Users Manual Part 1
![](/img.php?id=484547&img=bg1.png)
![](/img.php?id=484547&img=bg3.png)
P
Pr
re
ef
fa
ac
ce
e
Copyright 2004
All Rights Reserved.
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the
part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic,
or other means in any form without prior written permission of the manufacturer.
T
Tr
ra
ad
de
em
ma
ar
rk
ks
s
CardSoft is a trademark of SystemSoft Corporation. AutoCAD and Autoshade are
trademarks of Autodesk, Inc. IBM, OS/2, and VGA are trademarks of International
Business Machines Corp. Lotus, 1-2-3, and Symphony are trademarks of Lotus
Development Corp. Windows, Word, MS-DOS, and Microsoft are trademarks of
Microsoft Corp. VESA is a trademark of Video Electronics Standards Association.
Other product names mentioned herein are used for identification purposes only and
may be trademarks and/or registered trademarks of their respective companies.
L
Li
im
mi
it
ta
at
ti
io
on
n
o
of
f
L
Li
ia
ab
bi
il
li
it
ty
y
While reasonable efforts have been made to ensure the accuracy of this manual, the
manufacturer and distributor assume no liability resulting from errors or omissions in
this manual, or from the use of the information contained herein.
![](/img.php?id=484547&img=bg4.png)
N
No
ot
ti
ic
ce
es
s
F
Fe
ed
de
er
ra
al
l
C
Co
om
mm
mu
un
ni
ic
ca
at
ti
io
on
ns
s
C
Co
om
mm
mi
is
ss
si
io
on
n
R
Ra
ad
di
io
o
F
Fr
re
eq
qu
ue
en
nc
cy
y
I
In
nt
te
er
rf
fe
er
re
en
nc
ce
e
S
St
ta
at
te
em
me
en
nt
t
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and if not installed and
used in accordance with the instruction manual may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•
•
•
•
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio TV technician for help.
N
No
ot
ti
ic
ce
e:
:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment. Shielded
interface cables and a non-shielded AC power cord must be used in order to comply
with emission limits.
This equipment is to be used with power supply:
I/P: 100-240 Vac, 50-60Hz, 1.8A
O/P: 19Vdc, 3.42A
2
![](/img.php?id=484547&img=bg5.png)
There is no internal power supply.
C
Ca
an
na
ad
di
ia
an
n
D
DO
OC
C
N
No
ot
ti
ic
ce
e
F
Fo
or
r
C
Cl
la
as
ss
s
B
B
C
Co
om
mp
pu
ut
ti
in
ng
g
D
De
ev
vi
ic
ce
es
s
This Class B digital apparatus meets all requirements of the Canadian Interference -
Causing Equipment Regulations.
Cet appareil numerique de la classe B repecte toutes les exigences du Règlement sur
le matèriel brouilleur du Canada.
3
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the
specific operating instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
CH1~CH11 for 2.4GHz by specified firmware controlled in U.S.A
Highest SAR test Value: 0.562 W / kg
![](/img.php?id=484547&img=bg7.png)
Page intentionally left blank
4
![](/img.php?id=484547&img=bg8.png)
T
Ta
ab
bl
le
e
o
of
f
C
Co
on
nt
te
en
nt
ts
s
Chapter 1: Before you Start --------------------------------------------------------------------------------- 7
Conventions of This Manual..........................................................................................................................7
Things you must remember before working on your computer.....................................................................14
Chapter 2: Introduction --------------------------------------------------------------------------------------- 17
Welcome to the Notebook PC........................................................................................................................18
Getting to Know Your Computer...................................................................................................................18
Chapter 3: Getting Started ----------------------------------------------------------------------------------- 31
Connecting to a Power Source.......................................................................................................................31
Turning On Your Notebook Computer..........................................................................................................33
Operating on Battery Power...........................................................................................................................33
Chapter 4: Using the Notebook Computer ------------------------------------------------------------- 37
Adjusting the LCD Screen Display................................................................................................................37
A Tour of the Notebook’s Keyboard .............................................................................................................39
The TouchPad................................................................................................................................................40
Connecting an External Tracking Devices.....................................................................................................42
The CD-ROM/DVD-ROM/Combo Drive .....................................................................................................42
PCMCIA Cards and Expansion Sockets........................................................................................................44
Power Saving Modes .....................................................................................................................................46
Chapter 5: Desktop Operation------------------------------------------------------------------------------ 51
Audio .............................................................................................................................................................52
Connecting Peripheral Devices......................................................................................................................53
Chapter 6: Running BIOS Setup --------------------------------------------------------------------------- 57
Introduction....................................................................................................................................................57
Navigating through BIOS Setup ....................................................................................................................58
Accessing the BIOS Setup Program ..............................................................................................................58
The Menu Bar ................................................................................................................................................58
The Legend Bar .............................................................................................................................................59
5
![](/img.php?id=484547&img=bg9.png)
Launching Submenus.....................................................................................................................................60
General Help..................................................................................................................................................60
The Main Menu .............................................................................................................................................61
The Advanced Menu......................................................................................................................................62
The Security Menu.........................................................................................................................................63
The Boot Menu..............................................................................................................................................64
The Exit Menu ...............................................................................................................................................65
Chapter 7: The Software Utilities Disks ----------------------------------------------------------------- 67
AutoRun Installation......................................................................................................................................67
VGA Utilities.................................................................................................................................................72
Chapter 8: Troubleshooting --------------------------------------------------------------------------------- 82
Locating a Problem........................................................................................................................................82
Checking Cables and Connections.................................................................................................................83
The Power-On Self Test.................................................................................................................................84
General Hardware Problems ..........................................................................................................................85
Contacting Your Dealer.................................................................................................................................87
Chapter 9: Upgrading your System----------------------------------------------------------------------- 90
Upgrading your Memory ...............................................................................................................................90
The Easy to Upgrade HDD Module...............................................................................................................92
Upgrading your System CPU.........................................................................................................................93
Appendix A: Specification ----------------------------------------------------------------------------------- 96
Detailed Notebook Specifications..................................................................................................................96
6
![](/img.php?id=484547&img=bga.png)
B
Be
ef
fo
or
re
e
y
yo
ou
u
S
St
ta
ar
rt
t
Conventions of This Manual
Use this manual will help you get the most from your notebook computer.
If you are an experienced user of computers and/or Microsoft’s Windows
operating systems, you might find it useful to read the Quick Start Guide that
comes along with your accessories.
•
• If you are a less experienced user, you should through the manual carefully before
using your system.
7
![](/img.php?id=484547&img=bgb.png)
Whether or not you are an experienced user, you should consult on the
Troubleshooting Chapter if you encounter any problems with your notebook.
The check mark symbol indicates that you should take note on every
detailed information when you encounter some function that might be
useful when you are using your notebook.
The pencil symbol identifies information which is important for you to
read to avoid damage to the computer.
This warning cautions you against actions which might be destructive
to your data or might disrupt proper system operation.
S
Sa
af
fe
et
ty
y
P
Pr
re
ec
ca
au
ut
ti
io
on
ns
s
This section is designed to assist you in identifying potentially unsafe conditions
while working with this product. Required safety features have been installed in the
computer to protect you from injury. However, you should use good judgment to
identify potential safety hazards:
Please read these safety instructions carefully.
1
1.
.
2
2.
.
3
3.
.
4
4.
.
5
5.
.
6
6.
.
Please keep this User's Manual for later reference.
Please disconnect this equipment from AC outlet before cleaning. Don't use
liquid or sprayed detergent for cleaning. Use moisture sheet or cloth for
cleaning.
