templates, the use of schedules, and the design outputs from Application Code Manager.

Activation
Activating Application Code Manager provides access to all Application Code Manager features.
When not activated Application Code Manager has the following limitations:
� Application Code Manager can only connect to a local database instance.
� Application Code Manager can only support a single controller per project. Attempting to import projects with multiple controllers will result in an error.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 1

Application Code Manager
See also

Design process on page 8

Library objects on page 11

Templates on page 12

Schedules on page 13

Initial configuration of Application Code Manager on page 15

Design process

The Application Code Manager (ACM) design process introduces a modular, object-based approach to the creation of ACD controller code, FactoryTalk� View SE/ME display content, FactoryTalk Historian Tag and Alarms import configuration.

The Studio 5000 ACM design process separates function and configuration into two separate layers of data, and divides the design process into two distinct workflows, library management and project execution.

The design process involves a suite of applications:

� The Studio 5000 Logix Designer� application � The Library Designer � The Library Object Manager application � The Application Code Manager application � FactoryTalk View Studio

Library management workflow: Studio 5000 Logix Designer
The library management workflow begins when a specific instance of ACD controller code is created in the Logix Designer application. The specific instance is a single project containing a single controller. The project includes a logical structure containing these Logix objects:
� Controller Tags � Tasks � Motion Groups � Add-On Instructions � Data Types � Trends � I/O Configurations
Each Logix object has an internal hierarchy of elements. Example: a task may contain one or more programs, each of which may contain one or more routines.
Every project has one controller. There may be one, many, or no instances of any type of Logix object in the project when the specific instance is created. This single instance of controller code is saved to an ACD file.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 1

Application Code Manager

Traditionally, controller code was designed and configured for a specific project. In the library management workflow, content is not designed for a specific project, but to provide a widely applicable set of functions known as project components that are then used to create library objects. Each library object is an independent functional entity that can be easily configured to meet a wide range of applications and can be used in many projects.

Library Designer
Use the Library Designer to assign the project, the controller, and any of the Logix objects to one or many library objects. Each library object defines a set of functions, capabilities, and connections. Example: those that support function of the valve, motor, and controller modules. Rather than being tied to one application, library objects can be configured to meet the needs of multiple applications. The Library Designer allows the publishing of a library directly into an ACM database. Options include the ability to specify the location where the library will be published in the ACM database, and the ability to specify the status of the library, either Published or Pending.
Custom properties called "Decorations" can be added to a library object using the Library Designer. Decorations include parameters, sub-objects, functions, substitutions, and external references. Decoration lets the library object be configured when it is implemented in a project in the ACM application.
Logix objects can be restricted to a single library object or assigned to multiple library objects, each with a different set of decorations. A library object can contain a single Logix object, or a Logix object can be added as an element of a more complex library object. Example: a P_Alarm Add-On Instruction can be assigned to a valve library object and can also be an element of a Motor or Pump library object.
Each ACD file can support multiple projects, controller libraries, and library objects. The ACD is not required to contain a project or controller library. While decoration is stored as part of the ACD file, it is treated as a separate layer of information from the base controller code and does not affect code execution.
Decoration controls how the library object is instantiated, including configurations such as naming, tag values, conditional inclusion, and connections to other library objects. One or many distinct instances of a library object can be instantiated within an ACM project and each instance can be separately configured. Using Library Designer each Logix object can be published directly to the ACM database or to a file in HSL4 format.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 1

Application Code Manager
Library Object Manager
The library management workflow continues by opening the decorated ACD file in the Library Object Manager application. The Library Object Manager application can be used to publish each library object, either directly to the ACM database or to a file in HSL4 format. HSL4 files can be distributed individually or as part of a repository.
Use Library Object Manager to add HMI displays (FactoryTalk View SE/ME), FactoryTalk Alarms and Events configurations, FactoryTalk View ME Alarms and Historian (FactoryTalk Historian SE) components to the library object. This can only be done after the library object has been published from the ACD file to a folder or ACM database. The features added in the Library Object Manager application are saved to the individual HSL4 file or database entry for the library object and are not saved to the original ACD file.
Each library object file saved from the Library Object Manager application is classified within a four-level hierarchy:
Solution -> Library Type -> Category -> Catalog Number
Example: an analog input module might be classified as:
� Solution: (RA-LIB) ACM Solution will, in most cases, name the library object repository for the library object.
� Library Type: Modules Library Type is a general classification for the library object based on its function, such as module, control module or design pattern.
� Category: Analog Category is a more specific classification for the library object, based on its function.
� Catalog Number: 1734-IE2C/C The specific identifier for the library object.
Each library object file must have a distinct version number per solution. Just as the same Logix object can be used to create one or many library objects within the Library Designer, the same library object can be used to create one or many distinct library object files (versions) within the Library Object Manager application.
Library objects can be quickly distributed, then registered into and configured for multiple Projects in multiple locations. Library objects are available to any project that requires the functionality the library object provides.
Using Library Object Manager new library objects can be created and distributed rapidly to meet the needs of specific applications.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Library objects

FactoryTalk View Studio

Chapter 1

Application Code Manager

Use FactoryTalk View Studio to create Site Edition (SE) and Machine Edition (ME) graphic displays. When the graphic displays are exported to XML they are called "Symbol objects." The XML files can be imported into the Library Object Manager application and the graphic displays added as non-Logix content to library objects.

The Project Execution Workflow: Application Code Manager
In the Application Code Manager application, library objects become the building blocks used to rapidly create and deploy projects.
Execution is simply a matter of registering, adding, and configuring the library objects. Projects can be completed without requiring high-end programming support.
In the project execution workflow, library objects are selected in the ACM application and then the library object parameters are configured to meet the requirements of the current application. The workflow is complete when the Project to ACD controller code is created.
During the project, new library objects can be created using Library Designer, library objects from previous projects can be reused, or library objects can be shared from other databases.
After the project is complete, it can be used to create new library objects so that future projects can use the solutions developed.

See also
Application Code Manager Overview on page 7
Project Development on page 27
A library object is the class definition of an object, it can contain links to other libraries. A library object is instantiated. When instantiating a library, all the linked libraries can be instantiated to new objects, or can continue to link to an existing instantiated object in the library.
Individual library object files (HSL4) are XML formatted and registered in the ACM database. A library object typically defines parameters, subclasses, user

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 1

Application Code Manager

interface contents, and portions of controller code (example: Logix) and HMI code (example: FactoryTalk View SE/ME).

Templates
12

Library objects contain controller code, as well as decoration. Decoration is a set of custom properties applied to a library object using the Library Designer. Decoration can be inherited from a library object that is higher in scope such as the Controller and Project object. Decoration that is applied to a library object is inherited by, or available to, all elements that are contained within the library object. Decoration can also be applied directly to an element, overriding inheritance from the library object and from library objects of higher scope. ACM provides the option to include Project Data during the controller code generation. If this option is selected all instances with their parameter values, as well as all libraries (zipped) will be included as part of the Controller's Custom Properties. Every element created and included by ACM will also have project data custom properties which includes information about the instance and the library that owns or created the element.
See also
Application Code Manager Overview on page 7
Registered Libraries on page 41 A template defines the static content and format of design output (example: a FactoryTalk View display). A template is not a class definition. A template is not instantiated. Templates have a variety of formats (example: xml, csv, docx, xlsx) and are stored in the ACM program folder or an individual user folder. Before a template can be used the initial configuration of ACM must be completed, the local library must be registered, and the template installed.
Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Schedules

See also

Chapter 1

Application Code Manager

Application Code Manager Overview on page 7

Initial configuration of Application Code Manager on page 15

Local library and template file location on page 45

Use schedules to display or edit project data, typically parameter values.

Read-only schedules called "views" are temporarily generated for certain ACM reports (example: the I/O Schedule report).

The Import Export Manager tool can be used to export a schedule to a Microsoft� Excel� spreadsheet. Exporting a schedule to a spreadsheet can be useful for:

� Bulk additions, duplication, and changes � Transferring project contents � Snapshots � Backups � Version comparison

Import the schedule spreadsheet to ACM using the Import Export Manager tool.

See also
Application Code Manager Overview on page 7
Import Export Manager on page 61
Design Automation Concept The project design outputs are generated automatically by ACM. The objects
(instances) and parameter values, stored in the ACM database, are combined with various templates to create the following design outputs:
� Logix � FactoryTalk View SE/ME graphics � FactoryTalk Historian SE import file � FactoryTalk Alarms and Events import file � Excel (Schedules)

Create a central ACM database

See also
Application Code Manager Overview on page 7
When planning an ACM deployment if there are multiple people collaborating on projects make sure to select a computer to use as the ACM database server that can be accessed by all users in the project. This can be a standard computer that does not belong to a particular user or a project computer. The

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 1 14

Application Code Manager

computer must always be turned on and available. Microsoft SQL Server 2016 is the only software required on the shared computer.
Note: The ability to connect to a remote database is only available if the product has a Standard activation license and is not available in Lite mode.

Install SQL Server 2016 via the ACM installation media. Select only SQL Server 2016 when presented with the selection of install options.

When configuring the SQL Server note the following considerations when supporting multiple user connections to the database:

1. Add Users: Normally ACM uses Windows Authentication to connect to the ACM database. When the ACM database is located in a remote computer, local users must be created using the SQL Server Management Studio. Create one user account that is shared by all the project collaborators or add an individual user for each collaborator. Only assign users to the ACM database after the ACM database is created.
If the SQL user is not a sysadmin, creation of the database for the first time is a multi-step process:
a. Create users in SQL.
� Minimum Server Roles should be:
� dbcreator � public
� Permissions on Securables should be:
� Connect SQL � Control Server � View any database (optional, but if not, the database needs to
be mapped to this user in SQL)
b. Launch the database manager in ACM and create the database using the new user.

Creation of this database must be done from ACM and cannot be done manually in Microsoft SQL Server.
c. In order for the user to connect and update the database, add the newly created database to the User Mapping in SQL and set the memberships on the database to:
� db_owner � db_datareader � db_datawriter � public
d. In order for the user to back-up the database, add the newly created database to the User Mapping in SQL and set the memberships on the database to:
� db_backupoperator

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 1

Application Code Manager

2. Record Database Connection Information: Record the SQL Server computer name and/or computer IP address, the SQL Server instance name, the SQL Server authentication (username and password), and the ACM database name. This information is required by ACM users attempting to connect to the central ACM database.

Upgrading a central ACM database

See also
Initial configuration of Application Code Manager on page 15
Connect to an ACM database on page 21
After installing a new version of ACM, the database may sometimes require upgrading due to the adding of new tables or fields. You will be notified to upgrade the database if applicable.
The failure of the upgrade process could be related to you having insufficient permissions of the central server to execute the upgrade commands. The upgrade process could also fail due to the requirement of additional prerequisite software needed on the SQL server host machine.
If upgrading ACM from v2.xx to v4.xx then this error is likely due to the x64 versions of the following components not being installed:
� Microsoft System CLR Types for SQL Server 2012 (x64) � Microsoft SQL Server 2012 Management Objects (x64)
It is recommended that when installing a new version of ACM on a client machine on which the same version of ACM is also installed on the SQL server host machine to ensure all prerequisite software is also installed.

Initial configuration of Application Code Manager

See also
Create a central ACM database on page 13
Connect to an ACM database on page 21
Before using Application Code Manager, initial configuration must be completed. In this procedure, a database is created, the database connection method is specified, and the default ACM libraries are registered.
Tip: If the SQL Server installation option was selected, this procedure was completed automatically during installation.

To complete the initial configuration of Application Code Manager
1. Open Application Code Manager. On the main menu, click Tools > Database Manager.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 1

Application Code Manager

2. In Server Name, select the computer name and SQL Server instance from the drop down list or type a computer name and SQL Server instance in the following format:
<Computer Name> \ <SQL Server Instance>
3. In Log on to the server, type the User name and Password to use to authenticate the connection to the SQL Server, then click Connect.
Status updates to Connected.
4. In Specify the database, type a unique name for the ACM database. 5. In Actions, select Create database and then click Execute Task.
Once the database is created an Action completed successfully message displays. Click OK.
6. Click Close to close Database Manager.
Tip: The Application Code Manager title bar displays the application icon and application name followed by the computer name, SQL Server instance, and database name formatted as: <Computer Name> \ <SQL Server Instance>.<DataBase Name> If Application Code Manager is not able to connect to a database the title bar displays (Not Connected).
7. In Application Code Manager, right click Registered Libraries and then select Register.
The Open dialog box displays the default library file location. C:\User\Public\Public Documents\Rockwell Automation\Studio 5000\Libraries\Application Code Manager
8. Open the (RA-LIB) ACM folder. Select all the objects in the folder and then click Open.
9. The Libraries Registration window opens and displays the status of the library registration process.
Review any errors or warnings that were encountered.
Tip: The results of the registration process are also saved to a log file. Click Show Log File to view the contents of the Log file.
10. Click Finish to close the Libraries Registration window.
The registered libraries display Application Code Manager under Registered Libraries.

Upgrade the Application Code Manager application

See also
Create a central ACM database on page 13
Database Manager settings on page 77
When upgrading the Application Code Manager application, consider updating the libraries used in the ACM projects for a particular ACM database and obsoleting the previous version libraries.
IMPORTANT It is recommended to back up the current ACM database using the Database Manager before performing an upgrade. With the Export Used Libraries option enabled, export all projects using the Import Export Manager can also back up database.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 1

Application Code Manager

To upgrade the Application Code Manager application

1. Install a newer version of Application Code Manager. 2. Open Application Code Manager. A message appears with a prompt to
upgrade the database. Click OK. The Database Manager displays. 3. Select Upgrade database in the Actions - Tasks area and then click
Execute Task.

Click Close to close Database Manager.
4. Right click Registered Libraries and then select Register to ensure any new libraries are added to the database.
In the Open dialog box, browse the default library file location. C:\User\Public\Documents\Studio 5000\Libraries\Application Code Manager

5. Open each folder. Select all the objects in the folder and then click Open.
6. The Libraries Registration window opens and displays the status of the library registration process.

Review any errors or warnings that were encountered.
Tip: Results of the registration process are also saved to a log file. Click Show Log File to view the contents of the Log file.
7. Click Finish to close the Libraries Registration window.
The registered libraries display in Application Code Manager under Registered Libraries.

See also

Import Export Manager on page 61

Navigate the Application

Application Code Manager is composed of a menu bar, a toolbar, and several

Code Manager user interface

different panes that navigate through different objects. The objects (instances) contained in a project are arranged in a hierarchy. There are three

ways to view the hierarchy, which are accessed by clicking one of the three

panes (System View, Controller Preview, and Class View). Hide or float the

panes so that they can be arranged according to preference.

This table provides an overview of the user interface panes.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 1

Application Code Manager Pane System View

Controller Preview
Class View Object Identifiers

Description
A pane that contains a tree control that enables navigation through the different components of an ACM project. The System View pane displays branches for the objects contained in the project including FactoryTalk Historian Server objects, FactoryTalk View SE/ME Server objects, Libraries used in the project, and Controller objects. � Historian branch
The Historian branch contains all Historian ScanClass objects in the Project. The Historian objects are organized in a 3-level hierarchy: Historian --> ScanClass ----> Object The Historian Scan Class definitions are Sub-objects in the FT_Historian object (instance). � HMI branch The HMI branch contains all HMI objects in the Project. HMI objects are organized in a 3-level hierarchy: HMI --> Displays ----> Object HMI --> Colors ----> Object and HMI --> Alarms ----> Object � Used Libraries branch The Used Libraries branch displays the libraries that are used in the project. Libraries are organized in a 4-level hierarchy: Solution --> Library Type ----> Library Category ------> Library Catalog Number (Library Version) A pane that contains a tree control that enables navigation through the different controllers. The Controller Preview pane displays all the project data organized into the following folders: � Controllers � Controller-specific data � Logix-specific objects � Task/Programs � Control Modules Controller Preview displays Logix content similar to its final state after it is generated. Use this view to add objects, as well as generate code. A pane that contains a tree control that enables navigation through objects grouped by controller. Objects are organized by the Library object catalog numbers and show the instances below them. Use this view to add, copy, or delete any object instances as well as generate code and reports or navigate the library in the Registered Libraries tree.
Displays the identification information for the currently selected object. Includes � Name. The name of the object in the database � Description. Object category or user specified label for the object. � Catalog Number. The specific identifier assigned to the object in the library. � Solution. The name of the library object repository for the library object

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Pane Object Parameters
Registered Libraries Library Repositories

Chapter 1

Application Code Manager

Description

This pane displays the properties tab for the object currently selected in either the System, Controller, or Class view. When applicable, a toolbar is present in the parameter pane that provides the ability to: � Sort parameters alphabetically � Sort parameters into groups � Show only visible parameters � Show all (visible and hidden) parameters � Open additional properties The parameter name shows in the column on the left and the parameter value shows in the column on the right. Change parameter values by typing a new value in the right column. A description of the selected parameter displays at the bottom of the parameters tab. Some objects have additional tabs for sub-object parameters, (example: analog input of a 1756-IF16 or Attachments for libraries). Sub-object parameters show on an additional tab labeled with the sub-object display name. Each row in the sub-object parameters tab represents a sub-object. By default, sub-objects sort alphabetically by name. Sort sub-objects in groups by clicking on a column header. The sub-object name shows in the Name column. Additional columns display the sub-object parameters (example: Channel). Change the sub-object name and the sub-object parameter values by typing a new value below the column header. The sub-object name can be configured as read-only. When the sub-object name is read-only, the value is shown dimmed. If an object or sub-object parameter value is changed click Apply changes to save the changes to the ACM database. The version number of the Application Code Manager software displays in lower left corner of the object Parameter tab.
A pane that contains a tree view display of all libraries in the connected ACM database. These libraries can be added to an ACM project. The libraries are organized in a 4-level hierarchy with statistical information in parenthesis: Solution (Number of objects) --> Library Type (Number of objects) ----> Library Category (Number of objects) ------> Library Catalog Number (Library Version)
This pane displays the configured library repositories. A library repository refers to another ACM database that can monitored for library updates. Libraries from these source databases can be easily replicated over to the currently active database for use within a project. It is unavailable to create an object directly from a library in a library repository. The library must first be replicated to the current active ACM database before it can be used to create an object. Add or remove library repositories in this pane.

See also
Create a new project on page 28 Add a Historian object on page 29 Add a new HMI object on page 33 Update a project library on page 37

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Connect to an ACM database

Chapter 2

Connect to an ACM database To use Application Code Manager it must be connected to an ACM database.
During the initial configuration of Application Code Manager the default database was configured. Use this procedure to open the Connection properties sheet and update the database connection configuration if the original ACM database server becomes unavailable, if the authentication method needs to be modified, or if a different database is to be used.

To connect to an ACM database
1. Open Application Code Manager. On the main menu, click File > Connect.
2. In Data source confirm that the database type is Microsoft SQL Server (SqlClient).
3. In Server Name, select the computer name and SQL Server instance from the drop down list or type a computer name and SQL Server instance in the following format:
<Computer Name> \ <SQL Server Instance>
Tip: If the database is located on the same computer as Application Code Manager, type localhost.
4. In Log on to the server, either:
� Choose Use Windows Authentication to allow SQL Server log on using the logged on user account credentials.
� Choose Use SQL Server Authentication to allow SQL Server log on using SQL Server authentication.
If this method is selected then type the User name and Password to use to authenticate the connection to the SQL Server. If the SQL database is created by the ACM installer then the user name is "sa" and the default password is "ApplicationAdm1n".
Tip: Select Save my password to allow Application Code Manager to retain the password and log on automatically.
5. In Connect to a database, determine whether to connect to a database on the server or to attach a database file.
� Choose Select or enter a database name to select a database name from a pull-down list or enter a database name. The database must exist on the database server.
� Choose Attach a database file and then type a database file name or click Browse to navigate to the file.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 2

Connect to an ACM database

Then, in Logical name type the name of the database within the file that Application Code Manager should connect to.
6. (optional) Click Advanced to configure settings related to connection protocols, resiliency, content, initialization, pooling, replication, and additional security controls. Applying the recommended settings as defined on the help page for the Advanced Properties will improve performance, especially for network connections.
7. Click Test Connection to verify the connection settings specified. If the connection succeeds, click OK to close Connection Properties.

