Dynamics HYDRO Quad-Band GSM Mobile Phone with BT User Manual
Dynamics Hong Kong Limited Quad-Band GSM Mobile Phone with BT Users Manual
Dynamics >
Users Manual
User Manual
GSM Mobile Phone
Brand Name: Ice Mobile
Model Name: Hydro
FCC ID: C89-HYDRO
![](/img.php?id=2060131&img=bg2.png)
1
CONTENTS
Remarks: ______________________________________________________________ 2
1. Introductions __________________________________________________________ 2
1.1 INFORMATIONS: ___________________________________________________ 2
2. Before using ___________________________________________________________ 2
2.1 Keys description ___________________________________________________ 2
2.2 Functions of keys __________________________________________________ 3
2.3 Battery __________________________________________________________ 4
2.4 Installing the SIM Cards and the Battery ________________________________ 4
2.5 Charging the battery _______________________________________________ 4
2.6 Connecting to the network __________________________________________ 4
2.6.1 SIM card____________________________________________________ 4
2.6.2 Unlocking the SIM card ________________________________________ 4
2.6.3 Making and receiving calls _____________________________________ 5
3. FUNCTION MENU _______________________________________________________ 5
3.1 Powering your phone on/off _________________________________________ 5
3.3 Locking and Unlocking the Keypad ____________________________________ 5
3.4 Text Input ________________________________________________________ 5
3.5 Adding contact to the Phonebook _____________________________________ 5
3.6 Making and receiving calls ___________________________________________ 6
3.7 Sending and receiving messages ______________________________________ 6
3.8 Profiles __________________________________________________________ 6
3.9 Call center ________________________________________________________ 6
3.10 Setting your phone ________________________________________________ 6
3.11 How to take a photo ______________________________________________ 7
3.12 How to play music ________________________________________________ 7
3.13 How to use FM radio ______________________________________________ 7
3.14 Using Services ____________________________________________________ 7
![](/img.php?id=2060131&img=bg3.png)
2
Remarks:
It is a floatable phone and not 100% waterproof. So please avoid bring in the
water.
1. Introductions
1.1 INFORMATIONS:
Thank you for choosing our mobile phone. With this user manual, you can
understand the operation of the mobile phone and enjoy its perfect function and simple
operation. This phone is designed for GSM network. Besides basic messages function, it also
provides various practical functions, including alarm, calendar, FM radio, calculator and slide
key, to make your work and entertainment more convenient. In addition, the phone utilizes
personalized human-computer interface and satisfies your different requirements with its
perfect functions.
2. Before using
2.1 Keys description
![](/img.php?id=2060131&img=bg4.png)
3
2.2 Functions of keys
Left soft key
Performs the function indicated at the left bottom of
the screen
Right soft key
Performs the function indicated at the right bottom
of the screen
Centre key
Press to enter the main menu
Message key
Quick access to message function menus
Audio player
key
Quick access to Audio player function menus
4-Way
Navigation
keys
These keys (UP, DOWN, LEFT and RIGHT) allow for
navigation through menu options and quick access to
some function menus
Send key
Press to dial a phone number or answer a call, or
![](/img.php?id=2060131&img=bg5.png)
4
view the call history
End/Power key
Press to end a call. Press to exit to the idle mode.
Hold to switch on/off the phone.
numeric keys
Press to enter characters or alphabets, etc.
Note: In this User Manual, “press” means to press a key and release
it, while “hold” means to press the key for at least two seconds and
then release it.
2.3 Battery
The battery in original state has about 50% electricity and you can use it after
unpacking. It performs best after full charge/discharge for the first three times.
2.4 Installing the SIM Cards and the Battery
Hold the End key for a while to power off the mobile phone Push the back cover above
the battery and remove it.
Pull the left battery buckle outward and then lift the battery away.
Insert the SIM card into the SIM card slot lightly with the corner cutting of the card
aligning to the notch of the slot and the gold plate of the card facing download, till the SIM
card cannot be further pushed in.
