SAMSUNG DVE(G)55A7700* Dryer User Manual
File info: application/pdf · 136 pages · 16.79MB
Dryer - User manual - source url
2021-05-11 —
7.4 cu. ft. Smart Ivory Gas Dryer with Steam Sanitize Use and Care Manual
Samsung DVG55A7300E 887276557823 0887276557823 1006713280
7.4 cu. ft. Smart Brushed Black Gas Dryer with Steam Sanitize Use and Care Manual
Samsung DVG55A7700V 887276557847 0887276557847 1006713275
Extracted Text
Dryer
User manual
DVE(G)55A7700*/DVE(G)55A7300*/DVE(G)52A5500*
Untitled-3 1
2021-05-11 6:02:25
Contents
Contents
Safety information
What you need to know about the safety instructions Important safety symbols CALIFORNIA PROPOSITION 65 WARNING Important safety precautions Warnings Cautions
Regulatory notice
FCC Notice IC Notice Open Source Announcement
Installation requirements
Key installation requirements Location considerations Ducting requirements Exhausting requirements Gas requirements Electrical requirements
Installation
What's included Step-by-step installation Vent blockage test Exhaust ducting guide Switching the door position
Before you start
Sort and load Functional prerequisite Rack Dry (applicable models only)
2 English
Untitled-3 2
4
4 4 5 5 8 8
10
10 11 12
13
13 13 17 18 19 20
23
23 25 33 35 36
39
39 39 40
2021-05-11 6:02:25
Contents
Operations
42
Control panel
42
Simple steps to start
46
Cycle overview
47
Cycle chart
49
Cycle guide
52
Special features
53
Maintenance
55
Cleaning
55
Troubleshooting
56
Checkpoints
56
Information codes
59
Specifications
61
Fabric care chart
61
Protecting the environment
62
Specification sheet
63
Untitled-3 3
English 3
2021-05-11 6:02:25
Safety information
Safety information
Congratulations on your new Samsung dryer. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your dryer's many benefits and features.
What you need to know about the safety instructions
Please read this manual thoroughly to ensure that you know how to safely and efficiently operate the extensive features and functions of your new appliance. Please store the manual in a safe location close to the appliance for future reference. Use this appliance only for its intended purpose as described in this instruction manual. Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution and care when installing, maintaining and operating your dryer. Because the following operating instructions cover various models, the characteristics of your dryer may differ slightly from those described in this manual and not all warning signs may be applicable. If you have any questions or concerns, contact your nearest service center or find help and information online at www.samsung.com.
Important safety symbols
What the icons and signs in this user manual mean: WARNING
Hazards or unsafe practices that may result in severe personal injury, death and/or property damage.
CAUTION Hazards or unsafe practices that may result in personal injury and/or property damage.
NOTE Indicates that a risk of personal injury or material damage exists.
These warning signs are here to prevent injury to yourself and others. Please follow them explicitly. After reading this manual, store it in a safe place for future reference. Read all instructions before using the appliance. As with any equipment that uses electricity and moving parts, potential hazards exist. To safely operate this appliance, familiarize yourself with its operation and exercise care when using it.
4 English
SAVE THESE INSTRUCTIONS
Untitled-3 4
2021-05-11 6:02:25
Safety information
WARNING - Risk of Fire
� Clothes dryer installation must be performed by a qualified installer. � Install the clothes dryer according to the manufacturer's instructions and local codes. � Do not install a clothes dryer with flexible plastic venting materials. If flexible metal
(foil type) duct is installed, it must be of a specific type identified by the appliance manufacturer as suitable for use with clothes dryers. Flexible venting materials are known to collapse, be easily crushed, and trap lint. These conditions will obstruct clothes dryer airflow and increase the risk of fire. � To reduce the risk of severe injury or death, follow all installation instructions. � Save these instructions.
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
Important safety precautions
WARNING To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. Read all instructions before using this appliance. 2. Do not dry articles that have been previously cleaned in, washed in, soaked in,
or spotted with gasoline, dry-cleaning solvents, or other flammable or explosive substances, as they give off vapors that could ignite or explode. 3. Do not use the dryer to dry clothes which have traces of any flammable substance, such as vegetable oil, cooking oil, machine oil, flammable chemicals, paint thinner, etc., or anything containing wax or chemicals, such as mops and cleaning cloths. Flammable substances may cause the fabric to catch fire by itself. 4. Do not store or use gasoline or other flammable vapors and liquids near this or any other appliance. 5. Do not allow children to play on or in the appliance. Close supervision of children is necessary when the appliance is used near children.
SAVE THESE INSTRUCTIONS
English 5
Untitled-3 5
2021-05-11 6:02:25
Safety information
Safety information
6. Before the appliance is removed from service or discarded, remove the door to the drying compartment.
7. Do not reach into the appliance if the drum is moving. 8. Do not install or store this appliance where it will be exposed to the weather. 9. Do not tamper with internal controls. 10.Do not repair or replace any part of the appliance or attempt any service unless
specifically recommended in the user-maintenance instructions or in published userrepair instructions that you understand and have the skills to carry out. 11.Do not use fabric softeners or products to eliminate static unless recommended by the manufacturer of the fabric softener or product. 12.Clean the lint screen before or after each load. 13.Do not use heat to dry articles containing foam rubber or similarly textured rubber-like materials. 14.Keep area around the exhaust opening and adjacent surrounding areas free from the accumulation of lint, dust, and dirt. 15.The interior of the appliance and exhaust duct should be cleaned periodically by qualified service personnel. 16.Do not place items exposed to cooking oils in your dryer. Items contaminated with cooking oils may contribute to a chemical reaction that could cause a load to catch fire. To reduce the risk of fire due to contaminated loads, the final part of a tumble dryer cycle occurs without heat (cool down period). Avoid stopping a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated. 17.This appliance must be grounded. See "Electrical requirements" and "Grounding" in "Installation" section. 18.Do not allow children to play on or in the appliance. Close supervision of children is necessary when the appliance is used near children. 19.Do not insert your hand under the dryer. - This may result in injury. 20.Take care that children's fingers are not caught in the door when closing it. - This may result in injury. 21.Control board and inlet valve are intentionally not grounded and may present a risk of electric shock only during servicing. - Do not contact this part while appliance is energized.
6 English
Untitled-3 6
SAVE THESE INSTRUCTIONS
2021-05-11 6:02:25
Safety information
WARNING - To reduce the risk of fire or explosion:
� Do not dry items that have been previously cleaned, washed, soaked, or spotted with gasoline, dry cleaning solvents, or other flammable or explosive substances. They emit vapors that could ignite or explode. Any material that has been in contact with a cleaning solvent or flammable liquids or solids should not be placed in the dryer until all traces of these flammable liquids or solids and their fumes have been removed. There are many highly flammable items used in homes, such as acetone, denatured alcohol, gasoline, kerosene, some liquid household cleaners, some spot removers, turpentine, wpees, and wpe removers.
� Items containing foam rubber (may be labeled latex foam) or similarly textured rubberlike materials must not be dried on a heat setting. Heated foam rubber materials can, under certain circumstances, produce fire by spontaneous combustion.
WARNING - What to do if you smell gas:
� Do not try to light any appliance. � Do not turn on the appliance. � Do not touch any electrical switch. � Do not use any phone in your building. � Clear the room, building or area of all occupants. � Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions. � If you cannot reach your gas supplier, call the fire department. � Installation and service must be performed by a qualified installer, service agency, or
the gas supplier.
Untitled-3 7
SAVE THESE INSTRUCTIONS
English 7
2021-05-11 6:02:25
Safety information
Safety information
Warnings
WARNING
� Ensure pockets are free from small, irregularly shaped hard objects, foreign material, etc. ie. coins, knives, pins, etc. These objects could damage your dryer.
� Gas leaks may occur in your system, resulting in a dangerous situation.
Cautions
CAUTION
� Do not allow children or pets to play on, in, or in front of the appliance. Close supervision is necessary when the appliance is used near children and pets.
� Before discarding or removing your dryer from service, remove the door to the drying compartment to prevent children or animals from becoming trapped inside.
� Do not reach into the appliance when the drum is moving. � Do not install or store this appliance where it will be exposed to the weather. � Do not tamper with controls. � Do not repair, replace, or attempt to service any part of the appliance unless
specifically instructed to in the user-repair instructions and you have the understanding and skills to carry out the procedure. � Do not use fabric softeners or products to eliminate static unless the softener or product is recommended for dryer use by the manufacturer of the fabric softener or product. � Clean the lint screen before or after each load. � Keep the area around the exhaust opening and surrounding areas free from lint, dust, and dirt. � The interior of the dryer and exhaust duct should be cleaned periodically by qualified service personnel. � This appliance must be properly grounded. Never plug the power cord into a receptacle that is not grounded adequately or not in accordance with local and national codes. See installation instructions for information about grounding this appliance. � Do not sit on top of the dryer. � Do not wash clothing with large buckles, buttons, or other heavy metal or solid objects. � Gas leaks may not be detected by smell alone. � Gas suppliers recommend you purchase and install a UL-approved gas detector. � Install and use in accordance with the manufacturer's instructions.
8 English
SAVE THESE INSTRUCTIONS
Untitled-3 8
2021-05-11 6:02:25
Safety information
� Do not place items in your dryer that have been spotted or soaked with vegetable oil or cooking oil. Even after being washed, these items may contain significant amounts of these oils.
� Residual oil on clothing can ignite spontaneoulsy. The potential for spontaneous combustion increases when items containing vegetable oil or cooking oil are exposed to heat. Heat sources such as your dryer can warm these items, allowing an oxidation reaction in the oil to occur. Oxidation creates heat. If this heat cannot escape, the items can become hot enough to catch fire. Piling, stacking, or storing these kinds of items may prevent heat from escaping and can create a fire hazard.
� All washed and unwashed fabrics that contain vegetable oil or cooking oil can be dangerous. Washing these items in hot water with extra detergent will reduce, but not eliminate, the hazard. Always use the Cool Down cycle for these items to reduce their temperature. Never remove these items from the dryer hot or interrupt the drying cycle until the items have run through the Cool Down cycle. Never pile or stack these items when they are hot.
Untitled-3 9
SAVE THESE INSTRUCTIONS
English 9
2021-05-11 6:02:25
Regulatory notice
Regulatory notice
FCC Notice
CAUTION Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is Subject to following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received including interference that cause
undesired operation.
For products sold in the US and Canadian markets, only channels 1�11 are available. You cannot select any other channels.
FCC STATEMENT: This equipment has been tested and found to comply within the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: � Reorienting or relocating the receiving antenna � Increasing the separation between the equipment and receiver � Connecting the equipment to an outlet that is on a different circuit than the radio or TV. � Consulting the dealer or an experienced radio/TV technician for help.
FCC RADIATION EXPOSURE STATEMENT: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be colocated or operated in conjunction with any other antenna or transmitter.
10 English
Untitled-3 10
SAVE THESE INSTRUCTIONS
2021-05-11 6:02:25
Unintentional emitter per FCC Part 15
Product type : Clothes Dryers
Model : DVE55A7300*
Responsible Party � U.S. Contact Information
Samsung Electronics America, Inc. QA Lab America 19 Chapin Rd. Building D Pine Brook NJ 07058 Tel: 1-973-808-6375 Fax: 1-973-808-63
Regulatory notice
IC Notice
The term "IC" before the radio certification number only signifies that Industry Canada technical specifications were met. Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause
undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil num�rique de la classe B est conforme � la norme NMB-003 du Canada.
For products sold in the US and Canadian markets, only channels 1�11 are available. You cannot select any other channels.
IC RADIATION EXPOSURE STATEMENT: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be colocated or operated in conjunction with any other antenna or transmitter.
Untitled-3 11
SAVE THESE INSTRUCTIONS
English 11
2021-05-11 6:02:25
Regulatory notice
Open Source Announcement
The software included in this product contains open source software. You may obtain the complete corresponding source code for a period of three years after the last shipment of this product by sending an email to mailto:oss.request@samsung.com. It is also possible to obtain the complete corresponding source code in a physical medium such as a CD-ROM; a minimal charge will be required. The following URL http://opensource.samsung.com/opensource/SMART_AT_051/seq/0 leads to the download page of the source code made available and open source license information as related to this product. This offer is valid to anyone in receipt of this information.
Regulatory notice
NOTE
Hereby, Samsung Electronics, declares that the radio equipment type appliance is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: The official Declaration of conformity may be found at http://www.samsung.com, go to Support > Search Product Support and enter the model name. Wi-Fi max transmitter power : 20 dBm at 2.412 GHz � 2.472 GHz
12 English
Untitled-3 12
SAVE THESE INSTRUCTIONS
2021-05-11 6:02:26
Installation requirements
Installation requirements
Read through the following instructions before installing the dryer, and keep this manual for future reference.
WARNING Certain internal parts are intentionally not grounded and may present a risk of electric shock only during servicing. Service Personnel - Do not contact the following parts while the appliance is energized: Control board and inlet valve.
Key installation requirements
� A grounded electrical outlet. � A power cord for electric dryers (except in Canada). � Gas lines (for gas models) that must meet national and local regulations. � An exhaust system made of rigid metal or flexible stiff-walled metal exhaust ducting.
WARNING Remove the door from all discarded appliances to prevent a child from suffocating.
Location considerations
� Adequate clearances between the dryer and adjacent walls or other surfaces. � Adequate air circulation for ventilation and gas combustion. � Away from water and weather.
WARNING � Make sure to exhaust the dryer outdoors to reduce the risk of fire. � Keep the dryer area clear of combustible materials, gasoline, and other flammable
vapors and liquids. � Do not install other fuel-burning appliances around or in the same place as the dryer. � Place the dryer at least 18 in. (460 mm) above the floor for garage installation.
Untitled-3 13
English 13
2021-05-11 6:02:26
Installation requirements
Dimensions
A U
Dimensions (in. (mm))
9
Type Model
A. Overall height B. Width
C. Depth with door open D. Depth
Front loading dryer
DVE(G)55A7**** DVE(G)52A5****
45.8 (1163)
44.6 (1134)
27.0 (686)
50.1 (1273)
30.2 (768)
Installation requirements
14 English
Untitled-3 14
2021-05-11 6:02:26
Installation requirements
Clearance requirement This clearance requirement is applicable for dryers only.
NOTE
� For washer's clearance requirement, see the washer's user manual. � If the washer and dryer have different clearance requirements, use the one with the
larger value.
Alcove or closet installations
WARNING
� The dryer must be exhausted to the outside to reduce the risk of fire when installed in an alcove or closet.
� No other fuel-burning appliance should be installed in the same closet as the dryer. � Place the dryer at least 18 in. (460 mm) above the floor for garage installation. Minimum clearance for stable operation:
Sides 1 in. / 25 mm
Top 17 in. / 432 mm
Rear 5.9 in. / 150 mm
Front 1 in. / 25 mm
If both the washer and a dryer are installed in the same location, the front of the alcove or closet must have two unobstructed air openings for a combined minimum total area of 72 in.� (465 cm�).
Untitled-3 15
English 15
2021-05-11 6:02:26
Installation requirements
This clearance requirement is applicable for washer and dryer pair installation. Side by side installation
B
A
A
A
1 in. (25 mm)
B
21 in. (533 mm)
C
1 in. (25 mm)
D
5.9 in. (150 mm)
C
D
Installation requirements
16 English
Untitled-3 16
2021-05-11 6:02:26
Installation requirements
Ducting requirements
Recommended
Use only for short-run installation
Weather hood type
No. of 90� elbows 0 1 2 3
4" (10.2 cm) Rigid
80 ft. (24.4 m) 68 ft. (20.7 m) 57 ft. (17.4 m) 47 ft. (14.3 m)
2.5" (6.4 cm) Rigid
74 ft. (22.6 m) 62 ft. (18.9 m) 51 ft. (15.5 m) 41 ft. (12.5 m)
NOTE
* Use a 4-inch (10.2 cm) diameter rigid aluminum or galvanized steel duct.
If you integrate the dryer's vent system with an existing exhaust system, make sure: � The exhaust system meets all applicable local, state, and national regulations. � Not to use a flexible plastic duct. � To regularly check and clean all lint buildup from inside the existing ducts. � The duct is not kinked or crushed. � The exhaust hood damper opens and closes freely.
Manometer measurements The static pressure in any exhaust system must not exceed 0.83 inches of water column or be less than 0. Note that these values are measured with the dryer running with a manometer presented to the exhaust duct that connects to the dryer. The dryer tumbler must be empty and lint filter clean.
Untitled-3 17
English 17
2021-05-11 6:02:26
Installation requirements
Installation requirements
Exhausting requirements
The dryer must not be exhausted into a chimney, a wall, a ceiling, an attic, a crawl space, or a concealed space of a building. Exhausting the dryer to the outside will prevent large amounts of lint and moisture from being blown into the room.
In the United States and Canada � All dryers must be exhausted to the
outside. � The required exhaust duct is 4 inches
(10.2 cm) in diameter. � See "Ducting requirements" in the
"Installation" section for the maximum duct length and number of bends that can be used. � The total length of flexible metal duct must not exceed 7' 10 1/2" (2.4 m). � Do not assemble the duct with screws or other fastener means that extend into the duct and catch lint. � For the United States only: Use only those foil-type flexible ducts, if any, specifically identified for use with the appliance by the manufacturer and that comply with the Outline for Clothes Dryer Transition Duct. Use Subject 2158A.
Outside the United States and Canada � Refer to the local codes.
WARNING
� You must exhaust the dryer to the outside to reduce the risk of fire when you install the dryer in an alcove or closet.
� Do not use a plastic or non-metal flexible duct.
� If your existing ductwork is plastic, nonmetal, or combustible, replace it with metal.
� Use only a metal exhaust duct that is non-flammable to ensure containment of exhaust air, heat, and lint.
18 English
Untitled-3 18
2021-05-11 6:02:26
Installation requirements
Gas requirements
WARNING
� Use only natural or LP (liquid propane) gases.
� The installation must be conformed with local codes, or in the absence of local codes, with the national fuel gas code, ANSI Z223.1/NFPA 54, latest revision (for the UNITED STATES), or with the natural gas and propane installation code, CSA B149.1 (for Canada).
� Gas dryers are equipped with a burner vent for use with natural gas. If you plan to use your dryer with LP (liquid propane) gas, it must be converted for safe and proper performance by a qualified service technician. (LNG models only) You must check the burner of your model and use the proper LP Kit accordingly. To check the detail information of the burner, open the door and check the rating label location on the door frame.
- 20,000 BTU: LPKIT-4/XAA (DC9804114A)
- 22,000 BTU: LPKIT-3/XAA (DC9900792A)
� A 1/2" (1.27 cm) gas supply line is recommended and must be reduced to connect to the 3/8" (1 cm) gas line on your dryer. The National Fuel Gas Code requires that an accessible, approved manual gas shut-off valve be installed within 6" of your dryer.
� Gas dryers installed in residential garages must be raised 18 inches (46 cm) above the floor.
� Additionally, a 1/8" (0.3 cm) N.P.T. (National Pipe Thread) plugged tapping, accessible for test gauge connection, must be installed immediately upstream of your dryer's gas supply connection.
� Your dryer must be disconnected from the gas supply pipe system during any pressure testing of the system.
� Do not reuse old flexible metal gas lines. Flexible gas lines must be designed and certified by the standard for connectors for Gas Appliances, ANSI Z21.24 � CSA 6.10.
NOTE
� Your dryer uses an automatic ignition system to ignite the burner. There is no constant burning pilot.
� Any pipe joint compound used must be resistant to the action of any liquefied petroleum gas.
� As a courtesy, most local gas utilities will inspect a gas appliance installation.
Commonwealth of Massachusetts installation instructions Your dryer must be installed by a licensed plumber or gas fitter. A "T" handle manual gas valve must be installed in the gas supply line to your dryer. If a flexible gas connector is used to install your dryer, the connector can be no longer than 3' (36").
WARNING
� Gas leaks may occur in your system, creating a dangerous situation.
� Gas leaks may not be detected by smell alone.
� Gas suppliers recommend you purchase and install a UL-approved gas detector.
English 19
Untitled-3 19
2021-05-11 6:02:26
Installation requirements
Installation requirements
� Install and use in accordance with the manufacturer's instructions.
Electrical requirements
The wiring diagram is located on the plate under the control panel or rear frame.
WARNING
� Improperly connecting the equipment grounding conductor can result in a risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether your dryer is properly grounded. Do not modify the plug provided with your dryer � if it doesn't fit the outlet, have a proper outlet installed by a qualified electrician.
� To prevent unnecessary risk of fire, electrical shock, or personal injury, all wiring and grounding must be done in accordance with local codes, or in the absence of local codes, in accordance with the National Electrical Code, ANSI/ NFPA No. 70-Latest Revision (for the U.S.) or the Canadian Electrical Code CSA C22.1 � Latest Revisions and local codes and ordinances. It is your responsibility to provide adequate electrical service for your dryer.
� All gas installations must be done in accordance with the national Fuel Code ANSI/Z2231 � Latest Revision (for the U.S.) or CAN/CGA � B149 Installation Codes � Latest Revision (for Canada) and local codes and ordinances.
Grounding This dryer must be grounded. In the event of malfunction or breakdown, the ground will reduce the risk of electrical shock by providing a path of least resistance for the electrical current.
Gas models
WARNING
� Your dryer has a cord with an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
� Do not modify the plug provided with your dryer � if it doesn't fit the outlet, have a proper outlet installed by a qualified electrician.
� Do not connect the ground wire to plastic plumbing lines, gas lines, or hot water pipes.
20 English
Untitled-3 20
2021-05-11 6:02:27
Installation requirements
Electric models
WARNING
� Your dryer has an optional cord with an equipment-grounding conductor and a grounding plug. This cord is sold separately.
� The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
� Do not modify the plug provided with your dryer � if it doesn't fit the outlet, have a proper outlet installed by a qualified electrician.
� If a power cord is not used and the electric dryer is to be permanently wired, the dryer must be connected to a permanently grounded metal wiring system, or an equipment grounding conductor must be run with the circuit conductors and connected to the equipment grounding terminal or lead on the dryer.
Electrical connections Before operating or testing, follow all grounding instructions in the "Grounding" section. An individual branch (or separate) circuit serving only your dryer is recommended. Do not use an extension cord.
Gas models � U.S. and Canada A 120 volt, 60 Hz AC approved electrical service with a 15-ampere fuse or circuit breaker is required.
