Motherboard
TUF GAMING B660-PLUS WIFI D4
E18947 First Edition September 2021
Copyright � 2021 ASUSTeK COMPUTER INC. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. ("ASUS"). Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing. ASUS PROVIDES THIS MANUAL "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT. SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT. Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners' benefit, without intent to infringe.
ii
Contents
Safety information...................................................................................................... iv About this guide.......................................................................................................... v Package contents....................................................................................................... vi TUF GAMING B660-PLUS WIFI D4 specifications summary.................................. vi
Chapter 1
Product Introduction
1.1 Before you proceed...................................................................................... 1-1
1.2 Motherboard layout ...................................................................................... 1-1
1.3 Central Processing Unit (CPU).................................................................... 1-9
1.4 System memory.......................................................................................... 1-11
1.5 M.2 installation............................................................................................ 1-13
1.6 Wi-Fi antenna installation .......................................................................... 1-18
Chapter 2
BIOS and RAID Support
2.1 Knowing BIOS............................................................................................... 2-1
2.2 BIOS Setup program .................................................................................... 2-2
2.3 ASUS EZ Flash 3........................................................................................... 2-3
2.4 ASUS CrashFree BIOS 3.............................................................................. 2-4 2.5 RAID configurations..................................................................................... 2-5
Appendix Notices ..................................................................................................................... A-1 Warranty................................................................................................................... A-8 ASUS contact information.................................................................................... A-10 Service and Support ............................................................................................. A-10
iii
Safety information Electrical safety
� To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.
� When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.
� Before connecting or removing signal cables from the motherboard, ensure that all power cables are unplugged.
� Seek professional assistance before using an adapter or extension cord. These devices could interrupt the grounding circuit.
� Ensure that your power supply is set to the correct voltage in your area. If you are not sure about the voltage of the electrical outlet you are using, contact your local power company.
� If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer.
Operation safety
� Before installing the motherboard and adding components, carefully read all the manuals that came with the package.
� Before using the product, ensure all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer immediately.
� To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and circuitry.
� Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may be exposed to moisture.
� Place the product on a stable surface. � If you encounter technical problems with the product, contact a qualified service
technician or your retailer. � Your motherboard should only be used in environments with ambient temperatures
between 0�C and 40�C.
iv
About this guide
This user guide contains the information you need when installing and configuring the motherboard.
How this guide is organized
This guide contains the following parts: � Chapter 1: Product Introduction
This chapter describes the features of the motherboard and the new technology it supports. It includes descriptions of the switches, jumpers, and connectors on the motherboard. � Chapter 2: BIOS Information This chapter tells how to boot into the BIOS, and upgrade BIOS using the EZ Flash Utility.
Where to find more information
Refer to the following sources for additional information and for product and software updates. 1. ASUS website
The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information. 2. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer. These documents are not part of the standard package.
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual.
CAUTION: Information to prevent damage to the components and injuries to yourself when trying to complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to help you complete a task.
v
Package contents
Check your motherboard package for the following items.
Motherboard Cables
Miscellaneous
Application DVD Documentation
1 x TUF GAMING B660-PLUS WIFI D4 motherboard
2 x SATA 6Gb/s cables
1 x ASUS Wi-Fi moving antennas 1 x M.2 Rubber Package 1 x M.2 SSD screw package 1 x TUF Gaming sticker
1 x Support DVD 1 x TUF Certification card 1 x User guide
If any of the above items is damaged or missing, contact your retailer.
TUF GAMING B660-PLUS WIFI D4 specifications summary
CPU Chipset Memory
Graphics Expansion Slots
Intel� Socket LGA1700 for 12th Gen Intel� CoreTM, Pentium� Gold and Celeron� Processors*
Supports Intel� Turbo Boost Technology 2.0 and Intel� Turbo Boost Max Technology 3.0**
* Refer to www.asus.com for CPU support list. ** Intel� Turbo Boost Max Technology 3.0 support depends on the CPU types.
Intel� B660 Chipset
4 x DIMM, Max. 128GB, DDR4 5333(OC)/5000(OC)/4800(OC)/4600(OC)/ 4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/ 3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture Supports Intel� Extreme Memory Profile (XMP) OptiMem II
* Actual Memory data rate depends on the CPU types and DRAM modules, for more information refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
1 x DisplayPort** 1 x HDMI� port*** * Graphics specifications may vary between CPU types. Please refer to www.
intel.com for any updates. ** Supports 4K@60Hz as specified in DisplayPort 1.4. ***Supports 4K@60Hz as specified in HDMI� 2.1.
Intel� 12th Gen Processors
1 x PCIe 5.0/4.0/3.0 x16 slot Intel� B660 Chipset*
1 x PCIe 3.0 x16 slot (supports x4 mode) 2 x PCIe 3.0 x1 slots * Supports Intel� Optane Memory H Series on PCH-attached PCIe slot.
(continued on the next page)
vi
TUF GAMING B660-PLUS WIFI D4 specifications summary
Storage Ethernet Wireless & Bluetooth USB
Audio
Back Panel I/O Ports
Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports Intel� 12th Gen Processors M.2_1 slot (Key M), type 2242/2260/2280/22110 - Intel� 12th Gen processors support PCIe 4.0 x4 mode. Intel� B660 Chipset M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode) M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4
mode) 4 x SATA 6Gb/s ports * Intel� Rapid Storage Technology supports SATA RAID 0/1/5/10. ** Intel� Rapid Storage Technology supports Intel� Optane Memory H Series on
PCH attached M.2 slots. 1 x Intel� 2.5Gb Ethernet TUF LANGuard Wi-Fi 6 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) Supports 2.4/5GHz frequency band Bluetooth v5.2 Rear USB (Total 6 ports) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C�) 1 x USB 3.2 Gen 2 port (1 x Type-A) 3 x USB 3.2 Gen 1 ports (3 x Type-A) 1 x USB 2.0 port (1 x Type-A) Front USB (Total 7 ports) 1 x USB 3.2 Gen 2 connector (supports USB Type-C�) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Realtek 7.1 Surround Sound High Definition Audio CODEC - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback Audio Features - Rear optical S/PDIF out port - Premium audio capacitors - Dedicated audio PCB layers - Audio cover 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C�) 1 x USB 3.2 Gen 2 port (1 x Type-A) 3 x USB 3.2 Gen 1 ports (3 x Type-A) 1 x USB 2.0 port (1 x Type-A) 1 x DisplayPort 1 x HDMI� port 1 x Wi-Fi Module 1 x Intel� 2.5Gb Ethernet port 5 x Audio jacks 1 x Optical S/PDIF out port
(continued on the next page)
vii
TUF GAMING B660-PLUS WIFI D4 specifications summary
Internal I/O Connectors
Special Features
Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 3 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector 1 x 4-pin +12V Power connector Storage related 3 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2 connector (supports USB Type-C�) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x AURA RGB header 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x ThunderboltTM header
ASUS TUF PROTECTION - DIGI+ VRM (- Digital power design with DrMOS) - Enhanced DRAM Overcurrent Protection - ESD Guards - TUF LANGuard - Overvoltage Protection - SafeSlot - Stainless-Steel Back I/O
ASUS Q-Design - M.2 Q-Latch - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot
ASUS Thermal Solution - M.2 heatsink - VRM heatsink design
ASUS EZ DIY - CPU Socket lever protector - ProCool - Pre-mounted I/O shield - SafeDIMM
(continued on the next page)
viii
TUF GAMING B660-PLUS WIFI D4 specifications summary
Special Features
Software Features
BIOS Manageability Operating System Form Factor
AURA Sync - AURA RGB header - Addressable Gen 2 headers
ASUS Exclusive Software Armoury Crate
- AURA Creator - AURA Sync - Fan Xpert 4 - Two-Way AI Noise Cancelation AI Suite 3 - Performance And Power Saving Utility
TurboV EVO EPU DIGI+ VRM TUF GAMING CPU-Z DTS Audio Processing MyASUS Norton Anti-virus software (Free Trial version) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode 128 Mb ROM, UEFI AMI BIOS WOL by PME, PXE Windows� 11 64-bit, Windows� 10 64-bit ATX Form Factor 12 inch x 9.6 inch (30.5 cm x 24.4 cm)
� Specifications are subject to change without notice. Please refer to the ASUS website for the latest specifications.
� MyASUS offers a variety of support features such as helping to troubleshoot issues, optimizing product performance, integrating ASUS software, and recovery drive creation. Please scan the QR Code for installation guide and FAQ.
ix
x
Product Introduction
1
1.1 Before you proceed
Take note of the following precautions before you install motherboard components or change any motherboard settings.
� Unplug the power cord from the wall socket before touching any component.
� Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity.
� Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components.
