Collage Investments LK-101 Likuid GSM Mobile Phone User Manual
Collage Investments LLC. Likuid GSM Mobile Phone
User Manual
![](/img.php?id=1967607&img=bg1.png)
-1-
User manual
LK-101
Content
1 General Information ................................................................................................................................................. 3
1.1 Profile .............................................................................................................................................................. 3
1.2 Safety Information ........................................................................................................................................... 3
1.3 Safety warning and Attentions......................................................................................................................... 3
2 Your phone ................................................................................................................................................................. 5
2.1 Phone overview ............................................................................................................................................... 5
2.2 Functions of Keys ............................................................................................................................................ 5
2.3 Technical specifications................................................................................................................................... 6
3 Getting started ........................................................................................................................................................... 6
3.1 Installing the SIM Cards and the Battery ........................................................................................................ 6
3.2 Installing memory card .................................................................................................................................... 8
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg2.png)
-2-
3.3 Charging the Battery........................................................................................................................................ 8
3.4 Powering On/Off the Mobile Phone .............................................................................................................. 10
3.5 Linking to the Network ................................................................................................................................. 10
3.6 Dialing Calls .................................................................................................................................................. 10
3.7 Using the Headset .......................................................................................................................................... 11
4 Input method ........................................................................................................................................................... 11
4.1 Icons for Input Methods ................................................................................................................................ 12
4.2 To Shift Entry Methods ................................................................................................................................. 12
4.3 Numeric Input ............................................................................................................................................... 12
4.4 English input and numeric input: .................................................................................................................. 12
4.5 Inserting a Symbol......................................................................................................................................... 13
5 Using the Menus ...................................................................................................................................................... 13
5.1 Message ......................................................................................................................................................... 13
5.2 Phonebook ..................................................................................................................................................... 14
5.3 User profiles .................................................................................................................................................. 14
5.4 Call center ..................................................................................................................................................... 22
5.5 Multimedia .................................................................................................................................................... 25
5.6 Settings .......................................................................................................................................................... 18
5.7 Tools .............................................................................................................................................................. 19
5.8 Services .......................................................................................................................................................... 19
5.9 Cherry Zone ................................................................................................................................................... 19
6 Appendix .................................................................................................................................................................. 30
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg3.png)
-3-
1 General Information
1.1 Profile
Please read this pamphlet carefully in order to make your phone in perfect condition.
Perfectly combining humanized design and fine art, this mobile phone provides a streamlined outlook, comfortable hand-feeling,
pleasant sounds and MP3 player which bring convenience and fun to your work.
Our company may change this mobile phone without prior written notice and reserves the final right to interpret the performance
of this mobile phone.
Due to different software and network operators, display on your phone may be different, refer to your phone for details.
1.2 Safety Information
If your phone has lost or been stolen, notify the telecommunication office the SIM card is disabled (network support is
required). This can avoid economic loss caused by unauthorized use.
Please take measures as following to avoid your phone being unauthorized use:
· Set PIN code of SIM card
· Set phone password
1.3 Safety warning and Attentions
Safety warning
Ø ROAD SAFETY COMES FIRST
Do not use a hand-held phone while driving. Use hands-free fittings when calls are unavoidable while driving. In some countries,
dialing or receiving calls while driving is illegal!
Ø SWITCH OFF IN AIRCRAFT
Wireless devices can cause interference in aircraft. Using a mobile phone in flight is illegal and risky.
Please make sure that your mobile phone is powered off in flight.
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg4.png)
-4-
Ø SWITCH OFF BEFORE ENTERING RISKY AREAS
Strictly observe the relevant laws, codes, and regulations on the use of mobile phones in risky areas. Turn off your mobile phone
before entering a place susceptible to explosion, such as an oil station, oil tank, chemical plant or a place where a blasting process is
under way.
Ø OBSERVE ALL SPECIAL REGULATIONS
Follow any special regulations in force in any area such as hospitals and always switch off your phone whenever it is forbidden to
use it or, when it may cause interference or danger. Properly use your mobile phone near medical apparatuses, such as pacemakers,
hearing aids and some other electronic medical devices, as it may cause interference to such apparatuses.
