dormakaba ED250 IG Owner's Manual ... This Owner's Manual applies to the ED250 operator ... Manuals are available for review, download, and printing.
ED250
Installation in In-ground Case
Owner's Manual
DL4614-090 08-2018
| EN |
dormakaba ED250 IG Owner's Manual
Table of contents
Table of contents
2
1 General information
3
2 To our customers
3
3 What you should know
4
3.1 Distributor information
4
3.2 Knowing act
4
3.3 Low energy power operated door
4
3.4 Program switch panel
4
3.5 Optional key switch panels
4
4 AAADM safety information label
5
4.1 Safety label, low energy swing doors
5
5 Daily safety check procedure
6
5.1 Low energy power operated swing doors
6
6 General safety related items
7
6.1 Low energy power operated swing doors
7
7 ED250 door signage
8
7.1 Low energy operator
8
7.2 Door signage, low energy swing doors,
initiation of door operation
9
8 ED250 in-ground door threshold
10
8.1 Install door threshold
10
Table of Contents
2
ED250
DL4614-090
08-2018
dormakaba ED250 IG Owner's Manual
Chapters 1 and 2
1 General information
1.1 Owner's manual This Owner's Manual applies to the ED250 operator packaged in a cement case for in-ground floor installations.
1.2 Manual storage
This document must be kept in a secure place, and accessible for reference as required. If the door system should be transferred to another facility, insure that this document is transferred as well.
1.3 dormakaba.com website Manuals are available for review, download, and printing on dormakaba.com website.
1.4 Dimensions Unless otherwise specified, all dimensions are given in inches (").
1.5 Symbols used in this manual
WARNING
This symbol warns of hazards which could result in personal injury or threat to health.
2 To our customers
We are pleased that a dormakaba USA Inc. ED250 in-ground system has been selected for this installation. The system has been designed, tested and built to provide many years of service.
The purpose of this manual is to familiarize you with your ED250 in-ground swing door system.
It is essential that you "know your system" and that you recognize the importance of maintaining your door system in compliance with industry standards for safety.
It is your responsibility as owner and caretaker of the equipment, to inspect the operation of your door system on a daily basis as outlined in Chapter 4, Safety Information Checklist to insure that it is safe for use by your customers and employees.
WARNING
Should the door fail to operate as prescribed in the Safety information checklist or at any other time for any reason, do not attempt to repair or adjust the ED250 swing door system!
Access to the ED250 in-ground system must only be done by dormakaba USA Inc. certified technicians!
NOTICE Draws attention to important information presented in this document.
CAUTION This symbol warns of a potentially unsafe procedure or situation.
1.6 In-ground case and ED 250 operator Fig.1.1 In-ground case and ED250 operator
Call your local authorized dormakaba USA Inc. distributor for repair. The distributor's AAADM certified technicians are trained to service the ED250 in-ground swing door system using dormakaba USA Inc. installation and service manuals, and in accordance with ANSI/BHMA safety standards.
2.1 Service availability dormakaba USA Inc. has a nationwide network of authorized distributors for sales, installation and service of its products.
2.2 Compliance with industry standards for safety Your ED250 automatic swing door system was designed to the latest ANSI/BHMA operating and safety standards. In order to insure the continued safe operation of the door, it is important that: · Proper decals and labels be applied and maintained
on your doors (Chapter 7). · If decals and labels have been removed, or cannot be
read, contact your local authorized dormakaba USA Inc. distributor for replacement decals or labels.
ED250
DL4614-090
08-2018
3
dormakaba ED250 IG Owner's Manual
Chapter 3
3 What you should know
3.1 Distributor information
3.1.1 dormakaba USA Inc. distributor information. Be sure that the dormakaba USA Inc. distributor has provided the following information for each door installation: 1. dormakaba USA Inc. ED250 in-ground Owner's
Manual. 2. Review of the daily Safety Information Checklist
(Chapter 4). 3. Instructions on how to conduct the daily Safety
Information checklist by walk through example. 4. Annual compliance inspection label completion
(Chapter 4). 5. Circuit breaker or disconnect location for 115 Vac
power to the ED250 in-ground system. 6. ED250 program switch panel location and
instructions in its use. (Para. 3.4). 7. Discussion of problems that could result from
operator being allowed to operate after a malfunction observed. 8. Number to call for service or questions about your system if you are uncertain of any condition or situation.
