Variable Refrigerant Flow System HEAT PUMP & HEAT RECOVERY VRF CATALOGUE FUJITSU GENERAL AUSTRALIA Circular Flow Cassette DESIGNED for COMFORT AIRSTAGETM J-IIIL 14 / 16 HP model AIRSTAGETM VR-II 8 HP model 2 The AIRSTAGETM series provides high energy savings, comfort, and reliability to the end user. Design, installation, and servicing are highly flexible and simple. We offer an abundant VRF system lineup to match regional and local customer needs with a range of combinations from low to high capacity. For Residential & Light Commercial Heat Pump type 8 HP - 12 HP 3 Models / 3 phase 14 HP - 16 HP 2 Models / 3 phase Heat Pump type 4 HP - 6 HP 3 Models / Single phase Heat Pump type 4 HP - 6 HP 3 Models / Single phase For Commercial Heat Recovery Modular type for simultaneous heating and cooling operation 8HP - 48HP 33 models � Space saving combinations: 8 HP to 48HP / 21 models � Energy efficiency combinations: 16HP to 42HP / 12 models Heat Pump Modular type 8HP - 48HP 33 models � Space saving combinations: 8 HP to 48HP / 21 models � Energy efficiency combinations: 16HP to 42HP / 12 models Contents 004 FLEXIBLE SOLUTIONS 006 LIGHT COMMERCIAL SOLUTIONS 010 COMMERCIAL SOLUTIONS 014 AIRSTAGETM CORE TECHNOLOGY 016 HIGH ENERGY EFFICIENCY 018 MAXIMISED COMFORT 020 CONSISTENT RELIABILITY 022 DESIGN FLEXIBILITY 024 EASY INSTALLATION 026 EASY SERVICE & MAINTENANCE 028 AIRSTAGETM SERIES 030 AIRSTAGETM LINEUP 032 HEAT PUMP TYPE AIRSTAGETM J-IIS 036 HEAT PUMP TYPE AIRSTAGETM J-III 040 HEAT PUMP TYPE AIRSTAGETM J-IIIL 046 HEAT PUMP TYPE AIRSTAGETM V-III 052 HEAT RECOVERY TYPE AIRSTAGETM VR-II 060 AIRSTAGETM INDOOR UNITS 062 INDOOR UNITS LINEUP 064 4-way Flow Compact Cassette 066 4-way Flow Cassette 068 Circular Flow Cassette 070 Mini Duct 072 Slim Duct / Slim Concealed Floor 074 Medium Static Pressure Duct 076 High Static Pressure Duct 078 Compact Floor 080 Floor / Ceiling 082 Ceiling 084 Wall Mounted (EEV Internal / external) 090 VENTILATION 092 Energy Recovery Ventilator 094 Outdoor Air Unit 096 AIRSTAGETM CONTROL SYSTEMS 098 OPTIMISED CONTROL SOLUTIONS 100 CONTROL SYSTEM OVERVIEW 102 COMPARISON TABLE OF CONTROLLERS 104 INDIVIDUAL CONTROLLER 109 CENTRALISED CONTROLLER 118 CONVERTOR / ADAPTOR 124 AIRSTAGETM OPTION 126 External Power Supply Unit 127 Auto Louvre Grille Kit 128 CONTROL SYSTEM LIST 130 OPTIONAL PARTS LIST 132 OPTIONAL PARTS 136 EXTERNAL INPUTS AND OUTPUTS 138 PIPING AND REFRIGERATION ACCESSORIES 140 ABOUT US 142 OUR HISTORY 144 WORLD WIDE LOCATIONS 146 PROJECT REFERENCES 148 GLOBAL DEVELOPMENT AND PRODUCTION BASES 150 HIGH QUALITY DEVELOPMENT AND PRODUCTION FACILITIES 152 SUPPORT 154 AIRSTAGETM SUPPORT 156 AIRSTAGETM / RAC SUPPORT TOOL 158 QUICK SERVICE AND MAINTENANCE 160 SERVICE TOOL 161 WEB MONITORING TOOL 3 AIRSTAGETM Solutions FLEXIBLE SOLUTIONS Fujitsu General has been developing and manufacturing high quality and energy efficient products for more than 35 years. Using the latest Japanese technology and state of the art expertise, our products have been designed in accordance with our aim of creating the most comfortable environment possible, regardless of the project type or design. AIRSTAGETM Series Consistent Reliability High Energy Efficiency THE TOTAL SOLUTION Comfort Maximised Design Flexibility Easy Installation, Service and Maintenance Property Suitability RESIDENTIAL & LIGHT COMMERCIAL Fujitsu General offers a diverse range of air conditioning systems focused on residential and small sized buildings. COMMERCIAL Fujitsu General provides single and modular type VRF systems with efficient operation, comfort, design flexibility, easy installation and consistent reliability. 4 5 Light Commercial Solutions SMALL OFFICES Fujitsu General provides a wide range of solutions designed to meet the needs of a small building. With energy saving features, low noise design and centralised control, this range is sure to meet your light commercial projects requirements. Energy saving solutions suitable for meeting rooms and business private offices Energy saving features can be utilised with the human sensor feature and external input / output kit. This means unecessary power consumption will be prevented when no movement is detected in the room. Compact outdoor unit with low noise This compact outdoor unit achieves significant space saving, meaning you can install it on a rooftop or in a plant area. Low noise operation is possible at night by utilising low noise mode. 6 J-IIIL Series Up to 16 HP using the compact outdoor unit The J-IIIL Series is suitable for the buildings with multiple small rooms. Max. 30 indoor units can be connected. Even airflow throughout your space The Circular Airflow Cassette creates a consistent and even temperature via multi-directional airflow functionality. Each louvre can be set individually by the controller* to prevent people from being exposed to direct airflow. Energy saving operation commences when there are no occupants by linking up with the human sensor option. The unit will adjust its operation depending on the presence of occupants within a given room. The human sensor detects movement and activates or deactivates energy saving modes accordingly. 8.8m 3.2m Indoor units Human sensor (option) Centralised control of both air conditioning and third party equipment It is possible to perform centralised control of third party equipment in addition to air conditioners. This is useful in allowing whole building energy saving management and control. System Controller UTY-APGXZ1 VRF indoor units Wall Mounted Extensive range of low capacity indoor units to suit small rooms or spaces. Floor Duct Cassette *Touch panel wired RC (UTY-RNRYZ3) Third party equipment Lightning Ventilation Energy Recovery Ventilator 7 Light Commercial Solutions SHOPS, RESTAURANTS & MIXED USE DEVELOPMENTS J-IIS Series Purpose built and tenant friendly solutions for small commercial complexes. High Static Pressure Duct Air conditioning options for open areas Large duct system suitable or appropriate for high ceiling and large open spaces COMPLEX BUILDING Centralised control Temperature management of each room and one week operation control management / settings are supported easily. This controller makes energy saving management possible with upper / lower temperature limit settings and operation prohibited settings. Control and monitoring The controller allows high visibility and easy operation as all settings are accessible from the main screen. The controller can be monitored remotely using a tablet or smart phone through a web browser to show detailed information of an error status and the ability to view key sensor values for troubleshooting. Change Items Central Remote Controller UT Y-DCGY Z1 LAN PC Wireless LAN Router Fixed IP, IP forwarding and open Port required INTERNET Tablet PC Smart phone SHOPS RESTAURANT 8 Circular Flow Cassette Uniform air distribution for large areas Air distribution design allows for circular airflow to spread to every corner of the room. Capable of cooling in low ambient conditions Low outside air temperature cooling operation is necessary in winter in stores with a lot of heat inside. Our air conditioning systems allow flexibility supporting cooling operation at -15�C. 0-150 Pa Medium Static Pressure Duct 9 Commercial Solutions HOTELS & APARTMENTS Fujitsu General provides energy saving air conditioning systems offering flexible installation and cutting edge design solutions for hotels and apartments that also take into account comfort, efficiency, external appearance, and system safety features. Simultaneous cooling and heating The VR-II heat recovery series functionality allows simultaneous cooling and heating operation, with a maximum outdoor capacity of 48HP. Smart and cutting edge design. Extensive lineup from 8 HP to 48 HP in 2 HP increments. Connectable indoor unit capacity ratio of 50 to 150%. 8HP-48HP 33 models � Space saving combinations: 8HP to 48HP / 21 models � Energy efficiency combinations: 16HP to 42HP / 12 models Large area air conditioning for reception and lobby areas High Static Pressure Duct suitable for large spaces with high ceilings High Static Pressure Duct 10 Ventilation support Outdoor Air Units connect with the VRF system to meet ventilation requirements. Outdoor Air Unit Guest room air conditioning delivering excellent comfort, energy efficiency and easy installation Space saving Mini duct type with 198mm height and 450mm depth. This can be installed in narrow ceiling spaces. Mini Duct Centralised control Air conditioning in shared spaces such as waiting areas and hallways can be controlled centrally. Temperature and operating conditions can be managed without manual adjustment by guests. System Controller Comfortable airflow The optional Auto Louvre Grille Kit achieves comfortable airflow by adjusting the direction of airflow. Simple Remote Controller with sophisticated design Room card switch Using the room card prevents guests from forgetting to switch off the air conditioner when departing their room. Use of an external connection kit and a third party supplied room card switch. 11 Commercial Solutions LARGE BUILDINGS Fujitsu General provides modular VRF systems that are highly efficient, reliable and offer flexible installation for large or high rise buildings. Diverse lineup suitable to match your operating environment The VRF V-III series lineup is designed to meet various needs with energy efficient models. These units are compatible with high outdoor air ambient temperatures. Heat Pump Modular type for heating or cooling operation 8 HP - 48 HP 33 Models � Space saving combinations: 8 HP to 48 HP / 21 models � Energy efficiency combinations: 16 HP to 42 HP / 12 models Difference in height Up to 110 m The height difference between the outdoor unit and the indoor unit is usually 50 m for the V-III series, but by installing the pressure sensor kit it is possible to expand it to 110 m. (*This product can only be used connected to the V-III series.) Pressure Sensor Kit 12 Centralised control of both air conditioning and lighting* It is possible to centrally control lighting and ventilation equipment in addition to air conditioners. This is useful in allowing whole building energy saving management and control. System Controller (UTY-APGXZ1) System Controller Lite (UTY-ALGXZ1 & UTY-PLGXX2) *Requires a third party MODBUS DIDO device. 4-way Flow Cassette Improved airflow distribution The unique design of the louvres and added space between the chassis and ceiling maximises airflow distribution within the room. Front part Ceiling Bottom view Rear part Round louvre High ceiling mode This cassette can be installed up to a ceiling height o f 4.2m (36/45/54). High ceiling mode 4.2m 1m Standard mode 2m 3.2m 3m 4m VRF indoor units Under Ceiling Cassette Duct Facilities Lightning Ventilation Energy Recovery Ventilator BMS integration Major protocols including Modbus, BACnet, KNX and LonWorks are supported allowing Fujitsu AIRSTAGETM equipment to be easily integrated using one of our gateway options. 13 AIRSTAGETM CORE TECHNOLOGY HIGH ENERGY EFFICIENCY MAXIMISED COMFORT CONSISTENT RELIABILITY DESIGN FLEXIBILITY EASY INSTALLATION EASY SERVICE & MAINTENANCE 14 15 AIRSTAGETM CORE TECHNOLOGY HIGH ENERGY EFFICIENCY Energy Efficiency Comparison Operational efficiency has improved significantly through the new DC twin rotary compressor, inverter technology and large heat exchanger. 5 +12% 4 3.35 3 2.98 +19% 3.75 3.15 +35% 4.31 3.2 2 1 +31% 4.84 3.7 0 Heat Recovery (10HP) VR-II series Heat Pump (8HP) V-III series 16 New model Previous model EER COP +8% 3.71 3.45 +7% 4.23 3.95 Heat Pump (6HP) J-III series Performance and Control Room temperature set point limitation The minimum and maximum temperature ranges can be limited, which provides further energy saving functionality whilst maintaining the comfort of the occupants. Auto-off timer The new wired remote controller is equipped with an OFF timer function that automatically stops the units operation when a fixed time has elapsed from the start of operation. The schedule for the auto off timer can be programmed. (�C) 30 28 26 24 22 20 18 16 14 12 10 Original set temperature Heating Cooling Set point limitation setting Set interval time hour (17:00 to 24:00) ON Auto OFF 17:00 Set off time (30 to 240 minutes) OFF 24:00 Energy saving management A variety of energy saving operations can be set and managed depending on the season, weather and time period using the system controller and a third party watt hour meter. Energy management software(Option) System Controller Operational capacity Operation capacity can be set in 5 simple steps for rated capability. The power consumption at peak is cut down and the maximum load is suppressed. Setting range 100% 80% 60% 40% 0% Capacity Setting level Capacity save Time 17 AIRSTAGETM CORE TECHNOLOGY MAXIMISED COMFORT Auto change over function When the auto setting is selected, the unit automatically switches between cooling and heating modes according to the set temperature and room temperature. 2�C 0.5�C Set Temp. - 0.5�C - 2�C Cooling operation Heating operation time Cooling fan operation Heating fan operation Heating Dry Room A 24�C Room B 18�C Room C Room D 27�C OFF Room E 23�C Cooling Fan Individual rooms with automatic heating and cooling operation The auto change over setting allows for the product to easily switch between cooling and heating modes regardless of the operation mode of the other indoor units. This can be done via a specific indoor unit with a wired remote controller. This ensures comfortable operation all year round. *: Only available on VR-II Switching to cooling and heating mode with a specific remote controller in the main room, etc. 18 Precise refrigerant flow control Precise and smooth refrigerant flow control is achieved by using the DC Inverter control in conjunction with an individual indoor unit electronic expansion valve. This allows the set temperature to be controlled �0.5�C. High Set temp. Hot Hot Cold � 0.5�C Low Reach the set temperature quickly Thermal room temperature changes *Simulation in heating operation. Comfortable operation is achieved due to a small variation in room temperature. Quiet operation Low noise mode Two low noise modes can be selected automatically through the `quiet priority setting' and `capacity priority setting' depending on the noise or capacity requirements. This feature can be controlled via an outdoor unit external input and / or system controller. Quiet priority setting Air conditioning load factor Heat load Capacity 100% 0 Operating sound 58dB 0 down time Quiet priority low noise mode Quiet priority setting Air conditioning load factor Heat load Capacity priority Air conditioning load factor Capacity 100% 0 Operating sound 58dB 0 Capacity priority setting Air conditioning load factor down 100 Capacity time Quiet priority low noise mode Operating 58 sound Heat load Capacity 100% 0 Operating sound 58dB 0 Alternated automatically Reset automatically time Capacity priority low noise mode Non-stop oil recovery operation A comfortable room temperature is maintained during the oil recovery mode as the unit continues to operate without stopping the cooling or heating operation. *: Not available on the AIRSTAGE VR-II Previous model Operation stopped at oil recovery ON OFF V-III series (Heating operation) ON Time Non-stop oil recovery operation Time 19 AIRSTAGETM CORE TECHNOLOGY CONSISTENT RELIABILITY Backup operation If one compressor fails, backup operation will be performed by the remaining compressors*. * Note: Backup operation may not be possible depending on the system error. Outdoor unit rotational operation The compressor starting order is rotated so that the running time is shared. Rotation DC 1 DC 2 DC 3 DC 1 DC 2 DC 3 Rotation DC 1 DC 2 DC 3 Rotation Note: Rotational operation is alternated by the start / stop timing of the compressor. 20 Advanced refrigerant control Innovative compressor control logic has been introduced in order to balance the refrigerant mass flow rate of each outdoor unit by controlling the inverter speed. ON ON ON DC DC DC 1 2 3 Master Slave 1 Slave 2 Balanced operation condition Load level ON ON OFF DC DC DC 1 2 3 Master Slave 1 Slave 2 Unbalanced operation condition Liquid flow back protection Through a larger accumulator, the non vapourised refrigerant stays within the accumulator to ensure no liquid refrigerant is being fed into the compressor. Compressor Vapourised refrigerant From evaporator Large sized accumulator Liquid refrigerant (stays inside accumulator) Adoption of blue fin heat exchanger The corrosion resistance of the outdoor heat exchanger has been improved by the introduction of blue fin treatment. Blue fin heat exchanger Cobalt Blue protection Standard chromate protection Aluminium base material Hydrophilic coating 21 AIRSTAGETM CORE TECHNOLOGY DESIGN FLEXIBILITY Overall piping length 1,000m Actual pipe length 165m (VR-II, V-III) Pipe length from first separation tube to the farthest indoor unit 60m max. (VR-II) 90m* max. (V-III) * The limitation on the pipe length between the farthest indoor unit and the nearest indoor unit originated from the first separation tube must be 60m or less. Total pipe length 1,000m max. Height difference between outdoor and indoor units 50m max. For the outdoor unit installed below the indoor units: 40m max. (VR-II and V-III) Height difference 110m* max. * It is only when using the optional Pressure sensor kit. This product can be connected only to V-III series. Height difference between indoor units 15m max. (VR-II and V-III) High static pressure The outdoor unit can have a condenser hood easily connected with a static pressure up to 82Pa. This allows outdoor units to be installed within plant rooms in high rise buildings. Powerful discharge of air prevents a short-circuit. Previous model VR-II, V-III 80 Pa (VR-II) 82 Pa (V-III) Large diameter fan and DC motor has been utilised allowing an external static pressure up to 82Pa. This is approximately 2.6 times greater than the previous model. 22 High capacity connection 14HP-16HP AIRSTAGETM J-IIIL series Heat Pump type Connectable indoor unit capacity range 50% to 150% Connectable indoor unit number up to 30 4HP-6HP AIRSTAGETM J-IIS series Heat Pump type Connectable indoor unit capacity range 50% to 130% Connectable indoor unit number up to 8 8HP-12HP AIRSTAGETM J-IIIL series Heat Pump type Connectable indoor unit capacity range 50% to 150% Connectable indoor unit number up to 22 8HP-48HP AIRSTAGETM VR-II series Heat Recovery type Connectable indoor unit capacity range 50% to 150% Connectable indoor unit number up to 64 4HP-6HP AIRSTAGETM J-III series Heat Pump type Connectable indoor unit capacity range 50% to 150% Connectable indoor unit number up to 10 8HP-48HP AIRSTAGETM V-III series Heat Pump type Connectable indoor unit capacity range 50% to 150% Connectable indoor unit number up to 64 Wide operating range Installation in extreme temperature conditions is possible due to an increase in operational range. AIRSTAGETM J-IIIL series Heat Pump type (�C) 60 Cooling 50 46�C 40 30 20 10 0 -10 -20 -5�C *2 Heating 21�C -20�C AIRSTAGETM J-III series Heat Pump type (�C) 60 Cooling 50 46�C 40 30 20 10 0 -10 -5�C -20 Heating 21�C -20�C AIRSTAGETM J-IIS series Heat Pump type (�C) 60 Cooling 50 46�C 40 30 20 10 0 -10 -5�C -20 Heating 21�C -20�C AIRSTAGETM VR-II series Heat Recovery type (�C) 60 Cooling 50 40 46�C Cooling & Heating 30 21�C 20 10 0 -10 -20 -10�C -10�C Heating 21�C -20�C AIRSTAGETM V-III series Heat Pump type (�C) 60 Cooling 50 46�C 40 30 20 10 0 -10 -20 -15�C *1 Heating 21�C -20�C *1. Note: When a multiple outdoor unit connection is used, operating range is from -5�C to 46�C in cooling. *2. The cooling operation range of -15 to 46�C is allowed only when all of the indoor units connected to the system are higher than capacity of 5.6kW. 23 AIRSTAGETM CORE TECHNOLOGY EASY INSTALLATION Easily transported Easily craned using lifting belt hooks Design of outdoor unit allows for lifting straps to be used. Transporting by forklift Transport with forklift is possible. Can be transported in a small elevator Easy access By adopting an L-Shape front panel that can be removed, the work space for installation and service has been significantly improved by this new design. Flexible piping connection Piping and wiring are available to the front, rear, bottom and side. 24 Expansion of work space Removable front panel allows easy installation Flexible installation by 4 way pipe direction (J-IIIL is 3 way pipe direction.) Simple wiring Installation of the wiring is made easier as the communication wiring can be installed in a series or parallel configuration between the indoor, outdoor and RB units. or Parallel connection Serial connection Easy evacuation using vacuum mode function The vacuum mode function enables all expansion valves of the indoor units to be fully opened, making it easy to evacuate all the air inside pipe lines and indoor units. Air Air Outdoor unit Air Vacuum pump Automatic address setting* The address of the indoor unit, RB unit and signal amplifier can be set through the automatic function setting on the outdoor unit PCB. Automatic address setting is performed at outdoor unit Addresses are automatically distributed from outdoor unit. 1 Signal amplifier *Specific wiring method is required. RB unit 3 7 3 2 7 4 2 4 Manual address setting from indoor unit and remote controller is also possible 1 1 5 5 0 0 6 6 Easy commissioning using the Service Tool The service tool can be used to check system characteristics including the refrigerant temperature, pressure and the operating status of the electronic expansion valves, making it easy to determine whether the units are functioning correctly. 25 AIRSTAGETM CORE TECHNOLOGY EASY SERVICE & MAINTENANCE Easy maintenance design Self diagnosis can be performed using the LED display which makes it easy to check function setting status, refrigerant temperature, pressure, compressor operation time and other factors. Easy to read 7 segment LED : Provides detailed operational and error status without using any specific equipment. Movable PCB panel Easier for maintenance work behind the PCB 7 segment LED � Operation mode status � Discharge temperature / pressure status � Compressor operation indication � Address / type / number of outdoor units Error status can be checked easily via the indoor unit wired controller An error code is displayed on a liquid crystal screen. Wired Remote Controller Faulty unit number (Remote controller address) Error code SU MO TU WE TH FR SA Simple Remote Controller Remote controller address Error code Error status can be cheked easily by outdoor unit display Wired Remote Controller (Touch panel) Error status / Error history Error information Error code Abnormal indoor unit address 26 Error diagnosis using the Service Tool � Detail operation status and recent error history can be checked and analysed by using the Service Tool. Outdoor unit Transmission line Indoor unit Service Tool UTY-ASGXZ1 Software USB adaptor (Locally purchased) Remote monitoring The Web Monitoring system allows you to view system operation anytime over the internet in real time. Monitoring side Internet or public telephone line VRF Network system side Outdoor unit Transmission line USB adaptor (Locally purchased) Web Monitoring Tool Indoor unit 27 AIRSTAGETM SERIES 28 The 5 series of the AIRSTAGETM range has a total of 73 outdoor models to meet the project scope or building size requirements The AIRSTAGETM series outdoor units have been developed with structural designs and advanced inverter technology to provide higher efficiency. High durability technology has also been incorporated to ensure long-term use. AIRSTAGETM LINEUP HEAT PUMP TYPE AIRSTAGETM J-IIS HEAT PUMP TYPE AIRSTAGETM J-III HEAT PUMP TYPE AIRSTAGETM J-IIIL HEAT PUMP TYPE AIRSTAGETM V-III HEAT RECOVERY TYPE AIRSTAGETM VR-II 29 AIRSTAGETM Series AIRSTAGETM LINEUP Fujitsu General's range of AIRSTAGETM products allows installation flexibility to meet the unique size and application needs of your project. Outdoor units range HP kW class 4 5 6 8 10 12 14 16 18 20 12.1 14.0 15.5 22.4 28.0 33.5 40.0 45.0 50.4 55.9 Heat Pump AJT040LCLAH AJT045LCLAH AJT054LCLAH Heat Pump AJY040LBLAH AJY045LBLAH AJY054LBLAH Heat Pump Heat Pump Space saving High efficiency Heat Recovery Space saving High efficiency AJY072LELAH AJY090LELAH AJY108LELAH AJY126LELAH AJY144LELAH AJY072LALBH AJY090LALBH AJY108LALBH AJY126LALBH AJY144LALBH AJY162LALBH AJY180LALBH A J Y14 4L A LBHH A J Y180L A LBHH AJTA72GALH AJTA90GALH AJT108GALH AJT126GALH AJT144GBLH AJT162GALH AJT180GALH AJT144GALH AJT180GALHH 22 24 26 28 30 32 34 36 38 40 42 44 46 48 61.5 67.0 73.5 78.5 85.0 90.0 95.0 100.5 107.0 112.0 118.5 123.0 128.0 135.0 AJY198LALBH AJY216LALBH AJY234LALBH AJY252LALBH AJY270LALBH AJY288LALBH AJY306LALBH AJY324LALBH AJY342LALBH AJY360LALBH AJY378LALBH AJY396LALBH AJY414LALBH AJY432LALBH AJY216LALBHH AJY234LALBHH AJY252LALBHH AJY270LALBHH AJY288LALBHH AJY306LALBHH AJY324LALBHH AJY342LALBHH AJY360LALBHH AJY378LALBHH AJT198GALH AJT216GBLH AJT234GBLH AJT252GBLH AJT270GBLH AJT288GBLH AJT306GBLH AJT324GBLH AJT342GBLH AJT360GBLH AJT378GBLH AJT396GBLH AJT414GBLH AJT432GBLH AJT216GALHH AJT234GALHH AJT252GALHH AJT270GALHH AJT288GALHH AJT306GALHH AJT324GALHH AJT342GALHH AJT360GBLHH AJT378GBLHH 30 31 HEAT PUMP TYPE Fujitsu General provides air conditioning systems for a wide range of applications from small office buildings and stores to large houses. System Outline Space saving and low sound level design Compact design and high efficiency is realised by ALL-DC technology, large capacity DC twin rotary compressor and a 3-row heat exchanger Flexible systems for small and medium building air conditioning requirements Due to the compact size and flexible piping design, the J-IIS series can be installed easily in limited spaces, such as in homes, shops, and small offices. Multiple indoor units of various capacities and types can be connected. Large homes 32 System configuration example Outdoor unit Separation tube Header Liquid pipe Gas pipe Indoor unit Indoor unit Features Easy transportation and flexible installation Current model / 6HP class Height: 1334mm Weight: 117kg Model / 6HP class Height difference 998mm L25% Lightweight 87kg Advanced high efficiency technology Small and lightweight outdoor unit This model is much more compact than conventional 6HP comparable outdoor units. Even when installed on the balcony, it can fit within the height of the railing. The compact size, with a height of less than 1m, allows it to be installed in tight spaces High AEER* and ACOP* High average cooling and heating efficiency are significantly realised by utilising All DC inverter control, DC twin rotary compressor, and advanced airflow structure. AEER ACOP 4.07 3.78 3.61 3.16 3.10 2.63 3.14 3.15 3.25 6 HP Previous model 4 HP 5 HP 6 HP *AEER: Average Energy Efficiency Ratio *ACOP: Average Coefficiency Of Performance Large propeller fan High performance and low noise realised by the large propeller and angle optimisation. DC fan motor The outdoor unit utilises a miniaturised, high efficiency, multi-stage DC fan motor. Large heat exchanger Heat exchange performance is substantially improved by the use of a 3-row large heat exchanger. High heat transfer copper tube (improved lead angle) Smooth airflow grille The aerodynamic design enhances efficiency with little blow loss. DC inverter control Efficiency is improved through the new active filter module. Low noise rubber High efficiency compressor motor Optimised refrigerant flow design High precision parts Compact and high performance DC twin rotary compressor Efficiency is delivered in all load regions particularly when at low to medium load requirements. High Compressor efficiency Compressor capacity 100% High 33 Features Long piping capability Our advanced refrigerant control technology allows us to achieve a total refrigerant piping length of 80m. This opens up new possibilities in system design. Actual piping length 50m max. Total pipe length 80m max. Height difference between outdoor and indoor units 30m max. Piping length from first separation tube to the farthest indoor unit 40m max. Height difference between indoor and indoor units 15m max. Nonstop oil recovery operation A comfortable room condition is maintained during oil recovery mode because the product continues to operate without stopping the cooling or heating operation. Previous model *1 J-IIS series (Heating operation) Operation stopped at oil recovery Nonstop oil recovery operation ON ON OFF Time Time Easier installation With the connection check function it is possible to confirm whether the wiring connection and address settings are correct. � Displays connected indoor unit numbers � Duplicate set address numbers of indoor unit can be identified 34 Specifications Rating capacity range HP Model name Maximum connectable indoor unit 4 AJT040LCLAH 7 Power source Capacity Cooling Heating Input power Cooling Heating EER Cooling COP Heating Air flow rate Cooling Heating Sound pressure level Cooling Heating Heat exchanger fin Height Dimensions Width Depth Weight Refrigerant Type Charge Connection pipe diameter Liquid Gas Total pipe length Max. height difference Operation range Cooling Heating kW kW W/W m3/h (I/s) dB (A) mm kg kg mm m �C 12.1 13.6 3.44 3.09 3.52 4.40 4,040 (1,122) 4,040 (1,122) 51 54 Blue fin 998 970 370 86 R410A 4.0 9.52 15.88 80 30 -5 to 46 -20 to 21 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. 