Electric models � U.S. only Most U.S. dryers require a 120 / 240 volt, 60 Hz AC approved electrical service. Some require 120 / 208 volt, 60 Hz approved electrical service. The electric service requirements can be found on the data label located behind the door. A 30-ampere fuse or circuit breaker on both sides of the line is required. � If a power cord is used, the cord
should be plugged into a 30-ampere receptacle. � The power cord is not provided with U.S. electric model dryers. This cord is sold separately.
Untitled-3 21
English 21
2021-05-11 6:02:27
Installation requirements
Installation requirements
WARNING
Risk of Electric Shock When local codes allow, you can connect the dryer's electrical supply with a new power supply cord kit, marked for use with a dryer, that is U.L. listed and rated at a minimum of 120 / 240 volts, 30-amperes with three No. 10 copper wire conductors terminated with closed loop terminals, open-end spade lugs with turned up ends, or with tinned leads.
� Do not reuse a power supply cord from an old dryer. The power cord electric supply wiring must be supported at the dryer cabinet by a suitable UL-listed strain relief.
� Grounding through the neutral conductor is prohibited for (1) new branch-circuit installations, (2) mobile homes, (3) recreational vehicles, and (4) areas where local codes prohibit grounding through the neutral conductor. (Use a 4-prong plug for a 4 wire receptacle, NEMA type 14-30R.)
Electric models � Canada Only A 120 / 240 volt, 60 Hz AC approved electrical service fused through a 30-ampere fuse or circuit breaker on both sides of the line is required.
NOTE
All Canadian models are shipped with the power cord attached. The power cord should be plugged into a 30-ampere receptacle. In Canada, you may convert a dryer to 120 / 208 volts.
22 English
Untitled-3 22
2021-05-11 6:02:27
Installation
This dryer must be installed by a qualified technician. The installer is responsible for connecting the dryer to the main power while observing the relevant safety regulations of your area.
What's included
Make sure all the parts are included in the product package. If you have a problem with the dryer or the parts, contact a local Samsung customer center or the retailer.
01 02
03
04
01 Control panel 04 Door
05
02 Worktop 05 Exhaust duct
03 Lint filter
Installation
Untitled-3 23
English 23
2021-05-11 6:02:27
Installation
Parts supplied
Y-connector Tools needed for installation
Short water hose
Pliers
Cutting knife
Pipe wrench (gas models only)
Nut driver
Level
Phillips screwdriver
Duct tape
Wrench
LPG-safe compound or Teflon Tape (for
gas installation)
WARNING Packing materials can be dangerous to children. Keep all packing materials (plastic bags, polystyrene, etc.) out of children's reach.
Installation
24 English
Untitled-3 24
2021-05-11 6:02:28
Installation
Step-by-step installation
Make sure you have a qualified technician install the dryer. Step by step installation instructions start below. � Do not remove the protective film on the door before completing the product
installation. If you remove the protective film before the installation is complete, the door may get scratched or damaged during installation. � Make sure the installation location allows enough space for the dryer door to be fully open.
STEP 1 Install the exhaust system
1. Select a location and move the dryer to the site. For easy access, we recommend you install the dryer in the same location as your washer.
2. To change the door direction, see "Switching the door position" on page 36. 3. Install the exhaust system as instructed in the "Exhaust ducting guide" section.
CAUTION Before installing your dryer, remove the packing in the duct.
NOTE � To move the dryer easily, lay two of the carton cushion-from the packaging on the
floor. Tip the dryer on its side so it lies across both cushion-tops. Push the dryer so that it is near its final location, and then set the dryer upright. � Secure room around the dryer to facilitate ducting and wiring.
STEP 2 Connect the gas line (for gas models)
Before connecting the gas line, make sure you have read the "Gas requirements" section on page 19. 1. Remove the protective cap from the gas pipe. 2. Apply an LPG (Liquefied Petroleum Gas)-safe compound or 1.5 wraps of Teflon tape to
all threaded connections. 3. Connect the gas supply to the dryer. An additional fitting is required to connect
the 3/4" (1.9 cm) female thread end of a flexible connector to the 3/8" (1 cm) male threaded end on the dryer. Tighten up the fitting over all threads. 4. Turn on the gas supply, and check for any leaks using a soap solution. If a leak is found, tighten the connections and try again. Do not use an open flame to check for gas leaks.
Untitled-3 25
English 25
2021-05-11 6:02:28
Installation
STEP 3 Connect the electrical wiring (for electric models)
Before connecting the electrical wiring, make sure you have read the "Electrical requirements" section on page 20. 3-wire system
D
A B C L2
L1 E
A. External ground connector B. Neutral grounding wire (white) C. Center silver-colored terminal block
screw D. Neutral wire (white or center wire) E. 3/4" (1.9 cm) UL-listed strain relief
1. Loosen or remove the screws from the center terminal block.
2. Connect the neutral wire (white or center wire) of the power cable to the center, silver-colored terminal screw of the terminal block. Tighten the screws.
3. Connect the other wires to outer terminal block screws. Tighten the screws.
4. Tighten the strain relief screws.
5. Insert the terminal block cover into the rear panel of the dryer. Then, secure the cover with a hold-down screw.
CAUTION
� To convert from the 4-wire system to 3-wire system, connect the ground strap to the terminal block support to ground the dryer frame to the neutral conductor.
� Ring-type terminals are recommended. If using strap terminals, make sure they are tightened.
� Connect the power cord and check L1/ L2/N voltage. If the voltage is low, it may not heat properly. Review the "Electrical requirements" section on page 20 if needed.
Installation
26 English
Untitled-3 26
2021-05-11 6:02:28
Installation
4-wire system
F D
A B C L2
L1 E
A. External ground connector B. Neutral grounding wire (white) C. Center silver-colored terminal block
screw D. Neutral wire (white or center wire) E. �" (1.9 cm) UL-listed strain relief F. Neutral wire (white or center wire)
1. Remove the external ground connector's screw and connect the ground wire (green or unwrapped) of the power cable to the screw.
CAUTION
- To connect the ground wire to the neutral position without through contact A (cabinet ground), contact a technician. This is not user serviceable.
- Ring-type terminals are recommended. If using strap terminals, make sure they are tightened.
2. Loosen or remove the screws from the center terminal block.
3. Connect the neutral wire (white or center wire) and ground wire (white) to the center screw of the terminal block. Tighten the screw.
4. Connect the other wires to the outer terminal block screws. Tighten the screws.
5. Tighten the strain relief screws. 6. Insert the tab of the terminal block
cover into the rear slot of the dryer. Secure the cover with a hold-down screw.
CAUTION
Connect the power cord and check L1/L2/N voltage. If the voltage is low, it may not heat properly. Review the "Electrical requirements" section on page 20 if needed.
Untitled-3 27
English 27
2021-05-11 6:02:29
Installation
WARNING � All U.S. models are designed for a 3-wire system connection. The dryer frame is
grounded to the neutral conductor at the terminal block. A 4-wire system connection is required for new or remodeled construction, mobile homes, or if local codes do not permit grounding through neutral. If you use the 4-wire system, you cannot ground the dryer frame to the neutral conductor at the terminal block. � Remove the terminal block cover plate. Insert the power cord with a UL-listed strain relief through the hole provided in the cabinet near the terminal block. � A strain relief must be used. Do not loosen the nuts already installed on the terminal block. Be sure they are tight. Use a 3/8" (1 cm) deep well socket. � Since january 1, 1996, The national electric code requires that new wiring (not existing) utilize a 4-wire connection to this dryer.
STEP 4 Connect the water hose
The dryer must be connected to a cold water tap using the provided water hoses.
1. Close the cold water tap. If you have a washer's cold water hose attached to the cold water tap, unscrew and remove the hose. Then, connect the female end of the Y-connector to the cold water tap.
2. Connect the straight end of the water hose to the Y-connector.
3. Using pliers, tighten the coupling an additional two-thirds turn. Do not overtighten because the coupling may be damaged.
Installation
28 English
Untitled-3 28
2021-05-11 6:02:29
4. Connect the angled end of the water hose to the filling valve at the bottom of the rear frame. Turn the coupling manually until it is tight.
5. Using pliers, tighten the coupling an additional two-thirds turn. Do not overtighten because the coupling may be damaged.
6. If you detached the cold water hose from your washer, attach the hose to the open end of the Y-connector, tighten the coupling by hand until it is tight, and then, using a pliers, tighten an additional two-thirds turn.
7. Open the cold water tap, and then check for any leaks.
If the Y-connector cannot be directly connected to the cold water tap, use the short hose. See the "Using the short hose as an extension" section on page 30.
Installation
Untitled-3 29
English 29
2021-05-11 6:02:29
Installation
Using the short hose as an extension
B A C
1. Close the cold water tap. If you have a washer's cold water hose attached to the cold water tap, unscrew and remove the hose. Then, connect the short hose (B) to the cold water tap. Turn the coupling by hand until it is tight.
2. Using pliers, tighten the coupling an additional two-thirds turn. Do not overtighten because the coupling may be damaged.
3. Connect the Y-connector (A) to the brass male end of the short hose. Turn the coupling by hand until it is tight.
4. Using pliers, tighten the coupling an additional two-thirds turn. Do not overtighten because the coupling may be damaged.
5. Connect the angled end of the water hoses (C) to the filling valve at the bottom of the rear frame. Turn the coupling manually until it is tight.
6. Using pliers, tighten the coupling an additional two-thirds turn. Do not overtighten because the coupling may be damaged.
7. If you detached the cold water hose from your washer, attach the hose to the free end of the Y-connector, tighten the coupling by hand until it is tight, and then, using a pliers, tighten an additional two-thirds turn.
8. Open the cold water tap, and then check for any leaks.
Installation
30 English
Untitled-3 30
2021-05-11 6:02:29
STEP 5 Level the dryer To ensure optimal performance, the dryer must be level.
Using a level (A), check if the dryer is
level side to side and then front to back.
If the dryer is not level, turn the leveling
feet (B) clockwise to lower the dryer or
A
counterclockwise to raise the dryer.
Installation
B
A
B
NOTE
� To set the dryer to the same height as your washer, fully retract (A) the leveling feet by turning them counterclockwise, then loosen (B) the feet by turning them clockwise. Once the dryer is the same height as the washer, follow the directions above to level the dryer.
� Adjust the leveling feet only as much as necessary to level the dryer. Extending the leveling feet more than necessary can cause the dryer to vibrate.
Untitled-3 31
English 31
2021-05-11 6:02:29
Installation
STEP 6 Power on (for gas models)
Make sure all gas connections, the exhaust line, and all wiring is connected correctly. Then, plug the power cord into a power source and check the dryer's installation and operation using the final checklist in Step 7 below.
STEP 7 Final check
When installation is complete, confirm that: � The dryer is plugged into an electrical outlet and grounded properly. � The exhaust ductwork is connected, and the joints are taped. � You have used rigid or stiff-walled flexible metal duct material, not plastic flexible duct. � The dryer is level and is sitting firmly on the floor. � The dryer starts, runs, heats, and shuts off properly. For gas models: � The gas is supplied properly with no leaks (For gas models only).
CAUTION The burner may not ignite initially due to air in the gas line. Allowing your dryer to operate on a heat setting will purge the line. If the gas does not ignite within 5 minutes, turn your dryer off and wait 5 minutes. Be sure the gas supply to your dryer has been turned on. To confirm gas ignition, check the exhaust for heat.
Installation
32 English
Untitled-3 32
2021-05-11 6:02:30
Installation
Vent blockage test
After the dryer is installed, start the Vent Blockage Test to check if the duct system is properly installed. The Vent Blockage Test automatically detects the status of the ducts and reports any blockage or problems. Proper ducting can reduce drying time and save energy.
NOTE
The Vent Blockage Test must run when the dryer is cool. If the dryer warms up after the installation check, run the AIR FLUFF cycle for several minutes to reduce its internal temperature.
Running the vent blockage test 1. Make sure the drum is empty, and then close the door. (If there are any clothes or
other items in the drum, the test will not give accurate results.) 2. Press the Power button to turn the dryer on, then simultaneously press and hold the
Adjust Time and Dryness buttons for 3 seconds. "InS or In" appears in the dryer's display. (If you have started other procedures before the Vent Blockage Test, the dryer will not enter the Vent Blockage Test mode.) 3. Press the Start/Pause (Hold to Start) button. The Vent Blockage Test starts immediately. During the test, the number indicator makes a circle in 6 clockwise steps. The test takes about 2 minutes. Do not open the door during the test. 4. After 2 minutes, when the test is complete, the results are displayed and the dryer sounds a tone. If status of the duct system is normal, "0" appears and the dryer sounds a completion tone. If the duct system cannot exhaust properly, the check code appears, and the dryer sounds an alarm tone. For description about the code, see the "Installation check codes" section on page 34. If there are any other problems, an information code appears in the display. For description about the code, see the "Information codes" section on page 59. - To stop or cancel the Vent Blockage Test, press the Power button to turn off your
dryer. - The results remain on the display for about 5 minutes and then automatically turn
off. You can turn the results off immediately by pressing the Power button.
NOTE
� During or after the test, the internal drum is hot. Use caution to prevent burns. The Vent Blockage Test is used to check for problems in the current duct system when the dryer is installed for the first time.
Untitled-3 33
English 33
2021-05-11 6:02:30
Installation
Installation
� If the test result displays check code (the duct system is blocked ), refer to the "Ducting requirements" section on page 17 and the "Exhaust ducting guide" section below, and then take proper measures to correct any problems. If the test is suspended, it could result in incorrect results. Follow the proper procedures when testing the dryer.
� Even if the test result is normal ("End or 0"), the duct system could be blocked slightly. Properly install all duct work according to the installation instructions in this manual.
Installation check codes
Check code 0 Clg (Cg) C80 (C8) C90 (C9)
Ct tC C1
dC
9C1
Meaning Vent condition is good. The vent is clogged. About 80 % of the vent is clogged. (This may decrease the drying performance.) Over 90 % of the vent is clogged. (This may lead to poor drying performance or cause malfunction) The internal temperature of the dryer is too low (below 32 �F (0 �C)) or too high (over 104 �F (40 �C)) and therefore vent blockage cannot be detected. Temperature sensor error
Unit is detecting items inside the drum or there is an error on the dry sensor.
Unit is detecting door is open
Abnormal voltage detected
Solution
1. Clean the lint filter. 2. Check your vent condition. (Refer
to the "Ducting requirements" section) * You must take measures (such as cleaning) through expert personnel.
Leave the dryer at room temperature (41~95 �F (5~35 �C)) for an hour and check again.
Contact a service center. Remove items from the drum and check again. If the problem continues, contact a service center. Close the door properly and check again. If the problem continues, contact a service center. Check the power connection. (Refer to the "Connect the electrical wiring (for electric models)" section) If the problem continues, contact a service center.
34 English
Untitled-3 34
2021-05-11 6:02:30
Check code
Meaning
HC
Detection of abnormal temperature in drum.
Solution
Check the power connection. Check the vent condition if the problem continue, contact a service center.
Exhaust ducting guide
Ducting 1. Make sure the dryer is installed properly so the air exhausts freely. 2. Use 4-inch rigid metal ducts. Tape all joints including the dryer connection. Never use
lint-trapping screws. 3. To facilitate the exhaust, keep the ducts as straight as possible.
Cleaning Clean all old ducts before installing the dryer, and make sure the vent flap opens and closes freely. We recommend that you to clean the exhaust system annually or on a regular basis.
WARNING � To prevent fire, do not use plastic, thin-foil, or non-metal flexible ducts of any kind. � Do not use a poor exhaust system because it slows down the dryer's performance. � Do not use excessively long ducts that have multiple elbows. � Do not use crushed or clogged venting or ducts.
Installation
Untitled-3 35
English 35
2021-05-11 6:02:30
Installation
Switching the door position
To reverse the direction of the door, we recommend that you contact a qualified technician. 1. Put a soft rug on the floor to rest the
door on after you have removed it. This will prevent the door from being scratched. 2. Unplug the power cord of the dryer. 3. Remove the four hinge screws from the door, and then remove the door by lifting it up slightly.
4. Remove the two screws from the lever holder, and then remove the holder cover.
5. Put the lever holder on the other side as shown, and then tighten the screws. Install the holder cover on the opposite side as shown.
6. Use a flat-head screwdriver to remove the two hinge covers from the original side. Install the hinge covers on the opposite side as shown.
Installation
36 English
Untitled-3 36
2021-05-11 6:02:30
7. Locate and remove the 10 screws as shown. Note that screw B (x2) is longer than the others.
B
8. Remove the glass holder, and switch the positions of: a. the hinge cover and the door handle. b. the hinge holder and the glass-guide holder
9. Remove the door lever, and then move it to the other side as shown.
10.Remove the hole cover (C), and then insert and tighten the glass holder using the removed 10 screws.
11.Install the hole cover on the opposite side as shown.
B
C
Installation
Untitled-3 37
English 37
2021-05-11 6:02:31
Installation
12.Reinstall the door on the front frame, and then carefully insert and tighten the 4 hinge screws.
Installation
38 English
Untitled-3 38
2021-05-11 6:02:31
Before you start
Here are a few things you should know before starting your dryer.
Sort and load
� Put one wash load in the dryer at a time.
� Do not mix heavy and lightweight items together.
� To improve drying efficiency for one or two items, add a dry towel to the load.
� For best results, untangle items before inserting them into the dryer. Tangled items may degrade the drying efficiency or cause the door to open.
� Overloading reduces the tumbling performance, resulting in uneven drying and wrinkling.
� Unless recommended on the care label, do not dry woolens or fiberglass items.
� Avoid drying unwashed items. � Do not dry items soiled with oil, alcohol,
gasoline, etc.
Functional prerequisite Lint filter
A
To prevent a risk of fire, make sure to clean the lint filter before or after every load. 1. Turn off the dryer. 2. Open the door and pull out the lint filter
(A) from inside the drum. 3. Remove the lint, and then clean the lint
filter. 4. Reinsert the lint filter, and then close
the door.
CAUTION
� Do not operate the dryer without the lint filter in place.
� Do not use a damaged or broken lint filter. This may reduce performance and/or cause fire.
Before you start
Untitled-3 39
English 39
2021-05-11 6:02:31
Before you start
Rack Dry (applicable models only)
Some models come with a drying rack which is inserted into the drum at the factory. If your model came with a drying rack, remove the rack from the drum before you use the dryer for the first time. To remove the rack, pull the rack straight up, and then take it out of the drum. Remove the drying rack from its packaging and store the rack for later use.
If a drying rack is not provided, you can
purchase it at a local Samsung service
center. (Part Code : DC93-00374H)
To use the drying rack, follow these steps:
1. Insert the drying rack (A) inside the
tumbler with the filter handle to the
front.
2. Insert the rear legs of the drying rack
into the recessed areas of the rear wall,
A
and then press down the middle of the
drying rack to secure it in place.
3. Put items to dry on the rack. Make sure
to leave space between the items for air
flow.
4. Press Rack Dry or other Cycle Setting
according to rack drying suggestions
below, then select the drying time.
5. When the items are dry, remove the
them from the dryer, and then remove
the drying rack.
Before you start
40 English
Untitled-3 40
2021-05-11 6:02:31
Drying rack drying suggestions
Item Washable sweaters (fold sweater into same
shape as rack and lay it flat on the rack) Stuffed toys (cotton or polyester fiber-
filled) Stuffed toys (foam or rubber-filled)
Foam rubber pillows Sneakers
Cycle settings TIME DRY with the Low temperature
setting
AIR FLUFF
WARNING
� Make sure to unpack the drying rack before using it. Otherwise, the dryer can be damaged or its performance diminished.
� Drying foam rubber, plastic, or rubber on a heat setting may damage the items and create a fire hazard.
Before you start
Untitled-3 41
English 41
2021-05-11 6:02:31
Operations
WARNING To reduce the risk of fire, electric shock, or injury to persons, read the "Safety information" before operating this appliance.
Control panel
DVE55A7****
02
01
07
10
12 08
09
11 13
DVG55A7****
01
03
04 05 06
02
07
10
12 08
09
11
13
DVE52A5****
01
03
04 05 06
02
07
10
12 08
09
11 13
03
04 05 06
Operations
42 English
Untitled-3 42
2021-05-11 6:02:32
DVG52A5****
02
01
07
10
12 08
09
11
13
03
04 05 06
01 Cycle Selector 02 Digital Graphic
Display 03 Dryness
04 Temp.
Turn the Cycle Selector to select a desired cycle. When a cycle is selected, the cycle indicator lights up. � Steam Cycles: The dryer sprays water into the drum to
deodorize clothes and reduce static electricity and wrinkles. � Manual Dry: The drying time is fixed.
Displays all cycle information, including the cycle time, information code, and operating status.
Press to select a dry level. You can select from 5 different options (Less to More). Please refer to following recommendations to select the appropriate dryness. � For larger or bulkier loads, select More for complete dryness. � For items that needs to lay flat or hang to dry, use Less to
partially dry items.
NOTE
This option is not available with REFRESH, STEAM SANITIZE , ACTIVEWEAR, TIME DRY, QUICK DRY, and AIR FLUFF.
Temperature can only be adjusted in TIME DRY cycle. Press to change the temperature of the current cycle. You can select from 5 different options (Low to High). Please select the appropriate temperature depending on the items in the load. � High: For sturdy cottons or those labeled Tumble Dry. � Medium: For permanent press, synthetics, lightweight cottons,
or items labeled Tumble Dry Medium. � Low: For heat sensitive items labeled Tumble Dry Low
or Tumble Dry Warm. Provides the lowest heated drying temperature possible.
English 43
Operations
Untitled-3 43
2021-05-11 6:02:32
Operations
Operations
05 Time
06 Wrinkle Prevent
07 Eco Dry
08 Damp Alert
09 Drum Light
10 Adjust Time 11 Smart Control
(Electric models only) / Smart Monitor (Gas models only) 12 Power 13 Start/Pause (Hold to Start)
Press to adjust the drying time for the Manual Dry cycles. This is not available with the Sensor Dry cycles because the dryer determines the drying time by sensing the current moisture level of the load.
Wrinkle Prevent provides approximately 180 minutes of intermittent tumbling in unheated air at the end of the cycle to reduce wrinkling. Press Wrinkle Prevent to activate this feature. The load is dry, and can be removed at any time during the Wrinkle Prevent cycle.
This function is available with NORMAL and TIME DRY. With the Eco Dry activated, drying takes a longer time but the power consumption is reduced. The drying time can be extended by up to 3 times depending on the temperature and load. The Eco Dry function is enabled by default. (See the "Cycle chart" on page 51.)