1.2 Motherboard layout
Place this side towards the rear of the
chassis
HDMI_DP
U2_11 U32G1_10
5
ATX_12V_2 ATX_12V_1
41
4
24.4cm(9.6in)
CPU_FAN
CPU_OPT
DIGI+ VRM
U32G2X2_C1 LAN_U32G2_3
U32G1_E34 M.2(WIFI)
AUDIO
Intel Ethernet
M.2_1(SOCKET3)
PCIE 4.0 X4
SATA X
LGA1700
DDR4 DIMM_A1 (64bit, 288-pin module) DDR4 DIMM_A2 (64bit, 288-pin module) DDR4 DIMM_B1 (64bit, 288-pin module) DDR4 DIMM_B2 (64bit, 288-pin module)
2
ADD_GEN 2_2 ADD_GEN 2_3
11
CPU DRAM
VGA BOOT
18
5
ATX_PWR
8 9
U32G1_E12 U32G2_4
30.5cm(12in)
M.2_1(SOCKET3) CHA_FAN1 AIO_PUMP
SATA6G_4 SATA6G_3
2242
2260
2280
22110
6
PCIEX16(G5)
7
BATTERY
Intel� B660
3
PCIEX1(G3)_1
Super
I/O
128Mb BIOS
M.2_3(SOCKET3) M.2_2(SOCKET3)
PCIEX1(G3)_2
PCIE SATA Optane Memory
PCIE SATA
4.0 X4
X
V
COM_DEBUG
4.0 X2
X
6
M.2_3(SOCKET3) M.2_2(SOCKET3)
Audio Codec
22110
AAFP
15
2280
2260
2242
2242
2260
2280
COM
14
PCIEX16(G3)
TB_HEADER
USB_56 RGB_HEADER
ADD_GEN 2_1
USB_78
SATA6G_1
CLRTC SATA6G_2 PANEL
CHA_FAN2 CHA_FAN3
17 11 12 10
4
7 13 16
� Unplug the power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components.
The pin definitions in this chapter are for reference only. The pin names depend on the location of the header/jumper/connector.
ASUS TUF GAMING B660-PLUS WIFI D4
1-1
1.2.1 Layout contents
1. CPU socket The motherboard comes with a LGA1700 socket designed for 12th Gen Intel� CoreTM processors, Pentium� Gold and Celeron� Processors.
For more details, refer to Central Processing Unit (CPU).
2. DDR4 DIMM slots The motherboard comes with Dual Inline Memory Modules (DIMM) slots designed for DDR4 (Double Data Rate 4) memory modules.
For more details, refer to System memory.
3. Expansion slots
This motherboard supports two PCIe x16 graphics cards and two PCIe 3.0 x1 network cards, SCSI cards and other cards that comply with the PCI Express specification.
4. Fan headers The Fan headers allow you to connect fans to cool the system.
Header
CPU_FAN CPU_OPT AIO_PUMP CHA_FAN1 CHA_FAN2 CHA_FAN3
Max. Current
1A 1A 1A 1A 1A 1A
Max. Power
12W 12W 12W 12W 12W 12W
Default Speed
Q-Fan Controlled Q-Fan Controlled
Full-Speed Q-Fan Controlled Q-Fan Controlled Q-Fan Controlled
Shared Control
A A -
FAN PWM FAN IN
FAN PWR GND
FAN PWM FAN IN
FAN PWR GND GND FAN PWR FAN IN FAN PWM
5. Power connectors
These Power connectors allow you to connect your motherboard to a power supply. The power supply plugs are designed to fit in only one orientation. Find the proper orientation and push down firmly until the power supply plugs are fully inserted.
Ensure to connect the 8-pin power plug.
� For a fully configured system, we recommend that you use a power supply unit (PSU) that complies with ATX 12V Specification 2.0 (or later version) and provides a minimum power of 350 W.
� We recommend that you use a PSU with a higher power output when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate.
� If you are uncertain about the minimum power supply requirement for your system, we recommend you to refer to online resources for Power Supply Wattage Calculator.
� If you want to use two or more high-end PCI Express x16 cards, use a PSU with 1000W power or above to ensure the system stability.
1-2
Chapter 1: Product Introduction
6. M.2 slots (Key M) The M.2 slots allow you to install M.2 devices such as M.2 SSD modules.
� M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 X4) � M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 X2) � M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 X4) � To enable Intel� OptaneTM Memory (Hybrid Storage device), it must be installed in
PCH-attached slots with Intel� Rapid Storage Technology.
7. SATA 6Gb/s ports The SATA 6Gb/s ports allow you to connect SATA devices such as optical disc drives and hard disk drives via SATA cables.
8. USB 3.2 Gen 2 connector (supports USB Type-C�)
SBU2
VBUS
The USB 3.2 Gen 2 header (USB Type-C�) allows you to connect a
SBU1 CC1
TX2+ TX2-
USB 3.2 Gen 2 module for an additional USB 3.2 Gen 2 Type-C� port.
VBUS RX1RX1+
GND RX2+ RX2-
The header provides a data transfer speed of up to 10 Gb/s.
GND TX1-
GND D-
TX1+
D+
VBUS
CC2
9. USB 3.2 Gen 1 header The USB 3.2 Gen 1 header allows you to connect a USB 3.2 Gen 1 module for additional USB 3.2 Gen 1 ports. The USB 3.2 Gen 1 header provides data transfer speeds of up to 5 Gb/s.
The USB 3.2 Gen 1 module is purchased separately.
USB3+5V IntA_P2_SSRXIntA_P2_SSRX+
GND IntA_P2_SSTXIntA_P2_SSTX+
GND IntA_P2_DIntA_P2_D+
PIN 1
USB3+5V IntA_P1_SSRXIntA_P1_SSRX+ GND IntA_P1_SSTXIntA_P1_SSTX+ GND IntA_P1_DIntA_P1_D+ GND
USB+5V USB_P9USB_P9+ GND NC
10. USB 2.0 headers
The USB 2.0 headers allow you to connect a USB module for additional USB 2.0 ports. The USB 2.0 headers provide data transfer speeds of up to 480 Mb/s.
DO NOT connect a 1394 cable to the USB connectors. Doing so will
damage the motherboard!
PIN 1
The USB 2.0 module is purchased separately.
USB+5V USB_P10USB_P10+
GND
11. AURA Addressable Gen 2 headers
ADD_GEN 2
+5V Data Ground
The Addressable Gen 2 headers allow you to connect individually addressable PIN 1 RGB WS2812B LED strips or WS2812B based LED strips.
The Addressable Gen 2 headers support WS2812B addressable RGB LED strips (5V/Data/ Ground), with a maximum power rating of 3A (5V), and the addressable headers on this board can handle a combined maximum of 500 LEDs.
Before you install or remove any component, ensure that the power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components.
� Actual lighting and color will vary with LED strip.
ASUS TUF GAMING B660-PLUS WIFI D4
1-3
� If your LED strip does not light up, check if the addressable RGB LED strip is connected in the correct orientation, and the 5V connector is aligned with the 5V header on the motherboard.
� The addressable RGB LED strip will only light up when the system is powered on.
� The addressable RGB LED strip is purchased separately.
12. AURA RGB header The RGB header allows you to connect RGB LED strips.
The RGB headers support 5050 RGB multi-color LED strips (12V/G/R/B), with a maximum power rating of 3A (12V), and no longer than 3m.
Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components.
� Actual lighting and color will vary with LED strip. � If your LED strip does not light up, check if the RGB LED extension cable and the
RGB LED strip are connected in the correct orientation, and the 12V connector is aligned with the 12V header on the motherboard. � The LED strip will only light up when the system is powered on. � The LED strip is purchased separately.
13. Clear CMOS header This header allows you to clear the CMOS RTC RAM data of the system setup information such as date, time, and system passwords. To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
+3V_BAT GND
CLRTC
PIN 1
2. Use a metal object such as a screwdriver to short the two pins.
3. Plug the power cord and turn ON the computer.
4. Hold down the <Del> key during the boot process and enter BIOS Setup to reenter data.
If the steps above do not help, remove the onboard battery and short the two pins again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the battery.
RXD DTR DSR CTS
14. COM Port header
This header is for a serial (COM) port. Connect the serial port module cable to this header, then install the module to a slot opening at the back of the system chassis.
COM
PIN 1
DCD TXD GND RTS
RI
1-4
Chapter 1: Product Introduction
AGND NC SENSE1_RETUR SENSE2_RETUR
15. Front panel audio header
This header is for a chassis-mounted front panel audio I/O module that supports HD audio standard. Connect one end of the front panel audio I/O module cable to this header.
� We recommend that you connect a high-definition front panel
audio module to this header to avail of the motherboard's highdefinition audio capability.
AAFP
PORT1 L PORT1 R PORT2 R SENSE_SEND PORT2 L
� If you want to connect a high-definition front panel audio module to this header, set the Front Panel Type item in the BIOS Setup to [HD Audio]. By default, this header is set to [HD Audio].
HD-audio-compliant pin definition
16. System Panel header
This header supports several chassis-mounted functions.
� System power LED (4-pin PLED)
This 4-pin header is for the system power LED. Connect the chassis power LED cable to this header. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode.