Ø INTERFERENCE
The conversation quality of any mobile phone may be affected by radio interference. An antenna is built inside the mobile phone and
located below the microphone. Do not touch the antenna area during a conversation, lest that the conversation quality deteriorate.
Ø QUALIFIED SERVICE
Only qualified personnel may install or repair phone equipment. Installing or repairing the mobile phone on your own may bring
great danger and violates the warranty rules.
Ø ACCESSORIES AND BATTERIES
Use only approved accessories and batteries.
Ø USE SENSIBLY
Use only in a normal and proper manner.
Ø EMERGENCY CALLS
Ensure the phone is switched on and in service, enter the emergency number, e.g. 112, then press the Dial key. Give your location
and state your situation briefly. Do not end the call until told to do so.
Note: Just like all other mobile phones, this mobile phone does not necessarily support all the features described in this manual due
to network or radio transmission problems. Some networks even do not support the emergency call service. Therefore, do not rely
solely on the mobile phone for critical communications such as first aid. Please consult the local network operator.
Precautions
This mobile phone is well designed with fine art. Please exercise special care when using it. The following suggestions will help
your mobile phone survive the warranty period and extend its service life:
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg5.png)
-5-
Ø Keep the mobile phone and all its fittings beyond children's reach.
Ø Keep the mobile phone dry. Keep away from rain, moisture, liquid or other substances that may corrode electronic circuits.
Ø Do not use or store the mobile phone in dusty places, lest that active parts of the mobile phone be damaged.
Ø Do not store the mobile phone in a high-temperature place. High temperature will shorten the life of electronic circuits and damage
the battery and some plastic parts.
Ø Do not store the mobile phone in a chilly place. Otherwise, moistures will be formed inside the mobile phone to damage electronic
circuits when the mobile phone is moved to a constant temperature place.
Ø Do not throw, knock or shock the mobile phone, as that will destroy the internal circuits and high-precision components of the
mobile phone.
2 Your phone
2.1 Phone overview
2.2 Functions of Keys
The mobile phone provides the following keys:
u Left and right soft key
The bottom line on the screen displays the functions of the Left and Right soft key.
u Dial key
Press it to originate a call by entering the called number or selecting a contact from the phonebook; or press it to receive an
incoming call; or press it in standby state to show the latest call records
u End key
Press it to end a call being dialed or end an ongoing call; or press it to exit the menu and return to the standby state; or hold it for
two or three seconds to power on or off the mobile phone.
u Direction key
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg6.png)
-6-
Press them to scroll the options when browsing a function list. In edit state, press direction keys to navigate. In standby state,
press a direction key to enter the specified function page. You can also customize direction keys to match the desired functions.
u OK key
Press it to confirm your selection. In standby interface, pressing it can enter the main menu, long press it can turn on/off the
flashlight which situates at the top of the phone.
u Number keys, * key and # key
Press number keys 0 through 9 to input or edit state to input numbers and characters;
The # key and the * key represent different functions in different states or different function menus.
Hold the # key up to 2s in standby state to switch between silent, meeting and normal mode.
Press the # key in edit state to switch between input methods.
In idle screen, you can press left soft key then * key to lock keypad. When the keypad is locked, you can press left soft key
then * key to unlock it.
Press the * key twice to input "+" in standby interface. "+" are used for dialing an international call.
2.3 Technical specifications
Phone
Dimensions (W45.25×D111.20×H13.30):
Rated capacity: 600mAh
Continuous standby duration: (Relates to network status)
Continuous conversation duration: (Relates to network status)
Please refer to their labels for other data related to the battery and the charger.
3 Getting started
3.1 Installing the SIM Cards and the Battery
An SIM card carries useful information, including your mobile phone number, PIN (Personal Identification Number), PIN2,
PUK (PIN Unlocking Key), PUK2 (PIN2 Unlocking Key), IMSI (International Mobile Subscriber Identity), network information,
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg7.png)
-7-
contacts data, and short messages data.
Note:
After powering off your mobile phone, wait for a few seconds before removing or inserting an SIM card.
Exercise caution when operating an SIM card, as friction or bending will damage the SIM card.
Properly keep the mobile phone and its fittings such as the SIM cards beyond children's reach.
