2 EXCURSION SUBWOOFER FEATURESXR.v2 What we call our REFERENCE series is again in our 2nd version our flagship and the entry into the new EXCURSION design concept 2020.
is all you need - dBAkuten.se
CONGRATULATIONS ! Dealer's Name Date of Purchase Installaon Shop Installaon Date
172715419-1b8ad3-Excursion SXR Produktblad
Excursion SXR.v2 8 D4 - köp online på dBakuten.se
Full PDF Document
If the inline viewer fails, it will open the original document in compatibility mode automatically. You can also open the file directly.
Extracted Text
...is all you need SXREFERENCE PERFORMANCE EXCURSION CONGRATULATIONS ! You now own an EXCURSION SXR.v2 REFERENCE Subwoofer, a new T Genera on product of an uncompromising design and german engineering philosophy. A product made from and for Car Audio fana cs who truely believe in the relentless pursuit of perfec on. A product made to be our flagship and the entry into the new EXCURSION design concept 2020. EXCURSION Subwoofers are the result of several decades of product improvements, compe on, innova on and highest quality parts and control standards in industry. When properly installed these speakers will provide you with many years of listening pleasere and are the perfect balance between high fidelity, extreme performance and long-las ng reliabilty. Should your SXR.v2 Subwoofer ever need a service, Please record your informa on on the following lines to refer to in the event that you may need it later. Dealer's Name____________________________ Date of Purchase__________________________ Installa on Shop__________________________ Installa on Date __________________________ At EXCURSION Intl. we are confident you will have many years of outstanding enjoyment from your high performance investment. For maximum performance we recommend that you have your new EXCURSION SXR.v2 Subwoofer installed by an exclusive Authorizied EXCURSION Dealer To learn more about EXCURSION, please visit us on the World Wide Web at h p://www.excursion.us CAUTION ! Con nous exposure to sound pressure levels in excess of 100dB can cause permanent hearing loss. EXCURSION Speakers are capable of producing sound pressure levels well over 170dB. Please observe all local sound ordinances while listening to your EXCURSION System. EXCURSION Intl. acceptss no liability for hearing loss, bodily injury, or property damage due to the result of use or missuse of this product. 1 EXCURSION SXR.v2 SUBWOOFER F EATURE What we call our REFERENCE series is again in our 2nd version our flagship and the entry into the new EXCURSION design concept 2020. Our REFERENCE always stand for our engineering philosophy, adopt today the new Genera on T. But no doubt SXR stay for always our best bass buddies in our EXCURSION world. Those are Dads with whom others but be er not invest and should stay away. Innova ons from previous decades once again meet new materials and create fresh ideas of our me. As result, are much further ahead than ever expected. Performance totally unexpected to be possible in this price range. A lightweight, yet thick natural paper cone with kra pulp cores convinces with a dry and a voluminous impressive deep bass performance that keeps no eye dry. Our oversized and red-s tched rubberized foam surrounds allow unlimited movement in our completely redesigned EXCURSION T steel basket s ffened with our X embossing. A mul -stage cooling takes place in quadruple form by the circula on of the lateral ven la on openings of the basket and the upper ven la on openings of the bobbin, down to the voice coil nip and the ven la on openings and centrally through the core bore of the bo om plate. Our 4 layered 35mm high OFC copper coil is wounded on solid 2.5 "aluminum former and fits into our larger-sized linear spider. With blood-red color and the same-colored seams of the surround, they also set new visual accents and contrasts. However, our op mized 220 Oz Motor also ensures exact movements and accelera on. This comes now only, but for, with a single oversized magnet stack and reaches lossless another more on POWER. Brand-typical, of course, were