2021ParamountServiceCatalog

PARAMOUNT SERVICE CATALOG
Effective January 1, 2021

2021 CATALOG
This catalog contains replacement products offered by Paramount. Throughout the year we update the catalog links and e-mail you each time there is an update. Please hold on to the link to the Paramount catalog site so you'll always have the latest version with the most up to date information available for downloading and printing if you desire. We wish you the best of success in 2021! We look forward to serving you.

Paramount product color guide

White-01

Gray-02

Black-03

Blue-05

Light Blue-06

Not all colors available for all products.

Beige-07

Light Gray-08

Paramount Product Catalog Link
www.1paramount.com/servicecatalog
Prices subject to change without notice.

Cover photos courtesy of Design Ecology in Austin, TX.
1paramount.com · paramount@1paramount.com · 1.800.621.5886 ·

HOW TO ORDER FROM PARAMOUNT
To Order from Paramount
· Email your order to paramount@1paramount.com
Shipping Options
· All parcel orders will ship ground via UPS or FedEx at Paramount's discretion unless otherwise requested in writing on the customer's purchase order.
· Priority shipping is available for in-stock items when received by noon (Arizona local time). Additional charges apply. · Next day early AM by 8:30am. (Not available in all areas) · Next Day Air. · 2nd Day Air. · 3rd Day Air.
How to Return a Product to Paramount
· An RMA number MUST be obtained from Paramount before products will be considered for return.
· Please email paramount@1paramount.com or call Customer Service at (800)-621-5886 to get an RMA number for your return.
· All returns are subject to a 20% restock charge. · Freight on ALL returns must be prepaid. · A tracking number is required as proof of delivery.
Go to Link Below to View Warranty Certificate
https://www.1paramount.com/downloads/allinclusivewarranty.pdf
3

Invoice Terms And Conditions
ALL NEW ACCOUNTS WILL BE CREDIT CARD Upon receipt of a completed credit application, a credit search will be implemented. When the search is completed, the credit manager will determine whether to establish a credit account. The credit manager will inform the client in writing of the determination in each case. We do not offer C.O.D. as an option. CREDIT ACCOUNTS Terms are net 30 days from shipping date. A finance charge of 1¾% per month (21% annual percentage) will be assessed on past due balances, $1.50 minimum charge . Post-dated checks will be considered as payment on due date only. Pay by invoice. Shipments will be held on accounts of 10 days past due. Accounts past due 30 days will lose their credit privileges. RETURNED CHECKS A NSF check will automatically place an account on credit card. Customer will be required to replace the bad check with certified funds and will be assessed a NSF check charge. COLLECTION ACCOUNTS Accounts 90 days or NSF check accounts who have failed to make arrangements with the credit manager for payment of balances due will be referred to a collection agency or attorney in their area for implementation of any and all legal means available to effect repayment of the debt. SHIPMENT VARIANCES You have 48 hours to contact Customer Service on any missing or incorrect product. NO EXCEPTIONS! RETURN POLICY All of our merchandise goes through rigorous quality control inspections. In the event that a product is found to be defective, you must contact Paramount Pool & Spa Systems to obtain an RMA (Return Merchandise Authorization) number prior to returning goods. DO NOT ship item(s) to be replaced or credited without an RMA number or your return will not be processed. Freight on ALL returns must be prepaid. A tracking number is required as proof of delivery. C.O.D. shipments will be refused. All returns are subject to a 20% re-stock charge. Please contact Customer Service at 800-621-5886 to obtain an RMA number. Customer Service will need a fax number or e-mail address in order to provide the appropriate RMA documentation for all returns. Note: Subject to change without notice
Paramount Pool & Spa Systems | 1paramount.com | 1.800.621.5886 | Fax: 480-753-3397 | paramount@1paramount.com https://www.1paramount.com to ensure that you have the most up to date version. ©2020 Hayward Industries Inc.
4

CONTENTS - ALPHABETICAL
Click on product to go to page
Drains - Other . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
MDX2 Replacement Parts................................................................... 27
Debris Canisters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
DDC2 Canister Parts & Accessories............................................... 22 EDC Equipment Side Debris Canister............................................. 21
In-Floor Cleaning For Fiberglass Pools. . . . . . . . . . . . 12
In-Floor Cleaning & Circulation For Concrete Pools . . 6
Cyclean Nozzles.......................................................................................7 ECO POOL Nozzles...............................................................................8 EcoSystem Nozzles.................................................................................7 PCC 2000 Nozzles..................................................................................7 PV3 Nozzles...............................................................................................7 PVR Nozzles..............................................................................................7 VectorJet Nozzle & Aiming Tools...........................................................8
In-Floor Cleaning For Vinyl Pools. . . . . . . . . . . . . . . . . . 9
Vanish Nozzles, Parts, & Tools............................................................ 10 Vanquish Nozzles, Parts, & Tools......................................................... 11 Vantage Nozzles Parts, & Tools.......................................................... 12
Invoice Terms And Conditions. . . . . . . . . . . . . . . . . . . . 4
MDX-R3 Debris Removal Drain . . . . . . . . . . . . . . . . . . 24
MDX-R3 Parts & Accessories............................................................. 24
MVFuse In-Deck Magnetic Vacuum Release . . . . . . . 23
MVFuse In-Deck Unit Replacement Parts........................................ 23
Pool Valet Replacement Nozzles. . . . . . . . . . . . . . . . . 36
New Generation Pool Valet................................................................. 36 Pool Valet Nozzles................................................................................. 36 Pool Valet Parts, Tools & Accessories.............................................. 36 Pool Valet Retro..................................................................................... 37 RetroJets.................................................................................................. 38 RetroJet Tools/Parts.............................................................................. 38

SDX2 High Flow Safety Drain. . . . . . . . . . . . . . . . . . . 25
SDX2 Drain and Parts for Concrete Pools...................................... 25 SDX2 Drain and Parts for Vinyl and Fiberglass Pools.................. 26 SDX2 Retro............................................................................................. 26
Skimmers for Concrete, Vinyl, & Fiberglass Pools. . . 19
Paraskim Skimmer Replacement Parts............................................ 19
Spa Jets And Spa Air Solution For Concrete Spas. . 39
ParaJets - Spa Jets, Parts And Tool.................................................. 39
SwingJet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Tools, Test Plugs, Parts, & Accessories. . . . . . . . . . . . 13
Universal Parts & Accessories. . . . . . . . . . . . . . . . . . . 41
Water Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Air-Port Spa Air Solution...................................................................... 40 Parascope Telescoping Water Features.......................................... 40
Water Leveler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Paralevel Parts & Accessories............................................................ 35
Water Sanitizers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Clear O3 Ozone Generator................................................................ 33 Clear O3 Parts & Accessories........................................................... 33 HydraPure Parts & Accessories......................................................... 28 HydraPure UV & Ozone Water Sanitizer.......................................... 28 UltraClear UV & O3 Combo............................................................... 34 Ultra UV2 Parts & Accessories.......................................................... 29 Ultra UV2 Ultraviolet Water Sanitizer................................................ 29
Water Valves & Modules. . . . . . . . . . . . . . . . . . . . . . . . 15
Complete Water Valves........................................................................ 16 Water Valve Shells, Modules, Bases & Parts.................................. 17

Paramount Pool & Spa Systems | 1paramount.com | 1.800.621.5886 | Fax: 480-753-3397 | paramount@1paramount.com https://www.1paramount.com to ensure that you have the most up to date version. ©2020 Hayward Industries Inc.
5

In-Floor Cleaning & Circulation For Concrete Pools
The most advanced in-floor cleaning and circulation system designed to keep your pool clean, healthy, and always swim ready

Available in 6 colors for concrete pools

01 White

02 Gray

03 Black

06 Light Blue

07 Beige

08 Light Gray

PCC 2000 Nozzles

Rotating PCC2000 Nozzle

White 004-552-5020-01

Gray 004-552-5020-02

Black 004-552-5020-03

Lt. Blue 004-552-5020-06 Includes: Nozzle jet

Beige 004-552-5020-07

inserts

Lt. Gray 004-552-5020-08

Fixed PCC2000 Nozzle

White 004-552-5024-01 Gray 004-552-5024-02 Black 004-552-5024-03 Lt. Blue 004-552-5024-06 Beige 004-552-5024-07 Lt. Gray 004-552-5024-08

Includes: Nozzle jet inserts

Step Nozzle
White 004-552-5032-01 Gray 004-552-5032-02 Black 004-552-5032-03 Lt. Blue 004-552-5032-06
With twist lock caps
Beige 004-552-5032-07 Lt. Gray 004-552-5032-08

Step Nozzle Twist Lock Caps
White 005-552-5031-01 Gray 005-552-5031-02 Black 005-552-5031-03 Lt. Blue 005-552-5031-06 Beige 005-552-5031-07 Lt. Gray 005-552-5031-08

3 pieces - 1 ea. 1/4, 3/8, 5/8

Step Nozzle Snap On Caps
White 005-552-5032-01 Black 005-552-5032-03 Taupe 005-552-5032-04 Blue 005-552-5032-05 Lt. Blue 005-552-5032-06 Beige 005-552-5032-07 Lt. Gray 005-552-5032-08

