BX-15ZBS Outdoor Bellbox
Introduction
BX-15ZBS is a ZigBee Outdoor Bellbox. It is capable of raising alarm upon receiving alarm signal from
the coordinator in the ZigBee network when an alarm is activated. During the alarm, the Bellbox will
sound alarm with its built-in siren and also flash the strobe light to attract attention.
The Bellbox utilizes ZigBee technology for wireless signal transmission. ZigBee is a wireless
communication protocol that is reliable and has low power consumption and high transmission efficiency.
Based on IEEE802.15.4 standard, ZigBee allows a large amount of devices to be included in a network
and coordinated for data exchange and signal transmission
The Bellbox serves as an end device in the ZigBee network. It can be included in the ZigBee network to
receive alarm signal, but cannot permit any other ZigBee device to join the network through the Bellbox.
Parts Identification
1. Mounting Holes x 4
2. Function Button
- Press the button once to send a supervision signal.
- Press and hold the button for 10 seconds then release to
reset the Bellbox.
3. Alarm Length Dip Switches
The Dip Switches contain 4 switches which can be set to
either ON or Off position
4. Tamper Switch
The Tamper switch will be activated when the Bellbox is
removed from mounted surface, or it cover opened.
5. Battery Compartment
The Bellbox is powered by four 1.5V D-cell alkaline
battery.
6. LED Strobe Light
The strobe light includes 3 LEDs (From left to right: LED1-> LED2->
LED3)
Refer to below table for LED and siren beep for status indication.
S
Si
ir
re
en
n
A
Au
ud
di
io
o
S
St
tr
ro
ob
be
e
l
li
ig
gh
ht
t
i
in
nd
di
ic
ca
at
ti
io
on
n
Lost connection to current network LED3 flashes every 20 minutes
Joining ZigBee Network LED3 flashes twice
Arm 1 beep All 3 LED flash once
Home 3 beeps All 3 LED flash once
Disarm 2 beep Sequentially flash for 1 cycle
Arm (Tamper Fault) 5 beeps All 3 LED flash 5 times
Home (Tamper Fault) 5 beeps All 3 LED flash 5 times
Disarm (Tamper Fault) 5 beeps Sequentially flash for 5 cycles
Arm (Low Battery) 3 beeps All 3 LED flash 3 times
Home (Low Battery) 3 beeps All 3 LED flash 3 times
Disarm (Low Battery) 3 beeps Sequentially flash for 3 cycles
Burglar / Emergency Alarm Continuous alarm sound All 3 LED flash continuously
Fire Alarm Alarm sound for 2 seconds,
followed by a stop of 1
second All 3 LED flash continuously
ON
OFF
![](/img.php?id=2554300&img=bg2.png)
2
Features
z
z
A
Al
la
ar
rm
m
A
Ac
ct
ti
iv
va
at
ti
io
on
n
When an alarm is activated, the Bellbox will activate its siren and strobe light according to different
alarm type:
z Burglar and Emergency alarm: Continuous alarm and strobe flash
z Fire alarm: 2-second alarm with1-second interval and continuous strobe flash
z
z
A
Al
la
ar
rm
m
L
Le
en
ng
gt
th
h
S
Se
et
tt
ti
in
ng
g
When the Bellbox receives an alarm signal via ZigBee network, it will activate siren and strobe
light according to the alarm length set by the system control panel.
If the Bellbox receives an alarm signal, but the alarm length duration is not defined by the system
control panel, the Bellbox will activate alarm according to Dip Switch setting below:
SW1 SW2 SW3 SW4 Siren Duration
ON OFF
OFF OFF 3 minutes
OFF ON OFF OFF 5 minutes
ON ON OFF OFF 10 minutes
z
z
B
Ba
at
tt
te
er
ry
y
a
an
nd
d
L
Lo
ow
w
B
Ba
at
tt
te
er
ry
y
D
De
et
te
ec
ct
ti
io
on
n
The Bellbox uses four 1.5V alkaline D-cell batteries as its power source. The battery is included in
the package. Open the battery compartment then insert the batteries to power up the Bellbox.
The Bellbox features Low Battery Detection function. When the battery voltage is low, the Bellbox
will transmit Low Battery signal to the coordinator in ZigBee network.
When changing battery, after removing the old battery, press the Tamper Switch twice to fully
discharge before inserting new battery
z
z
T
Ta
am
mp
pe
er
r
P
Pr
ro
ot
te
ec
ct
ti
io
on
n
The Bellbox is protected by a tamper switch which is compressed against the mounting surface
when mounted. Whenever the Bellbox is removed from mounted location, or its cover opened, the
tamper switch will be activated and the Bellbox will send a tamper open signal to remind the user of
the condition and activate an alarm immediately. The alarm length of tamper alarm is determined by
the Dip Switch setting above.
z
z
S
Su
up
pe
er
rv
vi
is
si
io
on
n
The Bellbox will transmit a supervision signal to report its condition regularly according to user
setting. The factory default interval is 30 minutes. The user can also press the Function Button
once to transmit a supervision signal manually.