This alert is available for all Sensor Dry cycles except for ACTIVEWEAR. Available dry levels are Normal, More, and Extra. If a load contains mixed fabrics, the Damp Alert indicator blinks when average dryness of the items in the load is 80 % dry. This lets you take items that you don't want fully dried or that dry quickly out of the dryer early while letting others continue to dry.
Press to turn the interior lamp on or off. The lamp stays lit for 2 minutes after it has turned on, regardless of whether the power is on or off or the door is open or closed, and then turns off automatically.
You can change the set time in the Manual Dry cycles. (QUICK DRY, TIME DRY, and AIR FLUFF) To change the cycle time, press
or until the desired time is displayed.
After connecting the Tumble Dryer to your home network using the Samsung Smart Washer/Dryer app, you can control or monitor the dryer remotely. When started, the Smart Control (Smart Monitor) indicator blinks. The dryer enters waiting mode and waits for remote commands.
Press to turn on/turn off the dryer.
Press to start or stop operation.
44 English
Untitled-3 44
2021-05-11 6:02:32
NOTE Do not take extremely tangled items from your washer and put them into the dryer. They can degrade the drying efficiency of the dryer or cause the door to open. We recommend that you untangle the items before putting them into the dryer. Also, do not put objects on the dryer, especially on the control panel.
CAUTION Do not spray water directly onto the control panel. This may cause a system failure.
Icon description
Sensor Dry
Filter Check
Vent Sensor (DVE(G)55A7**** models only) Steam
Child Lock Alarm Off
This icon appears when the dryer operates the cycle which senses the internal humidity to determine the drying time.
This icon displays after every load as a reminder to clean the lint filter. Clean the lint filter before every cycle and make sure the filter is properly inserted before starting a cycle.
The dryer features a vent sensor that detects and notifies you when it is time to clean the ductwork. The indicator lets you know the status of the duct.
This icon appears when the dryer is in steam process. The dryer sprays water into the drum to deodorize clothes and reduce static electricity and wrinkles.
This icon indicates that Child Lock is on. For more information on Child Lock, see page 53.
This icon indicates that the alarm is off. For more information on Alarm Off, see page 53.
Wi-Fi
This icon indicates that the dryer is connected to Wi-Fi.
Operations
Untitled-3 45
English 45
2021-05-11 6:02:33
Operations
Simple steps to start
1. Press Power to turn the dryer on. 2. Turn the Cycle Selector to select a cycle. 3. Change the cycle settings (Dryness, Temp., and Time) as necessary. 4. Select desired options as necessary. 5. Press and hold Start/Pause (Hold to Start). To change the cycle during operation 1. Press Start/Pause (Hold to Start) to stop operation. 2. Select a different cycle, and repeat steps 2-4 above if necessary. 3. Press and hold Start/Pause (Hold to Start) again to start the new cycle.
Operations
46 English
Untitled-3 46
2021-05-11 6:02:33
Cycle overview Standard Cycles
Cycle NORMAL
HEAVY DUTY BEDDING PERM PRESS DELICATES
ACTIVEWEAR
DOWNLOADED
Description
For most fabrics including cottons and linens. If NORMAL is selected, the Eco Dry function is enabled by default. For more information, see Eco Dry in the "Control panel" section.
For drying items made out of heavy fabrics, such as jeans, corduroys, or work clothes, with high temperature heat.
For bulky items such as blankets, sheets, and comforters.
For drying wrinkle-free cottons, synthetic fabrics, knits, and permanent press fabrics automatically.
For heat-sensitive items at a low drying temperature.
For exercise wear and outdoor wear such as sports jerseys, training pants, water-repellent jackets, and other performance clothing. Thick fabrics like a zipper or velcro closure of a jacket, or training socks may not be completely dried.
� Select to choose from more cycles available on the Samsung Smart Washer/Dryer app on your smartphone.
� Available cycles: ECO NORMAL, SHIRTS, DENIM, TOWELS, RACK DRY, WRINKLE AWAY
� Factory setting: WRINKLE AWAY
Operations
Untitled-3 47
English 47
2021-05-11 6:02:33
Operations
Manual Dry You can change the drying settings manually to your preference.
QUICK DRY TIME DRY AIR FLUFF
A quick drying cycle running for 30 minutes. The default cycle time is 30 minutes. However, you may manually change the cycle time if necessary.
You can specify a cycle time in minutes. If TIME DRY is selected, the Eco Dry function is enabled by default. For more information, see Eco Dry in the "Control panel" section.
Tumbles the load in room temperature air.
Steam Cycles Use steam to reduce wrinkling and odors on items.
Cycle STEAM SANITIZE
REFRESH
Description
Use to sanitize items by applying steam and high-temperature heat to the fabric. This cycle can make items soft and reduce smells. Confirm that the laundry load is wet or partially wet before starting this cycle.
Use to smooth out wrinkles and reduce odors in loads of one to four items. With this cycle selected, a small amount of water is sprayed into the dryer drum after several minutes of tumbling with heat. Confirm that the laundry load is dry.
Operations
48 English
Untitled-3 48
2021-05-11 6:02:33
Cycle chart
NOTE
For best results, follow the load size recommendations for each dry cycle. � Large load: Fill the drum to about 3/4 full. Do not add items over this level as they
need to tumble freely. � Medium load : Fill the drum to about 1/2 full. � Small load : Fill the drum with 3-5 items, not more than 1/4 full.
Cycle NORMAL
HEAVY DUTY
BEDDING
DELICATES
PERM PRESS
ACTIVEWEAR QUICK DRY TIME DRY AIR FLUFF
STEAM SANITIZE REFRESH
Recommended items
Cottons, work clothes, linens, mixed loads
Heavy fabrics such as jeans, corduroys, heavy work clothes
Bulky items such as blankets, sheets, comforters, pillows
Underwear, blouses, lingerie
Shirts, synthetic fabrics, knits, wrinkle-free cottons, permanent press
Water-repellent wear, performance clothes, sports wear (Maximum : 4 lbs) Small loads Any load Foam,rubber, plastic
Bedding, curtains, children's clothing
Shirts, trousers, comforters, pillows
Load size
Dry level Normal dry (Adjustable) Normal dry (Adjustable) Normal dry (Adjustable) Normal dry (Adjustable) Normal dry (Adjustable) Normal dry (Not adjustable)
-
-
-
Very dry (Not adjustable)
-
Operations
Untitled-3 49
English 49
2021-05-11 6:02:34
Operations
NOTE : factory setting, : can be selected
Cycle
NORMAL HEAVY DUTY
BEDDING DELICATES PERM PRESS ACTIVEWEAR QUICK DRY TIME DRY AIR FLUFF STEAM SANITIZE REFRESH
High
Functions (Temp. Control)
Low
Time
Operations
50 English
Untitled-3 50
2021-05-11 6:02:34
DVE(G)55A7**** models
Cycle
NORMAL HEAVY DUTY
BEDDING DELICATES PERM PRESS ACTIVEWEAR QUICK DRY TIME DRY AIR FLUFF STEAM SANITIZE REFRESH
DVE(G)52A5**** models
Cycle
NORMAL HEAVY DUTY
BEDDING DELICATES PERM PRESS ACTIVEWEAR QUICK DRY TIME DRY AIR FLUFF STEAM SANITIZE REFRESH
Adjust Time
Damp Alert
Options Eco Dry
Adjust Time
Damp Alert
Options Eco Dry
Wrinkle Prevent
Wrinkle Prevent
Operations
Untitled-3 51
English 51
2021-05-11 6:02:34
Operations
Cycle guide
The best way to dry items is to follow the instructions on the care label. If no drying instructions are provided, see the following table for reference.
Cycle Bedspreads & Comforters
Blankets
Curtains & Draperies
Cloth Diapers Down�filled Items (jackets, sleeping bags, comforters, etc.) Foam Rubber (rug backs, stuffed toys, shoulder pads, etc.)
Pillows
Plastics (shower curtains, outdoor furniture covers, etc.)
Description Follow the care label instructions or dry using BEDDING. � Make sure the item is thoroughly dry before using or storing. � May require repositioning in the drum to ensure even drying. Use NORMAL and dry only one blanket at a time for best tumbling action. � Make sure blankets are thoroughly dry before using or
storing. Use PERM PRESS and the Medium temperature setting to help minimize wrinkling. � Dry curtains and draperies in small loads for best results and
remove as soon as possible. Use NORMAL and the Medium temperature setting for soft, fluffy diapers. Use NORMAL and the Medium temperature setting. � Add a couple of dry towels to absorb moisture and shorten
drying time. Do not dry on a heat setting.
WARNING
Drying a rubber item with heat may damage it or cause a fire. Use NORMAL. � Add a couple of dry towels and a pair of clean sneakers to
help the tumbling action and to fluff the items. � Do not dry kapok or foam pillows using a heated drying
cycle.
Use TIME DRY and the Low or Extra Low temperature settings depending on the care label instructions.
WARNING
Do not dry: � Fiberglass items (curtains, draperies, etc.) � Woolens, unless recommended on the label � Items spotted or soaked with vegetable or cooking oils
52 English
Operations
Untitled-3 52
2021-05-11 6:02:34
Special features
Child Lock Child Lock prevents children from playing with the dryer. When Child Lock is activated, all buttons except for the Power button are disabled. To activate/deactivate Child Lock, simultaneously press and hold Dryness and Temp. for 3 seconds.
NOTE Once Child Lock is activated, it will remain active even after you restart the dryer. If other buttons, except for the Power button, do not respond, check the Child Lock indicator. If the indicator is on, follow the instructions above to turn Child Lock off.
Alarm Off You can turn the alarm on or off. When the alarm is off, the melody of cycle completion and the power-off beep will not sound. However, the other sounds stay active. � Press and hold Drum Light for 3 seconds to turn the alarm on or off. � Your setting will be retained even after you turn off the dryer. You can turn the alarm
back on by pressing and holding the same button for 3 seconds.
Operations
Untitled-3 53
English 53
2021-05-11 6:02:35
Operations
Smart Care To enable this function, you must first download the Samsung Smart Washer/Dryer app at the Play Store or the App Store and install it on a mobile device featuring a camera function. The Smart Care function has been optimized for Galaxy & iPhone series (applicable models only). 1. When the dryer detects an issue to check, an information code appears on the display.
To enter Smart Care mode, press and hold Wrinkle Prevent for 3 seconds. 2. The dryer starts the self-diagnosis procedure and displays an information code if a
problem is detected. 3. Run the Samsung Smart Washer/Dryer app on your mobile device, and then tap Smart
Care. 4. Put the mobile device close to the dryer's display so that the smartphone camera and
the dryer face each other. The app automatically recognizes the information code. 5. When the information code is recognized correctly, the app provides detailed
information about the problem with applicable solutions. NOTE � The function name, Smart Care, may differ depending on the language. � If light is reflected off the dryer's display, the app may fail to recognize the information code. � If the app fails to recognize the information code, you can enter the code manually in the app.
Operations
54 English
Untitled-3 54
2021-05-11 6:02:35
Maintenance
Keep the dryer clean for best performance and to lengthen its life cycle. WARNING
Certain internal parts are intentionally not grounded and may present a risk of electric shock only during servicing. Service Personnel - Do not contact the following parts while the appliance is energized: Control board and inlet valve.
Cleaning
Control panel � Clean with a soft, damp cloth. Do not
use abrasive substances. � Do not spray liquid cleaning agents
directly onto the dryer display. � Some laundry pre-treatment soil and
stain removers may damage the control panel. � When using liquid cleaning agents, apply them to the cleaning cloth. Do not apply them directly to the dryer. Wipe up any spills or overspray immediately.
Drum � Remove any stains from the drum with
an all-purpose cleaner. � Tumble old towels or rags to remove
any remaining stains or cleaning substances. Stains may be still visible but will not affect subsequent loads.
Powder coated drum To clean the powder coated drum, use a damp cloth with a mild, non-abrasive cleaner suitable for easily marred surfaces. Remove cleaner residue and dry with a clean cloth.
Dryer exterior � Clean with a soft, damp cloth. Do not
use abrasive substances. � Protect the surface from sharp objects. � Do not place any heavy or sharp
objects or a detergent container on the dryer. They can scratch or damage the top cover of the dryer. � The dryer has a high-gloss finish on the entire surface. Be careful not to scratch or damage the surface.
Exhaust system � Check and clean the exhaust system on
a regular basis to maintain optimum performance. � The external exhaust hood must be cleaned frequently to ensure proper air flow.
Maintenance
Untitled-3 55
English 55
2021-05-11 6:02:35
Troubleshooting
Checkpoints
If the dryer operates abnormally, first check the list of problems in the table below and try the suggested actions.
Problem Does not run.
Does not heat.
Action
� Make sure the door is latched shut. � Make sure the power cord is plugged into a live electrical
outlet. � Check your home's circuit breakers or fuses. � Press or tap Start/Pause (Hold to Start) again if the door is
opened during a cycle. � Clean the lint filter.
� Check your home's circuit breakers or fuses. � Some cycles do not require heating. Check the selected
cycle again. � For a gas dryer, make sure the gas supply is on. � Clean the lint filter and exhaust duct. � The dryer may have moved into the cool-down phase of
the cycle. � Turn off the Eco Dry option for the NORMAL or TIME DRY
cycles. When the Eco Dry option is on, the dryer performs an air dry process in the beginning of the cycle to reduce energy consumption. The air dry process does not use heated air, so you may feel that the dryer is not being heated, but this is normal.
Troubleshooting
56 English
Untitled-3 56
2021-05-11 6:02:35
Problem Does not dry. Is noisy. Dries unevenly.
Action
� Check all of the above, plus... � Make sure the exhaust hood outside your home can open
and close freely. � Check the exhaust system for lint buildup. Ducting should
be inspected and cleaned annually. � Use a 4" rigid metal exhaust duct. � Do not overload. 1 wash load = 1 dryer load. � Dry heavy items and light weight items separately. � Large, bulky items, such as blankets or comforters, may
require repositioning to ensure even drying. � Make sure that your washer is draining properly and
extracting adequate water from the load. � The load may be too small to tumble properly. Add a few
towels and restart the dryer. � The load may be too large to tumble properly. Remove
some items and restart the dryer. � Clean the lint filter.
� Check the load for objects such as coins, loose buttons, nails, etc. Remove promptly.
� It is normal to hear the dryer gas valve or heating element cycle on and off during the drying cycle.
� Make sure the dryer is leveled properly as outlined in the installation instructions.
� It is normal for the dryer to hum due to the high velocity of air moving through the dryer drum, fan, or exhaust system.
� Seams, pockets, and other similarly heavy areas may not be completely dry when the rest of the load has reached the selected dryness level. This is normal. You can choose a higher dryness level or a cycle that involves a higher dryness level.
� If one heavy item is dried with a light weight load, such as one towel with sheets, it is possible that the heavy item will not be completely dry when the rest of the load has reached the selected dryness level.
� For the best drying results, dry heavy items and light weight items separately.
Troubleshooting
Untitled-3 57
English 57
2021-05-11 6:02:35
Troubleshooting
Problem
Has odors.
Lint on clothes.
Items still wrinkled after WRINKLE PREVENT (WRINKLECARE, WRINKLE RELEASE). Water drips from the nozzle when STEAM CARE starts. Sprayed water is not visible during STEAM CARE. Extended time.
Action � Household odors from paint, varnish, strong cleaners, etc.
may enter the dryer with the surrounding room air. This is normal as the dryer draws the air from the room, heats it, pulls it through the tumbler, and exhausts it outside. � When these odors linger in the air, completely ventilate the room before using the dryer. � Use a cycle featuring the Refresh function. If odors persist, wash and dry the item again. � Use the REFRESH cycle. If odors persist, wash and dry the items again. � Make sure the lint filter is cleaned before every load. For clothes that naturally build up lint, clean the filter during the cycle. � Some fabrics are lint producers (for example, a fuzzy white cotton towel) and they must be dried separately from clothes that are lint trappers (for example, a pair of black linen pants). � Divide larger loads into smaller loads for drying. � Check pockets thoroughly before drying, then dry clothes. � Remove lint inside the drum before drying.
� Small loads of 1 to 4 items work best. � Load fewer items. Load similar-type items. � Take out the items immediately after drying is complete.
� This is steam condensation. The dripping water will stop after a short time.
� Sprayed water is difficult to see when the door is closed.
� Sensor Dry automatically senses the moisture in the load and shuts the dryer off when the selected dryness level is reached. The drying time can change according to the type and amount of laundry. See the cycle chart for reference.
If a problem persists, contact a local Samsung service center.
58 English
Untitled-3 58
2021-05-11 6:02:35
Troubleshooting
Information codes
If the dryer fails to operate, you may see an information code on the display panel. To determine what you should do, check the list of codes in the table below, and then try the suggested actions.
Code dC FC AC HC
9C1
tC
tC5 dF
Action
Operating the dryer with the door open. � Make sure the door is properly closed. � Make sure laundry is not caught in the door.
Invalid power source frequency. � Try restarting the cycle. � If this information code remains, contact a Samsung service
center.
Electronic control problem (Invalid Communication). � Contact a Samsung service center.
High temperature heating check � Clean the lint filter. � If this information code remains, contact a Samsung service
center. (enter the line test mode)
The electronic control needs to be checked. � Check if power cord is connected properly. � Check if the electrical outlet is working properly. � If the information code remains, contact a Samsung service
center.
The Thermistor1 resistance is very low or high. � Check for a clogged lint screen � Check if the vent system is restricted. � If this information code remains, contact a Samsung service
center.
The Thermistor2 resistance is very low or high. � Check for a clogged lint screen. � Check if the vent system is restricted. � If this information code remains, contact a Samsung service
center.
Incorrect door switch. � Contact a Samsung service center.
Troubleshooting
Untitled-3 59
English 59
2021-05-11 6:02:35
Troubleshooting
Code 3C
Action The PBA needs to be checked. � Unplug the power plug and contact a Samsung service center.
If any information code keeps appearing on the display, contact a Samsung service center.
Troubleshooting
60 English
Untitled-3 60
2021-05-11 6:02:35
Specifications
Fabric care chart
The following symbols provide garment care direction. The clothing care labels include symbols for drying, bleaching, drying and ironing, or dry cleaning when necessary. The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow care label directions to optimize garment life and reduce laundering problems.
Wash cycle
Normal
Permanent press / Wrinkle resistant / Wrinkle control
Gentle / Delicates
Hand wash
Water temperature
Hot Warm Cold
NOTE The Water Temperature table lists appropriate wash water temperatures for various items. The temperature range is 106-126 �F (41-52 �C) for Hot, 84-106 �F (29-41 �C) for Warm, and 61-84 �F (1629 �C) for Cold. (Wash water temperature must be a minimum of 61 �F (16 �C) for detergent activation and effective cleaning.)
Bleach Any bleach (when needed) Only non-chlorine (color-safe) bleach (when needed) Tumble dry
Normal Permanent press / Wrinkle resistant / Wrinkle control Gentle / Delicates
Special instructions Line dry / Hang to dry Drip dry Dry flat
Heat setting High Medium Low Any heat No heat / Air
Specifications
Untitled-3 61
English 61
2021-05-11 6:02:37
Specifications
Iron dry or steam temperatures High Medium Low
Warning symbols for laundering Do not wash Do not wring Do not bleach Do not tumble dry No steam (added to iron) Do not iron
Dry-clean Dry-clean Do not dry-clean Line dry / Hang to dry Drip dry Dry flat
Protecting the environment
This appliance is manufactured from recyclable materials. If you decide to dispose of this appliance, please observe local waste disposal regulations. Cut off the power cord so that the appliance cannot be connected to a power source. Remove the door so that animals and small children cannot get trapped inside the appliance.
Specifications
62 English
Untitled-3 62
2021-05-11 6:02:39
Specification sheet
Type
Capacity (Cu.ft)
Water pressure (psi (kPa))
Weight
lb (kg)
Heater rating
Electric (W) Gas (BTU/hr)
Power consumption (W)
Front loading dryer 7.4
20-116 (137-800) 119.0 (54.0) 5300 20000 5400
Specifications
Untitled-3 63
English 63
2021-05-11 6:02:39
LIMITED WARRANTY (U.S.A.)
SAMSUNG DRYER
LIMITED WARRANTY TO ORIGINAL CONSUMER PURCHASER WITH PROOF OF PURCHASE
This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS AMERICA, INC. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials or workmanship for the limited warranty period, starting from the date of original purchase, of:
One (1) Year All Parts and Labor
This limited warranty is valid only on products purchased and used in the United States that have been installed, operated, and maintained according to the instructions attached to or furnished with the product. To receive warranty service, the purchaser must contact SAMSUNG at the address or phone number provided below for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG's authorized service center to receive warranty service.
SAMSUNG will provide in-home service within the contiguous United States during the warranty period at no charge, subject to availability of SAMSUNG authorized servicers within the customer's geographic area. If in-home service is not available, SAMSUNG may elect, at its option, to provide transportation of the product to and from an authorized service center. If the product is located in an area where service by a SAMSUNG authorized servicer is not available, you may be responsible for a trip charge or required to bring the product to a SAMSUNG authorized service center for service.
To receive in-home service, product must be unobstructed and accessible to the service agent.
During the applicable warranty period, a product will be repaired, replaced, or the purchase price refunded, at the sole option of SAMSUNG. SAMSUNG may use new or reconditioned parts in repairing a product, or replace the product with a new or reconditioned product. Replacement parts and products are warranted for the remaining portion of the original product's warranty or ninety (90) days, whichever is longer. All replaced parts and products are the property of SAMSUNG and you must return them to SAMSUNG.
64 English
Untitled-3 64
2021-05-11 6:02:39
This limited warranty covers manufacturing defects in materials or workmanship encountered in normal household, noncommercial use of this product and shall not cover the following: damage that occurs in shipment, delivery, installation, and uses for which this product was not intended; damage caused by unauthorized modification or alteration of the product; product where the original factory serial numbers have been removed, defaced, changed in any way, or cannot be readily determined; cosmetic damage including scratches, dents, chips, and other damage to the product's finishes; damage caused by abuse, misuse, pest infestations, accident, fire, floods, or other acts of nature or God; damage caused by use of equipment, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG; damage caused by incorrect electrical line current, voltage, fluctuations and surges; damage caused by failure to operate and maintain the product according to instructions; in-home instruction on how to use your product; and service to correct installation not in accordance with electrical or plumbing codes or correction of household electrical or plumbing (i.e., house wiring, fuses, or water inlet hoses). The cost of repair or replacement under these excluded circumstances shall be the customer's responsibility.