For pluggable equipment, that the socket-outlet shall be installed near the
equipment and shall be easily accessible.
Please keep this equipment from humidity.
Lay this equipment on a reliable surface when installed. A drop or fall could
cause injury.
8
![](/img.php?id=484547&img=bgc.png)
7
7.
.
8
8.
.
9
9.
.
1
10
0.
.
1
11
1.
.
1
12
2.
.
1
13
3.
.
b.
c.
d.
e.
f.
1
14
4.
.
1
15
5.
.
1
16
6.
.
1
17
7.
.
Make sure to use the right voltage for the power source when connecting the
equipment to the power outlet.
Place the power cord in such a way that people can not step on it. Do not place
anything on top of the power cord.
All cautions and warnings on the equipment should be noted.
If the equipment is not use for a long time, disconnect the equipment from the
main power outlet to avoid being damaged by transient overvoltage.
Never pour any liquid into the opening, this could cause fire or electrical shock.
Never open the equipment. For safety reason, the equipment should only be
opened by a qualified service personnel.
If on the following situations arises, get the equipment checked by a service
personnel:
a. The Power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment has not worked well or you cannot get it work according to
the user's manual.
The equipment has dropped and damaged.
If the equipment has obvious sign of breakage.
Do not leave this equipment in an environment unconditioned, storage
temperature above 60°C (140°f), it may damage the equipment.
The unit can be operated at an ambient temperature of max. 35°C.
The sound pressure level at the operators position according to IEC 704-1: 1982
is equal or less than 70 dB(A).
Power Cord Requirements
The power cord set used with the AC adaptor must meet the requirements of the
country where you use the AC adaptor, whether it is 100-120 or 200-240 Vac.
The following information explains the requirements for power cord set
9
![](/img.php?id=484547&img=bgd.png)
selection.
• The cord set must be approved for the country in which it is used.
• The appliance coupler must have a configuration for mating with a
CEE22/EN6032/IEC 320 appliance inlet.
For U.S. and Canada: A.
B.
C.
1
18
8.
.
1
19
9.
.
• The cord set must be UL Listed and CSA Certified.
• The minimum specifications for the flexible cord are No. 18 AWG.
For Japan:
• All components of the cord set must bear a “PSE” or “ T ” mark and
registration number in accordance with the Japanese Dentori Law.
• The minimum specifications for the flexible cord are .75m ㎡ conductors.
For Other Countries:
• The cord set fittings must bear the certification mark of the agency
responsible for evaluation in a specific country.
• The flexible cord must be of a HAR (harmonized) type H05VV-F.
• The cord set must have a current capacity of a least 2.5 Amperes and
voltage rating of 125 or 250 Vac.
When using your telephone equipment, basic safety precautions should always
be followed to reduce the risk of fire, electric shock and injury to persons.
These precautions includes the following:
Do not use this product near water, for example, near a bathtub, washbowl,
kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
Do not use the telephone to report a gas leak in the vicinity of the leak.
Use only the power cord indicated in this manual.
Do not use the AC adapter near open water or other liquids. Never spill liquid
10
![](/img.php?id=484547&img=bge.png)
into the AC adapter.
Laser Warning: Laser Class I Product Caution - Invisible laser radiation when
open avoid exposure to beam.
2
20
0.
.
2
21
1.
.
2
22
2.
.
Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer's instructions. Never remove the battery
pack while the power is on as this may result in data loss when the system loses
power.
The input receptacle is used as the main disconnecting device.
W
Wi
ic
ch
ht
ti
ig
ge
e
S
Si
ic
ch
he
er
rh
he
ei
it
ts
sh
hi
in
nw
we
ei
is
se
e
1
1.
.
2
2.
.
3
3.
.
4
4.
.
5
5.
.
6
6.
.
7
7.
.
8
8.
.
9
9.
.
1
10
0.
.
1
11
1.
.
Bitte lesen Sie diese Hinweis sorgfältig durch.
Heben Sie dirse Anleitung für den späteren Gebrauch auf.
Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Versenden Sie
Keine Flüssig- oder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes
Tuch zur Reinigung.
Die Netzanschluβsteckdose soll nahe dem Gerät angebracht und leicht
zugänglich sein.
Das Gerät ist vor Feuchtigkeit zu schützen.
Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen
oder Fallen könnte Beschädigungen hervorrufen.
Beachten Sie beim Anschluß an das Stromnet die Anschlußwerte.
Verlegen Sie die Netzanschlußleitung so, daß niemand darüber fallen kann. Es
sollte auch nichts auf der Leitun abgestellt werden.
Alle Hinweise und Warnungen, die sich am Gerät befinden, sind zu beachten.
Wird das Gerät üeinen längeren Zeitraum nicht benutzt, sollten Sie es vom
Stromnetz trennen. Somit wird im Falle einer Überspannung eine
Beschädigung vermieden.
Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeien in
11
![](/img.php?id=484547&img=bgf.png)
das Gerät gelangen. Dies könne einen Brand bzw. Elektrischen Schlag
auslösen.
1
12
2.
.
1
13
3.
.
b.
c.
d.
e.
f.
1
14
4.
.
1
15
5.
.
1
16
6.
.
1
17
7.
.
A.
Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen
Sicherheit nur von authorisiertem Servicepersonal geöffnet werden.
Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen
und von einer qualifizierten Servicestelle zu Überprüfung.:
a. Netzlabel oder Netzstecker sind beschädigt.
Flüssigkeit ist in das Gerät eingedrungen.
Das Gerät war Feuchtigkeit ausgesetzt.
Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert
oder Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen.
Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
VORSICHT: Explosiongsgetahr bei unsachgemäßen Austausch der Batterie.
Ersatz nur durch denselben oder einem vom Hersteller empfohlenem ähnlichen
Typ. Entsorgung gebrauchter Batterien nach Angaben des Herstellers.
Dieses Schaltnetzteil kann bis zu einer Außentemperatur von maximal 35ºC.
Die Ausgangswerte dürfen nicht die auf dem Label angegebenen Werte
überschreiten.
Anforderungen an das Stromkabel
Das Kabel-Set, das an das Netzteil angeschlossen wird, muss den
Anforderungen des Landes, in dem Sie das Netzteil einsetzen, genügen, je
nachdem, ob die Netzspannung 100-120 oder 200-240V Wechselspannung
beträgt.
• Das Kabel-Set muss für das Land, in dem es eingesetzt wird, zugelassen
sein.
• Der Gerätestecker des Kabels muss in eine CEE22/ EN603/ IEC 320
Buchse passen.
Für die USA und Kanada:
12
![](/img.php?id=484547&img=bg10.png)
• Das Kabel-Set muss UL-gelistet und CSA zertifiziert sein.
• Die Minimalanforderungen für das Kabel entsprechen No. 18 AWG.
Für Japan: B.
C.
1
18
8.
.
1
19
9.
.
2
20
0.
.
• Alle Teile des Kabel-Sets müssen entsprechend dem japanischen Dentori
Law mit einem „PSE“ or „T”-Symbol markiert sein
• Die Minimalanforderungen für das Kabel sind .75m ㎡ Leiter.
Für andere Länder:
• Die Zubehörteile des Kabel-Sets müssen das Prüfsiegel derjenigen Stelle,
die in dem jeweiligen Land für die Sicherheitsprüfung zuständig ist, tragen.
• Das Kabel muss vom HAR (harmonisierten) Typ H05VV-F sein.
• Das Kabel-Set muss eine Stromkapazität von mindestens 2,5 Ampere haben
und Spannungen von 125 oder 250 V Wechselstrom gestatten.
