WeatherMaker� 50A020-060
Single Package Electric Cooling Rooftop Units with Electric Heat Option, ComfortLink Controls
and Puron� Refrigerant (R-410A)

Installation Instructions

CONTENTS
Page
SAFETY CONSIDERATIONS. . . . . . . . . . . . . . . . . . . . . . 1
ACOUSTICAL CONSIDERATIONS . . . . . . . . . . . . . . . . 2 Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Acoustic Insulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-35 Step 1 -- Provide Unit Support . . . . . . . . . . . . . . . . . . . 3 � ROOF CURB � ALTERNATE UNIT SUPPORT Step 2 -- Rig and Place Unit . . . . . . . . . . . . . . . . . . . . . 3 � POSITIONING � ROOF MOUNT Step 3 -- Field Fabricate Ductwork. . . . . . . . . . . . . . . 3 Step 4 -- Make Unit Duct Connections . . . . . . . . . . . 3 � 50A2,A3,A6, AND A7 UNITS � 50A4, A5, A8, AND A9 UNITS Step 5 -- Trap Condensate Drain. . . . . . . . . . . . . . . . 21 Step 6 -- Make Electrical Connections . . . . . . . . . . 21 � POWER WIRING � FIELD POWER SUPPLY � FIELD CONTROL WIRING Step 7 -- Make Outdoor-Air Inlet
Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 � ECONOMIZER AND MIXED OUTDOOR
AIR DAMPER Step 8 -- Position Power Exhaust/Barometric
Relief Damper Hood . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Step 9 -- Route Static Pressure Sensors . . . . . . . . 28 � VAV DUCT PRESSURE TRANSDUCER � BUILDING PRESSURE TRANSDUCER Step 10 -- Install All Accessories/Options . . . . . . 30 � FIELD-FABRICATED WIND BAFFLES Step 11 -- Perform Field Modifications. . . . . . . . . . 32 � DUCTWORK BACnet Communication Option Wiring . . . . . . . . . 32 � WIRING THE UPC OPEN CONTROLLER TO THE
MS/TP NETWORK � MS/TP WIRING RECOMMENDATIONS
SAFETY CONSIDERATIONS
Installation and servicing of air-conditioning equipment can be hazardous due to system pressure and electrical components. Only trained and qualified service personnel should install, repair, or service air-conditioning equipment.
Untrained personnel can perform the basic maintenance functions of cleaning coils and filters and replacing filters. All other operations should be performed by trained service personnel. When working on air-conditioning equipment, observe precautions in the literature, tags, and labels attached to the unit, and other safety precautions that may apply.

Follow all safety codes. Wear safety glasses and work gloves. Use quenching cloth for unbrazing operations. Have fire extinguishers available for all brazing operations.
WARNING
Before performing service or maintenance operations on unit, turn off main power switch to unit. Electrical shock could cause personal injury.
CAUTION
Puron refrigerant (R-410A) systems operate at higher pressures than standard R-22 systems. Do not use R-22 service equipment or components on Puron refrigerant equipment. If service equipment is not rated for Puron refrigerant, equipment damage or personal injury may result.
WARNING
1. Improper installation, adjustment, alteration, service, or maintenance can cause property damage, personal injury, or loss of life. Refer to the User's Information Manual provided with this unit for more details.
2. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
WARNING
DO NOT USE TORCH to remove any component. System contains oil and refrigerant under pressure. To remove a component, wear protective gloves and goggles and proceed as follows: a. Shut off electrical power to unit. b. Recover refrigerant to relieve all pressure from system
using both high-pressure and low pressure ports. c. Traces of vapor should be displaced with nitrogen and
the work area should be well ventilated. Refrigerant in contact with an open flame produces toxic gases. d. Cut component connection tubing with tubing cutter and remove component from unit. Use a pan to catch any oil that may come out of the lines and as a gage for how much oil to add to the system. e. Carefully unsweat remaining tubing stubs when necessary. Oil can ignite when exposed to torch flame. Failure to follow these procedures may result in personal injury or death.

Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.

Catalog No. 04-53500233-01

Printed in U.S.A.

Form 50A-17SI

Pg 1

3-19

Replaces: 50A-16SI

CAUTION
DO NOT re-use compressor oil or any oil that has been exposed to the atmosphere. Dispose of oil per local codes and regulations. DO NOT leave refrigerant system open to air any longer than the actual time required to service the equipment. Seal circuits being serviced and charge with dry nitrogen to prevent oil contamination when timely repairs cannot be completed. Failure to follow these procedures may result in damage to equipment.
ACOUSTICAL CONSIDERATIONS
In order to minimize sound transmitted to the space, please conform to the following recommendations (see Fig. 1):
Location
� Avoid locating the unit above sound-sensitive areas. Instead, locate the unit above restrooms, storage areas, corridors, or other noise-tolerant areas.
� Avoid mounting the unit in the middle of large roof expanses between vertical supports. This will minimize the phenomenon known as roof bounce.
� Install the units close to vertical roof supports (columns or load bearing walls).
� Locate the units at least 25 ft away from critical areas. If this is not possible, the ductwork and ceiling structure should be acoustically treated.
� Consider the use of vibration isolators or an acoustic curb.
Ductwork
� Utilize flexible connectors between the unit and the supply and return ducts.

� Supply and return air main trunk ducts should be located over hallways and/or public areas.
� Provide trailing edge turning vanes in ductwork elbows and tees to reduce air turbulence.
� Make the ductwork as stiff as possible. � Use round duct wherever possible because it is less
noisy. � Seal all penetrations around ductwork entering the space. � Make sure that ceiling and wall contractors do not attach
hangers or supports to ductwork. � Provide as smooth and gradual transition as possible when
connecting the rooftop unit discharge to the supply duct. � If a ceiling plenum return is utilized, provide a return
elbow or tee to eliminate line-of-sight noise to the space. Face the entrance of the return duct away from other adjacent units.
Acoustic Insulation
� Provide acoustic interior lining for first 20 ft of supply and return duct or until the first elbow is encountered. The elbow prevents line-of-sight transmission in the supply and return ducts.
� Install a double layer of 2-in. low density quilted fiberglass acoustical pad with a 1/8-in. barium-loaded vinyl facing on top of the roof deck before building insulation and roofing installation occur. Place the material inside the curb and for 4 to 8 ft beyond the unit perimeter, dependent upon unit size (larger units require a wider apron outside the curb). Openings in the pad should only be large enough for the supply and return ducts. An alternate approach is to use two layers of gypsum board with staggered seams in addition to the acoustical pad.

FLEXIBLE CONNECTORS SUPPLY AND RETURN
VIBRATION ISOLATORS IN ROOF CURB

INTAKE PLENUM

SUPPLY FAN

DISCHARGE PLENUM

COMPRESSOR/ CONDENSING SECTION

ALL ROOF PENETRATIONS SHOULD BE SEALED AIR TIGHT

SUPPLY AND RETURN DUCTS LINED WITH ACOUSTICAL DUCT LINER
ROUND DUCT CONTROLS RUMBLE BEST
Fig. 1 -- Acoustical Considerations

2

INSTALLATION
Step 1 -- Provide Unit Support
CAUTION
1. All panels must be in place when rigging or damage to unit may occur.
2. Unit is not designed for handling by fork truck. Damage to unit may occur.
ROOF CURB -- For vertical discharge units, assemble or install accessory roof curb in accordance with instructions shipped with this accessory. See Fig. 2-5. Install insulation, cant strips, roofing, and counter flashing as shown. Ductwork can be installed to roof curb before unit is set in place. Curb should be level. This is necessary to permit unit drain to function properly. Unit leveling tolerance is shown in Fig. 2-5. Refer to Accessory Roof Curb Installation Instructions for additional information as required. When accessory roof curb is used, unit may be installed on class A, B, or C roof covering material.
IMPORTANT: The gasketing of the unit to the roof curb is critical for a watertight seal. Install gasket with the roof curb as shown in Fig. 2-5. Improperly applied gasket can also result in air leaks and poor unit performance.
ALTERNATE UNIT SUPPORT -- When the preferred curb or slab mount cannot be used, support unit with sleepers on perimeter, using unit curb support area. If sleepers cannot be used, support long sides of unit (refer to Fig. 6-14) with a minimum number of 4-in. x 4-in. pads spaced as follows: 50A020-035 units require 3 pads on each side; 50A040-050 units require 4 pads on each side; 50A060 units require 6 pads on each side. Unit may sag if supported by corners only.
Step 2 -- Rig and Place Unit -- Inspect unit for
transportation damage. See Tables 1-6 for physical data and specifications. File any claim with transportation agency.
Do not drop unit; keep upright. Use spreader bars over unit to prevent sling or cable damage. This unit must be handled with a crane and cannot be handled by a fork truck. Level by using unit frame as a reference; leveling tolerance is shown in Fig. 2-5. See Fig. 15 for additional information. Unit operating weight is shown in Tables 2-5.
NOTE: On retrofit jobs, ductwork may be attached to the old unit instead of a roof curb. Be careful not to damage ductwork when removing old unit. Attach existing ductwork to roof curb instead of unit.
Four lifting lugs are provided on the unit base rails as shown in Fig. 6-14. Refer to rigging instructions on unit.
POSITIONING -- Maintain clearance, per Fig. 6-14, around and above unit to provide minimum distance from combustible materials, proper airflow, and service access.
Do not install unit in an indoor location. Do not locate unit air inlets near exhaust vents or other sources of contaminated air.
Although unit is weatherproof, guard against water from higher level runoff and overhangs.
ROOF MOUNT -- Check building codes for weight distribution requirements. See Fig. 15. Unit operating weight is shown in Tables 2-5.

