WinCC V7.5 SP1 Architectures

unrestricted � Siemens 2019

siemens.de/wincc-v7

In addition to the standard WinCC packages in European version, SIMATIC WinCC V7.5 SP1 and SIMATIC WinCC V7.5 SP1 ASIA will be available at following WinCC V7.5 SP1 Options

� WinCC/Server V7.5 SP1 � WinCC/Redundancy V7.5 SP1 � WinCC/Archive V7.5 SP1 � WinCC/UserArchives V7.5 SP1 � WinCC/WebNavigator V7.5 SP1 � WinCC/DataMonitor V7.5 SP1 � WinCC/Connectivity Pack V7.5 SP1 � WinCC/Connectivity Station V7.5 SP1 � WinCC/WebUX V7.5 SP1 � WinCC/ODK V7.5 SP1 � WinCC/IndustrialDataBridge V7.5 SP1 � WinCC/Audit V7.5 SP1 � WinCC/SESV7.5 SP1 � WinCC/Calendar Scheduler V7.5 SP1 � WinCC/Event Notifier V7.5 SP1 � WinCC/Performance Monitor V7.5 SP1 � WinCC/ProAgent V7.5 SP1 � SIMATIC Energy Manager V7.2 � SIMATIC InformationServer 2014 SP3 upd4 � SIMATIC ProcessHistorian 2014 SP3 upd4

About the delivery or compatibility test of the following options will be informed separately � SIMATIC TeleControl
With the compatibility tool http://www.siemens.com/kompatool you could check the compatibility of the products.

unrestricted � Siemens 2019

Page 2

2019-12-16

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 � Overview

Standardfeatures
WinCC V7.5 SP1 � basic package

WinCC Server

WinCC Redundancy

WinCC WebNavigator/ WebUX

WinCC Userarchiv

WinCC TagLogging

WinCC AlarmLogging

Options / PM Add on

Process Historian 2014 SP3 upd4
or
PM-ANALYZE

Information Server 2014 SP3 upd4
or
PM-ANALYZE

Client/Serversolution

redundancy

work with Web-Clients

User data management

Archivtags

messagestags

Centralized data archiving

Reporting System

unrestricted � Siemens 2019

Page 3

2019-12-16

DI FA S MP PRO&SW 3

SIMATIC WinCC V7.5 SP1 / RT Professional WinCC Premium Add-ons for Process Management

The delivery and / or compatibility test of the following PM add-ons will be reported separately:

Efficient data management

Data consistency over the entire production process

PM-CONTROL PM-QUALITY

Flexible parameter managemnt and job control Batch-based archiving and reporting

Diagnostic management PM-MAINT PM-ANALYZE

Higher availability of machines and production plants Intelligent maintenance management system Efficient identification of weak points in the process + reporting

Open-mindedness PM-OPEN-EXPORT PM-OPEN-IMPORT PM-LOGON

Consolidation of automation and IT world Automatic export of process data Automatic import of messages and archive values Automatic registration, e.g.: via RFID

siemens.com/process-management
\\ww004.siemens.net\bu01$\NbgM\PROJ\PROMOTOREN_VM\VM_WARE_WORLD_WITHOUT_UCL\Inst_SW\2019_01_Install_PM_AddOn

unrestricted � Siemens 2019

Page 4

2019-12-16

DI FA S MP PRO&SW 3

Analysis + Reporting with PM-ANALYZE

Archiving, Display and analysis of alarms from several different systems in chronological order
� SIMATIC WinCC V7 � PCS7 � WinCC Comfort / RT Professional � WinCC Advanced � WinCC flexible � Event log of the operating system

� Database and archiving � Manual input values � Reporting with Microsoft Excel � Automatic report generation � Add-in for Microsoft Excel 2007, 2010, 2013, 2016
� Access to all process value and summarization archives
� Access to calculated values and key figures � Access to messages and operating actions

unrestricted � Siemens 2019

Page 5

2019-12-16

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 � Symbol explanations
WinCC single system

WinCC Server

WinCC Standard-Client

PC without WinCC

unrestricted � Siemens 2019

Page 6

2019-12-16

S7 system components
External database
Ex
z.B.: SQL, Oracle, Access
Ext
Software to be installed on the computer 1 2 3 ...
DI FA S MP PRO&SW 3

WinCC 7.5 SP1 news Basic information
� Notes on installation � Microsoft .NET Framework
Before installing WinCC, make sure the .NET Framework is enabled
� Installations-Medium from WinCC in the Delivery information � WinCC V7.5 SP1 SP1 � ,,Installation"
� WinCC V7.5 SP1 SP1 � ,,Additional Content" - SQL Server Management Studio
� The SQL Server Management Studio is no longer part of the SQL Server installation and can be found on the enclosed "Additional Content" medium.
� SIMATIC Net PC Software V16

unrestricted � Siemens 2019

Page 7

2019-12-16

DI FA S MP PRO&SW 3

Download Link for SCADA SSP only
\\ww004.siemens.net\bu01$\NbgM\PROJ\PROMOTOREN_VM\VM_WARE_WORLD_WITHOUT_UCL\Inst_SW\2019_11_Install_WinCC_V75_SP1 \\ww004.siemens.net\bu01$\NbgM\PROJ\PROMOTOREN_VM\VM_WARE_WORLD_WITHOUT_UCL\Inst_SW\2019_11_Install_WinCC_V75_SP1_Optionen

unrestricted � Siemens 2019

Page 8

2019-12-16

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 Compatibility and General

WinCC Server / single / Clients / WebClients
Support ONLY 64-bit operating systems
� Windows 7 SP1 (Professional, Enterprise und Ultimate)
� Windows10 (Professional, Enterprise) � Windows 10 LTSB 2015/2016, LTSC 2019 (64-Bit)
� Windows 8.1 (Professional, Enterprise) � Windows Server 2008 R2 Std SP1 (Standard + Enterprise Edition)
� Windows Server 2012 R2 64bit (Datacenter & Standard) � Windows Server 2016 (Datacenter & Standard) � Windows Server 2019 (Datacenter & Standard)

� includes more powerful SQL Server 2016 SP2 64bit

For WinCC WebNavigator and WinCC DataMonitor clients are also released
� Windows 7 SP1 Professional, Enterprise, Ultimate 32-Bit / 64-Bit ( but use if is possible Windows 10 *)

� Windows 8.1 Professional, Enterprise 32-Bit / 64-Bit

( but use if is possible Windows 10 *)

Release Notes �Support von MS Office 2013 (64bit) & Microsoft Office 2016 (64bit) �DataMonitor Excel Workbook Wizard nur Unterst�tzung von Office 32Bit Installationen

