Accton Technology SMC2536WAG2 Dual Band Wireless Cardbus Adapter User Manual Revised
Accton Technology Corp Dual Band Wireless Cardbus Adapter Users Manual Revised
Users Manual Revised
![](/img.php?id=990667&img=bg1.png)
EZ Connect N
Draft 11n Wireless USB2.0 Adapter
EliteConnect™
Dualband Wireless Cardbus Adapter
SMC2536W-AG2
![](/img.php?id=990667&img=bg2.png)
LIMITED WARRANTY
Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to be
free from defects in workmanship and materials, under normal use and service, for
the applicable warranty term. All SMC products carry a standard 90-day limited
warranty from the date of purchase from SMC or its Authorized Reseller. SMC may, at
its own discretion, repair or replace any product not operating as warranted with a
similar or functionally equivalent product, during the applicable warranty term. SMC
will endeavor to repair or replace any product returned under warranty within 30 days
of receipt of the product. The standard limited warranty can be upgraded to a Limited
Lifetime* warranty by registering new products within 30 days of purchase from SMC
or its Authorized Reseller. Registration can be accomplished via the enclosed product
registration card or online via the SMC website. Failure to register will not affect the
standard limited warranty. The Limited Lifetime warranty covers a product during the
Life of that Product, which is defined as the period of time during which the product is
an “Active” SMC product. A product is considered to be “Active” while it is listed on the
current SMC price list. As new technologies emerge, older technologies become
obsolete and SMC will, at its discretion, replace an older product in its product line
with one that incorporates these newer technologies. At that point, the obsolete
product is discontinued and is no longer an “Active” SMC product. A list of
discontinued products with their respective dates of discontinuance can be found
at: http://www.smc.com/index.cfm?action=customer_service_warranty
All products that are replaced become the property of SMC. Replacement products
may be either new or reconditioned. Any replaced or repaired product carries either a
30-day limited warranty or the remainder of the initial warranty, whichever is longer.
SMC is not responsible for any custom software or firmware, configuration
information, or memory data of Customer contained in, stored on, or integrated with
any products returned to SMC pursuant to any warranty. Products returned to SMC
should have any customer-installed accessory or add-on components, such as
expansion modules, removed prior to returning the product for replacement. SMC is
not responsible for these items if they are returned with the product. Customers must
contact SMC for a Return Material Authorization number prior to returning any product
to SMC. Proof of purchase may be required. Any product returned to SMC without a
valid Return Material Authorization (RMA) number clearly marked on the outside of
the package will be returned to customer at customer’s expense. For warranty claims
within North America, please call our toll-free customer support number at (800)
762-4968. Customers are responsible for all shipping charges from their facility to
SMC. SMC is responsible for return shipping charges from SMC to customer.
WARRANTIES EXCLUSIVE: IF AN SMC PRODUCT DOES NOT OPERATE AS
WARRANTED ABOVE, CUSTOMER’S SOLE REMEDY SHALL BE REPAIR OR
REPLACEMENT OF THE PRODUCT IN QUESTION, AT SMC’S OPTION. THE
FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU
OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED,
EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE,
INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. SMC NEITHER ASSUMES NOR
AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY
IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF
ITS PRODUCTS. SMC SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS
TESTING AND EXAMINATION DISCLOSE THE ALLEGED DEFECT IN THE
PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY
THIRD PERSON’S MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING,
UNAUTHORIZED ATTEMPTS TO REPAIR, OR ANY OTHER CAUSE BEYOND THE
RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR
OTHER HAZARD.
LIMITATION OF LIABILITY: IN NO EVENT, WHETHER BASED IN CONTRACT OR
TORT (INCLUDING NEGLIGENCE), SHALL SMC BE LIABLE FOR INCIDENTAL,
CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,
OR FOR LOSS OF REVENUE, LOSS OF BUSINESS, OR OTHER FINANCIAL
LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF ITS
PRODUCTS, EVEN IF SMC OR ITS AUTHORIZED RESELLER HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. SOME STATES DO NOT
ALLOW THE EXCLUSION OF IMPLIED WARRANTIES OR THE LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS,
SO THE ABOVE LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, WHICH MAY VARY
FROM STATE TO STATE. NOTHING IN THIS WARRANTY SHALL BE TAKEN TO
AFFECT YOUR STATUTORY RIGHTS.
* SMC will provide warranty service for one year following discontinuance from the
active
SMC price list. Under the limited lifetime warranty, internal and external power
supplies, fans, and cables are covered by a standard one-year warranty from date of
purchase.
SMC Networks, Inc.
20 Mason
Irvine, CA 92618
COMPLIANCES
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, (example - use only shielded
interface cables when connecting to computer or peripheral devices) any changes or
modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
IMPORTANT NOTE
FCC Radiation Exposure Statement:
This device has been tested for compliance with FCC RF Exposure (SAR) limits in the
typical laptop computer configuration and this device can be used in desktop or laptop
computers with side mounted PCMCIA slots. This device cannot be used with
handheld PDAs (personal digital assistants). This device and its antenna must not be
co-located or operated in conjunction with any other antenna or transmitter.
![](/img.php?id=990667&img=bg5.png)
EC Declaration of Conformity
SMC contact for these products in Europe is:
SMC Networks Europe,
Edificio Conata II,
Calle Fructuos Gelabert 6-8, 2o, 4a,
08970 - Sant Joan Despi,
Barcelona, Spain.
Marking by the above symbol indicates compliance with the Essential Requirements
of the R&TTE Directive of the European Union (1999/5/EC). This equipment meets
the following conformance standards:
EN 300 328
EN 301 489
EN 60950-1
Council recommendation 1999/519/EC of 12 July 1999, limitations of exposure
of the general public to electromagnetic fields (0 Hz to 300 GHz)
[Czech] Společnost SMC Networks tímto prohlašuje, že toto rádiové zařízení LAN je ve shodě
se základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Oficiální ES prohlášení o shodě je uvedeno v příslušné části k produktu na
webu http://www.smc.com
[Danish] SMC Networks erklærer herved, at følgende Radio LAN-enhed overholder de
væsentlige krav og andre relevante bestemmelser i direktiv 1999/5/EF. Den officielle
EU-overensstemmelseserklæring er tilgængelig under det relevante produktafsnit på
følgende webadresse: http://www.smc.com.
[German] Hiermit erklärt SMC Networks, dass sich dieses Wireless LAN Gerät in
Übereinstimmung mit den grundlegenden Anforderungen und den anderen relevanten
Vorschriften der Richtlinie 1999/5/EG befindet. Die offizielle EC-Declaration of
Conformity finden Sie im Internet unter http://www.smc.com unter der entsprechenden
Produktkategorie.
[Estonian] Käesolevaga kinnitab SMC Networks, et see Radio LAN seade vastab direktiivi
1995/5/EÜ põhinõuetele ja teistele asjakohastele sätetele. Ametliku EÜ
vastavusdeklaratsiooni leiate vastavast tootejaotisest aadressil http://www.smc.com.
[English] Hereby, SMC Networks, declares that this Radio LAN device is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC. The
official EC-Declaration of Conformity can be found under the corresponding product
section on the web http://www.smc.com.
[Spanish] Por medio de la presente SMC Networks declara que el Radio LAN device cumple con
los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la
![](/img.php?id=990667&img=bg6.png)
Directiva 1999/5/CE. The official EC-Declaration of Conformity can be found under the
corresponding product section on the web http://www.smc.com
[Greek] Με την παρούσα, η SMC Networks, δηλώνει ότι η συσκευή ασύρματου τοπικού δικτύου
συμμορφώνεται με τις ουσιώδεις απαιτήσεις και τις λοιπές σχετικές διατάξεις της
Οδηγίας 1999/5/EΚ. Η επίσημη δήλωση συμμόρφωσης EΚ παρέχεται στην αντίστοιχη
ενότητα προϊόντων, στην ιστοσελίδα http://www.smc.com.