Bei der Benutzung Ihres Telefongerätes sollten Sie immer die grundlegenden
Sicherheitsmaßnahmen beachten, um das Risiko von Feuer, Stromschlägen und
Verletzungen zu minimieren. Zu beachten sind u.a. folgende Punkte:
Benutzen Sie das Gerät nicht in der Nähe von Wasser, wie zum Beispiel
Badewanne, Waschbecken, Spülbecken, Waschbottich, in feuchten
Kellerräumen oder in der Nähe von Schwimmbecken.
Benutzen Sie kein Telefon (ausgenommen schnurlose Modelle) während
eines Gewitters. Es besteht das geringe Restrisiko eines Blitzschlages.
Benutzen Sie das Telefon nicht um ein Gasleck zu melden, falls es sich in der
Nähe des Lecks befindet.
Benutzen Sie nur solch ein Stromkabel, wie in dieser Anleitung beschrieben.
Benutzen Sie das Netzteil nicht in unmittelbarer Nähe zu Wasser oder anderen
Flüssigkeiten. Gießen Sie nie Flüssigkeiten über das Netzteil.
Achtung Laser: Laser Produkt der Klasse I. Achtung - Unsichtbarer Laserstrahl,
vermeiden Sie Kontakt mit dem Strahl bei offenem Gehäuse.
13
![](/img.php?id=484547&img=bg11.png)
Es besteht Explosionsgefahr, wenn der Akku nicht ordnungsgemäß ersetzt wird.
Ersetzen Sie den Akku nur durch einen Akku gleichen oder äquivalenten Typs,
der vom Hersteller empfohlen wird. Entsorgen Sie Akkus entsprechend den
Anweisungen des Herstellers. Entfernen Sie den Akku auf keinen Fall bei
eingeschaltetem Notebook, da hierdurch Daten verloren gehen könnten.
2
21
1.
.
2
22
2.
.
Der Netzeingabeanschluss dient als Hauptschalter des Geräts.
Things you must remember before working on your computer
Let your computer acclimate itself
Your notebook can easily stand temperature extremes but it doesn’t like rapid
changes in temperature, like going from the cold outdoors to a warm office. Rapid
changes in temperature can cause water droplets to condense inside your case,
threatening to damage the electronic parts inside.
After receiving your notebook when it’s hot or cold outside, try not to power up the
computer immediately, let the computer adjust to the room temperature gradually at
least for three to four hours.
If your system arrives in cold weather, do not apply power to the
computer or monitor until they have been allowed to come to room
temperature.
Heat, Cold, Humidity, and Glare
Find a suitable place for your computer that’s not too hot, too cold, too dark, or too
bright. Glare can make it hard to read the screen.
Try to avoid the computer components from being destroyed if it is over heated,
so try to allow plenty of room for air to circulate around the case.
•
•
•
Do not block the ventilation opening.
Do not place your computer in direct sunlight.
14
![](/img.php?id=484547&img=bg12.png)
Suitable place to work
Your computer will run well wherever you’re comfortable but extremes of
temperature and humidity can be challenging to your system’s parts.
There are some things you can tolerate that the computer can’t – things like static
electricity, dust, water, steam and oil. In case you decide to pull over for roadside
computing, try to choose a clean, comfortable work area for your system.
A lithium-ion battery pack will be available when you are traveling. If you are
running your system for the first time on battery power, remove the battery from the
package, install it into the system and recharge the battery to fully prepare for service.
15
![](/img.php?id=484547&img=bg13.png)
Page intentionally left blank
16
![](/img.php?id=484547&img=bg14.png)
I
In
nt
tr
ro
od
du
uc
ct
ti
io
on
n
There are more and more people spending large amounts of time in front of
computer monitors now that scientists from many fields including anatomy,
psychology, and occupational safety are involved in the study of ergonomically
sound work environments.
A few tips to help you work effectively without a lot of physical discomfort:
Purchase a chair with armrests and good back support. Don't slouch when sitting;
keep your back straight.
•
17
![](/img.php?id=484547&img=bg15.png)
Try to place the LCD panel or external monitor so that there is little glare from
the sun on the monitor.
•
•
•
•
Walk around the room every hour.
Every half hour look away from the computer screen for a few minutes.
Place everything that you need to work within easy reach.
Welcome to the Notebook PC
Congratulations on your purchase of the Notebook PC. Your Notebook features the
latest advances in portable computing technology. The Notebook’s modular design
provides maximum expandability without compromising portability.
The high-performance CPU and enhanced IDE hard drive provides you with extra
processing power for handling complex graphics and running large programs.
One PCMCIA slot gives you the ability to use standard PCMCIA cards, such as a
LAN adapter or memory cards.
Getting to Know Your Computer
Opening the LCD Panel
At the front of the Notebook you will find a retaining latch on the display panel that
locks the display in closed position when the Notebook is not in use.
18
![](/img.php?id=484547&img=bg16.png)
Slide the display panel latch to the right until the display panel releases, and
then raise the LCD screen.
1
1.
.
2
2.
.
At any time you can tilt the display toward or away from you to a comfortable
viewing position.
To avoid damage to the display panel:
1. Try not to slam the display upon closing it.
2. Try not to place any object on top when it is closed or open.
3. Be sure the system is turned off or in suspend mode before you
close the display panel.
To shutdown the system in non-Windows (DOS mode, System POST,
Setup Menu or Quick Boot Menu) based environment, enable the lid
switch. This will prevent the system from damaged if it exceeds the
temperature limit. Windows will control the lid switch in windows
environment.
With the LCD screen open, you will see several features important for operating your
Notebook computer.
19
![](/img.php?id=484547&img=bg17.png)
Each of these features is briefly described below.
20
![](/img.php?id=484547&img=bg18.png)
LCD Cover Release Latch
1
1.
.
2
2.
.
3
3.
.
4
4.
.
5
5.
.
Slide this latch to the right to open the LCD cover.
LCD Screen
Your Notebook computer is equipped with a replaceable color Liquid Crystal
Display (LCD) screen that supports up to 1400 x 1050 resolution.
A built-in backlight allows you to comfortably view the screen even when ambient
lighting is low.
Internet Explorer Button
Use this key to open the Internet Explorer.
Outlook Express Button
Use this key to open Microsoft's Outlook to send/receive your mail.
System Status Indicator Panel
The system status indicator panel keeps you informed of the computer’s operating
status.
Indicates that the computer is accessing the hard disk drive.
Indicates that the keyboard is in Num Lock mode.
Indicates when the keyboard is in Caps Lock mode. In this mode, the
keyboard produces uppercase text when you press a key. When you
press the Caps Lock key again, the indicator goes off and the keyboard
produces lowercase text.
Indicates when the keyboard is in Scroll Lock mode. Some
applications will move information across the screen differently when
Scroll Lock is on.
21
![](/img.php?id=484547&img=bg19.png)
Power/Resume Button
6
6.
.
7
7.
.
8
8.
.
9
9.
.
1
10
0.
.
Pressing this button for 1-2 seconds will turn on the system or pressing this button
when the computer is in Suspend mode will resume normal operation. Pressing this
button for 4-6 seconds will also turn off the system.
TouchPad
The TouchPad is hardware-compatible with the IBM PS/2 mouse and software-
compatible with the Microsoft mouse.
TouchPad Buttons
The buttons below the TouchPad correspond to the left and right buttons on a
standard mouse. The PS/2 compatible mouse will work with the Notebook PC’s
TouchPad simultaneously.
Scroll Button
Use this button to scroll up and down the scrolling bar.
The Built-in Microphone
The built-in microphone is located to the left of the TouchPad.