Connection Properties settings
Setting Data source: Server name: Log on to the server Use Windows Authentication Use SQL Server Authentication
Connect to a database Select or enter a database name: Attach a database file:
Advanced

See also
Connection Properties settings on page 22
Advanced Properties settings on page 23
Initial configuration of Application Code Manager on page 15
How do I open the Connection Properties dialog box?
� On the main menu, click File >Connect.
The Connection Properties dialog box defines the settings for how Application Code Manager connects with the SQL Server database. Use this dialog box to set the data source, the type of user authentication, to specify a different database file, or to modify advanced security settings.
This table describes the settings in the Connection Properties dialog box.
Description
Database type. Always select Microsoft SQL Server (SqlClient) Selects a computer name and SQL Server instance from the list or type a computer name and SQL Server instance in the following format: <Computer Name> \ <SQL Server Instance>
Allows SQL Server log on using Windows authentication. When selected the logged on Windows user account credential will be sent to SQL Server to authenticate the session. Allows SQL Server log on using SQL Server authentication. When selected the user name and password must be provided for authentication by the SQL Server. � User name. The SQL Server user name, "sa" by default. � Password. The SQL Server password associated with the user name specified, "ApplicationAdm1n" by default. � Save my password. When selected, saves the SQL Server password specified so that it can be used in the next
session.
Select a database name from the list or enter a database name. When selected specify the identifiers for the database file. SQL Server database files have two names, the operating system file name used to locate the database in the file system and the logical file name used to identify the database within SQL Server transactions. � Type a database file name or use the Browse button to use the Open dialog to locate the database file by clicking
through the file system. � In Logical name, type the logical name of the database. Select to configure advanced database properties.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Setting Test Connection
Advanced Properties settings

Chapter 2

Connect to an ACM database

Description

Tests the connection to the database. If a "Test connection succeeded." message is not returned, check that the following settings are correct: � Computer name � SQL Server authentication � Network access (remote SQL Server)

See also
Initial configuration of Application Code Manager on page 15 Advanced Properties settings on page 23 Connect to an ACM database on page 21 Create an ACM database on page 73 How do I open the Advanced Properties dialog box? 1. On the main menu, click File >Connect to open Connection Properties. 2. Click Advanced.

The Advanced Properties dialog box provides a means of changing how the connection between ACM and the SQL Server passes information.
This table describes the settings in the Advanced Properties dialog box. The dialog box is divided into functional areas.
Note: Applying the recommended settings will improve ACM performance especially for network connections.

Area Advanced

Setting MultipleActiveResultSets Network Library
Packet Size Transaction Binding

Possible Values

Description

True False (default)

When True, multiple result sets can be returned and read from one connection.

blank (required if local) The network library used to establish a connection to an instance of
Named Pipes (DBNMPNTW) SQL Server. Do not use when the SQL Server is resident on the Shared Memory (DBMSLPCN) local host computer, value should be blank.

TCP/IP (DBMSSOCN) (recommended if networked)

VIA (DBMSGNET)

8000 (recommended)

Size in bytes of the network packets used to communicate with an instance of SQL Server. PacketSize may be a value in the range of 512 and 32767 bytes.

Implicit Unbind (default) Explicit Unbind

Indicates the binding behavior of connection to the System.Transactions namespace. When set to Implicit Unbind, the connection detaches from the transaction when it ends, switching back to autocommit mode.

When set to Explicit Unbind the connection remains attached to the transaction until the transaction is closed. The connection will fail if the associated transaction is not active or does not match the current transaction.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 2

Connect to an ACM database Type System Version

Connection Resiliency ConnectRetryCount

Context Initialization
Pooling

ConnectRetryInterval
Application Name Workstation ID ApplicationIntent Asynchronous Processing Connect Timeout
Current Language Enlist Load Balance Timeout

Max Pool Size Min Pool Size PoolBlockingPeriod

Pooling

Latest (default) SQL Server 2012 SQL Server 2008 SQL Server 2005 2 (recommended)

Indicates which server type system the provider will expose through the DataReader.
Number of attempts to restore a connection. The number of reconnections attempted after identifying that there was a connection failure. This must be an integer between 0 and 255. Set to 0 to disable reconnecting on idle connection failures.

5 (recommended)
.Net SqlClient Data Provider ReadWrite (default) ReadOnly True False (default) 30 (recommended)
True (default) False 30 (default)
1000 (recommended)
1 (default)
Auto AlwaysBlock NeverBlock (recommended)
True (recommended) False

Delay between attempts to restore connection. The amount of time (in seconds) between each reconnection attempt after identifying that there was a connection failure. This must be an integer between 1 and 60. The name of the application. The name of the workstation connecting to SQL Server.
Declares the application workload type when connecting to a server.
When true, enables usage of the Asynchronous functionality in the .Net Framework Data Provider.
The length of time in seconds to wait for a connection to the server before terminating the attempt and generating an error. A value of 0 indicates no limit, and should be avoided in a ConnectionString because an attempt to connect waits indefinitely. The SQL Server Language record name.
When True sessions in a Component Services environment should automatically be enlisted in a global transaction where required.
The minimum amount of time (in seconds) for this connection to live in the pool before being destroyed. When a connection is returned to the pool, its creation time is compared with the current time, and the connection is destroyed if that time span (in seconds) exceeds the value specified by Load Balance Timeout. A value of zero (0) causes pooled connections to have the maximum connection timeout. The maximum number of connections allowed in the pool. Valid values are greater than or equal to 1. Values that are less than Min Pool Size generate an error. The minimum number of connections allowed in the pool. Valid values are greater than or equal to 0. Zero (0) in this field means no minimum connections are initially opened. Values that are greater than Max Pool Size generate an error. Defines the blocking period behavior for a connection pool. When connection pooling is enabled and a timeout error or other login error occurs, an exception will be thrown and subsequent connection attempts will fail for the next five seconds, the "blocking period". If the application attempts to connect within the blocking period, the first exception will be thrown again. Subsequent failures after a blocking period ends will result in a new blocking period that is twice as long as the previous blocking period, up to a maximum of one minute. When True, the connection object is drawn from the appropriate pool, or if necessary, is created and added to the appropriate pool. Any newly created connection is added to the pool when closed by the application. In the next attempt to open the same connection, that connection will be drawn from the pool. Connections are considered the same if they have the same connection string. Different connections have different connection strings.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Replication Security
Source

Replication

False (default) True

Chapter 2

Connect to an ACM database

Used by SQL Server in replication. Set to True if replication is supported using the connection.

Authentication Column Encryption Setting

NotSpecified (default) SqlPassword ActiveDirectoryPassword ActiveDirectoryIntegrated Enabled Disabled (default)

Specifies the method of authenticating with SQL Server.
Default column encryption setting for all the commands on the connection.

Encrypt Integrated Security Password Persist Security Info TrustServerCertificate
User ID

True False (default) True False (default)
******* True False (default)
True (recommended) False
sa

When True, SQL Server uses SSL encryption for all data sent between the client and server if the server has a certificate installed.
Whether the connection is to be a secure connection or not. When False, User ID and Password are specified in the connection. When True, the current Windows account credentials are used for authentication. Indicates the password to be used when connecting to the data source. When False, security-sensitive information, such as the password, is not returned as part of the connection if the connection is open or has ever been in an open state.
When True (and Encrypt is set to True), SQL Server uses SSL encryption for all data sent between the client and server without validating the server certificate. If TrustServerCertificate is set to True and Encrypt is set to False, the channel is not encrypted. Indicates the user ID to be used when connecting to the data source.

AttachDbFilename Context Connection Data Source Failover Partner Initial Catalog MultiSubnetFailover TransparentNetworkIPResolution
User Instance

True False (default) localhost\SQLACM (default)
Initial Database Name True False (default) True (default) False
True False (default)

The name of the primary file, including the full path name, of an attachable database.
When True, indicates the connection should be from the SQL Server context. Available only when running in the SQL Server process.
Indicates the name of the data source to connect to.
The name or network address of the instance of SQL Server that acts as a failover partner.
The name of the initial catalog or database in the data source.
If your application is connecting to a high-availability, disaster recovery (AlwaysOn) availability group (AG) on different subnets, setting this value to True configures SqlConnection to provide faster detection of and connection to the (currently) active server.
If your application connects to different networks, setting this value to True configures SqlConnection to provide transparent connection resolution to the currently active server, independently of the network IP topology. When set to True, the application is required to retrieve all IP addresses for a particular DNS entry and attempt to connect with the first one in the list. If the connection is not established within 0.5 seconds, the application will try to connect to all others IP addresses in parallel. When the first IP address answers, the application will establish the connection with the respondent IP address. If MultiSubnetFailover is set to True, this setting is ignored. If Failover Partner is specified, this setting is ignored. The default setting is False if Authentication is set to either Active Directory Password or Active Directory Integrated, otherwise the default setting is True.
Indicates whether the connection will be re-directed to connect to an instance of SQL Server running under the user's account.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 2

Connect to an ACM database
See also
Connection Properties settings on page 22 Import Export Manager on page 61

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Project Development

Chapter 3

Project Development

Application Code Manager organizes components into projects. Use one of the following methods to create projects:
� Add a new project using the Object Configuration Wizard � Create a new project from an existing project � Import a project using ACM or ACM Console
Once a project is created, add objects for your application, such as:
� Historian objects � HMI objects � Alarm objects � Controllers and controller objects

Project commands
Command View > Project History Export Import Delete Rename Refresh
Update All Child Objects Add Paste Special Paste Copy

See also

Create a new project on page 28

Create a new project from an existing project on page 29

In the System View pane, right-click the Project branch to view the project commands. Different branches have different commands available.

This table describes each project command.

Branch

Description

Project (top)

Displays a report showing the Project History.

Project (top), Used Libraries, Starts the Import Export Manager. Library Module

Project (top)

Starts the Import Export Manager.

Project (top), Historian object, Deletes the selected object. Displays object, Alarms object Note: The Projects Delete dialog box supports multiple select.

Project (top), Historian object, Renames the selected object. Displays object, Alarms object

Project (top), Historian,

Refreshes the tree view.

ScanClass, Historian object, HMI,

Displays, Displays object,

Alarms, Alarms object

Historian, HMI

Opens the Update Used Libraries window.

ScanClass, Colors, Displays, Alarms

Adds a new object (instance) to the selected Category.

ScanClass, Colors, Displays, Displays PasteSpecial window where child objects and reference values can be included or

Alarms

excluded.

ScanClass, Colors, Displays, Alarms

Pastes a copied object in the selected location.

Historian object, Displays object Copies the selected object.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 3

Project Development

Command

Branch

Description

Update Generate Historian Generate Displays
Generate Alarms Generate Documentation

Used Libraries, Library Module Historian object Displays Object
Alarms Object Project (top)

View > Project Library Usage Count
View > Project Library per Solution
View > Project Library Usage per Library Type
View > Project Library Usage per Category
View > Project Library Usage per Library

Used Libraries Library Solution Library Type Library Category Library Object

Displays the Update Used Library dialog.
Generates a copy of the selected Historian object from ACM. The Historian object is saved to an external folder. Generates a copy of the selected Displays object from ACM. The Display object is saved to an external folder.
Generates a copy of the selected Alarms object from ACM. The Alarms object is saved to an external folder. Generates the selected template file against the project object from ACM.As these templates are often custom built, generating at this level may not result in the desired outcome. The resulting file is saved to an external folder. Displays the Project Library Usage report for the selected object.
Displays the Project Library Usage per Solution report for the selected object.
Displays the Project Library Usage per Solution, Library Type report for the selected object. Displays the Project Library Usage per Solution, Library Type, Category report for the selected object. Displays the Project Library Usage per Library report for the selected object.

Create a new project

See also
Create a new project on page 28
Add ACM library content to an ACD project on page 107
Add a Historian object on page 29
Add an HMI object on page 33
Create a new project when the new project is not similar to existing projects.
To create a new project
1. Click File point to New and then click Project. The Object Configuration Wizard is displayed.
2. On the Select a library page click the + symbol to expand the library category and display the libraries registered in the connected ACM database.
3. Click a library to select it and then click Next. 4. If the library contains a library link, click the Linked Libraries tab. 5. Click the link and choose how to instantiate the linked library, select
either: a. Create New Instance. To create a new instance of the library the link is
attached to.
b. Link to Existing Instance. To link to a library instance of the target library that has already been created.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 3

Project Development

6. Enter a unique name in the Name field. Enter a description in the Description field and click Finish.

The new project appears highlighted in the System View pane.

Create a new project from an existing project

See also
Initial configuration of Application Code Manager on page 15 Create a new project from an existing project on page 29 Add a Historian object on page 29 Add an HMI object on page 33 Use an existing project in the ACM database as the basis for a new project if the projects use the same components and libraries. If the project is in a different ACM database, such as one from another installation, you must connect to that database, export the project, and then import it to the current database.

To create a new project from an existing project
1. Click File point to New and then click Project from Existing Project. The New Project Wizard is displayed.
2. On the Create a new Project from an existing Project page in From Project type a Project name or select the project name from the list.
3. In New Name, type a name for the new project. 4. (optional) In New Description, type a description of the new project. 5. Click Finish.
The new project appears highlighted in the System View pane.

Add a Historian object

See also
Connect to an ACM database on page 21 Add a Historian object on page 29 Add an HMI object on page 33 Add a Historian object to the project to support integration of Historian data.

To add a Historian object
1. In the System View pane, expand Historian, right click ScanClass and then click Add. The Object Configuration Wizard appears.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 3

Project Development

2. Under Select a library in the Solution column, click the + symbol to expand a library category and display the Historian libraries registered in the connected ACM database.
3. Click a Historian library, the row highlights to indicate that it is selected. Click Next.
4. In Name, type a unique name for the Historian object and then click Finish.
The Historian object is added to the System View pane as a child object of ScanClass.

Add a Historian sub-object

See also
Add a Historian sub-object on page 30
Historian Point Type parameters on page 31
Generate a Historian object on page 32
Update a project library on page 37
Historian objects have sub-objects that represent the point types configured. A FactoryTalk Historian point is the basic building block for controlling data flow to and from the FactoryTalk Historian SE server. A single point is configured for each measurement value that needs to be archived.

To add a Historian sub-object
1. In the System View pane, expand Historian, expand ScanClass and then click the Historian object to which the sub-object will be added.
2. In the object parameters pane, select the Point Type tab. 3. Right-click in the white space below the objects shown in the tab. Click
Add New.
Repeat this step to add all of the points that require configuration.
4. Click the appropriate column and modify the parameters as needed. 5. Click Apply Changes to save the parameter configuration.

Group sub-objects
Group sub-objects into categories based on the data columns.
� Double-clicking on a column heading updates the display in the parameters tab to group items with the same value together.
� Right-click anywhere in the parameters tab and select Reset Grouping to return to the default display.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Historian Point Type parameters
Parameter Name ScanClassNo ExcDev ExcDevPercent ExcMax ExcMin CompDev
CompDevPercent CompMax CompMin Compressing

See also

Chapter 3

Project Development

Add a Historian object on page 29

Historian Point Type parameters on page 31

Generate a Historian object on page 32

The Point Type tab displays a columnar grid of the parameters defined for the points of the Historian object.

This table describes the parameters in the Point Type tab of the Historian
object.
Description
The name of the point. Double-click to configure a unique name for the point. The scan class determines the frequency at which input points are scanned for new values.
Exception Deviation. Specifies in engineering units how much a point's value must change before the interface considers it a significant value, and sends it to the server. As a general rule, you should set the exception slightly smaller than the precision of the instrument system. Specifies the exception deviation as a percentage of span instead of in engineering units. For digital, string and Blob tags, ExcDev and ExcDevPercent are ignored and display by applications as zero. Exception Maximum. Specifies a limit on how long the interface can go without reporting a value to the Historian server. After the ExcMax time period elapses, the interface sends the next new value to the server, regardless of whether the new value is different from the last reported value. Exception Minimum. Specifies a limit on how frequently the interface can report values to the server. Example: For the interface to wait a full ten minutes before reporting a new value to the server, set the ExcMin attribute to ten minutes. ExcMin is typically set to zero. Compression Deviation. Specifies in engineering units how much a value may differ from the previous value before it is considered to be a significant value. In most environments, set CompDev to the precision of the data source or hardware (instrument). Initially, set it to a lower value so that important data is not lost. After collecting data for a while, go back and check the data for your most important tags, and then adjust CompDev to a higher value, if necessary. Setting the CompDev attribute value too low causes too little data compression, and wastes space in the archive. Setting the value too high causes loss of useful data. For most flows, pressures, and levels, use a deviation specification of 1% or 2% of span. For temperatures, the deviation should usually be 1 or 2 degrees. Specifies the compression deviation as a percentage of span instead of in engineering units. Note: For non-numeric tags, CompDev and CompDevPercent are ignored. They will be displayed by applications as zero. Compression Maximum. A point is archived if the elapsed time since the previous time the point was saved is greater than the maximum time. The recommended maximum time specification is one work shift (example: 8 hours). Duplicate values will be archived if the elapsed time exceeds CompMax. In most environments, set CompMax to the same value for all points in the system. Compression Minimum. A point is archived if the elapsed time since the previous time the point was saved is greater than or equal to the minimum time, and the value has changed by more than the deviation. For data points associated with interfaces that send exception reports, set CompMin to 0. Determines whether compression is turned on or off for the point. Compression should be turned on for all real-time points in the system. Set compression OFF for laboratory and manually entered tags so every value is recorded in the archive. To turn compression on, select the Compressing parameter for most points. With compression off, every value sent is saved in the archive. Compression affects digital points, since a new value is recorded only when the current value changes. Points of types Blob and string have a similar behavior; new events pass compression only when the value changes. String values are compared ignoring case. Example: "VaLuE" and "valUe" are evaluated as equal. For Blob events, any change is significant.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 3

Project Development

Parameter

Description

Step

The Step parameter affects only numeric points. It defines how numeric archived values are interpolated.

� When the checkbox is clear (OFF) archived values for the point are interpreted as a continuous signal and adjacent archived

values are linearly interpolated. Example: at 12:00:00, the value 101.0 is archived and at 12:01:00, the value 102.0 is archived. A

request for the archive value at 12:00:30 would return 101.5.

� When the checkbox is selected (ON) archived values for the point are interpreted discretely and adjacent archived values are

not interpolated. An archived value is assumed constant until the next archived value is recorded. Example: at 12:00:00, the

value 101.0 is archived, at 12:01:00, the value 102.0 is archived. A request for the value at 12:00:30 would return 101.0.

Data coming from continuous signals (such as signals from thermocouples, flow meters, and other devices that provide

continuous measurement) should be archived in points with the step flag OFF.

Data coming from discrete measurements (such as sampled lab data, batch charge weight, and other user-defined inputs) should

be archived in points with the step flag ON.

In addition, the step flag affects the compression calculation. When it is ON a linear change of value greater than or equal to

CompDev passes compression. When the step flag is OFF the complete compression algorithm is applied.

DigitalSet Scan AdviseMode SubObject Description

For digital points, the DigitalSet attribute specifies the name of the digital state set associated with the tag. The DigitalSet attribute has no meaning for non-digital tags.
Toggling this checkbox, turns scanning ON or OFF for a point. By default scanning is turned ON (selected), which indicates that the program should be able to collect data for the point. Setting the Scan attribute to OFF (cleared) turns off data collection for that point.
Specifies that the point should run in the Advised data collection mode. In this mode, data is collected only when a value changes in the controller. It is not based on the scan rate. AdviseMode is selected by default as this mode is the most efficient because data is sent to the Historian server only when the value changes.
Descriptive text that distinguishes this point from other points.

See also
Add a Historian object on page 29 Add a Historian sub-object on page 30 Generate a Historian object on page 32
Generate a Historian object Once a Historian Object has been configured it can be used to generate a
FactoryTalk Historian SE import file, this file is a comma-separated value (.csv) file.

To generate a Historian object file
1. In the System View pane, expand the Historian folder and the ScanClass folder so that the Historian objects are visible.
2. Right-click the Historian object to export and then choose the controller for which support is required.
� Click All Controllers to create an export file that supports all controllers in the project.
� Click a specific controller from the list if this object will only be used with that type of controller.
The Save As dialog box opens.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Add an HMI object

Chapter 3

Project Development

3. Use the tree control to browse to the location in which to save the Historian object file or use the default location:
C:\Users\<user name>\Documents\Studio 5000\Projects
The variable <user name> is replaced by the logged in user account name.

4. In File name type a name for the file or use the default file name which is created according to the following pattern:
<Controller Name>_<Historian object Name>.csv
The variable <Controller Name> is replaced by the name of the controller selected if a specific controller support was selected. If All Controllers are supported the controller portion of the default file name and the underscore are omitted.

5. Click Save. The Historian object generation is started. 6. Once the process is completed, the Generation Complete status dialog
box appears, click OK to close the dialog box.

See also
Add a Historian object on page 29 Generate an HMI object on page 35 Add an HMI object to support FactoryTalk View SE, FactoryTalk View ME, or Alarms displays in the project.