� Hard disk drive activity LED (2-pin HDD_LED)
This 2-pin header is for the HDD Activity LED. Connect the HDD Activity LED cable to this header. The HDD LED lights up or flashes when data is read from or written to the HDD.
� System warning speaker (4-pin SPEAKER)
This 4-pin header is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings.
� ATX power button/soft-off button (2-pin PWRSW)
This header is for the system power button. Pressing the power button turns the system on or puts the system in sleep or soft-off mode depending on the operating system settings. Pressing the power switch for more than four seconds while the system is ON turns the system OFF.
� Reset button (2-pin RESET)
This 2-pin header is for the chassis-mounted reset button for system reboot without turning off the system power.
� Chassis intrusion header (2-pin CHASSIS)
This header is for a chassis-mounted intrusion detection sensor or switch. Connect one end of the chassis intrusion sensor or switch cable to this header. The chassis intrusion sensor or switch sends a high-level signal to this connector when a chassis component is removed or replaced. The signal is then generated as a chassis intrusion event.
ASUS TUF GAMING B660-PLUS WIFI D4
1-5
I2C_SCL I2C_SDA I2C_IRQ# RTD3_POWER_EN NC PERST_N WAKE#
FORCE_PWR CIO_PLUG_EVENT
SLP_S3# SLP_S5#
GND RTD3_SW
17. ThunderboltTM header
The ThunderboltTM header allows you to connect an add-on ThunderboltTM I/O card that supports Intel�'s ThunderboltTM Technology, allowing you to connect ThunderboltTM-enabled devices to form a daisy chain-configuration.
� The add-on ThunderboltTM I/O card and ThunderboltTM cables are purchased separately.
� Please visit the official website of your purchased Thunderbolt card for more details on compatibility.
TB_HEADER
PIN 1
18. Q-LEDs The Q-LEDs check key components (CPU, DRAM, VGA, and booting devices) during the motherboard booting process. If an error is found, the critical component's LED stays lit up until the problem is solved.
The Q-LEDs provide the most probable cause of an error code as a starting point for troubleshooting. The actual cause may vary from case to case.
1-6
Chapter 1: Product Introduction
1.2.2 Rear panel connectors
1
2
3
456
7
8
9 10 8
11 12 13 14
1. DisplayPort. This port is for a DisplayPort-compatible device. 2. USB 2.0 port. This Universal Serial Bus (USB) port is for USB 2.0 devices. 3. Ethernet port. This port allows Gigabit connection to a Local Area Network (LAN)
through a network hub. Refer to the table below for the Ethernet port LED indications. Intel� I225-V 2.5Gb Ethernet port LED indications
Activity Link LED
Status OFF GREEN BLINKING
Description No link Linked Data activity
Speed LED
Status OFF
OFF
GREEN ORANGE
Description
No link 100 Mbps / 10 Mbps connection 2.5 Gbps connection 1 Gbps connection
ACT/LINK LED
SPEED LED
LAN port
4. Center / Subwoofer port (orange). This port connects the center/subwoofer speakers.
5. Rear Speaker Out port (black). This port connects the rear speakers in a 4 channel, 5.1 channel, or 7.1 channel audio configuration.
6. Line In port (light blue). This port connects the tape, CD, DVD player, or other audio sources.
7. HDMI� port. This port is for a High-Definition Multimedia Interface (HDMI) connector, and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected content.
8. USB 3.2 Gen 1 (up to 5Gbps) ports. These Universal Serial Bus (USB) ports connect to USB 3.2 Gen 1 devices.
ASUS TUF GAMING B660-PLUS WIFI D4
1-7
9. USB 3.2 Gen 2x2 (up to 20Gbps) port (USB Type-C�). This Universal Serial Bus 3.2 (USB 3.2) port is for USB 3.2 Gen 2x2 Type-C� devices.
10. USB 3.2 Gen 2 (up to 10Gbps) port (teal blue, Type A). This Universal Serial Bus 3.2 (USB 3.2) port is for USB 3.2 Gen 2 devices.
11. Wi-Fi 6 ports. These ports connect to Wi-Fi antennas.
� Ensure that the ASUS Wi-Fi moving antennas are securely installed to the Wi-Fi ports. � Ensure that the antennas are at least 20cm away from all persons.
12. Optical S/PDIF out port. This port allows you to connect your PC to amplified speakers, headphones, or Sony/Phillips Digital Interconnect Format (S/PDIF) compliant devices.
13. Microphone port (pink). This port connects a microphone.
Refer to the audio configuration table below for the function of the audio ports in 2, 4, 5.1, or 7.1-channel configuration.
Audio 2, 4, 5.1 or 7.1-channel configuration
Port
Light Blue Lime Pink
Orange Black
Headset 2-channel
Line In Line Out
Mic In -- --
4-channel
Line In Front Speaker Out
Mic In --
Rear Speaker Out
5.1-channel
Line In Front Speaker Out
Mic In Center/Subwoofer Rear Speaker Out
7.1-channel
Side Speaker Out Front Speaker Out
Mic In Center/Subwoofer Rear Speaker Out
14. Line Out port (lime). This port connects a headphone or a speaker. In 4-channel, 5.1-channel, and 7.1-channel configurations, the function of this port becomes Front
Speaker Out.
1-8
Chapter 1: Product Introduction
1.3 Central Processing Unit (CPU)
This motherboard comes with a LGA1700 socket designed for 12th Gen Intel� CoreTM, Pentium� Gold and Celeron� Processors.
Unplug all power cables before installing the CPU.
� Ensure that you install the correct CPU designed for the LGA1700 socket only. DO NOT install a CPU designed for LGA1155, LGA1156, LGA1151, and LGA1200 sockets on the LGA1700 socket.
� Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components.
� Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1700 socket.
� The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP cap.
� The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU.
Installing the CPU
1
2
3
Take caution when lifting the load lever, ensure to hold onto the load lever when releasing the load lever. Letting go of the load lever immediately after releasing it may cause the load lever to spring back and cause damage to your motherboard.
ASUS TUF GAMING B660-PLUS WIFI D4
1-9
4
5
Ensure to remove the CPU socket lever protector on the lever latch before locking the lever latch under the retention tab. Failure to do so may cause damages to your system when installing the cooling system.
1-10
Chapter 1: Product Introduction
1.4 System memory
This motherboard comes with four Double Data Rate 4 (DDR4) Dual Inline Memory Module (DIMM) sockets. The figure illustrates the location of the DDR4 DIMM sockets:
DIMM_A1 DIMM_A21st
DIMM_B1 DIMM_B21st
Channel Channel A Channel B
Sockets DIMM_A1 & DIMM_A21st DIMM_B1 & DIMM_B21st
� You may install varying memory sizes in Channel A and Channel B. The system maps the total size of the lower-sized channel for the dual-channel configuration. Any excess memory from the higher-sized channel is then mapped for single-channel operation.
� A DDR4 memory module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT install a DDR, DDR2, or DDR3 memory module to the DDR4 slot.
� The default memory operation frequency is dependent on its Serial Presence Detect (SPD), which is the standard way of accessing information from a memory module. Under the default state, some memory modules for overclocking may operate at a lower frequency than the vendor-marked value.
� For system stability, use a more efficient memory cooling system to support a full memory load.
� Always install DIMMs with the same CAS latency. For optimal compatibility, we recommend that you install memory modules of the same version or date code (D/C) from the same vendor. Check with the retailer to get the correct memory modules.
� Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types.
Recommended memory configurations
DIMM_B21st
DIMM_A21st DIMM_B21st
DIMM_A1 DIMM_A21st DIMM_B1 DIMM_B21st
ASUS TUF GAMING B660-PLUS WIFI D4
1-11
Installing a DIMM 1
2
A
A B
To remove a DIMM
A B
1-12
Chapter 1: Product Introduction
1.5 M.2 installation
Supported M.2 type varies per motherboard.
� The illustrations only show the installation steps for a single M.2 slot, the steps are the same for the other M.2 slots if you wish to install an M.2 to another M.2 slot.
� Use a Phillips screwdriver when removing or installing the screws or screw stands mentioned in this section.
� The M.2 is purchased separately.
When installing an M.2 to the M.2 slot, you may need to use the removable screw stand. 1. Remove the screws from the heatsink. 2. Remove the heatsink.
1
2 1
1
2
1
ASUS TUF GAMING B660-PLUS WIFI D4
1-13
3. Install your M.2 to your M.2 slot. The steps may differ between installing M.2 of different lengths, please refer to the different types and their installation steps below:
� To install an M.2 to M.2_1 and M.2_3 slot
For 2280, 22110 length
A.
(optional) Remove the pre-installed removable M.2 Q-Latch screw at
the 2280 length screw hole.
Follow step A only when you wish to install an 22110 length M.2 to M.2_1 and M.2_3.
B.
(optional) Install the bundled M.2 rubber pad if you are installing a
single sided M.2 storage device. DO NOT install the bundled M.2
rubber pads when installing a double-sided M.2 storage device. The
rubber pad installed by default is compatible with double sided M.2
storage devices.