[French] Par la présente SMC Networks déclare que l'appareil Radio LAN device est conforme
aux exigences essentielles et aux autres dispositions pertinentes de la directive
1999/5/CE. La déclaration de conformité officielle peut être trouvée sur notre site
internet http://www.smc.com dans la rubrique Produits.
[Italian] Con la presente SMC Networks dichiara che questo Radio LAN device è conforme ai
requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
La Dichiarazione di conformità CE ufficiale è disponibile nella sezione dedicata al
rispettivo prodotto sul sito Web http://www.smc.com.
[Latvian] Ar šo SMC Networks deklarē, ka Radio LAN device atbilst Direktīvas 1999/5/EK
būtiskajām prasībām un citiem ar to saistītiem noteikumiem. Oficiālā EK atbilstības
deklarācija ir atrodama attiecīgā produkta sadaļā tīmeklī http://www.smc.com.
[Lithuanian] Šiuo „SMC Networks“ deklaruoja, kad šis radijo LAN įrenginys atitinka esminius
reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. Oficialią jo EB atitikties
deklaraciją galima rasti atitinkamų gaminių skyriuje šiame
tinklalapyje: http://www.smc.com.
[Dutch] Hierbij verklaart SMC Networks dat het toestel Radio LAN device in overeenstemming
is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
Het officiële EC- gelijkvormigheidattest kan men vinden op de internetsite
http://www.smc.com onder de betrokken productcategorie.
[Maltese] B’dan, SMC Networks, tiddikjara li dan it-tagħmir LAN tar-Radju huwa konformi
mar-rekwiżiti essenzjali u dispożizzjonijiet rilevanti oħra ta’ Direttiva 1999/5/KE.
Id-Dikjarazzjoni ta’ Konformità uffiċjali tal-KE tinsab fit-taqsima korrispondenti fis-sit ta’
l-Internet http://www.smc.com.
[Hungarian] Az SMC Networks kijelenti, hogy a Radio LAN eszköz megfelel a vonatkozó alapvető
követelményeknek és az 1999/5/EC irányelv egyéb előírásainak. A hivatalos EC
megfelelőségi nyilatkozat megtalálható a vonatkozó termék ismertetőjénél, a következő
címen: http://www.smc.com
[Polish] Firma SMC Networks niniejszym oświadcza, że urządzenie Radio LAN jest zgodne z
zasadniczymi wymaganiami oraz pozostałymi stosownymi postanowieniami Dyrektywy
1999/5/EC. Oficjalna Deklaracja zgodności UE znajduje się w odpowiedniej sekcji
produktu w witrynie http://www.smc.com.
[Portuguese] A SMC Networks declara que este dispositivo de LAN de Rádio está em conformidade
![](/img.php?id=990667&img=bg7.png)
com os requisitos essenciais e com outras provisões relevantes da Directiva
1999/5/CE. A Declaração de Conformidade CE oficial encontra-se na secção
correspondente do produto na Web, http://www.smc.com.
[Slovenian] Družba SMC Network izjavlja, da je naprava Radio LAN skladna z bistvenimi zahtevami
in drugimi ustreznimi predpisi direktive 1999/5/ES. Za uradno izjavo o skladnosti ES
glejte razdelek za ustrezni izdelek na spletni strani http://www.smc.com.
[Slovak] Spoločnosť SMC Networks týmto vyhlasuje, že toto zariadenie Radio LAN spĺňa
základné požiadavky a ďalšie príslušné ustanovenia smernice 1999/5/ES. Oficiálne
prehlásenie ES o zhode je uvedené v sekcii príslušného produktu v
lokalite http://www.smc.com.
[Finnish] SMC Networks vakuuttaa täten, että Radio LAN device -tyyppinen laite on direktiivin
1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen
mukainen. EY:n virallinen vaatimustenmukaisuusvakuutus on tuotteen kohdalla
Web-sivustossa http://www.smc.com.
[Swedish] Härmed intygar SMC Networks att denna Radio LAN-apparat uppfyller de väsentliga
egenskapskrav och övriga relevanta bestämmelser i direktiv 1999/5/EG. Den officiella
EG-försäkran om överensstämmelse finns under motsvarande produktavsnitt
på http://www.smc.com.
[Icelandic] Hér með lýsir SMC Networks því yfir að þessi Radio LAN búnaður er í samræmi við
grunnkröfur og aðrar viðeigandi kröfur, sem gerðar eru í tilskipun 1999/5/EB. Opinberu
EB-samræmisyfirlýsinguna er að finna í viðeigandi hluta um þennan búnað á
vefsetrinu http://www.smc.com.
[Norwegian] SMC Networks erklærer herved at Radio LAN-enheten er i samsvar med de
grunnleggende kravene og øvrige relevante krav i direktiv 1999/5/EF. Denne offisielle
EU-konformitetserklæringen finnes under korresponderende produktseksjon på
Internett: http://www.smc.com.
Countries of Operation & Conditions of Use in EC/ EFTA member states
[English] This device is a 2.4 GHz / 5GHz wireless LAN transceiver, intended for home and office
use in all notified EC and EFTA member states. In accordance with article 6.4 of the
R&TTE Directive 1999/5/EC the following EC/ EFTA member states have been notified:
Austria, Belgium, Denmark, Finland, France, Germany, Italy, Luxembourg,
Netherlands, Norway, Spain, Sweden, Switzerland, United Kingdom, Portugal, Greece,
Ireland, Iceland. Requirements for outdoor operation, like license requirements and
allowed channels of operation apply in some countries. Please contact your local
regulation authority or SMC Networks for details on current restrictions for outdoor use.
[French] Ce produit est un appareil radio LAN transceiver de 2.4 GHz / 5 GHz destiné aux PME
![](/img.php?id=990667&img=bg8.png)
et à l’utilisation domestique dans tous les pays certifiés conformes aux conditions de
l’EU et de l’EFTA. En accord avec l’article 6.4 de la R&TTE directive 1999/5/EC, the
membres de la EU et de l’EFTA sont les suivants : Autriche, Belgique, Danemark,
finalnde, France, Allemagne, Italie, Luxembourg, Pays-Bas, Norvège, Espagne, Suède,
Suisse, Royaume-Uni, Portugal, Grèce, Irelande, Icelande. Des conditions sont
appliquées à certains pays pour l’utilisation en extérieur, tels que des licences
spécífiques et des canaux d’opération. Veuillez contacter votre autorité locale ou SMC
Networks pour plus de détails quant aux restrictions actuelles concernant l’utilisation en
extérieur.
[Dutch] Dit toestel is een draadloze Lan transceiver, bestemd voor gebruik binnen huis en
kantoor in alle geïnformeerde lidstaten van de EC en de EFTA. In overeenstemming
met artikel 6.4 van de R&T TE Directive 1999/5/EC zijn de volgende EC/EFTA lidstaten
verwittigd: België, Denemarken, Duitsland, Finland, Frankrijk,Griekenland, Ierland,
IJsland, Italië, Luxemburg, Nederland, Noorwegen,Oostenrijk, Portugal, Spanje ,
Verenigd Koninkrijk, Zweden, Zwitserland. Benodigdheden voor gebruik buiten, zoals
gebruiksvergunningen en toegelaten werkkanalen zijn van toepassing in sommige
landen. Gelieve uw lokale instantie of SMC Networks te contacteren voor details op
huidige beperkingen voor gebruik in buitenlucht.
[Spanish] Este aparato es un transmisor inalámbrico de 2.4 GHz / 5 GHz, previsto para el uso
interior en domicilios y Pymes en todos los Estados de la CE y la EFTA notificados. De
acuerdo con el artículo 6.4 de la Directiva R&TTE 1999/5/EC los siguientes estados de
la CE y de la EFTA han sido notificados: Austria, Bélgica, Dinamarca, Finlandia,
Francia, Alemania, Italia, Luxemburgo, Países Bajos, Noruega, España, Suecia, Suiza,
Reino Unido, Portugal, Grecia, Irlanda, Islandia. Los requisitos para su uso exterior,
como requerimiento de licencia y canales de operación permitidos se aplican en
algunos países. Por favor contacte la autoridad reguladora local o SMC Networks para
más detalles en relación con las restricciones actuales para uso exterior.