To add an HMI object
1. In the System View pane, expand HMI to see the HMI categories.
� To add a FactoryTalk View SE or FactoryTalk View ME HMI object, right-click Displays and then click Add.
� To add a FactoryTalk Alarms and Events object or FactoryTalk View ME alarm object, right-click Alarms and then click Add.
The Object Configuration Wizard appears.
2. Under Select a library in the Solution column, click the + symbol to expand a library category and display the libraries registered in the connected ACM database.
3. Click a library, the row highlights to indicate that it is selected. Click Next.
4. In Name, type a unique name for the object and then click Finish.
The object is added to the System View pane as a child object of the HMI category.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 3

Project Development

Add a Display sub-object

See also
Add a Display sub-object on page 34
HMI Display parameters on page 34
Add an Alarm Group sub-object on page 36
FTAE Alarm Group parameters on page 37
Generate an HMI object on page 35
Update a project library on page 37
FactoryTalk View objects have sub-objects that represent the display types configured. A FactoryTalk View graphic display represents a run-time operator's view of plant activity. A graphic display can show system or process data, and provide an operator with ways to write values to external devices such as programmable controllers.

To add a Display sub-object
1. In the System View pane, expand HMI, expand Displays and then click the FactoryTalk View object to which the sub-object will be added.
2. In the object parameters pane, select the Displays tab. 3. Right-click in the white space below the objects shown in the tab. Click
Add New.
Repeat this step to add all of the Displays that require configuration.
4. Click the appropriate column and modify the parameters as needed. 5. Click Apply Changes to save the parameter configuration.

HMI Display parameters

See also
Add an HMI object on page 33 HMI Display parameters on page 34 Generate an HMI object on page 35 The Display tab displays a columnar grid of the parameters defined for the displays of the FactoryTalk View object.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Parameter
Name DisplayTitle
DisplayLeft DisplayTop DisplayWidth DisplayHeight DisplayBackColor DisplaySecurity UpdateRate
LeftIndexMax VBAProjectObject SubObject Description

Chapter 3

Project Development

This table describes the parameters in the Displays tab.

Description
The name of the display. Double-click to configure a unique name for the display. Specifies the content of the display title bar.

Sets the left edge of a display to the number of units specified from the left edge of the screen. Sets the top edge of a display to the number of units specified from the top edge of the screen. Sets the width of a display. Sets the height of a display. Sets the background color of the display. Identifies the security class of the screen. Defines the amount of time to update a display in response to an event. Default setting is 1.0 seconds. For best performance set to .1 seconds. Identifies the maximum number of entries in the left index. Adds a VBA item to the FactoryTalk View SE display. Click the ellipsis (...) button to select a VBA item.
Provides a unique description of the display sub-object.

Generate an HMI object

See also
Add a Display sub-object on page 34
Once a HMI display object has been configured it can then be used to generate an import file for use with FactoryTalk View SE or FactoryTalk View ME. This file is an Extensible Markup Language (.xml) file.

To generate an HMI object file
1. In the System View pane, expand the HMI folder and the display category folder so that the objects are visible.
2. Right-click the object to export.
� For FactoryTalk View objects, select Generate Displays and then click All Displays to create an export file that supports all display types.
� For Alarms objects, select Generate Alarms and then click a specific controller from the list if this object will only be used with that type of controller or click All Controllers if this object will be used with all project controllers.
The Save As dialog box opens.
3. Use the tree control to browse to the location in which to save the HMI object file or use the default location:
C:\Users\<user name>\Documents\Studio 5000\Projects
The variable <user name> is replaced by the logged in user account name.
4. In File name type a name for the file or use the default file name which is created according to the following pattern:
<Controller Name>_<Object Name>.csv

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 3

Project Development

The controller portion of the default file name and the underscore are omitted when the All Controllers option is selected. For Alarms objects the variable <Controller Name> is replaced by the name of the controller selected if a specific controller was selected. FactoryTalk View objects are not controller specific.
5. Click Save. The HMI object generation is started. 6. Once the process is completed, the Generation Complete status dialog
box appears, click OK to close the dialog box.

Add an Alarm Group subobject

See also
Add a new HMI object on page 33
FactoryTalk Alarm and Event objects have sub-objects that represent the Alarm Groups configured in the FTAE system. In FactoryTalk Alarm and Events, alarms can be assigned to groups. A group represents a set of alarms with a common association. An alarm group can contain other groups organised in a hierarchy (FTAE only supports to 5 levels deep).

To add an Alarm Group sub-object
1. In the System View pane, expand HMI, expand Alarms and then click the FactoryTalk FTAE object to which the sub-object will be added.
2. In the object parameters pane, select the Alarm Group tab. 3. Right-click in the white space below the objects shown in the tab. Click
Add New.
Repeat this step to add all of the Alarm Group that require configuration.
4. An alarm group hierarchy is achieved by associating one alarm group to another using the ParentAlarmGroupID parameter.
5. Click the appropriate column and modify the parameters as needed. 6. Click Apply Changes to save the parameter configuration.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

FTAE Alarm Group parameters
Parameter Name
AlarmGroupID ParentAlarmGroupID AlarmGroup SubObject Description

See also

Chapter 3

Project Development

Add an HMI object on page 33

FTAE Alarm Group parameters on page 37

Generate an HMI object on page 35

The Alarm Group tab displays a columnar grid of the parameters defined for the alarm groups of the FactoryTalk Alarms and Events object.

This table describes the parameters in the Alarm Group tab.
Description
The name of the sub-object representing the Alarm Group (this is not the name that will be used in the FTAE system). Through name formatting a unique sub-object name is built up from the AlarmGroup and ParentAlarmGroupID parameters. Each AlarmGroupID must be unique (0 is reserved for the FTAETagServer ID). The ParentAlarmGroupID determines the alarm group hierarchy (Default: 0 = FTAETagServer ID). The alarm group name that will created in the FTAE system and assigned to FTAE alarm tag objects that reference it. Provides a unique description of the alarm group sub-object.

Find an object

See also
Add an Alarm Group sub-object on page 36
Use the Find dialog box to search for an object or a library in the Class View pane, contents in the Controller Preview tree, or a library in the Registered Libraries tree.

To find an object
1. On the toolbar, select EDIT > Find. 2. In Find what, enter the name of an object. 3. In Look in, select Class View, Controller Preview, or Registered
Libraries. 4. (optional) In Find Options, select the check boxes of Match case and
Match whole word. 5. Select Find Next or Find Previous.

Update a project library

See also
Project Development on page 27 Update a project library on page 37 Any of the libraries used in a project can be updated to incorporate additions or modifications to library components. If Newer Library Version Available is enabled in Application Code Manager settings, indications appear next to objects that can be updated.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 3

Project Development

To update a project library
1. In the System View pane, expand Used Libraries to see the library branches. Library versions are shown in parenthesis.
2. Right-click the library branch to be updated and then click Update.
The Update Used Libraries dialog box is displayed.
3. A tab is shown for each library in the selected library branch. Libraries with available updates will have different revisions.
If multiple libraries are included in the library branch, click the tab for the library to update. Each library tab has three sub-tabs.
4. In Update Library Revision, click the drop-down arrow to select the new revision number for the library.
5. Click the Library Changes sub-tab to review the parameter changes for the new version.
6. Click the Objects to Update sub-tab to define which objects in the library are to be updated.
� Under Update, select the checkbox to update the project objects that reference this project library.
� Clear the checkbox for each object that should not be updated.
7. Click the Relink References to Removed Items sub-tab and select the parameters and sub-parameters to relink to the objects that are affected by this update.
8. Click Finish.

Extract attached files

See also
Upgrade the Application Code Manager application on page 16
Library objects on page 11
Indications on page 39
Files attached to a project, Historian object, HMI display, FactoryTalk Alarms and Events server, controller, library, or library object can be extracted to a folder of your choice. When extracting the attachments from the various scopes in a project, all the objects within the scope have their attachment include conditions evaluated and only those attachments that evaluate to true will be extracted to their relative path. If the relative path is parameterized, the path will be resolved. If the resolved path is invalid, the attachment will be extracted to the root extraction folder. Attachments that are the same, but have a different relative path will be extracted into each of the relative paths. Attachments that already exist at the relative path will be overwritten.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 3

Project Development

To extract attached files in System View

1. In System View, right-click on one of the following, then select Extract Attached Files:
� The ACM project � A Historian object � An HMI display � A FactoryTalk Alarms and Events server � A controller or controllers � A library � A library object
2. In Browse for Folder, select a folder where the files should be extracted, then select OK.

To extract attached files in Registered Libraries
1. In Register Libraries, right-click an object or its descendant objects with an attachment, and then select Extract Attached Files.
2. In Browse for Folder, select a folder where the file should be extracted or create a new folder, and then click OK.

To extract attached files in Class View
1. In Class View, right-click an object or its descendant objects with an attachment, and then select Extract Attached Files.
2. In Browse for Folder, select a folder where the file should be extracted or create a new folder, and then click OK.
When you extract an attachment in Class View, if the extraction path of an attachment in the library is configured as {ObjectName}\Folder1\Folder2 by an expression in Library Object Manager and the Object instance is "XV100", then upon extraction of the attachment the extracted relative path will be XV100\Folder1\Folder2.

See also

Project Development on page 27

Indications
Indication

If Modified Objects or Newer Library Version Available is enabled in Application Code Manager settings, indications appear next to objects that have been modified or libraries that can be updated.
Description
This object has been modified since controller was last generated. The flag will be reset once the controller is generated. Class View: This library has a newer version available in Registered Libraries. Registered Libraries: This library has a newer version available in the configured Library Repositories.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 3

Project Development

Indication

Description

This node or folder contains one or more libraries that has a newer version available in Registered Libraries.

See also
Update a project library on page 37 ACM Default Settings on page 79

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Registered Libraries

Chapter 4

Registered Libraries
Command Registered Library Register Get updates View > Pending Libraries View > Library Usage

Registered Libraries displays all libraries (classes) in the connected ACM database in a tree view. Add a library to an ACM project to use the objects in it with your project.
A library object defines parameters, subclasses, user interface contents, and portions of controller code (example: Logix) and HMI code (example: FactoryTalk View SE/ME). It can also include custom properties that were applied using the Library Designer.
The library nodes on the Registered Libraries tree will show an indication if any of the selected library repositories contain a library with the same solution and catalog number but a higher revision number.
Right-click any branch in the Registered Libraries tree view to view the commands available.
This table describes each command. Commands appear at the applicable level of the tree.
Description
Used when a library object is provided as a HSL4 file and needs to be incorporated into ACM. Registers one or more library files (HSL4). Updates a library object to a newer version. Notifications appear when Newer Library Version Available in the ACM Default Settings is selected. Displays a report showing Database Pending Libraries report. Available only at the Registered Libraries branch. Displays a report showing the Registered Library usage for the libraries in the connected ACM database.

Export Extract Attached Files Reconstitute ACD Delete
Delete all unused

Exports the selected library to an HSL4 (xml) formatted file to a folder, the destination folder is automatically opened. Extracts the attached files in the selected library to a folder, the destination folder is automatically opened. Opens the ACD Re-constitution Wizard. Deletes the selected library in the connected ACM database. Libraries that are used in projects cannot be deleted. If the library selected for deletion is in use, a Global Library usage report is displayed instead. Deletes all unused libraries for the selected level in the connected ACM database.

Refresh ACM Library View > Pending Libraries per Solution
View > Library Usage per Solution
View > Pending Libraries per Library Type
View > Project Library Usage per Library Type
View > Pending Libraries per Category

Refreshes the tree view.
Displays a report showing the registered library usage for the pending libraries in the selected solution. Available only at a solution branch. Displays a report showing the registered library usage for the libraries in the selected solution. Available only at a solution branch node. Displays a report showing the registered library usage for the selected pending library type. Available only at a library type branch node. Displays a report showing the registered library usage for the selected library type. Available only at a library type branch node. Displays a report showing the registered library usage for the selected pending library category. Available only at a library category branch node.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 4

Registered Libraries

Command

View > Library Usage per Category

View > Library Usage per Library

Description
Displays a report showing the registered library usage for the libraries in the selected library category. Available only at a library category branch node. Displays a report showing the registered library usage for the selected library. Available only at a library branch node.

See also
Register an ACM Library on page 42 Reconstitute the ACD on page 42 View registered library usage on page 43 Share libraries, templates, and schedules on page 44 Register an ACM library object to use it in a project.
Prerequisites
� Verify that the ACM application is connected to the correct ACM database.
Tip: The connected database is shown in parenthesis in the Application Code Manager title bar.

To register an ACM library object
1. In the Register Libraries tree, right-click the library object to register. 2. Click Register. 3. The Libraries Registration window opens. 4. Review the information provided in the Library Registration window.
Perform any indicated actions. 5. Click Finish to complete the registration process.

Reconstitute an ACD file

See also
View registered library usage on page 43 Share libraries, templates, and schedules on page 44 Connect to an ACM database on page 21 Reconstitute the ACD on page 42 Reconstitute an ACD file when the original Logix Designer project used to create the object is not available for editing. After reconstituting the ACD file, it can be edited using Logix Designer. Hardware module libraries and ACM v1.x libraries do not support this feature.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 4

Registered Libraries

To reconstitute an ACD file

1. In the Registered Libraries tree view, right-click the library file(s).
To select multiple files hold down the <Ctrl> key and select the library files.

2. Click Reconstitute ACD. The ACD Reconstitution Wizard opens.
3. The Object Configuration page displays the details of the objects to be included in the ACD file. Click Next.
4. The Resolve Dependencies page displays any dependencies between the library objects that must be resolved.

� Click Add Dependency Library and add the library that contains required add-on instructions (AOIs) or user-defined data types (UDTs).
� Click Next.
5. The Unresolved Names page displays any objects that have unresolved name value. Click in the Value column and type valid values for any names highlighted on the page then click Next.
6. The L5X Generation Successful page displays a preview of the Logix content contained in the ACD file displays.
7. Click Next to display the Save As screen. In File name type a file name for the ACD file.
8. Click Save to save the file. The ACD successfully saved message displays with a link to open the folder where the file was saved.
9. Click Finish to close the wizard.

View registered library usage

See also
Add a controller from an ACD or L5X file on page 51 Update using an ACD or L5X file on page 51 Detach from ACD/L5X files on page 53 There are several different reports that provide information about registered library usage. Determine the scope of the report by navigating to the level of interest and then generate the report.

To view registered library usage
1. Select the scope of the report. � To generate a report that includes all of the registered libraries in the connected ACM database:

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 4

Registered Libraries

Right-click Registered Libraries, then point to View, then click Library Usage.
� To generate a report that includes all of the registered libraries used in a solution:
In the Registered Libraries tree, right-click the solution folder, then point to View, then click Library Usage per Solution.
� To generate a report that includes all of the registered libraries used in a library type:
In the Registered Libraries tree, expand the solution folder, rightclick the library type folder, then point to View, then click Library Usage per Library Type.
� To generate a report that includes all of the registered libraries used in a library category
In the Registered Libraries tree, expand the solution folder, expand the library type folder, right-click the library category folder, then point to View, then click Library Usage per Library Category.
� To generate a report that includes all of the registered libraries used for a library object
In the Registered Libraries tree, expand the solution folder, expand the library type folder, expand the library category folder, right click the library object then point to View, then click Library Usage per Library.
2. The selected report appears in a new window.

Share libraries, templates, and schedules

See also
Reports on page 109
Generate a report on page 111
All libraries in the Registered Libraries tree are available to all ACM users that are connected to the ACM database.
Schedule templates can be created that are limited to just a specific user account. If a template that is limited to a user account needs to be shared with other users, use Import/Export Manager to either copy or move the template from the users folder to the central ACM database.
ACM Program folder templates can be shared by placing the template files in a shared network folder.
Project data that can be reused in multiple ACM projects can be exported to a schedule and shared by placing the Schedule file in a shared network folder.
To avoid the possibility of ACM users overwriting each other's work in a central ACM database, ACM users should work in differnt projects or

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 4

Registered Libraries

branches of the same project tree view. Project work can be divided by function (example: Controller Hardware, Controller Software, HMI, Historian) or by area (example: Receiving, Mixer, Shipyard).

Use the partial export option to avoid exporting the same data to more than one schedule. If the same data is imported from more than one schedule, the last schedule imported will determine the data.

To help ensure that work is not lost, export a project schedule periodically for backup.

Local library and template file location

See also
Import Export Manager on page 61
Local library and template file location on page 45
By default library object files and template files are stored in this location:
C:\Users\Public\Public Documents\Rockwell Automation\Studio 5000
There are separate Libraries and Templates folders with an Application Code Manager subfolder in each. The library object repositories, (RA-LIB) ACM and (RA-LIB) Process, and the template repository, (RA-TPL) ACM, are located in their respective subfolders.
The (RA-TPL) ACM folder is set as the default documentation path for the Application Code Manager application. To change the documentation path open ACM Default Settings and specify the path to use.
Tip: If working in a collaborative design environment with a shared ACM database, template files can be copied to a shared folder so that all users can access them.

Library Repositories

See also
Initial configuration of Application Code Manager on page 15
Registered Libraries on page 41
ACM Default Settings on page 79
Library Repositories displays the configured library repositories. A library repository refers to another ACM database that can monitored for library updates. Libraries from these source databases can be easily replicated over to the currently active database for use within a project. It is unavailable to create an object directly from a library in a library repository. The library must first be replicated to the current active ACM database before it can be used to create an object. Add or remove library repositories in this pane.
Click View and select Library Repositories to open this pane.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 4

Registered Libraries

Command
Library Repositories Replicate to Active Database
Export Extract Attached Files Disable All Add Remove All Refresh Library repository nodes Replicate to Active Database
Export Extract Attached Files

Right-click any branch in the Library Repositories tree view to view the commands available.
This table describes each command. Commands appear at the applicable level of the tree.
Description
Loads the Available Libraries form to select libraries to copy or register to the current active ACM database. Exports the Library Repositories to an HSL4 (xml) formatted file. Extracts the attached files to a folder. Disables all update status checking of the databases. Adds a library repository. Removes all library repositories. Refreshes all library repositories.
Loads the Available Libraries form to select libraries to copy or register to the current ACM database. Exports this library repository to an HSL4 (xml) formatted file. Extracts the attached files of this library repository to a folder.

Disable Remove Connect Refresh Solution, library type, and category branch Replicate to Active Database
Export Extract Attached Files Refresh Catalog number node Replicate to Active Database
Export Extract Attached Files Refresh

Disables update status checking of this database. Removes this library repository. Sets this database as the current active database. Refreshes all contents in this library repository.
Loads the Available Libraries form to select libraries to copy or register to the current active ACM database. Exports this branch to an HSL4 (xml) formatted file. Extracts the attached files of this branch to a folder. Refreshes all contents in this branch.
Loads the Available Libraries form to select libraries to copy or register to the current active ACM database. Exports this library to an HSL4 (xml) formatted file. Extracts the attached files in this library to a folder. Refreshes this node.

See also
Register an ACM library object on page 42 Reconstitute an ACD file on page 42

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Configure controllers

Chapter 5

Configure controllers
Command Controller � Generate Controller
� Add New � Add New from ACD/L5X
� Update from ACD/L5X � Detach from ACD/L5X � Merge Controller
� Add New Program � Add New Task � Paste � Paste Special � Generate Partial Program
� Generate Partial Routine � Move Up � Move Down � Set Main Routine
� Set Routine Instance Order
Object � Import � Export � Delete � Copy � Rename � Update View � Project Library Usage per Library � Network Layout � Module I/O Schedule for Rack Module � Chassis Layout
� Add New Instance � Navigate to Library � Object References

Right-click any controller branch in the Controller Preview or Class View pane to view the controller configuration commands.
This table describes each Controller command. Commands appear at the applicable level of the tree.
Description
Generates a copy of the selected controller from ACM. Displays the Logix Code Generation dialog box. Generates code (example: L5X or ACD) for the selected controller. Adds a new controller object to the project using the Object Configuration Wizard. Adds a new controller object to the project from an ACD or L5X file. Additional objects may also be added depending on what is configured and available in the ACD file. Updates the ACM project based on an existing ACD file. Removes the link between the ACM project and the attached ACD or L5X file. Merges content between the original ACM project, updated ACM project, and existing ACD or L5X file. Utilizes the Logix Designer Compare Tool. Adds a new program to the current controller object using the Object Configuration Wizard. Adds a new task to the current controller object using the Object Configuration Wizard. Pastes the contents of the clipboard to the selected controller. Pastes the contents of the clipboard to the selected controller with options. Displays the Logix Code Generation dialog box. Generates a partial program for the selected task.
Displays the Logix Code Generation dialog box. Generates a partial routine for the selected task. Moves the highlighted object up the tree. Moves the highlighted object down the tree. This command is available when multiple main routines have been added from different library objects. There can only be one main routine. If a main routine is already selected this command is dimmed. Displays the Instance Execution Order dialog box which specifies the order in which any contributing objects insert their code into the routines.
Starts Import Export Manager. Starts Import Export Manager. Deletes the selected object. Copies the selected object to the clipboard. Renames the selected object. Updates the selected libraries to the most recent version.
Displays a report showing the registered library usage for the selected library. Available only at a library branch. Generates Network Layout report. Displays the I/O Schedule showing rack assignments. Displays or prints a report with the I/O Modules in the Controller (local) chassis. Pastes the contents of the clipboard to the selected Controller with options. Adds a new task in the Class View pane. Navigates to the library in the Registered Libraries tree. Displays the Object References report.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 5

Configure controllers

Command

� Exclude AOI (Add On Instructions)

� Include AOI (Add On Instructions) � Refresh

Description
Excludes the AOI (included by default). Only available in the Add-On Instructions branch. When two AOIs with same major and minor revision, but different extended text are added in the Controller Preview tree, AOI conflict shows. You can use Exclude AOI to select which one to use. Includes the AOI. Only available in the Add-On Instructions branch. Refreshes the tree view.