3 pieces - 1 ea. 1/4, 3/8, 5/8

PV3 Nozzles
PV3 Nozzle with twist lock caps 1/4", 3/8", 5/8"
White 004-627-5060-01 Gray 004-627-5060-02 Black 004-627-5060-03 Lt. Blue 004-627-5060-06 Beige 004-627-5060-07 Lt. Gray 004-627-5060-08
PV3 Twist Lock Caps 1/4", 3/8", 5/8"
White 005-627-5061-01 Gray 005-627-5061-02 Black 005-627-5061-03 Lt. Blue 005-627-5061-06 Beige 005-627-5061-07 Lt. Gray 005-627-5061-08
PV3 Snap On Caps 1/4", 3/8", 5/8"
Gray 005-627-5060-02 Black 005-627-5060-03 Blue 005-627-5060-05 Lt. Blue 005-627-5060-06 Beige 005-627-5060-07 Lt. Gray 005-627-5060-08

PVR Nozzles

PVR Nozzle with twist lock caps 1/4", 3/8", 5/8"
White 004-617-4000-01 Gray 004-617-4000-02 Black 004-617-4000-03 Lt. Blue 004-617-4000-06 Beige 004-617-4000-07 Lt. Gray 004-617-4000-08

PVR Twist Lock Caps 1/4", 3/8", 5/8"
White 005-617-1000-01 Gray 005-617-1000-02 Black 005-617-1000-03 Lt. Blue 005-617-1000-06 Beige 005-617-1000-07 Lt. Gray 005-617-1000-08

Includes: Cap

Cyclean Nozzles
Cyclean Nozzle with twist lock caps 1/4", 3/8", 5/8"
White 004-652-5070-01 Gray 004-652-5070-02 Black 004-652-5070-03 Lt. Blue 004-652-5070-06 Beige 004-652-5070-07 Lt. Gray 004-652-5070-08
Cyclean Twist Lock Caps 1/4", 3/8", 5/8"
White 005-652-5080-01 Black 005-652-5080-03 Taupe 005-652-5080-04 Blue 005-652-5080-05 Lt. Blue 005-652-5080-06 Beige 005-652-5080-07 Lt. Gray 005-652-5080-08
Cyclean Snap On Caps 1/4", 3/8", 5/8"
Black 005-652-5060-03 Taupe 005-652-5060-04 Blue 005-652-5060-05 Lt. Blue 005-652-5060-06 While supplies last Beige 005-652-5060-07 Lt. Gray 005-652-5060-08
EcoSystem Nozzles
EcoSystem Nozzle with twist lock caps 1/4", 7/16"
White 004-527-5080-01 Gray 004-527-5080-02 Black 004-527-5080-03 Lt. Blue 004-527-5080-06 Beige 004-527-5080-07 Lt. Gray 004-527-5080-08
EcoSystem Twist Lock Caps 1/4", 7/16"
White 005-527-5090-01 Gray 005-527-5090-02 Black 005-527-5090-03 Lt. Blue 005-527-5090-06 Beige 005-527-5090-07 Lt. Gray 005-527-5090-08

VectorJet Nozzle & Aiming Tools
VectorJet Nozzle White 004-562-4500-01 Gray 004-562-4500-02 Black 004-562-4500-03 Lt. Blue 004-562-4500-06 Beige 004-562-4500-07 Lt. Gray 004-562-4500-08
*Requires 004-562-2700-00 Locking Tool 004-562-4600-00 Aiming Tool
Vector Jet nozzles are custom built per system layout. As such all Vector Jet nozzle sales are final. Please be sure of color choice before ordering. Please refer to the plan number when ordering. Allow up to 5 days for production before shipping.
VectorJet Locking Tool 004-562-2700-00
VectorJet Aiming Tool for Vector Body 004-562-4600-00

ECO POOL Nozzles
ECO POOL Nozzle Twist Lock Cap White 004-527-5080-01 Gray 004-527-5080-02 Black 004-527-5080-03 Lt. Blue 004-527-5080-06 Beige 004-527-5080-07 Lt. Gray 004-527-5080-08
ECO POOL Nozzle ¼" Twist Lock Cap White 005-527-5090-01 Gray 005-527-5090-02 Black 005-527-5090-03 Lt. Blue 005-527-5090-06 Beige 005-527-5090-07 Lt. Gray 005-527-5090-08
ECO POOL Nozzle Snap on Cap Lt. Blue 005-527-5080-06 Beige 005-527-5080-07 Lt. Gray 005-527-5080-08

VectorJet Aiming Tool For PCC2000 Body
004-552-4600-00

In-Floor Cleaning For Vinyl Pools
The most advanced in-floor cleaning and circulation system designed to keep your pool clean, healthy, and always swim ready

Available in 5 colors for vinyl pools

01 White

02 Gray

03 Black

Blue

Light Gray

Vanish Nozzles, Parts, & Tools

Vanish Rotating Nozzle White 004-577-9000-01 Gray 004-577-9000-02 Black 004-577-9000-03 Blue 004-577-9000-05 Lt. Gray 004-577-9000-08 Includes: Nozzle jet inserts
Vanish Body White 004-577-9001-01 Gray 004-577-9001-02 Black 004-577-9001-03 Blue 004-577-9001-05 Lt. Gray 004-577-9001-08
Vanish Trim Ring White 005-577-9004-01 Gray 005-577-9004-02 Black 005-577-9004-03 Blue 005-577-9004-05 Lt. Gray 005-577-9004-08
Vanish Clamp Ring Kit White 005-577-9005-01 Gray 005-577-9005-02 Black 005-577-9005-03 Blue 005-577-9005-05 Lt. Gray 005-577-9005-08
Vanish Install Tool 004-577-8650-00
Vanish Screw Kit 005-577-9003-00

Vanish Step Nozzle
White 004-577-5025-01 Gray 004-577-5025-02 Black 004-577-5025-03 Blue 004-577-5025-05 Lt. Gray 004-577-5025-08
Includes: Twist lock caps

PAR

EMS

OUNT M

POOL

AND

SPA

SYST

4,188U ,6.7S3. P 4A ,2T1E 2N ,0T88N4 O,S 39. 1,005

PAR

OUNT M

POOL

AND

SPA

SYST

4,188U ,6.7S3. P 4A ,2T1E 2N ,0T88N4 O,S 39. 1,005

EMS

PAR

OUNT M

POOL

AND

SPA

SYST

4,188U ,6.7S3. P 4A ,2T1E 2N ,0T88N4 O,S 39. 1,005

EMS

Vanish Step Nozzle Twist Lock Caps
White 005-577-4842-01 Gray 005-577-4842-02 Black 005-577-4842-03 Blue 005-577-4842-05 Lt. Gray 005-577-4842-08

PAR

EMS

OUNT M

POOL

AND

SPA

SYST

4,188U ,6.7S3. P 4A ,2T1E 2N ,0T88N4 O,S 39. 1,005

PAR

OUNT M

POOL

AND

SPA

SYST

4,188U ,6.7S3. P 4A ,2T1E 2N ,0T88N4 O,S 39. 1,005

MS E

PAR

OUNT M

POOL

AND

SPA

SYST

4,188U ,6.7S3. P 4A ,2T1E 2N ,0T88N4 O,S 39. 1,005

(3 Pieces - 1/4", 3/8", 5/8" - 1 Each)

Vanish Step Nozzle Trim Ring
White 005-577-6438-01 Gray 005-577-6438-02 Black 005-577-6438-03 Blue 005-577-6438-05 Lt. Gray 005-577-6438-08 5 pieces

Vanish Step Nozzle Single Head Kit Replacement Parts
005-577-6435-00
5 screws, 2 gaskets, 1 ring

Vanish Step Nozzle Single Head Kit Replacement Screws 005-577-6439-00
Wall Fitting Escutcheon
White 005-577-5350-01 Gray 005-577-5350-02 Black 005-577-5350-03 Blue 005-577-5350-05 Lt. Gray 005-577-5350-08 6 pieces

MS E

iJet Aquadapter II Threaded
White 004-252-3022-01 Gray 004-252-3022-02 Black 004-252-3022-03 Blue 004-252-3022-05 Lt. Blue 004-252-3022-06 While supplies last Beige 004-252-3022-07 Lt. Gray 004-252-3022-08
iJet Down Jet Threaded
White 004-252-3032-01 Gray 004-252-3032-02 Black 004-252-3032-03 Blue 004-252-3032-05 Lt. Blue 004-252-3032-06 Beige 004-252-3032-07 Lt. Gray 004-252-3032-08

Vanquish Nozzles, Parts, & Tools

Vanquish Rotating Nozzle
White 004-577-5020-01 Gray 004-577-5020-02 Black 004-577-5020-03 Blue 004-577-5020-05 Lt. Gray 004-577-5020-08
Includes: Nozzle jet inserts
Vanquish Body Ring Top
White 005-577-4830-01 Gray 005-577-4830-02 Black 005-577-4830-03 Blue 005-577-4830-05 Lt. Gray 005-577-4830-08
Does not fit original Vanquish bodies.
Vanquish Body Gasket Set 005-577-0040-00
Does not fit original Vanquish bodies made before 1997
Vanquish Body Ring Top Screws 005-577-0816-00 10 pieces