Installation
u Hold the End key for a while to power off the mobile phone
u Push the back cover above the battery downward and remove it.
u Take the battery away.
u Insert the SIM card into the SIM card slot lightly with the corner cutting of the card aligning to the notch of the slot and the
gold plate of the card facing download, till the SIM card cannot be further pushed in.
u Aim the positive pole and negative pole of the battery at the battery connector of the mobile phone, and press the left of the
battery to install the battery into the battery tank.
Using code
The mobile phone and the SIM cards support sorts of passwords, in order to prevent the phone and the SIM cards from being
misused. When you are prompted to input any of the codes mentioned below, just input the correct code and then press the OK key.
If you input a wrong code, press the Right soft key to clear it and then input the correct code.
u Phone lock code
The phone lock code may be set to prevent your mobile phone from being misused. In general, this code is provided along with
the mobile phone by the manufacturer. The initial phone lock code is set to 0000 by the manufacturer. If the phone lock code is set,
you need to input the phone lock code when powering on the mobile phone.
u PIN
The PIN (Personal identification number, 4 to 8 digits) code prevents your SIM card from being used by unauthorized people. In
general, the PIN is supplied with SIM card by the network operator. If PIN check is enabled, you need to input the PIN each time
when you power on your mobile phone. The SIM card will be locked if you input wrong PIN code for three times.
Unlocking methods as follows:
-Input the correct PUK according to the screen tips to unlock the SIM card.
-Then input the new PIN and press the OK key.
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg8.png)
-8-
-Input the new PIN again and then press the OK key.
-If the input PUK is correct, the SIM card will be unlocked and the PIN will be reset.
Note: The SIM card will be locked if you input wrong PIN code for three times. To unlock the SIM card, you need to input the
PUK. In general, the PUK can be obtained from the network operator.
u PUK
The PUK code (Personal Unlocking Key, 8digits) is required to change a blocked PIN. It is supplied with SIM card. If not,
contact your network operator. If you input wrong PUK code for 10 times, SIM card will be invalid. Please contact the network
operator to replace the SIM card.
u Barring code
A barring code is required for setting the call barring function. You can obtain this code from the network operator to set the call
barring function.
3.2 Installing memory card
The memory card is a pluggable mobile storage card inside the mobile phone.
To install the memory card, open its latch, place its indented side downward, insert the card into the card slot, and then close the
latch.
To remove the memory card, open its latch and slightly press the card inward. The card will automatically pop out. Close the
latch.
Note:
1. The mobile phone cannot automatically identify the memory card being inserted when the mobile phone is powered on. You must
power off the mobile phone and then power it on, so that the phone can identify the Memory card.
2. The memory card is a miniature object. Keep it out of the reach of children for fear that children swallow it!
3.3 Charging the Battery
The lithium battery delivered with the mobile phone can be put into use immediately after being unpacked. A new battery will
have maximum performance after the first three full charge/discharge cycles.
Battery level indication:
u Your mobile phone can monitor and display the battery state.
u Normally the remaining energy of the battery is indicated by the battery level icon at the upper right corner of the display
screen.
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg9.png)
-9-
u When the battery energy is insufficient, the mobile phone prompts "Battery low". If you have set an alert tone, an alert tone
will be given off when the battery level is too low.
u A charging animation appears when the battery is being charged. When the charging is complete, the animation disappears.
Using a travel adapter:
u Install the battery into the mobile phone before charging the battery.
u Connect the adapter of the travel charger with the charging slot in the mobile phone. Ensure that the adapter is fully inserted.
u Insert the plug of the travel charger to an appropriate power outlet.
u During the charging, the battery level grids in the battery icon keep flickering till the battery is fully charged.
u It is normal when the battery is become hot during the charging period.
u The battery icon does no longer flicker when the charging process ends.
Note:
Ensure that the plug of the charger, the plug of the earphone, and the plug of the USB cable are inserted in the right direction.
Inserting them in a wrong direction may cause charging failure or other problems.
Before the charging, ensure that the standard voltage and frequency of the local mains supply match the rated voltage and power of
the travel charger.
Using the Battery
The performance of a battery is subject to multiple factors: radio network configuration, signal strength, ambient temperature,
chosen functions or settings, phone fittings, and the voice, data or other application mode you choose to use.