22
![](/img.php?id=484547&img=bg1a.png)
The Left Side
Ventilation Opening
1
1.
.
2
2.
.
Please don’t block this opening during operation of the system.
1394A
A very fast external bus standard that supports data transfer rates of up to 400 Mbps
(400 million bits per second).
23
![](/img.php?id=484547&img=bg1b.png)
Can be used to connect up 63 external devices, also supports isochronous data --
delivering data at a guaranteed rate. This makes it ideal for devices that need to
transfer high levels of data in real-time, such as video devices. Also supports both
Plug-and-Play and hot plugging, and also provides power to peripheral devices.
PCMCIA Socket Cover
3
3.
.
4
4.
.
5
5.
.
Open this cover to access the PCMCIA socket. The computer’s PCMCIA socket lets
you extend the capabilities of your computer by inserting PC cards.
PCMCIA Socket Button
The computer has one PCMCIA type II socket
The LAN Port
This jack provides a standard RJ-45 connection for integration with an existing
network or a high-speed (DSL or cable) connection via a network cable.
When using a LAN, please use an EMI Shielding Cable to minimize
an inteference when transmitting.
6
6.
.
The Modem Port
This jack is an internal 56K voice/fax/data modem. You will connect your computer
to your phone line through this port.
Always disconnect all telephone lines from the wall outlet before
servicing or disassembling this equipment. To reduce the risk of fire
use only No. 26 AWG or larger telecommunication line cord.
7
7.
.
Microphone Jack
Allows you to receive monophonic input from an external microphone. Use of an
external microphone will disable the built-in microphone.
24
![](/img.php?id=484547&img=bg1c.png)
Audio Line Out Jack
8
8.
.
You can plug an external speaker, headphone or connect the line out jack to an audio
device such as a cassette recorder to record the notebook's audio output.
L
LE
ED
D
I
In
nd
di
ic
ca
at
to
or
rs
s
These three LED indicators are separately program for the following functions:
Power On, Suspend Mode and Battery Charge.
Power On
1
1.
.
This indicator will lit when the notebook is powered On.
25
![](/img.php?id=484547&img=bg1d.png)
Battery Charge
2
2.
.
3
3.
.
This indicator will lit green when the battery is in charging status. When the
indicator light turns off, it indicates the system is in full charge.
Suspend Mode
This indicator will lit when the notebook enter the suspend mode.
The Right Side
26
![](/img.php?id=484547&img=bg1e.png)
The CD-ROM/DVD-ROM or DVD CD-RW Combo (Option)
1
1.
.
2
2.
.
Your Notebook comes with a swappable 24X (or higher) 5.25" IDE CD-ROM/DVD-
ROM/Combo Drive (DVD-ROM+CD-RW), DVD-RW, DVD+RW, DVD-Dual.
DC IN Connector
Plug the AC adapter into this connector.
The Rear
27
![](/img.php?id=484547&img=bg1f.png)
Ventilation Opening
1
1.
.
2
2.
.
3
3.
.
4
4.
.
5
5.
.
6
6.
.
7
7.
.
Please don't block this opening during operation of the system.
Kensington Lock
Allows you to connect a special computer lock to secure your system.
You can purchase a lock at most computer retailers.
S-Video Port
Allows you to connect any S-Video ready television to your system. You can
display output simultaneously on both the LCD and the television or toggle between
the two screens.
Parallel Port
This port allows you to easily connect a parallel printer or plotter using this 25-pin
bi-directional female port.
External CRT Port
This port allows you to easily connect an external VGA/SVGA display monitor into
your Notebook using the 15-pin female connector.
Infrared Data Port
The Infrared Data Port allows your Notebook to become truly wireless.
You can use this port to transfer large amounts of data very quickly to any other
machine (Notebook computers, printers, etc.), which is also equipped with an IrDA-
compliant IR port.
This allows you to print documents without any inconvenient cable hookups.
USB Ports
Your computer includes two Universal Serial Bus (USB) port. USB is the latest
development in Plug and Play technology.
28
![](/img.php?id=484547&img=bg20.png)
It will eventually replace the need for separate connectors for external keyboards,
serial ports, and parallel (printer) port.
The Bottom Panel
MiniPCI/Wireless LAN/Modem Combo Compartment (Option)
1
1.
.
2
2.
.
This compartment can be used to extend the capabilities of your system by providing
a connection with various extension card.
Expansion Compartment
This compartment will serve as an expansion to upgrade your RAM module.
29
![](/img.php?id=484547&img=bg21.png)
Battery Release Latch
3
3.
.
4
4.
.
5
5.
.
Lift up this latch to release the battery from its bay.
Battery
Your notebook comes equipped with a factory-installed battery pack module. After
the battery runs down, the module can be removed and replaced with a charged
battery.
Hard Disk Drive
Your computer includes a 2.5-inch IDE hard disk drive (9.5mm in height). The
notebook PC's BIOS automatically detects IDE drive types.
30
![](/img.php?id=484547&img=bg22.png)
G
Ge
et
tt
ti
in
ng
g
S
St
ta
ar
rt
te
ed
d
Connecting to a Power Source
Connecting the AC Adapter
A universal AC adapter is provided to supply your computer with power and also
charge the computer’s battery pack.
The adapter’s AC input voltage can range anywhere from 100 to 240 volts, covering
the standard voltages available in almost every country.
![](/img.php?id=484547&img=bg23.png)
The power cord for the AC
adapter requires a three-hole
grounded AC outlet. To connect
the computer to an external
power source:
Plug the AC adapter’s connector into the DC-IN connector on the rear of the
computer.
1
1.
.
2
2.
.
Connect the power cord to the AC adapter and then to a wall outlet.
The best kind of AC power source to connect your Notebook to is a
UPS (Uninterruptible Power Supply). Lacking this, use a power strip
with a built-in surge protector. Do not use inferior extension cords as
this may result in damage to your Notebook. The Notebook comes
with its own AC adapter. Do not use a different adapter to power the
computer and other electrical devices.
Whenever possible, keep the AC adapter plugged into the Notebook and an electrical
outlet to recharge the battery.
32
![](/img.php?id=484547&img=bg24.png)
Never turn off or reset your Notebook while the hard disk is in use and
the HDD status icon is lit; doing so can result in loss or destruction of
your data. Always wait at least 5 seconds after turning off your
Notebook before turning it back on; turning the power on and off in
rapid succession can damage the Notebook’s electrical circuitry.
Turning On Your Notebook Computer
Turn on your Notebook by pressing the power button. Hold the button down for a
second or two and release. The Power-On Self Test (POST) runs automatically.
After the POST is completed, the computer reads the operating system from the hard
disk drive into computer memory (this is commonly referred to as “booting” a
computer). If your OS (Operating System such as Windows XP…. etc) is installed,
it should start automatically.
To turn the Notebook off, save your work and close all open applications, click on
Start, then select the “Turn off the computer”. A selection box will be displayed and
click on the “Turn Off” button to shut down your computer.
When your computer hangs up, press the power button for 4-6 seconds
to shut down the computer
Operating on Battery Power
Your computer comes with a rechargeable battery pack that lets you operate the
computer without an external power source. When the battery pack is fully charged,
you can operate the computer for approximately 2 hours under the following
conditions:
The battery pack initially has a full charge. •
• No peripheral devices are installed.
33
![](/img.php?id=484547&img=bg25.png)
The disk/CD-ROM drives run no more than 10% of the time. •
Only use batteries that are approved by an authorized dealer. All
batteries are not the same and therefore should not be treated as such.