Generate a controller file

See also
Generate a controller file on page 48 Merge controllers on page 53 Add a hardware module on page 54 Add a new software object to a controller on page 56 After configuring a controller in Application Code Manager, generate the Logix Designer files for the controller.

To generate a controller file
1. In the Controller Preview or Class View pane, right-click the Controller folder or the controller object and then click Generate Controllers.
2. In the Logix Code Generation dialog box, select the Generate and ACM Project Data check boxes.
� Select the Overwrite Existing check box to replace an earlier controller file with the same name.
� Select Create ACD to create a Logix Designer Project file (.ACD) in addition to the Logix Designer XML file (.L5X).
IMPORTANT Generating controller files with ACM Project Data selected produces the most complete record of the controller data. Always select ACM Project Data when generating a controller file as part of a disaster recovery backup. If there is not a matching Studio 5000 Logix designer version installed and the SoftwareRevision is selected, the Create ACD checkbox is disabled.
3. In Save Path, type the path where the controller files should be saved or use the default path:
C:\Users\<user name>\AppData\Local\Rockwell Automation\Application Code Manager\Output
The variable <user name> is replaced by the logged in user account name.
4. Click Generate.
The controller files are generated. A status message displays when completed.
5. (optional) Click Open Folder to open the file explorer to the controller file location.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Add a new controller

See also

Chapter 5

Configure controllers

Navigate the Application Code Manager user interface on page 17

Generate a partial program on page 57

Generate a partial routine on page 58

Use the Object Configuration Wizard to add a controller from a predefined controller library that resides in the registered libraries, configure its parameters, and include it in the ACM design output.

Note: The ability to add multiple controllers to a project or open an existing project containing multiple controllers is only available if the product has a Standard activation license and is not available in Lite mode.

To add a controller
1. In the Controller Preview or Class View pane, right-click the Controllers folder and then click Add New.
The Object Configuration Wizard displays. Controller objects display in category groups. A triangular marker next to the column name denotes the current category grouping displayed. Change category groups by clicking a column heading.
2. Click the + symbol to expand a category and display the controllers in that group.
Controllers registered in the connected ACM database are listed.
3. Click the desired controller and click Next. 4. In Name, enter a name for the controller. 5. (optional) In Description, modify the descriptive text as needed to help
identify the controller. 6. In the Parameters tab, adjust Controller, HMI, Historian, and Motion
parameters as needed. 7. Click Finish.
The controller adds to the Controller Preview and Class View trees.

See also

Connect to an ACM database on page 21

Add a controller from an ACD or L5X file on page 51

Update using an ACD or L5X file on page 51

Move or copy a controller to For projects in the same database, Copy To and Move To allow you to copy or

another project

move a controller from one project to another project from the Class View pane.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 5

Configure controllers

Note: This feature is only available if the product has a Standard activation license and is not available in Lite mode.

To move or copy a controller to another project
1. In the Class View pane, expand Controllers. 2. Right-click the controller that will be copied or moved to another
project.
� Select Copy To.
When selecting Copy To, the controller will be copied and pasted to the destination project.
� Select Move To.
When selecting Move To, the controller will be cut and pasted to the destination project. When the controller has unresolvable references, they will be cleared.
3. In Select Destination Project, select an existing project or create a new project as the destination project.
When there are name conflict between the moved controller and the controller in the existing project, rename the destination controller in Rename Destination Controller.
4. Click OK. � When prompted, select OK. � Once the Log File Viewer opens, track the errors, warning, informational, and debug events.

Select Destination Project dialog box
Options
Name Description New OK Cancel

See also
Configure controllers on page 47
Select Destination Project dialog box on page 50
Add a new controller on page 49
The following table shows the options in the Select Destination Project dialog box.
Descriptions Displays the name of the destination project. Displays the description of the destination project. Opens the Object Configuration Wizard dialog box to create a new project. Starts the copying or moving process. Returns the home page.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

See also

Chapter 5

Configure controllers

Move or copy a controller to another project on page 49

Configure controllers on page 47

Add a controller from an ACD Add controllers to the Application Code Manager project from an existing

or L5X file

Logix Designer XML file (.L5X) or Logix Designer Project file (.ACD).

To add a controller from an ACD or L5X file
1. In the Controller Preview or Class View pane, right-click the Controller folder and then click Add New from ACD/L5X.
2. In the Select an ACD/L5X File dialog box, select the file to add then click Open.
3. In the Import From ACD Wizard - Instance Import Actions page review the items listed. Items with Add in the Action column are imported.
4. If any objects should not be imported, click Add and then select Exclude.
5. Select Next. The Import dialog displays. The information grid shows any errors, warning, info, or debug messages generated during the import. Review any warnings or errors listed.
� Click View Changes to see a comparison of the original and updated information in an Excel spreadsheet.
� Information buttons show how many of each type of message are present. Filter the displayed messages by clicking the button for the message type to toggle the display of those messages.
6. Select Next. The Import From ACD Wizard - Content Imported page displays.
7. Select Finish.
The new object will appear in the Controller Preview pane and Class View pane.

See also

Update using an ACD or L5X file on page 51

Detach from ACD/L5X files on page 53

Merge controllers on page 53

Update using an ACD or L5X Update controller configurations in an Application Code Manager project

file

using information from a Logix Designer XML file (.L5X) or a Logix Designer Project file (.ACD).

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 5

Configure controllers

To update a controller using an ACD/L5X file
1. In the Controller Preview or Class View pane right-click the controller to update and select Update from ACD/L5X.
2. In Select an ACD/L5X File choose the ACD or L5X file to use to update the controller
The Import from ACD Wizard - Instance Import Actions page displays.
� Objects that are present in the file but not in the target controller will be selected to be added by default. If any of these objects should not be added select Exclude from the Action column.
� Objects that already exist in the target controller will default to being excluded from the update. If any of these objects should be updated using the information in the file select Update from the Action column.
Note: When excluding an object, information in the ACM project is preserved. When an update is performed, information from the ACD or L5X overwrites the ACM project information.
3. Select Next. The import operation proceeds. After the operation is finished the Import Complete page displays. The information grid shows any error, warning, info, or debug messages generated during the import. Review any Warnings or Errors listed.
� Click View Changes to see a comparison of the original and updated information in an Excel spreadsheet.
� Information buttons show how many of each type of message are present. Filter the displayed messages by clicking the button for the message type to toggle the display of those messages.
4. Select Finish. The Import From ACD Wizard - Content Imported dialog appears. If one or more objects are set to update, then Update the Original Snapshot will be checked by default. Clear the check box to prevent the snapshot information from updating the current configuration and then click Finish to close the wizard.
Note: Snapshot information is used for the original ACM project data when performing the merge. If all items are excluded, by default Update the Original Snapshot is not checked.
5. If Update the Original Snapshot was selected click Next. The Import From ACD Wizard - Original Snapshot Updated confirmation page displays, click Finish to close the wizard.

See also
Detach from ACD/L5X Files on page 53 Reconstitute an ACD file on page 42 Generate a controller file on page 48

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Detach from ACD/L5X files

Chapter 5

Configure controllers

If a controller is updated using an ACD or L5X file then the controller will maintain an attachment to that file. The next time ACM is started, the ACM application will attempt to establish a connection to the file. Depending on file systems, file size, and file location establishing a connection to an ACD or L5X file may take more time than expected. If needed, the ACM application can detach the file from the controller.

To detach from an ACD/L5X file
� In the Controller Preview or Class View pane, right-click the controller to which the file is attached to and then select Detach from ACD/L5X.

Contribute instances

See also
Merge controllers on page 53 Update using an ACD or L5X file on page 51 Add a controller from an ACD or L5X file on page 51 Use Contributing instances to view and edit the properties of an object instance.

To contribute an instance
1. In the Controller Preview pane, expand Controllers. 2. Right-click a node shared by multiple instances, and then select
Contributing instances. A list of contributing instances is shown. 3. Select an instance. Its parameters property panel opens.

Merge controllers

See also
Configure controllers on page 47 Add a new instance on page 56 Use Merge Controller to add or update objects from an ACM project into the attached ACD file.

To merge controllers
1. In either the ClassView or Controller Preview pane right-click the object to merge.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 5

Configure controllers

2. Select Merge Controller. The Logix Designer Compare Tool will be launched.
Refer to the Logix Designer Compare Tool help files for further information.
Note: After the merge file has been created, confirm all information is correct prior to deploying.

Add a hardware module

See also
Generate a controller file on page 48 Add a hardware module on page 54 Add a new software object to a controller on page 56 Add hardware modules to your controller configuration in the I/O Configuration branch in the Controller Preview pane.

To add a hardware module
1. In the Controller Preview pane, expand the Controllers node, expand the controller object, expand the I/O Configuration folder and then right-click Backplane and then click Add New.
The Object Configuration Wizard displays.
2. Click the + symbol to expand the library category and display the hardware module libraries registered in the connected ACM database.
3. Select the library that will be copied to create the new hardware module and click Next.
4. (optional) In Description, type a unique description of the hardware module or accept the default description.
5. Click Finish.
The hardware module object appears in the Controller Preview pane under Backplane.

Delete a hardware module

See also
Use Copy and Paste Special on page 55 Add a new instance on page 56 Add a new software object to a controller on page 56 If a module is no longer relevant to the application it can be deleted from the project.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 5

Configure controllers

To delete a module

1. In the Class View pane, right-click the module and then select Delete. 2. In the Delete dialog box, click Yes to confirm that the module should
be deleted. 3. If the object is referenced by other objects the Delete Action dialog box
displays.
a. Click Clear to remove all references to the module being deleted.

b. Click OK to delete the module.

The module is removed from the Class View and Controller Preview panes.

See also

Add a hardware module on page 54

Use Copy and Paste Special

Copy and Paste Special provides the ability to decide whether to include children, sub-objects, and reference values when pasting a copied object. If an object is simply pasted all of the associated items are copied and pasted along with the object. The Copy and Paste Special command is only available from the Class View pane.

To use Copy and Paste Special
1. Select the object that will be copied to create the new object. Right-click and click Copy.
� Right-click the destination of the copied object and click Paste Special.
� Select the branch where the object will reside. Right-click and click Paste Special.
2. The PasteSpecial dialog box displays.
� Select the Include Children check box to include Communication Module Children.
� Select the Include Sub-Objects check box to include I/O Module Sub-Objects (example: Channels).
� Select the Include IO Reference Values check box to maintain references to I/O objects.
� Select the Include Non-IO Reference Values to maintain references to other types of objects
3. Click Paste. 4. The Rename dialog displays. The object names that must be changed
to prevent a naming conflict are shown in red.
� Enter a new name when a naming conflict exists. When there are no conflicts, the name is black in color.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 5

Configure controllers

� Click OK to paste the object.

Add a new instance

See also
Delete a hardware module on page 54 Configure controllers on page 47 Use Add a new instance to add a new library object instance to an existing library class in the Class View.

To add a new instance
1. In the Class View pane, right-click the library class from which the new instance will be created and then click Add New Instance.
The Object Configuration Wizard is displayed.
2. (optional) In Name, type a new name for this instance. 3. (optional) In Description, type identifying information about this
instance. 4. Configure the associated Task and Program. 5. Click Finish to add the new instance.

Add a new software object to a controller

See also
Configure controllers on page 47 Add a new software object to a controller on page 56 Add re-usable code for software objects (tasks, routines and programs) to the controller from the Application Code Manager library.

To add a new software object to a controller
1. Use one of the following methods:
� In Controller Preview, expand Controllers, expand the controller object, right-click a task or program object, then click Add New.
� In Class View, expand Controllers, right-click the controller object, then click Add New.
2. In the Object Configuration Wizard, expand the library categories to display the software libraries registered in the ACM database.
3. Select the library object to add to the selected task or program, then select Next.
4. (optional) In Description, type a unique description of the software or accept the default description.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 5

Configure controllers

5. (optional) Edit software object parameters and fields in the tabs on the bottom half of the Object Configuration Wizard.
6. (optional) If the software object depends on other linked library objects, select the Linked Libraries tab, then select Auto Create Linked Objects. Select linked library creation options, then click OK.
7. Select Finish.

The software object appears in the Controller Preview and Class View panes.

See also
Generate a partial program on page 57 Generate a partial routine on page 58 Object Configuration Wizard on page 58 Auto Create Linked Objects on page 59
Generate a partial program Generate Partial Program exports a Logix Designer XML file (L5X) that can
be imported into the Logix Designer as a program.

To generate a partial program
1. In the Controller Preview pane, expand Controllers, expand the controller object, right-click the program object to export and then click Generate Partial Program.
The Logix Code Generation dialog box displays.
2. (optional) To rename the file click in the Save As field. The text box becomes editable and the current file name is highlighted. Type the new file name.
3. Verify that the Generate and ACM Project Data check boxes are selected.
� Select the Overwrite Existing check box if you want to replace an earlier file with the same name.
The Create ACD option is disabled. Partial program and routine items can only be generated using .L5X files.
4. In Save Path, type the path where the exported files should be saved or use the default path:
C:\Users\<user name>\AppData\Local\Rockwell Automation\Application Code Manager\Output
The variable <user name> is replaced by the logged in user account name.
5. Click Generate.
The files are generated. A status message displays when completed.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 5

Configure controllers

6. (optional) Click Open Folder to open the file explorer to the file location.

Generate a partial routine

See also
Generate a partial routine on page 58 Generate Partial Routine allows you to create an export file (L5X) that can be imported into the Logix Designer as a routine.

To generate a partial routine
1. In the Controller Preview pane, expand Controllers, expand the controller object, right-click the routine object to export and then click Generate Partial Routine.
The Logix Code Generation dialog box displays.
2. (optional) To rename the file double-click in the Save As field. The text box becomes editable and the current file name is highlighted. Type the new file name.
3. Verify that the Generate and ACM Project Data check boxes are selected.
� Select the Overwrite Existing check box if you want to replace an earlier file with the same name.
The Create ACD option is disabled. Partial program and routine items can only be generated using .L5X files.
4. In Save Path, type the path where the exported files should be saved or use the default path:
C:\Users\<user name>\AppData\Local\Rockwell Automation\Application Code Manager\Output
The variable <user name> is replaced by the logged in user account name.
5. Click Generate.
The files are generated. A status message displays when completed.
6. (optional) Click Open Folder to open the file explorer to the file location.

See also
Add a new instance on page 56
Object Configuration Wizard How do I open the Object Configuration Wizard?
Use one of these methods:

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 5

Configure controllers

� In Controller Preview, right-click a folder, task, program, or I/O configuration node in the project, then select Add New, Add New Task, or Add New Program.
� In Class View, right-click the project or library, then select Add New or Add New Instance.

Use the Object Configuration Wizard to add a library object, program, or task to a project. The Object Configuration Wizard consists of two pages, the Select a Library page and the Parameters page.

� Select a Library displays the latest revisions of library objects, separated by category. Select Show All Revisions to display all revisions. To quickly search for a library, enter criteria in Filter.
� Parameters displays the name, description, and configuration parameters for a library object, program, or task. Parameters may be broken up into object-specific tabs, such as SubObjects, Linked Libraries, or Interface Links. Editable fields appear black, non-editable fields appear gray.
Note: If a library object contains links to other linked library objects, these objects can be created automatically. Select the Linked Libraries tab (if applicable), then select Auto Create Linked Objects.

See also

Add a new software object to a controller on page 56

Auto Create Linked Objects on page 59

Auto Create Linked Objects

How do I open Auto Create Linked Objects?
1. In Controller Preview, expand Controllers, expand the controller object, right-click a task or program object, then click Add New.
2. In the Object Configuration Wizard, expand the library categories to display the software libraries registered in the ACM database.
3. Select the library object to add to the selected task or program, then select Next.
4. If the software object depends on other linked library objects, select the Linked Libraries tab, then select Auto Create Linked Objects.
Use Auto Create Linked Objects to add objects linked by a library object to a project, rather than manually adding them to the project one at a time.

Column Link Name
Library

Hardware modules cannot be Auto Created but can still be linked to if they already exist in the project.
Description
Displays the name of the link in the object being added to the project. Auto Create Linked Objects uses the link name to find a matching library. Displays the name and version of a library that matches the link name. The latest version of the library is always used if the version was not specified. If an exact library match cannot be found, the Library column displays "No unique library matches link criteria". The Action field is locked to Ignore.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 5 Column Action

Configure controllers
Description
Sets the action that Auto Create Linked Objects should take for the linked library: � Create New: Creates a new library object with the parameters from the matched library object. � Use Existing: Uses the matched library object. � Ignore: Does not create or use the linked library object. Mandatory linked libraries cannot be set to Ignore. Select multiple linked objects and use the action list to sets the action to these objects.

Object Name Task Name Program Name

Browse for an existing object name or set the auto created library object name. Disabled if the library object is parameterized. When an exact match library is found, the match icon displays beside the object name.
Assigns the auto created library object to a task. Create a new task by selecting <Add New...>. Disabled if Action is set to Use Existing or Ignore. Select multiple auto created library objects and use the task name list to assign these objects to one task. Assigns the auto created library object to a program. Create a new program by selecting <Add New...>. Disabled if Action is set to Use Existing or Ignore. Select multiple auto created library objects and use the program name list to assign these objects to one program. The program name list is disabled if these objects are unassigned.

See also
Add a new software object to a controller on page 56 Object Configuration Wizard on page 58

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Use ACM Tools

Chapter 6

Use ACM Tools
Tool Import Export Manager
Database Manager Plugins Log Debug Information
Log Viewer Settings Document Template Editor Open Target ACD

Use Application Code Manager tools to assist in reusable code development and management.
This table describes each of the tools.
Description
Use to import or export ACM project content between Excel spreadsheets (Schedule). Use for bulk additions, duplications, changes; comparing versions; snapshots; backup customer parameter entry, and/or transferring project contents. Use to create, delete, upgrade, back up, and restore ACM databases. Add capabilities to Application Code Manager by installing plugins through the Tools > Plugins command. Choose to include debug information in the ACM Log File to help with troubleshooting applications. Information is written to the ACM log file when design outputs are generated (example:<CLX>, FactoryTalk View, FactoryTalk Historian, Word) or when schedules are imported or exported. Use to view the contents of the most recent ACM log file. A new ACM log file is created for each ACM session. Use to set the location of the system documentation, the language, and the default settings for Control Logix controllers. Use to develop and test document generation templates. Opens the directory and allows navigation to the ACD file location. Use to instantiate library content into an existing file, versus creating a new ACD file.

See also

Import Export Manager on page 61

Database Manager on page 73

ACM Default Settings on page 79

Add ACM library content to an existing ACD project on page 107

Import Export Manager

The Import Export Manager imports and exports ACM project content to and from schedules using the Excel file format (.xlsx and .xlsm). Schedules include the scope of the project (example: Project, Controller, Task, Program, Object, Tag) and content for the project (example: Device List, Device Interlocks).

The Import Export Manager has the following controls:

Control Menu Bar Project:

Description Includes a File menu for identifying the current project and a Tools menu for setting up templates and configuring logging. Displays the name of the current project selected. If creating a new project, this must be a unique name.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

Control

Description

Import Tab Export Tab

Specifies what effect the import will have on the target project and the location of the schedule to import. � New - Creates a new project using the specified project name. � Replace - Overwrites the specified project with the project being imported. � Update - Merges the information being imported into the project specified. � Auto Continue - Continues the import process automatically. � Excel File - Enters the path to the schedule Excel file (.xlsx) to import or select the ellipsis to browse to the file location. � Open Backup Folder - Opens the ACM backup folder. � Backup original - Creates a backup of the original project. Defines the scope and details of the export schedule. � All Projects - Exports all projects in the connected ACM database. � Complete Project - Exports the currently specified project. � Partial - Exports only specific objects and parameter values. To specify the objects to include in the export select the appropriate values
from the Type and Controller drop-down menus. � Use Template - Limit the content of the schedule to either:
Local - Locally available devices. Project - Devices used in the project being exported. Global - All devices in the library. � Show Modified - Color codes "changed" (not equal to default) and "unchanged" (equal to default) parameter values in the export file. � Export Used Libraries - Includes the libraries used by the projects being exported in the export schedule. � Export - Clicking this button performs the export as specified. � Export and Open - Clicking this button performs the export as specified and opens the exported schedule file. Not available when exporting all projects.