Step 3 -- Field Fabricate Ductwork -- Secure all
ducts to building structure. Use flexible duct connectors between unit and ducts as required. Insulate and weatherproof all external ductwork, joints, and roof openings with counter flashing and mastic in accordance with applicable codes.
NOTE: Due to width of the horizontal supply and return ductwork, provisions should be made for servicing of the outdoor air filters (i.e., catwalk over ductwork).
Ducts passing through an unconditioned space must be insulated and covered with a vapor barrier. Outlet grilles must not lie directly below unit discharge. The return duct must have a 90-degree elbow before opening into the building space if the unit is equipped with power exhaust.
To attach ductwork to roof curb, insert duct approximately 10 to 11 in. up into roof curb. Connect ductwork to 14-gage roof curb material with sheet metal screws driven from inside the duct.
Follow AMCA (Air Movement and Control Association) guidelines relating to ductwork connections to the unit. These guidelines recommend a minimum 21/2 equivalent duct diameters of straight duct connected to supply air inlet and outlet openings before any transitions, fittings, dampers, etc. Failure to adhere to these guidelines may result in system effects which can impact the unit's ability to achieve published performance.
WARNING
For vertical supply and return units, tools or parts could drop into ductwork and cause an injury. Install a 90-degree elbow turn in the supply and return ductwork between the unit and the conditioned space. If a 90-degree elbow cannot be installed, then a grille of sufficient strength and density should be installed to prevent objects from falling into the conditioned space.
Step 4 -- Make Unit Duct Connections
50A2,A3,A6,A7 UNITS -- Unit is shipped for thru-thebottom duct connections. Field-fabricated ductwork should be attached to the roof curb. Supply and return duct dimensions are shown in Fig. 6, 7, 10, and 12. Air distribution is shown in Fig. 16. Refer to installation instructions shipped with roof curb for more information.
50A4,A5,A8,A9 UNITS -- Remove shipping covers from supply and return air openings. Attach field-supplied ductwork to unit. Connect to the unit with a single duct for all supply openings and with a single duct for all return openings. Splitting of the airflow into branch ducts should not be done at the unit. Sufficient duct length should be used prior to branching to ensure the air temperatures are well mixed within the ductwork. See Fig. 8, 9, 11, and 13 for duct opening dimensions. Secure all ducts to building structure. Air distribution is shown in Fig. 8, 9, 11, 13, and 17. Verify the Outdoor Air Temperature (OAT) and Return Air Temperature (RAT) sensors as outlined in Fig. 18 can measure the OAT and RAT temperature sensors in the corresponding air streams. Relocate the sensor locations if needed.
Install accessory barometric relief or power exhaust in the field-fabricated return ductwork. Refer to Step 8 -- Position Power Exhaust/Barometric Relief Damper Hood section on page 28 for more information.
Instructions continued on page 21.

3

NOTES: 1. Unless otherwise specified, all dimensions are to outside of part. 2. Roof curb accessory CRRFCURB005A00 is shipped disassembled. 3. All roof curb parts are to be 14 ga. galvanized steel. 4. Units with electric heat must be installed with a 90 degree elbow on the supply duct prior to any supply take offs or branches. 5. Dimensions in [ ] are in millimeters. All other dimensions are in inches.

4

Fig. 2 -- Roof Curb -- 50A2,A3,A6,A7020-035 Units

(48A2/A3/A6/A7-035 HIGH GAS HEAT ONLY)

5

NOTES: 1. Unless otherwise specified, all dimensions are to outside of part. 2. Roof curb accessory CRRFCURB006A00 is shipped disassembled. 3. All roof curb parts are to be 14 ga. galvanized steel. 4. Units with electric heat must be installed with a 90 degree elbow on the supply duct prior to any supply take offs or branches. 5. Dimensions in [ ] are in millimeters. All other dimensions are in inches.
Fig. 3 -- Roof Curb -- 50A2,A3,A6,A7040-050 Units

6

NOTES: 1. Unless otherwise specified, all dimensions are to outside of part. 2. Roof curb accessory CRRFCURB014A00 is shipped disassembled. 3. All roof curb parts are to be 14 ga. galvanized steel. 4. Units with electric heat must be installed with a 90 degree elbow on the supply duct prior to any supply take offs or branches. 5. Dimensions in [ ] are in millimeters. All other dimensions are in inches.
Fig. 4 -- Roof Curb -- 50A2,A3,A6,A7060 Units

7

NOTES: 1. Unless otherwise specified, all dimensions are to outside of part. 2. Roof curb accessory CRRFCURB009A00 is shipped disassembled. 3. All roof curb parts are to be 14 ga. galvanized steel. 4. Units with electric heat must be installed with a 90 degree elbow on the supply duct prior to any supply take offs or branches. 5. Dimensions in [ ] are in millimeters. All other dimensions are in inches.
Fig. 5 -- Reduced Supply Duct Opening -- Roof Curb -- 50A2,A3,A6,A7060 Units

8

Fig. 6 -- Base Unit Dimensions -- 50A2,A3,A6,A7020-035

NOTES:

1. Weights include economizer.

2.

center of gravity.

3. Unit clearances:

Top of units: no overhang

Condenser coil: 4' - 0" [1219]

Economizer side: 6' - 0" [1829]

Heat side: 4' - 0" [1219]

Filter access side: 10' - 0" [3048] (for removal of

evaporator coil)

4. Bottom ducts are designed to be attached to acces-

sory roof curb. If unit is mounted on dunnage, it is

recommended that the ducts be supported by cross

braces as done on accessory roof curb.

5. Dimensions in [ ] are in millimeters. All other dimen-

sions are in inches.

*Operating weight includes largest indoor fan motor, microchannel heat exchanger, modulating power exhaust (variable air volume units), and variable frequency drive (variable air volume units).

a50-8837
9

Fig. 7 -- Base Unit Dimensions -- 50A2,A3,A6,A7040-050

10

Fig. 8 -- Base Unit Dimensions -- 50A4,A5,A8,A9020-035

NOTES:

1. Weights include economizer.

2.

center of gravity.

3. Unit clearances:

Top of units: no overhang

Condenser coil: 4' - 0" [1219]

Economizer side: 6' - 0" [1829]

Heat side: 4' - 0" [1219]

Filter access side: 10' - 0" [3048] (for removal of

evaporator coil)

4. Dimensions in [ ] are in millimeters. All other dimensions are in

inches.

*Operating weight includes largest indoor fan motor, microchannel heat exchanger, modulating power exhaust (variable air volume units), and variable frequency drive (variable air volume units).

a50-8838
11

Fig. 9 -- Base Unit Dimensions -- 50A4,A5,A8,A9040-050

FOR CENTERS OF GRAVITY, OPERATING AND CORNER WEIGHTS, SEE FIG. 14

10.49 [266]
A

50.00 [1270]
2.57 [65]

24 [613]

88.24 [2241] TOP COVERS

15.53 [395]

24 [613]

15.93 [405]

ECONOMIZER HOODS (HOODS FIELD INSTALLED)

8.60 [218]

(INCLUDED WITH UNIT)

3 REQ'D

FILTER/AUX CONTROL BOX

ACCESS DOOR (HINGED)

INDOOR MOTOR ACCESS DOOR (HINGED)
1"[25] NPT DRAIN CONN

ECON AIR
EXHAUST AIR
POWER EXHAUST OR BAROMETRIC
RELIEF HOODS OPTION
3 REQ'D
AUXILIARY CONTROL BOX

22.72 [577]

RETURN AIR

SUPPLY AIR

30.12

49.53

[765]

[1258]

TYP 4

PLACES 88.00

[2235] BASE FRAME

91.50

[2324] LIFTING POSITION

94.00 [2388] OVERALL LIFTING
SHIPPING DIM

85.09 [2161]

50.00 [1270]

50.00 [1270]
2.57 [65]

RETURN
SUPPLY
162.90 [4138]
INDOOR BLOWER ACCESS PANEL

HOOD REMOVED

DAMPER OPENING

A

18.25 [464]

42.31 [1075]

WITH HOOD

MAIN CONTROL BOX

31.25 [795] OPENING

45.44 [1154] OPENING

WITH PANEL PANEL REMOVED
VIEW A-A

NO POWER EXHAUST OR BAROMETRIC RELIEF

V

F

13.88

D

[353]

0.75 NPT LOW VOLTAGE [19]

44.28 [1125]
3.50 NPT FIELD POWER [89]

9.56 [243]

MCHX COILS

133.69 [3396] ACCESS DOORS (HINGED) CONTROL BOX / COMPRESSOR
42.56 [1081]

V F D

161.66 [4106]

HEAT SECTION ACCESS PANEL

311.28 [7906.6]

70.05 [1779]

78.60 [1997]

29.40 [747]

24.40 [620]

1.375 DIA [35] HOLE IN
LIFTING LUG
2.99 [76]

7/8" DIA [22] LOW VOLTAGE
3" DIA [76] FIELD WIRING (2)

8.05

2.10

[204]

[53]

82.02
[2083] INSIDE BASE RAILS

20.18 [513]
17.47 [444]
34.46 [875]
41.72 [1060]
45.06 [1145]
65.91 [1674]

12

Fig. 10 -- Base Unit Dimensions -- 50A2,A3,A6,A7060 MCHX

FOR CENTERS OF GRAVITY,

OPERATING AND CORNER

10.49 [266]

WEIGHTS, SEE FIG. 14

A

50.00 [1270]
2.57 [65]

50.00 [1270]

50.00 [1270]
2.57 [65]

A
MAIN CONTROL BOX

150.47 [3822.0]

12.93 [328.3]
5.12 [130.0]

13

88.24 [2241] TOP COVERS

V

13.88

F

[353]

D

ECON AIR

ECONOMIZER HOODS (HOODS FIELD INSTALLED) (INCLUDED WITH UNIT) 3 REQ'D
FILTER/AUX CONTROL BOX ACCESS DOOR (HINGED)
INDOOR MOTOR ACCESS DOOR (HINGED)

RETURN AIR
SUPPLY AIR

22.72 [577]

INDOOR BLOWER ACCESS PANEL

0.75 NPT LOW VOLTAGE [19]

44.28 [1125]
3.50 NPT FIELD POWER [89]

9.56 [243]

MCHX COILS

70.05

V

[1779]

F D

78.60 [1997]

29.40 [747]

24.40 [620]

AUXILIARY CONTROL BOX

30.12 [765] TYP 4 PLACES

1"[25] NPT DRAIN CONN
49.53 [1258]

88.00 [2235] BASE FRAME

91.50 [2324] LIFTING POSITION

94.00 [2388] OVERALL LIFTING
SHIPPING DIM

85.09 [2161]

161.66 [4106]

HEAT SECTION ACCESS PANEL

311.28 [7906.6]

1.375 DIA [35] HOLE IN
LIFTING LUG
2.99 [76]

Fig. 11 -- Base Unit Dimensions -- 50A4,A5,A8,A9060 MCHX

VIEW A-A

12.63 [320.8]

13.20 [335.3]
6.97 [177.0]

133.69 [3396] ACCESS DOORS (HINGED) CONTROL BOX / COMPRESSOR
42.56 [1081]

65.91 [1674]

7/8" DIA [22] LOW VOLTAGE

8.05 [204]

3" DIA [76] FIELD WIRING (2)

82.02
[2083] INSIDE BASE RAILS

41.72 [1060] 20.18 [513]
34.46 [875] 2.10 [53]
45.06 [1145]

FOR CENTERS OF GRAVITY, OPERATING AND CORNER WEIGHTS, SEE FIG. 14

10.49 [266]
A

50.00 [1270]
2.57 [65]

50.00 [1270]
2.57 [65]

50.00 [1270]

A
MAIN CONTROL BOX

18.25 [464]

HOOD REMOVED DAMPER OPENING
42.31 [1075]

WITH HOOD

88.24 TOP COVERS [2241]

15.53 [395]
15.93 [405]

24 [613]
24 [613]

8.60

ECONOMIZER HOODS

[218]

(HOODS FIELD INSTALLED)

(INCLUDED WITH UNIT)

3 REQ'D

FILTER/AUX CONTROL BOX

ACCESS DOOR (HINGED)