*) End of Support from windows 7 / 8.1 (14.01.2020 / 10.01.2023 )
unrestricted � Siemens 2019

Page 9

2019-12-16

DI FA S MP PRO&SW 3

WinCC 7.5 SP1 news Basic information
� General compatibility � For integrated operation in the SIMATIC Manager on an engineering station
compatible with � STEP 7 V5.6 HFx / SP1
� For industrial communication in combination with � SIMATIC Net V16
Notes on installation Compatible tested virus scanner � Trend Micro "OfficeScan" Client-Server Suite V12.0 � Symantec Endpoint Protection V14 (Norton Antivirus) � McAfee VirusScan Enterprise V8.8 � McAfee ePolicy Orchestrator (ePO) V5.3.1 � McAfee Agent V5.5 � McAfee Application Control V8.1 (Whitelisting) � Kaspersky Anti-Virus 2018 � Windows Defender (in the operating system contained version)

unrestricted � Siemens 2019

Page 10

2019-12-16

DI FA S MP PRO&SW 3

WinCC 7.5 SP1 news Basic information
� Release Notes & General Compatibility � For linked functionality with DataMonitor "Excel Workbook" Microsoft Excel is needed � Microsoft Office 2013 SP1 & 2016 32bit
� In order to call the online help of WinCC, it requires Microsoft Internet Explorer � Internet Explorer from V11.0 32-Bit
� Run on virtualization server ESXi 6.5, 6.7 & Hyper-V 2012/2016/2016
� The system requirements vary depending on the type of the selected WinCC installation and used Operating system. Support for all current IBM / AT PC platforms. WinCC always relies on current operating systems and high security requirements

unrestricted � Siemens 2019

Page 11

2019-12-16

https://support.industry.siemens.com/cs/ww/en/view/109745988

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 Upgrading WinCC licenses

WinCC V7.2

WinCC V7.3

WinCC V7.4

WinCC -V7.5 /
-V7.5SP1

� More favorable conditions if the customer already has the recent WinCC Version

Link to OSD

Online Software Delivery

cheaper in comparison with the DVD version

Link to the compatibility tool https://support.industry.siemens.com/cs/sc/2055/compatibilityTool

WinCC V7 upgrade

Upgrade RT-Version, V7.2/7.3 -> V7.5 SP1 Upgrade RT-Version, V7.4 -> V7.5 SP1 Upgrade Client RT-Version, V7.2/7.3 -> V7.5 SP1 Upgrade Client RT-Version, V7.4 -> V7.5 SP1 Upgrade RC-Version, V7.2/7.3 -> V7.5 SP1 Upgrade RC-Version, V7.4 -> V7.5 SP1 Upgrade Client RC-Version, V7.2/7.3 -> V7.5 SP1 Upgrade Client RC-Version, V7.4 -> V7.5 SP1 unrestricted � Siemens 2019

Page 12

2019-12-16

Bestellnummer DVD
6AV6381-2AA07-5AX3 6AV6381-2AA07-5AX4 6AV6381-2CA07-5AX3 6AV6381-2CA07-5AX4 6AV6381-2AB07-5AX3 6AV6381-2AB07-5AX4 6AV6381-2CB07-5AX3 6AV6381-2CB07-5AX4

Bestellnummer download
6AV6381-2AA07-5AK3 6AV6381-2AA07-5AK4 6AV6381-2CA07-5AK3 6AV6381-2CA07-5AK4 6AV6381-2AB07-5AK3 6AV6381-2AB07-5AK4 6AV6381-2CB07-5AK3 6AV6381-2CB07-5AK4

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 Compatibility and General (continued)
Side-by-side-Installation with other SIMATIC-Products � Compatible with STEP 7 V5.4/V5.5/V5.6, V10.5/V11/V12,V13,14,14SP1,V15,15.1,V16
WinCC flexible (from 2008) WinCC V7.5 SP1 SP1 can`t be installed together with WinCC Professional, WinCC Unified und WinCC V6 / V7.x.

� Remote-Software ( Link) � Remote Desktop Connection (RDP) in console mode (for WinCC clients release)
(If WinCC Server is running in service mode) � "RealVNC" Enterprise Edition V5.1.0

unrestricted � Siemens 2019

Page 13

2019-12-16

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 � Compatible operating systems

Windows
� 10

Server
Max. 3 Clients without redundancy

Single system

Client without Projekt

Client with Projekt

Windows Server
� 2012 R2 � 2016 � 2019 �

unrestricted � Siemens 2019

Page 14

2019-12-16

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 �

Recommended / Compatible Operating Systems for Web

Solutions

WebNavigator Client

DataMonitor Client

Windows

� 7 *) � 8.1 *) � 10

Windows Server
� 2012 R2 � 2016 � 2019

unrestricted � Siemens 2019

Page 15

2019-12-16

*) End of Support from windows 7 / 8.1 (14.01.2020 / 10.01.2023 )
DI FA S MP PRO&SW 3

WinCC V7.5 SP1� Lizenzen
RT- and RC-Lizenzen
WinCC differentiates between RT licenses (Runtime) and RC licenses (Runtime and Configuration) as well as the number of variables (tags).
RT licenses entitle you to unlimited use of WinCC in runtime.
The use of the editors is only possible in demo mode with a time limit.
� RC-Lizenzen berechtigen zum zeitlich unbegrenzten Einsatz von WinCC in Runtime und bei der Projektierung. RC licenses can be used locally or remotely. If an RC license is on a different computer, use is only permitted for the configuration. If you want to use Runtime, the RC license must be available locally or you also need an RT license.
How many external variables and archive tags are allowed for the configuration is shown by the number in the parenthesis, for example: Eg "WinCC RC (65536)". With this license, you can use up to 64 * 1024 external tags and up to 512 archive tags in runtime.
If you activate a project in which the number of external variables or archive variables exceeds the number of permitted variables, the demo mode is activated. The system then behaves as if the licenses were completely missing

unrestricted � Siemens 2019

Page 16

2019-12-16

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 Basic station � order number for SIMATIC WinCC V7.5 SP1...