Using the wrong battery could cause serious damage to your computer
and yourself through toxic emissions.
Inserting and Removing the Battery Pack
The battery pack should already be inserted in your Notebook computer when you
unpack it. If not inserted, follow these directions:
Turn over the notebook with the front of the unit facing you and place it on a
solid, flat surface.
1
1.
.
2
2.
.
3
3.
.
Angle the battery into the bay. The front edge of the battery should slide into
the grooves in the system case.
Gently lower the battery into the bay and push it until it clicks securely in the
bay.
34
![](/img.php?id=484547&img=bg26.png)
To remove the battery pack:
Turn off the notebook, and disconnect the AC adapter. Close the LCD panel
and turn it over and place it on a solid, flat surface.
1
1.
.
2
2.
.
3
3.
.
Lift the release latch to release the battery from the bay. At this time the battery
will now be angled slightly out of the bay.
Hold the battery at the finger grip and lift it out of the compartment.
Charging the Battery Pack
The installed battery pack charges automatically any time the computer is connected
to the AC adapter and an external power source.
It is a good idea to occasionally discharge the battery pack fully to preserve its
operating performance.
35
![](/img.php?id=484547&img=bg27.png)
Page intentionally left blank
36
![](/img.php?id=484547&img=bg28.png)
U
Us
si
in
ng
g
t
th
he
e
N
No
ot
te
eb
bo
oo
ok
k
C
Co
om
mp
pu
ut
te
er
r
Adjusting the LCD Screen Display
The LCD screen display can be adjusted by the following key combinations.
KEYS FUNCTIONS
[Fn] + [F7] Decreases the brightness level.
[Fn] + [F8] Increases the brightness level.
[Fn] + [F10] Use this key combination to expand your video screen or reset to its
ori
g
inal size. This function will be disabled when the s
y
stem is in
![](/img.php?id=484547&img=bg29.png)
Overlay mode (playing video).
[Fn] + [F12] This key combination toggles the display between the LCD, CRT,
simultaneous LCD/CRT, and TV only. This function will be disabled
when the system is in Overlay (playing video) or Extended Desktop
mode.
LCD Care
LCD screens are delicate devices that need careful handling. Please pay attention to
the following precautions:
When you are not using the computer, keep the LCD screen closed to protect it
from dust.
•
•
•
•
If you need to clean your LCD screen, use a soft tissue to gently wipe the LCD
surface.
Do not put your fingers or sharp objects directly on the surface and never spray
cleaner directly onto the display.
Do not press on, or store any objects on the cover when it is closed. Doing so
may cause the LCD to break.
E
Ex
xt
te
er
rn
na
al
l
C
CR
RT
T
D
Di
is
sp
pl
la
ay
y
You can hook up an external monitor through the 15-pin CRT connector.
Configurations are available:
LCD only •
•
•
•
CRT only
Simultaneous display of the LCD screen and CRT monitor
TV only
You can switch between these display configurations by pressing the key combination
[Fn] + [F12].
38
![](/img.php?id=484547&img=bg2a.png)
A Tour of the Notebook’s Keyboard
The Notebook’s keyboard uses a standard QWERTY layout with the addition of
special function keys and an embedded numeric keypad for number intensive data
entry. Your keyboard supports Windows by incorporating the two Windows specific
keys. With the two Windows keys you will be able to access and take advantage of
many of the timesaving features of Windows software.
The function keys (F1-F12) on the top row of the keyboard, serve different purposes
and carry out different tasks depending on the application you are running.
The cursor (arrow) keys (which are all located in the lower right corner of your
keyboard) and the [PgUp], [PgDn], [Home] and [End] keys (which are located along
the right edge of the keyboard) allow you to move the active cursor of the computer
to various locations on the screen or within the document.
The embedded numeric keypad consists of 15 keys that make number intensive input
more convenient. Like the [Num Lock] key, these keys are labeled in blue on the
keycaps. Numeric assignments are located at the upper right of each key.
When the numeric keypad is engaged, the NumLock icon will appear in the System
Window. The keypad is activated by pressing the [Fn] + [NumLk] key. If an
external keyboard is connected, pressing the NumLock key on either the Notebook or
external keyboard will enable/disable NumLock of both keyboards in unison.
To disable the Notebook numeric keypad while keeping the keypad on an external
keyboard activated, use the [Fn] + [NumLk] hot key on the Notebook keyboard.
39
![](/img.php?id=484547&img=bg2b.png)
The Notebook’s Hot Key Controls
KEYS FUNCTION(S)
Power Button Press this button once to power on or enter the
suspend/resume mode.
Press this button for more than 4 seconds to power off the
system.
Internet Button Open Internet WWW Home short-cut key
Email Button Open Email Reader short-cut key
[Fn] + [F1] This key combination turns on/off the battery beeping sound
[Fn] + [F2] This key combination turns on/off the volume.
[Fn] + [F3] Decreases the speaker volume.
[Fn] + [F4] Increases the speaker volume.
[Fn] + [F7] Decreases the brightness level.
[Fn] + [F8] Increases the brightness level.
[Fn] + [F10] Use this key combination to expand your video screen or reset
to its original size. This function will be disabled when the
system is in Overlay mode (playing video).
[Fn] + [F12] This key combination toggles the display between the LCD,
CRT, simultaneous LCD/CRT, and TV only. This function will
be disabled when the system is in Overlay (playing video) or
Extended Desktop mode.
The TouchPad
The touchpad is a rectangular electronic panel located just below your keyboard. You
can use the static-sensitive panel of the touchpad and slit it to move the cursor. You
can use the buttons below the touchpad as left and right mouse buttons.
40
![](/img.php?id=484547&img=bg2c.png)
TouchPad Precautions
The TouchPad is a pressure sensitive device. Please take note of the following
precautions.
Make sure the TouchPad does not come into contact with dirt, liquids or grease. •
•
•
Do not touch the TouchPad if your fingers are dirty.
Do not rest heavy objects on the TouchPad or the TouchPad buttons.
You can use the TouchPad with Microsoft Windows as well as non-Windows
applications.
41
![](/img.php?id=484547&img=bg2d.png)
Connecting an External Tracking Devices
The system will only enables you to use one tracking device whether it is an internal
or external tracking device.
Data Storage and Retrieval
Data storage and retrieval are two of the most fundamental tasks you will perform
when working with your computer. The Notebook is equipped with a hard disk drive
(HDD). The HDD is removable allowing for easy upgrades.
The CD-ROM/DVD-ROM/Combo Drive
Features of the CD-ROM/DVD-ROM/Combo Drive
The features of the CD-ROM/DVD-ROM/Combo Drive are listed below.
The Audio Play feature allows you to play music CDs •
•
•
•
•
•
•
•
Front panel load/unload button
Supports CD-DA, CD-ROM mode 1 and mode 2, Multi-Session Photo CD™,
CD-I/Video CD (pcs.)
Low power consumption
12.7mm height
Precautions for Handling CD-ROM/DVD-ROM/Combo Drive
Always hold the disc by the edges, avoid touching the surface.
Use a clean, dry, cloth to remove dust, smudges, or fingerprints. Wipe from the
center outward.
Do not write or place objects on the surface of the disc.
42
![](/img.php?id=484547&img=bg2e.png)
Store discs in a cool dry place not to damage the disc. •
•
•
1
1.
.
2
2.
.
3
3.
.
1
1.
.
2
2.
.
3
3.
.
Do not use benzene, thinners, or cleaners with detergent. Only use CD-
ROM/DVD-ROM cleaning kits.
Do not bend or drop the discs.