INDOOR MOTOR ACCESS DOOR (HINGED)
1"[25] NPT DRAIN CONN

ECON AIR

EXHAUST AIR
POWER EXHAUST OR BAROMETRIC
RELIEF HOODS OPTION
3 REQ'D
AUXILIARY CONTROL BOX

22.72 [577]

RETURN AIR

SUPPLY AIR

30.12 [765] TYP 4 PLACES

49.53 [1258]
88.00 [2235] BASE FRAME

91.50 [2324]

LIFTING POSITION

94.00 [2388]

OVERALL LIFTING SHIPPING DIM

RETURN

31.25 [795] OPENING

SUPPLY

162.90 [4138]

INDOOR BLOWER ACCESS PANEL

V F D

.75 [19] NPT LOW VOLTAGE
HEAT SECTION ACCESS PANEL

13.88 [353]

44.28 [1125]

9.56 [243]

3.50 [89] NPT FIELD POWER

LOW SOUND OUTDOOR FAN OPTION ONLY (ALL FAN POSITIONS)
STANDARD OUTDOOR FAN

78.60 [1997]

45.44 [1154] OPENING

WITH PANEL PANEL REMOVED

VIEW A-A

NO POWER EXHAUST OR BAROMETRIC RELIEF

133.69 [3396] ACCESS DOORS (HINGED) CONTROL BOX / COMPRESSOR
42.56 [1081]

V F D

85.09 [2161]

311.28 [7906.6]

161.66 [4106]

70.05 [1779]

78.60 [1997]

29.40 [747]

CONDENSER COIL BOTH SIDES

24.40 [620]
1.375 DIA [35] HOLE IN
LIFTING LUG

2.99 [76]

7/8" DIA [22] LOW VOLTAGE
3" DIA [76] FIELD WIRING (2)

8.05

2.10

[204]

[53]

82.02
[2083] INSIDE BASE RAILS

20.18 [513]
17.47 [444]
34.46 [875]
41.72 [1060]
45.06 [1145]
65.91 [1674]

14

Fig. 12 -- Base Unit Dimensions -- 50A2,A3,A6,A7060 RTPF

FOR CENTERS OF GRAVITY, OPERATING AND CORNER WEIGHTS, SEE FIG. 14

10.49 [266]
A

50.00 [1270]
2.57 [65]

50.00 [1270]
2.57 [65]

50.00 [1270]

A
MAIN CONTROL BOX

150.47 [3822.0]

12.93 [328.3]
5.12 [130.0]

88.24 TOP COVERS [2241]

ECONOMIZER HOODS (HOODS FIELD INSTALLED) (INCLUDED WITH UNIT) 3 REQ'D
FILTER/AUX CONTROL BOX ACCESS DOOR (HINGED)
1" [25] NPT DRAIN CONN
ECON
AIR

INDOOR MOTOR ACCESS DOOR (HINGED)

RETURN AIR
SUPPLY AIR

AUXILIARY CONTROL BOX

30.12
[765] TYP 4 PLACES

49.53 [1258]

88.00 [2235]

BASE FRAME

91.50 [2324]

LIFTING POSITION

22.72 [577]

94.00 [2388]

OVERALL LIFTING SHIPPING DIM

85.09 [2161]

V F D

13.88 [353]

44.28 [1125]

.75 [19] NPT LOW VOLTAGE

9.56 [243]

INDOOR BLOWER ACCESS PANEL

HEAT SECTION ACCESS PANEL

3.50 [89] NPT FIELD POWER

LOW SOUND OUTDOOR FAN OPTION ONLY (ALL FAN POSITIONS)
STANDARD OUTDOOR FAN

78.60 [1997]

V F D

311.28 [7906.6]

161.66 [4106]

70.75 [1797]

29.40 [747]

CONDENSER COIL BOTH SIDES

24.40 [620]

73.12 [1857]

1.375 [35] DIA

HOLE IN

LIFTING LUG

2.99

[76]

VIEW A-A
12.63 [320.8]

13.20 [335.3]
6.97 [177.0]

133.69 [3396]
ACCESS DOORS (HINGED) CONTROL BOX / COMPRESSOR
42.56 [1081]

65.91 [1674]

7/8' DIA [22] LOW VOLTAGE
3" DIA [76] FIELD WIRING (2) 8.05 [204]
INSIDE BASE RAILS 82.02 [2083]

41.72 [1060]
20.18 [513]

45.06 [1145]

34.46 [875]

2.10 [53]

15

Fig. 13 -- Base Unit Dimensions -- 50A4,A5,A8,A9060 RTPF

NOTES:

1. Weights include economizer or outdoor air damper.

2.

center of gravity.

3. Unit clearances:

Top of units: no overhang

Condenser coil: 4' - 0" [1219]

Economizer side: 6' - 0" [1829]

Heat side: 4' - 0" [1219]

Filter access side: 10' - 0" [3048] (for removal of

evaporator coil)

4. Bottom ducts are designed to be attached to accessory roof curb. If

unit is mounted on dunnage, it is recommended that the ducts be

supported by cross braces as done on accessory roof curb.

5. Base unit weights include outdoor air hoods and filters (indoor fan

motor is not included). Add indoor fan motor, FIOPs, and accesso-

ries for total operating weight.

6. VAV motor weights include indoor motor, VFD, VFD transducer,

and associated wiring.

7. Dimensions in [ ] are in millimeters. All other dimensions are in

inches.

8. For side-supply/return applications, a single return and supply

ductwork connection is recommended for covering all three return

and all three supply openings. The entire area around the duct

openings is available for a 1.5" duct flange attachment.

kW kW kW

*Operating weight includes largest indoor fan motor, microchannel heat exchanger, modulating power exhaust (variable air volume units), and variable frequency drive (variable air volume units).

a50-8839
16

Fig. 14 -- Center of Gravity and Weights -- 50A060

Table 1 -- Physical Data -- 50A Units

UNIT 50A
NOMINAL CAPACITY (tons)
BASE UNIT OPERATING WEIGHT (lb)
COMPRESSOR Quantity ... Type (Ckt 1/Ckt 2) Number of Refrigerant Circuits Oil
REFRIGERANT Operating Charge (lb), Ckt 1/Ckt 2 RTPF Coils MCHX Coils MCHX Coils with Humidi-MiZer� Coil
MCHX CONDENSER* Quantity Total Face Area (sq ft)
RTPF CONDENSER Quantity Rows...Fins/in. Total Face Area (sq ft)
CONDENSER FAN Nominal Cfm Quantity... Diameter (in.) Motor Hp
EVAPORATOR COIL Tube Size (in.) Rows ... Fins/in. Total Face Area (sq ft)
HUMIDI-MIZER COIL Quantity Face Area (sq ft)
EVAPORATOR FAN Quantity ... Size (in.) Type Drive Nominal Cfm Motor Hp Motor Frame Size Motor Bearing Type Maximum Allowable Rpm Motor Pulley Pitch Diameter (in.) Nominal Motor Shaft Diameter (in.) Fan Pulley Pitch Diameter (in.) Nominal Fan Shaft Diameter (in.) Belt Quantity Belt Type Belt Length (in.) Pulley Center Line Distance (in.)
Factory Speed Setting (rpm)
HIGH-PRESSURE SWITCH (psig) Cutout Reset (Auto.)
MIXED-AIR FILTERS Quantity ... Size (in.) Standard Pleated
OUTDOOR-AIR FILTERS Quantity...Size (in.)
POWER EXHAUST
Motor, Quantity...Hp Fan, Diameter...Width (in.)

020

025

027

030

20

25

27

30

See Unit Weights Table

2 ... ZP67/1...ZP91 2
Precharged
26.2/18.8 14.9/11.8 22.1/11.8

2 ... ZP91/1...ZP91 2
Precharged

2 ... ZP91/1...ZP91 2
Precharged
R-410A

30.2/15.2 16.5/11.0 23.7/11.0

32.8/16.5 16.5/11.0 23.7/11.0

2...ZP72, 2...ZP72 2
Precharged
30.5/34.3 15.1/15.3 15.1/22.5

1

1

1

1

32.9

32.9

32.9

32.9

1 2...15 33.3
19,500 2 ... 30
1
3/8 3 ... 15
31.7

1 3...15 33.3

1 3...15 33.3

19,500 2 ... 30
1

Propeller Type

19,500 2 ... 30
1

Cross-Hatched Copper Tubes, Aluminum Plate Fins with Intertwined Circuits

3/8

3/8

4 ... 14

4 ... 15

31.7

31.7

1 4...15 33.3
19,500 2 ... 30
1
3/8 4 ... 15
31.7

1 14.4

5 184T
4.8 11/8 12.4
1 BX56
56 16.018.7 717

2 ... 20 X 15

Belt

8,000

10

15

215T 254T

Ball

1200

4.4

5.7

13/8

15/8

8.6

9.1

115/16

2

2

BX50 5VX530

63

53

15.6-18.4 15.0-17.9

924

1096

1

1

14.4

14.4

Centrifugal Type

2 ... 20 X 15

2 ... 20 X 15

Belt

Belt

10,000

11,000

5

10

15

10

15

20

184T 215T 254T 215T 254T 256T

Ball

Ball

1200

1200

5.2

6.1

5.5

4.4

4.9

5.9

11/8

13/8

15/8

13/8

15/8

15/8

12.4 11.1 8.7

9.4

8.1

8.7

115/16

115/16

1

1

2

2

2

2

BX56 5VX570 5VX530 BX50 5VX500 5VX530

56

57

53

50

50

53

15.618.4

15.6- 15.018.4 17.9

15.618.4

15.0-17.9 15.0-17.9

773

962 1106

848

1059

1187

1 14.4

10 215T
4.4 13/8 9.0
2 BX50
50 15.618.4 856

2 ... 20 X 15

Belt

12,000

15

20

254T 256T

Ball

1200

5.7

5.9

15/8

15/8

9.1

8.7

115/16

2

2

5VX530 5VX530

53

53

15.0-17.9 15.0-17.9

1096 1187

650

650

650

650

500

500

500

500

10 ... 20 x 24 x 2 5 ... 20 x 20 x 4 5 ... 20 x 24 x 4

10 ... 20 x 24 x 2 5 ... 20 x 20 x 4 5 ... 20 x 24 x 4

10 ... 20 x 24 x 2 5 ... 20 x 20 x 4 5 ... 20 x 24 x 4

10 ... 20 x 24 x 2 5 ... 20 x 20 x 4 5 ... 20 x 24 x 4

8...16 x 25 x 2 4...20 x 25 x 2
Direct Drive, Single-Phase Motors (Factory-Wired for High Speed Operation), Forward-Curved Fan Wheels with Backdraft Dampers on Each Fan Housing 4...1 11 x 10

LEGEND
MCHX-- Microchannel Heat Exchanger RTPF -- Round Tube Plate Fin

*Sizes 020 to 027: Circuit 1 uses the lower portion of condenser coil, Circuit 2 uses the upper portion. Sizes 030 and 035: Circuit 1 uses the upper portion of condenser coil, Circuit 2 uses the lower portion. Sizes 040 and 050: Circuit 1 uses the left condenser coil, Circuit 2 the right. Size 060: Circuit A uses the two MCHX coils near the bulkhead, Circuit B uses the two MCHX coils near the control box.