5 AJT045LCLAH 8 6 AJT054LCLAH 8 Single-phase, ~230V, 50Hz 14.0 16.0 4.23 3.93 3.31 4.07 4,200 (1,167) 4,200 (1,167) 53 55 Blue fin 998 970 370 86 R410A 4.0 9.52 15.88 80 30 -5 to 46 -20 to 21 15.1 16.5 4.58 4.11 3.30 4.01 4,540 (1,261) 4,200 (1,167) 56 56 Blue fin 998 970 370 87 R410A 4.0 9.52 15.88 80 30 -5 to 46 -20 to 21 These are the measured values in the manufacturer's anechoic chamber. Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here. Dimensions Models: AJT040LCLAH / AJT045LCLAH / AJT054LCLAH (Unit: mm) Top view Front view Side view Bottom view Detail A Rear view 35 HEAT PUMP TYPE Fujitsu General provides air conditioning systems for a wide range of applications from small office buildings and stores to large houses and apartments. System Outline High energy efficiency Heat pump inverter control is used to achieve efficient cooling or heating operation with any indoor unit combination. Flexible systems for small and medium size building air conditioning requirements The space saving design and long piping design allows flexible installation on roofs or balconies of small and medium size buildings. Multiple indoor units of various capacities and types can be connected. Small office 36 System configuration example � This system is typically used for small and medium-sized buildings � This example shows the connection of multiple indoor units using separation tubes and headers Outdoor unit Separation tube Header Liquid pipe Gas pipe Indoor unit Indoor unit Features Efficiency during operation The high COP is achieved for all models through a large heat exchanger, highly efficient DC twin compressor and our own technologies. High EER / COP Single phase 4.86 4.17 EER / COP 4.51 3.92 4.23 3.71 6HP class 8 % UP 3.71 3.45 7 % UP 4.23 3.95 4HP 5HP 6HP Advanced high efficiency technology J-II J-III J-II J-III Large propeller fan High performance and low noise is realised by the large propeller and angle optimisation. DC inverter control Efficiency is improved through the new active filter module. DC fan motor The outdoor unit utilises a miniaturised, high efficiency, multi-stage DC fan motor. Large heat exchanger Heat exchange performance is substantially improved by the inclusion of a 3-row large heat exchanger. High efficiency compressor motor Optimised refrigerant flow design High precision parts Subcool heat exchanger Cooling performance is improved from the dual tube heat exchanger. Effect Compressor efficiency Pressure DC twin rotary compressor Efficiency in all load regions is consistent, especially when meeting low to medium load requirements. High DC twin rotary compressor Compressor capacity High Cooling performance improved Enthalpy 37 Features Long piping capability Our advanced refrigerant control technology allows us to achieve a total refrigerant piping length of 180m, opening up new possibilities in system design. Actual piping length 120m max. Total pipe length 180m max. Height difference between outdoor and indoor units 50m max. For the outdoor unit installed below the indoor units: 40m max. Piping length from first separation tube to the farthest indoor unit 40m max. Height difference between indoor units 15m max. Nonstop oil recovery operation A comfortable room condition is maintained during oil recovery mode because the product continues to operate without stopping the cooling or heating operation. Previous model J-III series (Heating operation) Easier installation With the connection check function it is possible to confirm whether the wiring connection and address settings are correct. Operation stopped at oil recovery Nonstop oil recovery operation ON ON OFF Time Time � Connected unit indoor numbers are displayed � Duplicate address numbers of indoor unit can be identified 38 Specifications Rating capacity range HP Model name Maximum connectable indoor unit 4 AJY040LBLAH 1-8 Power source Capacity Cooling Heating Input power Cooling Heating EER Cooling COP Heating Air flow rate Sound pressure level / Power level Cooling Heating Heat exchanger fin Height Dimensions Width Depth Weight Refrigerant Type Charge Connection pipe diameter Liquid Gas Max. total pipe length Max. height difference Operation range Cooling Heating kW kW W/W m3/h(l/s) dB (A) mm kg kg mm m �C 12.1 13.6 2.90 2.80 4.17 4.86 6,200 (1,722) 50 / 66 52 / 68 Blue fin 1,334 970 370 117 R410A 4.8 9.52 15.88 180 -5 to 46 -20 to 21 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. The protective function may not work when using it outside the operation range. Dimensions Models: AJY040LBLAH / AJY045LBLAH / AJY054LBLAH 166 650 154 5 AJY045LBLAH 1-9 Single-phase, ~230V, 50Hz 14.0 16.0 3.57 3.55 3.92 4.51 6,400 (1,778) 51 / 67 53 / 69 Blue fin 1,334 970 370 117 R410A 5.3 9.52 15.88 180 50 / 40 (Outdoor unit: upper / lower) -5 to 46 -20 to 21 6 AJY054LBLAH 1-10 15.5 18.0 4.18 4.26 3.71 4.23 6,900 (1,916) 53 / 69 55 / 71 Blue fin 1,334 970 370 119 R410A 5.3 9.52 19.05 180 -5 to 46 -20 to 21 (Unit: mm) 43(Liquid) 51(Gas) (410) 40 370 32 1,334 21 36 970 32 370 12 Terminal blocks (Transmission) Terminal blocks (Power) 907 1,000 3-Way valve (Liquid) 3-Way valve (Gas) �28 (Cable port) 131 87 �28 (Cable port) 89 Pipe port A 25 50 95 279 (Liquid valve) 297 (Gas valve) 50 120 111 155 21 55 �28 (Cable port) �28 (Cable port) Pipe port 65 15 A Detail 50 �28 (Cable port) 21 65 �28 (Cable port) Pipe port 142 70 50 14 50 438 622 Pipe & cable port 39 341 305 227 HEAT PUMP TYPE Fujitsu General provides air conditioning systems for a wide range of applications from small office buildings and stores to large houses. System Outline Compact outdoor unit The compact design and low noise level allows the units to be installed in various locations with restricted and / or limited spaces, such as mechanical rooms and / or rooftops. Small room application Up to 30 indoor units can be connected due to the optimum heat exchanger structure. The J-IIIL series offers flexibility in design, particularly in instances where there are various small rooms present. Quiet design Through unit design and innovation we have developed a system that has low noise operation, whilst maintaining a comfortable environment. This potentially allows installation of units to various places without special sound prevention work. Small office 40 System configuration example � This system is typically used for small and medium-sized buildings � This example shows the connection of multiple indoor units using separation tubes and headers Outdoor unit Separation tube Header Liquid pipe Gas pipe Indoor unit Indoor unit Features Efficiency in actual operation Top class high EER / COP is achieved for all models by large heat exchanger, highly efficient DC twin compressor, and our own technologies. High EER / COP EER / COP (Max.Heating) 4.56 3.56 3.80 3.26 3.66 3.22 3.81 3.30 3.50 3.01 8HP 10HP 12HP 14HP 16HP Advanced high efficiency technology 570mm Large propeller fan High efficiency and low sound operation is achieved by the reduction of draft loss due to Fujitsu General's blade design and large diameter propeller fan. DC fan motor The outdoor unit utilises a miniaturised, high efficiency, multi-stage DC fan motor. Large heat exchanger Heat exchange performance is substantially improved by mounting a 2-row large heat exchanger. DC inverter control Efficiency is improved by the use of a new active filter module. 15-120 rps Pressure Subcool heat exchanger Cooling performance is improved by utilising a dual tube heat exchanger. Effect Cooling performance improved Enthalpy Scroll compressor The scroll compressor has a wide range of rotational frequencies from 15 to 120 rps. Fujitsu General's unique sensorless sine wave control method enables smooth control of the input power into the motor improving the energy efficiency operating characteristics and the low sound operation. 41 Features Fujitsu General provides perfect total air conditioning systems that take into account energy saving, low noise, comfortable airflow, small room application and centralised control for small-sized office buildings with many small rooms. Various installation options AIRSTAGETM V-III Series outdoor unit AIRSTAGETM J-IIIL Series outdoor unit Narrow space between buildings Space saving Due to the compact and slim design, direct ground installation or wall mounted installation is possible in narrow locations. Slim & compact design 14 / 16HP model Current model AIRSTAGETM V-Series outdoor unit 14 / 16HP model 765mm Depth difference -285mm J-IIIL all models Compared with all current models 42 480mm 1,690 mm 1,428mm Image: 8 / 10 / 12HP models Height difference -262mm Compared with current 8HP model 8 / 10 / 12HP model Current model AIRSTAGETM V-Series outdoor unit 8 / 10HP model AIRSTAGETM V-III Series outdoor unit AIRSTAGETM J-IIIL Series outdoor unit Installation at the back of the building Flexible installation This model is a front discharge type with a slim and low body, so installation space is compact. Building windows are not blocked and space saving is possible. 43 Features Long piping capability Our advanced refrigerant control technology allows us to achieve a total refrigerant piping length of 400m. Actual piping length 120m max. Up to 30* connectible units A new outdoor unit with optimum heat exchanger structure enables the connection of up to 30 indoor units. (*:16HP model. 14HP model:27 units, 12HP model: 22 units, 10HP model: 19 units, 8HP model: 15 units) Piping length from the first separation tube to the farthest indoor unit 90m max. High static pressure External static pressure is available up to 60 Pa. (only 14 / 16HP) 60 Pa Low noise characteristics Low operating sound makes this unit highly suitable to densely populated areas. Sound power level 66 dB(A) 44 Total pipe length 400m max. Height difference between outdoor and indoor units 50m max. For the outdoor unit installed below the indoor units: 40m max. Height difference between indoor units* 50m max. *Only for new indoor units, check technical manual to confirm. 77dB(A) 11dB(A) difference Current model (8HP) Specifications Rating capacity range HP Model name Maximum connectable indoor unit 8 AJY072LELAH 1-15 10 AJY090LELAH 1-19 12 AJY108LELAH 1-22 14 AJY126LELAH 1-27 Power source Cooling Capacity Nominal heating kW Max heating Cooling Input power Nominal heating kW Max heating EER Cooling Nominal heating W/W COP Max heating Air flow rate m3/h(l/s) External static pressure (max.) Pa Sound pressure level / Power level Cooling Heating dB (A) Height Dimensions Width mm Depth Weight kg Refrigerant Type Charge kg Connection pipe diameter Liquid Gas mm Max. total pipe length m Max. height difference Cooling Operation range �C Heating 22.4 22.4 25.0 6.30 4.65 5.45 3.56 4.82 4.56 8,400 (2,334) 20 52 / 66 54 / 1,428 1,080 480 170 R410A 7.0 9.52 19.05 400 -5 to 46* -20 to 21 28.0 28.0 31.5 8.59 6.61 8.29 3.26 4.24 3.80 9,000 (2,500) 30 54 / 69 57 / 1,428 1,080 480 177 R410A 7.5 9.52 22.20 400 -5 to 46* -20 to 21 3-phase, ~400V, 50Hz 33.5 33.5 37.5 10.42 8.18 10.25 3.22 4.10 3.66 11,000 (3,056) 30 59 / 73 61 / 1,428 1,080 480 178 R410A 7.5 12.70 28.58 400 50 / 40 (Outdoor unit: upper / lower) -5 to 46* -20 to 21 40.0 40.0 45.0 12.12 9.71 11.81 3.30 4.12 3.81 13,000 (3,611) 60 62 / 75 63 / 1,638 1,080 480 213 R410A 11.0 12.70 28.58 400 -5 to 46* -20 to 21 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. * The cooling operation range of -15 to 46�C is allowed only when all of the indoor units connected to the system are higher than capacity of 5.6kW. 16 AJY144LELAH 1-30 45.0 45.0 50.0 14.96 11.81 14.29 3.01 3.81 3.50 14,000 (3,889) 60 64 / 77 65 / 1,638 1,080 480 213 R410A 11.0 12.70 28.58 400 -5 to 46* -20 to 21 Dimensions Models: AJY072LELAH / AJY090LELAH / AJY108LELAH 196 688 196 Models: AJY126LELAH / AJY144LELAH 196 688 196 (Unit: mm) (515.5) 40.5 Top view 39 1,080 40 480 12 Terminal blocks (Power) Terminal blocks (Transmission) Top view 1,080 40 480 1,638 (515.5) 40.5 1,428 1,017 1,102 23.5 447 Front view 479 Bottom view Side view Front view Bottom view Side view 45 HEAT PUMP TYPE � Smart and cutting edge design � Extensive lineup from 8HP to 48HP in 2HP increments � Connectible indoor unit capacity ratio of up to 150% System Outline Excellent energy saving Our heat pump inverter type systems achieve energy efficient operation for both cooling or heating with the use of inverter technology. High design flexibility for various building requirements High rise building air conditioning design and installation flexibility is achieved with concentrated rooftop or individual plant area installation made possible by flexible piping options and the high static pressure design. Easy installation and maintenance The flexible communication wiring method and piping connections makes installation and maintenance easy. Large office 46 System configuration example � This system is used for medium and large sized buildings. Connecting a combination of outdoor units makes it possible to create a high-capacity system. � This example shows the connection of multiple indoor units using separation tubes and headers. Outdoor unit Separation tube Header Liquid pipe Gas pipe Indoor unit Indoor unit Features Efficiency during operation A high COP is realised for all combinations by our unique heat exchanger structure, highly efficient DC twin compressor and additional proprietary technologies. Space saving combination (COP) 5 4 4.84 4.35 4.34 4.03 3.67 4.55 4.34 4.28 4.15 3.90 4.03 3.83 3.67 4.21 4.02 4.11 3.95 3.81 3.89 3.77 3.67 3 2 8 10 12 14 16 18 20 22 24* 26 28 30 32 34 36 38 40 42 44 46 48 (HP) (COP) 5 Energy efficiency 4 combination 3 4.84 4.84 4.52 4.63 4.61 4.42 4.45 4.30 4.34 4.21 4.11 4.03 2 16 20 24* 26 28 30 32 34 36 38 40 42 (HP) For 24HP combination Space saving Energy efficiency COP 15 % UP Energy saving technology that enhances operational efficiency Powerful large propeller fan By using CFD*1 technology, the newly designed fan achieves high performance and low noise operation. *1. CFD = Computational Fluid Dynamics 3 phase DC fan motor Efficiency is improved with the highly efficient motor with sophisticated drive control. Additionally, the DC fan motor exhibits a low noise output. Subcool heat exchanger High heat exchanger efficiency is achieved by using an internal projection shape with double pipe construction. Sine-wave DC inverter control High efficiency is realised by adoption of reduced switching loss IPM. Large capacity ALL DC inverter compressor The large capacity highly efficient DC twin rotary compressor with 0.1Hz steps compressor speed control Capacity 0.1Hz Inverter frequency 4-face heat exchanger Heat exchange efficiency is significantly improved by the introduction of a new 4-face heat exchanger that increases the effective surface area. Front intake port (corner cut air inhaling structure) Advanced energy saving control Multiple outdoor operation control This control method operates all compressors at part load and distributes refrigerant to all heat exchangers to improve the overall system efficiency. Inefficient operation Old technology Compressor Load level Highly efficient operation Current control logic Heat exchanger refrigerant control The efficiency of the top and bottom heat exchanger in the outdoor unit has been improved by adopting an optimum refrigerant path control. Fan Large intake airflow Small intake airflow Heat exchanger Outdoor unit Highly efficient refrigerant flow control Larger refrigerant flow EEV Heat exchanger Distributor 47 Outdoor units lineup � Combinations other than those specified are not supported. Space saving combinations 22.4kW (8HP) 28.0kW (10HP) 33.5kW (12HP) 40.0kW (14HP) 45.0kW (16HP) AJY072LALBH UNIT: AJY072LALBH 50.4kW (18HP) AJY090LALBH UNIT: AJY090LALBH 56.0W (20HP) AJY108LALBH UNIT: AJY108LALBH 62.4kW (22HP) AJY126LALBH UNIT: AJY126LALBH 68.0kW (24HP) AJY144LALBH UNIT: AJY144LALBH 73.0kW (26HP) AJY162LALBH UNIT: AJY090 / 072LALBH 80.0kW (28HP) AJY180LALBH UNIT: AJY090 / 090LALBH 85.0kW (30HP) AJY198LALBH UNIT: AJY126 / 072LALBH 90.0kW (32HP) AJY216LALBH UNIT: AJY126 / 090LALBH 96.0kW (34HP) AJY234LALBH UNIT: AJY144 / 090LALBH 101.0kW (36HP) AJY252LALBH UNIT: AJY126 / 126LALBH 108.0kW (38HP) AJY270LALBH UNIT: AJY144 / 126LALBH 113.0kW (40HP) AJY288LALBH UNIT: AJY144 / 144LALBH 118.0kW (42HP) AJY306LALBH UNIT: AJY126 / 090 / 090LALBH 125.0kW (44HP) AJY324LALBH UNIT: AJY144 / 090 / 090LALBH 130.0kW (46HP) AJY342LALBH UNIT: AJY126 / 126 / 090LALBH 135.0kW (48HP) AJY360LALBH UNIT: AJY144 / 126 / 090LALBH AJY378LALBH UNIT: AJY144 / 144 / 090LALBH AJY396LALBH UNIT: AJY144 / 126 / 126LALBH AJY414LALBH UNIT: AJY144 / 144 / 126LALBH AJY432LALBH UNIT: AJY144 / 144 / 144LALBH Energy efficiency combinations 44.8kW (16HP) 55.9kW (20HP) 67.2kW (24HP) 72.8kW (26HP) 78.3kW (28HP) AJY144LALBHH UNIT: AJY072 / 072LALBH 84.8kW (30HP) AJY180LALBHH UNIT: AJY108 / 072LALBH 89.4kW (32HP) AJY216LALBHH UNIT: AJY072 / 072 / 072LALBH 95.9kW (34HP) AJY234LALBHH UNIT: AJY090 / 072 / 072LALBH 100.5kW (36HP) AJY252LALBHH UNIT: AJY108 / 072 / 072LALBH 107.0kW (38HP) AJY270LALBHH UNIT: AJY126 / 072 / 072LALBH 113.5kW (40HP) AJY288LALBHH UNIT: AJY108 / 108 / 072LALBH 120.0kW (42HP) AJY306LALBHH UNIT: AJY126 / 108 / 072LALBH AJY324LALBHH UNIT: AJY108 / 108 / 108LALBH AJY342LALBHH UNIT: AJY126 / 108 / 108LALBH AJY360LALBHH UNIT: AJY126 / 126 / 108LALBH AJY378LALBHH UNIT: AJY126 / 126 / 126LALBH 48 Dimensions 8 / 10HP: AJY072LALBH / AJY090LALBH 690 (Bolt pitch) 80 530 (Bolt pitch) 8-12 � 17 (Hole) 732 (Bolt pitch) 765 (Unit: mm) 930 1,690 1,339 1,576 B AC 12 / 14 / 16HP: AJY108LALBH / AJY126LALBH / AJY144LALBH 1,000 (Bolt pitch) 80 840 (Bolt pitch) 8-12�7 (Hole) 732 (Bolt pitch) 765 (Unit: mm) 1,240 1,690 B AC A Front side knockout position 73 43 � 50 Power supply cable port � 34.5 Power supply cable port � 43.7 Power supply cable port � 22.2 Transmission cable port � 22.2 Transmission cable port Pipe port 9 5 10 75 100 125 199 B Left side knockout position � 50 Power supply cable port � 22.2 Transmission cable port � 34.5 Power supply cable port � 43.7 Power supply cable port � 22.2 Transmission cable port C Bottom side knockout position Top view Pipe port 82 80 42 197 49 Outdoor units specifications Space saving combinations Rating capacity range HP 8 10 12 14 16 18 20 22 24 Model name Unit 1 Unit 2 Unit 3 Maximum connectible indoor unit*1 Indoor unit connectible capacity Cooling kW Power source Capacity Input power EER COP Cooling kW Heating Cooling kW Heating Cooling W/W Heating Air flow rate High m3/h (I/s) Sound pressure level*2 Cooling Heating dB (A) Maximum external static pressure Pa Compressor motor output kW Heat exchanger fin Height Dimensions Width mm Depth Weight kg Refrigerant Type Charge kg Liquid Connection pipe diameter mm Suction gas Operation range Cooling �C Heating AJY072LALBH A J Y072L A LBH AJY090LALBH AJY090LALBH AJY108LALBH A J Y108L A LBH AJY126LALBH A J Y126L A LBH AJY144LALBH A J Y14 4L A LBH AJY162LALBH AJY090LALBH A J Y072L A LBH AJY180LALBH AJY090LALBH AJY090LALBH AJY198LALBH A J Y126L A LBH A J Y072L A LBH AJY216LALBH A J Y126L A LBH AJY090LALBH 15 11.2 to 33.6 22.4 25.0 5.20 5.17 4.31 4.84 11,100 (3,084) 56 58 82 7.5 Blue fin 1,690 930 765 252 R410A 11.7 12.70 22.22 -15 to 46 -20 to 21 16 14.0 to 42.0 28.0 31.5 7.28 7.25 3.85 4.35 11,100 (3,084) 58 59 82 7.5 Blue fin 1,690 930 765 252 R410A 11.7 12.70 22.22 -15 to 46 -20 to 21 17 16.8 to 50.2 33.5 37.5 8.96 8.65 3.74 4.34 13,000 (3,611) 57 60 82 11.0 Blue fin 1,690 1,240 765 275 R410A 11.8 12.70 28.58 -15 to 46 -20 to 21 21 20.0 to 60.0 24 22.5 to 67.5 27 25.2 to 75.6 40.0 45.0 10.96 11.17 3.65 4.03 3-phase 4 wire, 400 V, 50Hz 45.0 50.0 13.01 13.63 3.46 3.67 50.4 56.5 12.48 12.42 4.04 4.55 13,000 (3,611) 13,700 (3,806) 11,100�2 (3,084�2) 60 62 82 11.0 Blue fin 1,690 1,240 765 275 R410A 11.8 12.70 28.58 -15 to 46 -20 to 21 62 64 82 11.0 Blue fin 1,690 1,240 765 275 R410A 11.8 12.70 28.58 -15 to 46 -20 to 21 60 62 82 7.5�2 Blue fin 1,690 930�2 765 252�2 R410A 11.7�2 15.88 28.58 -5 to 46 -20 to 21 30 28.0 to 84.0 33 31.2 to 93.6 36 34.0 to 102.0 56.0 63.0 14.56 14.50 3.85 4.34 11,100�2 (3,084�2) 61 62 82 7.5�2 Blue fin 1,690 930�2 765 252�2 R410A 11.7�2 15.88 28.58 -5 to 46 -20 to 21 62.4 70.0 16.16 16.34 3.86 4.28 13,000+11,100 (3,611+3,084) 61 63 82 11.0+7.5 Blue fin 1,690 1,240+930 765 275+252 R410A 11.8+11.7 15.88 34.92 -5 to 46 -20 to 21 68.0 76.5 18.24 18.42 3.73 4.15 13,000+11,100 (3,611+3,084) 62 64 82 11.0+7.5 Blue fin 1,690 1,240+930 765 275+252 R410A 11.8+11.7 15.88 34.92 -5 to 46 -20 to 21 Energy efficiency combinations Rating capacity range HP 16 22 24 26 28 30 32 34 36 Model name Unit 1 Unit 2 Unit 3 Maximum connactible indoor unit*1 Indoor unit connectible capacity Cooling kW Power source Capacity Input power EER COP Cooling kW Heating Cooling kW Heating Cooling W/W Heating Air flow rate High m3/h (I/s) Sound pressure level*2 Cooling Heating dB (A) Maximum external static pressure Pa Compressor motor output kW Heat exchanger fin Height Dimensions Width mm Depth Weight kg Refrigerant Type Charge kg Liquid Connection pipe diameter mm Suction gas Operation range Cooling �C Heating AJY144LALBHH A J Y072L A LBH A J Y072L A LBH 24 22.4 to 67.2 AJY180LALBHH A J Y108L A LBH A J Y072L A LBH 29 28.0 to 83.8 AJY216LALBHH A J Y072L A LBH A J Y072L A LBH A J Y072L A LBH 36 33.6 to 100.8 AJY234LALBHH AJY090LALBH A J Y072L A LBH A J Y072L A LBH 39 36.4 to 109.2 AJY252LALBHH A J Y108L A LBH A J Y072L A LBH A J Y072L A LBH 41 39.2 to 117.4 AJY270LALBHH A J Y126L A LBH A J Y072L A LBH A J Y072L A LBH 45 42.4 to 127.2 AJY288LALBHH A J Y108L A LBH A J Y108L A LBH A J Y072L A LBH 47 44.7 to 134.1 AJY306LALBHH A J Y126L A LBH A J Y108L A LBH A J Y072L A LBH 51 48.0 to 143.8 AJY324LALBHH A J Y108L A LBH A J Y108L A LBH A J Y108L A LBH 53 50.3 to 150.7 44.8 50.0 10.40 10.34 4.31 4.84 11,100�2 (3,084�2) 59 61 82 7.5�2 Blue fin 1,690 930�2 765 252�2 R410A 11.7�2 12.70 28.58 -5 to 46 -20 to 21 55.9 62.5 14.16 13.82 3.95 4.52 13,000+11,100 (3,611+3,084) 60 62 82 11.0+7.5 Blue fin 1,690 1,240+930 765 275+252 R410A 11.8+11.7 15.88 28.58 -5 to 46 -20 to 21 67.2 75.0 15.60 15.51 4.31 4.84 11,100�3 (3,084�3) 61 63 82 7.5�3 Blue fin 1,690 930�3 765 252�3 R410A 11.7�3 15.88 34.92 -5 to 46 -20 to 21 72.8 81.5 17.68 17.59 4.12 4.63 3-phase 4 wire, 400 V, 50Hz 78.3 87.5 19.36 18.99 4.04 4.61 84.8 95.0 21.36 21.51 3.97 4.42 89.4 100.0 23.12 22.47 3.87 4.45 95.9 107.5 25.12 24.99 3.82 4.30 11,100�3 (3,084�3) 13,000+11,100�2 13,000+11,100�2 13,000�2+11,100 13,000�2+11,100 (3,611+3,084�2) (3,611+3,084�2) (3,611�2+3,084) (3,611�2+3,084) 62 63 82 7.5�2 Blue fin 1,690 930�3 765 252�3 R410A 11.7�3 15.88 34.92 -5 to 46 -20 to 21 61 64 82 11.0+7.5�2 Blue fin 1,690 1,240+930�2 765 275+252�2 R410A 11.8+11.7�2 15.88 34.92 -5 to 46 -20 to 21 63 65 82 11.0+7.5�2 Blue fin 1,690 1,240+930�2 765 275+252�2 R410A 11.8+11.7�2 19.05 34.92 -5 to 46 -20 to 21 61 64 82 11.0�2+7.5 Blue fin 1,690 1,240�2+930 765 275�2+252 R410A 11.8�2+11.7 19.05 34.92 -5 to 46 -20 to 21 63 65 82 11.0�2+7.5 Blue fin 1,690 1,240�2+930 765 275�2+252 R410A 11.8�2+11.7 19.05 34.92 -5 to 46 -20 to 21 100.5 112.5 26.88 25.95 3.74 4.34 13,000�3 (3,611�3) 64 66 82 11.0�3 Blue fin 1,690 1,240�3 765 275�3 R410A 11.8�3 19.05 41.27 -5 to 46 -20 to 21 50 26 28 30 32 34 36 38 40 42 44 46 48 AJY234LALBH A J Y14 4L A LBH AJY090LALBH 39 36.5 to 109.5 73.0 81.5 20.29 20.88 3.60 3.90 13,700+11,100 (3,806+3,084) 63 65 82 11.0+7.5 Blue fin 1,690 1,240+930 765 275+252 R410A 11.8+11.7 15.88 34.92 -5 to 46 -20 to 21 AJY252LALBH A J Y126L A LBH A J Y126L A LBH 42 40.0 to 120.0 80.0 90.0 21.92 22.34 3.65 4.03 13,000�2 (3,611�2) 63 65 82 11.0�2 Blue fin 1,690 1,240�2 765 275�2 R410A 11.8�2 15.88 34.92 -5 to 46 -20 to 21 AJY270LALBH A J Y14 4L A LBH A J Y126L A LBH 45 42.5 to 127.5 85.0 95.0 23.97 24.80 3.55 3.83 13,700+13,000 (3,806+3,611) 64 66 82 11.0�2 Blue fin 1,690 1,240�2 765 275�2 R410A 11.8�2 19.05 34.92 -5 to 46 -20 to 21 AJY288LALBH A J Y14 4L A LBH A J Y14 4L A LBH 48 45.0 to 135.0 AJY306LALBH A J Y126L A LBH AJY090LALBH AJY090LALBH 51 48.0 to 144.0 AJY324LALBH A J Y14 4L A LBH AJY090LALBH AJY090LALBH 54 50.5 to 151.5 AJY342LALBH A J Y126L A LBH A J Y126L A LBH AJY090LALBH 57 54.0 to 162.0 AJY360LALBH A J Y14 4L A LBH A J Y126L A LBH AJY090LALBH 60 56.5 to 169.5 AJY378LALBH A J Y14 4L A LBH A J Y14 4L A LBH AJY090LALBH 63 59.0 to 177.0 AJY396LALBH A J Y14 4L A LBH A J Y126L A LBH A J Y126L A LBH 64 62.5 to 187.5 AJY414LALBH A J Y14 4L A LBH A J Y14 4L A LBH A J Y126L A LBH 64 65.0 to 195.0 AJY432LALBH A J Y14 4L A LBH A J Y14 4L A LBH A J Y14 4L A LBH 64 67.5 to 202.5 90.0 100.0 26.02 27.26 3.46 3.67 13,700�2 (3,806�2) 65 67 82 11.0�2 Blue fin 1,690 1,240�2 765 275�2 R410A 11.8�2 19.05 34.92 -5 to 46 -20 to 21 96.0 108.0 25.52 25.67 3.76 4.21 3-phase 4 wire, 400 V, 50Hz 101.0 108.0 113.0 121.5 27.57 29.20 28.13 29.59 3.66 3.70 4.02 4.11 113.0 126.5 31.25 32.05 3.62 3.95 118.0 131.5 33.30 34.51 3.54 3.81 125.0 140.0 34.93 35.97 3.58 3.89 130.0 145.0 36.98 38.43 3.52 3.77 13,000+11,100�2 13,700+11,100�2 13,000�2+11,100 13,700+13,000+11,100 13,700�2+11,100 13,700+13,000�2 13,700�2+13,000 (3,611+3,084�2) (3,806+3,084�2) (3,611�2+3,084) (3,806+3,611+3,084) (3,806�2+3,084) (3,806+3,611�2) (3,806�2+3,611) 64 65 82 11.0+7.5�2 Blue fin 1,690 1,240+930�2 765 275+252�2 R410A 11.8+11.7�2 19.05 34.92 -5 to 46 -20 to 21 65 66 82 11.0+7.5�2 Blue fin 1,690 1,240+930�2 765 275+252�2 R410A 11.8+11.7�2 19.05 41.27 -5 to 46 -20 to 21 64 66 82 11.0�2+7.5 Blue fin 1,690 1,240�2+930 765 275�2+252 R410A 11.8�2+11.7 19.05 41.27 -5 to 46 -20 to 21 65 67 82 11.0�2+7.5 Blue fin 1,690 1,240�2+930 765 275�2+252 R410A 11.8�2+11.7 19.05 41.27 -5 to 46 -20 to 21 66 68 82 11.0�2+7.5 Blue fin 1,690 1,240�2+930 765 275�2+252 R410A 11.8�2+11.7 19.05 41.27 -5 to 46 -20 to 21 66 68 82 11.0�3 Blue fin 1,690 1,240�3 765 275�3 R410A 11.8�3 19.05 41.27 -5 to 46 -20 to 21 66 68 82 11.0�3 Blue fin 1,690 1,240�3 765 275�3 R410A 11.8�3 19.05 41.27 -5 to 46 -20 to 21 135.0 150.0 39.03 40.89 3.46 3.67 13,700�3 (3,806�3) 67 69 82 11.0�3 Blue fin 1,690 1,240�3 765 275�3 R410A 11.8�3 19.05 41.27 -5 to 46 -20 to 21 38 40 42 AJY342LALBHH A J Y126L A LBH A J Y108L A LBH A J Y108L A LBH 57 53.5 to 160.5 AJY360LALBHH A J Y126L A LBH A J Y126L A LBH A J Y108L A LBH 60 56.8 to 170.2 AJY378LALBHH A J Y126L A LBH A J Y126L A LBH A J Y126L A LBH 64 60.0 to 180.0 107.0 120.0 28.88 28.47 3.70 4.21 3-phase 4 wire, 400 V, 50Hz 113.5 127.5 30.88 30.99 3.68 4.11 120.0 135.0 32.88 33.51 3.65 4.03 13,000�3 (3,611�3) 13,000�3 (3,611�3) 13,000�3 (3,611�3) 64 66 82 11.0�3 Blue fin 1,690 1,240�3 765 275�3 R410A 11.8�3 19.05 41.27 -5 to 46 -20 to 21 64 66 82 11.0�3 Blue fin 1,690 1,240�3 765 275�3 R410A 11.8�3 19.05 41.27 -5 to 46 -20 to 21 65 67 82 11.0�3 Blue fin 1,690 1,240�3 765 275�3 R410A 11.8�3 19.05 41.27 -5 to 46 -20 to 21 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. *1: Minimum connectible indoor unit number is 2. However ARXC72 and ARXC90 can be used to signal connection. *2: The noise value is the value when measured in an anechoic room. When measured in the actual installed state, surrounding noise and reflections are received, and the measured value is usually larger than the indicated value. 