OSCILLOSCOPE SELECTION GUIDE OSCILLOSCOPE SELECTION GUIDE OSCILLOSCOPE SELECTOR GUIDE Tektronix offers oscilloscopes for many different applications and uses. To help you choose the right scope for your needs, the most common criteria for selecting a scope are listed below, along with helpful tips for determining your requirements. 1 Bandwidth All oscilloscopes have a low-pass frequency response that rolls off at higher frequencies. Oscilloscope bandwidth is specified as being the frequency at which a sinusoidal input signal is attenuated to 70.7% of the signal's true amplitude � the -3 dB point. Your oscilloscope must have sufficient bandwidth to capture all relevant frequency components of your signal. If you regularly work with digital signals, it may be easier to consider bandwidth by comparing signal and oscilloscope rise time specifications. Use an oscilloscope with a rise time specification five times faster than your signal rise time to keep error below 2%. Rule: Bandwidth > 5 x Highest Signal Frequency 2 Sample Rate The faster an oscilloscope samples, the greater the resolution and detail of the displayed waveform, and the less likely that critical information or events will be lost. Tektronix recommends at least 5X oversampling to ensure signal details are captured and to avoid aliasing. Rule: Sample Rate > 5 x (Highest Frequency Component) 3 Record Length Record length is the number of samples the oscilloscope can digitize and store in a single acquisition. Since an oscilloscope can store only a limited number of samples, the waveform duration � or length of "time" captured � will be inversely proportional to the oscilloscope's sample rate. A longer record length enables a longer time window to be captured with high resolution. Rule: Captured Time = (Record Length) / (Sample Rate) 4 Digital Channels and Spectrum Analyzer Input Today's oscilloscopes offer more than just analog channels for system-level troubleshooting of complex designs. � If you need to analyze a parallel bus or multiple serial buses, the Tektronix MSO Series of mixed signal oscilloscopes and MDO Series of mixed domain oscilloscopes offer 16 digital channels and up to 4 analog channels for analyzing multiple signals at once. � If you are working with RF signals, the Tektronix MDO Series of mixed domain oscilloscopes offers a built-in spectrum analyzer for time-correlated analysis of analog, digital and RF signals. CONTENTS CHOOSING YOUR OSCILLOSCOPE MIXED SIGNAL AND MIXED DOMAIN OSCILLOSCOPES MSO/DPO2000B MDO3000 MDO4000C ADVANCED SIGNAL ANALYSIS OSCILLOSCOPES 5 Series MSO 6 Series MSO MSO/DPO5000B DPO7000C Series MSO/DPO70000 Series DPO70000SX Series BASIC OSCILLOSCOPES TBS1000 TBS1000B/TBS1000B-EDU TBS2000 LOW PROFILE OSCILLOSCOPES 5 Series MSO Low Profile SAMPLING OSCILLOSCOPES DSA8300 BATTERY POWERED OSCILLOSCOPES WITH ISOLATED CHANNELS THS3000 TPS2000B TDS SERIES OSCILLOSCOPES TDS2000C TDS3000C PROBES AND ACCESSORIES SERIAL SUPPORT SELECTOR BY MSO/DPO AND MDO PRODUCT SERIES 1-3 4 4 5 6 6 7 7 8 8 9 9 9 10 10 11 11 11 11 12-13 14-17 5 Features and Analysis Capability Tektronix oscilloscopes offer a range of features and analysis capabilities. When choosing your scope, you should review available triggers, waveform search tools, automated measurements, and analysis packages such as serial bus analysis, jitter and power analysis to ensure they meet your needs. TEK.COM/OSCILLOSCOPE | 1 OSCILLOSCOPE SELECTION GUIDE CHOOSING YOUR OSCILLOSCOPE Engineers, technicians and educators all have different workloads, different measurement needs, and different environments. To meet your needs Tektronix offers a wide range of oscilloscopes. This guide gives an overview of the various types of oscilloscopes currently available, along with high-level specifications that you can use for comparison. If you need a refresher on oscilloscope specifications, download the XYZs of Oscilloscopes Primer. TYPES OF OSCILLOSCOPES Mixed Domain Oscilloscopes � 100 MHz to 1 GHz The new standard for design and debug work. They offer the same capabilities as mixed signal oscilloscopes, but also offer a built-in spectrum analyzer, adding RF debugging to the analog/digital capabilities. Mixed Signal Oscilloscopes � 70 MHz to 8 GHz The engineer's choice for design and debug. They combine traditional oscilloscope input channels with digital input channels, long record length with powerful search features, and protocol support for serial buses. Advanced Signal Analysis Oscilloscopes � 350 MHz to 70 GHz The emphasis is on analysis. They provide high acquisition performance and run Windows, thus supporting a wide range of analysis software. MSO versions include digital channels. They can be equipped for serial data analysis, jitter analysis, standards testing, and serial decoding capability. Low Profile Oscilloscopes When performance, channel density and cost-per-channel are critical, these low-profile instruments are a great fit. They offer the same performance as bench instruments in a rack-friendly form factor. 