Remote Controller (RC-16-F1)
The Remote Controller is used to arm the system in home or away mode, disarm the system and send a panic signal.
z
z
I
Id
de
en
nt
ti
if
fy
yi
in
ng
g
t
th
he
e
p
pa
ar
rt
ts
s
1. Away Arm Buttom
Press the button to arm the system in Away Arm mode.
2. Disarm Buttom
Press the button to disarm the system. When an alarm is activated,
press the button to stop the alarm.
3. Home Arm Buttom
Press the button to arm the system in Home Arm mode.
4. Panic Buttom
Press and hold the button for 3 seconds to activate a Panic alarm.
<
<N
NO
OT
TE
E>
>
) Panic alarm cannot be stopped after activation by pressing
disarm button on Remote Controller.
5. LED Indicator
The LED will flash when the Remote Control is transmitting radio
signal.
z
z
B
Ba
at
tt
te
er
ry
y
The Remote Controller uses one CR2032 3V mAh Lithium battery as its power source. When low battery voltage is detected, a
low battery signal will be sent to the Control Panel along with regular signal transmission to notify the Control Panel.
Insert the battery according to instruction below:
1. Separate the Remote Controller casing from the middle to reveal the battery compartment. (Figure 1)
2. Insert the battery into battery compartment, with the positive side facing the logo on the back, (Figure 2)
3. Replace the casing. (Figure 3)
Figure 1 Figure 2 Figure 3
<
<N
NO
OT
TE
E>
>
) When changing battery, after removing the old battery, press any button twice to fully discharge before inserting
new battery.
) When a low voltage battery is inserted, the LED will flash 3 times to indicate low battery.
z
z
G
Ge
et
tt
ti
in
ng
g
S
St
ta
ar
rt
te
ed
d
z Insert the battery according to instruction.
z Put the Control Panel into learning mode, refer to Control Panel manual for detail.
z Press any buttons on the Remote Controller.
z If the Control Panel receives the Remote Controller signal successfully, it will display the information accordingly.
z Please refer to your Control Panel manual to complete the learning process
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