C.
Rotate and adjust the M.2 Q-latch so that the handle points away
from the M.2 slot.
D.
Install your M.2 to the M.2 slot.
E.
Rotate the M.2 Q-Latch clockwise to secure the M.2 in place.
OPTIONAL
1-14
Chapter 1: Product Introduction
For 2242, 2260 length
A.
(optional) Remove the M.2 rubber pad.
Follow this step only if you wish to install an M.2 to type 2242.
B.
(optional) If required, remove the pre-installed removable M.2 Q-Latch
screw at the 2280 length screw hole.
C.
Install the M.2 Q-Latch to the M.2 length screw hole you wish to install
your M.2 to.
D.
Rotate and adjust the M.2 Q-latch so that the handle points away
from the M.2 slot.
E.
Install your M.2 to the M.2 slot.
F.
Rotate the M.2 Q-Latch clockwise to secure the M.2 in place.
ASUS TUF GAMING B660-PLUS WIFI D4
1-15
� To install an M.2 to M.2_2 slot
For 2280 length
A.
(optional) Install the bundled M.2 rubber pad if you are installing a
single sided M.2 storage device. DO NOT install the bundled M.2
rubber pads when installing a double-sided M.2 storage device. The
rubber pad installed by default is compatible with double sided M.2
storage devices.
B.
Rotate and adjust the M.2 Q-latch so that the handle points away
from the M.2 slot.
C.
Install your M.2 to the M.2 slot.
D.
Rotate the M.2 Q-Latch clockwise to secure the M.2 in place.
OPTIONAL
1-16
Chapter 1: Product Introduction
For 2242, 2260 length
A.
Install the bundled screw stand to the M.2 length screw hole you wish
to install your M.2 to.
B.
Install your M.2 to the M.2 slot.
C.
Secure your M.2 using the bundled screw stand's screw.
ASUS TUF GAMING B660-PLUS WIFI D4
1-17
1.6 Wi-Fi antenna installation
Installing the ASUS Wi-Fi moving antenna Connect the bundled ASUS Wi-Fi moving antenna connectors to the Wi-Fi ports at the back of the chassis.
� Ensure that the ASUS Wi-Fi moving antenna is securely installed to the Wi-Fi ports. � Ensure that the antenna is at least 20 cm away from all persons. The illustration above is for reference only. The I/O port layout may vary with models, but the Wi-Fi antenna installation procedure is the same for all models.
1-18
Chapter 1: Product Introduction
BIOS and RAID Support
2
2.1 Knowing BIOS
The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboardonly BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system. The term "BIOS" in this user manual refers to "UEFI BIOS" unless otherwise specified. BIOS (Basic Input and Output System) stores system hardware settings such as storage device configuration, overclocking settings, advanced power management, and boot device configuration that are needed for system startup in the motherboard CMOS. In normal circumstances, the default BIOS settings apply to most conditions to ensure optimal performance. DO NOT change the default BIOS settings except in the following circumstances: � An error message appears on the screen during the system bootup and requests you to run the BIOS Setup. � You have installed a new system component that requires further BIOS settings or update.
Inappropriate BIOS settings may result to instability or boot failure. We strongly recommend that you change the BIOS settings only with the help of a trained service personnel.
BIOS settings and options may vary due to different BIOS release versions. Please refer to the latest BIOS version for settings and options.
For more information on BIOS configurations, please refer to https://www.asus.com/support, or download the BIOS manual by scanning the QR code.
ASUS TUF GAMING B660-PLUS WIFI D4
2-1
2.2 BIOS Setup program
Use the BIOS Setup to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief onscreen help to guide you in using the BIOS Setup program.
Entering BIOS at startup To enter BIOS Setup at startup, press <Delete> or <F2> during the Power-On Self Test (POST). If you do not press <Delete> or <F2>, POST continues with its routines.
Entering BIOS Setup after POST To enter BIOS Setup after POST: � Press <Ctrl>+<Alt>+<Delete> simultaneously. � Press the reset button on the system chassis. � Press the power button to turn the system off then back on. Do this option only if you
failed to enter BIOS Setup using the first two options. After doing either of the three options, press <Delete> key to enter BIOS.
� Ensure that a USB mouse is connected to your motherboard if you want to use the mouse to control the BIOS Setup program.
� If the system becomes unstable after changing any BIOS setting, load the default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu or press hotkey <F5>.
� If the system fails to boot after changing any BIOS setting, try to clear the CMOS and reset the motherboard to the default value.
� The BIOS Setup program does not support Bluetooth devices.
BIOS menu screen The BIOS Setup program can be used under two modes: EZ Mode and Advanced Mode. You can change modes from Setup Mode in Boot menu or by pressing the <F7> hotkey.
2-2
Chapter 2: BIOS and RAID Support
2.3 ASUS EZ Flash 3
The ASUS EZ Flash 3 feature allows you to update the BIOS without using an OS-based utility.
Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu or press hotkey <F5>.
To update the BIOS by USB:
� This function can support devices such as a USB flash disk with FAT 32/16 format and single partition only.
� DO NOT shut down or reset the system while updating the BIOS to prevent system boot failure!
1. Insert the USB flash disk that contains the latest BIOS file to the USB port. 2. Enter the Advanced Mode of the BIOS Setup program. Go to the Tool menu to select
ASUS EZ Flash 3 Utility and press <Enter>. 3. Press the Left/Right arrow keys to switch to the Drive field. 4. Press the Up/Down arrow keys to find the USB flash disk that contains the latest BIOS,
and then press <Enter>. 5. Press the Left/Right arrow keys to switch to the Folder field. 6. Press the Up/Down arrow keys to find the BIOS file, and then press <Enter> to perform
the BIOS update process. Reboot the system when the update process is done.
ASUS TUF GAMING B660-PLUS WIFI D4
2-3
2.4 ASUS CrashFree BIOS 3
The ASUS CrashFree BIOS 3 utility is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using a USB flash drive that contains the BIOS file.
Recovering the BIOS 1. Download the latest BIOS version for this motherboard from
https://www.asus.com/support/. 2. Rename the BIOS file as ASUS.CAP or TGB660W4.CAP and copy the renamed BIOS
file to a USB flash drive. 3. Turn on the system. 4. Insert the USB flash drive containing the BIOS file to a USB port. 5. The utility automatically checks the devices for the BIOS file. When found, the utility
reads the BIOS file and enters ASUS EZ Flash 3 automatically. 6. The system requires you to enter BIOS Setup to recover the BIOS setting. To ensure
system compatibility and stability, we recommend that you press <F5> to load default BIOS values.
DO NOT shut down or reset the system while updating the BIOS! Doing so can cause system boot failure!
2-4
Chapter 2: BIOS and RAID Support
2.5 RAID configurations
The motherboard comes with the Intel� Rapid Storage Technology that supports RAID 0, RAID 1, RAID 5 and RAID 10 configuration.
For more information on configuring your RAID sets, please refer to the RAID Configuration Guide which you can find at https://www.asus.com/support, or by scanning the QR code.
RAID definitions RAID 0 (Data striping) optimizes two identical hard disk drives to read and write data in parallel, interleaved stacks. Two hard disks perform the same work as a single drive but at a sustained data transfer rate, double that of a single disk alone, thus improving data access and storage. Use of two new identical hard disk drives is required for this setup. RAID 1 (Data mirroring) copies and maintains an identical image of data from one drive to a second drive. If one drive fails, the disk array management software directs all applications to the surviving drive as it contains a complete copy of the data in the other drive. This RAID configuration provides data protection and increases fault tolerance to the entire system. Use two new drives or use an existing drive and a new drive for this setup. The new drive must be of the same size or larger than the existing drive. RAID 5 stripes both data and parity information across three or more hard disk drives. Among the advantages of RAID 5 configuration include better HDD performance, fault tolerance, and higher storage capacity. The RAID 5 configuration is best suited for transaction processing, relational database applications, enterprise resource planning, and other business systems. Use a minimum of three identical hard disk drives for this setup. RAID 10 is data striping and data mirroring combined without parity (redundancy data) having to be calculated and written. With the RAID 10 configuration you get all the benefits of both RAID 0 and RAID 1 configurations. Use four new hard disk drives or use an existing drive and three new drives for this setup.
ASUS TUF GAMING B660-PLUS WIFI D4
2-5
2-6
Chapter 2: BIOS and RAID Support
Appendix
Notices
FCC Compliance Information
Responsible Party: Asus Computer International
Address: 48720 Kato Rd., Fremont, CA 94538, USA
Phone / Fax No: (510)739-3777 / (510)608-4555
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected. - Consult the dealer or an experienced radio/TV technician for help.