2 |TEK.COM/OSCILLOSCOPE OSCILLOSCOPE SELECTION GUIDE VOTED 2017 INDUSTRY BEST LEARN MORE! This Changes Everything With a remarkably innovative pinch-swipe-zoom touchscreen user interface, the industry's largest high-definition display, and 4, 6, or 8 FlexChannelTM inputs that let you measure one analog or eight digital signals, the 5 Series MSO is ready for today's toughest challenges, and tomorrow's too. It sets a new standard for performance, analysis, and overall user experience. LEARN MORE Sampling Oscilloscopes � DC to 80 GHz For very high speed signal analysis, both electrical and optical, our sampling oscilloscopes support jitter and noise analysis with ultra-low jitter acquisitions. They also perform TDR and S-parameter measurements. Basic Oscilloscopes � 30 MHz to 200 MHz For basic signal visualization and more, these instruments are solid performers with ample supporting materials, and generous warranties. Special features for education. Battery Powered Oscilloscopes with Isolated Channels � 100 MHz to 200 MHz Safely and easily make 4-channel floating measurements, including 3-phase power measurements TDS Series Oscilloscopes � 50 MHz to 500 MHz These capable industry-favorites have a large installed base, and thousands of companies rely on them as part of their test and measurement fleets. They continue to be fully supported. TEK.COM/OSCILLOSCOPE | 3 OSCILLOSCOPE SELECTION GUIDE MIXED SIGNAL AND MIXED DOMAIN OSCILLOSCOPES MSO/DPO2000B Additional Resources Channels Bandwidth Spectrum Analyzer Frequency Range Sample Rate Max Record Length 2, 4 analog channels; 16 digital channels (MSO2000B) 70 MHz to 200 MHz -- 1 GS/s (analog); 1 GS/s (digital, only 1 pod); 500 MS/s (digital, both pods) 1 Mpoints Trigger Types Edge, Logic, Pulse Width, Runt, Setup and Hold, Rise/Fall Time, Video, I2C*, SPI*, CAN*, LIN*, RS-232/422/485/UART*, Parallel (MSO2000B) *Optional Optional Serial Bus Decode and Analysis DPO2AUTO: CAN and LIN DPO2COMP: RS-232/422/485/UART DPO2EMBD: I2C, SPI DPO2BND: Includes DPO2AUTO, DPO2COMP, DPO2EMBD Connectivity USB Host, USB Device, GPIB*, Optional DPO2CONN Module: LAN (10/100 Base-T Ethernet) and Video Out *Optional MDO3000 2, 4 analog channels; 16 digital channels (MDO3MSO option) 1 spectrum analyzer input 1 Arbitrary/Function Generator (MDO3AFG option) 100 MHz to 1 GHz Standard: 9 kHz to Analog Bandwidth Optional: 9 kHz to 3 GHz 2.5 GS/s to 5 GS/s (analog); 121.2 ps (8.25 GS/s) MagniVuTM (digital) 10 Mpoints Edge, Sequence, Logic, Pulse Width, Runt, Timeout, Setup and Hold, Rise/Fall Time, Video, Extended Video, I2C*, SPI*, CAN FD*, CAN*, LIN*, FlexRay*, RS-232/422/485/UART*, I2S/LJ/RJ/TDM*, MIL-STD-1553*, ARINC 429, USB 2.0*, Parallel (with MDO3MSO option) *Optional MDO3AERO: ARINC 429, MIL-STD-1553 MDO3AUDIO: I2S, LJ, RJ, TDM MDO3AUTO: CAN FD, CAN and LIN MDO3COMP: RS-232/422/485/UART MDO3EMBD: I2C, SPI MDO3FLEX: FlexRay MDO3USB: USB2.0 MDO3BND: Enables MDO3AERO, MDO3AUDIO, MDO3AUTO, MDO3COMP, MDO3EMBD, MDO3FLEX, MDO3LMT, MDO3PWR, MDO3USB USB Host (x2), USB Device, LAN (10/100 Base-T Ethernet, LXI Core 2011 Compliant), Video Out, GPIB* *Optional Waveform Math and Analysis 29 Automated Measurements, Waveform and Screen Cursors: Arithmetic Waveform Math, FFT 44 Automated Measurements, Waveform and Screen Cursors, Advanced Math, FFT, Measurement Statistics, Waveform Histograms Optional: MDO3PWR: Power Analysis MDO3LMT: Limit/mask test MDO3BND: Enables MDO3AERO, MDO3AUDIO, MDO3AUTO, MDO3COMP, MDO3EMBD, MDO3FLEX, MDO3LMT, MDO3PWR, MDO3USB Software Upgrade PC communications software: OpenChoice� Desktop Add serial bus triggering and decode PC Communications Software: OpenChoice� Desktop � Increase bandwidth � Add Arbitrary/Function generator � Add 16 digital channels � Increase spectrum analyzer maximum frequency to 3 GHz � Add measurements and analysis (power, limit/mask) � Add serial bus triggering and decode � Add security for password control of ports and firmware updates 4 |TEK.COM/OSCILLOSCOPE OSCILLOSCOPE SELECTION GUIDE MIXED SIGNAL AND MIXED DOMAIN OSCILLOSCOPES Additional Resources Channels Bandwidth Spectrum Analyzer Frequency Range Sample Rate Max Record Length Trigger Types Optional Serial Bus Decode and Analysis Connectivity MDO4000C 4 analog channels; 16 digital channels (with MDO4MSO option); 1 spectrum analyzer input (with SA3 or SA6 option); 1 Arbitrary/Function Generator (with MDO4AFG option) 200 MHz to 1 GHz Optional: 9 kHz - 3 GHz or 9 kHz - 6 GHz 2.5 GS/s to 5 GS/s (analog); 60.6 ps (16.5 GS/s) MagniVuTM (digital) 20 Mpoints RF Power Level**, Edge, Sequence, Logic, Pulse Width, Runt, Timeout, Setup and Hold, Rise/Fall Time, Video, Extended Video*, I2C*, SPI*, USB*, Ethernet*, CAN FD*, CAN*, LIN*, FlexRay*, RS-232/422/485/UART*, I2S/LJ/RJ/TDM*, MIL-STD-1553*, ARINC 429, Parallel* **With optional MDO4TRIG module, RF power level can be used as source for Pulse Width, Timeout, Runt, Logic, Sequence DPO4AERO: ARINC 429, MIL-STD-1553 DPO4AUDIO: I2S, LJ, RJ, TDM DPO4AUTO: CAN FD, CAN and LIN DPO4AUTOMAX: CAN FD, CAN, LIN and FlexRay DPO4COMP: RS-232/422/485/UART DPO4EMBD: I2C, SPI DPO4ENET: 10Base-T, 100Base-TX Ethernet DPO4USB: USB DPO4BND: Enables DPO4AERO, DPO4AUDIO, DPO4AUTO, DPO4COMP, DPO4EMBD, DPO4ENET, DPO4LMT, DPO4PWR, DPO4USB, DPO4VID USB Host (x4), USB Device, LAN (10/100/1000 Base-T Ethernet, LXI Core 2011 Compliant), Video Out, GPIB* *Optional Waveform Math and Analysis 44 Automated Measurements, Waveform and Screen Cursors,Spectrum Math, FFT, Advanced Math, Measurement Statistics, Waveform Histograms Optional: DPO4LMT: Limit and Mask Testing MDO4TRIG: Adv. RF Power Level Trigger DPO4PWR: Power Analysis DPO4VID: HDTV and Custom Triggering DPO4BND: Enables DPO4AERO, DPO4AUDIO, DPO4AUTO, DPO4COMP, DPO4EMBD, DPO4ENET, DPO4LMT, DPO4PWR, DPO4USB, DPO4VID Software Upgrade PC Communications Software: OpenChoice� Desktop Vector Signal Analysis Software: SignalVu-PC � Increase bandwidth � Add Arbitrary/Function Generator � Add 16 digital channels � Add or upgrade spectrum analyzer channel � Add measurements & analysis (power, limit/mask, video, RF trigger) � Add serial bus triggering and decode � Add security for password control of ports and firmware updates TEK.COM/OSCILLOSCOPE | 5 OSCILLOSCOPE SELECTION GUIDE ADVANCED SIGNAL ANALYSIS OSCILLOSCOPES 5 SERIES MSO Additional Resources Channels Bandwidth 4, 6, or 8 FlexChannel� inputs; 8 digital channels per FlexChannel input (optional); 1 Arbitrary/Function Generator (with 5-AFG option) 350 MHz to 2 GHz Sample Rate 6.25 GS/s (analog); 6.25 GS/s (digital) Max Record Length Up to 125 Mpoints 6 SERIES MSO 4 FlexChannel� inputs; 8 digital channels per FlexChannel input (optional); 1 Arbitrary/Function Generator (with 6-AFG option) 1 GHz to 8 GHz 25 GS/s / channel (analog); 25 GS/s / channel (digital) Up to 250 Mpoints Trigger Types Edge, Sequence, Logic, Pulse Width, Runt, Visual Trigger, Timeout, Window, Setup and Hold, Rise/Fall Time, I2C*, SPI*, USB*, Ethernet*, CAN*, CAN FD*, LIN*, FlexRay*, RS-232/422/485/ UART*, I2S/LJ/RJ/ TDM*, MIL-STD-1553*, ARINC 429*, SENT*, * SPMI*, Parallel Optional Edge, Sequence, Logic, Pulse Width, Runt, Visual Trigger, Timeout, Window, Setup and Hold, Rise/Fall Time, I2C*, SPI*, USB*, Ethernet*, CAN*, CAN FD*, LIN*, FlexRay*, RS-232/422/485/ UART*, I2S/LJ/RJ/ TDM*, MIL-STD-1553*, ARINC 429*, SENT*, * SPMI*, Parallel Optional Optional Serial Bus Decode and Analysis 5-SRAERO: MIL-STD-1553, ARINC 429 5-SRAUDIO: I2S, LJ, RJ, TDM 5-SRAUTO: CAN, CAN FD, LIN, FlexRay 5-SRAUTOSEN: SENT 5-SRCOMP: RS-232/422/485/UART 5-SREMBD: I2C, SPI 5-SRENET: Ethernet 5-SRPM: SPMI 5-SRUSB2: USB 2.0 Connectivity USB Host (x7), USB 3.0 Device, LAN (10/100/1000 Base-T Ethernet, 1.4 LXI Core 2011 Compliant), Display Port, DVI-D, Video Out 6-SRAERO: MIL-STD-1553, ARINC 429 6-SRAUDIO: I2S, LJ, RJ, TDM 6-SRAUTO: CAN, CAN FD, LIN, FlexRay 6-SRAUTOSEN: SENT 6-SRCOMP: RS-232/422/485/UART 6-SREMBD: I2C, SPI 6-SRENET: Ethernet 6-SRPM: SPMI 6-SRUSB2: USB 2.0 USB Host (x7), USB 3.0 Device, LAN (10/100/1000 Base-T Ethernet, 1.4 LXI Core 2011 Compliant), Display Port, DVI-D, Video Out Waveform Math and Analysis 36 Automated Measurements, Waveform and Screen Cursors, Arithmetic Waveform Math, FFT, Advanced Math, Measurement Statistics Optional: 5-CMAUTOEN: Automotive Ethernet Compliance; 5-CMUSB2: USB 2.0 Compliance; 5-DJA: Advanced Jitter and Eye Diagram Analysis; 5-PWR: Advanced Power Measurements. 36 Automated Measurements, Waveform and Screen Cursors, Arithmetic Waveform Math, FFT, Advanced Math, Measurement Statistics Optional: 6-CMAUTOEN: Automotive Ethernet Compliance; 6-CMUSB2: USB 2.0 Compliance; 6-DJA: Advanced Jitter and Eye Diagram Analysis; 6-PWR: Advanced Power Measurements Software Optional: TekScope AnywhereTM Upgrade � Add serial bus triggering and decode � Add serial bus compliance testing � Add digital channels with each TLP058 logic probe � Add extended record length, up to 125 Mpoints � Add advanced measurements and analysis (power, jitter) 6 |TEK.COM/OSCILLOSCOPE Optional: TekScope AnywhereTM � Add serial bus triggering and decode � Add serial bus compliance testing � Add digital channels with each TLP058 logic probe � Add extended record length, up to 250 Mpoints � Add advanced measurements and analysis (power, jitter) OSCILLOSCOPE SELECTION GUIDE ADVANCED SIGNAL ANALYSIS OSCILLOSCOPES MSO/DPO5000B Additional Resources DPO7000C Channels Bandwidth Sample Rate Max Record Length Trigger Types 4 analog channels; 16 digital channels (MSO5000B) 350 MHz to 2 GHz 5 GS/s to 10 GS/s (analog); 60.6 ps (16.5 GS/s) MagniVuTM (digital) Up to 250 Mpoints 4 analog channels 500 MHz to 3.5 GHz 10 GS/s to 40 GS/s Up to 500 Mpoints Edge, Sequence, Logic, Pulse Width, Glitch, Runt, Timeout, Transition, Setup and Hold, Rise/Fall Time, Video, I2C*, SPI*, USB (Low, Full, High)*, RS-232/422/485/UART*, USB*, Ethernet*, CAN*, LIN*, FlexRay*, MIL-STD-1553*, Parallel (MSO5000B), * Visual Trigger Optional PinpointTM Triggering, Edge, Glitch, Pulse Width, Runt, Time-out, Transition. Setup/Hold, Pattern, State, Window, Trigger Delay (by Time and by Event), I2C*, SPI*, USB (Low, Full)*, RS-232/422/485/UART*, I2C*, SPI*, USB*, Ethernet*, CAN*, LIN*, FlexRay*, RS-232/422/485/ UART*, MIL-STD-1553*, Visual Trigger *Optional Optional Serial Bus Decode and Analysis SR-AERO: MIL-STD-1553 SR-AUTO: CAN/LIN/FlexRay SR-COMP: RS-232/422/485/UART SR-DPHY: MIPI D-PHY SR-EMBD: I2C, SPI SR-ENET: 10/100Base-T Ethernet SR-USB: USB SR-AERO: MIL-STD-1553 SR-AUTO: CAN/LIN/FlexRay SR-COMP: RS-232/422/485/UART SR-DPHY: MIPI D-PHY SR-EMBD: I2C, SPI SR-ENET: 10/100Base-T Ethernet SR-PCIE: PCI Express SR-USB: USB Connectivity USB Host (x6), USB Device, LAN (10/100/1000 Base-T Ethernet, LXI Class C Compliant), Video Out, GPIB* *Optional USB Host (x5), LAN (10/100/1000 Base-T Ethernet, LXI Class C Compliant), GPIB, eSATA, DVI, VGA Waveform Math and Analysis 53 Automated Measurements, Waveform and Screen Cursors, Arithmetic and Advanced Waveform Math, FFT, Measurement Statistics, Waveform Histograms, Waveform Limit Testing Optional: BRR: BroadR-Reach Compliance Test; DDRA: DDR Memory Bus Analysis; DJA: DPOJET Advanced Jitter and Eye Diagram Analysis; ET3: Ethernet Compliance Test Solution; MTM: Mask Testing; PWR: Power Analysis; SignalVu Vector Signal Analysis; USB2: USB Compliance Test Solution; MOST: MOST 50/150 Compliance Test Solution; HSIC: HSIC Electrical Validation; USBPWR: USB Power Adapter/ EPS Compliance Automated Test Solution 53 Automated Measurements, Waveform and Screen Cursors, Arithmetic and Advanced Waveform Math, FFT, Measurement Statistics, Waveform Histograms, Waveform Limit Testing Optional: BRR: BroadR-Reach Compliance Test; DDRA: DDR Memory Bus Analysis; DJA: DPOJET Advanced Jitter and Eye Diagram Analysis; D-PHY: MIPI D-PHY Essentials; ET3: Ethernet Compliance Test Solution; MTM: Mask Testing; PWR: Power Analysis; SignalVu Vector Signal Analysis; USB2: USB Compliance Test Solution; MOST: MOST 50/150 Compliance Test Solution; HSIC: HSIC Electrical Validation; USBPWR: USB Power Adapter/ EPS Compliance Automated Test Solution Software Upgrade Optional: TekScope AnywhereTM � Add 16 digital channels � Add extended record length, up to 250 Mpoints � Add serial bus compliance testing � Add measurements and analysis (power, jitter, mask, RF) � Add serial bus triggering and decode Optional: TekScope AnywhereTM � Trade in older DPO7000 Series models for credit toward the newest DPO7000C version (50% credit of the old scope price) � Add extended record length, up to 500 Mpoints � Add serial bus compliance testing � Add measurements and analysis (power, jitter, mask, RF) � Add serial bus triggering and decode TEK.COM/OSCILLOSCOPE | 7 OSCILLOSCOPE SELECTION GUIDE ADVANCED SIGNAL ANALYSIS OSCILLOSCOPES MSO/DPO70000 Additional Resources Channels 4 analog channels; 16 digital channels (MSO70000) Bandwidth Sample Rate Max Record Length 4 GHz to 33 GHz Analog 25 GS/s to 100 GS/s (analog); 80 ps (12.5 GS/s) (digital) Up to 1 Gpoints DPO70000SX 2 or 4 analog channels 23 GHz to 70 GHz 50 GS/s to 200 GS/s Up to 1 Gpoints Trigger Types Optional Serial Bus Decode and Analysis Connectivity Waveform Math and Analysis Software Upgrade PinpointTM Triggering, Edge, Glitch, Pulse Width, Runt, Time-out, Transition, Setup/Hold, Pattern, State, Window, Trigger Delay (by Time and by Event), I2C*, SPI*, USB (Low, Full)*, RS-232/422/485/ UART*, Serial Pattern*, Visual Trigger* *Optional PinpointTM Triggering, Edge, Glitch, Pulse Width, Runt, Time-out, Transition, Setup/Hold, Pattern, State, Window, Trigger Delay (by Time and by Event), Visual Trigger* *Optional SR-AERO: MIL-STD-1553; SR-AUTO: CAN/LIN/FlexRay; SR-COMP: RS-232/422/485/UART; SR-DPHY: MIPI D-PHY; SR-EMBD: I2C, SPI; SR-ENET: 10/100Base-T Ethernet SR-PCIE: PCI Express; SR-USB: USB; SR-810B: 8b/10b; 10G-KR: 10GBASE-KR/KR4 SR-COMP: RS-232/422/485/UART; SR-EMBD: I2C, SPI; SR-ENET: 10/100Base-T Ethernet SR-PCIE: PCI Express; SR-USB: USB; SR-810B: 8b/10b USB Host (x5), LAN (10/100/1000 Base-T Ethernet, LXI Class C Compliant), GPIB, eSATA, DVI, VGA USB2.0 Host (4 on front)/3.0 Host (4 on rear), USB Device, LAN (10/100/1000 Base-T Ethernet, LXI Class C Compliant), DVI, VGA, DisplayPort (2) 53 Automated Measurements, Waveform and Screen Cursors, Arithmetic and Advanced Waveform Math, FFT, Measurement Statistics, Waveform Histograms Optional: BRR: BroadR-Reach Compliance Test; DDR Memory Bus Analysis; DPOJET Advanced Jitter and Eye Diagram Analysis; Ethernet Compliance; Waveform Limit Testing; Mask Testing; Power Analysis; USB2 and USB3 Compliance and Analysis; USB Power Adapter/ EPS Compliance Automated Test Solution; MOST 50/150 Compliance Test; SignalVu Vector Signal Analysis; HDMI Compliance Test; HSIC Electrical Validation; MIPI D-PHY and M-PHY Characterization and Analysis; SAS Testing; SFP+ Compliance and Debug; Serial Data Link Analysis; 10G-KR Compliance and Debug; PCIe Compliance and Debug; Thunderbolt Characterization, Compliance and Debug; UHS Measurements; PAM4 Transmitter Analysis Software; SignalCorrect Cable, Channel and Probe Compensation Software 53 Automated Measurements, Waveform and Screen Cursors, Arithmetic and Advanced