17

Table 1 -- Physical Data -- 50A Units (cont)

UNIT 50A
NOMINAL CAPACITY (tons)
BASE UNIT OPERATING WEIGHT (lb)
COMPRESSOR Quantity ... Type (Ckt 1/Ckt 2) Number of Refrigerant Circuits Oil
REFRIGERANT Operating Charge (lb), Ckt 1/Ckt 2 RTPF Coils MCHX Coils MCHX Coils with Humidi-MiZer� Coil
MCHX CONDENSER* Quantity Total Face Area (sq ft)
RTPF CONDENSER Quantity Rows...Fins/in Total Face Area (sq ft)
CONDENSER FAN Nominal Cfm Quantity... Diameter (in.)
Motor Hp
EVAPORATOR COIL Tube Size (in.) Rows ... Fins/in. Total Face Area (sq ft)
HUMIDI-MIZER COIL Quantity Face Area (sq ft)
EVAPORATOR FAN Quantity ... Size (in.) Type Drive Nominal Cfm Motor Hp Motor Frame Size Motor Bearing Type Maximum Allowable Rpm Motor Pulley Pitch Diameter (in.) Nominal Motor Shaft Diameter (in.) Fan Pulley Pitch Diameter (in.) Nominal Fan Shaft Diameter (in.) Belt Quantity Belt Type Belt Length (in.) Pulley Center Line Distance (in.)
Factory Speed Setting (rpm)
HIGH-PRESSURE SWITCH (psig) Cutout Reset (Auto.)
MIXED-AIR FILTERS Quantity ... Size (in.) Standard Pleated
OUTDOOR-AIR FILTERS Quantity...Size (in.)
POWER EXHAUST
Motor, Quantity...Hp Fan, Diameter...Width (in.)

035

040

050

060

35

40

50

60

See Unit Weights Table

2 ... ZP67/2...ZP104 2
Precharged
28.7/44.0 17.9/26.0 17.9/31.5

2...ZP104/2...ZP104 2
Precharged

2...ZP122/2...ZP122 2
Precharged

R-410A

44.0/44.0 23.0/23.5 23.0/30.5

56.3/57.3 27.0/28.0 26.5/34.5

2...ZP154/2...ZP154 2
Precharged
78.5/82.0 36.6/37.8 36.6/47.6

1

2

2

4

32.9

65.8

65.8

105.2

1 4...15 33.3
19,500 2 ... 30
1
1/2 6 ... 16
31.3

2 3...15 66.7

2 4...15 66.7

2 6...30 100.0

32,000 4 ... 30
1

Propeller Type

35,000 4 ... 30
1

40,000 4...30.5(MCHX),
6...30(RTPF) 1

Cross-Hatched Copper Tubes, Aluminum Plate Fins with Intertwined Circuits

1/2

1/2

4 ... 17

6 ... 16

31.3

31.3

1/2 4...17
48.1

1

1

1

1

14.4

14.4

14.4

14.4

Centrifugal Type

2 ... 20 X 15

2 ... 20 X 15

2 ... 20 X 15

3 ... 20 X 15

Belt

Belt

Belt

Belt

14,000

16,000

18,000

24,000

15

20

25

15

20

25

20

25

30

25

30

40

254T 256T 284T 254T 256T 284T 256T 284T 286T 284T 286T 324T

Ball

Ball

Ball

Ball

1300

1300

1300

1200

5.1

5.7

6.2

5.3

5.7

7.5

5.7

6.2

6.7

5.3

5.9

6.5

15/8

15/8

17/8

15/8

15/8

17/8

15/8

17/8

17/8

17/8

17/8

21/8

8.7

8.7

8.7

9.5

9.5

11.1

9.5

9.5

9.5

9.1

9.5

9.5

115/16

2

2

2

115/16

2

2

2

115/16

2

2

2

115/16

3

3

3

5VX500 5VX530 5VX550 5VX530 5VX550 5VX590 5VX550 5VX570 5VX570 5VX530 5VX550 5VX570

50

53

55

53

55

59

55

57

57

53

55

57

15.0- 15.0- 15.0- 15.0- 15.0- 14.6- 15.0- 14.6- 14.6- 15.2- 14.7- 14.2-

17.9 17.9 17.9 17.9 17.9 17.6 17.9 17.6 17.6 17.5 17.2 17.0

1025 1147 1247 976 1050 1182 1050 1142 1234 1019 1087 1197

650

650

650

650

500

500

500

500

10 ... 20 x 24 x 2 5 ... 20 x 20 x 4 5 ... 20 x 24 x 4

10 ... 20 x 24 x 2 5 ... 20 x 20 x 4 5 ... 20 x 24 x 4

10 ... 20 x 24 x 2 5 ... 20 x 20 x 4 5 ... 20 x 24 x 4

16...20 x 24 x 2 8...20 x 20 x 4 8...20 x 24 x 4

8...16 x 25 x 2 4...20 x 25 x 2

8...16 x 25 x 2 4...20 x 25 x 2

8...16 x 25 x 2 4...20 x 25 x 2

12...16 x 25 x 2 6...20 x 25 x 2

Direct Drive, Single-Phase Motors (Factory-Wired for High Speed Operation), Forward-Curved Fan Wheels

with Backdraft Dampers on Each Fan Housing

4...1

4...1

4...1

6...1

11 x 10

11 x 10

11 x 10

11 x 10

LEGEND
MCHX-- Microchannel Heat Exchanger RTPF -- Round Tube Plate Fin

*Sizes 020 to 027: Circuit 1 uses the lower portion of condenser coil, Circuit 2 uses the upper portion. Sizes 030 and 035: Circuit 1 uses the upper portion of condenser coil, Circuit 2 uses the lower portion. Sizes 040 and 050: Circuit 1 uses the left condenser coil, Circuit 2 the right. Size 060: Circuit A uses the two MCHX coils near the bulkhead, Circuit B uses the two MCHX coils near the control box.

18

UNIT SIZE 50A2,A3,A6,A7 50A4,A5,A8,A9

Table 2 -- 50A Base Unit Operating Weights (lb)

020 3625 3703

025 3761 3839

027 3761 3839

030 3792 3870

035 4025 4218

Table 3 -- 50A Option and Accessory Weights (lb)

UNIT SIZE

020

025

027

030

035

Barometric Relief

300

300

300

300

300

Non-Modulating Power Exhaust

450

450

450

450

450

Modulating Power Exhaust

500

500

500

500

500

Electric Heat

110

110

110

110

110

Cu Tube/Alum Fin Cond. Coil

100

100

100

150

150

Cu Tube/Cu Fin Cond. Coil

263

263

263

370

370

OA Hood Crate/Packaging (Less Hoods' Weight)

45

45

45

45

45

(Packaging Only)

Outdoor Air Hoods/Filters (included with unit)

170

170

170

170

170

Hail Guards

73

73

73

73

73

Roof Curb (14-in.)

365

365

365

365

365

Double Wall

275

275

275

275

275

Humidi-MiZer Coil

150

150

150

150

150

040 4455 4648
040 300 450 500 110 187 512
45
170 146 410 275 180

050 4599 4792
050 300 450 500 110 317 751
45
170 146 410 275 180

060 6826 7041
060 450 675 725 165
26 677
45
255 219 540 375 195

Table 4 -- Constant Volume Fan Motor Weights (lb)

MOTOR HP 5 HP
10 HP 15 HP 20 HP 25 HP 30 HP 40 HP

UNIT VOLTAGE
230/460 380 575
230/460 380 575
230/460 380 575
230/460 380 575
230/460 380 575
230/460 380 575
230/460 380 575

PREMIUM EFFICIENCY
IFM 80 75 80 126 120 126 217 155 217 250 185 250 309 225 309 303 283 303 551 601 551

Table 5 -- Variable Air Volume / Staged Air Volume Fan Motor Weights (lb)

MOTOR HP 5 HP
10 HP 15 HP 20 HP 25 HP 30 HP 40 HP

UNIT VOLTAGE
230/460 380 575
230/460 380 575
230/460 380 575
230/460 380 575
230/460 380 575
230/460 380 575
230/460 380 575

PREMIUM EFFICIENCY
IFM 138 133 149 195 198 195 316 254 319 385 320 357 444 360 454 338 318 342 686 736 686

LEGEND
Cu -- Copper FIOP -- Factory-Installed Option HP -- Horsepower IFM -- Indoor Fan Motor OA -- Outdoor Air SAV -- Staged Air Volume VAV -- Variable Air Volume VFD -- Variable Frequency Drive

LEGEND AND NOTES FOR TABLES 2-5
NOTES: 1. Base unit weight includes outdoor-air hoods. Base unit weight does NOT include indoor-fan motor. ADD indoor-fan motor, FIOPs, and accessories for TOTAL operating weight. 2. VAV/SAVTM motor weights include the indoor motor and the VFD, optional VFD bypass, VFD transducer and associated wiring.

19

20

NOTE: Add 312 lbs (142 kg) for export crating. (027-035 units) Add 346 lbs (157 kg) for export crating. (040-050 units) Add 588 lbs (266 kg) for export crating. (060 units) Add the weights shown below for round tube plate fin coils

Unit Size ----------

027

030-035

040

050

060

Copper Tube/Aluminum Fin Cond Coil 105 lbs (48 kg) 160 lbs (72 kg) 192 lbs (87 kg) 317 lbs (144 kg) 26 lbs (12 kg)

Copper Tube/Copper Fin Cond.Coil 268 lbs (122 kg) 377 lbs (171 kg) 518 lbs (235 kg) 751 lbs (341 kg) 677 lbs (307 kg)

MODEL
50A2/A3/A6/A7 027 48A2/A3/A6/A7D 027 48A2/A3/A6/A7E 027

WEIGHT LBS KGS 4854 2202 4944 2243 5024 2279

A

INCHES MM

87.7

2227

87.7

2227

87.7

2227

B INCHES MM
97.2 2469 96.1 2441 95.6 2428

C

INCHES MM

44.1

1120

43.7

1110

43.4

1102

50A4/A5/A8/A9 027 4932 2237 87.7 48A4/A5/A8/A9D 027 4984 2261 87.7 48A4/A5/A8/A9E 027 5064 2297 87.7

2227 93.6

2379

48.4

1230

2227 92.7

2354

48.0

1220

2227 92.3

2344

47.7

1211

50A2/A3/A6/A7 030 4834 2193 87.7 48A2/A3/A6/A7D 030 4924 2233 87.7 48A2/A3/A6/A7E 030 5004 2270 87.7 50A4/A5/A8/A9 030 4912 2228 87.7