Compare Tab
Tags Import
Tag Export
IAB/Architect Cancel <<Previous Next>> 62

Compares the currently selected project to a previously saved schedule file and creates a report. � Only Show Changes - When this item is enabled the comparison report will only include items that are different between the current project
and the specified schedule file. � Excel File - Provides the path and file name of the schedule file to compare with the current project. Use the ellipsis (...) button to navigate to
a file to open. � Compare - Clicking this button runs the compare operation. The results of the comparison are displayed in an Excel spreadsheet. Updates parameters in the ACM database with the related tag values in the Tag Configurator workbook. Typically, these values in the workbook are first uploaded from an online Logix Controller using Open Platform Communications (OPC). A Tag Configurator workbook can be used to change, download, and upload a controller's AOI or UDT instance tag values. � Controller - Select an ACM controller to update. � Excel File - Enter full path of the Tag Configurator workbook (.xlsm) to import or click the ellipsis (...) button to browse to the file location. � Configuration File - Enter the configuration file name (.xml) or click the ellipsis (...) button to browse to the file location. � Import - Import the AOI or UDT instance tag values from a Tag Configurator workbook to object parameter values as defined in the
configuration file. Generates a Tag Configurator workbook from ACM with the tag values of the configured ACM object. The Tag Configurator workbook is then used to write these tag values to an online Logix Controller via Open Platform Communications (OPC). � Controller - Select an ACM controller containing the tags to export to the Tag Configurator workbook (.xlsm). � Template File - Enter the template file name (.xls) or click the ellipsis (...) button to browse to the file location. � Create New Configuration File - Create and uses a new configuration file based on Tag members decorated with the OPC Tag Export option. � Use Existing Configuration File - Use the defined configuration file to generate the Tag Configurator workbook from the ACM project. � Configuration File - Enter the configuration file name (.xml) or click the ellipsis (...) button to browse to the file location. � Export - Export the AOI or UDT instance tag values to a Tag Configurator workbook. Creates an ACM partial import file containing Logix hardware modules that are configured in Integrated Architecture Builder (IAB), RSLogix Architect, or Studio5000 Architect. The utility converts the IAB/Architect (.xml) file into an ACM partial import file (.xlsx). Import the partial import file when a corresponding ACM library exists in the database. � IAB / RSLogix Architect XML - Enter the configuration file name (.xml) or click the ellipsis (...) button to browse to the file location. � Convert - Create an ACM partial import file. Closes the Import Export Manager. Not available Not available
Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Control Finish

Description
Closes the Import Export Manager. (Available after the import, export, or compare process is completed.)

Chapter 6

Use ACM Tools

Import a schedule

See also
Import a schedule on page 63
Export a schedule on page 64
Compare a project to a saved schedule on page 66
Create a new schedule template on page 70
Use the Import Export Manager Import tab to import objects (instances) and parameter values from a schedule (xlsx). Verify that the correct database name displays in the ACM Title Bar before starting the import process.
Tip: When importing objects (instances), a compatible library (class) must be registered in the ACM database. The Catalog Number of the registered library must match the Catalog Number in the schedule and a Library with a revision greater than or equal to the revision in the schedule must be registered. If a library with the same revision is registered, the library with the same revision is used. If a library with the same revision is not registered and a library with a greater revision is registered, the newest library is used.

To import a schedule
1. Click Tools, Import Export Manager to open the Import Export Manager. The most recently used project opens by default.
2. To choose a different project to import, click File > Open and then select the project from the list. If the ACM database does not contain any projects, the Project is blank.
3. Select the import method:
� New - Create a new project.
Use to bring projects into a new ACM database.
� Replace- Overwrite project.
Use to revert projects to a previously exported version.
� Update - Merge with existing project.
Use to add content from other projects, or earlier versions of the same project, to the current project
4. Type a schedule file name (xlsx) in the Excel File text box or click the ellipsis to browse to the file.
5. Click Import. � If you choose Replace as the import method, the Import dialog box opens. � If you choose New or Update as the import method, the Import Complete dialog box opens.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

Errors, warnings, info, and debug log entries display.
Tip: Filter the list of exceptions by clicking Errors, Warnings, Info, and/or Debug.
6. (optional) Click Show Log File on the Import Complete dialog box to display the entire contents of the most recent ACM log file in a text editor.
7. If you chose Replace as the import method, click Next to continue with the import and change the data in the ACM database. If you chose New or Update as the import method, click Finish to close the Import Complete dialog box.
8. Click Finish to close the Import Export Manager.

See also

Import Export Manager Import Tab settings on page 64

Import Export Manager Import tab settings

The Import Export Manager Import tab is used to import objects and parameter values from a schedule file.
This table describes the settings on the Import Export Manager Import Tab.

Setting

Description

New � Create new project Replace � Overwrite project
Update � Merge with existing project (will not delete existing objects)
Auto-Continue Excel File: Open Backup Folder Backup original Import

Select this option to create a new project based on the imported schedule. The project name in the schedule cannot exist in the connected ACM database. Select this option to replace the specified project with the project in the imported schedule. The project name in the schedule must be the same as the project name specified in the Project text box. When this import option is run the current version of the specified project is exported to the ACM backup folder and deleted from the ACM database before importing the schedule to the project. Select this option to update the specified project with the information contained in the imported schedule. When this import option is run the current version of the specified project is exported to the ACM backup folder and deleted from the ACM database before merging the imported schedule with the project. Schedule content that is new will be added to the specified project while schedule content that is different between the project in the database and the project in the schedule will be updated to match the content from the schedule. However, schedule content that was deleted or was not exported is not deleted from the selected Project. Select this checkbox to automatically continue the import process using the specified schedule without requiring additional confirmations if no errors or warnings are present. Type the path to the schedule Excel file (.xlsx) to import or click the ellipsis to browse to the file location. Opens the ACM backup folder. Creates a backup of the original project.
Imports the specified schedule file to the specified project. The Import button is available when the import configuration is valid.

Export a schedule
64

See also
Import a schedule on page 63 Export a schedule on page 64 Use the Import Export Manager Export tab to export objects (instances) and parameter values to a schedule file. Schedules are primarily used for backup
Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

and recovery. Verify that the correct database name displays in the ACM title bar before starting the export process.

To export a schedule
1. Click Tools, Import Export Manager to open the Import Export Manager. The most recently used project opens by default.
2. To choose a different project to export, click File > Open and then select the project from the list.
3. Click the Export tab. 4. Configure the scope of the schedule:
� All Projects
Use to export all projects in the connected ACM database.
� Complete Project
Use to export the currently specified project.
� Partial
Use to export only specific objects and parameter values.
� Under Type, choose either Controller, Hardware, Object, or Library, then specify the controller and instance to export.
5. (optional) Limit the content (example: Device List, Device Interlocks) of the schedule by selecting the Use Template check box. Under the Type category the following options are available:
� Choose Local to limit the schedule to locally available devices. � Choose Project to limit the schedule to only those devices used in
the project being exported. � Choose Global to include all devices in the library.
6. (optional) Select Show Modified to color code "changed" (not equal to default) and "unchanged" (equal to default) parameter values.
7. (optional) Select Export Used Libraries to include the libraries in the schedule.
8. Click Export. 9. Enter a path and file name in the Save As dialog. 10. Click Save to save the schedule as an Excel Workbook (*.xlsx) file. 11. If there is an error or warning, the ACM Log File entries are displayed
when the export is complete.
Tip: Errors, warnings, info, and debug information are displayed by default. Filter the list of exceptions by clicking Errors, Warnings, Info, and/or Debug. Clicking the Show Log File command will display the contents of the most recent ACM Log File. Click Finish to return to the Import Export Manager.
12. Click Finish to close the Import Export Manager.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

See also

Import Export Manager Export tab settings on page 66

Import Export Manager Export tab settings

The Import Export Manager Export tab is used to export objects and parameter values to a schedule file.
This table describes the settings on the Import Export Manager Export Tab.

Setting

Description

All Projects Complete Project Partial

Select this option to export a schedule for each project in the connected ACM database. A template cannot be applied.
Select this option to export a schedule for the current project A template can be applied to the export. Select this option to export a schedule that includes only selected information from the current project. With this option, these types of items can be specifically exported: � Controller � Hardware � Object � Library

Use Template
Show Modified Export Used Libraries Export
Export and Open

Select this check box to limit the items exported to the schedule using a schedule template. When selected, choose to use either a Local, Project, or Global schedule template. Select this check box to apply color codes in the schedule to denote "changed" (not equal to default) and "unchanged" (equal to default) parameter values. Includes all the associated library files for the project/controller in the export. Exports the schedule. The Export button is available when a valid export configuration has been selected. Exports the schedule and opens the schedule in Excel when the export is complete. The Export and Open button is available when a valid Complete Project or Partial export configuration has been selected.

Compare a project to a saved schedule

See also
Import Export Template Manager on page 71
Export a schedule on page 64
Use the Import Export Manager Compare tab to compare the current project to a previously saved schedule file and create a report that highlights the differences.

To compare a project to a saved schedule
1. Click Tools, Import Export Manager to open the Import Export Manager. The most recently used project is opened by default.
2. To choose a different project to compare with, click File > Open and then select the project from the list.
3. Click the Compare tab. 4. In Excel File type the name of the schedule file to use for comparison
or click the ellipsis to browse to the schedule file.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

5. (optional) Select Only Show Changes to limit the content of the comparison report to items in the current project that differ from the schedule.
6. Click Compare.

The comparison report opens in Excel.

7. Click Finish to close the Import Export Manager.

Import Export Manager Compare Tab settings
Control Only Show Changes Excel File: Compare
Cancel
Previous Next Finish

See also
Export a schedule on page 64
Import Export Manager Compare Tab settings on page 67
Use the Import Export Manager Compare tab to compare the current project to a previously saved schedule.
This table describes the settings on the Import Export Manager Compare Tab.
Description
Select this check box to create a report that only lists the project content that has changed. Click the ellipsis to identify the schedule file (*.xlsx) to compare with the current project. Compares the current project to the selected schedule file. The Compare button is available when a valid schedule has been selected. Cancels the comparison. The Cancel button is available once the comparison is in progress. Not used Not used Closes the tab. The Finish button is available once the comparison file has been created.

See also

Compare a project to a saved schedule on page 66

Update controller parameters with the related tag values

Use the Import Export Manager Tag Import tab to update parameters in the ACM database with the related tag values in the Tag Configurator workbook. Typically, these values in the workbook are first uploaded from an online Logix Controller using Open Platform Communications (OPC). A Tag Configurator workbook can be used to change, download, and upload a controller's AOI or UDT instance tag values.

To update controller parameters with the related tag values
1. Click Tools > Import Export Manager > Tag Import. 2. In the Controller box, select a controller. 3. In the Excel File box, do one of the following:
� Enter the full path of the Tag Configurator workbook (.xlsm).

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

� Click the ellipsis (...) button to browse to the file location. 4. In the Configuration File box, do one of the following:
� Enter the full path of the configuration file name (.xml). � Click the ellipsis (...) button to browse to the file location. 5. Click Import.

See also

Import Export Manager Tags Import tab settings on page 68

Import Export Manager Tags The Import Export Manager Tags Import tab is used to update parameters in

Import tab settings

the ACM database with the related tag values in the Excel Tag Configurator workbook.

This table describes the settings on the Import Export Manager Tags Import Tab.

Setting Controller Excel File
Configuration File Import

Description
Select an ACM controller to update. Enter the full path of the Tag Configurator workbook (.xlsm) to import or click the ellipsis (...) button to browse to the file location. Enter the full path of the configuration file name (.xml) or click the ellipsis (...) button to browse to the file location. Import the AOI or UDT instance tag values from a Tag Configurator workbook to object parameter values as defined in the configuration file. The Import button is available when the import configuration is valid.

See also

Update controller parameters with the related tag values on page 67

Generate a Tag Configurator Use the Import Export Manager Tag Export tab to generate a Tag

workbook

Configurator workbook from ACM with the tag values of the configured ACM object. The Tag Configurator workbook is then used to write these tag values

to an online Logix Controller via Open Platform Communications (OPC).

To generate a Tag Configurator workbook
1. Click Tools > Import Export Manager > Tag Export. 2. In the Controller box, select a controller. 3. In the Template File box, do one of the following:
� Enter the full path of the template file name(xls.). � Click the ellipsis (...) button to browse to the file location.
4. Select Create New Configuration File or Use Existing Configuration File.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

5. In the Configuration File box, do one of the following:

� Enter the full path of the configuration file name (.xml). � Click the ellipsis (...) button to browse to the file location.

6. Click Export.

See also

Import Export Manager Tags Export tab settings on page 69

Import Export Manager Tags The Import Export Manager Tags Export tab is used to generate an Excel Tag

Export tab settings

Configurator workbook from ACM with the tag values of the configured ACM object.

This table describes the settings on the Import Export Manager Tags Export Tab.

Setting Controller Template File Create New Configuration File Use Existing Configuration File Configuration File Export

Description
Select an ACM controller containing the tags to export to the Tag Configurator workbook (.xlsm). Enter the full path of the template file name (.xls) or click the ellipsis (...) button to browse to the file location. Create and use a new configuration file based on Tag members decorated with the OPC Tag Export option. Use the defined configuration file to generate the Tag Configurator workbook from the ACM project. Enter the full path of the configuration file name (.xml) or click the ellipsis (...) button to browse to the file location. Export the AOI or UDT instance tag values to a Tag Configurator workbook. The Export button is available when the export configuration is valid.

See also

Generate a Tag Configurator workbook on page 68

Create an ACM partial import Use the Import Export Manager IAB/Architect tab to create an ACM partial

file

import file containing Logix hardware modules that are configured in the Integrated Architecture Builder (IAB) or Studio 5000 Architect. The utility

converts the IAB/Architect (.xml) file to an ACM partial import file (.xlsx).

Import the partial import file when a corresponding ACM library exists in the

database.

To create an ACM partial import file
1. Click Tools > Import Export Manager > IAB/Architect. 2. In the IAB/Architect XML box, do one of the following:
� Enter the full path of the configuration file (.xml). � Click the ellipsis (...) button to browse to the file location.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

3. Click Convert. 4. In Object Configuration Wizard, configure properties of the imported
file. 5. Click Finish.

Import Export Manager IAB/Architect tab settings

See also
Import Export Manager IAB/Architect tab settings on page 70
The Import Export Manager IAB/Architect tab is used to create an ACM partial import file containing Logix hardware modules that are configured in the Integrated Architecture Builder (IAB) or Studio5000 Architect.
IMPORTANT Select the EPlan XML export option when exporting the configuration file from IAB.

This table describes the settings on the Import Export Manager IAB/Architect Tab.

Setting IAB/Architect XML Convert

Description
Enter the full path of the configuration file (.xml) or click the ellipsis (...) button to browse to the file location. Create an ACM partial import file.

Create a new schedule template

See also
Import Export Manager on page 61
Create an ACM partial import file on page 69
Use the Template Manager tool of the Import Export Manager to create schedule templates. Schedule templates determine the scope of the schedule (local, project, or global), the library objects used, and the parameters that are visible.

To create a new schedule template

1. Click Tools > Import Export Manager. The Import Export Manager appears.
2. In the Import Export Manager, click Tools > Import Export Template Editor. The Template Manager appears with the Template Editor tab displayed.
3. In the Template area, make the following selections: a. Select the scope of the template:

� Local � Project

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

� Global

b. (if project scoped) Click the down arrow and select the project name.

c. Click the down arrow and select the schedule template.

4. Click New. The Template Name dialog box appears. 5. In New Template Name, enter a name for the new schedule template
and click OK.
The new schedule template name appears in the Template area.
6. In the Library Section Selection area, add the object and sub-object parameters to the new schedule template.
a. Select an object in the Library Section Selection area.

b. In the Not Visible Parameters area select the parameters to include.

Click Select All to select all of the parameters for an object. c. Click Add >.

d. Repeat as needed.

e. In the Visible Parameters area, order the parameters as they should appear in the template file.

7. Click Save to save the changes. 8. Click Reload to cancel all edits made since the last time the Save
command was executed. 9. Click Finish to close the Import Export Template Manager.

Import Export Template Manager

See also
Import a schedule on page 63
How do I open the Template Manager?
1. Click Tools, Import Export Manager to open the Import Export Manager.
2. In the Import Export Manager window, click Tools > Import Export Template Editor.
The Template Manager can be used to create custom schedule templates, copy schedule templates, or move schedule templates from one location to another.
Three schedule template locations are available:
� Local � Located in the Windows User Folder. Available only to the ACM User.
� Project � Located in the ACM database. Available to all ACM users with this project currently open.
� Global � Located in the ACM database. Available to all ACM users connected to this ACM database.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

Template Manager Copy/Move Templates tab settings
Setting
Source Template
� Rename � Duplicate � Delete Copy Move Destination Template

See also
Template Manager Template Editor tab settings on page 72
Template Manager Copy/Move Templates tab settings on page 72
Database Manager on page 73
The Copy/Move Templates tab is used to copy or move a template.
This table describes the settings on the Copy/Move Templates tab.
Description Selects a schedule template. Select a schedule template location, a project name (if located in a project), and a schedule name. Rename the source template Duplicate the source template Delete the source template Copies the source template to the location specified in Destination Template. Moves the source template to the location specified in Destination Template. Selects a location to move or copy the selected source template to. Choose either � Global - Places the template in the ACM database and makes it available to all users � Project - Places the template in the ACM database and makes it available when the specified project is opened. � Local - Places the template in the locate user template folder on the local computer. The template is only
available to the local user.

Open User Template Folder Finish

Opens the file browser scoped to the local user template folder. Close the Template Manager and returns to the Import Export Manager.

See also

Import Export Template Manager on page 71

Template Manager Template Use the Template Editor tab of the Template Manager to create, delete, or

Editor tab settings

edit schedule templates.

This table describes the settings on the Template Editor tab.

Setting Template

Description
Selects a schedule template. Use the combo boxes to select a schedule template location, a project name (if located in a project), and a schedule name. Click New to create a new schedule template Click Delete to delete the selected schedule template. If the schedule template format is old, Template Manager asks for permission to upgrade the template format to the latest version when the schedule template is selected.

Library Section Selection

Selects a library object or sub-object definition from the registered libraries. The object or sub-object parameters display in the Not Visible Parameters or Visible Parameters list boxes.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Setting Not Visible Parameters
Visible Parameters
Add > < Remove Save Reload Finish

Chapter 6

Use ACM Tools

Description

Displays the object or sub-object parameters that are not be included in schedules exported using this schedule template. To include a parameter in the exported schedule, select the item from the Not Visible Parameters list and then click Add to move it to the Visible Parameters list. Use the mouse key combinations Ctrl-click, Shift-Click, Click-and-Drag, and the Select All, and Deselect All buttons to select multiple parameters.
Displays the object or sub-object parameters included in schedules exported using this schedule template. To remove a parameter from the exported schedule, select the item from the Visible Parameters list and then click Remove to move it to the Not Visible Parameters list. Use the mouse key combinations Ctrl-click, Shift-Click, Click-and-Drag, and the Select All, and Deselect All buttons to select multiple parameters. Use the Up, Down, Top, and Bottom commands to control the order in which the parameters display in the exported schedule. Use the sort buttons to display the parameters in category groups or alphabetically.
Moves the parameter selected in the Not Visible Parameter list to the Visible Parameter list.
Moves the parameter selected in the Visible Parameter list to the Not Visible Parameter list.
Saves the schedule template to the schedule template settings file (C:\Documents and Settings\<username>\Local Settings\Application Data\ Rockwell Automation\Application Code Manager \Templates\<template>).

Cancels any template changes made since the last Save command was executed by reloading the schedule template from the schedule template settings file (C:\Documents and Settings\<username>\Local Settings\ Application Data\Rockwell Automation\Application Code Manager \ Templates\<template>).
Closes Template Manager.

Database Manager

See Also
Template Manager Copy/Move Templates tab settings on page 72
The Database Manager controls how Application Code Manager interacts with the SQL Server database. It also provides the ability to create, backup, and recover databases.

Create an ACM database

See also
Create an ACM database on page 73 Upgrade an ACM database on page 74 Backup an ACM database on page 75 Restore an ACM database on page 75 Database Manager settings on page 77 Application Code Manager (ACM) uses a database to store re-usable code. At least one database is required, but additional databases can be created as needed.

To create an ACM database
1. Open Application Code Manager, in the main menu, click Tools > Database Manager.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

Upgrade an ACM database

See also
Connecting to an ACM database on page 22
Application Code Manager (ACM) uses a database to store re-usable code. If ACM is upgraded to a newer version the existing ACM database can still be used, but the database schema must be upgraded.