[German] Dieses Wireless LAN Gerät arbeitet im 2.4 GHz / 5 GHz Frequenzband und ist für den
Einsatz im Innenbereich in den benachrichtigten EC/ EFTA Mitgliedstaaten geeignet. In
Übereinstimmung mit Artikel 6.4 der R&TTE Direktive 1999/5/EC wurden folgende
Mitgliedstaaten benachrichtigt: Österreich, Belgien, Dänemark, Finland, Frankreich,
Deutschland, Italien, Luxemburg, Niederlande, Norwegen, Spanien, Schweden,
Schweiz, Großbritannien, Portugal, Griechenland, Irland, Island. Für den Einsatz im
Aussenbereich sind in einigen Ländern Lizenzen erforderlich oder die Anzahl der
Kanäle ist eingeschränkt. Bitte kontaktieren Sie Ihre Regulierungsbehörde oder SMC
Networks für die aktuellen Einschränkungen beim Einsatz im Aussenbereich.
[Czech] Toto zařízení je přijímač a vysílač pro bezdrátové sítě LAN v pásmu 2,4 GHz / 5GHz,
určený pro použití v interiéru domácností a kanceláří ve všech členských zemích ES a
ESVO, kterým byl oznámen záměr uvést zařízení na trh. V souladu s čl. 6 odst. 4
směrnice 1999/5/ES o rádiových zařízeních a telekomunikačních koncových zařízeních
byly uvědoměny tyto členské země ES nebo ESVO: Belgie, Dánsko, Finsko, Francie,
Irsko, Island, Itálie, Lucembursko, Německo, Nizozemsko, Norsko, Portugalsko,
Rakousko, Řecko, Spojené království, Španělsko, Švédsko, Švýcarsko. Na použití ve
![](/img.php?id=990667&img=bg9.png)
venkovním prostředí se v některých zemích vztahují určité požadavky, např. požadavky
na licenci nebo provoz v povolených kanálech. O omezení venkovního použití se
informujte u místních regulátorů nebo u společnosti SMC Networks.
[Danish] Enheden er en 2,4 GHz / 5 GHz trådløs LAN-transceiver, beregnet til indendørs
hjemme- og kontorbrug i alle notificerede EU- og EFTA-medlemslande. I henhold til
afsnit 6.4 i R&TTE-direktivet 1999/5/EF er følgende EU-/EFTA-medlemslande
notificeret: Østrig, Belgien, Danmark, Finland, Frankrig, Tyskland, Grækenland, Island,
Irland, Italien, Luxembourg, Holland, Norge, Portugal, Spanien, Sverige, Schweiz og
Storbritannien. I visse lande gælder der krav vedrørende udendørs betjening af
enheden, f.eks. licenskrav og tilladte betjeningskanaler. Kontakt de lokale lovgivende
myndigheder eller SMC Networks for at få oplysninger om aktuelle begrænsninger
vedrørende udendørs betjening.
[Estonian] See seade on 2.4 GHz / 5 GHz juhtmeta LAN vastuvõtu-saatejaam, mis on mõeldud
kodus ja kontoris kasutamiseks kõikides teavitatud EÜ ja Euroopa Vabakaubanduse
Assotsiatsiooni (EFTA) liikmesriikides. Vastavalt R&TTE direktiivi 1999/5/EÜ
paragrahvile 6.4 on teavitatud järgmisi EÜ/EFTA liikmesriike: Austriat, Belgiat, Taanit,
Soomet, Prantsusmaad, Saksamaad, Itaaliat, Luksemburgi, Hollandit, Norrat,
Hispaaniat, Rootsit, Šveitsi, Ühendkuningriiki, Portugali, Kreekat, Iirimaad, Islandi.
Mõningates riikides kehtivad väljas kasutamiseks nõuded, näiteks litsentsinõuded ja
lubatud töökanalid. Palun teavitage vastavat kohalikku ametkonda või ettevõtet SMC
Networks’i, kui soovite täpsemaid andmeid väljas kasutamisel kehtivate piirangute
kohta.
[Greek] Αυτή η συσκευή είναι ένας ασύρματος πομποδέκτης τοπικού δικτύου 2,4 GHz / 5 GHz,
που προορίζεται για οικιακή και επαγγελματική χρήση σε εσωτερικό χώρο, σε όλα τα
κράτη-μέλη της ΕΚ και της ΕΖΕΣ. Σύμφωνα με το άρθρο 6.4 της Οδηγίας για
ραδιοεξοπλισμό και τηλεπικοινωνιακό τερματικό εξοπλισμό (R&TTE), 1999/5/ΕΚ, έχουν
ανακοινωθεί τα ακόλουθα κράτη-μέλη ΕΕ/ΕΖΕΣ: Αυστρία, Βέλγιο, ∆ανία, Φιλανδία,
Γαλλία, Γερμανία, Ιταλία, Λουξεμβούργο, Ολλανδία, Νορβηγία, Ισπανία, Σουηδία,
Ελβετία, Ηνωμένο Βασίλειο, Πορτογαλία, Ελλάδα, Ιρλανδία, Ισλανδία. Σε ορισμένες
χώρες επιβάλλονται απαιτήσεις για χρήση σε εξωτερικό χώρο, όπως απαιτήσεις
παραχώρησης άδειας και επιτρεπόμενα κανάλια λειτουργίας. Απευθυνθείτε στην τοπική
αρμόδια αρχή ή στην SMC Networks για λεπτομέρειες σχετικά με τους τρέχοντες
περιορισμούς για χρήση σε εξωτερικό χώρο.
[Italian] Il presente device è un ricetrasmettitore LAN wireless da 2,4 GHz / 5 GHz, previsto per
l'uso in interni a casa e in ufficio in tutti gli Stati membri della CE e dell'EFTA notificati.
Conformemente all'articolo 6.4 della Direttiva 1999/5/CE R&TTE, sono stati notificati i
seguenti Stati membri della CE/dell'EFTA: Austria, Belgio, Danimarca, Finlandia,
Francia, Germania, Grecia, Irlanda, Islanda, Italia, Lussemburgo, Norvegia, Paesi
Bassi, Portogallo, Regno Unito, Spagna, Svezia, Svizzera. In alcuni Paesi si applicano i
requisiti per il funzionamento in esterni, quali requisiti di licenza e canali consentiti.
Contattare l'Autorità normativa locale del proprio Paese o SMC Networks per
informazioni dettagliate sulle limitazioni correnti per l'utilizzo in esterni.
![](/img.php?id=990667&img=bga.png)
[Latvian] Šī ierīce ir 2,4 GHz / 5 GHz bezvadu LAN raiduztvērējs, kas paredzēts izmantošanai
iekštelpās mājās un birojos visās paziņotajās EK un EBTA (European Free Trade
Association - Eiropas brīvās tirdzniecības asociācija) dalībvalstīs. Atbilstoši radioiekārtu
un telekomunikāciju gala iekārtu direktīvas 1999/5/EK 6.4. pantam paziņotās EK/EBTA
valstis ir : Austrija, Beļģija, Dānija, Somija, Francija, Vācija, Itālija, Luksemburga,
Nīderlande, Norvēģija, Spānija, Zviedrija, Šveice, Apvienotā Karaliste, Portugāle,
Grieķija, Īrija, Islande. Dažās valstīs ir spēkā ierobežojumi lietošanai ārvidē, piemēram,
licences prasības un darbībai atļautie kanāli. Lūdzu, sazinieties ar vietējo regulējošo
instanci vai SMC Network, lai saņemtu informāciju par pašreizējiem ierobežojumiem
lietošanai ārvidē.