Waveform Math, FFT, Measurement Statistics, Waveform Histograms Optional: DPOJET Noise, Jitter and Eye Analysis Tools; Frequency Counter-Timer; PAM4 Transmitter Analysis Software; Serial Data Link Analysis; 10G/40G/100G KR4/CR4 Transmitter Compliance; DDR Memory Bus Analysis; DisplayPort 1.2/1.4 Test Software; MIPI D-PHY Transmitter Debug and Compliance Test Solution; EDP Compliance Test Package; Ethernet Compliance Testing; Fiber Channel Essentials; HDMI 2.0 Analysis and Compliance; High Speed Serial Link Training Analysis; HDMI Compliance Testing; MIPI M-PHY Debug and Compliance Test; NBASE-T TekExpress Conformance and Debug Software; PCI Express Gen1/2/3/4 TekExpress Compliance/ Debug; Power Measurement and Analysis Software; SAS-3 Tx Compliance Test; SATA PHY Transmitter Test; SignalCorrect Cable, Channel, and Probe Compensation Software; SFP+ Compliance and Debug Solution; Embedded Serial Triggering and Analysis (I2C, SPI); USB 2.0/3.0/3.1 Automated Compliance Test; SignalVu Vector Signal Analysis Optional: TekScope AnywhereTM Optional: TekScope AnywhereTM � Increase bandwidth � Add 16 digital channels � Upgrade older platforms to the latest platforms � Add extended record length, up to 1 Gpoints � Add serial bus compliance testing � Add measurements and analysis (jitter, DDR, mask, RF) � Add serial bus triggering and decode � Increase bandwidth � Upgrade older platforms to the latest platforms � Add extended record length, up to 1 G points � Add measurements and analysis (jitter, mask, RF) 8 |TEK.COM/OSCILLOSCOPE BASIC OSCILLOSCOPES OSCILLOSCOPE SELECTION GUIDE Additional Resources Channels Bandwidth Sample Rate Max Record Length Trigger Types Optional Serial Bus Decode and Analysis Connectivity Waveform Math and Analysis Software Battery Operation TBS1000 TBS1000B/ TBS1000B-EDU TBS2000 4 60 MHz to 150 MHz 1 GS/s 2.5 k points Edge, Pulse (width), Video 2 30 MHz* to 200 MHz * 30 MHz TBS1032B available in North America and Europe 500 MS/s to 2 GS/s 2.5 k points Edge, Pulse (width), Video 2, 4 70 MHz, 100 MHz 1 GS/s 20 M points Edge, Pulse (width), Runt -- -- -- USB Host, USB Device, Optional: GPIB USB Host, USB Device, Optional: GPIB USB Host, Wi-Fi adapter support, 10/100 Base-T Ethernet port 16 Automated Measurements, Arithmetic Waveform Math, FFT, Waveform Limit Testing, Automated Datalogging 34 Automated Measurements, Arithmetic Waveform Math, FFT, Dual-Channel Frequency Counter, Waveform Limit Testing*, TrendPlotTM function*, Automated Datalogging* * Not available on EDU models PC Communications Software: OpenChoice� Desktop, Educator Classroom and Lab Resource CD PC Communications Software: OpenChoice� Desktop Software, PC Courseware Editor Tool, Product Documentation and Lab Resource CD -- -- 32 Automated Measurements, Arithmetic Waveform Math, FFT, Frequency Counter PC Communications Software: OpenChoice� Desktop, PC Courseware Editor -- Teaching Oscilloscopes TBS2000 and TBS1000B-EDU Oscilloscopes have unique features designed to meet the needs of schools and universities. They use an innovative courseware system that enables educators to build teaching materials into the oscilloscope. Along with a powerful PC Courseware Editor Tool and a courseware website, these oscilloscopes support a complete education ecosystem that makes it easier to teach engineering and easier to learn. LEARN MORE TEK.COM/OSCILLOSCOPE | 9 OSCILLOSCOPE SELECTION GUIDE LOW PROFILE AND SAMPLING OSCILLOSCOPES Additional Resources Channels Bandwidth Sample Rate Max Record Length Trigger Types Optional Serial Bus Decode and Analysis Connectivity Waveform Math and Analysis Software Upgrade 5 SERIES MSO LOW PROFILE DSA8300 8 FlexChannel� inputs; 8 digital channels per FlexChannel input (optional); 1 Arbitrary/Function Generator (5-AFG option); Aux trigger 1 GHz Six modules support up to 8 single-ended or 4 differential channels and/or 2 optical channels Up to 70+ GHz Electrical bandwidth and 80+ Optical bandwidth modules available with intrinsic jitter as low as <100 fs RMS 6.25 GS/s (analog); 6.25 GS/s (digital) 300 ks/s Maximum sample rate 125 Mpoints Edge, Sequence, Logic, Pulse Width, Runt, Visual Trigger, Timeout, Window, Setup and Hold, Rise/Fall Time, I2C*, SPI*, USB*, Ethernet*, CAN*, CAN FD*, LIN*, FlexRay*, RS-232/422/485/UART*, I2S/LJ/RJ/ TDM*, MIL-STD-1553*, ARINC 429*, SENT*, SPMI*, Parallel *Optional 5-SRAERO: MIL-STD-1553, ARINC 429 5-SRAUDIO: I2S, LJ, RJ, TDM 5-SRAUTO: CAN, CAN FD, LIN, FlexRay 5-SRAUTOSEN: SENT 5-SRCOMP: RS-232/422/485/UART 5-SREMBD: I2C, SPI 5-SRENET: Ethernet 5-SRPM: SPMI 5-SRUSB2: USB 2.0 50 to 16,000 per channel native record length; with up to 1M points when using available IConnect Signal Integrity Software, 10M samples (100k unit intervals, 100 samples per unit interval) when equipped with available 80SJNB Jitter, Noise and BER Analysis software Clock Input/Prescale Trigger, TDR clock (generated internally), Clock Recovery from Optical Sampling modules and Electrical Clock Recovery modules, and Phase Reference time base supports acquisitions Free