xEffect - Industrial Switchgear Range Miniature Circuit Breakers FAZ6
Catalog

1.1
SG08911

Miniature Circuit Breakers
FAZ6 Miniature Circuit Breakers

Description
� High-quality miniature circuit breakers for industrial applications and residential applications
� Contact position indicator red - green � Guide for secure terminal connection � 3-position DIN rail clip, permits removal from
existing busbar system � Comprehensive range of accessories suitable
for subsequent installation � Rated currents up to 63 A � Tripping characteristics B, C, D

1

EATON CORPORATION CA003029EN

Miniature Circuit Breakers
FAZ6 Miniature Circuit Breakers

1.2

Rated current In (A)

Type Designation

Article No.

Units per package

SG11911 SG06911

Characteristic B
1-pole
1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63
1+N-poles
1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63

FAZ6-B1/1 FAZ6-B1,5/1 FAZ6-B1,6/1 FAZ6-B2/1 FAZ6-B2,5/1 FAZ6-B3/1 FAZ6-B3,5/1 FAZ6-B4/1 FAZ6-B5/1 FAZ6-B6/1 FAZ6-B8/1 FAZ6-B10/1 FAZ6-B12/1 FAZ6-B13/1 FAZ6-B15/1 FAZ6-B16/1 FAZ6-B20/1 FAZ6-B25/1 FAZ6-B32/1 FAZ6-B40/1 FAZ6-B50/1 FAZ6-B63/1
FAZ6-B1/1N FAZ6-B1,5/1N FAZ6-B1,6/1N FAZ6-B2/1N FAZ6-B2,5/1N FAZ6-B3/1N FAZ6-B3,5/1N FAZ6-B4/1N FAZ6-B5/1N FAZ6-B6/1N FAZ6-B8/1N FAZ6-B10/1N FAZ6-B12/1N FAZ6-B13/1N FAZ6-B15/1N FAZ6-B16/1N FAZ6-B20/1N FAZ6-B25/1N FAZ6-B32/1N FAZ6-B40/1N FAZ6-B50/1N FAZ6-B63/1N

177373 177374 177375 177376 177377 177378 177379 177380 177381 239001 177382 239006 177395 239011 177396 239016 239023 239024 239025 239026 239027 239028

12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120

177494 1/60 177495 1/60 177496 1/60 177497 1/60 177498 1/60 177499 1/60 177500 1/60 177501 1/60 177502 1/60 239044 1/60 177503 1/60 239045 1/60 177504 1/60 239046 1/60 177505 1/60 239047 1/60 239048 1/60 239049 1/60 239050 1/60 239051 1/60 239052 1/60 239053 1/60

2

EATON CORPORATION CA003029EN

1.3
SG08711
SG08811

Miniature Circuit Breakers
FAZ6 Miniature Circuit Breakers
Rated current In (A)

Type Designation

2-poles
1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63
3-poles
1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63

FAZ6-B1/2 FAZ6-B1,5/2 FAZ6-B1,6/2 FAZ6-B2/2 FAZ6-B2,5/2 FAZ6-B3/2 FAZ6-B3,5/2 FAZ6-B4/2 FAZ6-B5/2 FAZ6-B6/2 FAZ6-B8/2 FAZ6-B10/2 FAZ6-B12/2 FAZ6-B13/2 FAZ6-B15/2 FAZ6-B16/2 FAZ6-B20/2 FAZ6-B25/2 FAZ6-B32/2 FAZ6-B40/2 FAZ6-B50/2 FAZ6-B63/2
FAZ6-B1/3 FAZ6-B1,5/3 FAZ6-B1,6/3 FAZ6-B2/3 FAZ6-B2,5/3 FAZ6-B3/3 FAZ6-B3,5/3 FAZ6-B4/3 FAZ6-B5/3 FAZ6-B6/3 FAZ6-B8/3 FAZ6-B10/3 FAZ6-B12/3 FAZ6-B13/3 FAZ6-B15/3 FAZ6-B16/3 FAZ6-B20/3 FAZ6-B25/3 FAZ6-B32/3 FAZ6-B40/3 FAZ6-B50/3 FAZ6-B63/3

Article No.

Units per package

177540 1/60 177541 1/60 177542 1/60 177543 1/60 177544 1/60 177545 1/60 177546 1/60 177547 1/60 177548 1/60 239085 1/60 177549 1/60 239086 1/60 177550 1/60 239087 1/60 177551 1/60 239088 1/60 239089 1/60 239090 1/60 239091 1/60 239092 1/60 239093 1/60 239094 1/60
177577 1/40 177578 1/40 177579 1/40 177580 1/40 177581 1/40 177582 1/40 177583 1/40 177584 1/40 177585 1/40 239110 1/40 177586 1/40 239111 1/40 177587 1/40 239112 1/40 177588 1/40 239113 1/40 239114 1/40 239115 1/40 239116 1/40 239117 1/40 239118 1/40 239119 1/40

3

EATON CORPORATION CA003029EN

Miniature Circuit Breakers
FAZ6 Miniature Circuit Breakers

1.4

Rated current In (A)

Type Designation

Article No.