With the metallic contacts of the battery facing the metallic contacts in the battery slot,
press the battery down until it locks into place.
2.5 Charging the battery
Normally the remaining energy of the battery is indicated by the battery level icon at the
upper right corner of the display screen. When the battery energy is insufficient, the mobile
phone prompts "Battery low". If you have set an alert tone, an alert tone will be given off
when the battery level is too low. A charging animation appears when the battery is being
charged. When the charging is complete, the animation disappears.
2.6 Connecting to the network
2.6.1 SIM card
Please inset a valid SIM card (user identification card) into the phone before using it.
SIM card is the key for you to enter digital GSM network. Inside the battery compartment
you can see SIM card slot then insert your SIM card.
2.6.2 Unlocking the SIM card
By setting PIN1 (personal identification number) code of SIM card and handset lock
code, you can protect your SIM card and phone from illegal use. When this function is put in
![](/img.php?id=2060131&img=bg6.png)
5
use, you have to enter PIN1 code each time you power on your phone. To unlock the SIM
card before you dial or receive calls, You may cancel the SIM card protection (referring to
chapter “Security setup”), and in this case, the SIM card will be unable to prevent illegal use.
Press the END key to power on the phone.
Enter PIN1 code use the right soft key to clear the incorrect input. If you enter a
wrong PIN1 code for three times in a row, your SIM card will be locked by network and the
phone will ask for PUK code. If you don’t know the PUK code, do not enter any code and
send your SIM card to the operator. Details can be referred to in chapter “Security setup”
2.6.3 Making and receiving calls
In the standby interface, press number keys to input the area code and the telephone
number, and then press the OK key to dial a call. To end the call, press the End key.
3. FUNCTION MENU
3.1 Powering your phone on/off
Make sure that the SIM card is in your device and the battery is charged.
Hold the End/Power key to power on/off the phone.
3.2 Turning the torch on/off
In the idle screen, hold the Right soft key can turn on or off the torch.
3.3 Locking and Unlocking the Keypad
In idle screen, press the left soft key and then press the *key with two seconds to lock
the keypad. The unlock method is the same. Locking the keypad can prevent unintentional
operations on it. You can answer an incoming call with the regular operation when the
keypad is locked.
3.4 Text Input
Press the # key to change the input modes.
Press the * key to Select the specific symbols
Delete Character: Press the Right soft key to clear a character. Hold the Right soft
key to delete all characters.
Move cursor to left or right: Among the text, press the Left/Right navigation keys to
move the cursor to left or right.
3.5 Adding contact to the Phonebook
You can save numbers to your Phonebook. Access these numbers quickly and easily.
![](/img.php?id=2060131&img=bg7.png)
6
1. Go to Menu>Phonebook>Add new contact.
2. Edit the information and save it.
3.6 Making and receiving calls
The most basic way to make a call is to input the number in the standby mode and press
the Send key. You can also make a call from the Phonebook list.
To call someone: Go to Menu> Phonebook. Use the Up/Down keys to find the
name of the person you want to call, and press the Send key.
To receive a call, press the Send key.
To end or reject a call, press the End/Power key.
3.7 Sending and receiving messages
You can use your mobile phone to send and receive messages.
Send a message
1. Go to Menu>Messaging>Write message>Text message.
2. Write your message.
3. When you finish writing an SMS, select to send or save the message.
Receive a message
When you receive a new message, press “View” to open it. You can also go to Inbox to
read the message.
3.8 Profiles
Go to Menu>Settings>profiles. You can select Options>Activate to activate a profile. Or
you can select Options>Customize to edit a profile.
3.9 Call center
Go to Menu>Call center.
Call history
Missed calls, Dialled calls and Received calls are saved in Call history. If the records are
full, the earliest saved records will be deleted.
Also, you can delete call logs in Call history.
Call settings
You can set Call waiting, Call divert, Call barring and so on.
3.10 Setting your phone
You can adjust various settings of your phone. Go to Menu>Settings.
Phone settings: Set Time and date, Language and Display, etc.
Network settings: Set Network selection, GPRS connection, etc.