51 HEAT RECOVERY TYPE � Smart cutting edge design � Extensive lineup from 8HP to 48HP in 2HP increments � Connectible indoor unit capacity ratio of up to 150% System Outline Simultaneous cooling and heating operation using one refrigerant system Cooling and heating can be freely selected for each indoor unit to provide simultaneous cooling and heating in rooms with large temperature differences. Annual cooling operation The VR-II series provides annual cooling operation functionality for spaces that require constant temperature control throughout the year. Temperature difference control The operation mode can be freely changed when there are large temperature differences during the day, such as between seasons. Large building 52 Heat exchanger 4 way valve Compressor Outdoor unit Cooling High pressure liquid Low pressure gas High pressure gas Heating RB unit Heat exchanger Indoor unit EEV Our heat recovery systems can achieve high operating energy efficiency by drawing heat from the room to be cooled and transferring it as energy for rooms to be heated. High Heating & cooling Mainly cooling Mainly heating COP Non heat recovery model 0 50 100 (%) Heating ratio Features Efficiency during operation A high COP is achieved for all combinations through our unique heat exchanger structure, highly efficient DC twin compressor and our own proprietary technologies. Space saving combination (COP) 5 4 3 4.16 3.75 3.92 3.66 3.45 3.92 3.75 3.84 3.696 3.56 3.64 3.55 3.45 3.69 3.61 3.67 3.57 3.52 3.57 3.51 3.45 2 8 10 12 14 16 18 20 22 24* 26 28 30 32 34 36 38 40 42 44 46 48 (HP) Energy efficient combination (COP) 5 4 4.16 4.01 4.16 3.99 4.05 3.92 3.98 3.87 3.92 3.82 3.72 3.64 3 2 16 20 24* 26 28 30 32 34 36 38 40 42 (HP) For 24HP combination Space saving Energy efficiency COP 15 % UP Energy saving technology that enhances operational efficiency Powerful large propeller fan By using CFD*1 technology, the newly designed fan achieves high performance and low noise operation. *1. CFD = computational fluid dynamics 3 phase DC fan motor Efficiency is improved with the highly efficient motor with sophisticated drive control. Additionally, the DC fan motor exhibits low noise output. Subcool heat exchanger High heat exchanger efficiency is achieved by using an internal projection shape with double pipe construction. Sine-wave DC inverter control High efficiency is realised by adoption of reduced switching loss IPM. Large capacity DC inverter compressor Large capacity highly efficient DC twin rotary compressor with excellent part load capability. 4-face heat exchanger Heat exchanger efficiency is significantly improved by the introduction of a new 4-face heat exchanger with increased effective surface area. Front intake port (corner cut air inhaling structure) In multiple outdoor unit installations, the unique front intake design improves airflow into the heat exchanger. 53 Features All inverter compressor Large capacity DC inverter compressor Large capacity highly efficient DC twin rotary compressor with excellent intermediate capability. Flexible piping connection Flexible refrigerant pipe work is possible through the use of various piping and RB Unit connections to match the floor layout and building structure. RB Unit (single type) Separation tube RB Unit (multi type) Capacity High efficiency compressor speed control Comfortable space with small room temperature changes and minimum energy loss is created by 0.1Hz steps for compressor speed control. 0.1Hz Multiple outdoor operation control When multiple outdoor units are connected, a sophisticated operation is performed by each compressor. RB Unit Rather than running one compressor at full load and distributing refrigerant to one heat exchanger, this control method operates all compressors at part load UaTnPd-dRisXtr0ib8uAteHs re�friUgeTrPan-Rt tXo1a2ll AofHthe heat exchangers allowing for the overall system efficiency to be improved. 8 and 12 Port Heat Recovery Refrigerant Branch Units Inverter frequency New Product Release! Refrigerant Branch Units for VRF Compressor load level UTP-RX08AH High efficient operation UTP-RX12AH Inefficient operation FNLewE X8 &I B12L ERBPunIiPt I N G C O N N E C T I O N The new 8 and 12 branch RB units allow for greater flexibility with refrigerant piping work for various floor layouts and building structures. Current set up (3 x 4-Port RB Units example) Separation tube 4-Port RB Unit NEW SET UP (12-Port RB Unit example) 12-Port RB unit FLEXIBLE INSTALLATION 54 Height 298mm Easy to maintain in a narrow space Max. 3 or 8 indoor units* Max. 8 indoor unit* Single connection Group connection Single connection & Group connection Application Individual cooling and heating Simultaneous cooling and heating Individual cooling and heating � The RB unit can be freely positioned between the first branch and the indoor unit � The maximum height difference between RB units is 15m * 2. RB Unit is not necessary for cooling only use Capacity limitations apply. See technical manual Simultaneous cooling and heating RB Unit less connection*2 Cooling only Flexible installation of RB unit Height 198mm � Compact and slim design saves space � Drain pipe not required � The control box position can be changed to meet installation conditions RB unit (single type) RB unit (multi type) Easy maintenance in narrow spaces Installation is possible from either side due to the interchangeable positioning of the control box Installation of the control box is possible on the upper side to enable use in narrow spaces � Compact space saving design � Drain pipe not required � Simple installation series connection design �2-way connection Up to 2 multi type RB units can be connected in series � Maintenance can be performed from the side � Sliding down the panel on the electrics box allows easy repair and maintenance � Parts can be replaced easily even within narrow ceiling spaces RB unit Ceiling 55 Outdoor units lineup � Combinations other than those specified are not supported. Space saving combinations 22.4kW (8HP) 28.0kW (10HP) 33.5kW (12HP) 40.0kW (14HP) 45.0kW (16HP) AJTA72GALH UNIT: AJTA72GALH 50.4kW (18HP) AJTA90GALH UNIT: AJTA90GALH 56.0W (20HP) AJT108GALH UNIT: AJT108GALH 61.5kW (22HP) AJT126GALH UNIT: AJT126GALH 67.4kW (24HP) AJT144GBLH UNIT: AJT144GBLH 73.0kW (26HP) AJT162GALH UNIT: AJTA90 / A72GALH 78.5kW (28HP) AJT180GALH UNIT: AJTA90 / A90GALH 85.0kW (30HP) AJT198GALH UNIT: AJT108 / A90GALH 90.0kW (32HP) AJT216GBLH UNIT: AJT144GBLH / A72GALH 95.4kW (34HP) AJT234GBLH UNIT: AJT144GBLH / A90GALH 101.0kW (36HP) AJT252GBLH UNIT: AJT144GBLH / 108GALH 106.5kW (38HP) AJT270GBLH UNIT: AJT144GBLH / 126GALH 112.4kW (40HP) AJT288GBLH UNIT: AJT144 / 144GBLH 118.0kW (42HP) AJT306GBLH UNIT: AJT144GBLH / A90 / A72GALH AJT324GBLH UNIT: AJT144GBLH / A90 / A90GALH 123.5kW (44HP) 130.0kW (46HP) AJT342GBLH UNIT: AJT144GBLH / 108 / A90GALH AJT360GBLH UNIT: AJT144 / 144GBLH / A72GALH AJT378GBLH UNIT: AJT144 / 144GBLH / A90GALH AJT396GBLH UNIT: AJT144 / 144GBLH / 108GALH AJT414GBLH UNIT: AJT144 / 144GBLH / 126GALH 135.0kW (48HP) AJT432GBLH UNIT: AJT144 / 144 / 144GBLH Energy efficiency combinations 44.8kW (16HP) 55.9kW (20HP) 67.2kW (24HP) 72.8kW (26HP) 78.3kW (28HP) AJT144GALH UNIT: AJTA72 / A72GALH 83.9kW (30HP) AJT180GALHH UNIT: AJT108 / A72GALH 89.4kW (32HP) AJT216GALHH UNIT: AJTA72 / A72 / A72GALH 95.0kW (34HP) AJT234GALHH UNIT: AJTA90 / A72 / A72GALH 100.5kW (36HP) AJT252GALHH UNIT: AJT108 / A72 / A72GALH 107.0kW (38HP) AJT270GALHH UNIT: AJT108 / A90 / A72GALH 112.0kW (40HP) AJT288GALHH UNIT: AJT108 / 108 / A72GALH 118.5kW (42HP) AJT306GALHH UNIT: AJT108 / 108 / A90GALH AJT324GALHH UNIT: AJT108 / 108 / 108GALH AJT342GALHH UNIT: AJT126 / 108 / 108GALH AJT360GBLHH UNIT: AJT144GBLH / 108 / 108GALH AJT378GBLHH UNIT: AJT144GBLH / 126 / 108GALH 56 Dimensions 8 / 10HP: AJTA72GALH / AJTA90GALH 690 (Bolt pitch) 80 530 (Bolt pitch) 8-12 � 17 (Hole) 732 (Bolt pitch) 765 (Unit: mm) 930 1,690 1,339 1,576 B AC 12 / 14 / 16HP: AJT108GALH / AJT126GALH / AJT144GBLH 1,000 (Bolt pitch) 80 840 (Bolt pitch) 8-12�7 (Hole) 732 (Bolt pitch) 765 (Unit: mm) 1,240 1,690 B AC A Front side knockout position 73 43 � 50 Power supply cable port � 34.5 Power supply cable port � 43.7 Power supply cable port � 22.2 Transmission cable port � 22.2 Transmission cable port Pipe port 9 5 10 75 100 125 199 B Left side knockout position � 50 Power supply cable port � 22.2 Transmission cable port � 34.5 Power supply cable port � 43.7 Power supply cable port � 22.2 Transmission cable port C Bottom side knockout position Top view Pipe port 82 80 42 197 57 Outdoor units specifications Space saving combinations Rating capacity range HP 8 10 12 14 16 18 20 22 24 Model name Unit 1 Unit 2 Unit 3 Maximum connectible indoor unit*1 Indoor unit connectible capacity Cooling kW Power source Capacity Cooling kW Heating Input power Cooling kW Heating EER COP Air flow rate Sound pressure level*2 Cooling Heating High Cooling Heating W/W m3/h (I/s) dB (A) Maximum external static pressure Pa Compressor motor output kW Heat exchanger fin Height Dimensions Width mm Depth Weight kg Refrigerant Type Charge kg Liquid Connection pipe diameter Discharge gas mm Suction gas Cooling Operation range Heating �C Cooling/Heating AJTA72GALH AJTA72GALH 15 11.2 to 33.6 22.4 25.0 6.14 6.01 3.65 4.16 11,100 (3,084) 56 58 80 7.5 Blue fin 1,690 930 765 262 R410A 11.8 12.70 15.88 22.22 -10 to 46 -20 to 21 -10 to 21 AJTA90GALH AJTA90GALH 16 14.0 to 42.0 28.0 31.5 8.37 8.41 3.35 3.75 11,100 (3,084) 58 59 80 7.5 Blue fin 1,690 930 765 262 R410A 11.8 12.70 19.05 22.22 -10 to 46 -20 to 21 -10 to 21 AJT108GALH AJT108GALH 17 16.8 to 50.2 33.5 37.5 10.04 9.57 3.34 3.92 13,000 (3,611) 57 59 80 11.0 Blue fin 1,690 1,240 765 286 R410A 11.8 12.70 19.05 28.58 -10 to 46 -20 to 21 -10 to 21 AJT126GALH AJT126GALH AJT144GBLH AJT144GBLH AJT162GALH AJTA90GALH AJTA72GALH 21 20.0 to 60.0 24 22.5 to 67.5 27 25.2 to 75.6 3-phase 4 wire, 400 V, 50Hz 40.0 45.0 50.4 45.0 48.5 56.5 13.00 14.48 14.51 12.31 14.06 14.42 3.08 3.11 3.47 3.66 3.45 3.92 13,000 (3,611) 13,000 (3,611) 11,100�2 (3,084�2) 61 61 60 61 64 62 80 80 80 11.0 11.0 7.5�2 Blue fin Blue fin Blue fin 1,690 1,690 1,690 1,240 1,240 930�2 765 765 765 286 286 262�2 R410A R410A R410A 11.8 11.8 11.8�2 12.70 12.70 15.88 22.22 22.22 22.22 28.58 28.58 28.58 -10 to 46 -10 to 46 -10 to 46 -20 to 21 -20 to 21 -20 to 21 -10 to 21 -10 to 21 -10 to 21 AJT180GALH AJTA90GALH AJTA90GALH 30 28.0 to 84.0 AJT198GALH AJT108GALH AJTA90GALH 32 30.8 to 92.2 AJT216GBLH AJT144GBLH AJTA72GALH 36 33.7 to 101.1 56.0 63.0 16.74 16.82 3.35 3.75 11,100�2 (3,084�2) 61 62 80 7.5�2 Blue fin 1,690 930�2 765 262�2 R410A 11.8�2 15.88 22.22 28.58 -10 to 46 -20 to 21 -10 to 21 61.5 69.0 18.41 17.98 3.34 3.84 13,000+11,100 (3,611+3,084) 61 62 80 11.0+7.5 Blue fin 1,690 1,240+930 765 286+262 R410A 11.8�2 15.88 28.58 34.92 -10 to 46 -20 to 21 -10 to 21 67.4 73.5 20.62 20.07 3.27 3.66 13,000+11,100 (3,611+3,084) 62 65 80 11.0+7.5 Blue fin 1,690 1,240+930 765 286+262 R410A 11.8�2 15.88 28.58 34.92 -10 to 46 -20 to 21 -10 to 21 Energy efficiency combinations Rating capacity range HP 16 22 24 26 28 30 32 34 36 Model name Unit 1 Unit 2 Unit 3 Maximum connectible indoor unit*1 Indoor unit connectible capacity Cooling kW Power source Capacity Cooling kW Heating Input power Cooling kW Heating EER COP Air flow rate Cooling Heating High W/W m3/h (I/s) Sound pressure level*2 Cooling Heating dB (A) Maximum external static pressure Pa Compressor motor output kW Heat exchanger fin Height Dimensions Width mm Depth Weight kg Refrigerant Type Charge kg Liquid Connection pipe diameter Discharge gas mm Suction gas Cooling Operation range Heating �C Cooling/Heating AJT144GALH AJTA72GALH AJTA72GALH 24 22.4 to 67.2 44.8 50.0 12.28 12.02 3.65 4.16 11,100�2 (3,084�2) 59 61 80 7.5�2 Blue fin 1,690 930�2 765 262�2 R410A 11.8�2 12.70 22.22 28.58 -10 to 46 -20 to 21 -10 to 21 AJT180GALHH AJT108GALH AJTA72GALH 29 28.0 to 83.8 55.9 62.5 16.18 15.58 3.45 4.01 13,000+11,100 (3,611+3,084) 60 62 80 11.0+7.5 Blue fin 1,690 1,240+930 765 286+262 R410A 11.8�2 15.88 22.22 28.58 -10 to 46 -20 to 21 -10 to 21 AJT216GALHH AJTA72GALH AJTA72GALH AJTA72GALH 36 33.6 to 100.8 67.2 75.0 18.42 18.03 3.65 4.16 11,100�3 (3,084�3) 61 63 80 7.5�3 Blue fin 1,690 930�3 765 262�3 R410A 11.8�3 15.88 28.58 34.92 -10 to 46 -20 to 21 -10 to 21 AJT234GALHH AJTA90GALH AJTA72GALH AJTA72GALH 39 36.4 to 109.2 AJT252GALHH AJT108GALH AJTA72GALH AJTA72GALH 41 39.2 to 117.4 AJT270GALHH AJT108GALH AJTA90GALH AJTA72GALH 44 42.0 to 125.8 AJT288GALHH AJT108GALH AJT108GALH AJTA72GALH 47 44.7 to 134.1 AJT306GALHH AJT108GALH AJT108GALH AJTA90GALH 50 47.5 to 142.5 AJT324GALHH AJT108GALH AJT108GALH AJT108GALH 53 50.3 to 150.7 3-phase 4 wire, 400 V, 50Hz 72.8 78.3 83.9 81.5 87.5 94.0 20.65 22.32 24.55 20.43 21.59 23.99 3.53 3.51 3.42 3.99 4.05 3.92 11,100�3 (3,084�3) 13,000+11,100�2 13,000+11,100�2 (3,611+3,084�2) (3,611+3,084�2) 62 61 62 63 63 63 80 80 80 7.5�3 11.0+7.5�2 11.0+7.5�2 Blue fin Blue fin Blue fin 1,690 1,690 1,690 930�3 1,240+930�2 1,240+930�2 765 765 765 262�3 286+262�2 286+262�2 R410A R410A R410A 11.8�3 11.8�3 11.8�3 15.88 15.88 19.05 28.58 28.58 28.58 34.92 34.92 34.92 -10 to 46 -10 to 46 -10 to 46 -20 to 21 -20 to 21 -20 to 21 -10 to 21 -10 to 21 -10 to 21 89.4 100.0 26.22 25.15 3.41 3.98 13,000�2+11,100 (3,611�2+3,084) 61 63 80 11.0�2+7.5 Blue fin 1,690 1,240�2+930 765 286�2+262 R410A 11.8�3 19.05 28.58 34.92 -10 to 46 -20 to 21 -10 to 21 95.0 106.5 28.45 27.55 3.34 3.87 13,000�2+11,100 (3,611�2+3,084) 62 64 80 11.0�2+7.5 Blue fin 1,690 1,240�2+930 765 286�2+262 R410A 11.8�3 19.05 28.58 34.92 -10 to 46 -20 to 21 -10 to 21 100.5 112.5 30.12 28.71 3.34 3.92 13,000�3 (3,611�3) 62 64 80 11.0�3 Blue fin 1,690 1,240�3 765 286�3 R410A 11.8�3 19.05 28.58 41.27 -10 to 46 -20 to 21 -10 to 21 58 26 28 30 32 34 36 38 40 42 44 46 48 AJT234GBLH AJT144GBLH AJTA90GALH 39 36.5 to 109.5 AJT252GBLH AJT144GBLH AJT108GALH 42 39.3 to 117.7 73.0 80.0 22.85 22.47 3.19 3.56 13,000+11,100 (3,611+3,084) 63 65 80 11.0+7.5 Blue fin 1,690 1,240+930 765 286+262 R410A 11.8�2 15.88 28.58 34.92 -10 to 46 -20 to 21 -10 to 21 78.5 86.0 24.52 23.63 3.20 3.64 13,000�2 (3,611�2) 62 65 80 11.0�2 Blue fin 1,690 1,240�2 765 286�2 R410A 11.8�2 15.88 28.58 34.92 -10 to 46 -20 to 21 -10 to 21 AJT270GBLH AJT144GBLH AJT126GALH 45 42.5 to 127.5 85.0 93.5 27.48 26.37 3.09 3.55 13,000�2 (3,611�2) 64 66 80 11.0�2 Blue fin 1,690 1,240�2 765 286�2 R410A 11.8�2 19.05 28.58 34.92 -10 to 46 -20 to 21 -10 to 21 AJT288GBLH AJT144GBLH AJT144GBLH 48 45.0 to 135.0 90.0 97.0 28.96 28.12 3.11 3.45 13,000�2 (3,611�2) 64 67 80 11.0�2 Blue fin 1,690 1,240�2 765 286�2 R410A 11.8�2 19.05 28.58 34.92 -10 to 46 -20 to 21 -10 to 21 AJT306GBLH AJT144GBLH AJTA90GALH AJTA72GALH 51 47.7 to 143.1 AJT324GBLH AJT144GBLH AJTA90GALH AJTA90GALH 54 50.5 to 151.5 AJT342GBLH AJT144GBLH AJT108GALH AJTA90GALH 57 53.3 to 159.7 AJT360GBLH AJT144GBLH AJT144GBLH AJTA72GALH 60 56.2 to 168.6 AJT378GBLH AJT144GBLH AJT144GBLH AJTA90GALH 63 59.0 to 177.0 95.4 105.0 28.99 28.48 3.29 3.69 13,000+11,100�2 (3,611+3,084�2) 64 66 80 11.0+7.5�2 Blue fin 1,690 1,240+930�2 765 286+262�2 R410A 11.8�3 19.05 28.58 34.92 -10 to 46 -20 to 21 -10 to 21 3-phase 4 wire, 400 V, 50Hz 101.0 106.5 111.5 117.5 31.22 32.89 30.88 32.04 3.24 3.24 3.61 3.67 13,000+11,100�2 13,000�2+11,100 (3,611+3,084�2) (3,611�2+3,084) 64 64 66 66 80 80 11.0+7.5�2 11.0�2+7.5 Blue fin Blue fin 1,690 1,690 1,240+930�2 1,240�2+930 765 765 286+262�2 286�2+262 R410A R410A 11.8�3 11.8�3 19.05 19.05 28.58 34.92 41.27 41.27 -10 to 46 -10 to 46 -20 to 21 -20 to 21 -10 to 21 -10 to 21 112.4 122.0 35.10 34.13 3.20 3.57 13,000�2+11,100 (3,611�2+3,084) 65 68 80 11.0�2+7.5 Blue fin 1,690 1,240�2+930 765 286�2+262 R410A 11.8�3 19.05 34.92 41.27 -10 to 46 -20 to 21 -10 to 21 118.0 128.5 37.33 36.53 3.16 3.52 13,000�2+11,100 (3,611�2+3,084) 65 68 80 11.0�2+7.5 Blue fin 1,690 1,240�2+930 765 286�2+262 R410A 11.8�3 19.05 34.92 41.27 -10 to 46 -20 to 21 -10 to 21 AJT396GBLH AJT144GBLH AJT144GBLH AJT108GALH 64 61.8 to 185.2 123.5 134.5 39.00 37.69 3.17 3.57 13,000�3 (3,611�3) 65 68 80 11.0�3 Blue fin 1,690 1,240�3 765 286�3 R410A 11.8�3 19.05 34.92 41.27 -10 to 46 -20 to 21 -10 to 21 AJT414GBLH AJT144GBLH AJT144GBLH AJT126GALH 64 65.0 to 195.0 130.0 142.0 41.96 40.43 3.10 3.51 13,000�3 (3,611�3) 66 68 80 11.0�3 Blue fin 1,690 1,240�3 765 286�3 R410A 11.8�3 19.05 34.92 41.27 -10 to 46 -20 to 21 -10 to 21 AJT432GBLH AJT144GBLH AJT144GBLH AJT144GBLH 64 67.5 to 202.5 135.0 145.5 43.44 42.18 3.11 3.45 13,000�3 (3,611�3) 66 69 80 11.0�3 Blue fin 1,690 1,240�3 765 286�3 R410A 11.8�3 19.05 34.92 41.27 -10 to 46 -20 to 21 -10 to 21 38 40 42 AJT342GALHH AJT126GALH AJT108GALH AJT108GALH 57 53.5 to 160.5 AJT360GBLHH AJT144GBLH AJT108GALH AJT108GALH 60 56.0 to 168.0 AJT378GBLHH AJT144GBLH AJT126GALH AJT108GALH 63 59.3 to 177.7 3-phase 4 wire, 400 V, 50Hz 107.0 112.0 118.5 120.0 123.5 131.0 33.08 34.56 37.52 31.45 33.20 35.94 3.23 3.24 3.16 3.82 3.72 3.64 13,000�3 (3,611�3) 13,000�3 (3,611�3) 13,000�3 (3,611�3) 64 64 65 65 66 67 80 80 80 11.0�3 11.0�3 11.0�3 Blue fin Blue fin Blue fin 1,690 1,690 1,690 1,240�3 1,240�3 1,240�3 765 765 765 286�3 286�3 286�3 R410A R410A R410A 11.8�3 11.8�3 11.8�3 19.05 19.05 19.05 34.92 34.92 34.92 41.27 41.27 41.27 -10 to 46 -10 to 46 -10 to 46 -20 to 21 -20 to 21 -20 to 21 -10 to 21 -10 to 21 -10 to 21 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. *1: Minimum connectible indoor unit number is 2. *2: These are the measured values in the manufacturer's anechoic chamber. Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here. 59 AIRSTAGETM INDOOR UNITS 60 16 types and 93 models available to meet the requirements of almost any building design. The AIRSTAGETM indoor units were developed to be highly efficient, compact, low noise producing with user friendly operation. With a variety of indoor units and capacities available, Fujitsu General has a unit that's easy to install and maintain and matches almost any requirement. INDOOR UNITS LINEUP 4-way Flow Compact Cassette 4-way Flow Cassette Circular Flow Cassette Mini Duct Slim Duct / Slim Concealed Floor Medium Static Pressure Duct High Static Pressure Duct Compact Floor Floor / Ceiling Ceiling Wall Mounted (EEV Internal / External) 61 AIRSTAGETM Indoor units INDOOR UNITS LINEUP Comprehensive range of indoor units with various design and capacity ranges to suit most air conditioning needs. 16 types, 93 models, with a capacity range from 2.2kW to 28.0kW. Indoor units range Model code Capacity range (kW) 4-way Flow Compact Cassette 4-way Flow Circular Flow Duct Mini Duct (With drain pump) Slim Duct (With drain pump) Medium Static Pressure Duct 7 9 12 14 18 2.2 2.8 3.6 4.5 5.6 AUXB007GLEH AUXB07GALH (Slim type) (Large type) AUXB009GLEH AUXB09GALH AUXB012GLEH AUXB12GALH AUXB014GLEH AUXB14GALH AUXB018GLEH AUXB18GALH AUXD18GALH AUX A18G A LH*1 (Slim type) AUXM018GLEH AUX M018GL A H (Large type) AUXK018GLEH AUXK018GL A H ARXK007GLEH ARXK009GLEH ARXK012GLEH ARXK014GLEH ARXK018GLEH ARXD007GLEH ARXD009GLEH ARXD012GLEH ARXD014GLEH ARXD018GLEH Floor Ceiling Wall Mounted 62 High Static Pressure Duct Floor (Same as Ceiling models) Slim Concealed Floor (Same as Slim Duct models) Compact Floor Compact Floor (EEV external) Ceiling Wall Mounted Wall Mounted (EEV external) ABYA012GTEH ABYA014GTEH ABYA018GTEH ARXD007GLEH ARXD009GLEH ARXD012GLEH ARXD014GLEH ARXD018GLEH AGYA007GCEH AGYE007GCEH AGYA009GCEH AGYE009GCEH AGYA012GCEH AGYE012GCEH AGYA014GCEH AGYE014GCEH With this model, connection of EV kit is necessary. ABYA012GTEH ABYA014GTEH ABYA018GTEH ASYA007GTEH ASYE007GTEH ASYA009GTEH ASYE009GTEH ASYA012GCEH ASYE012GCEH ASYA014GCEH ASYA18GBCH ASYE014GCEH With this model, connection of EV kit is necessary. 24 30 34 36 45 54 60 72 90 96 7.1 9.0 10.0 11.2 12.5 14.0 18.0 22.4 25.0 28.0 AUXB024GLEH AUXB24GALH AUXD24GALH AUX A 24G A LH*1 AUXA30GALH AUXA34GALH AUXA36GALH AUX A45G A LH AUXA54GALH AUXM024GLEH AUX M024GL A H AUXM030GLEH AUX M030GL A H AUXK024GLEH AUXK024GL A H AUXK030GLEH AUXK030GL A H AUXK034GLEH AUXK034GL A H AUXK036GLEH AUXK036GL A H AUXK045GLEH AUXK045GL A H AUXK054GLEH AUXK054GLAH ARXK024GLEH ARXD024GLEH A R X A024GLEH A R X A030GLEH A R X A036GLEH A R X A045GLEH ARXC036GTEH ARXC36GATH ARXC45GATH A R XC60G ATH*2 A R XC072GTEH*2 A R XC090GTEH*2 A R XC096GTEH*2 ABYA024GTEH ARXD024GLEH ABYA024GTEH ABYA030GTEH ABYA036GTEH ABYA045GTEH ABYA054GTEH ASYA24GBCH ASYA030GTEH ASYA034GTEH *1:AUXA18 / 24GALH cannot be connected to J-III L series. *2: ARXC60 / 072 / 090 / 096G cannot be connected to J-IIS series and J-III series. 63 AIRSTAGETM Indoor units 4-way Flow Compact Cassette Models (Slim type) AUXB007GLEH / AUXB009GLEH / AUXB012GLEH AUXB014GLEH / AUXB018GLEH / AUXB024GLEH AUXB07GALH / AUXB09GALH / AUXB12GALH AUXB14GALH / AUXB18GALH / AUXB24GALH Features 2-stage turbo fan High efficiency design through 2-stage structure Air distribution is evenly spread across the heat exchanger due to the new 2-stage turbo fan which produces two separate airflow streams. 1-stage += 2-stage 2-stage turbo fan Heat exchange efficiency 20%UP Previous turbo fan In the case of a previous fan, the air outlet range was narrow as the airflow moved to the motor side which meant the velocity of air passing through the heat exchanger was uneven. Wind velocity Fast Slow Quiet operation Optimised wing form (laminar wing type) and wing number (7 blades each) Designed by CFD-analysis (fluid) simulations Adoption of laminar wing Quiet Laminar wing Airflow runs through smoothly along the laminar wing Spin direction Airflow direction Quiet No airflow separation Improvement of the airflow distribution 1 A B C D 3 2 Grille cover 1 Maintenance of fan motor and fan Maintenance of the fan motor and fan can be done easily after taking off the panel as the bell mouth of the fan can be removed easily. A: Fan motor C :Bell-mouth B: 2-stage turbo fan D: Panel 2 Air filter: standard equipment 3 Adaptation of transparent drainage parts During installation, maintenance and operation, the drain pump and kit can be checked easily. 64 High ceiling mode The compact cassette can be installed up to a height of 3.0m (12 / 14 / 18 / 24). Model code 7 9 12 14 18 24 The maximum height from floor to ceiling (m) Standard mode High ceiling mode 2.7 - 2.7 - 2.7 3.0 2.7 3.0 2.7 3.0 2.7 3.0 Compact design The world's first 24,000Btu model in the compact cassette category. (Easily installed by taking off ceiling panel of 600 x 600 size) 570mm 570mm High lift drain pump Ceiling panel Max. 700mm Optional parts Air outlet shutter plate: UTR-YDZB Insulation kit for high humidity: UTZ-KXGC Fresh air intake kit: UT Z-V X A A External power supply unit: Cassette Grille: UTZ-GXXA (AUXB***GLEH) UTG-UFYC-W Specifications Model name Power source Capacity Cooling kW Heating Input power W High Med-H* Airflow rate Med Med-L* m3/h (l/s) Low Quiet* High Med-H* Sound pressure Med dB level Med-L* (A) Low Quiet* Dimensions (H � W � D) mm Weight kg Connection Liquid (flare) pipe diameter Gas (flare) mm Drain hose diameter (I.D./O.D.) Model name Cassette g rille Dimensions (H�W�D) mm Weight kg AUXB007GLEH AUXB07GALH AUXB009GLEH AUXB09GALH 2.2 2.8 2.8 3.2 25 25 540 (150) 550 (153) 500(138) 520 (144) 460 (127) 480 (133) 420 (116) 440 (122) 390 (108) 400 (111) 350 (97) 350 (97) 34 35 32 33 30 31 28 29 27 27 25 25 245 � 570 � 570 245 � 570 � 570 15 15 6.35 6.35 12.70(GALH) / 9.52(GLEH) 12.70(GALH) / 9.52(GLEH) AUXB012GLEH AUXB12GALH AUXB014GLEH AUXB14GALH Single - phase, ~230V, 50Hz 3.6 4.5 4.1 5.0 29 35 600 (167) 680 (189) 560 (156) 620 (172) 520 (144) 560 (156) 480 (133) 500 (139) 430 (119) 440 (122) 390 (108) 390 (108) 37 38 34 37 33 34 31 32 29 30 27 27 245 � 570 � 570 245 � 570 � 570 15 15 6.35 6.35 12.70 12.70 25 / 32 UTG-UFYC-W 49 � 700 � 700 2.6 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. Dimensions (Unit: mm) 530 (Bolt pitch) AUXB018GLEH AUXB18GALH 5.6 6.3 36 710 (197) 660 (183) 590 (164) 520 (144) 460 (128) 400 (111) 41 39 36 33 30 27 245 � 570 � 570 17 9.52(GALH) / 6.35(GLEH) 15.88(GALH) / 12.70(GLEH) AUXB024GLEH AUXB24GALH 7.1 8.0 84 1,030 (286) 910 (253) 790 (231) 680 (189) 560 (156) 450 (125) 50 46 43 39 35 30 245 � 570 � 570 17 9.52 15.88 * AUXB***GLEH only 580-660 (Ceiling openings) 540 (Bolt pitch) 570 (Indoor unit) 700 75 58 124 262 700 Bottom view Side view 30 49 245 146 40 135 135 102 250 40 99 250 Top view 108 30 222 116 Control box Liquid pipe Gas pipe Side view Ceiling 65 AIRSTAGETM Indoor units 4-way Flow Cassette Models (Slim type) AUXD18GALH / AUXD24GALH Models (Large type) AUXA18GALH / AUXA24GALH / AUXA30GALH AUXA34GALH / AUXA36GALH / AUXA45GALH AUXA54GALH (Slim type) (Large type) Features High efficiency turbo fan with 3-dimensional blade High efficiency airflow distribution has been achieved by the introduction of a 3 dimensional blade which increases the air passing over the heat exchanger. 500mm 3-dimensional blade Wind velocity Fast Slow Heat exchanger < motor side > Quiet No airflow separation Previous turbo fan Air passing through the heat exchanger was uneven and the air would only flow close to the ceiling. 