Loading a Disc
To play a CD disc, follow the instructions listed below.
Push the CD-ROM/DVD-ROM/Combo Drive eject button on the CD drive door.
Gently pull the tray all the way out.
Carefully lift the CD-ROM/DVD-ROM/Combo Drive by the edges and make
sure the shiny surface is face down (the side with no writing on it). Carefully
insert the CD-ROM onto the tray. Push the CD-ROM/DVD-ROM/Combo
Drive down gently so that it snaps onto the center ring.
Push the tray back into the drive.
To remove a disk, do the following:
Check the LED display and make sure that the computer is not accessing the
CD-ROM/DVD-ROM/Combo Drive.
Push the eject button and pull the tray all the way out.
Carefully pick up the CD disk by the edges and – while pressing down on the
center ring – remove the CD-ROM/DVD-ROM/Combo from the tray.
43
![](/img.php?id=484547&img=bg2f.png)
Do not insert any foreign objects into the disc tray. If you experience
difficulty when ejecting the CD disk tray, stretch a paper clip (or use a
pin or a thin metal rod) and insert it into the emergency eject hole
located on the right side of the front panel. The CD disk tray should
eject immediately. This procedure can also be used to remove a CD
from the drive when the Notebook is powered off.
PCMCIA Cards and Expansion Sockets
The Notebook features one PCMCIA expansion socket design to interface with one
Type II card.
44
![](/img.php?id=484547&img=bg30.png)
Inserting a PCMCIA Card
The computer will emit a medium tone followed by a high tone when a PC card is
inserted. When you eject a card, the computer will emit a high tone followed by a
medium tone. You can insert and remove a PC card whether the computer is turned
On or Off.
Follow these instructions to insert a PCMCIA card:
Hold the PCMCIA card with the arrow side up and the connector side toward
the socket.
1
1.
.
2
2.
.
Align the card connectors with the socket and carefully slide into the socket
until it locks into place. The system will beep once to indicate that it has
detected the PC card.
To remove a PC card push the eject button, the button will pop out, push the button
again to eject the PCMCIA.
When inserting a Type II PC card, make sure the connector is inserted
in the socket. Before ejecting a PC card, ensure that it is not being
accessed by the System.
For example, if the message “Write protect error writing Drive x” is
displayed, the user has to change the write protect switch setting on
the memory card. To change the switch setting, (a) eject the card, (b)
change the switch setting, and (c) re-insert the card.
Always disconnect all telephone lines from the wall outlet before
servicing or disassembling this equipment. To reduce the risk of fire,
use only No. 26 AWG or larger telecommunication line cord.
45
![](/img.php?id=484547&img=bg31.png)
Power Saving Modes
This section contains information on the Notebook’s power system, including the AC
Adapter, the battery system, recharging the battery, and tips for conserving battery
power.
The power system is comprised of two parts, the AC Adapter and the battery system.
The AC Adapter converts AC power from a wall outlet to the DC power required by
the computer.
The Battery Power System
A fully charged pack will provide approximately 2 hours of battery life depending on
your system configuration application it runs.
Before using the computer on battery power for the first time, check the battery status
icon on the Windows Toolbar to make sure the battery is fully charged.
See Battery Status later in this section for a description and explanation of the
Windows Battery icon. Charging the battery takes about 3 hours to charge when the
system is in off state. If possible, always charge the battery completely.
Removing the Battery Pack
To remove the battery pack from its compartment, please refer to Chapter 3,
Inserting and Removing the Battery Pack.
Preparing the Battery Pack for Use
Before using the battery pack for the first time, the Smart Battery IC within the
battery pack should be calibrated in order to get accurate reporting of remaining
battery life status.
46
![](/img.php?id=484547&img=bg32.png)
To calibrate the battery pack follows the instructions below:
Insert the battery into the battery compartment and turn on the Notebook. If the
battery is completely without power go to the next step.
Otherwise, let the battery run down until the battery low-low warning beeps are
heard.
The system will automatically enter Suspend mode.
1
1.
.
2
2.
.
3
3.
.
4
4.
.
Turn the Notebook off. Connect the AC adapter and let the battery fully
recharge. When the battery charge indicator turns off, the battery is fully
charged.
Turn On the notebook, let the battery run down until the battery is in low-low
state and you hear a warning beeps. The system will automatically enter the
Suspend mode. You can now connect the AC adapter.
The battery pack is now calibrated properly.
In general, using the battery until the low-low battery-warning indicator appears and
fully recharges the battery each time (full discharge/charge cycle) will ensure the
accurate reporting of the battery gauge status.
Automatic Battery Pack Charging Function
You can automatically charge the battery pack by using the AC Adapter. The charge
time is about three hours when the Notebook power is turned off. The following
table summarizes the charging modes:
Charge Mode Charge Time
Fast 3 hours with the system off or in Suspend mode. The temperature
must be 25°C or below room temperature.
Pre-Charge A pre-charge is supplied to the Li-Ion battery pack.
47
![](/img.php?id=484547&img=bg33.png)
Battery Status
Windows XP has an applet in the Control Panel that will display an icon in the
Windows taskbar indicating when the Notebook is running on battery power or is
attached to the AC adapter.
This applet also displays a meter that indicates how much charge is remaining in the
battery.
Battery Low Warning
When the pack initially reaches the “Battery Low” state approximately 10 ~ 15
minutes of the usable battery life is left.
You will hear an audible beep signal every 1.5 seconds alerting you to the “Battery
Low” status. When the battery power reaches the “Battery Low Low” status the
beeping sound will accelerate.
Your battery now has 1 ~ 2 minutes of battery charge remaining. You must save your
data or connect AC power immediately; otherwise, you may lose your data.
Sound Meaning
Continuous
beeping every 1.5
seconds
Battery Low: Indicates that there is 7 to 10 minutes charge
remaining.
Beeping
accelerates
Battery Low Low: Indicates that there is 1 to 2 minutes of
battery charge remaining. Save your work and turn off the
Notebook, or connect the AC adapter.
When there is only one minute of battery charge remaining, the Notebook will
suspend to the HDD and power off. You should connect AC power and resume to
save your work.
48
![](/img.php?id=484547&img=bg34.png)
Small Battery for the Real Time Clock
There is a small built-in battery pack that supplies power to the system in order to
maintain certain system information while the power is off.
If the Notebook is left without a power source for long period of time, this battery
will be exhausted and system information will be lost.
Danger of explosion if battery is incorrectly replaced. Replace only with the same
or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer's instructions. Never remove the battery pack while
the power is on as this may result in data loss when the system loses power.
Resetting the System
After installing a software application package, you may be prompted to reset the
system to load the changed operating environment. To reset the system, or “reboot,”
press the [Ctrl] + [Alt] + [Delete] keys simultaneously. This is known as “warm
boot.” This key combination acts as “software” reset switch when you encounter
hardware or software problems, which lock up the Notebook.
If this key combination does not shut down the Notebook, you can reset the Notebook
by using the Notebook’s power button. Should the Notebook lock up for some reason,
pressing this button powers the Notebook off.
Adjusting the Brightness
To adjust the brightness on the LCD screen, press and hold down the [Fn] key in the
lower left hand corner of the keyboard and press the [F7] key to reduce the brightness
or [F8] to increase the brightness.
49
![](/img.php?id=484547&img=bg35.png)
Page intentionally left blank
50
![](/img.php?id=484547&img=bg36.png)
D
De
es
sk
kt
to
op
p
O
Op
pe
er
ra
at
ti
io
on
n
Your notebook is capable of providing you with efficient and productive mobile
computing, it also has the speed and capacity to service as a desktop system.