To guarantee the optimal performance of your battery, please stick to the following rules:
u Use only the battery provided by the vendor. Otherwise, damages or even injuries could be caused during the charging.
u Power off the mobile phone before removing the battery.
u The charging process lasts a longer time for a new battery or a battery not in use for long. If the battery voltage is too low to
enable the mobile phone to be powered on, charge the battery for a longer time. In this case, the battery icon does not flicker
until a long time after the battery enters the charge status.
u During the charging, ensure the battery is placed in a room temperature environment or in an environment close to room
temperature.
u Immediately stop using the battery if the battery produces odor, overheats, cracks, distorts or has other damage, or if the
electrolyte leaks.
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bga.png)
-10-
u The battery wears out with use. A longer charging time is required as the battery is put into use for a long time. If the total
conversation duration decreases but the charging time increases even though the battery is properly charged, purchase a
standard battery from the OEM or use a battery approved by our company. Using any poor-quality fittings will cause harm to
your mobile phone or even incur danger!
Note: To guarantee your personal safety and protect the environment, do not litter the battery! Return the old battery to the mobile
phone manufacturer or place it in specified battery reclamation areas. Do not litter any battery with other rubbish.
Warning: Short-circuits of the battery may cause explosion, fire, personal injury or other severe consequences!
3.4 Powering On/Off the Mobile Phone
Hold the End key for a while to power on the mobile phone. A power-on animation appears on the display screen.
Input the phone lock code and press the OK key if the mobile phone prompts you to input the phone lock code. The original code is
0000.
Input the PIN and press the OK key if the mobile phone prompts you to input the PIN. The PIN is provided by the network operator
for new opening SIM card.
Enter the standby interface.
To power off the mobile phone, hold the End key for a while.
3.5 Linking to the Network
After the SIM card and the mobile phone are successfully unlocked, the mobile phone automatically searches for an available
network. After finding a network, the mobile phone enters the standby state. When the mobile phone is registered in the network, the
name of the network operator is displayed on the screen. Then you can dial or receive a call.
3.6 Dialing Calls
In the standby interface, press number keys to input the area code and the telephone number, and then press the Dial key to dial a
call. To end the call, press the End key.
u Dialing an international call
Press the * key twice and input "+". Then input the country code, the area code and the telephone number. Finally, press the
Dial key.
u Dialing a call to a number in the phonebook
Enter the phonebook and use the up and/or down direction keys to find the telephone number you want to call.
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bgb.png)
-11-
Press the Dial key. The mobile phone automatically dials the chosen telephone number.
u Redialing the last number
In the standby interface, press the dial key to show the dialed calls.
Press the up and/or down direction keys to select a number you want to dial and then press the Dial key.
u Adapting volume
During a conversation, you can press the Up and/or Down direction keys to tune the sound volume.
u Answering incoming calls
Press the Dial key or the Left soft key to answer an incoming call.
Press the End key to end the current conversation.
To reject an incoming call, press the End key or the Right soft key.
Note: If the caller can be identified, the mobile phone will present the calling number. If the calling number exists in the phonebook,
the mobile phone will present both the name and the phone number of the caller. If the caller cannot be identified, the mobile phone
will present the calling number only. You can answer an incoming call when using a function list or browsing the phonebook.
u Using options during a conversation
Select Menu during a conversation to turn on hands-free, switch and start recording, etc. For details, refer to the menu guide.
3.7 Using the Headset
It would enter headset mode automatically when you insert headset to the slot. Make sure of inserting it at the bottom of the slot,
or you can’t use it normally.
4 Input method
This mobile phone provides multiple input methods, including smart English input, English input and numeric input. You can
use these input methods when editing the phonebook, short messages, files and greeting text.
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bgc.png)
-12-
4.1 Icons for Input Methods
After you enter an edit window such as a window for editing the phonebook, short messages or the memorandum, an icon is
displayed to indicate the current input method:
Numeric input:“123”
English input:“ ABC, abc”
Smart English input: “ES, es”
4.2 To Shift Entry Methods
Press the # key to switch between input methods.
4.3 Numeric Input
You can input numbers with the numeric input method. Press a number key to input the corresponding number.