Run mode and Trigger Direct Input for <100 fs RMS intrinsic jitter typical 80SJNB Jitter, Noise, BER, Serial Data Link and PAM4 Analysis Software; IConnect Signal Integrity Software; 100GBASE-SR4 Transmitter and Dispersion Eye Closure (TDEC) Automation Test Solution USB Host (x6), USB 3.0 Device, LAN (10/100/1000 Base-T Ethernet, 1.4 LXI Core 2011 Compliant), DisplayPort, DVI-D, Video Out 3 USB 2.0 Port(s) connector on the front panel, 4 USB 2.0 Ports on the rear panel; LAN PORT, RJ-45 connector, supports 10BASE-T, 100BASE-T, 1000BASE-T on rear panel; 1 Serial Port, DB-9 COM1, COM2 ports; 1 DVI IEEE488.2 connector on rear panel; 1 DVI connector, female on rear panel, DVI to VGA 15-pin D-sub connector adapter provided; PS2 Serial Ports Mouse and keyboard inputs; Audio Ports 1/8 in. microphone input and line output 36 Automated Measurements, Waveform and Screen Cursors, Arithmetic Waveform Math, FFT, Advanced Math, Measurement Statistics Optional: 5-DJA: Advanced Jitter and Eye Diagram Analysis; 5-PWR: Advanced Power Measurements Optional: TekScope AnywhereTM Over 120 automated measurements include RZ, NRZ, and pulse signal types, and the following measurement types, plus 8 math waveforms using the following math functions: Add, Subtract, Multiply, Divide, Average, Differentiate, Exponential, Integrate, Natural Log, Log, Magnitude, Min, Max, Square Root, and Filter. In addition, measurement values can be utilized as scalars in math waveform definitions; Mask support for many applications, standard masks are available as predefined, built-in masks; Automated Masked Margin based on Mask Hit Ratio as required by many standards. Windows� 7 Ultimate (32-bit) Operating System; IConnect Signal Integrity Software for frequency domain analysis, S-parameter measurements, and impedance characterization 80SJNB Jitter, Noise, BER, and Serial Link analysis including Cross-Talk aware TJ (BUJ and PAM4 Analysis); 80SJARB Jitter Analysis of Arbitrary Data with J2-J9 measurements, and support for pattern lengths to PRBS31; 100GBASE-SR4 (IEEE 802.3bm) optical transmitter characterization measurements, including TDEC, signaling rate, Average Launch Power, OMA, ER, Transmitter Eye Mask � Add serial bus triggering and decode � Add digital channels with each TLP058 logic probe � Add advanced measurements and analysis � Modular architecture lets you add channels or bandwidth � Add TDR, optical and electrical standards support � Add advanced analysis, compliance test, frequency domain analysis software � Add clock recovery trigger pickoff (CRTP) to select optical modules � Enhance system jitter floor performance to <100 fs RMS 10 |TEK.COM/OSCILLOSCOPE OSCILLOSCOPE SELECTION GUIDE BATTERY POWERED OSCILLOSCOPES WITH ISOLATED CHANNELS AND TDS SERIES OSCILLOSCOPES THS3000 Additional Resources Channels 4 (isolated) TPS2000B 2, 4 (isolated) TDS2000C 2, 4 TDS3000C 2, 4 Bandwidth 100 MHz to 200 MHz 100 MHz to 200 MHz 50 MHz to 200 MHz 100 MHz to 500 MHz Sample Rate Max Record Length 2.5 GS/s to 5 GS/s 10 k points Trigger Types Edge, Pulse (width), Event, Video, Non-interlaced Optional Serial Bus Decode and Analysis -- Connectivity USB Host, USB Device Waveform Math and Analysis Software Battery Operation 21 Automated Measurements, Arithmetic Waveform Math, FFT PC Communications Software: OpenChoice� Desktop One THSBAT Battery Pack Included Standard 1 GS/s to 2 GS/s 2.5 k points Edge, Pulse (width), Video 500 MS/s to 2 GS/s 2.5 k points Edge, Pulse (width), Video 1.25 GS/s to 5 GS/s 10 k points Edge, Logic (Pattern, State), Pulse (Glitch, Width, Runt, Slew Rate), Video, Optional: Extended Video, Comm -- -- -- RS-232 (includes RS-232-to-USB Host Serial Cable), Centronics, CompactFlash USB Host, USB Device, Optional: GPIB USB Host, LAN (10Base-T Ethernet) Optional: TDS3GV Module: GPIB, RS-232, and Video Out 11 Automated Measurements, Arithmetic Waveform Math, FFT Optional: TPS2PWR1: Power Measurement and Analysis 16 Automated Measurements, Arithmetic Waveform Math, FFT, Waveform Limit Testing, Automated Datalogging 25 Automated Measurements, Arithmetic Waveform Math, FFT Optional: TDS3LIM: Limit Testing, TDS3TMT: Telecom Mask Testing, TDS3VID: HDTV & Custom Video Triggering PC Communications Software: OpenChoice� Desktop PC Communications Software: PC Communications Software: OpenChoice� Desktop OpenChoice� Desktop One TPSBAT Battery Pack Included Standard -- Requires Optional TDS3BATC Battery Pack TEK.COM/OSCILLOSCOPE | 11 OSCILLOSCOPE SELECTION GUIDE INTERACTIVE PROBE SELECTOR TOOL Need help finding the right probe for your application? The online Tektronix Probe Selector Tool will guide you through a few easy questions to match your need to the right probe. Visit us anytime, anywhere at: tektronix.com/probes. LEARN MORE ON THE GO! IsoVu� Isolated Probes See What's Been Hidden - Until Now Common mode interference often causes engineers to design, debug, evaluate, and optimize "blind." Revolutionary IsoVuTM technology uses optical communications and power-over-fiber for complete galvanic isolation. When