Vanquish Step Nozzle
White 004-577-5025-01 Gray 004-577-5025-02 Black 004-577-5025-03 Blue 004-577-5025-05 Lt. Gray 004-577-5025-08
Includes: Twist lock caps

PAR

EMS

OUNT M A

POOL

AND

SPA

SYST

4,188U ,6.7S3. P 4A ,2T1E 2N ,0T88N4 O,S 39. 1,005

PAR

OUNT M A

POOL

AND

SPA

SYST

4,188U ,6.7S3. P 4A ,2T1E 2N ,0T88N4 O,S 39. 1,005

EMS

PAR

OUNT M

POOL

AND

SPA

SYST

4,188U ,6.7S3. P 4A ,2T1E 2N ,0T88N4 O,S 39. 1,005

EMS

Vanquish Step Nozzle Twist Lock Caps
White 005-577-4842-01 Gray 005-577-4842-02 Black 005-577-4842-03 Blue 005-577-4842-05 Lt. Gray 005-577-4842-08

PAR

EMS

OUNT M A

POOL

AND

SPA

SYST

4,188U ,6.7S3. P 4A ,2T1E 2N ,0T88N4 O,S 39. 1,005

PAR

OUNT M

POOL

AND

SPA

SYST

4,188U ,6.7S3. P 4A ,2T1E 2N ,0T88N4 O,S 39. 1,005

EMS

PAR

OUNT M

POOL

AND

SPA

SYST

4,188U ,6.7S3. P 4A ,2T1E 2N ,0T88N4 O,S 39. 1,005

(3 Pieces - 1/4", 3/8", 5/8" - 1 Each)

EMS

Vanquish Step Nozzle Trim Ring
White 005-577-6438-01 Gray 005-577-6438-02 Black 005-577-6438-03 Blue 005-577-6438-05 Lt. Gray 005-577-6438-08 5 pieces
Vanquish Step Nozzle Single Head Kit Replacement Parts
005-577-6435-00
5 screws, 2 gaskets, 1 ring
Vanquish Step Nozzle Single Head Kit Replacement Screws 005-577-6439-00
Wall Fitting Escutcheon
White 005-577-5350-01 Gray 005-577-5350-02 Black 005-577-5350-03 Blue 005-577-5350-05 Lt. Gray 005-577-5350-08 6 pieces
iJet Aquadapter II Threaded
White 004-252-3022-01 Gray 004-252-3022-02 Black 004-252-3022-03 Blue 004-252-3022-05
While supplies last
Lt. Blue 004-252-3022-06 Beige 004-252-3022-07 Lt. Gray 004-252-3022-08
iJet Down Jet Threaded
White 004-252-3032-01 Gray 004-252-3032-02 Black 004-252-3032-03 Blue 004-252-3032-05 Lt. Blue 004-252-3032-06 Beige 004-252-3032-07 Lt. Gray 004-252-3032-08

In-Floor Cleaning For Fiberglass Pools
The most advanced in-floor cleaning and circulation system designed to keep your pool clean, healthy, and always swim ready

Available in 5 colors for fiberglass pools

01 White

02 Gray

Blue

Beige

Light Gray

Vantage Nozzles Parts, & Tools

Vantage Rotating Nozzle
White 004-602-5020-01 Gray 004-602-5020-02 Blue 004-602-5020-05 Beige 004-602-5020-07 Lt. Gray 004-602-5020-08
Includes: Nozzle jet inserts
Vantage Fixed Nozzle
White 004-602-5024-01 Gray 004-602-5024-02 Blue 004-602-5024-05 Beige 004-602-5024-07 Lt. Gray 004-602-5024-08
Includes: Nozzle jet inserts

Vantage Trim Ring
White 005-602-6216-01 Gray 005-602-6216-02 Blue 005-602-6216-05 Lt. Gray 005-602-6216-08 4 pieces
Vantage Step Nozzle
White 004-602-5054-01 Gray 004-602-5054-02 Blue 004-602-5054-05 Beige 004-602-5054-07 Lt. Gray 004-602-5054-08 Includes: Twist lock caps

Vantage Step Nozzle Twist Lock Caps
White 005-602-5053-01 Gray 005-602-5053-02 Blue 005-602-5053-05 Beige 005-602-5053-07 Lt. Gray 005-602-5053-08
(3 Pieces - 1/4", 3/8", 5/8" - 1 Each)
Vantage Step Nozzle Snap On Caps
White 005-602-5054-01 Gray 005-602-5054-02 Blue 005-602-5054-05 Beige 005-602-5054-07 Lt. Gray 005-602-5054-08
(3 Pieces - 1/4")

· Enjoy Cleaner, Healthier Water · Improves Overall Circulation &
Heating · Saves Energy & Chemical Costs
for the Life of the Pool · Adjustable 3-Step 90 Degree
Cleaning Arc · Only Wall Return with Ratcheting
Sweep Technology · Patented Automatic Reversing
Mechanism

SwingJet - Adjustable Oscillating Cleaning Wall Jet
White 004-721-4501-01 Gray 004-721-4501-02 Black 004-721-4501-03 Taupe 004-721-4501-04 Blue 004-721-4501-05 Lt. Blue 004-721-4501-06 Beige 004-721-4501-07 Lt. Gray 004-721-4501-08

SwingJet U.S. PATENTS 7,481,377 6,89 W.1PARAMOUNT.COM

9,285 #,###,### WW

SwingJet

9,285 #,###,### WW

SwingJet - Adjustable Oscillating Cleaning Wall Jet - 3 Pack
White 004-721-4600-01

SwingJet U.S. PATENTS 7,481,377 6,89 W.1PARAMOUNT.COM
SwingJet U.S. PATENTS 7,481,377 6,89 W.1PARAMOUNT.COM

Gray 004-721-4600-02

Black 004-721-4600-03

SwingJet U.S. PATENTS 7,481,377 6,89 W.1PARAMOUNT.COM

Taupe 004-721-4600-04

Blue 004-721-4600-05

Lt. Blue 004-721-4600-06

Beige 004-721-4600-07

Lt. Gray 004-721-4600-08

SwingJet Install Tool 005-721-4541-00

Tools, Test Plugs, Parts, & Accessories

Large Nozzle Tool, Plastic Handle
004-552-5440-00

Small Nozzle Tool, Plastic Handle
004-552-5452-00

Large Professional Nozzle Tool, Chrome Handle
004-552-5442-00

Small Professional Nozzle Tool, Chrome Handle
004-552-5454-00

Large Stainless Steel Nozzle Tool
004-552-5446-00

Small Stainless Steel Nozzle Tool
004-252-5443-00

Large Nozzle Tool Replacement Heads 005-552-5404-00 6 pieces
Large Nozzle Tool Stainless Steel Replacement Head 005-552-5406-00
Small Nozzle Tool Replacement Heads 005-552-5410-00 6 pieces
½" Drive Adapter for Stainless Steel Small & Large Service Nozzle Tool 005-251-5443-00
Large Nozzle Pressure Test Plug 004-552-1632-00 Includes O-Ring
Large Pressure Test Plug O-Ring 005-552-0140-00 4 Pieces
Large Nozzle O-Ring 005-552-0142-00 4 Pieces

Large Nozzle Jet Inserts For Rotating Nozzles 005-552-5600-00
1/8", 1/4", 3/8" For Fixed Nozzles 005-552-5602-00
1/4", 3/8", 1/2"
Small Nozzle Pressure Test Plug 004-552-1642-00 Includes O-Ring
Small Pressure Test Plug O-Ring 005-552-0152-00 4 Pieces Also fits Retrojet A&A Quickclean Gamma 3
Small Nozzle Retainer O-Ring 005-552-0150-00 4 Pieces
Small Weighted Nozzle Gasket 005-627-0060-00 4 Pieces

Water Valves & Modules

Pressure Gauge 005-302-3590-00

Pause Assembly Includes: Screw Knob, O-Ring & Pawl 005-302-3502-00

Top Dome Complete Includes: Top, Gauge & Pause Assembly 005-302-4300-03

Modules: 004-302-4400-00 004-302-4402-00 004-302-4404-00 004-302-4406-00 004-302-4408-00

2 Port 4 Gear 2 Port 5 Gear 3 Port 4 Port 6 Port

Band Clamp (Complete) Includes Knob & Nut 005-302-3570-00

Band Clamp Knob 005-302-3600-00

Band Clamp Nut 005-302-0640-00

Base O-Ring 005-302-0100-00

Valve Base (US)*: 005-302-4002-03 005-302-4012-03 005-302-4018-03 005-302-4032-03

2 Port Base 2" Black 3 Port Base 2" Black 4 Port Base 2" Black 6 Port Base 2" Black

Valve Base (Metric): 005-302-4006-03 005-302-4009-03 005-302-4020-03 005-302-4038-03

2 Port Base 63 mm Black 3 Port Base 63 mm Black 4 Port Base 63 mm Black 6 Port Base 63 mm Black

*US 2" is equivalent to Australian 50 mm.