4.4 English input and numeric input:
The keyboards for English input and numeric input are defined in the following table:
Key Character or Function Remarks
Number key 1 . , - ? ! ’@ : /_ 1
Number key 2 ABCabc2
Number key 3 DEFdef3
Number key 4 GHIghi4
Number key 5 JKLjkl5
Number key 6 MNOmno6
Number key 7 PQRSpqrs7
Number key 8 TUVtuv8
Number key 9 WXYZwxyz9
Number key 0 0
# key Press it to switch between input methods
Left direction
key
Press it to move to the left
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bgd.png)
-13-
Right direction
key
Press it to move to the right
Left soft key Equivalent to OK or Options
Right soft key Equivalent to Back or Delete
End key Press it to return to the standby interface
English input:
n Each key is used to represent multiple characters. Quickly and continuously press a key till the character you want
appears. Input the next character after the cursor moves.
n Press the # key to switch between input methods
n To input a blank, switch to the English input mode (in upper or lower case) and then press number key 0.
n To clear wrong inputs, press the Right soft key.
4.5 Inserting a Symbol
Press the number key 1 to enter a symbol you want.
5 Using the Menus
5.1 Message
If the short message memory is full, a blinking message icon appears on the top of the screen. To normally receive short
messages, you need to delete some of the existing short messages.
Write message
Through this function, you can create a new text message. You can type a message, and you're also able to insert a pre-defined
message from “Templates”.
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bge.png)
-14-
Inbox
Received messages are listed in this menu.
Outbox
Messages sent failed are stored in this item.
Drafts
Draft messages are listed in this item.
Sent box
The messages which are sent successfully are stored in this menu.
5.2 Phonebook
The mobile phone can store up to 100 telephone numbers. The telephone numbers that an SIM card can store depends on the
storage capacity of the SIM card. The telephone numbers stored in the mobile phone and in the SIM cards form a phonebook.
The phonebook search function enables you to view contacts. You can search a contact as required from the phonebook. Select
this option, in the search interface, input the name of the contact you want to search or the first letter(s) of the name. All the contacts
meeting the search condition are listed. Press the Up and Down direction keys to browse the contacts and select contact. Press left or
right direction key to view other groups: Unclassified, family, business, classmates, blacklist and so on.
5.3 User profiles
The mobile phone provides multiple user profiles, so that you can customize some settings to adapt to the specific events and
environments.
Customize the user profiles according to your preference and then activate the user profiles. The user profiles fall into five
scenarios: General, Silent, Meeting, Indoor and Earphone.
Select Options and you can perform the following operations: Activate, Customize and Rename.
Activate
Select Activate to activate the selected mode.
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bgf.png)
-15-
Customize
u Ring settings: Set call ring and message ring.
u Adjust volume: Set the volume of the caller ringtone, message ringtone, call, alarm & calendar ringtone and power ringtone.
u Call alert: Select ringtone, vibrate, silent, ring and vibrate, or vibrate then ring mode.
u Message alert: Select ringtone, vibrate, silent or ring and vibrate.
u Alarm & calendar remind: Select ring, vibrate, silent or ring and vibrate.
u Key tone: Silent, Ringtone1 and Ringtone2 are available. Users can select one of them as needed.
u Battery low alert: Activate or deactivate this function as needed.
u Power ringtone: Activate or deactivate this function as needed.
Rename
Select Rename to rename the selected profile.
5.4 Call center
n Call logs
Dialed calls
You can view the latest dialed calls. Choose Dialed calls and then select a dialed call to call, delete or delete all (or send SMS
to it) etc.
Received calls
You can view the latest received calls. Choose Received calls and then select a received call to call, delete or delete all (or send
SMS to it) etc.
Missed calls
You can view a list of the latest missed calls.
Note: When the mobile phone indicates that some calls are missed, you can select Details to enter the missed calls list.
Navigate to a missed call and then press the Dial key to dial the number that originated that call.
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg10.png)
-16-
Rejected calls
You can view a list of the latest rejected calls.
Delete all
You can delete the latest call records. Choose Delete all and confirm to delete all the numbers in the call history.