450mm Previous blade Heat exchanger < motor side > Uneven airflow Separation phenomenon of airflow causes noise Spin direction Airflow direction Turbulent flow noise Improvement of the airflow distribution The unique design of the louvres and added space between the chassis and ceiling maximises airflow distribution within the room. Bottom view Adjustment of hanger position is possible after installation Detachable grille corner Adjustment can be done by taking off the corner part 66 Front part Ceiling Rear part Round louvre Much less temperature irregularity happens by spreading airflow widely High ceiling mode This cassette can be installed up to a height of 4.2m (36 / 45 / 54). Model code 18 24 30 34 36 45 54 The maximum height from floor to ceiling (m) Standard mode High ceiling mode 3.0 3.5 3.0 3.5 3.2 3.6 3.2 3.6 3.2 4.2 3.2 4.2 3.2 4.2 One way installation Parallel apertures High lift drain pump Ceiling panel Max. 850mm Optional parts IR receiver unit: UTY-LRHYB1 Air outlet shutter plate: UTR-YDZK Panel spacer: UTG-BKXA-W Insulation kit for high humidity: UTZ-KXRA Wide panel: UTG-AKXA-W Fresh air intake kit: UTZ-VXRA Cassette grille: UTG-UGYA-W Specifications Model name AUXD18GALH AUXD24GALH AUXA18GALH AUXA24GALH AUXA30GALH AUXA34GALH AUXA36GALH AUXA45GALH AUXA54GALH Power source Single - phase, ~230V, 50Hz Cooling 5.6 7.1 5.6 7.1 9.0 10.0 11.2 12.5 14.0 Capacity kW Heating 6.3 8.0 6.3 8.0 10.0 11.2 12.5 14.0 16.0 Input power W 39 46 51 51 59 77 80 99 119 Airflow rate High Med Low m3/h (l/s) 1,150 (319) 940 (261) 870 (242) 1,280 (356) 1,040 (289) 870 (242) 1,420 (394) 1,420 (394) 1,230 (342) 1,230 (342) 1,100 / 1,000*1(306 / 278) 1,100 / 1,000*1(306 / 278) 1,600 (444) 1,300 (361) 1,100 (306) 1,750 (486) 1,300 (361) 1,100 (306) 1,800 (500) 1,300 (361) 1,100 (306) 1,900 (528) 1,370 (381) 1,100 (306) 2,000 (556) 1,370 (381) 1,100 (306) High 36 38 40 40 40 43 44 46 47 Sound pressure level Med dB (A) 30 33 36 36 38 38 38 39 39 Low 29 29 33 / 31*1 33 / 31*1 33 33 33 33 33 Dimensions (H � W � D) mm 246 � 840 � 840 246 � 840 � 840 288 � 840 � 840 288 � 840 � 840 288 � 840 � 840 288 � 840 � 840 288 � 840 � 840 288 � 840 � 840 288 � 840 � 840 Weight kg 22 22 27 27 27 27 27 27 27 Connection Liquid (flare) pipe diameter Gas (flare) mm 9.52 15.88 9.52 15.88 9.52 15.88 9.52 15.88 9.52 15.88 9.52 19.05 9.52 19.05 9.52 19.05 9.52 19.05 Drain hose diameter (I.D./O.D.) 25 / 32 Model name UTG-UGYA-W Cassette grille Dimensions (H�W�D) mm 50 � 950 � 950 Weight kg 5.5 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. *1: This value is under cooling operation. Dimensions (Unit: mm) AUXD18 / AUXD24 IR receiver (option) 950 796 Hanging bolt position 420 699 Hanging bolt position 860 to 910 Ceiling opening 840 : Indoor unit 607 950 142 (Control) Box Ceiling 142 200 10 Drain hose 358 358 278 60 40 44 140 289(256) Liquid pipe Gas pipe Wire hole 67 AIRSTAGETM Indoor units Circular Flow Cassette Models (Slim type) AUXM018GLEH / AUXM024GLEH / AUXM030GLEH AUXM018GLAH / AUXM024GLAH / AUXM030GLAH Models (Large type) AUXK018GLEH / AUXK024GLEH / AUXK030GLEH AUXK034GLEH / AUXK036GLEH / AUXK045GLEH AUXK054GLEH AUXK018GLAH / AUXK024GLAH / AUXK030GLAH AUXK034GLAH / AUXK036GLAH / AUXK045GLAH AUXK054GLAH (Slim type) (Large type) Features Unique Circular Flow design The new cassette type creates a consistent and even temperature via multi-directional 360� airflow functionality. This is achieved by mounting a high performance DC fan motor, new turbo fan and unique seamless airflow louvre design. �7mm high density heat exchanger New DC fan motor Highly efficient turbo fan Seamless airflow louvre Uniform temperature air conditioning Achieve a consistent and even temperature in the room with circular flow and wide vertical airflow spreading conditioned air to every corner of the room. Comfortable! Individual louvre control Each louvre can be set individually with the touch panel wired remote control, allowing different directional airflows according to various room layouts. * Touch Panel Wired RC (UTY-RNRYZ3) only Comfortable air conditioning by preventing direct blowing of cold air and by providing swinging airflow simultaneously. Efficient air conditioning based on the room layout 68 Human sensor increases energy saving operation Energy saving operation starts automatically by detecting the motion of a person. The human sensor detects movement and activates or deactivates energy saving mode accordingly. Two modes can be selected: save operation and stop mode. *Touch Panel Wired RC (UTY-RNRYZ3) only 2 modes can be selected Auto saving Power is saved while people are away. Auto OFF Operation stops after people go out. Optional parts IR receiver unit: UTY-LBHXD Human sensor kit: UTY-SHZXC Air outlet shutter plate: UTR-YDZK Panel spacer: UTG-BKXA-W Wide panel: UTG-AGXA-W Insulation kit for high humidity: UTZ-KXRA Fresh air intake kit: UTZ-VXRA External power supply unit: Cassette grille: UTZ-GXXA (AUXM***GLEH, AUXK***GLEH) UTG-UKYC-W Specifications Model name Power source Capacity Cooling kW Heating Input power W High Med-H Airflow rate Med Med-L m3/h (l/s) Low Quiet High Med-H Sound pressure Med dB level Med-L (A) Low Quiet Dimensions (H � W � D) mm Weight kg Connection Liquid (flare) pipe diameter Gas (flare) mm Drain hose diameter (I.D./O.D.) Model name Cassette grille Dimensions (H�W�D) mm Weight kg AUXM018GLEH AUXM024GLEH AUXM030GLEH AUXK018GLEH AUXK024GLEH AUXK030GLEH AUXK034GLEH AUXK036GLEH AUXK045GLEH AUXK054GLEH AUXM018GLAH AUXM024GLAH AUXM030GLAH AUXK018GLAH AUXK024GLAH AUXK030GLAH AUXK034GLAH AUXK036GLAH AUXK045GLAH AUXK054GLAH Single - phase, ~230V, 50Hz 5.6 7.1 9.0 5.6 7.1 9.0 10.0 11.2 12.5 14.0 6.3 8.0 10.0 6.3 8.0 10.0 11.2 12.5 14.0 16.0 20 25 49 40 40 47 47 61 89 116 1,050(292) 1,120(311) 1,470(408) 1,420(394) 1,420(394) 1,440(400) 1,440(400) 1,620(450) 1,820(506) 2,040(567) 930(258) 1,050(292) 1,160(322) 1,360(378) 1,360(378) 1,400(389) 1,400(389) 1,500(417) 1,590(442) 1,800(500) 900(250) 930(258) 1,070(297) 1,300(361) 1,300(361) 1,340(372) 1,340(372) 1,400(389) 1,500(417) 1,590(442) 870(242) 900(250) 930(258) 1,270(353) 1,270(353) 1,300(361) 1,300(361) 1,340(372) 1,400(389) 1,440(400) 810(225) 870(242) 900(250) 1,200(333) 1,200(333) 1,280(356) 1,280(356) 1,280(356) 1,300(361) 1,300(361) 780(217) 780(217) 780(217) 1,150(319) 1,150(319) 1,150(319) 1,150(319) 1,150(319) 1,150(319) 1,150(319) 33 35 40 38 38 39 39 41 44 47 32 33 36 37 37 38 38 40 42 45 31 32 34 36 36 37 37 38 40 42 30 31 32 35 35 36 36 37 38 39 29 30 31 34 34 35 35 36 36 36 28 28 28 33 33 33 33 33 33 33 246�840�840 246�840�840 246�840�840 288�840�840 288�840�840 288�840�840 288�840�840 288�840�840 288�840�840 288�840�840 24.0 24.5 24.5 26.5 26.5 29.5 29.5 29.5 29.5 29.5 6.35 9.52 9.52 6.35 9.52 9.52 9.52 9.52 9.52 9.52 12.70 15.88 15.88 12.70 15.88 15.88 15.88 15.88 15.88 15.88 25 / 32 UTG-UKYC-W 53�950�950 6.0 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. When AUX*018GLAH, GLEH is connected to the outdoor unit other than J-IIIL, pipe diameter should be �9.52 / �15.88 (Liq / Gas) When AUXK036GLAH, GLEH, AUXK045GLAH, GLEH, and AUXK054GLAH, GLEH are connected to the outdoor unit other than J-IIIL, gas pipe diameter should be �19.05. Dimensions (Unit: mm) Models: AUXM018 / AUXM024 / AUXM030 IR receiver (option) Human sensor (option) 796 Hanging bolt position Models: AUXK018 / AUXK024 / AUXK030 / AUXK034 AUXK036 / AUXK045 / AUXK054 IR receiver (option) Human sensor (option) 796 Hanging bolt position 768 Hanging bolt position 950 950 200-205 (Control) box 950 Drain hose 840: Indoor unit 39 256 Ceiling Liquid pipe Gas pipe (Control) box 950 Drain hose 840: Indoor unit 39 298 200 Ceiling Liquid pipe Wire hole Gas pipe 69 768 Hanging bolt position AIRSTAGETM Indoor units Mini Duct Models (with drain pump) ARXK007GLEH / ARXK009GLEH / ARXK012GLEH ARXK014GLEH / ARXK018GLEH / ARXK024GLEH ARXK007 ARXK009 ARXK012 ARXK014 ARXK018 ARXK024 Features Compatible with the requirements of the installation space � The compact design allows for the installation space to be reduced down to a minimum depth of 450mm and height of 198mm � Lightweight: 16kg, 10% down (Unit: mm) 450 198 225* 600* * Minimum installation dimension Optimum airflow path and low noise operation Low noise is realised drastically with the stabilised airflow design Air Stabiliser Highly efficient DC fan motor Lower power consumption V-shape heat exchanger Easy design and maintenance for drainage By using the DC fan motor, it is possible to change the static pressure range from 0 to 50 Pa*. The change of static pressure range is possible by the remote controller. * 0 to 30 Pa. (012 model) Built-in drain pump as standard: Maintenance is easy Parts can be replaced from the side of the body where maintenance is easier 70 6-speed control* Multistep airflow speed control allows this model to be installed in quiet areas. 6-step speed High Low noise 21 dB(A) at 007 / 009 models Med-H Med Med-L Low Quiet * Compatible remote controllers: UTY-RNRYZ3 / UTY-RSRY / UTY-RHRY / UTY-DCGYZ1 / UTY-DTGYZ1 / UTY-ALGXZ1 / UTY-APGXZ1 Auto louvre grille kit (option) � Thin design provides a comfortable living environment over a wide area � Automatic louvre grille provides comfortable air conditioning from floor to ceiling (option) Optional parts Remote sensor unit: UTY-XSZX IR receiver unit: UTB-TWC Auto louvre grille kit: UTD-GXTA-W (for ARXK007 / 009 / 012 / 014) UTD-GXTB-W (for ARXK018) UTD-GXTC-W (for ARXK024) External power supply unit: UTZ-GXXA Specifications Model name Power source Capacity Cooling Heating Input power High Med-H Airflow rate Med Med-L Low Quiet Static pressure range Standard static pressure High Med-H Sound pressure level Med Med-L Low Quiet Dimensions (H � W � D) Weight Connection Liquid (flare) pipe diameter Gas (flare) Drain hose diameter (I.D./O.D.) kW W m3/h (l/s) Pa dB (A) mm kg mm AR XK007GLEH 2.2 2.8 28 460(128) 440(122) 420(117) 400(111) 370(103) 340(94) 0 to 30 10 26 25 24 23 22 21 198 � 700 � 450 15.5 6.35 9.52 ARXK009GLEH 2.8 3.2 28 460(128) 440(122) 420(117) 400(111) 370(103) 340(94) 0 to 30 10 26 25 24 23 22 21 198 � 700 � 450 15.5 6.35 9.52 AR XK012GLEH AR XK014GLEH Single - phase, ~230V, 50Hz 3.6 4.5 4.0 5.0 35 66 550(153) 760(211) 520(144) 660(183) 480(133) 560(156) 450(125) 490(136) 410(114) 410(114) 340(94) 340(94) 0 to 30 0 to 50 10 15 29 34 27 31 26 28 25 26 24 24 22 22 198 � 700 � 450 198 � 700 � 450 16.0 16.0 6.35 6.35 12.70 12.70 25 / 32 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. AR XK018GLEH 5.6 6.3 73 930(258) 840(233) 740(206) 640(178) 540(150) 470(131) 0 to 50 15 33 30 28 26 24 22 198 � 900 � 450 19.0 6.35 12.70 AR XK024GLEH 7.1 8.0 80 1,160(322) 1,060(294) 960(267) 860(239) 750(208) 610(169) 0 to 50 15 32 30 28 27 25 22 198 � 1,100 � 450 22.5 9.52 15.88 Dimensions (Unit: mm) 775 52 Drain port 30 10 30 150 182 193 450 295 72 153 174 Rear view View A 1 Refrigerant pipe flare connection (liquid) 2 Refrigerant pipe flare connection (gas) 3 Drain hose connection ARXK007-014 A P100�6=600 B 650 C 752 D 650 E 665 F 700 ARXK018 P100�8=800 850 952 850 864 900 ARXK024 P100�10=1,000 1,050 1,152 1,050 1,064 1,100 198 168 150 78 57 A B C Top view D E F Front view 49 49 56 78 85 66 92 Side view 43 169 33 (Drain hose) 71 AIRSTAGETM Indoor units Slim Duct / Slim Concealed Floor Models (with drain pump) ARXD007GLEH / ARXD009GLEH / ARXD012GLEH ARXD014GLEH / ARXD018GLEH / ARXD024GLEH ARXD007 ARXD009 ARXD012 ARXD014 Slim Concealed Floor ARXD018 ARXD024 Features Slim design With a slim design, this indoor unit can be installed in narrow ceiling spaces. Drain port Drain pump Height 198mm Drain pump built-in Air intake Air intake direction can be selected to match the installation site. Bottom side Flexible installation Ceiling concealed Back side Selectable static pressure By using DC fan motor, it is possible to change the static pressure range from 0 to 90Pa. The static pressure range is configurable through the remote controller. Static pressure range 0 to 90Pa *024 model is 0 to 50Pa High lift drain pump Max. 850mm Drain hose (standard accessory) Filter (accessory) ARXD007 / 009 / 012 / 014 / 018 Filter (2pcs.) ARXD024 Filter (3pcs.) Floor concealed 72 Auto louvre grille kit (option) Simple flat auto louvre will provide comfortable airflow and complement luxury interiors. Slim Duct Auto louvre grille Optional parts Remote sensor unit: UTY-XSZX IR receiver unit: UTB-TWC Auto louvre grille kit: UTD-GXTA-W (for ARXD007 / 009 / 012 / 014) UTD-GXTB-W (for ARXD018) UTD-GXTC-W (for ARXD024) External power supply unit: UTZ-GXXA Wired Remote Controller Wireless Remote Controller Specifications Model name Power source Capacity Cooling Heating Input power High Med-H Airflow rate Med Med-L Low Quiet Static pressure range Standard static pressure High Med-H Sound pressure level Med Med-L Low Quiet Dimensions (H � W � D) Weight Connection Liquid (flare) pipe diameter Gas (flare) Drain hose diameter (I.D./O.D.) kW W m3/h (l/s) Pa dB (A) mm kg mm AR XD007GLEH 2.2 2.8 44 550 (153) 520 (144) 480 (133) 410 (114) 370 (103) 320 (89) 0 to 90 25 28 26 25 24 22 21 198 � 700 � 620 17 6.35 9.52 ARXD009GLEH 2.8 3.2 50 600 (167) 510 (142) 460 (127) 420 (116) 370 (103) 320 (89) 0 to 90 25 29 27 25 24 22 21 198 � 700 � 620 17 6.35 9.52 AR XD012GLEH AR XD014GLEH Single - phase, ~230V, 50Hz 3.6 4.5 4.0 5.0 54 92 600 (167) 800 (222) 530 (147) 680 (189) 490 (136) 600 (167) 450 (125) 520 (144) 410 (114) 440 (122) 340 (94) 340 (94) 0 to 90 0 to 90 25 25 30 34 28 32 27 30 26 28 24 25 22 22 198 � 700 � 620 198 � 700 � 620 18 18 6.35 6.35 12.70 12.70 25 / 32 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. AR XD018GLEH 5.6 6.3 83 940 (261) 820 (228) 730 (203) 630 (175) 540 (150) 470 (131) 0 to 90 25 34 31 29 27 25 23 198 � 900 � 620 22 6.35 12.70 AR XD024GLEH 7.1 8.0 122 1,330 (369) 1,140 (317) 1,020 (283) 900 (250) 780 (217) 610 (169) 0 to 50 25 35 31 29 27 24 21 198 � 1,100 � 620 26 9.52 15.88 Dimensions (Unit: mm) *Service accessibility must be allowed for when installing the product. Please consult the installation manual for the necessary service access size. 51 G 174 71 152 30 (Bolt pitch) 377 30 198 F (All surroundings) 168 78 E D C (Bolt pitch) B A 82 48 47 55 78 89 119 163 43 10 31 69 144 264 367 620 ARXD007-014 A 700 B 650 C 734 D 650 E P100x6=600 F 18x�5 G 574 ARXD018 900 850 934 850 P100x8=800 22x�5 774 ARXD024 1,100 1,050 1,134 1,050 P100x10=1,000 26x�5 974 73 AIRSTAGETM Indoor units Medium Static Pressure Duct Models ARXA024GLEH / ARXA030GLEH ARXA036GLEH / ARXA045GLEH Features Slim and compact design In the case of bottom return air connection, not only does the indoor unit design allow for installation in a narrow ceiling space of up to 270mm, further space savings have been achieved by mounting the electrical control box internally inside the chassis. 1,200 1,135mm 270mm Control box is now included as part of the main chassis One touch operating and easy to install long life filter (optional parts) Low energy consumption through the high efficiency DC fan motor Improved motor efficiency compared to the previous model. 024 model 030 / 036 / 045 model Can be installed in various locations This unit can be installed in a range of locations such as high rise apartments through low static pressure design. It can also be installed in open spaces when higher static pressure is required, such as offices. Selectable with a wide range of static pressure It is possible to change the static pressure range from 0 to 150Pa. Static pressure range 0 to 150Pa 74 Easy maintenance See below for the case of rear suction type 1 Previous model 3 4 2 Large bottom panel: 1 piece New model 1 4 1.Control box 2 2.Fan casing 3.Fan 4.Motor 3 Bottom panel: 2 pieces Structural improvement is attained by making the bottom panel two pieces, front and rear. The internal fan casing is also manufactured in two pieces, namely upper and lower. The maintenance of the motor and fan can be easily carried out by removing the rear panel and the lower part of the casing while leaving the main chassis installed. Two direction drain piping Installation styles Embedded in ceiling Hanging from ceiling Duct indoor unit Two direction drain piping Static pressure setting via the remote controller Changing the static pressure range is possible with the remote controller Optional parts Remote sensor unit: UTY-XSZX Flange (round): UTD-RF204 Long life filter: UTD-LF25NA IR receiver unit: UTB-TWC Flange (square): UTD-SF045T Drain pump unit: UTZ-PX1NBA External power supply unit: UTZ-GXXA Specifications Model name Power source Capacity Cooling Heating Input power High Med-H Airflow rate Med Med-L Low Quiet Static pressure range Standard static pressure High Med-H Sound pressure level Med Med-L Low Quiet Dimensions (H � W � D) Weight Connection Liquid (flare) pipe diameter Gas (flare) Drain hose diameter (I.D./O.D.) kW W m3/h (l/s) Pa dB (A) mm kg mm AR X A024GLEH 7.1 8.0 94 1,280 (356) 1,180 (328) 1,090 (303) 1,000 (278) 920 (256) 840 (233) 0 to 150 40 36 33 31 29 28 26 270 � 1,135 � 700 36 9.52 15.88 ARXA030GLEH ARXA036GLEH Single - phase, ~230V, 50Hz 9.0 11.2 10.0 12.5 108 194 1,410 (392) 1,840 (511) 1,350 (375) 1,750 (486) 1,280 (356) 1,660 (461) 1,240 (344) 1,600 (444) 1,190 (331) 1,530 (425) 1,150 (319) 1,470 (408) 0 to 150 0 to 150 50 50 34 37 33 36 32 35 31 35 30 34 29 33 270 � 1,135 � 700 270 � 1,135 � 700 40 40 9.52 9.52 15.88 15.88 25 / 32 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. ARXA045GLEH 12.5 14.0 240 1,970 (547) 1,910 (530) 1,860 (517) 1,780 (494) 1,710 (475) 1,640 (456) 0 to 150 60 41 40 38 38 37 36 270 � 1,135 � 700 40 9.52 15.88 Dimensions (Unit: mm) *Service accessibility must be allowed for when installing the product. Please consult the installation manual for the necessary service access size. 270 32 240 138 264 264 264 3 82 �200 (knock out hole) 138 161 �205 hole Front view 1 Refrigerant piping flare connection (liquid) 2 Refrigerant piping flare connection (gas) 3 Drain piping connection (drain pipe) 75 P.C.D. �225 121 Side view (L) 173 447(Bolt pitch) 1,177(Bolt pitch) Outlet 1,015 1,135 Top view Rear view 700 168 240 281 114 66 32 1 3 2 107 240 270 Side view (R) 75 AIRSTAGETM Indoor units High Static Pressure Duct Models AR XC036GTEH ARXC36GATH / ARXC45GATH / ARXC60GATH Models ARXC072GTEH / ARXC090GTEH Models AR XC096GTEH ARXC036 ARXC36 ARXC45 ARXC60 ARXC072 ARXC090 Features Static pressure selection By using DC fan motor, it is possible to change the static pressure range from 0 to 200Pa (36 model) / 300Pa (96 model). [Pa] 200 or 300 MAX. 200Pa (36 / 45 / 60 models) MAX. 300Pa (72 / 90 models) MAX. 0 [m3/h] 300Pa Air flow rate (96 model) ARXC096 Low noise Models: 36 / 45 / 60 models Cutting off the corners of the conventional indoor unit front panel and fan casing has enabled less turbulent airflow. Low noise is realised by adopting a plastic case and a plastic fan. New model (36 model) Low energy consumption with high efficiency DC fan motor Improved motor efficiency from previous model. (36 model) (96 model) ARXC036GTEH : Plastic fan [42dB(A)] * Model: material (At 100Pa: actual noise measurement value) Plastic fan � 225mm Casing (plastic) 500mm Heat exchanger 400mm 76 400 450 550 Easy installation (compact size and lightweight) A compact size and lightweight indoor unit has been developed by reducing the basic chassis and the overall material weight. (36 / 45 / 60 models) (72 / 90 models) 1,050 500 1,587 (96 model) (Unit: mm) 700 1,587 700 Optional parts Long-life filter: UTD-LF60KA (For ARXC036 / 36 / 45 / 60) IR receiver unit: UTB-TWC (For ARXC**GATH) Remote sensor unit: UTY-TRHX (For ARXC***GTEH) UTY-XSZX External power supply unit: UTZ-GXXA (ARXC***GTEH) Specifications Model name AR XC036GTEH AR XC36G ATH AR XC45G ATH AR XC60G ATH* AR XC072GTEH AR XC090GTEH AR XC096GTEH Power source Single - phase, ~230V, 50Hz Cooling 11.2 11.2 12.5 18.0 22.4 25.0 28.0 Capacity kW Heating 12.5 12.5 14.0 20.0 25.0 28.0 31.5 Input power W 207 405 715 730 1,110 1,250 838 Airflow rate High Med Low m3/h (l/s) 1,990 (552) 1,680 (466) 1,330 (369) 2,600 (722) 1,950 (542) 1,450 (403) 3,000 (833) 2,700 (750) 2,300 (639) 3,350 (931) 2,850 (792) 2,550 (708) 3,900 (1,083) 3,300 (917) 3,000 (833) 4,300 (1,195) 4,000 (1,111) 3,500 (972) 4,850 (1,347) 4,250 (1,181) 3,600 (1,000) Static pressure range Standard static pressure 0 to 200 Pa 100 100 to 200 100 100 to 250 100 100 to 250 100 50 to 300 260 100 to 300 250 0 to 300 150 High 42 45 47 48 47 48 48 Sound pressure level Med dB (A) 36 38 43 44 43 46 45 Low 32 32 40 41 40 44 42 Dimensions (H � W � D) mm 400 � 1,050 � 500 400 � 1,050 � 500 400 � 1,050 � 500 400 � 1,050 � 500 450 � 1,550 � 700 450 � 1,550 � 700 550 � 1,587 � 700 Weight kg 40 43 46 46 83 85 105 Connection pipe diameter Liquid Gas mm 9.52 (Flare) 15.88 (Flare) 9.52 (Flare) 19.05 (Flare) 9.52 (Flare) 19.05 (Flare) 9.52 (Flare) 19.05 (Flare) 9.52(Flare) 19.05(Flare) 9.52(Flare) 19.05(Flare) 9.52 (Brazing) 22.22 (Brazing) Drain hose diameter (I.D./O.D.) 25 / 32 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. * ARXC60 / 072 / 090 / 096G cannot be connected to J-III series. Dimensions (Unit: mm) Models: ARXC036 / ARXC36 / ARXC45 / ARXC60 88 400 324 14 295 Side view (L) 585 500(Bolt pitch) Rear view 1,080(Bolt pitch) 1,000 862 851 1,050 Top view 71 371 356 208 108 1 2 3 4 Side view (R) 85 Front view 1 Refrigerant piping flare connection (liquid) 2 Refrigerant piping flare connection (gas) 3 Drain piping connection 41 123 139 Models: ARXC072 / ARXC090 46 60 Models: ARXC096 2 1 MAIN DARAIN PORT 60 49 SAFETY DARAIN PORT 235 318 403 427 33 56 450 370 15 8 68 Rear view 1,550 1,410 (Bolt pitch) 1,251 98 Main drain port Safety drain port 151 550 470 15 8 65 Rear view 81 1,587 1,410 (BOLT PITCH) 1,250 149 700 653(BOLT PITCH) 29 50 25 655 (Bolt pitch) 29 50 25 700 50 25 50 25 P160�2 =320 15 350 35 �3 Side view (L) P150�7=1,050 1,199 1,454 AIR FLOW Top view 75 127 Side view (R) 85 (Drain hose) Front view 1 Refrigerant pipe flare connection (liquid) 2 Refrigerant pipe flare connection (gas) 3 Drain hose P160�2 =320 15 350 35 Side view (L) P150�7=1,050 75 1,200 125 1,450 117 Top view (Drain hose) Front view 1 Refrigerant pipe flare connection (liquid) 2 Refrigerant pipe flare connection (gas) 3 Drain hose 77 42 327 411 504 527 38 AIRSTAGETM Indoor units Compact floor Models (EEV internal) AGYA007GCEH / AGYA009GCEH AGYA012GCEH / AGYA014GCEH Models (EEV external) AGYE007GCEH / AGYE009GCEH AGYE012GCEH / AGYE014GCEH Features 2 fans and wide airflow Individual vertical airflow by 2 fans can control the whole room comfortably. Cooling Prevents cold air from falling at operation start at stable operation Heating Window Prevents cold draft from window at stable operation Quiet operation Quiet operation is realised by 6 fan speed control. (via 2 wired controllers) Low noise 22 dB(A) 6-Step Speed High at 007 / 009 models Med-H Med Med-L Low Quiet * Compatible remote controllers are as follows: UTY-RNRYZ3 / UTY-RSRY / UTY-RHRY / UTY-DCGYZ1 / UTY-DTGYZ1 / UTY-ALGXZ1 / UTY-APGXZ1 78 Flexible and easy installation Due to compact and flexible methods for installation including floor, concealed, half concealed, or wall mounted, installation approach can be modified to match the room layout. Beneath standard window (unit:mm) Standard concave portion Min.900 Min. 700 600 700 740 200 Wall (unit:mm) (unit:mm) Half concealed (Optional parts necessary) (unit:mm) Min. 590 Max. 150 Min. 730 Max. 80 Flexible piping connection Drain hose and piping can be drawn flexibly in the right, left, sideways, and down directions. Back view 1 2 3 Drain hose 4 6 5 Piping Optional parts Half concealed kit: UTR-STA External power supply unit: UTZ-GXXA Specifications Model name Power source Capacity Cooling Heating Input power High Med-H Airflow rate Med Med-L Low Quiet High Med-H Sound pressure level Med Med-L Low Quiet Dimensions (H � W � D) Weight Connection Liquid (flare) pipe diameter Gas (flare) Drain hose diameter (I.D./O.D.) EV Kit (option) kW W m3/h (l/s) dB (A) mm kg mm AGYA007GCEH 2.2 2.8 16 470(131) 420(117) 390(108) 360(100) 330(92) 270(75) 37 35 33 31 29 22 600�740�200 15.0 6.35 9.52 - AGYA009GCEH 2.8 3.2 17 500(139) 450(125) 400(111) 360(100) 330(92) 270(75) 38 36 34 31 29 22 600�740�200 15.0 6.35 9.52 - AGYA012GCEH 3.6 4.0 22 590(164) 520(144) 470(131) 420(117) 390(108) 340(94) 42 39 37 35 33 30 600�740�200 15.0 6.35 12.70 - Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. AGYA014GCEH AGYE007GCEH Single - phase, ~230V, 50Hz 4.0 2.2 4.5 2.8 29 16 670(186) 470(131) 590(164) 420(117) 520(144) 390(108) 450(125) 360(100) 390(108) 330(92) 340(94) 270(75) 46 37 42 35 39 33 36 31 33 29 30 22 600�740�200 600�740�200 15.0 14.5 6.35 6.35 12.70 9.52 13.8 / 15.8 to 16.7 - UTR-EV09XB AGYE009GCEH 2.8 3.2 17 500(139) 450(125) 400(111) 360(100) 330(92) 270(75) 38 36 34 31 29 22 600�740�200 14.5 6.35 9.52 UTR-EV09XB AGYE012GCEH 3.6 4.0 22 590(164) 520(144) 470(131) 420(117) 390(108) 340(94) 42 39 37 35 33 30 600�740�200 14.5 6.35 12.70 UTR-EV14XB AGYE014GCEH 4.0 4.5 29 670(186) 590(164) 520(144) 450(125) 390(108) 340(94) 46 42 39 36 33 30 600�740�200 14.5 6.35 12.70 UTR-EV14XB When AGY*007GCEH and AGY*009GCEH are connected to the outdoor unit other than J-IIIL, gas pipe diameter should be �12.70. Dimensions (Unit: mm) 200 600 740 Front view Side view 79 AIRSTAGETM Indoor units Floor / Ceiling Models ABYA012GTEH / ABYA014GTEH ABYA018GTEH / ABYA024GTEH Features Flexible installation Example for floor installation Floor console Floor standing Example for ceiling installation Under ceiling Double auto swing A combination of up / down and right / left directional swing allows three dimensional air direction control. Right and left swing 2 3 4 1 5 5 steps selectable Up and down swing 80 1 2 3 4 4 steps selectable High power DC fan motor � High power � Wide rotation range � High efficiency Compact design Symmetrical, slim and compact design. (Unit: mm) Auto-closing louvre When operation is stopped, the louvres will automatically close. (This function is available on all non-ducted models) Super vane 655 Double Louvre super vane with newly developed special configuration boosts airflow sending cool air quickly to every corner of the room. 990 199 Optional parts External power supply unit: UTZ-GXXA Specifications Model name Power source Capacity Cooling Heating Input power High Med-H Airflow rate Med Med-L Low Quiet High Med-H Sound pressure level Med Med-L Low Quiet Dimensions (H � W � D) Weight Connection Liquid (flare) pipe diameter Gas (flare) Drain hose diameter (I.D./O.D.) kW W m3/h (l/s) dB (A) mm kg mm ABYA012GTEH 3.6 4.0 30 660 (183) 620 (172) 580 (161) 550 (153) 520 (144) 490 (136) 36 34 33 31 29 28 199 � 990 � 655 25 6.35 12.70 ABYA014GTEH ABYA018GTEH Single - phase, ~230V, 50Hz 4.5 5.6 5.0 6.3 42 74 780 (216) 1,000 (277) 740 (206) 910 (253) 690 (192) 830 (231) 640 (178) 750 (208) 600 (167) 660 (183) 550 (153) 580 (161) 40 46 39 44 38 42 36 40 35 37 34 35 199 � 990 � 655 199 � 990 � 655 26 26 6.35 6.35 12.70 12.70 25 / 32 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. Dimensions (Unit: mm) ABYA024GTEH 7.1 8.0 99 1,000 (277) 930 (258) 870 (242) 800 (222) 740 (206) 680 (188) 47 45 43 41 39 37 199 � 990 � 655 27 9.52 15.88 21 2 1 1 Refrigerant piping flare connection (liquid) 2 Refrigerant piping flare connection (gas) 3 Drain piping connection 3 3 81 AIRSTAGETM Indoor units Ceiling Models ABYA030GTEH / ABYA036GTEH ABYA045GTEH / ABYA054GTEH Features Installation Open Concealed Wall mounted (Field supplied) General installation pattern which suspends the indoor unit from the ceiling. Installation pattern where part of the indoor unit is embedded into the ceiling. Installation which fixes the indoor unit to the wall by the use of wall brackets (field supplied). This type of installation can be used when the ceiling space is insufficient. Double auto swing and wide airflow Auto airflow direction and auto swing Right and left 5 steps selectable Up and down 1 2 3 4 4 steps selectable 82 Long airflow Long airflow ensures comfort to every corner of a large room. Long distance air-flow High-powered DC fan motor � High power � Wide rotation range � High efficiency Fresh air intake Indoor Fresh air Outdoor Slim and Compact design Hight 240mm High lift drain pump Optional drain pump unit allows flexible installation design. Max. 500mm Optional parts Drain Pump Unit: UTR-DPB24T Flange: UTD-RF204 External Power Supply