Complete Water Valves

2 Port Water Valve - 2", 2 Port, 4 Gear Module 004-302-4154-03
With valve shell and o-ring

6 Port Water Valve - 2", 6 Port Module 004-302-4184-03
With valve shell and o-ring

2 Port Water Valve - 2", 2 Port, 5 Gear Module 004-302-4156-03
With valve shell and o-ring

9 Port Water Valve - 2", (1) 6 Port Module, (1) 4 Port Module
004-302-4190-03
With valve shell and o-ring

3 Port Water Valve - 2", 3 Port Module 004-302-4168-03 With valve shell and o-ring
4 Port Water Valve - 2", 4 Port Module 004-302-4176-03 With valve shell and o-ring

12 Port Water Valve - 2", (1) 2 Port, 5 Gear Module, (2) 6 Port Module
004-302-4194-03
With valve shell and o-ring

· Functions as the brain of the system and directs a powerful flow of water to each set of cleaning nozzles.
· R equires no routine maintenance, and is also 100% pressure safe.

Water Valve Shells, Modules, Bases & Parts
Note: A 9 Port Module Replacement Requires One 6 Port Module and One 4 Port Module. A 12 Port Module Replacement Requires Two 6 Port Modules and One 2 Port 5 Gear Module.

2 Port Water Valve Shell - 2"
005-302-4102-03

2 Port - 4 Gear Module
004-302-4400-00 Includes o-ring

2 Port - 1½" Valve Base 005-302-4000-03

3 Port Water Valve Shell - 2"
005-302-4112-03

2 Port - 5 Gear Module
004-302-4402-00 Includes o-ring

2 Port - 2" Valve Base 005-302-4002-03

4 Port Water Valve Shell - 2" 005-302-4118-03
6 Port Water Valve Shell - 2" 005-302-4132-03
9 Port Water Valve Shell - 2" 005-302-4140-03

3 Port Module 004-302-4404-00 Includes o-ring
4 Port Module 004-302-4406-00 Includes o-ring
6 Port Module 004-302-4408-00 Includes o-ring

3 Port - 2" Valve Base 005-302-4012-03
4 Port - 1½" Valve Base 005-302-4016-03
4 Port - 2" Valve Base 005-302-4018-03
6 Port - 1½" Valve Base 005-302-4030-03

12 Port Water Valve Shell - 2"
005-302-4146-03

6 Port - 2" Valve Base 005-302-4032-03

Water Valve Top 005-302-4300-03 Includes Pressure Gauge, Knob & Pawl Assembly
Paramount Pool & Spa Systems | 1paramount.com | 1.800.621.5886 | Fax: 480-753-3397 | paramount@1paramount.com https://www.1paramount.com to ensure that you have the most up to date version. ©2020 Hayward Industries Inc.
17

NOTES
Valve Base O-Ring 005-302-0100-00
Knob & Pawl Assembly 005-302-3502-00 Run/Pause Switch Pressure Gauge 005-302-3590-00
¼" NPT Plug For Valve Top 004-252-1680-00 10 pieces
Band Clamp 005-302-3570-00 Includes Knob & Nut
Band Clamp Knob 005-302-3600-00 Includes Knob & Nut
Band Clamp Nut 005-302-0640-00
Winterizing Plug For Water Valve 004-302-1670-00
Winterizing Plug For Water Valve (6 count) 004-302-1672-00
Water Valve Plumbing Alignment Tool 004-251-8250-00
Paramount Pool & Spa Systems | 1paramount.com | 1.800.621.5886 | Fax: 480-753-3397 | paramount@1paramount.com https://www.1paramount.com to ensure that you have the most up to date version. ©2020 Hayward Industries Inc.
18

Skimmers for Concrete, Vinyl, & Fiberglass Pools Paraskim Skimmer Replacement Parts

Deck Side Deck Lid & Ring White 005-252-4570-01 Beige 005-252-4570-07 Lt. Gray 005-252-4570-08
Deck Side Deck Lid White 005-252-4572-01 Beige 005-252-4572-07 Lt. Gray 005-252-4572-08
Deck Ring White 005-252-4880-01 Beige 005-252-4880-07 Lt. Gray 005-252-4880-08 Fits Bermuda Skimmer
Deck Ring Adapter Round to Square Beige 005-252-4886-07 Lt. Gray 005-252-4886-08 For DDC2, All Paraskim Skimmers
Paraskim Skimmer Weir Door For Concrete, Vinyl & Fiberglass White 005-702-3000-01 Gray 005-702-3000-02 For Concrete Vinyl & Fiberglass
Paraskim Venturi Nozzle 005-702-8000-00

Paraskim Trimmer Plate
White 005-702-9100-01 Gray 005-702-9100-02
ParaskimV Return Guard for Concrete, Vinyl & Fiberglass Pools
White 005-702-9200-01 Gray 005-702-9200-02 Black 005-702-9200-03 Blue 005-702-9200-05 Lt. Blue 005-702-9200-06 Beige 005-702-9200-07 Lt. Gray 005-702-9200-08
ParaskimV Return Guard Assembly for Concrete Pools
White 005-702-9205-01 Gray 005-702-9205-02 Black 005-702-9205-03 Lt. Blue 005-702-9205-06 Beige 005-702-9205-07 Lt. Gray 005-702-9205-08
ParaskimV Return Guard Flush Mount Assembly for Concrete Pools
White 005-702-9210-01 Gray 005-702-9210-02 Black 005-702-9210-03 Lt. Blue 005-702-9210-06 Beige 005-702-9210-07 Lt. Gray 005-702-9210-08
Winterizing Plug for ParaskimV Venturi Skimmer
004-702-9970-00

Replacement Handle for Basket 005-152-2210-00 Fits basket for Paraskim, EDC and DDC2 canisters
Ozone Injection Feed Tube Kit for Concrete Pools 005-702-0002-00
Paraskim Faceplate Kit for Vinyl Pools - Standard Mouth White 005-702-9400-01 Gray 005-702-9400-02
Paraskim Screw Pack for Vinyl Pools - Standard Mouth 005-702-0906-00
Paraskim Faceplate Kit for Vinyl Pools - Wide Mouth White 005-702-9700-01 Gray 005-702-9700-02
Paraskim Screw Pack for Vinyl Pools - Wide Mouth 005-702-0907-00
Paraskim Flange Spacer for Vinyl Pools - 3 Pack 005-702-9930-00

Paraskim Plugs with O-rings
005-702-5000-00
(3) Plugs (3) O-rings

Fine Mesh Bag
004-152-4517-00 Fits Paraskim, EDC and DDC2 canisters. Must be used with Replacement Basket
Replacement Basket
005-152-2207-00
Fits Paraskim, EDC and DDC2 canisters

Paraskim Faceplate Kit for Fiberglass Pools White 005-702-9960-01 Gray 005-702-9960-02
Paraskim Screw Pack for Fiberglass Pools 005-702-0908-00

Bonding Lug 2" Male Slip Fitting 004-252-9227-00
ParaskimV Return Guard Assembly for Vinyl & Fiberglass Pools White 005-702-9220-01 Gray 005-702-9220-02 Black 005-702-9220-03 Blue 005-702-9220-05 Beige 005-702-9220-07 Lt. Gray 005-702-9220-08 2" Paraskim Winterizing Stack 004-252-1645-00
1½" Paraskim Winterizing Stack with 12" Foam for Venturi Return Line 004-252-5615-00
23" Winterizing Foam Replacement 004-252-5620-00 (6 pieces) Cut in half for use on venturi return line
Plug Wrench 004-252-5476-00
Paramount Pool & Spa Systems | 1paramount.com | 1.800.621.5886 | Fax: 480-753-3397 | paramount@1paramount.com https://www.1paramount.com to ensure that you have the most up to date version. ©2020 Hayward Industries Inc.
20

· Conveniently located and mounted at the equipment pad for easy installation and maintenance
· Plumbed before the circulation pump to trap debris from spa, skimmer and main drain lines before it reaches the pump and filter
· Eliminates an additional deck lid for a cleaner looking pool deck

Debris Canisters EDC Equipment Side Debris Canister

EDC - Equipment Side Canister 004-152-4516-00
EDC - Replacement Canister 005-152-2208-00
EDC - Replacement Lid with O-ring 005-152-2205-00
EDC - Replacement Lid O-Ring 005-152-2206-00

Fine Mesh Bag
004-152-4517-00 Fits Paraskim, EDC and DDC2 canisters. Must be used with Replacement Basket
Replacement Basket
005-152-2207-00
Fits Paraskim, EDC and DDC2 canisters
Replacement Handle for Basket
005-152-2210-00 Fits basket for Paraskim, EDC and DDC2 canisters