Call timers
Choose Call timers to view the last call time, the total time of all dialed calls, the total time of all received calls and the total
time of call history, and/or to reset all the time.
n Call settings
u Network selection: Set Network selection mode to Auto select or Manual select. Auto select is recommended. When Network
selection mode is set to Auto select, the mobile phone will prefer the network where the SIM card is registered. When Network
selection mode is set to Manual select, you need to select the network operator's network where the SIM card is registered.
u Call divert: This network function enables you to forward incoming calls to another number you have previously specified.
u Call barred: The call barred function enables you to bar calls as needed.
u Call waiting: After you choose Activate, the mobile phone will contact the network. A moment later, the network will make a
response and send a message to acknowledge your operation. If the call waiting function is activated, the network will alert you
and the mobile phone screen will display the incoming call number if others are calling you while you are already in a
conversation.
u Hide ID: When you call someone, he or she can’t find out your number if you enable this function.
u Select line: Switch to Line 1 or Line 2. By default, Line 1 is used.
u Flight mode: When this function is engaged, it will suspend many signal transmitting functions of some devices – thereby
disabling the device's capacity to place or receive calls or text messages– while still permitting use of other functions that do not
require signal transmission (e.g., games, built-in camera, MP3 player.)
u Others: It includes 50 secs warning, vibration when connected, answer/reject mode and auto redial.
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg11.png)
-17-
5.5 Multimedia
Camera
The phone is provided with a camera, which supports the photographing functions. Roll the phone to align the camera to the
picture and then press OK key to capture photos. Pictures will be saved in the file system of the phone or the memory card. You can
change the image/camera settings, by accessing the options after entering the camera mode.
Video recorder
Use this function to record video files. Press OK key to start/pause recording, press left soft key to stop.
Video player
Use this function to play video files. By pressing the corresponding key can you control the playing process of video player:
play/pause(up direction key, stop(down direction key) switch to last video/next video (press left or right direction key), fast
forward (press and hold right direction key) and rewind (press and hold left direction key). In video player interface, you can press *
or # key to tune volume, number key 2 to switch to full screen play.
Image browser
Use this function to view photo.
Audio player
Use this function to play video files. By pressing the corresponding key can you control the playing process of video player:
play/pause(up direction key, stop(down direction key) switch to last video/next video (press left or right direction key), fast
forward (press and hold right direction key) and rewind (press and hold left direction key). In video player interface, you can press *
or # key to tune volume.
Recorder
Use this function to record audio files. The phone support WAV. The recording file you stopped would be stored in record file
list automatically.
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg12.png)
-18-
FM radio
You can use the application as a traditional FM radio. You need to insert headset into its corresponding slot before using this
function.
5.6 Settings
Dual-SIM
Access this item to perform following operations: Standby mode, Reply by original SIM and Set SIM name.
Phone settings
u Time & date: Set time, date, time format and date display type.
u Select language: Select the display language for the mobile phone.
u Shortcut settings: Customize the shortcut functions of the Up, Down, Left, and Right direction keys. In the standby interface,
you can press a direction key to directly enter the function menu corresponding to that direction key.
u Auto power on/off: Set the time when the mobile phone will be automatically powered on or off.
Alert: Before entering an area where the use of mobile phones is forbidden, make sure that the scheduled power-on function is
deactivated to avoid accidents.
u Power management: Show the remaining battery level.
Display settings
Users can access this item to set wallpaper, backlight, animation effect, etc.
Security settings
PIN: The PIN (Personal identification number, 4 to 8 digits) code prevents your SIM card from being used by unauthorized
people. In general, the PIN is supplied with SIM card by the network operator. If PIN check is enabled, you need to input the PIN
each time when you power on your mobile phone. The SIM card will be locked if you input wrong PIN code for three times
PIN2: The PIN2 code (4 to 8 digits), supplied with SIM card, is required to access some functions such as “call costs setup”
and “fixed dialing setup”. Please contact the network operator to verify whether your SIM card supports these functions. If you input
wrong PIN2 for three times, the PIN2 will be locked.
Privacy: The initial password is 0000. After accessing this function, you can select some items. Once an item is selected, you
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg13.png)
-19-
need to input correct password whenever you want to enter this item to perform further operations.
Auto keypad lock: The function enables you to lock/unlock the keypad. Set the auto locking time, 5s, 15s, 30s, 1min and
5mins are available.