Units per package

SG08911 SG12011

3+N-poles
1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63
4-poles
1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63

FAZ6-B1/3N FAZ6-B1,5/3N FAZ6-B1,6/3N FAZ6-B2/3N FAZ6-B2,5/3N FAZ6-B3/3N FAZ6-B3,5/3N FAZ6-B4/3N FAZ6-B5/3N FAZ6-B6/3N FAZ6-B8/3N FAZ6-B10/3N FAZ6-B12/3N FAZ6-B13/3N FAZ6-B15/3N FAZ6-B16/3N FAZ6-B20/3N FAZ6-B25/3N FAZ6-B32/3N FAZ6-B40/3N FAZ6-B50/3N FAZ6-B63/3N
FAZ6-B1/4 FAZ6-B1,5/4 FAZ6-B1,6/4 FAZ6-B2/4 FAZ6-B2,5/4 FAZ6-B3/4 FAZ6-B3,5/4 FAZ6-B4/4 FAZ6-B5/4 FAZ6-B6/4 FAZ6-B8/4 FAZ6-B10/4 FAZ6-B12/4 FAZ6-B13/4 FAZ6-B15/4 FAZ6-B16/4 FAZ6-B20/4 FAZ6-B25/4 FAZ6-B32/4 FAZ6-B40/4 FAZ6-B50/4 FAZ6-B63/4

177446 1/30 177447 1/30 177448 1/30 177449 1/30 177450 1/30 177451 1/30 177452 1/30 177453 1/30 177454 1/30 239155 1/30 177455 1/30 239156 1/30 177456 1/30 239157 1/30 177457 1/30 239158 1/30 239159 1/30 239160 1/30 239161 1/30 239162 1/30 239163 1/30 239164 1/30
177420 1/30 177421 1/30 177422 1/30 177423 1/30 177424 1/30 177425 1/30 177426 1/30 177427 1/30 177428 1/30 239180 1/30 177429 1/30 239181 1/30 177430 1/30 239182 1/30 177431 1/30 239183 1/30 239184 1/30 239185 1/30 239186 1/30 239187 1/30 239188 1/30 239189 1/30

4

EATON CORPORATION CA003029EN

1.5
SG11911
SG06911

Miniature Circuit Breakers
FAZ6 Miniature Circuit Breakers
Rated current In (A)

Type Designation

Article No.

Units per package

Characteristic C
1-pole
0.16 0.25 0.5 0.75 1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63
1+N-poles
0.16 0.25 0.5 0.75 1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63

FAZ6-C0,16/1 FAZ6-C0,25/1 FAZ6-C0,5/1 FAZ6-C0,75/1 FAZ6-C1/1 FAZ6-C1,5/1 FAZ6-C1,6/1 FAZ6-C2/1 FAZ6-C2,5/1 FAZ6-C3/1 FAZ6-C3,5/1 FAZ6-C4/1 FAZ6-C5/1 FAZ6-C6/1 FAZ6-C8/1 FAZ6-C10/1 FAZ6-C12/1 FAZ6-C13/1 FAZ6-C15/1 FAZ6-C16/1 FAZ6-C20/1 FAZ6-C25/1 FAZ6-C32/1 FAZ6-C40/1 FAZ6-C50/1 FAZ6-C63/1

177397 177398 239029 177383 239030 177384 177385 239031 177386 239032 177387 239033 177388 239034 177389 239035 177390 239036 177391 239037 239038 239039 239040 239041 239042 239043

12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120 12/120

FAZ6-C0,16/1N FAZ6-C0,25/1N FAZ6-C0,5/1N FAZ6-C0,75/1N FAZ6-C1/1N FAZ6-C1,5/1N FAZ6-C1,6/1N FAZ6-C2/1N FAZ6-C2,5/1N FAZ6-C3/1N FAZ6-C3,5/1N FAZ6-C4/1N FAZ6-C5/1N FAZ6-C6/1N FAZ6-C8/1N FAZ6-C10/1N FAZ6-C12/1N FAZ6-C13/1N FAZ6-C15/1N FAZ6-C16/1N FAZ6-C20/1N FAZ6-C25/1N FAZ6-C32/1N FAZ6-C40/1N FAZ6-C50/1N FAZ6-C63/1N

177506 1/60 177507 1/60 239054 1/60 177508 1/60 239055 1/60 177509 1/60 177510 1/60 239056 1/60 177511 1/60 239057 1/60 177512 1/60 239058 1/60 177513 1/60 239059 1/60 177514 1/60 239060 1/60 177515 1/60 239061 1/60 177516 1/60 239066 1/60 239071 1/60 239076 1/60 239081 1/60 239082 1/60 239083 1/60 239084 1/60

5

EATON CORPORATION CA003029EN

SG08711 SG08811

Rated current In (A)
2-poles
0.16 0.25 0.5 0.75 1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63
3-poles
0.16 0.25 0.5 0.75 1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63

Miniature Circuit Breakers
FAZ6 Miniature Circuit Breakers

1.6

Type Designation

Article No.

Units per package

FAZ6-C0,16/2 FAZ6-C0,25/2 FAZ6-C0,5/2 FAZ6-C0,75/2 FAZ6-C1/2 FAZ6-C1,5/2 FAZ6-C1,6/2 FAZ6-C2/2 FAZ6-C2,5/2 FAZ6-C3/2 FAZ6-C3,5/2 FAZ6-C4/2 FAZ6-C5/2 FAZ6-C6/2 FAZ6-C8/2 FAZ6-C10/2 FAZ6-C12/2 FAZ6-C13/2 FAZ6-C15/2 FAZ6-C16/2 FAZ6-C20/2 FAZ6-C25/2 FAZ6-C32/2 FAZ6-C40/2 FAZ6-C50/2 FAZ6-C63/2