RF exposure warning This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
HDMI Compliance Statement
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
ASUS TUF GAMING B660-PLUS WIFI D4
A-1
Compliance Statement of Innovation, Science and Economic Development Canada (ISED)
This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. CAN ICES-003(B)/NMB-003(B)
D�claration de conformit� de Innovation, Sciences et D�veloppement �conomique Canada (ISED)
Le pr�sent appareil est conforme aux CNR d'Innovation, Sciences et D�veloppement �conomique Canada applicables aux appareils radio exempts de licence. L'exploitation est autoris�e aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radio�lectrique subi, m�me si le brouillage est susceptible d'en compromettre le fonctionnement. CAN ICES-003(B)/NMB-003(B)
VCCI: Japan Compliance Statement Class B ITE
Japan JATE
LAN
KC: Korea Warning Statement
A-2
Appendix
GoogleTM License Terms
Copyright� 2021 Google Inc. All Rights Reserved. Licensed under the Apache License, Version 2.0 (the "License"); you may not use this file except in compliance with the License. You may obtain a copy of the License at:
http://www.apache.org/licenses/LICENSE-2.0
Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.
NCC: Taiwan Wireless Statement
*
Japan RF Equipment Statement
5GHz5.2GHz5.3GHz
Pr�cautions d'emploi de l'appareil :
a. Soyez particuli�rement vigilant quant � votre s�curit� lors de l'utilisation de cet appareil dans certains lieux (les avions, les a�roports, les h�pitaux, les stations-service et les garages professionnels).
b. �vitez d'utiliser cet appareil � proximit� de dispositifs m�dicaux implant�s. Si vous portez un implant �lectronique (stimulateurs cardiaques, pompes � insuline, neurostimulateurs...), veuillez imp�rativement respecter une distance minimale de 15 centim�tres entre cet appareil et l'implant pour r�duire les risques d'interf�rence.
c. Utilisez cet appareil dans de bonnes conditions de r�ception pour minimiser le niveau de rayonnement. Ce n'est pas toujours le cas dans certaines zones ou situations, notamment dans les parkings souterrains, dans les ascenseurs, en train ou en voiture ou tout simplement dans un secteur mal couvert par le r�seau.
d. Tenez cet appareil � distance du ventre des femmes enceintes et du bas-ventre des adolescents.
ASUS TUF GAMING B660-PLUS WIFI D4
A-3
Declaration of compliance for product environmental regulation
ASUS follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASUS product is in line with global environmental regulations. In addition, ASUS disclose the relevant information based on regulation requirements. Please refer to http://csr.asus.com/Compliance.htm for information disclosure based on regulation requirements ASUS is complied with:
EU REACH and Article 33 Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals) regulatory framework, we published the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm.
EU RoHS This product complies with the EU RoHS Directive. For more details, see http://csr.asus.com/english/article.aspx?id=35
India RoHS This product complies with the "India E-Waste (Management) Rules, 2016" and prohibits use of lead, mercury, hexavalent chromium, polybrominated biphenyls (PBBs) and polybrominated diphenyl ethers (PBDEs) in concentrations exceeding 0.1% by weight in homogenous materials and 0.01% by weight in homogenous materials for cadmium, except for the exemptions listed in Schedule II of the Rule.
Vietnam RoHS ASUS products sold in Vietnam, on or after September 23, 2011,meet the requirements of the Vietnam Circular 30/2011/TT-BCT. C�c sn phm ASUS b�n ti Vit Nam, v�o ng�y 23 th�ng 9 nm2011 tr v sau, u phi �p ng c�c y�u cu ca Th�ng t 30/2011/TT-BCT ca Vit Nam.
Turkey RoHS AEEE Y�netmeliine Uygundur
ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for detailed recycling information in different regions.
A-4
Appendix
DO NOT throw the motherboard in municipal waste. This product has been designed to enable proper reuse of parts and recycling. This symbol of the crossed out wheeled bin indicates that the product (electrical and electronic equipment) should not be placed in municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste.
Simplified UKCA Declaration of Conformity ASUSTek Computer Inc. hereby declares that this device is in compliance with the essential requirements and other relevant provisions of The Radio Equipment Regulations 2017 (S.I. 2017/1206). Full text of UKCA declaration of conformity is available at https://www.asus.com/support/. The WiFi operating in the band 5150-5350MHz shall be restricted to indoor use for the country listed below:
UKCA RF Output table (The Radio Equipment Regulations 2017) Intel� WI-FI 6 AX201 (Model: AX201NGW):
Function
Frequency
WiFi Bluetooth
2412 - 2472 MHz 5150 - 5350 MHz 5470 - 5725 MHz 5725 - 5850 MHz 2402 - 2480 MHz
Maximum Output Power (EIRP)
19.494 dBm 22.229 dBm 21.959 dBm 13.197 dBm 12.176 dBm
For the standard EN 300 440, if this device operates in 5725-5875 MHz, it will be considered as a receiver category 2.
TA2018/3315
APPROVED
Complies with IMDA Standards
DB103778
ASUS TUF GAMING B660-PLUS WIFI D4
A-5
Simplified EU Declaration of Conformity
ASUSTek Computer Inc. hereby declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. Full text of EU declaration of conformity is available at https://www.asus.com/support/
The WiFi operating in the band 5150-5350MHz shall be restricted to indoor use for countries listed in the table below:
D�claration simplifi�e de conformit� de l'UE
ASUSTek Computer Inc. d�clare par la pr�sente que cet appareil est conforme aux crit�res essentiels et autres clauses pertinentes de la directive 2014/53/EU. La d�claration de conformit� de l'UE peut �tre t�l�charg�e � partir du site internet suivant : https://www.asus.com/support/
Dans la plage de fr�quence 5150-5350 MHz, le Wi-Fi est restreint � une utilisation en int�rieur dans les pays list�s dans le tableau ci-dessous:
Vereinfachte EU-Konformit�tserkl�rung
ASUSTek COMPUTER INC erkl�rt hiermit, dass dieses Ger�t mit den grundlegenden Anforderungen und anderen relevanten Bestimmungen der Richtlinie 2014/53/EU �bereinstimmt. Der gesamte Text der EUKonformit�tserkl�rung ist verf�gbar unter: https://www.asus.com/support/
Der WLAN-Betrieb im Band von 5150-5350 MHz ist f�r die in der unteren Tabelle aufgef�hrten L�nder auf den Innenbereich beschr�nkt:
Dichiarazione di conformit� UE semplificata
ASUSTek Computer Inc. con la presente dichiara che questo dispositivo � conforme ai requisiti essenziali e alle altre disposizioni pertinenti con la direttiva 2014/53/EU. Il testo completo della dichiarazione di conformit� UE � disponibile all'indirizzo: https://www.asus.com/support/
L'utilizzo della rete Wi-Fi con frequenza compresa nell'intervallo 51505350MHz deve essere limitato all'interno degli edifici per i paesi presenti nella seguente tabella:
ASUSTek Computer Inc. , 2014/53/ EU. https://www.asus.com/support/
WiFi 5150-5350 , :
ASUSTek Computer
.2014/53/EU :
https://www.asus.com/support/
5150-5350 WiFi .
ASUSTek Computer Inc. , 2014/53/EC. https://www.asus.com/support/
WiFi, 5150-5350MHz, , -:
Declara��o de Conformidade UE Simplificada
ASUSTek Computer Inc. declara que este dispositivo est� em conformidade com os requisitos essenciais e outras disposi�es relevantes relacionadas �s diretivas 2014/53/UE. O texto completo da declara��o de conformidade CE est� dispon�vel em https://www.asus.com/support/
O WiFi operando na banda 5150-5350MHz deve ser restrito para uso interno para os pa�ses listados na tabela abaixo:
Pojednostavljena EU Izjava o sukladnosti
ASUSTeK Computer Inc. ovim izjavljuje da je ovaj ureaj sukladan s bitnim zahtjevima i ostalim odgovarajuim odredbama direktive 2014/53/EU. Cijeli tekst EU izjave o sukladnosti dostupan je na https://www.asus.com/support/
WiFi koji radi na opsegu frekvencija 5150-5350 MHz bit e ogranicen na upotrebu u zatvorenom prostoru u zemljama na donjem popisu:
Zjednodusen� prohl�sen� o shod EU
Spolecnost ASUSTek Computer Inc. t�mto prohlasuje, ze toto za�zen� spluje z�kladn� pozadavky a dals� p�slusn� ustanoven� smrnice 2014/53/ EU. Pln� znn� prohl�sen� o shod EU je k dispozici na adrese https://www.asus.com/support/
V zem�ch uveden�ch v tabulce je provoz s�t Wi-Fi ve frekvencn�m rozsahu 5 150 - 5 350 MHz povolen pouze ve vnitn�ch prostorech:
Forenklet EU-overensstemmelseserkl�ring
ASUSTeK Computer Inc. erkl�rer hermed at denne enhed er i overensstemmelse med hovedkravene og �vrige relevante bestemmelser i direktivet 2014/53/EU. Hele EU-overensstemmelseserkl�ringen kan findes p� https://www.asus.com/support/
Wi-Fi, der bruger 5150-5350 MHz skal begr�nses til indend�rs brug i lande, der er anf�rt i tabellen:
Vereenvoudigd EU-conformiteitsverklaring
ASUSTeK Computer Inc. verklaart hierbij dat dit apparaat voldoet aan de essenti�le vereisten en andere relevante bepalingen van Richtlijn 2014/53/EU. De volledige tekst van de EU-conformiteitsverklaring is beschikbaar op https://www.asus.com/support/
De WiFi op 5150-5350MHz zal beperkt zijn tot binnengebruik voor in de tabel vermelde landen:
Lihtsustatud E� vastavusdeklaratsioon
K�esolevaga kinnitab ASUSTek Computer Inc, et seade vastab direktiivi 2014/53/E� olulistele n�uetele ja teistele asjakohastele s�tetele. EL vastavusdeklaratsiooni t�istekst on saadaval veebisaidil https://www.asus.com/support/
Sagedusvahemikus 5150-5350 MHz t��tava WiFi kasutamine on j�rgmistes riikides lubatud ainult siseruumides:
Eurooppa - EY:n vaatimustenmukaisuusvakuutus
ASUSTek Computer Inc. ilmoittaa t�ten, ett� t�m� laite on direktiivin 2014/53/ EU olennaisten vaatimusten ja muiden asiaankuuluvien lis�ysten mukainen. Koko EY:n vaatimustenmukaisuusvakuutuksen teksti on luettavissa osoitteessa https://www.asus.com/support/
5 150 - 5 350 MHz:in taajuudella toimiva WiFi on rajoitettu sis�k�ytt��n taulukossa luetelluissa maissa:
ASUSTek Computer Inc . .2014/53/EU
: .https://www.asus.com/support/
WiFi 5150-5350 .