WinCC V7.5 SP1 (RC = RT and Engineering (n tags) inkl. 512 archiv tags

description

Order number EU DVD

WinCC RC 128

6AV6381-2BM07-5AX0

WinCC RC 512

6AV6381-2BN07-5AX0

WinCC RC 2048

6AV6381-2BP07-5AX0

WinCC RC 8192

6AV6381-2BS07-5AX0

WinCC RC 65536

6AV6381-2BQ07-5AX0

WinCC RC 102400

6AV6381-2BT07-5AX0

WinCC RC 153600

6AV6381-2BU07-5AX0

WinCC RC 262144 WinCC RC Client

6AV6381-2BV07-5AX0 6AV6381-2CB07-5AX0

WinCC V7.5 SP1 Runtime (RT inkl. 512 archiv tags)

Online Software Download
6AV6381-2BM07-5AH0 6AV6381-2BN07-5AH0 6AV6381-2BP07-5AH0 6AV6381-2BS07-5AH0 6AV6381-2BQ07-5AH0 6AV6381-2BT07-5AH0 6AV6381-2BU07-5AH0 6AV6381-2BV07-5AH0 6AV6381-2CB07-5AH0

description
WinCC RT 128 WinCC RT 512 WinCC RT 2048 WinCC RT 8192 WinCC RT 65536 WinCC RT 102400 WinCC RT 153600 WinCC RT 262144 WinCC RT Client

Order number EU
DVD 6AV6381-2BC07-5AX0 6AV6381-2BD07-5AX0 6AV6381-2BE07-5AX0 6AV6381-2BH07-5AX0 6AV6381-2BF07-5AX0 6AV6381-2BJ07-5AX0 6AV6381-2BK07-5AX0 6AV6381-2BL07-5AX0 6AV6381-2CA07-5AX0

Online Software Download
6AV6381-2BC07-5AH0 6AV6381-2BD07-5AH0 6AV6381-2BE07-5AH0 6AV6381-2BH07-5AH0 6AV6381-2BF07-5AH0 6AV6381-2BJ07-5AH0 6AV6381-2BK07-5AH0 6AV6381-2BL07-5AH0 6AV6381-2CA07-5AH0

unrestricted � Siemens 2019

Page 17

2019-12-16

Order number DVD 6AV6381-2BM07-5AV0 6AV6381-2BN07-5AV0 6AV6381-2BP07-5AV0 6AV6381-2BS07-5AV0 6AV6381-2BQ07-5AV0 6AV6381-2BT07-5AV0 6AV6381-2BU07-5AV0 6AV6381-2BV07-5AV0 6AV6381-2CB07-5AV0
Order number ASIA DVD 6AV6381-2BC07-5AV0 6AV6381-2BD07-5AV0 6AV6381-2BE07-5AV0 6AV6381-2BH07-5AV0 6AV6381-2BF07-5AV0 6AV6381-2BJ07-5AV0 6AV6381-2BK07-5AV0 6AV6381-2BL07-5AV0 6AV6381-2CA07-5AV0
DI FA S MP PRO&SW 3

WinCC WebNavigator and DataMonitor V7.5 SP1 � Order number

WinCC WebNavigator (countable)
description WinCC WebNavigator � 1 Client WinCC WebNavigator � 3 Clients WinCC WebNavigator� 10 Clients WinCC WebNavigator � 30 Clients WinCC WebNavigator � 100 Clients WinCC WebNavigator Load Balancing WinCC WebNavigator Load Balancing Step Up WinCC WebNavigator Diagnostic Client

Order number DVD � EU 6AV6362-1AB00-0BB0 6AV6362-1AD00-0BB0 6AV6362-1AF00-0BB0 6AV6362-1AJ00-0BB0 6AV6362-1AM00-0BB0 6AV6362-1FA00-0BB0 6AV6362-1GA00-0BB0 6AV6362-1BA00-0BB0

Online Software Download � EU 6AV6362-1AB00-0AH0 6AV6362-1AD00-0AH0 6AV6362-1AF00-0AH0 6AV6362-1AJ00-0AH0 6AV6362-1AM00-0AH0 6AV6362-1FA00-0AH0 6AV6362-1GA00-0AH0 6AV6362-1BA00-0AH0

WinCC DataMonitor (countable)
description WinCC DataMonitor � 1 Client WinCC DataMonitor � 3 Clients WinCC DataMonitor � 10 Clients WinCC DataMonitor � 30 Clients

Order number DVD � EU 6AV6362-3AB00-0BB0 6AV6362-3AD00-0BB0 6AV6362-3AF00-0BB0 6AV6362-3AJ00-0BB0

Online Software Download � EU 6AV6362-3AB00-0AH0 6AV6362-3AD00-0AH0 6AV6362-3AF00-0AH0 6AV6362-3AJ00-0AH0

Order number DVD � ASIA 6AV6362-1AB00-0BB0 6AV6362-1AD00-0BB0 6AV6362-1AF00-0BB0 6AV6362-1AJ00-0BB0 6AV6362-1AM00-0BB0 6AV6362-1FA00-0BB0 6AV6362-1GA00-0BB0 6AV6362-1BA00-0BB0
Order number DVD � ASIA 6AV6362-3AB00-0BB0 6AV6362-3AD00-0BB0 6AV6362-3AF00-0BB0 6AV6362-3AJ00-0BB0

unrestricted � Siemens 2019

Page 18

2019-12-16

DI FA S MP PRO&SW 3

Integrated licensing concept NEW as of WinCC V7.4 / RT Professional V14

Web solutions with WebNavigator and WebUX
In the future, these SCADA options will have standardized MLFBs as of V7.4 or V14 and therefore there will no longer be any in-house MLFBs for WinCC V7.5 SP1 / RT Professional V16
Note: WebNavigator / DataMonitor licenses as of V7.4 can no longer be used for WinCC V7.3 WebNavigator / DataMonitor or older

Separate Web licenses

WebUX Operate Monitor

WebNavigator

unrestricted � Siemens 2019

Page 19

2019-12-16

Combined Web licenses
WebNavigator WebUX Operate
Monitor

Scalable web access Switching between two license models:
� Separate or combined Web-licenses WebUX Monitor Client (read only) WebUX Operate Client (read-write) Web Navigator Client (read-write)
Web Licenses are additive:
all WebClients = sum of the individual licenses (countable)
� (1, 3, 10, 30, 100 clients)
� Reserving licenses for users
� No update costs, because version-independent licenses (existing licenses remain valid after upgrade)
1x WinCC WebUX Monitor Client FREE!
DI FA S MP PRO&SW 3

WinCC WebUX V7.5 SP1 / WinCC RT Professional V16 Order number

WinCC WebUX (Monitor: Countable)

description WinCC WebUX Monitor 1 Client WinCC WebUX Monitor 3 Clients WinCC WebUX Monitor 10 Clients WinCC WebUX Monitor 30 Clients WinCC WebUX Monitor 100 Clients

Order number DVD � EU 6AV6362-2AB00-0BB0 6AV6362-2AD00-0BB0 6AV6362-2AF00-0BB0 6AV6362-2AJ00-0BB0 6AV6362-2AM00-0BB0

Online Software Download � EU 6AV6362-2AB00-0AH0 6AV6362-2AD00-0AH0 6AV6362-2AF00-0AH0 6AV6362-2AJ00-0AH0 6AV6362-2AM00-0AH0