177552 1/60 177553 1/60 239095 1/60 177554 1/60 239096 1/60 177555 1/60 177556 1/60 239097 1/60 177557 1/60 239098 1/60 177558 1/60 239099 1/60 177559 1/60 239100 1/60 177560 1/60 239101 1/60 177561 1/60 239102 1/60 177562 1/60 239103 1/60 239104 1/60 239105 1/60 239106 1/60 239107 1/60 239108 1/60 239109 1/60

FAZ6-C0,16/3 FAZ6-C0,25/3 FAZ6-C0,5/3 FAZ6-C0,75/3 FAZ6-C1/3 FAZ6-C1,5/3 FAZ6-C1,6/3 FAZ6-C2/3 FAZ6-C2,5/3 FAZ6-C3/3 FAZ6-C3,5/3 FAZ6-C4/3 FAZ6-C5/3 FAZ6-C6/3 FAZ6-C8/3 FAZ6-C10/3 FAZ6-C12/3 FAZ6-C13/3 FAZ6-C15/3 FAZ6-C16/3 FAZ6-C20/3 FAZ6-C25/3 FAZ6-C32/3 FAZ6-C40/3 FAZ6-C50/3 FAZ6-C63/3

177589 1/40 177590 1/40 239120 1/40 177399 1/40 239121 1/40 177400 1/40 177401 1/40 239122 1/40 177402 1/40 239127 1/40 177403 1/40 239132 1/40 177404 1/40 239139 1/40 177405 1/40 239144 1/40 177406 1/40 239147 1/40 177407 1/40 239148 1/40 239149 1/40 239150 1/40 239151 1/40 239152 1/40 239153 1/40 239154 1/40

6

EATON CORPORATION CA003029EN

1.7
SG08911
SG12011

Miniature Circuit Breakers
FAZ6 Miniature Circuit Breakers
Rated current In (A)

Type Designation

Article No.

Units per package

3+N-poles
0.16 0.25 0.5 0.75 1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63
4-poles
0.16 0.25 0.5 0.75 1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63

FAZ6-C0,16/3N FAZ6-C0,25/3N FAZ6-C0,5/3N FAZ6-C0,75/3N FAZ6-C1/3N FAZ6-C1,5/3N FAZ6-C1,6/3N FAZ6-C2/3N FAZ6-C2,5/3N FAZ6-C3/3N FAZ6-C3,5/3N FAZ6-C4/3N FAZ6-C5/3N FAZ6-C6/3N FAZ6-C8/3N FAZ6-C10/3N FAZ6-C12/3N FAZ6-C13/3N FAZ6-C15/3N FAZ6-C16/3N FAZ6-C20/3N FAZ6-C25/3N FAZ6-C32/3N FAZ6-C40/3N FAZ6-C50/3N FAZ6-C63/3N

177458 1/30 177459 1/30 239165 1/30 177460 1/30 239166 1/30 177461 1/30 177462 1/30 239167 1/30 177463 1/30 239168 1/30 177464 1/30 239169 1/30 177465 1/30 239170 1/30 177466 1/30 239171 1/30 177467 1/30 239172 1/30 177468 1/30 239173 1/30 239174 1/30 239175 1/30 239176 1/30 239177 1/30 239178 1/30 239179 1/30

FAZ6-C0,16/4 FAZ6-C0,25/4 FAZ6-C0,5/4 FAZ6-C0,75/4 FAZ6-C1/4 FAZ6-C1,5/4 FAZ6-C1,6/4 FAZ6-C2/4 FAZ6-C2,5/4 FAZ6-C3/4 FAZ6-C3,5/4 FAZ6-C4/4 FAZ6-C5/4 FAZ6-C6/4 FAZ6-C8/4 FAZ6-C10/4 FAZ6-C12/4 FAZ6-C13/4 FAZ6-C15/4 FAZ6-C16/4 FAZ6-C20/4 FAZ6-C25/4 FAZ6-C32/4 FAZ6-C40/4 FAZ6-C50/4 FAZ6-C63/4

177432 1/30 177433 1/30 239190 1/30 177434 1/30 239191 1/30 177591 1/30 177592 1/30 239192 1/30 177593 1/30 239193 1/30 177594 1/30 239194 1/30 177595 1/30 239199 1/30 177596 1/30 239204 1/30 177597 1/30 239211 1/30 177598 1/30 239216 1/30 239219 1/30 239220 1/30 239221 1/30 239222 1/30 239223 1/30 239224 1/30

7

EATON CORPORATION CA003029EN

Miniature Circuit Breakers
FAZ6 Miniature Circuit Breakers

1.8

Rated current In (A)

Type Designation

Article No.

Units per package

SG11911 SG06911

Characteristic D
1-pole
0.5 1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63
1+N Pole
0.5 1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63

FAZ6-D0,5/1 FAZ6-D1/1 FAZ6-D1,5/1 FAZ6-D1,6/1 FAZ6-D2/1 FAZ6-D2,5/1 FAZ6-D3/1 FAZ6-D3,5/1 FAZ6-D4/1 FAZ6-D5/1 FAZ6-D6/1 FAZ6-D8/1 FAZ6-D10/1 FAZ6-D12/1 FAZ6-D13/1 FAZ6-D15/1 FAZ6-D16/1 FAZ6-D20/1 FAZ6-D25/1 FAZ6-D32/1 FAZ6-D40/1 FAZ6-D50/1 FAZ6-D63/1
FAZ6-D0,5/1N FAZ6-D1/1N FAZ6-D1,5/1N FAZ6-D1,6/1N FAZ6-D2/1N FAZ6-D2,5/1N FAZ6-D3/1N FAZ6-D3,5/1N FAZ6-D4/1N FAZ6-D5/1N FAZ6-D6/1N FAZ6-D8/1N FAZ6-D10/1N FAZ6-D12/1N FAZ6-D13/1N FAZ6-D15/1N FAZ6-D16/1N FAZ6-D20/1N FAZ6-D25/1N FAZ6-D32/1N FAZ6-D40/1N FAZ6-D50/1N FAZ6-D63/1N