Unit: UTZ-GXXA Specifications Model name Power source Capacity Cooling Heating Input power High Med-H Airflow rate Med Med-L Low Quiet High Med-H Sound pressure level Med Med-L Low Quiet Dimensions (H � W � D) Weight Connection Liquid (flare) pipe diameter Gas (flare) Drain hose diameter (I.D./O.D.) kW W m3/h (l/s) dB (A) mm kg mm ABYA030GTEH 9.0 10.0 66 1,630 (452) 1,520 (422) 1,420 (394) 1,320 (367) 1,220 (339) 1,140 (316) 42 40 39 37 35 33 240 � 1,660 � 700 46 9.52 15.88 ABYA036GTEH ABYA045GTEH Single - phase, ~230V, 50Hz 11.2 12.5 12.5 14.0 85 131 1,690 (469) 2,010 (558) 1,560 (433) 1,840 (511) 1,450 (403) 1,690 (469) 1,360 (378) 1,530 (425) 1,270 (353) 1,380 (383) 1,170 (325) 1,230 (342) 45 48 41 46 39 45 38 41 36 38 34 35 240 � 1,660 � 700 240 � 1,660 � 700 48 48 9.52 9.52 15.88 15.88 25 / 32 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. Dimensions (Unit: mm) ABYA054GTEH 14.0 16.0 180 2,270 (629) 2,070 (575) 1,860 (517) 1,660 (461) 1,470 (408) 1,280 (355) 51 49 46 43 40 36 240 � 1,660 � 700 48 9.52 15.88 1 Refrigerant piping flare connection (liquid) 2 Refrigerant piping flare connection (gas) 3 Drain piping connection 213 3 83 AIRSTAGETM Indoor units Wall Mounted Models (EEV internal) ASYA007GTEH / ASYA009GTEH Models (EEV external) ASYE007GTEH / ASYE009GTEH Feature Highly efficient compact design 5mm high density heat exchanger is mounted for the first time in the industry. High density heat exchanger Making the tube thin: 7mm 5mm Increase of heat exchanger volume through high density and adopting a sub heat exchanger 6 fan speed control Multistep airflow control is possible to suit the environment. Fan speed Quiet Low noise 22 dB(A) 6-Step Speed High Med-H Med Med-L Low Quiet * Compatible remote controllers are as follows: UTY-RNRYZ3 / UTY-RSRY / UTY-RHRY / UTY-DCGYZ1 / UTY-DTGYZ1 / UTY-ALGXZ1 / UTY-APGXZ1 84 Easy installation Communication wiring can be installed easily by opening the front panel and wire cover. Optimised design Efficient operation and refrigerant saving are realised by the optimum heat exchanger design suited for small rooms. Optional parts External power supply unit: UTZ-GXXA Specifications Model name Power source Capacity Cooling Heating Input power High Med-H Airflow rate Med Med-L Low Quiet High Med-H Sound pressure level Med Med-L Low Quiet Dimensions (H � W � D) Weight Connection Liquid (flare) pipe diameter Gas (flare) Drain hose diameter (I.D./O.D.) EV Kit (option) kW W m3/h (l/s) dB (A) mm kg mm ASYA007GTEH 2.2 2.8 19 550(153) 460(128) 420(117) 390(108) 360(100) 330(92) 35 32 30 27 24 22 262�820�206 7.5 6.35 9.52 - ASYA009GTEH ASYE007GTEH Single - phase, ~230V, 50Hz 2.8 2.2 3.2 2.8 34 19 720(200) 550(153) 570(158) 460(128) 500(139) 420(117) 410(114) 390(108) 360(100) 360(100) 330(92) 330(92) 43 35 38 32 34 30 29 27 24 24 22 22 262�820�206 262�820�206 7.5 7.0 6.35 6.35 9.52 9.52 13.8 / 15.8 to 16.7 - UTR-EV09XB ASYE009GTEH 2.8 3.2 34 720(200) 570(158) 500(139) 410(114) 360(100) 330(92) 43 38 34 29 24 22 262�820�206 7.0 6.35 9.52 UTR-EV09XB Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. When ASY*007GTEH and ASY*009GTEH are connected to an outdoor unit other than the J-IIIL range, gas pipe diameter will require an expander to alter the pipe size from 9.52mm to 12.70mm. Dimensions (Unit: mm) 820 206 262 85 AIRSTAGETM Indoor units Wall Mounted Models (EEV internal) ASYA012GCEH / ASYA014GCEH Models (EEV external) ASYE012GCEH / ASYE014GCEH Feature Highly efficient and compact design Highly efficient compact design is realised by mounting a high density and large heat exchanger. The compact body makes it possible to install discreetly even in a meeting room or office where comfortable air conditioning is provided. More comfortable airflow Comfortable air conditioning is provided by mounting our unique power diffuser. Heating Vertical airflow provides powerful floor level heating. Power diffuser Cooling Horizontal airflow does not blow cool air directly at the occupants in the room. High density heat exchanger 7mm Making the tube thin: 5mm Increase of heat exchanger volume due to high density and adopting sub heat exchanger Even temperature Improved heat exchanger effectiveness Human sensor increases energy saving operation Energy saving operation starts automatically by detecting the motion of a person in the space. There are 2 modes available, an energy saving mode or an aut-off mode. People go out AUTO SAVE AUTO OFF Human sensor People come back AUTO RESET OFF 86 Power diffuser 6 fan speed control Multistep airflow control is possible to suit the environment. Fan speed Quiet Low noise 24 dB(A) 6-Step Speed High Med-H Med Med-L Low Quiet * Compatible remote controllers are as follows: UTY-RNRYZ3 / UTY-RSRY / UTY-RHRY / UTY-DCGYZ1 / UTY-DTGYZ1 / UTY-ALGXZ1 / UTY-APGXZ1 Optional parts External power supply unit: UTZ-GXXA Specifications Model name Power source Capacity Cooling Heating Input power High Med-H Airflow rate Med Med-L Low Quiet High Med-H Sound pressure level Med Med-L Low Quiet Dimensions (H � W � D) Weight Connection Liquid (flare) pipe diameter Gas (flare) Drain hose diameter (I.D./O.D.) EV Kit (option) kW W m3/h (l/s) dB (A) mm kg mm ASYA012GCEH 3.6 4.0 25 690(192) 610(169) 560(156) 530(147) 470(131) 330(92) 40 37 35 33 30 24 268 � 840 � 203 8.5 6.35 12.70 - ASYA014GCEH ASYE012GCEH Single - phase, ~230V, 50Hz 4.0 3.6 4.5 4.0 36 25 800(222) 690(192) 740(206) 610(169) 680(189) 560(156) 610(169) 530(147) 550(153) 470(131) 330(92) 330(92) 44 40 42 37 40 35 37 33 34 30 24 24 268 � 840 � 203 268 � 840 � 203 8.5 8.5 6.35 6.35 12.70 12.70 13.8 / 15.8 to 16.7 - UTR-EV14XB Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. Dimensions (Unit: mm) ASYE014GCEH 4.0 4.5 36 800(222) 740(206) 680(189) 610(169) 550(153) 330(92) 44 42 40 37 34 24 268 � 840 � 203 8.5 6.35 12.70 UTR-EV14XB 840 203 268 87 AIRSTAGETM Indoor units Wall Mounted Models ASYA18GBCH / ASYA24GBCH Models ASYA030GTEH / ASYA034GTEH ASYA18 ASYA24 Feature Powerful and comfortable airflow Powerful airflow (ASYA030GTEH) Airflow 20% up! ASYA030 ASYA034 Power diffuser (ASYA18 / 24GBCH) Vertical airflow Horizontal airflow (24) (24) 33 32 31 30 29(�C) 15 16 17 18(�C) Human sensor (ASYA030 / 034GTEH only) A human sensor senses the movement of people to reduce operation when no one is in the room. The wasteful consumption of energy is reduced automatically to assist in energy usage reduction. (Available to wired remote controller as UTY-RNRYZ3) Human sensor SAVE AUTO RESET Quiet operation and 6 fan speed control Noise level is drastically reduced through the new airflow structure. Additionally, multistep quiet operation is available by 6 step sound level settings. 35dB(A) -2 dB(A) 33dB(A) Current model New model (030 / 034class) 6-Step Speed High Med-H Med Med-L Low Quiet * Compatible remote controllers are as follows: UTY-RNRYZ3 / UTY-RSRY / UTY-RHRY / UTY-DCGYZ1 / UTY-DTGYZ1 / UTY-ALGXZ1 / UTY-APGXZ1 Optional parts External power supply unit: UTZ-GXXA (For ASYA***GTEH) 88 Specifications Model name Power source Capacity Cooling Heating Input power High Med-H Airflow rate Med Med-L Low Quiet High Med-H Sound pressure level Med Med-L Low Quiet Dimensions (H � W � D) Weight Connection Liquid (flare) pipe diameter Gas (flare) Drain hose diameter (I.D./O.D.) kW W m3/h (l/s) dB (A) mm kg mm ASYA18GBCH 5.6 6.3 32 840(233) 770(214) 690(192) 41 39 35 320 � 998 � 238 15 6.35 12.70 12 / 16 ASYA24GBCH ASYA030GTEH ASYA034GTEH Single - phase, ~230V, 50Hz 7.1 9.0 10.0 8.0 10.0 11.2 60 74 103 1,100(306) 1,440(400) 1,620(450) / 1,520(422) - 1,200(333) 1,300(361) 910(253) 1,050(292) 1,120(311) - 940(261) 980(272) 730(203) 890(247) 890(247) - 700(194) 700(194) 48 53 55 / 54 - 49 51 43 45 47 - 42 43 35 39 39 - 33 33 320 � 998 � 238 340 x 1,150 x 280 340 x 1,150 x 280 15 18 18 9.52 9.52 9.52 15.88 15.88 15.88 13.8 / 15.8 to 16.7 Note: Specifications are based on the following conditions: Cooling: Indoor temperature of 27�CDB / 19�CWB, and outdoor temperature of 35�CDB / 24�CWB. Heating: Indoor temperature of 20�CDB / (15�CWB), and outdoor temperature of 7�CDB / 6�CWB. Pipe length: 7.5m; height difference between outdoor unit and indoor unit: 0m. Voltage: 230V. When ASYA18GBCH is connected to the outdoor unit other than J-IIIL, pipe diameter should be �9.52 / �15.88 (Liq / Gas). Dimensions (Unit: mm) Models: ASYA18 / ASYA24 Models: ASYA030 / ASYA034 998 238 1150 280 �32 �16 �12 320 340 25 520 590 721 520 1 Refrigerant piping flare connection (liquid) 2 Refrigerant piping flare connection (gas) 3 Drain piping connection 89 VENTILATION 90 EFFECTIVE HEAT EXCHANGE AND SIMULTANEOUS FRESH AIR VENTILATION High efficiency and low noise levels are achieved by using a highly efficient heat exchange process. A comfortable air conditioned space is achieved by conveniently selecting whether to use the heat exchange or normal ventilation setting according to the requirements of the space. VENTILATION Energy Recovery Ventilator Outdoor Air Unit Energy Recovery Ventilator Range Airflow rate (m3/h (l/s)) Model code 250 (69) 025 350 (97) 035 Energy Recovery Ventilator UTZ-BD025C UTZ-BD035C 500 (139) 050 800 (222) 080 1,000 (278) 100 UTZ-BD050C UTZ-BD080C UTZ-BD100C Outdoor Air Unit Range Airflow rate (m3/h (l/s)) Model code 1,080 (300) 054 Outdoor Air Unit ARXH054GTAH 1,680 (467) 072 ARXH072GTAH 2,100 (583) 096 ARXH096GTAH 91 Ventilation Energy Recovery Ventilator Models UTZ-BD025C UTZ-BD035C UTZ-BD050C UTZ-BD080C UTZ-BD100C UTZ-BD025C UTZ-BD035C UTZ-BD050C Controller UTZ-BD080C UTZ-BD100C Features Heat exchange ventilation and normal ventilation Heat exchange ventilation When a room is cooled or heated, the exhausted cooling / heating energy is recovered through heat exchange ventilation. Normal ventilation This operation is used during periods when the room space requires no cooling or heating effect, i.e. when there is minimal temperature difference between the indoor and outdoor environments. Adopts a highly efficient counterflow heat exchange element Outside air Exhaust air Supply air Room air Heat exchanger Energy efficiency and ecology Energy consumption is dramatically reduced by using a counterflow heat exchange element. The air conditioning load is reduced by approximately 20% and approximately 77% of the heat in the outgoing air is recovered, resulting in significant energy savings. Energy saving 20% Features of heat exchange element With the crossflow element, air moves in a straight line across the element. With the counterflow element, air flows through the element for a longer time (longer distance), so the heat exchange effect is improved. Other element (crossflow element) Fujitsu element (counterflow element) Quiet operation Significantly reducing low pressure loss and noise allows low noise operation. 92 Reverse mountable direct air supply / exhaust system Adoption of straight air supply / exhaust system: The duct design is simplified because the air supply / exhaust ducts are straight. Since each unit can be mounted in reverse position, only one inspection hole is needed for two units: Two units can share one inspection hole so duct work is easier and more flexible. Room air Straight unit Supply air Inspection cover Inspection hatch Room air Reverse mounted unit Exhaust air Outside air Exhaust air Slim shape and easier installation A counterflow heat exchange element is used for reduced noise and a slimmer, more compact body shape. Height 270mm UTZ-BD025C Height 317mm UTZ-BD035C / BD050C Height 388mm UTZ-BD080C / BD100C Improved static pressure Static pressure is improved by adopting a powerful fan motor allowing these units to be used in a wide variety of building types. Easy remote operation � Power : ON / OFF � Air volume : High / Low � Heat exchange /Normal Ventilation � ON / OFF Timer � Clean filter display Specifications Rated flow rate Model name Power source Input power Extra high / High / Low Airflow rate Extra high / High / Low External static pressure Extra high / High / Low Temperature exchange efficiency Extra high / High / Low W m3/h (l/s) Pa % 250 m3/h (69 l/s) UTZ-BD025C 128 / 123 / 96 250 / 250 / 190 (69 / 69 / 53) 105 / 95 / 45 75 / 75 / 77 HEAT EXCHANGE VENTIL ATION Energy exchange efficiency cooling Extra high / High / Low % 63 / 63 / 65 Energy exchange efficiency heating Sound pressure level Input power Extra high / High / Low Extra high / High / Low Extra high / High / Low NORMAL VENTIL ATION Airflow rate Extra high / High / Low External static pressure Extra high / High / Low Sound pressure level Extra high / High / Low Dimensions (W � D � H) Weight Outlet duct diameter Operation range Maximum humidity % dB* W m3/h (l/s) Pa dB* mm kg mm �C % 70 / 70 / 72 31.5 / 30.5 / 26.5 128 / 123 / 96 250 / 250 / 190 (69 / 69 / 53) 105 / 95 / 45 31.5 / 30.5 / 26.5 882 � 599 � 270 29 150 -10 to 40 85 * The noise level must be measured 1.5m below the centre of the unit. 350 m3/h (97l/s) UTZ-BD035C 190 / 185 / 168 350 / 350 / 240 (97 / 97 / 67) 140 / 60 / 45 75 / 75 / 78 66 / 66 / 71 69 / 69 / 73 33.0 / 31.0 / 25.5 190 / 185 / 168 350 / 350 / 240 (97 / 97 / 67) 140 / 60 / 45 33.0 / 31.0 / 25.5 1,050 � 804 � 317 49 150 -10 to 40 85 500 m3/h (139 l/s) UTZ-BD050C 220 - 240V, 50Hz 289 / 225 / 185 500 / 500 / 440 (139 / 139 / 122) 120 / 60 / 35 75 / 75 / 76 62 / 62 / 64 67 / 67 / 69 37.5 / 35.5 / 32.5 289 / 225 / 185 500 / 500 / 440 (139 / 139 / 122) 120 / 60 / 35 38.5 / 38.0 / 32.5 1,090 � 904 � 317 57 200 -10 to 40 85 800 m3/h (222 l/s) UTZ-BD080C 418 / 378 / 295 800 / 800 / 630 (222 / 222 / 175) 140 / 110 / 55 75 / 75 / 76 65 / 65 / 68 71 / 71 / 74 37.5 / 37.0 / 34.5 418 / 378 / 295 800 / 800 / 630 (222 / 222 / 175) 140 / 110 / 55 37.5 / 37.0 / 34.5 1,322 � 884 � 388 71 250 -10 to 40 85 1,000 m3/h (278 l/s) UTZ-BD100C 464 / 432 / 311 1,000 / 1,000 / 700 (278 / 278 / 194) 105 / 80 / 75 75 / 75 / 79 65 / 65 / 70 71 / 71 / 76 38.5 / 37.5 / 34.5 464 / 432 / 311 1,000 / 1,000 / 700 (278 / 278 / 194) 105 / 80 / 75 40.5 / 39.5 / 36.5 1,322 � 1,134 � 388 83 250 -10 to 40 85 Dimensions (Unit: mm) Maintenance space Maintenance opening UTZ-BD025C A 810 B 599 C 315 D 142 E 600 F 655 G 19 H 270 I 135 J 159 K 882 L 414 M 95 N �164 O �144 UTZ-BD035C 978 804 580 112 600 860 19 317 159 182 1050 470 70 �164 �144 UTZ-BD050C 1018 904 640 132 600 960 19 317 159 182 1090 470 70 �210 �194 UTZ-BD080C 1250 884 428 228 600 940 19 388 194 218 1322 612 85 �258 �242 UTZ-BD100C 1250 1134 678 228 600 1190 19 388 194 218 1322 612 85 �258 �242 93 Ventilation Outdoor Air Unit Models ARXH054GTAH ARXH072GTAH ARXH096GTAH ARXH054 ARXH072 ARXH096 Features One VRF system can provide air conditioning and air supply at the same time An outdoor air unit can be connected in the same VRF*1 system as the indoor units and can create fresh and comfortable air supply together using our highly advanced technology. VRF system Duct *1. Connectable VRF series: J-IIS, J-III, J-IIIL, V-III and VR-II OAU cannot be used where the ambient temperature is 40�C or higher. Outdoor air unit Indoor unit Indoor unit Fan Heat Exchanger Outdoor Air Unit Fresh Air Fresh Air Wired Remote Controller (Touch Panel) Wired Remote Controller (Touch Panel) Wired Remote Controller (Touch Panel) * Make sure the connected capacity is within the range of 50% to 100% of the outdoor air unit capacity. In addition, if there are mixed connections with indoor units, the Outdoor Air Unit connection capacity becomes 30% or less of the outdoor unit capacity. High energy savings and flexible duct design by using a DC motor � Greatly reduces electricity consumption by adopting a permanent magnet compared to when using an AC motor 054 / 072 type 096 type � Compared with an AC motor, changing the fan speed makes it possible to respond with flexibility to the external static pressure from 50 Pa to 240 Pa. Even when the damper equipment is not used, the static pressure can be adjusted and duct design is made easy � Static pressure can be set easily using wired remote controller DC Motor (When external static pressure is low) Low speed 50 to 240 Pa (096 type) (When external static pressure is high) High speed AC Motor High speed (Constant) Damper opening small (Field supplied) High speed (Constant) Damper opening large (Field supplied) 94 Compact design � A lightweight compact design at just 425 mm in height and 55 kg in weight for ARXH072 type. This unit can be installed easily even within a narrow space. 55 kg (072 type) 1367 mm (ARXH072 type) 425 mm 572 mm Various controllers A variety of optional controllers are available, such as individual controllers, central controllers and building management controllers. Individual controllers Central controllers Wireless Remote Controller Simple Remote Controller Change Items Wired Remote Controller (Touch Panel) Central Remote Controller Touch Panel Controller System Controller System Controller Lite (Software) * The temperature setting is discharged air temperature setting. The air volume is set to a constant speed. Specifications Rated flow rate Model name Power source V/�/Hz 1,000 m3/h (278 l/s) AR XH054GTAH Capacity Input power Airflow rate Cooling Heating Cooling Heating kW W m3/h (l/s) 14.0 8.9 179 179 1,080 (300) Static pressure Standard (range) Pa 185 (50-185) Sound pressure level Dimensions (H � W � D) Weight Connection pipe diameter Small Large dB(A) mm kg mm 42 425 � 1,367 � 572 48 9.52 (Flare) 19.05 (Flare) Operation range Refrigerant Cooling Heating �CDB 5 to 43 -7 to 21 R410A Note: Specifications are based on the following conditions. Cooling: Outdoor temperature of 33�CDB / 28�CWB. Heating: Outdoor temperature of 0�CDB / -2.9�CWB. Pipe length: 7.5m Voltage: 230 V. 1,500 m3/h (417 l/s) AR XH072GTAH 230 / 1 / 50 22.4 13.9 292 292 1,680 (467) 200 (50-200) 44 425 � 1,367 � 572 55 12.70 (Brazing) 22.22 (Brazing) 5 to 43 -7 to 21 R410A 2,000 m3/h (556 l/s) AR XH096GTAH 28.0 17.4 370 370 2,100 (583) 200 (50-240) 47 450 � 1,583 � 700 71 12.70 (Brazing) 22.22 (Brazing) 5 to 43 -7 to 21 R410A Dimensions (Unit: mm) Model: ARXH054 425 351 14 181 1367 1192(BOLT PITCH) 1062 Model: ARXH072 400 382 231 Main drain port 130 425 351 14 181 1367 1192(BOLT PITCH) 1062 39 44 572 526(BOLT PITCH) 489 28 120 146 39 44 572 526(BOLT PITCH) 304 30 Side view (L) (Drain hose) 921 1247 Top view Front view Safety drain port 111 Side view (R) 304 30 Side view (L) (Drain hose) 921 1247 Top view Front view 489 36 28 146 Model: ARXH096 400 382 Main 450 8 drain port 700 655(BOLT PITCH) 29 50 50 25 25 Safety drain port 111 Side view (R) P160�2=320 15 350 35 Side view (L) 1583 Main drain port 1412(BOLT PITCH) 1251 151 Safety drain port P150�7=1050 1199 1454 Top view 75 125 111 Side view (R) (Drain hose) Front view 95 49 73 AIRSTAGETM CONTROL SYSTEMS User friendly control system provides individual and centralised control The AIRSTAGETM control system can control air conditioning of individual rooms, centralise control by floor or by building, or centralise energy saving air conditioning control for large buildings. A variety of air conditioning management options are available to match the requirements of the application, including integrating with the building control system, connecting with single split models and various interfaces. OPTIMISED CONTROL SOLUTIONS CONTROL SYSTEM OVERVIEW COMPARISON TABLE OF CONTROLLERS INDIVIDUAL CONTROLLER CENTRALISED CONTROLLER CONVERTOR / ADAPTOR 96 97 AIRSTAGETM Control Systems OPTIMISED CONTROL SOLUTIONS Fujitsu General provides a diverse range of flexible control solutions to suit a variety of applications. SHOP Type Individual control Automatic control of A/C (schedule timer, weekly timer etc.) Customise the level of control for staff and end users (RC prohibition, room temp set point limitation etc.) Group control Advanced energy saving (peak cut, indoor unit rotation operation etc.) Remote management Wired Remote Controller UT Y-RNRY Z3 Manage multiple sites Monitor energy consumption Control third party products Integrate FGL A/C into BMS Change Items Central Remote Controller UT Y-DCGY Z1 Centralised control Touch Panel Controller UT Y-DTGY Z1 System Controller UT Y-APG X Z1, UT Y-ALG X Z1 Integrating control (interface) Network Convertor for LONWORKS� UT Y-VLG X MODBUS� Convertor UT Y-VMG X KNX� Convertor UT Y-VKG X HOTEL Type Local control for hotel guest Centralised A/C control for common space Limited control for hotel guests Remote management Advanced energy saving (peak cut, indoor unit rotation operation etc.) Monitor energy consumption Control third party products Integrate FGL A/C into BMS 98 Wired Remote Controller UT Y-RNRY Z3 Individual control Centralised control Integrating control (interface) Simple Remote Controller UTY-RSRY, UTY-RHRY WHITE-USB-KEY (Software Protection Key) Change Items Wireless Remote Central Remote Touch Panel Controller Controller Controller System Controller UT Y-LNHY UT Y-DCGY Z1 UT Y-DTGY Z1 UT Y-APG X Z1, UT Y-ALG X Z1 BACnet� Gateway Network Convertor for LONWORKS� UT Y-ABG X Z1, UT Y-VBG X UT Y-VLG X MODBUS� Convertor UT Y-VMG X KNX� Convertor UT Y-VKG X OFFICE Type Local control for office staff Automatic control of A/C (schedule timer, weekly timer etc.) Centralised A/C control for management Customise the level of control for office staff (RC prohibition, room temp set point limitation etc.) Advanced energy saving (peak cut, indoor unit rotation operation etc.) Remote management Energy charge apportionment Monitor energy consumption Control third party products Integrate FGL A/C into BMS Wired Remote Controller UT Y-RNRY Z3 Individual control Simple Remote Controller UTY-RSRY, UTY-RHRY Centralised control Integrating control (interface) WHITE-USB-KEY (Software Protection Key) Change Items Wireless Remote Central Remote Touch Panel Controller Controller Controller System Controller UT Y-LNHY UT Y-DCGY Z1 UT Y-DTGY Z1 UT Y-APG X Z1, UT Y-ALG X Z1 BACnet� Gateway Network Convertor for LONWORKS� UT Y-ABG X Z1, UT Y-VBG X UT Y-VLG X MODBUS� Convertor UT Y-VMG X KNX� Convertor UT Y-VKG X 99 AIRSTAGETM Control Systems CONTROL SYSTEM OVERVIEW User's needs are supported by offering a variety of controls, such as individual control, central control and building management control options. Air Conditioning Individual Control Wired Remote Controller (touch panel) UTY-RNRYZ3 Simple Remote Controller UTY-RSRY UTY-RHRY Without operation mode Wireless Remote Controller UTY-LNHY IR Receiver Unit UTY-TRHX For Duct type UTB-TWC For Duct type For Cassette For Circular Flow Cassette IR Receiver Unit UTY-LRHYB1 For Cassette type UTY-LBHXD For Circular Flow Cassette Air Conditioning Centralised Control USB adapter *1 Internet or public telephone line (Field supplied) Remote / monitoring side System Controller Software UTY-APGXZ1 UTY-ALGXZ1 (Lite edition) Max. controllable 1600* indoor units * Lite edition is max. controllable 400 indoor units Touch Panel Controller UTY-DTGYZ1 Internet or LAN Remote / monitoring side Max. controllable 400 indoor units Central Remote Controller Max. controllable Change Items UTY-DCGYZ1 NEW 100 indoor units For Light Commercial � Small VRF Convertor / Adaptor For external devices BACnet� Gateway UTY-ABGXZ1 Software BACnet� Gateway UTY-VBGX Hardware Network Convertor (BMS / LONWORKS�) UTY-VLGX MODBUS� Convertor For VRF UTY-VMGX MODBUS� Convertor for indoor unit UTY-VMSX KNX� Convertor For VRF UTY-VKGX KNX� Convertor for indoor unit UTY-VKSX 100 For Commercial � Large VRF BMS / BAS *2 BMS, home automation system or *1. USB Adaptor: Echelon� U10 USB Network Interface *2. BMS / BAS: Building Management System / Building Automation System Convertor / Adaptor For system expansion Network Convertor (DC power supply) UTY-VTGX Single split Signal Amplifier UTY-VSGXZ1 101 AIRSTAGETM Control Systems COMPARISON TABLE OF CONTROLLERS Type Model name Max. controllable remote controller groups Max. controllable indoor units Max. controllable groups On / Off Operation mode setting Fan speed setting Room temp. setting Air conditioning control function Room temp. set point limitation Test operation Up / down air direction flap setting Right / left air direction flap setting Individual louvre control Group setting RC prohibition Anti freeze setting Set temp. auto return Economy mode setting Human sensor control Error Defrosting Current time Day of week R.C. prohibition Display Address display Room temp Multi language Summer time Name registration Backlight 2D floor layout / 3D building display Schedule timer Period On / Off, temp, mode, times per day On / Off timer Timer Sleep timer Program timer Auto off timer Day off Min. unit of timer setting (minutes) Status monitoring system Electricity charge apportionment Error history Emergency stop Control Remote management Energy saving management E-mail notification for malfunction Key lock Low noise mode 102 Wired Remote Controller (touch panel) UT Y-RNRY Z3 1 16 -- -- -- -- Week 8 -- -- 10 � 30 -- -- -- -- -- -- Child lock -- Simple Remote Controller UT Y-R SRY 1 16 -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- Simple Remote Controller*1 UT Y-RHRY 1 16 -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- Wireless Remote Controller UT Y-LNHY 1 16 -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- 5 -- -- -- -- -- -- -- -- -- Change Items Central Remote Controller UT Y-DCGY Z1 100 100 50 -- *3 -- -- -- *4 -- Week 20 -- -- -- 10 -- *2 -- Password setting -- Touch Panel Controller UT Y-DTGY Z1 400 400 400 *4 -- Year 20 -- -- -- 10 *2 -- Password setting System Controller Lite Software UT Y-ALGX Z1 400 400 400 -- -- -- *4 -- -- Year 144 -- -- -- -- 10 -- Password setting System Controller Software UT Y-APGX Z1 1600 1600 1600 -- -- -- *4 -- Year 144 -- -- -- -- 10 -- Password setting *1 "Operation mode" setting is not available for this model. *2 This function is available only through external input control. *3 Only individual airflow batch reset is mounted. *4 This function is available only when using wired remote controller. : Supported : Optional function -- : Not supported yet 103 AIRSTAGETM Control Systems Individual Controller Wired Remote Controller (Touch Panel) UTY-RNRYZ3 Easy operation with a high-definition large LCD touch panel screen � Easy touch operation via the touchscreen LCD panel � Built-in weekly / daily timer (ON / OFF, temp, mode) � Backlight enables easy operation in a dark room � Room temperature display � Control up to 16 indoor units � 12 different languages (English, Chinese, French, German, Spanish, Russian, Polish, Italian, Greek, Portuguese, Turkish and Dutch) � 2-wire type Functions High performance and compact size � In addition to the individual control, various energy saving controls can be utilised via the controller. Individual control Thermo sensor Weekly timer Auto off timer Various convenient functions Displays setting status and limitations � The remote controller settings can be easily checked. Accurate and comfortable control � Indoor temperature can be detected accurately by the inclusion of a thermo sensor in the body of the wired controller. Summer time display � This function can be set easily from the Menu screen. Max. controllable 16 indoor units Child lock � Lock / unlock method: push the ON / OFF button and the screen (4 seconds). Room temperature sensor Backlight � Backlight enables easy operation in a darkened room. � The backlight setting can be adjusted for 30 or 60 seconds. � Backlight activates while the controller is in use and turns off 30 or 60 seconds after the operation stops. 