Visits by an authorized servicer to explain product functions, maintenance or installation are not covered by this limited warranty. Please contact SAMSUNG at the number below for assistance with any of these issues.
Untitled-3 65
English 65
2021-05-11 6:02:39
LIMITED WARRANTY (U.S.A.)
EXCLUSION OF IMPLIED WARRANTIES IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. This warranty gives you specific rights, and you may also have other rights, which vary from state to state.
LIMITATION OF REMEDIES YOUR SOLE AND EXCLUSIVE REMEDY IS PRODUCT REPAIR, PRODUCT REPLACEMENT, OR REFUND OF THE PURCHASE PRICE AT SAMSUNG'S OPTION, AS PROVIDED IN THIS LIMITED WARRANTY. SAMSUNG SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO TIME AWAY FROM WORK, HOTELS AND/OR RESTAURANT MEALS, REMODELING EXPENSES, LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific rights, and you may also have other rights, which vary from state to state.
SAMSUNG does not warrant uninterrupted or error-free operation of the product. No warranty or guarantee given by any other person, firm, or corporation with respect to this product shall be binding on SAMSUNG.
To obtain warranty service, please contact SAMSUNG at: Samsung Electronics America, Inc. 85 Challenger Road Ridgefield Park, NJ 07660 1-800-SAMSUNG (726-7864) www.samsung.com/us/support
66 English
Untitled-3 66
2021-05-11 6:02:39
Memo
Untitled-3 67
2021-05-11 6:02:39
Scan this with your smartphone
Energy Star only applies to DVE(G)55A7**** model. This product qualifies for ENERGY STAR in the factory default "Normal + Eco dry" setting. If you change the factory default setting or enable other features, power consumption could increase and exceed the limits qualified for ENERGY STAR.
QUESTIONS OR COMMENTS?
COUNTRY U.S.A
CALL 1-800-SAMSUNG (726-7864)
OR VISIT US ONLINE AT www.samsung.com/us/support
DC68-03784S-00
Untitled-3 68
2021-05-11 6:02:39
Secadora
Manual del usuario
DVE(G)55A7700*/DVE(G)55A7300*/DVE(G)52A5500*
Untitled-4 1
2021-05-11 6:04:43
Contenido
Contenido
Informaci�n sobre seguridad
Lo que necesita saber sobre las instrucciones de seguridad S�mbolos de seguridad importantes PROPOSICI�N 65 DE CALIFORNIA: ADVERTENCIA Precauciones de seguridad importantes Advertencias Precauciones
Aviso regulatorio
Aviso para FCC Aviso IC Anuncio sobre c�digo abierto
Requisitos de instalaci�n
Requisitos de instalaci�n importantes Consideraciones acerca de la ubicaci�n Requisitos para el tendido de conductos Requisitos de drenaje Requisitos en cuanto al gas Requisitos el�ctricos
Instalaci�n
Componentes Instalaci�n paso a paso Prueba de bloqueo de la ventilaci�n Gu�a de los conductos de drenaje Cambiar la posici�n de la puerta
Antes de comenzar
Clasificaci�n y carga Requisito de funcionamiento Secado en estante (�nicamente para los modelos aplicables)
2 Espa�ol
Untitled-4 2
4
4 4 5 5 8 8
10
10 11 12
13
13 13 17 18 19 20
23
23 25 33 36 36
39
39 39 40
2021-05-11 6:04:43
Funcionamiento
Panel de control Sencillos pasos para comenzar Descripci�n del ciclo Tabla de ciclos Gu�a de ciclos Funciones especiales
Mantenimiento
Limpieza
Soluci�n de problemas
Verificaciones C�digos de informaci�n
Especificaciones
Tabla de indicaciones sobre telas Protecci�n del medio ambiente Hoja de especificaciones
Untitled-4 3
42
42 46 47 49 52 53
55
55
56
56 60
62
62 63 64
Espa�ol 3
2021-05-11 6:04:43
Contenido
Informaci�n sobre seguridad
Informaci�n sobre seguridad
Felicitaciones por la compra de la nueva secadora Samsung. Este manual contiene informaci�n importante acerca de la instalaci�n, el uso y el cuidado del electrodom�stico. Lea detenidamente estas instrucciones a fin de aprovechar al m�ximo los m�ltiples beneficios y funciones de la secadora.
Lo que necesita saber sobre las instrucciones de seguridad
Lea este manual detenidamente para aprender a utilizar con seguridad y eficacia todas las caracter�sticas y funciones de su nuevo electrodom�stico. Conserve el manual en un lugar seguro cerca del electrodom�stico para consultas futuras. Utilice este electrodom�stico solo para el prop�sito para el que fue destinado como se describe en este manual. Las advertencias y las instrucciones de seguridad importantes de este manual no cubren todas las posibles condiciones y situaciones que pueden ocurrir. Es su responsabilidad actuar con sentido com�n, precauci�n y cuidado cuando instale, realice el mantenimiento y ponga en funcionamiento la secadora. Puesto que las siguientes instrucciones de funcionamiento sirven para varios modelos, las caracter�sticas de su secadora pueden diferir ligeramente de las que se describen en este manual y es posible que no todos los signos de advertencia sean aplicables. Si tiene alguna consulta o duda, comun�quese con el centro de servicio m�s cercano o busque ayuda e informaci�n en l�nea en www.samsung.com.
S�mbolos de seguridad importantes
Los �conos y las se�ales incluidas en este manual del usuario significan lo siguiente: ADVERTENCIA
Peligros o pr�cticas inseguras que podr�an causar lesiones f�sicas graves o la muerte y/o da�os materiales. PRECAUCI�N
Peligros o pr�cticas inseguras que podr�an causar lesiones f�sicas y/o da�os materiales. NOTA
Indica que existe el riesgo de lesiones f�sicas o da�os materiales.
Estas se�ales de advertencia est�n aqu� para evitar que usted u otras personas sufran lesiones. Siga las instrucciones completamente. Despu�s de leer este manual, gu�rdelo en un lugar seguro para consultas futuras. Lea todas las instrucciones antes de usar el electrodom�stico. Al igual que con cualquier equipo que usa electricidad y piezas movibles, existen riesgos potenciales. Para usar este electrodom�stico en forma segura, familiar�cese con su funcionamiento y man�jelo con cuidado cuando lo use.
4 Espa�ol
CONSERVE ESTAS INSTRUCCIONES
Untitled-4 4
2021-05-11 6:04:43
Informaci�n sobre seguridad
ADVERTENCIA - Riesgo de incendio
� La instalaci�n de la secadora de ropa debe estar a cargo de un instalador calificado. � Instale la secadora de ropa seg�n las instrucciones del fabricante y los c�digos locales. � No instale una secadora de ropa con materiales para ventilaci�n de pl�stico flexible. Si se instala un
conducto de metal flexible (tipo l�mina met�lica), debe ser de un tipo espec�fico identificado por el fabricante del electrodom�stico como adecuado para utilizar con secadoras de ropa. Los materiales para ventilaci�n flexibles suelen hundirse, aplastarse f�cilmente y atrapar pelusa. Estas condiciones obstruir�n el flujo de aire de la secadora de ropa y aumentar�n el riesgo de incendio. � Para reducir el riesgo de lesiones graves o muerte, siga todas las instrucciones de instalaci�n. � Guarde estas instrucciones.
PROPOSICI�N 65 DE CALIFORNIA: ADVERTENCIA
ADVERTENCIA
C�ncer y afecciones reproductivas - www.P65Warnings.ca.gov.
Precauciones de seguridad importantes
ADVERTENCIA Para reducir el riesgo de incendio, descarga el�ctrica o lesiones f�sicas cuando usa este electrodom�stico, siga las instrucciones de seguridad b�sicas que figuran a continuaci�n: 1. Lea todas las instrucciones antes de usar este electrodom�stico. 2. No seque prendas que han sido previamente limpiadas, lavadas, remojadas o salpicadas con gasolina,
solventes de limpieza en seco u otras sustancias inflamables o explosivas, ya que emiten vapores que pueden incendiarse o explotar. 3. No utilice la secadora para secar ropa que tenga restos de sustancias inflamables, como aceites vegetales, de cocci�n o de m�quina, productos qu�micos inflamables, disolventes de pinturas, etc., o que contengan cera o productos qu�micos, como trapeadores y pa�os de limpieza. Las sustancias inflamables pueden ocasionar que la tela se incendie. 4. No almacene ni utilice gasolina u otros vapores o l�quidos inflamables cerca de este o cualquier otro aparato el�ctrico. 5. No permita que los ni�os jueguen sobre el electrodom�stico ni dentro de �l. Se requiere de supervisi�n cuando el electrodom�stico es utilizado cerca de los ni�os.
CONSERVE ESTAS INSTRUCCIONES
Espa�ol 5
Untitled-4 5
2021-05-11 6:04:43
Informaci�n sobre seguridad
Informaci�n sobre seguridad
6. Antes de descartar el electrodom�stico o de retirarlo de servicio, extraiga la puerta del compartimiento de secado.
7. No introduzca la mano en el electrodom�stico si el tambor est� en movimiento. 8. No instale ni almacene este electrodom�stico donde quede expuesto a los factores clim�ticos. 9. No modifique los controles internos. 10. No repare, reemplace ni intente realizar el mantenimiento de cualquier pieza del electrodom�stico
salvo que est� recomendado espec�ficamente en las instrucciones de mantenimiento del usuario o en las instrucciones de reparaci�n para el usuario publicadas y que, a su juicio, usted tenga la habilidad para llevarlas a cabo. 11. No utilice suavizante de telas o productos para eliminar la est�tica a menos que el fabricante del suavizante o del producto lo recomiende. 12. Limpie el filtro para pelusas antes o despu�s de cada carga. 13. No aplique calor para secar prendas que contengan goma espuma o materiales semejantes a la goma con textura similar. 14. Mantenga el �rea alrededor de la salida del drenaje y las �reas adyacentes libres de la acumulaci�n de pelusa, polvo y suciedad. 15. El personal t�cnico calificado debe efectuar una limpieza peri�dica del interior del electrodom�stico y del conducto de drenaje. 16. No coloque elementos expuestos a aceites de cocina en la secadora. Los elementos contaminados con aceites de cocina pueden contribuir a que se produzca una reacci�n qu�mica que ocasione que la carga de ropa se incendie. Para reducir el riesgo de incendio debido a cargas de ropa contaminada, la parte final del ciclo de la secadora se realiza sin calor (per�odo de enfriamiento). No detenga la secadora antes de terminar el ciclo de secado, pero si lo hace, retire r�pidamente la ropa y esp�rzala para que se disipe el calor. 17. Este electrodom�stico debe conectarse a tierra. Consulte "Requisitos el�ctricos" y "Conexi�n a tierra" en la secci�n "Instalaci�n". 18. No permita que los ni�os jueguen sobre el electrodom�stico ni dentro de �l. Se requiere de supervisi�n cuando el electrodom�stico es utilizado cerca de los ni�os. 19. No introduzca las manos bajo la secadora. - Puede provocar lesiones f�sicas. 20. Al cerrar la puerta tenga cuidado de no atrapar los dedos de los ni�os. - Puede provocar lesiones f�sicas. 21. El panel de control y la v�lvula de entrada no est�n conectados a tierra intencionalmente y pueden presentar riesgo de descarga el�ctrica �nicamente durante el servicio t�cnico. - No toque esta parte mientras el electrodom�stico est� recibiendo electricidad.
6 Espa�ol
CONSERVE ESTAS INSTRUCCIONES
Untitled-4 6
2021-05-11 6:04:43
Informaci�n sobre seguridad
ADVERTENCIA - Para reducir el riesgo de incendio o explosi�n:
� No seque prendas que hayan sido previamente limpiadas, lavadas, remojadas o salpicadas con gasolina, solventes de limpieza en seco u otras sustancias inflamables o explosivas. Emiten vapores que pueden incendiarse o explotar. No se debe colocar en la secadora ning�n material que haya estado en contacto con un solvente de limpieza o con l�quidos o s�lidos inflamables hasta que se haya eliminado todo vestigio de tales l�quidos o s�lidos inflamables y sus vapores. Existen muchos art�culos altamente inflamables en los hogares, tales como acetona, alcohol desnaturalizado, gasolina, kerosene, algunos limpiadores l�quidos de uso dom�stico, algunos quitamanchas, aguarr�s, ceras y removedores de cera.
� No se deben secar art�culos que contengan goma espuma (puede estar catalogada como espuma de l�tex) o materiales semejantes a la goma y con textura similar en la opci�n de secado con calor. Los materiales de goma espuma que reciben calor pueden, en ciertas circunstancias, provocar incendios por combusti�n espont�nea.
ADVERTENCIA - Qu� hacer si percibe olor a gas:
� No intente encender ning�n electrodom�stico. � No encienda el electrodom�stico. � No toque ning�n interruptor el�ctrico. � No utilice ning�n tel�fono de su edificio. � Haga que todos los ocupantes se retiren del cuarto, edificio o �rea. � Comun�quese inmediatamente con el proveedor de gas desde el tel�fono de un vecino. Siga las
instrucciones del proveedor de gas. � Si no se puede comunicar con el proveedor de gas, llame al departamento de bomberos. � La instalaci�n y el servicio t�cnico deber�n estar a cargo de un instalador calificado, una agencia de
reparaciones o el proveedor de gas.
CONSERVE ESTAS INSTRUCCIONES
Espa�ol 7
Untitled-4 7
2021-05-11 6:04:44
Informaci�n sobre seguridad
Informaci�n sobre seguridad
Advertencias
ADVERTENCIA
� Aseg�rese de que los bolsillos no contengan objetos peque�os, s�lidos y de forma irregular, material extra�o, etc., por ejemplo: monedas, cuchillos, alfileres, etc. Tales objetos podr�an da�ar la secadora.
� Se pueden producir p�rdidas de gas en su sistema que generen una situaci�n peligrosa.
Precauciones
PRECAUCI�N
� No permita que los ni�os o las mascotas jueguen sobre el electrodom�stico, dentro de �l o frente a �l. Se requiere de supervisi�n cuando el electrodom�stico es utilizado cerca de ni�os y mascotas.
� Antes de eliminar la secadora o de retirarla de servicio, quite la puerta del compartimiento de secado para evitar que los ni�os o las mascotas queden atrapados dentro de la secadora.
� No introduzca la mano en el electrodom�stico cuando el tambor est� en movimiento. � No instale ni almacene este electrodom�stico donde quede expuesto a los factores clim�ticos. � No modifique los controles. � No repare ni reemplace ni intente realizar el mantenimiento de ninguna pieza del electrodom�stico
salvo que est� indicado espec�ficamente en las instrucciones de reparaci�n para el usuario y que comprenda y tenga la habilidad para llevar a cabo el procedimiento. � No utilice suavizante de telas o productos para eliminar la est�tica a menos que el suavizante o producto est� recomendado para uso con la secadora por el fabricante del mismo. � Limpie el filtro para pelusas antes o despu�s de cada carga. � Mantenga el �rea alrededor de la salida del drenaje y las �reas circundantes libres de pelusa, polvo y suciedad. � El personal t�cnico calificado debe efectuar una limpieza peri�dica del interior de la secadora y del conducto de drenaje. � Este electrodom�stico debe conectarse a tierra correctamente. Nunca enchufe el cable de alimentaci�n a un recept�culo que no est� conectado a tierra correctamente y que no guarde conformidad con los c�digos locales y nacionales. Consulte las instrucciones de instalaci�n para obtener informaci�n sobre c�mo conectar este electrodom�stico a tierra. � No se siente encima de la secadora. � No lave ropa que contenga hebillas grandes, botones u otros objetos de metal pesado o s�lido. � Las p�rdidas de gas pueden no ser detectadas �nicamente por el olor. � Los proveedores de gas recomiendan que compre e instale un detector de gas aprobado por UL. � Instale y utilice de acuerdo con las instrucciones del fabricante.
8 Espa�ol
CONSERVE ESTAS INSTRUCCIONES
Untitled-4 8
2021-05-11 6:04:44
Informaci�n sobre seguridad
� No coloque prendas en la secadora que hayan sido salpicadas o remojadas con aceite vegetal o aceite de cocina. Incluso despu�s del lavado, estas prendas pueden contener una cantidad importante de dichos aceites.
� El aceite residual en las prendas puede incendiarse en forma espont�nea. La posibilidad de combusti�n espont�nea aumenta cuando las prendas que contienen aceite vegetal o aceite de cocina son expuestas al calor. Las fuentes de calor, tales como la secadora, pueden calentar estas prendas y permitir que se produzca la oxidaci�n del aceite a modo de reacci�n. La oxidaci�n genera calor. Si dicho calor no tiene forma de salir, las prendas pueden calentarse lo suficiente como para incendiarse. Amontonar, apilar o guardar este tipo de prendas puede impedir que el calor escape y puede generar un peligro de incendio.
� Todas las prendas limpias y sucias que contengan aceite vegetal o aceite de cocina pueden resultar peligrosas. Lavar dichas prendas en agua caliente con una dosis adicional de detergente reducir� el peligro, aunque no lo eliminar�. Siempre use el ciclo Cool Down (Enfriamiento) para estas prendas a fin de reducir la temperatura. Nunca retire estas prendas cuando la secadora est� caliente ni interrumpa el ciclo de secado hasta que las prendas hayan pasado por el ciclo Cool Down (Enfriamiento). Nunca amontone o apile estas prendas cuando est�n calientes.
CONSERVE ESTAS INSTRUCCIONES
Espa�ol 9
Untitled-4 9
2021-05-11 6:04:44
Aviso regulatorio
Aviso regulatorio
Aviso para FCC
PRECAUCI�N Todos los cambios y modificaciones que no cuenten con la aprobaci�n expresa de la parte responsable del cumplimiento invalidar� la autoridad del usuario para operar el equipo.
Este dispositivo cumple con el Apartado 15 de las Normas de la FCC. El funcionamiento se encuentra sujeto a las siguientes dos condiciones: 1. Este electrodom�stico no puede causar interferencia da�ina, y 2. Este electrodom�stico debe aceptar la recepci�n de cualquier interferencia, incluidas aquellas que
puedan causar un funcionamiento indeseado.
En los productos vendidos en los mercados de Estados Unidos y Canad�, solo est�n disponibles los canales 1�11. No es posible seleccionar otros canales.
DECLARACI�N DE LA FCC: Este equipo ha sido sometido a pruebas y se ha determinado que se encuentra dentro de los l�mites para los dispositivos digitales clase B, de acuerdo con el apartado 15 de las Normas de la FCC. Dichos l�mites han sido dise�ados para proporcionar una protecci�n razonable contra la interferencia da�ina en una instalaci�n residencial. Este equipo genera, utiliza y puede irradiar energ�a de frecuencias de radio y, si no se lo instala y utiliza de acuerdo con las instrucciones, puede provocar interferencia da�ina a las comunicaciones de radio. Sin embargo, no existe garant�a alguna de que no habr� interferencia en una instalaci�n determinada. Si el equipo provoca interferencia da�ina a la recepci�n de radio o televisi�n, que puede determinarse al encender y apagar el equipo, se sugiere que el usuario trate de corregir la interferencia mediante una o m�s de las siguientes medidas: � Reorientar o reubicar la antena receptora � Aumentar la distancia entre el equipo y el receptor � Conectar el equipo a un tomacorriente que est� en un circuito diferente al de la radio o el televisor. � Consultar al distribuidor o a un t�cnico experimentado en radio/TV para obtener ayuda.
DECLARACI�N DE LA FCC SOBRE LA EXPOSICI�N A LA RADIACI�N: Este equipo cumple con los l�mites de exposici�n a la radiaci�n establecidos por la FCC para un entorno no controlado. Este equipo debe instalarse y utilizarse con una distancia m�nima de 8 pulgadas (20 cm) entre el radiador y su cuerpo. Este electrodom�stico y su/s antena/s no deben ubicarse ni utilizarse junto con ninguna otra antena o transmisor.
10 Espa�ol
CONSERVE ESTAS INSTRUCCIONES
Untitled-4 10
2021-05-11 6:04:44
Emisor involuntario seg�n el apartado 15 de las Normas de la FCC
Tipo de producto: Secadora de ropa
Modelo: DVE55A7300*
Parte responsable: Informaci�n de contacto en EE. UU.
Samsung Electronics America, Inc. QA Lab America 19 Chapin Rd. Building D Pine Brook NJ 07058 Tel: 1-973-808-6375 Fax: 1-973-808-63
Aviso regulatorio
Aviso IC
El t�rmino "IC" antes del n�mero de certificaci�n de radio significa �nicamente que se han cumplido las especificaciones t�cnicas del Ministerio de Industria del Canad�. El funcionamiento se encuentra sujeto a las siguientes dos condiciones: 1. Este electrodom�stico no puede causar interferencia, y 2. Este electrodom�stico debe aceptar cualquier interferencia, incluidas aquellas que puedan causar un
funcionamiento indeseado del dispositivo.
Este aparato digital Clase B cumple con la norma canadiense ICES-003. Cet appareil num�rique de la classe B est conforme � la norme NMB-003 du Canada.
En los productos vendidos en los mercados de Estados Unidos y Canad�, solo est�n disponibles los canales 1�11. No es posible seleccionar otros canales.
DECLARACI�N DE LA IC SOBRE LA EXPOSICI�N A LA RADIACI�N: Este equipo cumple con los l�mites de exposici�n a la radiaci�n RSS-102 establecidos por la IC para un entorno no controlado. Este equipo debe instalarse y utilizarse con una distancia m�nima de 8 pulgadas (20 cm) entre el radiador y su cuerpo. Este electrodom�stico y su/s antena/s no deben ubicarse ni utilizarse junto con ninguna otra antena o transmisor.
CONSERVE ESTAS INSTRUCCIONES
Espa�ol 11
Untitled-4 11
2021-05-11 6:04:44
Aviso regulatorio
Anuncio sobre c�digo abierto
El software incluido en este producto contiene software de c�digo abierto. Puede obtener el correspondiente c�digo fuente completo por un per�odo de tres a�os a partir del �ltimo env�o de este producto enviando un correo electr�nico a mailto:oss.request@samsung.com. Asimismo es posible obtener el correspondiente c�digo fuente completo en un soporte f�sico como un CDROM; se le cobrar� una tasa m�nima. La siguiente URL http://opensource.samsung.com/opensource/SMART_AT_051/seq/0 lleva a la p�gina de descarga del c�digo fuente disponible y a la informaci�n de licencia de c�digo abierto relacionada con este producto. Esta oferta es v�lida para quienes reciban esta informaci�n.