Order number DVD � ASIA 6AV6362-2AB00-0BB0 6AV6362-2AD00-0BB0 6AV6362-2AF00-0BB0 6AV6362-2AJ00-0BB0 6AV6362-2AM00-0BB0

WinCC WebUX (Monitor and Operate: Countable)

description
WinCC WebUX Operate 1 Client WinCC WebUX Operate 3 Clients WinCC WebUX Operate 10 Clients WinCC WebUX Operate 30 Clients WinCC WebUX Operate 100 Clients

Order number DVD � EU 6AV6362-2BB00-0BB0 6AV6362-2BD00-0BB0 6AV6362-2BF00-0BB0 6AV6362-2BJ00-0BB0 6AV6362-2BM00-0BB0

Online Software Download � EU 6AV6362-2BB00-0AH0 6AV6362-2BD00-0AH0 6AV6362-2BF00-0AH0 6AV6362-2BJ00-0AH0 6AV6362-2BM00-0AH0

Please note the limited number of connections for Windows desktop operating systems

unrestricted � Siemens 2019

Page 20

2019-12-16

Order number DVD � ASIA 6AV6362-2BB00-0BB0 6AV6362-2BD00-0BB0 6AV6362-2BF00-0BB0 6AV6362-2BJ00-0BB0 6AV6362-2BM00-0BB0
DI FA S MP PRO&SW 3

WinCC V7.5 SP1? � In which use case V7 or RT Professional ?

Quantity structure
18 Server each with 64 Clients or 50 Multiclient
WinCC RT Professional V16 does not extend the range of functions
� No multiclient available � Extended archiving (database, size, etc. ...) � Dynamic properties in SVG graphics missing � WinCC V7 becomes the standard gateway for smart data in
cloud solutions Integrated communication with the cloud through the standardized MQTT protocol � WebUX (Faceplate) � Telecontrol Option missing MQTT � WinCC Audit

Distributed system architecture
� with Multi-Clients � WebNavigator Load balancing
Standard monitoring function
� System Tags for Performance Monitoring � Real-time information for archiving and communication
connections Efficient Engineering: � new Tag Simulator with significantly extended functionality � New Symbol Fonts for example "Font Awesome � Support of the S7-1500 R / H � Simulation of external Tags

unrestricted � Siemens 2019

Page 21

2019-12-16

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 � New: System diagnostics with performance tags
� To analyze the WinCC project, WinCC provides the system variables "@PRF _...". � This allows you to evaluate the time behavior of the server � The WinCC Tag Management creates the system tags when creating a WinCC project. As soon as you
create a new connection under a communication driver, additional performance variables are created for this connection.
Windows Performance Monitor

unrestricted � Siemens 2019

Page 22

2019-12-16

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 Scalability � Configuration principle and function tasks

Summery quantity structure � Following configurations were tested as typical scenarios

WinCC Server-Server communication

Quantity 18 Server

Comment
Connection to a multi-user system with MULIT-Clients has not been approved � One server can access the data from up to 17 other servers or redundant pairs of servers � The server accessing the data behaves as a client in respect of the configuration and operation,
except that a standard server cannot be configured

WinCC Server or redundant Server pairs
WinCC UNI-Clients (without their own project)

18 Servers 64 Clients

Access to a maximum of 18 WinCC servers or redundant server pairs from WinCC MULTI-Clients
Maximum of 64 WinCC UNI-Clients interconnect to one Server � Redundant server pairs are possible

WinCC MULTI-Clients (with their own project)
WinCC WebN.-Clients

50 Clients 150 Clients

Maximum of 50 WinCC MULTI-Clients in the WinCC distributed system � A maximum of 36 servers in the form of 18 redundant server pairs is possible

WinCC WebUX-Clients

100 Clients

As a typical scenario, we tested the simultaneous access of 100 WebUX clients to one WebUX server � 100 clients are not a "hard" system limit � it is technically possible to connect more than 100 clients simultaneously � The performance depends on the employed hardware and the volume of process data

unrestricted � Siemens 2019

Page 23

2019-12-16

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 Scalability Configuration principle & function tasks

Configuration of mixed systems (means minimum one UNI- & one MULTI-Client exist in the

system)

� Different quantity structures can be realized according to the type and number of client

types used.

�

Mixed

systems

are

possible,

meaning

the

parallel

use

of

clients

with

and

without

Web-Distributed Server-Client System

Web-Client

Web-Client

with web-solution Web-Client

Clients

within one client/server system.

...

� When configuring a mixed system, the following rule* of thumb should be observed to achieve the maximum quantity structures:

Client as Web-Server

� Each client type has one value: � WebNavigator-Client / Thin-Client = 1 WebUX-Client / MULIT & UNI-Client = 2 UNI-Client with the "Configure remote" function = 4 � The total of all values of all clients should not exceed 120 per server in the case of WinCC servers without operating function � In the case of servers with operating function, the total value should not exceed 32.

unrestricted � Siemens 2019

Page 24

2019-12-16

...
Server Multi-User Project
...

HTML 5 Client

...
DI FA S MP PRO&SW 3

WinCC V7.5 SP1 process communication

PROFIBUS-Network

WinCC V7.5 SP1 Ethernet-Network

E.g.: For more than 8 Ethernet connections: Ethernet-Karte des PC:
� SOFTNET-IE S7 V16 � 6GK1704-1CW16-0AA0
with CP � CP 1623 PCIe: 6GK1162-3AA00 � HARDNET-IE S7 V16 :
6GK1716-1CB16-0AA0

CP 5621 PCIe Softnet Grid size
� Protocol operating distance Multi Point Interface/PROFIBUS included in WinCC
CP 5613 A2 PCIe Hardnet Grid size
� Protocol operating distance Multi Point Interface/PROFIBUS a license is required

unrestricted � Siemens 2019

Page 25

2019-12-16

PC Ethernet Board

� Protocols 1200/1500, S7 TCP/IP, Ind. Eth

� Licences: Softnet S7 Lean/Basis included

in WinCC 8 connections max.

� 128 x S7-1500

connections max.

� 64 x S7-1200

connections max.

� 64 x S7-300/400

connections max.