[Lithuanian] Šis įrenginys yra 2,4 GHz / 5 GHz belaidis LAN siųstuvas-imtuvas, skirtas naudoti
patalpose namie ar biure visose notifikuotose EB ir ELPA šalyse narėse. Pagal RTTE
Direktyvos 1999/5/EB 6.4 straipsnį, notifikuotos yra šios EB/ELPA šalys narės: Austrija,
Belgija, Danija, Suomija, Prancūzija, Vokietija, Italija, Liuksemburgas, Nyderlandai,
Norvegija, Ispanija, Švedija, Šveicarija, Jungtinė Karalystė, Portugalija, Graikija, Airija,
Islandija. Kai kuriose šalyse galioja tam tikri reikalavimai norint naudoti įrenginį lauke,
pvz., licencijos ir suteikti ryšio kanalai. Jei norite sužinoti, kokie apribojimai galioja norint
naudoti įrenginį lauke, kreipkitės į nacionalinę reguliavimo instituciją arba „SMC
Networks“.
[Maltese] Dan it-tagħmir huwa LAN transreciever mingħajr fili ta’ 2.4 GHz / 5 GHz maħsub biex
jintuża fuq ġewwa fi djar u uffiċċini fil-pajjiżi notifikati tal-KE u
l-Istati Membri ta’ l-EFTA. B’mod konformi ma’ Artikolu 6.4 tad-Direttiva R&TTE
1999/5/KE l-Istati Membri tal-KE/EFTA li ġejjin ġew notifikati: L-Awstrija, Il-Belġju,
Id-Danimarka, Il-Finlandja, Franza, Il-Ġermanja, L-Italja, Il-Lussemburgu, L-Olanda,
In-Norveġja, Spanja, L-Iżveżja, L-Iżvizzera, Ir-Renju Unit, Il-Portugal, Il-Greċja,
L-Irlanda, L-Islanda. Rekwiżiti għal tħaddim fuq barra, bħal ħtiġijiet ta’ liċenzja u kanali
permessi għal tħaddim japplikaw f’ċertu pajjiżi. Jekk jogħġbok ikkuntattja lill-awtorità
regolarorja lokali jew SMC Networks għal dettalji dwar restrizzjonijiet attwali dwar l-użu
fuq barra.
[Hungarian] Ez az eszköz egy 2,4 GHz / 5 GHz-es vezeték nélküli LAN adó-vevő, amely beltéri és
irodai használatra készült, és az összes értesített EC- és EFTA-tagországban
használható. Az 1999/5/EC jelű R&TTE előírás 6.4-es cikkének megfelelően a
következő EC/ EFTA tagországok kaptak értesítést: Ausztria, Belgium, Dánia,
Finnország, Franciaország, Németország, Olaszország, Luxemburg, Hollandia,
Norvégia, Spanyolország, Svédország, Svájc, Egyesült Királyság, Portugália,
Görögország, Írország és Izland. Egyes országokban külön előírások vonatkoznak a
kültéri használatra, például a licencre és az engedélyezett csatornákra. A kültéri
használatra vonatkozó aktuális előírásokkal kapcsolatos részletekért forduljon a helyi
szabályozó hatósághoz vagy az SMC Networkshöz.
[Polish] Niniejsze urządzenie to urządzenie do odbierania i przesyłania sygnału (transceiver) w
bezprzewodowej sieci LAN o częstotliwości 2,4 GHz / 5 GHz, przeznaczone do użytku
wewnątrz pomieszczeń, w domach i biurach we wszystkich krajach członkowskich UE i
EFTA. Zgodnie z artykułem 6.4 dyrektywy 1999/5/EC dotyczącej norm dla urządzeń
![](/img.php?id=990667&img=bgb.png)
radiowych i końcowych urządzeń teletransmisyjnych powiadomione zostały
następujące kraje członkowskie: Austria, Belgia, Dania, Finlandia, Francja, Niemcy,
Włochy, Luksemburg, Holandia, Hiszpania, Szwecja, Szwajcaria, Wielka Brytania,
Portugalia, Grecja, Irlandia, Islandia. W niektórych krajach obowiązują wymagania
dotyczące działania na zewnątrz budynków, na przykład wymagania licencyjne i
dozwolone kanały pracy. Szczegółowe informacje na temat obowiązujących ograniczeń
użytkowania zewnętrznego można uzyskać, kontaktując się z lokalnym urzędem
regulacji lub firmą SMC Networks.
[Portuguese] Este dispositivo é um transreceptor de LAN sem fios de 2,4 GHz / 5 GHz, destinado a
uma utilização interior em casa e no escritório, em todos os Estados membros
notificados da CE e da EFTA. De acordo com o artigo 6.4 da Directiva sobre R&TTE
1999/5/CE, foram notificados os seguintes Estados membros da CE/EFTA: Áustria,
Bélgica, Dinamarca, Finlândia, França, Alemanha, Itália, Luxemburgo, Holanda,
Noruega, Espanha, Suécia, Suíça, Reino Unido, Portugal, Grécia, Irlanda, Islândia. Os
requisitos para uma utilização no exterior, tais como de licença e de canais de
funcionamento permitidos aplicam-se a alguns países. Para obter informações sobre
as restrições de utilização no exterior, contacte a autoridade local competente ou a
SMC Networks.
[Slovenian] Ta naprava je oddajno-sprejemna enota za brezžično lokalno omrežje, namenjena
uporabi na domu ali v pisarni v vseh priglašenih državah članicah ES in EFTA. Skladno
s členom 6.4 Direktive 1999/5/ES o radijski opremi in telekomunikacijski terminalski
opremi so bile obveščene naslednje države članice ES/EFTA: Avstrija, Belgija, Danska,
Finska, Francija, Nemčija, Italija, Luksemburg, Nizozemska, Norveška, Španija,
Švedska, Švica, Velika Britanija, Portugalska, Grčija, Irska, Islandija. V nekaterih
državah veljajo zahteve za delovanje na prostem, kot so zahteve za dovoljenje in
dovoljeni kanali za delovanje. Če potrebujete natančne informacije o trenutnih
omejitvah uporabe na prostem, se obrnite na lokalni regulativni organ ali družbo SMC
Networks.
[Slovak] Toto zariadenie je prijímač a vysielač pre bezdrôtové siete v pásme 2,4 GHz / 5 GHz a
je určené na použitie v interiéroch domácností a kancelárií vo všetkých členských
štátoch ES a EZVO, ktorým bol oznámený zámer uviesť zariadenie na trh. V súlade s
čl. 6 odst. 4 smernice 1999/5/ES o rádiovom zariadení a koncových telekomunikačných
zariadeniach boli upovedomené nasledujúce členské štáty ES/EZVO: Belgicko,
Dánsko, Francúzsko, Fínsko, Grécko, Holandsko, Island, Írsko, Luxembursko,
Nemecko, Nórsko, Portugalsko, Rakúsko, Španielsko, Švajčiarsko, Švédsko,
Taliansko, Veľká Británia. V niektorých štátoch sa na prevádzku v exteriéroch vzťahujú
určité požiadavky, napríklad požiadavky na licenciu alebo požiadavky na prevádzkové
kanály. Podrobné informácie o aktuálnych obmedzeniach pri prevádzke v exteriéroch
vám poskytnú miestne regulačné orgány alebo spoločnosť SMC Networks.
[Finnish] Laite on 2,4 GHz / 5 GHz:n langaton LAN-vastaanotin, joka on tarkoitettu koti- ja
toimistokäyttöön kaikissa EY:n ja EFTAn jäsenmaissa, joihin siitä on ilmoitettu. Radio-
ja telepäätelaitedirektiivin 1999/5/EY mukaisesti seuraaville EY-/EFTA-maille on
ilmoitettu: Itävalta, Belgia, Tanska, Suomi, Ranska, Saksa, Italia, Luxemburg,
![](/img.php?id=990667&img=bgc.png)
Alankomaat, Norja, Espanja, Ruotsi, Sveitsi, Iso-Britannia, Portugali, Kreikka, Irlanti ja
Islanti. Joissakin maissa ulkokäyttöä koskevat erilliset vaatimukset, kuten erikseen
anottava lupa ja sallittujen kanavien rajoittaminen. Ota yhteyttä paikalliseen käyttöä
valvovaan viranomaiseen tai SMC Networksiin, jos haluat lisätietoja laitteen ulkokäytön
rajoituksista.