WARNING
If there are any problems, discontinue door operation immediately and secure the door in a safe manner. Call your local dormakaba USA Inc. distributor for repair.
3.4 Program switch panel
3.4.1 Program switch door control modes. 1. Auto, door opens when actuated by: · Knowing act device (Para. 3.2). Door will remain at
full open position for not less than 5 seconds. · Push/pull actuation of door, Para. 6.1.4. Door will
remain at full open position for not less than 3 seconds. 2. Open, door opens automatically and remains open. 3. Close, door will remain closed, or if door is open door will close.
3.4.2 Exit only switch modes · Off, Interior and exterior activation sensors both
active. · On, exterior activation sensor disabled when door
fully closed. Only interior activation sensor will enable door opening.
1 Program switch panel
2 Program switch, three position
3 Exit only switch, two position
4 Comm port for dormakaba handheld
Fig. 3.4.1 Program switch panel
1 2
4
3
3.2 Knowing act
3.2.1 ANSI/BHMA standard A159.19 definition. Consciously initiating the powered opening of a low energy door using acceptable methods including: · Push plates. · Fixed non-contact switches. · Action of manually opening (pushing or pulling)
a door. · Controlled access devices such as keypads, card
readers, and key switches.
3.3 Low energy power operated door
3.3.1 ANSI/BHMA standard A159.19 definition. A door with a power mechanism that opens the door upon receipt of a knowing act signal, does not generate more kinetic energy than specified in the ANSI/BHMA A156.19 standard, and is closed by a power mechanism or other means.
3.5 Optional key switch panels
Fig. 3.5.1 Optional key switch panels
4
ED250
DL4614-090
08-2018
dormakaba ED250 IG Owner's Manual
Chapter 4
4 AAADM safety information label
4.1 Safety label, low energy swing doors
4.1.1 Low energy swing door safety information label. This AAADM label outlines safety checks that should be performed daily on an automatic swing door controlled by an ED250 in-ground operator configured for low energy operation.
4.1.2 Safety information label location. Place label in a protected, visible location on door frame, near operator power switch if possible.
4.1.3 Annual compliance section of label. This section of label is only completed on low energy swing doors that comply with ANSI/BHMA A156.19 standard and pass inspection by a AAADM certified dormakaba USA Inc. technician.
4.1.4 Additional annual compliance inspection labels. Place additional labels over annual compliance inspection section of safety information label.
Fig. 4.1.1 Annual compliance inspection label
ANNUAL COMPLIANCE INSPECTION
INSPECT FOR AND COMPLIES WITH ANSI
A156.19 ON: DATE: ______________
by AAADM Certified Inspector
Number: ___________
Fig. 4.1.2 Safety information label
SAFETY INFORMATION
Low Energy Swinging Doors
These minimum safety checks, in addition to those in the Owner's Manual, should be made each day and after any loss of electrical power.
1. Activate the door. Door should open at a slow smooth pace (4 or more seconds), and stop without impact.
2. Door must remain fully open for a minimum of 5 seconds before beginning to close.
3. Door should close at a slow, smooth pace (4 or more seconds), and stop without impact.
4. Inspect the floor area. It should be clean with no loose parts that might cause user to trip or fall. Keep traffic path clear.
5. Inspect door`s overall condition. The appropriate signage should be present and the hardware should be in good condition.
6. Have door inspected by an AAADM certified inspector at least annually.
DO NOT USE DOOR if it fails any of these safety checks of if it malfunctions in any way. Call a qualified automatic door service company to have door repaired or serviced.
See Owner's manual or instructions for details on each of these and other safety items. If you need a copy of the manual, contact the manufacturer.