Aviso regulatorio
NOTA
Por la presente, Samsung Electronics declara que el artefacto del tipo de equipo radioel�ctrico se ajusta a lo dispuesto en la Directiva 2014/53/EU. El texto completo de la declaraci�n de conformidad de la UE est� disponible en la siguiente direcci�n de internet: La declaraci�n oficial de conformidad puede encontrarse en http://www.samsung.com, vaya a Soporte > busque Conoce tu producto e ingrese el nombre del modelo. Potencia m�xima de transmisor Wi-Fi: 20 dBm a 2.412 GHz � 2.472 GHz
12 Espa�ol
CONSERVE ESTAS INSTRUCCIONES
Untitled-4 12
2021-05-11 6:04:44
Requisitos de instalaci�n
Requisitos de instalaci�n
Lea atentamente las siguientes instrucciones antes de instalar la secadora y conserve este manual para futuras consultas.
ADVERTENCIA Algunas piezas internas no est�n conectadas a tierra intencionalmente y pueden presentar riesgo de descarga el�ctrica �nicamente durante el servicio t�cnico. Personal del servicio t�cnico: No toque las siguientes piezas mientras el electrodom�stico est� recibiendo electricidad: Panel de control y v�lvula de entrada.
Requisitos de instalaci�n importantes
� Un tomacorriente con conexi�n a tierra. � Un cable de alimentaci�n para las secadoras el�ctricas (excepto en Canad�). � Conductos de gas (para modelos a gas) que deben cumplir con la normativa local y nacional. � Un sistema de drenaje de metal r�gido o flexible con un recubrimiento de metal resistente.
ADVERTENCIA Retire la puerta de todos los electrodom�sticos desechados para evitar que un ni�o se asfixie.
Consideraciones acerca de la ubicaci�n
� Espacios libres suficientes entre la secadora y las paredes adyacentes u otras superficies. � Circulaci�n de aire adecuada para la ventilaci�n y combusti�n de gas. � Alejada del agua y los factores clim�ticos.
ADVERTENCIA � Aseg�rese de que la secadora drene afuera a fin de reducir el riesgo de incendio. � Mantenga el �rea de la secadora libre de materiales combustibles, gasolina y otros vapores y l�quidos
inflamables. � No instale otros electrodom�sticos que quemen combustible cerca o en el mismo lugar que la secadora. � Coloque la secadora al menos a 18 pulgadas (460 mm) sobre el suelo en una instalaci�n en un garaje.
Untitled-4 13
Espa�ol 13
2021-05-11 6:04:44
Requisitos de instalaci�n
Dimensiones
A U
Dimensiones (in. (mm))
9
Tipo Modelo
A. Altura total B. Ancho
C. Profundidad con la puerta abierta D. Profundidad
Secadora de carga frontal
DVE(G)55A7****
DVE(G)52A5****
45.8 (1163)
44.6 (1134)
27.0 (686)
50.1 (1273)
30.2 (768)
Requisitos de instalaci�n
14 Espa�ol
Untitled-4 14
2021-05-11 6:04:44
Requisito de espacio libre Este requisito de espacio libre solo se aplica a las secadoras.
NOTA
� Para el requisito de espacio libre para lavadoras, consulte el manual del usuario de la lavadora. � Si la lavadora y la secadora tienen distintos requisitos de espacio libre, utilice el valor mayor.
Instalaciones del electrodom�stico en un gabinete o en un hueco
ADVERTENCIA
� La secadora debe tener un drenaje con salida hacia el exterior para reducir el riesgo de incendio cuando se instala en un gabinete o en un hueco.
� No se debe instalar ning�n otro electrodom�stico que queme combustible en el mismo gabinete de la secadora.
� Coloque la secadora al menos a 18 pulgadas (460 mm) sobre el suelo en una instalaci�n en un garaje. Espacio libre m�nimo para un funcionamiento estable:
Laterales 1 in / 25 mm
Arriba 17 in / 432 mm
Posterior 5.9 in / 150 mm
Frente 1 in / 25 mm
Si se instalan una lavadora y una secadora en la misma ubicaci�n, el frente del gabinete o hueco debe tener dos aberturas de aire sin obstrucciones que combinadas sean de al menos 72 in� (465 cm�).
Requisitos de instalaci�n
Untitled-4 15
Espa�ol 15
2021-05-11 6:04:44
Requisitos de instalaci�n
Este requisito de espacio libre se aplica a la instalaci�n de lavadora y secadora juntas. Instalaci�n lado a lado
B
A
A
A
1 in (25 mm)
B
21 in (533 mm)
C
1 in (25 mm)
D
5.9 in (150 mm)
C
D
Requisitos de instalaci�n
16 Espa�ol
Untitled-4 16
2021-05-11 6:04:45
Requisitos de instalaci�n
Requisitos para el tendido de conductos
Recomendado
Utilice solo para instalaci�n de distancia corta
Tipo tapa para intemperie
N.� de codos de 90� 0 1 2 3
4" (10.2 cm) R�gido
80 ft (24.4 m) 68 ft (20.7 m) 57 ft (17.4 m) 47 ft (14.3 m)
2.5" (6.4 cm) R�gido
74 ft (22.6 m) 62 ft (18.9 m) 51 ft (15.5 m) 41 ft (12.5 m)
NOTA
* Utilice un conducto de acero galvanizado o de aluminio, de 4 pulgadas (10.2 cm) de di�metro.
Si integrar� el sistema de ventilaci�n de la secadora con un sistema de drenaje existente, aseg�rese de: � Que el sistema de drenaje cumpla con todas las normativas locales, estatales y nacionales. � No utilizar un conducto flexible de pl�stico. � Controlar y limpiar regularmente toda la pelusa acumulada del interior de los conductos existentes. � Que el conducto no est� enroscado o aplastado. � Que el regulador de tiro de la tapa del drenaje se abra y se cierre sin inconvenientes.
Mediciones del man�metro La presi�n est�tica de cualquier sistema de drenaje no debe superar las 0,83 pulgadas de la columna de agua ni ser inferior a 0. Tenga en cuenta que estos valores se miden con la secadora en funcionamiento con un man�metro en el conducto que conecta al drenaje de la secadora. El tambor de la secadora debe estar vac�o y el filtro para pelusas limpio.
Untitled-4 17
Espa�ol 17
2021-05-11 6:04:45
Requisitos de instalaci�n
Requisitos de instalaci�n
Requisitos de drenaje
La secadora no debe drenarse hacia una chimenea, pared, techo, altillo, s�tano de peque�a altura o espacio oculto de un edificio. Si la secadora tiene un drenaje con salida hacia el exterior se evitar� que ingrese una gran cantidad de pelusa y humedad a la habitaci�n.
En Estados Unidos y Canad� � Todas las secadoras deben tener un drenaje
con salida hacia el exterior. � El conducto de drenaje requerido tiene 4
pulgadas (10.2 cm) de di�metro. � Consulte "Requisitos para el tendido de
conductos" en la secci�n "Instalaci�n" para conocer la longitud m�xima del conducto y el n�mero de codos que pueden utilizarse. � La longitud total del conducto flexible met�lico no debe superar los 7' 10 1/2" (2.4 m). � No fije el conducto con tornillos u otros medios de sujeci�n que se extiendan dentro del conducto y atrapen pelusa. � �nicamente para Estados Unidos: Utilice solo los conductos flexibles tipo l�mina met�lica, si los hubiera, identificados espec�ficamente para su utilizaci�n con el electrodom�stico por el fabricante y que cumplan con el Esquema para conductos de transici�n de secadora de ropa. Use el Tema 2158A.
Fuera de Estados Unidos y Canad� � Rem�tase a los c�digos locales.
ADVERTENCIA
� Debe colocar en la secadora un drenaje con salida hacia el exterior para reducir el riesgo de incendio cuando instala la secadora en un gabinete o en un hueco.
� No utilice conductos flexibles de pl�stico o de un material que no sea el metal.
� Si su red de conductos existente es de pl�stico, de un material no met�lico o que sea inflamable, reempl�cela por una que sea de metal.
� Utilice �nicamente un conducto de drenaje de metal que no sea inflamable para asegurar la contenci�n del aire expulsado, el calor y la pelusa.
18 Espa�ol
Untitled-4 18
2021-05-11 6:04:45
Requisitos de instalaci�n
Requisitos en cuanto al gas
ADVERTENCIA
� Utilice �nicamente gas natural o gas LP (gas licuado de propano).
� La instalaci�n debe realizarse en conformidad con los c�digos locales, o en ausencia de ellos, con el C�digo Nacional para Gas y Combustibles ANSI/Z223.1/NFPA 54, la revisi�n m�s reciente (para los Estados Unidos), o con el C�digo de Instalaci�n de Gas Natural y Propano CSA B149.1 (para Canad�).
� Las secadoras a gas est�n equipadas con un orificio para el quemador de modo que puedan ser utilizadas con gas natural. Si tiene pensado utilizar su secadora con gas LP (gas licuado de propano), deber� efectuarse la conversi�n para lograr un funcionamiento adecuado y seguro, tarea que deber� estar a cargo de un t�cnico calificado. (S�lo modelos LNG) Debe revisar el quemador de su modelo y usar el kit de propano licuado (LP) correspondiente. Para consultar la informaci�n detallada del quemador, abra la puerta y vea la etiqueta de voltaje en el marco de la puerta.
- 20,000 BTU: LPKIT-4/XAA (DC98-04114A) - 22,000 BTU: LPKIT-3/XAA (DC99-00792A) � Se recomienda usar un conducto de suministro de gas de 1/2" (1.27 cm) y el mismo debe reducirse para la conexi�n con el conducto de gas de 3/8" (1 cm) de su secadora. El C�digo Nacional para Gas y Combustibles exige que se instale una v�lvula manual de cierre del gas, aprobada y de f�cil acceso, dentro de las 6" de distancia de la secadora. � Las secadoras a gas instaladas en garajes residenciales deben estar elevadas a 18 pulgadas (46 cm) del piso.
� Adem�s, se debe instalar una conexi�n roscada macho de 1/8" (0.3 cm) N.P.T. (rosca nacional para tubos), accesible para la conexi�n del medidor de prueba, inmediatamente contra corriente de la conexi�n del suministro de gas de la secadora.
� Su secadora debe estar desconectada del sistema de suministro de gas durante las pruebas de presi�n del sistema.
� No vuelva a utilizar los viejos conductos de gas de metal flexible. El dise�o del conducto de gas flexible debe estar certificado por el est�ndar utilizado para aparatos a gas ANSI Z21.24 � CSA 6.10.
NOTA
� La secadora utiliza un sistema de encendido autom�tico para encender el quemador. No existe un piloto que permanezca constantemente encendido.
� Todo compuesto de uni�n de tuber�as utilizado debe ser resistente a la acci�n del gas licuado de petr�leo.
� A modo de cortes�a, la mayor�a de las empresas locales de gas inspeccionar�n la instalaci�n del artefacto a gas.
Instrucciones de instalaci�n de la comunidad de Massachusetts La instalaci�n de la secadora deber� estar a cargo de un plomero o un instalador de gas calificado. Se deber� instalar una v�lvula de gas manual con una manija en forma de "T" en el conducto de suministro de gas de la secadora. Si se utiliza un conector de gas flexible para instalar la secadora, el conector debe tener una longitud m�xima de 3' (36").
Untitled-4 19
Espa�ol 19
2021-05-11 6:04:45
Requisitos de instalaci�n
Requisitos de instalaci�n
ADVERTENCIA
� Se pueden producir p�rdidas de gas en su sistema y ocasionar una situaci�n peligrosa.
� Las p�rdidas de gas pueden no ser detectadas �nicamente por el olor.
� Los proveedores de gas recomiendan que compre e instale un detector de gas aprobado por UL.
� Instale y utilice de acuerdo con las instrucciones del fabricante.
Requisitos el�ctricos
El diagrama del cableado se encuentra en la placa debajo del panel de control o en el armaz�n posterior.
ADVERTENCIA
� La conexi�n inadecuada del conductor de conexi�n a tierra del equipo puede generar el riesgo de descarga el�ctrica. Consulte a un electricista o t�cnico calificado si le surgen dudas acerca de si la conexi�n a tierra de su secadora es correcta. No modifique el enchufe provisto con la secadora; si no entra en el tomacorriente, solicite a un electricista calificado que instale el tomacorriente adecuado.
� Para evitar el riesgo innecesario de incendio, descarga el�ctrica o lesiones f�sicas, todo el cableado y la conexi�n a tierra deben realizarse de conformidad con los c�digos locales o, en ausencia de ellos, de conformidad con el C�digo El�ctrico Nacional, ANSI/NFPA Nro. 70, su �ltima revisi�n (para EE.UU.) o el C�digo El�ctrico Canadiense CSA C22.1, sus �ltimas revisiones y los c�digos y ordenanzas locales. Es su responsabilidad proveer el servicio el�ctrico adecuado para su secadora.
� Todas las instalaciones de gas deber�n realizarse de conformidad con el C�digo Nacional para Combustibles ANSI/Z2231, su �ltima revisi�n (para EE.UU.) o con los C�digos de Instalaci�n CAN/CGA - B149, su �ltima revisi�n (para Canad�) y los c�digos y ordenanzas locales.
Conexi�n a tierra Esta secadora debe conectarse a tierra. En caso de que el electrodom�stico funcione mal o se descomponga, la conexi�n a tierra reducir� el riesgo de descarga el�ctrica al ofrecer una v�a de menos resistencia a la corriente el�ctrica.
Modelos a gas
ADVERTENCIA
� Su secadora tiene un cable con un conductor de conexi�n a tierra del equipo y un enchufe de conexi�n a tierra. El enchufe debe conectarse a un tomacorriente adecuado que est� correctamente instalado y conectado a tierra en conformidad con todos los c�digos y ordenanzas locales.
� No modifique el enchufe provisto con la secadora; si no entra en el tomacorriente, solicite a un electricista calificado que instale el tomacorriente adecuado.
� No conecte el cable a tierra a las tuber�as de pl�stico, las tuber�as de gas o a las ca�er�as de agua caliente.
20 Espa�ol
Untitled-4 20
2021-05-11 6:04:45
Requisitos de instalaci�n
Modelos el�ctricos
ADVERTENCIA
� Su secadora tiene un cable opcional con un conductor de conexi�n a tierra del equipo y un enchufe de conexi�n a tierra. El cable se vende por separado.
� El enchufe debe conectarse a un tomacorriente adecuado que est� correctamente instalado y conectado a tierra en conformidad con todos los c�digos y ordenanzas locales.
� No modifique el enchufe provisto con la secadora; si no entra en el tomacorriente, solicite a un electricista calificado que instale el tomacorriente adecuado.
� Si no se utiliza un cable de alimentaci�n y la secadora el�ctrica debe estar permanentemente conectada, se la debe conectar a un sistema de cableado de metal con conexi�n a tierra permanente, o se debe conectar un conductor con conexi�n a tierra del equipo a los conductores del circuito y a la terminal con conexi�n a tierra del equipo o al cable de la secadora.
Conexiones el�ctricas Antes de poner el electrodom�stico en funcionamiento o realizar pruebas, siga las instrucciones de conexi�n a tierra de la secci�n "Conexi�n a tierra". Se recomienda que se destine un circuito derivado individual (o separado) solo para la secadora. No utilice un cable prolongador.
Modelos a gas � EE.UU. y Canad� Se requiere un servicio el�ctrico aprobado de CA de 120 voltios, 60 Hz, con un fusible o interruptor de 15 A.
Modelos el�ctricos � Solo EE.UU. La mayor�a de las secadoras estadounidenses requieren un servicio el�ctrico aprobado de CA de 120/240 voltios, 60 Hz. Algunas requieren un servicio el�ctrico aprobado de 120/208 voltios, 60 Hz. Los requisitos del servicio el�ctrico pueden encontrarse en la etiqueta con informaci�n ubicada detr�s de la puerta. Se requiere un fusible o interruptor de 30 A a ambos lados del conducto. � Si se utiliza un cable de alimentaci�n, el cable
debe enchufarse a un tomacorriente de 30 A. � No se provee el cable de alimentaci�n
con los modelos el�ctricos de secadoras estadounidenses. El cable se vende por separado.
Untitled-4 21
Espa�ol 21
2021-05-11 6:04:45
Requisitos de instalaci�n
Requisitos de instalaci�n
ADVERTENCIA
Riesgo de descarga el�ctrica Si lo permiten los c�digos locales, se puede conectar el suministro el�ctrico de la secadora por medio de un nuevo kit de cable de alimentaci�n el�ctrica, rotulado para que se lo utilice con una secadora, es decir que cuente con certificaci�n U.L. y categorizado en un m�nimo de 120/240 voltios, 30 amperes con tres conductores de cobre Nro. 10 que finalicen en terminales de bucle cerrado, pernos de pala de tipo abierto con extremos rebatidos o con conductores de esta�o.
� No vuelva a utilizar un cable de alimentaci�n el�ctrica de una secadora vieja. El cable de alimentaci�n el�ctrica debe asegurarse en el gabinete de la secadora con una protecci�n contra los tirones adecuada con certificaci�n UL.
� La conexi�n a tierra a trav�s del conductor neutro est� prohibida para (1) instalaciones nuevas con circuito derivado, (2) casas rodantes, (3) veh�culos de recreo y (4) �reas en las que los c�digos locales proh�ban la conexi�n a tierra a trav�s de un conductor neutro. (Utilice un enchufe de 4 pines para un tomacorriente de 4 ranuras, tipo NEMA 1430R.)
Modelos el�ctricos � Solo Canad� Se requiere un servicio el�ctrico aprobado de CA de 120/240 voltios, 60 Hz, equipado con un fusible o interruptor de 30 A a ambos lados del conducto.
NOTA
Todos los modelos canadienses se env�an con el cable de alimentaci�n adjunto. El cable de alimentaci�n debe conectarse a un tomacorriente de 30 A. En Canad� est� permitido convertir una secadora a 120/208 voltios.
22 Espa�ol
Untitled-4 22
2021-05-11 6:04:45
Instalaci�n
La instalaci�n de la secadora debe estar a cargo de un t�cnico calificado. El instalador ser� responsable de conectar la secadora a la fuente de alimentaci�n principal y a la vez de cumplir con las normas de seguridad correspondientes de su zona.
Componentes
Aseg�rese de que todos los componentes est�n incluidos en el paquete. Si tiene alg�n problema con la secadora o las piezas, comun�quese con un centro de atenci�n al cliente de Samsung o con el vendedor.
01 02
03
04
01 Panel de control 04 Puerta
05
02 Encimera 05 Conducto de drenaje
03 Filtro para pelusas
Instalaci�n
Untitled-4 23
Espa�ol 23
2021-05-11 6:04:45
Instalaci�n
Partes suministradas
Conector en forma de "Y" Herramientas necesarias para la instalaci�n
Manguera de agua corta
Pinzas
C�ter
Llave inglesa para tuber�as (solo para
modelos a gas)
Llave de tuercas
Nivelador
Destornillador Phillips Cinta para conductos
Llave inglesa
Compuesto GLP (gas licuado de petr�leo) o cinta de tefl�n (para la
instalaci�n del gas)
ADVERTENCIA Los materiales de empaque pueden ser peligrosos para los ni�os. Mantenga todos los materiales de empaque (bolsas de pl�stico, poliestireno, etc.) lejos del alcance de los ni�os.
Instalaci�n
24 Espa�ol
Untitled-4 24
2021-05-11 6:04:47
Instalaci�n
Instalaci�n paso a paso
Aseg�rese de que un t�cnico calificado instale la secadora. A continuaci�n aparecen unas instrucciones paso a paso de la instalaci�n. � No retire la pel�cula protectora de la puerta antes de finalizar la instalaci�n del producto. Si retira
la pel�cula protectora antes de finalizar la instalaci�n, la puerta puede rayarse o da�arse durante la instalaci�n. � Aseg�rese de que el lugar de instalaci�n cuente con espacio suficiente para abrir la puerta de la secadora por completo.
PASO 1 Instale el sistema de drenaje
1. Seleccione un lugar y coloque all� la secadora. Para facilitar el acceso, le recomendamos que instale la secadora en la misma ubicaci�n que la lavadora.
2. Para modificar la direcci�n de la puerta, consulte "Cambiar la posici�n de la puerta" en la p�gina 36. 3. Instale el sistema de drenaje como se indica en la secci�n "Gu�a de los conductos de drenaje".
PRECAUCI�N
Antes de instalar la secadora, quite el empaque del conducto.
NOTA
� Para mover la secadora con facilidad, coloque dos de las protecciones de cart�n del empaque en el piso. Incline la secadora hacia uno de los laterales, de modo tal que quede apoyada sobre ambas protecciones. Empuje la secadora hasta que se encuentre cerca de su ubicaci�n final y col�quela en posici�n vertical.
� Aseg�rese de que haya espacio suficiente alrededor de la secadora para facilitar la instalaci�n de conductos y el cableado.
PASO 2 Conecte el conducto de gas (para modelos a gas)
Antes de conectar el conducto de gas, aseg�rese de haber le�do la secci�n "Requisitos en cuanto al gas" en la p�gina 19. 1. Retire la tapa protectora del tubo de gas. 2. Aplique un compuesto GLP (Gas licuado de petr�leo) o 1.5 vueltas de cinta de tefl�n en todas las
conexiones roscadas. 3. Conecte el suministro de gas a la secadora. Se requiere un accesorio adicional para conectar el extremo
de la rosca hembra de 3/4" (1.9 cm) de un conector flexible al extremo de la rosca macho de 3/8" (1 cm) de la secadora. Ajuste los accesorios que cubren todas las roscas. 4. Abra el suministro de gas y verifique que no haya p�rdidas con una soluci�n jabonosa. Si encuentra alguna p�rdida, ajuste las conexiones e int�ntelo nuevamente. No use una llama abierta para verificar si hay p�rdidas de gas.