[Swedish] Apparaten är en 2,4 GHz / 5 GHz trådlös LAN-mottagare för inomhusbruk i hem och på
kontor i alla underrättade EG- och EFTA-medlemsstater. Enligt artikel 6.4 i
R&TTE-direktivet 1999/5/EG är följande EG-/EFTA-stater underrättade: Österrike,
Belgien, Danmark, Finland, Frankrike, Tyskland, Italien, Luxemburg, Nederländerna,
Norge, Spanien, Sverige, Schweiz, Storbritannien, Portugal, Grekland, Irland och
Island. I vissa länder tillkommer krav för utomhusbruk, t.ex. licenskrav och tillåtna
användarkanaler. Kontakta lokala tillsynsmyndigheter eller SMC Networks för
information om aktuella bestämmelser för utomhusbruk.
[Icelandic] Þessi búnaður er 2,4 GHz / 5 GHz þráðlaust LAN sendiviðtæki til notkunar innanhúss á
heimili og skrifstofu í öllum tilkynntum aðildarríkjum EB og EFTA. Í samræmi við grein
6.4 í R&TTE tilskipuninni 1999/5/EB hefur eftirfarandi aðildarríkjum EB/EFTA verið
tilkynnt þar um: Austurríki, Belgía, Danmörk, Finnland, Frakkland, Þýskaland, Ítalía,
Lúxemborg, Holland, Noregur, Spánn, Svíþjóð, Sviss, Bretland, Portúgal, Grikkland,
Írland, Ísland. Kröfur fyrir notkun utanhúss, svo sem kröfur um leyfi og heimilaðar rásir
eiga við í sumum löndum. Hafið samband við reglugerðaryfirvöld á hverjum stað eða
SMC Networks til að fá upplýsingar um gildandi takmarkanir á notkun utanhúss.
[Norwegian] Denne enheten er en trådløs 2.4 GHz / 5 GHz LAN-mottaker som er beregnet for
innendørs privat- og kontorbruk i alle underrettede EF- og EFTA-medlemsstater. I
overensstemmelse med artikkel 6.4 i R&TTE-direktivet 1999/5/EF, har følgende EF-/
EFTA-medlemsstater blitt underrettet: Østerrike, Belgia, Danmark, Finland, Frankrike,
Tyskland, Italia, Luxembourg, Nederland, Norge, Spania, Sverige, Sveits, Storbritannia,
Portugal, Hellas, Irland og Island. Krav for utendørsbruk, som lisenskrav og tillatte
brukskanaler, gjelder i noen land. Ta kontakt med din lokale regulerende myndighet
eller SMC Networks for detaljert informasjon om gjeldende begrensninger for utendørs
bruk.
Requirements for indoor vs. outdoor operation, license requirements and
allowed channels of operation apply in some countries as described below:
. In Italy the end-user must apply for a license from the national spectrum authority to
operate this device outdoors.
. In Belgium outdoor operation is only permitted using the 2.46 - 2.4835 GHz band:
Channel 13.
. In France outdoor operation is only permitted using the 2.4 - 2.454 GHz band:
Channels
1 - 7.
Italian:
In alcuni Paesi si applicano i requisiti per il funzionamento in interni-esterni, i requisiti
di licenza e i canali consentiti, come descritto si seguito:
- In Italia l'utente finale deve richiedere una licenza all'Autorità competente nazionale
per il funzionamento in esterni del device.
Dutch:
Vereisten voor werking indoor versus outdoor, licentie vereisten en toegestane
kanalen voor gebruik zijn van toepassing in bepaalde landen zoals hieronder
beschreven.
- In Belgïe is outdoor gebruik enkel toegestaan gebruik makend van de 2.46 -
2.4835 GHz band: Kanaal13.
French:
Conditions requises pour des installations intérieures ou extérieures, licences
requises et canaux autorisés dans certains pays comme décrits ci-dessous:
- En Belgique, l'installation extérieure est seulement autorisée sur la bande 2.46 -
2.4835 GHz:: Canal 13
- En France, l'installation extérieure est seulement autorisée sur la bande 2.4 -
2.454 GHz : Canal 1-7
Within the 5.15-5.25GHz band, this device will be restricted to indoor operations to
reduce any potential for harmful inteference to co-channel MSS operations.
Package Contents ..................................................................................................................... 1
Chapter 1.Introduction ..................................................................................................... 2
1.1Overview of the product ................................................................................ 2
1.2Features ........................................................................................................ 2
1.3LED Status .................................................................................................... 3
Chapter 2.Installation Guide ............................................................................................ 4
2.1Hardware Installation ..................................................................................... 4
2.2Software Installation ...................................................................................... 4
2.2.1Overview ............................................................................................................. 4
2.2.2Software Installation for Windows 2000 and XP ................................................. 4
2.2.3Installation for Windows Vista ............................................................................. 8
Chapter 3.Configuration................................................................................................. 11
3.1Current Status ............................................................................................. 11
3.2Profile Management .................................................................................... 13
3.2.1Add or Modify a Configuration Profile ............................................................... 14
3.2.2Remove a profile ............................................................................................... 17
3.2.3Switch another Profile ....................................................................................... 18
3.2.4Import a Profile.................................................................................................. 18
3.2.5Export a Profile ................................................................................................. 18
3.2.6Scan Available Networks .................................................................................. 18
3.2.7Auto Profile Selection Management ................................................................. 19
3.3Diagnostics .................................................................................................. 20
3.3.1Check Driver Information .................................................................................. 21
3.3.2Check Receive and Transmit Statistical Information ........................................ 21
Chapter 4.Configuration for windows Vista ................................................................. 22
Appendix A: Specifications .................................................................................................... 25
Appendix B: Glossary ............................................................................................................. 26
Appendix C: Contact Information .......................................................................................... 27
![](/img.php?id=990667&img=bgf.png)
SMC2536W-AG2 User Guide
1
Package Contents
The following contents should be found in your box:
¾ One SMC2536W-AG2 EliteConnect™ Dualband Wireless Cardbus Adapter
¾ Quick Installation Guide
¾ One Resource CD for SMC2536W-AG2:
• SMC2536W-AG2 Wireless Client Utility (SMC WCU) and Drivers
• User Guide
• Other Helpful Information
) Note:
If any of the listed contents are damaged or missing, please contact the retailer from whom you
purchased the SMC2536W-AG2 EliteConnect™ Dualband Wireless Cardbus Adapter for
assistance.
![](/img.php?id=990667&img=bg10.png)
SMC2536W-AG2 User Guide
2
Chapter 1.
Introduction
1.1 Overview of the product
The SMC2536W-AG2 - EliteConnect™ Dualband Wireless Cardbus Adapter - can provide high
performance of wireless connectivity, without the restrictions of phone lines or Ethernet cables.
With the IEEE 802.11a, 802.11b and 802.11g standards, the SMC2536W-AG2 can connect with
existing 802.11b, 802.11g- or 802.11a- compliant routers, access points and cards. That means
you can still communicate with colleagues and friends while you have the ability to link to even
more wireless networks.
The adapter's auto-sensing capability allows high packet transfer rate of up to 54Mbps for
maximum throughput, or dynamic range shifting to lower speeds due to distance or operating
limitations in an environment with a lot of electromagnetic interference. Your wireless
communications are protected by up to 152-bit WEP and WPA/WPA2 encryption for high security.
1.2 Features
¾ Complies with IEEE802.11a, IEEE802.11g and IEEE802.11b standards
¾ Supports WPA/WPA2 data security, IEEE802.1x authentication, TKIP/AES encryption,
64/128/152-bit WEP encryption
¾ Supports 54/48/36/24/18/12/9/6Mbps or 11/5.5/3/2/1Mbps wireless LAN data transfer rates
¾ Provides 32-bit CardBus interface
¾ Supports Ad-Hoc and Infrastructure modes
¾ Supports roaming between access points when configured in Infrastructure mode
¾ Supports Pairwise Master Key (PMK) caching for fast roaming support
¾ Ease to configure and provides monitoring information
¾ Support for Windows 2000, XP (32-bit) and Vista (32-bit and 64-bit) WHQL certified Drivers
¾ Intelligent Internal Diversity Antenna
![](/img.php?id=990667&img=bg11.png)
SMC2536W-AG2 User Guide
3
1.3 LED Status
LED Indications SMC2536W-AG2 Working Status
Status Green Intermittently The adapter is in an electricity saving status.