ASUSTek Computer Inc. 2014/53/E. https://www.asus.com/support/
WiFi 5150-5350MHz :
ASUSTek Computer Inc. .2014/53/EU : https://www.asus.com/support/
5150-5350MHz Wi-Fi
: Egyszers�tett EU megfelels�gi nyilatkozat
Az ASUSTek Computer Inc. ezennel kijelenti, hogy ez az eszk�z megfelel az 2014/53/EU sz. ir�nyelv alapvet k�vetelm�nyeinek �s egy�b vonatkoz� rendelkez�seinek. Az EU megfelels�gi nyilatkozat teljes sz�veg�t a k�vetkez weboldalon tekintheti meg: https://www.asus.com/support/
Az 5150-5350 MHz-es s�vban mk�d Wi-Fi-t belt�ri haszn�latra kell korl�tozni az al�bbi t�bl�zatban felsorolt orsz�gokban:
Pernyataan Kesesuaian UE yang Disederhanakan
ASUSTeK Computer Inc. dengan ini menyatakan bahwa perangkat ini memenuhi persyaratan utama dan ketentuan relevan lainnya yang terdapat pada Petunjuk 2014/53/EU. Teks lengkap pernyataan kesesuaian EU tersedia di: https://www.asus.com/support/
WiFi yang Beroperasi pada 5150-5350 MHz akan terbatas untuk penggunaan dalam ruangan di negara yang tercantum dalam tabel
Vienkrsota ES atbilstbas paziojums
ASUSTeK Computer Inc. ar so pazio, ka s ierce atbilst Direktvas 2014/53/ES btiskajm prasbm un citiem citiem saistosajiem nosacjumiem. Pilns ES atbilstbas paziojuma teksts pieejams seit: https://www.asus.com/support/
Wi-Fi darbba 5150�5350 MHz ir jierobezo lietosanai telps valsts, kuras nordtas tlk.
A-6
Appendix
Supaprastinta ES atitikties deklaracija
Siame dokumente bendrov ,,ASUSTek Computer Inc." pareiskia, kad sis prietaisas atitinka pagrindinius reikalavimus ir kitas susijusias Direktyvos 2014/53/ES nuostatas. Visas ES atitikties deklaracijos tekstas pateikiamas cia: https://www.asus.com/support/
Toliau nurodytose salyse,,WiFi" rysiu, veikianciu 5 150�5 350 MHz daznio juostoje, galima naudotis tik patalpose:
Forenklet EU-samsvarserkl�ring
ASUSTek Computer Inc. erkl�rer herved at denne enheten er i samsvar med hovedsaklige krav og andre relevante forskrifter i direktivet 2014/53/EU. Fullstendig tekst for EU-samsvarserkl�ringen finnes p�: https://www.asus.com/support/
Wi-Fi-omr�det 5150�5350 MHz skal begrenses til innend�rs bruk for landene som er oppf�rt i tabellen:
Uproszczona deklaracja zgodnoci UE
Firma ASUSTek Computer Inc. niniejszym owiadcza, e urzdzenie to jest zgodne z zasadniczymi wymogami i innymi wlaciwymi postanowieniami dyrektywy 2014/53/EU. Pelny tekst deklaracji zgodnoci UE jest dostpny pod adresem https://www.asus.com/support/
W krajach wymienionych w tabeli dzialanie sieci Wi-Fi w pamie 5150� 5350 MHz powinno by ograniczone wylcznie do pomieszcze:
Declara��o de Conformidade Simplificada da UE
A ASUSTek Computer Inc. declara que este dispositivo est� em conformidade com os requisitos essenciais e outras disposi�es relevantes da Diretiva 2014/53/UE. O texto integral da declara��o de conformidade da UE est� dispon�vel em https://www.asus.com/support/
A utiliza��o das frequ�ncias WiFi de 5150 a 5350MHz est� restrita a ambientes interiores nos pa�ses apresentados na tabela:
Declaraie de conformitate UE, versiune simplificat
Prin prezenta, ASUSTek Computer Inc. declar c acest dispozitiv este �n conformitate cu reglementrile eseniale i cu celelalte prevederi relevante ale Directivei 2014/53/UE. Textul complet al declaraiei de conformitate UE este disponibil la adresa https://www.asus.com/support/
Pentru rile listate �n tabelul de mai jos, reelele WiFi care funcioneaz �n banda de frecven de 5.150-5.350 MHz trebuie utilizate doar �n interior:
Pojednostavljena Deklaracija o usaglasenosti EU
ASUSTek Computer Inc. ovim izjavljuje da je ovaj ureaj usaglasen sa osnovnim zahtevima i drugim relevantnim odredbama Direktive 2014/53/ EU. Ceo tekst Deklaracije o usaglasenosti EU dostupan je na lokaciji https://www.asus.com/support/
WiFi koji radi u frekventnom opsegu od 5150 MHz do 5350 MHz ogranicen je iskljucivo na upotrebu u zatvorenom prostoru za zemlje navedene u tabeli ispod:
Zjednodusen� vyhl�senie o zhode platn� pre E�
Spolocnos ASUSTek Computer Inc. t�mto vyhlasuje, ze toto zariadenie je v s�lade so z�kladn�mi poziadavkami a als�mi pr�slusn�mi ustanoveniami smernice c. 2014/53/E�. Pln� znenie vyhl�senia o zhode pre E� je k dispoz�cii na lokalite https://www.asus.com/support/
Cinnos WiFi v p�sme 5150 - 5350 MHz bude obmedzen� na pouzitie vo vn�tornom prostred� pre krajiny uveden� v tabuke nizsie:
Poenostavljena izjava EU o skladnosti
ASUSTek Computer Inc. tukaj izjavlja, da je ta naprava skladna s temeljnimi zahtevami in drugimi relevantnimii dolocili Direktive 2014/53/EU. Polno besedilo izjave EU o skladnosti je na voljo na https://www.asus.com/ support/
WiFi, ki deluje v pasovnem obmocju 5150�5350 MHz, mora biti v drzavah, navedenih v spodnjem seznamu, omejen na notranjo uporabo:
Declaraci�n de conformidad simplificada para la UE
Por la presente, ASUSTek Computer Inc. declara que este dispositivo cumple los requisitos b�sicos y otras disposiciones pertinentes de la directiva 2014/53/EU. En https://www.asus.com/support/ est� disponible el texto completo de la declaraci�n de conformidad para la UE.
La conexi�n WiFi con una frecuencia de funcionamiento de 5150-5350 MHz se restringir� al uso en interiores para los pa�ses enumerados en la tabla:
F�renklad EU-f�rs�kran om �verensst�mmelse
ASUSTek Computer Inc. deklarerar h�rmed att denna enhet �verensst�mmer med de grundl�ggande kraven och andra relevanta best�mmelser i direktiv 2014/53/EU. Fullst�ndig text av EU-f�rs�kran om �verensst�mmelse finns p� https://www.asus.com/support/
WiFi som anv�nder 5150-5350 MHz kommer att begr�nsas f�r anv�ndning inomhus i de l�nder som anges i tabellen:
ASUSTek Computer Inc. 2014/53/EU EU https://www.asus.com/support/
WiFi 5150-5350MHz Basitletirilmi AB Uyumluluk Bildirimi
ASUSTek Computer Inc., bu aygitin 2014/53/EU Y�nergesinin temel gereksinimlerine ve dier ilgili h�k�mlerine uygun olduunu bildirir. AB uygunluk bildiriminin tam metni u adreste bulunabilir: https://www.asus.com/support/
5150-5350 MHz arasindaki WiFi �alimasi, tabloda listelenen �lkeler i�in i� mek�n kullanimiyla kisitlanacaktir.