Untitled-4 25
Espa�ol 25
2021-05-11 6:04:47
Instalaci�n
PASO 3 Conecte el cableado el�ctrico (para los modelos el�ctricos)
Antes de conectar el cableado el�ctrico, aseg�rese de haber le�do la secci�n "Requisitos el�ctricos" en la p�gina 20. Sistema de 3 cables
D
A B C L2
L1 E
A. Conector a tierra externo B. Cable a tierra neutro (blanco) C. Tornillo central de color plateado del bloque
de terminales D. Cable neutro (cable blanco o central) E. Dispositivo de alivio de tensi�n con
certificaci�n UL de 3/4" (1.9 cm)
1. Afloje o retire los tornillos del bloque central de terminales.
2. Conecte el cable neutro (cable blanco o central) del cable de alimentaci�n a la terminal de tornillo central de color plateado del bloque de terminales. Ajuste los tornillos.
3. Conecte los dem�s cables a los tornillos externos del bloque de terminales. Ajuste los tornillos.
4. Ajuste los tornillos de alivio de tensi�n.
5. Inserte la cubierta del bloque de terminales en el panel trasero de la secadora. Luego, asegure la cubierta con un tornillo de sujeci�n.
PRECAUCI�N
� Para realizar la conversi�n del sistema de 4 cables a 3 cables, conecte la cinta de conexi�n a tierra al soporte del bloque de terminales para conectar a tierra el armaz�n de la secadora al conductor neutro.
� Se recomienda utilizar terminales de tipo anillo. Si utiliza terminales de correa, aseg�rese de que est�n ajustados.
� Conecte el cable de alimentaci�n y verifique el voltaje de L1/L2/N. Si el voltaje es bajo, es posible que el calentador sea deficiente. De ser necesario, consulte la secci�n "Requisitos el�ctricos" en la p�gina 20.
Instalaci�n
26 Espa�ol
Untitled-4 26
2021-05-11 6:04:47
Instalaci�n
Sistema de 4 cables
F D
A B C L2
L1 E
A. Conector a tierra externo B. Cable a tierra neutro (blanco) C. Tornillo central de color plateado del bloque
de terminales D. Cable neutro (cable blanco o central) E. Protecci�n contra los tirones con
certificaci�n UL de �" (1.9 cm) F. Cable neutro (cable blanco o central)
1. Retire el tornillo del conector externo a tierra y conecte el cable de conexi�n a tierra (verde o sin cubierta) del cable de alimentaci�n al tornillo.
PRECAUCI�N
- Para conectar el cable de conexi�n a tierra a la posici�n neutra sin atravesar el contacto A (conexi�n a tierra del gabinete), comun�quese con un t�cnico. No se trata de una operaci�n que pueda realizar el usuario.
- Se recomienda utilizar terminales de tipo anillo. Si utiliza terminales de correa, aseg�rese de que est�n ajustados.
2. Afloje o retire los tornillos del bloque central de terminales.
3. Conecte el cable neutro (cable blanco o central) y el cable de conexi�n a tierra (blanco) al tornillo central del bloque de terminales. Ajuste el tornillo.
4. Conecte los dem�s cables a los tornillos externos del bloque de terminales. Ajuste los tornillos.
5. Ajuste los tornillos de alivio de tensi�n. 6. Inserte la leng�eta de la cubierta del bloque de
terminales en la ranura trasera de la secadora. Asegure la cubierta con un tornillo de sujeci�n.
PRECAUCI�N
Conecte el cable de alimentaci�n y verifique el voltaje de L1/L2/N. Si el voltaje es bajo, es posible que el calentador sea deficiente. De ser necesario, consulte la secci�n "Requisitos el�ctricos" en la p�gina 20.
Untitled-4 27
Espa�ol 27
2021-05-11 6:04:47
Instalaci�n
ADVERTENCIA � Todos los modelos estadounidenses est�n fabricados para una conexi�n de sistemas de 3 cables.
El armaz�n de la secadora est� conectado a tierra al conductor neutro del bloque de terminales. Se requiere una conexi�n de sistemas de 4 cables para las construcciones nuevas o remodeladas, las casas rodantes o si los c�digos locales no permiten la conexi�n a tierra a trav�s del neutro. Si utiliza un sistema de 4 cables, no puede conectar a tierra el armaz�n de la secadora al conductor neutro del bloque de terminales. � Retire la tapa del bloque de terminales. Inserte el cable de alimentaci�n con un dispositivo de alivio de tensi�n con certificaci�n UL a trav�s del orificio provisto en el gabinete cerca del bloque de terminales. � Se debe utilizar un dispositivo de alivio de tensi�n. No afloje las tuercas ya instaladas en el bloque de terminales. Aseg�rese de que est�n ajustadas. Utilice un tomacorriente para huecos profundos de 3/8" (1 cm). � Desde el 1 de enero de 1996, el C�digo El�ctrico Nacional requiere que el cableado nuevo (que no exista) utilice una conexi�n de 4 cables a esta secadora.
PASO 4 Conectar la manguera de agua
La secadora debe conectarse a una llave de agua fr�a mediante las mangueras de agua provistas.
1. Cierre la llave de agua fr�a. Si tiene una manguera de agua fr�a de la lavadora conectada a la llave de agua fr�a, desatornille y quite la manguera. Luego, conecte el extremo hembra del conector en forma de Y a la llave de agua fr�a.
2. Conecte el extremo recto de la manguera de agua al conector en forma de "Y".
3. Ajuste la uni�n con otros dos tercios de giro adicionales utilizando la pinza. No ajuste de m�s dado que puede da�ar la uni�n.
Instalaci�n
28 Espa�ol
Untitled-4 28
2021-05-11 6:04:48
4. Conecte el extremo angular de la manguera de agua a la v�lvula de carga en la parte inferior del armaz�n trasero. Gire la uni�n manualmente hasta que est� ajustada.
5. Ajuste la uni�n con otros dos tercios de giro adicionales utilizando la pinza. No ajuste de m�s dado que puede da�ar la uni�n.
6. Si ha desconectado la manguera de agua fr�a de la lavadora, una la manguera al extremo abierto del conector en forma de Y, ajuste bien la uni�n a mano y, luego, ajuste con otros dos tercios de giro adicionales utilizando la pinza.
7. Abra la llave de agua fr�a y verifique que no haya p�rdidas.
Si el conector en forma de "Y" no puede conectarse directamente a la llave de agua fr�a, use una manguera corta. Consulte la secci�n "Uso de una manguera corta como prolongaci�n" en la p�gina 30.
Instalaci�n
Untitled-4 29
Espa�ol 29
2021-05-11 6:04:48
Instalaci�n
Uso de una manguera corta como prolongaci�n
B A C
1. Cierre la llave de agua fr�a. Si tiene una manguera de agua fr�a de la lavadora conectada a la llave de agua fr�a, desatornille y quite la manguera. Luego, conecte la manguera corta (B) a la llave de agua fr�a. Gire la uni�n manualmente hasta que est� ajustada.
2. Ajuste la uni�n con otros dos tercios de giro adicionales utilizando la pinza. No ajuste de m�s dado que puede da�ar la uni�n.
3. Una el conector en forma de Y (A) al extremo macho de bronce de la manguera corta. Gire la uni�n manualmente hasta que est� ajustada.
4. Ajuste la uni�n con otros dos tercios de giro adicionales utilizando la pinza. No ajuste de m�s dado que puede da�ar la uni�n.
5. Conecte el extremo angular de las mangueras de agua (C) a la v�lvula de carga en la parte inferior del armaz�n trasero. Gire la uni�n manualmente hasta que est� ajustada.
6. Ajuste la uni�n con otros dos tercios de giro adicionales utilizando la pinza. No ajuste de m�s dado que puede da�ar la uni�n.
7. Si ha desconectado la manguera de agua fr�a de la lavadora, una la manguera al extremo libre del conector en forma de Y, ajuste bien la uni�n a mano y, luego, ajuste con otros dos tercios de giro adicionales utilizando la pinza.
8. Abra la llave de agua fr�a y verifique que no haya p�rdidas.
Instalaci�n
30 Espa�ol
Untitled-4 30
2021-05-11 6:04:48
PASO 5 Nivele la secadora Para garantizar un desempe�o �ptimo, la secadora debe estar nivelada.
Con un nivel (A), verifique si la secadora est�
nivelada de lado a lado y de adelante hacia
atr�s. Si la lavadora no est� nivelada, gire la pata
niveladora (B) hacia la derecha para bajar la
A
lavadora y hacia la izquierda para elevarla.
Instalaci�n
B
A
B
NOTA
� Para colocar la secadora a la misma altura que la lavadora, retraiga (A) completamente las patas niveladoras gir�ndolas en sentido contrario al de las agujas del reloj, luego afloje (B) las patas gir�ndolas en el sentido de las agujas del reloj. Una vez que la secadora est� a la misma altura que la lavadora, siga las instrucciones precedentes para nivelar la secadora.
� Ajuste las patas niveladoras solo lo necesario para nivelar la secadora. Extender las patas niveladoras m�s de lo necesario puede hacer que la secadora vibre.
Untitled-4 31
Espa�ol 31
2021-05-11 6:04:48
Instalaci�n
PASO 6 Encendido (para modelos a gas)
Aseg�rese de que todas las conexiones de gas, el conducto de drenaje y el cableado se realicen correctamente. Luego, enchufe el cable de alimentaci�n a una fuente de alimentaci�n y verifique la instalaci�n y el funcionamiento de la secadora con la lista final de verificaci�n del paso 7.
PASO 7 Verificaci�n final
Una vez finalizada la instalaci�n, confirme que: � La secadora est� enchufada a un tomacorriente y est� conectada a tierra correctamente. � Los conductos de drenaje est�n conectados y se coloc� cinta a las uniones. � Usted us� conducto r�gido o flexible con un recubrimiento de metal resistente, no conducto flexible de
pl�stico. � La secadora est� nivelada y apoyada firmemente sobre el piso. � La secadora se pone en funcionamiento, funciona, calienta y se apaga correctamente. Para modelos a gas: � El gas se proporciona correctamente, sin p�rdidas (Solo para modelos a gas).
PRECAUCI�N Es posible que al principio el quemador no se encienda debido a la presencia de aire en el conducto de gas. Permitir que la secadora funcione con la opci�n de calor purgar� el conducto. Si en el lapso de 5 minutos el gas no se enciende, apague la secadora y espere 5 minutos. Aseg�rese de que el suministro de gas hacia su secadora est� abierto. Para confirmar que el gas est� encendido, controle que se sienta calor en el drenaje.
Instalaci�n
32 Espa�ol
Untitled-4 32
2021-05-11 6:04:48
Instalaci�n
Prueba de bloqueo de la ventilaci�n
Una vez instalada la secadora, inicie la prueba de bloqueo de la ventilaci�n para verificar si el sistema de conductos est� instalado correctamente. La prueba de bloqueo de la ventilaci�n detecta autom�ticamente el estado de los conductos e informa de cualquier bloqueo o problema. Una instalaci�n correcta de los conductos puede reducir el tiempo de secado y ahorrar energ�a.
NOTA La prueba de bloqueo de la ventilaci�n debe realizarse cuando la secadora est� fr�a. Si la secadora se calienta luego de la verificaci�n de la instalaci�n, ejecute el ciclo AIR FLUFF (TEMPERATURA AMBIENTE) durante algunos minutos para reducir su temperatura interna.
Ejecuci�n de la prueba de bloqueo de la ventilaci�n 1. Aseg�rese de que el tambor est� vac�o y luego cierre la puerta. (Si hay ropa u otros productos en el
tambor, los resultados de la prueba no ser�n precisos.) 2. Presione el bot�n Encender/Apagar para encender la secadora, luego mantenga presionados
simult�neamente los botones Adjust Time (Ajustar tiempo) y Dryness (Nivel de secado) durante 3 segundos. "InS o In" aparece en la pantalla de la secadora. (Si ha iniciado otros procedimientos antes de la prueba de bloqueo de la ventilaci�n, la secadora no accede al modo de prueba de bloqueo de la ventilaci�n.) 3. Presione el bot�n Inicio/Pausa (Hold to Start (Mantenga presionado para iniciar)) para comenzar el secado. La prueba de bloqueo de la ventilaci�n se inicia inmediatamente. Durante la prueba, el indicador num�rico gira en 6 pasos en el sentido de las agujas del reloj. La prueba dura aproximadamente 2 minutos. No abra la puerta durante la prueba. 4. Luego de 2 minutos, cuando la prueba se ha completado, se muestran los resultados y la secadora emite una se�al. Si el estado del sistema de conductos es normal, se muestra "0" y la secadora emite una se�al de finalizaci�n. Si el sistema de conductos no puede drenarse correctamente, aparece el c�digo de verificaci�n y la secadora emite una se�al de alarma. Para obtener una descripci�n del c�digo, consulte la secci�n "C�digos de verificaci�n de la instalaci�n" en la p�gina 35. Si hay otros problemas, aparece un c�digo de informaci�n en la pantalla. Para obtener una descripci�n del c�digo, consulte la secci�n "C�digos de informaci�n" en la p�gina 60. - Para detener o cancelar la prueba de bloqueo de la ventilaci�n, presione el bot�n Encender/Apagar
para apagar la secadora. - Los resultados se muestran en la pantalla durante aproximadamente 5 minutos y luego �sta se
apaga en forma autom�tica. Puede apagar el resultado inmediatamente presionando el bot�n Encender/Apagar.
NOTA � Durante y luego de la prueba, el interior del tambor est� caliente. Tenga cuidado para evitar
quemaduras. La prueba de bloqueo de la ventilaci�n se usa para detectar problemas en el sistema de conductos actual cuando la secadora se instala por primera vez.
Espa�ol 33
Untitled-4 33
2021-05-11 6:04:48
Instalaci�n
� Si el resultado de la prueba muestra un c�digo de verificaci�n (el sistema de conductos est� bloqueado), consulte la secci�n "Requisitos para el tendido de conductos" en la p�gina 17 y la secci�n "Gu�a de los conductos de drenaje" a continuaci�n, y tome las medidas correspondientes para corregir cualquier problema. Si la prueba se suspende, puede dar resultados incorrectos. Siga los procedimientos adecuados para realizar la prueba de la secadora.
� Aunque el resultado sea normal ("End o 0"), el sistema de conductos puede estar ligeramente bloqueado. Instale correctamente los conductos de acuerdo con las instrucciones de instalaci�n de este instructivo.
Instalaci�n
34 Espa�ol
Untitled-4 34
2021-05-11 6:04:49
Instalaci�n
C�digos de verificaci�n de la instalaci�n
C�digo de verificaci�n 0 Clg (Cg) C80 (C8)
C90 (C9)
Ct tC C1
dC
9C1
HC
Significado
Soluci�n
El estado de la ventilaci�n es bueno.
La ventilaci�n est� obstruida.
Aproximadamente el 80 % de la ventilaci�n est� obstruida.
1.
Limpie el filtro para pelusas.
(Esto puede afectar el desempe�o del secado.)
2. Verifique el estado de la ventilaci�n. (Consulte la secci�n "Requisitos para el tendido de conductos")
M�s del 90 % de la ventilaci�n est�
* Debe tomar medidas (como la limpieza) a
bloqueada.
realizar por personal especializado.
(Esto puede generar problemas de secado
o fallas de funcionamiento.)
La temperatura interna de la secadora es demasiado baja (inferior a 32 �F [0 �C]) o demasiado alta (superior a 104 �F [40 �C]) y, por lo tanto, no se puede detectar el bloqueo de la ventilaci�n.
Deje la secadora a temperatura ambiente (41~95 �F [5~35 �C]) durante una hora y vuelva a verificarla.
Error en el sensor de temperatura
Cont�ctese con el Servicio t�cnico.
La unidad detecta art�culos en el tambor o hay un error en el sensor de secado.
Retire los art�culos del tambor y vuelva a intentar.
Si el problema persiste, comun�quese con un centro de servicio.
La unidad detecta que la puerta est� abierta.
Cierre la puerta correctamente y vuelva a intentar.
Si el problema persiste, comun�quese con un centro de servicio.
Se detect� un voltaje an�malo.
Verifique la conexi�n el�ctrica. (Consulte la secci�n "Conecte el cableado el�ctrico (para los modelos el�ctricos)")
Si el problema persiste, comun�quese con un centro de servicio.
Detecci�n de temperatura anormal en el tambor.
Verifique la conexi�n el�ctrica.
Verifique el estado de la ventilaci�n. Si el problema persiste, comun�quese con un centro de servicio.
Untitled-4 35
Espa�ol 35
2021-05-11 6:04:49
Instalaci�n
Gu�a de los conductos de drenaje
Conductos 1. Aseg�rese de que la secadora est� instalada correctamente para que drene f�cilmente. 2. Utilice conductos de metal r�gido, de 4 pulgadas. Coloque cinta en todas las uniones, incluso en la
conexi�n de la secadora. Nunca use tornillos que atrapen pelusa. 3. Para facilitar el drenaje, mantenga los conductos tan rectos como sea posible.
Limpieza Limpie los conductos viejos antes de instalar la secadora y aseg�rese de que la ventilaci�n se abra y se cierre sin inconvenientes. Le recomendamos que limpie el sistema de drenaje anualmente o en forma regular.
ADVERTENCIA � A fin de evitar incendios, no use ning�n tipo de conducto pl�stico, con un recubrimiento delgado o de
un material que no sea el metal. � No use un mal sistema de drenaje dado que demora el desempe�o de la secadora. � No use conductos excesivamente largos con muchos codos. � No use conductos o tubos de ventilaci�n aplastados u obstruidos.
Cambiar la posici�n de la puerta
Para invertir el sentido en que se abre la puerta, le recomendamos que llame a un t�cnico calificado.
1. Coloque una pa�o suave sobre el piso para apoyar la puerta despu�s de retirarla. Esto impedir� que se raye la puerta.
2. Desenchufe el cable de alimentaci�n de la secadora.
3. Retire los cuatro tornillos de la bisagra de la puerta y luego retire la puerta levant�ndola levemente.
Instalaci�n
36 Espa�ol
Untitled-4 36
2021-05-11 6:04:49
Untitled-4 37
4. Retire los dos tornillos de la placa de apoyo y retire la cubierta de la placa.
5. Coloque la placa de apoyo del otro lado como se muestra y ajuste los tornillos. Instale la cubierta de la placa en el lado opuesto como se muestra.
6. Use un destornillador plano para retirar las dos cubiertas de la bisagra del lado original. Instale las cubiertas de la bisagra en el lado opuesto como se muestra.
7. Ubique y retire los 10 tornillos como se muestra. Tenga en cuenta que el tornillo B (x2) es m�s largo que los dem�s.
B
8. Retire el soporte del vidrio e invierta las posiciones de: a. la cubierta de la bisagra y la manija de la puerta. b. el soporte de la bisagra y el soporte de la gu�a del vidrio
9. Retire la manija de la puerta y col�quela del otro lado como se ilustra.
Espa�ol 37
2021-05-11 6:04:49
Instalaci�n
Instalaci�n
B
10. Retire la tapa del orificio (C) e inserte y ajuste el soporte del vidrio usando los 10 tornillos que retir�.
11. Instale la tapa del orificio en el lado opuesto como se muestra.
C
12. Coloque nuevamente la puerta en el marco frontal y luego inserte y ajuste con cuidado los 4 tornillos de la bisagra.
Instalaci�n
38 Espa�ol
Untitled-4 38
2021-05-11 6:04:50
Antes de comenzar
Antes de encender la secadora, debe saber algunas cosas.
Clasificaci�n y carga
� Coloque una carga de ropa en la secadora por vez.
� No mezcle prendas pesadas y livianas. � Para mejorar la eficiencia de secado al secar
una o dos prendas, agregue una toalla seca a la carga. � Para obtener mejores resultados, desenrede las prendas antes de colocarlas en la secadora. Las prendas enredadas pueden disminuir la eficacia del secado o hacer que se abra la puerta.
� Sobrecargar la secadora limita su funcionamiento y ocasiona un secado desparejo as� como la formaci�n de arrugas.
� A menos que se recomiende en la etiqueta, no seque prendas de lana o fibra de vidrio.
� Evite secar art�culos sin lavar. � No seque art�culos muy sucios con aceite,
alcohol, gasolina, etc.
Requisito de funcionamiento Filtro para pelusas
A
Para evitar el riesgo de incendios, aseg�rese de limpiar el filtro de pelusa antes o despu�s de cada carga. 1. Apague la secadora. 2. Abra la puerta y retire el filtro de pelusa (A)
del tambor. 3. Retire la pelusa y luego limpie el filtro. 4. Inserte el filtro nuevamente y cierre la puerta.
PRECAUCI�N
� No haga funcionar la secadora sin el filtro para pelusas insertado.
� No utilice un filtro de pelusa da�ado o roto. Esto podr�a reducir el desempe�o y/o provocar un incendio.
Antes de comenzar
Untitled-4 39
Espa�ol 39
2021-05-11 6:04:50
Antes de comenzar
Secado en estante (�nicamente para los modelos aplicables)
Algunos modelos se suministran con un estante de secado que viene de f�brica insertado en el tambor. Si su modelo se suministra con un estante de secado, retire este del tambor antes de usar la secadora por primera vez. Para retirarlo, jale el estante en l�nea recta hacia arriba y, luego, ret�relo del tambor. Retire el estante de secado de su empaque y gu�rdelo para uso futuro.
Si no se proporciona el estante de secado, puede
comprarlo en un centro de servicio local de
Samsung. (C�digo de pieza: DC93-00374H)
Para usar el estante de secado, siga estos pasos:
1. Inserte el estante de secado (A) en el tambor
con la tapa del filtro hacia el frente.
2. Inserte las patas traseras del estante de secado
en las �reas empotradas de la pared trasera y
presione el centro del estante de secado para
A
calzarlo.
3. Coloque las prendas que desea secar sobre el
estante. Aseg�rese de dejar espacio entre las
prendas para que fluya el aire.
4. Presione Rack Dry (Secado en estante) o
seleccione otros ajustes de ciclo de acuerdo
con las siguientes "Sugerencias para el secado
en estante", luego, seleccione el tiempo de
secado.
5. Cuando las prendas est�n secas, ret�relas de la
secadora y, luego, retire el estante de secado.
Antes de comenzar
40 Espa�ol
Untitled-4 40
2021-05-11 6:04:50
Sugerencias para el secado en estante
Elemento Su�teres lavables (d�blelos de acuerdo con la forma del estante y col�quelos en posici�n
horizontal sobre el estante) Mu�ecos de peluche (rellenos con fibras de
algod�n o poli�ster) Mu�ecos de peluche (rellenos con goma espuma)
Almohadas de goma espuma Zapatillas
Ajustes de los ciclos TIME DRY (SECADO CON TEMPORIZADOR) con el
ajuste de temperatura Low (Baja)
AIR FLUFF (TEMPERATURA AMBIENTE)
ADVERTENCIA
� Aseg�rese de desempacar el estante de secado antes de usarlo. Si no lo hace, la secadora puede da�arse o reducirse su desempe�o.