This chapter discusses those functions of your notebook that are typical of desktop
systems.
![](/img.php?id=484547&img=bg37.png)
Audio
The Multimedia Sound System
The Notebook’s built-in audio capabilities allow you to take advantage of a wide
range of education and entertainment multimedia software. The Notebook is
equipped with internal stereo speakers, a microphone, and input audio ports for
external audio units.
An external microphone can be connected to the microphone jack. External speakers
or headphones can be connected to the Notebook’s audio-out jack.
External audio devices can be connected to the Line in jack. All audio features are
software controlled. The Notebook’s multimedia sound system includes the
following features:
Supports Windows Sound System compatibility •
•
•
•
•
•
•
Full Duplex operation
Dynamic filtering reduces noise and distortion rate
16-bit digitized audio playback
A built-in microphone for convenient recording
Built-in stereo speakers
Digitized audio recording through the Notebook’s built-in microphone or any
external source
Audio Volume Control
The Notebook is equipped with hot-key volume controls: Pressing the [Fn] + [F3]
hot-key combination decreases the audio output volume, press the [Fn] + [F4] hot-
key combination increases the audio output volume.
52
![](/img.php?id=484547&img=bg38.png)
Audio Software
Your notebook comes equipped with an integrated sound system capable of providing
you with quality audio sound through the built-in speakers or through external
speakers connected via the system ports.
Sound Recording
Your system allows you to record sounds and store them as files using the
microphone via the microphone jack on the rear of the notebook computer.
Check the Windows Help and Support Center in Windows for information on using
the various elements in sound recording.
For a high-quality sound, click on the "Volume Control" at the lower
right end of your screen. From the Volume Control windows, click on
the "Advanced" tab, click and select the "Microphone Boost" item.
Playing Sound Files
Your notebook can play audio files stored in MIDI, WAVE or MP3 file format.
Check the Help and Support Center in Windows for information on the functions of
the Media Player.
External Speakers and Microphone
The sound system is capable in providing high-quality sound to external speakers and
receiving and processing sounds from an external microphone or external sound
source.
Connecting Peripheral Devices
To expand your computing capabilities, you can add a variety of external devices to
your computer. You may, for example, want to add a mouse, modem, or a printer.
53
![](/img.php?id=484547&img=bg39.png)
The computer is equipped with several interface ports, including an enhanced parallel
(printer) port, a serial port, and USB ports. These are provided as a means of
connecting peripheral devices to the computer.
Connect peripheral devices to the computer's interface ports as shown below:
54
![](/img.php?id=484547&img=bg3a.png)
55
![](/img.php?id=484547&img=bg3b.png)
Page intentionally left blank
56
![](/img.php?id=484547&img=bg3c.png)
R
Ru
un
nn
ni
in
ng
g
B
BI
IO
OS
S
S
Se
et
tu
up
p
Introduction
The BIOS (Basic Input and Output System) Setup program is a menu driven utility
that enables you to make changes to the system configuration and tailor your system
to reflect installed hardware or alter system performance. When the Notebook is
turned back on, the system is configured with the values stored in CMOS. With easy-
to-use menus, you can configure such items as:
Hard drives and peripherals •
![](/img.php?id=484547&img=bg3d.png)
Bootup Drive Sequence •
• Password protection
The settings made in the BIOS Setup program intimately affect how the Notebook
performs.
Navigating through BIOS Setup
The Setup program has been designed to make it as easy to use as possible. If you
accidentally make a setting and don’t know which one to switch back to, the Setup
program has a hot key that allows you to return to the previous value.
Accessing the BIOS Setup Program
To access the BIOS Setup program, press the DEL key after the Notebook has run
through its POST.
Item Specific Help
On the right side of the Setup screen is an area labeled Item Specific Help. This area
will list navigation key shortcuts and information that is specific for the item that you
are currently editing.
The Menu Bar
The top of the screen has a menu bar with the following selections:
Main - Use this menu to make changes to the basic system configuration.
Advanced - Use this menu to enable and make changes to the advanced features
available on your system, such as enabling the FIR module.
58
![](/img.php?id=484547&img=bg3e.png)
Security - Use this menu to set a password. The password allows bootup and
controls access to the BIOS setup menu.
Boot - Use this menu to configure the default system device used to locate and load
the Operating System and for booting up the Notebook.
Exit - Use this menu to exit the current menu or specify how to exit the Setup
program.
To access the menu bar items, press the right or left arrow key on the keyboard until
the desired item is highlighted.
The Legend Bar
At the bottom of the Setup screen you will notice a legend bar. The keys in the
legend bar allow you to navigate through the various setup menus.
The following table lists the keys found in the legend bar with their corresponding
alternates and functions.
Legend Key Alternate
Key
Function
F1 Displays the General Help window. It can be
enabled from anywhere in the BIOS.
Esc Jumps to the Exit menu or returns to the Main
menu from a submenu.
← Selects the menu item to the left.
→ Selects the menu item to the right.
↑ or ↓ Keypad
arrow keys
Moves the cursor up and down between fields.
Tab Enter Moves the cursor to the next position available in
the field.
59
![](/img.php?id=484547&img=bg3f.png)
Minus key (-) Scrolls backward through the values for the
highlighted field.
Plus key (+) Scrolls forward through the values for the
highlighted field.
Home PgUp Moves the cursor to the field at the top of the
window.
End PgDn Moves the cursor to the field at the bottom of the
window.
F9 Sets the parameters for the current menu to their
default values.
F10 Save and Exit.
Enter Will select a sub menu or show a range of options
for a field.
Launching Submenus
Note that a right pointer symbol X appears to the left of certain fields. This pointer
indicates that a submenu can be launched from this field. A submenu contains
additional options for a field parameter.
To call up a submenu, simply move the cursor to highlight the field and press the
[Enter] key. Use the [Esc] key to return to the Main menu.
General Help
In addition to the Item Specific Help window, the BIOS Setup program also provides
a General Help screen can be called up from any menu by simply pressing [F1].
60
![](/img.php?id=484547&img=bg40.png)
Use the [PgUp] and [PgDn] keys or the up and down arrow keys (↑↓) to scroll
through the entire help document. Press the Home key to display the first page, press
End to go to the last page. To exit the help window, press the [Enter] or the [Esc]
key.
Save Changes and Exit the Setup Program
Refer to the Exit menu section of this chapter for detailed information on saving
changes and exiting the setup program.
The Main Menu
When the Setup program is accessed, the following screen appears:
61
![](/img.php?id=484547&img=bg41.png)
The Advanced Menu
Selecting Advanced from the menu bar displays the Advanced menu:
62
![](/img.php?id=484547&img=bg42.png)
The Security Menu
The Notebook’s advanced system of security allows you to set a password to prevent
unauthorized access to system resources, data, and the BIOS Setup Program.
63
![](/img.php?id=484547&img=bg43.png)
The Boot Menu
The Boot menu allows the user to specify the order in which the Notebook is to check
for a device to boot the system. You can also configure the way that the system will
boot up.
To make changes, select Boot from the menu bar. The following screen appears:
64
![](/img.php?id=484547&img=bg44.png)
The Exit Menu
Once you have made all of your selections from the various menus in the Setup
program, you should save your changes and exit Setup. Select Exit from the menu
bar to display the following menu:
65
![](/img.php?id=484547&img=bg45.png)
Page intentionally left blank
66
![](/img.php?id=484547&img=bg46.png)
T
Th
he
e
S
So
of
ft
tw
wa
ar
re
e
U
Ut
ti
il
li
it
ti
ie
es
s
D
Di
is
sk
ks
s
AutoRun Installation
Follow the step-by-step procedures on the CD-ROM/DVD-ROM to execute the
“AutoRun” application by selecting the topic of “Driver Installation”.