ASUSTek Computer Inc. , 2014 / 53 / EU. https://www.asus.com/support/
Wi-Fi 5150-5350 , :
AT
BE
BG
CZ
DK
EE
FR
DE
IS
IE
IT
EL
ES
CY
LV
LI
LT
LU
HU
MT
NL
NO
PL
PT
RO
SI
SK
TR
FI
SE
CH
HR
UK(NI)
CE RED RF Output table (Directive 2014/53/EU) Intel� WI-FI 6 AX201 (Model: AX201NGW):
Function WIFI
Bluetooth
Frequency
2412 - 2472 MHz 5150 - 5350 MHz 5470 - 5725 MHz 5725 - 5850 MHz 2402 - 2480 MHz
Maximum Output Power (EIRP)
19.494 dBm 22.229 dBm 21.959 dBm 13.197 dBm 12.176 dBm
For the standard EN 300 440, if this device operates in 5725-5875 MHz, it will be considered as a receiver category 2.
TA2018/3315
APPROVED
Complies with IMDA Standards
DB103778
ASUS TUF GAMING B660-PLUS WIFI D4
A-7
Warranty
EN: ASUS Guarantee Information
� ASUS offers a voluntary manufacturer's Commercial Guarantee.
� ASUS reserves the right to interpret the provisions of the ASUS Commercial Guarantee.
� This ASUS Commercial Guarantee is provided independently and in addition to the statutory Legal Guarantee and in no way affects or limits the rights under the Legal Guarantee.
For all the guarantee information, please visit https://www.asus.com/support.
F:
Garantie ASUS
� ASUS fournit une garantie commerciale en tant que garantie volontaire du fabricant.
� ASUS se r�serve le droit d'interpr�ter et de clarifier les informations relatives � la garantie commerciale ASUS.
� Cette garantie commerciale ASUS est fournie ind�pendamment et parall�lement � la garantie l�gale, elle n'affecte ou ne limite d'aucune fa�on les droits acquis par la garantie l�gale.
Pour plus d'informations sur la garantie, consultez le site https://www.asus.com/fr/support/.
G:
ASUS Garantieinformationen
� ASUS bietet eine freiwillige Warengarantie des Herstellers an.
� ASUS beh�lt sich das Recht zur Auslegung der Bestimmungen in der ASUS Warengarantie vor.
� Diese ASUS Warengarantie wird unabh�ngig und zus�tzlich zur rechtm��igen gesetzlichen Garantie gew�hrt und beeintr�chtigt oder beschr�nkt in keiner Weise die Rechte aus der gesetzlichen Garantie.
Die vollst�ndigen Garantieinformationen finden Sie unter https://www.asus.com/de/support/.
I:
Informativa sulla Garanzia ASUS
� ASUS offre una Garanzia Commerciale volontaria del produttore.
� ASUS si riserva il diritto di interpretare le disposizioni della Garanzia Commerciale ASUS.
� La presente Garanzia Commerciale ASUS viene fornita in modo indipendente e in aggiunta alla Garanzia Legale prevista per legge e non pregiudica o limita in alcun modo i diritti previsti dalla Garanzia Legale.
Per tutte le informazioni sulla garanzia, visitare https://www.asus.com/it/support.
R:
ASUS
� ASUS .
� ASUS ASUS.
� ASUS , .
https://www.asus.com/ru/support/.
DA: ASUS garantioplysninger
� ASUS tilbyder en valgfri handelsm�ssig garanti.
� ASUS forbeholder sig retten til at fortolke bestemmelserne i ASUS' handelsm�ssige garanti.
� Denne handelsm�ssige garanti fra ASUS tilbydes uafh�ngigt, som en tilf�jelse til den lovbestemte juridiske garanti og den p�virker eller begr�nser p� ingen m�de rettighederne i den juridiske garanti.
Alle garantioplysningerne kan findes p� https://www.asus.com/dk/support/.
BG: ASUS
� ASUS .
� ASUS ASUS.
� ASUS . .
, , https://www.asus.com/support.
CZ: Informace o z�ruce spolecnosti ASUS
� Spolecnost ASUS nab�z� dobrovolnou komercn� z�ruku v�robce.
� Spolecnost ASUS si vyhrazuje pr�vo vykl�dat ustanoven� komercn� z�ruky spolecnosti ASUS.
� Tato komercn� z�ruka spolecnosti ASUS je poskytov�na nez�visle a jako doplnk z�konn� z�ruky a z�dn�m zpsobem neovlivuje ani neomezuje pr�va vypl�vaj�c� ze z�konn� z�ruky.
Vsechny informace o z�ruce najdete na adrese https://www.asus.com/cz/support/.
CR: Informacije o ASUS jamstvu
� ASUS dragovoljno nudi komercijalno proizvoacko jamstvo. � ASUS zadrzava prava na tumacenje odredbi ASUS komercijalnog
jamstva.
� Ovo ASUS komercijalno jamstvo daje se neovisno i kao dodatak zakonskom jamstvu i ni na koji nacin ne ogranicuje prava iz okvira zakonskog jamstva.
Sve informacije o jamstvu potrazite na https://www.asus.com/support.
DU: ASUS-garantie-informatie
� SUS biedt een vrijwillige commerci�le garantie van de fabrikant.
� ASUS behoudt zich het recht voor om de bepalingen van de commerci�le garantie van ASUS uit te leggen.
� Deze commerci�le garantie van ASUS wordt onafhankelijk en als aanvulling op de statutaire Wettelijke garantie geboden en be�nvloedt of beperkt in geen geval de rechten onder de wettelijke garantie.
Voor alle informatie over de garantie, gaat u naar https://www.asus.com/nl/support/.
EE: Teave ASUS-e garantii kohta
� ASUS pakub vabatahtlikku tasulist tootjagarantiid.
� ASUS j�tab endale �iguse t�lgendada ASUS-e tasulise garantii tingimusi.
� See ASUS-e tasuline garantii on s�ltumatu lisagarantii seadusega kehtestatud garantiile ega m�juta mingil m��ral seadusega kehtestatud garantiid ning seadusega kehtestatud garantii piiranguid.
Vaadake garantiiga seotud teavet veebisaidilt https://www.asus.com/ee/.
GK: ASUS
� ASUS .
� ASUS ASUS.
� ASUS .
, https://www.asus.com/gr-el/.
HUG: ASUS garanci�lis inform�ci�k
� Az ASUS �nk�ntes gy�rt�i kereskedelmi garanci�t k�n�l.
� Az ASUS fenntartja mag�nak a jogot, hogy �rtelmezze az ASUS kereskedelmi garanci�ra vonatkoz� rendelkez�seket.
� Ezt a kereskedelmi garanci�t az ASUS f�ggetlen�l �s a t�rv�nyes garancia mellett ny�jtja �s semmilyen m�don nem befoly�solja, vagy korl�tozza a jogi garancia ny�jtotta jogokat.
A garanci�ra vonatkoz� teljes k�r inform�ci�k�rt l�togasson el a
https://www.asus.com/hu/support/ oldalra.
LV: ASUS garantijas informcija
� ASUS piedv brvprtgu razotja komercilo garantiju.
� ASUS patur tiesbas interprett ASUS komercils garantijas
noteikumus.
� S ASUS komercil garantija tiek piedvta neatkargi un papildus likum noteiktajai juridiskajai garantijai, un t nekdi neietekm vai neierobezo juridiskaj garantij noteikts tiesbas.
Lai iegtu informciju par garantiju, apmekljiet vietni
https://www.asus.com/lv/.
LT:
Informacija apie ASUS garantij
� ASUS silo savanorisk komercin gamintojo garantij. � ASUS pasilieka teis savo nuozira aiskinti sios komercins ASUS
garantijos nuostatas.
� Si komercin ASUS garantija suteikiama nepriklausoma, be statymins teisins garantijos, ir jokiu bdu nepaveikia ar neapriboja teisins garantijos suteikiam teisi.
Nordami gauti vis informacij apie garantij, apsilankykite https://www.asus.com/lt/.
PL: Informacje o gwarancji firmy ASUS
� Firma ASUS oferuje dobrowoln gwarancj handlow producenta. � Firma ASUS zastrzega sobie prawo do interpretacji warunk�w
gwarancji handlowej firmy ASUS.
� Niniejsza gwarancja handlowa firmy ASUS jest udzielana niezalenie, jako dodatek do wymaganej ustawowo gwarancji prawnej i w aden spos�b nie wplywa na prawa przyslugujce na mocy gwarancji prawnej ani ich nie ogranicza.
Wszelkie informacje na temat gwarancji mona znale na stronie https://www.asus.com/pl/support.
