Technical Data
Chapter Overview
The technical data contain the technical specifications of the converter, e.g., the ratings, sizes, and technical requirements, provisions for fulfilling the requirements for CE and other markings, and warranty policy.
Environmental Conditions
System Connections
| Parameter | Value |
|---|---|
| Voltage, 3-phase | 100 ... 1000 V acc. to IEC 60038 100 ... 690 V acc. to UL508c |
| Voltage deviation | IEC: -10% +15% continuous; ±20% short-time (0.5 to 30 cycles) UL: ±10% continuous; ±15% short-time (0.5 to 30 cycles) |
| Rated frequency | 50 Hz or 60 Hz |
| Static frequency deviation | 50 Hz ± 2%; 60 Hz ± 2 % |
| Dynamic frequency range | 50 Hz ± 5 Hz; 60 Hz ± 5 Hz |
| df/dt | 17 % / s |
Note: Special consideration must be taken for voltage deviation in regenerative mode.
Environmental Limit Values
| Parameter | Value |
|---|---|
| Permissible cooling air temp. at converter module air inlet | 0 ... +55°C |
| Permissible cooling air temp. with rated DC current | 0 ... +40°C |
| Permissible cooling air temp. with different DC current | +30 ... +55°C |
| Permissible cooling air temp. (Options) | 0 ... +40°C |
| Relative humidity (at 5...+40°C) | 5 ... 95%, no condensation |
| Relative humidity (at 0...+5°C) | 5 ... 50%, no condensation |
| Change of the ambient temp. | < 0.5°C / minute |
| Storage temperature | -40 ... +55°C |
| Transport temperature | -40 ... +70°C |
| Pollution degree (IEC/EN 61800-5-1) | 2 |
The drive must be installed in clean air according to enclosure classification. Cooling air must be clean, free from corrosive materials and electrically conductive dust.
Degree of Protection
| Parameter | Value |
|---|---|
| Converter module and options (IEC) | IP 00; acc. to IEC/EN 60529 |
| (line chokes, fuses, field exciters, etc.) | UL: open type acc. to UL 508c |
| Overvoltage category (all inputs) | III acc. to IEC 60664-1 |
| Protective class | I acc. to IEC 61800-5-1 |
Site Elevation
| Elevation | Current Reduction |
|---|---|
| < 1000 m above M.S.L. | 100%, without current reduction |
| > 1000 m above M.S.L. | with current reduction |
Permissible Supply Systems
- IT, TN, TT (neutral earthed)
- IT (corner earthed)
- TT (corner earthed)
Paint Finish
| Component | Color |
|---|---|
| Converter module body | RAL 7012 |
| Cover | RAL 9017 & RAL 9002 |
Note: If a FSPS-21 module is used, the storage and transport temperature is derated to -15 to 40°C at higher elevations and the atmospheric pressure of the module is limited to 70 to 106 kPa. For reference, see FSPS-21 manual.
Sound Pressure Level and Vibration
| Size | Sound pressure level Lp (1 m distance) | Vibration | |
|---|---|---|---|
| as module | enclosed conv. | ||
| H1 | 55 dBA | 68 dBA | 3 mm, 2-9 Hz |
| H2 | 55 dBA | 72 dBA | 1 g, 9 ... 200 Hz |
| H3 | 60 dBA | 78 dBA | |
| H4 | 66 ... 70 dBA, depending on fan | 77 dBA | 0,3 mm, 2-9 Hz |
| H5 | 75 dBA | 77 dBA | 0,1 g, 9 ... 200 Hz |
| H6 | 70 dBA | 78 dBA | |
| H7 | 69 dBA | 67 dBA | |
| H8 | 82 dBA | 80 dBA | |
North American Standards
In North America, the system components fulfill the requirements of the table below.
| Standards | Converter module | Enclosed converter |
|---|---|---|
| UL 61800-5-1 Power Conversion Equipment CSA C 22.2 No. 274-13 Industrial Control Equipment, Industrial Products | Available for converter modules including field exciter units. Types with UL mark: • see UL Listing www.ul.com / certificate no. E196914 • or on request | UL/CSA types: on request |