177392 177393 177394 177483 177484 177485 177486 177487 177488 177489 168061 177490 168062 177491 177492 177493 168063 168064 168065 168066 168067 168068 168069

1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120 1/120

177517 1/60 177518 1/60 177519 1/60 177520 1/60 177521 1/60 177522 1/60 177523 1/60 177524 1/60 177525 1/60 177526 1/60 177527 1/60 177528 1/60 177529 1/60 177530 1/60 177531 1/60 177532 1/60 177533 1/60 177534 1/60 177535 1/60 177536 1/60 177537 1/60 177538 1/60 177539 1/60

8

EATON CORPORATION CA003029EN

1.9
SG08711
SG08811

Miniature Circuit Breakers
FAZ6 Miniature Circuit Breakers
Rated current In (A)

Type Designation

2-poles
0.5 1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63
3-poles
0.5 1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63

FAZ6-D0,5/2 FAZ6-D1/2 FAZ6-D1,5/2 FAZ6-D1,6/2 FAZ6-D2/2 FAZ6-D2,5/2 FAZ6-D3/2 FAZ6-D3,5/2 FAZ6-D4/2 FAZ6-D5/2 FAZ6-D6/2 FAZ6-D8/2 FAZ6-D10/2 FAZ6-D12/2 FAZ6-D13/2 FAZ6-D15/2 FAZ6-D16/2 FAZ6-D20/2 FAZ6-D25/2 FAZ6-D32/2 FAZ6-D40/2 FAZ6-D50/2 FAZ6-D63/2
FAZ6-D0,5/3 FAZ6-D1/3 FAZ6-D1,5/3 FAZ6-D1,6/3 FAZ6-D2/3 FAZ6-D2,5/3 FAZ6-D3/3 FAZ6-D3,5/3 FAZ6-D4/3 FAZ6-D5/3 FAZ6-D6/3 FAZ6-D8/3 FAZ6-D10/3 FAZ6-D12/3 FAZ6-D13/3 FAZ6-D15/3 FAZ6-D16/3 FAZ6-D20/3 FAZ6-D25/3 FAZ6-D32/3 FAZ6-D40/3 FAZ6-D50/3 FAZ6-D63/3

Article No.

Units per package

177563 1/60 177564 1/60 177565 1/60 177566 1/60 177567 1/60 177568 1/60 177569 1/60 177570 1/60 177571 1/60 177572 1/60 168070 1/60 177573 1/60 168071 1/60 177574 1/60 177575 1/60 177576 1/60 168072 1/60 168073 1/60 168074 1/60 168075 1/60 168076 1/60 168077 1/60 168078 1/60
177408 1/40 177409 1/40 177410 1/40 177435 1/40 177436 1/40 177437 1/40 177438 1/40 177439 1/40 177440 1/40 177441 1/40 168079 1/40 177442 1/40 168080 1/40 177443 1/40 177444 1/40 177445 1/40 168081 1/40 168082 1/40 168083 1/40 168084 1/40 168085 1/40 168086 1/40 168087 1/40

9

EATON CORPORATION CA003029EN

Miniature Circuit Breakers
FAZ6 - Technical Data

1.10

Rated current In (A)

Type Designation

Article No.

Units per package

SG08911 SG12011

3+N Pole
0.5 1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63
4-poles
0.5 1 1.5 1.6 2 2.5 3 3.5 4 5 6 8 10 12 13 15 16 20 25 32 40 50 63

FAZ6-D0,5/3N FAZ6-D1/3N FAZ6-D1,5/3N FAZ6-D1,6/3N FAZ6-D2/3N FAZ6-D2,5/3N FAZ6-D3/3N FAZ6-D3,5/3N FAZ6-D4/3N FAZ6-D5/3N FAZ6-D6/3N FAZ6-D8/3N FAZ6-D10/3N FAZ6-D12/3N FAZ6-D13/3N FAZ6-D15/3N FAZ6-D16/3N FAZ6-D20/3N FAZ6-D25/3N FAZ6-D32/3N FAZ6-D40/3N FAZ6-D50/3N FAZ6-D63/3N
FAZ6-D0,5/4 FAZ6-D1/4 FAZ6-D1,5/4 FAZ6-D1,6/4 FAZ6-D2/4 FAZ6-D2,5/4 FAZ6-D3/4 FAZ6-D3,5/4 FAZ6-D4/4 FAZ6-D5/4 FAZ6-D6/4 FAZ6-D8/4 FAZ6-D10/4 FAZ6-D12/4 FAZ6-D13/4 FAZ6-D15/4 FAZ6-D16/4 FAZ6-D20/4 FAZ6-D25/4 FAZ6-D32/4 FAZ6-D40/4 FAZ6-D50/4 FAZ6-D63/4