A-8
Appendix
PG: Informa�es de Garantia ASUS � A ASUS oferece uma Garantia Comercial volunt�ria do fabricante.
� A ASUS reserva o direito de interpretar as disposi�es da Garantia Comercial da ASUS.
� Esta Garantia Comercial da ASUS � fornecida de forma independente al�m da Garantia Legal estatut�ria e n�o afeta nem limita de qualquer forma os direitos estabelecidos na Garantia Legal.
Para consultar todas as informa�es sobre a garantia, visite https://www.asus.com/pt/support/. RO: Informaii despre garania ASUS
� ASUS ofer o garanie comercial voluntar a productorului.
� ASUS �i rezerv dreptul de a interpreta prevederile garaniei comerciale ASUS.
� Aceast garanie comercial ASUS este oferit independent i �n plus fa de garania obligatorie legal i nu afecteaz sau limiteaz �n niciun fel drepturile acordate conform garaniei legale.
Pentru toate informaiile legate de garanie, vizitai https://www.asus.com/ro/support. SL: Informacije o garanciji ASUS � ASUS ponuja prostovoljno trzno garancijo proizvajalca. � ASUS si pridrzuje pravico do razlage dolocb trzne garancije
druzbe ASUS. � Ta trzna garancija druzbe ASUS je na voljo neodvisno in kot
dodatek zakonsko predpisani pravni garanciji ter na noben nacin ne vpliva na pravice, ki jih zagotavlja pravna garancija, oziroma jih omejuje.
Vse informacije o garanciji najdete na spletnem mestu https://www.asus.com/support. SK: Inform�cie o z�ruke ASUS � ASUS pon�ka dobrovon� obchodn� z�ruku v�robcu. � ASUS si vyhradzuje pr�vo interpretova ustanovenia obchodnej
z�ruky ASUS. � T�to obchodn� z�ruka ASUS je poskytnut� nez�visle a navyse
k z�konnej z�ruke a v ziadnom pr�pade neovplyvuje ani neobmedzuje tieto pr�va poda tejto z�konnej z�ruky. Vsetky alsie inform�cie o z�ruke n�jdete na https://www.asus.com/sk/support. ES: Informaci�n de garant�a de ASUS � ASUS ofrece una garant�a comercial voluntaria del fabricante.
� ASUS se reserva el derecho de interpretar las disposiciones de esta garant�a comercial de ASUS.
� Esta garant�a comercial de ASUS se proporciona de forma independiente y adicional a la garant�a estatutaria y de ninguna manera afecta a los derechos bajo la garant�a legal ni los limita.
Para obtener toda la informaci�n sobre la garant�a, visite https://www.asus.com/ES/support/. TR: ASUS Garanti Bilgileri � ASUS, g�n�ll� olarak �retici Ticari Garantisi sunar. � ASUS, ASUS Ticari Garantisinin h�k�mlerini yorumlama hakkini
sakli tutar. � Bu ASUS Ticari Garantisi, baimsiz olarak ve hukuki Yasal
Garanti'ye ek olarak salanir ve hi�bir ekilde Yasal Garanti kapsamindaki haklari etkilemez veya sinirlandirmaz. T�m garanti bilgileri i�in l�tfen https://www.asus.com/tr/support adresini ziyaret edin. FI: ASUS-takuutiedot
� ASUS tarjoaa vapaaehtoisen valmistajan kaupallisen takuun.
� ASUS pid�tt�� oikeuden tulkita ASUS-kaupallisen takuun ehdot.
� T�m� ASUS-kaupallinen takuu tarjotaan itsen�isesti lakis��teisen oikeudellisen takuun lis�ksi eik� se vaikuta mill��n tavoin laillisen takuun oikeuksiin tai rajoita niit�.
Saadaksesi kaikki takuutiedot, siirry osoitteeseen https://www.asus.com/fi/support. NW: Informasjon om ASUS-garanti
� ASUS tilbyr som produsent en frivillig kommersiell garanti.
� ASUS forbeholder seg retten til � tolke bestemmelsene i ASUS sin kommersielle garanti.
� ASUS sin kommersielle garanti gis uavhengig og i tillegg til den lovbestemte juridiske garantien, og verken p�virker eller begrenser rettighetene under den juridiske garantien p� noen m�te.
Du finner fullstendig informasjon om garanti p� https://www.asus.com/no/support/. SB: Informacije o ASUS garanciji � ASUS nudi dobrovoljnu proizvoacku komercijalnu garanciju. � ASUS zadrzava pravo da tumaci odredbe svoje ASUS
komercijalne garancije.
� Ova ASUS komercijalna garancija daje se nezavisno, kao dodatak zakonskoj pravnoj garanciji, i ni ka koji nacin ne utice na i ne ogranicava prava data pravnom garancijom.
Za sve informacije o garanciji, posetite https://www.asus.com/support/.
ASUS TUF GAMING B660-PLUS WIFI D4
SW: ASUS garantiinformation
� ASUS erbjuder en frivillig kommersiell tillverkningsgaranti.
� ASUS f�rbeh�ller sig r�tten att tolka best�mmelserna i ASUS kommersiella garanti.
� Denna kommersiella garanti fr�n ASUS tillhandah�lles separat och som till�gg till den lagstadgade garantin, och p�verkar eller begr�nsar p� intet s�tts r�ttigheterna under den lagstadgade garantin.
F�r all garantiinformation, bes�k https://www.asus.com/se/support/. UA: ASUS � ASUS .
� ASUS ASUS
� ' ; .
: https://www.asus.com/ua/support. MX: Garant�a y Soporte Esta Garant�a aplica en el pa�s de compra. Usted acepta que en esta garant�a:
� Los procedimientos de servicio pueden variar en funci�n del pa�s.
� Algunos servicios y/o piezas de reemplazo pudieran no estar disponibles en todos los pa�ses.
� Algunos pa�ses pueden tener tarifas y restricciones que se apliquen en el momento de realizar el servicio, visite el sitio de soporte de ASUS en https://www.asus.com/mx/support/ para ver m�s detalles.
� Si tiene alguna queja o necesidad de un centro de reparaci�n local o el periodo de garant�a del producto ASUS, por favor visite el sitio de Soporte de ASUS en https://www.asus.com/mx/support/ para mayores detalles.
Informaci�n de contacto ASUS Esta garant�a est� respaldada por: ASUSTeK Computer Inc. Centro de Atenci�n ASUS +52 (55) 1946-3663 BP: Informa�es de garantia ASUS Esta garantia aplica-se ao per�odo definido pela garantia legal (90 dias) mais o per�odo de garantia comercial oferecido pela ASUS. Por exemplo: 12M significa 12 meses de garantia no total (3 meses de garantia legal mais 9 meses de garantia contratual), 24 meses significa 24 meses de garantia no total (3 meses de garantia legal mais 21 meses de garantia contratual) e 36 meses significa 36 meses de garantia no total (3 meses de garantia legal e 33 de garantia contratual) a contar da data da garantia declarada (Data de In�cio da Garantia).
Para todas as informa�es de garantia, visite https://www.asus.com/br/support/.
ID: Informasi Garansi ASUS
Garansi ini berlaku di negara tempat pembelian.
Periode Garansi tertera pada kemasan/kotak dari Produk dan Masa Garansi dimulai sejak tanggal pembelian Produk ASUS dengan kondisi baru.
Silahkan pindai Kode QR di bagian bawah halaman terakhir untuk Kartu Garansi versi Web dalam format PDF untuk lebih informasi jelas mengenai jaminan garansi Produk ASUS.
� Informasi Dukungan ASUS, silakan kunjungi https://www.asus.com/id/support.
� Informasi Lokasi Layanan, silakan kunjungi https://www.asus.com/id/support/Service-Center/Indonesia.
� Layanan Call Center: 1500128 VI: Th�ng tin m bo ca ASUS � ASUS cung cp Bo h�nh thng mi t nguyn ca nh� sn xut.
� ASUS bo lu quyn gii th�ch c�c iu khon ca Bo h�nh thng mi ca ASUS.
� Bo h�nh thng mi n�y ca ASUS c cung cp c lp v� ngo�i Bo m ph�p l� theo lut nh v� kh�ng c� c�ch n�o nh hng n hoc gii hn c�c quyn theo Bo l�nh ph�p l�. bit tt c c�c th�ng tin bo h�nh, vui l�ng truy cp
https://www.asus.com/vn/support
A-9
ASUS contact information
ASUSTeK COMPUTER INC. Address: 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112, Taiwan
ASUS COMPUTER INTERNATIONAL (America) Address: 48720 Kato Rd., Fremont, CA 94538, USA
ASUS COMPUTER GmbH (Germany and Austria) Address: Harkortstrasse 21-23, 40880 Ratingen, Germany
ASUSTeK (UK) LIMITED Address: 1st Floor, Sackville House, 143-149 Fenchurch Street, London, EC3M 6BL,
England, United Kingdom
Service and Support
Visit our multi-language website at https://www.asus.com/support.
A-10
Appendix