� IF > 8 connections  Softnet-IE S7 license required

or

� CP 1623/1628 PCIe + Licences f�r Hardnet-IE S7

� (S7 1613) required

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 process communication

The included communication drivers do not require an additional license:

�Allen Bradley - Ethernet IP �Mitsubishi Ethernet / iQF PLC �Modbus TCP/ IP �OPC �OPC UA �PROFIBUS DP �SIMATIC 505 TCPIP

� SIMATIC S7 Protocol Suite � SIMATIC S7-1200, S7-1500 � SIMATIC TI Ethernet Layer 4 � SIMATIC TI Serial � SIMOTION � System Info

�SIMATIC S5 Ethernet Layer 4 �SIMATIC S5 Profibus FDL �SIMATIC S5 Programmers Port AS511 �SIMATIC S5 Serial 3964R

unrestricted � Siemens 2019

Page 26

2019-12-16

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 Extended support of the S7-1500 R / H
Increased availability and reliability through redundant automation systems with S7-1500R / H controllers

Communication with R / H Systems by using the "System IP Address"

unrestricted � Siemens 2019

Page 27

2019-12-16

For R / H (1st delivery level IM 155-6PN HF ET 200SP

DI FA S MP PRO&SW 3

WinCC V7.5 SP1 Communication S7-1500 H/R - with the System-IP
The System-IP has to be configured. The HMI-Connection will be configured with the IP-Address.

unrestricted � Siemens 2019

Page 28

2019-12-16

DI FA S MP PRO&SW 3

Single-user station � Monitoring/Operating from a single PC
Single-user station WinCC V7.5 SP1 engineering-Station + RT
1

Additional Information
Quantity: Process Variables: Up to 262 144 (depending on the license selected) Archiving variables: Max. 80 000 (based on the WinCC Tag Logging option) (Reminder: The WinCC V7.5 SP1 base includes 512 archiving variables)

unrestricted � Siemens 2019

Page 29

2019-12-16

1 WinCC V7.5 SP1

WinCC V7.5 SP1 RC / RT n

z.B.

� WinCC V7.5 SP1

128

� WinCC V7.5 SP1

512

� WinCC V7.5 SP1

2048

� WinCC V7.5 SP1

8192

� WinCC V7.5 SP1

65 536

� WinCC V7.5 SP1

102 400

� WinCC V7.5 SP1

153 600

� WinCC V7.5 SP1

262 144

SIMATIC Net V16

DI FA S MP PRO&SW 3

Redundant Single-user stations � 2 monitoring/operating stations with high availability

2

1

1

Redundant WinCC V7.5 SP1 single-user stations

1 WinCC V7.5 SP1
WinCC V7.5 SP1 RT n SIMATIC Net V16
2 WinCC Redundancy
MLFB: 6AV6371-1CF07-5AX0

Additional Information
Both stations work in parallel (both are connected to the process). In case of a breakdown of one of the 2 WinCC stations, the other takes over the archiving of messages, process Data and user archive data (Recipe). Automatic synchronization of all archives after resumption of normal operation.

unrestricted � Siemens 2019

Page 30

2019-12-16

DI FA S MP PRO&SW 3

redundant engineering single-user stations

engineering-

Station

1

3 redundante
WinCC V7.5 SP1
single-user stations

2 1

redundant WinCC V7.5 SP1 single-user stations

1 WinCC V7.5 SP1
WinCC V7.5 SP1 RT n SIMATIC Net V16
2 WinCC Redundancy
MLFB: 6AV6371-1CF07-5AX0

Please note
WinCC V7.5 SP1 RC license hast to be installed at one station to implement modifications (longer than 1h) to the WinCC project.

unrestricted � Siemens 2019

Page 31

2019-12-16

3 WinCC Engineering
WinCC V7.5 SP1 RC n
DI FA S MP PRO&SW 3

Multi-user stations � Central server with monitoring / operation stations � Standard client (UNI-Client)

2 WinCC

WinCC V7.5 SP1 Clients

2 WinCC

2 WinCC

13

...
WinCC V7.5 SP1 Server

1 � 64 WinCC UNI-Clients

Please note
A Standard Client has no WinCC project and is connected to a very specific server from which he retrieves data and views.

1 WinCC V7.5 SP1
WinCC V7.5 SP1 RT n SIMATIC Net V16
2 WinCC Client
MLFB: 6AV6381-2CA07-5AX0
3 WinCC Server
MLFB: 6AV6371-1CA07-5AX0

unrestricted � Siemens 2019

Page 32

2019-12-16

DI FA S MP PRO&SW 3

Multi-user stations � Central server with monitoring/operation station � MULTI-Clients

WinCC V7.5 SP1 Clients

2
MULTIClient

WinCC

2 WinCC

2 WinCC
...

13

WinCC V7.5 SP1 Server

13

WinCC V7.5 SP1 Server

1 � 50 WinCC Multi-Clients

Please note
A MULTI Client with their own WinCC project and is connected to a very specific server from which he retrieves data and views.

1 WinCC V7.5 SP1
WinCC V7.5 SP1 RT n SIMATIC Net V16
2 WinCC Client
MLFB: 6AV6381-2CA07-5AX0
3 WinCC Server
MLFB: 6AV6371-1CA07-5AX0

unrestricted � Siemens 2019

Page 33

2019-12-16

DI FA S MP PRO&SW 3

Multi-user stations with multi clients1) � Engineering � Deployment on the server

Case 1: The Engineering license is on the server. You can work directly on the project located on the server to make changes

2
StandardClients

WinCC

2 WinCC

2 WinCC
...

Remote Engineering Client

13 WinCC V7.5 SP1 RT Server

1 WinCC V7.5 SP1
WinCC V7.5 SP1 RT n
2 WinCC Client
MLFB: 6AV6381-2CA07-5AX0
3 WinCC Server

MLFB: 6AV6371-1CA07-5AX0

Please note: Differences relative to the preceding case
The Engineering license (RC) must be added on the server. In case of changes, some changes may require shutting down the server. Furthermore, any inadvertent error may cause the server to crash!

unrestricted � Siemens 2019

Page 34

2019-12-16

4 WinCC Engineering
RC Client : MLFB: 6AV6381-2CB07-5AX0
DI FA S MP PRO&SW 3

Multi-Client stations/Server with Redundancy � High availability

2
StandardClients

WinCC

Redundancy WinCC V7.5 SP1 RT servers

2 WinCC
13 4

2 WinCC

Engineering- WinCC 5 Station

...
13

1 � 64 WinCC Clients

1 WinCC V7.5 SP1
WinCC V7.5 SP1 RT n SIMATIC Net V16
2 WinCC Client
MLFB: 6AV6381-2CA07-5AX0
3 WinCC Server
MLFB: 6AV6371-1CA07-5AX0

Please note
Due to the redundancy of the servers, the Clients can continue to work in case of a server crash. The data are synchronized across the servers and the database is entirely replicated when operations return to normal.

