SANDSBERG Chair Assembly Instructions

Product Overview

This document provides assembly instructions for the SANDSBERG chair by IKEA. Please follow these steps carefully to ensure correct and safe assembly.

Brand: IKEA

Product Name: SANDSBERG Chair

Assembly Reference: AA-2275682-2

Parts and Tools Required

Before starting, check that you have all the necessary parts and tools.

Tools:

• 1x Allen Key (Part No: 100092)

Parts:

• 4x Bolt (Part No: 10081663)
• 4x Bolt (Part No: 131996)
• 4x Bolt (Part No: 10086971)

General Advice:

• Assemble on a soft surface, like a carpet, to avoid scratching the chair parts. ❌ [Do not assemble directly on hard floors].
• Ensure all parts are present and undamaged before assembly. ❓ [If parts are missing or damaged, contact IKEA customer support].

Assembly Steps

Step 1: Attach Backrest

Insert the backrest into the top of the chair frame. The diagram shows the backrest being slid downwards into the two vertical posts of the chair frame.

Step 2: Attach Seat to Frame (Part 1)

Attach the seat to the chair frame using four bolts (Part No: 10086971). The diagram shows a close-up of a bolt being inserted through a hole in the frame and into the seat. It indicates correct assembly with a checkmark (✔️) and incorrect assembly with a cross (❌).

Step 3: Attach Seat Supports

Attach the two side support pieces to the underside of the seat. The diagram shows fingers pointing to the connection points where these supports attach to the seat.

Step 4: Attach Seat Frame to Legs

Attach the assembled seat frame to the chair legs using four bolts (Part No: 131996). The diagram shows the chair frame upside down, with bolts being inserted through the seat frame into the legs. It includes indicators for correct (✔️) and incorrect (❌) assembly.

Step 5: Secure Seat

Secure the seat to the chair frame using four bolts (Part No: 10081663). The diagram shows a close-up of a bolt being inserted through the seat frame and into the seat. An information icon with a crossed-out power drill (ℹ️ ❌ [Do not use power drill]) is displayed, advising against the use of power tools for tightening.

Step 6: Repeat Seat Attachment

Repeat the process from Step 2 for the other side of the chair, attaching the seat to the frame using four bolts (Part No: 10086971). The diagram shows a close-up of a bolt being inserted and tightened, with indicators for correct (✔️) and incorrect (❌) assembly.

Step 7: Final Tightening

Perform the final tightening of all bolts using the provided Allen key (Part No: 100092). The diagram shows the Allen key being used to tighten bolts on the chair frame, with indicators for correct (✔️) and incorrect (❌) tightening.

Completion

Your SANDSBERG chair is now assembled. Ensure all bolts are securely tightened before use.