dispensed with in the new SXR.v2 series on the market cheap compression spring terminal and instead, similar to power connec ons of amplifiers, feature massive double 10mm� high current terminals and allen screws. This ensures lossless perfect contact under the most extreme working condi ons. In another op on and in the accessories range of Hollywood ENERGETIC you will find suitable HPST8 (10mm� double Power Support Terminals). This means that even in the REFERENCE class a connec on cabling of up to 8x 10mm� OFC cable leads for each subwoofer is theore cally possible. This certainly makes every perfec onist sleep absolutely quiet. 2 EXCURSION Pre-Installa on Instruc ons: It is recommend that you have your new EXCURSION SXR.v2 Sub professionally installed by your authorizied EXCURSION dealer. This will ensure use of proper installa on techniques & materials. If you choose to perform your own installa on, the following instruc on will give you direc on making your purchase complete. The factors for the port area are manifold and can not be reduced only to depend on the cone area of the woofer that is used. But at least it is a good advice not to go with less than 1/7 of the cone area for ported and 1/4 for bandpass enclosures. While you are building up and tuning your sub system you should use a trial-port. This should be longer than calculated or recommend. While tuning the system you can find the best sounding length by shortening the port in aprox 2 cm steps. The final tuning in the car does not only result out of what you do with the port. Also the posi on of the port in the enclosure and surrounding areas and posi on in the trunk have notable impact. The load-through of rear seats are also uncalcubale as well size and construc on type of the car. This easy effect with different results. Please do NOT use carpet or cloth within the port or inside the enclosure. It has bad effects on the air flow. It is recommend to round up the ends of the port and ensure a glossy surface where ever the air moves inside the enclosure or port. The moving air mass will speed up and thank you by producing less side noises. You can also prevent the port itself from resona ng. The techniques are the same as you know from building enclosures or damping doors. You can use energy absorbing material or you can raise the s ffness of the port by bracing. To have your subwoofer system playing clear and acurate you must follow the idea of an acous cal "dead" workplace, with just the moving cone. First of all, the enclosure itself might be not rigid enough. In most cases you can raise the s ffness by implemen ng braces, that connect in best way four walls. Or at least s ff up the baffle against back-wall. You can build enclosures with wallthickness of many cen metres, but bracing will have same effect with less weight! Now, when your enclosure is s ff and rigid to save you against bomb a acks, you can put it in your trunk. Do not forget it is important to fix it in the trunk of your car. For further direc on consult an authorizied EXCURSION installa on specialst 3 If you are intending to use mul ple subwoofers in your system, EXCURSION recommends having seperate chambers for each subwoofer if the subwoofers will be operated by different amplified signals. This prevent possible cancella on. WARNING: The use of silicone rubber to seal in a speaker will void the Warranty! If sealing is needed to the speaker gasket, use caulking cord or vinyl weather strip. IMPORTANT: Never cut any metal that is an integral part of an automobile`s safety or structural support system. NOTE: EXCURSION strongly recommends that you operate the complete audio system at low volume before final installa on of your MXT Series Subwoofers. This will allow a trial listening test to set maximum volume without distor on. CAUTION: Make sure that all speaker wiring is fully protected from cu ng or wear. Any short circuits developing as a result could severaley damage the radio unit or amplifier. Make sure that all speaker wires easily reach the speaker terminals without stress on the wire or