177469 1/30 177470 1/30 177471 1/30 177472 1/30 177473 1/30 177474 1/30 177475 1/30 177476 1/30 177477 1/30 177478 1/30 177479 1/30 177480 1/30 177481 1/30 177482 1/30 177411 1/30 177412 1/30 177413 1/30 177414 1/30 177415 1/30 177416 1/30 177417 1/30 177418 1/30 177419 1/30
177599 1/30 177600 1/30 177601 1/30 177602 1/30 177603 1/30 177604 1/30 177605 1/30 177606 1/30 177607 1/30 177608 1/30 168088 1/30 177609 1/30 168089 1/30 177610 1/30 177611 1/30 177612 1/30 168090 1/30 168091 1/30 168092 1/30 168093 1/30 168094 1/30 168095 1/30 168096 1/30

10

EATON CORPORATION CA003029EN

1.11

Miniature Circuit Breakers
FAZ6 - Technical Data

Miniature Circuit Breakers FAZ6
Accessories: Auxiliary switch for subsequent installation
Tripping signal contact for subsequent installation Shunt trip release Undervoltage release
Technical Data
Electrical Approvals Standards Short-circuit trip response Supplementary Protectors-UL/CSA Current range Maximum voltage ratings - UL/CSA
Single-pole, single-pole + neutral
Two-, three-, four-pole and three-pole + neutral Two poles in series Thermal tripping characteristics Single-pole Multi-pole Short-circuit ratings (at max. voltage) Single-pole Two-, three-pole Single-pole Two poles in series Miniature Circuit Breaker - IEC Current range Maximum voltage ratings - IEC 60947-2 Single-pole, single-pole + neutral
Two-, three-, four-pole and three-pole + neutral Maximum voltage ratings - IEC 60898
Single-pole, single-pole + neutral Two-, three-, four-pole and three-pole + neutral Thermal tripping characteristics - IEC 60947-2
Interrupt ratings (at max. voltage) IEC 60947-2 IEC 60898 Operational switching capacity Max. back-up fuse [gL/gG] Rated impulse withstand voltage - Uimp Rated insulation voltage - Ui
Environmental / General Selectivity class Endurance (operations) Shock (IEC 68-2-22) Operating temperature range Mechanical Device height Terminal protection Mounting width per pole Mounting Degree of protection Terminals top and bottom Supply connection Terminal capacity [mm2] Torque of terminals Thickness of busbar material Mounting position

ZP-IHK ZP-WHK ZP-NHK ZP-ASA/.. Z-USA Z-USD

286052 286053 248437 248438, 248439 258288, 248289, 248290 248292, 248291

B Characteristic

C Characteristic

UR (UL 1077), CSA (CSA 22.2 No. 235), CE, �VE, EAC

IEC/EN 60947-2, IEC/EN 60898-1

3�5 In

5�10 In

1�63 A

0,16�63 A

D Characteristic
10�20 In 0,5�40 A

277 V AC 48 V DC 480Y/277 V AC 96 V DC

277 V AC 48 V DC 480Y/277 V AC 96 V DC

277 V AC 48 V DC 480Y/277 V AC 96 V DC

< 1 hour @ 1.35 x In @ 40�C < 1 hour @ 1.45 x In @ 40�C

< 1 hour @ 1.35 x In @ 40�C < 1 hour @ 1.45 x In @ 40�C

< 1 hour @ 1.35 x In @ 40�C < 1 hour @ 1.45 x In @ 40�C

10 kA (5 kA for 40�63A device) 10 kA (5 kA for 40�63A device) 10 kA @ 48 V DC 10 kA @ 96 V DC

10 kA (5 kA for 40�63A device) 10 kA (5 kA for 40�63A device) 10 kA @ 48 V DC 10 kA @ 96 V DC

5 kA 5 kA 10 kA @ 48 V DC 10 kA @ 96 V DC

1�63 A

0.16�63 A

0.5�63 A

230 V AC 60 V DC 400 V AC

230 V AC 60 V DC 400 V AC

230 V AC 60 V DC 400 V AC

240 V AC 415 V AC

240 V AC 415 V AC

240 V AC 415 V AC

> 1 hour @ 1.05 x In @ 40�C < 1 hour @ 1.3 x In @ 40�C

> 1 hour @ 1.05 x In @ 40�C < 1 hour @ 1.3 x In @ 40�C

> 1 hour @ 1.05 x In @ 40�C < 1 hour @ 1.3 x In @ 40�C

10 kA 6 kA 7.5 kA 100 A 4000 V AC 440 V AC

10 kA 6 kA 7.5 kA 100 A 4000 V AC 440 V AC

10 kA (Type D50 and D63: 10 kA) 6 kA (Type D50 und D63: not testet) 7.5 kA (Type D50 und D63: 6 kA) 100 A 4000 V AC 440 V AC

3 >10000 (1 operation = ON/OFF) 15 g / 20 ms -40 up to +75�C

3 >10000 (1 operation = ON/OFF) 15 g / 20 ms -40 up to +75�C

3 >10000 (1 operation = ON/OFF) 15 g / 20 ms -40 up to +75�C

80 mm Finger and back-of-hand proof 17.5 mm IEC/EN 60715 top-hat rail IP20 Twin-purpose terminals Line or load side 1 x 25 / 2 x 10 2.4 Nm 0.8 - 2 mm As required
11

80 mm Finger and back-of-hand proof 17.5 mm IEC/EN 60715 top-hat rail IP20 Twin-purpose terminals Line or load side 1 x 25 / 2 x 10 2.4 Nm 0.8 - 2 mm As required

80 mm Finger and back-of-hand proof 17.5 mm IEC/EN 60715 top-hat rail IP20 Twin-purpose terminals Line or load side 1 x 25 / 2 x 10 2.4 Nm 0.8 - 2 mm As required