DDC2 Canister Parts & Accessories

Deck Side Deck Lid & Ring White 005-252-4570-01 Beige 005-252-4570-07 Lt. Gray 005-252-4570-08
Deck Side Deck Lid White 005-252-4572-01 Beige 005-252-4572-07 Lt. Gray 005-252-4572-08
Deck Ring White 005-252-4880-01 Beige 005-252-4880-07 Lt. Gray 005-252-4880-08 Fits Bermuda Skimmer
Deck Ring Adapter Round to Square Beige 005-252-4886-07 Lt. Gray 005-252-4886-08 For DDC2, All Paraskim Skimmers
Canister Ring Stop 005-670-6192-02 With Wedge, Gray (Fits original DDC)
Clear Internal Lid 005-152-4580-00

Canister O-Ring 005-152-0120-00 For Inside Clear Lid Not standard in canister
MVFuse Retro Canister With Ring Stop 004-670-2000-00
Ring Stop fits original DDC
Replacement Ring Stop For MVFuse Retro 005-670-6193-01
Ring Stop fits original DDC
MVFuse Test Gauge For Canister 004-150-1002-00
2" Threaded Winterizing Plug 004-302-4330-00
Fine Mesh Bag 004-152-4517-00 Fits Paraskim, EDC and DDC2 canisters. Must be used with Replacement Basket

Replacement Basket 005-152-2207-00 Fits Paraskim, EDC and DDC2 canisters
Replacement Handle for Basket 005-152-2210-00 Fits basket for Paraskim, EDC and DDC2 canisters
2½" DDC2 Winterizing Stack 004-252-4745-00
23" Winterizing Foam Replacement 004-252-5620-00 (6 pieces) Cut in half for use on venturi return line

MVFuse In-Deck Magnetic Vacuum Release

MVFuse In-Deck Unit Replacement Parts

MVFuse Start Up Kit 004-672-0502-00

MVFuse In-Deck Lid & Ring
White 005-670-6250-01 Beige 005-670-6250-07 Lt. Gray 005-670-6250-08

MVFuse In-Deck Test Gauge
004-150-1001-00

MVFuse In-Deck Extender
005-252-5522-00

Paramount's MVFUSE, the only listed magnetic Safety Vacuum Release System (SVRS), takes pool and spa safety to the next level with an additional layer of antientrapment protection.
Designed to operate pool and spa-side, which is closer to the point of suction, cutting down on precious seconds lost by other systems waiting to engage.

MVFuse In-Deck Lid White 005-670-4352-01 Beige 005-670-4352-07 Lt. Gray 005-670-4352-08
MVFuse In-Deck Ring White 005-670-6190-01 Beige 005-670-6190-07 Lt. Gray 005-670-6190-08

MVFuse Screw Pack 005-672-0001-00

MDX-R3 Debris Removal Drain MDX-R3 Parts & Accessories

MDX-R3 Adjustable Concrete Leveling Ring
005-262-2045-00

MDX-R3 Torx Screwdriver 005-252-8226-00

MDX-R3 Screw Pack Complete 005-262-0840-00 7 pieces
MDX-R3 Screw Pack Complete 005-262-0840-00 7 pieces
MDX-R3 Universal Parts & Tools MDX-R3 Funnel Adapter 005-252-1045-00

Threaded Plug 005-252-1605-00
Threaded Plug With O-Ring 005-252-1610-00
Threaded 2½" Plug With O-Ring 005-252-1611-00

MDX-R3 Cover
White 005-252-2110-01 Gray 005-252-2110-02 Black 005-252-2110-03 Taupe 005-252-2110-04 Blue 005-252-2110-05 Lt. Blue 005-252-2110-06 Beige 005-252-2110-07 Lt. Gray 005-252-2110-08
MDX-R3 Funnel Assembly
White 005-252-8234-01 Gray 005-252-8234-02 Black 005-252-8234-03 Taupe 005-252-8234-04 Blue 005-252-8234-05 Lt. Blue 005-252-8234-06 Beige 005-252-8234-07 Lt. Gray 005-252-8234-08
MDX-R3 Security Screwdriver
005-252-0895-00

01 White
03 Black

02 Gray
06 Light Blue

SDX2 High Flow Safety Drain

SDX2 Drain and Parts for Concrete Pools

SDX2 for Concrete Pools Single Drain
White 004-162-2213-01 Gray 004-162-2213-02 Black 004-162-2213-03 Lt. Blue 004-162-2213-06 Beige 004-162-2213-07 Lt. Gray 004-162-2213-08
SDX2 for Concrete Pools 2 Drains
White 004-162-2231-01 Gray 004-162-2231-02 Black 004-162-2231-03 Lt. Blue 004-162-2231-06 Beige 004-162-2231-07 Lt. Gray 004-162-2231-08
SDX2 for Concrete Pools 12 Pack - 2 Drains Per Pack
White 004-162-2215-01 Gray 004-162-2215-02 Black 004-162-2215-03 Lt. Blue 004-162-2215-06 Beige 004-162-2215-07 Lt. Gray 004-162-2215-08

Universal SDX2 Parts SDX2 Replacement Cover with Screws for Concrete Pools White 005-252-2097-01 Gray 005-252-2097-02 Black 005-252-2097-03 Lt. Blue 005-252-2097-06 Beige 005-252-2097-07 Lt. Gray 005-252-2097-08
SDX2 Support for Concrete Pools 005-252-2066-00
SDX2 Ring for Concrete Pools 005-252-2050-00
SDX2 Screw Pack for Concrete Pools 005-252-0810-00

07 Beige

08 Light Gray

· No Sump required. · Low velocity 1.396 feet per second at
the maximum at the floor (188 gpm) flow rating. · Patented ribbed design achieves very high flow via 60 independent flow partitions. · Approved as a bulkhead fitting as the safety is in the cover and backplate.

SDX2 Drain and Parts for Vinyl and Fiberglass Pools

SDX2 for Vinyl and Fiberglass Pools - 2 Drains
White 004-172-2231-01 Gray 004-172-2231-02 Black 004-172-2231-03 Blue 004-172-2231-05 Beige 004-172-2231-07 Lt. Gray 004-172-2231-08
SDX2 for Vinyl and Fiberglass Pools 8 Pack - 2 Drains Per Pack
White 004-172-2215-01 Gray 004-172-2215-02 Black 004-172-2215-03 Black 004-172-2215-05 Beige 004-172-2215-07 Lt. Gray 004-172-2215-08

Universal SDX2 Parts SDX2 Replacement Cover with Screws for Vinyl and Fiberglass Pools
White 005-252-2098-01 Gray 005-252-2098-02 Black 005-252-2098-03 Blue 005-252-2098-05 Beige 005-252-2098-07 Lt. Gray 005-252-2098-08
SDX2 Support for Vinyl and Fiberglass Pools
005-252-2061-00

SDX2 Gasket Set For Vinyl and Fiberglass Bulkhead 005-252-0072-00
SDX2 Screw Pack for Vinyl and Fiberglass Pools 005-252-0811-00
3" Threaded Winterizing Plug For SDX2 004-302-4340-00

SDX2 Retro
For Concrete Pools
SDX2 Retro for Concrete Pools Single Drain
White 004-192-2231-01 Gray 004-192-2231-02 Black 004-192-2231-03 Lt. Blue 004-192-2231-06 Beige 004-192-2231-07 Lt. Gray 004-192-2231-08
SDX2 Retro for Concrete Pools 12 Pack
White 004-192-2213-01 Gray 004-192-2213-02 Black 004-192-2213-03 Lt. Blue 004-192-2213-06 Beige 004-192-2213-07 Lt. Gray 004-192-2213-08

Universal SDX2 Retro Parts SDX2 Retro Cover for Concrete, Vinyl, and Fiberglass Pools
White 005-252-2099-01 Gray 005-252-2099-02 Black 005-252-2099-03 Blue 005-252-2099-05 Lt. Blue 005-252-2099-06 Beige 005-252-2099-07 Lt. Gray 005-252-2099-08 Includes screws
SDX2 Support for Concrete & Vinyl Pools
005-252-2067-00

SDX2 Retro Screw Pack For Concrete
005-252-0886-00

MDX2 Replacement Parts

MDX2 Cover
White 005-202-2204-01 Gray 005-202-2204-02 Black 005-202-2204-03 Taupe 005-202-2204-04 Blue 005-202-2204-05 Lt. Blue 005-202-2204-06 Beige 005-202-2204-07 Lt. Gray 005-202-2204-08
Non retro version, includes screws
MDX2 Cover Retrofit
White 005-202-2205-01 Gray 005-202-2205-02 Black 005-202-2205-03 Taupe 005-202-2205-04 Blue 005-202-2205-05 Lt. Blue 005-202-2205-06 Beige 005-202-2205-07 Lt. Gray 005-202-2205-08
For New Construction Accommodates Concrete, Vinyl, Fiberglass. Retrofit Only. Includes screws

MDX2 Screw Pack Complete 005-202-2210-00
MDX2 Screw Pack Complete - Vinyl Pools 005-202-2211-00
MDX2 Gasket For Vinyl & Fiberglass 005-252-0010-00 2 pieces
MDX2 Seal Ring For Vinyl Pools 005-252-2044-00