combined with an oscilloscope equipped with the TekVPI interface, it is the first, and only, measurement system capable of accurately resolving high bandwidth differential signals in the presence of large common mode voltage. LEARN MORE 12 |TEK.COM/OSCILLOSCOPE OSCILLOSCOPE SELECTION GUIDE OSCILLOSCOPE PROBES AND ACCESSORIES Tektronix probes and accessories are perfectly matched to our industry-leading oscilloscopes. With over 100 choices available, you will find the probe you need. Need help finding the right probe for your application? The online Tektronix Probe Selector Tool will guide you through a few easy questions to match your need to the right probe. LEARN MORE ON THE GO! Isolated Probes � High-resolution measurements in the presence of common mode signals or noise � Up to 1 GHz bandwidth � Complete galvanic isolation � 1 Million to 1 (120 dB) of common mode rejection at 100 MHz http://www.tek.com/isolatedmeasurement-systems Low Voltage Differential Probes � Bandwidth up to 33 GHz � Easily measure differential signals � Low input capacitance: down to < 0.3 pF � High common mode rejection ratio (CMRR) � Wide range of probe tips for easier circuit access tek.com/differentialprobe-low-voltage High Voltage Differential Probes � Dynamic range to � 6000 V � Bandwidth up to 200 MHz � Most extensive set of probe accessories Current Probes � Easy to use and accurate AC/DC current measurements � DC up to 2 GHz � Amplitude measurements from 1 mA to 2,000 A � Split core and solid core construction tek.com/differentialprobe-high-voltage tek.com/current-probe Passive Probes � Best-in-class bandwidth up to 1 GHz � Best-in-class input capacitance as low as 3.9 pF, which minimizes probe loading effects � Dynamic range to 300 V CAT II � Rugged and reliable tek.com/passive-probe Low Voltage Single-ended Probes � Bandwidth up to 4 GHz � True signal reproduction and fidelity � Low input capacitance: down to < 0.8 pF � Small, compact probe heads for probing small geometry circuit elements tek.com/low-voltage-probesingle-ended High Voltage Single-ended Probes � Bandwidth up to 800 MHz � Dynamic range to 2500 V � Best-in-class probe loading with input capacitance as low as 1.8 pF tek.com/high-voltage-probesingle-ended Optical � Broad Wavelength Response: 500 to 950 nm or 1100 to 1700 nm � High-bandwidth DC up to 1.2 GHz � High Gain 1 V/mW � Low Noise <11 pW/Hz � DC to 33 GHz (DPO7OE1) Optical Probe DPO7OE2 DC to 59 GHz tek.com/optical-probe TEK.COM/OSCILLOSCOPE | 13 OSCILLOSCOPE SELECTION GUIDE SERIAL SUPPORT BY MSO/DPO PRODUCT SERIES AND REQUIRED OPTIONAL SOFTWARE Embedded Transportation Serial Standard I2C SPI RS-232/UART SPMI I2S CAN CAN FD LIN FlexRay MOST SENT Automotive Ethernet ARINC 429 MIL-STD-1553B USB 2.0 USB 3.0 MIPI D-PHY MIPI M-PHY PCIe DiiVA DisplayPort HDMI MHL SATA SAS3 Thunderbolt UHS-II MSO/DPO70000C/DX Series Decode & Search SR-EMBD SR-EMBD Serial Trigger SR-EMBD SR-EMBD Compliance Test - - SR-COMP SR-COMP - - - - - - - SR-AUTO SR-AUTO - - - - SR-AUTO SR-AUTO - SR-AUTO - SR-AUTO - MOST BRR - SR-AERO SR-AERO - SR-USB SR-USB (LS, FS) USB2 SR-USB SR-DPHY SR-PCIE - - USB3, TEKEXP Opt. USB-RMT, USB-TX - D-PHY, TEKEXP Opt. D-PHYTX - M-PHY, M-PHYTX, M-PHYRX - PCE3 - TEKEXP Opt. DIIVA - DP12, TEKEXP Opt. DP-SINK - HT3, HT3DS - MHD - SATA-RSG, SATA-TSG - SAS3, SAS-TSG, SAS-TSGW - TBT-TX - UHS2 DPO7000C Series Decode & Search SR-EMBD SR-EMBD Serial Trigger SR-EMBD SR-EMBD Compliance Test - - SR-COMP SR-COMP - - - - - - - SR-AUTO SR-AUTO - - - - SR-AUTO SR-AUTO - SR-AUTO - SR-AUTO - MOST BRR - SR-AERO SR-AERO - SR-USB SR-USB (LS, FS) USB2 - - - SR-DPHY - D-PHY TEKEXP Opt. D-PHYTX - - - SR-PCIE - - - - - - - - - - - - - - - - - - - - - - - - - - Computer / Peripherals Memor y DDR - - DDRA, DDR-LP4 - - DDRA Datacom Advanced Analysis Ethernet Comm. Mask Testing Fibre Channel 10GBASE-T KR SFP+ Custom Serial 8b/10b NRZ Serial PAM4 Serial Data Link Analysis Jitter & Eye Diagram Analysis SR-ENET - SR-CUST SR-810B - - ST6G - - ET3, XBGT2, NBASET MTH FC-16G 10G-KR SFP-TX, SFP-WDP PAM4 SDLA64 DJA (DJE incl. std), DJAN SR-ENET - SR-CUST SR-810B - - - ET3, XBGT2, NBASET - MTM - - - - - - - - - - ST1G - - - - - - DJA (DJE incl. std), DJAN 14 |TEK.COM/OSCILLOSCOPE OSCILLOSCOPE SELECTION GUIDE SERIAL SUPPORT BY MSO PRODUCT SERIES AND REQUIRED OPTIONAL SOFTWARE Embedded Transportation Serial Standard I2C SPI RS-232/UART SPMI I2S CAN CAN FD LIN FlexRay MOST SENT Automotive Ethernet ARINC 429 MIL-STD-1553B USB 2.0 USB 3.0 MIPI D-PHY MIPI M-PHY PCIe DiiVA DisplayPort HDMI MHL SATA SAS3 Thunderbolt UHS-II 5 Series MSO Decode & Search Serial Trigger Compliance Test 5-SREMBD 5-SREMBD - 5-SREMBD 5-SREMBD - 5-SRCOMP 5-SRCOMP - 5-SRPM 5-SRPM - 5-SRAUDIO 5-SRAUDIO - 5-SRAUTO 5-SRAUTO - 5-SRAUTO 5-SRAUTO - 5-SRAUTO 5-SRAUTO - 5-SRAUTO 5-SRAUTO - - - - 5-SRAUTOSEN 5-SRAUTOSEN - - - 5-CMAUTOEN 5-SRAERO 5-SRAERO - 5-SRAERO 5-SRAERO - 5-SRUSB2 5-SRUSB2 5-CMUSB2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Decode & Search 6-SREMBD 6-SREMBD 6-SRCOMP 6-SRPM 6-SRAUDIO 6-SRAUTO 6-SRAUTO 6-SRAUTO 6-SRAUTO 