Lock screen by end-key: Users can activate/deactivate this function as needed.
Power-on password: Once this function is activated, password is required when powering on the phone.
Restore factory settings
Use this function to restore factory settings. The initial password is 0000.
5.7 Tools
Alarm
Three alarm clocks are set but deactivated by default. You can activate one, multiple or all of them as needed. For each alarm
clock, the ringing date and the ringing time can be set.
Bluetooth
With Bluetooth, you can make a wireless connection to other compatible devices, such as mobile phones, computers, headsets
and car kits. You can use the Bluetooth to send images, video clips, music, sound clips and notes, and transfer files from your
compatible pc.
Calendar
Once you enter this menu, there is a monthly-view calendar for you to keep track of important appointments, etc. Days with
events entered will be marked.
Calculator
The calculator can add, subtract, multiply and divide. To use the calculator:
u Press the up, down, left, right and OK key to select +, -, ×, ÷ and = respectively.
u Press right soft key to delete the figure.
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg14.png)
-20-
Flashlight
You can long press key 0K in idle screen to turn on/off the flashlight which situates at the top of the phone.
File manager
The phone supports the memory card. The capacity of the memory card is selectable. You can use the file manager to
conveniently manage various directories and files on the memory card.
Choose File management to enter the root directory of the memory. The root directory will list the default folders, new folders
and user files. When the mobile phone is powered on for the first time or when you have not changed the directory, the root directory
contains the default folders only..
5.8 Games
Sokoban
A game named sokoban is embedded in the phone. For specific operation, please refer to ‘help’ option the game.
6 Appendix
Appendix 1:Troubleshooting
If you find exceptions when operating the mobile phone, restore the factory settings and then refer to the following table to solve the
problem. If the problem persists, contact the distributor or service provider.
Fault Cause
Solution
SIM card error
The SIM card
is damaged. Contact your network service provider
The SIM card
is not in
position.
Check the SIM card
The metal
face of the
SIM card is
polluted.
Clean the SIM card with a clean cloth
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg15.png)
-21-
Poor received
signal quality
Signals are
obstructed.
For instance,
radio waves
cannot be
effectively
transmitted
nearby a high
building or in
a basement.
Move to a place where signals can be effectively transmitted
Line
congestions
occur when
you use the
mobile phone
in high-traffic
hours
Avoid using the mobile phone in high-traffic hours
The mobile
phone cannot
be powered on
The battery
energy is
exhausted.
Charge the battery
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg16.png)
-22-
Calls cannot be
dialed
Call barring is
activated Cancel call barring
The mobile
phone cannot
connect the
network
The SIM card
is invalid Contact your network service provider
The mobile
phone is not
in a service
area of the
GSM network
Move to the network operator's service area
The signal is
weak Move to a place where the signal quality is high
The battery
cannot be
charged
The charging
voltage does
not match the
voltage range
indicated on
the charger
Ensure the charging voltage matches the voltage range
indicated on the charger
An improper
charger is
used
Use the charger specially designed for the mobile phone
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg17.png)
-23-
Poor contact Ensure the charger plug is in good contact with the mobile
phone
FCC Caution.
§ 15.19 Labelling requirements.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
§ 15.21 Information to user.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Specific Absorption Rate (SAR) information:
PDF pdfFactory Pro www.fineprint.cn
![](/img.php?id=1967607&img=bg18.png)
-24-
This GSM Mobile Phone meets the government's requirements for exposure to radio waves. The guidelines are based on standards
that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health.
FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device
types: LK-101 (FCC ID: GAO-LK-101) has also been tested against this SAR limit. The highest SAR value reported under this
standard during product certification for use at the ear is 0.76W/kg and when properly worn on the body is 0.60W/kg. This device
was tested for typical body-worn operations with the back of the handset kept 1.5cm from the body. To maintain compliance with
FCC RF exposure requirements, use accessories that maintain a 1.5cm separation distance between the user's body and the back of
the handset. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of
accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided.
Body-worn Operation
This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance
of 1.5 cm must be maintained between the user’s body and the handset, including the antenna. Third-party belt-clips, holsters, and
similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these
requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna.
PDF pdfFactory Pro www.fineprint.cn