![](/img.php?id=2060131&img=bg8.png)
7
Security settings: Set security features to protect you from unauthorized use of
your phone and SIM card.
Connectivity: Set Bluetooth and Data account.
Restore settings: Input the phone password to restore to the factory settings. Some
personal information might be lost if you use this function, so be careful.
Note: You may be required to input the phone password in some of the security settings
interfaces. The default password is 1122.
3.11 How to take a photo
Go to Menu>Multimedia>Camera.
To take a photo: aim the camera at the object and then press the Center key to
take the shot.
Configure camera: press the Left soft key to configure your camera.
3.12 How to play music
Go to Menu>Multimedia>Audio player. You can play the audio in your phone or the
memory card.
3.13 How to use FM radio
Go to Menu>Multimedia>FM radio.
With the radio, you can search for radio channels, listen to them, and save them on your
device.
Note: please take your handset as the standard.
3.14 Using Services
Go to Menu>Services. In Services you can view internet content.
Important Regulatory Informatiory
FCC RF EXPOSURE INFORMATION:
WARNING!! Read this information before using your phone
In August 1986 the Federal Communications Commission (FCC) of the United States with
its action in Report and Outer FCC 96-326 adopted an updated safety standard for human
exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety standard previously set by both
U.S. and international standards bodies. The design of this phone complies with the FCC
guidelines and these international standards. Use only the supplied or an approved antenna.
Unauthorized antennas modifications, or attachments could impair call quality, damage the
8
phone, or result in violation of FCC regulations. Do not use the phone with a damaged
antenna. If a damaged antenna comes into contact with the skin, a minor burn may result.
Please contact your local dealer for replacement antenna.
BODY-WORN OPERATION:
This device was tested for typical body-worn operations with the back of the phone kept
0.5cm from the body. To comply with FCC RF exposure requirements, a minimum separation
distance of 0.5cm must be maintained between the user's body and the back of the phone,
including the antenna, whether extended or retracted. Third-party belt-clips, holsters and
similar accessories containing metallic components shall not be used. Body-worn accessories
that cannot maintain 0.5cm separation distance between the user’s body and the back
of the phone, and have not been tested for typical body-worn operations may not comply
with FCC RF exposure limits and should be avoided.
For more information about RF exposure, please visit the FCC website at www.fcc.gov
Your wireless handheld portable telephone is a low power radio transmitter and receiver.
When it is ON, it receives and also sends out radio frequency (RF) signals. In August, 1996,
the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety
levels for hand-held wireless phones. Those guidelines are consistent with the safety
standards previously set by both U.S. and international standards bodies:
<ANSIC95.1> (1992) / <NCRP Report 86> (1986) / <ICIMIRP> (1996)
Those standards were based on comprehensive and periodic evaluations of the relevant
scientific literature. For example, over 120 scientists, engineers, and physicians from
universities, government health agencies, and industry reviewed the available body of
research to develop the ANSI Standard (C95.1). Nevertheless, we recommend that you use a
hands-free kit with your phone (such as an earpiece or headset) to avoid potential exposure
to RF energy. The design of your phone complies with the FCC guidelines (and those
standards).
Use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications, or attachments could damage the phone and may violate FCC regulations.
NORMAL POSITION:
Hold the phone as you would any other telephone with the antenna pointed up and over
your shoulder.
TIPS ON EFFICIENT OPERATION:
For your phone to operate most efficiently:
• Extend your antenna fully.
• Do not touch the antenna unnecessarily when the phone is in use. Contact with the
antenna affects call quality and may cause the phone to operate at a higher power level than
otherwise needed.
9
RF Exposure Information:
FCC RF Exposure requirements: The highest SAR value reported under this standard
during product certification for use next to the body with the minimum separation distance
of 0.5cm is 1.024W/kg; next to the head is 1.065W/kg. This transmitter must not be
collocated or operating in conjunction with any other antenna or transmitter.
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Do not use the device with the environment which below minimum -10℃ or over
maximum 50℃, the device may not work.
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