connectors. PREPARING FOR INSTALLATION Note: The tools listed below may be required for proper installa on. * An elec ric drill with drill bits * Phillips-head and standard screwdrivers * Crimping tool and needle-nose pliers * Silicon sealant or closed cell weather-stripping * Metal file, Hole saw, Tin Snips, Wire strippers INSTALLATION PRECAUTIONS Note: Proceed only if you are a qualified installer otherwise let your dealer do it. * Always wear protec ve eyewear when using tools * Turn OFF all stereo and other electrical devices before you begin * Disconenect the (-) nega ve lead from your vehicle`s ba ery. * Keep the speakers in the package un l final installa on. * Locate fuel lines, brake lines, oil lines, electrical cables when planning installa on. * Check to see clearance behind the moun ng surface before installing speakers. * When running speaker wires through sheet metal, be sure to use gromments to properly insualte the wires from metal edges. 4 EXCURSION SX R.v2 8-D2 SPECIFICATIONS 214*127 400 1000 88 49-300 Pulp in Matrix 4.0 mm W/RMS W/MAX SPLO HZ . kg Dual 2 Dual 1.85 Ohm Ohm 50.8 28 6 11 / 22 Aluminium Black OFC Copper 4 High Flux Ferrite 12.43 mm mm mm mm . . layers . N.A. Suspension Compliance Cms Mechanical Q Factor Qms Electrical Q Factor Qes Total Q Factor Qts Moving Mass Mms Eq.Cas Air Load( liters) VAS Resonant Frequency Fs Effective Piston Area SD 0.103 5.4 0.74 0.65 99.6 5.93 49 201.06 g Liter Hz cm� Ported 8" SPL Box : Ported 8" SQPL Box : Internal Volume: 30,3 Liter VB nett Volume: 26,6 Liter Port Diameter: 1x 100mm Port Length: 250mm F3: 41,9 Hz F3: 53,4 Hz Internal Volume: 20,8 Liter VB nett Volume: 16,0 Liter Port Height: 25 mm Port Wide: 238 mm Port Length: 359 mm F3: 44,1 Hz - FB: 54,4 Hz 5 EXCURSION SX R.v2 8-D4 SPECIFICATIONS 214*127 400 1000 88 48-300 Pulp in Matrix 4.0 mm W/RMS W/MAX SPLO HZ . kg Dual 4 Dual 3.8 Ohm Ohm 50.8 28 6 11 / 22 Aluminium Black OFC Copper 4 High Flux Ferrite 7.55 mm mm mm mm . . layers . N.A. Suspension Compliance Cms Mechanical Q Factor Qms Electrical Q Factor Qes Total Q Factor Qts Moving Mass Mms Eq.Cas Air Load( liters) VAS Resonant Frequency Fs Effective Piston Area SD 0.123 5.08 0.74 0.64 86.38 7.06 46 201.06 g Liter Hz cm� Ported 8" SPL Box : Ported 8" SQPL Box : Internal Volume: 30,3 Liter VB nett Volume: 26,6 Liter Port Diameter: 1x 100mm Port Length: 250mm F3: 41,9 Hz F3: 53,4 Hz Internal Volume: 20,8 Liter VB nett Volume: 16,0 Liter Port Height: 25 mm Port Wide: 238 mm Port Length: 359 mm F3: 44,1 Hz - FB: 54,4 Hz 6 EXCURSION SX R.v2 10-D2 SPECIFICATIONS 262*171 600 1500 89 39-300 Pulp in Matrix 7.0 mm W/RMS W/MAX SPLO HZ . kg Dual 2 Dual 1.9 Ohm Ohm 61.1 35 8 13.5 / 27 Aluminium Black OFC Copper 4 High Flux Ferrite 15.8 mm mm mm mm . . layers . N.A. Suspension Compliance Cms Mechanical Q Factor Qms Electrical Q Factor Qes Total Q Factor Qts Moving Mass Mms Eq.Cas Air Load( liters) VAS Resonant Frequency Fs Effective Piston Area SD 0.088 5.45 0.68 0.6 178.5 12.44 39 314.1 g Liter Hz cm� Ported 10" SPL Box : Ported 10" SQPL Box : Internal Volume: 42.8 Liter VB nett Volume: 38,8 Liter Port Diameter: 2x 75mm Port Length: each 240mm F3: 41,5 Hz F3: 49,4 Hz Internal Volume: 40 Liter VB nett Volume: 31,3 Liter Port Height: 38 mm Port Wide: 332 mm Port Length: 390 mm F3: 44,8 Hz - FB: 53 Hz 7 EXCURSION SX R.v2 10-D4 SPECIFICATIONS 262*171 600 1500 89 43-300 Pulp in Matrix 7.0 mm W/RMS W/MAX SPLO HZ . kg Dual 4 Dual 3.2 Ohm Ohm 61.1 35 8 13.5 / 27 Aluminium Black OFC Copper 4 High Flux Ferrite 9.08 mm mm mm mm . . layers . N.A. Suspension Compliance Cms Mechanical Q Factor Qms Electrical Q Factor Qes Total Q Factor Qts Moving Mass Mms Eq.Cas Air Load( liters) VAS Resonant Frequency Fs Effective Piston Area SD 0.093 5.5 0.759 0.66 142.4 13.03 43 314.1 g Liter Hz cm� Ported 10" SPL Box : Ported 10" SQPL Box : Internal Volume: 42.8 Liter VB nett Volume: 38,8 Liter Port Diameter: 2x 75mm Port Length: each 240mm F3: 41,5 Hz F3: 49,4 Hz Internal Volume: 40 Liter VB nett Volume: 31,3 Liter Port Height: 38 mm Port Wide: 332 mm Port Length: 390 mm F3: 44,8 Hz - FB: 53 Hz 68 EXCURSION