AAADM-3044
AAADM
American Association of Automatic Door Manufacturers
ANNUAL COMPLIANCE INSPECTION
INSPECT FOR AND COMPLIES WITH ANSI
A156.19 ON: DATE:______________
by AAADM Certified Inspector
Number:___________
ED250
DL4614-090
08-2018
5
dormakaba ED250 IG Owner's Manual
Chapter 5
5 Daily safety check procedure
5.1 Low energy power operated swing doors
5.1.1 Performing daily safety checks Perform safety checks daily on your low energy swing door to insure your customer and employee safety. These daily safety checks are also listed in Chapter 4, Safety Information labels, low energy swinging doors.
1. Activate the door by a knowing act (Para.3.3). · Door should open at a slow smooth pace
(4 seconds or more) and stop without impact. 2. Door must remain fully open for a minimum of
5 seconds before beginning to close. · Door should close at a slow smooth pace
(4 seconds or more) and stop without impact. 3. Inspect the floor area, it should be kept clean with no
loose parts that might cause user to trip or fall. Keep traffic path clear. 4. Inspect door's overall condition. The appropriate signage (Chapter 7) should be present and all hardware should be in good condition. 5. Have door inspected by a dormakaba USA Inc. AAADM certified technician at least annually.
Fig. 5.1.1 In-ground ED250 door (LH door with track and arm example)
WARNING
If there are any problems, discontinue door operation immediately and secure the door in a safe manner. Call your local dormakaba USA Inc. distributor for repair.
6
ED250
DL4614-090
08-2018
dormakaba ED250 IG Owner's Manual
Chapter 6
6 General safety related items
6.1 Low energy power operated swing doors
6.1.1 Review safety related items and perform checks periodically as noted
TIPS AND RECOMMENDATIONS
WARNING
Perform these checks while traffic is restricted.
1. Housekeeping · Check door area for tripping or slipping hazards. · Make sure all door hardware is properly secured. · There should be no bulletin boards, literature racks,
merchandise displays, or other attractions in the door area that would interfere with the use of the door or encourage people to stop and stand in the door area. 2. Check all doors for damage. 3. Door closing force
TIPS AND RECOMMENDATIONS
If there are any problems, discontinue door operation immediately and secure the door in a safe manner. Call your local dormakaba USA Inc. distributor for repair.
Reference ANSI/BHMA A156.19 standard, power assist and low energy power operated doors.
· Force to prevent the door from closing should not exceed 15 pounds measured with a force gauge.
4. Door safety signage · Refer to Chapter 7 for door safety signage
requirements. Chapter 4 documents safety information (daily safety check) and annual compliance inspection labels requirements. 5. Lock stile · With door open, grasp lock stile of door and attempt to move horizontally and vertically. · There should be no looseness in the door pivots or in connections between door and operator. 6. Breakout stop · Center pivoted in swinging doors may be supplied with an emergency breakout stop or switch that will allow the door to open in the direction of emergency egress. · When the door is pushed into the breakout mode, check that the door will not activate.
ED250
DL4614-090
08-2018
7
dormakaba ED250 IG Owner's Manual
7 ED250 door signage
7.1 Low energy operator
7.1.1 Overview Signage and warnings are specified in ANSI /BHMA A156.19, American National Standard for power assist and low energy power operated doors.
7.1.2 All low energy doors Fig. 7.1.1 AUTOMATIC CAUTION DOOR decal
AUTOMATIC
CAUTION
DOOR
DD0586-010
DD0586-010
1. AUTOMATIC CAUTION DOOR decal. · All low energy doors shall be marked with signage
visible from both side of door with the words "AUTOMATIC CAUTION DOOR". · Signs shall be mounted 50" ± 12" from floor to centerline of sign.
7.1.3 Knowing act switch used to initiate door operation1
Fig. 7.1.2 ACTIVATE SWITCH TO OPERATE decal
ACTIVATE SWITCH TO OPERATE
DD0758-010 DD0758-010
DD0758-010
1. ACTIVATE SWITCH TO OPERATE decal. · When a knowing act device is used to initiate operation
of door operator, door shall be provided with sign on each side of door where switch is operated with message "ACTIVATE SWITCH TO OPERATE".