Activity Not lit
Status Lit The adapter is on wake up status.
Activity Not lit
Status Flashing
Alternately The adapter is trying to scan a networking
connection.
Activity Flashing
Alternately
Status Intermittently
The adapter is already connected but is not
transmitting or receiving data.
Activity Intermittently
Status Flashing The adapter is transmitting or receiving data.
Activity Flashing
![](/img.php?id=990667&img=bg12.png)
SMC2536W-AG2 User Guide
4
Chapter 2.
Installation Guide
2.1 Hardware Installation
To install the adapter, follow these steps listed below:
1. Locate an available CardBus slot on your laptop.
2. With the connector pin end facing the CardBus slot and the label facing up, slide the Adapter
into the CardBus slot until it locks in place.
3. The Status LED should Intermittent flashing when the Adapter is installed correctly.
2.2 Software Installation
2.2.1 Overview
The EZ Installation Wizard on the provided CD will guide you through the Installation procedure
for Windows 2000, XP and Vista. The Setup Wizard will install the SMC Wireless Client Utility
(SMC WCU) and drivers.
Please make sure you have inserted the hardware before installing the software! The system will
prompt “Found New Hardware Wizard”, click Cancel, and run the Setup Wizard program
(SMC2536W_AG2.exe) on the CD-ROM if the CD will not autostart by itself.
The Setup steps for Windows 2000 and XP are very similar. The following setup steps are for
Windows 2000 and Windows Vista.
2.2.2 Software Installation for Windows 2000 and XP
1. IMPORTANT: Plug in the EliteConnect™ Dualband Wireless Cardbus Adapter into an
available CardBus slot as instructed and Cancel the driver installation process at this time, if
needed.
2. Put the EZ Installation & Documentation CD in to your CD-ROM drive. The CD will auto run
and Figure 2-1 will appear.
![](/img.php?id=990667&img=bg13.png)
SMC2536W-AG2 User Guide
5
Figure 2-1
3. Click [Install Driver & Utility], then [Next] to start the installation.
4. You can click Cancel to end the installation on the Preparing Setup screen of Figure 2-2.
Otherwise, the Setup Wizard will display a screen similar to that shown in Figure 2-3 after a
moment.
Figure 2-2 SMC Wireless Client Utility – Install Shield Wizard
5. To continue, click Next on the screen, Figure 2-3. If you want to cancel the installation at this
point you can Click Cancel to end the Installation.
![](/img.php?id=990667&img=bg14.png)
SMC2536W-AG2 User Guide
6
Figure 2-3 SMC2536W-AG2 Wireless Client Utility Installation Program
6. The Setup Wizard will ask you to choose a Setup type in Figure 2-4. It is recommended that
you select Install Client Utilities and Driver. Select Install Driver Only to install driver only.
Select Install Client Utilities and Driver and click Next to continue the Installation. Click
Back to return to the previous page, or click Cancel to end the Installation.
Figure 2-4 Select the Setup type.
7. Click Browse to change the destination location for the software in Figure 2-5. Click Next to
continue the Installation. Click Back to return to the previous page, or click Cancel to end the
Installation.
![](/img.php?id=990667&img=bg15.png)
SMC2536W-AG2 User Guide
7
Figure 2-5 Choose Destination Location
8. The Setup Wizard will ask you to create a new folder name or select one from the Existing
Folders list shown in Figure 2-6. It is recommended that you keep the default value. Click
Next to continue the Installation. Click Back to return to the previous page, or click Cancel to
end the Installation.
Figure 2-6 Select a Program Folder
9. After the files have been successfully copied, the screen in Figure 2-7 will appear. Click
Finish to reboot the system.
![](/img.php?id=990667&img=bg16.png)
SMC2536W-AG2 User Guide
8
Figure 2-7 Finish
2.2.3 Installation for Windows Vista
1. IMPORTANT: Plug in the EliteConnect™ Dualband Wireless Cardbus Adapter into an
available CardBus slot as instructed and Cancel the driver installation process at this time, if
needed.
2. Put the EZ Installation & Documentation CD in to your CD-ROM drive. The CD will auto run
and Figure 2-8 will appear.
Figure 2-8
![](/img.php?id=990667&img=bg17.png)
SMC2536W-AG2 User Guide
9
3. Click [Install Driver & Utility], then [Next] to start the installation. Figure 2- will appear; Click
Cancel to end the installation in the screen. Otherwise, the installation will continue.
Figure 2-9
4. Click Next in the screen below (shown in Figure 2-10) to continue, you can click Cancel to
end the installation.
Figure 2-10
5. After that, the files will be copied as the next screen shown (shown in Figure 2-11). To end
the Installation, click Cancel.
![](/img.php?id=990667&img=bg18.png)
SMC2536W-AG2 User Guide
10
Figure 2-11
6. Click the Finish button to complete.
Figure 2-12
![](/img.php?id=990667&img=bg19.png)
SMC2536W-AG2 User Guide
11
Chapter 3. Configuration
The SMC2536W-AG2 can be configured by the SMC2536W-AG2 Wireless Client Utility (SMC
WCU). This chapter describes how to configure your SMC EliteConnet™ Dualband Wireless
Cardbus Adapter for wireless connectivity on your Wireless Local Area Network (WLAN) and use
the data security encryption features.
After Installing the SMCWCU icon will appear in your system tray. It appears at the bottom of
the screen, and shows the wireless connection status.
If the icon is red, there is no wireless connection.
If the icon is green a wireless connection is established.
Double-click the icon and the SMC WCU will run. You can also run the utility by clicking the Start >
Program > SMC > SMC2536W-AG2 Wireless Client Utility. The SMC WCU provides a complete
and easy to use set of tools to:
¾ Display current status information
¾ Edit and add configuration profiles
¾ Display current diagnostics information
The section below introduces these above capabilities.
3.1 Current Status
The Current Status tab contains general information about the program and its operations. The
Current Status tab does not require any configurations.
![](/img.php?id=990667&img=bg1a.png)
SMC2536W-AG2 User Guide
12
Figure 3-1 Current Status
The following table describes the items found on the Current Status screen.
¾ Profile Name - The name of current selected configuration profile. Set up the configuration
name on the General tab of Profile Management.
¾ Link Status - Shows whether the station is associated to the wireless network.
¾ Wireless Mode - Displays the wireless mode. Configure the wireless mode on the
Advanced tab of Profile Management.
¾ Network Type - The type of network and the station currently connected. The options
include:
• Infrastructure (access point)
• Ad Hoc
Configure the network type on the Advanced tab of Profile Management.
¾ IP Address - Displays the computer’s IP address.
¾ Current Channel - Shows the currently connected channel.
¾ Data Encryption - Displays the encryption type the driver is using. Configure the encryption
type on the Security tab of Profile Management.
¾ Server Based Authentication - Shows whether server based authentication is used.
¾ Signal Strength - Shows the strength of the signal.
Click Advanced to see advanced information about the program and its operations. For more
information, please refer to the help file of the utility.
![](/img.php?id=990667&img=bg1b.png)
SMC2536W-AG2 User Guide
13
Figure 3-2 Advance Status
3.2 Profile Management
Click the Profile Management tab of the SMC WCU and the Profile Management screen will
appear, Figure 3-3. The Profile Management screen provides tools to:
¾ Add a profile
¾ Edit a profile
¾ Remove a profile
¾ Switch to another Profile
¾ Import a Profile
¾ Export a Profile
¾ Scan Available Networks
¾ Order profiles
Figure 3-3 Profile Management tab
![](/img.php?id=990667&img=bg1c.png)
SMC2536W-AG2 User Guide
14
3.2.1 Add or Modify a Configuration Profile
To add a new configuration profile, click New on the Profile Management tab. To modify a
configuration profile, select the configuration from the Profile list and click Modify.