� Secar art�culos de goma espuma, pl�stico o goma con la opci�n de calor puede ocasionar da�os al art�culo y crear un peligro de incendio.
Antes de comenzar
Untitled-4 41
Espa�ol 41
2021-05-11 6:04:50
Funcionamiento
ADVERTENCIA Para reducir el riesgo de incendio, descarga el�ctrica o lesiones personales, lea "Informaci�n sobre seguridad" antes de poner en funcionamiento el electrodom�stico.
Panel de control
DVE55A7****
02
01
07
10
12 08
09
11 13
DVG55A7****
01
03
04 05 06
02
07
10
12 08
09
11
13
DVE52A5****
01
03
04 05 06
02
07
10
12 08
09
11 13
03
04 05 06
Funcionamiento
42 Espa�ol
Untitled-4 42
2021-05-11 6:04:51
DVG52A5****
02
01
07
10
12 08
09
11
13
03
04 05 06
01 Selector de ciclos 02 Pantalla gr�fica
digital
03 Dryness (Nivel de secado)
Gire el Selector de Ciclos para seleccionar el ciclo deseado. Al seleccionar un ciclo, se enciende el indicador correspondiente. � Steam Cycles (Ciclos de vapor): La secadora roc�a agua sobre el tambor
para desodorizar la ropa y reducir la electricidad est�tica y las arrugas. � Manual Dry (Secado manual): El tiempo de secado se fija.
Muestra toda la informaci�n del ciclo, incluyendo el tiempo del ciclo, el c�digo de informaci�n y el estado de funcionamiento de la secadora.
Presione para seleccionar el nivel de secado. Puede seleccionar entre 5 opciones diferentes (Menos a M�s). Consulte las siguientes recomendaciones para seleccionar el nivel de secado adecuado. � Para cargas m�s grandes o voluminosas, seleccione M�s para un nivel de
secado completo. � Para prendas que deben secarse en posici�n horizontal o colgadas, utilice
Menos para secarlas parcialmente.
NOTA
Esta opci�n se encuentra disponible �nicamente con REFRESH (REFRESCAR), STEAM SANITIZE (DESINFECCI�N CON VAPOR) , ACTIVEWEAR (ROPA DEPORTIVA), TIME DRY (SECADO CON TEMPORIZADOR), QUICK DRY (SECADO R�PIDO) y AIR FLUFF (TEMPERATURA AMBIENTE).
Funcionamiento
Untitled-4 43
Espa�ol 43
2021-05-11 6:04:51
Funcionamiento
04 Temp. (Temperatura)
05 Time (Tiempo) 06 Wrinkle Prevent
(Prevenci�n de arrugas)
07 Eco Dry (Secado eco)
08 Damp Alert (Prendas Secas)
La temperatura solo se puede ajustar en el ciclo TIME DRY (SECADO CON TEMPORIZADOR).
Presione para cambiar la temperatura del ciclo actual. Puede seleccionar entre 5 opciones diferentes (Baja a Alta). Seleccione la temperatura adecuada dependiendo de las prendas de la carga.
� High (Alta): Para los algodones resistentes o aquellos con el r�tulo Secar en secadora.
� Medium (Media): Para prendas de plancha permanente, telas sint�ticas, algodones livianos u otras prendas con el r�tulo Secar en secadora a temperatura media.
� Low (Baja): Para prendas sensibles al calor con el r�tulo Secar en secadora a temperatura baja o Secar en secadora a temperatura c�lida. Ofrece la menor temperatura de secado con calor posible.
Presione para ajustar el tiempo de secado al usar ciclos de Manual Dry (Secado manual). No se encuentra disponible en los ciclos de secado con Secado con sensor porque la secadora determina el tiempo de secado al medir el nivel de humedad de la carga.
Prevenci�n de arrugas ofrece aproximadamente 180 minutos de secado intermitente con aire fresco al final del ciclo para reducir la formaci�n de arrugas. Presione Wrinkle Prevent (Prevenci�n de arrugas) para activar dicha funci�n. La carga est� seca y puede ser retirada en cualquier momento durante el ciclo Prevenci�n de arrugas.
Esta funci�n est� disponible en los ciclos NORMAL y TIME DRY (SECADO CON TEMPORIZADOR).
Con Secado eco activado, el secado requiere m�s tiempo pero el consumo de energ�a se reduce.
El tiempo de secado puede prolongarse hasta 3 veces, dependiendo de la temperatura y la carga. La funci�n Secado eco est� activada de manera predeterminada. (Consulte la "Tabla de ciclos" de la p�gina 51.)
Esta alerta est� disponible para todos los ciclos de Secado con sensor con excepci�n de ACTIVEWEAR (ROPA DEPORTIVA). Los niveles de secado disponibles son Normal, M�s y Extra Seco.
Si una carga contiene prendas mixtas, el indicador de Prendas Secas parpadea cuando el promedio de secado de las prendas de la carga es de 80 %. Esto le permite retirar las prendas que no desea que se sequen completamente o que se secan r�pidamente fuera de la secadora mientras deja que otras prendas sigan sec�ndose.
Funcionamiento
44 Espa�ol
Untitled-4 44
2021-05-11 6:04:51
09 Drum Light (Luz Interior)
10 Adjust Time (Ajustar tiempo)
11 Smart Control (solo para modelos el�ctricos) / Smart Monitor (solo para modelos a gas)
12 Encender/Apagar 13 Inicio/Pausa (Hold
to Start (Mantenga presionado para iniciar))
Presione para encender o apagar la luz interior. La luz permanece encendida durante 2 minutos despu�s de que se enciende, independientemente de si est� encendida o apagada o de si la puerta est� abierta o cerrada, y luego se apaga autom�ticamente. Puede cambiar el tiempo de los ciclos de Manual Dry (Secado manual). (QUICK DRY (SECADO R�PIDO), TIME DRY (SECADO CON TEMPORIZADOR), y AIR FLUFF (TEMPERATURA AMBIENTE)) Para cambiar la duraci�n del ciclo, presione o hasta que aparezca el tiempo deseado. Despu�s de conectar la Secadora a la red dom�stica mediante la aplicaci�n Samsung Smart Washer/Dryer, puede controlar o supervisar la secadora de forma remota. Cuando se activa, el indicador de Smart Control (Smart Monitor) parpadea. La secadora entra en modo de espera para los comandos remotos. Presione para encender y apagar la secadora.
Presione para iniciar o detener una operaci�n.
NOTA
No tome prendas extremadamente enredadas de su lavadora y las coloque en la secadora. Pueden disminuir la eficacia de la secadora o hacer que se abra la puerta. Recomendamos desenredar las prendas antes de colocarlas en la secadora. Tampoco coloque objetos sobre la secadora, en especial sobre el panel de control.
PRECAUCI�N
No roc�e agua directamente sobre el panel de control. Puede producirse una falla de sistema.
Funcionamiento
Untitled-4 45
Espa�ol 45
2021-05-11 6:04:51
Funcionamiento
Descripci�n de �conos Secado con sensor
Control del filtro
Sensor de ventilaci�n (Solo para modelos DVE(G)55A7****) Vapor
Seguro para ni�os
Alarma apagada Wi-Fi
Este �cono aparece cuando la secadora ejecuta el ciclo que detecta la humedad interna para determinar el tiempo de secado. Este �cono aparece luego de cada carga para recordar que se debe limpiar el filtro para pelusas. Limpie el filtro para pelusas antes de cada ciclo y aseg�rese de que el filtro est� bien colocado antes de iniciar un ciclo.
La secadora est� equipada con un sensor de ventilaci�n que detecta y le informa cu�ndo es momento de limpiar los conductos. El indicador
le informa del estado del conducto.
Este �cono aparece cuando la secadora est� ejecutando el proceso de vaporizaci�n. La secadora roc�a agua sobre el tambor para desodorizar la ropa y reducir la electricidad est�tica y las arrugas. Este �cono indica que la funci�n Seguro para ni�os est� activada. Para obtener m�s informaci�n sobre la funci�n Seguro para ni�os, consulte la p�gina 53. Este �cono indica que la alarma est� apagada. Para obtener m�s informaci�n sobre la funci�n Alarma apagada, consulte la p�gina 53.
Este �cono indica que la secadora est� conectada a una Wi-Fi.
Sencillos pasos para comenzar
1. Presione Encender/Apagar para poner en funcionamiento la secadora. 2. Gire el selector de ciclos para seleccionar el ciclo deseado. 3. Cambie las configuraciones de ciclo (Dryness (Nivel de secado), Temp. (Temperatura) y Time (Tiempo))
seg�n sea necesario. 4. Seleccione las opciones deseadas seg�n sea necesario. 5. Mantenga presionado Inicio/Pausa (Hold to Start (Mantenga presionado para iniciar)).
Para cambiar el ciclo durante el funcionamiento 1. Presione Inicio/Pausa (Hold to Start (Mantenga presionado para iniciar)) para detener el
funcionamiento. 2. Seleccione un ciclo diferente y repita los pasos 2 y 4 de arriba si es necesario. 3. Mantenga presionado Inicio/Pausa (Hold to Start (Mantenga presionado para iniciar)) nuevamente para
iniciar el nuevo ciclo.
Funcionamiento
46 Espa�ol
Untitled-4 46
2021-05-11 6:04:52
Descripci�n del ciclo
Ciclos normales Ciclo
NORMAL
HEAVY DUTY (CARGA PESADA) BEDDING (ROPA DE CAMA) PERM PRESS (PLANCHA PERMANENTE) DELICATES (DELICADOS)
ACTIVEWEAR (ROPA DEPORTIVA)
DOWNLOADED (DESCARGADO)
Descripci�n Para la mayor�a de las telas, incluido algod�n y lino. Si est� seleccionado NORMAL, la funci�n Secado eco est� activada de manera predeterminada. Para obtener m�s informaci�n, consulte Secado eco en la secci�n "Panel de control". Para secar prendas de tela resistente, tales como los jeans, la pana y la ropa de trabajo con calor a alta temperatura.
Para prendas voluminosas, como cobijas, s�banas y edredones.
Para secar autom�ticamente prendas de algod�n sin arrugas, tambi�n telas sint�ticas, tejidos y telas antiarrugas. Para secar prendas sensibles al calor a baja temperatura de secado. Para prendas para hacer ejercicio y actividades al aire libre tales como jerseys de deporte, pantalones deportivos, chaquetas impermeables u otras prendas de entrenamiento. Es posible que las telas gruesas como los cierres rel�mpago o de velcro de una chaqueta o las medias de entrenamiento no queden totalmente secas. � Seleccione para elegir m�s ciclos disponibles en la aplicaci�n Samsung
Smart Washer/Dryer desde su tel�fono inteligente. � Ciclos disponibles: ECO NORMAL (NORMAL ECO), SHIRTS (CAMISAS),
DENIM (JEANS), TOWELS (TOALLAS), RACK DRY (ESTANTE DE SECADO), WRINKLE AWAY (ANTIARRUGAS) � Configuraci�n de f�brica: WRINKLE AWAY (ANTIARRUGAS)
Funcionamiento
Untitled-4 47
Espa�ol 47
2021-05-11 6:04:52
Funcionamiento
Secado manual Puede cambiar los ajustes de secado en forma manual seg�n su preferencia.
QUICK DRY (SECADO R�PIDO)
TIME DRY (SECADO CON TEMPORIZADOR)
AIR FLUFF (TEMPERATURA AMBIENTE)
Un ciclo de secado r�pido que dura 30 minutos. El tiempo predeterminado del ciclo es de 30 minutos. No obstante, puede modificar el tiempo del ciclo manualmente de ser necesario. Permite seleccionar el tiempo del ciclo en minutos. Si SECADO CON TEMPORIZADOR est� seleccionado, la funci�n Secado eco est� activada de manera predeterminada. Para obtener m�s informaci�n, consulte Secado eco en la secci�n "Panel de control".
Seca la carga con aire a temperatura ambiente.
Ciclos de vapor Usa vapor para reducir las arrugas y los olores de las prendas.
Ciclo STEAM SANITIZE (DESINFECCI�N CON VAPOR)
REFRESH (REFRESCAR)
Descripci�n
�selo para desinfectar prendas mediante la aplicaci�n de vapor y calor a alta temperatura a las telas. Este ciclo puede suavizar las prendas y reducir los olores. Verifique que la carga de ropa est� mojada o parcialmente mojada antes de iniciar este ciclo.
�selo para alisar arrugas y reducir olores en cargas de una a cuatro prendas. Cuando se selecciona este ciclo, se roc�a una peque�a cantidad de agua en el tambor de la secadora despu�s de varios minutos de secado con calor. Verifique que la carga de ropa est� seca.
Funcionamiento
48 Espa�ol
Untitled-4 48
2021-05-11 6:04:52
Tabla de ciclos
NOTA
Para obtener los mejores resultados, siga las recomendaciones sobre el tama�o de la carga para cada ciclo de secado. � Carga grande: Llene aproximadamente 3/4 del tambor. No agregue prendas por encima de este
nivel para que puedan dar vueltas con libertad. � Carga media : Llene aproximadamente 1/2 del tambor. � Carga peque�a : Coloque de 3 a 5 prendas y no llene m�s de 1/4 del tambor.
Ciclo
NORMAL
HEAVY DUTY (CARGA PESADA)
BEDDING (ROPA DE CAMA)
DELICATES (DELICADOS)
PERM PRESS (PLANCHA PERMANENTE)
ACTIVEWEAR (ROPA DEPORTIVA)
QUICK DRY (SECADO R�PIDO) TIME DRY (SECADO CON TEMPORIZADOR)
AIR FLUFF (TEMPERATURA AMBIENTE)
STEAM SANITIZE (DESINFECCI�N CON VAPOR)
REFRESH (REFRESCAR)
Prendas recomendadas Algod�n, ropa de trabajo, ropa de cama y de mesa,
cargas mixtas Telas resistentes, tales como jeans, pana y ropa de
trabajo pesado Prendas voluminosas, tales como cobijas, s�banas,
edredones y almohadas
Ropa interior, blusas, lencer�a
Camisas, telas sint�ticas, tejidos, prendas de algod�n sin arrugas y telas con planchado Prendas impermeables, prendas de entrenamiento,
ropa deportiva (M�ximo: 4 lbs) Cargas peque�as
Tama�o de la carga Nivel de secado Secado normal (Ajustable) Secado normal (Ajustable) Secado normal (Ajustable) Secado normal (Ajustable) Secado normal (Ajustable)
Secado normal (No ajustable)
-
Cualquier carga
-
Goma espuma, pl�stico Ropa de cama, cortinas, prendas para ni�os Camisas, pantalones, edredones, almohadas
-
Muy seco (No ajustable) -
Funcionamiento
Untitled-4 49
Espa�ol 49
2021-05-11 6:04:53
Funcionamiento
NOTA : configurado de f�brica, : se puede seleccionar
Ciclo
NORMAL HEAVY DUTY (CARGA PESADA)
BEDDING (ROPA DE CAMA) DELICATES (DELICADOS)
PERM PRESS (PLANCHA PERMANENTE) ACTIVEWEAR (ROPA DEPORTIVA) QUICK DRY (SECADO R�PIDO) TIME DRY (SECADO CON TEMPORIZADOR)
AIR FLUFF (TEMPERATURA AMBIENTE) STEAM SANITIZE (DESINFECCI�N CON
VAPOR) REFRESH (REFRESCAR)
High (Alta)
Funciones (Control de temperatura)
Low (Baja)
Time (Tiempo)
Funcionamiento
50 Espa�ol
Untitled-4 50
2021-05-11 6:04:53
Modelos DVE(G)55A7****
Ciclo
NORMAL HEAVY DUTY (CARGA PESADA)
BEDDING (ROPA DE CAMA) DELICATES (DELICADOS)
PERM PRESS (PLANCHA PERMANENTE) ACTIVEWEAR (ROPA DEPORTIVA) QUICK DRY (SECADO R�PIDO) TIME DRY (SECADO CON TEMPORIZADOR)
AIR FLUFF (TEMPERATURA AMBIENTE) STEAM SANITIZE (DESINFECCI�N CON
VAPOR) REFRESH (REFRESCAR)
Adjust Time (Ajustar tiempo)
Damp Alert (Prendas Secas)
Opciones Eco Dry (Secado eco)
Wrinkle Prevent (Prevenci�n de arrugas)
Modelos DVE(G)52A5****
Ciclo
NORMAL HEAVY DUTY (CARGA PESADA)
BEDDING (ROPA DE CAMA) DELICATES (DELICADOS)
PERM PRESS (PLANCHA PERMANENTE) ACTIVEWEAR (ROPA DEPORTIVA) QUICK DRY (SECADO R�PIDO) TIME DRY (SECADO CON TEMPORIZADOR)
AIR FLUFF (TEMPERATURA AMBIENTE) STEAM SANITIZE (DESINFECCI�N CON
VAPOR) REFRESH (REFRESCAR)
Adjust Time (Ajustar tiempo)
Damp Alert (Prendas Secas)
Opciones Eco Dry (Secado eco)
Wrinkle Prevent (Prevenci�n de arrugas)
Funcionamiento
Untitled-4 51
Espa�ol 51
2021-05-11 6:04:53
Funcionamiento
Gu�a de ciclos
La mejor manera de secar las prendas es seguir las instrucciones de la etiqueta. Si no se brindan instrucciones de secado, consulte la siguiente tabla a modo de referencia.
Ciclo
Cubrecamas y edredones
Cobijas
Cortinas y pa�os de tela
Pa�ales de tela Prendas con relleno de plumas (chaquetas, bolsas de dormir, edredones, etc.) Goma espuma (reverso de alfombras, mu�ecos de peluche, hombreras, etc.)
Almohadas
Pl�sticos (cortinas de ba�o, cubiertas de muebles para exteriores, etc.)
Descripci�n Siga las instrucciones de la etiqueta o seque en el ciclo BEDDING (ROPA DE CAMA). � Aseg�rese de que la prenda est� completamente seca antes de usarla o
guardarla. � Tal vez deba volver a colocarla en el tambor para garantizar un secado
uniforme. Utilice NORMAL y seque de a una sola cobija por vez para lograr un mejor funcionamiento de la secadora. � Aseg�rese de que las cobijas est�n completamente secas antes de
usarlas o guardarlas. Utilice PERM PRESS (PLANCHA PERMANENTE) y la temperatura Media para minimizar la formaci�n de arrugas. � Seque cortinas y pa�os de tela en tandas peque�as para obtener
mejores resultados y ret�relos lo antes posible. Utilice NORMAL y la temperatura Media para pa�ales suaves y mullidos.
Utilice NORMAL y la opci�n de temperatura Media. � Agregue un par de toallas secas para absorber la humedad y acortar el
tiempo de secado.
No seque con el ciclo de secado con calor. ADVERTENCIA
Secar un art�culo de goma con calor puede da�arlo o causar un incendio. Utilice NORMAL. � Agregue un par de toallas secas y un par de zapatillas limpias para
mejorar el funcionamiento de la secadora y para que las prendas queden m�s esponjosas. � No seque almohadas de capoc o de goma espuma utilizando un ciclo de secado con calor.
Utilice TIME DRY (SECADO CON TEMPORIZADOR) o el ajuste de temperatura Baja o Extra Baja de acuerdo con las instrucciones de la etiqueta.
Funcionamiento
52 Espa�ol
Untitled-4 52
2021-05-11 6:04:54
ADVERTENCIA No seque: � Art�culos de fibra de vidrio (cortinas, pa�os de tela, etc.) � Lanas, salvo que se recomiende en la etiqueta � Art�culos manchados o embebidos en aceite vegetal o de cocina
Funciones especiales
Seguro para ni�os La funci�n Seguro para ni�os evita que los ni�os jueguen con la secadora. Cuando el Seguro para ni�os est� activado, todos los botones excepto Encender/Apagar se desactivan. Para activar/desactivar el Seguro para ni�os, mantenga presionados simult�neamente Dryness (Nivel de secado) y Temp. (Temperatura) durante 3 segundos.
NOTA Una vez activado el Seguro para ni�os permanecer� activo incluso despu�s que encienda la secadora nuevamente. Si otros botones, salvo el bot�n Encender/Apagar, no responden, verifique el indicador de Seguro para ni�os. Si el indicador est� encendido, siga las instrucciones precedentes para desactivar el Seguro para ni�os.
Alarma apagada Puede encender o apagar la alarma. Cuando la alarma est� apagada, la melod�a de finalizaci�n de ciclo y el pitido de apagado no suenan. Sin embargo, los dem�s sonidos permanecen activos. � Presione y mantenga presionada la tecla Drum Light (Luz Interior) durante 3 segundos para encender
y apagar la alarma. � La configuraci�n se conservar� incluso una vez que apague la secadora. Puede encender la alarma
nuevamente manteniendo presionado el mismo bot�n durante 3 segundos.
Funcionamiento
Untitled-4 53
Espa�ol 53
2021-05-11 6:04:54
Funcionamiento
Smart Care Para activar esta funci�n, primero se debe descargar la aplicaci�n Samsung Smart Washer/Dryer en Play Store o en App Store e instalarla en un dispositivo m�vil con la funci�n de c�mara. La funci�n Smart Care se ha optimizado para las series Galaxy e iPhone (�nicamente para los modelos aplicables). 1. Cuando la secadora detecta un problema que requiere revisi�n, aparece un c�digo de informaci�n en
el display. Para seleccionar el modo Smart Care, mantenga presionado Wrinkle Prevent (Prevenci�n de arrugas) durante 3 segundos. 2. La secadora inicia el proceso de autodiagn�stico y muestra un c�digo de informaci�n en caso de que detecte alg�n problema. 3. Ejecute la aplicaci�n Samsung Smart Washer/Dryer en su dispositivo m�vil y, luego, toque Smart Care. 4. Coloque el dispositivo m�vil cerca de la pantalla de la secadora de manera que la c�mara del tel�fono inteligente quede frente a la secadora. La aplicaci�n reconoce el c�digo de informaci�n autom�ticamente. 5. Cuando el c�digo de informaci�n se reconoce correctamente, la aplicaci�n proporciona informaci�n detallada sobre el problema y las soluciones aplicables. NOTA � El nombre de la funci�n, Smart Care, puede variar seg�n el idioma. � Si se refleja una luz en la pantalla de la secadora, es posible que la aplicaci�n no reconozca el c�digo de informaci�n. � Si la aplicaci�n no reconoce el c�digo de informaci�n, puede ingresarlo manualmente en la aplicaci�n.
