Accton Technology 7822GMN WiFi Module User Manual 1
Accton Technology Corp WiFi Module 1
User Manual
![](/img.php?id=1873608&img=bg1.png)
Mini-Size, up to 300Mbps
IEEE 802.11b/g/n, 2T2R
• Comply with IEEE 802.11b/g/n standards.
• High transfer data rate – up to 300Mbps.
• Supports WMM wireless QoS feature.
• Supports 64/128-bit WEP, WPA, WPA2 with IEEE 802.1x functions for high level of
security.
• Support the most popular operating system: Windows XP/Vista/7.
• Supports WPS (WiFi Protected Setup) hardware button for easy connection.
• Supports software AP function.
• Supports USB 2.0/1.1 interface.
• Portable and mini size design.
• Green power saving.
Specification
Product 300N Wireless LAN USB Module
Main Chip Realtek RTL8192CU
Standard IEEE 802.11b/g/n
Bus Type USB 2.0 Type A
Frequency Band 2.4000~2.4835GHz (Industrial Scientific Medical Band)
Data Rate 11b: 1/2/5.5/11Mbps
11g: 6/9/12/24/36/48/54Mbps
11n (20MHz): MCS0-15, up to 144Mbps
11n (40MHz): MCS0-15, up to 300Mbps
Output Power 11n: 21dBm±1.5dBm
11g: 19dBm±1.5dBm
11b: 14.5dBm±1.5dBm
Security WEP 64/128, WPA, WPA2, IEEE 802.1x
Antenna Chip Antenna x 2 (2T2R)
Drivers Windows XP/Vista/7
LED Link/Activity
Dimension 9.5(H) x 19.2(W) x 56(D) mm
Temperature Operating: 32~104°F (0~40°C) , Storage: -4~140°F (-20~60°C)
Humidity Operating: 10~90% (Non-Condensing)
Storage: Max. 95% (Non-Condensing)
Certification 47 CFR FCC Part 15 Subpart B, Class B
47 CFR FCC Part 15 Subpart C & 15.247
Canada Standard ICES-003 Issue 5, Class B
IC RSS-210 Annex 8
Feature
EW-7822GMn
300N Wireless LAN USB Module