To upgrade an ACM database
1. Open Application Code Manager, in the main menu, click Tools > Database Manager
2. In Server Name, select the computer name and SQL Server instance from the drop down list or type a computer name and SQL Server instance in the following format:
<Computer Name> \ <SQL Server Instance>
3. In Log on to the server, use Windows Authentication or type the User name and Password to use to authenticate the connection to the SQL Server, then click Connect.
Status updates to Connected.
4. In Specify the database, select the name of the ACM database you want to upgrade.
5. In Actions, select Upgrade database and then click Execute Task.
Once the database is created an Action completed successfully message displays. Click OK.
6. Click Close to close Database Manager.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Backup an ACM database

See also

Chapter 6

Use ACM Tools

Connecting to an ACM database on page 22

Upgrade the Application Code Manager application on page 16

Backup an ACM database on page 75

Application Code Manager (ACM) uses a database to store re-usable code. Making a backup of the ACM database on a regular schedule is recommended to ensure that your re-usable code library can be restored in case of hardware failure or unintended changes to the data.

IMPORTANT When backing up a remote database, the file location must be accessible with read and write access granted to the user account under which the remote database service runs.

To backup an ACM database
1. Open Application Code Manager, in the main menu, click Tools > Database Manager
2. In Server Name, select the computer name and SQL Server instance from the drop down list or type a computer name and SQL Server instance in the following format:
<Computer Name> \ <SQL Server Instance>
3. In Log on to the server, use Windows Authentication or type the User name and Password to use to authenticate the connection to the SQL Server, then click Connect.
Status updates to Connected.
4. In Specify the database, select the ACM database you want to backup. 5. In Actions, select Backup database and then click Execute Recovery.
The Select file to backup database dialog box opens. 6. In File name type a name for the backup file being created and then
click Save.
Once the backup file is created an Action completed successfully message displays. Click OK.
7. Click Close to close Database Manager.

Restore an ACM database

See also
Connecting to an ACM database on page 22
Application Code Manager (ACM) uses a database to store re-usable code. If ACM is being moved to new database server or if the existing database server has incorrect ACM data, the backup made of the database can be restored to the database server so that all of the previous data is available.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

IMPORTANT When restoring a remote database, the file location must be accessible with read and write access granted to the user account under which the remote database service runs. Restoring an ACM database backup onto a machine other than the one on which it was created will require database ownership to be set. This is because the user associated with the backed-up database does not exist in the new environment. If ownership is not set, then ACM users will continuously receive the following message: "Timed out waiting for the heart beat notification from the SQL Broker from within the ACM application. Please check the log file for details". Database ownership can be set by the database administrator. The database administrator will need to run the script as below within either a SQL Management Studio query window or via a SQLCMD session: ALTER AUTHORIZATION on DATABASE::[Database Name] TO [SQL User] � The [Database Name] section must be replaced with the ACM database name. � The [SQL User] section must be replaced with the name of the user who will be assigned ownership of the database. Running the above script ensures that you will no longer receives the timeout messages.

To restore an ACM database
1. Open Application Code Manager, in the main menu, click Tools > Database Manager
2. In Server Name, select the computer name and SQL Server instance from the drop down list or type a computer name and SQL Server instance in the following format:
<Computer Name> \ <SQL Server Instance>
3. In Log on to the server, use Windows Authentication or type the User name and Password to use to authenticate the connection to the SQL Server, then click Connect.
Status updates to Connected.
4. In Specify the database, select the name of the ACM database on which you want to restore the data.
Tip: If you are restoring databases to a new database server or if the database is not present on the database server, create the database before restoring the data to it.
5. In Actions, select Restore database and then click Execute Recovery. The Selected database backup to restore dialog box opens.
6. Select the database backup file (.bak) to restore and then click Open. 7. The Confirm database restore dialog box opens warning you that the
current database will be overwritten and asking you if you are sure you want to restore the database.
Click Yes to confirm the restoration process.
8. Once the database is restored an Action completed successfully message displays. Click OK.
9. Click Close to close Database Manager.

See also
Connecting to an ACM database on page 22

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Delete an ACM database

Chapter 6

Use ACM Tools

Application Code Manager (ACM) uses a database to store re-usable code. At least one database is required.

To delete an ACM database
1. Open Application Code Manager, in the main menu, click Tools > Database Manager
2. In Server Name, select the computer name and SQL Server instance from the drop down list or type a computer name and SQL Server instance in the following format:
<Computer Name> \ <SQL Server Instance>
3. In Log on to the server, use Windows Authentication or type the User name and Password to use to authenticate the connection to the SQL Server, then click Connect.
Status updates to Connected.
4. In Specify the database, select the ACM database to delete. 5. In Actions, select Delete database and then click Execute Task. The
Confirm database delete dialog box opens. 6. Click Yes to confirm deletion of the database
Once the database is deleted an Action completed successfully message displays. Click OK.
7. Click Close to close Database Manager.

See also

Create an ACM database on page 73

Restore an ACM database on page 75

Database Manager settings

How do I open the Database Manager dialog box?
� On the main menu, click Tools > Database Manager.
The Database Manager dialog box contains the settings that control how Application Code Manager interacts with the SQL Server database. It also provides the ability to create, backup, and recover databases.

This table describes the settings in the Database Manager dialog box.

Setting

Description

Server name:

Identifies the server that is hosting the SQL Server used by ACM. Use the drop-down list to select a computer name and

SQL Server instance from, or enter a computer name and SQL Server instance in the following format:

Refresh

Queries the network for a list of SQL Server computer names and instances and updates the selections available in the

drop-down list with the results.

Log on to the server

Using Windows Authentication or SQL Server Authentication

(Note: This account and password are configured during installation of SQL Server.)

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

Setting

� User name:

� Password: � ACM default sa password

� Connect
� Status:
Specify the database � Select a database name Actions - Tasks � Create database � Upgrade database � Delete database � Execute Task Actions � Disaster Recovery Backup database Restore database
Execute Recovery

Description The SQL Server user name associated with the ACM database. The default user name is "sa".
The SQL Server password associated with the user name. Use the default ACM password instead of typing a password. Check this box if the default SQL Server password was entered when SQL Server was installed.
When this button is clicked Application Code Manager attempts to connect to the database named in the Select a database name on the SQL Server entered in the Server name combo box.
Displays the result of the database connection attempt. � Connected � Login failed for user
Identifies the database to manage. Enter a name or select an existing name from the list. If the name entered is not present on the SQL Server, the option is provided to create a new database.
Creates a database with the database name entered in the Select a database name on the SQL Server entered in the Server name when Execute Task is clicked. Upgrades the ACM database named in the Select a database name combo box with the current schema when Execute Task is clicked. Deletes the database named in Select a database name from the SQL Server identified in Server name when Execute Task is clicked. Performs the selected task.
Makes a backup copy of the database file named in Select a database name when Execute Recovery is clicked. Replaces the database file named in Select a database name combo box with the backup database file when Execute Recovery is clicked.
Performs the selected recovery.

Log Debug Information

See also
Create an ACM database on page 73 Upgrade an ACM database on page 74 Delete an ACM database on page 77 Backup an ACM database on page 75
Restore an ACM database on page 75 To assist in troubleshooting Application Code Manager enable logging of debug information to the ACM Log File. Information is written to the ACM log file when design outputs are generated (example:<CLX>, FactoryTalk View, FactoryTalk Historian, Word) or when schedules are imported or exported. Once the additional logging information is no longer needed, disable log debug information.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Log File Viewer

Chapter 6

Use ACM Tools

To log debug information

� Click Tools > Log Debug Information.

A check mark appears next to the Log Debug Information entry in the Tools menu. Clicking the item again disables logging of debug information.

See also
Use ACM Tools on page 61
The Log File Viewer provides a quick way to view the most recent events sent to the ACM log file. The Log File Viewer can be opened from the Application Code Manager Tools menu and from the Import Export Manager Tools menu.
The Log File Viewer displays errors, warning, informational, and debug events in a a grid.
At the top of the Log File Viewer is a set of buttons listing of the type of log entries and the number of entries for each type:

The entries displayed in the event grid can be filtered by type of events by clicking the button corresponding to the item to remove from the list.
When an item is not included in the view the button is shaded gray:

By default, the Log File Viewer displays events in ascending date time order.
The order can be changed to be either ascending or descending and be based on any of the columns displayed in the events grid. Click on the column heading to sort the display by Type, Date/Time or Description. A small arrow appears next to the column heading being sorted and denotes whether the current sort order is by ascending (up arrow) or descending (down arrow) values.

ACM Default Settings

See also
Use ACM Tools on page 61 Import Export Manager on page 61 Log Debug Information on page 78 How do I open ACM Default Settings? � From the Tools menu, select Settings.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

Setting System Documentation Path
Language Auto-expand Controller Preview Control Logix Generation Defaults
Overwrite Existing Output ACM Project Data Create ACD Indications Modified Objects
Newer Library Version Available

Use ACM Default Settings to specify the location of the system file, the language shown in the display, how Control Logix content is generated, and whether or not to show indications.
Description
The location of the template files. By default these are located at \Users\Public\Documents\Studio 5000\Templates\Application Code Manager. The language used by Application Code Manager. The default value uses the operating system language. Determines whether the tree in Controller Preview is automatically expanded. The default value is selected.
Determines what is selected to include in Logix code generated by ACM and whether Application Code Manager should overwrite existing output with new code. The default setting for Overwrite Existing in the Logix Code Generation window. The default setting for ACM Project Data in the Logix Code Generation window. The default setting for Create ACD in the Logix Code Generation window. Determines whether indications are shown. Sets whether an indication is shown when a library object has been modified. The default value is cleared.
Sets whether an indication is shown when a node or folder contains one or more libraries that has a newer version available in Registered Libraries. The default value is cleared.

Document Template Editor

See also
Use ACM Tools on page 61
Generate a controller file on page 48
Create a new schedule template on page 70
Indications on page 39
How do I open the Document Template Editor?
� From the Tools menu, select Document Template Editor. The Document Template Editor provides an environment to develop and test document generation templates.
Note: The ability to use this is only available if the product has a Standard activation license and is not available in Lite mode.
The Document Template Editor includes the following functions: � Highlights reserved words in the template language. � Folds repeat blocks. � Error checking and highlighting. � Ability to save frequently used code fragments for later re-use. � Generates an output template file.

See also
Components on the Document Template Editor on page 81 Menu bar on page 82

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Components on the Document Template Editor

Tool bar on page 84 Output panel on page 86 Editor pane on page 86

Chapter 6

Use ACM Tools

This table describes each section of the Document Template Editor.

Item

Name

Description

Menu and toolbar

Selects editing options and features or application configuration options in this section.

Editor

Develops and tests templates in this section.

Output Code Snippets

Displays the Output, Syntax Error, and Compile Info panes. � Output
Displays output results from the template after the generation process. You can save the output to a file. � Syntax Error Displays any current syntax error descriptions that appear in the Editor pane. � Compile Info Provides compilation information about the previously executed template generation process.
Displays usable code snippets, including Base Snippets and Custom Snippets. � Base Snippets
Includes snippets, which are the predefined template instructions that make up the template generation language. � Custom Snippets Includes snippets, which are reusable code fragments consist of preconfigured base snippets. Drag snippets to the Editor pane for implementation in a template.

The Editor, Output, and Code Snippets panes can be undocked and moved around on the desktop to suit your requirements.

See also
Menu bar on page 82 Tool bar on page 84

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

Menu bar

Output panel on page 86

Editor pane on page 86

Selects editing options in the Menu bar. This table describes each option.

Item

Description

File

� New

Creates a new file.

� Open

Opens an existing file.

� Save

Saves the currently active template document if it changed.

� Save As

Saves the currently active template document with a different file

name.

� Close All

Closes all active windows.

� Recent Files

Displays the last ten recently closed template document files.

� Exit

Closes the Document Template Editor.

Edit

� Cut

Cuts the selected text in the Editor pane to the clipboard. This option is only active if more than one character is selected in the active Editor pane.

� Copy

Copies the selected text in the Editor pane to the clipboard. This option is only active if more than one character is selected in the active Editor pane.

� Paste

Pastes text from the clipboard into the current position selected in the Editor pane. This option is only active if the clipboard is not empty.

� Clear Clipboard

Clears all items copied to the clipboard.

� Delete

Deletes selected text in the Editor pane. This option is only active if more than one character is selected in the active Editor pane.

� Undo

Undoes the last operation executed in the active Editor pane.

� Redo

Redoes the last undo operation.

� Find / Replace

Starts the Find / Replace dialog box where text strings can be found and replaced.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Find / Replace
View Settings > Preferences > General

Chapter 6

Use ACM Tools

� Match Case Matches words that conform exactly to the sequence of upper and lower case text.
� Match whole word Matches against entire word sequences. If a word contains the sequence but contains other characters, then the match will not be found.
� Regular Expression Includes special non printable characters that may be included in a search word. As an example, a search word containing a carriage return character sequence would only be matched against words in the search document where the word includes the carriage return. These special characters will not be included in the search when this option is not selected i.e. a match would be found on a word that may include a special character like a carriage return character.
� Wildcards Includes the "*" character in the search word. Characters appearing between the sequence will be matched i.e. in the search word "R*t", Repeat would be a match as "epea" are treated as wild card characters. If "?" is included in the search word then any single character will be matched in the placeholder where the wildcard is placed i.e. in the search word "Repe?at", "Repe1at" will be a match.
� Search up Starts the search at the end of the document and works its way up to the start. Otherwise if not selected then the search would begin as normal from the beginning of the template document.
� Restore Default Layout Restores all undocked windows back to their original positions.
� Float All Windows Undocks all docked windows.
� Snippets View Closes or opens the Code Snippets pane.
� Output View Closes or opens the Output pane.
� Show Toolbar Adds or removes the tool bar.
� Show Menubar Adds or removes the menu bar. Press F12 to show the menu bar if it is removed.
� Show Statusbar Sets the status bar displayed at the bottom be visible or not.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

Settings > Preferences >Editing

� Display Line Numbers Shows or hides the editor line numbers depending on this selection. This option is global for all open editor panes and the setting is saved and will be applied on application startup.
� Enable Line Wrap Wraps the text in the editor to the space available in the Editor pane depending on this selection. This option is global for all open editor panes and the setting will be saved and applied on application startup.
� Display End Of Line Character Shows the carriage return character when this option is selected. This option is global for all open editor panes and the setting will be applied on application startup.

Tool bar

Settings > Preferences > Compile

� Compile Messages
Two selections are possible, either Basic or Advanced. When generating documentation compile information will be generated in the Compile Info pane. This information can be useful to debug a template or to determine how long the document generation process is spending within specific instruction loops. The Advanced option is verbose intensive and provides detailed information on the generation process. � Send Messages to ACM log
Enables or disables the writing of document generation messages to the ACM log.

See also

Components on the Document Template Editor on page 81

Selects application configuration options in the Tool bar. This table describes the options in the Tool bar.

Item New File
Open File

Description
Creates a new template file. A new Editor pane will be created starting with the name new (x), (x) being the first new unique number used after the last new file was opened i.e. if a new unsaved file is already loaded with the name new 1, then this editor pane will get the name new 2. Once the file is saved to disk then this name will be replaced with the actual file name of the template document.
Opens the File Browse dialog to navigate and select a template file to open. Files of type (.txt), (.csv) and (.xml) can be selected and opened.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Save File
Cut Text Copy Text Paste Text
Delete Text Undo Redo Word Wrap
Line Numbers Show EOL Char Validate Generate
Stop Generation Selected Project Selected ACM Object

Chapter 6

Use ACM Tools

Saves the document template file. This button will be enabled when changes are made to the currently active Editor pane. If the file has not been previously saved but is a new file then the Save As dialog will be presented to the engineer allowing for a file name and location to be selected.
Cuts the selected text. This button will be enabled when at least one character in the active Editor pane is selected. When clicked, selected text will be cut from the page and stored on the clipboard.
Copies the selected text. This button will be enabled when at least one character in the active Editor pane is selected. When clicked, selected text will be copied and stored on the clipboard.
Pastes the copied text. This button will be enabled when there is information stored on the clipboard and if an active Editor pane is currently selected. When clicked, the contents of the clip board will be pasted into the active editor pane at the currently selected location.
Deletes the selected text. This button will be enabled when at least one character in the active editor pane is selected. When clicked then the selected text will be deleted from the Editor pane.
Undoes the previous edit operation in the active Editor pane.
Redoes the previous undo operation in the active Editor pane.
Wraps the text in the editor to the space available in the Editor pane. If this function is switched off then text for a line will extend off the page and the horizontal draw bar will need to be used to view parts of the line that extend past the end of the editor panel. This option will only apply to the currently active editor window and will not be applied on application startup.
Displays a vertical list of line numbers on the left side of the Editor pane when this option is enabled.
Displays end of line characters (CR / LF). This option will only apply to the currently active editor window and will not be applied on application startup.
Runs a validation check on the currently active editor pane. Any detected syntax errors will be displayed in the output Syntax Error pane. If no syntax errors are encountered then the following prompt will be displayed.
Runs a document generation process for the active Editor pane. Output, syntax errors and compile information will be displayed in the Output pane. Compile information will be displayed in the status bar on the left hand side and progress on the right side while the document generation process is running.
Stops the generation process. This button will only be enabled when a document generation process is underway.
Displays the currently loaded ACM project. The Document Generation Editor will always use the loaded project that is active within ACM. This field is not configurable.
Compiles document template against various available ACM objects. All available project objects will show in a grouped drop down list control. The categories of items available include Controller, Display, Alarms and Historian. The list will only contain items appearing in the project. All objects in the Execute Against list can be compiled against a specific controller or all controllers in the project by selecting a controller option from the Controller selection option (discussed in the next section), except for Display objects which can only be compiled against all controllers. When selecting a Display item, the Controller selection list will be disabled with the Generate All Controllers option will be pre-set.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

Selected Controller

Displays all controllers configured in the ACM project. Once a project object has been selected as outlined in the previous section (excluding display objects), a single controller or all controllers can be selected to compile against. Output would then only be generated for the specific controller selection. This option will be disabled if a display object is selected in the Execute Against list discussed in the previous section.

Output panel

See also

Components on the Document Template Editor on page 81

The Output panel contains three tabs for the following output information: Generated output, syntax error and compilation activity output.

Tab Output
Syntax Error
Compile Info

Description
The Output pane contains the result of a documentation generation process as processed through the loaded template. It is also possible to save the document to either (.txt), (.csv), (.xml) via the save button on the Output toolbar. The Clear Display button is also available for clearing all output from the pane.
The Syntax Error panel contains a description of any syntax errors detected by the documentation engine. One line will be printed for every error detected. The line number of where the error occurs as well as the type of error will be included in the error message. The Syntax Error panel will only contain syntax errors for the currently active editor pane.
The Compile Info panel contains information pertaining to the document generation process. Each line will always print out a date and time for the event, followed by the actual message description. When the Advanced option is selected see section (Compile Options) then more detailed information would be printed out such as a list of project libraries in use, objects cached etc. Sometimes a compilation error may be encountered. An example of a compilation error would be where a defined object name could not be resolved. This error would be highlighted in blue as follows:

See also

Components on the Document Template Editor on page 81

Editor pane

This table describes the functions of the Editor pane.

Item
Language keyword highlighting

Description

The Editor pane supports language text highlighting for the documentation generation language.

Document generation instructions are always highlighted in blue:

Library items in orange:

Comments will be printed in green:

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Code completion

Chapter 6

Use ACM Tools

The Editor pane provides code completion functionality where a list of keywords is supplied after a matching text sequence has been typed. This allows the engineer to add an instruction without having to type out the complete text sequence. Here is a graphic example of Code Completion options available through a sequence of typed characters:

Text folding
Working with custom snippets
Executing a code fragment

With the completed line looking as follows:

Text folding consists of grouping a section of code so that it can be collapsed as a complete section to make other areas of the document easier to read. In the above example we are creating folding sections around each repeat block, identified by the repeat number. The Repeat.2 block is encased within the Repeat.1 block and is shown as collapsed within the Repeat.1 block. The Repeat.1 block can also be collapsed.

Click Add Code To Custom Snippet will invoke the Create New Snippet editor where it will be possible to create a new custom snippet. Click Insert Snippet will display a list of base and custom snippets which can be selected for inclusion in the active template document. Tip: Some sample snippets are provided. Right-click Custom Snippets and select Import. From the Open dialog box navigate to the default file location: C:\Users\Public\Documents\Studio 5000\Samples\Application Code Manager\Snippets Select the sample snippet to import, repeat if required.

Right click in the Editor pane and select Execute Selected Fragment to execute a code fragment or highlight a section of code. The Execute Selected Fragment menu option is only be enabled if text has been selected in the editor: Important: Select and execute a fragment could result in syntax errors being generated as it's possible to select any combination of lines for execution which could result in required block termination instructions been excluded when document generation processing takes place. In the above example the ##Repeat.1 block instruction has been selected and if executed will result in a syntax error as the fragment does not include an ##EndRepeat.1 instruction.