If you encounter this message when executing the Auto Run in
![](/img.php?id=484547&img=bg47.png)
Windows 2000, please perform the following procedures:
Click on the “Start” – “Setting” – “Control Panel” – “System” –
“Advanced” tab – “Performance” tab – “Change” tab – reduce the
maximum Virtual Memory setting to 200MB.
Installing the INTEL_INFINST Driver
Insert the CD-ROM Driver into your CD-ROM/DVD-ROM drive. •
•
•
•
•
•
•
•
•
•
•
•
Click “Start” and Select “Run”.
Type the following: D:\Driver\INTEL_INFINST\INFINST_enu (If D is not your
CD-ROM/DVD-ROM drive, substitute D with the correct drive letter).
Click on “INFINST_enu” to begin the Installation Wizard.
Follow the Wizard’s on-screen instructions to complete the installation.
Restart the system.
Installing VGA Display Drivers
This section describes the operation and installation of VGA display software drivers
supplied on the Driver Utility CD-ROM that is shipped with your computer.
Insert the CD-ROM Driver into your CD-ROM/DVD-ROM drive.
Click “Start” and Select “Run”.
Type the following: D:\Driver\VGA\Win2K&XP\Setup.exe (If D is not your CD-
ROM/DVD-ROM drive, substitute D with the correct drive letter).
Click on “Setup” to begin the Installation Wizard.
Follow the Wizard’s on-screen instructions to complete the installation.
Restart the system.
Intalling the Audio Driver
To install the audio driver you must first remove the currently installed driver.
68
![](/img.php?id=484547&img=bg48.png)
Insert the CD-ROM Driver into your CD-ROM/DVD-ROM drive. •
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Click “Start” and Select “Run”.
Type the following: D:\Driver\Audio\Setup.exe (If D is not your CD-ROM/DVD-
ROM drive, substitute D with the correct drive letter).
Click on “Setup” to begin the Installation Wizard.
Follow the Wizard’s on-screen instructions to complete the installation.
Restart the system.
Intalling the IR Driver
To install the audio driver you must first remove the currently installed driver.
Insert the CD-ROM Driver into your CD-ROM/DVD-ROM drive.
Click “Start” and Select “Run”.
Type the following: D:\Driver\IR\Setup.exe (If D is not your CD-ROM/DVD-
ROM drive, substitute D with the correct drive letter).
Click on “Setup” to begin the Installation Wizard.
Follow the Wizard’s on-screen instructions to complete the installation.
Restart the system.
Intalling the LAN Driver
To install the LAN driver you must first remove the currently installed driver.
Insert the CD-ROM Driver into your CD-ROM/DVD-ROM drive.
Click “Start” and Select “Run”.
Type the following: D:\Driver\LAN\Setup.exe (If D is not your CD-ROM/DVD-
ROM drive, substitute D with the correct drive letter).
Click on “Setup” to begin the Installation Wizard.
Follow the Wizard’s on-screen instructions to complete the installation.
Restart the system.
69
![](/img.php?id=484547&img=bg49.png)
Installing the TouchPad Driver
To install the touchpad driver you must first remove the currently installed driver.
Insert the CD-ROM Driver into your CD-ROM/DVD-ROM drive. •
•
•
•
•
•
•
•
•
•
•
•
Click “Start” and Select “Run”.
Type the following:
D:\Driver\Touchpad\Win2K&XP\Setup.exe (If D is not your CD-ROM/DVD-
ROM drive, substitute D with the correct drive letter).
Click on “Setup” to begin the Installation Wizard.
Follow the Wizard’s on-screen instructions to complete the installation.
Restart the system.
Installing the MDC Modem Driver
Please follow these instructions to install the Modem driver:
Insert the CD-ROM Driver into your CD-ROM/DVD-ROM drive.
Click “Start” and Select “Run”.
Type the following:
D:\Driver\MDC\Liteon\Win2K&XP\MDMCHIPV.inf or
D:\Driver\MDC\Billionton\WinXP\Setup.exe or
D:\Driver\MDC\Billionton\Win2K\Setup.exe or
D:\Driver\MDC\QCOM\Win2K&XP\Setup.exe (If D is not your CD-ROM/DVD-
ROM drive, substitute D with the correct drive letter).
Click on “Setup” to begin the Installation Wizard.
Follow the Wizard’s on-screen instructions to complete the installation.
Restart the system.
Installing the MiniPCI Wireless LAN Card Driver
Please follow these instructions to install the Wireless LAN driver:
70
![](/img.php?id=484547&img=bg4a.png)
From Start, click on the "My Computer" icon and click the "View System
Information".
•
•
•
•
•
•
Click on the "Hardware" tab from the "System Properties" dialog window.
Click the "Device Manager" button.
Double click on the "Other Devices" , double click the " Network Controller "
and click on the "Driver" tab.
Click the "Update Driver" tab and select the "Install from a list or specific
location (Advanced)" item and click "Next".
Select the "Include this location in the search" item and click on the "Browse"
button and specify for the designate location of your CD driver
D:\Driver\MiniPCI\Intel\21003B\PROW7100\WinXP\W70N51.inf (WinXP Intel
21003B)
D:\Driver\MiniPCI\Intel\21003B\PROW7100\Win2K\W70N5.inf (Win2K Intel
21003B)
D:\Driver\MiniPCI\Intel\2200BG\PROW2200\WinXP\W22N51.inf (WinXP Intel
2200BG)
D:\Driver\MiniPCI\Intel\2200BG\PROW2200\Win2K\W22N50.inf (Win2K Intel
2200BG)
D:\Driver\MiniPCI\Billionton\WinXP\NET8180.inf (WinXP Billionton)
D:\Driver\MiniPCI\Billionton\Win2000\NET8180.inf (Win2K Billionton)
D:\Driver\MiniPCI\QCOM\802MR\WinXP\NET8180.inf (WinXP QCOM 802MR)
D:\Driver\MiniPCI\QCOM\802MR\Win2000\NET8180.inf (Win2K QCOM
802MR)
D:\Driver\MiniPCI\QCOM\802MKG\XP\RT2500.inf (WinXP QCOM 802MKG )
D:\Driver\MiniPCI\QCOM\802MKG\2K\RT2500.inf (Win2K QCOM 802MKG)
D:\Driver\MiniPCI\MSI\802.11G\XP\RT2500.inf (MSI 802.11g for WinXP)
D:\Driver\MiniPCI\MSI\802.11G\2K\RT2500.inf (MSI 802.11g for Win2K)
71
![](/img.php?id=484547&img=bg4b.png)
VGA Utilities
After you have restarted Windows, open the “Control Panel” and double click on the
“Display” icon. From the “Display Properties” window, select the “Settings” tab and
click on the “Advanced” tab to enter the “INTEL® 82852/82855 GM/GME Graphics
Controller Properties" window.
Devices
You can connect up to three displays simultaneously to the notebook. You can watch
a DVD movie on an external television while checking email on your notebook
screen - or surf the web on a CRT monitor while working on a presentation on a
digital flat panel. The option is yours with these features.
72
![](/img.php?id=484547&img=bg4c.png)
73
![](/img.php?id=484547&img=bg4d.png)
74
![](/img.php?id=484547&img=bg4e.png)
75
![](/img.php?id=484547&img=bg4f.png)
76
![](/img.php?id=484547&img=bg50.png)
Color
You can adjust the right resolution for your screen display.
77