SX R.v2 12-D2 SPECIFICATIONS 318*192 600 1500 90 31-300 Pulp in Matrix 7.4 mm W/RMS W/MAX SPLO HZ . kg Dual 2 Dual 1.9 Ohm Ohm 61.1 35 8 13.5 / 27 Aluminium Black OFC Copper 4 High Flux Ferrite 15.57 mm mm mm mm . . layers . N.A. Suspension Compliance Cms Mechanical Q Factor Qms Electrical Q Factor Qes Total Q Factor Qts Moving Mass Mms Eq.Cas Air Load( liters) VAS Resonant Frequency Fs Effective Piston Area SD 0.125 5.11 0.62 0.55 197.1 39.7 31 471.4 g Liter Hz cm� Ported 12" SPL Box : Ported 12" SQPL Box : Internal Volume: 60 Liter VB nett Volume: 50 Liter Port Height: 250 mm Port Wide: 100 mm Port Length: 300 mm F3: 53 Hz - FB: 60 Hz Internal Volume: 80 Liter VB nett Volume: 70 Liter Port Height: 250 mm Port Wide: 100 mm Port Length: 300 mm F3: 45 Hz - FB: 52 Hz 9 EXCURSION SX R.v2 12-D4 SPECIFICATIONS 318*192 600 1500 90 32-300 Pulp in Matrix 7.4 mm W/RMS W/MAX SPLO HZ . kg Dual 4 Dual 3.2 Ohm Ohm 61.1 35 8 13.5 / 27 Aluminium Black OFC Copper 4 High Flux Ferrite 9.0 mm mm mm mm . . layers . N.A. Suspension Compliance Cms Mechanical Q Factor Qms Electrical Q Factor Qes Total Q Factor Qts Moving Mass Mms Eq.Cas Air Load( liters) VAS Resonant Frequency Fs Effective Piston Area SD 0.133 5.29 0.71 0.62 174.2 42.2 32 471.4 g Liter Hz cm� Ported 12" SPL Box : Ported 12" SQPL Box : Internal Volume: 60 Liter VB nett Volume: 50 Liter Port Height: 250 mm Port Wide: 100 mm Port Length: 300 mm F3: 53 Hz - FB: 60 Hz Internal Volume: 80 Liter VB nett Volume: 70 Liter Port Height: 250 mm Port Wide: 100 mm Port Length: 300 mm F3: 45 Hz - FB: 52 Hz 610 EXCURSION 11 EXCURSION LIMITED WARRANTY POLICY EXCURSION Intl. offers limited warranty on EXCURSION products under normal use on the following terms: EXCURSION Speakers are to be free of defects in material and workmanship for a period of one year. This warranty applies only to EXCURSION products sold to consumers by Authorizied EXCURSION Dealers in Germany. Products purchased by consumers from an EXCURSION dealer in another country are covered only by that country�s Distributor and not by EXCURSION Intl. This warranty covers only the original purchaser of EXCURSION product. In order to receive service, the purchaser must provide EXCURSION with the receipt sta ng the consumer name, dealer, product and date of purchase. Products found to be defec ve during the warranty period will be repaired or replaced (with a product deemed to be equivalent) at Excursion`s discre on and will not be liable for incidental or consequen al damages. EXCURSION will not warranty this product under the following situa ons: * Speakers received with bent frames or water damages * Abuse such as holes in the cone, surround or ripped spider * Voice coil damage due to amplifier clipping or distor on * Product that has not been installed according to this owner manual Any implied warran es including warran es of fitness for use and merchantability are limited in dura on to the period of the express warranty set forth above. No person is authorizied to assume for EXCURSION any other liability in connec on with the sale of this product. Please call prior your authorizied EXCURSION dealer the product got purchased. In case they are not accessible call 0961-416-0420 for EXCURSION Customer Service. You must obtain an RA# (Return Authoriza on Number) to return any product to EXCURSION Intl. The RA number must be prominently marked on the outside of the shipping carton or the delivery will be refused. Please pack your return carefully! We are not responsibile for items damaged in shipping. Return the defec ve product along with a copy of the original dated retail sales receipt, plus 10,- EUR for handling and diagnos c evalua on to: EXCURSION Intl. - A Division of CHPW A n: Returns (RA# ........................ ) Neustaedter Str. 20 D-92685 Floss / Germany 142 ...is all you need x EXCURSION - A Division of CHPW All Rights reserved - Intl. Trademark No: 010 640 597 Friedrich-Ebert-Str. 42 - D-92637 Weiden / Germany Tel: (+49) 961-416 04 20 - Fax: (+49) 961-46 04 41 www.facebook.com/Excursion.us EASCA EUROPEAN AUTO SOUND ASSOCIATION