EATON CORPORATION CA003029EN

Connection diagram

1-pole

1+N-poles (2MU) 2-poles

3-poles

Miniature Circuit Breakers
FAZ6 - Technical Data

1.12

3+N-poles

4-poles

Dimensions (mm) FAZ6
1-pole

1+N-poles, 2-poles

3-poles

3+N-poles, 4-poles

12

EATON CORPORATION CA003029EN

1.13

Miniature Circuit Breakers
FAZ6 - Technical Data

Tripping Characteristics FAZ6
Characteristics B, C and D - IEC 898, EN 60898

Tripping time [s]

7200 3600
1 1200
600 300
120 60 30
10 5
2 1 0.5
0.2 0.1 0.05
0.02 0.01 0.005
0.002 0.001 0.0005
1

2 3

Tripping Characteristic
acc. to IEC 898 / EN 60898

1 conventional non-tripping current Int = 1.13 In : t > 1 h

2 conventional tripping current It = 1.45 In : t < 1 h

3 2.55 In : t = 1- 60 s (In  32A) t = 1-120 s (I > 32A)
n

4 Type B: 3 In : t  0.1 s

5

5 In : t < 0.1 s

6 Type C: 5 In : t  0.1 s

7

10 In : t < 0.1 s

8

Type D: 10 I : t  0.1 s n

9

20 In : t < 0.1 s

3

5

7

9

B 4

6

C8

D

2

3

4 5 6 7 8 9 10

15 20

30 40 50

I / In

DG001083 Ver. 2 - 07/13

Characteristics B, C and D - IEC 947, EN 60947

Tripping time [s]

7200

3600

2

1

1200 600 300

120 60 30

10 5
2 1 0.5
0.2 0.1 0.05
0.02 0.01 0.005
0.002 0.001 0.0005
1

Tripping Characteristic
acc. to IEC 947 / EN 60947 ambient temperature = 40�C

1 conventional non-tripping current Int = 1.05 In : t > 1 h

2 conventional tripping current

I = 1.3 I : t < 1 h

t

n

3 Type B: 3 In : t  0.1 s

4

5 In : t < 0.1 s

5 Type C: 5 In : t  0.1 s

6

10 In : t < 0.1 s

7 Type D: 10 In : t  0.1 s

8

20 In : t < 0.1 s

4

6

8

B 3

5

C7

D

2

3

4 5 6 7 8 9 10

15 20

30 40 50

I / I n

DG001366 Ver. 1 - 07/13

13

EATON CORPORATION CA003029EN

Internal ResistanceFAZ6

Type B

At room temperature (single pole)

In [A]

R* [mW]

6

46.8

10

17.5

13

13.4

16

8.0

20

7.2

25

5.0

32

3.7

40

2.6

50

2.1

63

2.0

*50/60 Hz

Type B

At room temperature (single pole)

In [A]

R* [mW]

6

39.3

10

14.1

16

8.0

20

4.9

25

3.9

32

3.5

40

2.7

50

1.9

63

1.5

*50/60 Hz

Miniature Circuit Breakers
FAZ6 - Technical Data

1.14

Type C

At room temperature (single pole)

0.5

4680

1

1120

2

335

3

131

4

87.7

6

39.3

10

14.1

13

13.4

16

8.0

20

7.2

25

5.0

32

3.7

40

2.6

50

2.1

63

2.0

*50/60 Hz

14

EATON CORPORATION CA003029EN

1.15

Miniature Circuit Breakers
FAZ6 - Technical Data

Power Loss at In FAZ6

Type B
In [A] 6 10 13 16 20 25 32 40 50 63 * 50 Hz

1p P* [W] 1.8 1.9 2.5 2.2 3.2 3 3.7 34 4.5 5.2

1pN P* [W] 2 2.1 2.9 2.6 3.6 3.5 4.4 4.1 5.4 6.3

2p P* [W] 3.6 3.9 5.3 4.7 6.6 6.4 8.1 7.5 9.9 11.5

3p P* [W] 5.5 5.9 7.8 6.9 9.8 9,4 12.1 11.2 14.9 17.2

3pN P* [W] 5.6 6.1 8.1 7.2 10.1 9.7 12.5 11.5 15.3 17.7

Type C
In [A] 0.5 1 2 3 4 6 10 13 16 20 25 32 40 50 63 * 50 Hz

1p P* [W] 1.2 1.6 1.4 1.2 1.4 1.5 1.5 2.5 2.2 3.2 3 3.7 3.4 4.5 5.2

1pN P* [W] 1.3 1.7 1.5 1.3 1.6 1.6 1.7 2.9 2.6 3.6 3.5 4.4 4.1 5.4 6.3

2p P* [W] 2.4 3.1 2.8 2.4 2.9 2.9 3 5.3 4.7 6.6 6.4 8.1 7.5 9.9 11.5

3p P* [W] 3.5 4.7 4.1 3.6 4.4 4.4 4.6 7.8 6.9 9.8 9.4 12.1 11.2 14.9 17.2

3pN P* [W] 3.7 4.8 4.3 3.7 4.5 4.6 4.7 8.1 7.2 10.1 9.7 12.5 11.5 15.3 17.7

Type D
In [A] 6 10 16 20 25 32 40 50 63 * 50 Hz

1p P* [W] 1.5 1.5 2.2 2 2.5 3.4 3.2 4.9 6.8

1pN P* [W] 1.6 1.7 2.6 2.2 2.9 4 3.8 7.5 11.9

2p P* [W] 2.9 3 4.7 4.1 5.2 7.4 7 9.8 13.6

3p P* [W] 4.4 4.6 6.9 6.8 7.7 11.1 10.4 14.6 20.4

3pN P* [W] 4.6 4.7 7.2 6.2 7.9 11.4 10.7 17.3 25.5

15

EATON CORPORATION CA003029EN

Miniature Circuit Breakers
FAZ6 - Technical Data

1.16

Influence of Ambient Temperature on Load Carrying Capacity (temperature derating) at In IEC 898, FAZ6