104 Room temperature display Name registration � Remote controller names can be registered in the remote controller screen.This makes it easy to identify the indoor unit you want to control in the room. Initial Setting Language Setting Temp. Unit Setting Back Page 1/ 3 Date Setting R.C.Group Name Setting Next Page Various energy saving controls Custom Auto � Maintains 2 separate set points for heating and cooling � Automatically changes mode between heating and cooling * This function is not available for some models. Cooling set temp. 27�C, heating set temp. 26�C Changeover Cooling set point Heating set point Changeover Operation Start Auto changeover Auto OFF timer Room temperature � The indoor unit is automatically turned off when it reaches the preset operating time frame � The time frame of the "Auto off timer" allows flexibility for setting and scheduling � Can be set to turn off in 30 to 240 minutes Set interval time (17:00 to 24:00) ON OFF ON Auto OFF ON Auto OFF 1 hour 1 hour Normal time Over time 8 17 24 Ex.) a particular interval time hour (17:00 to 24:00) to prevent forgetting to turn off Set off time: 1 hour 2 schedules weekly timer � 2 schedules, for example summer and winter can be set � 8 settings are changeable per day of week (setting items: On / Off, temperature, mode, time) Ex) Set temperature auto return � The setting temperature automatically returns to the previous temperature setting � The time range in which the set temperature can be changed is 10 to 120 minutes Set temperature upper and lower limit � The set temperature range can be set for each operation mode (cooling / heating / auto) Specifications Model name Power supply Dimensions (H x W x D) mm Weight g DC12V is supplied by indoor unit. Simplified installation Uses non polar 2 wire type � Incorrect wiring can be prevented by using non-polar 2-wire I.U. Y1Y2 Y3 I.U. Y1Y2 Y3 non-polar 2-wire OK OK Y1 Y2 Y1 Y2 Auto address setting / setting position notification � Reduce errors and install time compared with the current specification of using the rotary SW � When using the touch panel controller to control a remote controller group, new functionality enables the controller to set the respective RC addresses � After the addresses are assigned these can be confirmed from the indoor unit Address 04 03 02 01 The appropriate indoor unit fan operates and LED lamps blink. 05 Easy maintenance Error history display � Errors that occur in the indoor unit or or on the remote controller are saved in the error history � A maximum of 32 error incidents can be saved UT Y-RNRY Z 3 DC 12V 120 � 120 � 20.4 220 105 AIRSTAGETM Control Systems Individual Controller Simple Remote Controller UTY-RSRY UTY-RHRY (without operation mode) Compact remote controller provides access to basic functions � Up to 16 indoor units can be controlled with one remote controller � Suitable for hotels or offices as it is easily operated with no complex functions � Simple and stylish design to match stylish interiors � Large LCD screen and simple operation buttons � Backlight: white coloured backlight on monitor enables easy operation in dark environments � 2-wire type Functions Corresponding with various applications � Vertical louvre control: Vertical airflow direction can be adjusted for Mini Duct & Slim Duct types, and cassette types, using the auto louvre option. This suits indoor units installed in applications such as hotels and conference rooms. Max. controllable 16 indoor units UT Y-R SRY UT Y-RHRY without operation mode � Room temperature set point limitation: The Simple Remote Controller can assist with management of energy usage in small buildings without the central control unit. During cooling 30�C 25�C 18�C � Built in room temperature sensor: The Simple Remote Controller detects actual room temperature and controls room climate accordingly. During heating 30�C 25�C 16�C Room temperature sensor Specifications Model name Power supply Dimensions (H x W x D) mm Weight g DC12V is supplied by indoor unit. 106 UT Y-R SRY DC 12V 120 � 75 � 19.4 120 UT Y-RHRY AIRSTAGETM Control Systems Individual Controller Wireless Remote Controller UTY-LNHY Simple and sophisticated operations with a choice of 4 daily timers � A single controller controls up to 16 indoor units. Max. controllable 16 indoor units Selectable 4 daily timers Functions Built-in daily timer Select from 4 different timer programs : ON / OFF / program / sleep Program timer: The program timer operates the ON and OFF timer once within a 24 hour period. Sleep timer: The sleep timer function automatically corrects the set temperature according to the time setting to prevent excessive cooling or heating during sleep hours. Cooling operation / dry operation When the sleep timer is set, the set temperature automatically rises 1�C every hour. The set temperature can rise up to a maximum of 2�C. Timer setting 60min. 2�C 1�C Heating operation When the sleep timer is set, the set temperature automatically drops 1�C every 30 minutes. The set temperature can drop to a max. of 4�C. 1�C 2�C 3�C 4�C 30min. 60min. 90min. T imer setting Easy operation with multiple indoor units The code selector switch prevents indoor units from unintended control. (Up to 4 codes can be set.) Wide and precise Address setting During installation work, address setting can be performed using the wireless remote controller, thus eliminating manual switch setting. Transmission line Outdoor unit Indoor unit Wireless Remote Controller Specifications Model name Power supply Dimensions (H x W x D) mm Weight g UT Y-LNH Y 1.5V (R03 / LR03 / AAA) � 2 170 � 56 � 19 85 107 AIRSTAGETM Control Systems Individual Controller IR Receiver Unit for Duct UTB-TWC, UTY-TRHX Option required to control ducted type units via a Wireless Remote Controller � Up to 16 indoor units can be controlled with one remote controller � Suitable for hotels or offices as it is easily operated with no complex functions * The wireless remote controller (model: UTY-LNHY) is necessary separately Functions Wiring connection IR Receiver Unit UTB-TWC Duct type indoor unit Wireless Remote Controller IR Receiver Unit UT Y-TRHX Duct type indoor unit Wireless Remote Controller Specifications Model name Power supply Dimensions (H x W x D) mm Weight g UTB-TWC DC 5V 145 � 90 � 30 150 UT Y-TRH X IR Receiver Unit for Cassette UTY-LRHYB1 UTY-LBHXD Cassette type indoor unit can be controlled with the Wireless Remote Controller *The wireless remote controller (model: UTY-LNHY) is necessary separately Functions Wiring connection Wireless Remote Controller Wireless Remote Controller UT Y-LRHYB1 UT Y-LBHXD Specifications Model name Power supply Dimensions (H x W x D) mm Weight g 108 UT Y-LRH YB1 DC 5V 193.9 � 193.9 � 31.2 140 UT Y-LBH XD AIRSTAGETM Control Systems Centralised Controller Central Remote Controller UTY-DCGYZ1 For small- and medium-sized buildings and tenants � Individual control and monitoring of up to 100 indoor units � 7.0inch TFT colour screen � High visibility and easy operation � Supports 12 different languages (English, Spanish, German, French, Italian, Russian, Portuguese, Turkish, Polish, Greek, Dutch, Chinese) Max. controllable 100 indoor units Max. controllable 50 groups Change Items Functions Easy operation � Intuitive operation through the simple touch panel � All functions can be accessed from the top screen and the operations are displayed in a pop-up window Top display Batch control of all indoor unit operation status Schedule setting change Menu button Change Items Indoor units in the group are expanded. Change Items All indoor unit groups display Operation setting are displayed at pop-up window. Trouble support function Display error details Display descriptive explanation when an error occurs All indoor unit groups display Display error details Sensor value monitoring function Monitor sensor data of indoor unit / outdoor unit Notify room temperature by email* Notify by email when the temperature around the air conditioner is too high or too low * This function is available only when using wired remote controller. Specifications Model name Power supply Dimensions (H x W x D) mm Weight g Remote monitoring / Remote operation New central remote controller can control your tenant's air conditioner anytime and anywhere. Example � Control / monitoring Fujitsu air conditioner � Error notification by email ! Error Shop UT Y-DCGY Z1 100-240 V 50 / 60 Hz 134.6 � 216.2 � 37.9 800 109 AIRSTAGETM Control Systems Centralised Controller Touch Panel Controller UTY-DTGYZ1 � Large-sized 7.5-inch TFT colour � LCD easy touch operation � Stylish shape and design to suit all applications � Up to 400 indoor units can be controlled � Selectable 2 display types (icon / list) in monitoring mode � Supports 7 different languages - English, Chinese, French, German, Spanish, Russian, Polish � Mounted with LAN interface for remote control and operation, external input / output with emergency stop and batch ON / OFF Functions Easy operation � Wide range of simple-to-understand icons � Operation can be selected using your finger or the dedicated touch pen by pressing the appropriate on-screen icon. � Back colour identifies current control operation: blue for monitoring; green for operational control. Max. controllable 400 indoor units Max. controllable 100 outdoor units Max. controllable 400 groups Easy maintenance � Flat touch screen is easily cleaned � Non glare coating on touch panel controller minimises fingerprint marking � Easy to remove front cover Up to 400 indoor units can be controlled Group A Easy installation � The touch panel controller is easily mounted to the wall � The flat back surface allows the controller to be installed wherever required � No additional components are required for installation Group B 110 Emergency stop control Air conditioner can be turned off through the external input control It allows multiple indoor unit grouping ability Emergency stop function Control and monitoring � Control and monitor Fujitsu air conditioners via LAN or Internet � Allow the user or tenant to manage only assigned equipment by their PC or tablet from anywhere � Error messages can be notified automatically by email upon an error occurrence to enable the issue to be handled promptly Operation status monitoring Operation mode setting Tablet PC Error notification by email LAN or Internet VRF network system Not only operations but also detailed settings such as schedule or group settings can be operated from remote locations. Individual control Smart phone Model name Nexus 6P (Android 7.1.1) iPhone 7 (iOS 10.1) Flexible grouping Schedule control Indoor units operation monitoring Browser Google Chrome 5.5 Safari 10 Tablet Model name iPad Pro 9.7inch (iOS 10.2.1) Browser Safari 10 Flexible access permission with individual user levels The administrator can register multiple users to permit which indoor unit(s) and which functions can be accessed. ON / OFF prohibition Operation ON Monitoring from website Administrator Operation ON Staff / employee Additional language functionality Available in 7 different languages- English, Chinese, French, German, Spanish, Russian and Polish as standard. Additional languages can be integrated on a remote device by creating a language database. Additional languages are displayed only on the remote device. The touch panel controller cannot be configured to display these additional languages. 7 Languages Monitoring from website Write Language data 7 + Languages Other languages 111 AIRSTAGETM Control Systems Centralised Controller Functions Electricity charge apportionment � Electricity charge apportionment can be utilised to easily attribute power usage to each tenant based on their usage � Apportionment charge / bill calculation � Tenant (block) setting � Common facilities apportionment setting � Rated power consumption allotment setting � Individual calculation for both cooling and heating � Electricity meter supported Automatic summer time setting Function overview 1) This function enables a schedule to be set within the system to adjust the timer to summer time at the appropriate time to ensure the time matches the time zone. UT Y-P TG X A VRF network system Electricity charges Block (tenant) A Electricity Electric power meter company Signal line* Block (tenant) B LAN cable * Electricity meter (1 unit) can be connected to external input connector of the TPC unit. In this case, electricity meter cannot be connected to outdoor unit simultaneously. Automatic clock adjustment 2) The time setting of each controller can be set from the one location. Outdoor low noise operation Users can choose from 4 low noise levels, depending on the installation environment. The operation time can be set using the timer. Block (Tenant) A Block (Tenant) B Quiet priority setting Air conditioning load factor Heat load Capacity Operating sound 100% 0 58dB 0 down time Quiet priority low noise mode Energy saving control Custom Auto � Maintains 2 separate set points for heating and cooling � Automatically changes mode between heating and cooling * This function is not available for some models. 112 Cooling set temp. 27�C, heating set temp. 26�C Operation Start Auto changeover Room temperature Changeover Cooling set point Heating set point Changeover FUNCTIONS SUMMARY UTY-DTGYZ1 Monitoring side Air conditioning control function On / Off Operation mode setting Fan speed setting Room temp. setting Room temp. set point limitation Test operation Up / down air direction flap setting Right / left air direction flap setting Individual louvre control *1 Group setting RC prohibition Anti freeze setting Set temp. auto return - Various energy saving controls - Economy mode setting Human sensor control - Custom Auto setting Display Error Defrosting Current time Day of week R.C. prohibition Cooling / heating priority Address display Room temp *3 *3 Multi language Summer time Time zone setting Name registration Backlight Language setting 7 7+other : Supported : Optional function - : Not supported yet *1 Only setting cancellation can be operated. *2 This function is available only through external input control. *3 This function is available only when using wired remote controller. Timer Schedule timer Period On / Off, temp, mode, times per day On / Off timer Sleep timer Program timer Auto off timer Day off Min. unit of timer setting (minutes) Control Status monitoring system Electricity charge apportionment Error history Emergency stop Remote management Energy saving management Email notification for malfunction Key lock Low noise mode UTY-DTGYZ1 Monitoring side Year Year 20 20 - - - - - - - 10 10 *2 *2 - - - - Password setting - Specifications Model name Power supply Dimensions (H x W x D) mm Weight g Interface UT Y-DTGY Z1 100-240V 50 / 60Hz, Single phase 260 � 246 � 54 2,150 Transmission / LAN / USB / EXT IN / EXT OUT / Reset SW 113 AIRSTAGETM Control Systems Centralised Controller System Controller UTY-APGXZ1 System Controller offers advanced integrated monitoring and control of the VRF network system from small to large scale buildings. � Up to a maximum of 4 VRF network systems, 1600 indoor units, and 400 outdoor units can be controlled � In addition to the air conditioning control function, central remote control, electricity charge calculation, schedule management and energy saving functions ensure the building manager and owner needs are met System Controller Lite UTY-ALGXZ1 System Controller Lite has functions suited for air conditioning management in small and medium scale buildings. � Up to a maximum of 1 VRF network system, 400 indoor units, and 100 outdoor units can be controlled � In addition to air conditioning precision control function, a variety of management software is available as an option to give customers a wide range of choice Max. controllable 4 VRF network systems Max. controllable 1,600 indoor units Max. controllable 400 outdoor units Max. controllable 1 VRF network system Max. controllable 400 indoor units Max. controllable 100 outdoor units Functions User friendly view and operation � Click and operate: The property is shown visually from the perspective most suitable for operation and operated accordingly (Click and Operate). You can select from among the 4 displays of site, building, floor, or list. Click & operate the whole building! Properties can be shown using one of the four displays of site, building, floor, or list. � Define custom groups for batched control: Indoor units can be grouped for simple batched control from a tree menu. Grouping by hierarchal structure, such as by section, division or department is possible. Custom Auto operation display List view Click & operate any specified unit(s)! Site view Batched control of freely defined groups Batched control of freely selected units Note: 2D floor layout / 3D building display are not available for System Controller Lite. Click & operate the whole floor! Batched control of freely selected units 114 Building view The floor layout drawing can be imported to easily make the settings for the actual building Floor view Click & operate the unit! 3rd party devices connected by Modbus can be controlled Standard for System Controller Option for System Controller Lite UTY-PLGXX2 When a Modbus Adaptor (locally purchased) is connected to PC, the devices supported by Modbus can be controlled from a central location. Electricity usage can be reduced by enabling all unrequired devices to be turned off or scheduled to turn off at the end of the day. System controller (System Controller Lite) VRF network Remote I / O devices Supported Modbus communication (field supply) Electricity meter supported Modbus communication Electric power company Facilities Energy recovery ventilator system Outdoor air unit system Supply & exhaust fan Diverse operation management and data management Standard for System Controller and System Controller Lite Schedule management � Annual schedules can be set for each remote controller group / user defined group � Start / stop, operating mode, remote controller prohibition, and temperature settings can be set up to 143 times per day at 10 minute intervals for up to 101 configurations for each remote controller group � Allows programming of special settings for holidays, including public holidays, for a complete year � Low noise operation of the outdoor unit can be scheduled Diverse control of indoor unit and outdoor unit � Indoor unit operation state, operation mode, etc. are displayed � Indoor unit start / stop and operation mode switching � Room temperature set point limitation Remote controller prohibition This prohibits changes to the operation mode, temperature, start / stop, etc. Error display and email notification Errors are notified with pop-up message, audible sound and email in real time when errors occur. Errors for the past year are logged and can be reviewed at any time. Operating and control record Displays the history of operation status and control. Database import / export Imports / exports registration data, layout data, and image data. Only the administrator can make this setting. Automatic clock adjustment The time setting of each controller can be set centrally with one command. Electricity charge apportionments* Standard for System Controller Option for System Controller Lite UTY-PLGXA2 Electricity charge apportionment calculation framework Suppose you want to find the power consumed by the air conditioners of each tenant from the electricity charge for each month. With electricity charge apportionment function, the used energy apportionment ratio will be provided, calculating in detail the energy consumed by the units within each tenancy. This information is then used to calculate the charges for the electricity consumed for air conditioning by each tenant from the total electricity charges in the bill from the electric power company. (See figure on the right.) The detailed calculation takes into consideration variables such as unused rooms and nighttime electricity charges and shows them in the charge calculation sheet. System configuration example Electric power company Electricity charges (air conditioning) Power distribution board System Controller Tenant A-1 Tenant A-2 Outdoor unit Tenant A-4 Tenant A-5 Signal transmission line Tenant A-3 Tenant A-6 Power distribution board Tenant B-1 Tenant B-2 Tenant B-3 3�, 4 wire 400V, 50Hz Tenant C-1 Tenant C-2 Tenant C-3 1�, 2wire 230V, 50Hz * The electricity charge apportionment function does not calculate official electricity charges like those established by the laws and regulations of each country. 115 AIRSTAGETM Control Systems Centralised Controller Remote managemVRFeEnxpltorer VRF Controller Building management company, A10mlSoacxtaiamtinounmds,aosfurdch as for System Controller management centre, etc. officeOs opr tfaicotonries for System Controller Lite UTY-PLGXR2 The System Controller may be used on site or remotely over1vVaRFriEoxuplsorenrecatnworks for remote central control. System Controller requires 2 sIontfeortrnwet are applications working ctoongtroeltohr mero.niVtoRr F Controller runs on site and communicates with the VRF system. VRF Explorer runs remotely and provides Telephone Line or LAN user interface anducpotom10msiutens.icates with the VRF Controller. VRF Controller and the VRF Explorer program may operate on a single PC or on different PCs separated by a network. By using VRF Explorer software, one PC can perform central control of 10 VRF system sites with a max. 20 buildings per site. Remote central control VRF Explorer VRF Explorer Building Management Company A (In charge of the day shift) VRF Explorer Building Management Company B (In charge of the night shift) VRF Explorer Internet or Telephone Line or LAN Security company VRF Explorer Office management centre VRF Controller 1 VRF Controller can be monitored from any number of VRF Explorers (Up to 5 connections simultaneously). VRF Controller A maximum of 10 locations, such as offices or factories VRF Explorer Building management company, management centre, etc. Internet or Telephone Line or LAN 1 VRF Explorer can control or monitor up to 10 sites. Headquarters management centre Web operation PC and smartphones can be used as a simple remote controller. VRF Explorer VRF Explorer Building Management Company A (In charge of the day shift) VRF Explorer � ON / OFF � Temperature setting � Check remaining amount*1 � Mode setting � Fan speed � Louvre setting *1 prepaid AC function Building WAN*2 (Intranet) Management Company B (In charge of the night shift) Internet or Wireless Telephone Line or Office management centre VRF Explorer LAN LAN LAN (IntrVaRnFeCto)ntroller HUB VRF Explorer 1 VRF Controller can be monitored from any number of VRF Explorers (Up to 5 connections simultaneously). Security company Wireless LAN access point System Controller Headquarters management centre PC *2 For connection via the Internet, the following setting is necessary. Fix IP address (or similar) Open the router's port of No.80. Energy saving management Option Option for System Controller UTY-PEGX for System Controller Lite UTY-PLGXE2 A variety of energy saving operations can be set and managed depending on the season, weather, and time period. Energy Saving Management Main Screen Energy saving graph data: this graph compares the electricity consumption with the previous month and previous year to make it easy to analyse the energy saving effect. 116 Indoor unit rotation operation The operation of indoor units can be automatically rotated within a group in accordance with the set annual schedule to reduce power consumption while maintaining comfort. The indoor unit operation stop rate can be selected. Peak cut operation A power meter is connected to detect the total power consumption by shifting the indoor unit set temperature, turning the indoor unit forced thermostat off, and taking other measures to carefully control the power consumed to maintain target power consumption set for the specified time. The indoor units to be controlled can be grouped and the control level can be set. Outdoor unit capacity save Outdoor unit capacity save function switches the outdoor unit capability upper limit to suppress power consumption during hot summers and cold winters by averaging the power saving effect of each refrigerant system. You can select from 50% or more of the capacity upper limit. FUNCTIONS SUMMARY Function System specification Site supervision Error management History Operation control Schedule Remote managemment Electricity charge apportionment Energy saving management External device control Others Type Max. VRF networks supported Max. indoor unit / remote controller groups per VRF network Max. outdoor units per System Controller Max. indoor units / remote Controller groups per System Controller Max. outdoor units per System Controller Multi-site display Number of building per 1 site Number of floors per 1 site Number of floors per 1 building 3D graphical layout view 2D graphical layout view List display Tree display Group display Error notification Audible alarm Error email notification Error history Operation history Control history On / Off Operation mode Room temperature Individual control Fan speed Air flow direction Economy mode Room temperature set point limitation Anti freeze Outdoor unit low noise setting Individual management Remote control prohibition setting Temperature upper and lower limit setting Filter sign reset Memory operation Other Pattern operation Web operation Annual schedule Special day setting On / Off per day On / Off per week Day off Min. unit of timer setting (minutes) Low noise mode weekly schedule Web operation Remote monitoring Remote operation control Remote function setting Apportionment charge / bill calculation Tenant (block) setting Common facilities apportionment setting Rated power consumption allotment setting Individual calculation at cooling and heating Electricity meter supported Indoor unit rotation Peak cut control Outdoor unit capacity save Record of energy saving operation Energy saving information Power consumption monitor Electricity meter supported Monitor Control Database import / export Automatic clock adjustment Multi language System controller UT Y-APG X Z1 Option UT Y-PEG X Z1 4 - 400 - 100 - 1600 - 400 - 10 - 20 - 200 - 50 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 72 - 504 - - 10 - - - - - - - - - - - - - - - - - - - - - 7 languages - Available. - Not available. * Power calculation application software is necessary, please contact the local FGL representative. UT Y-ALG X Z1 1 400 100 400 100 10 72 504 10 - 7 languages Option UT Y-PLG XR 2 - System controller lite Option UT Y-PLG X A 2 - - Option UT Y-PLG XE 2 - - Option UT Y-PLG X X 2 - - Personal computer system requirements The required PC specifications are shown in the following table. System Controller System Controller Lite Operating system � Microsoft� Windows� 7 Home Premium (32-bit or 64-bit) SP1, Windows� 7 Professional (32-bit or 64-bit) SP1 � Microsoft� Windows� 8.1 (32-bit or 64-bit), Windows� 8.1 Pro (32-bit or 64-bit) � Microsoft� Windows� 10 Home (32-bit or 64-bit), Windows� 10 Pro (32-bit or 64-bit) [Supported languages] English, Chinese, French, German, Russian, Spanish, and Polish CPU Memory HDD Display Intel� CoreTM i3 2 GHz or higher � 2 GB or more (for Windows� 7 [32-bit]) 40 GB or more of free space 1024 x 768 or higher resolution � 4 GB or more (for Windows� 7 [64-bit], Windows� 8.1, and Windows� 10) Interface �Ethernet port (for accessing the Internet using LAN) or modem (for accessing the Internet using a public telephone line) �USB ports (maximum of 6 ports) (Required only for the server PC that works as VRF Controller) - Maximum of 2 USB ports are required for WHITE-USB-KEY / WibuKey connection - Maximum of 4 USB ports are required for Echelon� U10 USB Network Interface * Maximum number of required USB port depends on the applicable system configuration. �Ethernet port (for accessing the Internet using LAN) or modem (for accessing the Internet using a public telephone line) �USB ports (Maximum of 6 ports) (Required only for the server PC that works as VRF Controller) - Maximum of 4 USB ports are required for WHITE-USB-KEY / WibuKey connection - 1 USB port is required for Echelon� U10 USB Network Interface * The maximum number of required USB port depends on the applicable system configuration. Graphic accelerator Microsoft� DirectX� 9.0c compatible Software Adobe� Reader� 9.0 or later � Echelon� U10 USB Network Interface � TP / FT-10 Channel (Model number: 75010R) (Required for each VRF Network.) <PACKING LIST> For System Controller For System Controller Lite Type System controller Option Energy manager System Controller Lite Remote access Option Electricity charge apportionment Energy saving Model name UT Y-APG X Z1 UT Y-PEG X Z1 UT Y-ALG X Z1 UT Y-PLG XR 2 UT Y-PLG X A 2 UT Y-PLG XE 2 WHITE-USB-KEY 1 1 1 1 1 1 Central Control UT Y-PLG X X 2 1 *1 Software protection key to be inserted in a USB slot running System Controller or System Controller Lite. System Controller or System Controller Lite may only run on a PC with WHITE-USB-KEY. However, WHITE-USB-KEY is not required for remote VRF Explorer software. 