2227 95.2

2417

44.4

1128

2227 94.0

2389

44.0

1118

2227 93.6

2376

43.7

1110

2227 91.6

2327

48.8

1238

48A4/A5/A8/A9D 030 4964 2252 87.7 48A4/A5/A8/A9E 030 5044 2288 87.7 50A2/A3/A6/A7 035 5121 2323 87.7

2227 90.6

2302

48.3

1228

2227 90.3

2293

48.0

1219

2227 95.9

2436

41.4

1053

48A2/A3/A6/A7D 035 5326 2416 87.7 48A2/A3/A6/A7E 035 5486 2489 87.7 50A4/A5/A8/A9 035 5314 2411 87.7 48A4/A5/A8/A9D 035 5366 2434 87.7

2227 94.8

2408

41.0

1042

2227 94.2

2394

40.7

1035

2227 92.7

2354

45.7

1162

2227 91.7

2329

45.3

1151

48A4/A5/A8/A9E 035 5526 2507 87.7 50A2/A3/A6/A7 040 5559 2521 87.7 48A2/A3/A6/A7D 040 5764 2614 87.7

2227 91.3

2318

44.9

1141

2227 121.8 3094

41

1052

2227 120.3 3056

41

1041

48A2/A3/A6/A7E 040 5924 2687 87.7 50A4/A5/A8/A9 040 5752 2609 87.7 48A4/A5/A8/A9D 040 5804 2633 87.7 48A4/A5/A8/A9E 040 5964 2705 87.7

2227 118.8 3018

41

1033

2227 116.5

2958

45.4

1152

2227 115.1

2924

44.9

1142

2227 113.9

2893

44.6

1132

50A2/A3/A6/A7 050 5744 2606 87.7

2227 119.5 3035

42

1059

48A2/A3/A6/A7D 050 5949 2699 87.7 48A2/A3/A6/A7E 050 6109 2771 87.7 50A4/A5/A8/A9 050 5937 2693 87.7

2227 118.1 2999

41

1048

2227 116.6 2962

41

1040

2227 114.3

2904

45.5

1156

48A4/A5/A8/A9D 050 5989 2717 87.7

2227 112.9

2868

45.1

1145

48A4/A5/A8/A9E 050 6149 2789 87.7

2227 111.7

2837

44.7

1135

50A2/A3/A6/A7 060 8311 3770 161.7 4106 184.9 4698

43

1102

48A2/A3/A6/A7D 060 8386 3804 161.7 4106 177.6 4511

41

1049

48A2/A3/A6/A7E 060 8626 3913 161.7 4106 170.4 4329

39

996

50A4/A5/A8/A9 060

8526 3868 161.7 4106 176.5 4484

47.1

1196

48A4/A5/A8/A9D 060 8426 3822 161.7 4106 169.6 4309

45.2

1149

48A4/A5/A8/A9E 060 8676 3936 161.7 4106 163.3 4147

43.2

1097

The weight distribution and center of gravity information are representative of a standard unit and include the impact of factory installed economizer, largest IFM

motor & VFD, modulating power exhaust (both factory installed and field installed options), and electric heat (on 50A only). 50EJ500305 REV 2.0

Fig. 15 -- Rigging Information

Table 6 -- Evaporator Fan Motor Data

UNIT SIZE 50A 020 025 027 030 035 040 050 060

MOTOR HP
5 10 15
5 10 15
10 15 20
10 15 20
15 20 25
15 20 25
20 25 30
25 30 40

MOTOR SHAFT DIA.
(in.)
1.125 1.375 1.625
1.125 1.375 1.625
1.375 1.625 1.625
1.375 1.625 1.625
1.625 1.625 1.875
1.625 1.625 1.875
1.625 1.875 1.875
1.875 1.875 2.125

FAN SHAFT SPEED (RPM)
717 924 1096
773 962 1106
848 1059 1187
856 1096 1187
1025 1147 1247
976 1050 1182
1050 1142 1234
1019 1087 1197

MOTOR SHEAVE
(P/N)
BK55 2BK50 2B5V56
BK55 1B5V60 2B5V54
2BK50 2B5V56 2B5V58
2BK50 2B5V56 2B5V58
2B5V50 2B5V56 2B5V62
2B5V52 2B5V56 2B5V74
2B5V56 2B5V62 2B5V66
3B5V52 3B5V58 3B5V64

MOTOR SHEAVE
PITCH DIAMETER
(in.)
4.8 4.4 5.7
5.2 6.1 5.5
4.4 4.9 5.9
4.4 5.7 5.9
5.1 5.7 6.2
5.3 5.7 7.5
5.7 6.2 6.7
5.3 5.9 6.5

BUSHING DIAMETER
(in.)
NONE - 1.125 NONE - 1.375
B - 1.625
NONE - 1.125 H - 1.375 B - 1.625
NONE - 1.375 B - 1.625 B - 1.625
H - 1.375 B - 1.625 B - 1.625
B - 1.625 B - 1.625 B - 1.875
B - 1.625 B - 1.625 B - 1.875
B - 1.625 B - 1.875 B - 1.875
B - 1.875 B - 1.875 B - 2.125

FAN SHEAVE
(P/N)
1B5V124 2B5V86 2B5V90
1B5V124 1B5V110 2B5V86
2B5V94 2B5V90 2B5V86
2B5V94 2B5V90 2B5V86
2B5V86 2B5V86 2B5V86
2B5V94 2B5V94 2B5V110
2B5V94 2B5V94 2B5V94
3B5V90 3B5V94 3B5V94

FAN SHEAVE
PITCH DIAMETER
(in.)
12.4 8.6 9.1
12.4 11.1
8.7
9.4 8.1 8.7
9.0 9.1 8.7
8.7 8.7 8.7
9.5 9.5 11.1
9.5 9.5 9.5
9.1 9.5 9.5

BUSHING DIAMETER
(in.)
B - 1.9375 B - 1.9375 B - 1.9375
B - 1.9375 B - 1.9375 B - 1.9375
B - 1.9375 B - 1.9375 B - 1.9375
B - 1.9375 B - 1.9375 B - 1.9375
B - 1.9375 B - 1.9375 B - 1.9375
B - 1.9375 B - 1.9375 B - 1.9375
B - 1.9375 B - 1.9375 B - 1.9375
B - 1.9375 B - 1.9375 B - 1.9375

BELT (QUANTITY)
(P/N)
BX56 (2) BX50 (2) 5VX530
BX56 5VX570 (2) 5VX530
(2) BX50 (2) 5VX530 (2) 5VX530
(2) BX50 (2) 5VX530 (2) 5VX530
(2) 5VX500 (2) 5VX530 (2) 5VX530
(2) 5VX530 (2) 5VX550 (2) 5VX590
(2) 5VX550 (2) 5VX570 (2) 5VX570
(3) 5VX530 (3) 5VX550 (3) 5VX570

NOTES: 1. Motor shaft speed is 1750 rpm. The fan shaft diameter is 115/16 inches. 2. All indoor fan motors meet the minimum efficiency requirements as estab-
lished by the Energy Policy Act of 1992 (EPACT), effective October 24,
1997.

BELT TENSION (lb at .25 in.)
8 8 9
8 11
9
8 10 11
8 9 11
9 10 11
10 11 11
10 11 13
12 12 14

a50-8108
Fig. 16 -- Air Distribution -- Thru-the-Bottom
a50-8109
Fig. 17 -- Air Distribution -- Thru-the-Side

Fig. 18 -- Outdoor Air and Return Air Sensors Location
Step 5 -- Trap Condensate Drain -- See Fig. 6-14
for drain location. Condensate drain is open to atmosphere and must be trapped. Install a trapped drain at the drain location. One 1-in. female pipe coupling is provided inside the unit evaporator section for condensate drain connection. A trap at least 4 in. deep must be used. See Fig. 19. Trap must be installed to prevent freeze-up.
Condensate pans are sloped so that water will completely drain from the condensate pan to comply with indoor air quality guidelines. The condensate drain pans are not insulated.
Step 6 -- Make Electrical Connections
POWER WIRING -- Units are factory wired for the voltage shown on the unit nameplate.
Provide a unit safety disconnect switch in the main power supply to each unit (see Fig. 20). Select switch size and mounting location in accordance with applicable local codes or National Electrical Code (NEC). If combining the functions of safety disconnect with maximum overcurrent protection (MOCP) fuses ("fused disconnect"), coordinate safety switch size with MOCP size data as marked on unit informative plate.

21

a48-3714
Fig. 19 -- Condensate Drain Trap Piping Details (Typical Roof Curb or Slab Mount Shown)
Unit may be equipped with optional factory-installed nonfused disconnect switch (see Fig. 20). Provide maximum overcurrent protection devices (fuses or UL489 rated breakers, per local codes) in branch circuit wiring remote from unit. Observe requirements of NEC Article 440. Install service switch upstream of remote fuses if required.
The main power terminal block is suitable for use with aluminum or copper wire. See Fig. 20. Units have circuit breakers for compressors, fan motors, and control circuit. If required by local codes, provide an additional disconnect switch. Unit must be electrically grounded in accordance with local codes or, in absence of local codes, with NEC, ANSI (American National Standards Institute) C1-latest year.
FIELD POWER SUPPLY -- Unit is factory wired for voltage shown on unit nameplate.
Field wiring can be brought into the unit from bottom (through basepan and roof curb) or through side of unit (corner post next to control box).
A 31/2-in. NPT coupling for field power wiring and a 3/4-in. NPT coupling for 24-v control wiring are provided in basepan. In the side post, there are two 21/2-in. (sizes 020-035) or 3-in. (sizes 040-060) knockouts for the field power wiring. See Fig. 6-13. If control wiring is to be brought in through side of unit, a 7/8-in. diameter hole is provided in the condenser side post next to the control box.
Do not route control wiring in the same conduit as power wiring.
If disconnect box is mounted to corner post, be careful not to drill or screw into the condenser coil.
Routing Through Bottom of Unit -- If wiring is brought in through bottom of unit, use field-supplied watertight conduit to route power wiring through the 31/2-in. diameter hole provided in the unit basepan.
Install conduit connector in unit basepan as shown in Fig. 613. Route power and ground lines through connector to terminal connections in unit control box as shown on unit wiring diagram and Fig. 20.
Use strain relief going into control box through 35/8-in. diameter hole provided. After wires are in unit control box, connect to power terminal block (see Power Wiring section on page 21).
Low-voltage wiring must be run in watertight conduit from the basepan to control box and through 7/8-in. diameter hole provided in bottom of unit control box. Field-supplied strain relief must be used going into the box. After wiring is in control box, make connections to proper terminals on terminal blocks (see Field Control Wiring section on page 23).

Routing Through Side of Unit -- Route power wiring in field-supplied watertight conduit into unit through 21/2-in. (sizes 020-035) or 3-in. (sizes 040-060 units) hole.
Use field-supplied strain relief going into control box through 35/8-in. diameter hole provided. After wires are in unit control box, connect to power terminal block (see Power Wiring section on page 21).
Bring low-voltage control wiring through the 7/8-in. diameter hole provided in the condenser section side post. Use strain relief going into 7/8-in. diameter hole in bottom of unit control box.
After wiring is in control box, make connection to proper terminals on terminal blocks (see Field Control Wiring section on page 23).
Affix crankcase heater sticker (located in the installer's packet) to unit disconnect switch.