Values in the table display the nominal current In in ampere depending on the ambient temperature

In [A] 0.5 1 2 3 4 6 10 13 16 20 25 32 40 50 63

Ambient Temperature T [�C] -40 -30 -20 -10 0

10 20 30

0.64 0.62 0.6

1.3 1.2 1.2

2.6 2.5 2.4

3.8 3.7 3.6

5.1 5

4.8

7.7 7.5 7.2

10 12 12

17 16 16

20 20 19

26 25 24

32 31 30

41 40 38

51 50 48

64 62 60

81 78 76

0.58 0.56 0.54 0.52 0.5

1.2 1.1 1.1 1

1

2.3 2.2 2.2 2.1 2

3.5 3.4 3.3 3.1 3

4.7 4.5 4.3 4.2 4

7

6.7 6.5 6.3 6

12 11 11 10 10

15 15 14 14 13

19 18 17 17 16

23 22 22 21 20

29 28 27 26 25

37 36 35 33 32

47 45 43 42 40

58 56 54 52 50

73 71 68 66 63

35 40 45 50 55 60 65 70 75

0.49 0.48 0.47 0.46 0.45 0.44 0.43 0.42 0.41

0.99 0.97 0.95 0.93 0.9 0.89 0.87 0.85 0.83

2

1.9 1.9 1.9 1.8 1.8 1.7 1.7 1.7

3

2.9 2.8 2.8 2.7 2.7 2.6 2.5 2.5

3.9 3.9 3.8 3.7 3.6 3.5 3.5 3.4 3.3

5.9 5.8 5.7 5.6 5.4 5.3 5.2 5.1 5

9.9 9.7 9.5 9.3 9

8.9 8.7 8.5 8.3

13 13 12 12 12 12 11 11 11

16 15 15 15 14 14 14 14 13

20 19 19 19 18 18 17 17 17

25 24 24 23 23 22 22 21 21

32 31 30 30 29 28 28 27 26

39 39 38 37 36 35 35 34 33

49 48 47 46 45 44 43 42 41

62 61 60 58 57 56 55 53 52

Influence of Ambient Temperature on Load Carrying Capacity (temperature derating) at In IEC 947, FAZ6

Values in the table display the nominal current In in ampere depending on the ambient temperature

In [A] 0.5 1 2 3 4 6 10 13 16 20 25 32 40 50 63

Ambient Temperature T [�C] -40 -30 -20 -10 0

10 20 30 35 40

0.68 0.66 0.64 0.62 0.6

1.4 1.3 1.3 1.2 1.2

2.8 2.7 2.6 2.5 2.4

4

3.9 3.8 3.7 3.6

5.4 5.3 5.1 5

4.8

8.2 8

7.7 7.5 7.2

12 11 10 12 12

18 17 17 16 16

21 21 20 20 19

28 27 26 25 24

34 33 32 31 30

44 42 41 40 38

54 53 51 50 48

68 66 64 62 60

86 83 81 78 76

0.58 0.56 0.54 0.52 0.5

1.2 1.1 1.1 1

1

2.3 2.2 2.2 2.1 2

3.5 3.4 3.3 3.1 3

4.7 4.5 4.3 4.2 4

7

6.7 6.5 6.3 6

12 11 11 10 10

15 15 14 14 13

19 18 17 17 16

23 22 22 21 20

29 28 27 26 25

37 36 35 33 32

47 45 43 42 40

58 56 54 52 50

73 71 68 66 63

45 50 55 60 65 70 75

0.49 0.48 0.47 0.46 0.45 0.44 0.43

0.99 0.97 0.95 0.93 0.9 0.89 0.87

2

1.9 1.9 1.9 1.8 1.8 1.7

3

2.9 2.8 2.8 2.7 2.7 2.6

3.9 3.9 3.8 3.7 3.6 3.5 3.5

5.9 5.8 5.7 5.6 5.4 5.3 5.2

9.9 9.7 9.5 9.3 9

8.9 8.7

13 13 12 12 12 12 11

16 15 15 15 14 14 14

20 19 19 19 18 18 17

25 24 24 23 23 22 22

32 31 30 30 29 28 28

39 39 38 37 36 35 35

49 48 47 46 45 44 43

62 61 60 58 57 56 55

16

EATON CORPORATION CA003029EN

500 1000 1500 2000 3000 4000 5000 6000 7000 8000 9000 10000
DG001368 Ver. 1 - 07/13

1.17

Miniature Circuit Breakers
FAZ6 - Technical Data

Let-t Lhret-oTuhrgohugehnEenrerggyyI[2At [2sA]2 sec]
500 1000 1500 2000 3000 4000 5000 6000 7000 8000 9000 10000
DG001369 Ver. 1 - 07/13

Let-thLreto-uThgrohugehneErnegrygyI [2tA [2As]2 sec]
500 1000 1500 2000 3000 4000 5000 6000 7000 8000 9000 10000
DG001367 Ver. 1 - 07/13