Supported instructions

See also
Components on the Document Template Editor on page 81
Use instructions to develop a document template in the Editor pane. The Document Template Editor supports the following instructions:
� Repeat � Break � Conditional � Define � Set � Substitution � Comment � Log

Repeat instruction

See also
Document Template Editor on page 80 Editor pane on page 86 Looping is the most important functionality in the template language and determines where the documentation engine attaches its data source. In

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

essence the looping statement opens a data set specified by a query string, and then iterates each record within the dataset. All the text contained within the loop will be repeated for every record returned by the specified query.

The basic layout of the looping statement is as follows:

##Repeat.n(RepeatType: Query) ... Text to be repeated ... ##EndRepeat.n

The looping statement consists of an opening and closing denominator, with the ##Repeat determining the beginning and the ##EndRepeat statement defining the ending of the block of text to be repeated. For every ##Repeat.n statement there must be a corresponding ##EndRepeat.n statement.

Repeat Block Structure

Statement Breakdown Description

##Repeat

This instruction informs the documentation that the current line denotes the start of the loop.

Specifies the nesting level of the repeat statement. This is

used to attach substitution links.

This is the type of loop being performed, the repeat type
Repeat Type determines which data source is used to execute the repeat
block.

Query

This is the query string used to filter the resulting dataset that is then iterated by the repeat statement.

##EndRepeat This instruction informs the documentation that the current
line denotes the end of the loop.

OrderBy

(Optional)This instruction allows the values returned in a ##Repeat statement based on the provided query to be sorted in ascending or descending order. See Types datasets for available fields. The sort order can be controlled by specifying asc for ascending order or desc for descending order.

Repeat Types

Repeat Type Object SubObject SubObjectAll ObjectReferences
Collection
CollectionAll
SQL

Data Source Typed Dataset
Typed Dataset
Typed Dataset
Typed Dataset
Collection Dataset Collection Dataset Raw SQL data set

Description All object instances matching the query All sub object instances matching the query, of the object instance currently iterating All sub object instances matching the query All objects referencing the instance specified in the query All collection items of the currently iterating object or sub-object matching the query All collection items of all objects matching the query
All items (rows) returned by the query.

SubObject and Collection repeat types are only valid when directly nested under other specific repeat types.

1. SubObject Must be directly nested under an Object repeat type

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Operator * / % mod + &
Operator ! Not
Operator = == != <> > >= < <= && and || or
Operator ?:

Chapter 6

Use ACM Tools

2. Collection Must be directly nested under either an Object, SubObject or SubObjectAll repeat type.

When using the above two repeat types, care must be taken to ensure that the nesting levels follow numerically i.e. the statements are directly nested.

Object, SubObject and SubObjectAll Queries

When querying a typed dataset, the following tables list the available operators that may be used to build the query statement.

Binary computational operators

Description Multiply Divide
Modulo
Add Subtract String Concatenate
Unary logical operators

Description

Logical Not

Binary logical operators

Description
Equals
Not Equals Not Equals Greater Than Greater Than And Equal To Less Than Less Than And Equal To
Logical And

Logical Or

Ternary logical operators
Description Logical If
Object Reference Queries
Object reference queries are designed to filter objects and subobjects referencing each other. This is achieved in ACM by declaring a parameter or sub-parameter (parameter on a subobject) as a Reference and then referencing the objects to each other.
The syntax for this query type is as follows:

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

Reference Type ObjectRef SubObjectRef

Break instruction

##Repeat.n(ObjectReferences: ReferenceType = "id")
Object References query reference types
ID Object ID. The query will return all objects referencing this ID. SubObjectID. The query will return all parent objects of subobjects referencing this ID.
Collection Dataset Queries There is only one possible query on collection datasets:
Name = "CollectionName"
Raw SQL Queries There is no predefined syntax for raw SQL queries. When executing these repeat types the documentation engine passes the SQL query straight through the project database. Any valid SQL statement may be entered. Important: SQL statements must me entered on a single line within the template i.e. no line-breaks may be present within the SQL statement.
See also
Supported instructions on page 87 The break statement terminates the closest enclosing loop in which it appears. Control is passed to the statement that follows the terminated statement, if any. The syntax for the break statement is as follows:
##Break
Example: The break statement is useful when filtering loops with a conditional statement. The example below breaks the inner most loop once the filterexpression is matched.

Conditional instruction

See also
Supported instructions on page 87 Conditional statements in the template language allow blocks of text to be included based on a logical statement. This conditional inclusion of text is

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

implemented using the if--else-end pattern found in most programming languages.

The conditional statement is defined as follows:

##If statement ##Then

... Text to be included if statement is true ...

##ElseIf statement ##Then

... Text to be included if statement is true ...

##Else

... Text to be included if statement is false ...

##EndIf

The ##ElseIf and ##Else portions of the conditional statement is optional and may be omitted.

Substitution instruction
Statement Breakdown n FieldName

See also
Supported instructions on page 87
The substitution functionality in the template language is used to replace text in the template with values from the attached data source. This allows the template to be replaced with actual application data for each specific record.
The substitution statement has the following format:
[n.{FieldName}]
Breakdown of [n.{Substitution}] syntax
Description The data source number. Any valid field name for the associated data source.
Important:
Template language substitutions
In addition to being replaced within the body of a template, substitutions are also valid in the template language itself:
� Looping queries � Conditional statements
Project parameters
With ACM the project parameters are global to all objects in a specific project. In order to simplify the substitution syntax, project parameters may be accessed directly within the template language.
The project parameter syntax is defined as follows:
[p.{AnyValidProjectParameterName}]

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

Define instruction

See also
Supported instructions on page 87
The define instruction is used to define a new variable to be used throughout a document template. The variable is not bound by any Repeat loops.
The define instruction is typically used in conjunction with the ##Set instruction and is useful when a value from an outer Repeat loop needs to be passed to another outer Repeat loop.
The define statement has the following format:
##Define(variable, datatype, value)
The syntax for using the value of the variable in a template has the following format:
[d.{variable}]
Example:
##Define(myObjName, string, "") ##Define(myObjNameLength, int, 0)

Set instruction
Function Round Format Modulus ABS INT 92

See also
Supported instructions on page 87
The set instruction allows for a variable that is declared in the ##Define instruction to be updated with a new value. The set instruction accepts two parameters: 'variable' which is the name of the variable to be updated and 'value' which refers to the new variable value or reference.
The set statement has the following format:
##Set(variable, value)
The syntax for using the value of the variable in a template has the following format:
[d.{variable}]
Example:
##Set(myObjName, "[1.{ObjectName}]") ##Set(myObjNameLength, [1.{ObjectName.Length}])
A number of standard Microsoft functions can be used with the instruction when assigning or manipulating the value and are listed in the following table.
Example ##Set(myRound,Round(87.6)) ##Set(myFormat, Format(87.6, "###0.00")) ##Set(myMod, Modulus(5,4)) ##Set(myABS, ABS(-87.6)) ##Set(myINT, INT(87.6))
Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Function Length Ucase Lcase Truncate Sin
Cos Tan now()
Today() Rnd() Trim IndexOf Mid Right Left Substring Pow

Example ##Set(myLength, Length("[1.{ObjectDescription}]")) ##Set(myUpperCase, Ucase("[1.{ObjectDescription}]")) ##Set(myLowerCase, Lcase("[1.{ObjectDescription}]")) ##Set(myTruncate, Truncate([1.{MaxValue}])) ##Set(mySin, Sin(87.6))
##Set(myCos, Cos(87.6)) ##Set(myTan, Tan(87.6)) ##Set(myDateTime, now()) ##Set(myDateTimeFormated, Format(now(), "dd MMM yyyy")) ##Set(myDate, Today()) ##Set(myRandomize, Rnd()) ##Set(myTrim, Trim("[1.{ObjectDescription}]")) ##Set(myIndexOf, IndexOf("[1.{ObjectDescription}]", "word")) ##Set(myMid1, Mid("[1.{ObjectDescription}]", 12, 22)) ##Set(myRight, Right("[1.{ObjectDescription}]", 12)) ##Set(myLeft, Left("[1.{ObjectDescription}]", 22)) ##Set(mySubString1, substring("[1.{ObjectDescription}]", 12, 22)) ##Set(myPower, Pow(2, 0) + Pow(2, 1) + Pow(2, 2) + Pow(2, 3) + Pow(2, 4))

Chapter 6

Use ACM Tools

Comment instruction

See also
Supported instructions on page 87 Comments may be added to templates with the following syntax:
##! I am a comment
It is important to note that all comments are removed from the template during generation.

Log instruction

See also
Supported instructions on page 87 Logging may be added to templates with the following syntax:
##Log I am log message
It is important to note that all logging is removed from the template during generation. All log messages are written to the ACM log with level `Debug'.

Types datasets

See also

Supported instructions on page 87

There are two typed datasets available to the documentation engine, one for Object repeat types and one for SubObject repeat types shows the available fields in the Object typed dataset. SubObject typed datasets contain all the fields shown in the SubObject fields table, with additional SubObject specific fields.

Object fields

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools
Field ObjectID ProjectID ControllerID ParentObjectID ObjectName ObjectDescription LibraryID CatalogNumber Family LibraryType CoreType Category LibraryDescription MajorRev MinorRev Owner

Field SubObjectID SubObjectName SubObjectDescription SubObjectType

Data Type Int Int Int Int String String String String String String String String String Int Int String
SubObject fields
Data Type Int String String String

Original Database Table Objects Objects Objects Objects Objects Objects RegisteredLibraries RegisteredLibraries RegisteredLibraries RegisteredLibraries RegisteredLibraries RegisteredLibraries RegisteredLibraries RegisteredLibraries RegisteredLibraries RegisteredLibraries
Original Database Table SubObjects SubObjects SubObjects SubObjects

Raw SQL data
Reference Type 1 2 3 94

See also
Raw SQL data on page 94
Raw SQL datasets are dynamic and the fields available are dependent on the columns returned by the specified SQL query. As such this section will briefly define the important ACM database tables and outline how the data source filtering, mentioned previously, can be obtained using raw SQL statements.
The core ACM database layout, consists of four main tables: Objects, Parameters, SubObjects and SubParameters. Although not holding core project information, the RegisteredLibraries table provides a way to fine tune the object filtering based on CoreType (Solution), Family, LibraryType, etc.
Reference Parameters
Objects within an ACM project can reference each other, normally either by an Object or SubObject reference. This relationship is denoted in the ACM database by the "RefType" column in both the Parameters and SubParameters table. This column contains an enumeration denoting what the data in the Value column of these tables represents. A full list of this enumeration is given in the table below.
ACM reference types enumeration
Name Immediate ObjectRef SubObjectRef
Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

ParentObjectRef (Not Used)

ObjectNIBRef (Object External Reference)

Calculated

SubObjectNIBRef (SubObject External Reference)

InterfaceRef

InterfaceMemberRef

ParameterRef

SubParameterRef

Dataset filtering/scoping

In order to provide dataset scoping on raw SQL queries, the documentation engine will create four temporary tables at the beginning of each generation session.

The four temporary tables are listed as follows:

1. #Objects 2. #Parameters 3. #SubObjects 4. #SubParameters

The following example shows the use of these temporary tables within an ACM documentation template. Consider the scenario to list the names of all the objects in system.

The first example will return all the Objects in the database regardless of the level from which the generation was executed within the ACM.

##Repeat.1(SQL: SELECT * FROM Objects)

[1.{Name}]

##EndRepeat.1

The second example which uses the temporary table #Objects, will only return the objects from the level which the document was generated (i.e. Project objects or Controller Objects).

##Repeat.1(SQL: SELECT * FROM #Objects)

[1.{Name}]

##EndRepeat.1

Technical view of looping statements

See also
Types datasets on page 93 Perform a technical review on the following methods after code editing. Object
##Repeat.1(Object: Query)
... Text to be repeated ...
##EndRepeat.1

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

for each object where Query {
... Text to be repeated ...
}
SubObject
##Repeat.1(Object: ...) ##Repeat.2(SubObject: Query)
... Text to be repeated ...
##EndRepeat.2 ##EndRepeat.1
for each object where ... {
for each SubObject where Query And ObjectId = [1.{ObjectId}]
{
... Text to be repeated ...
} }
SubObjectAll
##Repeat.1(SubObjectAll: Query)
... Text to be repeated ...
##EndRepeat.1
for each SubObject where Query {
... Text to be repeated ...
}
Collection
##Repeat.1(Object/SubObject/SubObjectAll: ...) ##Repeat.2(Collection: Query)
... Text to be repeated ...
##EndRepeat.2 ##EndRepeat.1

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

for each object/sub-object where ...

{

for each item in collection And ObjectId = [1.{ObjectId}]/SubObjectId =
[1.{SubObjectId}]

{

... Text to be repeated ...

} }

CollectionAll
for each Object where "has collection" {
for each item in collection {
... Text to be repeated ...
} }

Getting to know the ACM database structure

See also
Repeat language on page 87
A working knowledge of the structure of the ACM database will assist when writing document generation scripts for data extraction. There are several tables and views which will be useful for generating documentation.
In addition to the SQL tables there are also several views available. A view is a virtual table which can be queried in the same way as a table. Views can provide advantages over tables in the following ways:
� Views can represent a subset of data contained within a table. � Views can join and simplify multiple tables into a single virtual table.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

Important tables in use in the ACM database are as follows:

Table descriptions are as follows: � Projects: Contains ACM project information. Columns available in this table are displayed below:
� Controllers: All controllers in use in projects in the ACM database will be recorded in this table. Columns available are displayed below:

� Objects: All objects used in ACM projects will be recorded in this table. Columns available are displayed below:

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

� SubObjects: All SubObjects linked to parent objects in use in ACM projects in the ACM database will be stored in this table. Columns available are displayed below:
� SubParameters: All parameters created for SubObjects used in ACM projects will be recorded in this table. Columns available are displayed below:

� RegisterdLibraries: All libraries registered in the ACM database will be recorded in this table. Columns available are displayed below:

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

View Descriptions are as follows:
As mentioned earlier, several views are available which contain consolidated information that may simplify SQL query construction in that they make information from different tables available from a single source. Search parameters will need to be provided to ensure that only data for the loaded ACM project is retrieved.
Views available are as follows:
� ControllerDetail: Provides information about each controller including the controller name, library catalog number, description and other library information. Columns available in this view are displayed below:

� ObjectsDetail: Provides information about each object in use in projects within the ACM database. Useful information provided includes the object name, object description and library information including the current revision in use. Columns available in the view are displayed below:

100

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

� ProjectsDetail: Provides information about projects available within the ACM database. Useful information includes the project name and library information for each project type library. Columns available in the view are displayed below:
� SubObjectDetail: Provides information about sub objects linked to objects within the ACM database. Useful information includes the name for the object to which the sub object belongs, the descripiton for the object to which the sub object belongs, sub object name, sub object description and library information for the object to which the sub object belongs. The columns available in the view are displayed below:

� SubParameterDetail: Provides information about sub parameters belonging to sub objects. These sub objects in turn would belong to a specific object. Useful information provided includes the sub parameter name, datatype, reference type, name of the sub object and

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

101

Chapter 6

Use ACM Tools

library information for the object to which the sub parameters parent (sub object) belongs. The columns available in the view are displayed below:

Practical Scenario Overview:
The number of instances created in an ACM project for the library with CatlogNumber MsDinSiS are needed for a project management meeting. This information can be easily obtained from the ACM database via the use of a number of SQL queries. The first step is to get the Project Id of the relevant project in ACM. We know the name of the project and can get the Id from the Projects table via a SQL statement. The first step is to open either a query window within Microsoft SQL Server Management Studio, a new command line session for Microsoft sqlcmd or via the use of any other tool that provides access to the ACM database for querying purposes.
The following SQL query will retrieve the ProjectID for the known project name "RAMSProjectSmall":
SELECT ProjectID, Name
FROM [ACM_V400].[dbo].[Projects] WHERE Name = 'RAMSProjectSmall'
In the above query we are returning only the "ProjectID" and "Name" columns for records that match on the name "RAMSProjectSmall". The following result is returned for the given example:

From the above screenshot we can see that the ProjectID we are looking for has a value of 6. The next step is to write a query for the Objects table using the ProjectID with a filter value of 6 which will return only records for this project. In addition to the ProjectID we need to return records for only instances of the library with a catalog number of "MsDinSiS". We are also only interested

102

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

in the total count of returned records and not the records themselves. In order to accomplish this we will use the SQL COUNT instruction. The query to return the required information will look as follows:

SELECT COUNT(*) AS Total FROM [ACM].[dbo].[Objects] WHERE ProjectID = 6 AND CatalogNumber = 'MsDinSiS'

Breakdown and Explanation:

� COUNT(*) AS Total: Ensures that the total number of matched records rather than the records themselves is returned. The returned count column is given the name of "Total".
� FROM [ACM].[dbo].[Objects]: References the Objects table within the ACM database.
� WHERE ProjectID = 6 AND CatalogNumber = 'MsDinSiS': This section of the SQL statement provides the filtering required in order to ensure that only relevant records are returned. Firstly, only records relating to the project with an ID of 6 are returned (ProjectID = 6) and in addition to this, only objects that match on the name 'MsDinSiS' in the CatalogNumber column will be returned.

A total count for the number of matches will be returned in the result. An example is provided for a specific project where 128 matches are found:

See also

Types datasets on page 93

Working with SQL Queries in Document Generation Scripts

A valid SQL query will need to be constructed and verified before it can be incorporated into a document generation script via the use of a SQL: keyword. A basic working knowledge of SQL would be required in order to accomplish this task. Queries would need to be written and tested via a SQL tool in order to determine that no syntax errors are present and that the correct information is returned. Examples of available tools include Microsoft SQL Server Management Studio and the Microsoft sqlcmd utility. More information about both utilities can be obtained via the Microsoft website.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

103

Chapter 6

Use ACM Tools

A dataset returned via a SQL statement would need to be processed within a Document Generation Template via a looping statement in the form of a ##Repeat statement. This statement allows for the Document Generation Engine to process each record within a dataset for output.
Example Query 1
In this example we are going to return a list of all objects within the ACM database. The SQL statement that we will be using is as follows:
SELECT * FROM Objects.
Running this query when connected to a SQL database via SQL Management Studio or sqlcmd will return a list of all data contained within the Objects table within the ACM database.
IMPORTANT In order to provide dataset scoping on raw SQL queries, the documentation engine will create four temporary tables at the beginning of each generation session. The four temporary tables are listed as follows: 1. #Objects 2. #Parameters 3. #SubObjects 4. #SubParameters Each table will contain information pertaining to the currently open ACM project. It is possible to retrieve any information contained in the ACM database though by specifying the specific table or view. As an example, we could retrieve all data from the Objects table which does not have the preceeding "#" in the name as with the temporary table name (#Objects).
We will be using a document generation ##Repeat instruction to print each record contained within the SQL result set which is returned from the database. The statement we will be inserting into the Document Template Editor is as follows:
##Repeat.1(SQL: SELECT * FROM Objects) [1.{Name}] ##EndRepeat.1
Once the SQL query completes execution, we will have a dataset containing matched data from the database. This matched data object can be thought of as a temporary table of information existing in memory. The ##Repeat instruction will be used to iterate through this temporary table and in the above example we have elected to return data from the column named "Name". This column must exist within the returned dataset. Any column can be selected for returned data and the original ACM Objects table can be reviewed to check on what columns may contain information that may be useful for the task at hand. As an example: information on each object may be required and the required columns that are need are known ("Name" and "Description" columns in the Objects table). All columns are specified to be returned via the SQL statement by using the "*" wildcard character: (SELECT * FROM Objects). The following document generation script will enable us to return the information as required:

104

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

##Repeat.1(SQL: SELECT * FROM Objects) [1.{Name}], [1.{Description}] ##EndRepeat.1

Chapter 6

Use ACM Tools

The highlighted section above shows the columns that will be returned ("Name" and "Description" fields). Running this script within the Document Template Editor would return a list of all information contained within the Objects table of the ACM database. Below is an example of output from the above script (returned information will vary depending on how the objects are created within the ACM database):

MyProject, Project Information

My_Controller, ControlLogix Controller

Controller_Fault_Handler, Task Description

PowerUp_Handler, Task Description

Unscheduled, Task Description

FTAlarmEvent_Server, FactoryTalk Alarms and Events

FTViewSE_Server, FactoryTalk View SE Display

FTHistorianSE_Server, FactoryTalk Historian SE Scan Classes

Looking at the information returned above, we may decide that we only want to return objects related to the currently opened ACM project. Earlier in this section we spoke of the four temporary tables created behind the scenes when running a document generation script. One of these tables (#Objects) contains information pertaining to objects for the current ACM project. Switching the SQL script to use the temporary objects table can be achieved by changing the table name to the temporary table name:

SQL: SELECT * FROM #Objects

The complete script would now look as follows:

##Repeat.1(SQL: SELECT * FROM #Objects) [1.{Name}], [1.{Description}] ##EndRepeat.1

Example Query 2
In this example we are going to be querying information from the temporary objects table which will provide information relating to the current ACM project only. We are going to retrieve information on objects relating to a specific library. Once again, we are going to be selecting the "Name" and "Description" fields but this time the query will be optimized and will only return these fields to the dataset. We will replace the "*" wildcard used in the previous query with the actual fields we want to return.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

105

Chapter 6

Use ACM Tools

Search parameters will be to a specific library so that we return objects for this library only. The WHERE part of the SQL statement will accomplish this and provide the filter. The catalog number field within the #Objects temporary table will be used where we will be returning records that match the value as specified. In the test example only record matches will be returned where the CatalogNumber column equals the value `MsVlv2sS'.
The statement we will be inserting into the Document Template Editor is as follows:
##Repeat.1(SQL: SELECT Name, Description FROM #Objects WHERE CatalogNumber='MsVlv2sS') [1.{Name}], [1.{Description}] ##EndRepeat.1
As can be seen via the highlighted section, we have replaced the "*" wildcard used in example 1 with the actual field names that are required from the dataset. This will improve efficiency and will be seen in the speed of execution of the query with only the required columns returned.
Once again, each record that is returned in the result-set will be processed by the ##Repeat instruction and we will be returning both available columns, namely "Name" and "Description".
Below is an example of some returned information (returned information will vary depending on how the objects are created within the ACM database):
XV_0001, Valve Two State 1
XV_0002, Valve Two State 2
XV_0003, Valve Two State 3
XV_0004, Valve Two State 4
XV_0005, Valve Two State 5
Advanced Query
The following sample will return all libraries in use for a specific library type.
The SQL statement that we will be using is as follows:
SELECT COUNT(libs.CatalogNumber) AS Qty, libs.CatalogNumber, libs.Description
FROM #Objects AS objs INNER JOIN RegisteredLibraries AS libs
ON objs.LibraryID = libs.LibraryID
WHERE libs.LibraryType = 'ControlModule'
GROUP BY libs.CatalogNumber, libs.Description
ORDER BY libs.CatalogNumber

106

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 6

Use ACM Tools

The above query selects information across two tables (#Objects and RegisteredLibraries) and returns all libraries of the type `ControlModule' in use within the currently loaded ACM project as we are querying information from the temporary #Objects table as discussed earlier.