FIELD POWER SUPPLY

TB1

11

21

12

22

13

23

FIELD SUPPLIED DISCONNECT PER NEC

EQUIP GND FIELD-INSTALLED DISCONNECT

OPTIONAL FACTORY-INSTALLED
DISCONNECT

11

21

12

22

13

23

FIELD POWER WIRING

GND a48-6977
FACTORY-INSTALLED DISCONNECT LEGEND GND -- Ground NEC -- National Electrical Code TB -- Terminal Block
Fig. 20 -- Field Power Wiring Connections
IMPORTANT: The variable air volume units use variable frequency drives, which generate and can radiate radio frequency energy. If units are not installed and used in accordance with these instructions, they may cause radio interference. They have been tested and found to comply with limits of a Class A computing device pursuant to International Standard in North American FN 61000-2/3, which are designed to provide reasonable protection against such interference when operated in a commercial environment.
WARNING
The unit must be electrically grounded in accordance with local codes and NEC ANSI/NFPA 70 (National Fire Protection Association). Failure to ground unit could cause personal injury.

22

Voltage to compressor terminals during compressor operation must be within the voltage range indicated on the unit nameplate. Phases must be balanced within 2%.
Use the following formula to determine the percent of voltage imbalance.
% Voltage Imbalance:
max voltage deviation from average voltage = 100 x
average voltage

Example: Supply voltage is 230-3-60

AB C

AB = 224 v

BC = 231 v

MOTOR

AC = 226 v

Average Voltage = (224 + 231 + 226) = 681 = 227

3

3

Determine maximum deviation from average voltage. (AB) 227-224 = 3 v (BC) 231-227 = 4 v (AC) 227-226 = 1 v Maximum deviation is 4 v. Determine percent of voltage imbalance.

% Voltage Imbalance= 100x 4 = 1.78% 227
This amount of phase imbalance is satisfactory as it is below the maximum allowable 2%.

IMPORTANT: If the supply voltage phase imbalance is more than 2%, contact your local electric utility company immediately.

NOTE: Check all factory and field electrical connections for tightness.
Unit failure as a result of operation on improper line voltage or excessive phase imbalance constitutes abuse and may cause damage to electrical components.
IMPORTANT: On 208/230-v units, transformers 1 to 5 are wired for 230-v. If 208/230-v unit is to be run with 208-v power supply, the transformers must be rewired as follows:
For transformer 1 move the black wire connected to terminal H2 and connect it to terminal H3.
For transformers 2 to 4, used for the 24 volt control circuits, connect as follows:
1. Remove cap from red (208 v) wire.
2. Remove cap from spliced orange (230 v) wire. Disconnect orange wire from black unit power wire.
3. Cap orange wire.
4. Splice red wire and black unit power wire. Cap wires.
If the unit is equipped with the optional convenience outlet, connect the yellow wire to H2 on transformer 5.

IMPORTANT: BE CERTAIN UNUSED WIRES ARE CAPPED. Failure to do so may damage the transformers.

FIELD CONTROL WIRING -- The 50A Series units support a large number of control options that can impact the field control wiring. Refer to Fig. 21 and 22.
The control options that the unit can provide relate to the following parameters:
� CV (constant volume), VAV (variable air volume), SAV (staged air volume), or VVT� (variable volume and variable temperature) control operation
� Standalone with a thermostat (CV) or with a space sensor (CV and VAV)
� Network application with CCN (Carrier Comfort Network�) or other networks
� Demand controlled ventilation with CO2 sensor � Economizer and economizer with changeover control � Building and duct static pressure control � Fire shutdown and smoke control

� Diagnostics and monitoring � For constant volume applications a thermostat (T-Stat) or
space temperature sensor (SPT) will be required.
FIELD-SUPPLIED THERMOSTAT
LIGHT

R RC Y1 Y2 W1 W2 G

C

X

R

Y1 Y2 W1 W2 G

C

X

1

2

3

4

5

6

7

8

a48-8243

TB4

Fig. 21 -- Field Control Thermostat Wiring

a48-6854

T55 SPT

T1 T2

T56 SPT TH C SN

1

3

5

7

9

11 13 15

UNIT

TB5

2

4

6

8

10 12 14 16

Fig. 22 -- Space Temperature Sensor Wiring

T-STAT (Conventional Thermostat) -- Unit can be controlled with a Carrier-approved accessory electro-mechanical or electronic thermostat that has two stages of cooling, two stages of heating control, and an output for indoor fan control. It may also include time of day scheduling or use the scheduling routines built into the ComfortLink controls.
Install thermostat according to the installation instructions included with accessory thermostat. Locate thermostat assembly on a solid interior wall in the conditioned space to sense average temperature.
Route thermostat cable or equivalent single leads of colored wire from subbase terminals through conduit into unit to low voltage connection in the main control box, as shown in Fig. 21 and 22. For thermostat TB4 connections see Fig. 21.
NOTE: For wire runs up to 50 ft, use no. 18 AWG (American Wire Gage) insulated wire (35 C minimum). For 50 to 75 ft, use no. 16 AWG insulated wire (35 C minimum). For over 75 ft, use no. 14 AWG insulated wire (35 C minimum). All wire larger than no. 18 AWG cannot be directly connected at the thermostat and will require a junction box and splice at the thermostat. Set heat anticipator settings as follows:

UNIT SIZE 50A
020-050
060

STAGE 1 (W1) ON
0.24
0.36

STAGE 2 (W1 AND W2) ON
0.13
0.13

Settings may be changed slightly to provide a greater degree of comfort for a particular installation.

SPT (Space Temperature Sensor) -- For constant volume applications the ComfortLink controls can also be used with T55 and T56 space temperature sensors that use a 10K thermistor. The T56 sensor also has the capability for a configurable temperature set point offset at the thermostat. For variable air volume applications only the T55 sensor can be used.
Install sensor according to the installation instructions included with accessory sensor. Locate sensor assembly on a solid interior wall in the conditioned space to sense average temperature.

23

Run wiring to the space sensor as shown in Fig. 22.
Note that when the remote sensor is used, the red jumper wires provided must be connected from TB4 terminal 4 to 5 and TB4 terminal 5 to 1.
Both the T55 and T56 have a CCN communications port and this should be wired to the CCN Communications TB3 board if it is desired to have access to the CCN system through the sensor. If more than one T55 sensor is being used and averaged, sensors must be wired in multiples of 4 or 9 as shown in Fig. 23.
T58 Communicating Thermostat -- Carrier also has a fully communicating thermostat which, if used, will be wired to the CCN communication connections on TB3 as described in the Carrier Comfort Network� Interface section below.
Carrier Comfort Network (CCN) Interface -- The rooftop units can be connected to the CCN system. The communication bus wiring is supplied and installed in the field. Wiring consists of shielded, 3-conductor cable with drain wire. The system elements are connected to the communication bus in a daisy chain arrangement. The positive pin of each system element communication connector must be wired to the positive pins of the system element on either side of it, the negative pins must be wired to the negative pins, and the signal pins must be wired to signal ground pins. Wiring connections for CCN system should be made at the TB3 terminal block using the screw terminals. The TB3 board also contains an RJ14 CCN plug that can be used to connect a field service computer or other CCN device. There is also an RJ14 LEN (local equipment network) connection that is used to connect a NavigatorTM display or download software.
Conductors and drain wire must be 20 AWG minimum stranded, tinned copper. Individual conductors must be insulated with PVC, PVC/nylon, vinyl, Teflon1, or polyethylene. An aluminum/polyester 100% foil shield and an outer jacket of PVC, PVC/nylon, chrome vinyl, or Teflon with a minimum operating temperature range of �4�F to 140�F is required. Table 7 lists cables that meet the requirements.
Table 7 -- CCN Connection Approved Shield Cable

MANUFACTURER ALPHA
AMERICAN BELDEN
COLUMBIA

CABLE PART NO. 2413 or 5463 A22503 8772 02525

IMPORTANT: When connecting the CCN communication bus to system elements, use color coding system for the entire network to simplify installation and checkout. See Table 8.

1. Teflon is a registered trademark of DuPont.

Table 8 -- Color Code Recommendations

SIGNAL TYPE
POSITIVE (+) GROUND
NEGATIVE (�)

CCN BUS CONDUCTOR INSULATION COLOR
RED
WHITE
BLACK

CCN PLUG PIN NO.
1
2
3

If a cable with a different color scheme is selected, a similar color code should be adopted for the entire network. At each system element, the shields of the communication bus cables must be tied together. If the communication bus is entirely within one building, the resulting continuous shield must be connected to a ground at one point only. If the communication bus cable exits from one building and enters another, the shields must be connected to grounds at the lightning suppressor in each building where the cable enters or exits the building (one point per building only).
To connect the unit to the network:
1. Turn off power to the control box. 2. Cut the CCN wire and strip the ends of the red (+), white
(ground), and black (�) conductors. (If a different network color scheme is used, substitute appropriate colors.) 3. Remove the 3-pin male plug from the base control board in the main control box, and connect the wires as follows: a. Insert and secure the red (+) wire to terminal 1 of
the 3-pin plug. b. Insert and secure the white (ground) wire to termi-
nal 2 of the 3-pin plug. c. Insert and secure the black (�) wire to terminal 3
of the 3-pin plug.
4. Insert the plug into the existing 3-pin mating connector on the base module in the main control box.
VAV Units with Heat -- For variable air volume units that will use heat, the variable air volume terminals should be interlocked with the unit at TB5 terminals 1 and 2 as shown on the wiring diagram.
Demand Ventilation -- The unit can be equipped with a CO2 sensor for use in demand ventilation. This can be factory supplied and will be mounted in the return duct. It can also be field supplied and mounted in the return duct or in the space. Connect the field-installed 4 to 20 mA sensor to TB5 terminals 6 and 7. Do not remove the factory-installed 182-ohm resistor.
If an outdoor IAQ (indoor air quality) sensor is used then it should be wired to terminals 11 and 12 on TB6. This will require the use of the optional controls expansion module.

24

TB5 RED
3

4

BLK

SENSOR 1

SENSOR 2

SENSOR 3

SENSOR 4

SPACE TEMPERATURE AVERAGING (4 SENSOR APPLICATION) TB5
3
4

SENSOR 1

SENSOR 2

SENSOR 3

SENSOR 4

SENSOR 5

SENSOR 6

SENSOR 7

SENSOR 8

SENSOR 9

a48-6855 NOTE: Use T55 sensor only.