Drains - Other

01 White

02 Gray

03 Black

04 Taupe

Blue

Light Blue

07 Beige

08 Light Gray

· For concrete, vinyl, and one-piece pools. · Large debris passes efficiently through
mdx2 for easy removal outside the pool. · Rated for a maximum system flow rate of
90gpm. · Non-clogging sweep reduces "plugged
drain service calls"
Paramount Pool & Spa Systems | 1paramount.com | 1.800.621.5886 | Fax: 480-753-3397 | paramount@1paramount.com https://www.1paramount.com to ensure that you have the most up to date version. ©2020 Hayward Industries Inc.
27

Water Sanitizers HydraPure UV & Ozone Water Sanitizer

HydraPure 120V Plug In 004-952-0010-00

HydraPure 120V/230V Hard Wire
004-952-0020-00

HydraPure Parts & Accessories

HydraPure Replacement UV-C Lamp
005-422-9017-00

HydraPure Board with Tubes and Sensors
005-952-1501-00

HydraPure ½" Drain Plug with O-rings
005-952-2915-00

HydraPure Lamp Assembly, 2 Lamps 005-422-9015-00
HydraPure UV Ballast Replacement 005-422-3865-00
HydraPure 2 Lamp Retainer 005-422-4271-00
HydraPure O3 Lamp 005-952-1230-00
HydraPure O3 Ballast Replacement 005-952-1570-00
HydraPure Ribbon Cable 005-952-1471-00
HydraPure Wire Harness 005-952-1581-00

HydraPure Quartz Tube With Seal Kit 005-422-2009-09
HydraPure Quartz Tube Sealing Assembly 005-422-5102-00
HydraPure Quartz Tube Seal 005-422-5103-00
HydraPure Lid with Switch and Screws 005-952-1401-00
HydraPure 2½" Union Kit 005-252-8320-00
HydraPure 2½" O-rings for Unions, 4 pc. 005-252-8315-00
HydraPure Side Panel Screw Pack, 16 pc. 005-952-8325-00

HydraPure 2" Plug with O-rings 005-252-1640-00
HydraPure Ozone Flex Tube 005-952-1250-00
HydraPure Check Valve Swing with Springs 5 lb. (no body) 005-252-8290-00
Check Valve NPT x 3/8" Compression 1.0 lb. 005-402-2505-00 Use when pump is 1'-2' above water level Check Valve NPT x 3/8" Compression 2.0 lb. 005-402-2506-00 Use when pump is 3'-4' above water level Check Valve NPT x Compression 3 lb 005-401-2503-00 Use when pump is 4'-8' above water level Check Valve NPT x Compression 4 lb 005-401-2504-00 Use when pump is 8'-10' above water level

Ultra UV2 Ultraviolet Water Sanitizer

230V - Hard Wire

Ultra UV2, 230V - Hard Wire

1 UV-C Lamp

004-422-2025-00

Ultra UV2, 230V - Hard Wire

2 UV-C Lamp

004-422-2026-00

120V - Plug In

Ultra UV2, 120V - Plug In

1 UV-C Lamp

004-422-2021-00

Ultra UV2, 120V - Plug In

2 UV-C Lamp

004-422-2022-00

Ultra UV2, 230V - Hard Wire

3 UV-C Lamp

004-422-2027-00

Ultra UV2, 120V - Plug In

3 UV-C Lamp

004-422-2023-00

Ultra UV2 Parts & Accessories

Ultra UV2 Universal Ballast Replacement Kit for 1 & 2 Lamp
005-422-9030-00

Ultra UV2 Lamp Assembly, 1 Lamp
005-422-9014-00

Ultra UV2, Replacement UV-C Lamp 005-422-9017-00 NOTE: You must purchase one of the following lamp retainers with replacement lamp. Select the retainer that matches your lamp configuration.
Ultra UV2 1 Lamp Retainer 005-422-4272-00
Ultra UV2 2 Lamp Retainer 005-422-4271-00
Ultra UV2 3 Lamp Retainer 005-422-4270-00

Ultra UV2 Lamp Assembly, 2 Lamps 005-422-9015-00
Ultra UV2 Lamp Assembly, 3 Lamps 005-422-9016-00
Plug-In, 120V Flow Switch For 2" Pipe 004-421-3824-00
Flow Switch 1½" or 2" 004-402-0010-00 1½" I.D. and 2" fits inside 2" union or coupler
Ultra UV2 - Quartz Tube Sealing Assembly 005-422-5102-00

· Inactivates 99.9% Bacteria, Viruses, Fungus, Algae & Micro-Organisms Instantaneously
· Destroys Micro-Organisms That Chlorine Or Salt Chlorine Generators Can't
· Dramatically Reduce Chemical Demand By Up To 50%
· No Harmful By-Products, Reduce Eye & Skin Irritations, Cleaner, Healthier Water
· Minimal Maintenance

Ultra UV2 Parts & Accessories

Ultra UV2 - Seal Kit 005-422-9018-00
Ultra UV Screw Kit (22 Pieces) 005-422-2009-04

Ultra UV Pressure Switch 005-422-2009-10
Ultra UV Cover 005-422-2009-11

Ultra UV 2" Union Kit 005-422-2009-06
Ultra UV 2" Blanking Plug 005-422-2009-08

Ultra UV Replacement Housing 120V
005-422-3000-00
Ultra UV Replacement Housing 230V
005-422-3100-00

Ultra UV Quartz Tube With Seal Kit
005-422-2009-09

Ultra UV Quartz Tube Seal
005-422-5103-00

1
6 7
9 11
12

2 3

1 005-422-9014-00 2 005-422-9015-00 3 005-422-9016-00

Lamp Assembly - 1 Lamp Lamp Assembly - 2 Lamps Lamp Assembly - 3 Lamps

14
Universal Ballast Replacement

11
Paramount Part# 1 005-422-2009-11 2 005-422-9017-00 3 4 005-422-5102-00 5 005-422-5103-00 6 005-422-9018-00 7 005-422-9003-00 7 005-422-9004-00 8 005-422-2009-10 9 005-422-9010-00 10 11 005-422-2009-06 12 005-422-3000-00 13 005-422-2009-09 14 005-422-2009-08 15 005-422-2009-04
16 004-402-0010-00
17 004-421-3824-00

Description Cover UV Lamp Spring Clip Quartz Tube Sealing Assembly Quartz Tube Seal O-Ring, 3 Pack Ultra UV2 Seal Kit Program Start Ballast for 1 Lamp Program Start Ballast for 2 Lamps Pressure Switch Ballast Mounting Bracket UV Lamp Holder 2" Union Kits Replacement Housing Quartz Tube With Seal Kit 2" Blanking Plug Screw Kits 230V Hard Wire Flow Switch 1½" or 2" (Optional) 120V Plug In Flow Switch 1½" or 2" (Optional)

8 9

2 3 4 5 7
13 14

10 12
2" Union Kits
15

230V Hard Wire Flow Switch (optional)

120V Plug In Flow Switch (optional)

Universal Ballast Replacement

Paramount Part# 1 005-422-2009-11 2 005-422-9005-00 3 4 005-422-5102-00 5 005-422-5103-00 6 005-422-9003-00 6 005-422-9004-00 7 005-422-2009-10 8 005-422-9010-00 9 005-422-2009-05 10 005-422-2009-06 11 005-422-3000-00 12 005-422-2009-09 13 14 005-422-2009-08 15 005-422-2009-04
16 004-402-0010-00
17 004-421-3824-00

Description Cover UV Lamp Centering Disk Quartz Tube Sealing Assembly Quartz Tube Seal O-Ring, 3 Pack Program Start Ballast for 1 Lamp Program Start Ballast for 2 Lamps Pressure Switch Ballast Mounting Bracket Pressure Gauge 2" Union Kits Replacement Housing Quartz Tube With Seal Kit 230V J Box & Flex Conduit 2" Blanking Plug Screw Kits 230V Hard Wire Flow Switch 1½" or 2" (Optional) 120V Plug In Flow Switch 1½" or 2" (Optional)

Clear O3 Ozone Generator

Clear O3 Water Purifying System - Dual Voltage Without Startup Kit
004-402-3879-00
Clear O3 Water Purifying System - Dual Voltage - Single

Clear O3 Water Purifying System For Mazzei - Single 004-402-3877-00
Clear O3 Water Purifying System For Mazzei - 6 Pack

004-402-3880-00 Clear O3 Water Purifying System - Dual Voltage - 6 Pack
004-402-3881-00

004-402-3883-00
Requires Mazzei Injector Kit 004-402-3873-00. Works with Paraskim V Skimmer, requires ozone injection feed tube kit 005-702-0002-00

Clear O3 Parts & Accessories

Clear O3 Replacement Ballast 005-402-3876-00 Note: Fits U.S. and Australian Clear O3 units built after 10/01/2015.
Clear O3 Lamp 005-402-3834-00
Clear O3 Mounting Brackets (4 Pack) 005-402-3820-00
Clear O3 Tubing With Fittings & Check Valve 005-402-3361-00
Clear O3 Gaskets & Screw Set
005-402-0082-00
Clear O3 Replacement Tubing Sold By The Foot 004-402-3360-03

