Beautiful Enterprise RKS100 Portable Bluetooth Sound System User Manual ETON Safety Card
Beautiful Enterprise Co., Ltd. Portable Bluetooth Sound System ETON Safety Card
User Manual
![](/img.php?id=1669104&img=bg1.png)
PLUGGING IN THE AC ADAPTER
PLAYING BACK VIA BLUETOOTH
PLAYING BACK VIA AUX
ELECTRICAL
OUTLET
DC JACK
Press the ON/OFF button to turn on the unit. The power indicator lights up.
Connect any device with headphone or line out jack with a 3.5mm line in cable
to AUX IN jack on the bottom of the unit.
1
Press the button to turn on the unit.
You can enjoy the sound from an external device such as a portable digital music player.
Be sure to turn off the power of the external device before making any connections.
For details, refer to the instruction manual of the device to be connected.
USB PORT FOR MOBILE DEVICE CHARGING (5V, 500mAh)
ADJUSTING THE VOLUME LEVEL
Connect one end of the USB cord to your device and the other end
to the USB jack of the unit.
1
Press the button to start charging for your device. Press the button again
to stop charging.
Note: Use the USB power cord that came with your device to connect to the unit.
2
The USB jack can be used to charge most devices that allow for USB charging
(including many mobile phones, smart phones and wireless headsets).
Press the and buttons to adjust the volume levels.
Note: During volume adjustments, if the LED indicator starts to blink,
minimum or maximum volume level has been reached.
BASS BOOST
Press the button to turn on bass boost. Press the button again to turn off.
AUTOMATIC ENERGY SAVING
If unit is idle for 10 minutes (no sound output or operation), the unit will turn off
automatically.
SWITCHING E INK DISPLAY BACKGROUND COLORS
Press and hold the for 5 seconds to toggle between black and white
backgrounds on the E Ink display.
CHARGING THE BUILT-IN BATTERY BY THE AC POWER/SOLAR ENERGY
The unit has a built-in Lithium ion battery for portable power when not using the AC
adapter. When the adapter is plugged in or the unit is exposed under the sunshine, the
unit will start charging. During charging, the indicator on the display starts blinking.
To fully charge an empty battery:
AC/DC: 3 hours
Solar: 6 hours
*Charge times may vary depending on solar conditions.
Note: To maximize battery life, charge the unit through AC for 12 hours
prior to first use.
Press the Bluetooth button to switch the sound source to Bluetooth mode.
The indicator appears on the display.
Connect one end of the AC adapter to the DC jack of the unit and
the other end to an electrical outlet.
Hold the button for 3 seconds to place the unit in pairing mode. The indicator starts
blinking rapidly. Unit will give off two short beeps.
Note: The indicator turns solid after the unit is successfully connected. If the indicator
turn to blink slowly after 3 minutes, the pair was unsuccessful.
Open the Bluetooth settings menu on your Bluetooth-enabled mobile device or
computer. Once it is recognized, “rukus solar” will appear on the display of the
Bluetooth-enabled device. Select “rukus solar” to pair and connect with your device.
Note: On an iPhone or iPad, tap “rukus solar” to select.
If prompted for a password, enter "1234”.
Once Bluetooth is connected, seclect the music and press button on your device.
The unit will playback music automatically.
Note: Playback time on built-in battery is ~8 hours, depending on music level
and other factors.
2
Press the button to switch the sound source to AUX mode,
if the unit is not in AUX mode.
3
Turn on your external device and press button.
4
The unit will play back the music from the external device automatically.
5
AUX
BASS
Portable Bluetooth Sound System
with Solar Panel
v030612
![](/img.php?id=1669104&img=bg2.png)
16 Mar 2012
Safety Information
WARNINGS:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
DO NOT REMOVE COVER or OPEN THE CABINET.
Dangerous high voltages are present inside the enclosure. No user serviceable parts inside. Leave all servicing to qualied
service personnel.
PORTABLE CART WARNING
(Symbol provided by RETAC)
Canada IC statments
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
FCC&IC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment
and meets the exemption from the routine evaluation limits in section 2.5 of RSS 102.
1. This Transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters from user and bystanders.
Note:This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determ ined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
Consult the dealer or an experienced radio TV technician for help.
By disposing of this product correctly, you will help to conserve natural resources and will help prevent
potential negative eects on the environment and human health that could otherwise be caused by
inappropriate waste handling of this product. For more information about collection point and
recycling of this product, please contact your local municipal oce, your household waste disposal
service or the shop where you purchased the product.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national
legislation.
[Other Countries outside the European Union]
If you wish to dispose of this product, please do so in accordance with applicable national legislation
or other rules in your country for the treatment of old electrical and electronic equipment.
CAUTION - Proper Installation
Install the system in a place which is level, dry and neither too hot nor too cold. The appropriate
temperature is between 5 oC and 35 oC.
Install the system in a location with adequate ventilation to prevent internal heat from building up
inside the unit.
Leave sucient distance between the system and TV.
Keep the system away from TV to avoid interference with TV.
CAUTION - Proper Ventilation
To avoid risk of electric shock and re, and to prevent damage, locate the apparatus as follows:
Front: No obstructions and open spacing.
Sides / Top / Back: No obstructions should be placed in the areas shown by the dimensions.
Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand
with a height of 10 cm (3-15/16") or more.
Front View: Side View:
15cm
(5- 15 /16 ") 15cm
(5- 15 /16 ")
15cm
(5- 15 /16 ")
15cm
(5- 15 /16 ")
15cm
(5- 15 /16 ")
10 cm (3- 15 /16 ")
Front side
Back side
QDID:
Information for Users on Disposal of Old Equipment
[European Union]
This symbol indicates that the electrical and electronic equipment should not
be disposed as general household waste at its end-of-life. Instead, the
product should be handed over to the applicable collection point for the
recycling in accordance with your national legislation. Attention:
This symbol is only valid in the
European Union.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding - type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong is provided for your safety. If the provided
plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket or table specied by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15. Apparatus shall not be exposed to dripping or splashing and no objects lled with liquids, shall
not be placed on the apparatus.
16. The mains plug is used as disconnect device and it shall remain readily operable during
intended use. In order to disconnect the mains plug from the mains completely, the mains plug
should be disconnected from the mains socket outlet completely.
17. The batteries (battery pack & batteries installed) shall not be exposed to excessive heat such as
sunshine, re or the like.
18. Do not place any naked ame sources, such as lighted candles, on the apparatus.
19. The battery used in this product must be properly recycled or disposed of. Please contact your
local recycling center for proper battery handling and disposal instructions.
For compatibility between the RK100/RKS100 system and another device with Bluetooth technology,
consult the device's documentation and dealer. In some countries, there may be restrictions on using
Bluetooth devices. Check with your local authorities.
Bluetooth is a registered trademark of Bluetooth SIG, Inc
WARNING! Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
WARNING! Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Please read rating label at the bottom of system for power input and other safety information.
FCC and IC Information:
This device complies with Part 15 of the FCC Rules and RSS-210 of the IC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
Warnings: The device meets the exemption from the routine evaluation limits in section 2.5 of RSS
102 and users can obtain Canadian information on RF exposure and compliance from the Canadian
Representative Burnport Holdings Ltd. 72MT Belcher Pls, East, Calgary, Alberta, T2Z 2G1, CANADA.
Tel: 403-257-4961
The lightning ash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sucient
magnitude to constitute a risk of electric shock to persons.