The Profile Management dialog box will display a screen similar to that shown in Figure 3-5.
1. Edit the General tab
¾ Profile Name - Identifies the configuration profile. This name must be unique. Profile names
are not case-sensitive.
¾ Client Name - Identifies the client machine.
¾ Network Names (SSIDs) - The IEEE 802.11 wireless network name. This field has a
maximum limit of 32 characters.
Figure 3-4 General Tab of Profile Management
2. Edit the Security tab
Edit the fields in the Security tab of Profile Management to configure the profile. To define the
security mode, select the radio button of the desired security mode.
![](/img.php?id=990667&img=bg1d.png)
SMC2536W-AG2 User Guide
15
Figure 3-5 Security tab of Profile Management
¾ WPA/WPA2: Wi-Fi Protected Access
¾ WPA/WPA2 Passphrase: Wi-Fi Protected Access Passphrase
¾ 802.1x: Enables 802.1x security.
¾ Shared Key (Static WEP): Enables the use of shared keys that are defined on both the
access point and the station. To define shared encryption keys, choose the Shared Key radio
button and click Configure to fill in the Define Shared Keys window.
¾ None: No security (not recommended).
) Note:
If the access point that the wireless adapter is associating to has WEP set to Optional and the
client has WEP enabled, make sure that Allow Association to Mixed Cells is checked on
the Security Tab to allow association. To complete WEP encryption configuration, you must select
the 802.11 Authentication Mode as appropriate on the Advanced tab of this Profile Management
dialog.
To configure the Encryption Keys under the Pre-Shared keys (Static WEP) Security mode:
![](/img.php?id=990667&img=bg1e.png)
SMC2536W-AG2 User Guide
16
Figure 3-6 Define Shared Keys
3. Edit the Advanced tab
This screen below allows you make advanced configuration for the profile.
Figure 3-7 Advanced tab of Profile Management
¾ Power Save Mode -
• Maximum - Selects maximum mode to let the access point buffer incoming messages
for the wireless adapter. The adapter will detect the access point if any messages are
waiting periodically.
• Normal - In Normal mode, the adapter will be switched to maximum mode automatically
when no large packets are retrieved.
• Off - turns power saving off, thus powering up the wireless adapter continuously for a
short message response time.
¾ Network Type: Select Infrastructure or Ad Hoc.
![](/img.php?id=990667&img=bg1f.png)
SMC2536W-AG2 User Guide
17
¾ 802.11b Preamble: Specifies the preamble setting in 802.11b. The default setting is Short &
Long (access point mode), which allows both short and long headers in the 802.11b
frames. The adapter can only use short radio headers if the access point supports and uses
them. Set to Long Only to override allowing short frames.
¾ Wireless Mode: Specifies 5 GHz 54 Mbps or 2.4 GHz 54 Mbps or 2.4 GHz 11 Mbps
operation in an access point network. The wireless adapter must match the wireless mode of
the access point with which it associates.
¾ Wireless Mode when Starting an Ad Hoc Network: Specifies 5G/2.4 GHz 54/11 Mbps to
start an Ad Hoc network if no matching network name is found after scanning all available
modes. This mode also allows the selection of the channel the wireless adapter uses. The
channels available depend on the regulatory domain. If the adapter finds no other ad hoc
adapters, the channel that the adapter starts the ad hoc network with will be selected
automatically.
¾ 802.11 Authentication Mode: Select which mode the wireless adapter uses to authenticate
to an access point:
• Automatic causes the adapter to attempt authentication using shared, but switches it to
open authentication if shared fails.
• Open System enables an adapter to attempt authentication regardless of its WEP
settings. It will only associate with the access point if the W EP keys on both the adapter
and the access point match.
• Shared-key only allows the adapter to associate with access points that have the same
WEP key.
For infrastructure (access point) networks, click Preferred APs to specify up to four access points
to the client adapter that attempts to be associated to the access points. The four access points
have different priorities; the frontal has the higher priority.
Figure 3-8 Preferred APs
3.2.2 Remove a profile
1. Go to the Profile Management tab.
2. Select the profile name to remove in the Profiles List.
3. Click Remove.
![](/img.php?id=990667&img=bg20.png)
SMC2536W-AG2 User Guide
18
3.2.3 Switch another Profile
1. Go to the Profile Management tab.
2. Click on the profile name in the Profiles List.
3. Click Activate.
3.2.4 Import a Profile
1. From the Profile Management tab, click Import…. The Import Profile will then appear.
2. Browse to the directory where the profile is located.
3. Highlight the profile name.
4. Click Open, the imported profile will then appear in the Profiles List.
Figure 3-9 Import Profile Dialog
3.2.5 Export a Profile
1. From the Profile Management tab, highlight the profile to export.
2. Click Export, the Export Profile window will then appear.
3. Browse the directory to export the profile to.
4. Click Save. The profile should then be exported to the specified location.
Figure 3-10 Export Profile Dialog
3.2.6 Scan Available Networks
1. Click Scan on the Profile Management, the Available Infrastructure and Ad Hoc Networks
window will appear.
![](/img.php?id=990667&img=bg21.png)
SMC2536W-AG2 User Guide
19
2. Click Refresh to refresh the list at any time.
3. Highlight a network name and click Activate to connect an available network. If no
configuration profile exists for that network, the Profile Management window will open the
General tab. Fill in the Profile name and click OK to create the configuration profile for that
network.
Figure 3-11 Scan Available Networks Dialog
3.2.7 Auto Profile Selection Management
The auto selection feature allows the wireless adapter to automatically select a profile from the list
of profiles and use it to connect to the network. To add a new profile into the Auto Selected
Profiles list, please follow these steps.
1. On the Profile Management tab, click Order Profiles.
2. The Auto Profiles Selection management window will appear, with a list of all created profiles
in the Available Profiles box.
3. Highlight the profiles to add to auto profile selection, and click Add. The profile will appear in
the Auto Selected Profiles box.
4. Highlight a profile in the Auto Selected Profiles box.
5. Click Move Up or Move Down as appropriate. Note: The first profile in the Auto Selected
Profiles box has highest priority, and the last profile has lowest priority.
6. Click OK.
7. Check the Auto Select Profiles checkbox on the Profile Management tab.
) Note:
When auto profile selection is enabled by checking Auto Select Profiles on the Profile
Management tab, the client adapter will scan for an available network. The profile with the
highest priority and the same SSID as one of the found networks will be used to connect to the
network. If the connection fails, the client adapter will try the next highest priority profile that
matches the SSID until an available network is found.
![](/img.php?id=990667&img=bg22.png)
SMC2536W-AG2 User Guide
20
Figure 3-12 Auto Profile Selection Management Dialog
3.3 Diagnostics
The Diagnostics tab of the SMC2536W-AG2 Wireless Client Utility (SMC WCU) provides buttons
used to retrieve receiving and transmitting statistics. The Diagnostics tab does not require any
configuration.
The Diagnostics tab lists the following receive and transmit diagnostics for frames received or
transmitted by the wireless network adapter:
¾ Multicast frames transmitted and received
¾ Broadcast frames transmitted and received
¾ Unicast frames transmitted and received
¾ Total bytes transmitted and received
Figure 3-13 Diagnostics tab
![](/img.php?id=990667&img=bg23.png)
SMC2536W-AG2 User Guide
21
3.3.1 Check Driver Information
¾ The Adapter Information contains general information about the wireless network adapter
and the Network Driver Interface Specification (NDIS) driver. Access the adapter
information from the Diagnostics tab.
¾ Card Name - The name of the wireless network adapter.
¾ MAC Address - The MAC address of the wireless network adapter.
¾ Driver - The driver name and path of the wireless network adapter driver.