4 WinCC Redundancy
MLFB: 6AV6371-1CF07-5AX0
5 WinCC Engineering
WinCC V7.5 SP1 RC n

unrestricted � Siemens 2019

Page 35

2019-12-16

DI FA S MP PRO&SW 3

Dedicated archives server (SIMATIC ProcessHistorian) � Data archiving

Access to short and long-term archiving

PH 2

Long-term archiving

WinCC

1

Single-user station

Short-term archiving

WinCC

The WinCC station has transparent access to the PH server archives (display of data in the trend and alarm objects) (no strings)

1 WinCC V7.5 SP1 basic package
WinCC V7.5 SP1 RT n SIMATIC Net V16
2 SIMATIC ProcessHistorian 2014 SP3 upd4
MLFB: 6AV6361-1AA01-4AA0
Operating system, MS SQL Server � Windows Server 2008 R2 SP1
64 Bit Standard/Enterprise � Windows Server 2012 R2 /2016
64 Bit Standard/Enterprise

Additional Information
Process Historian is installed only on one OS Server 2008 R2 SP1 or 2012 R2 /2016 . WinCC is not required (and must not be installed) on a PH server. The Alarm Logging and Tag Logging archives are transferred to the PH server in real time with a secure connection. If the communication is interrupted, the data is buffered on the WinCC computer (Store & Forward Cache)

unrestricted � Siemens 2019

Page 36

2019-12-16

DI FA S MP PRO&SW 3

Archive server (SIMATIC ProcessHistorian) � Centralized data archiving

WinCC 2

WinCC V7.5 SP1 Clients

WinCC 2

...
1)
136

4

PH 5
1)
136 WinCC V7.5 SP1 Servers

1 WinCC V7.5 SP1 basic package WinCC V7.5 SP1 RT n SIMATIC Net V16
2 WinCC Client MLFB: 6AV6381-2CA07-5AX0
3 WinCC Server MLFB: 6AV6371-1CA07-5AX0
4 WinCC Redundancy MLFB: 6AV6371-1CF07-5AX0

Additional Information
All archive tags and the messages of all servers are stored centrally on the PH server. The administration and configuration of the data is still carried out in WinCC, so a configuration in the PH is not necessary again. The clients transparently access the data of the servers and the PH server.

1) There is no archive license on the PH server. If required, the archive licenses are located on the affected servers and / or single-user computers

unrestricted � Siemens 2019

Page 37

2019-12-16

5 ProcessHistorian 2014 SP3 upd4 Basic Package MLFB: 6AV6361-1AA01-4AA0 6 WinCC Tag Logging � Optionally with> 512 archives Z. B.: for 5000 Archiv tags MLFB: 6AV6371-1DQ17-5BX0
DI FA S MP PRO&SW 3

SIMATIC ProcessHistorian � Redundancy � High availability archiving

WinCC 2

WinCC Clients

WinCC 2

...

136

4

PH Redudancy 5
1)
136
WinCC V7.5 SP1 servers

Additional Information
PH redundancy is based on SQL server replication mechanisms. Reminder: Switch-over to PH redundancy if a PH Single server is already present can be done with � a new PH single license � a PH Redundancy license (6AV6361-1BA01-4AA0)

1 WinCC V7.5 SP1 RT Basic
WinCC V7.5 SP1 RT n SIMATIC Net V16

2 WinCC Client MLFB: 6AV6381-2CA07-5AX0

3 WinCC Server MLFB: 6AV6371-1CA07-5AX0

4 WinCC Redundancy

MLFB: 6AV6371-1CF07-5AX0

5

Process Historian 2014 SP3 upd4 � Redundancy Complete

MLFB: 6AV6361-1AA01-4AA0

6 WinCC Tag Logging � optional if > 512 archives
E.g.: For 5,000 archive variables MLFB: 6AV6371-1DQ17-4BX0

unrestricted � Siemens 2019

Page 38

2019-12-16

DI FA S MP PRO&SW 3

SIMATIC Information Server � Web Reporting System

PC with HTML 5 Browser (and MS Office) Internet

12

WinCC V7.5 SP1

LAN

single system

with Web-reports

Additional Information
IS and DataMonitor can be installed and used on the same computer.
Standard- and user-sepcific reports (with report builder of MS SQL reporting services) Transparent accesses on WinCC Archive in excel and word (2007, 2010, 2013 and 2016)

unrestricted � Siemens 2019

Page 39

2019-12-16

1 WinCC V7.5 SP1 Basic WinCC V7.5 SP1 RT n SIMATIC Net V16 2 SIMATIC Information Server 2014 SP3 upd4
Basic package MLFB: 6AV6361-2AA01-4AH0 The basic package includes: � 1x data source access
(connection with a WinCC-database) � 3x client access
(three client-accesses at the same time)
DI FA S MP PRO&SW 3

SIMATIC Information Server � Web Reporting System

WinCC 2

WinCC V7.5 SP1 1

Server

3

WinCC Clients

WinCC 2

WinCC 2

WinCC 2

456

WinCC V7.5 SP1 Einzelplatz system
WinCC

Information Server

Additional Information
The client access- and data source access-licenses are required parallel. In our example there are max. four clients simultaneously and two WinCC-data sources.

1 WinCC V7.5 SP1 basic package

WinCC V7.5 SP1 RT n SIMATIC Net V16
2 WinCC Client
MLFB: 6AV6381-2CA07-5AX0

3 WinCC Server

MLFB: 6AV6371-1CA07-5AX0

4

WinCC IS 2014 SP3 upd4 basic package (enth�lt 3 Client-Access Lizenzen)

MLFB: 6AV6361-2AA01-4AH0

5 WinCC IS Client Access (1) MLFB: 6AV6361-2BD00-0AJ0

6 WinCC IS Datasource Access (2) MLFB: 2 x 6AV6361-2CD00-0AJ0

unrestricted � Siemens 2019

Page 40

2019-12-16

DI FA S MP PRO&SW 3

Analyse + Reporting with PM-ANALYZE installation variants

PM-ANALYZE Client with/without
WinCC Client)

* * The installation on a separate server requires a Microsoft SQL Server 2008, 2014, 2016 (32/64)
PM-ANALYZE Server (without WinCC)

unrestricted � Siemens 2019

Page 41

2019-12-16

WinCC Server
PM-AGENT
Distributed system

WinCC Comfort Panels OPC UA
DI FA S MP PRO&SW 3

Single-user station Web server � Remote monitoring/operation stations and display and analysis for Web client
1 WinCC V7.5 SP1 Basic