ZigBee Network Setup
z
z
Z
Zi
ig
gB
Be
ee
e
D
De
ev
vi
ic
ce
e
G
Gu
ui
id
de
el
li
in
ne
e
ZigBee is a wireless communication protocol that is reliable and has low power consumption and
high transmission efficiency. Based on IEEE802.15.4 standard, ZigBee allows a large amount of
devices to be included in a network and coordinated for data exchange and signal transmission.
Due to the fundamental structure of ZigBee network, ZigBee device will actively seek and join
network after powering on. Since performing a task in connecting network may consume some
power, it is required to follow the instructions to avoid draining battery of a ZigBee device
- Ensure your ZigBee network router or coordinator is powered on before inserting battery into the
ZigBee device.
- Ensure the ZigBee network router or coordinator is powered on and within range while a ZigBee
device is in use.
- Do not remove a ZigBee device from the ZigBee network router or coordinator without removing
the battery from a ZigBee device.
z
z
J
Jo
oi
in
ni
in
ng
g
t
th
he
e
Z
Zi
ig
gB
Be
ee
e
N
Ne
et
tw
wo
or
rk
k
As a ZigBee device, the Bellbox needs to join a ZigBee network to send and receive alarm signal.
Please follow the steps bellow to join the Bellbox into the ZigBee network.
1. Insert the batteries.
2. Press and hold the function button for 10 seconds then release to join ZigBee network. Please
make sure to enable the permit-join feature on the router or coordinator of your ZigBee network
3. After joining the ZigBee network, the Bellbox will be registered in the security system in the
network automatically. Please check the security system control panel or CIE (Control and
Indicating Equipment) to confirm if joining and registration is successful.
![](/img.php?id=2554300&img=bg3.png)
3
4. After joining the ZigBee network, if the Bellbox loses connection with current ZigBee network,
the LED 3 will flash every 20 minutes to indicate the situation. Please check your ZigBee
network condition and Bellbox signal transmission range to correct the problem.
z
z
F
Fa
ac
ct
to
or
ry
y
R
Re
es
se
et
t
If you want to remove the Bellbox from current network and join a new network, you need to use
the Factory Reset function to clear the Bellbox for its stored setting and actively search for a
ZigBee network. To perform Factory Reset:
1. Press and hold the function button for 10 seconds, then release the button.
2. The Bellbox has been reset to factory default setting with all its previous network information
removed. It will now actively search for available ZigBee network again and join the network
automatically.
3. If the Bellbox successfully joins a ZigBee network, the LED3 will flash twice to indicate.
Installation
z
z
I
In
ns
st
ta
al
ll
la
at
ti
io
on
n
G
Gu
ui
id
de
el
li
in
ne
e
z The Bellbox is designed with a waterproof case to be mounted on external wall of you house.
z When mounting the Bellbox, mount as high as possible for its siren and strobe light to attract
attention when an alarm is activated.
z The Bellbox is designed to be mounted on a flat surface with fixing screws and plugs provided.
z The base has 4 mounting holes for you to screw the Bellbox onto the wall.
z
z
M
Mo
ou
un
nt
ti
in
ng
g
t
th
he
e
B
Be
el
ll
lb
bo
ox
x
1. Use the 4 mounting holes as template, drill holes on the wall.
2. Insert the wall plugs if fixing it into plaster or brick.
3. Screw the base into the wall plugs. Make sure the tamper switch is properly depressed
against the wall surface.
4. Screw the cover back onto its base.
z
z
U
Us
si
in
ng
g
B
Be
el
ll
lb
bo
ox
x
w
wi
it
th
h
Z
Zi
ig
gB
Be
ee
e
R
Ro
ou
ut
te
er
r
IMPORTANT NOTE
If the Bellbox installation location is away from your system control panel and requires ZigBee
routers to improve signal strength. DO NOT use a ZigBee Router without backup battery. A ZigBee
router without battery will be powered down during AC power failure and the Bellbox connected to
the router will lose connection with ZigBee network. You should plan your Bellbox installation
location using only ZigBee router with backup battery.
Appendix
(The Appendix information is for developers only.)
z
z
B
Be
el
ll
lb
bo
ox
x
C
Cl
lu
us
st
te
er
r
I
ID
D
Device ID: IAS Warning Device: 0x0403
Endpoint: 0x01
Server Side Client Side
Mandatory
Basic (0x0000) None
Identify(0x0003)
IAS Zone(0x0500)
IAS WD(0x0502)
Optional
None None
z
z
A
At
tt
tr
ri
ib
bu
ut
te
e
o
of
f
B
Ba
as
si
ic
c
C
Cl
lu
us
st
te
er
r
I
In
nf
fo
or
rm
ma
at
ti
io
on
n
Identifier Name Type Range Access Default
Mandatory
/ Optional
0x0000 ZCLVersion Unsigned
8-bit
integer 0x00 –0xff Read
only 0x01 M
0x0001 ApplicationVersion Unsigned 0x00 – Read 0x00 O