Funcionamiento
54 Espa�ol
Untitled-4 54
2021-05-11 6:04:54
Mantenimiento
Mantenga la secadora limpia para lograr un mejor rendimiento y prolongar su vida �til. ADVERTENCIA
Algunas piezas internas no est�n conectadas a tierra intencionalmente y pueden presentar riesgo de descarga el�ctrica �nicamente durante el servicio t�cnico. Personal del servicio t�cnico: No toque las siguientes piezas mientras el electrodom�stico est� recibiendo electricidad: Panel de control y v�lvula de entrada.
Limpieza
Panel de control � Limpie con un pa�o suave y h�medo. No utilice
sustancias abrasivas. � No roc�e productos de limpieza l�quidos
directamente en la pantalla de la secadora. � Algunos productos removedores de suciedad y
manchas de tratamiento previo pueden da�ar el panel de control. � Al usar productos de limpieza l�quidos, apl�quelos a la ropa. No los aplique directamente en la secadora. Limpie el l�quido derramado o rociado inmediatamente.
Tambor � Elimina las manchas del tambor con un
limpiador multiuso. � Seque toallas o trapos para eliminar restos de
manchas o productos de limpieza. Las manchas ser�n visibles, pero no afectar�n las cargas posteriores.
Tambor acabado con pintura en polvo Para limpiar el tambor acabado con pintura en polvo, use un pa�o humedecido con un limpiador suave, no abrasivo, adecuado para superficies que se deterioran f�cilmente. Elimine los residuos del limpiador y seque con un pa�o limpio.
Exterior de la secadora � Limpie con un pa�o suave y h�medo. No utilice
sustancias abrasivas. � Proteja la superficie de objetos afilados. � No coloque objetos pesados ni afilados ni
tampoco un envase de detergente sobre la secadora. Pueden rayar o da�ar la cubierta superior de la secadora. � La secadora tiene un acabado brillante en toda su superficie. Tenga cuidado de no rayar ni da�ar la superficie.
Sistema de drenaje � Controle y limpie el sistema de drenaje
regularmente para mantener un desempe�o �ptimo. � La tapa de drenaje externa debe limpiarse con frecuencia para garantizar un flujo de aire adecuado.
Mantenimiento
Untitled-4 55
Espa�ol 55
2021-05-11 6:04:54
Soluci�n de problemas
Verificaciones
Si la secadora funciona en forma anormal, primero consulte la lista de problemas en la tabla siguiente y pruebe las sugerencias.
Problema No funciona.
No calienta.
Acci�n
� Aseg�rese de que la puerta est� cerrada. � Aseg�rese de que el cable de alimentaci�n est� conectado a un
tomacorriente que funcione. � Controle los disyuntores o fusibles de su casa. � Presione o toque Inicio/Pausa (Hold to Start (Mantenga presionado
para iniciar)) nuevamente si la puerta se abri� durante un ciclo. � Limpie el filtro para pelusas.
� Controle los disyuntores o fusibles de su casa. � Algunos ciclos no requieren calor. Verifique nuevamente el ciclo
seleccionado. � En una secadora a gas, aseg�rese de que el suministro de gas est�
abierto. � Limpie el filtro para pelusas y el conducto de drenaje. � La secadora puede haberse desplazado a la fase de enfriamiento del
ciclo. � Encienda la opci�n Secado eco para los ciclos NORMAL o TIME DRY
(SECADO CON TEMPORIZADOR) . Cuando se activa la opci�n Secado eco, la secadora realiza un proceso de secado con aire al inicio del ciclo para reducir el consumo de energ�a. El proceso de secado por aire no utiliza aire caliente, por lo que puede sentir que la secadora no se caliente, pero es normal.
Soluci�n de problemas
56 Espa�ol
Untitled-4 56
2021-05-11 6:04:54
Problema No seca. Hace ruido.
Acci�n
� Verifique todos los �tem anteriores y, adem�s... � Aseg�rese de que la tapa de drenaje hacia el exterior de su casa se
pueda abrir y cerrar sin inconvenientes. � Verifique que el sistema de drenaje no presente obstrucciones. Los
conductos deben inspeccionarse y limpiarse todos los a�os. � Utilice un conducto de drenaje de metal r�gido, de 4". � No la sobrecargue. 1 carga de lavado = 1 carga de secado. � Seque los art�culos pesados y los livianos por separado. � Es posible que sea necesario volver a colocar los art�culos grandes
y voluminosos, como las cobijas o los edredones, para garantizar un secado uniforme. � Aseg�rese de que la lavadora est� drenando en forma correcta y extrayendo el agua de la carga adecuadamente. � Es posible que la carga sea demasiado peque�a como para secarse correctamente. Agregue algunas toallas y reinicie la secadora. � Es posible que la carga sea demasiado grande como para secarse correctamente. Retire algunas prendas y vuelva poner en funcionamiento la secadora. � Limpie el filtro para pelusas.
� Verifique si en la carga hay objetos tales como monedas, botones flojos, clavos, etc. Ret�relos de inmediato.
� Es normal escuchar el ruido de la v�lvula de gas de la secadora o que el ciclo del dispositivo de calor se enciende o se apaga durante el ciclo de secado.
� Aseg�rese de que la secadora est� correctamente nivelada tal como se describe en las instrucciones de instalaci�n.
� Es normal que la secadora emita un zumbido debido a la alta velocidad del aire que se mueve por el tambor de la secadora, el ventilador y el sistema de drenaje.
Soluci�n de problemas
Untitled-4 57
Espa�ol 57
2021-05-11 6:04:54
Soluci�n de problemas
Problema
Acci�n
No seca de manera uniforme.
� Es posible que las costuras, los bolsillos y otras �reas resistentes similares no se sequen por completo cuando el resto de la carga ha llegado al nivel de secado seleccionado. Esto es normal. Puede elegir un nivel de secado m�s alto o un ciclo que incluya un nivel de secado m�s alto.
� Si se seca un art�culo pesado con una carga liviana, por ejemplo una toalla con s�banas, es posible que el art�culo pesado no est� completamente seco cuando el resto de la carga alcance el nivel de secado seleccionado.
� Para obtener mejores resultados, seque los art�culos pesados y los livianos por separado.
Tiene olor.
� Los olores del hogar, ya sea que provengan de la pintura, el barniz, los limpiadores potentes, etc., pueden ingresar en la secadora con el aire del ambiente. Esto es normal puesto que la secadora extrae el aire de la habitaci�n, lo calienta y lo hace circular por el tambor y lo expulsa a trav�s del drenaje hacia el exterior.
� Si estos olores permanecen en el aire, ventile bien la habitaci�n antes de usar la secadora.
� Utilice el ciclo REFRESH (REFRESCAR). Si los olores persisten, vuelva a lavar y secar los art�culos.
Pelusa en las prendas.
� Limpie el filtro para pelusas antes de cada carga. Para la ropa que naturalmente acumula pelusas, limpie el filtro durante el ciclo.
� Algunas telas producen pelusa (por ejemplo, una toalla de algod�n blanco con mucho pelo) y deben secarse por separado de las prendas que atrapan pelusa (por ejemplo, un par de pantalones de lino negro).
� Divida las cargas grandes en cargas m�s peque�as para el secado. � Revise bien los bolsillos antes de secar las prendas, luego s�quelas. � Quite las pelusas de adentro del tambor antes del secado.
Prendas arrugadas despu�s del ciclo Wrinkle Prevent (Prevenci�n de arrugas) (WRINKLE-CARE, WRINKLE RELEASE (ANTIARRUGAS)).
� Funciona mejor con cargas peque�as de 1 a 4 prendas. � Cargue menos prendas. Cargue prendas similares. � Retire las prendas de inmediato una vez finalizado el secado.
Gotea agua de la boquilla cuando comienza el proceso con vapor.
�
Esto se debe a la condensaci�n del vapor. El goteo de agua se detendr� en unos minutos.
Soluci�n de problemas
58 Espa�ol
Untitled-4 58
2021-05-11 6:04:54
Problema No se ve el agua rociada durante el proceso con vapor.
Tiempo prolongado.
Acci�n
� El agua rociada es dif�cil de ver cuando la puerta est� cerrada.
� Secado con sensor detecta autom�ticamente la humedad de la carga y apaga la secadora cuando alcanza el nivel de secado seleccionado. El tiempo de secado puede variar de acuerdo con el tipo y la cantidad de prendas. Consulte la tabla de ciclos para obtener referencias.
Si el problema persiste, comun�quese con un centro de servicio local de Samsung.
Soluci�n de problemas
Untitled-4 59
Espa�ol 59
2021-05-11 6:04:54
Soluci�n de problemas
C�digos de informaci�n
Si la secadora no funciona bien, puede ver un c�digo de informaci�n en el panel de la pantalla. Para determinar qu� debe hacer, consulte la lista de c�digos en la tabla siguiente y pruebe las sugerencias.
C�digo dC FC AC HC
9C1
tC
tC5 dF
Acci�n
La secadora funciona con la puerta abierta. � Aseg�rese de que la puerta est� perfectamente cerrada. � Aseg�rese de que no quede ropa trabada en la puerta.
Frecuencia de fuente de alimentaci�n no v�lida. � Intente reiniciar el ciclo. � Si este c�digo de informaci�n permanece, comun�quese con un centro de
servicio de Samsung.
Problema con el control electr�nico (Comunicaci�n no v�lida). � Comun�quese con un centro de servicio de Samsung.
Verificaci�n de temperatura alta � Limpie el filtro para pelusas. � Si este c�digo de informaci�n permanece, comun�quese con un centro de
servicio de Samsung. (ingrese el modo prueba de l�nea)
Se debe revisar el control electr�nico. � Revise que el cable de alimentaci�n est� conectado correctamente. � Revise que el tomacorriente funciona correctamente. � Si el c�digo de informaci�n permanece, comun�quese con un centro de
servicio de Samsung.
La resistencia del termistor 1 es muy baja o muy alta. � Revise si el filtro para pelusas est� obstruido � Revise si el sistema de ventilaci�n est� restringido. � Si este c�digo de informaci�n permanece, comun�quese con un centro de
servicio de Samsung.
La resistencia del termistor 2 es muy baja o muy alta. � Revise si el filtro para pelusas est� obstruido. � Revise si el sistema de ventilaci�n est� restringido. � Si este c�digo de informaci�n permanece, comun�quese con un centro de
servicio de Samsung.
Interruptor de la puerta incorrecto. � Comun�quese con un centro de servicio de Samsung.
Soluci�n de problemas
60 Espa�ol
Untitled-4 60
2021-05-11 6:04:54
C�digo 3C
Acci�n Se debe revisar el PBA. � Desenchufe el cable de alimentaci�n y comun�quese con el centro de servicio
de Samsung.
Si un c�digo de informaci�n sigue apareciendo en la pantalla, comun�quese con un centro de servicio de Samsung.
Soluci�n de problemas
Untitled-4 61
Espa�ol 61
2021-05-11 6:04:54
Especificaciones
Tabla de indicaciones sobre telas
Los siguientes s�mbolos ofrecen indicaciones acerca de las prendas. La etiqueta de indicaciones de la prenda incluye s�mbolos para secado, blanqueado, secado y planchado, o limpieza en seco cuando son necesarios. El uso de s�mbolos garantiza la consistencia entre los fabricantes textiles de art�culos nacionales e importados. Siga las indicaciones de la etiqueta para optimizar la vida �til de la prenda y reducir los problemas del lavado.
Ciclo de lavado
Normal
Plancha permanente/Antiarrugas/ Control de arrugas
Prendas suaves/delicadas
Lavado a mano
Temperatura del agua
Caliente Tibia Fr�a
NOTA La tabla de la temperatura del agua presenta las temperaturas del agua del lavado apropiadas para diversas prendas. El rango de temperatura es de 106-126 �F (41-52 �C) para Caliente, 84-106 �F (29-41 �C) para Tibia y 61-84 �F (16-29 �C) para Fr�a. (La temperatura del agua del lavado debe alcanzar un m�nimo de 61 �F (16 �C) para que se active el detergente y se logre un lavado eficaz.)
Blanqueador Cualquier blanqueador (cuando sea necesario) Solo blanqueador sin cloro (protecci�n del color) (si es necesario) Secar en secadora
Normal Plancha permanente/Antiarrugas/ Control de arrugas Prendas suaves/delicadas
Instrucciones especiales Secar colgado/tender Colgar para que escurra Secar en posici�n horizontal
Secado con calor Alta Media Baja Cualquier calor Sin calor/aire
Especificaciones
62 Espa�ol
Untitled-4 62
2021-05-11 6:04:57
Temperaturas de secado con plancha o vapor Alta Media Baja
S�mbolos de advertencia para el lavado No lavar No retorcer No usar blanqueador No secar en secadora Sin vapor (agregado a la plancha) No planchar
Limpiar en seco Limpiar en seco No limpiar en seco Secar colgado/tender Colgar para que escurra Secar en posici�n horizontal
Protecci�n del medio ambiente
Este electrodom�stico se fabrica con materiales reciclables. Si decide desechar este electrodom�stico, siga la normativa local relacionada con la eliminaci�n de desechos. Corte el cable de alimentaci�n para que el electrodom�stico no pueda conectarse a una fuente de alimentaci�n. Retire la puerta para que los animales y los ni�os peque�os no puedan quedar atrapados dentro del electrodom�stico.
Especificaciones
Untitled-4 63
Espa�ol 63
2021-05-11 6:04:58
Especificaciones
Hoja de especificaciones
Tipo
Capacidad (pies c�b.)
Presi�n de agua (psi (kPa))
Peso
lb (kg)
Potencia del calentador
El�ctrico (W) A gas (BTU/h)
Consumo de potencia (W)
Secadora de carga frontal 7.4
20-116 (137-800) 119.0 (54.0) 5300 20000 5400
Especificaciones
64 Espa�ol
Untitled-4 64
2021-05-11 6:04:58
Garant�a limitada (Estados Unidos)
SECADORA SAMSUNG
GARANT�A LIMITADA AL COMPRADOR CONSUMIDOR ORIGINAL CON PRUEBA DE COMPRA
El presente producto de la marca SAMSUNG, tal como lo provee y distribuye SAMSUNG ELECTRONICS AMERICA, INC. (SAMSUNG) y lo entrega como nuevo, en su caja de cart�n original al comprador consumidor original, est� garantizado por SAMSUNG contra defectos de fabricaci�n de los materiales o la mano de obra durante el per�odo limitado de la garant�a, a partir de la fecha original de compra, de:
Un (1) a�o para todas las piezas y la mano de obra
La presente garant�a limitada es v�lida �nicamente para productos comprados y usados en Estados Unidos que fueron instalados, operados y mantenidos de acuerdo con las instrucciones adjuntas o provistas con el producto. Para recibir el servicio t�cnico en garant�a, el comprador debe comunicarse con SAMSUNG en la direcci�n o el tel�fono que figuran m�s abajo con el fin de que se determine el problema y los procedimientos del servicio. El servicio t�cnico de la garant�a solo puede ser prestado por un centro de servicio t�cnico autorizado de SAMSUNG. Para recibir el servicio t�cnico en garant�a debe presentarse la factura original de compra fechada cuando as� lo solicite SAMSUNG o el Centro de Servicio autorizado Samsung como prueba de compra.
Samsung brindar� servicio t�cnico a domicilio dentro del territorio contiguo de Estados Unidos durante el per�odo de garant�a sin cargo, sujeto a la disponibilidad de los centros de servicio autorizados por SAMSUNG dentro de la zona geogr�fica del cliente. Si el servicio t�cnico a domicilio no est� disponible, SAMSUNG puede, a su elecci�n, optar por transportar el producto hasta y desde un centro de servicio t�cnico autorizado. Si el producto est� ubicado en una zona en la que no se encuentra disponible ning�n centro de servicio autorizado por SAMSUNG, usted podr� ser responsable del cargo por transporte o se le podr� requerir que transporte el producto a un centro de servicio autorizado por SAMSUNG para recibir asistencia t�cnica.
Para recibir el servicio t�cnico a domicilio, el producto no debe presentar obstrucciones y debe ser accesible para el agente del servicio t�cnico.
Durante el periodo de garant�a aplicable, el producto se reparar� o se reemplazar�, o se devolver� el importe de compra, a la entera discreci�n de SAMSUNG. SAMSUNG podr� usar piezas nuevas o reacondicionadas para la reparaci�n del producto, o reemplazar el producto por un producto nuevo o reacondicionado. La vigencia de la garant�a de las piezas y los productos reemplazados ser� por el per�odo restante de la garant�a original del producto o por un per�odo de noventa (90) d�as, el que sea el m�s largo. Todas las piezas y los productos reemplazados son propiedad de SAMSUNG y deben ser devueltos a SAMSUNG.
Untitled-4 65
Espa�ol 65
2021-05-11 6:04:58
Garant�a limitada (Estados Unidos)
La presente garant�a limitada cubre defectos de fabricaci�n de los materiales o la mano de obra que ocurran durante el uso normal y dom�stico de este producto y no cubrir� lo siguiente: da�os que ocurran durante el env�o, entrega e instalaci�n y usos para los cuales el presente producto no fue destinado; da�os causados por modificaci�n o alteraci�n no autorizada del producto; producto cuyos n�meros de serie originales de f�brica fueron eliminados, desfigurados, alterados en alg�n modo o que no se puedan determinar f�cilmente; da�os cosm�ticos incluyendo rayones, hendiduras, abolladuras y otros da�os al acabado del producto; da�o causado por abuso o mal uso, plagas, accidente, incendio, inundaci�n u otros casos fortuitos o de fuerza mayor; da�o causado por el uso de equipo, utilidades, servicios, piezas, suministros, accesorios, aplicaciones, instalaciones, reparaciones, cableado externo o conectores no provistos ni autorizados por SAMSUNG; da�o causado por l�nea el�ctrica o voltaje incorrecto, fluctuaciones y sobretensi�n; da�o causado por no operar y mantener el producto de acuerdo con las instrucciones; instrucci�n a domicilio acerca de c�mo usar el producto; y servicio t�cnico para corregir una instalaci�n que no cumpla con los c�digos el�ctricos o de plomer�a o correcci�n de cableado el�ctrico o tuber�as (es decir, cableado dom�stico, fusibles o mangueras de entrada de agua). El costo de reparaci�n o reemplazo bajo estas circunstancias excluidas ser� responsabilidad del cliente.
Las visitas de un proveedor de servicio t�cnico autorizado para explicar funciones, mantenimiento o instalaci�n del producto no se cubren bajo esta garant�a limitada. Comun�quese con Samsung al n�mero que figura abajo para obtener ayuda con cualquiera de estos problemas.
66 Espa�ol
Untitled-4 66
2021-05-11 6:04:58
EXCLUSI�N DE GARANT�AS IMPL�CITAS LAS GARANT�AS IMPL�CITAS, INCLUYENDO GARANT�AS IMPL�CITAS DE COMERCIABILIDAD O APTITUD PARA UN PROP�SITO EN PARTICULAR, EST�N LIMITADAS A UN A�O O AL PERIODO M�S CORTO PERMITIDO POR LA LEY. Algunos estados no permiten limitaciones en cuanto al periodo de vigencia de una garant�a impl�cita, de tal forma que las limitaciones o exclusiones mencionadas tal vez no se apliquen a usted en particular. Esta garant�a le otorga derechos espec�ficos, e incluso usted tambi�n puede tener otros derechos que var�an de un estado a otro.
LIMITACI�N DE RECURSOS EL �NICO Y EXCLUSIVO RECURSO ES LA REPARACI�N DEL PRODUCTO, EL REEMPLAZO DEL PRODUCTO O LA DEVOLUCI�N DEL IMPORTE DE COMPRA, A DISCRECI�N DE SAMSUNG, CONFORME A ESTA GARANT�A LIMITADA. SAMSUNG NO SER� RESPONSABLE POR DA�OS ESPECIALES, IMPREVISTOS O DERIVADOS, INCLUYENDO ENTRE OTROS, TIEMPO FUERA DEL TRABAJO, HOTELES Y/O COMIDAS EN RESTAURANTES, GASTOS DE REMODELACI�N, P�RDIDAS DE INGRESOS O GANANCIAS, INCAPACIDAD DE GENERAR AHORROS U OTROS BENEFICIOS INDEPENDIENTEMENTE DE LA TEOR�A LEGAL EN LA QUE SE BASE EL RECLAMO, E INCLUSO SI SAMSUNG HA SIDO ADVERTIDA DE LA POSIBILIDAD DE DICHOS DA�OS. Algunos estados no permiten la exclusi�n o la limitaci�n de da�os imprevistos o derivados, por lo que las limitaciones o exclusiones mencionadas tal vez no se apliquen a usted en particular. Esta garant�a le otorga derechos espec�ficos, e incluso usted tambi�n puede tener otros derechos que var�an de un estado a otro.
SAMSUNG no garantiza el funcionamiento ininterrumpido o sin errores del producto. Ning�n aval o garant�a otorgados por otra persona, compa��a o corporaci�n con respecto al presente producto revestir� car�cter vinculante para SAMSUNG.
Para obtener el servicio de garant�a, comun�quese con SAMSUNG en: Samsung Electronics America, Inc. 85 Challenger Road Ridgefield Park, NJ 07660 1-800-SAMSUNG (726-7864) www.samsung.com/us/support
Untitled-4 67
Espa�ol 67
2021-05-11 6:04:58
Scan this with your smartphone
Energy Star corresponde �nicamente al modelo DVE(G)55A7****. Este producto califica para ENERGY STAR en la configuraci�n predeterminada de f�brica "Normal + Eco dry (Secado eco)". Si cambia la configuraci�n predeterminada de f�brica o habilita otras funciones, el consumo de energ�a podr�a aumentar y superar los l�mites de calificaci�n para ENERGY STAR.
�TIENE PREGUNTAS O COMENTARIOS?
PA�S U.S.A
LLAME AL 1-800-SAMSUNG (726-7864)
O VIS�TENOS EN L�NEA EN www.samsung.com/us/support
DC68-03784S-00
Untitled-4 68
2021-05-11 6:04:59