7.1.4 Push/Pull used to initiate door operation. Fig. 7.1.3 PUSH TO OPERATE, PULL TO OPERATE decals
PUSH TO OPERATE
DD0762-010
DD0762-010
PULL TO OPERATE
DD0762-020
DD0762-020
1. PUSH TO OPERATE, PULL TO OPERATE decals. · When push/pull is used to initiate operation of door
operator, doors shall be provided with the message "PUSH TO OPERATE" on push side of door and "PULL TO OPERATE" on pull side of door.
8
ED250
DL4614-090
Chapter 7 08-2018
dormakaba ED250 IG Owner's Manual
Chapter 7
7.2 Door signage, low energy swing doors, initiation of door operation
7.2.1 Single door Fig. 7.2.1 Activate Switch To Operate
Fig. 7.2.2 Push/Pull Push To Operate
Pull To Operate
AUTOMATIC
CAUTION
DOOR
DD0586-010
ACTIVATE SWITCH TO OPERATE
DD0758-010 DD0758-010
50" ± 12"
AUTOMATIC
CAUTION
DOOR
DD0586-010
ACTIVATE SWITCH TO OPERATE
DD0758-010 DD0758-010
50" ± 12"
AUTOMATIC
CAUTION
DOOR
DD0586-010
PUSH TO OPERATE
DD0762-010
50" ± 12"
AUTOMATIC
CAUTION
DOOR
DD0586-010
PULL TO OPERATE
DD0762-020
50" ± 12"
Pivot side
Pivot side
7.2.2 Double doors Fig. 7.2.1 Activate Switch to Operate
Pivot side
Pivot side
Fig. 7.2.2 Opposite side, no device
AUTOMATIC
CAUTION
DOOR
DD0586-010
ACTIVATE SWITCH TO OPERATE
DD0758-010 DD0758-010
50" ± 12"
AUTOMATIC
CAUTION
DOOR
DD0586-010
ACTIVATE SWITCH TO OPERATE
DD0758-010 DD0758-010
AUTOMATIC
CAUTION
DOOR
DD0586-010
50" ± 12"
AUTOMATIC
CAUTION
DOOR
DD0586-010
Fig. 12.623 Push/Pull, Pull side
AUTOMATIC
CAUTION
DOOR
DD0586-010
PULL TO OPERATE
DD0762-020
50" ± 12"
AUTOMATIC
CAUTION
DOOR
DD0586-010
PULL TO OPERATE
DD0762-020
Fig. 12.2.4 Push/Pull, Push side
AUTOMATIC
CAUTION
DOOR
DD0586-010
PUSH TO OPERATE
DD0762-010
50" ± 12"
AUTOMATIC
CAUTION
DOOR
DD0586-010
PUSH TO OPERATE
DD0762-010
ED250
DL4614-090
08-2018
9
dormakaba ED250 IG Owner's Manual
Chapter 8
8 ED250 in-ground door threshold
8.1 Install door threshold
Fig. 8.1.1 Threshold example for ED250 in-ground
NOTICE
Door threshold installation and maintenance is owner's responsibility
Fig. 8.1.2 Door threshold installation example for ED250 in-ground
8.1.1 Door threshold seal at spindle. CAUTION
Spindle opening at threshold must be sealed with an O-ring or similar device.
8.1.2 Door threshold perimeter seal
CAUTION Threshold perimeter must be sealed with a silicone sealant.
8.1.3 Cleaning door threshold and floor area around threshold.
Fig. 8.1.3 Threshold installation end view example
CAUTION
Do not pressure wash door threshold or floor area adjacent to door threshold!
Spindle Door threshold
ED250 in-ground cement case
WARNING
Access to the ED250 in-ground system must only be done by dormakaba USA Inc. certified technicians!
10
ED250
DL4614-090
08-2018
dormakaba ED250 IG Owner's Manual
Blank page
This page left intentionally blank.
ED250
DL4614-090
01-2018
11