117 AIRSTAGETM Control Systems Convertor / Adaptor BACnet� Gateway UTY-ABGXZ1 Max. controllable 4 VRF network systems Max. controllable 1,600 indoor units Max. controllable 400 outdoor units � Enables the connection of medium to large sized BMS to VRF network system via BACnet�, a global standard for open networks � A maximum of 1600 indoor units with 4 VRF network systems (a maximum of 400 indoor units and 100 outdoor units for one network system) can be connected to one BACnet� Gateway � Control or monitor VRF network system from BMS via BACnet� Gateway � Compatible with BACnet� (ANSI / ASHRAE-135-2012) application specific controller (B-ASC) � Compatible with BACnet� / IP over Ethernet � Scheduling, alarm and event functions as well as electricity charge apportionment function are provided in the BACnet� Gateway � The connection between VRF network system to personal computer is possible via small U10 USB interface. However, both U10 USB interface and personal computer are field supplied items � Available for use in 7 different languages, English, Chinese, French, German, Spanish, Russian, Polish WHITE-USB-KEY (SoftWwHarIeTEP-rUotSeBc-tKioEnYKey) (Software Protection Key) Functions Installation example VRF network system 1 Indoor unit Outdoor unit USB adaptor*1 (field supplied) VRF network system 2 Indoor unit Outdoor unit USB adaptor (field supplied) USB adaptor (field supplied) Max. 4 VRF network systems USB adaptor (field supplied) BACnet � BACnet� Gateway (UTY-ABGXZ1) WHITE-USB-KEY Software Protection Key BACnet� Operator Workstation (B-OWS) Lighting facilities Security system Automatic fire alarm interface Ventilation system = USB cable = Transmission line (VRF network) = Ethernet *1 USB adaptor is U10 USB network interface of Echelon� Corporation. Personal computer system requirements UT Y-ABG X Z1 Operating system � Microsoft� Windows� 7 Home Premium (32-bit or 64-bit) SP1, Windows� 7 Professional (32-bit or 64-bit) SP1 � Microsoft� Windows� 8.1 (32-bit or 64-bit), Windows� 8.1 Pro (32-bit or 64-bit) � Microsoft� Windows� 10 Home (32-bit or 64-bit), Windows� 10 Pro (32-bit or 64-bit) [Supported languages] English, Chinese, French, German, Russian, Spanish, and Polish CPU Intel� CoreTM i3 2 GHz or higher Memory � 2 GB or more (for Windows� 7 [32-bit]) � 4 GB or more (for Windows� 7 [64-bit], Windows� 8.1, and Windows� 10) HDD Display 40 GB or more of free space 1024 x 768 or higher resolution Interface � Ethernet port (for getting access to the Internet using LAN) � USB ports (Maximum of 5 ports) - 1 USB port is required for WHITE-USB-KEY / WibuKey connection - Maximum of 4 USB ports are required for Echelon� U10 USB Network Interface * Maximum number of required USB ports depends on the applicable system configurations. Software Adobe� Reader� 9.0 or later �Echelon� U10 USB Network Interface � TP / FT-10 Channel (Model number: 75010R) (Required for each VRF Network.) <PACKING LIST> Name and shape WHITE-USB-KEY Quantity Application 1 Includes the software and manuals, license for BACnet� Gateway. 118 BACnet� Gateway (hardware) UTY-VBGX � BACnet� Gateway enables connection between the BMS and FG VRF system � A maximum of 128 indoor units and 32 refrigerant system can be connected to a single BACnet� Gateway � Compatible with BACnet� (ANSI / ASHRAE-135-2010) application specific controller (B-ASC) � Compatible with BACnet� / IP over Ethernet Max. controllable 1 VRF network system Max. controllable 32 refrigerant system Max. controllable 128 indoor units Functions Installation example BACnet� Operator Workstation (B-OWS) Controller Lighting facilities Security system Automatic fire alarm interface Windows bind Specifications Model name Number of controllable indoor units Number of controllable refrigerant system Number of controllable VRF network Number of connectable units / one VRF network UT Y-VBG X 128 32 1 4 BACnet� Gateway (Hardware) BACnet� Max.128 indoor units & Max.32 refrigerant system VRF indoor unit VRF indoor unit VRF outdoor unit Model name Power supply Power consumption Dimensions (H x W x D) Weight UT Y-VBG X 208-240V 50 / 60Hz, single phase W - mm 260 � 59 � 145 g - Network Convertor for LONWORKS� UTY-VLGX � For connection between VRF network system and a LONWORKS� open network for management of small to medium sized BMS and VRF network systems � The UTY-VLGX permits central monitoring and control of a VRF network system from a BMS through a LONWORKS� interface � Up to 128 indoor units can be connected to one Network Convertor for LONWORKS� Max. controllable 4 units to BMS Max. controllable 128 indoor units Max. controllable 100 outdoor units Functions Installation example General-purpose building control computer (LONWORKS� device) Controller Lighting facilities Security system Automatic fire alarm interface Windows bind Network Convertor for LONWORKS� LONWORKS� Network Max.128 indoor units & Max.100 outdoor units VRF indoor unit VRF indoor unit VRF outdoor unit Specifications Model name Power supply Power consumption Dimensions (H x W x D) Weight UT Y-VLG X 208-240V 50 / 60Hz, Single phase W 4.5 mm 67 � 288 � 211 g 1,500 Transmission specifications (BMS side) Transmission speed Transceiver Transmission way form Terminal resistor 78 kbps FT-X1 (Echelon� Corporation) Free topology None (It attaches at the terminal of a network.) 119 AIRSTAGETM Control Systems Convertor / Adaptor MODBUS� Convertor (for VRF) UTY-VMGX Max. connectable 9 units to one VRF Max. controllable 128 indoor units Max. controllable 100 outdoor units The MODBUS Convertor allows a complete integration of air conditioners into MODBUS Networks � Compact and lightweight design � Direct connection to MODBUS network � Up to 128 indoor units can be controlled in one MODBUS Convertor � The MODBUS Convertor permits central monitoring and control of air conditioners from BMS or central controller Functions BMS/Central Controller Controller Lighting facilities Security system Automatic fire alarm interface * BMS : Bulding Management System Windows bind Specifications Model name Power supply Input power W Dimensions (H x W x D) mm Weight g MODBUS Convertor for VRF VRF System (LON network) VRF indoor unit VRF indoor unit VRF outdoor unit UT Y-VMG X 220-240V 50 / 60Hz, single phase Max. 2 54 � 260 � 150 1,100 KNX� Convertor (for VRF) UTY-VKGX It is possible to control the VRF system from the Central / Home Controller via the KNX network � The new KNX Convertor enables connection of the Central / Home Controller and FG VRF system � A maximum of 128 indoor units and 100 outdoor units can be connected to single KNX Convertor Max. controllable 128 indoor units Max. controllable 100 outdoor units Functions KNX Convertor for VRF VRF network Central / Home Controller Specifications Model name Power supply Input power W Dimensions (H x W x D) mm Weight g 120 Registrable 128 indoor units 100 outdoor units UT Y-VKG X 220-240V 50 / 60Hz 1.5 54 � 260 � 150 1,200 MODBUS� Convertor (for indoor unit) UTY-VMSX The MODBUS Convertor allows a complete integration of air conditioners into MODBUS networks � Simple installation due to small and compact size � No separate external power supply required � The MODBUS Convertors must be connected one by one in the indoor unit � The MODBUS controller permits central monitoring and control of air conditioners from BMS / Central / Home Controller Functions BMS/Central/ Home Controller Specifications Model name Power supply Input power W Dimensions (H x W x D) mm Weight g MODBUS network Lighting facilities Security system Automatic fire alarm interface Windows bind UT Y-VMSX DC12V Max. 1.2 140 � 117 � 43 200 MODBUS Convertor Temperature Operating / packaged �C Humidity Operating / packaged % Maximum connectible indoor unit number per 1 MODBUS Convertor Max. controllable 1 single indoor unit 0~46 / -10~60 0~95 / 0~95 1 KNX� Convertor (for indoor unit) UTY-VKSX It is possible to control the VRF system from the Central / Home Controller via the KNX network � New KNX Convertor enables connection between Central / Home Controller and FG indoor unit � Compact and lightweight design Functions Single split indoor unit Max. controllable 1 single indoor unit Central / Home Controller Specifications Model name Power supply Input power W Dimensions (H x W x D) mm Weight g KNX Convertor for indoor unit UT Y-VK SX (DC12V) 0.6 140 � 117 � 43 250 121 AIRSTAGETM Control Systems Convertor / Adaptor Network Convertor UTY-VTGX (DC power supply type) The Network Convertor offers a total solution to control multiple air conditioning systems. Max. controllable 16 single indoor units Max. controllable 100 network convertors Functions Solutions for multiple air conditioning systems � The convertor is required when connecting single units to a VRF network system � Administrator can perform total management of single units with a centralised VRF controller Single unit with VRF Single split type unit management VRF network system VRF network system Network Convertors Max Network Convertors in one VRF network system: 100 Signal Amplifier UTY-VSGXZ1 � Transmission line length can be extended up to 3,600m with multiple Signal Amplifiers � Up to 40 signal amplifiers can be installed in a VRF network system � A signal amplifier is required (1) When the total wiring length of the transmission line exceeds 500m (2) When the total number of units on the transmission line exceeds 64 Functions Installation example B C A D Signal Amplifier Specifications Model name Power supply Input power W Dimensions (H x W x D) mm Weight g UT Y-VSG X Z1 208-240V 50 / 60Hz, single phase 4.5 67 � 288 � 211 1,500 Solutions for easy installation DC power supply type can be powered by indoor unit No power supply construction for convertor Easy wiring VRF network system Network Convertors Simple connection Single unit Specifications Model name Power supply Input power W Dimensions (H x W x D) mm Weight g 122 polar 3-wire DC12V Max indoor units connected by one convertor: 16 The new convertor is lightweight and compact, reducing the installation space required Design flexibility Size 85% REDUCTION Previous model 288 Weight 250g 140 211 117 40 67 UT Y-V TG X Max. 1.2 43 � 117 � 140 250 non-polar 2-wire DC12V 123 AIRSTAGETM OPTION 124 Diverse building air conditioning control functions can be controlled easily by AIRSTAGETM options. Various kinds of optional parts are provided such as controllers, adaptors and convertors to meet the needs of every user. AIRSTAGETM OPTION External Power Supply Unit Auto Louvre Grille Kit CONTROL SYSTEM LIST OPTIONAL PARTS LIST OPTIONAL PARTS EXTERNAL INPUTS AND OUTPUTS PIPING AND REFRIGERATION ACCESSORIES 125 AIRSTAGETM Option External Power Supply Unit Models UTZ-GXXA Features A) When power is isolated the system will not go into a communication error B) The expansion valve is controlled even when the power is isolated C) 24V power supply control when mains power is isolated Main power AC 220 / 230 / 240V Auxiliary power AC 24V Main power AC 220 / 230 / 240V Auxiliary power AC 24V Breaker ON Relay* (Power shut down detection part) External power supply unit Indoor unit Breaker OFF Relay* (Power shut down detection part) External power supply unit A B C Indoor unit Outdoor unit VRF network system Note � When changing the power supply voltage to AC24V, use a power transformer with an insulation structure equivalent to CLASS 2. � Indoor units that are powered off and driven by an external Power Supply Unit are handled in the same manner as operation off units in the electricity charge apportionment function. Since standby power may be charged to them, the electricity charge apportionment result for them may not be 0. Specifications Model name Power Supply Dimensions (H � W � D) mm Weight g 126 UTZ-GXXA AC 24 V 50 / 60 Hz, single phase 65 � 186 � 178 500 Auto Louvre Grille Kit Models UTD-GXTA-W UTD-GXTB-W UTD-GXTC-W Closed louvre Opened louvre Features Flexible control � Operation with indoor unit The Auto louvre can be operated via the remote controller of the indoor unit. � Up and down auto swing � Auto airflow direction and auto swing � 4 steps selectable � Auto closing louvre When the operation of the indoor unit is stopped, the louvre will automatically close. Duct type Auto louvre grille Dimensions W2 Fitting frame Grille Model name UTD-GXTA-W UTD-GXTB-W UTD-GXTC-W H1 H2 W1 D1 D2 W1 W2 H1 H2 683 645 883 845 180 148 1,083 1,045 Unit: mm D1 D2 9 84 Wired remote controller Wireless remote controller Specifications Model name Applicable indoor unit Power source Fixing of auto louvre grille Extension square duct limit Dimensions (H � W � D) Weight Net Gross Color Louvre motor Accessories Operation range Cooling Heating mm kg �C % RH �C UTD-GXTA-W ARXD007 / 009 / 012 / 014GLEH ARXK007 / 009 / 012 / 014GLEH 180 � 683 � (84+9) 2.0 3.0 UTD-GXTB-W AR XD018GLEH AR XK018GLEH Connecting with control box of indoor unit Screw fixing to flange or square duct 1.0m (Max. duct length between indoor unit and grille) 180 � 883 � (84+9) 2.5 3.5 White Stepping motor Fitting frame, etc. 18 to 32 80% or less 16 to 30 UTD-GXTC-W AR XD024GLEH AR XK024GLEH 180 � 1083 � (84+9) 3.0 4.0 127 AIRSTAGETM Option CONTROL SYSTEM LIST Controllers / Interface Type 4-way Flow Compact 4-way Flow Slim type Cassette 4-way Flow Large type Indoor unit Circular Flow Slim type Circular Flow Large type Duct Mini Slim (with drain pump) (with drain pump) AUXB 007 / 009 / 012 / 014 / 018 / 024 GLEH AUXB 07 / 09 / 12 / 14 / 18 / 24 GALH AUXD 18 / 24GALH AUXA 18 / 24 / 30 / 34 / 36 / 45 / 54 GALH AUXM 018 / 024 / 030 GLEH AUXM 018 / 024 / 030 GLAH AUXK 018 / 024 / 030 / 034 / 036 / 045 / 054GLEH AUXK 018 / 024 / 030 / 034 / 036 / 045 / 054GLAH ARXK 007 / 009 / 012 / 014 / 018 / 024 GLEH ARXD 007 / 009 / 012 / 014 / 018 / 024 GLEH Controllers Wired Remote Controller Simple Remote Controller Wireless Remote Controller 2-wire type 2-wire type UT Y-RNRY Z3 UTY-RSRY, UTY-RHRY UT Y-LNHY Central Remote Controller Change Items UT Y-DCGY Z1 Touch Panel Controller System Controller, System Controller Lite UT Y-DTGY Z1 UTY-APGXZ1, UTY-ALGXZ1 Interface BACnet Gateway UTY-ABGXZ1, UTY-VBGX Network Convertor for LONWORKS UT Y-VLG X MODBUS Convertor for VRF UT Y-VMG X KNX Convertor for VRF UT Y-VKG X MODBUS Convertor for indoor unit UT Y-VMSX UT Y-VMSX KNX Convertor for indoor unit UT Y-VK SX UT Y-VK SX Medium Static Pressure Duct High Static Pressure ARXA 024 / 030 / 036 / 045 GLEH ARXC 36 / 45 / 60 GATH High Static Pressure ARXC 036 / 072 / 090 / 096 GTEH Floor - EEV external AGYA 007 / 009 / 012 / 014 GCEH AGYE 007 / 009 / 012 / 014 GCEH Ceiling / Floor Indoor unit Ceiling ABYA 012 / 014 / 018 / 024 GTEH ABYA 030 / 036 / 045 / 054 GTEH - ASYA 007 / 009 GTEH EEV external ASYE 007 / 009 GTEH Wall mounted - EEV external - ASYA 012 / 014 GCEH ASYE 012 / 014 GCEH ASYA 18 / 24GBCH ASYA 030 / 034 GTEH UT Y-RNRY Z3 UTY-RSRY, UTY-RHRY UT Y-LNHY UT Y-DCGY Z1 UT Y-DTGY Z1 UTY-APGXZ1, UTY-ALGXZ1 UTY-ABGXZ1, UTY-VBGX UT Y-VLG X UT Y-VMG X UT Y-VKG X UT Y-VMSX UT Y-VMSX UT Y-VMSX UT Y-VK SX UT Y-VK SX UT Y-VK SX 128 129 AIRSTAGETM Option OPTIONAL PARTS LIST Others Others Type IR Receiver Unit 4-way Flow Compact 4-way Flow Slim type Cassette 4-way Flow Large type Indoor unit Circular Flow Slim type Circular Flow Large type Duct Mini Slim (with drain pump) (with drain pump) AUXB 007 / 009 / 012 / 014 / 018 / 024 GLEH AUXB 07 / 09 / 12 / 14 / 18 / 24 GALH AUXD 18 / 24GALH AUXA 18 / 24 / 30 / 34 / 36 / 45 / 54 GALH AUXM 018 / 024 / 030 GLEH AUXM 018 / 024 / 030 GLAH AUXK 018 / 024 / 030 / 034 / 036 / 045 / 054GLEH AUXK 018 / 024 / 030 / 034 / 036 / 045 / 054GLAH ARXK 007 / 009 / 012 / 014 / 018 / 024 GLEH ARXD 007 / 009 / 012 / 014 / 018 / 024 GLEH UT Y-LRHYB1 UT Y-LBHXD UT Y-TRHX Human Sensor Kit UT Y-SHZ XC Remote Sensor Unit Replaces indoor return air sensor and allows return air to be sensed from a remote location. UTG-UFYC-W UT Y-X S Z X Cassette Grille UTG-UGYA-W Auto Louvre Grille Kit Long Life Filter UTG-UKYC-W UTD-GXTA-W (007-014), UTD-GXTB-W (018), UTD-GXTC-W (024) Flange Drain Pump Unit Wide Panel Panel Spacer Indoor unit 950 600 Panel 600 (mm) (mm) 242 Panel spacer Fresh Air Intake Kit For Compact Cassette For Cassette Air Outlet Shutter Plate For Compact Cassette For Cassette Insulation for High Humidity For Compact Cassette type / Cassette type UT Z-V X A A UTR-YDZB UT Z-K XGC Half Concealed Kit External Power Supply Unit This kit is used to half conceal floor type indoor unit into the wall. UT Z- G X X A Pressure Sensor Kit UTG-AKXA-W UTG-BKXA-W UT Z-V XR A UTR-YDZK UT Z-K XR A UT Z- G X X A UT Z- G X X A UT Z- G X X A 130 Medium Static Pressure Duct High Static Pressure High Static Pressure Indoor unit Floor Ceiling / - EEV external Floor Ceiling - ARXA 024 / 030 / 036 / 045 GLEH ARXC 36 / 45 / 60 GATH ARXC 036 / 070 / 090 / 096 GTEH AGYA 007 / 009 / 012 / 014 GCEH AGYE 007 / 009 / 012 / 014 GCEH ABYA 012 / 014 / 018 / 024 GTEH ABYA 030 / 036 / 045 / 054 GTEH ASYA 007 / 009 GTEH EEV external ASYE 007 / 009 GTEH Wall mounted - EEV external Outdoor unit V-III - ASYA 012 / 014 GCEH ASYE 012 / 014 GCEH ASYA 18 / 24GBCH ASYA 030 / 034 GTEH AJY 072 / 090 / 108 / 126 / 144 / 162 LALBH UT Y-TRHX UTB-TWC UT Y-TRHX UT Y-X S Z X UTD-LF25NA UTD-LF60KA UTD-LF60KA (036) UTD-SF045T UTD-RF204 UTZ-PX1NBA UTD-RF204 UTR-DPB24T UT Z- G X X A UTR-STA UT Z- G X X A UT Z- G X X A UT Y-SPW X 131 AIRSTAGETM Option OPTIONAL PARTS Controllers For Individual Control Wired Remote Controller (Touch Panel) UTY-RNRYZ3 Simple Remote Controller UTY-RSRY with operation mode UTY-RHRY without operation mode Wireless Remote Controller UTY-LNHY IR Receiver Unit UTB-TWC, UTY-TRHX For Duct type IR Receiver Unit UTY-LRHYB1 For Cassette type UTY-RSRY UTY-RHRY IR Receiver Unit UTY-LBHXD For Circular Flow Cassette type Human Sensor Kit UTY-SHZXC For Circular Flow Cassette type For Centralised Control Central Remote Controller UTY-DCGYZ1 Change Items System Controller UTY-APGXZ1 UT Y-PEG X Z1 132 Touch Panel Controller UTY-DTGYZ1 UT Y-P TG X A System Controller Lite UTY-ALGXZ1 UT Y-PLG XR 2 UT Y-PLG X A 2 UT Y-PLG XE2 UT Y-PLG X X 2 Convertors / Adaptors For External Device BACnet� Gateway UTY-ABGXZ1 WHITE-USB-KEY (Software Protection Key) MODBUS� Convertor for VRF UTY-VMGX KNX� Convertor for Indoor unit UTY-VKSX For System Expansion Network Convertor for single split system UTY-VTGX DC power supply type Panels For Cassette type Cassette Grille UTG-UFYC-W For Compact Cassette type BACnet� Gateway UTY-VBGX KNX� Convertor for VRF UTY-VKGX Signal Amplifier UTY-VSGXZ1 Cassette Grille UTG-UGYA-W For Cassette type Network Convertor for LONWORKS� UTY-VLGX MODBUS� Convertor for Indoor unit UTY-VMSX For Indoor unit External Power Supply Unit UTZ-GXXA Cassette Grille UTG-UKYC-W For Circular Flow Cassette type 133 AIRSTAGETM Option OPTIONAL PARTS For Duct type Flange (round) UTD-RF204 For Medium Static Pressure Duct type / Ceiling type Flange (square) UTD-SF045T For Medium Static Pressure Duct type Remote Sensor Unit UTY-XSZX For all Duct type Remote temperature sensor unit replaces indoor unit return air sensor with sensor from location of remote sensor. Long-Life Filter UTD-LF25NA For Medium Static Pressure Duct type UTD-LF60KA For High Static Pressure Duct type Auto Louver Grille Kit UTD-GXTA-W (for ARXD07 / 09 / 12 / 14, ARXK07 / 09 / 12 / 14) UTD-GXTB-W (for ARXD18, ARXK18) UTD-GXTC-W (for ARXD24, ARXK24) For Slim Duct type / Mini Duct type Drain Pump Unit UTZ-PX1NBA For Medium Static Pressure Duct type For Cassette type Wide Panel UTG-AKXA-W For Cassette type Indoor unit 950 Panel 600 600 Panel Spacer UTG-BGYA-W For Cassette type (mm) Fresh Air Intake Kit UT Z-V X A A For Compact Cassette type UTZ-VXRA For Cassette type Air Outlet Shutter Plate UTR-YDZB For Compact Cassette type Shuts the 4th outlet when installed in a 3 outlet directional airflow scenario. (mm) 50 Panel spacer Insulation Kit for high humidity UTZ-KXRA For Cassette type UTZ-KXGC For Compact Cassette type Air Outlet Shutter Plate UTR-YDZK For Cassette type Shuts the 4th outlet when installed in a 3 outlet directional airflow scenario. For Ceiling type Drain Pump Unit UTR-DPB24T For Ceiling type For Floor type Half Concealed Kit UTR-STA For Floor type For Outdoor Unit Pressure Sensor Kit UTY-SPWX For V-III 134 Others Communication system: External Connect Kit For Indoor unit UTY-XWZXZ7 UTY-XWZXZD UTY-XWZXZB UTY-XWZXZE UTY-XWZXZC For RB unit UTY-XWZXZ6 For Central Remote Controller UTY-XWZXZ7 UTY-XWZXZB UTY-XWZXZ8 UTY-XWZXZA For Outdoor unit UTY-XWZXZ6 UTY-XWZXZ9 UTY-XWZXZF For Touch Panel Controller UTY-XWZXZA 135 AIRSTAGETM Option EXTERNAL INPUTS AND OUTPUTS External Input and Output Function / External Connect Kit / Communication Kit Cassette Indoor unit Duct 4-way Flow Compact 4-way Flow Slim type 4-way Flow Large type Circular Flow Slim type Circular Flow Mini Slim Medium Static Large type (with drain pump) (with drain pump) Pressure High Static Pressure Floor EEV external Ceiling / Floor Type AUXB 07 / 09 / 12 / 14 / 18 / 24 GALH, AUXB 007 / 009 / 012 / 014 / 018 / 024 GLEH AUXD 18 / 24GALH AUXA 18 / 24 / 30 / 34 / 36 / 45 / 54 GALH AUXM 018 / 024 / 030 GLEH, AUXM 018 / 024 / 030 GLAH AUXK 018 / 024 / 030 / 034 / 036 / 045 / ARXK ARXD 054GLEH, 007 / 009 / 012 / 007 / 009 / 012 / AUXK 014 / 018 / 024 014 / 018 / 024 018 / 024 / 030 / GLEH GLEH 034 / 036 / 045 / 054GLAH ARXA 024 / 030 / 036 / 045 GLEH ARXC 36 / 45 / 60GATH, ARXC 036 / 072 / 090 / 096 GTEH AGYA 007 / 009 / 012 / 014 GCEH AGYE 007 / 009 / 012 / 014 GCEH ABYA 012 / 014 / 018 / 024 GTEH Input Operation / Stop UT Y-X W Z X ZD UT Y-X W Z X ZB All On / All Off Batch stop Forced stop Emergency stop Forced thermostat off Low noise mode operation Cooling / Heating priority Outdoor unit operation peak control Power usage information from electricity meter Operation status UT Y-X W Z X ZD UT Y-X W Z X ZB UT Y-X W Z X ZD UT Y-X W Z X ZB UT Y-X W Z X ZE UT Y-X W Z X Z7 UT Y-X W Z X ZC Output Error status UT Y-X W Z X ZC Indoor unit fun operation status Auxiliary heater output UT Y-X W Z X ZC UT Y-X W Z X ZC Base heater *2: Touch Panel Controller has these functions for Dry contact and Apply voltage, however, the above External Connect Kit is not necessary because Touch Panel Controller has an external input terminal block. 136 Ceiling Indoor unit Wall mounted EEV external Outdoor unit Controller Other J-IIIL J-III J-IIS VR-II V-III Central Remote Touch Panel Controller Controller RB Unit ABYA 030 / 036 / 045 / 054 GTEH ASYA 007 / 009 GTEH, ASYA 012 / 014 GCEH ASYE 007 / 009 GTEH, ASYE 012 / 014 GCEH ASYA 18 / 24GBCH ASYA 030 / 034 GTEH AJY 072 / 090 / 108 / 126 / 144 LELAH AJY 040 / 045 / 054 LBLAH AJT 040 / 045 / 054 LCLAH AJT A72 / A90GALH, AJT 108 / 126GALH, AJT 144GBLH AJY 072 / 090 / 108 / 126 / 144 LALBH UT Y-DCGY Z1 UT Y-DTGY Z1 UTP-RX01AH UTP-RX01BH UTP-RX01CH UTP-RX04BH UT Y-X W Z X ZD UT Y-X W Z X ZB UT Y-X W Z X Z7 UT Y-X W Z X Z8 *2 *2 UT Y-X W Z X Z6 UT Y-X W Z X ZD UT Y-X W Z X ZB UT Y-X W Z X ZD UT Y-X W Z X ZB UT Y-X W Z X ZE UT Y-X W Z X Z7 UT Y-X W Z X Z6 UT Y-X W Z X Z7 UT Y-X W Z X Z8 *2 *2 UT Y-X W Z X Z6 UT Y-X W Z X Z6 UT Y-X W Z X Z6 UT Y-X W Z X ZB UT Y-X W Z X Z6 UT Y-X W Z X ZF *2 *2 UT Y-X W Z X ZC UT Y-X W Z X Z6 UT Y-X W Z X Z A UT Y-X W Z X ZC UT Y-X W Z X Z6 UT Y-X W Z X Z A UT Y-X W Z X ZC UT Y-X W Z X Z9 UT Y-X W Z X Z9 : Dry contact : Apply voltage 137 AIRSTAGETM Option PIPING AND REFRIGERATION ACCESSORIES Connection units Separation Tube UTP-AX054A Gas Pipe UTP-AX090A Gas Pipe UTP-AX180A Gas Pipe UTP-AX567A Gas Pipe Liquid Pipe UTP-BX090A Suction Gas Pipe Discharge Gas Pipe Liquid Pipe Header UTR-H0906L / UTR-H1806L Gas Pipe Liquid Pipe UTP-BX180A Suction Gas Pipe Discharge Gas Pipe Liquid Pipe UTR-H0908L / UTR-H1808L Gas Pipe Liquid Pipe Liquid Pipe Outdoor Unit Branch Kit UTP-CX567A Gas Pipe Liquid Pipe RB Unit UTP-RX01AH / UTP-RX01BH / UTP-RX01CH Single type UTP-DX567A Suction Gas Pipe Discharge Gas Pipe Liquid Pipe UTP-RX04BH Multi type Liquid Pipe UTP-BX567A Suction Gas Pipe Discharge Gas Pipe Liquid Pipe UTP-J0906A / UTP-J1806A Suction Gas Pipe Discharge Gas Pipe Liquid Pipe UTP-RX08AH Multi type Liquid Pipe UTP-J0908A / UTP-J1808A Suction Gas Pipe Discharge Gas Pipe Liquid Pipe EV Kit Model code 09 : UTR-EV09XB Model code 12 : UTR-EV14XB For Compact Wall Mounted type Compact Floor type UTP-RX12AH Multi type 138 Specifications Separation Tube Model name Total cooling capacity of indoor unit kW Model name Total cooling capacity of indoor unit kW UTP-AX054A 19.6 or less UTP-BX090A (for VR-II) 28.0 or less UTP-AX090A 28.0 or less UTP-A X180A 28.1 to 56.0 UTP-BX180A (for VR-II) 28.1 to 56.0 UTP-A X 567A 56.1 or more UTP-BX567A (for VR-II) 56.1 or more Header Model name 3-6 Branches 3-8 Branches Total cooling capacity of indoor unit kW Model name 3-6 Branches 3-8 Branches Total cooling capacity of indoor unit kW UTR-H0906L UTR-H0908L 28.0 or less UTP-J0906A (for VR-II) UTP-J0908A (for VR-II) 28.0 or less UTR-H1806L UTR-H1808L 28.1 to 56.0 UTP-J1806A (for VR-II) UTP-J1808A (for VR-II) 28.1 to 56.0 Outdoor unit Branch kit Model name Model name 2 outdoor units 3 outdoor units UTP-CX567A (for V-III) UTP-DX567A (for VR-II) 1 2 EV Kit Model name Application model ASYE007GTEH ASYE009GTEH UTR-EV09XB AGYE007GCEH AGYE009GCEH ASYE012GCEH ASYE014GCEH UTR-EV14XB AGYE012GCEH AGYE014GCEH RB Unit Model name Single type Number of outdoor unit UTP-R X01AH UTP-R X01BH UTP-R X01CH UTP-RX04BH Power source V/�/Hz 230 / 1 / 50 Input power W 17 24 31 96 Number of branches 1 1 1 4 Maximum capacity of connectable indoor units(Q) kW Maximum capacity of connectable indoor units per branch(Q) kW Maximum number of connectable indoor units per branch Q 8.0 Q 8.0 3 Q 18.0 Q 18.0 8 Q 28.0 Q 28.0 8 Q 56.0*1 Q 18.0 8 Dimensions (H�W�D) mm 198 � 298 � 268 198 � 298 � 268 198 � 298 � 268 260 � 658 � 428 *1: In the case of two RB units connected in series ( total 8-branches ), the maximum capacity of connectable indoor units is up to 56.0kW. Multi type UTP-RX08AH 136 8 Q 72.0 Q 8.0 7 298 � 660 � 618 UTP-R X12 AH 204 12 Q 95.0 Q 8.0 7 298 � 990 � 618 139 ABOUT US Since we began our air conditioning business in 1971, our products have been popular globally, and we continue to improve, evolve and expand our lineup to exceed customers' expectations. OUR HISTORY WORLD WIDE LOCATIONS PROJECT REFERENCES GLOBAL DEVELOPMENT AND PRODUCTION BASES HIGH QUALITY DEVELOPMENT AND PRODUCTION FACILITIES 140 141 About Us OUR HISTORY Fujitsu General's overseas air conditioning business has been in operation since 1971, with our VRF solutions being on the market since 2001. Fujitsu General's VRF AirstageTM Series has been developed based on our air conditioning technology along with an ongoing investment in research and development. We offer a series of products suitable for large homes to large scale buildings to meet the various needs of the market. For Residential & Light Commercial Use For Commercial Use 2004 J Series 6HP / Heat Pump 2011 J-II Series High efficiency and small capacity model 4HP to 6HP / Heat Pump 1936 Established as Yaou Shouten Ltd. 1971 Air conditioner exports to Middle East. 2001 S Series 10HP / Heat Recovery & Heat Pump 2003 10HP / Heat Recovery 8HP,10HP / Heat Pump & Cooling 2007 V Series 8HP to 42HP / Heat Pump 2009 V-II Series High efficiency and compact design model Extensive lineup from 8HP to 48HP in 2HP increments / Heat Pump 2012 VR-II Series High efficiency and compact design model 8HP to 48HP / Heat Recovery 1936-1971 1998 2001-2003 2004-2011 2012 Certification Acquisition of 1998 Fujitsu General (Shanghai) Co.,Ltd. 1999 Fujitsu General (Thailand) Co.,Ltd. 2002 FGA (Thailand) Co.,Ltd. 2006 Fujitsu General Central Air-conditioner (Wuxi) Co.,Ltd. 2004 New Product Initiatives Fujitsu introduced inverter technology which used R410A refrigerant. 