In using Internet Explorer or WinCC Viewer RT 1 � 150 Web-Clients Internet

WinCC V7.5 SP1 RT n SIMATIC Net V16
2 WinCC WebNavigator

12

WinCC V7.5 SP1 Single-user station RT Web Server

E.g.: For 3 Clients LAN MLFB: 6AV6362-1AD00-0BB0
2 WinCC DataMonitor

E.g.: For 1 Clients MLFB:6AV6362-3AD00-0BB0

Additional Information
WinCC/WebNavigator allows remote PC-stations to behave as monitoring/operating stations via a local Intranet or via the Internet. WinCC/DataMonitor serves to evaluate the real-time data, archives or alarms of the process and to Distribute them via an Intranet or Internet in Display mode only! In all cases, a Web license for n Clients allows n clients to log in at the same time to the WinCC Web server

and/or

unrestricted � Siemens 2019

Page 42

2019-12-16

DI FA S MP PRO&SW 3

Single-user station Web server � A particular case for 1 Web connection (WebNavigator diagnostics)

Internet

WebDiagnostics Clients 2

1

WinCCV7.5 SP1

Web Server

Single-user station

1 WinCC V7.5 SP1 Basic
WinCC V7.5 SP1 RT n SIMATIC Net V16
2 WinCC WebDiagnostics Client
MLFB: 6AV6362-1BA00-0BB0

Additional Information
In contrast to the preceding case, a token is assigned to a Web client station and only that station will be able to connect to the Web server (always via Intranet or Internet)
An additional diagnostic server license on the WebNavigator server is no longer necessary.

unrestricted � Siemens 2019

Page 43

2019-12-16

DI FA S MP PRO&SW 3

Single-user station Web server � Combination of WebNavigator and Diagnostic Client licenses

Internet

1 dedicated Web Client 3

12

Single-user station Web Server

1 WinCC V7.5 SP1 RT Basic
WinCC V7.5 SP1 RT n SIMATIC Net V16
2 WinCC WebNavigator
E.g.: For 3 Clients MLFB: 6AV6362-1AD00-0BB0
3 WinCC WebDiagnostics Client
MLFB: 6AV6362-1BA00-0BB0

Additional Information
In the case of 4 connections: It is possible to use a 3-connections package that allows for the connection of 3 standard clients with the addition of a 4th dedicated client with this Diagnostics license

unrestricted � Siemens 2019

Page 44

2019-12-16

DI FA S MP PRO&SW 3

Web-Solution 1: Web Solution based on (RDP-Clients) on Industrial ThinClient V3 / Thin Client V3 PRO
1 � 25 Thin Clients (RDP-Clients)

Web

Internet

Clients

3

1

WinCC V7.5 SP1 Web Server

2

Single-user station

By using the services of the Windows Server Terminal, it is possible to use the functions of the WebNavigator or DataMonitor for thin Clients (low resources and operating system not supported by WinCC) e.g.: SIMATIC webpanel (customiced Thin Client)

unrestricted � Siemens 2019

Page 45

2019-12-16

1 WinCC V7.5 SP1 basic package
WinCC V7.5 SP1 RT n SIMATIC Net V16
2 WinCC WebNavigator
Z.B.: f�r 10 Clients MLFB: 6AV6362-1AF00-0BB0
Or 2 WinCC DataMonitor
Z.B.: F�r 10 Clients MLFB: 6AV6362-3AF00-0BB0
3 Thin Client V3 / Thin Client V3 PRO
6AV6646-1BA15-0AA0 SIMATIC ITC1500 V3 6AV6646-1BA15-0NA0 SIMATIC ITC1500 V3 6AV6646-1BA18-0AA0 SIMATIC ITC1900 V3 6AV6646-1BA18-0NA0 SIMATIC ITC1900 V3 6AV6646-1BA22-1AA0 SIMATIC ITC2200 V3 6AV6646-1BA22-1NA0 SIMATIC ITC2200 V3
DI FA S MP PRO&SW 3

Web Solution 2: Operator control and monitoring of WinCC systems with HTML 5 browser (Tablet / PC / WebPanel)
1

WinCC V7.5 SP1 Basispaket

Internet

WinCC V7.5 SP1 RT n
SIMATIC Net V16 3

3 any WebUX-Clients

Webserver-

1

Stand-alone

2

system

Additional Information WebPanel IWP (Linux based software ) Integrated current Chromium Browser v66 (perfect for WebUX) The IWP software supports different hardware architect (Basic Panels / ITC /IPC)

2

WinCC WebUX

z. B.: WebUX Operate 3 Clients MLFB: 6AV6362-2BD00-0BB

3

WebPanel (IWP)

Attention: Standard ThinClient V3 uses a Mozilla Firefox browser that is not optimal for WebUX

Please order the new WebPanel based on Thin Client V3 with the new Google Chrome browser
*) WebPanel (IWP) available from Q1/2020

unrestricted � Siemens 2019

Page 46

2019-12-16

DI FA S MP PRO&SW 3

Virtualization for the clients and/or WinCC Servers

Beispiel Virtuelle WinCC Clients on Hypervisor
2 2 2

Thin Clients via remote access to the WinCC clients of the host machine

1

WinCC V7.5 SP1

3

Server

WinCC clients run with the hypervisor system. That WinCC systems run like a normal applicationin virtual machines. WinCC itself can not be a virtual system on a hypervisor, but always requires a Windows VM. WinCC servers can also be operated with the hypervisor system. The number of WinCC clients / servers depends on the physical resources of the host computer

unrestricted � Siemens 2019

Page 47

2019-12-16

1 WinCC V7.5 SP1 basic package
WinCC V7.5 SP1 RT n SIMATIC Net V16
2 WinCC Client
MLFB: 6AV6381-2CA07-5AX0
3 WinCC Server
MLFB: 6AV6371-1CA07-5AX0
DI FA S MP PRO&SW 3

WinCC V7.5 SP1 User archiv � User data management

WinCC 2

WinCC Clients WinCC 2

...

1

WinCC V7.5 SP1

3

Server

4

WinCC 2

WinCC user archive allows a user to manage his archives in the form of tables; E.g.: Management of recipes � management of batch parameters, etc. The user archive license is on the server. The user archive component is installed for each Client but no user archive license is required for these customers.

unrestricted � Siemens 2019

Page 48

2019-12-16

1 WinCC V7.5 SP1 RT Basic
WinCC V7.5 SP1 RT client SIMATIC Net V16
2 WinCC Client
MLFB: 6AV6381-2CA07-5AX0
3 WinCC Server
MLFB: 6AV6371-1CA07-5AX0
4 WinCC Userarchiv
MLFB: 6AV6371-1CB07-5AX0
DI FA S MP PRO&SW 3

WinCC Archive � archive tags

WinCC 2

WinCC Clients WinCC 2

...