¾ Driver Version - The version of the wireless network adapter driver.
¾ Driver Date - The creation date of the wireless network adapter driver.
¾ Client Name - The name of the client computer.
3.3.2 Check Receive and Transmit Statistical Information
The Advanced Statistics show receiving and transmitting statistical information for the following
receive and transmit diagnostics for frames received by or transmitted to the wireless network
adapter.
Figure 3-15 Advanced Statistics
![](/img.php?id=990667&img=bg24.png)
SMC2536W-AG2 User Guide
22
Chapter 4. Configuration for windows Vista
After the Adapter's driver has been installed, Windows Vista will display a wireless Network
Connection message like this one.
Figure 4-1
Icon means the connection has been established. Icon means there is no connection.
If the icon does not appear, please follow the steps below. If the icon still does not appear, the
driver may be installed incorrectly or the adapter is unplugged, please try again.
1. Right-click the icon in your system tray, then click Connect to a network .
Figure 4-2
2. The screen that appears (Figure 4-3) will show you many available wireless networks.
Highlight the network that you want, and then click Connect.
![](/img.php?id=990667&img=bg25.png)
SMC2536W-AG2 User Guide
23
Figure 4-3
3. When you choose to connect to a Security-enabled network, you will be asked to enter the
key or passphrase as shown in Figure 4-4.
Figure 4-4
4. After that, the installation will proceed as shown below (Figure 4-5), click Close.
![](/img.php?id=990667&img=bg26.png)
SMC2536W-AG2 User Guide
24
Figure 4-5
5. The screen below will appear if the connection is successful.
Figure 4-6
![](/img.php?id=990667&img=bg27.png)
SMC2536W-AG2 User Guide
25
Appendix A: Specifications
Normal
Interface 32-bit CardBus
Standards IEEE802.11a; IEEE802.11b; IEEE802.11g; IEEE802.11d;
IEEE802.11e; IEEE802.11h; IEEE802.11i and IEEE802.11j
Operating System Windows 2000, XP (32-bit) and Vista (32- and 64-bit)
Transmission Distance Indoor up to 100m, outdoor up to 300m (Standard transmission
distance, it is limited to the environment).
Radio Data Rate 54/48/36/24/18/12/9/6Mbps or 11/5.5/3/2/1Mbps
(Auto Rate Sensing)
Modulation 1M DBPSK; 2M DQPSK; 5.5M, 11M CCK; 6M, 9M, 12M, 18M,
24M, 36M, 48M, 54M OFDM;
Media Access Protocol CSMA/CA with ACK
Transmit Power 16dBm (Typical)
Data Security WPA/WPA2; 64/128/152-bit WEP; TKIP/AES
Frequency 2.4 ~ 2.4835GHz
5.150 ~ 5.850GHz
Spread Spectrum Direct Sequence Spread Spectrum (DSSS)
Power Consumption Typically 685mA in full Transmit (TX), 515mA in full Receive
(RX)
Safety & Emissions FCC, CE
Environmental and Physical
Operating Temp. 0~40Ԩ (32Ԭ~104Ԭ)
Storage Temp. -40– 70Ԩ (-40Ԭ~158Ԭ)
Humidity 10% - 90% RH, Non-condensing
Dimensions
(W×D×H)
4.5×2.1×.2 in. (115×54×5 mm)
![](/img.php?id=990667&img=bg28.png)
SMC2536W-AG2 User Guide
26
Appendix B: Glossary
¾ 802.11b - The 802.11b standard specifies a wireless product networking at 11 Mbps using
direct-sequence spread-spectrum (DSSS) technology and operating in the unlicensed radio
spectrum at 2.4GHz, and WEP encryption for security. 802.11b networks are also referred to
as Wi-Fi networks.
¾ 802.11g - specification for wireless networking at 54 Mbps using direct-sequence
spread-spectrum (DSSS) technology, using OFDM modulation and operating in the
unlicensed radio spectrum at 2.4GHz, and backward compatibility with IEEE 802.11b devices,
and WEP encryption for security.
¾ 802.11a - specification for wireless networking at 54 Mbps using OFDM modulation and
operating in radio band at 5GHz.
¾ Ad-hoc Network - An ad-hoc network is a group of computers, each with a wireless adapter,
connected as an independent 802.11 wireless LAN. Ad-hoc wireless computers operate on a
peer-to-peer basis, communicating directly with each other without the use of an access point.
Ad-hoc mode is also referred to as an Independent Basic Service Set (IBSS) or as
peer-to-peer mode, and is useful at a departmental scale or SOHO operation.
¾ DSSS (Direct-Sequence Spread Spectrum) - DSSS generates a redundant bit pattern for all
data transmitted. This bit pattern is called a chip (or chipping code). Even if one or more bits
in the chip are damaged during transmission, statistical techniques embedded in the receiver
can recover the original data without the need for retransmission. To an unintended receiver,
DSSS appears as low power wideband noise and is rejected (ignored) by most narrowband
receivers. However, to an intended receiver (i.e. another wireless LAN endpoint), the DSSS
signal is recognized as the only valid signal, and interference is inherently rejected (ignored).
¾ FHSS (Frequency Hopping Spread Spectrum) - FHSS continuously changes (hops) the
carrier frequency of a conventional carrier several times per second according to a
pseudo-random set of channels. Because a fixed frequency is not used, and only the
transmitter and receiver know the hop patterns, interception of FHSS is extremely difficult.
¾ Infrastructure Network - An infrastructure network is a group of computers or other devices,
each with a wireless adapter, connected as an 802.11 wireless LAN. In infrastructure mode,
the wireless devices communicate with each other and to a wired network by first going
through an access point. An infrastructure wireless network connected to a wired network is
referred to as a Basic Service Set (BSS). A set of two or more BSS in a single network is
referred to as an Extended Service Set (ESS). Infrastructure mode is useful at a corporation
scale, or when it is necessary to connect the wired and wireless networks.
¾ Spread Spectrum - Spread Spectrum technology is a wideband radio frequency technique
developed by the military for use in reliable, secure, mission-critical communications systems.
It is designed to trade off bandwidth efficiency for reliability, integrity, and security. In other
words, more bandwidth is consumed than in the case of narrowband transmission, but the
trade off produces a signal that is, in effect, louder and thus easier to detect, provided that the
![](/img.php?id=990667&img=bg29.png)
SMC2536W-AG2 User Guide
27
receiver knows the parameters of the spread-spectrum signal being broadcast. If a receiver is
not tuned to the right frequency, a spread-spectrum signal looks like background noise.
There are two main alternatives, Direct Sequence Spread Spectrum (DSSS) and Frequency
Hopping Spread Spectrum (FHSS).
¾ SSID - A Service Set Identification is a thirty-two character (maximum) alphanumeric key
identifying a wireless local area network. For the wireless devices in a network to
communicate with each other, all devices must be configured with the same SSID. This is
typically the configuration parameter for a wireless PC card. It corresponds to the ESSID in
the wireless Access Point and to the wireless network name. See also Wireless Network
Name and ESSID.
¾ WEP (Wired Equivalent Privacy) - A data privacy mechanism based on a 64-bit or 128-bit or
152-bit shared key algorithm, as described in the IEEE 802.11 standard.
¾ Wi-Fi - A trade name for the 802.11b wireless networking standard, given by the Wireless
Ethernet Compatibility Alliance (WECA, see http://www.wi-fi.net), an industry standards
group promoting interoperability among 802.11b devices.
¾ WLAN (Wireless Local Area Network) - A group of computers and associated devices
communicate with each other wirelessly, which network serving users are limited in a local
area.
¾ WPA (Wi-Fi Protected Access) - A wireless security protocol use TKIP (Temporal Key
Integrity Protocol) encryption, which can be used in conjunction with a RADIUS server.
Appendix C: Contact Information
For help with the Installation or operation of the SMC2536W-AG2 EliteConnect™ Dualband
Wireless Cardbus Adapter, please contact us.
http://www.smc.com
![](/img.php?id=990667&img=bg2a.png)
SMC2536W-AG2