6-SRAUTOSEN 6-SRAERO 6-SRAERO 6-SRUSB2 - 6 Series MSO Serial Trigger Compliance Test 6-SREMBD - 6-SREMBD - 6-SRCOMP - 6-SRPM - 6-SRAUDIO - 6-SRAUTO - 6-SRAUTO - 6-SRAUTO - 6-SRAUTO - - - 6-SRAUTOSEN - - 6-CMAUTOEN 6-SRAERO - 6-SRAERO - 6-SRUSB2 6-CMUSB2 - - - - - - - - - - - - - - - - - - - - - - - - Computer / Peripherals Memor y DDR - - - - - - Datacom Advanced Analysis Ethernet Comm. Mask Testing Fibre Channel 10GBASE-T KR SFP+ Custom Serial 8b/10b NRZ Serial PAM4 Serial Data Link Analysis Jitter & Eye Diagram Analysis 5-SRENET - 5-SRENET - 5-DJA 6-SRENET - 6-SRENET - 6-DJA TEK.COM/OSCILLOSCOPE | 15 OSCILLOSCOPE SELECTION GUIDE SERIAL SUPPORT BY MDO PRODUCT SERIES AND REQUIRED OPTIONAL SOFTWARE Embedded Transportation Serial Standard I2C SPI RS-232/UART SPMI I2S CAN CAN FD LIN FlexRay MOST SENT Automotive Ethernet ARINC 429 MIL-STD-1553B USB 2.0 USB 3.0 MIPI D-PHY MIPI M-PHY PCIe DiiVA DisplayPort HDMI MHL SATA SAS3 Thunderbolt UHS-II DDR MDO4000C Series Decode & Search Serial Trigger Compliance Test DPO4EMBD DPO4EMBD - DPO4EMBD DPO4EMBD - DPO4COMP DPO4COMP - - - - DPO4AUDIO DPO4AUDIO - DPO4AUTO DPO4AUTO - DPO4AUTO DPO4AUTO - DPO4AUTO DPO4AUTO - DPO4AUTOMAX DPO4AUTOMAX - - - - - - - - - - DPO4AERO DPO4AERO - DPO4AERO DPO4AERO - DPO4USB DPO4USB - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - MDO3000 Series Decode & Search Serial Trigger Compliance Test MDO3EMBD MDO3EMBD - MDO3EMBD MDO3EMBD - MDO3COMP MDO3COMP - - - - MDO3AUDIO MDO3AUDIO - MDO3AUTO MDO3AUTO - MDO3AUTO MDO3AUTO - MDO3AUTO MDO3AUTO - MDO3FLEX MDO3FLEX - - - - - - - - - - - - - MDO3AERO MDO3AERO - MDO3USB MDO3USB - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Computer / Peripherals Memor y Datacom Ethernet DPO4ENET DPO4ENET - - Comm. Mask Testing - - DPO4LMT - Fibre Channel - - - - 10GBASE-T KR - - - - SFP+ - - - - Custom Serial - - - - 8b/10b - - - - NRZ Serial - - - - PAM4 - - - - Serial Data Link Analysis - - - - Jitter & Eye Diagram Analysis - - - - Advanced Analysis 16 |TEK.COM/OSCILLOSCOPE - - - MDO3LMT - - - - - - - - - - - - - - - - - - OSCILLOSCOPE SELECTION GUIDE SERIAL SUPPORT BY MSO/DPO PRODUCT SERIES AND REQUIRED OPTIONAL SOFTWARE Embedded Transportation Serial Standard I2C SPI RS-232/UART SPMI I2S CAN CAN FD LIN FlexRay MOST SENT Automotive Ethernet ARINC 429 MIL-STD-1553B USB 2.0 USB 3.0 MIPI D-PHY MIPI M-PHY PCIe DiiVA DisplayPort HDMI MHL SATA SAS3 Thunderbolt UHS-II DDR MSO/DPO2000B Series Decode & Search DPO2EMBD DPO2EMBD Serial Trigger DPO2EMBD DPO2EMBD Compliance Test - - DPO2COMP DPO2COMP - - - - - - - DPO2AUTO DPO2AUTO - - - - DPO2AUTO DPO2AUTO - - - - - - - - - - - - - MDO3AERO MDO3AERO - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - MSO/DPO5000B Series Decode & Search Serial Trigger Compliance Test SR-EMBD SR-EMBD - SR-EMBD SR-EMBD - SR-COMP SR-COMP - - - - - - - SR-AUTO SR-AUTO - SR-AUTO SR-AUTO - SR-AUTO SR-AUTO - MOST - - - BRR SR-AERO - - SR-AERO - SR-USB SR-USB USB2 - - - SR-DPHY - - - - - SR-PCIE - - - - - - - - - - - - - - - - - - - - - - - - - - - - DDRA Computer / Peripherals Datacom Memory Advanced Analysis Ethernet - - - Comm. Mask Testing - - - Fibre Channel - - - 10GBASE-T KR - - - SFP+ - - - Custom Serial - - - 8b/10b - - - NRZ Serial - - - PAM4 - - - Serial Data Link Analysis - - - Jitter & Eye Diagram Analysis - - - SR-ENET SR-CUST SR-810B - - SR-ENET - - ET3 MTM - DJA (DJE incl. std), DJAN TEK.COM/OSCILLOSCOPE | 17 Contact Information Australia* 1 800 709 465 Austria 00800 2255 4835 Balkans, Israel, South Africa and other ISE Countries +41 52 675 3777 Belgium* 00800 2255 4835 Brazil +55 (11) 3759 7627 Canada 1 800 833 9200 Central East Europe / Baltics +41 52 675 3777 Central Europe / Greece +41 52 675 3777 Denmark +45 80 88 1401 Finland +41 52 675 3777 France* 00800 2255 4835 Germany* 00800 2255 4835 Hong Kong 400 820 5835 India 000 800 650 1835 Indonesia 007 803 601 5249 Italy 00800 2255 4835 Japan 81 (3) 6714 3086 Luxembourg +41 52 675 3777 Malaysia 1 800 22 55835 Mexico, Central/South America and Caribbean 52 (55) 56 04 50 90 Middle East, Asia, and North Africa +41 52 675 3777 The Netherlands* 00800 2255 4835 New Zealand 0800 800 238 Norway 800 16098 People's Republic of China 400 820 5835 Philippines 1 800 1601 0077 Poland +41 52 675 3777 Portugal 80 08 12370 Republic of Korea +82 2 565 1455 Russia / CIS +7 (495) 6647564 Singapore 800 6011 473 South Africa +41 52 675 3777 Spain* 00800 2255 4835 Sweden* 00800 2255 4835 Switzerland* 00800 2255 4835 Taiwan 886 (2) 2656 6688 Thailand 1 800 011 931 United Kingdom / Ireland* 00800 2255 4835 USA 1 800 833 9200 Vietnam 12060128 * European toll-free number. If not accessible, call: +41 52 675 3777 Rev. 02.2018 Find more valuable resources at TEK.COM Copyright � Tektronix. All rights reserved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Specification and price change privileges reserved. TEKTRONIX and TEK are registered trademarks of Tektronix, Inc. All other trade names referenced are the service marks, trademarks or registered trademarks of their respective companies. 081618 46W-31080-4