Maximum Let-Through Energy IEC 947, FAZ6
Let-through energy FAZ6, Characteristic B, 1-pole
230 V / 400 V

80000 70000 60000 50000 40000
30000
20000
15000
10000 9000 8000 7000 6000 5000 4000
3000
2000
1500
1000 900 800 700 600 500 400
300

BB6530 B40 B32 B25 B20 B16 B13 B10
B6

ProspPreocstpievcetivSe hSohorrtt CCiirrccuuit iCtuCrruenrtre[An] t [A]

Let-through energy FAZ6, Characteristic D, 1-pole
230 V / 400 V

80000

DD6530

70000 60000

DD3420

50000 40000

DDD221056

30000

D10

20000 D6
15000

10000 9000 8000 7000 6000 5000
4000
3000

2000 1500

1000 900 800 700 600 500
400
300

ProsPproescpteivcteiveSShhoorrttCCiricrucituCiturCreunrt r[Ae]nt [A]

Let-t Lhret-oTuhrgohugehnEenrerggyyI[2At [2sA]2 sec]

Let-through energy FAZ6, Characteristic C, 1-pole
230 V / 400 V
80000 70000 60000 50000 40000
30000
20000
15000
10000 9000 8000 7000 6000 5000 4000
3000
2000
1500
1000 900 800 700 600 500 400
300

C63 C50 C40 C32 CC2205 C16 C13 C10 C6 C4 C3
C2
C1 C0.5

ProsPproescpteicvtieveSShhoorrttCCircirucituCiutrrCeuntr[rAe]nt [A]

17

EATON CORPORATION CA003029EN

Maximum Let-Through Current IEC 947, FAZ6

Let-through current FAZ6, Characteristic B, 1-pole

10000 9000 8000 7000 6000
5000
4000

230 V / 400 V

3000

BBBB64213056

BBB532020 B13

B10

B6

2000 1500

1000

LeLt-ett-hTrhroouugghhCcururrernte [ntA][A]

500

Miniature Circuit Breakers
FAZ6 - Technical Data

1.18

Let-through current FAZ6, Characteristic C, 1-pole

10000 9000 8000 7000 6000
5000
4000

230 V / 400 V

3000

2000 1500

1000

C63 C50

C40 C25 C16

C32 C20 C13

C10

C6 C4 C3

C2

LeLte-tt-ThhrroougghhCcurrurernte[nAt] [A]

500 C1 C0.5

500 1000 1500 2000 3000 4000 5000 6000 7000 8000 9000 10000
DG001371 Ver. 1 - 07/13

500 1000 1500 2000 3000 4000 5000 6000 7000 8000 9000 10000
DG001370 Ver. 1 - 07/13

ProspPreocstpievcetivSe hSohorrtt CCiirrccuuit iCtuCrruenrtre[An] t [A]

Let-through current FAZ6, Characteristic D, 1-pole

10000 9000 8000 7000 6000
5000
4000

230 V / 400 V

3000

2000 1500

1000

DD4603 D25

DD3520 D20

D16

D10

D6

LeLte-tt-ThhrroouugghhCcurrurernte[nAt] [A]

500

ProspPreocsptievcetivSe hShoorrtt CCiirrccuuit iCtuCrruenrtr[eAn] t [A]

500 1000 1500 2000 3000 4000 5000 6000 7000 8000 9000 10000
DG001372 Ver. 1 - 07/13

ProsPproescpteivcteiveSShhoorrttCCiricrucituCiturCreunrt r[Ae]nt [A]

18

EATON CORPORATION CA003029EN

1.19

Miniature Circuit Breakers
FAZ6 - Technical Data

Influence of the Line Frequency FAZ
On the Instantaneous Tripping Current IMA
Line Frequency f [Hz] 162/3 50 60 100 200 300 400 IMA(f)/IMA(50 Hz) [%] 91 100 101 106 115 134 141

Load Capacity of Series Connected Miniature Circuit Breakers

Number of devices (n) 1-pole

Load capacity factor KN

19

EATON CORPORATION CA003029EN

Eaton's electrical business is a global leader with deep regional application expertise in power distribution and circuit protection; power quality, backup power and energy storage; control and automation; life safety and security; structural solutions; and harsh and hazardous environment solutions. Through end-to-end services, channel and an integrated digital platform & insights Eaton is powering what matters across industries and around the world, helping customers solve their most critical electrical power management challenges. For more information, visit Eaton.com.
To contact us please visit https://www.eaton.com/us/en-us/ support/international-support-contacts.html For technical questions please contact your local Eaton team.

9 010238 196759

Eaton Industries (Austria) GmbH Scheydgasse 42 1210 Vienna Austria

Eaton EMEA Headquarters Route de la Longeraie 7 1110 Morges, Switzerland
� 2021 Eaton All Rights Reserved Printed in Austria Publication No. CA003029EN Article number 304259-MK April 2021 Grafics: SRA, Schrems

Changes to the products, to the information contained in this document, and to prices are reserved; as are errors and omissions. Only order confirmations and technical documentation by Eaton is binding. Photos and pictures also do not warrant a specific layout or functionality. Their use in whatever form is subject to prior approval by Eaton. The same applies to trademarks (especially Eaton, Moeller, and Cutler-Hammer). The Terms and Conditions of Eaton apply, as referenced on Eaton Internet pages and Eaton order confirmations.

Eaton is a registered trademark.

Follow us on social media to get the latest product and support information.

All other trademarks are property of their respective owners.