2006 RoHS Compliant Restriction of Hazardous Substances (RoHS) is an EU directive on the restriction of the use of certain hazardous substances in all consumer electrical and electronic equipment. 142 2014 J-IIS Series High efficiency and compact design model 4HP to 6HP / Heat Pump 8HP - 12HP 14HP - 16HP 2016 J-III Series High efficiency and small capacity model 4HP to 6HP / Heat Pump 2017 - 2019 J-IIIL Series High efficiency and compact design model 10HP to 18HP / Heat Pump 2013 V-II TROPICAL Series Tropical spec model Extensive lineup from 8HP to 42HP in 2HP increments / Heat Pump 2015 V-III Series High efficiency and large capacity model Extensive lineup from 8HP to 54HP in 2HP increment / Heat Pump 2016 V-III TROPICAL Series Extensive lineup from 8HP to 54HP in 2HP increments / Heat Pump 2013 2014 2012 DC Inverter Compressors Use of 100% inverter driven DC compressors. 2015 2016 2017-2019 143 About Us WORLD WIDE LOCATIONS Fujitsu General Limited is focused on promoting globalisation whilst still emphasizing a local approach in the five key identified markets (Europe, Middle East, Asia & Oceania, Americas, and Japan). JAPAN Head Office Technology Research Building (Japan) 15 Overseas Sales Companies � Air conditioner solution centre "THE AIRSTAGE" in Manhattan, New York � Fujitsu General America, Inc. � Fujitsu General Do Brasil Ltda. Fujitsu General Orient International Fujitsu General (Taiwan) Co., Ltd. Electronics Sales (Shanghai) Co., Ltd. (China) (Taiwan) Fujitsu General (Thailand) Co.,Ltd. Bangkok Office (Thailand) Fujitsu General (Asia) PTE. Ltd. (Singapore) Fujitsu General (EURO) GmbH (Germany) 144 Fujitsu General (U.K.) Co., Ltd. (U.K.) Fujitsu General Air Conditioning (UK) Limited (U.K.) Fujitsu General Commercial Air Conditioning Italia S.p.A. (Italy) � Fujitsu General Air Conditioning (UK) Limited � Fujitsu General (U.K.) Co., Limited � Fujitsu General (Euro) GmbH � Fujitsu General Commercial Air Conditioning Italia S.p.A. � Fujitsu General Orient International Electronics Sales (Shanghai) Co., Ltd. � Fujitsu General Limited � Fujitsu General (Taiwan) Co., Ltd. � Fujitsu General (Thailand) Co.,Ltd. Bangkok Office � Fujitsu General (India) Private Limited � Fujitsu General (Middle East) FZE � Fujitsu General (Asia) Pte. Ltd. � Fujitsu General (Aust.) Pty Limited � Fujitsu General New Zealand Limited Fujitsu General (Aust.) Pty Ltd. (Australia) Fujitsu General New Zealand Ltd. (New Zealand) Fujitsu General (Middle East) FZE (U.A.E.) Fujitsu General Do Brasil Ltda.(Brasil) Fujitsu General (India) Private Limited Fujitsu General America, Inc. (U.S.A.) Fujitsu General Solution Centre "The Airstage" (U.S.A.) 145 About Us PROJECT REFERENCES Our products are popular due to their high quality, energy saving functionality and design for easy installation. They have been utilised in a wide range of building types including high rise office buildings, retail, hotels, public facilities, schools, hospitals and residential applications. Fujitsu General's products have been installed in over 50 countries worldwide. 1 2 3 6 146 4 5 For LIGHT COMMERCIAL 1 Shop in Asia 2 Restaurant in Middle East 3 Office in Europe 4 Hotel in Australia 5 School in U.S.A. 6 Hospital in Asia 7 9 10 11 8 For COMMERCIAL 7 Office in Europe 8 Office in Europe 9 Hotel in Asia 12 For RESIDENTIAL 10 Residential in Europe 11 Residential in Europe 13 12 Residential in Oceania 12 Residential in Middle East 147 About Us GLOBAL DEVELOPMENT AND PRODUCTION BASES Research and Development centres are set up in five countries around the world including Japan, Europe, Asia, China and North America. Globally we aim to provide customers with high quality and performance tested products to meet the comfort needs of each country. � Head Office � R&D Centre � Manufacturing Companies � Fujitsu General (Euro) GmbH - R&D Centre � Fujitsu General America, Inc. - R&D Centre R&D Centre & Technology Research Building R&D Centre in Fujitsu General (Shanghai) 148 R&D Centre in Fujitsu General Engineering (Thailand) R&D Centre in Fujitsu General (EURO) GmbH (Germany) R&D Centre in Fujitsu General America (U.S.A.) Overseas Manufacturing Companies � Fujitsu General Central Air-conditioner (Wuxi) Co., Ltd. � F.G.L.S Electric Co., Ltd. � Fujitsu General Limited - R&D Centre � Fujitsu General (Shanghai) Co., Ltd. - R&D Centre � Fujitsu General (Thailand) Co., Ltd. � Fujitsu General Engineering (Thailand) Co., Ltd. - R&D Centre � FGA (Thailand) Co., Ltd. � TCFG Compressor (Thailand) Co., Ltd. Technology Research Building in Japan Head Office JAPAN Head Office R&D Centre and 60m Height Difference Testing Tower (Japan) Fujitsu General (Shanghai) Co., Ltd. (China) F.G.L.S. Electric Co., Ltd. (China) Fujitsu General Central Air-conditioner (Wuxi) Co., Ltd. (China) Fujitsu General (Thailand) Co., Ltd. (Thailand) Fujitsu General Engineering (Thailand) Co., Ltd. (Thailand) FGA (Thailand) Co., Ltd. (Thailand) TCFG Compressor (Thailand) Co.,Ltd. (Thailand) 149 About Us HIGH QUALITY DEVELOPMENT AND PRODUCTION Fujitsu General is one of Japan's leading air conditioning manufacturers with an R&D Centre in Japan. We aim to provide customers with high quality and performance tested products. Advanced Research Facility and Equipment Performance Testing Air Volume Measurement Room Measures air volumes of the air conditioners from compact RAC models to VRF. Calorimeter Room Measures the cooling / heating capacity by measuring the inlet and outlet temperatures, humidity, and air volume of the air conditioner. Anechoic Chamber Measures the operating sound characteristics of air conditioners within a purpose built room deigned to acquire precise readings. Reliability Testing Fujitsu General is one of Japan's leading manufacturers with an R&D Centre in Japan. We provide customers with the highest quality and performance using these facilities. FACILITIES Acquisition of ISO 9001 and ISO 14001 ISO 9001 ISO 14001 ( ) Number of companies Each of the overseas production bases (5 companies) have completed the acquisition of ISO 9001 and ISO 14001 individually. In 2012, overseas sales bases (11 companies) acquired the certification of ISO 14001. North America Sales subsidiary (1) Europe Sales subsidiary (3) Middle East Sales subsidiary (1) South America Sales subsidiary (1) Asia � Sales subsidiary (3) � Manufacturing subsidiary (5) Japan � Head office � Manufacturing subsidiary (2) Oceania Sales subsidiary (2) Constant Temperature Room Practical Test Room Evaluates the product Evaluates the air conditioners performance in cooling / heating performance under actual operation under the various installation conditions. temperature and humidity conditions. Water Injection Testing Room Evaluates whether the electrical box of the outdoor unit is protected by rain waters with Typhoon like wind. Transportation & Handling Technology Research Building in Japan Head Office Compressibility testing Vibration testing Testing Laboratory Fujitsu General EMC Laboratory Limited 60m Height Difference Testing Tower Objective is to confirm oil circulation of compressor for reliability 150 High Product Quality Assurance All Fujitsu General factories have acquired ISO 9001, and have built a quality control system common around the world. This ensures high quality products are offered through consistent and stringent quality inspections. Receiving inspection Parts procurement requires a supplier's test report. European regulation RoHS inspection is also performed by a special test department in house. There are a number of inspections performed especially on main parts to ensure the identification and removal of any defects. Stringent product quality inspection High quality is maintained through stringent quality inspections which are carried out at each stage of the production process. Receiving inspections � Balancer inspection Parts & Material � RoHS inspection � Parts visual inspection � Parts specifications inspection Product quality inspections � Pressure resistance inspection � Primary leak inspection � Secondary leak inspection Assembly � Heat run inspection � Assembly visual inspection � Insulation resistance inspection � Withstand voltage inspection � Insulation resistance inspection � Withstand voltage inspection � Abnormal sound inspection � Completed product visual inspection Packing Completed product inspection � Performance inspection � Sampling inspection � Visual inspection � Water injection inspection � Vibration drop test Shipping 151 SUPPORT Our support offering methodology is focused on total support. From the stages of design, installation and commissioning through to after sales support. AIRSTAGETM SUPPORT AIRSTAGETM / RAC SUPPORT TOOL QUICK SERVICE AND MAINTENANCE SERVICE TOOL WEB MONITORING TOOL Mobile Technician Service Tool / Web Monitoring Tool CFD Simulation Design Simulator (RAC, PAC, VRF) Service Manual Installation Manual 3D CAD (Revit) Data 2D CAD Data Certificate Data Design & Technical Manual Operating Manual Feature Promotion Movie Brochures Product News Product Technical Training Material Product Sales Training Material Category Information Material Tool Product Training Product Information Technical Information Model Selection Design Verification Installation After Sales and Service 152 153 Support AIRSTAGETM SUPPORT Fujitsu General provides a variety of product and technical information to engineers and consultants. We also conduct new product research and design support activities. We provide a wide range of support to maintain high quality from design to installation. Training Fujitsu General has many training facilities around the world that regularly conduct specialised product, technical, and service training. These research facilities also support the development of people to ensure high technical capability. Features � Designing AIRSTAGETM Systems � Control systems on site training Head Office Training Centre: Japan Europe Training Centre: Germany Europe Training Centre: U.K. China Training Centre: China Asia Training Centre: Singapore America Training Centre: U.S.A. Middle East Training Centre: UAE 154 Oceania Training Centre: Australia Technical information We provide information and tools that are useful for air conditioning system design, such as unit performance data and tools that make model selection and estimation easy. Features � Design and Technical Manual � Model Selection and Estimation � Certificate Data � 2D / 3D CAD Data Product information New product information is provided in the form of documents for every new model released. These can be downloaded from a private section of our website. To access this website, please contact your Fujitsu representative. Features � Product News � Brochures and all Manuals � Feature / Promotion Movie Technical support Technical support is provided at every stage from design to installation to assist in providing the most suitable air conditioning solution. Features � CFD Simulation � Commissioning Support CFD Simulation 52.000 47,750 43.500 39.250 35.000 Commissioning Support 155 Support AIRSTAGETM / RAC SUPPORT TOOL Put the charts and pens away and design your projects on your computer with ease using the Design Simulator. Everything from selecting indoor and outdoor units, allocating controls and optional parts to designing the piping and wiring systems is made easier using the program's built-in features. Once your project is designed, take advantage of the Export functions to easily get materials lists, product specifications, refrigerant calculations and more. You can even export to Word, Excel, or Acrobat formats and group the relevant CAD data for your project. Design Simulator Automatically create model selection information � Each unit can be automatically set by entering the required performance, type, and temperature conditions for each indoor unit and then dragging and dropping into the outdoor unit. � Piping and wiring diagrams can be created automatically and it is easy to set branches, grouping and options. � The additional refrigerant charging amount is automatically calculated when the pipe length is entered. � It is also easy to set the remote controller groups, central controller and convertors. � The equipment list including the equipment information is created automatically. Output the format that matches the application The information specific to your project can be exported in a number of industry standard file formats. � Word format (rtf)(doc) � Excel format (csv) � Acrobat format (pdf) � Auto CAD format (DXF) � 2D Data (DXF) � 3D Data (RFA) Update your Design Simulator The database can be easily updated online using Auto Update function through FTP. 156 User side(PC) Information on the latest history update is demanded. Information on the latest history update replied. FTP server side (PC) BIM Building Information Modeling Fujitsu General provides the Building Information Modeling (BIM) object models and content for our VRF systems and other products for architects, designers and contractors using Autodesk� Revit� technology from our Website and Autodesk� Seek Website etc. 3D and 2D product data We provide 3D data for our products. 2D CAD design operations are supported and 2D display is also provided. The data can also be output in other formats, such as DXF and DWG, which are used by other design CAD design programs. Installation limitation The equipment installation limitation range is shown. Installation requirements, such as distance from the wall, are automatically displayed to make it easy to produce highly reliable design layouts. Update your Design Simulator Other information, such as symbols showing the airflow direction that are required for installation drawings, are built in and can be automatically reflected in 2D drawings. Installation drawings can be created easily. Product specifications and link information Contains the basic information required for air conditioner design, including unit size, capacity, input power, noise, and airflow rate. This data can be procured from the Fujitsu General Website, Design Simulator and Autodesk� Seek Website. 157 Support QUICK SERVICE AND MAINTENANCE If an error should occur on a unit or system, there is an abundance of support tools such as trouble code display on the product. The VRF Service Tool allows checking of the detailed status for the entire system, and a remote monitoring tool that uses the internet meaning support, quick service and maintenance is available anywhere and at any time. Mobile troubleshooting tool for smart phones Mobile Technician, our Service Support app, can be used for error code checking, obtaining service instructions, troubleshooting and sensor checking information for our RAC, PAC and VRF ranges. The Mobile Technician app is available free of charge for compatible devices. Mobile Technician FREE 158 Easy maintenance and monitoring Design for easy maintenance The air conditioner operating status and trouble status are viewable on the 7 segment display of the outdoor unit PCB or on the remote controller screen. The unit status can be checked efficiently enabling a quick response. � Operation mode status � Discharge temperature / Pressure status � Compressor operation indication � Address / Type / Number of outdoor units � Error code 7 segment LED Wired Remote Controller (Touch panel) Error status / Error history Wired Remote Controller Faulty unit number (Remote controller address) Error code SU MO TU WE TH FR SA Error diagnosis with the Service Tool The unit status details for the VRF system can be checked on a PC screen by connecting to the Service Tool. A quick analysis can be made. Viewable parameters include: � Operation status / control � Monitoring operating condition � Monitoring sensor data � Indication of trend graph � Error history � Indication of refrigerant circuit diagram � Automatic operation check for refrigeration cycle Remote monitoring VRF system operating status and error status details can be constantly monitored over the Internet. Transmission line Refrigerant piping Indoor unit (Locally purchased) Service Tool USB adaptor UT Y-A SGX Z1 (Locally purchased) Software Internet or Public Telephone Line Remote Monitoring Web Monitoring Tool UTY-AMGXZ1 Software 159 Support SERVICE TOOL Extensive monitoring and analysis functions for installation and maintenance � Operation status can be checked and analysed to detect even the smallest abnormalities � Service Tool can be used to log system operation for further analysis off site � Up to 400 indoor units (a single VRF network system) can be controlled and monitored for large scale buildings or hotels � This software can be connected to any point of transmission line with USB adaptor (locally purchased) * The saved data can be displayed offline. However, the data saved by the following model cannot be displayed. � UTR-YSTB / UTR-YSTC (Service Tool) � UTR-YMSA (Web Monitoring Tool) Automatic operation check for refrigeration cycle After product installation, an operation check can be performed automatically. Self diagnosis functionality automatically judges whether each sensor value is normal, saving time and workload. The diagnosis can also be output as a report. Note : Use only as a guide Whether each sensor value is normal is judged automatically. OK Discharge temperature normal value OK Super heat volume normal value OK High pressure pipe normal value OK Low pressure pipe normal value etc. Remote technical support and maintenance On site the service tool's screen can be shared with support personnel in a remote location. When visiting a site for troubleshooting, operation status can be shared in real time making assistance easy. The online chat function helps to support on site staff. Remote location An error occurs at local system. ERROR Internet Technical support Installer / Administrator Various trend graphs are displayable Previously, only 3 graphs could be viewed simultaneously, now multiple graphs can be displayed on the new Service Tool depending on the requirements. Personal computer system requirements UT Y-A SG X Z1 Operating system � Microsoft� Windows� 7 Professional (32-bit or 64-bit) SP1 � Microsoft� Windows� 8.1 Pro (32-bit or 64-bit) � Microsoft� Windows� 10 Pro (32-bit or 64-bit) CPU 1 GHz or higher Memory � 1 GB or more (for Windows� 7 [32-bit], Windows� 8.1 [32-bit], and Windows� 10 [32-bit]) � 2 GB or more (for Windows� 7 [64-bit], Windows� 8.1 [64-bit], and Windows� 10 [64-bit]) HDD Display 40 GB or more of free space 1366 x 768 or higher resolution Interface � 2 USB ports - 1 USB port is required for software protection key connection - 1 USB port is required for Echelon� U10 USB Network Interface Software Internet Explorer� 11 or Microsoft Edge / Adobe� Reader� 9.0 or later �Echelon� U10 USB Network Interface � TP / FT-10 Channel (Model number: 75010R) (Required for each VRF Network.) NOTE: Echelon adapter is sold separately. <PACKING LIST> Name and shape Quantity Application WHITE-USB-KEY (Software protection key) 1 Software protection key to be connected to USB port on the Service Tool-installed PC. These products run only on a PC with WibuKey. �Personal computer that satisfies the following system requirements 160 WEB MONITORING TOOL Product features � Troubleshooting is performed by monitoring each air conditioning unit remotely during periodical system checks � Error notification can be automatically transmitted to several locations using the internet *1 � Requires either a dedicated internet connection or public telephone line � Identification of an error is possible via error warnings and equipment status information obtained from a remote location � The system data can be downloaded remotely. This data can be viewed in the offline mode of the service tool � The PC being used to monitor equipment isn't required to install special software as access is via a general web browser *1: Use of internet mail system required. Web Monitoring System Monitoring Side Internet VRF Network System Side Outdoor unit Transmission line Web Monitoring Tool USB adapter (Locally purchased) Indoor unit Support 4 VRF network systems USB adaptor (max. 4 adaptors per PC) permitted, monitoring of up to 1,600 indoor units. Suitable for large scale buildings or hotels. USB adaptors VRF Network System 1 Max. 400 Indoor unit VRF Network System 2 Max. 400 Indoor unit VRF Network System 3 Max. 400 Indoor unit VRF Network System 4 Max. 400 Indoor unit Personal computer system requirements UT Y-A MG X Z1 Operating system � Microsoft� Windows� 7 Professional (32-bit or 64-bit) SP1 � Microsoft� Windows� 8.1 Pro (32-bit or 64-bit) � Microsoft� Windows� 10 Pro (32-bit or 64-bit) CPU 1 GHz or higher Memory � 1 GB or more (for Windows� 7 [32-bit], Windows� 8.1 [32-bit], and Windows� 10 [32-bit]) � 2 GB or more (for Windows� 7 [64-bit], Windows� 8.1 [64-bit], and Windows� 10 [64-bit]) HDD Display 40 GB or more of free space 1366 x 768 or higher resolution Interface � 2 USB ports - 1 USB port is required for software protection key connection - 1 USB port is required for Echelon� U10 USB Network Interface per VRF wiring network (max 400 indoor units, 100 outdoor units) Up to 4 Echelon adapters may be required if there are multiple VRF Wiring networks on site. 1 x Echelon adapter per wiring network, max 4 x wiring networks. Software Internet Explorer� 11 or Microsoft Edge / Adobe� Reader� 9.0 or later �Echelon� U10 USB Network Interface � TP / FT-10 Channel (Model number: 75010R) (Required for each VRF Network.) NOTE: Echelon adapters are sold separately. <PACKING LIST> Name and shape Quantity Application WHITE-USB-KEY (Software protection key) 1 Software protection key to be connected to USB port on the Service Tool-installed PC. These products run only on a PC with WibuKey. �Personal computer that satisfies the following system requirements 161 FUJITSU COMMUNITY SPORTING CHANCE Fujitsu General Australia is extremely proud to be a major sponsor of the Sporting Chance Cancer Foundation. Established in 1996 by a number of high profile Australian sports men and women, including Fujitsu General's longstanding ambassador Mark Taylor, Sporting Chance is a not-for-profit organisation that helps provide home support and care to children with cancer. To date, Fujitsu General has donated more than $8.5M to this worthy cause, with a percentage of sales from Fujitsu's air conditioning units going towards the funding of outreach programs and exploring better ways to treat and overcome cancer. This support has enabled the Sporting Chance Cancer Foundation to fund nurses across Australia allowing children to receive improved cancer care closer to home. This funding also allows for remote treatment and care for families, and considerably reduces the time spent travelling to and from the nearest hospital, which could be thousands of kilometres from home. Sporting Chance initiatives allow families to spend more quality time at home together, while still having access to the correct care for their child. Fujitsu General is dedicated to the ongoing support of the Sporting Chance Cancer Foundation and its commitment to improving the cancer care available for children, as well as research and new treatment developments. 162 163 SATISFACTION FOR ALL CUSTOMERS FUJITSU GENERAL (AUST.) PTY LIMITED ABN 55 001 229 554 A Subsidiary of FUJITSU GENERAL LIMITED www.fujitsugeneral.com.au HEAD OFFICE NSW 1 Telopea Place, Eastern Creek NSW 2766 Tel: (02) 8822 2500 Fax: (02) 8822 2501 VIC / TAS Suite 1, Building 2, Omnico Business Centre, 270 Ferntree Gully Road, Notting Hill VIC 3168 Tel: (03) 9543 5899 Fax: (03) 9543 8299 QLD Tenancy 1.02, 371 Macarthur Avenue, Hamilton QLD 4007 Tel: (07) 3257 2800 Fax: (07) 3257 2184 SA / NT 128A Rose Terrace, Wayville SA 5034 Tel: (08) 8172 1180 Fax: (08) 8172 1190 WA Unit 1, 24 Gibberd Road, Balcatta WA 6021 Tel: (08) 9240 5877 Fax: (08) 9240 5866 Email contact@fujitsugeneral.com.au - or call 1300 882 201 164 Fujitsu General (Thailand) Co., Ltd. ISO 9001 Certified number: 01 100 075229 ISO 14001 Certified number: 01 104 9245 Fujitsu General (Shanghai) Co., Ltd. ISO 9001 Certified number: ISO 14001 Certified number: 01 100 79269 CNBJ312244-UK Fujitsu General Central Air-conditioner (Wuxi) Co., Ltd. ISO 9001 Certified number: 15917Q20073R5M ISO 14001 Certified number: 15918E20021R5M All products specified in this brochure comply with the Australian Communications Authority's (ACA) requirements for Electromagnetic � Specifications and design are subject to change without notice for future improvement. � The products or equipments in this catalogue contain fluorinated greenhouse gases. � " " is a worldwide trademark of FUJITSU GENERAL LIMITED and is a registered trademark in Japan and other countries or areas. � " " is a worldwide trademark of FUJITSU GENERAL LIMITED. � "BACnet" is a trademark or registered trademark of the American Society of Heating, Refrigerating and Air-Conditioning Engineers, Inc. � "MODBUS" is a registered trademark of Schneider Electric. � "LONWORKS" and Echelon are trademarks of Echelon Corporation registered in the United states and other countries. � Other company and product names mentioned herein may be registered trademarks, trademarks or trade names of their respective owners. � Actual products' colors may be different from the colors shown in this printed material. 165 Variable Refrigerant Flow System HEAT PUMP & HEAT RECOVERY VRF CATALOGUE � Actual products' colours may be different from the colours shown in this printed material. Distributed by : FUJITSU GENERAL AUSTRALIA 1 Telopea Place, Eastern Creek, NSW, 2768 fujitsugeneral.com.au Copyright� 2008-2020 Fujitsu General Limited. All rights reserved. 6OF009-1903E