SPACE TEMPERATURE AVERAGING (9 SENSOR APPLICATION)
Fig. 23 -- Space Temperature Averaging Wiring

Remote IAQ Override -- If the control is being used with non-Carrier building management system, it supports the use of the remote IAQ override switch. This should be connected to TB6 terminal 13 and 14. Use of this will require the optional controls expansion module.
Remote Economizer Position Control -- The ComfortLink controller will normally control the position of the economizer, but it can also support field control of the economizer position through a 4 to 20 mA signal. If this is used it should be connected to TB5 terminal 6 and 7. If the signal is a 4 to 20 mA signal, then leave the 182-ohm resistor in place.
Remote Economizer Minimum Position Control -- If the ComfortLink controller is controlling the economizer but a remote minimum position is required, then an external 100K potentiometer should be connected to TB5 terminal 6 and 7. Remove the factory-installed 182-ohm resistor.
Remote Economizer Enable -- If the control is being used with other building management systems and the system will control the enabling and disabling of the economizer free cooling, this switch input can be connected to TB6 terminals 1 and 2. Note that the controls also support integrated economizer changeover using outdoor dry bulb, differential dry bulb, outdoor enthalpy, and differential enthalpy.
Remote Occupancy Switch -- For interface to other building management systems the control also supports a switch input

for remote occupancy signals. This wiring can be connected to terminal TB6 terminal 1 and 3.
Smoke Sensor Interface -- The ComfortLink controls include an optional factory-installed return air smoke detector. Remote alarm circuits can be wired to TB5 terminal 8 and 9.
Fire Shutdown and Smoke Control -- The control supports interface to fire and smoke control systems and allows for the following system overrides from remote switch inputs.
� Fire Shutdown -- Connect to TB5 terminals 10 and 11. � Smoke Pressurization -- Connect to TB5 terminal 12
and 13. This requires the use of the optional controls expansion module. � Smoke Evacuation -- Connect to TB5 terminal 12 and 14. This requires the use of the optional controls expansion module. � Smoke Purge -- Connect to TB5 terminal 12 and 15. This requires the use of the optional controls expansion module.
Demand Limiting -- The control can also be used with demand limiting control from remote building management systems. If a two-stage system is going to be used with redline limiting where the machine is not allowed to increase load and load shed where the load is decreased to a configurable limit in capacity then these can be connected to TB6 terminals 4 and 5 and 5 and 6. This requires use of the controls expansion module.

25

Step 7 -- Make Outdoor-Air Inlet Adjustments
ECONOMIZER AND MIXED OUTDOOR AIR DAMPER -- Hoods are used on all units with economizer or adjustable self-closing mixed outdoor air damper.
NOTE: If accessory power exhaust or barometric relief packages are being added to the unit, install power exhaust or barometric relief before installing economizer hoods.
Economizer Hood Assembly -- The economizer hood is shipped in a package secured to the outside of the unit. The hood assemblies must be field-assembled. The 50A4,A5,A8,A9 units are side supply and side return. The return duct limits access to economizer filters from below.
The 50A020-050 units have two hoods on every unit. The 50A060 units have 3 hoods on every unit.
NOTE: Before assembly of the economizer hood, check along the outer edges of the economizer assembly for any seal strip protruding past the flanges. Trim the excess seal strip so that it is flush with the economizer assembly flanges.
Perform the following procedure to assemble the economizer hood.
1. Apply black seal strip (provided) to outside top-edge of hood sides. Wrap seal strip over edge to cover top flange (2 hood sides per hood assembly). Make sure seal strip covers screw holes. See Fig. 24.
2. Add gray foam strip (provided) to cross members on bottom tray. See Fig. 25.
3. Assemble hood sides, top, and cross member with gasketed screws provided. See Fig. 26.
4. Attach speed clips (provided) to hood top. Engagement section of the clip faces inside hood. See Fig. 27.
5. Apply black seal strip (provided) to mounting flanges of hood sides being sure to cover mounting holes. See Fig. 28.
6. Apply black seal strip (provided) to back of hood top mounting flange. Seal strip of hood top mounting flange must press tightly against seal strip of hood side mounting flanges. See Fig. 28.
7. Attach gray foam strip (provided) to block-off baffle on outer face of flange. See Fig. 29.
8. Remove the screws on each end and along top of the outdoor air opening of unit. Set hood assembly in place and attach to unit using gasketed screws. See Fig. 30.
9. Locate and mount block-off baffle using 3 screws. See Fig. 31.
10. Assemble bottom filter tracks side by side with the mounting angle together. The filter track assemblies must be installed with the flange and mounting angle pointing down. See Fig. 32-34.
11. Attach speed clips (provided) to hood side panels. Engagement section of clip faces up and towards the outside of the hood side panels. Attach mounting angles to hood with gasketed screws provided. See Fig. 35.
NOTE: Be sure the filters are installed with the airflow in the correct direction.
12. Attach filter track under the hood assembly. See Fig. 36.
13. Attach black seal strip (provided) to filter cover. Seal strip should be applied centered over the holes of the one flange, making sure to fully cover holes and center over the other large flange. See Fig. 37.
14. Slide two 20 x 25-in. filters into cross members of hood assembly. Attach filter cover over filters with screws and speed clips provided. See Fig. 38.

TOP FLANGE
BLACK SEAL STRIP

HOOD SIDE

Fig. 24 -- Adding Seal Strip to Top of Hood Sides

GRAY FOAM STRIP
CROSS MEMBER
Fig. 25 -- Adding Foam Strip to Cross Member
HOOD SIDE
HOOD TOP

CROSS MEMBER

HOOD SIDE

Fig. 26 -- Economizer Hood Assembly

Fig. 27 -- Top Hood with Speed Clips

26

TOP HOOD

CROSSMEMBER

SIDE HOOD

SEAL STRIP

Fig. 28 -- Adding Seal Strip to Hood Top and Side Hoods

BLOCKOFF BAFFLE

GRAY FOAM STRIP
Fig. 29 -- Adding Foam Strip to Block-Off Baffle

FILTER ASSEMBLY

FLANGE POINTING DOWN

MOUNTING ANGLE FASTENED TO BOTTOM OF FILTER ASSEMBLY

Fig. 32 -- Correctly Assembled Bottom Filter Assembly, Sizes 020-035 Only

FILTER ASSEMBLY

FLANGE POINTING DOWN

MOUNTING ANGLE FASTENED TO BOTTOM OF FILTER ASSEMBLY

Fig. 33 -- Correctly Assembled Bottom Filter Assembly, Sizes 040-060 Only

FILTER TRACK

MOUNTING ANGLE

Fig. 34 -- Flange and Mounting Angle Pointing Down

Fig. 30 -- Removing Screws from the Outdoor Air Opening of Unit
SPEED CLIPS
Fig. 35 -- Bottom Filters Installed with Flange Pointing Down

BLOCK-OFF BAFFLE
Fig. 31 -- Mounting Block-Off Baffle to the Unit

27

FLANGE POINTING DOWN

MOUNTING ANGLE

Fig. 36 -- Bottom Filters Installed with Flange Pointing Down

BLACK SEAL STRIP (CENTERED)

FILTER COVER

48-1110f
Fig. 37 -- Attaching Seal Strip to Filter Cover
FILTER COVER
FILTERS
Fig. 38 -- Slide Two Filters
Step 8 -- Position Power Exhaust/Barometric Relief Damper Hood -- All units are shipped with the
hoods folded inside the unit in a shipping position. For 50A2,A3,A6,A7 units the hood must be tilted out once the

unit is installed. On 50A4,A5,A8,A9 units (designed for horizontal supply and return), the assemblies will have to be relocated to return ductwork. See Fig. 39 for dimensions and details.
All electrical connections have been made and adjusted at the factory. The power exhaust blowers and barometric relief dampers are shipped assembled and tilted back into the unit for shipping. Brackets and extra screws are shipped in shrink wrap around the dampers. If ordered, each unit will have 4 (50A020-050 units) or 6 (50A060 units) power exhaust blowers and motors or barometric relief dampers.
1. Remove 9 screws holding each damper assembly in place. See Fig. 40. Each damper assembly is secured with 3 screws on each side and 3 screws along the bottom. Save screws.
CAUTION
Be careful when tilting blower assembly. Hoods and blowers are heavy and can cause injury if dropped.
2. Pivot each damper assembly outward until edges of damper assembly rest against inside wall of unit.
3. Secure each damper assembly to unit with 6 screws across top (3 screws provided) and bottom (3 screws from Step 1) of damper.
4. With screws saved from Step 1, install brackets on each side of damper assembly.
5. Remove tape from damper blades.
Step 9 -- Route Static Pressure Sensors
VAV DUCT PRESSURE TRANSDUCER -- The VAV duct pressure transducer (VAV inverter pressure transducer) is located behind the filter access door on the lower inner panel. See Fig. 41. A section of field-supplied 1/4-in. plastic tubing must be run from the high pressure tap on the differential pressure switch and connected to a field-supplied tap in the supply-air duct. The tap is usually located 2/3 of the way out on the main supply duct. Remove plug button in panel to route tubing.
BUILDING PRESSURE TRANSDUCER -- The building pressure transducer (modulating power exhaust pressure transducer) is located behind the filter access door on the lower inner panel. See Fig. 41. A section of field-supplied 1/4-in. plastic tubing must be run from the high-pressure tap on the differential pressure switch to the conditioned space. The pressure tube must be terminated in the conditioned space where a constant pressure is required. This location is usually in an entrance lobby so that the building exterior doors will open and close properly. Remove plug button in panel to route tubing.
The low pressure tap is factory-routed to the atmosphere. For a positive-pressure building, route the high tap to building air and low tap to atmosphere. For a negative-pressure building, route the high tap to atmosphere and the low tap to building air.

28

LOCATION BAROMETRIC RELIEF OR POWER EXHAUST "SIDE #2"

ECONOMIZER HOOD

42.56"

ECONOMIZER HOOD

23.28" TYP

"END #2"

42" MIN.

R/A

12.94 (UNIT

OPENING)

a50-8110
ALTERNATE LOCATION (END)

"END #1"
42.62 TYP

"SIDE #1"

23.28"

42.62"

R/A

S/A

J BOX

S/A J BOX
PLENUM RATED CABLE (FIELD SUPPLIED)
NOTE: Sizes 020-050 shown (2 power exhaust fans). Size 060 has 3 power exhaust fans. All unit sizes have the same size power exhaust.