Clear O3 Flow Meter 005-402-3247-00
Clear O3 Air-Bleed Kit 006-402-3872-00
Clear O3 Compression Nut
005-402-1386-00
Clear O3 Pressure Side Mazzei Injector Manifold 004-402-3873-00
Clear O3 Mazzei Conversion Kit 005-252-3260-00 Ozone Injection Feed Tube Kit For ParaskimV Venturi Skimmer Concrete Pools 005-702-0002-00 Ozone feed tube kit for use with the ParaskimV Venturi Skimmer

Clear O3 Adapter Pump Pot
005-402-1050-00

Clear O3 Start Up Kit 3.5 lb. Check Valve 004-402-5850-00
Clear O3 Start Up Kit 1.5 lb. Check Valve 004-402-5860-00

· Save up to 60% on chemical costs · Maximum ozone production with minimal
impact to the pool equipment · Single unit works effectively on pools up
to 55,000 gallons · Sealed unit virtually eliminates ozone loss
while delivering the ideal level of ozone into the pool water
Clear O3 Check Valve NPT x Compression 0.5 lb 005-402-1250-00 Use when pump is 1' above water level
Clear O3 Check Valve NPT x 3/8" Compression 1.0 lb. 005-402-2505-00 Use when pump is 1'-2' above water level
Clear O3 Check Valve NPT x Compression 1.5lb 005-402-2502-00 Use when pump is 2'-3' above water level
Clear O3 Check Valve NPT x 3/8" Compression 2.0 lb. 005-402-2506-00 Use when pump is 3'-4' above water level
Clear O3 Check Valve NPT x Compression 3 lb 005-401-2503-00 Use when pump is 4'-8' above water level
Clear O3 Check Valve NPT x Compression 4 lb 005-401-2504-00 Use when pump is 8'-10' above water level
Clear O3 Check Valve Barb x Barb .5lb 005-402-1242-00
Flow Switch 1½" or 2"
004-402-0010-00 1½" I.D. and 2" fits inside 2" union or coupler

UltraClear UV & O3 Combo

ClearO3 - 203V + Ultra UV2 - 120V ClearO3 Ultra UV2, 120V - 1 UV-C Lamp 006-422-0000-00
ClearO3 Ultra UV2, 120V - 2 UV-C Lamp 006-422-0010-00
ClearO3 Ultra UV2, 120V - 3 UV-C Lamp 006-422-0020-00

ClearO3 - 203V + Ultra UV2 - 230V ClearO3 Ultra UV2, 230V - 1 UV-C Lamp 006-422-0030-00
ClearO3 Ultra UV2, 230V - 2 UV-C Lamp 006-422-0040-00
ClearO3 Ultra UV2, 230V - 3 UV-C Lamp 006-422-0050-00

The powerful combination of Paramount's ClearO3 ozone oxidizer and Ultra UV2 ultraviolet sanitizer makes your pool cleaner, healthier, sparkling clear and dramatically reduces the amount of chlorine needed to maintain an adequate level of residual sanitizer saving you time and money year after year.
All Combo Units ship with ClearO3 dual voltage, the Ultra UV2 must be selected as 120v or 230v.

* The UltraClear Units below require the Mazzei Injector Kit 004-402-3873-00 sold separately. Works with Paraskim V Skimmer, requires ozone injection feed tube kit 005-702-0002-00

ClearO3 - 203V Mazzei* + Ultra UV2 - 120V
ClearO3 Mazzei Ultra UV2, 120V - 1 UV-C Lamp
006-422-0060-00

ClearO3 - 203V Mazzei* + Ultra UV2 - 230V
ClearO3 Mazzei Ultra UV2, 230V - 1 UV-C Lamp
006-422-0090-00

ClearO3 Mazzei Ultra UV2, 120V - 2 UV-C Lamp
006-422-0070-00

ClearO3 Mazzei Ultra UV2, 230V - 2 UV-C Lamp
006-422-0100-00

ClearO3 Mazzei Ultra UV2, 120V - 3 UV-C Lamp
006-422-0080-00

ClearO3 Mazzei Ultra UV2, 230V - 3 UV-C Lamp
006-422-0110-00

Clear O3 Pressure Side Mazzei Injector Manifold
004-402-3873-00

Ozone Injection Feed Tube Kit for Concrete Pools
005-702-0002-00

Paralevel Parts & Accessories

Paralevel Start Up Kit 004-760-2921-00

Paralevel Deck Ring & Lid
White 005-760-2912-01 Beige 005-760-2912-07 Lt. Gray 005-760-2912-08

Paralevel Start Up Linkage Replacement Kit 005-762-2932-00
1" Paralevel Float Extender 005-761-2934-00
2" Paralevel Float Extender 005-761-2935-00
Paralevel Start Up Replacement Parts Kit 005-762-2931-00
Paralevel Winterization Kit 005-760-2911-00

Paralevel Deck Lid White 005-760-2901-01 Beige 005-760-2901-07 Lt. Gray 005-760-2901-08
Paralevel Deck Ring White 005-760-2915-01 Beige 005-760-2915-07 Lt. Gray 005-760-2915-08
Paralevel Deck Ring Extender 005-252-1541-00
Pour-A-Lid Cover For Paralevel Gray 004-762-2930-02 Beige 004-762-2930-07

Water Leveler
· Simple to set and use · Easy, accurate "Posi-Click" adjustment · Smaller footprint in your pool deck · Large balance line · Overflow line ready · Quick fill capable · Service industry friendly · "Smart-Sensing" not affected by water
splashing

Pool Valet Replacement Nozzles

Pool Valet Nozzles

Pool Valet Blank Nozzle
Gray 004-502-5000-02 Black 004-502-5000-03 Taupe 004-502-5000-04 Lt. Gray 004-502-5000-08
Pool Valet 1 Hole Nozzle
White 004-502-5002-01 Gray 004-502-5002-02 Black 004-502-5002-03 Taupe 004-502-5002-04 Lt. Blue 004-502-5002-06 Beige 004-502-5002-07 Lt. Gray 004-502-5002-08

Pool Valet 2 Hole Nozzle
Gray 004-502-5004-02 Black 004-502-5004-03 Taupe 004-502-5004-04 Lt. Blue 004-502-5004-06 Beige 004-502-5004-07 Lt. Gray 004-502-5004-08
ATTENTION: POOL VALET NOZZLES ARE
DISCONTINUED.
REPLACE WITH POOL VALET RETRO ON PAGE 37.

New Generation Pool Valet

Pool Valet Parts, Tools & Accessories
Pool Valet Nozzle Threaded Retainer Ring
White 005-502-4800-01 Gray 005-502-4800-02 Black 005-502-4800-03 Taupe 005-502-4800-04 Lt. Gray 005-502-4800-08
Pool Valet Hand Nozzle Tool
004-502-5420-00
Pool Valet Professional Nozzle Tool
004-502-5421-00

New Generation Pool Valet Blank Nozzle with Retainer Ring
Gray 004-502-5010-02 Black 004-502-5010-03 Lt. Gray 004-502-5010-08
New Generation Pool Valet 1 Hole Nozzle with Retainer Ring
White 004-502-5012-01 Gray 004-502-5012-02 Black 004-502-5012-03 Blue 004-502-5012-05 Beige 004-502-5012-07 Lt. Gray 004-502-5012-08

New Generation Pool Valet 2 Holes Nozzle with Retainer Ring
Black 004-502-5014-03 Blue 004-502-5014-05 Beige 004-502-5014-07 Lt. Gray 004-502-5014-08
New Generation Pool Valet Threaded Retainer Ring
White 005-502-4810-01 Gray 005-502-4810-02 Black 005-502-4810-03 Blue 005-502-4810-05 Beige 005-502-4810-07 Lt. Gray 005-502-4810-08

ATTENTION: NEW GENERATION POOL VALET ARE
DISCONTINUED.
REPLACE WITH POOL VALET RETRO ON PAGE 37.

Pool Valet Professional Nozzle Tool Replacement Handle Only with Hardware 004-252-5444-00
Pool Valet Professional Tool Replacement Part 005-502-5400-00
Pool Valet Threaded Body Plug 004-502-1620-00
Pool Valet Body Check Valve 005-502-1204-00
NOTE: THIS IS NOT COMPATIBLE WITH POOL VALET RETRO BODIES.

