Immobilizer Function
Keyless Function
LOCK Button
UNLOCK Button
Trunk Button
The connector is arran
g
ed as shown in the fi
g
ure below.
Terminal No. I/O
A-
B I/O
C I/O
D I/O
E I/O
F-
G-
■CAUTION■
Operation of frequency
B-CAN(-)
B-CAN(+)
IGN
Operating voltage Keyless DC9~16V
Immobilizer DC6~16V
+B
A
C/DC Suppl
y
DC12V
When the user pushes LOCK, UNLOCK, and the TRUNK button of
HAND UNIT, the RF electric wave is output, and IMMOBI UNIT receives
it, and an open lock, the close lock of the door, and the signal of the
t
r
u
nk
ope
nin
g
a
r
e
output
.
W69xL90.8xH77.2(mm)
FCC WARNING
Changes or modifications not expressly approved by the part
y
responsible for compliance could void the user’s authority to operate the
Size
・Give a shock.
・Get it wet. If it got wet, wipe and dry up.
・Disassembly and modification.
This device complies with Part 15 of FCC Rules and RSS-Gen of IC
Rules. Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation
of this device.
MAX 230mA(@12.5V 25℃) at operation
User's Manual
GND
S-NET
K-LINE
This unit is installed in vehicle. It performs communication with keyless unit
by LF, processes RF signal from keyless unit, and performs actions
according to the signal.
Unit Assy Immobi&Keyless communicates with the transponder in the
hand unit when the user inserts the hand unit in the key cylinder, and it
rotates
Product name : UNIT ASSY IMMOBI &KEYLESS
Type : TWD1G763
Terminal Name
Operating temperature
range -40~+85 degree C
RF : 433.92MHz
LF: 125kHz
MAX 2mA(@12.5V 25℃) at standb
y
Weight
Please DO NOT the following. Engine is not started by failure of
electronic parts. (Product can not receive the signal correctly)
Pay attention to the following.
・It may not be operated when using the equipment of the same
frequency band in the vicinity.
0.075kg
Consumption current
spec
HUND UNIT UNIT ASSY IMMOBI&KEYLESS
IG1