Fig. 39 -- Side Return Air Conversion (for CRPWREXH033A00, 034A00, 035A00, and 036A00)

a48-3808 NOTES:
1. Unless otherwise specified, all dimensions are to outside of part. 2. Dimensions are in inches. 3. On 50A4,A5,A8,A9 units, accessory barometric relief or power exhaust must be mounted in the field-supplied return ductwork.
Fig. 40 -- Barometric Relief Damper and Power Exhaust Mounting Details (for CRPWREXH033A00, 034A00, 035A00, and 036A00)
29

a48-6983

AUXILIARY CONTROL PANEL

PRESSURE TRANSDUCERS (INSIDE OF PANEL)

Fig. 41 -- Pressure Transducer Locations

Step 10 -- Install All Accessories/Options -- Af-
ter all the factory-installed options have been adjusted, install all field-installed accessories. Refer to the accessory installation instructions included with each accessory.
The 50A Series units have a large number of factory-installed options which were previously available only as accessories. Some of the available options can also be installed in the field if needed. In most cases the units have been pre-wired so that the accessories can be easily installed. Instructions are shipped with each accessory. Configuration of the controls for these accessories as well as the factory-installed options can be found in the Controls, Start-up, Operation, Service and Troubleshooting book. The following is a list of some of the common accessories:
� Thermostats and space temperature sensors � Accessory barometric relief damper � Accessory power exhaust � Non-modulating to modulating power exhaust � Condenser coil hail guards � Outdoor humidity sensor (used for economizer enthalpy
changeover)

� Return air humidity sensors (used for economizer differential enthalpy changeover, factory-installed with HumidiMiZer option)
� Return air smoke detector � Controls expansion module (used for interface to build-
ing management systems, not typically needed on system with Carrier Comfort Network� [CCN] devices) � Plugged filter sensor � Motormaster� V low ambient head pressure control FIELD-FABRICATED WIND BAFFLES
IMPORTANT: Carrier recommends the installation of field-fabricated wind baffles on all vertically oriented condenser coils when operating in environments with prevailing winds of more than 5 mph and where temperatures drop below 32�F. See the Motormaster accessory installation guide for instructions.
WARNING
To avoid the possibility of electrical shock, open all disconnects before installing or servicing this accessory.
In areas with prevailing winds of more than 5 mph and where temperatures drop below 32�F, wind baffles must be field fabricated to ensure proper cooling cycle operation at low-ambient temperatures with Motormaster V controls. Baffles are not needed on size 060 units with MCHX (microchannel heat exchangers). See Fig. 42 for baffle details. Use 20gage galvanized sheet metal, or similar corrosion-resistant material for the baffles. Use field-supplied screws to attach baffles to unit. Screws should be 1/4-in. diameter or larger. Screws should not be more than 1/2 inch in length. Drill required screw holes for mounting baffles.
CAUTION
To avoid damage to refrigerant coils, electrical components, and wiring use extreme care when drilling screw holes and screwing in fasteners.

30

SIZES 020-035

SIZES 036-050 AND 060 RTPF

UNIT SIZE 50A

QUANTITY

DIMENSION "A"

IN.

MM

020-035

1

78.125 � 0.125 1984 � 3

036-050

2

78.125 � 0.125 1984 � 3

060

2

118 � 0.125

2997 � 3

NOTE: 50A060 units with MCHX do not require baffles.

LEGEND
MCHX -- Microchannel Heat Exchanger RTPF -- Round Tube Plate Fin Heat Exchanger

Fig. 42 -- Wind Baffle Details 31

Step 11 -- Perform Field Modifications
DUCTWORK
Bottom Return Units (50A2,A3,A6,A7) Field-Modified for Side Return -- The 50A2,A3,A6,A7 units with bottom return air connections may be field-modified to accommodate side return air connections.
IMPORTANT: The following section is a guideline and not a comprehensive procedure to field modify the units. The installing contractor must provide some design initiative. Field conversion is complex and is not recommended. Units with electric heat must not be converted because of potential heating mode operating problems.
Conversion to horizontal return requires that the bottom return openings of the unit must be sealed with airtight panels capable of supporting the weight of a person. The return ductwork connection locations on the side of the unit are higher than normal (31 in. high). Unit-mounted power exhaust or barometric relief cannot be used because return air ductwork will cover the power exhaust or barometric relief installation locations. Power exhaust or barometric relief may be installed in the return air ductwork.
To convert the unit, perform the following:
1. Seal the bottom return openings of the unit with airtight panels capable of supporting the weight of a person.
2. Remove the panels located below the economizer outdoor-air dampers. These openings will be used for the return-air ductwork. There are 2 panels on 50A3,A6,A7020-050 units. There are 3 panels on 50A2,A3,A6,A7060 units. These openings are normally used for power exhaust or barometric relief.
3. Run the return air ductwork up to the openings. One single duct is recommended to connect to the unit over the return air openings. See Fig. 43. The return duct must incorporate a minimum 3/4-in. flange for connection to the unit cabinet. The unit does not have duct flanges for this conversion.
Side Supply and Return Units (50A4,A5,A8,A9) with FieldInstalled Power Exhaust in Return Duct -- Space must be available in the return duct to mount the power exhaust fan (gravity relief) modules. Dimensions and suggested locations are shown in Fig. 43. These instructions are a guideline and not a comprehensive procedure. The design contractor must provide some design initiative.
The wiring harness that is provided with the power exhaust accessory is not long enough for the fan modules to be mounted in the return air duct. Field-supplied wiring must be spliced into the harness. Use a junction box at each splice. The wiring may be run in the return duct as shown in Fig. 43 or externally in conduit. A service access panel will be needed near each power exhaust fan.

BACnet1 Communication Option Wiring
WIRING THE UPC OPEN CONTROLLER TO THE MS/ TP NETWORK -- The UPC Open controller communicates using BACnet on an MS/TP network segment communications at 9600 bps, 19.2 kbps, 38.4 kbps, or 76.8 kbps.
Wire the controllers on an MS/TP network segment in a daisy-chain configuration. Wire specifications for the cable are 22 AWG (American Wire Gage) or 24 AWG, low-capacitance, twisted, stranded, shielded copper wire. The maximum length is 2000 ft.
Install a BT485 terminator on the first and last controller on a network segment to add bias and prevent signal distortions due to echoing. See Fig. 44-46.
To wire the UPC Open controller to the BAS network:
1. Pull the screw terminal connector from the controller's BAS Port.
2. Check the communications wiring for shorts and grounds.
3. Connect the communications wiring to the BAS port's screw terminals labeled Net +, Net -, and Shield.
NOTE: Use the same polarity throughout the network segment.
4. Insert the power screw terminal connector into the UPC Open controller's power terminals if they are not currently connected.
5. Verify communication with the network by viewing a module status report. To perform a module status report using the BACview2 keypad/display unit, press and hold the "FN" key then press the "." key.
To install a BT485 terminator, push the BT485 terminator on to the BT485 connector located near the BACnet connector.
NOTE: The BT485 terminator has no polarity associated with it.
To order a BT485 terminator, consult Commercial Products i-Vu� Open Control System Master Prices.
MS/TP WIRING RECOMMENDATIONS -- Recommendations are shown in Tables 9 and 10. The wire jacket and UL temperature rating specifications list two acceptable alternatives. The Halar3 specification has a higher temperature rating and a tougher outer jacket than the SmokeGard4 specification, and it is appropriate for use in applications where the user is concerned about abrasion. The Halar jacket is also less likely to crack in extremely low temperatures.
NOTE: Use the specified type of wire and cable for maximum signal integrity.
1. BACnet is a registered trademark of ASHRAE (American Society of Heating, Refrigerating, and Air-Conditioning Engineers).
2. BACview is a registered trademark of Automated Logic Corporation. 3. Halar is a registered trademark of Solvay Plastics. 4. SmokeGard is a trademark of AlphaGary-Mexichem Corp.

32

97.78" (020-050), 150.47" (051 AND 060) INSIDE DIMENSION

RA

31.25"

INSIDE

Fig. 43 -- Side Return Duct Dimensions

a48-8245

Table 9 -- Open System Wiring Specifications and Recommended Vendors

WIRING SPECIFICATIONS

RECOMMENDED VENDORS AND PART NUMBERS

WIRE TYPE

DESCRIPTION

MS/TP NETWORK
(RS-485)
RNET

22 AWG, single twisted shielded pair, low capacitance, CL2P, TC foam FEP, plenum rated. See MS/TP Installation Guide for specifications.
24 AWG, single twisted shielded pair, low capacitance, CL2P, TC foam FEP, plenum rated. See MS/TP Installation Guide for specifications.
4 conductor, unshielded, CMP, 18 AWG, plenum rated.

AWG CL2P CMP FEP TC

LEGEND
-- American Wire Gage -- Class 2 Plenum Cable -- Communications Plenum Rated -- Fluorinated Ethylene Polymer -- Tinned Copper

CONNECT AIR INTERNATIONAL

BELDEN

RMCORP

CONTRACTORS WIRE AND

CABLE

W221P-22227

--

25160PV CLP0520LC

W241P-2000F 82841 25120-OR W184C-2099BLB 6302UE 21450

-- CLP0442

33

Table 10 -- MS/TP Wiring Recommendations

SPECIFICATION CABLE
CONDUCTOR INSULATION COLOR CODE TWIST LAY SHIELDING

JACKET

DC RESISTANCE CAPACITANCE CHARACTERISTIC IMPEDANCE
WEIGHT

UL TEMPERATURE RATING

VOLTAGE LISTING

AWG CL2P DC FEP NEC O.D. TC UL

LEGEND
-- American Wire Gage -- Class 2 Plenum Cable -- Direct Current -- Fluorinated Ethylene Polymer -- National Electrical Code -- Outside Diameter -- Tinned Copper -- Underwriters Laboratories

RECOMMMENDATION Single twisted pair, low capacitance, CL2P, 22 AWG (7x30), TC foam FEP, plenum rated cable 22 or 24 AWG stranded copper (tin plated) Foamed FEP 0.015 in. (0.381 mm) wall 0.060 in. (1.524 mm) O.D. Black/White 2 in. (50.8 mm) lay on pair 6 twists/foot (20 twists/meter) nominal Aluminum/Mylar shield with 24 AWG TC drain wire SmokeGard Jacket (SmokeGard PVC) 0.021 in. (0.5334 mm) wall 0.175 in. (4.445 mm) O.D. Halar Jacket (E-CTFE) 0.010 in. (0.254 mm) wall 0.144 in. (3.6576 mm) O.D. 15.2 Ohms/1000 feet (50 Ohms/km) nominal 12.5 pF/ft (41 pF/meter) nominal conductor to conductor 100 Ohms nominal 12 lb/1000 feet (17.9 kg/km) SmokeGard 167�F (75�C) Halar -40 to 302�F (-40 to 150�C) 300 Vac, power limited UL: NEC CL2P, or better

BT485 TERMINATOR
BACNET CONNECTION (BAS PORT)
Tx1 LED Rx1 LED
Tx2 LED Rx2 LED
EIA-485 JUMPERS

POWER LED

Fig. 44 -- UPC Open Controller 34

45

45

BACNET

BAUD RATE

6 789

DIP SWITCHES

01

ADDRESS

6 789

ROTARY

01

SWITCHES

23 23

RUN LED ERROR LED

Fig. 45 -- Open System Network Wiring

BACnet�

BT 485

SHIELD

PORT S1 BACnet MS/TP

n/c n/c NET-

NET+

EIA-485

485-2WIRE

Fig. 46 -- BT485 Terminator Installation

35

� Carrier Corporation 2019

Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.

Catalog No. 04-53500233-01

Printed in U.S.A.

Form 50A-17SI

Pg 36

3-19

Replaces: 50A-16SI