1

WinCC V7.5 SP1

3

Server

4

WinCC 2

1 WinCC Runtime
WinCC V7.5 SP1 RT n
2 WinCC Client
MLFB: 6AV6381-2CA07-5AX0
3 WinCC Server
MLFB: 6AV6371-1CA07-5AX0

With WinCC archive, the number of archive tags can be increased. The base license is valid for 512 archive tags. The archive license is located on the server. Licenses are countable (which become 512 archive variables of the base package not added to the 5000 archive tag package) You can increase the number of archive tags that need to be licensed by combining several packages

unrestricted � Siemens 2019

Page 49

2019-12-16

4 WinCC Archive
Z.B.: 1500 archive variables MLFB: 6AV6371-1DQ17-5AX0 Z.B.: 5000 archive variables MLFB: 6AV6371-1DQ17-5BX0
DI FA S MP PRO&SW 3

Functional differences of WinCC RT Professional V16 und WinCC 7.5 SP1

Functions

WinCC RT Professional V16

WinCC V7.5 SP1

PowerTags

ES: 512, 4k, max. RT: 128, 512, 2k, 4k, 8k, 64k1,, 100K, 150K, 265k

RC: 128, 512, 2k, 8k, 64k, 100K, 150K, 256k RT: 128, 512, 2k, 8k, 64k, 100K, 150K, 265k

Screens / screen objects

No limit / no limit

No limit / no limit

Alarms

150,000

150,000

Server/client

256 alarm classes, 32 types in groups, 17 alarm priorities
1 server / 32 clients

256 alarm classes 17 alarm priorities (0 to 16)
18 servers / 64 clients 50 multi-clients

Trends *) 500/ 512 archive tags incl.
Recipes **)
WebNavigator WebUX

max. 80,000 (server)
Recipes: No limit / Elements per recipe: 500 / 1 000000 fields Records per archive: 10 000
max.150 clients max.100 clients

max. 80,000 (server)
Recipes: No limit / Elements per recipe: 500 / 1 000000 fields Records per archive: 10 000
max.150 clients max.100 clients

PLC connections

Up to 128 connections,

-max. 128 x S7-1200 / S7-1500 Connections

-max. 64 x S7-300 / 400

Connections

128 x S7-1500/ 32 x S7-1200 / 64 x S7-300/400

*) V7.x: Archive tags

Max. 80,000 tags (32-bit OS) / 260,000 tags (64-bit OS) in a project (incl. logging tags)

**) V7.x: UserArchives

Max. 320,000/640,000 screen objects in a project (32-bit OS/64-bit OS)

unrestricted � Siemens 2019

Page 50

2019-12-16

DI FA S MP PRO&SW 3

Functional differences of WinCC RT Professional V16 und WinCC 7.5 SP1

Communication MPI / PROFIBUS OPC UA
SIMOTION SINUMERIK Allen Bradley Modicon Mitsubishi IEC Client DNP3 MQTT

WinCC Professional V16 Yes OPC UA Server : DA, HAD, A&C (Alarm & Condition) UA Client (DA) Via OPC UA NO Ethernet/IP Modbus (TCP) MC TCP/IP NO NO NO

unrestricted � Siemens 2019

Page 51

2019-12-16

WinCC V7.5 SP1 Yes UA Server: DA, HAD, A&C (Alarm & Condition) UA Client (DA / A&C) Yes Add-on Ethernet/IP Modbus (TCP) i-QR PLCs IEC 61850 (Add-on) Option Telecontrol WinCC Cloud Connect
DI FA S MP PRO&SW 3

Packages
SIMATIC IPC and SIMATIC Software
+Best State of the art technology
+SIMATIC WinCC Software

Packages
Available for all SIMATIC IPCs that meet the SCADA requirements 2 x order numbers: � 1 x for the IPC and � 1 x for the software Price advantage with simultaneous ordering of the - SIMATIC IPC and the WinCC software

unrestricted � Siemens 2019

Page 52

2019-12-16

DI FA S MP PRO&SW 3

IPC-Package

description
WinCC-IPC-Package V7.5 SP1, RT Client WinCC-IPC-Package V7.5 SP1, RT 128 WinCC-IPC-Package V7.5 SP1, RT 512 WinCC-IPC-Package V7.5 SP1, RT 2048 WinCC-IPC-Package V7.5 SP1, RT 8192 WinCC-IPC-Package V7.5 SP1, RT65536

description
WinCC-IPC-Package V7.5 SP1, ASIA , RT Client WinCC-IPC-Package V7.5 SP1, ASIA , RT 128 WinCC-IPC-Package V7.5 SP1, ASIA , RT 512 WinCC-IPC-Package V7.5 SP1, ASIA , RT2048 WinCC-IPC-Package V7.5 SP1, ASIA , RT8192 WinCC-IPC-Package V7.5 SP1, ASIA , RT65536

unrestricted � Siemens 2019

Page 53

2019-12-16

Order number
6AV6382-2AA07-5AX0 6AV6382-2CA07-5AX0 6AV6382-2DA07-5AX0 6AV6382-2EA07-5AX0 6AV6382-2HA07-5AX0 6AV6382-2FA07-5AX0
Order number
6AV6382-2AA07-5AV0 6AV6382-2CA07-5AV0 6AV6382-2DA07-5AV0 6AV6382-2EA07-5AV0 6AV6382-2HA07-5AV0 6AV6382-2FA07-5AV0

DI FA S MP PRO&SW 3

Promoters Selection Guide � Software packages for SIMATIC IPCs

2x7D/E

WinCC flexible RT

WinCC RT Advanced

4x7D

WinCC RT Professional
client

WinCC V7.x client

6x7 / 8x7 C

647 / 847 C/D 547E/G 347E

unrestricted � Siemens 2019

Page 54

2019-12-16

DI FA S MP PRO&SW 3

Promoters Selection Guide � Software packages for SIMATIC IPCs

2x7E

WinCC flexible RT

WinCC RT Advanced

377E

Additional information
WinCC RT Professional
client
client

WinCC V7.x client client

ITP1000

647 / 847E

127E

Only for german SCADA SSP

\\ww004.siemens.net\bu01$\NbgM\PROJ\PROMOTOREN_VM\VM_Ware\2019_10_Image_IP127E_Wind10WinCCV75 upd4
unrestricted � Siemens 2019

Page 55

2019-12-16

DI FA S MP PRO&SW 3

Thank you for your attention!

unrestricted � Siemens 2019

Page 56

2019-12-16

Subject to changes and errors. The information given in this document only contains general descriptions and/or performance features which may not always specifically reflect those described, or which may undergo modification in the course of further development of the products. The requested performance features are binding only when they are expressly agreed upon in the concluded contract.
All product designations, product names, etc. may contain trademarks or other rights of Siemens, its affiliated companies or third parties. Their unauthorized use may infringe the rights of the respective owner.

siemens.de/wincc-v7

DI FA S MP PRO&SW 3