Note that the query above is making use of the temporary #Objects table. The "#" will need to be removed when testing this query with a SQL tool like SQL Management Studio or sqlcmd as the temporary Objects table is only created by the Documentation Generation Engine when a documentation generation script is run within ACM. An error will be generated if the "#" is not removed as the table does not exist within the ACM database.

The complete document generation script would look as follows:

##Repeat.1(SQL: SELECT COUNT(libs.CatalogNumber) AS Qty, libs.CatalogNumber, libs.Description FROM #Objects AS objs INNER JOIN RegisteredLibraries AS libs ON objs.LibraryID = libs.LibraryID WHERE libs.LibraryType = 'ControlModule'GROUP BY libs.CatalogNumber, libs.Description ORDER BY libs.CatalogNumber) [1.{Qty}] [1.{CatalogNumber}] [1.{Description}] ##EndRepeat.1

Once the data has been retrieved from the database, the result-set is then processed and itereated through via the ##Repeat instruction. Three columns would be created in the output. The first column would display the number of instances in which the selected library is used, followed by the catalog number for the library and finally the libraries description information in the last column.

Below is an example of some returned information (returned information will vary depending on how the objects are created within the ACM database):

112 MsAinSiS Analog Input

128 MsDinSiS Digital Input

128 MsVlv2sS

Valve Two State

Add ACM library content to an existing ACD project

See also
Raw SQL data on page 94 Add content from the ACM library to an existing ACD project by opening the ACD in Application Code Manager.

To add ACM library content to an ACD project
1. Click Tools and click Open Target ACD. The Open dialog will display. 2. Select the desired ACD file and click Open. 3. The Target ACD File tab will replace the Controller Preview pane.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

107

Chapter 6

Use ACM Tools

4. Drag and drop content from the registered libraries or an existing ACM project to the Target ACD File tab. The Target ACD Generation Wizard - Object Configuration page appears.
Tip: Click the Override Calculated Parameters button to unlock the calculated parameter of this object. The unlocked calculated parameter can be edited. After editing, click the Enforce Calculated Parameters button to lock this parameter.
5. (optional) Click Options > Include Project Data to include all instances with their parameter values, as well as all libraries (zipped) will be included as part of the Controller's Custom Properties.
6. Resolve any values in the Unresolved Names page, then click Next. The Target ACD Generation Wizard - Merge Actions page appears.
7. Review the list of merge actions. � If any merge actions are incorrect, click Back to update the parameters as needed. � If the merge actions are correct, click Next.
The Target ACD Generation Wizard - L5X Generation Successful page appears.
8. Click Finish. The Save As dialog box opens. In File name either: � Type a new name for the ACD file that contains the merged content. � Leave the original name to overwrite the existing ACD project (default).
9. Click Save to save the target ACD file.
See also
Update a project library on page 37

108

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Reports

Chapter 7

Reports
Report Project History All Library Usage (Current Project)

Application Code Manager includes a variety of reports to help you track the usage of code objects in your projects.
This table lists the reports available:
Description
For the current project, shows the major revision, minor revision, the user account that made the revision, the date and time that the revision occurred, the comment associated with the revision, and the status of the project at the revision point. For the current project, shows the name of the solution, the type of library, the category of the library object, the catalog number of the library object, the major revision of the library, the minor revision of the library, the number of usages of the library object in the project, and the status of the library.

Library Usage per Solution (Current Project) Library Usage per Library Type (Current Project) Library Usage per Category (Current Project)

For the selected library in the current project, shows the type of library, the category of the library object, the catalog number of the library object, the major revision of the library, the minor revision of the library, the number of usages of the library object in the solution, and the status of the library.
For the selected library type in the current library of the current project, shows the category of the library object, the catalog number of the library object, the major revision of the library, the minor revision of the library, the number of usages of the library object in the solution, and the status of the library. For the selected category in the selected library type of the current library associated with the current project, shows the catalog number of the library object, the major revision of the library, the minor revision of the library, the number of usages of the library object in the solution, and the status of the library.

Library Usage for Selected Library (Current Project)

For the selected library object within a selected category in the selected library type of the current library associated with the current project, shows the total number of times the library object is referenced and the number of times the object is used by each controller in the current project.

Chassis Layout I/O Schedule Network Layout Library Usage per Project

For the chassis of the selected controller object, shows the slot assignments, module names, module type, and module information.
For the selected I/O module of the current controller object, shows the I/O points, type, module information, and description.
For the selected communication module of the current controller object, shows the IP Address assigned to the module the module name, the module type, and connections information.
For the connected ACM database, shows the solution, the library type, the library category, the catalog number, the major revision, the minor revision and the number of times used in projects.

Pending Libraries in database Library Usage per Solution in database Pending Libraries per Solution in database
Library Usage per Library Type in database

For the connected ACM database, shows the libraries that have not yet been published. Identifying them by solution, library type, category, catalog number, major revision and minor revision. For the selected solution in the connected ACM database, shows the library type, the library category, the catalog number, the major revision, the minor revision and the number of times used in projects. For the selected solution in the connected ACM database, shows the libraries that have not yet been published. Identifying them by library type, category, catalog number, major revision and minor revision.
For the selected library type of a solution in the connected ACM database, shows the library category, the catalog number, the major revision, the minor revision and the number of times used in projects.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

109

Chapter 7

Reports

Report

Pending Libraries per Library Type in database

Library Usage for Selected Library in database

Description For the selected library type of a solution in the connected ACM database, shows the libraries that have not yet been published. Identifying them by category, catalog number, major revision and minor revision.
For the selected library object within a library type, shows the total number of times the object is used and the usages per project.

See also

Report command reference on page 110

Generate a report on page 111

View registered library usage on page 43

Report command reference Reports are generated by selecting the report command from the View
context menu. Different reports are available depending on the object selected.

Use this table to locate each report. Items enclosed in brackets [] are replaced by the name of the item in your ACM database.

Report
Project History Project Library Usage

Command
System View > [Project] > View > Project History System View > [Project] > Used Libraries > View > Project Library Usage Count

Project Library Usage per Solution
Project Library Usage per Solution, Library Type Project Library Usage per Solution, Library Type, Category
Project Library Usage per Library

System View > [Project] > Used Libraries > [Library folder] > View > Project Library Usage per Solution
System View > [Project] > Used Libraries > [Library folder] > [Library type folder] > View > Project Library Usage per Library Type System View > [Project] > Used Libraries > [Library folder] > [Library type folder] > [Library category folder] > View > Project Library Usage per Category
System View > [Project] > Used Libraries > [Library folder] > [Library type folder] > [Library category folder] > [Library object] > View > Project Library Usage per Library

Chassis Layout

Controller Preview > [Controller object] > I/O Configuration > View > Chassis Layout

I/O Schedule Network Layout
Library Usage

Controller Preview > [Controller object] > I/O Configuration > Backplane > [I/O Module] > View > Module I/O Schedule for Rack Module Controller Preview > [Controller object] > I/O Configuration > Backplane > [Communication Module] > View > Network Layout
Registered Libraries > View > Library Usage

Pending Libraries Database Library Usage per Solution

Registered Libraries > View > Pending Libraries Registered Libraries > [Solution] > View > Library Usage per Solution

110

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Report Database Pending Libraries per Solution

Command Registered Libraries > [Solution] > View > Pending Libraries per Solution

Chapter 7

Reports

Database Library Usage per Library Type Database Pending Libraries per Library Type Database Library Usage per Library

Registered Libraries > [Solution] > View > Library Usage per Library Type Registered Libraries > [Solution] > [Library Type] > View > Pending Libraries per Library Type Registered Libraries > [Solution] > [Library Type] > [Library Object} > Library Usage per Library Type

Generate a report

See also
Reports on page 109 Generate a report on page 111 Reports are generated from the View context menu. Different reports are available depending on the object selected.

To generate a report
1. Select the object in the tree that you want to report on. Reports are available from objects in the System View, Controller Preview, Class View, and Registered Libraries panes.
2. Right-click the object, select View and then choose the report to run. 3. The report appears in a new window.
� If there are multiple pages in the report, use the navigation controls to move forwards and backwards through the report information.
� To rerun the report to incorporate changed information, click Refresh.
� To send the report to a printer, click Print.
The Print dialog box opens. Confirm the printer in Select Printer is correct. Optionally, specify the Page Range and Number of copies to print. By default one copy of all pages in the report are printed. Click Print to print the report.
� To save the report to a file, click Export and then choose Excel, PDF, or Word.
The Save As dialog box opens. In File name, type a name for the report being exported. Save as type is already selected for the appropriate file format (.pdf, .xlsx, or .docx). Click Save to save the report

See also

Generate detailed command information on page 115

ACM Console on page 113

Open the ACM Console on page 114

Generate detailed command Use the help function in the ACM Console to provide detailed information

information

about a specific command.

To generate detailed command information
1. Open the ACM Console. 2. Type help then the full command and then press Enter.
Example: type help exportproject, then press Enter. Detailed information on the exportproject command displays.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

115

Chapter 8

ACM Console

Console scripts

See also
ACM Console on page 113
Open the ACM Console on page 114
A console script is a text file (.txt) containing a set of valid Application Code Manager Console commands. The commands are run in order, top to bottom.
If using the CREATEPROJECT, CREATECONTROLLER, or CREATEOBJECTS commands, the console script requires an Extended script (.xml) file. The Extended script is called as part of the command to provide data to Application Code Manager about the project, controller, or object that is created.

See also

Create an Application Code Manager Console script on page 116

Run an Application Code Manager Console script on page 116

Extended scripts on page 117

Create an Application Code Create an Application Code Manager Console script to store a set of

Manager Console script

commands for later or repeated use.

To create an Application Code Manager Console script
1. Open a text editor, such as Notepad. 2. Enter one or more valid Application Code Manager Console
commands into the script.
IMPORTANT Only enter one Application Code Manager Console command per line of the script.

3. Save the script as a plain text (.txt) file.

Run an Application Code Manager Console script

See also
Run an Application Code Manager Console script on page 116 ACM Console on page 113 Run an Application Code Manager Console script to execute a set of predefined commands on the Application Code Manager database.

To run an Application Code Manager Console script
1. Double-click the ACM Console shortcut on the desktop. 2. Select File > Run Script. 3. In Select an ACM Script File locate the file, then click Open.

116

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Chapter 8

ACM Console

The script executes.

Alternatively:

� At the Application Code Manager Console prompt, type run filelocationpath\scriptfilename.txt, then press Enter.
Replace filelocationpath with the file path, such as C:\Users\<username>\Desktop\ and scriptfilename.txt with the script filename.

Extended scripts

See also
ACM Console on page 113
An Extended script is an XML (.xml) file that contains information about a project, controller, or library object. The Extended script is called from a CREATE command in an Application Code Manager Console script, which passes the object data contained in the Extended script to the Application Code Manager database.
Projects and controllers may not be defined in the same XML file. For best results, create three Extended scripts: one for the project, one for the controller, and one for all the associated objects.
Tip: When creating a Project or Controller XML file, set up a reference (@Project or @Controller) to use the project name passed in from the Application Code Manager Console script. This allows a single Project or Controller XML file to be used for multiple projects.
An example of an Application Code Manager Console script that calls an Extended script is:
BEGINCREATE CREATEPROJECT "myProject" "C:\Script Files\Project.xml" CREATECONTROLLER "myProject" "myController" "C:\Script Files\Controller.xml" CREATEOBJECTS "myProject" "myController" "C:\Script Files\Objects.xml"
ENDCREATE

Generate an example Extended script

See also
Generate an example Extended script on page 117 Generate an example Extended script to copy and paste the XML structures and parameters to a new Extended script file for editing.

To generate an example Extended script
1. Create a Project, Controller, and Object in Application Code Manager.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

117

Chapter 8

ACM Console

Library <IObj>
Attribute Name Task Program Description Guid
Sol Catalog Number Maj Min
Parameter <IPar>
Attribute Name Value
118

2. Generate an L5X controller file with the ACM Project Data option enabled.
3. Open the .L5X controller file in a text editor. 4. Copy the <IObjs> and <ICOObjs> nodes to a new Extended script file.
See also
Generate a controller file on page 48
The Library <IObj> node represents a library instance configuration.
Parent node:
� <IObjs>
Description The name of the library object instance. The task name in which the instantiated library content will reside if the library is a task type library. If applicable, Project and Controller objects may be left empty. The program name in which the instantiated library content will reside if the library is a program type library. If applicable, Project and Controller objects may be left empty. The description message of the library instance. The unique ID of the library in the ACM database. During instantiation, if a Guid is supplied, the database is queried to find a match. � If the Guid is supplied then the Sol, Catalog Number, Maj and Min
attributes are ignored. � If the Guid is not supplied then Sol and Catalog Number must be
supplied. The solution category defined within the library. This is a mandatory field if Guid is not supplied. The catalog number as defined within the library. This is a mandatory field if Guid is not supplied. The major revision number of the library. This is an optional field. If omitted and Guid is not supplied then the highest major library revision number will be selected. The minor revision number of the library. This is an optional field. It can only be included if the Maj attribute is present. If it is excluded then the highest minimum library revision number will be selected.
The Parameter <IPar> node represents a library parameter.
Parent node:
� <IPars>
Description The name of the parameter. This is a mandatory field and must be supplied. The value assigned to the parameter. This is a mandatory field and must be supplied.
Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Attribute RefVal
SubObject <ISObj>
Attribute Name Type Description OverrideDesc
Linked Library <ILLib>
Attribute Name Value

Chapter 8

ACM Console

Description

This attribute only applies to reference type parameters. If supplied, this value adds the reference to the parameter value, such as #refvalue. If not supplied, then a reference value is not added to the parameters value.

The SubObject <ISObj> node represents a Sub Object. SubObject parameters must be supplied as <IPar> nodes within the child <IPars> node. Parent node:
� <ISObjs> Child node(s):
� <IPars>

Description
The name of the SubObject, such as Inp_Intlk01. The type of SubObject, such as Interlock.
The description of the SubObject. If formatting is applied to the SubObject description field in the library and this field is set to true, then the description can be overridden.

The Linked Library <ILLib> node represents a linked library reference. Parent node:
� <ILLibs>

Description
The name displayed for the Linked Library. The instance name of the target library.

Interface Links <IILink>

The Interface Links <IILink> node represents an interface link for a library instance. An Interface Link requires one <IMems> child nodes and one or more <IMem> grandchild nodes.
Parent node: � <IObjs>
Child node(s): � <IMems>

Attribute Name

Description The name of the interface link.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

119

Chapter 8 Attribute Keying

ACM Console

RefInt

Description
Can either be specified as ExactMatch or Disabled. ExactMatch: ACM matches input members against their respective Key Id and Revision field values. Disabled: ACM does not match input members against their respective Key Id and Revision field values. A reference to the library instance to which the Interface Link points.

See also
Interface Members <IMem> on page 120
Interface Members <IMem> The Interface Member <IMem> node represents the configuration of an
Interface Link member. Parent node:
� <IMems>

Attribute Name Value
RefVal

Description
The name of the Interface Member. The library instance name and output interface member to which to connect. The name of the output interface member in the destination library.

Controller Object <ICOObj>

See also
Interface Links <IILink> on page 119 The Controller Object <ICOObj> node represents an object that appears in the Application Code Manager Controller Preview pane. Controller Objects are only required when additional object configuration is required for a controller object, such as Instance Execution Ordering. Parent node:
� <ICOObjs>

Attribute
Name Obj COParent Type NameSub

Description
The name to be assigned to the controller object. The instantiated name of the library object. The name of the parent within which the object resides. The type of object, such as PROGRAM, ROUTINE, or AOI. The substitution name, if applied.

120

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

Attribute Order
MarkDel MainRtn
InstExecOrder

Chapter 8

ACM Console

Description

Specifies where a routine would be displayed under its parent program node within the ACM Controller Preview panel. For example, a routine with an Order value of 0 is displayed at the top of the tree. A routine with an Order value of 1 is displayed next in the list.
Excludes an AIO for a specific controller.
Specifies the level of the routine. 2: Sets the routine as the active routine. 1: Sets the routine as an inactive routine. 0: Sets the routine as a normal routine.
Specified for ROUTINE types, otherwise the value is blank. The value specifies the routine execution order number. This value will determine in what sequence routines are processed when generating a controller from within ACM.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

121

Legal Notices

Legal Notices
Rockwell Automation publishes legal notices, such as privacy policies, license agreements, trademark disclosures, and other terms and conditions on the Legal Notices page of the Rockwell Automation website.
End User License Agreement (EULA)
You can view the Rockwell Automation End User License Agreement (EULA) by opening the license.rtf file located in your product's install folder on your hard drive. The default location of this file is:
C:\Program Files (x86)\Common Files\Rockwell\license.rtf.
Open Source Software Licenses
The software included in this product contains copyrighted software that is licensed under one or more open source licenses. You can view a full list of all open source software used in this product and their corresponding licenses by opening the index.html file located your product's OPENSOURCE folder on your hard drive. The default location of this file is:
C:\Program Files\Rockwell Automation\Application Code Manager\Release Notes\OPENSOURCE\index.htm You may obtain Corresponding Source code for open source packages included in this product from their respective project web site(s). Alternatively, you may obtain complete Corresponding Source code by contacting Rockwell Automation via the Contact form on the Rockwell Automation website: http://www.rockwellautomation.com/global/aboutus/contact/contact.page. Please include "Open Source" as part of the request text.

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020

123

Rockwell Automation support

Use these resources to access support information.

Technical Support Center
Knowledgebase Local Technical Support Phone Numbers

Find help with how-to videos, FAQs, chat, user forums, and product notification updates. Access Knowledgebase articles. Locate the telephone number for your country.

rok.auto/support
rok.auto/knowledgebase rok.auto/phonesupport

Literature Library
Product Compatibility and Download Center (PCDC)

Find installation instructions, manuals, brochures, and technical data publications. Get help determining how products interact, check features and capabilities, and find associated firmware.

rok.auto/literature rok.auto/pcdc

Documentation feedback
Your comments help us serve your documentation needs better. If you have any suggestions on how to improve our content, complete the form at rok.auto/docfeedback.
Waste Electrical and Electronic Equipment (WEEE)
At the end of life, this equipment should be collected separately from any unsorted municipal waste.
Rockwell Automation maintains current product environmental information on its website at rok.auto/pec.

Allen-Bradley, expanding human possibility, Logix, Rockwell Automation, and Rockwell Software are trademarks of Rockwell Automation, Inc. EtherNet/IP is a trademark of ODVA, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies. Rockwell Otomayson Ticaret A.. Kar Plaza Merkezi E Blok Kat:6 34752, �erenk�y, stanbul, Tel: +90 (216) 5698400 EEE Y�netmeliine Uygundur

Rockwell Automation Publication LOGIX-UM003G-EN-P-December 2020
Rockwell Automation Publication LOGIX-UM003F-EN-P-October 2020