Pool Valet Retro

Pool Valet Retro Single Head Kit
White 006-502-4714-01 Gray 006-502-4714-02 Black 006-502-4714-03 Taupe 006-502-4714-04 Blue 006-502-4714-05 Lt. Blue 006-502-4714-06 Beige 006-502-4714-07 Lt. Gray 006-502-4714-08 Includes (1) body adapter, (1) body adapter cap (1) nozzle, (3) caps

Pool Valet Retro Nozzle Twist Lock Caps
White 005-252-4980-01 Gray 005-252-4980-02 Black 005-252-4980-03 Taupe 005-252-4980-04 Blue 005-252-4980-05 Lt. Blue 005-252-4980-06 Beige 005-252-4980-07 Lt. Gray 005-252-4980-08
3 Pieces, 1 Each - 1/4", 3/8", 5/8"

Pool Valet Retro Nozzle
White 004-502-5006-01 Gray 004-502-5006-02 Black 004-502-5006-03 Taupe 004-502-5006-04 Blue 004-502-5006-05 Lt. Blue 004-502-5006-06 Beige 004-502-5006-07 Lt. Gray 004-502-5006-08

Universal In-Floor Nozzle Replacements RetroJets

Retrojet® Nozzle Replacements For A&A Quickclean 1
White 004-652-4955-01 Black 004-652-4955-03 Beige 004-652-4955-07 Cream 004-652-4955-09 Md. Gray004-652-4955-10
Retrojet® Nozzle Replacements For A&A Quickclean 2
White 004-652-4956-01 Black 004-652-4956-03 Beige 004-652-4956-07 Cream 004-652-4956-09 Md. Gray004-652-4956-10

Retrojet® Nozzle Replacements For Net'N'Clean White 004-652-4945-01
RetroJet Tools/ Parts
A&A Quickclean 1 Removal Tool 004-652-5421-00

Retrojet® Nozzle Replacements For A&A Quickclean Gamma 3
White 004-652-4957-01 Black 004-652-4957-03 Beige 004-652-4957-07 Cream 004-652-4957-09 Md. Gray004-652-4957-10

A&A Quickclean 2 Removal Tool
004-652-5422-00

Retrojet® Nozzle Replacements For Caretaker 99 Bayonet
White 004-652-4954-01 Gray 004-652-4954-02 Black 004-652-4954-03 Taupe 004-652-4954-04 Lt. Gray 004-652-4954-08 Cream 004-652-4954-09 Aqua Blue 004-652-4954-11
Retrojet® Nozzle Replacements For Caretaker 99 Threaded
White 004-652-4949-01 Gray 004-652-4949-02 Black 004-652-4949-03 Taupe 004-652-4949-04 Lt. Gray 004-652-4949-08 Cream 004-652-4949-09 Aqua Blue 004-652-4949-11

A&A Gamma 3 Removal Tool 004-652-5423-00
Retrojet® Removal And Installation Tool 004-652-5422-00
RetroJet Installation Tool. Fits all Retro nozzles except Pool Valet Retro
Quickclean 1 O-ring - 4pk 005-822-0151-00
Quickclean 2 O-ring - 4pk 005-822-0155-00
Net-N-Clean O-ring - 4pk 005-822-0154-00

Spa Jets And Spa Air Solution For Concrete Spas ParaJets - Spa Jets, Parts And Tool

ParaJets Shiatsu Massage Jet
White 004-852-4100-01 Gray 004-852-4100-02 Black 004-852-4100-03 Beige 004-852-4100-07 Lt. Gray 004-852-4100-08
ParaJets Pulsating Massage Jet
White 004-852-5100-01 Gray 004-852-5100-02 Black 004-852-5100-03 Beige 004-852-5100-07 Lt. Gray 004-852-5100-08
ParaJets Soft Stream Massage Jet
White 004-852-6100-01 Gray 004-852-6100-02 Black 004-852-6100-03 Beige 004-852-6100-07 Lt. Gray 004-852-6100-08
ParaJets Shiatsu Faceplate
White 004-852-4000-01 Gray 004-852-4000-02 Black 004-852-4000-03 Beige 004-852-4000-07 Lt. Gray 004-852-4000-08
ParaJets Pulsating Faceplate
White 004-852-5000-01 Gray 004-852-5000-02 Black 004-852-5000-03 Beige 004-852-5000-07 Lt. Gray 004-852-5000-08
ParaJets Soft Stream Faceplate
White 004-852-6000-01 Gray 004-852-6000-02 Black 004-852-6000-03 Beige 004-852-6000-07 Lt. Gray 004-852-6000-08

ParaJets Deep Tissue Faceplate White 004-852-3000-01 Gray 004-852-3000-02 Black 004-852-3000-03 Beige 004-852-3000-07 Lt. Gray 004-852-3000-08 ParaJets True Directional Return White 004-852-9500-01 Gray 004-852-9500-02 Black 004-852-9500-03 Beige 004-852-9500-07 Lt. Gray 004-852-9500-08
ParaJets Body With Cap 004-852-1000-00
ParaJets Construction Cap - 6 Pack 004-852-2000-00
ParaJets Install and Removal Tool 004-852-0000-00

Design your spa with ParaJets to deliver a relaxing hydro-therapeutic massage. Choose between 4 interchangeable massage therapy jet face plates; Deep Tissue, Shiatsu, Pulsating or Soft Stream to create a relaxing spa experience.
The unique advantage of installing ParaJets is the universal housing that allows the ability to change or move the therapy jet face plates to different stations in your spa with a simple . Choose different combinations for your legs, back and other muscle groups. The choice is yours to mix and match as you see fit.

01 White

02 Gray

03 Black

07 Beige

08 Light Gray
Paramount Pool & Spa Systems | 1paramount.com | 1.800.621.5886 | Fax: 480-753-3397 | paramount@1paramount.com https://www.1paramount.com to ensure that you have the most up to date version. ©2020 Hayward Industries Inc.
39

Water Features Air-Port Spa Air Solution

Air-Port Muffler 004-252-3110-00

Deck Side Deck Lid
White 005-252-4572-01 Beige 005-252-4572-07 Lt. Gray 005-252-4572-08

Deck Side Deck Lid & Ring
White 005-252-4570-01 Beige 005-252-4570-07 Lt. Gray 005-252-4570-08

Deck Ring
White 005-252-4880-01 Beige 005-252-4880-07 Lt. Gray 005-252-4880-08
Fits Bermuda Skimmer

Parascope Telescoping Water Features

Parascope Replacement Bubbler
White 005-059-2502-01 Gray 005-059-2502-02 Black 005-059-2502-03 Blue 005-059-2502-05 Lt. Blue 005-059-2502-06 Beige 005-059-2502-07 Lt. Gray 005-059-2502-08

Parascope Replacement Umbrella
White 005-059-2504-01 Gray 005-059-2504-02 Black 005-059-2504-03 Blue 005-059-2504-05 Lt. Blue 005-059-2504-06 Beige 005-059-2504-07 Lt. Gray 005-059-2504-08

Parascope Replacement Flower
White 005-059-2503-01 Gray 005-059-2503-02 Black 005-059-2503-03 Blue 005-059-2503-05 Lt. Blue 005-059-2503-06 Beige 005-059-2503-07 Lt. Gray 005-059-2503-08

Parascope Accessory Pack
White 005-059-2505-01 Gray 005-059-2505-02 Black 005-059-2505-03 Blue 005-059-2505-05 Lt. Blue 005-059-2505-06 Beige 005-059-2505-07 Lt. Gray 005-059-2505-08

Universal Parts & Accessories

iJet Aquadapter II Slip
White 004-252-3020-01 Gray 004-252-3020-02 Black 004-252-3020-03 Taupe 004-252-3020-04 Blue 004-252-3020-05 Lt. Blue 004-252-3020-06 While supplies last Beige 004-252-3020-07 Lt. Gray 004-252-3020-08
iJet Aquadapter II Threaded
White 004-252-3022-01 Gray 004-252-3022-02 Black 004-252-3022-03 Taupe 004-252-3022-04 Blue 004-252-3022-05
While supplies last
Lt. Blue 004-252-3022-06 Beige 004-252-3022-07 Lt. Gray 004-252-3022-08

Wall Fitting 1 1/2" Slip X Thread - 6 Pieces White 005-252-3044-01 Gray 005-252-3044-02 Black 005-252-3044-03 Taupe 005-252-3044-04 Blue 005-252-3044-05 Lt. Blue 005-252-3044-06 Beige 005-252-3044-07 Lt. Gray 005-252-3044-08
2" Threaded Plug 6 Pieces 005-252-1605-00
Plug Wrench 004-252-5476-00

iJet Down Jet Threaded
White 004-252-3032-01 Gray 004-252-3032-02 Black 004-252-3032-03 Taupe 004-252-3032-04 Blue 004-252-3032-05 Lt. Blue 004-252-3032-06 Beige 004-252-3032-07 Lt. Gray 004-252-3032-08
iJet Downjet Eyeball 6 Pieces
Clear 005-252-3030-00 White 005-252-3030-01
1½" Threaded Return with 1" Opening
White 004-252-3040-01 Gray 004-252-3040-02 Black 004-252-3040-03 Taupe 004-252-3040-04 Blue 004-252-3040-05 Lt. Blue 004-252-3040-06 Beige 004-252-3040-07 Lt. Gray 004-252-3040-08

2" Threaded Winterizing Plug 004-302-4330-00
2½" Threaded Winterizing Plug 004-152-4810-00
3" Threaded Winterizing Plug for SDX2 for Vinyl & Fiberglass Pools 004-302-4340-00
Equipment Labels 100 Per Roll 005-252-8224-00

Adobe InDesign 16.0 (Macintosh) Adobe PDF Library 15.0
